The cardiorespiratory system

Section 3

Section 3: The

cardiorespiratory system

The heart

The heart is a muscular pump which transports blood to the tissues via the blood vessels. It is about the size of a

man’s clenched fist, and it is located behind and to the left of the sternum.

The walls of the heart consist of three layers:

• The pericardium – this layer forms a protective

sac around the heart and is also known as the

epicardium.

• The myocardium – this layer is the largest with the

greatest mass, and is formed from cardiac muscle.

The left layer of myocardium is much thicker than

the right so that it is able to pump blood around the

body.

• The endocardium – this is the inner lining of the

heart wall; it is formed of epithelial tissue resting on

a connective tissue base.

The heart is divided by the septum (the central wall) into separate left and right halves.

• The right half receives blood from the body and pumps blood to the lungs.

• The left half receives blood from the lungs and pumps blood to the body.

POINT OF

INTEREST

Root words:

Many anatomical terms are made up of

root words which give away the function,

location or structure of the subject.

• peri = ‘around’

• myo = ‘muscle’

• endo = ‘inside’

• cardium = ‘heart’

Figure 3.1: Walls of the heart


The left half of the heart has thicker, more muscular walls than the right, therefore enabling it to pump blood to a

greater distance around the body.

Anatomy and physiology for exercise and health

There are four chambers in total:

• The two upper chambers (atria) receive blood from the veins.

• The left atrium receives oxygenated blood from the pulmonary vein.

• The right atrium receives deoxygenated blood from the superior and inferior venae cavae.

• The two lower chambers (ventricles) pump blood into the arteries.

• The left ventricle pumps oxygenated blood around the body via the aorta.

• The right ventricle pumps deoxygenated blood to the lungs via the pulmonary artery.

SAMPLE VERSION | Copyright © 2022 AIQ International Qualifications. Not for resale

3

Section 3


The upper atria are smaller and less muscular than the lower ventricles. This is because the atria have a receptive

function that does not require the muscular force of the ventricles, which are required to pump blood powerfully out

to the lungs or to the body.

Heart valves

Figure 3.2: Anatomy of the heart

Heart valves are formed from tough connective tissue; they are made up of cusps, or flaps, that cover the entrance

or exit to a vessel or chamber. They open and close passively – either sucked into place or blown open, depending

on the differential pressure in each chamber or vessel.

• Semilunar valves lie between the ventricles

and arteries and prevent backflow of

blood from the chamber to the vessel.

The aortic semilunar valve separates

the left ventricle and the aorta, and the

pulmonary semilunar valve separates the

right ventricle and pulmonary artery.

• Atrioventricular (AV) valves lie between

the atria and ventricles and prevent

backflow of blood from the lower to upper

chambers. The left AV valve is also known

as the bicuspid valve (two cusps) or the

mitral valve. The right AV valve is also

known as the tricuspid valve (three cusps).


Figure 3.3: The valves of the heart

4



Section 3

Circulation

Pulmonary

arteries

Lungs

Pulmonary

veins

Right

ventricle

Right

atrium

Venae

cavae

Figure 3.4 Blood flow around the body

The right side of the heart receives blood from the upper and lower body via the superior vena cava and inferior vena

cava. The blood is saturated in carbon dioxide (CO2) and is referred to as deoxygenated. The deoxygenated blood

is ejected to the lungs by the right ventricle via the pulmonary artery.

In the pulmonary capillaries, CO2 diffuses into the lungs to be expired, while oxygen (O2) enters the blood (gaseous

exchange). The oxygenated blood travels to the left atrium of the heart via the merging venules and veins that finally

become the pulmonary vein. The left ventricle then ejects the blood and O2 via the aorta to the tissues of the body.

Once the oxygenated blood reaches the capillaries, gaseous exchange occurs – the oxygen diffuses into the tissues

and CO2 diffuses into the bloodstream.

Contraction of the heart

SA node

The stimulation starts in the sinoatrial

(SA) node.

Atria contract

The interconnected cardiac muscle

fibres pass the impulse across the atria.

AV node

The atrioventricular (AV) node

is stimulated and allows the full

contraction of the atria before

stimulating the ventricular muscle to

contract.

Body

Aorta

Left

atrium

Left

ventricle

The heart is stimulated to contract by a complex series of integrated

systems. The heart’s pacemaker – the sinoatrial (SA) node – initiates the

cardiac muscle contraction. The SA node is located in the wall of the right

atrium (see Figure 3.5). The heart muscle at rest is stimulated to contract

at a regular, rhythmic rate.



Ventricles contract

The AV node stimulates the ventricular

muscles to contract.

Figure 3.5: The contraction of the heart


5

Section 3


Resting heart rate

Traditionally it has been taught that average resting heart rate for males is 72 beats per minute (bpm) with the female

average a little higher at 78 bpm. However, resting heart rates vary considerably between different individuals

within Western populations, with research showing up to 70 bpm variations, depending on a range of different

factors. A study of 92,457 people published in 2020 found the average heart rate for the whole population group

was 65.5 bpm with a range of 40–108 bpm. However, 95% of males had a resting heart rate between 50–80 bpm

and females between 53–82 bpm.

Average Resting HR

68

66

64

62

60

Heart rate training zones

Figure 3.6: Average resting heart rate versus age

It is common practice to use the valid and reliable method of tracking heart rate data to gauge exercise intensity. To

calculate heart rate training zones, it is necessary to calculate the maximum heart rate (MHR) and the target heart

rate (THR).

Calculating maximum heart rate (MHR) & target heart rate (THR)

There is a very simple equation for calculating maximum heart rate (MHR):

Age-predicted MHR = 220 – age

58 20 30 40 50 60 70 80

For example, a 26-year-old would have an MHR of 194 bpm (220 – 26 = 194 bpm).

This theoretical calculation is known to have a level of inaccuracy equivalent to +/– 11 bpm, therefore the actual

maximum heart rate could range from 183–205 bpm.

Intensity

Age


% MHR

Very light


Section 3

Based on ACSM guidelines, most clients should exercise at a target heart rate (THR) between 57% and 100% of

MHR.

THR can be calculated by multiplying the individual’s MHR by the desired % MHR.

Using the 26-year-old above as an example, with an intended training target of 80% MHR:

THR = MHR x % MHR

THR = 194 x 80%

THR = 155 bpm

If the inaccuracy of the MHR calculation is included, then the target heart rate will have a range.

183 x 80% = 146 bpm

205 x 80% = 164 bpm

Therefore, 80% training intensity will be between 146–164 bpm.

ACTIVITY

Use the simple equation above to calculate your:

• 60% MHR

• 75% MHR

• 90% MHR




7

Section 3


Structure and function of blood vessels

As the name suggests, blood vessels are responsible for carrying blood around the body. There are various types of

blood vessels, which are differentiated by their shape, size and function.

Blood vessel Structure Function

Arteries • Thick, muscular walls.

• Subdivide into smaller blood vessels

called arterioles.

• The largest artery is the aorta, which

leaves the left ventricle carrying blood

under the highest pressure.

Veins • Thinner walls than arteries with little

muscle.

• Subdivide into smaller blood vessels

called venules.

• Contain one-way valves to prevent blood

from flowing in the wrong direction.

Capillaries • Extremely thin walls (approximately one

cell thick).

• Link arteries to veins.

• Significantly higher in number than

arteries and veins.

• Carry blood under high pressure away

from the heart.

• All carry oxygenated blood except the

pulmonary artery.

• Carry blood towards the heart under lowto-moderate

pressure.

• All carry deoxygenated blood except the

pulmonary vein.

• Allow for diffusion of gases and nutrients

throughout the body, including muscle

tissues.

Table 3.2: Blood vessel properties


Figure 3.7: Structure of the blood vessels

8



Section 3

Atherosclerosis

In a healthy blood vessel, blood flows smoothly to reach its target tissue or organ and supply it with the nutrients

and oxygen it requires for optimal function. Vascular disease is the narrowing of the blood vessels, and it is one

of the main causes of death in the developed world. It is triggered by inflammation within blood vessels and the

subsequent accumulation of mineral, protein and fat deposits. This creates a build-up of plaque on vessel walls; this

can ultimately lead to a blockage that can severely restrict, or completely prevent, blood flow. As a consequence of

this, tissues and organs can be starved of vital nutrients and oxygen.

Vascular disease is most commonly caused by the hardening of arteries – a condition called atherosclerosis (see

Figure 3.8). Atherosclerosis is initiated by the inflammatory response to vessel damage that creates plaque, using

cholesterol, protein and mineral deposits in an attempt to heal the area.

As plaque builds up, the artery wall becomes thicker, harder and less elastic. The artery narrows as a consequence

of the build-up and cannot effectively stretch to accommodate blood.

A lack of blood flow as a result of atherosclerosis can cause target tissue death unless those tissues are supplied

by blood from alternative arteries.

1 – Inflammation

Known as the ‘fatty streak’ stage because this is how

the condition first becomes visible.

Damage (e.g. caused by smoking or hypertension)

initiates an inflammatory response.

2 – Narrowing

The body tries to repair the damaged area using

cholesterol, proteins and minerals.

These substances build up, creating a ‘plaque’ that

thickens and hardens the artery walls.

The artery is narrowed by the plaque build-up.

3 – Blockage

The plaques build up so much that they rupture and

release cholesterol and connective tissue into the

artery.

The body’s protective mechanism creates a blood

clot around the rupture which further scars, hardens

and can block the entire artery. These are called

‘complicated lesions’.

Figure 3.8: Atherosclerosis

Atherosclerosis commonly affects the arteries of the heart and brain and produces varying symptoms, depending

on the tissues involved. Coronary atherosclerosis can be associated with chest pain on exertion that settles with

rest. This is referred to as angina pectoris, which literally means ‘strangles chest’, and is the direct result of

reduced blood flow to the heart muscle.


If a coronary artery is completely blocked, the area of

the heart which is deprived of blood will die, causing a

heart attack (myocardial infarction).

Blockages in small arteries in the brain deprive areas of

the brain of blood, resulting in a stroke (cerebrovascular

accident).


A combination of genetic and lifestyle factors (such

as family history, lack of exercise, stress, unhealthy

diet, being overweight and smoking) play a role in the

damage and gradual build-up of plaque within the

vessel walls.


9

Section 3


Coronary heart disease

Figure 3.9: Plaque build-up within the coronary artery

The coronary arteries are the major blood vessels that supply the heart with blood. Due to a range of different

factors, it is possible that they can begin to narrow because of arterial plaque build-up, resulting in a reduced blood

supply to the heart. This can cause angina pectoris. Angina often feels like a heaviness or tightness in the chest,

which may spread to the arms, neck, jaw, back or stomach as well. If a coronary artery becomes completely blocked,

it can cause a heart attack. Heart attack symptoms vary from one person to another. The most common signs and

symptoms are:

• Chest pain: tightness, heaviness, pain or a burning feeling in the chest.

• Varying levels of pain in arms, neck, jaw, back or stomach.

• Sweating.

• Light-headedness.

• Shortness of breath.

• Nausea or vomiting.

Risk factors for coronary heart disease (CHD)

The main risk factors for all cardiovascular disease, especially coronary heart disease (CHD) are identified in Table

3.3 as non-modifiable (cannot change) and modifiable (can change) risk factors.

Non-modifiable CHD risk factors

• Family history of heart disease.

• Ethnicity, e.g. Asian, Hispanic and Latino, African

American.

• Sex – males are at greater risk than females.

• Age – older ages groups are at greater risk.

Modifiable CHD risk factors

• Smoking.

• High blood pressure.

• High blood cholesterol.

• Type 2 diabetes mellitus.

• Overweight or obesity.

• Physical inactivity.

• Poor dietary habits.

• Chronic, high stress.

• Excess alcohol consumption.


Table 3.3: Heart disease risk factors

The greater the number of risk factors present, the higher the possibility of developing CHD. The non-modifiable

risk factors cannot be changed, but by themselves they are less likely to result in CHD without the impact of some

of the modifiable risk factors. The modifiable risk factors are mostly related to lifestyle and behaviour choices, and

are therefore subject to change to help reduce the risk of CHD.

10



Section 3

Lifestyle interventions

Addressing one risk factor, such as smoking cessation, will elicit health benefits. However, to significantly reduce the

risk of developing CHD, a broader lifestyle change approach will be required.

Important lifestyle changes that will improve health and also reduce CHD risk may include:

• Smoking cessation.

• Staying within recommended alcohol limits (1–2 units per day maximum).

• Following a healthy diet, according to recommendations.

• Maintaining a healthy body weight, according to BMI.

• Engaging in regular physical activity and exercise, according to current guidelines.

• Planning adequate rest and relaxation time, and reducing stress where possible.




11

Q6 Quorum Park

Benton Lane

Newcastle upon Tyne

NE12 8BT

T 01480 467 950

F 01480 456 283

info@activeiq.co.uk

www.activeiq.co.uk

Active IQ wishes to emphasise that

whilst every effort is made to ensure

accuracy, the material contained within

this document is subject to alteration

or amendment in terms of overall

policy, financial or other constraints.

Reproduction of this publication is

prohibited unless authorised by Active IQ

Ltd. No part of this document should be

published elsewhere or reproduced in any

form without prior written permission.


Copyright © 2022 AIQ International Qualifications. Not for resale

International Personal Training (sample manual)

Transform your PDFs into Flipbooks and boost your revenue!

Delete template?

Save as template ?
