EDUCATION INFRASTRUCTURE

Low carbon funding helps Ruthin School

to decarbonise

Funding from the Welsh

Government has helped a

Ruthin secondary school

decarbonise their heating by

replacing gas boilers with renewable

air source heat pumps.

Ysgol Brynhyfryd is a bilingual

co-educational comprehensive

school for over 1,000 pupils aged

between 11 and 18 years of age in

the beautiful valley of Clywd, in

North Wales.

The school is maintained by the

Denbighshire Education Authority

and in 2019 Council Members

decided to declare a climate and

ecological emergency and to work to

net zero by 2030.

“As part of this we are looking at

all our buildings and in particular

schools as this is an area where we

know we can make a direct impact

on carbon emissions,” explained Cllr

Barry Mellor, Denbighshire County

Council.

Councillor Barry Mellor was full of praise for the

school for allowing the work to be done adding:

“This will lead to savings in both running costs and

carbon emissions for both of us.”

The solution was the installation

of 70kW of solar photovoltaic panels

on the school roof, along with

replacing three gas boilers with two

commercial air source heat pumps.

“Between the schemes, the air

source heat pumps and the solar

panels system that we installed here,

it is estimated that the school will

save an average of £17 to £19

thousand per annum, along with 28

tonnes of carbon,” commented Ben

Musgrave, Director of JM Renewable

Solutions, who installed the systems.

JM Renewables replaced the

existing gas boilers in the school

with two 40kw CAHV air source heat

pumps from Mitsubishi Electric. The

school building has underfloor floor

heating throughout. Coupled with

this JM Renewables installed a

further 75kW of solar panels on the

building’s roof, to help with the

running costs.

Although the CAHV units are

4 AUGUST 2024, REFURBISHMENT PROJECTS

very quiet at 64 dBA, JM Renewables

built an acoustic enclosure as the

heat pumps are outside classroom

windows. The project was completed

over the Easter half term and the

plant room was also refitted with a

new 800 litre buffer tank and

associated pumps. The entire system

was fully operational on the day the

children came back after the break.

The CAHV heat pumps achieve

70°C water temperatures down to -

20°C ambient temperature to deliver

continuous heating. Multiple unit

cascade control offers capacity from

7.8kW to 640kW to make the system

suitable for a wide range of

applications.

The heat pumps meet the design

temperature of the school, so it was

almost a direct swop from the

boilers,” explained Elliot Sullivan,

Head of Mechanical Division at JM

Renewables. “The efficiency of the

heat pumps installed should be

around 300 to 400 per cent, so for

every one kilowatt of electricity

consumed, it will deliver 3 to 4

kilowatts of heat to the building”.

The entire project to upgrade the

heating and install the additional

solar panels took almost four

months and the JM Renewables

installers were full of praise for the

way the school caretakers helped

them get the job done.

It’s been a lot of hard work to

get the air source heat pumps, the

solar panels and some additional LED

lighting, commented Tefor Jones,

Head Teacher at Ysgol Brynhyfryd.

“However, it’s been worth it as

it’s all part of a long line of

initiatives and plans that have

happened in the school to make the

school more efficient as we move

forward,

Denbighshire County Council has

now completed upgrades in around

30 schools out of around 70 schools

in the County. For Ysgol Brynhyfryd

the Council was able to secure

Welsh Government Low Carbon Heat

Grant funding for 90% of the

project with the County Council

finding the other 10%.

The Low Carbon Heat Capital

Grant funding is intended for capital


works associated with retrofitting

low carbon heat solutions in nondomestic,

local authority-owned

buildings.

Councillor Barry Mellor was full

of praise for the school for allowing

the work to be done adding: “This

will lead to savings in both running

costs and carbon emissions for both

of us.”

Installation Summary:

2 x 40kw CAHV-P air source heat

pumps

https://youtu.be/gX8RCog9lyk?feat

ure=shared

les.mitsubishielectric.co.uk



IG Masonry Support solution is ahead of the curve

Pershore Junction is new

state-of-the-art student

accommodation in

Birmingham that has been

built for the growing number of

students at Aston University,

University College Birmingham and

Birmingham City University. The

regeneration of a former BT

brownfield site, this 167-bed

accommodation in Stirchley consists

of 101 studios, a student hub, leisure

facilities, a retail unit and an

enhanced public space. Targeting a

BREEAM ‘Excellent’ rating, this

contemporary building comprises

brickwork and terracotta tile

detailing and features a stunning

curved bull-nose brick façade due to

the site being bounded by Pershore

Road and Dogpool Lane.

Following a tour of IG Masonry

Support’s manufacturing operations

in Swadlincote and Brick Cutting

facility in Overseal, brickwork

contractor Meath Build Ltd chose IG

Masonry Support to design and

manufacture the masonry support

and brick soffit package for the

development.

THE CHALLENGE

The project’s unusual, curved façade

was one of the defining challenges

on this build as it would be

extremely difficult and timeconsuming

to complete with

traditional hand-laid brickwork. This

design feature required IG Masonry

Support’s unrivalled experience and

ability to deliver complex brickwork

with precision and efficiency. In

addition, the use of a steel frame

rather than a concrete slab

introduced further complexities. This

would mean that components had

to be pre-set, with masonry support

specially designed to fit around the

steel frame structure. Furthermore,

the masonry support had to be

spanned to accommodate breaks in

the wing plates around the piers.

THE SOLUTION

Following a site survey, IG Masonry

Support produced a variety of

solutions to overcome the design

challenges presented during the

development of this student

accommodation. This required

coordination and regular design

meetings with all parties to avoid

any clashes with other building

elements and ensure the build

remained on schedule.

A1 fire-rated Brick Slip Lintels

were required for the smaller

openings on both the ground and

first levels of the build (under 3.6m)

while bespoke Curved Lintels were

required to support the tiled finish

on the curved façade. A1 fire-rated

and carbon neutral B.O.S.S. A1

systems in soldier course bond were

required for larger openings on

levels one to four of the building.

Many of these were fabricated as

smaller units to account for the

curved façade design.

On the curved run of B.O.S.S. A1,

there were several high load areas

with windows above and in-between

the brick piers. IG Masonry Support

therefore had to adapt its units to

suit these loads and the tiled finish

on the curved façade. Rather than

the usual serrated lock washers, the

bespoke lintels were designed and

manufactured by IG Masonry

Support with rear restraint which

involved fabricating holes on the

back of the lintels to provide more

surface area and thus more space

for additional mortar. This would

ensure extra support for the extreme

loads and double skin brickwork.

These lintels also matched the curve

of the façade.

Through close collaboration with

brickwork contractor Meath Build

Ltd and the design team, IG Masonry

Support provided technical and

design assistance, and a range of

bespoke brickwork solutions for the

Pershore Junction’s unique curved

façade detail. The company’s onsite

expertise and offsite manufacturing

capability proved integral to

realising this stand-out architectural

feature and its aesthetically pleasing

finish.

John Flynn, Managing Director of

Meath Build Ltd, said: “While the

project threw up some challenges

along the way with design, IG

Masonry Support solved any

problems and the project was

handed over on time and on budget.

Meath Build Ltd look forward to

working with IG Masonry Support

on the next project.”

Giedre Jonuskaite, Senior

Architectural Designer at Glen

Howells Architects, added: “IG

Masonry Support dealt really well

with some of the design challenges

on Pershore Junction project. The

variety of products IG provided

helped to maintain the design and

deliver to the highest standard.”

https://igmasonrysupport.com/


McCoy Contractors awarded

Oaks Student Village Phase 4 & 5


Leading provider of

groundworks McCoy

Contractors has been

appointed to deliver the

groundworks and hard landscaping

for Phase 4 and 5 of The Oaks

Student Village in Coventry. This

prestigious project will provide an

additional 1,210 rooms in purposebuilt

accommodation for students

attending the nearby University of

Warwick.

The Oaks Student Village,

designed by architects Corstorphine

& Wright, comprises nine buildings

ranging from five to six stories.

Phase 1 delivered 378 beds in 2021,

with Phase 2 and 3 adding 639 more

rooms. Phase 4 and 5 will deliver a

further 1,209 rooms. Having

successfully completed the

groundworks for Phases 1-3 to the

client's satisfaction, McCoy was

awarded the latest £8 million

groundworks package by main

contractor McLaren Construction.

McCoy is delivering a range of

groundworks including earthworks,

foundations, reinforced retaining

Marshland Primary

Academy to benefit

from low-cost, highly

efficient renewable

heating with Kensa’s Ground Source

Heat Pump installation

Marshland Primary Academy, in

Moorends, Doncaster, is preparing

for the future by switching its

heating and hot water system from

gas boilers to highly efficient, lowcarbon

Ground Source Heat Pumps.

Kensa Contracting, the UK’s

leading ground source heat pump

solutions provider, is delivering the

retrofit project, and on Tuesday 18th

June 2024, representatives were on

hand to show the school’s pupils

how freely available, renewable heat

energy from the ground will be used

to keep classrooms warm for the

next 100 years.

Switching from gas to

electrically powered ground source

heat pumps will decarbonise the

school's heating and hot water

system, reducing the CO2 emissions

it produces from heat by as much as

77%.

The decarbonisation project,

which started in May and is

expected to be completed in

October, has been part-funded by

walls, external drainage, attenuation

tanks, service trenching, and hard

landscaping across the extensive site.

Despite challenging weather and

groundwater conditions, McCoy is

working ahead of schedule,

underscoring their commitment to

delivering complex projects

efficiently.

“McCoys has made a fantastic

start to our project at 120

Longwood Close.

On a project with some

challenging details the team have

performed to a very high standard

through a difficult and wet winter,”

said Alex Derbyshire, Construction

Manager, McLaren Construction.

“McCoys has been very agile

through change and have enhanced

our project team with their vast

knowledge and expertise in

groundworks. The helpful and

approachable nature of the team at

McCoys has gone a long way to the

current successes at Longwood Close

moving into the summer months,”

added Alex Derbyshire.

Renewable heating renovation at

South Yorkshire Primary School

the Government’s Condition

Improvement Fund and will see 18

boreholes drilled deep beneath the

school’s playing field to access the

renewable energy source.

Once installed, six new ground

source heat pumps will convert this

energy into usable heat for the

school’s upgraded heating and hot

water system. The heat pumps will

also be housed indoors, shielded

from the elements, with some

located where the school’s current

gas boilers are.

Along with the heat pumps and

ground source infrastructure

installation, the school’s green

heating renovations also include

new radiators and solar PVT being

fitted. These measures will help the

primary academy achieve the

highest possible energy efficiencies

while also providing greater energy

security.

This latest project follows a

string of successful school ground

source heat pump installations

undertaken by Kensa, which is the

Department for Education’s

preferred heat pump method for

decarbonising heat in schools.*

School ground source heat pump

projects completed by Kensa include

installations at Richmond Hill

Primary School, also in Doncaster,

Stamfordham Primary School in

Newcastle-Upon-Tyne and a one-ofa-kind

installation for Ffynnon Taf

Primary School in Taffs Well, Wales.

Commenting, Penny Marshall,

Deputy Headteacher at Marshland

Primary Academy, said: "We are very

"We are extremely proud to

continue our involvement in this

landmark student accommodation

development," said Chris Haughey,

Managing Director of McCoy

Contractors. "Being re-appointed by

McLaren Construction for Phases 4

& 5 is a testament to our team's

dedication and expertise in

delivering high-quality groundworks

on large-scale projects. The Oaks

Student Village is setting new

standards for purpose-built student

living in the Midlands, and we're

excited to play a key role in bringing

this exceptional development to

fruition."

McCoy's strong health and safety

practices have also been recognised

on-site, recently ranking 3rd out of

45 subcontractors – further

highlighting the company's

professionalism and commitment to

creating safe working environments.

The final phase of McCoy's works

at The Oaks Student Village is

scheduled for completion in 2025.

https://www.mccoycontractors.co.uk/

excited by the new innovative

heating system. It is wonderful for

Marshland to be at the forefront of

new technology. At the same time,

hopefully, it will save us money on

our heating bills and, most

importantly, support our quest to

help combat climate change.”

Discussing the project, Anna

Cain, Kensa Contracting Operation

Director, said: “We’re thrilled to be

working with Marshland Primary

Academy. When complete, their new

ground source heat pump heating

system will provide the school, its

teachers, and pupils with 100+ years

of highly efficient, clean heating

and hot water – all thanks to the

renewable heat stored in the ground.

“Thousands of Schools right

across the UK will likely need to

change their heating in the coming

years, with the Government aiming

to reduce public sector emissions by

75%. Our ground source heat pump

solution cuts those emissions and

provides heating and hot water for

the long term, giving any school

that invests in the technology the

reassurance they’ve secured their

heating source for many years to

come.”

https://www.kensacontracting.com/



Bradford College receives £2.6m grant

to help tackle climate change

Bradford College has been

awarded a £2.6 million grant

for energy-efficiency works

that will contribute to

ambitious national net-zero targets.

Delivered by Salix and run by the

Department for Energy Security and

Net Zero, the Phase 3c Public Sector

Decarbonisation Scheme (PSDS) aims

to slash energy bills and reduce

carbon emissions.

The Scheme targets public sector

buildings that still use fossil fuels for

heating, hot water, and catering. In

total, more than £530 million of

funding is being handed to schools,

hospitals, fire stations, universities

and other public buildings across the

country to help tackle climate

change.

With a Bradford College

contribution taking the funding

total to over £3 million, the project

will connect the David Hockney

building and Advanced Technology

Centre to the Bradford Energy

Network by March 2026. Networks

such as this produce heat on a large

scale from the same source to

buildings that are separated by

miles.

Bradford has one of the UK's

largest Air Source Heat Pump

installations. Buildings on the

Bradford district heating network

will benefit from an 85-90%

reduction in emissions, contributing

to a city-wide reduction in emissions

of approximately 8,000 tonnes of

carbon dioxide equivalent in the

first phase of the network.

Bradford College is one of 189

public sector organisations

nationwide that were awarded

grants for heat decarbonisation and

energy efficiency schemes. Work will

also cover improvements to hot

water distribution systems, pipework

insulation, and emitter and

substation upgrades.

Pamela Sheldon, Head of Projects

at Bradford College, said:

“Bradford College is committed

to reducing its carbon footprint. This

latest funding will be a huge boost

to our decarbonisation strategy.

Over the last two years, Bradford

College has secured nearly £32

million in funding incorporating the

PSDS grant. This substantial

investment is helping us to rethink,

reshape, rework, and rebuild

aspirational new sustainable

facilities in the heart of Bradford.”

The Public Sector

Decarbonisation Scheme was

launched in 2020 and Phase 3 of

Scheme was announced in 2021 to

reduce fossil fuel usage and make

public buildings more comfortable

and efficient to heat. Phase 3c is the

latest funding released by the

Department for Energy Security to

achieve net zero targets.

Director of Programmes at Salix

Ian Rodger said:

“Climate crisis is one of the

greatest challenges of our time and

we are pleased to be working with

Bradford College on reducing its

carbon footprint.

“Our teams will work closely with

the college as they progress their

decarbonisation journey, ensuring

these buildings not only become

more energy efficient but better

places in which to work and study.”

Alongside this grant, other

upcoming Bradford College capital

work includes improvement of the

fabric of buildings for optimum

thermal performance, the

incorporation of high levels of

natural daylight to reduce artificial

light sources in new buildings,

energy-efficient LED lighting and

optimising lighting control, as well

as adding social value by targeting

local SME labour and supply chains.

The PSDS grant comes as

Bradford College was announced

winner of the national Planet Earth

Games - the biggest sustainability

competition for the UK further

education sector. Student and staff

were encouraged to participate in

various planet-friendly challenges to

earn points for the College from tree

planting and litter picking to green

commuting. With over 3,000 good

deeds for the planet undertaken

since January, Bradford College

topped the national leader board of

FE colleges.

Find out more about the latest

Bradford College Capital Projects

news:

www.bradfordcollege.ac.uk/capitalp

rojects


AIR CONDITIONING

We supply the most cost-effective remanufactured

compressors throughout the transport industry

By Trevor Dann, Thermagroup

Many trains and train

carriages use module

type chillers; these

incorporate air handling

units and are run in hostile

environments. With our experience

in chiller design and environmental

awareness, we are able to maintain

and improve these chillers to their

original design specification and

beyond.

REMOTE MONITORING

Our compressors have built in test

areas to provide us with high quality

diagnostic abilities and allow direct

feedback to resolve any issues. This

data allows us to decide whether to

maintain the whole chiller, improve

the reliability and control or design

and build a new improved chiller.

AIR CONDITIONING SOLUTIONS

FOR THE TRANSPORT INDUSTRY

ThermaGroup is a renowned

manufacturer and provider of air

conditioning and refrigeration units,

specialising in chillers and

compressors. With our expertise, we

supply, repair, and service all the

leading makes of compressors,

chillers, air-conditioning, and

refrigeration units found throughout

the HVAC industry. When it comes

to transport air conditioning, we

understand the unique needs of

various industries that rely on

efficient cooling systems. Let’s

explore the type of work we do, who

we do it for, and why our services

are invaluable:

1. RAILWAY CHILLERS:

Efficient and reliable cooling is

essential for railway systems,

ensuring passenger comfort and

maintaining optimal operating

conditions. ThermaGroup specializes

in designing and manufacturing

railway chillers that meet the unique

requirements of train air

conditioning systems. Our railway

chillers are engineered to deliver

consistent cooling performance,

withstand the vibrations and

demands of railway environments,

and provide a comfortable journey

for passengers.

2. FOOD TRANSPORTATION

CHILLERS:

The transportation of perishable

goods, especially food, requires

precise temperature control to

preserve freshness and ensure food

safety. ThermaGroup understands

the critical role of reliable

refrigeration units in food

transportation. Our specialized

chillers for food transportation are

designed to maintain consistent and

appropriate temperatures

throughout the journey, protecting

perishable goods from spoilage. With

our food transportation chillers, you

can have peace of mind knowing

that your products will arrive in

optimal condition.

3. EXTEND LONGEVITY:

Transportation vehicles, whether

they are commercial trucks, buses, or

trains, require reliable and durable

air conditioning systems to ensure

passenger comfort and safety.

ThermaGroup specialises in

designing and manufacturing air

conditioning units that are built to

withstand the rigorous demands of

the transportation industry. Our

solutions are engineered to extend

the longevity of your air

conditioning systems, providing

reliable performance even in

challenging operating conditions.

4. CHILLER EFFICIENCY:

Efficient cooling is essential for

maintaining optimal conditions

inside transport vehicles.

ThermaGroup offers state-of-the-art

chillers that are designed for

maximum efficiency. Our units are

equipped with advanced

technologies that minimise energy

consumption while delivering

powerful and reliable cooling

performance. By choosing our

transport air conditioning solutions,

you can enhance energy efficiency,

reduce operating costs, and ensure

passenger comfort during

transportation.

5. WITHSTAND HARSH

CONDITIONS:

Transportation vehicles often face

harsh operating environments,

including extreme temperatures,

vibrations, and variable weather

conditions. ThermaGroup

understands the need for robust and

rugged air conditioning systems that

can withstand such conditions. Our

units are built using high-quality

components and materials that are

designed to endure the challenges of

transportation environments,

ensuring consistent performance

and reliability throughout the

journey.

WHY CHOOSE THERMAGROUP

FOR YOUR TRANSPORT AIR

CONDITIONING NEEDS?

Industry Expertise: With our deep

understanding of the transport

industry, we offer specialised

solutions that meet the unique

needs of different transportation

vehicles. Whether it’s commercial

trucks, buses, or trains, our expertise

ensures reliable and effective air

conditioning systems.

Quality and Reliability: We pride

ourselves on delivering high-quality

air conditioning units known for

their durability and reliability. Our

products are manufactured to the

highest industry standards, ensuring

long-lasting performance and

passenger comfort.

Energy Efficiency: ThermaGroup

is committed to energy-efficient

solutions. Our air conditioning units

are designed to optimize cooling

performance while minimising

energy consumption. By choosing

our solutions, you can reduce fuel

costs and contribute to a greener

and more sustainable transport

operation.

Customised Solutions: We

understand that each transport

vehicle has unique requirements.

ThermaGroup offers customised air

conditioning solutions tailored to

your specific needs, ensuring optimal

cooling performance and passenger

comfort.

Take the first step towards

reliable and efficient transport air

conditioning. Contact ThermaGroup

today to discuss your cooling

requirements, schedule a

consultation, or request a quote. Our

team of experts is ready to provide

customised solutions that withstand

harsh conditions and deliver

exceptional performance for your

transport vehicles.

https://thermagroup.com/


AWARDS

Hull’s STEAM Studios wins two major awards

The transformation of Hull’s

former central fire station into

a new creative studio for Ron

Dearing University Technical

College (UTC) has been recognised at

a prestigious awards ceremony.

The project by Sewell

Construction to refurbish the disused

fire station into a state-of-the-art

sustainable learning space was the

winner of the Regeneration and

Retrofit category at the Constructing

Excellence Yorkshire and Humber

Awards.

The project then went on to take

home the overall ‘Best of the Best’

prize as the top winner out of all

projects showcased on the night,

being commended for its

sympathetic yet sustainable

conversion of the building into a

modern education facility.

The STEAM Studios are a

dedicated centre for creativity,

opened by Ron Dearing UTC in

September 2023. The facility

contains a gallery and exhibition

space, 2D and 3D art studios, a

photography studio and a sixth form

independent study centre, as well as

being used to educate engineering

students about opportunities in

green skills.

The judges were impressed by the

long-term view the refurbishment

took towards the carbon footprint of

the studio, ensuring the fabric of the

building was upgraded so the site

will use less energy to heat in future,

helping the UTC on its journey to net

zero.

The STEAM Studios are also

futureproofed for new innovations in

green technology, with the building

made connection-ready for the new

Hull District Heating Network.

The project is also being used to

help the UTC’s students learn new

skills, with Sewell Construction and

Ron Dearing UTC now working in

partnership to embed the STEAM

Studios refurbishment into the

curriculum so students can learn

about how decarbonisation and the

environment are integral to good

construction practices.

Chris Soper, Managing Director

of Sewell Construction said:

“The STEAM Studios project was

fantastic to work on, as the team at

the UTC were really receptive to our

ideas about how to make the

building as sustainable as possible.

Instead of trying to chase quick wins,

they were happy to work with us to

look a bit differently at the

refurbishment, enabling us to support

their long term journey to net zero.

It’s vital for the sustainability of our

cities that we learn to work with

existing buildings to breathe new life

into them and make them more

efficient, instead of simply knocking

them down and building anew.

“The STEAM Studios are now a

fantastic new facility for the UTC,

not only giving students a space to

express their creativity, but also

enabling students to learn from a

real life case study about how

careers in green skills can combine

design, creativity and technical

knowledge.”

Sarah Pashley, Principal at Ron

Dearing UTC said:

“The STEAM Studios project has

enabled Ron Dearing UTC to offer an

additional 200 student places, which

is fantastic. STEAM Studios provides

a beautiful, purpose-designed

facility for students studying our

creative subjects and those studying

Renewables modules on our

Engineering qualifications. The

design and build process was a

wonderful opportunity for our

students to learn about sustainable

construction practices and we are

very grateful to Sewell Construction

for involving them in this process.

We are also extremely grateful to

Orsted for their sponsorship which

provided the additional funding we

needed to upgrade the fabric of the

building to ensure its energy

efficiency.“

The Sewell Construction team

will now go on to the UK finals of

the awards in November, where

they’ll be hoping to repeat their

success at a national level.

Sewell Construction, who have

their headquarters in Hull, deliver a

range of construction projects across

the Yorkshire and Humber region.

Part of the larger Sewell Group, the

company works on design, build,

refurbishment and retrofit schemes,

and recent projects have included

the refurbishment of the Endeavour

building for Hull Trinity House

Academy, the creation of new T-

Level facilities at Bradford College,

the construction of West Hull health

Hub and the refurbishment of The

Edge fitness centre at the University

of Leeds.

Last year, the company became

part employee-owned, with all staff

becoming co-owners in the business,

which gives them a greater say in

how the business is run.

www.sewell-construction.co.uk

www.rondearingutc.com


AWARDS

Ibstock products feature in the most

shortlisted projects for BDA Brick Awards 2024

The prestigious annual Brick

Development Association

(BDA) Brick Awards is a ‘mustgo’

event in the construction

calendar and Ibstock’s bricks feature

in more than 40 of the project

nominations for this year’s event –

the most of any brick manufacturer.

Organised by the BDA, the Brick

Awards seek to shine a spotlight on

some of the most innovative and

dynamic uses of brick in

contemporary architecture. The 2024

awards will take place at the Royal

Lancaster Hotel in London on

November 6.

Ibstock - the UK’s largest brick

manufacturer – is delighted that its

products have been used in so many

inspiring buildings spanning such a

diverse range of project types from

housing developments of varying

scales to commercial, public,

education and refurbishment

projects which have been shortlisted

for this year’s ceremony. Indeed,

Ibstock products were used in the

most shortlisted projects among the

widest number of award categories

– highlighting the diversity of

applications and developments

Ibstock bricks are suitable for.

Among the shortlisted projects

include an outdoor amphitheatre

near Tower Bridge, London;

Greenock Ocean Terminal in

Renfrewshire; the historic Elephant

Tea Rooms in Sunderland, and phase

two of a large housing development

at Royal Eden Docks in Newham.

John Lovatt, Head of Marketing

Communications & Brand at Ibstock,

commented: “We are delighted that

our bricks have been featured within

43 nominated projects across a

varied range of schemes helping to

enhance the aesthetic appeal of

these buildings. The developments

range from an individual housing

development through to largescale

urban regeneration projects, as well

as standalone public buildings

including schools, hospitals and

universities.

“As a leading manufacturer with

over 200 years or heritage and

experience, we have established a

reputation for innovation and our

wide-ranging brick products are

manufactured in a large variety of

colours, textures and shapes –

meaning they can lend aesthetic

appeal, alongside durability, to any

project. What’s more, our technical

experts can work with architects and

builders to provide the ideal

solution, ensuring the solutions they

specify match the exact

requirements of their brief.

“We are especially proud to see

our work with some of the UK’s

leading housebuilders recognised.

This year developments by Cala

Homes, Redrow, Miller Homes and

Taylor Wimpey, all of which feature

Ibstock bricks as a primary facet of

their properties, are nominated – a

truly fantastic achievement.

“We’re looking forward to the

ceremony at the end of the year and

highlighting each and every one of

the shortlisted projects in due

course.”

For more information, visit:

https://www.ibstock.co.uk/products/

bricks


AWARDS

Lilidorei Shortlisted for

Three Construction Awards

Since its opening 12 months

ago, Lilidorei at The Alnwick

Garden has attracted nearly

200,000 visitors from across

the UK and overseas. This month it

has been revealed that the

attraction has been shortlisted for a

trio of construction awards since

opening.

Having already won the Judges

Choice Award at the regional North

East RICS (Royal Institute of

Chartered Surveyors) Awards 2024,

earlier this month, Lilidorei will

progress to the prestigious national

RICS UK Grand Final Awards. The

winners will be announced at a

ceremony in London in the autumn.

The project also received a

second nomination, for Building

Project of the Year at the

Constructing Excellence Awards for

the North East in June. Additionally,

the project received a third

nomination for Best Project of the

Year at the Royal Town Planning

Institute (RTPI) Awards, with the

awards ceremony taking place in

late June.

At 26-metres high, the timber

play structure is the largest in the

world, designed and constructed by

playground specialists, Monstrum

(Denmark).

Charlie Aviston, senior quantity

surveyor at AtkinsRealis, who

supported The Alnwick Garden team

throughout the project, said: “We

joined the Lilidorei project from the

outset, committed to delivering this

unique initiative while overcoming

many challenges along the way. Our

dedication to the project ensured

that we navigated various obstacles,

ultimately achieving our goal of

bringing this ambitious project to

life.

“The success of Lilidorei hinged

on a unique team dynamic. The

specialists involved not only

exhibited technical excellence but

also respected and supported each

other’s roles, creating a culture of

mutual assistance.

“The final outcome is a fantastic

family facility that will be enjoyed

by many communities for years to

come. We are incredibly proud of

what the whole team achieved in

realising the Duchess’ vision to

create a sustainable and magical

village that inspires children from all

walks of life to play.”

The £15.5m mythical play village

was created with primary school

children in mind by the Duchess of

Northumberland to encourage them

to play outside and use their

imaginations to uncover the secrets

of Lilidorei and the nine clans who

reside there.

Mark Brassell, chief executive of

The Alnwick Garden said: “After

many years of planning, Lilidorei

started its transformative journey in

2019, amidst the challenges posed

by the pandemic, and opened its

doors to the public in 2023.

“The design of the play structure,

Elfwin Drin, was ambitious and there

was no blueprint for creating a

unique experience like Lilidorei.

Enlisting the expertise of our

partners, including AtkinsRealis,

helped us navigate the design and

build phases, enabling the creation

of this special and truly individual

attraction.

“We feel very proud to be

nominated for these awards and it is

a testament to the skill of our

designers, management and

construction teams. We are

delighted to see they have all been

recognised regionally and nationally

for their talents through these

awards.”

Since opening its doors last May,

Lilidorei has welcomed over 200,000

visitors and 3,500 primary school

children with its Free School Friday

initiative.

https://www.lilidoreialnwick.co.uk/


AWARDS

Sensitive Victorian retrofit wins West Leigh

Best Commercial Project at SWA Awards 2024

London based, West Leigh has

won the Best Commercial

Project category at the Steel

Window Association (SWA)

Awards 2024 for its sensitive and

painstaking work on the restoration

of a former Victorian wallpaper

factory in West London.

Voysey House in Chiswick had

previously been refurbished in the

1980s with the work featuring the

ever-popular W20 window, in the

large pane format. All the

architecturally important curved

heads had been panelled to save

money, severely detracting from the

period styling of the property, which

the client wanted to renovate as

offices. Thankfully, West Leigh had

both the experience of commercial

refurbishments, and the logistical

resources to rectify the

shortcomings of the one-time

industrial building and its imposing

three-storey façades.

Voysey House will now be reoccupied

by one of the most

renowned interiors brands

worldwide who originally built the

manufacturing facility extension in

1902.

Andy Bawn, Managing Director

West Leigh, commented, “We

initially offered a W20 section frame

in small panes, which is a common

product for this type of building but

the client felt this was not

sympathetic enough. We then

realised we needed a more radical

approach and instead, found a rarely

used arrow section Series 200

alternative, which is still rolled and

mimics the appearance of the

original cast iron frames. However, a

regular heritage double-glazed unit

would have been too large for the

rebate. We therefore sourced a

product that is new to the UK - the

Fineo double-glazed unit - a vacuum

technology that delivers a U-value

of 0.7 W/m2K and a front to back

dimension of just 8 mm; but more

importantly the sight line is of only

6mm. The combination of these two

materials is ideal for period

properties of this type and achieved

a genuinely great finished result.”

“We provided samples and design

information, then quickly moved to

manufacture in our London factory

and in December 2023 we were very

proud to deliver the finished product

to our client. From the factory visits

to discussions on site, the West

Leigh team were totally clear and

knowledgeable in what they were

delivering. The finished product has

helped transform the building.”

West Leigh’s attention to detail

and in-house skills were displayed in

the fact its team designed new

tooling to enable all of the end and

crucifix notching to be achieved.

This was employed in the company’s

power presses to create uniform

joint details. The largest windows

produced for Voysey House were a

trio measuring 4.5m wide by 3.7m

high which, like the rest of the

frames were hot zinc sprayed and

then given a RAL6007 Bottle Green

polyester coat finish. West Leigh’s

own operatives carried out all of the

installation work.

The SWA Awards judge,

Architecture Today’s Technical Editor,

John Renshaw, said, “Completed in

1902, Voysey House is the only

commercial building designed by the

celebrated modernist architect CFA

Voysey. This project demonstrated

what can be achieved when a

committed client and a highly

knowledgeable and experienced

window manufacturer work

together. The overall result is

stunning, with West Leigh playing a

crucial role in returning an

architecturally significant building

back to its original aesthetic, while

providing modern levels of

performance. From onsite

discussions and factory visits to the

provision of product samples and

comprehensive design information,

this SWA member has clearly gone

above and beyond to find the right

solution for this demanding and

important project. Congratulations

to all involved.”

www.steel-windowassociation.co.uk


“When we approach the design of the chiller we always

consider the following;

Clients Requirement

Energy Efficient

Concept Design + Scope

Longevity

Reliability

We also take into account the way the chiller is going to last and

mature over its running life time”

Chief Designer

Enquiry Number 12 at www.modbs.co.uk/enquiries

LIGHTING

Newport Railway bridge development brought

to life by DW Windsor lighting solutions

Anew pedestrian and cycle

bridge has been built at

Newport station in Wales,

forming a vital crossing

over the Great Western Mainline

Railway. The bridge has been

introduced to encourage active

travel and improve connectivity for

local residents and commuters.

Designed by renowned

architectural practice, Grimshaw,

with additional engineering support

from Arup, the 230m bridge is

divided into several distinct parts,

including two dark grey steel

sections that span the railway lines

plus stairs and a lightweight stepfree

ramp on each side. The whole

structure has been unified with

continuous orange flooring to create

a bold statement and a unique

identity.

Lighting was a key aspect of the

bridge's construction, with a

particular focus on safety, security,

and accessibility. The design called

for a discreet handrail solution to

illuminate the floor deck while also

supporting users with limited

mobility. Additional lighting was also

specified to enhance the

surrounding public spaces.

Leading M&E consultants, Vitec,

were appointed to oversee the

lighting and approached DW

Windsor to fulfil key elements of the

scheme's design.

To satisfy the brief, DW Windsor

supplied products from its awardwinning

Garda® illuminated handrail

range, adapted to suit the project's

unique requirements. For the ramps

and stairs, nearly 500m of seamless

stainless-steel handrail was installed,

fitted with 300mm Garda Classic

asymmetric modules. Special

attention was paid to how the

handrail attached to the balustrade

fins, which had pre-drilled holes,

meaning a lot of coordination

between all parties was needed to

ensure everything fitted together on

site without modification.

For the main bridge deck, where

handrail could not be used for safety

reasons, an alternative approach was

required. To overcome this challenge,

DW Windsor developed a bespoke

solution, integrating Garda LED

modules directly into the two

parapet structures slotted between

the vertical ribs. Additional lighting

was also supplied for the central

section between these structures

where, again, handrails could not be

used. Here, the designers came up

with an innovative solution to

vertically mount recessed Ligman

Lightalk luminaires between the

balustrade fins.

To achieve the required light

levels, 3000K LED modules were

spaced at approximately 2m across

the whole structure. This provided a

consistent appearance and ensured

the scheme delivered an average

maintained illuminance of 30 lux

and a minimum uniformity of 0.5 to

comply with British Standards.

Discussing the installation, David

Anstee, Technical Manager at DW

Windsor, said, "This was a very large

project, requiring a lot of

coordination, particularly for the

handrail, which had hundreds of

touch points. Additionally, the power

supplies needed to be in one

location, meaning a lot of planning

was needed to calculate circuit loads

and voltage drop to ensure the

lighting would operate as intended.

This included planning all of the

cable routing and ducting which had

to be built into the bridge

structure."

In addition to the bridge

lighting, the brief specified that

lighting should be integrated into

the hard landscaping beneath each

ramp, which has been styled into

amphitheatre-like areas. To support

this, DW Windsor supplied sections

of its Vaio linear system, which were

recessed horizontally into the

granite seating around the

perimeter. This offered a point of

focus for users while also providing

low-level lighting to guide people

into the space. Additional Ligman

uplighters were also installed into

the planters to illuminate the ramp

soffits and vertical supports,

enhancing the general ambience of

the space while having minimal

impact on the surrounding areas.

Shaun Davies, Project Engineer at

Vitec, commented, “The Newport

Station bridge provides residents and

visitors to the area with a safer,

more accessible link over the

mainline railway. With its distinctive

design and discreet lighting scheme,

the new bridge has helped to

transform a neglected area into a

vibrant public space.”

www.dwwindsor.com


Best practice for internal wall insulation

Internal wall insulation (IWI)

offers a potential solution for

reducing energy demand for

some solid walled homes. To

avoid unintended consequences,

however, it is essential that work is

carefully tailored for the specific

project.

INSULATION

HANDLING MOISTURE

IWI installations will impact how a

building handles the moisture which

enters constructions from

external/internal sources. If not

properly addressed, this can increase

interstitial condensation risk leading

to damp and potential structural

damage. It is therefore essential to

understand the moisture properties

of the existing building before

undertaking work.

Many solid walled properties

feature permeable wall

constructions which allow moisture

to pass slowly through. However, not

all solid walls are permeable, and

some may have been altered to

become much less so. As heat is

retained more effectively once IWI is

fitted, outer constructions remain

colder – potentially increasing

moisture risk.

IWI APPROACHES

Two approaches can be adopted to

upgrade the thermal performance of

a wall using IWI:

• ‘vapour open’ — using permeable

materials that can buffer moisture

(although this buffering capacity is

limited beyond a certain point); and

• ‘vapour closed’ — using moisture

closed materials, such as phenolic

insulated plasterboard. The outer

construction should be made

suitably resistant to the relevant

level of driving rain and a

continuous vapour control layer

(VCL) fitted on the warm side of the

insulation. This helps to limit any

interstitial condensation which may

form to a safe level.

In either case, an appropriate

condensation risk assessment is

needed in accordance with BS 5250.

In addition, steps should be taken to

ensure adequate ventilation is

provided (which may not be the case

for the building pre-improvement),

any issues or defects addressed, any

problems with rainwater goods and

external drainage/ground conditions

resolved and the system to be

installed needs appropriate detailing

to avoid issues of internal surface

condensation and mould growth.

Ultimately, the most appropriate

solution will depend on building

specific factors including location,

construction, condition, ventilation,

moisture load and level of heating.

For this reason, the pre-planning

Careful detailing at junctions and around openings is essential when fitting moisture closed IWI to ensure a continuous

VCL and insulation.

work needs to include a proper

assessment of the full building. This

should be completed under PAS

2035:2023 for domestic work or PAS

2038:2021 for commercial.

These specifications set out a

clear process for assessing properties

and developing tailored

improvement plans. In all cases, this

includes a full survey of the building

characteristics and any defects.

Where an IWI system is being

considered, additional assessments

must be carried out to consider

moisture risk and ventilation.

Installers looking to carry out

work under PAS 2035 or PAS 2038

will need to be accredited under PAS

2030. This sets out their

responsibilities during IWI

installations, including ensuring the

insulation is correctly installed (with

particular attention to junction

details) and that post-completion

ventilation rates are no worse than

prior to the works.

A WHOLE HOUSE APPROACH

Properly considered IWI installations

can notably reduce the energy

demand and operating cost of solid

walled homes. By adopting a whole

house approach which carefully

considers the building, it should be

possible to identify where IWI is

appropriate and the best approach

to take.

www.kingspaninsulation.co.uk

Kingspan Kooltherm K118 Insulated Plasterboard features an integral VCL and has a thermal conductivity

of just 0.019 W/mK.


APPOINTMENTS

Torsion Construction announces

senior appointments

Left to right: Priesh Soni, Richard Potts, Ed Wootton

Torsion Construction, part of

Leeds-based construction and

property business Torsion

Group, under the leadership of

Ed Wootton, has announced two

new senior appointments.

It follows a record number of

new project appointments for

Torsion during the last few months.

Torsion is on track to deliver its

strategic growth plans implemented

with Ed’s appointment as Managing

Director in 2023. Torsion has

experienced significant growth,

which has seen It become a broader

business in terms of geographic

spread (expanding operations in the

Northwest), strengthen its market

presence in core market sectors

(PBSA, Senior Living, Homes and

Residential), and increased the

average size of projects to £54m.

To support the business

expansion, business improvements

and insure continued strong delivery

of the secured schemes, Richard

Potts and Priesh Soni have been

appointed as new Regional Directors

for North and Midlands, respectively.

Richard joins Torsion

Construction with over 30 years of

industry experience, having served

most recently as an Area Director

with Morgan Sindall Construction.

He has a proven track record of

delivering projects in the residential,

commercial, leisure, health,

education and blue light sectors. As

Regional Director for the North, this

will be highly relevant to the

business during these next periods

of growth.

Priesh has worked at Torsion

Construction as a Commercial

Manager and a Commercial Director,

where he has significantly

contributed to the success of many

projects. As Regional Director for the

Midlands Region, Priesh will be

instrumental in driving growth and

success through strong delivery and

client satisfaction. He brings over 15

years of experience and expertise in

project management, business

development, leadership, and

strategic planning.

Dan Spencer, CEO of Torsion

Group, said: “The successful

implementation of our business

improvement plans under Ed’s

Leadership has allowed us to focus

on securing a record order book in

line with continued business growth.

I am delighted to support our

construction business moving to a

regional delivery model, and the

appointments of Priesh and Richard

are another step towards our longterm

vision for the Torsion Group of

companies.”

Dan added: “With a construction

career spanning over 35 years, Ed

has brought the business refreshed

energy, clear direction and strong

leadership.”

Ed Wootton, Managing Director

at Torsion Construction, said: “We

are delighted to welcome Richard

and Priesh to their new roles as

Regional Director. Their wealth of

experience, combined with their

deep understanding of the industry,

will be invaluable to our company as

we continue to drive business

growth and exceptional value to our

clients.”

Torsion Construction is a focused

and progressive construction

business dedicated to finding better

solutions for clients. Its innovative

approach to project delivery is

centred around ‘design to budget’,

which focuses on safety, efficiency,

and sustainability working within

the client's original budgetary

expectations.

In 2023 Torsion Group was listed

in The Times (Sunday Times) Best

Places to Work, Large Business of

the Year at the Yorkshire Post

Excellence in Business Awards, and

Developer of the Year at the

Property Week Student

Accommodation Awards.

Find out more about Torsion Group

at: www.torsiongroup.co.uk

Find out more about Torsion

Construction at:

https://www.torsionconstruction.co.

uk/


PROJECTS

West

Fraser

launches

a guide

for

architects

Tried and trusted by architects

for over 50 years, West

Fraser’s OSB, particleboard and

MDF engineered wood panels

take pride of place in so many

buildings today. All are net carbon

negative, come with all the

necessary accreditations and safety

marks, and are made in the UK.

A new guide details all the

information an architect or specifier

needs when considering the very

best panel selection. Specifying

precise products means there’s less

margin for error; when drawing up

contract documents drawings should

include the product manufacturer,

product name and grade to avoid

contractors subbing in products that

they ‘think’ will do the job. Leaving

such important decisions to supply

teams and contractors can not only

affect the sustainability and carbon

footprint of a project, but also

fundamentals such as the structural

integrity of the build. Not all

products are equal. Cheap imports

from Eastern Europe, China and

South America may be appealing to

contractors but cutting corners

comes at a price.

All West Fraser panel products

manufactured in the UK are net

carbon negative and manufactured

in mills that have obtained the

coveted environmental ISO 14001

accreditation. Responsibly sourced,

the panels are FSC-certified

(CO12533) and created from locally

grown timber, cutting embodied

carbon from transportation.

To find out more about West

Fraser’s support for architects and to

access useful downloads, visit the

architects’ page at:

https://uk.westfraser.com/resources

/architect-support/

For further information,

call 01786 812 921or visit

https://uk.westfraser.com/


PROJECTS

Reviving History –

A Victorian renovation adventure in Highbury

Nestled in the vibrant heart

of Highbury, North London,

lies Aberdeen Road – a

street where time seems to

pause, allowing the echoes of

Victorian grandeur to linger in the

air. Amongst these historic relics, one

house stands on the brink of a

remarkable transformation. This is the

home of Katy and Clive, a dynamic

duo driven by their shared passion

for property and design, ready to

breathe new life into a tired Victorian

beauty.

Katy Ayling, an alumna of the

prestigious Chelsea College of Art,

runs her own interior design agency.

Her impeccable taste and keen eye

for style have earned her a

reputation for creating spaces that

effortlessly blend form and function.

Meanwhile, Clive, the

entrepreneurial force behind Love

London Apartments, a boutique

lettings agency found a project they

can both get behind.

This journey into the world of

property development began during

the quiet, introspective days of the

COVID-19 lockdown. Confined to

their home, Katy and Clive found

solace in daydreams of new projects

and untapped potential. It was

during one of these moments of

reflection that they stumbled upon a

large Victorian property on Aberdeen

Road, a victorian maisonette

brimming with possibilities yet in

desperate need of a revival.

The upper maisonette, boasting

1,000 square feet of space and two

terraces (including a rooftop with

breathtaking views of the city

skyline), was a diamond in the

rough. Its grandeur had faded over

time, leaving it weary and outdated.

But where others saw decay, Katy

and Clive saw a canvas. They

envisioned a modern masterpiece

that would honour the home’s

storied past while injecting it with

contemporary flair.

Their ambitious plan involves

reordering the property’s internal

layout, a bold move that will see the

kitchen and living area relocated to

the top floor, taking full advantage

of the stunning skyline views. This

reconfiguration not only maximises

the aesthetic appeal but also

enhances the functionality of the

space, creating a living area that is

as inspiring as it is practical.

Additionally, Katy and Clive aim

to add both an extra bathroom and

a bedroom, ensuring that the house

is not only beautiful but also

accommodating for modern families

and young professionals.

Katy’s design philosophy centres

around a harmonious blend of the

contemporary and the traditional.

For this project, she has set her

sights on high-quality materials and

bespoke furnishings that will bring

her vision to life.

Imagine sleek, modern fixtures

juxtaposed with ornate Victorian

mouldings; luxurious, state-of-theart

appliances set against the

backdrop of exposed brick walls that

whisper tales of yesteryear.

Every element of this renovation

is meticulously planned, from the

grand, open- plan kitchen with its

polished countertops and cuttingedge

appliances to the cozy yet

elegant living area, complete with

large modern sash windows and

patio doors that flood the space

with natural light. The additional

bedroom will offer a serene retreat,

featuring carefully selected

furnishings that promise comfort

and style and the ever important

practical storage.

The extra bathroom, a sanctuary

of relaxation, will boast a blend of

traditional charm and modern

luxury. Each room in the house will

reflect Katy’s ability to merge the

old with the new, creating a space

that feels both timeless and fresh.

Gain an inside look at Katy and

Clive’s transformation of their

Victorian home as we follow their

journey in Project Spotlight.

Whether you’re a seasoned property

enthusiast or a fan of

transformation stories, follow their

journey in Refurb Projects.


ASWS flies to the rescue for a

leading Scottish Hotel

PROJECTS

The conversion of a former

warehouse property in the

heart of Glasgow into a

leading hotel required the

speedy intervention of a steel door

specialist, with London-based

Associated Steel Window Services

(ASWS) subsequently flying one of

its teams up to Prestwick to carry

out the required work.

The building’s imposing red

sandstone frontage is dominated by

a trio of arched headed openings,

which were to be a key feature of

the refurbished element to a much

larger and very stylish new

destination on the famous Clyde

Street. Unfortunately, despite the

city’s association with shipbuilding

and engineering generally, the main

contractor could not identify a

company North of the border,

capable of meeting the technical

and time demands of the project.

The Contract Director for ASWS,

Kris Bennell, commented, “The

creation of this landmark hotel

involved the construction of a new

building alongside the refurbishment

and conversion of the original stone

structure with which we became

involved. These were very large and

extremely heavy steel doors and

fixed lights which required a lot of

work – and though the client could

probably have replaced them with

alternatives, they wanted to stay

faithful to the heritage of the

building and its architectural style.”

“After I originally flew up to

Glasgow, as a specialist contractor

could not be found locally, and our

tender was accepted, we sent a

whole team up there on the plane

while two other operatives drove

vans up with all the necessary

equipment. The three doors, frames

and subframes were then

demounted and prepped ready to be

transported back to our London

premises so restoration could be

carried out.”

This process with the frames

being deglazed and then grit-blasted

back to bare metal, ready for repairs,

involved some replacement of

heavily corroded sections. The

bottom rails had been almost

completely eaten away through

resting on the stone paving without

any weathering detail. Some of the

corroded T-bars were also replaced

using stock sections.

An anomaly to the original

design or installation was the

presence of a substantial, but

intrusive and badly deteriorated,

Kris Bennell, Director for ASWS.

timber subframe to all of the three

frames, which the project team

wanted to have substituted by a

tubular section insulated aluminium

frame; in order to create a thermal

as well as visual uplift. Designed inhouse

by ASWS engineers, this was

made up in several straight and

templated curved sections which

were bolted together on site and set

back into the stone reveal for the

doorframe to be fixed to.

Kris Bennell continued, “The

centre double door had originally

featured a central ‘slamming bar’.

However, in order to facilitate the

double doors being converted to two

individual entrance doors the

slamming bar had been cut out

disposed of and the doors inverted

at some time. As the doors required

rehanging as one double door we

ended up having a complete new

sub-frame fabricated and fitted and

the repaired original opening leaves

were rehung into it. Primed in the

workshops, the three assemblies

were finished in-situ while the main

door was fitted with new

ironmongery and an electronic

closing mechanism. Despite this just

involving three openings, due to the

condition and the logistics of the

location for us, it turned out to be a

demanding contract.”

The original 10mm plate glass

was replaced by a similar thickness

of toughened glass to protect

building users, while new solid steel

beading was mitred, drilled and

taped for its retention. In addition,

the solid steel bead had to be cut

and curved to match the shape of

the main semi headed frame.

ASWS is a long-established

member of the Steel Window

Association and well recognised

expert in the repair of metal

windows, from the earliest wrought

iron examples through to

contemporary curtain walling. The

family run business is frequently

called upon to prepare condition

surveys during the appraisal stages

of a project, which then become

part of the planning or listed

building permission process. The

company also maintains a very large

stock of ironmongery and metal

frame components to assist in its

restoration work.

www.asws.co.uk.


PROJECTS

Aruba: A trusted ceiling tile for generations

Trusted by generations of

architects and installers, Aruba

is specified throughout the UK

almost every single day. With

impressive sound properties, and a

range of colours available it is an

incredibly versatile range that can be

found everywhere from hotels and

offices to classrooms and retail

environments.

The range has been named after

the white sandy beaches of the

Caribbean due to the finely sanded

finish of the tile’s surface. The Aruba

tile also reflects the vibrancy and

colourful nature of the Caribbean, as

it is available in 35 colours, the

largest option of standard colours

available on the UK market. For

further design creativity, the Aruba

family can be specified in alternative

shapes such as the Aruba Triangle.

Additional tiles with enhanced

performances are available within

the Aruba family including Aruba

hH, Aruba Max and Aruba dB, each

bringing unique performance

capabilities.

ARUBA

The Aruba tile is incredibly versatile,

with a number of attributes that

deliver a thorough solution.

Combining Class C sound absorption

with a sound attenuation level of

34dB, the tile controls background

noise levels whilst allowing sound to

travel, creating an acoustically

comfortable setting. It contains up

to 44% recycled content, is 100%

recyclable and is scratch resistant.

Recently specified for an

industrial site in one of the UK’s

most important manufacturing

areas, the coloured Aruba tile was

able to meet the aesthetic,

functional and acoustic

requirements set out for the project.

Ceiling installer, Barry Deane,

Director at East Midlands Ceilings

commented on the Aruba family:

“It’s always exciting when the

customer wants a change from the

standard types of suspended ceiling

designs. It made the project

extremely interesting to be involved

with, and the Aruba coloured tiles

look amazing, giving a modern and

visual twist over the standard install.

The quality of the materials was also

fantastic, with everything being

manufactured and delivered to suit

the project requirements perfectly.”

ARUBA HH

The Aruba hH tile offers enhanced

high humidity resistance, making it

ideal for areas such as changing

rooms. It also has the same acoustic

qualities as the Aruba tile; but can

remain stable in conditions of up to

99% Relative Humidity (RH).

ARUBA MAX

The Aruba Max is a more robust

variation of the standard Aruba tile,

designed for interiors that require a

higher technical performance. With

an increased tile thickness, it offers

higher sound attenuation levels of

35dB, and is perfect for settings

such as classrooms where sound still

has to travel but in a controlled

manner.

ARUBA DB

For internal settings that require

extra levels of privacy such as

meeting rooms and small offices, the

Aruba dB tile offers the highest

sound absorption rating at 39dB and

reduces sound transmission through

the ceiling void.

https://www.zentia.com/en-gb/


PROJECTS

Style adds sustainable flexibility to

Aviva Seminar Space

Working with architect, T

P Bennett and

contractor, Overbury,

moveable wall specialist

Style was recently specified to create

flexible seminar space on floor 1 of

Aviva’s new London head offices in

Fenchurch Street.

A single Dorma Huppe Variflex

ComforTronic, semi-automatic

moveable wall, boasting an

outstanding 59dB acoustic

performance, separates the seminar

area from the catering and breakout

zone. A second Variflex system

allows the space to be further subdivided

into two smaller rooms.

Both walls are finished in a chic

Kvadrat Encircle fabric, one grey and

the other a deep green, perfectly

complementing the interior décor.

Aligning with Aviva’s

commitment to achieve Net Zero by

2040, the Variflex system has an EPD

(Environmental Product Declaration)

in accordance with ISO 14025 and

EN 15804. This certification provides

transparent and verified information

about the environmental impact of

the product across its lifecycle.

Aviva’s new head office is spread

over multiple floors, providing

modern and spacious working areas

that aim to facilitate collaboration

and innovation amongst the 1,500

employees that work there.

“This is a very sophisticated

seminar area,” said Michael Porter,

Style’s group managing director,

“and thanks to the ease of

manoeuvrability and high-end

acoustic ratings of the two Dorma

Huppe Variflex moveable walls, it

can be quickly transformed to cater

for one large, or two small, seminars.

“Once the seminars are over, the

room can also be fully opened up

into a vast open plan area for

catering and networking, making

this an exceptional solution for

Aviva whose requirements can

change daily.”

Style is the exclusive UK partner

to Dorma Huppe, offering a wide

range of manual, semi-automatic

and fully automated moveable walls.

Further attesting to the

sustainability of the installation,

Style is accredited under the ISO

14001:2004 Environmental

Management System. This

certification ensures that the

company adheres to practices that

maximize sustainability and

minimize waste throughout their

operational processes.

www.style-partitions.co.uk


PROJECTS

Invisible Door Automation Opens Historic

Oxford College Entrance

The Grade II listed dining hall

at Pembroke College, Oxford

University has undergone a

significant upgrade. Architects

Walters & Cohen, in collaboration

with Glasstec, has addressed the

issue of draughts from the hall’s

heavy timber doors by installing an

elegant yet highly functional, selfopening

glazed entrance door.

This creative solution

incorporates a TORMAX iMotion

1401 concealed door drive, providing

invisible automation for the swing

door. The result is a warm, draughtfree

environment that enhances

thermal comfort and energy

efficiency without compromising the

hall’s historic charm.

The new entrance door is a

testament to the seamless

integration of modern technology

within a historic setting. The

TORMAX iMotion 1401, located

discreetly in a steel casing beneath

the door, ensures that the aesthetic

integrity of the Victorian stonework

remains intact.

"We are delighted with the

successful installation of the new

entrance door, which cleverly

balances functionality and heritage

conservation," said Vanessa Gouws,

Operations Bursar of Pembroke

College. "This intervention has

helped improve the energy

efficiency of the dining hall, the

second biggest fuel consumer in

Pembroke’s estate, not to mention

helping keep diners and dinners

warm."

TORMAX is a global leader in

door automation systems, renowned

for their innovative designs and

commitment to quality.

Designed in-house at the

TORMAX headquarters in

Switzerland, the iMotion range of

automatic door operators

incorporate a motor with none of

the elements that generally wear

out, such as gears and brushes. This

ensures exceptional longevity and

demands only minimal ongoing

maintenance, making it entirely

feasible to situate the drive in a

concealed location.

“In addition to the iMotion 1401

underfloor door drive, we offer the

iMotion 1302.KI which is concealed

within the door lintel,” comments

Simon Roberts, MD for TORMAX UK.

“Together, these options can deliver

practical access solutions for almost

any location where the traditional

appearance of an entrance must be

preserved.”

www.tormax.co.uk


PROJECTS

Tsurumi Tree Planting Project Update

Tsurumi Pumps UK are on track

to achieve their target of

planting in excess of 10,000

trees in the UK and overseas,

as part of the ‘Tsurumi Tree Planting

Project’ which was implemented at

the start of this year.

They have pledged to plant a

tree for every Tsurumi brand pump

sold in 2024 to continue to

contribute to their journey to net

zero whilst supporting customers

and Tsurumi pump users with their

own nature and biodiversity

strategies.

After calculating their figures,

the total has amounted to an

impressive 5,812 trees that had been

ordered or planted by the end of

June.

The planting of trees not only

removes the equivalent of 4,641

tonnes of CO2 from the atmosphere

but also has created 58 working

days for tree planters in the UK and

overseas.

Tsurumi Pumps UK has partnered

with Carma, a B Corp-certified

company that will carry out the

tree-planting project across a range

of locations in the UK and Kenya.

Trees planted in the UK are

planted by armed force veterans via

The Green Task Force, a charity

established to take action on issues

surrounding the environment, whilst

also assisting veterans back into

employment.

6% of serving and former

serving personnel, and 17% of those

that have been in a combat

situation, are suffering from some

form of Post-Traumatic Stress

Disorder (PTSD). It has been proven

that getting veterans involved in

Nature-Based Therapy (NBT) has a

positive effect on their mental

health.

Trees planted overseas assist in

providing work for those in areas

where a large percentage of the

population lives below the poverty

line.

One of the projects that Tsurumi

have been able to contribute

towards is the planting of

mangroves in Mteza Creek Kenya,

which will provide fishing grounds

and additional income streams for

the local communities, where 62%

live below the poverty line.

In addition, the mangroves will

provide nutrition and sustainable

harvests, whilst stabilising the

coastlines as a vital defence during

tropical storms.

A live status report is available

on their website, to keep up to date

with the continued development of

their tree-planting efforts as we

progress into the second half of the

year.

www.tsurumi.co.uk

Photograph courtesy of Carma

Earth: Trees being planted in the UK


PROJECTS

Shoreline marks the first phase of a

Folkestone beachside regeneration

Occupying a prominent

position on the Folkestone

beachfront, Shoreline is a

contemporary take on the

traditional Edwardian curved terrace

and the first phase of an impressive

masterplan. Constructed by Jenner

and designed by ACME architectural

practice for the Folkestone Harbour

& Seafront Development Company,

the impressive residential building is

the first step in creating a vibrant

new community along the historic

seafront.

Forming part of ACME’s 2016

Folkestone Harbour and Seafront

masterplan, Shoreline it is the first

phase of a landmark project that

will provide up to 1,000 new homes,

shops, bars and restaurants as well

as attractive public and green

spaces, including Leas Square and

Marine Parade along the seafront in

Folkestone.

Located at the foot of the Grade

II listed Leas Lift, one of the oldest

water lifts in the UK and on the

edge of Lower Leas Coastal Park,

Shoreline is surrounded by heritage

and nature.

The schemes 84 luxury homes

benefit from a prime position with

uninterrupted views onto the beach

and across the sea, stretching as far

as the French coastline on a clear

day.

Overcoming a multitude of

challenges along the way, this

incredibly beautiful, unique building

sits upon robust foundations of over

200 piles, driven to a depth of 27

metres making the foundations as

deep as the building is high.

Constructed with a reinforced

concrete frame, Shoreline’s flowing

curved form echoes the shape of the

waves, pebbles and coast.

Built to endure the everchanging

weather patterns

experienced on the UK’s coastline,

every detail of Shoreline has been

meticulously considered. The

facade’s white glazed bricks, sourced

from La Paloma in Spain, reflects

the changing colours of the sea and

sky according to the weather and

the time of day. ‘Standardised’ was

never going to be an option and as

such over 24 different specially

designed bricks were required to

achieve the complex geometry.

Metal used on the exterior of the

building is rust-proof, whilst wall

ties beneath the facade are made

from the same marine grade

materials found on deep sea oil rigs,

ensuring longevity and

sustainability.

With the design of the balconies

proving problematic in terms of

their load bearing weight, engineers

implemented lighter-weight

aluminium support systems that

seamlessly integrated into the

building's curved design. There were

also five different balcony designs

each bespoke to mirror the shape

and curve of the structure. The

coping stones on the parapet walls

were individual in size and shape

requiring special moulds. The curved

structure also demanded bespoke

windowsills; each unit scanned as a

3D image.

The bespoke finish is most

certainly not limited to what the

public eye can see with communal

areas clad with acoustic walls and


PROJECTS

terrazzo floors to ensure quality

radiates throughout.

Private roof terraces are included

for the beach houses and penthouse

apartments and all units have the

exclusive use of a private communal

garden above the under-croft car

park that promotes natural daylight

through carefully placed openings to

provide a secure and pleasant

environment with EV charging

points and sufficient headroom for

all modern vehicles.

Other sustainable features

include shingle gardens that provide

an ecological habitat, increasing

species diversity within the beach,

rainwater harvesting and communal

heating. Storage units and cycle

parking are provided within the car

park to encourage bike use, there is

LED lighting throughout the

apartments and common areas and

a communal boiler provides efficient

heating for the apartments.

Martin Sandall, Managing

Director, Jenner: “As a Folkestone

based main contractor, we are

delighted to have been able to

deliver the initial phase of the

transformative Folkstone seafront

development. Shoreline Crescent is a

truly spectacular interpretation of

an English seaside crescent-shaped

apartment building. Whilst its

coastal location presented a number

of construction challenges, from

ground engineering through to the

selection and installation of

materials, the exceptional quality of

the finished building stands as

testament to the remarkable work of

the entire project team.”

From initial concept through to

articulation of its architecture by

utilising state-of-the art

construction techniques and

products of the highest

specification, the project serves as a

prime example of how the built

form positively impacts upon a

region.

Shoreline is a short walk to

Folkestone Central Station, which

provides direct trains to central

London in under an hour, whilst the

Eurotunnel station at Folkestone

connects directly to Calais. Gatwick

Airport and is just over an hour

away by car, with London City

Airport one hour and 30 minutes

away.

The boardwalk easily connects

residents to the Harbour Arm, which

has quickly become the Kent Coast’s

leading food and beverage

destination, and provides access to a

thriving waterside community

attracting many artistic industries

with the town’s Creative Quarter

providing an urban village of

designers, filmmakers, musicians,

web developers and artists amongst

the 90 or so restored buildings.

Folkestone was recently voted as one

of the best places to live in the UK

due to its thriving arts community

and public spaces, such as the

refurbished train station, viaduct

and Fountain Square, as well as

high-achieving schools and its

proximity to both London and the

Eurotunnel.

For further information on

Shoreline contact

Tel: 01303 760 940 or visit

www.shorelinefolkestone.co.uk


PROJECTS

G F Tomlinson and Henry Brothers share vision

for the future of Castle Meadow Campus

Asuccessful event at Castle

Meadow Campus hosted by

G F Tomlinson and Henry

Brothers Construction

provided an opportunity for Fbe and

ProCon members and guests to look

at the new University of Nottingham

city centre redevelopment site.

The collaborative event was held

at the Grade II Listed site where

current works include the

transformation of the former HMRC

headquarters - the Central Building

being delivered by G F Tomlinson,

and the remodelling of Buildings D

and F, by Henry Brothers, into

modern office spaces.

Encompassing seven buildings,

the complete redevelopment is set

to establish the Castle Meadow

Campus as a vibrant hub for

innovation and entrepreneurship,

featuring state-of-the-art facilities

for its community of students,

academics, and industry partners.

60 members of the Fbe (Forum

for the Built Environment) East

Midlands and ProCon

Nottinghamshire – both of which

are professional regional

construction and property groups –

attended the event, and were

treated to a morning of insightful

presentations, networking

opportunities and firsthand

experiences of the ongoing

redevelopment works.

While enjoying breakfast

sandwiches and hot refreshments,

representatives from the University

of Nottingham, Arup, and Bond

Bryan provided detailed site plans,

offering a comprehensive overview

of the campus scope and objectives.

Visitors were given guided tours

of the current works by G F

Tomlinson and Henry Brothers,

providing a unique insight into the

intricate renovation processes. A

highlight of the event was the

demonstration of the large-scale

Projection Augmented Relief Model

(PARM) by Dr. Gary Priestnall from

the University’s School of

Geography. The interactive 3D model

of Nottingham city centre

showcased the innovative use of

digital and data tools in urban

planning and development.

Led by Director, Prof. Paul

Grainge, University of Nottingham,

‘City as Lab’ also presented work on

leveraging digital and data

innovation to address real-world

challenges in the Nottingham city

region, emphasising the role of the

campus as a catalyst for

technological advancement and

community engagement.

G F Tomlinson, a longstanding

partner of the University of

Nottingham, is leading the

refurbishment of the Central

Building, including the complex

replacement of the tensile fabric

roof and the addition of a new

mezzanine level, designed to

enhance the building's functionality

and sustainability.

Adrian Grocock, Managing

Director of G F Tomlinson, said: "The

event at Castle Meadow Campus was

a fantastic opportunity to showcase

the extensive work being done to

transform the Central Building.

“We were delighted to share our

progress with the community and

our industry peers and we are

extremely proud to contribute our

expertise to such a landmark project.

“We have a long-standing

working relationship with the

University of Nottingham, with this

being our 8th scheme working

together. It is a real pleasure to

combine our university and heritage

experience to help the university to

deliver another world class facility.”

Henry Brothers Construction,

alongside a consortium of leading

industry experts, is nearing

completion of the remodelling works

on Buildings D and F. Managing

Director of Nottingham-based Henry

Brothers Construction Ian Taylor

said: “The Castle Meadow Campus is

a hugely exciting project for the

University of Nottingham and for

the city as a whole and we are

proud to be playing a part in it.

“Henry Brothers has extensive

experience of working with

universities across the Midlands to

improve their facilities. This is our

first contract with the University of

Nottingham, and we are really

pleased to see the partnership

creating such fantastic new facilities

in our home city. They will be a

tremendous asset to the community,

and we are honoured to have jointly

hosted this event for our peers in

the local construction and property

sector.”

James Hale, Building and Design

Lead for Castle Meadow Campus,

University of Nottingham, said:

“We’re pleased to be working

together with our partners on the

Castle Meadow Campus

development. The chance to

welcome ProCon and Fbe members

and guests to showcase the great

work that’s already happening to

transform the site was excellent.

“We’re pleased that members and

guests showed a keen interest in this

historically significant site. With

more work to come, we are

determined to create an accessible

and sustainable world-class campus

environment.”

The event underscored the

importance of fostering partnerships

in technological advancement and

sustainable development. With the

University of Nottingham, G F

Tomlinson and Henry Brothers at the

forefront, the Castle Meadow

Campus is poised to make a lasting

impact on the region.

https://gftomlinson.co.uk/


Landmark expansion of technology hub

completes in Coventry

PROJECTS

Works have completed at

Project Holst – a £75

million industrial

warehouse scheme

located at Coventry’s renowned

Prospero Ansty Park.

Ansty Park is a major business

park positioned next to the M6 and

M69 junction providing unrivalled

access to the UK’s major motorway

network, which is home to a number

of high-profile companies including

Rolls-Royce, Sainsbury’s, Cadent,

Meggitt and MTC.

McLaren Construction (Midlands

and North) commenced the delivery

of four industrial units and

associated offices at Project Holst in

January last year, on behalf of

Manse Opus. All units are now

finished and open to speculative

tenants.

The commercial units span a

total of 856,109 sq. ft. and

predominantly comprise a cladded

portal frame with a CAT A open plan

layout. The site also features an

external logistics yard with a level

and dock access area, dedicated

parking spaces with electric charging

points, communal areas and

landscaped gardens.

The offices have a largely open

plan design to provide flexibility to

prospective tenants, and the

architecture has focused on the

business culture and purpose of the

technology park, reflecting the

current variety of highly skilled

professions already present within

the surrounding developments.

Units are highly energy efficient

and were designed to meet a

BREEAM Excellent rating. Their

design has incorporated the

application of roof top PVs and

rainwater harvesting tanks.

The scheme entailed a complex

earthworks operation which took

place prior to construction and

extensive infrastructure works were

needed to access the plots and

associated balancing ponds, to

accommodate storm water. All

removed earth was also reused back

within the site, to reduce waste and

provide a greater circular approach.

As part of the wider landscaping

scheme, new ecological areas were

also developed during the

construction and population of the

site, and prior to works commencing,

great crested newts were identified

and relocated, with protective

fencing installed around the

perimeter of the site.

Giving back to the local

community, voluntary works were

also carried out at the Grace

Academy during the summer months

and the team created a sensory open

space for students to enjoy.

Project Holst marks the third

scheme at the park that McLaren

Construction and Manse Opus have

partnered together for, following

more than three years of

collaboration.

Operations director of McLaren

Construction Midlands and North,

Shaun Colley, said: “We’re delighted

to have partnered with Manse Opus

again to provide further expansion

to Prospero Ansty Park for this next

phase, which is now complete.

“Prospero Ansty Park is a fastgrowing

business and industrial hub

for the West Midlands, for which we

previously completed works for

Apollo and Cadent. We have

managed to overcome many

challenges with this site – battling

extreme weather. However, our

skilled team of contractors managed

to stick to the critical timelines of

the programme and delivered an

exceptional product.

“Our focus for the scheme has

been on providing energy efficiency

and indoor environmental quality,

which ensures energy consumption

efficiencies whilst promoting a

healthier and inviting workspace.

The central high-specification

commercial office space is ideally

positioned to cater to clients in the

industrial and logistics sector,

bringing our client’s vision to life.”

David Mitchell & Victoria

Turnbull, Joint Managing Directors

of Manse Opus commented “We are

proud of what we have achieved on

site since our appointment in 2019.

The transformation of this unused

land to create the stunning

buildings you see there today has

been a great privilege and one we

are really proud to have been able to

achieve. We have contributed to

safeguarding the legacy of a site

which has such an impressive

history.”

To find out more about McLaren

Construction (Midlands and North)

Ltd, please visit:

www.mclarengroup.com.


PROJECTS

The Tung Auditorium: igus® HD e-spool®

supports award-winning Concert Hall

The Tung Auditorium in the

heart of the University of

Liverpool’s campus has

undergone an incredible

transformation, with the help of

igus®, to enhance both the acoustic

technology and architectural design,

resulting in the venue winning at

the MONDO-DR Awards in the

concert hall category.

Situated within the Yoko Ono

Lennon Centre, The Tung Auditorium

is a state-of-the-art concert hall

designed to be a hive of musical

activity. The well-executed final

design required the efforts of many

talented teams, such as Ellis Williams

Architects, Arup Consultants

(Venues), and the Adlib team, who

specified igus® HD e-spool as a cable

management system solution.

The vision was clear: to create a

space that nurtures creativity and

functions effortlessly for the

audience and performers. This was

certainly achieved as The Tung

Auditorium was nominated in the

concert hall category for the 2024

MONDO-DR Awards, taking the

winning spot to celebrate the best

installation projects around the

world.

As Tung’s Artistic Director

Richard Hartwell explains, the venue

needed to be flexible to meet the

brief of facilitating pianists, string

quartets, singers, and up to 70-piece

orchestras whilst also being used as

a lecture hall as part of its daily

operation. The auditorium required

strict organisation in its design in

order to provide an adaptable space

for its range of visitors and the

proposed igus® solution successfully

achieved the desired cable

management.

The igus® HD E-spool is a cable

The MONDO-DR Award winning Tung Auditorium uses the igus® HD e-spool® as part of their project to modernise and

simplify the space for audience and performers alike.

management system, designed to

suit limited spaces and provide

flexibility of use in any direction.

The cables are encased in an energy

chain, and the use of an igus

twisterband means that no break in

the cable is needed, and there are no

slip rings or other systems.

Adjustments and extensions of the

filling are also possible at any time

afterwards, so the product can be

adapted to suit customer needs

exactly. Additionally, while lack of

space was not a factor in this

particular project, the e-spool® is

designed to work around tight

spaces, so there are almost no limits

to the locations in which it can

operate.

THE IGUS® DESIGN IN PRACTICE

The igus® HD e-spool® sits alongside

the motorised winches, in the roof

void above the auditorium, deployed

to address the challenges of dynamic

cable management. At the heart of

the e-spool® is the innovative

twisterband that manages moving

cables without twisting them. In the

words of Adlib, this gives the venue

a ‘reliable and efficient way to

manage its large amounts of data,

audio and multi-core cabling’.

Created with the intention of being

cost-effective and space-saving, the

e-spool® consistently exceeds

expectations and extends the service

life of the cables it manages to

reduce unnecessary downtime. In a

space as fast-paced as a university

auditorium, the show must go on,

and the igus e-spool® has a proven

track record of supporting multipurpose

venues where flexibility is

required.

While igus® is perhaps more

well-known for products in

industries such as manufacturing

and construction, the e-spool® is a

great example of the diverse range

of products offered to a variety of

industries. The Tung Auditorium is

also an excellent example of a

project that resulted in an exemplary

final design, rewarded with the

winning title in this year’s MONDO-

DR award in its category.

www.igus.co.uk


PROJECTS

ESW achieves ‘massive’ improvement

in heat retention, comfort & aesthetic at

BCL pilot with a Mapei Mapetherm EWI System

The Mapetherm Mineral Wool

External Wall Insulation (EWI)

system from Mapei, has been

installed as part of a Bristol

City Leap (BCL) pilot retrofits

scheme. The scheme, in the City’s

Brentry district, comprised the

upgrade of 16 Easiform homes to

achieve energy efficiency and

carbon reduction. The EWI system

was installed by Bristol-based ESW

Construction Services Ltd. Following

installation of a cavity fill system

combined with the Mapetherm EWI,

a u-value of 0.22 W/m2K was

achieved, compared with a preretrofit

rating of 2.06 W/m2K,

demonstrating greatly improved

heat retention and comfort.

An innovative partnership

between Bristol City Council and

Ameresco Ltd, Bristol City Leap aims

to accelerate green energy

investment in Bristol and help

towards decarbonising the whole

city. Over the next five years, it will

invest at least £424 million into low

carbon energy infrastructure

including solar, wind, heat networks,

heat pumps and energy efficiency

measures in order to help the city

meet its carbon reduction target of

becoming carbon neutral by 2030.

Each of the 16 Easiform homes

in Brentry features a non-standard

concrete cast-in-situ construction.

The scope of renovation works

included replacement of roofing

elements, renovation of chimney

stacks, insulation of cold roof space,

internal ventilation works, cavity

wall extraction, fenestration

installation, cavity wall fill and a

wide range of enabling works. As

part of the energy efficiency

improvements, Mapetherm Mineral

Wool - BBA 13/4977 certified highdensity

rock wool insulating panels

for thermal insulations systems –

were installed throughout the

properties external walls, totalling

over 1400 m2.

“The Mapetherm system has been

tried and tested on many of our

projects. Mapei’s products are high

quality, easy to use and the final

results speak for themselves. The

service we get from Mapei’s sales

and technical team has always been

first class and the support they offer

on site is second to none,”

commented

Carlo Bonomini, ESW’s

Commercial Manager.

“ESW has been instrumental in

the success of the pilot project;

having accumulated experience and

knowledge of the Mapetherm

Mineral Wool EWI system over

several years proved essential in

overcoming the initial teething

problems of the pilot. Diligence and

thoroughness prior, during and after

works paved the way for high

standards, outstanding results and a

happy client, as well as improving

the lives of those residing in the

properties,” commented Jay

Shuttleworth, Construction Manager

at Bristol City Leap.

“Tenant comments have been

positive following the completion of

their properties, with a remarkable

difference and satisfaction of the

results experienced, an improved

exterior with a massive improvement

to internal heat retention and

comfort. Many tenants also

appreciate the reduced CO2

footprint resulting from the works,”

Jay Shuttleworth added.

For more information, please

contact: info@mapei.co.uk or visit

www.mapei.co.uk


PROJECTS

Illuminating Heritage: DHA Designs Transforms Exeter

College Library with a Sympathetic Lighting Scheme

DHA Designs proudly

announce the completion

of a transformative lighting

design project for the

historic Exeter College Library.

Originally constructed in 1857 by

renowned architect George Gilbert

Scott, the neo-gothic library is a

treasured architectural gem in

Oxford.

The library is one of several

works by Scott at the college and is

situated overlooking the Rector’s

Garden, adjacent to the 17th

century walls of Convocation House,

the Grade I listed historic court

room of the Bodleian Library,

separated only by a sliver of ground

between buttresses.

The project’s primary challenge

was to meet the needs of the

college and its students while

honouring the library's heritage. Key

to this was the provision of suitable

lighting for reading desks and

bookshelves, alongside creating a

calm, inviting atmosphere that

encourages study.

The main building, spanning the

ground and first floors, features tall,

free-standing bookcases that were

meticulously removed and

refurbished, which allowed DHA

Designs to fix lights and cabling to

the tops of these cases without

damaging their fabric. These

cantilevered lights then cast light

down over the shelves. Additionally,

an uplighting system on top of the

bookcases highlights the intricate

decorative ceilings, showcasing the

library’s architectural splendour.

Custom-made oak desks,

equipped with integrated task lights,

offer students personalised control

over their lighting. These task lights

not only blend seamlessly with the

bookcases but also feature energysaving

automatic shut-off

functionality.

The ground floor features long

reed glass pendants suspended over

the desks, while the first floor boasts

a tall reeded glass light that

accentuates the room's height,

drawing attention to the wooden

ceiling and stone-framed windows.

The restored windows, showcasing

stained-glass roundels by Edward

Burne-Jones and crafted by William

Morris’s factory, now find new

resonance through modern light

fittings that utilise diverse glass

types to create varied atmospheric

effects. Specially commissioned

dichroic glass fins in the roof light

of the new circulation spaces further

enhance this interplay of light and

glass.

The annexe continues the theme

with similar reading and bookcase

lights. Concealed uplights within the

bookcases and the new clerestory

provide an airy, illuminated

environment. At the ceiling level,

four large pendants outline the

space, creating a striking visual

effect.

In the historic turret stairs,

outdated surface-mounted

bulkheads have been replaced with a

continuous low-profile LED

extrusion that discreetly illuminates

the space - running vertically up the

side of the wall, disappearing into

the steps to reappear on the next

level. The dome of the turret and

the figure that supports it have been

illuminated for the first time using

discreet spotlights placed at the top

of the profile.

All lighting elements are

connected to a sophisticated control

system, allowing for dimming and

switching based on time of day or

student needs. This ensures an

optimal balance of lighting and

energy efficiency, tailored to the

dynamic requirements of the

library’s users.

Des O'Donovan, Director at DHA

Designs said “Completing the

lighting design for Exeter College

Library hasn’t been without its

challenges, but it’s been a truly

rewarding project. Our goal was to

enhance the heritage features of the

college, whilst providing an

environment that students find

comfortable to study in. We are

proud to have created an inviting

and inspiring environment for

students and scholars alike.”

With a deep understanding of

architectural context and of creating

lighting design schemes for heritage

projects, DHA Designs collaborates

closely with clients to create lighting

designs that enhance both the

historic features and functionality of

spaces. The lighting design for

Exeter College Library respects its

historical significance while also

enhancing its functionality for the

future.

https://www.dhadesigns.com/

Project credits:

Client:

Exeter College, Oxford

Lighting Design: DHA Designs

Architect:

Nex

Heritage Consultant &

Conservation Architect:

Donald Insall

Services Engineer:

Laurence Owen

Photography: James Newton


PROJECTS

STO’s external wall insulation system specified

for 8,000m² Canary Wharf recladding project

ASto external wall insulation

(EWI) system spanning

8,000m² has upgraded the

exterior of a waterside

residential development in Canary

Wharf, London, providing fire

compliant facades.

Pierhead Lock is situated

opposite the O2 arena on the River

Thames. Beginning with a 12-storey

tower by the water, the

development gradually steps down

to two storeys as it curls round the

dock. Aiming to reflect the

appearance of a 1930s cruise ship,

the scheme also features semicircular

apartment blocks and a

rounded tower, all with white

facades.

Noviun Architects were

responsible for designing remedial

works for the exterior cladding,

which required the existing

expanded polystyrene insulation

(EPS) to be removed, to comply with

amendments to the Building

Regulations. Following extensive

investigative work, the architects

and façade restoration specialist

Stoneguard worked with Sto to

develop a detailed specification of

the EWI system.

The BBA-certified StoTherm

Mineral K external wall insulation

system achieves a reaction to fire of

A2-s1, d0 in accordance with BS EN

13501-1. The A1-rated mineral fibre

insulation boards were adhesively

fixed to the concrete substrate using

StoLevell Duo Plus. This levelling

mineral adhesive was applied to the

back of the insulation boards, with

fixings used to secure the insulation

boards to the substrate, including

through the mesh to suit wind load

conditions.

StoFlexyl, an acrylic-based, fibrereinforced

waterproofing product

was also used to encapsulate the

insulation below the dampproof

course. This coating protects against

moisture or water ingress of the

insulated system.

To reflect Pierhead Lock’s original

architectural style, the system was

finished with StoSilco K1.5 silicone

resin render. This provided a crisp

white finish as well as high levels of

water repellence and protection

from harsh weather conditions.

Given the development’s waterside

location, the render was coated with

StoColor Dryonic G and StoSilco G

façade paint ensuring robust

protection against algae growth.

In the development’s rounded

tower, the StoVentec carrier board,

which is made of recycled glass

granulate and has a high

compressive strength, was installed

over the soffit with new insulation.

This replaced an existing dry lining

system featuring EPS.

Andreas Constantinou, Finance

Director from Stoneguard said: “We

have a long and successful history

with Sto, so knew we could rely on

its products and service to deliver

this extensive recladding project.

“Not only did we have to install

the Sto system across a huge area,

we had to overcome various

challenges. The development was

occupied by residents throughout

the duration of the refurbishment

project, and its proximity to the

River Thames made access difficult.

The architectural curves that feature

throughout Pierhead Lock added

further complexity as the new

insulation had to be carefully cut

into the right shape.

“Sto’s technical team was on

hand to support us throughout.

Thanks to this strong working

relationship and the skills of our onsite

team, we were able to complete

the project two months ahead of

schedule.”

Chris Watts, Director at Noviun

Architects added: “The installation of

the A1 non-combustible render from

Sto was one of only 50 in the

country successfully delivered at the

time. This impressive project was

signed off by Building Control

without any issues and completed

on budget and programme.”

www.sto.co.uk.


PROJECTS

London railway arches converted into modern

space as part of £200m rejuvenation plan

THE TRANSFORMATION of six

vacant railway arches in the

East End of London has

reached completion, providing

a range of new commercial spaces

that mix the city’s heritage with

modern need.

The project, which was delivered

by leading multi-disciplinary

consultancy Pick Everard in

partnership with Stephen George +

Partners (SGP), sees the rejuvenation

of an area steeped in history located

only 16 minutes away from the City

of London.

Creating a space suitable for

light industrial use, works completed

at Witan Street, Bethnal Green have

included comprehensive surveys of

the arch structures and original

brickwork, with new interiors

installed alongside glazed infills and

electric roller shutter doors.

The new commercial spaces are

part of Project 1000, The Arch

Company’s £200m plan to bring a

thousand empty or derelict spaces

into use across England and Wales

by 2030.

Providing expertise in structural,

civil and building engineering,

Santosh Patel, strategic account

director at Pick Everard, said: “From

concept to completion, we were able

to advise and coordinate with SGP

to allow efficient structural and

drainage solutions to be designed.

“This collaborative approach has

delivered exceptional results that

converts the unused archways into

modern industrial units, creating

spaces that are both functional and

versatile. With every inch of space in

London highly valuable, the

regeneration of the arches grants

exciting new opportunities.

“It’s been a rewarding experience

to once again collaborate with SGP

and The Arch Company on a

development that will support local

businesses and enrich the urban area

of Bethnal Green.”

Alan Soper, studio director at

SGP, said: “Urban industrial property

can play a vital part in local

economies, yet good-sized, modern

industrial space close to central

London is often difficult to find.

“That’s why we’re delighted to be

working with The Arch Company on

the transformation of these

previously unloved arches on Witan

Street into vital commercial spaces

that will suit a variety of industrial

occupiers and support their daily

operations in a location close to the

heart of one of the busiest cities in

the world.

“Witan Street, with its nearby

transport links to central London, is

perfectly located for commercial

businesses to thrive and it’s

incredibly gratifying to have

refurbishment work complete and

see these arches back in productive

use.”

Elsewhere in London, work has

commenced on the refurbishment of

four disused and dilapidated railway

arches on America Street,

Southwark, into spaces for

restaurants, cafés and bars.

To learn more on Pick Everard on

the services it provides, visit:

www.pickeverard.co.uk


2 - 4 December 2024

ExCeL London

REGISTRATION IS

OPEN

Register now

Over 23,000

attendees

from over 180

countries

180+ Speakers

Over 200

hours of

content

19-20 November

COATINGS • TOOLS • DEMOS • IDEAS • DEALS

CBS Arena, Coventry

NATIONAL

PAINTING AND

DECORATING

SHOW

It’s where the trade meets!

w w w . p a i n t s h o w . c o . u k

Refurb Projects August 2024

Transform your PDFs into Flipbooks and boost your revenue!

Delete template?

Save as template ?
