EDITORIAL

A plea for Europe

The Foundry Technology Conference 2024 in Salzburg – 25 specialist presentations

in front of more than 600 participants, an attractive and well-booked

trade exhibition exhibition – and two keynote speeches plus a panel discussion,

which formed the main framework.

Photo: BDG

Martin Vogt

Editor-in-chief

e-mail: martin.vogt@bdguss.de

If it is the sign of a good event that it

causes a kind of thought overload in

the brain, then the Foundry Technology

Conference 2024 in Salzburg was

actually a very good event. From the ten

technical presentations alone, which I

myself moderated in the “Non-ferrous

metal casting” and “Digitalization” sessions,

it was certainly possible to identify

three dozen keywords that outline

the typical specialist topics of our industry

very well. From mold steels, aluminum

alloys and the core production of

the future to casting defects, braking

systems, resource efficiency and digitalization.

So technical, so good – although

this is to be expected at an event that is

essentially a lecture event with parallel

sessions in several halls.

If you could call the lecture program

the duty, the framework takes on the

character of freestyle. Futurologist

Franz Kühmayer and energy expert

Prof. Karl Rose proclaimed unpleasant

truths in their keynote speeches, but

also spoke highly of our industry (our

report on Salzburg with a detailed

appraisal of the specialist presentations

in this issue). Thus, the speakers – neither

of whom were explicitly foundry

experts – stated in general business

terms that complaining does not help.

Credo: Entrepreneurs are called entrepreneurs

because they do something.

Rose was also not sparing in his criticism

of the political establishment in view of

the supposed deafness that medium-sized

businesses face from the political

establishment in the form of more and

more bureaucracy and a general deterioration

in framework conditions. „It‘s a

systemic issue. Only charismatic individuals

can change the system“.

However, both experts also emphasized

how great Europe is as a business

location despite all the criticism. Kühmayer

said: “Europe is an area that is

the envy of the world”. It is indeed a

community of values – key words are

democracy and human rights. Europe is

solidarity in action, legal certainty and

stability – with a social model in which

freedom and responsibility are in balance.

And the futurologist uttered

words that were balm to the soul of

every participant and could be the stuff

of image campaigns. “If you want to be

happy, go into the SME sector. This is

still fast, genuine entrepreneurship with

which you can achieve a lot. They are

speedboats, so to speak”.

The tenor of the two external

observers of our economy: the potential

is there and it is huge. It is up to the

individual entrepreneur to make the

most of it. Courage and dynamism,

openness to ideas and sometimes

uncomfortable employees – these are

the potentials. Seen in this light, the

conference has clearly strengthened the

industry.

Have a good read!

CASTING PLANT & TECHNOLOGY 2-3/2024 3

CONTENTS

FEATURES

10 ALUMINUM WHEELS

Sustainable and cost-efficient production

with secondary alloys

Promoting the sustainable production of aluminum

wheels is the aim of the SUPAWheel

research project.

Tobias Beyer, Robert Kleinhans

15 IRON CASTING

Experiences with innovative hot-air

curing binder

Heated mold boxes have proven their worth in

large-scale production. Hot air curing offers a

cheaper alternative that is also suitable for smaller

batches.

Hartmut Polzin, Theo Kooyers

20 SAND RECLAMATION

MAGNESIUM

Repair using laser

cladding.

STEEL MELTS

Clean steel casting

at ultra low pouring

tempertures.

Reclamation of used sand secures the

future of the site

The reclamation of used sand ensures greater

sustainability by increasing the recycling rate,

reducing the volume of transport and lowering

the CO 2

emissions.

Alexander Dornhöfer, Kevin Grebe

25 MAGNESIUM DIE CASTING

Additive manufacturing as a pioneering

repair technology

By using special alloys, repairs should be achieved

without a change in diameter, additionally leading

to a better wear resistance and an increasing

number of possible casting cycles.

Marie Bode, Gerhard Schoch

IRON CASTING

High-quality, inorganically

bonded cores

can also be produced

without a heated

core box.

4

CONTENTS

FEEDING

Thermal analysis

system for quantifying

different supply ranges.

28 FEEDING

Impact of modifier and grain refiner on

the feeding effectivity

First time under industrial conditions, operators

at the foundry floors will be capable to control the

impact of master alloys additions on the feeding

effectivity of cast aluminum alloys.

Olivier Dünkelmann, Mile B. Djurdjevic, Robin

Unland, Julian Schröter

36 STEEL MELTS

Clean steel castings at ultra low pouring

temperatures

This article describes a new technique for

improving the quality of steel melts in the ladle

prior to pouring.

David Hrabina. Colin Powell, Dalibor Čáp,

Milan Turták, Jiří Kolár

44 COMPANY

German ship propellers for the largest

ships in the world

Mecklenburger Metallguss is spcialized in the

large-scale production and international distribution

of ship propellers.

Christian Thieme

50 GGT 2024

”Salzburg has committed us“

GGT 2024 – an extremely successful event,

organized by the foundry associations of Austria,

Germany and Switzerland.

Kristina Krüger, Martin Vogt, Monika Wirth

COMPANY

MMG is confidently

looking to the future

and is expanding its

portfolio by introducing

new product

lines.

COLUMNS

3 EDITORIAL

6 NEWS IN BRIEF

59 SUPPLIERS GUIDE

65 FAIRS AND CONGRESSES/AD INDEX

66 PREVIEW/IMPRINT


NEWS

TEXMO BLANK

John Deere „Partner-level Supplier”

Texmo Blank was recognized as a “Partner-level

Supplier” for 2023 and inducted

into the “Supplier Hall of Fame” of

the John Deere Achieving Excellence

Program.

Hall of Fame status is awarded when a

supplier has achieved Partner status for

five consecutive years. Partner status is

Deere & Company’s highest supplier

rating. Employees of family-owned

Texmo Blank, which has exported investment

casting products around the world

for more than 60 years, accepted the

award during a ceremony on April 10

and 11 in East Moline, Illinois.

Suppliers participating in the Achieving

Excellence program are evaluated

annually in several key performance

categories, including quality, delivery,

process alignment, value creation and

business relationship. John Deere Supply

Management established the program

in 1991 to create a supplier evaluation

and feedback process that

promotes continuous improvement.

www.texmoblank.com

Texmo Blank earns recognition as a

John Deere Partner-level Supplier.

Would you like us to include your

press information in our News

section?

Then please send your reports to:

redaktion@bdguss.de

Photo: Texmo

BINDER JET 3D PRINTING

Now available with aluminum and titanium

Desktop Metall‘s P-1 production system,

which uses Single Pass Jetting

(SPJ) technology, is now offered with

an optional Reactive Safety Kit, which

also enables the safe 3D printing of

ultra-fine titanium and aluminum

powders.

The Desktop Metal Production System

P-1 is a binder jet 3D printing system

that is capable of processing 17 metals.

It features ATEX-rated components, as

well as critical hardware and software

updates to ensure the highest level of

safety. However, a Reactive Safety Kit is

required for printing titanium and aluminum.

“Titanium and aluminum are two of

the most frequently requested materials

at Desktop Metal, and we’re proud to

say that we can now offer a commercial

3D printer with the necessary safety

features to binder jet 3D print these

materials”, said Ric Fulop, Founder and

CEO of Desktop Metal.

www.desktopmetal.com

The Safety Kit enables 3D printing of ultra-fine titanium and aluminum powders.

Photo: Desktop Metal

6

Photo: James Durrans

The Carbon International Ltd. plant

in Sasolburg.

JAMES DURRANS GROUP

5th anniversary in South Africa

On March 18, the James Durrans Group

in Sasolburg celebrated the 5th anniversary

of its subsidiary Carbon International

Trading.

In South Africa, coal liquefaction plants

operated by the predominantly stateowned

company SASOL supply more

than 50 percent of the liquid fuels used

there. Among other things, these plants

produce green coke, i.e. coke that has

not been heat-treated or calcined. Carbon

International Ltd. calcines this

green wax coke using vertical shaft calcination

(VSK), which was developed in

Europe around 1920.

In order to avoid dependence on

China and generate jobs and income in

South Africa, the decision was made to

build a VSK plant in South Africa, which

began operations in 2019. The financing

of the project was supported by

the shareholders of the Durrans Group,

Christopher and Nicholas Durrans. An

anchor customer was also found in the

MAT Foundry Group. The advantages of

the product – low sulphur and nitrogen

values and high C-solubility – should

also convince other potential customers

such as automotive foundries. In order

to provide independent data, the

Foundry Institute at the Technical University

of Freiberg, Germany, headed by

Prof. Gotthard Wolf and Dr. Claudia

Dommaschk, carried out extensive research

and development work.

The plant was quickly able to

achieve its capacity utilization target

and today sells a diverse product portfolio

to various metallurgical industries

and specialty graphite producers (60 %

export, 40 % domestic). Although it

produces carbon, the resulting processes

and products make a significant contribution

to the decarbonization of the

industry. For example, only 200 kWh/t

of electricity is required to produce calcined

wax coke, but up to 3000 kWh/t is

needed to produce graphite suitable for

casting.

The company looks to the future

with confidence. A state-of-the-art

laboratory was put into operation at

the Sasolburg site in 2023. Here, test

series can be carried out to ensure that

a product meets the specifications

requested by the customer, e.g. the

determination of ash content and volatile

components using muffle furnaces,

the moisture content using a drying

oven, sulfur and nitrogen values using

equipment provided for this purpose

and the particle size distribution using a

mechanical sieving machine.

„The VSK plant is extremely energy

efficient and self-sufficient, as it does

not require external energy sources

such as electricity or gas to cover the

required heat demand. In addition, the

indirect heating of the green coke

material avoids the risk of burning off

finer material, which minimizes calcination

losses. The fines are not only not

burned but agglomerated, which

further increases the overall yield of calcined

coke and coarse sorting compared

to green coke feeding. ... The operation

currently produces no process waste

and much of the electricity consumed

by the plant is generated by our own

solar PV system“, explained Stefan Pfeffer,

Director of CI-Trading (Pty) Ltd. at

the anniversary celebration.

www.durransgroup.com


NEWS

CASTFAST FOR FOUNDRIES

Ultra-fast moulds on demand

German printed casting platform Castfast

is inviting foundries to experience

the many benefits of a patternless casting

process – without having to invest

in 3D sand printing equipment. Aluminum,

iron and steel foundries can

now buy 3D-printed molds directly

online and then pour them in-house.

Many foundries have already invested

in 3D sand printing to dramatically

speed up the production of castings –

especially one-offs, small series or

initial runs – by skipping the time-intensive

and expensive pattern making process.

For those foundries who don’t yet

have a 3D sand printer, Castfast is offering

the facility to order just the molds

and/or cores through the Castfast platform,

via a simple form with instant

quote and projected delivery date.

Initially set up to offer casting buyers

a better, faster, more digital way of procuring

high-quality castings, the Castfast

team have seen an unexpectedly high

volume of enquiries from foundries

interested in buying molds. Marcel

Tschillaev, Product Lead at CASTFAST,

explains: “Our mission at Castfast is to

accelerate the adoption of 3D sand printing

among small and medium-sized

foundries and revolutionize access to

great quality castings. The patternless

process enabled by sand printing is

exactly what the foundry industry needs

– and what casting buyers want. It

offers agility, flexibility and precision,

and allows us to digitize parts of the

foundry process that have never been

digitized before”.

DEBURRINGEXPO

Now part of the Parts Finishing

trade fair

DeburringEXPO will no longer be an independent event, but will be incorporated

into the new Parts Finishing trade fair, which will therefore be held for the first

time in Karlsruhe, Germany, on November 12 and 13, 2025.

The current changes in the economy and society are not without impact on the

trade fair landscape. „After many discussions with DeburringEXPO exhibitors and

intensive observation of the development of various trade fairs, we have decided

to no longer hold the trade fair for deburring technologies as a stand-alone

event“, reports Hartmut Herdin, Managing Director of the private trade fair organizer

fairXperts. „In future, the topic of deburring technologies will be bundled

together with the areas of component cleaning and surface finishing in the new,

two-day Parts Finishing trade fair“. As many companies interested in the trade

fair had already completed their trade fair planning, it was decided to postpone

the start of the new event by one year.

www.parts-finishing.de

ASK CHEMICALS GROUP

New CEO

On March 20, ASK Chemicals announced

that Luiz Totti is the new CEO of the

Group with immediate effect.

Luiz Totti has been with ASK Chemicals

for more than 11 years, having demonstrated

remarkable leadership and vision

during his tenure with the company. Prior

to his appointment as CEO, he held several

key positions within ASK Chemicals,

including Managing Director for South

America, Executive Vice President (EVP) Americas and EVP for Asia. His extensive

experience and successful track in these roles have been pivotal in expanding the

company‘s footprint and strengthening its competitive advantage in the global

marketplace.

Prior to joining ASK Chemicals, Luiz Totti worked for renowned companies

such as Akzo Nobel and PPG, where he held various leadership positions.

www.ask-chemicals.com

A sand mold from Castfast.

The printed casting process doesn’t

need a pattern. Sand molds are “printed”

by selectively binding layers of

sand. The mold is built up layer by layer,

based on a 3D print file that can be created

from drawings. The process is faster

than traditional methods with a permanent

pattern, and more precise than

and superior to other fast alternatives,

like full mold casting. The Castfast team

then works with the foundry to plan

the mold along with the gating system,

risers, any other mold parts they need.

The molds are then printed (currently in

Mainz, Germany) and shipped for pouring.

Foundries interested in buying a

mold or cores can securely upload a 3D

drawing of the required part or simply

give the rough dimensions to get an

instant cost indication and delivery time

frame and start the order.

www.castfast.de

Photo: Castfast

8

PERFECTION IN EVERY SINGLE MOULD

Innovative Moulding and Casting Technologies from HWS

• SEIATSU Moulding

Machines and Plants

• Flaskless Moulding


• Vacuum Moulding


• Pouring Units, semi

and fully automatic

• Low-Pressure Die Casting Machines

• Gravity Die Tilt Casting Machine

• Mechanical Sand Reclaimer

• Software for Foundries

•

Pouring Machine

FVN

•

Molding Machine

FBMX

www.sinto.com

HEINRICH WAGNER SINTO Maschinenfabrik GmbH

SINTOKOGIO GROUP

Bahnhofstr. 101 · 57334 Bad Laasphe, Germany

Tel +49 2752 / 907 0 · Fax +49 2752 / 907 280 · www.wagner-sinto.de

ALUMINUM WHEELS

Photo: Fotolia

Joint project SUPA-Wheel for aluminum wheels

Sustainable and cost-efficient

production with secondary alloys

Promoting the sustainable production of aluminum wheels is the aim of the SUPA-

Wheel (Sustainable Production of Aluminum Wheels) research project. For the joint

project at the Dortmund University of Applied Sciences, the companies Borbet GmbH,

Trimet Aluminium SE, Jordan Spritzgusstechnik and the Fraunhofer Institute for Foundry,

Composite and Processing Technology (IGCV) have joined forces to develop a wheel that

meets the technical, economic and ecological requirements of manufacturers for different

drive systems.

By Tobias Beyer, Robert Kleinhans

To this end, the partners are developing

a cross-industry and

cross-material development and

design methodology with which the

carbon footprint of a product can be

calculated at the beginning and during

the product development process and

optimized if necessary. CO 2

emissions

are to be reduced and, where possible,

avoided. SUPA-Wheel was launched at

the beginning of 2023 and should be

completed by the end of 2025.

Use of recycled materials

The use of single-origin recycled material

can significantly improve the carbon

footprint of aluminum wheels, for

example if only used wheels from the

same manufacturer are used in production.

What seems like an ideal material

cycle, however, reduces the potential of

recycling rates and hardly allows for

dynamic development. A better option

is to also make aluminum scrap available

for use outside the specific product

cycle. This requires the recycling material

to be sorted in advance using laserbased

spectroscopic online measurement

processes. This is because the use

of any recycling material without prior

spectroscopic sorting influences the

properties of the aluminum and thus

the characteristic values. For this reason,

the recycling process at the wheel manufacturer

and the aluminum supplier

must be considered separately and in

combination. The aim here is to select

10

Tabelle 1: Alloy compositions of pre-alloyed A365 (AlSi7Mg0.3) and four derivatives based on it.

Alloy Si [wt.%] Fe [wt.%] Cu [wt.%] Mn [wt.%] Mg [wt.%] Zn [wt.%] Others [wt.%]

300-0140 7.18 0.11 0.01 0.03 0.30 0.01 92.36

300-0141 7.17 0.15 0.05 0.05 0.31 0.09 92.18

300-0142 7.18 0.35 0.09 0.09 0.30 0.09 91.90

300-0143 7.22 0.35 0.15 0.14 0.31 0.14 91.69

300-0144 7.27 0.52 0.29 0.28 0.31 0.30 91.03

the optimum solution that takes into

account CO 2

emissions as well as material

requirements and costs.

Wheel design is a key factor influencing

the optimum material design. At

the same time, the design depends on

the material properties. For example,

the material composition can change

the strength. An adapted wheel design

can compensate for this effect, but may

lead to an increase in wheel mass,

which increases the amount of material

used and therefore fuel consumption

during operation. The consequence

would be increased rather than reduced

CO 2

emissions. It is therefore also

important to find a compromise here

that avoids effects in the production

processes that cause CO 2

emissions.

Changes to the material composition

can affect the manufacturing temperatures

and times, the casting temperature

and solidification time, the temperature

and duration of solution

annealing and heat treatment. Such

changes to the process affect CO 2

emissions

and thus life cycle emissions, the

minimization of which is the goal of

optimization. The research project

examines these different aspects as a

multidimensional influence matrix with

regard to the best combination.

Making life cycle analysis usable for

product development

Minimizing CO 2

emissions over the

entire life cycle from development and

production through the use phase to

recycling, is a social concern and a

requirement of car manufacturers. This

is why the project not only focuses on

the CO 2

emissions in the life cycle of the

wheel to be developed, but also integrates

the life cycle analysis (LCA) into

the development process. This means

that the LCA can also be incorporated

into future product development. In

addition to the process, the project

partners also want to develop an

LCA-optimized recycling material for

cast alloys (for example by recycling

end-of-life scrap) that offers optimal

material characteristics for a heavily

loaded component with high demands

Fig. 1: Sample geometry

on surface quality and acoustic properties.

Trimet is responsible for the development,

characterization and production

of recyclable materials and recycled

material-based materials for the production

of wheels using the low-pressure

casting process (LP casting).

Using a DoE-based development

methodology, equilibrium, microstructure

and property simulations, laboratory

casts and specific heat treatments

are evaluated. Subsequent property

Competence in

Shot Blast Technology

As a full-range supplier, we design and manufacture

shot blasting machines including filter and

transport technology.

➜ New shot blast machines

➜ Service and spare parts

➜ Inspection & consulting

AGTOS | GmbH | D-48282 Emsdetten

info@agtos.de | www.agtos.com

➜ Second hand machines

➜ Reparation & maintenance

➜ Performance improvement

412-07/24-4c-GB



PHOTOS and GRAPHICS: Trimet, Fraunhofer IGCV

Fig. 2: Microstructural properties for the F and T6 state of 300-0140.

Fig. 3: Microstructural properties for the F and T6 state of 300-0144.

Fig. 4: Yield and tensile strength.

screening makes it possible to iteratively

approach the alloy that optimally

meets the requirements. In addition to

appropriate pre-treatment and cleaning

measures for the material, the various

development alloys are melted and

the maximum possible proportion of

recycled material is determined. In

addition, Trimet investigates alloying

measures in order to map the required

property profile. Trimet then produces

the most promising alloys on a preseries

and production scale using continuous

casting. The project partners

then process the alloys further on the

corresponding scale using LP casting.

The overarching aim of the sub-project

is to gain a fundamental understanding

of the relevant interactions

between process parameters and their

effects on the technological properties

12

Fig. 5: Brinell hardness and elongation at break.

of the secondary materials along the

entire process chain.

In order to prove the suitability of

scrap material especially for low-pressure

cast wheels in particular, Trimet

and the Fraunhofer IGCV have investigated

defined alloy compositions. The

aim was to understand the effect of

increased concentrations of previously

undesirable alloying elements. The

influence of increased amounts of Fe,

Cu and Zn was evaluated with particular

consideration of phase formation.

The design of the alloys was based on

the recommendations for compensating

for undesirable side effects caused by

the alloying elements introduced. The

aim was to achieve an Fe:Mn ratio of

2:1 [1]; while at the same time taking

into account J. A. Taylor’s recommendations

on the critical Fe content for AlSibased

alloys [2]. A combined approach

of thermodynamic calculation, microstructural

investigation and mechanical

testing was used to demonstrate the

suitability and at the same time reveal

the microstructural origins of the

observed effects. The test results provide

initial answers to the question of

whether targeted heat treatment can

compensate for the formation of harmful

phases.

Pre-alloyed A365 (AlSi7Mg0.3) and

four derivatives based on it were produced

by permanent mold casting with

different compositions (table 1). Samples

for static tensile tests (shape B6x30

according to DIN 50125, manufactured

by CNC turning) and samples for microscopic

analyses (height 15 mm, diameter

20 mm) were taken from cast rods (fig.

1). The samples were examined in the

as-cast state (F) and in the heat-treated

state (T6). On the basis of the light

microscopic examination, the greatest

differences were found between the

low-alloy variant 300-0140 and the

high-alloy variant 300-0144. The microstructural

properties for the F and T6

condition of 300-0140 (fig. 2) show a

typical cast microstructure with a finely

distributed Al-Si eutectic between the

dendrites. It seems that only one dominant

Fe-rich phase can be detected in

the form of the Mg-rich π-phase.

Cu-rich and Zn-rich phases were not

detected. In the T6 state, a more homogeneous

structure with incorporated Si

particles is recognizable. The π-phase

can no longer be found, but small

b-phase networks are present. Cu- and

Zn-rich phases were also not detected in

this state.

In the alloy variant 300-0144 (fig. 3),

the eutectic region of the material in

the F-state appears to be dominated by

larger a- or b-phase platelets, in contrast

to 300-0140. The Al-Si eutectic

appears to have a similar structure, but

with a lower overall phase fraction. It

Expertise for more

than 50 years

IROPA Elektrotechnik GmbH

Bergiusstr. 2a

D-46244 Bottrop

was found that the π-phase has a lower

phase fraction than the other Fe phases

and is not as dominant as in variant

300-0140. In addition, there is also evidence

of Cu phases, which are Thetaphases.

They are surrounded by a fringe

that can be identified as a Theta-phase

in terms of composition. Zn-rich phases

were not detected. Compared to the

as-cast state, a homogeneous distribution

of Mg, Cu and Zn can be seen in

the T6 state. This indicates that the

phases containing Mg and Cu have dissolved.

There are still recognizable a-

and b-phases, some of which occur in

combination with Cu. However, the

b-phases present appear to be less

affected by the homogenization.

Iron affects the mechanical

properties

The tests also provided information

about the mechanical properties. The

added alloying elements cause an

Automation technology

Data technology System software

Automation technology for foundries and mechanical engineering

Conversion from Siemens S5 -> S7 / TIA

Plant visualisation

Fault data acquisition and evaluation, BDE, SQL databases

P: +49 (0) 2045/89 07 0 eMail info@iropa.de

F: +49 (0) 2045/89 07 77 www.iropa.de



Fig. 6: Ductility.

increase in the yield strength R p0.2

and

tensile strength R m

in the as-cast state

(fig. 4). This behavior does not occur in

the T6 condition. A similar behavior of

the alloy variants can also be observed

in the results of the Brinell hardness

measurement (fig. 5). In the as-cast condition,

the elongation at break is halved

from just under 15 % in the base alloy

to 8 % in the high-alloy variant. Similar

behavior can be observed for the T6

condition, with the values determined

falling from an initial 9 % to 4 %.

Regardless of the alloy variant, HBW,

R p0.2

and R m

remain almost unaffected

in the T6 state, but the characteristic

values in the F state increase slightly

with increasing Fe content. Fe has the

greatest influence on A in both the F

and T6 states. An Fe:Mn ratio of 2:1

could not convert the majority of

b-phases into a-phases, as recommended

in the literature [1]. Following

Taylor [2], a critical Fe content of 0.475

wt.% can be determined for the present

AlSi7Mg0.3 alloy. Taylor describes

this limit as the point at which the

b-phase forms before the fcc-Al solid

solution, which can lead to uncontrolled

growth of Fe-rich phases. Especially

in 300-0144, whose Fe content is

above the limit suggested by Taylor, it

seems hardly possible to distinguish the

b- and a-phases on the basis of microscopic

shape alone. This raises the question

of whether the limits of Mn for the

conversion of b-phases into a-phases

have been reached.

The T6 process used is suitable for

most of the samples examined, but can

still be optimized. Adaptation is particularly

necessary to ensure that a material

such as 300-0144 also has a microstructure

that leads to higher elongation.

Other well-known microstructural

mechanisms such as the rounding of Si

particles and the dissolution of Cu-rich

phases can be achieved with the

selected T6 process regardless of the

alloy variant. Finally, the increased Zn

appears to have only a negligible effect

on the mechanical properties and does

not form any harmful phases. The

investigations carried out have confirmed

that Fe has a major influence on

the mechanical properties. The ductility

in particular decreases with increasing

Fe content (fig. 6). The influence of Cu

and Zn is low compared to Fe. This is

particularly important in view of the

increasing use of scrap material with

higher Fe concentrations for the production

of primary alloys as scrap-based

alloys.

Outlook

The knowledge gained forms the basis

for the iterative production of further

diverse secondary alloys on a laboratory

scale, which also target the combination

of parameters in the manufacturing

process. These include melt purification

measures and adjustable recycling

content as well as the use of additional

alloying elements to optimize or compensate

for material properties.

Homogenization and heat treatment

parameters are also being developed.

Around 30 iteration steps are planned

in the calculation. All the variants produced

are then compared and checked

again for their suitability for the continuation

of the project. In addition to

hardness measurement, microstructural

analysis, static tensile testing and other

assessment methods, dynamic material

tests will also be carried out. Further

project steps include the testing of optical

properties as well as casting properties

(Sipp casting spiral, star mold) and

corrosion properties. The aim is to produce

a low-pressure casting mold for

the demonstrator, cast the demonstrator

taking into account the production

parameters and then produce the

wheels on a pre-series scale.

The finished prototype then undergoes

a durability test and modal analysis

on the test bench and is put through

its paces on a test track.

The authors would like to thank the

Federal Ministry for Economic Affairs

and Climate Protection, which is financially

supporting the research activities

as part of the SUPA-Wheel project

(03LB2054) through a resolution of the

German Bundestag.

www.trimet.eu/en,

www.igcv.fraunhofer.de/en

Tobias Beyer, Deputy Head of Research

& Development, TRIMET Aluminium SE,

Robert Kleinhans, Research Associate,

Fraunhofer IGCV

References

[1] F. Ostermann (2014), Anwendungstechnologie

Aluminium, 3rd edition,

Springer Vieweg, Berlin, p 437-440

[2] J. A. Taylor (2004), The effect of iron

in Al-Si casting alloys, In 35th Australian

foundry institute national conference,

Casting Concepts, p 148-157

14

IRON CASTING

Photos and Graphics: Peak

High-quality, inorganically bonded cores can also be produced without a heated core box.

Inorganics for iron casting

Experiences with innovative

hot-air curing binder

Water glass-bonded molding materials can achieve the strength levels required of inorganic

binder systems through hot air gassing. Heated mold boxes have proven their

worth in large-scale production. Hot air curing offers a cheaper alternative that is also

suitable for smaller batches.

By Hartmut Polzin and Theo Kooyers

Starting at GIFA 2003, various

binder manufacturers presented

work on the development of new

heat-curing inorganic binder systems,

which is still ongoing today. The basis

for these developments was the wellknown

fact that water glass-bonded

molding materials can be brought to

significantly higher strengths with tempered

molding tools than, for example,

with classic carbon dioxide gassing.

These high strengths were a fundamental

requirement for inorganic

binder systems, as one of the main

impulses for this development came

from the automotive industry and thus

from the large-scale production of

sometimes highly complex and filigree

cores for vehicle components. This

paper reports on a hot-air-curing inorganic

core production process that

works without an actively heated core

production tool [1].


IRON CASTING

State of the art

The current state of the art is still that a

silicate-based binder system is usually

mixed with the mold base material and

shot into a steel core-making tool tempered

to 160 - 200 °C, in which a stable

edge shell is formed. The cycle times can

be brought into acceptable ranges by

combining this process with hot air gassing.

The main disadvantage of these

processes is that they can only be used

in large-scale core production (usually in

automotive casting) due to the high

tool and energy costs. In addition, the

application is limited to the production

of aluminum castings due to various

inadequate technological properties

(e.g. residual strength/decomposition

behavior). A still largely valid overview

of these processes can be found in [2].

Hot air-curing inorganic cores

The development of the binder system

presented is intended to provide iron

foundries, which in many cases are customer

foundries with frequently changing

product ranges and batch sizes,

with an opportunity to use inorganically

bonded cores. The key aspect here

is the elimination of an expensive

heated steel core production tool,

which can only be justified in largescale

production. The binder system

used is an alkali silicate or water glassbased

binder that has been modified

with a whole range of oxides and does

not contain any organic components

[3]. The molding material is solidified

exclusively by gassing with air at

approx. 160 °C. The binder is a

one-component binder that can be

dosed without additional additives in

ranges of less than 2.5 %, in many cases

less than 2 %.

Practical experience

Molding material strengths

in comparison

Figure 1 compares the flexural strengths

of the binder system with those of

three other commercially available inorganic

binders (labeled B1 to B3). An initial

difference becomes clear in the

binder contents used, as with these

binders the binder itself and at least

one additive must be considered as the

total binder content. Furthermore, the

comparison systems are exclusively

warm box systems. The process parameters

of the Peak CC-VC system were as

follows: 150 °C curing air temperature,

curing time 45 s, sand temperature 23

°C, relative humidity 45 %.

a

Flexural strengths 150°C in MPa

4

3,5

3,41

3,41

3,26

3,4

3,37

3

2,78

2,86 2,73 2,71

2,56

2,54

2,5

2,29

2

1,64

1,45

1,5

1,41

1,15

1,03

1

0,62

0,61

1,18

0,5

0

B1 3,3% B2 3,4% B3 3,3% Peak 2,3%

immediately 1d 2d 3d 1dfeucht

b

Specific flexural strengths 150°C in MPa

1,4

1,2

1

0,8

0,6

0,4

0,2

0

1,19

1,18


1 1,03

0,96


1

0,78

0,84

0,87

0,75

0,44 0,48 0,43 0,45

0,51

0,34

0,19

0,18

B1 3,3% B2 3,4%

B3 3,3%i

Peak 2,3%


Fig. 1: CC-VC binder system compared with other inorganic systems, curing temperature

150 °C: a) flexural strengths, b) specific flexural strengths.

a

Flexural strengths 200°C in MPa

5

4,4

4,5

4,28 4,17

3,9

4

3,67

3,5

3,5

3,24 3,02

2,85 2,89

2,86 2,78

3

2,66

2,69

2,62

2,5

2,4

2 1,73 1,63 1,71

1,5

1

0,87

0,5

0

B1 3,3% B2 3,4% B3 3,3% Peak 2,3%


b

Specific flexural strengths 200°C in MPa

1,4

1,16

1,2

1,13


1,1 1,071,05

0,97


1 0,92

0,92

0,83 0,77

0,8

0,75 0,74

0,75

0,69

0,6

0,45 0,42

0,45

0,4

0,33

0,2

0

B1 3,3% B2 3,4% B3 3,3%

Peak 2,3%


Fig. 2: CC-VC binder system compared with other inorganic systems, curing temperature

200 °C: a) flexural strengths, specific flexural strengths.

16

a

3

2,5

2

1,5

1

0,5

0

b

2,5

2

1,5

1

0,5

0

c

2,5

2

1,5

Flexural strengths 1,75 % VC vs. temperature

2,53

2,41

2,3

2,05 2,05

2,05

2,011,98

2,04

2,14

1,85

1,75 1,7 1,68 1,66 1,65

1,62 1,59

1,45 1,46

160°C 120°C 100°C 80°C 60°C

immediately 1d 2d 3d

Flexural strengths 1,75 % VC-HR vs. temperatue

1,98

1,87 1,92 1,77

1,81

1,86

1,811,77 1,69

1,75

1,73 1,85

1,75

1,65

2,09

2,07

1,97

1,75

1,56

1

160°C 120°C 100°C 80°C 60°C


Flexural strengths 1,75 % VC-CB vs. temperature

2,18

2,17 2,21

1,73

1,83

1,87

1,75 1,76 1,82 1,72

1,91

1,79

1,61

1,71 1,77

1,69

1,77

1,56

1,35

which achieves the significantly

higher specific strengths determined

after one day.

In principle, it is assumed that the

strengths also increase when higher

temperatures are used. Figure 2 shows

this for a temperature of 200 °C (again

core box or gassing temperature). An

increase in strength actually only results

for binders B1 and B3; the strengths of

the Peak system remain approximately

the same. This is interesting for determining

the optimum gassing temperature

in terms of cost and environmental

protection. When cores are stored in a

humid environment, the advantage of a

higher hardening temperature is clearly

evident. Binder B3 has the better values

for specific strengths.

Influence of the gassing temperature

As the temperature of the curing air is a

cost factor, tests were carried out to

vary the air temperature for gassing

and curing. Figure 3 shows the results

of these tests for three binder systems.

The binder labeled VC is the initial system,

while VC-HR and VC-CB are binders

designed for special applications.

The following parameters were used in

this series of tests:

> Gassing temperature 160 °C to 60 °C

in five stages,

> Gassing time 60 s,

> Sand temperature 25 °C,

> Silica sand QQs 26,

> relative humidity 45 %.

1

0,5

0

Fig. 3: Flexural strengths in MPa at different curing temperatures, binder content 1.75 %:

a) CC-VC binder, b) CC-VC-HR binder, c) CC-VC-CB binder.

The strengths were determined immediately

and after 1 to 3 days. The test conditions

for the “1d wet” values were 25 °C

and 75 % relative humidity. For binders

B1 to B3, the temperature refers to the

core box temperature. The strengths

achieved speak for themselves:

> All binders experience increases in

strength during the first few days of

storage under normal conditions,

which can be attributed to progressive

drying.

0,92

160°C 120°C 100°C 80°C 60°C


> Two of the comparison systems react

more sensitively to storage in a

damp environment.

> The strengths of the peak binder system

are lower than those of the

other systems, which is due to the

lower binder content. These values

could be increased by adding more

binder if necessary, but the strengths

shown here are sufficient for many

applications. The potential of the

system becomes clear in fig. 1b,

Figure 3 shows that usable results can

be achieved up to a gassing temperature

of 60 °C, with a few exceptions.

The very low binder content of 1.75 %

is also interesting at this point! The reason

for this behavior lies in the use of

very dry air for gassing the test specimens.

As a result, a satisfactory removal

of water and water vapor from the core

during curing can be achieved even at

lower temperatures. These correlations

will be examined in more detail in the

near future.

Decoring behavior and residual

strength

One of the “classic disadvantages” of

water glass binder systems known from

the literature is the high residual

strength of cores or molds after pouring,

combined with a high decoring

effort. Last but not least, this disadvantage

was a decisive factor in the sharp

decline in process shares from around

the 1970s. The aim of the development


IRON CASTING

a b c

Fig. 4: a) Core for brake disk, approx. 15 kg, b) cast brake disk made of cast iron, inorganic core, sand adhesions, c) cast brake disk made

of cast iron, PUR cold box core.

of modern inorganic binder systems

must therefore be to improve the

decoring behavior in addition to other

properties. As the binder system presented

here was developed especially

for use in iron and steel casting, particular

attention had to be paid to this

point. To this end, casting tests were

carried out in an iron foundry in which

coated and uncoated test cores (fig. 4a)

were used to cast a ventilated brake

disk made of cast iron with lamellar

graphite (core mass approx. 15 kg). The

standard PUR cold box cores were used

for comparison.

First of all, it should be noted that

there were no clear differences

between coated and uncoated cores.

Visual observation of the disintegration

and decoring behavior showed that the

channels of the castings in the inorganic

cores were filled with mold material

adhesions, which was not the case with

the cold box cores (fig. 4b, c). After the

normal sandblasting process, however,

these sand deposits were also completely

removed. The other cores in this

series were fed into production as normal

and did not give rise to any complaints.

During the evaluation of the castings,

one advantage of the inorganic

binder systems based on water glass

that should not be underestimated

became clear: the extensive absence of

veining. This molding material expansion

defect, which is particularly typical

for the PUR cold box process, only

occurs to a very small extent with water

glass-based binder systems due to the

thermoplastic bonding present there

and with special casting ranges (fig. 5).

Fig. 5: Cast part from Fig. 4 after blasting: a) inorganic core without veining, b) PUR

Cold Box core with veining.

Residual flexural strength N/cm 2 VC 2%

200

180

180

160

140

130

120

100

80

60

40

20

9

0

0

RT 200°C 400°C 800°C

Fig. 6: Residual flexural strength at different annealing temperatures.

Fig. 7: Inorganically

bonded

core package

cores for iron

casting.

18

Fig. 8: Inorganically bonded intake manifold

cores for non-ferrous casting.

In order to substantiate this subjectively

positive behavior with figures, the

decoring behavior should be evaluated

on the basis of the residual bending

strength:

> For this purpose, bending bars were

produced which were exposed to

the test temperature for 5 min 24 h

after production and tested 2 h after

removal from the furnace.

> The test temperatures were 200, 400

and 800 °C.

The results shown in figure 6 confirm

the positive properties already evident

from the casting tests in this direction.

The test temperature of 400 °C is

intended to represent the trend in the

area of aluminum casting, while the

temperature of 800 °C stands for iron

casting. It can be concluded from this

that the inorganic binder system presented

exhibits decomposition and

decoring behavior similar to the PUR

cold box process.

Examples from practice

To date, cores with the inorganic binder

system presented have been produced

and successfully used in a whole series

of foundries. The cores shown in figure

7 are exemplary for the field of iron

casting. The range extends from outer

cores for core packages to the aforementioned

brake disk core and the filigree

core for valve casting. The area of

non-ferrous casting, which has not

been the focus of this article so far, is

impressively illustrated by the example

shown in figure 8. Here, too, the range

of possible applications extends from

simple cores, e.g. for intake manifolds,

to the highly complex core of a cylinder

head. The examples shown are

used in the areas of copper and aluminum

casting.

Summary

The presented inorganic binder system

based on water glass is an alternative to

the PUR cold box process that can be

used in iron and steel casting. The liquid

one-component binder is dosed less

than comparable binder systems: the

binder quantities used to date are

between 1.5 and 2.5 %, but can also

be increased if required.

The single-component system facilitates

binder dosing on the core

shooter, and the desired strengths are

ensured by comparably higher specific

strengths. The curing of the manufactured

cores takes place via 160 °C

warm gassing air. The core production

tool is not heated. When selecting the

core box material, care should be

taken to use thermally resistant plastics.

Core boxes made of metal (aluminum

or steel) offer advantages in terms

of shorter cycle times.

If particularly dry air is used, curing

can be achieved at lower temperatures.

The binder system can of course also be

used in the warm or hot box process.

The fact that veining only occurs in

exceptional cases with the inorganically

bonded cores is certainly a welcome

advantage in the fettling shop.

The residual strength and decoring

behavior is very similar to that of the

PUR cold box process. In addition to the

binders designed for iron and steel casting,

variants for aluminum or copper

casting are also available.

www.peak-giesserei.de

Prof. Dr.-Ing. habil. Hartmut Polzin,

Dr.-Ing. Theo Kooyers, Peak Deutschland

GmbH, Nossen

References

[1] Polzin, H., Kooyers, T.: Anorganisches

Kernbindersystem für den Eisenguss –

ein neuer Ansatz, GIESSEREI 105, 2018,

Nr. 10, S. 70-75.

[2] Polzin, H.: Anorganische Binder zur

Form- und Kernherstellung in der

Gießerei. Fachverlag Schiele & Schön

Berlin, 2012

[3] Europäisches Patent Nr. 2916976 –

Verfahren zur Herstellung von verlorenen

Kernen oder Formteilen zur

Gussteilproduktion.

RUDOLF UHLEN GmbH

Face protection for every application

Rudolf Uhlen GmbH is a manufacturer of personal protective

equipment (PPE) for face protection. Especially for the steel

and foundry industry we provide special solutions in the field

of IR-protection. We produce:

Ÿ Visor Carriers

Ÿ Gold-coated visors

Ÿ Mesh visors

Ÿ PC-visors

Ÿ Bochumer Brillen

Ÿ Flip-up goggles

RUDOLF UHLEN GmbH Telefon: (02129) 1444

Am Höfgen 13 - 42781 Haan Telefax: (02129) 59980

www.aschua-uhlen.de info@aschua-uhlen.de


SAND RECLAMATION

HEINRICH WAGNER SINTO

The reuse of foundry sand contributes to the circular economy and saves costs.

Trendsetting

Reclamation of used sand

secures the future of the site

The disposal and landfilling of foundry sand are causing steadily rising costs. Reducing

the quantities of used sand and reusing it in the material cycle – a core competence of

the foundry industry – are more important today than ever before. In this context, the

use of used sand as a recyclable material is the logical extension of internal recycling

management. It offers opportunities for improving economic efficiency and conserving

natural resources. The reclamation of used sand contributes to the long-term security of

the site, ensures greater sustainability by increasing the recycling rate, reducing the

volume of transport and lowering the CO 2

emissions.

By Alexander Dornhöfer and Kevin Grebe

20

Heinrich Wagner Sinto Maschinenfabrik

GmbH (HWS) is one of the

leading international suppliers

of machinery and equipment for the

foundry industry and part of the Sintokogio

group of companies with its headquarter

in Japan. The company employs

more than 300 skilled workers at its site

in Germany, Bad Laasphe. The focus is

on the manufacture and sale of molding

machines and molding plants as

well as pouring units for sand and die

casting. The portfolio is supplemented

by machines and plants for the mechanical

reclamation of used sands in green

sand foundries.

With its own regeneration processes

and a technical center, HWS offers a

comprehensive service to master the

topic of sand reclamation. This improves

sustainability and contributes to the

long-term security of the foundry site.

The question is not if we are able and

willing to reclaim, but when we start.

There is a consensus that the disposal of

one of the world’s most used and valuable

resources, sand, is not a sustainable

model.

Introduction to sand reclamation

The reclamation of molding material

serves to break down and remove the

binder shells and other non-sand constituents

in order to obtain a reusable

basic molding material [1]. The target

is to use this basic molding material

(reclaimed) as a substitute of new sand,

mostly in core production. In a green

sand foundry, it can be assumed that

the used sand has to be reclaimed in

most cases as a mixture of bentonite-bonded

molding sand and organically

bonded core sand (cold-box).

More diverse than the number of

processes are the properties of the specific

used sand to be reclaimed, which

usually varies from foundry to foundry.

The appropriate solution should ideally

be sought in close coordination with

the machine and binder suppliers. An

optimum design of the overall process

can only be made after determining the

initial situation and the planned reuse

of the reclaim. Further consideration

here will concentrate on mechanical

reclamation. Unless explicitly stated

otherwise, the term “reclamation” in

the following always refers to mechanical

reclamation.

Mechanical sand reclamation

The reclamation of used sand must

always be regarded as an interlinked

overall process. This consists of several

Sand

Grain

Binder

Oolitics

Used sand

Reuse

reclaimed sand

Separate dust

Fig. 1: Reclamation process USR-II.

Dust collection

Dedusting

Rotation and

pressurizing

Reclaimed.sand

Pressure

Fig. 2: Workflow and machine overview USR-II.

stations for sand pre-treatment and

sand post-treatment as well as the

cleaning process on the sand grains

themselves. The correct ratio of the

degree of reclamation (reduction of the

signal components compared to the

used sand) and the reclaim output

(ratio of reclaim to used sand quantity)

should be observed [2]. For the economic

operation of a sand reclamation

plant, the following applies in a simplified

way: “Reclaim as clean as necessary

and output as high as possible!”.

Rubbing from

grain to grain

Dust

Blower

bite 5t/h

Remove

foreign

material

Reclaimed sand

Air

Sand

Depending on the reuse case, an associated

reclaim aftertreatment ensures

compliance with further target parameters,

such as the target temperature,

which are not directly set by the reclamation

unit.

Mechanical reclamation by

friction – USR-II

Sand

Grain

Vibrating

feeder

Reclamation

unit

Pressurize

cylinders

Fluidized

bed

The HWS sand reclamation unit type

USR-II (Ultra Sand Reclaimer) with a

processing capacity of up to 5 t of used

sand per hour forms the core compo-



Used sand

1. pass

The connected dedusting system separates

the fine particles from the

reclaimed material of the sand-dust

mixture separated by the fluid bed. The

sand grains are transported via the fluid

bed as reclaim to the machine outlet. In

a green sand reclamation process, this

process or pass is typically repeated two

to four times, depending on the target

properties, in order to achieve the

required reclaim quality. With the right

process steps, this continuous flow process

can successfully reuse green sandcore

sand mixtures in distributions of up

to 100 % in each case.

HWS test plant for sand

reclamation

2. pass 3. pass

Fig. 3: Pictures of used sand and reclaimed material.

Table 1: Criterion and effects Cold-Box [3].

Cold-Box-Process

Effects on

Criterion Change Binder Processing Molding

requirement time strength

Water Content – –

Loss of ignition –

Sediment Content ()

pH-Value –

pH-Value – () ()

Acid consumption –

Acid consumption – () ()

Oolitization

Average grain size – ()

(at constant

uniformity level)

nent of a HWS reclamation plant for

green sand foundries. It provides efficient

cleaning based on a friction process

with high flexibility with regard to

used sand composition and quantity.

The process can be individually adjusted

with a view to high reclaim yield (ratio

of input quantity to output quantity)

for both easy and demanding used

sands to be reclaimed. An important

feature is the gentle friction from grain

to grain, without additional friction

tools (fig. 1). This largely avoids grain

breakage and keeps wear on the sand

grain low.

For grain cleaning, a ceramic-lined

rotary drum is rotated by an electric

motor via V-belt. The used foundry sand

is continuously fed to the drum by

means of a vibrating feeder (fig. 2).

Pneumatic press cylinders apply pressure

on the sand layer between the rolls

and the drum via the press rolls. The

resulting relative movement of the sand

grains among themselves ensures that

the binder shells are rubbed off, which

are then present as dust in the reclaim.

The use of ceramic components ensures

a long service life of the components

that come into contact with the rubbing

sand. Uniformly flowing material

displaces the sand already reclaimed

and the binder residues from the rotary

drum.

The generated sand-dust mixture

falls onto the fluid bed in the lower

part of the machine and is transported

by it to the integrated classifier (fig. 2).

In its in-house test plant, HWS provides

interested foundries the opportunity to

convince themselves of the efficiency of

used sand reclamation. With the USR-II

machine in a near-series design, reclamation

tests can be carried out under

conditions that are similar to production.

The focus here is on determining

the suitability for reclamation and the

process parameters for the conceptual

design of an overall plant. The following

explanations show a representative

excerpt from reclamation trials already

carried out with a customer foundry. In

addition to the use in the core shop,

where large quantities of new sand are

processed, the reclaim can also serve as

a substitute of new sand in the green

sand system of sand preparation.

Example 1 – Green sand foundry

with < 10-20 % cold-box core sand

Use of the reclaim material: Sand for

core shop as a proportional substitute

of new sand (cold-box process). Figure 3

shows a sequence of pictures with sand

grains (light microscope 200x magnification)

of the different passes. Here, the

increasing cleaning can be seen. After

three reclamation passes already, the

target values for the application case of

the reclaim could be achieved.

The test had four passes, in the last

pass only a slightly improved degree of

cleaning was achieved (results in higher

efficiency in fig. 4). In this case, three

passes will be planned only because the

necessary quality will be achieved and

also to simplify the plant concept,

reduce dust quantity for disposal and

operating costs of the overall plant. It is

important to reclaim only as much as

necessary, not as much as possible. In

this way, economical operation of the

reclamation plant is achieved.

Empirical values show a trend

22

[%]

4.0

3.5

3.0

2.5

2.0

1.5

1.0

0.5

0

3.51

1.29

0.66

0.47 0.36

used sand

1. pass

2. pass

3. pass

4. pass

[%]

100

90

80

70

60

50

93.7 94.8 95.6

88.7 88.7

83.2

78.8

75.4

1. pass 2. pass 3. pass 4. pass

overall efficiency % efficiency per pass %

Fig. 4: Loss on ignition (left), efficiency (right).

towards reusability at a determined loss

on ignition in the range of less than or

equal to 0.5 %. However, this value alone

is only an initial indicator. It must be supported

by corresponding laboratory tests

on further criteria from table 1. The final

reusability must be verified in each individual

case based on the target specifications.

The loss on ignition decreases in percentage

terms with increasing number

of passes and increasing degree of

cleaning. As less and less foreign material

is present on the surface of the sand

grain, the amount of removed foreign

material on the sand grains decreases

and the efficiency increases. In addition

to the degree of cleaning, the fines content

in the reclaim is a significant value

for determining the usability of the

reclaim, which means that the dedusting

or screening of the material produced

plays a decisive role. More

important criteria (sand properties) and

their effects on the use in the cold-box

process can be taken from table 1, so

that they are not further addressed

here.

The mentioned example with the

extract from test series clearly show

that the molding materials of the

respective foundry are to be considered

individually. In particular, the suitability

for reclamation of the material has to

be examined depending on the defined

target specifications. The evaluation

and interpretation of all data between

process suppliers and foundry forms the

basis of a customized overall concept.

Example 2 – Kovis Group – sand

reclamation

The Slovenian foundry Kovis-livarna

d.o.o. decided to invest in a mechanical

reclamation system from HWS for the

TAILOR-MADE

SOLUTIONS

Turn-key supplier for no bake-foundries

• mechanical and thermal reclamation plants (Furan, CB, etc.)

• complete moulding lines

• continuous mixers (up to 100 t/h)

• pneumatic conveying systems

• electrics and automation

In-house manufacturing and testing

MADE IN GERMANY

FAT Förder- und Anlagentechnik GmbH · D-57572 Niederfischbach · Phone +49 (0) 27 34/5 09-0 · fat.info@f-a-t.de · www.f-a-t.de


Sinto USR-II sand reclamation system

DON´T WASTE YOUR SAND

Fig. 5: System diagram

of the customer

plant (as an

integration solution

in the existing

foundry).

Save resources

Mechanical sand reclamation for green + core sand

Flexible plant design

No continous operation necessary

System designed to be operated with renewable energy

reclamation of green sand with a

capacity up to 5 tons per hour depending

on the reclamation program. The

reclaimed sand will be used again in the

core shop as a substitute of new sand.

This saves significant amounts of new

sand (fig. 5).

Remark: The test results under

Example 1 – Green sand foundry is quite

similar to the results in the Kovis customer

project. The detailed values in

the application are specific for the customer.

The corresponding process

parameters for the plant were determined

with the in-house test plant from

HWS in Germany, Bad Laasphe.

The concept (fig. 5) is planned as an

integration solution in the existing

foundry. The system takes over the

material at the sand inlet point of the

used sand silo that is currently still

being used for recycling. In the future,

this integration will be able to process

used sand independently in order to

provide the material as required. The

sand reclamation plant essentially consists

of the sand pre-treatment and the

main reclamation area. The pre-treatment

offers the option of grain separation

in the form of a small lump breaker

supplemented by the separation of

magnetizable elements via a magnetic

separator. The following process step is

sand drying, which removes the residual

moisture from the used sand if

required. For tempering, a sand cooler

is also installed. The reclamation area

includes the core component (USR-II)

with silos and conveyor technology and

is located in a second section in order to

enable the corresponding material flow

including targeted reclaim treatment

(left side fig. 5). The conditioned material

is conveyed to the customer’s silos in

the core shop and ready for use.

In this outside area, a small dedusting

system is installed for collecting the

mechanically removed fines particles of

the sand grain, which are undesirable

for reuse. The combination of equipment

selected for the overall plant

allows the customer to produce the necessary

quality with an efficient reclaiming

circulation for a certain range of

used sand requirements. The plant layout

is designed to a material circulation

and pre-treatment in a way that different

quality levels of reclaim can be produced

depending on the customer’s

choice. This provides a flexible system

that can be adapted to changing

requirements for their use cases, e.g.

the core shop.

With this very flexible material concept,

the customer is pursuing a futureproof

strategy that enables adaptation

even with changing requirement profiles

by adjusting the control parameters

and optimizing the material processing

in the degrees of freedom for

the application.

Reclamation of used sand

instead of landfilling

Is the reclamation of used sand a real

alternative to landfilling? Many foundries

have to ask themselves this question.

In case of suitability for reclamation,

individual concept planning in

cooperation with the process supplier

and an economic analysis for the overall

investment, reclamation can be a real

alternative. For this, a sustainable cost

reduction must be guaranteed. Other

effects, such as the conservation of natural

resources and the improved CO 2

balance of the plant, also contribute

to increased sustainability and should

be taken into account in the decision-making

process for investment

approval. Reclamation must already

today be included in the strategy for

securing the long-term future of our

foundries in Europe. With its own reclamation

process and technical center,

HWS offers a full service to successfully

address this issue.

www.wagner-sinto.de/en

Alexander Dornhöfer, Project Manager,

Kevin Grebe, Team leader corporate

development, Heinrich Wagner Sinto

Maschinenfabrik GmbH

References

[1] Oberschelp, P.: Reclamation of

moulding material. In: Fundamentals

and practice of sand preparation and

control of clay-bound moulding materials.

VDG Qualification course, Düsseldorf,

28./29.02.2008

[2] Polzin, H.: Condition of the sand grain

surface before and after reclamation.

1. BDG Symposium Used Sand –

03./04.04.2017, Hannover, April 2017

[3] Verein Deutscher Giessereifachleute

e.V. - Data Sheet R 093, Reclaimed Sands

As Moulding Base Material Requirements,

assessment criteria, February

1992

24

MAGNESIUM DIE CASTING

Photos and graphics: RWTH Aachen

Repair of the plunger track of a gooseneck using laser cladding.

Magnesium die casting

Additive manufacturing as a

pioneering repair technology

An important cost factor in the die casting process is the wear of the gooseneck and its

related wearing parts. By using special alloys, repairs should be achieved without a

change in diameter, additionally leading to a better wear resistance and an increasing

number of possible casting cycles.

By Marie Bode, Gerhard Schoch

As the lightweight industry continues

to develop, magnesium

die casting products are increasingly

gaining importance. Due to its

high production value, the hot chamber

process is used to produce large numbers

of small magnesium components

with a low shot weight. The gooseneck,

and in particular the plunger and sleeve

are therefor subject to a considerable

amount of thermal and mechanical

stress.

Challenges

Casting temperatures of around 650 °C

and the design of hot chamber

machines expose the gooseneck to permanently

high temperatures. Mechanical

stresses are caused by high injection

pressure (200 - 400 bar) and plunger

speeds of up to 3 m/s. As a result, the

plunger wears out in an unsymmetric

way. Hence, plunger and rings will no

longer have a tight seal and the

required injection pressure cannot be

reached. The result is a bad part quality,

which leads to replacing the gooseneck.

The current lifetime of a DIN 1.2888

(X20CoCrWMo10-9) high alloy steel

gooseneck is between 50 000 and


MAGNESIUM DIE CASTING

Powder feed

nozzle

Laser beam

Melt pool

Filler material

Melting zone

Heat-affected zone

Substrate

Fig. 1: Schematic illustration of the laser cladding process.

100 000 cycles. The replacement process

is complex and involves the enlargement

of the sleeve and adapting

plunger and rings to nonstandard sizes.

This has a negative impact on the reproducibility

of process parameters and can

lead to increased product scrap.

New repair concept

The current research project, funded as

part of the Lightweight Construction

Technology Transfer Program research

initiative of the German Federal Ministry

of Economics and Climate Protection

(BMWK), aims to overcome the limitations

on gooseneck lifetime. Direct

Energy Deposition (DED-LB/M or laser

cladding), an additive manufacturing

process is considered, to apply material

onto the injection sleeve, keeping the

plunger diameter constant and compensate

wear.

Material is applied on to the injection

sleeve by means of Direct Energy

Deposition (DED-LB/M). During this process,

laser radiation locally melts the

sleeve surface, forming a melt pool (fig.

1). At the same time, a powdered filler

material is also precisely added via a

nozzle and melted by the laser beam.

This is implemented in the melt pool in

a controlled manner using an inert gas.

This way, the added powder bonds metallurgically

with the substrate material

forming a high-quality steel layer that

protects the surface and respectively

the component against wear and corrosion.

In the context of magnesium

gooseneck repairs, this filler material is

1.2888 or a similar hot work tool steel.

Due to the many factors influencing

this process, the research project developed

specific parameters to produce a

suitable coating on 1.2888. To consider

a coating suitable, its properties should

be like those of the gooseneck. Comparison

of a sample taken from a magnesium

gooseneck with a coating produced

by direct energy deposition (fig.

2) shows no significant differences in

pore distribution and size in the coating

produced. This is further confirmed by

comparing the measured density. In the

considered area, the density of 99.97 %

of the produced coating even shows a

slight increase compared to that of the

gooseneck (99.91 %). The average measured

hardness of the coating produced

is 585 HV, which is significantly higher

than the 300 HV measured on the

gooseneck, due to the rapid cooling in

the coating process. This is believed to

reduce wear and therefore improves

the lifetime.

Practical tests

Based on these findings, it is now possible

to optimize the sleeve surface of

magnesium goosenecks by applying a

successful coating. The coating process

of a gooseneck is shown in figure 3. In a

practical test, the goosenecks were

installed under production conditions.

Impressive running times of over

120 000 shots were achieved without

any detectable change in the quality of

the components. This means that the

lifetime of the coated goosenecks is at

1000 µm 1000 µm

Fig. 2: Microscopic images of a) the surface of a magnesium gooseneck, b) a layer produced by laser cladding.

26

least equal to conventional uncoated

goosenecks, considering certain variations

in process parameters during the

production process. The long lifetime is

assumed to result from the increase in

hardness due to the observable similarities

in the microstructures of the gooseneck

and the coating. In addition, after

100 000 shots, the maximum wear on

the sleeve measured only 0.18 mm,

whereas the maximum wear measured

on an uncoated gooseneck was already

0.26 mm after 50 000 shots. DED-LB/M

plunger coating therefore ensures a stable

casting process with a longer gooseneck

life span.

Gießbehälter

Beschichtungseinheit

Fig. 3: Illustration of the coating process: gooseneck on the system.

Fig. 4: Cone coating.

In addition, the coating can be reapplied

after the next wear, resulting in a

repetitive repair with a constant inner

diameter. Furthermore, this manufacturing

process also allows cones of the

gooseneck to be coated (fig. 4). To further

reduce wear, new alloys with

higher wear resistance could be used

for coating and thus for remanufacture

of goosenecks in the next step of the

project. Due to the processing of additional

materials, the additive manufacturing

process used can generate material

combinations that were previously

unnoticed and thus significantly boost

the production of high-quality magnesium

castings.

www.dap-aachen.de/en,

www.g-s-d.info/en

Marie Bode, M.Sc., Chair of Digital

Additive Production, RWTH Aachen University,

marie.bode@dap.rwth-aachen.

de, Gerhard Schoch, Gerhard Schoch

Druckgießtechnik, Görlitz, office@g-s-d.

info

When Temperature

Matters

↑ 1321.0 °C

Engineering support to guide you to the best solution.

IR Cameras. Pyrometers. Accessories. Software.

Non-contact temperature measurement from − 50 °C to +3000 °C.

Visit: www.optris.com | Phone: +49 30 500 197-0

Repair process

The process of a casting container overhaul

includes the following steps:

> Cleaning,

> Pre-honing to an exact bore geometry,

> Material application using direct

energy deposition (DED-LB/M),

> Subsequent honing to the exact diameter.

The project on which this article is

based was funded by the Federal Ministry

for Economic Affairs and Climate

Protection under grant number

03LB3050D. Responsibility for the content

of this publication lies with the

authors.

500 nm to

14 μm

FEEDING

Photos and Graphics: IDECO

Thermal analysis system for quantifying different supply ranges.

Aluminum casting alloy EN AC-42100

Impact of modifier and grain

refiner on the feeding effectivity

This work will show how IDECO thermal feeding analysis system can be used to quantify

different feeding regions of cast EN AC-42100 alloy. First time under industrial conditions,

operators at the foundry floors will be capable to control the impact of master

alloys additions on the feeding effectivity of cast aluminum alloys. Collected parameters

can be used to feed existing simulation data bases with more correct information and

on that way improve their accuracy.

By Olivier Dünkelmann, Mile B. Djurdjevic, Robin Unland, Julian Schröter

28

The EN AC-42100 (AlSi7Mg0.3)

alloy is a type of cast aluminum-silicon

hypoeutectic alloys

with addition of magnesium as a major

alloying element. This alloy may find

application in a variety of general engineering

and structural components

where a balance of good mechanical

properties, corrosion resistance, and

metallurgical properties (fluidity and

castability) is required. Two major alloying

elements, silicon, and magnesium in

combination with some other minor

alloying elements (Sr, Ti, Fe, Mn, B,

Zn…) outline the metallurgical,

mechanical, and structural properties of

this alloy [1, 2]. As cast structure of the

EN AC-42100 alloy characterized the

presence of primary a-aluminum dendritic

structure, primary aluminum-silicon

eutectic as well as magnesium-rich

intermetallic phases. Moderate amount

of silicon gives this alloy good fluidity,

while added magnesium improve its

strength, hardness and fatigue properties.

During liquid-solid transformation,

most metals and alloys contract, reducing

their volume. The aluminum-silicon

cast alloys also decrease their volume

during solidification in the range of 4

to 8 % [3].

Silicon is one of few elements that

during transformation from liquid to

solid state increase its volume. Thanks

to that property, silicon will to some

degree compensate the volume

decrease of aluminum-silicon alloys

during solidification. In the available

literature [4] it has been mentioned

that feeding capability is closely related

to the aluminum-silicon eutectic characteristic

formed during solidification. The

higher amount of magnesium extends

the solidification range of these alloys,

reducing their feeding ability. The aluminum-silicon

alloys without magnesium

characterized narrow solidification

range with significant amount of liquid

eutectic. Therefore, the feeding of the

liquid eutectic by those alloys should be

relatively easy. Presence of magnesium

in these alloys, noticeably extends their

solidification range, making feeding of

the last liquid eutectic portion during

solidification difficult and causing the

formation of shrinkage porosity.

Feeding mechanism

According to Campbell [5], five feeding

mechanisms (liquid, mass, interdendritic,

burst and solid feedings) occur

during solidification of cast aluminum

alloys.

> The liquid and mass feedings, which

ABSTRACT

The EN AC-42100 (AlSi7Mg0.3) aluminum alloy is commonly used in various

applications due to its favorable combination of mechanical properties, corrosion

resistance and casting characteristics. Non-adequate feeding of this hypoeutectic

alloy leads to the formation of shrinkage porosity. Addition of grain

refiners and modifiers into aluminum melt can be beneficial directing to better

feeding ability of this cast alloy. Thermal (cooling curve) analysis has been

routinely used at aluminum foundry floors for assessment the efficiency of

master alloys additions into aluminum melt. Cooling curve analysis can additionally

provide information regarding to characteristic solidification temperatures

such as: liquidus, dendrite coherency point, rigidity and solidus. These

temperatures are important parameters of solidifying aluminum alloys, which

mark transitions between five types of feeding mechanisms: liquid feeding,

mass feeding, interdendritic feeding, burst feeding and solid feeding.

Fig. 1: Bordering five feeding mechanisms using characteristic solidification temperatures

determined from the cooling curve.

appear at the beginning of solidification

process, are uncomplicated due to

low melt viscosity, wide active feeding

path and relatively elevated melt temperature.

> The numbers of dendrites, which start

to develop immediately after liquidus

temperature, is still not so significant to

slow down melt movement. As the melt

temperature decreases during further

solidification, growing dendrites start to

impinge on each other forming coherent

dendritic network, which additionally

slows down the flow of the remaining

melt. The temperature at which this

happens is called Dendrite Coherency

Temperature (DCT). This temperature

borders the transition from mass to

interdendritic feeding regions in all cast

aluminum alloys [6 - 14].

> Further solidification decreases the

liquid fraction, and the stress is spread

over larger distances through the rigid

solid skeleton [15, 16]. According to

Campbell [5], at the rigidity temperature,

the stress will exceed the strength

leading to breakdown of solid dendritic

skeleton. The rigidity temperature

marks the moment when the interdendritic

feeding stops and burst feeding

starts.

> The solid feeding starts at the solidus

temperature when the last drop of melt

is transformed into the solid.

Characteristic solidification temperatures

such as liquidus, dendrite coherency

temperature, rigidity and solidus

temperature have been recognized as

important parameters of solidifying aluminum

alloys, which can be used to

mark transitions between several types

of feeding mechanisms [8 - 14]. All

those characteristic solidification temperatures

as figure 1 illustrates can be

easily determined using IDECO thermal


FEEDING

porosity [19]. Dash and Makhlouf [17]

found in their paper that besides the

cooling rate, which plays significant

impact on feeding issue chemistry also

has some contribution. According to

their results, iron, silicon, magnesium

and copper present in the aluminum

alloys during solidification form various

intermetallics compounds such as

Al 5

Mg 8

Cu 2

SI 6

, needle like Al 5

FeSi or

Al 2

Cu. All these compounds form a net

like structure that hinder the flow of

the melt leading to formation of shrinkage

porosity [19].

Fig. 2: Layout of equipment during experiments at IDECO technical center.

Table 1: Chemical composition of the investigated alloy in wt.%, experiment 1.

Alloy Si Mg Sr Ti Cu Fe Mn Zn

AlSi7Mg0,3 7.138 0.337 0.0001 0.125 0.001 0.056 0.002 0.002

Table 2: Chemical composition of the investigated alloy in wt.% after the addition of the modifier,

experiment 2.


Al Si7 Mg0,3 6.866 0.337 0.0072 0.13 0.001 0.052 0.002 0.002

Table 3: Chemical composition of the investigated alloy in wt.% after the addition of the modifier

and grain refiner, experiment 3.


Al Si7 Mg0,3 7.019 0.328 0.0072 0.154 0.001 0.057 0.0020 0.002

Fig. 3: Thermal analysis ceramic cup and samples with two thermocouples.

feeding analysis system and apply to

boundary those feeding regions.

Chemical structure

In the available literature, it has been

documented that the solidification

feeding behavior of cast aluminum

alloys is affected by their chemical

compositions [17, 18]. J. Cho et al. [18]

found that copper has significant

impact on the feeding characteristics of

cast aluminum-silicon alloys. Added

magnesium prolongs the freezing time,

extends eutectic mushy zone influencing

feeding ability and causing formation

in large amount of microshrinkage

Modifier and grain refiner

The main aim of this work is to analyze

the impact of modifier and grain refiner

on the various feeding regions of cast

EN AC-42100 alloy applying a new

IDECO thermal feeding analysis system

and try to quantify them.

Modifier and grain refiner are

important additives used in the casting

of aluminum alloys to improve their

microstructure and mechanical properties.

Modifiers are added to change the

size, shape and distribution of the silicon

phase in the solidified structure.

Their main purpose is to improve the

feedability of the alloy by promoting

the formation of fine, spherical silicon

particles. Grain refiners are added to

aluminum alloys to reduce the size of

the primary a-aluminum grains and

thereby improve feedability. In addition,

these additives can help reduce

casting defects and ensure a more reliable

and consistent cast structure.

Experimental Procedure

Materials and melting procedures

Four experiments have been carried out

at IDECO technical center in Bocholt,

Germany, using Rheinfelden primary

hypoeutectic EN AC-42100 (AlSi7Mg0.3)

alloy. Table 1 summarizes the chemical

composition of investigated alloy, after

being melted in an electric resistance

furnace capacity 4 kg. Figure 2 shows

IDECO laboratory set up with following

equipment: Nabertherm electric resistance

furnace and IDECO SA800SN thermal

feeding analysis system.

Three kilograms of EN AC-42100

alloy were charged in the furnace and

melted down. The melt was neither

grain refined nor modified. During all

experiments the melt was also not

degassed. The melt temperature in the

furnace during all experiments was kept

constant at 720 °C. Chemical composition

of melted alloy has been determined

using optical emission spectros-

30

copy apparatus. Ten thermal analysis

test samples have been run during the

first experiment and their corresponding

cooling curves have been collected

and later used to quantify feeding

effectivity of this alloy.

At the beginning of the second

experiment 3.0 kg of EN AC-42100 alloy

were added into the furnace and

melted down. Additionally, 63,5 grams

of Al10%Sr master alloy in the rod form

has been also added into the melt to

analyze the impact of modifier on the

characteristic solidification temperatures

and the feeding ability of EN

AC-42100 alloy. Targeted concentration

of Sr in the melt was approximately 75

ppm. Table 2 shows the chemical composition

of the melt applied during this

experiment. In total, five cooling curves

have been collected using modified EN

AC-42100 melt. Characteristic solidification

temperatures determined from

these curves have been used to border

the various feeding regions of this alloy.

For the third experimental step, the

modified melt from the previous trial

has been mixed and grain refined by

adding 32,4 g of AlTi3B1 master alloy in

the rod form to analyze its impact on

the solidification path of this alloy.

Table 3 displays the achieved chemical

composition of the EN AC-42100 melt

after addition of grain refiner. Five

cooling curves have been collected

using grain refined and modified

EN AC-42100 melt and determined

parameters from the curves have been

used to evaluate impact of grain refiner

and modifier on the feeding ability of

this alloy.

For the fourth experiment, the original

(no grain refined and modified)

Rheinfelden EN AC-42100 alloy in the

quantity of 2.5 kg was charged in the

furnace and melted down. After

remelting, 32 g of AlTi3B1 master alloy

in the rod form has been added into

the melt to analyze only the impact of

grain refiner on the solidification path

of this alloy. Table 4 displays the

achieved chemical composition of the

EN AC-42100 melt after addition of

grain refiner. Five cooling curves have

been collected using grain refined

EN AC-42100 melt, and their characteristic

solidification temperatures have

been applied to evaluate the impact of

grain refiner on its feeding ability.

Fig. 4: The cooling curve, its first derivative and delta T curve for EN AC-42100 alloy

without addition of modifier and grain refiner.

Fig. 5: The cooling curve, its first derivative and delta T curve for EN AC-42100 alloy with

addition of modifier.

Thermal Feeding analysis procedure

Thermal analysis test samples with

masses of approximately 220 ± 20 g

were poured into IDECO thermal analysis

ceramic test cup with a height of

59.5 mm and a diameter of 54 mm. Two

calibrated K type thermocouples were

inserted into the melt and temperatures

between 700 and 400 °C were recorded.

As figure 3 illustrates, one thermocouple

was placed in the center of the cup

(TC), while the second one was placed ≈

5 mm from the cup wall (TW). The tip of

the thermocouple was kept always at

the constant height of ≈ 20 mm from

the bottom of the ceramic cup. The

cooling conditions were kept constant

during all experiments. During all trials,

the acquisition system read ten data

sets (temperature/time/sensor) per

second.

Results and discussions

To meet strict industrial requirements,

IDECO developed and implemented a

novel thermal feeding analysis system.

The new system can define the solidification

path of any cast aluminum alloy

and quantifying its feeding ability as a

function of temperature, time, and fraction

solid. The stable test sample mass,

optimal test cup and melt sampling


FEEDING


addition of modifier and grain refiner.

technique together with applied high

resolution K type thermocouples allows

high level of repeatability and reproducibility

of each measurement as well

as unbiased analysis. System is user

friendly and easy to operate.


has been applied in all experiments

with the main aim to analyze the

impact of modifier and grain refiner on

the characteristic solidification temperatures

of EN AC-42100 alloys. Modifiers

and grain refiner are important additives

used in the casting of aluminum

alloys to improve their microstructure

and mechanical properties. Modifiers

are added to aluminum alloys to modify

the size, shape, and distribution of the

silicon phase in the solidified microstructure.

The primary purpose of modifiers

is to improve the feeding ability of

the alloy by promoting the formation

of fine, globular silicon particles. Grain

refiners are added to aluminum alloys

to reduce the size of primary a-aluminum

grains and to enhance the feeding

ability of the cast aluminum alloys.

Additionally, these additives can help

to reduce casting defects and ensure

more reliable and uniform casting

structures. Figures 4 to 7 show cooling

curves, their first derivative curves and

corresponding delta T curves (TW – TC)

for EN AC-42100 alloy

> without addition of modifier and

grain refiner (fig. 4),

> with addition of modifier (fig. 5)

> with addition of modifier and grain

refiner (fig. 6) and

> with addition of only grain refiner

(fig. 7).


addition of grain refiner.

Table 4: Chemical composition of the investigated alloy in wt.% after the addition of grain

refiner, without modifier, experiment 4.


AlSi7Mg0,3 7.188 0.327 0.0001 0.123 0.001 0.054 0.002 0.002

Table 5: Influence of modifier and grain refiner on the characteristic solidification temperatures

of the alloy EN AC 42100 in °C. These are average values from multiple measurements.

Alloy T LIQ

T DCP

T Rigidity

T SOL

Al Si7 Mg0.3 621.2 610.4 571.3 535.6

Al Si7 Mg0.3 + Sr 0.0072 620.4 612.6 566.3 540.0

Al Si7 Mg0.3 + TiBor 0.154 + Sr 0.0072 625.4 612.8 565.8 540.8

Al Si7 Mg0.3 + TiBor 0.123 620.0 612.2 569.4 538.0

The cooling curve, its first derivative

curve and delta T curve have been used

to determine liquidus (TLIQ), dendrite

coherency (TDCP), rigidity (TRigidity)

and solidus temperatures (TSOL) of the

investigated alloy. All four characteristic

solidification temperatures from four

previously described trials have been

summarized in table 5. These temperatures

delineate the five feeding regions

of this alloy.

Influence of modifier

As table 5 and figure 5 show, strontium

has significant impact only on rigidity

temperature. Addition of 72 ppm strontium

reduced the rigidity temperature

from 571.3 °C to 566.3 °C. The depression

of rigidity temperature caused by

adding modifier in the EN AC-42100

alloy leads to an extension of the Inter

Dendritic Feeding (IDF) region by 5 °C.

32

Influence of grain refiner plus modifier

Added grain refiner (0.154 wt.% of Ti)

into the modified melt has no impact on

the rigidity temperature as figure 7

shows, but impacts the dendrite coherency

temperature, increasing it by 2.2 °C.

Influence of grain refiner

Addition of grain refiner into EN

AC-42100 melt in the amount of 0.123

wt.% as figure 7 and table 5 indicated,

does not significantly change the rigidity

temperature and has some moderate

impact on dendrite coherency temperature,

increasing it by 2.4 °C compared to

the melt without any addition of grain

refiner and modifier.

Feeding behavior

Shrinkage porosity is one of the most

common defects in aluminum cast parts

caused by non-proper feeding ability.

Understanding the feeding behavior of

aluminum-silicon alloys is an important

aspect for sound casting production. In

the available literature, only a few

papers attempt a quantitative description

of some feeding regions in aluminum-silicon

alloys using the beam and

scales principle [19, 20, 21]. By measuring

the time of mass and total feeding

during solidification in cast parts, Engler

and Michel [19-21] established two criteria

that can be employed to describe

mass feeding (up to the dendrite coherency

point) and total feeding (from the

dendrite coherency point up to the solidus

temperature). The main disadvantage

of these criteria was their inability

to quantitatively describe feeding

regions such as interdendritic feeding

or burst feeding.

Especially interdendritic and burst

feedings are of great importance in

producing sound cast parts through

gravity and high-pressure die casting

processes. Those regions are mostly

responsible for defects formation in the

as-cast structure, such as shrinkage

porosity, hot tearing, and segregation.

In addition, it is well known that time is

an intensive property that is very sensitive

to the mass of solidified samples.

Any difference in the size of thermal

analysis test sample can significantly

influence the total solidification time

and impact the accuracy of quantitatively

described feeding regions. Therefore,

the foundry industry needs a better

analytical description of those two

feeding regions. A new IDECO thermal

feeding system proposes three equations

based on the previous work [22]

which can be used quantitatively to

describe following three feeding

regions of any cast aluminum alloys:

MB = T SLL − T DDD

T SLL − T SSS

x 100 1

IIB = T DDD − T RRRRRRRR


x 100 2

BB = T RRRRRRRR − T SSS


x 100

where:

MF temperature ratio for mass

feeding, %

IDF temperature ratio for interdendritic

feeding, %

BF temperature ratio for burst

feeding, %

T LIQ

liquidus temperature, °C

T DCP

dendrite coherency temperature,

°C

T Rigidity

rigidity temperature, °C

T SOL

solidus temperature, °C

3

From figure 1 it is obvious that four

characteristic solidification temperatures

(liquidus, dendrite coherency,

rigidity and solidus) are needed parameters

for quantitative description of different

feeding intervals. Applying equations

(1 - 3) and calculated

corresponding temperature ratio for

various feeding regions, the impact of

grain refiners and modifiers can be

quantified.

Figure 8 illustrates, that the introduction

of strontium led to an approximate

12 % extension of the Interdendritic

Feeding (IDF) temperature ratio,

concurrently resulting in a notable 9 %

reduction in the Burst Feeding (BF) temperature

ratio. The influence of strontium

aligns with expectations. It is

widely recognized that strontium does

not impact dendrite coherency temperature

but significantly lowers the

rigidity temperature, thereby expanding

the interdendritic feeding region

[21]. Particularly, grain refiners, commonly

based on elements such as titanium

or boron, are incorporated into

aluminum alloys to refine the grain

structure. They facilitate the formation

of smaller and more uniformly distributed

grains within the alloy. A finer

grain structure enhances the feeding

capacity of the alloy by providing more

nucleation sites for the growth of solidification

fronts. This, in turn, promotes a

more uniform and controlled solidification

process, mitigating the risk of

shrinkage defects and ensuring proper

mold filling. Analyzing figure 8, the

addition of titanium (0.154 wt.%) to a

non-modified aluminum melt (experiment

4) increased IDF temperature ratio

by approximately 7 % and decreased BF

temperature ratio by around 3.5 %.

Simultaneous incorporation of a

modifier and grain refiner into the aluminum

melt resulted in a 10 % expansion

of IDF temperature ratio and a 12 %

YOUR PROFESSIONAL

PARTNER FOR ALUMINUM

CASTING FILTERS

ASTI Gießereigeräte GmbH

Tel: +49 (0)7261| 97 27 -0

Fax: +49 (0)7261| 97 27 -29

info@asti-filter.de | asti-filter.de

CASTING FILTERS • GIESSFILTER • FILTRES DE COULÉE • FILTRO MODELO


FEEDING

Temperature ratio, %

Mass feeding, % Interdendritic feeding, %

Burst feeding, %

Fig. 8: The impact of adding modifier and grain refiner (separately or together) on the

temperature ratio of different feeding regions. All values associated with these feeding

regions are derived from averaging multiple measurements. The vertical lines on the

bars represent the standard deviations of the corresponding measurements.

reduction in BF temperature ratio. The

low standard deviation observed in figure

8 indicates the high repeatability of

all measurements, demonstrating

IDECO feeding thermal analysis’s ability

to quantify the various feeding ranges

with high accuracy.

Simulation

In modern aluminum casting foundries

has been applied as a routine procedure

in their everyday works, drastically

reducing the number of experiments,

improving quality of final cast products

as well as reducing the costs for developing

new products. On that way,

foundry engineers are capable to

shorten the period of a new development

and earlier launch a novel product

to customer. To be capable to achieve

these tasks, the simulation software

packages need to have an accurate data

base for various aluminum cast alloys.

Presently applied data bases are

using thermal, physical, and chemical

parameters for standard types of aluminum

alloys with exact chemical compositions.

These data bases are not sensitive

enough to accommodate any

changes in the actual chemistry of

applied alloys. The impact of grain

refinement, modification and/or influence

of minor alloying elements on the

solidification paths of cast aluminum

alloys are usually not considered in

those standard data bases. Commercial

software suppliers usually only provide

parameters for standard alloys with predefined

chemical compositions in their

databases. If additional material parameters

for advanced alloy compositions

are needed, they need to be purchased,

measured, or calculated. Therefore, it is

necessary to find out other sources that

can update an existing data base with

more accurate information.

As it has been demonstrated in this

paper, a good way to obtain a new

information is IDECO thermal feeding

analysis system. This system makes it

possible to find missing parameters such

as characteristic solidification temperatures,

corresponding amount of fraction

solid at each characteristic temperature,

amount of latent heat, temperature

range of various feeding regions and

improve the accuracy of simulation.

Conclusions

In the available literature there is limited

information related to the quantitatively

description of each of the five

feeding mechanisms proposed by

Campbell. This paper analyzed the

impact of modifier (AlSr10) and grain

refiner (AlTi3B1) on the different feeding

regions of EN AC-42100 alloy using

IDECO thermal feeding analysis system.

The three novel criterions to characterize

the feeding behavior during the

solidification process, such as

> temperature ratio for mass free feeding,

> temperature ratio for interdendritic

constrained feeding and

> temperature ratio for burst feeding

have been proposed.

These criterions assume that solidification

parameters such as liquidus temperature,

dendrite coherency temperature,

rigidity temperature and solidus

temperature mark transitions between

different types of feeding mechanisms.

It was found that addition of modifier

and grain refiner has influence on the

temperature ranges of inter dendritic

(IDF) and burst feeding (BF) regions.

Added strontium up to 72 ppm increases

IDF temperature ratio for 12 % and

reduces BF temperature ratio for 9 %.

Grain refiner (0.123 wt.% Ti) increases

the IDF temperature ratio for 6.7 % and

decreases the BF temperature ratio for

3.5 %. Combined addition of modifier

and grain refiner (72 ppm Sr and 0.154

wt. % Ti) increase the IDF temperature

ratio for 10 % and decrease the BF temperature

ratio for 12 %.

This paper demonstrated that the


can be used accurately to quantify various

feeding regions and feed existing

data base with new data that so far

have not been applied in simulation.

www.ideco-gmbh.de/en

Olivier Dünkelmann, Robin Unland,

IDECO, Bocholt, Mile B. Djurdjevic,

Nemak Linz GmbH, Linz, Julian Schröter,

M. Busch GmbH & Co. KG, Bestwig

References

[1] J. Gubicza et al: “Effect of Mg addition

on microstructure and mechanical

properties of aluminum“, Materials Science

and Engineering A 387–389 (2004)

55–59.

[2] A.M.A. Mohamed et. al: “Bewertung

der Wirkung einer Magnesiumzugabe

auf der Erstarrungsverhalten von

Al-Si-Cu-Gusslegierungen”, Giesserei

Praxis, 2013, Vol. 7-8, S. 286-294.

[3] O. E. Okorafor: “Some Considerations

of the Volume Shrinkage of Aluminium-Silicon

Alloy Castings Produced

in Full Moulds“, Transactions of the

Japan Institute of Metals, Vol. 27, No. 6

(1986), pp. 463 to 468.

[4] J. M. Kim at al.: Porosity formation

in relation to the feeding behavior of

AlSi alloys, AFS Transactions 1997.

[5] Campbell, J.: “Feeding Mechanisms

in Castings”. AFS Cast Metal Research

Journal, 1969. 5: p. 1-8.

34

[6] Paul L. Schaff er et al.: “The Eff ect of Aluminum Content

and Grain Refinement on Porosity Formation in

Mg-Al Alloys”, Magnesium Technology 2001, Edited by J.

Hryn, TMS (The Minerals, Metals and Materials Society,

2001, pp. 87-94).

[7] Arnberg, L. et al.: “Feeding Mechanism in Aluminum

Foundry Alloys”, AFS Transactions, 1995, 115, 753- 759.

[8] Arnberg, et al.: “Studies of dendrite coherency in

solidifying aluminum alloy melts by rheological measurements”,

Mater. Sci. Eng., 1993, A173, 101-103.

[9] Chai, G.: “Dendrite Coherency During Equiaxed Solidification

in Aluminum Alloys”, Chemical Communications.

No. 1, Stockholm University, Stockholm, Sweden, 1994.

[10] Chai, G. et al.: “Dendrite Coherency during Equiaxed

Solidification in Binary Aluminum Alloys”, Metall. Mater.

Trans. A, 1995, 26A, 965-970.

[11] Veldman, N. et al.: “Determination of Dendrite

Coherency Point”, Die Casting & Tooling Technology Conference,

22-25 June, 1997, Melbourne, Australia.

[12] Claxton, R.J.: “Aluminum alloy coherence”, Continuous

Casting, AIME Metallurgical Society, New York (1973),

pp. 341-352.

[13] Zamarripa, R.C et al.: “Determination of the Dendrite

Coherency Point during Solidification by means of Thermal

Diff usivity Analysis”, Metall. Mater. Trans. A, 2007,

38A, 1875-1879.

[14] Djurdjevic, M. et al.: “Detection of the Dendrite

Coherency Point of Al 3XX Series of Alloys Using a Single

Sensor Thermal Analysis Technique”, 40th Annual Conference

of Metallurgists of CIM 2001.

[15] Eskin, D.; Katgerman, L.: “A Quest for a new hot tearing

criterion”, Metallurgical and Materials Transactions A,

2007, pp.1511-1519.

[16] Bäckerud, L. et al.: “Solidification Characteristics of

Aluminum Alloys”, Vol. 2: Foundry Alloys, AFS/Scan Aluminium,

Oslo, Norway, 1990.

[17] M. Dash, M. Makhlouf “Effect of key alloying elements

on the feeding characteristics of aluminum–silicon

casting alloys”, Journal of Light Metals 1 (2001) 251-265;

[18] J. Cho et al.: “The effect of copper on-feeding characteristics

of aluminum casting-alloys”, Proceedings of the

12th international conference on aluminum alloys, September

5-9, 2010, Yokohama, Japan, pp. 745-750.

[19] Michel W. and Engler S; “Speisungskinetik von Aluminum-Silizium

Gußlegierungen”, Giesserei 75, Nr. 14, 1988,

S. 445-448.

[20] Michel W. and Engler S; “Erstarrungsmorphologie

und Speisungsablauf von Aluminium-Silizium Legierungen

bei Kokillenguß“,Giesserei 77, Nr. 3, 1990, s. 79-82.

[21] Michel W and Engler S., “Speisungsverhalten und

Porosität von Aluminium-Silicium-Gußwerkstoffen“,

Giessereiforschung 41, 1989, Nr. 4, pp.174-187.

[22] G. Huber et al.: “Impact of silicon, magnesium and

strontium on feeding ability of AlSiMg cast alloys”, Material

Science Forum, 2016, Vol. 879, pp. 784-789, ISSN: 1662-

9752.

Ecological

& economical

into the future

EvacTherm®

Made-to-measure

molding sand preparation

• Energy-saving

• Low emission

• Conserving resource

Enhance your sustainable performance with a

constant molding temperature even with variable

ambient conditions

eirich.com

STEEL MELTS

Improving the quality of steel melts

Clean steel castings at ultra

low pouring temperatures

This article describes a new technique for improving the quality of steel melts in the

ladle prior to pouring. The Process involves a rotary treatment process that stirs the

metal in the ladle whilst passing a curtain of fine argon bubbles through it. Together

with flux and wire additions the process leads to effective inclusion removal, homogenized

temperature, modification and desulfurization. The technique allows the steel

to be cast at much lower temperatures even semi liquid, resulting in fine cast micro

structures and reduced defects.

By David Hrabina. Colin Powell, Dalibor Čáp, Milan Turták, Jiří Kolár

36

Molten metal in the melting furnace

will be clean but tapping

into the pouring ladle significantly

contaminates it [1]. The metal

tapping process is not well controlled

and splashed metal exposed to the

atmosphere reacts with oxygen forming

oxide films having melting temperature

greater than temperature of the liquid

metal in the ladle. Formed oxide films

cannot dissolve or remelt in the ladle

and floating up to the surface through

their buoyancy would take excessive

time due to their large surface area and

negligible volume.

Injecting treatments and deoxidizing

alloys such as Al, SiCa, FeTi and FeZr

into the stream of tapped steel makes

the situation even worse. Massive

amounts of air entrained into the molten

metal in the ladle (fig. 1 a and b)

immediately react with those high oxygen

affinity elements forming even

more non-metallic inclusions and oxide

films.

The metal temperature in the ladle

may vary significantly in different locations

due to the cooling effect of the

refractory lining. The difference

between the metal temperatures

between the bottom and top of the

ladle might be tens of degree before

the pouring process starts (fig. 2 a and

b). Especially sensitive are smaller bottom

pour ladles because of the cooling

effect of stoppers and nozzles. The

coldest metal sinks to the lowest area

around the stopper nose and is the first

metal to flow into the nozzle when the

stopper is lifted up. This metal cools

even further as it passes through the

unpreheated running system and leads

to mis-runs and cold shut defects on the

casting surface. The pouring temperature

is measured by thermo probe at the

top of the ladle before pouring starts

but this is not representative of metal

temperatures at other ladle locations.

a

b

Fig. 1: a) Water modeling of tapping process, b) CFD simulation of metal tapping.

a

b

Fig. 2: MAGMA simulation of metal temperature distribution at the ladle 6 min after tapping.

a

b

Fig. 3: a) Very fine Ar bubbles helically dispersed, b) effective bifilm and inclusions removal by

Ar bubbles.

a

b

Fig. 4: a) Cold spots of metal after the tapping, b) metal temperature homogenization by Rotoclene – Rotary Treatment Process.


STEEL MELTS

Fig. 5: Alumina inclusion modification by Ca to globular shape less harmful to low temperature notch toughness test and fatigue performance.

Table 1: Desulfurization at the ladle by synthetic slag within Rotoclene treatment.

Test No Time C Mn Si P S Cr Mo Ni V Cu Al Al soluble

1 12:40 0.67 0.85 0.18 0.016 0.017 0.30 0.20 0.22 0.01 0.05 *0.234 *0.220

2 13:08 0.31 0.16 0.00 0.002 0.012 0.09 0.27 0.20 0.00 0.05 *0.150 *0.143

3 13:45 0.40 0.42 0.42 0.006 0.007 0.89 0.26 0.19 0.01 0.05 0.027 0.023

4 14:37 0.45 0.82 0.52 0.008 0.002 1.13 0.26 0.19 0.01 0.05 0.033 0.031

Test No 1 – EAF just after smelting (6800 kg)

Test No 2 – EAF after oxidation

Test No 3 – EAF before tapping → 1 % of synthetic slag Sulfamin 70 into the pouring ladle within tapping

Test No 4 –Taken from the ladle after Rotoclene treatment at the end of pouring process. Sulfur level reduced from 70 to 20 ppm

The Rotoclene process

The Rotoclene process has been developed

to treat molten metal effectively

in the ladle. For reducing hydrogen and

nitrogen pick up we would ideally

deoxidize the melt with cored wire

before or during the rotary treatment

rather than into the stream during

metal tapping from either arc or induction

melting furnace. A hollow ceramic

rotor stirs the molten metal as argon is

purged through it gets dispersed to

form curtains of very fine bubbles (fig.

3a). These float up slowly in a helical

trajectory that extends their passage

through the metal rotating around the

vertical axis of the ladle. Slag particles

inclusions and oxide films adhere to surface

of the argon micro bubbles and

float up into the slag layer at the top.

The small size of the argon bubbles

gives them a long residence time in the

melt and together with the extended

floating trajectory means that very

effective metal purification is achieved

(fig. 3b). The rotation of the melt also

effectively homogenizes metal temperature

and eliminates critical cold

spots at the bottom (fig. 4a). Molten

metal in the ladle keeps rotating

through its moment of inertia even several

minutes after the end of the rotary

treatment. The metal temperature stays

consistent at any ladle location without

cold spots (fig. 4b) and pouring temperature

can be significantly reduced

compared to conventional practice.

Synthetic slag can also be stirred into

the molten metal to partially dissolve

nonmetallic inclusions and perform deep

desulfurization (table 1) at the neutral

or basic lining ladle similarly to a ladle

furnace in secondary metallurgy [2]. The

stirring action also allows a deeper deoxidation

by extruded pure Ca wire to

modify alumina inclusions (fig. 5) to a

more nodular shape more effectively

than SiCa [3]. Pure Ca normally reacts

too violently with steel and cannot be

applied in foundry ladles, however,

injecting the Ca into a moving stream

dissolves it before it reaches the critical

vapor concentration. Pure Ca also does

not contribute to premature filter clogging

in the way that SiCa typically does.

Metal solidification

Metal solidification is very complex process

of transformation from liquid

phase to solid involving the formation

of dendrites and segregation of low solubility

elements at the grain boundaries.

Atoms are converted from liquid

disordered phase to solid ordered phase

releasing significant latent heat being

accompanied by volumetric shrinkage

[4, 5, 6]. The liquidus point can be identified

reliably by the initial chemical

composition of the cast metal while the

solidus point is varied by the actual

metal composition being continuously

saturated by segregating elements.

Fig. 6: Dendritic growth from primary. secondary.

tertiary to quaternary dimensions

according to solidification time by Robert

Wlodawer [7].

38

a b c

Fig. 7: a) Model of dendrite structure with primary, secondary, and tertiary axis [5], b) section through the structure of steel dendrite [6], c) dendrites

growth at the shrinkage [6].

The temperature of the liquidus at

any casting part is identical. However,

the solidus temperature in thin sections

of the same casting is higher than solidus

temperature in thick sections.

Extended solidification time in the thick

casting sections allows dendrites to

develop more and segregation at their

grain boundaries changes their chemical

composition due to the higher concentrations.

This phenomenon results in the

solidification range being narrower in

thin sections and wider in thicker ones

within the same casting. Solidification

time highly influences the structure and

therefore the final mechanical properties

of steel castings. Longer solidification

times allow dendrites to grow bigger

and inter-dendritic segregation is

higher (fig. 6, 7a, 7b, 7c, 8) [7, 8].

This impacts mechanical properties

negatively. Solidification time depends

on many parameters but most importantly

on cast section modulus and

pouring temperature. Modulus is

mainly defined by castings geometry

while pouring temperature depends on

foundry practice. Superheat (the difference

from pouring temperature to temperature

of the liquidus) is applied to

ensure the casting cavity is filled up

before solidification starts. The mold

absorbs superheat energy from the liquid

steel and is heated up before molten

metal temperature drops below the

liquidus to start the solidification process.

Higher pouring temperature leads

to more energy absorption by the mold

before solidification starts and lowers

the capacity for the mold to absorb

heat from the solidifying casting (fig. 9).

Fig. 8: Dendrite’s growth and inter-dendritic segregation of carbon model [9].

Fig. 9: Extended solidification time by superheating steel over the temperature of liquidus.

Volumetric contraction starts from pouring temperature, but shrinkage cavity cannot be

formed until temperature drops under the liquidus and solidification process starts.


STEEL MELTS

Table 2: Inclusion’s removal and metal cleanliness comparison Rotoclene versus Purging

Plug process. (Samples taken from the test block cast as connected to casting).

047 – Metal

treated by Purging

Plug at the ladle

Total Area Analyzed (mm²) 116.64 116.64

Total Number of Classified

Features

Total Area Analyzed Features

without unclassified (μm 2 )

4709 2142

49576 34942

Si > 70 143 81

Al > 70 208 107

70 > Al > 50 407 298

Mn > 25 and S > 10 2373 1426

Mg > 25 1 0

Ca > 50 2 7

50 > Ca > 10 1471 141

Rest 104 82

a

Fig. 10: a) PP treatment 20’ metallography, b) Rotoclene treatment 7’.

a

092 – Metal treated by

rotary treatment

Fig. 11: a) Air entrainment and bifilm formation principal, b) air entrainment within pouring

process.

b

b

Reduction of pouring

temperature

To maximize the reduction of pouring

temperature and casting solidification

time, the molten metal in the ladle is

stirred by powerful ceramic rotor This

prevents the embryonic crystals nucleating

in the melt from agglomerating and

limits the growth of dendrites and segregation

when the temperature falls

below the liquidus. Latent heat released

by solid phase formation slows down

metal cooling in the ladle and provides

sufficient time to heat up the stoper,

nozzle, and lining of the ladle very close

to the molten metal temperature.

The requirement to superheat the

steel for casting is eliminated and the

ultralow pouring temperature, already

in the range between liquidus and solidus,

ensures that heat energy can be

absorbed quickly by cold molds. This

leads to immediate solidification achieving

a very fine grain size and minimal

segregation at the grain boundaries.

Metal cast at an ultralow pouring

temperature must be protected effectively

from reoxidation and air entrainment

ideally by a ceramic shroud.

Semi-liquid metal is still sufficiently

fluid to fill up the mold cavity but pouring

time must be very short to avoid

cold shuts and misrun defects. Oxide

films and entrained air bubbles are not

able to float up to the casting surface

through semi liquid steel.

It may not be possible to produce

every casting at ultralow pouring temperature

but massive, thick-walled castings

which benefit from fast solidification

process are exceptionally well

suited to this technology. The limit to

how far below the liquidus the molten

metal stays fluid enough to be cast by

gravity is determined by the chemical

composition of the steel being cast. Carbon

and high strength low alloy steels

having a narrow solidification range

and high heat conductivity are more

sensitive to ultra-low pouring temperature

than medium and high alloy steel

having solidification ranges that are

much wider and heat conductivity that

is lower. The feasibility of casting at

ultra-low pouring temperature will

need to be considered based on the

casting size and shape, and individual

foundry experience. Nevertheless any

superheat reduction reduces primary

grain size and segregation and consequently

improves mechanical properties.

Casting defects detected by ultrasonic,

X-ray or magnetic particle

inspection (MPI) are significantly

40

STEEL MELTS

reduced and castings achieve the higher

grades of quality acceptance demanded

by final customers.

a

b

Use of the Rotoclene process

More than one thousand steel melts in

range from 3 to 20 tons have already

been treated by the Rotoclene process.

Overall casting results show significant

improvement in terms of casting surface,

internal homogeneity and metal

cleanliness followed by higher mechanical

properties compared to conventional

technology (table 2, fig. 10 a and b).

Molten metal exposed to atmospheric

oxygen forms oxide films at any

time. (fig. 11 a and b). Super clean and

temperature homogenous metal in the

pouring ladle contaminated during the

pouring process may still contribute to

casting defects [9, 10, 11]. The Hollotex

Shroud is highly recommended to protect

cast steel from air entrainment and

metal re-oxidation within the casting

process. especially in combination with

molten metal treated by Rotoclene in

the pouring ladle.

Case study: piston

This thick piston casting from carbon

steel (GS-70) was produced regularly

last 10 years and never passed inspection

without excessive welding. It’s

shape is apparently simple (fig. 12a) but

solidification time of about 15 hours

(fig. 12b) leads to excessive dendrite

growth and severe segregation complicates

feeding within the last solidification

stage.

Primary shrinkage has never been

present, but ultrasonic echo was always

lost within inspection of the bottom

hub and upper part under the riser.

Repeated heat treatment has been

applied to try to refine the grain size

and allow ultrasonic inspection but

unsuccessfully. Defective parts from the

drag (fig. 13a) and under the riser

(fig. 13b) were machined out by carousel

to a depth of 135 mm until porosity

detected by penetration was removed

(fig. 14a and b). Excavated diamater

was 300 mm in the drag and 400 mm

under the riser. Porosity detected by

penetration test was finally much bigger

than identified by ultrasonic test.

Additional annealing heat treatment

had to be applied after the welding.

The Rotoclene process has been

applied to clean up the molten metal

and reduce pouring temperature to liquidus

level. 7400 kg of steel from EAF

was treated in an 8.5 ton capacity ladle

for 32 minutes until the temperature

Fig. 12: a) Shot blasted casting, b) Magma simulation of solidification time.

a

Fig. 13: a) Porosity in bottom hub, b) porosity under the riser.

a

Fig. 14: a) Defective part excavated up to 135 mm, b) defects on the diameter are still present

and needs to be further machined.

b

b

dropped to 1495 °C, then the ladle was

transferred to the molding shop for

pouring which took 7 minutes from the

end of rotary treatment. Pouring temperature

was 1480 °C which was calculated

as the liquidus temperature of this

melt. Casting was through the Hollotex

Shroud to protect cast steel from reoxidation

air entrainment and bifilm formation.

The mold was filled within 44

seconds. Cast weight was 6400 kg and

weight of the casting 3700 kg. There

was no trace of molten metal freezing

in the ladle. This casting passed ultrasonic

inspection successfully without

welding (fig. 15).

Operation of the Rotoclene process

even under the liquidus temperature

has been tried for other castings. The

challenge is to measure metal temperature

when it drops under 1500 °C.

Thermo probes for steel suffer from

slag freezing on the metallic cup protecting

the thermocouple and mostly

does not record the temperature. Metal

was treated until the temperature

dropped under 1480°C before casting.

There was some residual metal frozen

42

Fig. 15: Sound casting.

in the ladle bottom but this could be

cleaned up by oxygen lance when the

ladle was emptied. One mold from the

ladle can be cast from such ultra low

pouring temperature significantly

under the liquidus, but the casting must

be thick and not sensitive to cold shuts

or mis-runs. Pouring of more than one

mold from the ladle might be problematic

as metal may start to solidify at the

nozzle to shroud connection.

Summary

Rotoclene – Rotary treatment of molten

steel is an innovative technology allowing

higher level of metal purification

and temperature homogenization at

the pouring ladle. Rotating molten steel

heats up the ladle lining and stopper

avoiding premature metal solidification

at the ladle and stopper freezing risk.

Treatment can be continued until metal

temperature cools down to the desired

pouring temperature regardless the

metal holding time. Steel may be further

desulfurized by synthetic slag stiring

and alumina inclusions modified to

less harmful globular shape by pure Ca.

In combination with Hollotex Shroud

pouring temperature may be significantly

reduced and cleaner castings

achieved with finer grain size and

higher levels of homogeneity.

www.vesuvius.com

[2] Chao Fan, Alexis Gosa, Lifeng

Zhang, Qingcai Liu and Dayong Chen,

The Minerals, Metals & Materials Society

(2018) Mathematical Modeling on

the Fluid Flow and Desulfurization

During KR Hot Metal Treatment

[3] N. Verma, Petrus C. Pistorius, Richard

J. Fruehan, Michael Potter, Minna

Lind and Scott R. Story, Transient Inclusion

Evolution During Modification of

Alumina Inclusions by Calcium in Liquid

Steel: The Minerals, Metals & Materials

Society and ASM International (2011)

[4] Upendra Kumar Mohanty, Hrushikesh

Sarangi, Solidification of Metals

and Alloys (2020)

[5] M. Strouhalova, Studium Fazovych

Zmen v Oceli Behem Jejiho Tuhnuti –

VSB TU Ostrava – Doctor Thesis (2018)

[6] E. Munsterova, Obecne Udaje o

Fazovych Premenach Behem Tuhnuti,

Brno (2005)

[7] R. WLODAWER, Directional Solidification

of Steel Casting book. (1966)

[8] M. Amirthalingam, E. M. van der

Aa, C. Kwakernaak, M. J. M. Hermans, I.

M. Richardson, Elemental Segregation

During Resistance Spot Welding of

Boron Containing Advanced High

Strength Steels (2015)

[9] D. Hrabina, P. Filip, Foundry Practice

267, Advances in the pouring of

steel castings with a shrouded metal

stream (2019)

[10] Ch. Beckermann & S. H. Majidi,

University of Iowa, Simulation of Air

Entrainment during Mold Filling: Comparison

with Water Modeling Experiments,
