cover story

Tooling, a key part of the

overall generating gear grinding process

written by Walter Graf

Shopfloor environment with ARGUS monitoring of process and tooling

In the precision-driven field of

gear manufacturing, the efficiency

and reliability of gear grinding

machines are crucial. This

article examines the characteristics

of Reishauer gear

grinding machines and

their integrated system approach.

While all system

components are important,

this article focuses on the

tooling, with other elements

addressed in less detail.

The Reishauer

Circle of Competence

At the core of Reishauer’s grinding

philosophy lies the “Circle of Competence”,

a holistic system encompassing

every aspect of the gear grinding

process. Instead of concentrating

solely on building machine tools,

Circle of Competence

Reishauer offers an integrated system that

includes machines, automation systems,

tooling, technol ogy, digital solutions,

and support services. This comprehensive

approach ensures

that all elements function

together effectively, enhancing

efficiency and precision in gear

grinding.

Machines:

precision and reliability

Reishauer gear grinding

machines are engineered for

precision, reliability, and high

performance. Equipped with advanced

CNC controls and modern

interface concepts, they maintain

consistent quality and machine availability.

This consistency is crucial for

manufacturers requiring high-volume

production with repeatable accuracy.


cover story

Automation: integrated efficiency

The company builds automation systems that

integrate with the gear grinding machines

to meet modern production demands. These

modular and customizable systems allow

manufacturers to tailor automation to their

specific needs. By synchronizing automation

with machine operations, idle times are minimized,

and throughput is maximized.

Digital systems:

industry 4.0 integration

Furthermore, Reishauer provides digital

solutions that are aligned with Industry 4.0

standards. The digital portfolio includes:

predictive maintenance: uses data

analytics to anticipate maintenance needs,

aiming to reduce downtime

advanced analytics: offers insights into

machine and tooling performance and

process optimization

process monitoring: tracks key

parameters throughout the grinding

operation to ensure consistent quality

Integrating these digital systems enhances the

performance and output of the machines and

the tooling, enabling manufacturers to improve

efficiency and productivity.

Tooling: an integral component

supported by digital technology

A key feature of Reishauer’s system is the inhouse

production of tooling components such

as grinding wheels, diamond dressing tools,

3D-printed coolant nozzles, and clamping

fixtures. By manufacturing these tools internally

and using a digital process monitoring

system, the company ensures they are precisely

matched to their machines and grinding

processes. This synergy between tooling and

machinery enhances performance, consistency

and reliability, highlighting that tooling

is not merely an accessory but an essential

part of the entire system.

figure 1 – Grinding wheel monitoring

whereas the finishing strokes display an increasing intensity in the same direction.

The decrease in grinding intensities during roughing indicates process-induced

wear of the threaded grinding wheel. Ideally, a calibrated force

model would maintain almost constant grinding intensities across the full

grinding wheel width. The observed drop in intensity during roughing is

attributed to continuous microscopic deterioration of the bond-grain matrix

of the threaded wheel, leading to gradually reduced material removal from

the workpieces. The increase in grinding intensity during finishing strokes

compensates for the reduced material removal from the preceding roughing

strokes. This wear effect on the threaded wheel results in an unstable process

and causes rejected workpieces, depicted as dark red dots on the lower left

side of the roughing stroke point cloud. In this case, the user had to change

the grinding wheel specification to stabilize the process.

Evaluation of the performance of clamping devices

As with the grinding wheels, the ARGUS can also assess the effectiveness of

the clamping tools. Monitoring the grinding intensity, for example, provides

information on concentricity deviations that indicate faulty clamping devices

or deviations in pre-machined workpieces. In the example shown in figure 2,

roundness differences between the two workpiece spindles, C1 and C2, can

be seen. ARGUS uses complex algorithms to simplify the interpretation of

the dynamic effects on grinding intensity and to enable process analysis

without requiring the user to have specific expertise. In this case the C2

spindle was misaligned, increasing intensities due to out-of-roundness. After

aligning the workpiece spindle C2 on reaching 4,000 workpieces, both spindles

showed an identical range of grinding intensities, as shown in figure 2

on the right side of the diagram.

Reishauer employs the ARGUS process

monitoring system to evaluate and continuously

improve tooling. This system leverages

data and analytics to optimize tooling processes,

improving production efficiency.

Evaluation of grinding worm behavior

By highlighting the synergy between ARGUS

and tooling, figure 1 illustrates the grinding

intensities across the shifting axis covering

the full width of a grinding worm for producing

over 5,000 workpieces. The upper blue

point cloud represents roughing strokes, while

the lower green point cloud represents finishing

strokes. The roughing strokes show a decreasing

grinding intensity from right to left,

figure 2 – Monitoring clamping devices


7

cover story

Advantages of large database model

Evaluation of the performance of

diamond dressing rolls

Diamond dressing tools are also monitored within the process.

Measured dressing intensities objectively evaluate a

dresser’s useful service life, often exceeding the indicated or

guaranteed dressing cycles. To be on the safe side users traditionally

perform eight roughing strokes and two finishing

strokes during dressing. With ARGUS dressing monitoring,

the number of dressing strokes can be reduced, as the monitoring

system indicates after how many strokes the grinding

worm is properly dressed.

As of September 2024, Reishauer had accumulated around

30 million grinding cycles and all associated data points,

each cycle comprising approximately one million data points,

stored anonymously in a dedicated cloud. This substantial

data pool allows for applying data science and AI for pattern

recognition and algorithm optimization. Insights gained

from data analysis are continually incorporated into updates

for the benefit of all subscribers. In terms of tooling the data

analysis leads to an objective evaluation of the performance

of tools, whether being grinding wheels, diamond dressers,

or clamping fixtures. These valuable insights are used to

improve tool performance continuously.

ARGUS minimizes tooling costs by providing detailed

insights into the condition of the tools. This insight allows

using tools to their performance limits without prematurely

removing them from the production process based on the

potentially incorrect assumption that their service life is nearly

exhausted after a predefined number of usage cycles.

Technology: addressing modern challenges

The advent of electric drives (e-drives) has introduced new

challenges in gear manufacturing, including higher rotational

speeds, increased torque, and stringent requirements to minimize

noise, vibration and harshness (NVH). Reishauer addresses

these challenges with advanced technologies such as,

for example:

twist-control grinding: manages the distribution

of twist along the gear flank to meet

specific performance criteria

polish grinding: enhances surface finish to improve

gear performance and longevity; moreover, polish

grinding reduces gear noise (NVH) in transmission,

which is particularly important in electric drives

These technological innovations enable manufacturers to

produce gears that meet the demanding specifications of

modern applications.

Services: ensuring maximum availability

A global network of service engineers and decentralized spare

parts stores ensures that Reishauer machines maintain maximum

availability. Their support services minimize downtime

and provide customers with prompt assistance, contributing

to the reliability of the entire system.

Proven performance and global adoption

With over 1,000 modern RZx60 machines operating worldwide

around the clock, Reishauer’s gear grinding machines

have demonstrated reliability and effectiveness on a global

scale. Leading automotive manufacturers and suppliers rely

on these machines to produce gear sets that meet the most

demanding standards.

Conclusion

Reishauer’s gear grinding machines stand out due to their

integrated system approach, where each element – from

tooling to digital systems – is designed to support the others.

This philosophy ensures high precision, reliability, and efficiency,

meeting the evolving demands of gear manufacturing.

By recognizing tooling as an essential part of a cohesive

system, the company exemplifies how integration and innovation

drive performance in engineering.

further information: www.reishauer.com



Superior life

and grinding speed

cool tools 2024

MICRO DRILLS FOR TITANIUM

Diameter range

Drilling depth

Machinable materials

Ø 0.2 - 2.0 mm

3 x d and 6 x d

All titanium grades

CHATTER-FREE END-MILLS


Effective length

Flutes


Ø 1.0 - 8.0 mm


Z4 and Z5

P M K N

S1 S2 S3

SUPER FINISHING END-MILLS

Cool SF

Weiler Abrasives, a leading provider of abrasives and

power brushes for surface conditioning, has announced its new

Metalynx MAX Ceramic flap discs. The flap discs feature enhanced

abrasive cloth and improved flap configuration to provide users

with longer product life and greater efficiency, removing up to 40 %

more material.

“The new Metalynx MAX Ceramic flap discs are engineered to deliver

superior life and grinding speed”, says Uroš Filipič, product manager,

Weiler Abrasives. “This allows users to remove more metal in less time, so

they can get more done.”

Metalynx MAX Ceramic flap discs feature advanced ceramic alumina

grains that maintain a high cut rate. The flap configuration has been improved

to optimize the exposure of new abrasive cloth, maximizing

the disc’s effectiveness. The innovative design increases disc life and enhances

performance, removing more material and reducing change-overs.

In addition Metalynx MAX Ceramic flap discs have a topcoat that grinds

cool, protecting high-value parts from heat discoloration. The flap discs

contain less than 0.1 % of iron, sulfur and chlorine, for contaminant-free

grinding of stainless steel and other high-value metal parts.

Metalynx MAX Ceramic flap discs are available in standard F27 and F29

styles as well as a unique angled shape. Metalynx MAX Ceramic angled

flap discs are designed for grinding fillet welds, T-joints and other hardto-reach

areas. The 90-degree angled flap design optimizes flap-to-metal

contact for improved user control and feel while grinding.

further information: www.weilerabrasives.com


Effective length

Flutes


Ø 1.0 - 8.0 mm


Z5 and Z6

P

M K N

S1 S2 S3

MIKRON SWITZERLAND AG

Division Tool

6982 Agno | Switzerland

mto@mikron.com

www.mikrontool.com


Manufactured from 99 % reprocessed carbide

A milling cutter which is extremely powerful, universally

applicable and at the same time manufactured

in a resource-efficient manner: sounds unlikely? With

the ProACT-Mill UNI and ProACT-Mill UNImax

from CERATIZIT, a tool series is now available that

easily meets every requirement.

It’s all thanks to the latest geometry and coating technologies

combined with the carbide grade CT-GS20Y, which offers

unbeatable sustainability.

Machining a wide variety of materials means constantly

adapting to new challenges. The solution takes the form of

universal milling cutters that can cope with steels, stainless

steels and cast materials in equal measure. Alongside the

targeted process efficiency, the aspect of sustainability is

increasingly growing in importance. CERATIZIT shows how

the two objectives can be reconciled – with the ProACT-Mill

universal solid carbide milling cutter series. The milling

cutters are manufactured from a particularly sustainable carbide,

which CERATIZIT calls upGRADE.

Full performance from

99 % reprocessed raw material

The upGRADE CT-GS20Y grade is the ideal choice for a wide

range of applications. “What’s special about it is the significantly

smaller carbon footprint generated during production,

compared to carbides from conventional production. We

achieve this by using 99 % reprocessed cutting tools as a raw

material”, explains Michael Wucher, global technical product

manager at CERATIZIT. Customers enjoy both economic

and ecological advantages, thanks to a specific product carbon

footprint (PCF).

The test results of the new series underline its potential:

ProACT-Mill milling cutters deliver up to 30 % higher performance

compared to other universal tools. The newly developed

coating, which brings with it additional performance

and tool life reserves, further contributes to this.

The new ProACT-Mill UNI and

UNImax power milling cutters

“With the ProACT-Mill series we’ve developed our most powerful

tool for universal milling, packed with everything that

modern milling cutters need – including CT-GS20Y, our most

sustainable carbide grade to date”, says Michael Wucher. The

variable helix pitch ensures extremely quiet running and

optimum chip removal. The ProACT-Mill UNI has an HB

shank for perfect force transmission, while the reinforced

tool core ensures even force distribution throughout the

milling process.

To guarantee unbeatable cutting edge stability, the milling

cutter has been given a radial clearance face. The face finishing

chamfer promises top surface quality with base machining,

while cutting edges with an irregular pitch specifically suppress

vibrations. Ramping milling and helical milling are

possible up to an angle of 30 °. Thanks to the impressive

milling acoustics of the ProACT-Mill UNI (even with high

infeed values and full-face milling), the machine room is

never too noisy.

The ProACT-Mill UNI with a cutting edge length of 3xDC

is particularly suitable for series production and trochoidal

machining. Innovative chip breakers in a radial design deliver

the longest possible tool life and break the chips to a length

of 1xD; these are then evenly and consistently removed due

to the special shape of the chip space. Thanks to the minimal

conical tool core, the 5-edge cutter runs very quietly even

with a high lateral width of cut.

When it comes to maximum material removal rates, the

ProACT-Mill UNImax is the ideal solution. A special geometry

design has been selected for this purpose – and is perfectly

suited for depths of cut of up to 2xDC. The tool is available

with HA and HB shanks for unbeatable force transmission

and balance qualities. With the variable tool core, optimum

force distribution was the key focus.

Data Matrix Code has all the details

All tools in the series bear a laser-applied Data Matrix Code

(DMC), which can be used to call up the data of the “digital

twin”. “This DMC contains all the information needed – once

scanned, the tool can be correctly identified and its relevant

technical data displayed. The customer can also see whether

the tool is new or reconditioned, and how often it has already

been sent to us for regrinding. And there is of course

also a link to the online shop to make reordering quick and

easy. We’ll be expanding the DMC functions in the future to

deliver an even more comprehensive service”, reveals Michael

Wucher.

further information: www.ceratizit.com



Innovative tools

At AMB ZCC Cutting Tools Europe presented

three new products, which drive lower costs and

higher quality in a variety of manufacturing processes

– the QF chip breaker, the zClamp Hydro

hydraulic expansion chuck and the SMP09 side mill

cutter. Turning, milling and reliable tool clamping

are key issues in machining.

Maximum control during

precision machining operations

The QF chip breaker is specially designed for low to very

low cutting depths, making it ideal for use on sliding head

lathe machines. The custom chip-forming elements provide

for maximum chip control during finishing operations.

In addition the positive rake angle helps to reduce

cutting forces and vibrations, resulting in extremely good

chip forming. With a peripherally ground cutting edge the

QF chip breaker also guarantees a high level of precision in

machining operations. In the case of thin-walled components

the optimally prepared cutting edge reduces vibrations,

which lowers the risk of damage to the surface and

ensures a high-quality surface finish.

At market launch the QF chip breaker will be offered with

the high-performance PVD grade, YBG205H, which is extremely

well suited for machining steel and stainless steel.

The QF chip breaker is available in positive 7 ° geometries

and includes the CCGT, DCGT and VBGT insert types.

With its new QF chip breaker available in combination

with the PVD grade YBG205H, ZCC-CT Europe offers a

solution suitable for precision machining that has the potential

to significantly increase the efficiency and quality of

custom turning applications.

New hydraulic expansion chuck

Thanks to clamping forces of up to 2,000 Nm, the hydraulic

expansion technology found in zClamp Hydro ensures

that the tool is reliably clamped in place. Here the actuation

piston is used to press hydraulic medium into the

chamber system. The expansion sleeve loops evenly against

the tool shank, which it first centers and then clamps over

the entire surface of the shank. In order to maintain the

clamping force oil and lubricant residue is pushed into the

groove, keeping the clamping surface clean and free of residue.

The chamber system is filled with hydraulic fluid, exerting

a damping effect on the clamped tool. In this way,

it is perfectly clamped in the center and features an ultra-high

concentricity (< 0.003 mm) to guarantee the best

surface quality possible. zClamp Hydro is able to guarantee

tool stability at all times and as a result of this there is also

less wear on the tool’s cutting edge. With the new tool

holder the actuation screw can be tightened to the end

stop without a torque wrench. This guarantees quick and

reliable tool changes every time.

The QF chip breaker, the zClamp Hydro hydraulic expansion chuck

and the SMP09 side mill cutter

The overall tool life is up to 40 % longer thanks to the hydraulic

expansion chuck. Another handy feature is the ability to set

the adjustable depth stop when clamping the tool.

Adapter sleeves that come in a number of clamping diameters

also ensure that zClamp Hydro is extremely versatile and

therefore economical to use. Optional peripheral cooling along

the tool shank is also available with the inserts, which has a

positive impact on chip removal and tool life.

further information: www.zccct-europe.com

TRUST IN

TECHNOLOGY

70 %

optimisation of the quality criteria

for e-mobility gears compared to

conventional components -

process-reliable with KAPP NILES

Scan QR Code

and learn more.


PCD milling program for aluminum machining

With over 30 years of experience in the development and production

of precision tools made from ultra-hard cutting materials, Horn

offers a comprehensive range of PCD milling cutters for productive

machining of aluminum. During this time Horn has proven itself in

numerous industries – and has thus become an important partner in

the field of PCD tools.

The new PCD milling program is part of this long-standing development

and complements the portfolio. Based on market experience and customer

requirements, Horn has methodically developed a complete standard program

of milling tools. The standard series range DM20 to DM90 enables

reliable machining of aluminum, non-ferrous metals and technical plastics.

With a focus on resource conservation, customized cutting edge lengths and

tool design, the tools are available from stock.

With this product program, Horn offers a wide range of standard and

special tools, from simple PCD end mills to complex and modular combination

tools. As a driving force the focus is on economical, well thought out

solutions with high productivity combined with Horn technology, flexibility

and reliability. The Horn high-performance PCD grade consists of a sophisticated

mixture of diamond grains of different sizes. As the volume percentage

of diamond increases, so do the effective hardness, toughness and cutting

edge quality. Strict quality standards and their control are a matter of

course and ensure strong performance.

Machining of aluminum

The tensile strength, elongation, hardness and yield strength of aluminum

can be influenced by alloying elements such as silicon, magnesium, copper,

zinc and manganese. The material can become soft during machining

due to heat development, stick to the cutting tool and even destroy it due to

dis rupted chip flow. It is therefore important that the material and cutting

With the new PCD milling program,

Horn offers a wide range of standard and special tools, from simple

PCD end mills to complex and modular combination tools

The Horn high-performance PCD grade consists

of a sophisticated mixture of diamond grains

of different sizes

parameters are properly matched. It depends

on the aluminum alloy, the cutting tool, the

cutting feed rate and speed, as well as the type

and quantity of coolant.

Aluminum is a versatile material that is

used in all sectors of the economy. Supplemented

by the new PCD milling program,

Horn offers a broad portfolio of optimized

tools for economical machining of the light

metal.

HORN tools for machining aluminum

The most important features of HORN’s wide

range of standard and special tools are special

chip breaking geometries with sharp inserts,

polished rake faces and coatings with

very good anti-friction properties to counter

the strong adhesion tendency of aluminum.

Carbide inserts for grooving are ground peripherally

to ensure extremely sharp inserts.

For machining aluminum alloys with a high

silicon content, the inserts are coated. The

portfolio includes coated and uncoated circular

tools and solid carbide cutters for milling.

Single-edged milling cutters with a large

chip space are also available for rapid metal

r emoval rate based on high cutting data. Ultra

hard cutting materials such as PCD and

CVD-D with precision-lasered cutting edges

are available for long service life or more complex

work. MCD-tipped tools are used for

high-polish machining of reflective surfaces

or aluminum blow moulds, for example.

further information: www.horn-group.com



Quickly to a

customized solution

With its tool configurator (HTC– Horn tool configurator), Horn

offers the possibility of supplying grooving tools in a short lead time.

Horn focuses here on the grooving insert system 117.

Following an enquiry from the customers, the HTC system offers the option

of automatically generating a tool drawing of all insert profiles. This eliminates

the lengthy design phase. The system enables quotations to be generated

together with the technical drawing within 48 hours. Delivery time for

tool holders and inserts is ten days from the time of order.

Numerous cutting edge shapes and widths are possible for the grooving

system. The inserts have a blank width of 8.5 mm (0.335") to 26 mm (1.024").

The tool system is mainly used for groove and gear broaching. Thanks

to the Greenline process, Horn offers a delivery time of five working days.

The number of pieces is limited to a batch size of fifty and is subject to the

customer’s approval of the drawing.

further information: www.horn-group.com

With its tool configurator (HTC – Horn tool

configurator), Horn offers the possibility of

supplying grooving tools in a short lead time

New catalog out!

Request your copy here:

SPR ABRASIVES

STRONGER TOGETHER

• Trusted global superabrasives supplier

• Guaranteed quality through testing and certification

• Setting new industry standards for excellence

• In-house formulated and produced coatings

• Commitment to innovation and customer collaboration

• Premium products that exceed expectations

• Exclusive Services including Laser and EDM cutting

CBN powder • Resin Bond powder • Metal Bond powder • Micron powder • Natural Diamond powder PCD & PCBN

CVD • HPHT Mono • Exclusive Services

sprabrasives.com • contact@sprabrasives.com • +49 33205 74690


Better chip control

with laser geometries

SIMTEK Präzisionswerkzeuge GmbH presented its

range of tools with 3D-lasered chip forming geometries

to specialists publicly for the first time at AMB

in Stuttgart. According to the manufacturer, lasering

the cutting edge geometry can sustainably improve

production processes in metalworking and increase

process reliability. A comprehensive selection of turning

tools with 3D chip geometries was on display.

“We have been working with our customers for decades to

develop optimal tool solutions for specific applications, particularly

in precision and micro machining”, explains

Norbert Seifermann. The CEO of the Mössingen-based precision

tool manufacturer SIMTEK played a leading role in the

development of the new 3D laser technology.

Years of development work lead to success

The company has been investing heavily in the research and

development of 3D-lasered chip forming geometries since

2018. After five years and numerous tests, the tool specialist

was able to produce high-precision 3D-lasered chip forming

geometries in series production according to individual

customer requirements outside of laboratory conditions.

In the meantime tools with 3D-lasered chip forming geometries

have also been implemented in the standard range.

SIMTEK plans to include around 100 tools in the standard

Diverse application

scenarios: lasered

chip-forming

geometries show

their strengths

particularly in complex

geometries, form tools with

different machining directions or high form depths

The simturn AX tool with

3D-lasered chip forming

geometry and internal

coolant supply (not

visible) enables the

precise machining of

deep grooves in valve

cover housings, for example

catalog range. In the future, the manufacturer intends to

continuously expand its standard range with additional laser

geometries. These have proven themselves in practice in various

pilot projects over the last two years.

“The introduction of laser geometries marks an enormous

advance in tool technology”, Norbert Seifermann is certain.

Individually designed and 3D-lasered chip forming geometries

are the most effective and economical solution for optimum

chip control. “Our tools are not only sharper and more

precise, they are also able to reliably meet the requirements

for chip control.” Long tool life and process reliability is not

only of crucial importance in sectors such as the automotive,

aerospace and medical technology industries.

The optimum design of a 3D-lasered chip forming geometry

is developed in coordination with the customer, taking

into account the component and the respective process

parameters (such as cutting speed, feed rate, cutting depth,

etc.). Thanks to this, optimum results can be achieved when

machining small diameters, running with high cutting

speeds with a high heat input, high forming depths or longchipping

materials, for example.

Complex three-dimensional chip forming geometries:

SIMTEK brought a wide range of grooving, longitudinal turning

and boring tools with 3D-lasered chip forming geometries to AMB;

this technology ensures improved chip control and

increased process reliability

The SIMTEK tool range currently includes over 11,000

standard tools listed in the catalog. In addition several thousand

individual tool concepts are created every year. The

development and design expertise is extremely high and

ranges from blanks to coating on own systems. Despite the

large number of individual tool developments per year the

company is known for its reliable delivery times. The target

delivery reliability is over 98 %, which now also applies to the

new 3D-lasered chip forming geometries.

further information: www.simtek.com


Six times higher metal removal rate


The new RF 100 AL Micro from Gühring offers an

outstanding combination of precision, efficiency and

process reliability, making it the first choice when

machining aluminum, copper and brass. With its

innovative properties and superior performance, this

tool raises the bar for micro-machining.

The world of machining is changing: while some are working

on ever-improving electric drives, others are striving to

create lighter components to increase their efficiency. All of

this means that the ISO-N group is currently considered one

of the fastest growing material groups in the machining industry.

The demand for specific tool solutions achieving the

best possible performance is also increasing in the micromachining

segment.

With the RF 100 AL Micro, Gühring has now created a

true high-end tool for these materials. The micro-precision

milling cutter meets all relevant requirements with its performance,

process reliability, burr-free finish and surface quality

at the highest level. It achieves up to six times higher metal

removal rates in rough machining than other products.

No more built-up edges

The RF 100 AL Micro has been specially developed for the

high demands of machining ISO-N materials and offers exceptional

performance and reliability. This allows the microprecision

milling cutter to strike the perfect balance between

soft, adhesive aluminum materials and high-strength alloys.

The tool consists of an ultra-fine carbide substrate, which offers

the optimum ratio of hardness and toughness for this

material group. The special, ultra-thin Carbo+ coating significantly

increases performance and, in combination with the

exclusive GühroJet internal cooling, prevents material adhesions

and built-up edges due to significantly improved chip

removal. The user thus benefits from higher application parameters,

a longer tool life and improved surface quality. The

specially developed geometry of the milling cutter with its

dynamic flute profile offers optimum stability and maximum

chip space, which also increases machining efficiency.

Tests show impressive results

In extensive tests and applications the RF 100 AL Micro

has delivered impressive results. When milling soft (3.3206/

AlMgSi0.5) and also high-strength aluminum alloys (3.4365/

AlZn5.5MgCu), the tool was able to achieve a reliable metal

removal rate of up to 81.6 cm 3 , while other products achieved

only 13.5 cm 3 . This corresponds to up to six times higher

metal removal rates, which significantly increases production

efficiency.

Another development focus was on high running smoothness.

The tool shows no tendency to swing up during either

roughing or finishing. This produces excellent, streak-free

surfaces with burr-free transitions on the component. When

finishing with a lateral infeed of less than 5 % of the diameter,

Ra values of 0.15 µm and above are to be expected, depending

on the material, tooth feed and tool diameter.

The fields of application range from the electronics

industry with the production of circuit boards, sensor carriers,

heat sinks to precision engineering, joint bodies, rail

and sliding technology, as well as connection elements or

end caps. This versatility makes the RF 100 AL Micro an

indispensable tool for companies involved in the micromachining

of ISO-N materials.

Broad product range

The portfolio of the RF 100 AL Micro includes four main

types with a diameter range of 0.50 to 3.00 mm. The articles

differ in corner radius and corner chamfer, as well as the

length versions 2.5 x D and 5.0 x D cutting edge length. The

variety of available diameter, length and corner radius or

corner chamfer combinations allows the user to always select

the most suitable tool for their specific requirements.

The RF 100 AL Micro

further information: www.guehring.de


15


Innovation in the field of shoulder machining

Boehlerit is expanding its portfolio of helical cutters

to include new slip-on versions to complement the

DELTAtec 90N Tang program.

The DELTAtec 90N Tang 90 ° corner milling cutters are predestined

for the medium machining of steel and cast iron

materials and impress with a light cut and extremely stable

cutting properties. The 4-edged indexable inserts guarantee

high productivity and low tool costs.

Boehlerit is introducing a new type of helical milling cutter

that offers optimum chip evacuation, improved surface

quality and smooth running thanks to its special design. The

innovative milling cutter is perfectly suited for efficient

shoulder machining and represents an economical alternative

to existing helical tools. The roller end mill from

Boehlerit has a newly conceived helical design that enables

improved chip evacuation. This ensures a smooth machining

process. The tried-and-tested uneven pitch of the tool helps to

improve running smoothness and reduce vibrations. Available

in slip-on versions with a diameter of 40 to 63 mm, the

helical end mill from Boehlerit offers maximum flexibility

for different applications.

DELTAtec 90N

Tang 90 °

With the special arrangement and overlapping of the indexable

inserts over the helical rise, particular attention was paid

to improved surface quality and smooth running. As a result,

outstanding results are achieved even with larger cutting

widths. “Our helical cutter sets new standards in shoulder

machining and offers our customers an economical alternative

to the popular tools already available in the DELTAtec

90N Tang portfolio”, says Patrick Schwaiger, product manager

milling at Boehlerit.

further information: www.boehlerit.com

Valuable tools for the collet industry

The development started in 1969, exactly 55 years

ago – for the first time, General Electric, back then a

manufacturer of super abrasives, offered Borazon as

an abrasive for the development of so-called boron nitride

CBN grinding wheels and pins to the abrasives

industry.

Borazon, advertised as abrasive of a new era, with its extraordinary

hardness and heat-resistance made it possible

to grind hardened steels, starting from 58 HRC, faster and

more efficient than ever before.

LACH DIAMANT developed resin-bond Borazon CBN

grinding wheels under the branding K-MX and tressex® for

the grinding of HSS and hardened steels were, from the very

start, so successful that they quickly took the place of conventional

ceramic wheels, e.g. for tool grinding.

One grinding task was immediately taken over by Borazon –

internal cylindrical grinding! LACH DIAMANT developed

G-MX grinding pins and internal grinding wheels with electroplated

bonds turned out to be an immediate success, especially

for the manufacturers of “collets”. To this day, LACH

DIAMANT provides a large portfolio of Borazon CBN

grinding pins and internal grinding wheels for all collet

manufacturers, all immediately available from stock.

G-MX Borazon CBN grinding pin, 0 6 mm, in a collet chuck

The G-MX 500 program for internal grinding is available.

Also in stock are diamond-coated internal abrasives for carbide

machining. Depending on the application, all internal

abrasives – diamond and CBN – as well as all produced

grinding wheels can be delivered in special resin, metal and

ceramic bonds.

further information: www.lach-diamond.com



The future is here

Mitsubishi Materials has developed a very special

series of grades that reaches across both milling and

turning applications. The key feature of this innovative

grades is due to the adoption of the newly developed

AL-Rich coating method.

turning grade MV9005 specialises in the high efficiency machining

of heat resistant super alloys.4

This advanced CVD coating of aluminum titanium nitride

(Al,Ti)N is a compound of aluminum and titanium that is

widely used as a coating for advanced cutting tools because of

its extremely hard and heat-resistant properties.

The combination of

atoms with different

sizes creates an

exceptionally hard

crystal structure

The hardness of (Al,Ti)N increases as the Al content ratio increases,

but with conventional technology, when the Al content

ratio exceeds 60 %, the crystal structure changes and the

hardness of (Al,Ti)N decreases.

When the Al ratio is

over 60 %, a softer

crystal phase

is formed

Milling inserts

Milling

MV1020: this grade has advanced wear and thermal shock

resistance and also achieves stable cutting at unprecedented

cutting speeds, especially when machining steel and ductile

cast iron, thus greatly reducing work time.

MV1030: the new Al-Rich coating also provides excellent

wear resistance. An unprecedented performance against sudden

breakage was also realized especially during problematic

wet cutting and when machining stainless steel.

MV inserts are extremely versatile and are available for

WWX, WSX, WJX, WSF, VPX, AHX and ASX cutters.

By using a new coating process based on Mitsubishi Materials’

own original technology the Al-Rich coating does not change

its crystal structure, even when the Al content is increased.

This allows a higher Al content and provides higher hardness

(Al,Ti)N.

Crystal image of

MV1000 series

Turning

MV9005: This grade

exceeds all current

standards when machining

heat resistant

super alloys. A range

of negative and positive

inserts and five

different chip breakers

ensure the optimum

combination for efficient

turning. Cutting

speeds up to 110 m/min

can be achieved.

Turning inserts

The MV1000 series includes two new grades for milling,

MV1020 and MV1030 for machining a wide range of materials

from alloy and stainless steels through to cast iron. The

Negative geometry inserts CNMG, DNMG, SNMG, TNMG

and VNMG types are available together with a 7º RCMT and

RCMX positive geometry types.

further information: www.mmc-carbide.com


17


Three new “crazy” high-performance cutting tools

Mikron Tool, world leader in micro-machining of

difficult materials, presented three new solid hard

metal tools for the AMB and IMTS 2024. The highperformance

bit CrazyDrill Titanium TN/TK, for all

types of titanium, and the two high-performance mills

CrazyMill Cool CF and CrazyMill Cool SF, specially

designed for delicate components. With these three

products, Mikron Tool has set new benchmarks for

high-performance micro-machining.

“The madmen from Agno” have gone full throttle again:

CrazyDrill Titanium TN/TK, CrazyMill Cool CF, and

CrazyMill Cool SF are the latest high-performance micro

tools from the Swiss-based tool manufacturer Mikron Tool.

Over the past 25 years they have established new standards in

the machining of difficult materials and won several industry

awards for their Crazy Tools.

Let’s start with the CrazyDrill Titanium TN/TK. This

microdrill has been developed especially for drilling in all

titanium alloys, including pure titanium (!), at diameters

from 0.2 to 2 mm and depths of 3 x d and 6 x d. It can be used

from 15 bar internal cooling already, so a high-pressure cooling

lubricant system is not absolutely necessary.

The design of the new CrazyDrill Titanium TN/TK microdrill

includes the following features:

The CrazyMill Cool SF

has been developed as a

superfinishing mill

that produces milled

surfaces at a grinding

or polishing level

of quality

• a tip geometry tailored to all titanium grades,

which guarantees a low axial cutting force and,

together with the designed drill outer profile,

ensures maximum drilling precision

• polished grooves for reliable chip removal

• coating specially designed for titanium material drilling

This means the high-performance CrazyDrill Titanium TN/

TK bit is capable of drilling all titanium alloys and even pure titanium

with high process reliability. The CrazyDrill Titanium

TN/TK provides maximum feed rates, very long service life,

optimal process reliability, and very high drilling precision.

High-performance milling with excellent

surface quality, up to ground finish quality

Two new high-performance mills have been developed for

milling applications. One is the “Chatter-Free” (CF) CrazyMill

Cool CF and the other is the “Super Finishing” (SF) Crazy-

Mill Cool SF.

CrazyMill Cool CF – chatter-free

The CrazyMill Cool CF is a high-performance micro mill

designed for very high machining rates and capable of handling

very challenging, delicate component structures. A

perfect balance between cutting angle, clearance angle and

cutting-edge conditioning results in a low radial cutting force

and thus ensures the best form and squareness tolerances

even at maximum depth of cut.

Mikron Tool developed a high-performance drill for all types

of titanium and two highly efficient precision mills,

specifically designed for delicate components

Its specific cutting geometry, combined with a dynamic

milling process, makes it the ideal mill for delicate, thinwalled

parts, or for parts that are not stable when clamped,

which is a particularly common occurrence in the medical

field (bone plates) and aerospace industry (structural components),

as well as the watch industry. CrazyMill Cool CF

is also very efficient, precise, and runs quietly when cutting

grooves, insets, or other large volume machining tasks.

The mill is immediately available in diameters from

1 - 8 mm and two different full cutting lengths (3 x d and 4 x d).



The CrazyMill Cool CF is a high-performance micromill

designed for very high machining rates and capable

of handling delicate component structures

The CrazyDrill Titanium TN/TK microdrill has been

developed especially for drilling in all titanium alloys,

including pure titanium (!), at diameters from 0.2 - 2 mm

and depths of 3 x d and 6 x d, especially under production

conditions designed to work without high-pressure

cooling lubricant systems

CrazyMill Cool SF – superfinishing

at less than Ra 0.3 µm

The CrazyMill Cool SF has been developed as a superfinishing

mill that produces milled surfaces at a grinding or polishing

level of quality, with roughness of less than Ra 0.3 µm.

This greatly reduces the effort required for polishing. The

CrazyMill Cool SF also produces excellent surface quality of

less than 0.3 µm in (chromium) steel, lead-free brass, copper,

cobalt-chromium, and Inconel.

The CrazyMill Cool SF is immediately available in diameters

from 1 - 8 mm and two different full cutting lengths

(3 x d and 4 x d). “Visitors at AMB and IMTS had the opportunity

to explore the latest ‘crazy’ innovations at the Mikron

Tool booth and even experience test workpieces firsthand. In

short, the ‘Madmen of Agno’ are always eager to welcome

users in search of ‘crazy manufacturing solutions.’

further information: www.mikrontool.com

Platinum Tooling named North American distributor

for Tecnicrafts

Effective immediately, Platinum Tooling

Technologies, Inc., will be selling products from

Tecnicrafts Industries, a manufacturer of collets and

guide bushings for Swiss Type CNC lathes.

Tecnicrafts is an ISO 9001:2015 certified company, with its

manufacturing plant in South India with state of the art machine

tools and 115 technicians. Tecnicrafts collets and guide

bushings are exclusively used for Swiss Turning applications

on Citizen-Cincom, Tsugami, Star, Tornos, Hanwha, Traub,

Hardinge, Manurhin-Kmx, Miyano, Nomura and other popular

machine brands and are widely recognized and accepted

by customers in Europe and Asia.

Collets

The collets are offered in steel and carbide lined versions with

grooved, smooth, serrated bores in standard and Long Nose

types. Tecnicrafts produces special collets such as V-Line, U-

Line, Over-grip collets, for positive gripping of delicate parts

without marks. The Ultra Precision (XP) W-Type collets are

available for tool grinding applications on machines like

Rollomatic, Anca, Ewag and others. Other collets offered includes

5C and 16C types.

Guide bushings

Tecnicrafts guide bushings are generally offered in carbide

lining having Super Finish bore with roughness value of

less than 0.4 micron. These special guide bushings include

U-Line, Extended Nose and Long carbide bores (Max Land)

for special turning applications.

Bar feeder collets

The Bar feeder collets are available for various bar feeders like

Fedek, LNS, Ikura-seiki, Iemca, Citizen, FMB and other popular

brands. All collets and guide bushings are offered in Standard

and Ultra-Precision grades. The bore profile includes

round, square, hexagon, rectangular and profile bores as per

customer drawings.

Platinum Tooling Technologies, Inc., with its expertise in

precision tooling and customer representatives throughout

North America, is ready to meet the work holding tool needs

for Swiss Turning applications with this new Tecnicrafts

product line on its roster of quality tooling.

further information: www.platinumtooling.com


19

news & facts

Setting an example for the future

TIGRA is once again drawing attention

on itself with an impressive investment

in the future. The company has put

a large-scale photovoltaic system into

operation on the factory premises in

Oberndorf am Lech – a sustainable step

in the region.

The ultra-modern system is spread over two

areas: over 500 solar modules have been installed

on the roof of the new production hall,

and a much larger installation with over 2,000

high-performance modules extends over the

neighbouring open space. Together they generate

an impressive total output of 1.5 MWh –

enough to cover sustainably around 25 % of

the company’s energy requirements.

TIGRA paid particular attention to the protection

and maintenance of the system. Not

only were the open-space modules carefully

fenced in, but the company also favoured a

charming and environmentally friendly solution

for grounds maintenance: sheep take over

the natural lawn care under the solar modules,

thus ensuring a harmonious interplay between

technology and nature.

This forward-looking project, the planning

for which began in 2022, was successfully com -

pleted August 2024 after intensive prepa ra tion

and careful implementation. The investment

Photovoltaic system on the factory premises in Oberndorf am Lech

of a proud 1.5 million Euro is a clear statement: TIGRA wants to take responsibility

not only economically, but also ecologically.

All of the green electricity generated is used directly within the company,

which significantly reduces dependence on external electricity supplies and

lowers running costs. The fact that this sustainable energy source flows

entirely into the company’s own operations is proof of the high in-house

energy requirements that are permanently necessary for the production of

high-precision carbide parts for the tool industry and the consistent focus on

the use of green energy.

With this initiative TIGRA is demonstrating how regional companies can

actively shape the future – with a clear vision for sustainability and responsibility

towards future generations.

further information: www.tigra.com

Strategic realignment

The Fair Friend Group (FFG) has initiated

a comprehensive strategic realignment

to address the current global challenges

in the machine tool industry and

to strengthen its competitive position.

CEO

Dr. Sebastian

Schöning

CFO

Rong-Rong Liu

As part of this transformation FFG has appointed

Dr. Sebastian Schöning as its new

chief executive officer (CEO). Dr. Schöning,

who holds a PhD in mechanical engineering,

brings over 20 years of professional and management

experience. Since 2021 he has served

as the group’s chief operating officer and as

CEO of MAG IAS GmbH. In his new role

Dr. Schöning will spearhead global strategy

development and lead the group’s operations.

He will be supported by Ms. Rong-Rong Liu,

who has been appointed chief financial officer

(CFO) and will be responsible for overseeing

the group’s financial management.

A key element of the realignment is the increased leveraging of synergies

among Fair Friend Group’s globally operating companies. This enables

FFG to provide customers with even more integrated and customized solutions.

Additionally FFG plans to expand its range of standard machines and

develop new technologies in emerging industries such as humanoid robotics

and energy. By deeply integrating artificial intelligence, smart manufacturing,

energy effi ciency and decarbonization, FFG aims to ensure futureoriented

and environmentally friendly production. Customers will benefit

from a wide range of highly specialized machines and manufacturing

systems, allowing manufactures to respond flexibly to both regional and

global market demands.

further information: www.ffg-ea.com


news & facts

New location in Mexico supports

strong industrial growth

On August 22, 2024, SCHUNK officially opened its

new location in Santiago de Querétaro, Mexico. The

building has its own assembly and manufacturing

capabilities as well as a CoLab application center for

automation and depaneling technology.

This enables SCHUNK to serve the industry in North and

South America with customized applications. The new location

is geared towards future growth, so the company can

be capable of responding to the increasing market demands

with high flexibility and efficiency.

The high-tech center Parque Tecnológico Innovación in

Santiago de Querétaro, about 200 km north of Mexico City,

is now home of SCHUNK. The new location will strengthen

its global presence. The building, with an area of around

5,000 m 2 , houses assembly and manufacturing capacities for

the most important components and applications to offer

regional and local customers specific solutions with particularly

short delivery times. In addition the engineering capacities

will be expanded at the new location and the CoLab application

center for automation and depaneling technology

will be put into operation.

Industrial investment focus Mexico

Mexico is a major investment destination for several key industries,

especially in the automotive and electronics industries.

International companies are expanding their activities

here or planning to do so. SCHUNK is prepared to give

support with appropriate, efficiency-enhancing production

technology as well as engineering know-how and advice.

Marcos Sepúlveda, general manager in Mexico, says: “We are

now able to serve the needs of customers across the Americas

In the new location in the technology parc of Santiago de

Querétaro, 80 employees are now working to serve the

North and South American markets

with a particularly responsive approach. In the future we

expect a higher demand for customized orders, which we will

now meet with a strengthened on-site set-up.”

Rapid growth is planned

The location in Santiago de Querétaro begins operation with

around 80 employees. To meet the anticipated strong demand

and serve the local market with engineering, manufacturing

and assembly expertise, rapid growth is planned for

the coming years. Kristina I. Schunk, CEO of the company,

says: “The strategic expansion in Mexico strengthens our

global presence, as well as the future viability of our company.

As in other regional markets we are focusing on building a

network of partners hand-in-hand in Mexico to optimally

serve our customers.”

further information: www.schunk.com

New member of the MAPAL Group

The MAPAL Group has acquired X-Pro S.r.l., an Italian

specialist for turnkey projects and fixtures. “X-Pro

fits perfectly into the MAPAL Group”, emphasises

Dr. Jochen Kress, president of the MAPAL Group.

“We are a recognized specialist in the development of complete

projects, with the focus so far being on our excellent

cooperation with machine tool builders and on large-scale

projects for the automotive industry.” With the expertise and

know-how of X-Pro, MAPAL is creating additional capabilities

to be able to offer projects quickly and comprehensively

to customers in other focus industries as well. The company

is thus meeting a global demand from potential customers,

who want to completely outsource the design of machining

processes to a reliable technology partner.

MAPAL has been working successfully with X-Pro on the

Italian market for several years. Claudio Gabos, chief sales

officer of the MAPAL Group: “We are convinced that the

acquisition of X-Pro will enable us to tap additional market

potential even in these challenging times and generate momentum

for further development.”

X-Pro S.r.l. was founded in 2001 in Bologna, Italy, and

employs about 35 people. Stefano Vitali continues in his role

as managing director in charge of the organisation.

further information: www.mapal.com


21

news & facts

LACH DIAMANT – 100 Years

Tradition. Passion. Innovation.

part 11:

The question was: “If not now, then when?”

LACH DIAMOND INC. is founded

“When I held my first diamond in my hand in 1908, I would not have

imagined that one day diamonds would not only be used in the automobile

industry but also for the machining of wood and plastics”.

Jakob Lach, the company founder, said this on camera in 1980. It

would become the preface for the first presentation of a new technique

for machining wood and plastics – using diamonds as cutting

material – the Dia Tool. This video, with audio translated into multiple

languages, has lost none of its relevance for the choice of appropriate

tools within the furniture, flooring and composite industries; the

video can be viewed at: https://bit.ly/LACHDIAMANT

Should you, dear reader, have stumbled over the final sentence in my last article

“The adventure diamonds love wood in America had begun”, perhaps

with the thought: “Oh, I always thought that since 1969, LACH DIAMANT

had risen to its position as an innovative partner of the automobile and

supply industry with the development of Borazon T CBN grinding wheels

for HSS tool grinding and grinding of high-alloyed steels, as well as, in 1973,

with the manufacturing of the first polycrystalline diamond (PCD) cutting

tools – but now wood?” Then my answer is: yes and no – let’s just try it.

The following three trademarks illustrate and symbolize the 100-year-long

entrepreneurial activity of the company Jakob Lach, founded by my father in

1922:

First, the brilliant, the cut jewellery

diamond until 1960. Natural diamonds

were cut in LACH diamond shops in and

around Hanau with 600 employees.

The industrial diamond from 1960 – 2000, was set

in a holder and used for dressing conventional

grinding wheels, and also served as a symbol

for set polycrystalline diamond tools

(PCD and PCBn) e.g.

Symbol for all

high-performance tools/milling

cutters/drills etc. PCD/PCBn, CVD, Mono

from 1979 until today. After the fusion of

LACH-SPEZIAL-WERKZEUGE GMBH

Company founder Jakob Lach, 1894-1984

(photo taken in 1980)

with the LACH DIAMANT enterprise on

January 1 st , 2000, the entire portfolio of both

companies was combined under this registered

trademark. Included were traditional

industrial diamond tools, diamond dressing

tools, profiling and forming tools, “Dia-

Fliese-perfect”, multi-point dressers, precision

diamond dressing rolls, diamond and

CBN grinding tools, diamond pastes and

“Diamant-Spray MF”, as well as the entire

LACH DIAMANT machine programme for

the eroding of diamond PCD tools for the

machining of wood and plastic, manufacturing

and service, among others with the

“Dia-2200-mini” … a long list of products,

incorporating pioneering advancements

which are state of the art technology today.

The first steps in America

It must have been for this reason that I felt

compelled to venture out into America, a

country unknown to me (see part 10 of this

article series).

Frankly speaking, I never had the intention

to conquer this huge country all by myself

with this new technology “Diamond

for all wooden materials”. Remember what

was said during the first presentation of

LACH-Diamant tools for wood processing

during LIGNA 1979 in Hanover:

“Lach must have gone crazy – he wants to process

wood with diamonds.”

It was a blessing for the manufacturer of

super-abrasives, General Electric in Columbus,

Ohio.


news & facts

Technology, in this case LACH, had shown GE a way to expand

the production of polycrystalline diamonds (PCD) and

therefore make it finally more profitable. So far, PCD turning

tools only required ONE diamond – however, milling cutters

needed many more, depending on the number of teeth.

So, it might not be surprising that I took this step with

confidence. GE wanted to sell more diamonds (PCD), and

LACH had not only the expertise but also the matching tools.

In particular it was the diamond cutting tool (PCD) for the

wood and plastic industry, superior to carbide, PLUS the

know-how to manufacture these diamond-armoured tools.

LACH DIAMANT’s key invention made this possible: spark/

electrical erosion “EDGplus®” (EDG = Electrical Discharge

Grinding Technology).

In short, LACH intended to bring this technology to

the USA as well. After all we had the experience with such

transfer of know-how (see part 9 of this article series, cues

“Israel” and “Asahi, Japan”).

There were interested parties – according to GE – in the

United States; we intended to visit them individually. In for

a penny, in for a pound. So we designed an ad and placed it

in The Wall Street Journal on July 15 th , 1982:

“CUTTING TOOLS Revolutionary new technology”

With the help of my

assistant Rita Stein-

Junkuhn we put to–

gether a travel route in

order to visit approximately

100 interested

companies who had

answered to our ad.

My wife Margot accom

panied me on this

4-to-5-week strenuous

journey from the US

West coast all the way to

Boston in New England

in the East. We met

Ad in The Wall Street Journal with the top decision

makers in the management

of all the companies we visited, ranging from conglomerates

to medium-sized tool manufacturers.

Apart from friendships which lasted for many years on

a personal and business level, these answers showed that

the American companies were not yet open to a successful

project like ours at the time. By the way, during the later

launch of the diamond tool in the USA, we encountered similar

counter-arguments.

Since the diamond tool was at least ten times more expensive

than traditional carbide tools, critics stated that the diamond

tool would not fit into the existing “3-months budget”.

All arguments that the diamond tool had a 300-350 times

longer tool life, were ignored. Interestingly this rejection

came mostly from large scale industry companies; privately

owned companies showed less resistance.

After evaluating our tour, GE also agreed that we had to

find another way for America. Chance played into our hands.

Mr. Theo Leon, born in Belgium, applied in Hanau after he

had completed his job as interpreter and marketing staff

member at a major machine manufacturer in Cincinnati.

He worked out a new marketing plan which considered the

American mentality, and aimed for exhibiting at the next US

wood tradeshow in Louisville, Kentucky, so that we could

better reach and convince potential licensees.

Up to the date of the Louisville show events moved at unprecedented

speed. GE was of course in favour of this project

– general manager Louis Kapernaros even suggested to

generously support LACH. A few weeks before the event our

employee Theo Leon succeeded in his search for Germanspeaking

personnel for our tradeshow stand. That is how

we met Karen Deutschler who had worked for an American

bank in Frankfurt, and she and her husband now lived in

the USA. We communicated frequently, and as a result, she

was hired AND we founded LACH DIAMOND INC. as a

Delaware corporation just a few days before the start of the

Louisville show.

Our presentations focused on our success and numbers

since 1979 when diamond tools were first used in the wood

and furniture industries in Germany, Italy, the Netherlands

and Spain. Additionally we showed a selection of PCD tools,

and wood and MDF/composite samples made with such tools.

First experiences

Even in hindsight, I must say that we could not have done it

any better. My proposal focussed on licensing. Most reactions

were something like “Sounds interesting, surely something

for the future, maybe we can talk again in two years”, and I

countered that “if you don’t participate in the market launch,

how is the market supposed to develop in this direction?”

Foundation document for Delaware Corporation


23

news & facts

LACH diamond tools at the first USA tradeshow in Louisville,

well guarded by a sheriff

Our tradeshow team, relaxing after an eventful day;

left to right: Theo Leon, Karen Deutschler, Dieter Claus

(product manager LACH-SPEZIAL-WERKZEUGE GMBH),

my wife Margot Lach and me

The decision was made. I would do the market launch

myself; even major tool manufacturers in Germany had at

that point no interest in expanding their carbide tool portfolio

and adding “diamond”.

At the Louisville show, the tradeshow stand became an

attraction. Probably also because our exhibited diamond

tools were moved back and forth on an LGB model train

track, under the watchful eyes of an armed sheriff.

Appearance: the Viking

The good mood and motivation also carried over to our new

friend, Mr. Matsui from the show in Los Angeles (see part 10

of this article series) who was also exhibiting with his company

HEIAN at the Louisville show. The president of his company

had commissioned him to negotiate a licensing contract with

LACH. Our meeting took place in a nearby Japanese restaurant

where the tables were separated in typical fashion, with

sliding doors made of tissue paper.

In the midst of our lively and noisy discussion about the

future of diamond, one of the sliding doors suddenly opened,

without any advance warning. A stout, brawny Swede – much

resembling a Viking – dashed to our table, “armed” with a

piece of paper which he slammed on the table. “Carbide is

always better than diamond” we read, and also noticed the

terrified look in our Japanese friend’s wide-open eyes. The

giant had slammed the sliding door and had disappeared

without a word. Our lively, and so far promising, discussion

ended abruptly, and – after a brief “retreat” meeting – we continued

our talk on the edge of our bed in our hotel room.

In the evening, we had an appointment in Lancaster, in the

(allegedly) second-longest American western bar. Gigantic.

Above three bars on the sides of the room I discovered a ticker.

I was briefly distracted, and all of a sudden, I read a new text:

“Diamonds are always better than carbide.” Who had done

that? Deep breaths, okay, my wife … the evening and the day

were saved.

By the way, the first large presentation at the tradeshow

in Louisville was excellent, and LACH DIAMOND INC.

had been founded and celebrated its anniversary together

with LACH DIAMANT Germany in September of 2022 –

LACH DIAMANT in Hanau 100 years, and

LACH DIAMOND INC. 40 years.

Horst Lach

“From now on, only LACH DIAMOND tools

for mass production” – words from our very first enthusiastic

customer, Bob Mitchell of August Lotz Company

p.s.: you can read

part 1 to 10 of this article series

“100 Years LACH DIAMANT”

here ☛

further information: www.lach-diamond.com


news & facts

Technology partnership driving

cloud-based CAM automation

ModuleWorks, a leading innovator in

toolpath generation and simulation

software for digital manufacturing,

and Toolpath, a developer of a new

cloud-based, AI-driven manufacturing

workflow automation platform, have

signed a multi-year technology partner -

ship focusing on accelerated deployment

of innovative cloud computing technology

for machining estimation and CAM

automation.

The ModuleWorks and Toolpath teams outside

the ModuleWorks office in Aachen, Germany

The technology partnership focuses on accelerating the development of

unique and innovative software solutions that automate tasks for shop

owners, estimators, planners and CNC programmers. Since its introduction,

the Toolpath platform – built using specialized optimization methods and

artificial intelligence – has included proven technology from ModuleWorks.

The extended technology partnership will focus on accelerating the performance

of both companies’ software and the eventual integration of the full

range of ModuleWorks functionalities into the Toolpath platform.

Al Whatmough, CEO of Toolpath, explains: “Toolpath’s vision is to empower

manufacturing professionals from the front office to the shop floor

with a tool that, much like an autopilot in aviation, allows them to focus on

higher value tasks as opposed to the time-consuming but necessary tasks

of reviewing incoming RFQs, evaluating the machinability and viability of

potential work, and then calculating the cost estimates based on real-world

variables like their actual tooling and machining resources.”

To accomplish their mission, Toolpath has already started building a

strong network of advisors drawn from the broad machining community,

and many of their executives have been actively engaged in the industry over

the past ten to fifteen years. Additionally they are developing highly optimized

algorithms and AI solutions. They are committed to delivering what

machinists deserve and they trust ModuleWorks as a dedicated partner in

their journey.

“ModuleWorks and Toolpath have an aligned vision”, said Dr. Yavuz

Murtezaoglu, founder & managing director of ModuleWorks. “We want

to develop the best technology – empowering professionals in manufacturing

– and get it to them fast. This is only possible with trusted partnerships

and aligned software development. Because Toolpath has leveraged

ModuleWorks technology from the beginning, we can move quickly to empower

users with highly intelligent cloud-based manufacturing solutions for

machining estimation and CAM automation.”

further information: www.moduleworks.com

Guill announces Guill Tool Europe

Gerjan ter Wal

sales manager Europe

Guill Tool, the global

leader in extrusion

tooling, recently announced

their expansion

in the European market with the

creation of Guill Tool Europe.

They will offer a full line of Guill products,

as well as sales and engineering support

throughout Europe. Padraic Lunn Enterprises Ltd will continue to represent

Guill in the UK. From concept design to engineering, manufacturing

and supporting client processes, Guill has more than sixty years of experience

in regular extrusion, multi-layered applications, jacketing, multi lumen,

rubber, silicone and much more. The company maintains the highest quality

standards regardless of application.

Padraic Lunn Enterprises Ltd offers a full range of extrusion machinery

and consultancy for all extrusion processes with a strong emphasis on tubing,

wire, pipe and profile applications. The firm represents extrusion equipment

companies in the UK, Ireland and other parts of Europe.

With local sales representatives in each country, Guill looks forward to

establishing a strong presence on the European continent.

further information: www.guill.com


25

processes

A new level of flexibility in gear grinding

KAPP NILES, a globally operating group of

companies providing solutions for finishing gears and

profiles, has reached a new milestone thanks to the

new KNG 350 machine series.

The KX 300 P gear center was already a true success story.

The fact that more than 500 machines have been sold proves

how successful the concept has been, with a combination

of high flexibility and productivity. This is where the new

KNG 350 series story begins. When designing this new machine

platform, KAPP NILES took a look back at previous

developments. Tried-and-tested solutions were adopted and

further optimized, while adding new capabilities.

This has led to a sophisticated modular system which provides

a uniform basis for various machine concepts. Thanks

to three different configurations for the tool and workpiece

drive, the customers’ requirements can be catered perfectly.

Flexible robot loading

by means of intelligent components (smart tooling). Process

monitoring, part tracing and inline quality assurance are

available as an integral component for an industry 4.0 capable

processing machine.

The gear center has an excellent design (iF Design AWARD),

and a view to further development concerning energy efficiency.

The hydraulic functions, reduced to a minimum, are

provided by a controlled pump unit, and pneumatic functions

have largely been replaced by electric drives. Moreover,

when considering the entire lifecycle of the machine,

the switch from a machine base made of cast iron to one

made of polymer concrete reduces the overall CO 2

equivalent

of the machine. These aspects being increasingly important

to OEMs.

KNG 350 flex gear center

The machine concept

The KNG 350 series is based on a compact, optimized set-up

machine concept and is perfect for the job shop environment

to large-scale series production of geared components with

diameters of up to 400 mm. Thanks to the integrated ring

loader, non-productive times are reduced up to 5 s, and bore

parts as well as shaft-type workpieces up to 700 mm length

can be auto loaded. The concept provides full flexibility when

loading the components – from manual loading or simple

pallet conveyors up to complex robot solutions.

The functional and ergonomic machine design paired

with the user-friendly interface KN grind supports the user

during set-up and optimisation of grinding projects. A major

aim was also to reduce non-productive times. So the series

is characterized by short set-up times, which are achieved e.g.

The assessment from the long-standing partner Scania in

Södertälije/Sweden provides an example. Anders Urefors, responsible

maintenance technician, has followed the technical

evolution since the KX 300 P. He recently saw the KNG 350

during the technical machine acceptance and was excited

about the results. Things that previously had to be implemented

upon individual customer requests have now become

standard, like the height-adjustable operator panel. In addition,

one is now much closer to the workpiece and tool axis

when opening the operator door. Together with the quickchange

systems for complete workpiece-dependent tooling,

a new benchmark has been set for the machine set-up. It is

immediately noticeable that ergonomics and usability were

heavily emphasized in the requirements specifications during

the development of the machine. “Lessons learned”, said the

usually rather reserved Swede.

KNG 350 expert

The starting point for the new series was the expert machine,

with an exclusive focus on the generating grinding of gears.

The concept of a grinding spindle without counter bearing


processes

Especially when it comes to electrically driven commercial

vehicles, there is currently a trend towards gears with greater

diameters. While typical gear wheels for trucks used to

have diameters of no more than approx. 300 mm, current

components can reach diameters of up to 350 mm, or even

400 mm in individual cases. The KNG 350 flex machine is

also equipped to handle such cases thanks to the optional

diameter extension.

Optimum operability

has already been proven in the DYNAMIC machines. The

automatic HSK interface allows for a semi-automatic tool

change, which is implemented consistently in both the expert

machine and the other variants of this machine series.

The machine features high-performance technology options,

for example bias-free grinding of gears or, in order to meet

greater surface requirements, by using combined grinding

worms. Thanks to selectable dressing methods all requirements

are met in a cost-efficient way, from single item production

(topological dressing) up to mass production (multiribbed

dressing). An integrated measuring device is available

for all machines of this family. The probe allows for a complete

gear measurement within the machine and is also used

to cyclically measure definable gear characteristics.

KNG 350 flex HS

E-mobility presents new challenges when it comes to the production

of gears. High power density in a compact space in pas -

senger cars, and miniaturisation for complex bicycle drives

often lead to challenging workpiece geometries for ma nufacturing.

In the past the hard fine machining of gears with

interfering geometries was primarily implemented by means

of discontinuous profile grinding or gear honing, because the

typical grinding worms with a diameter of 300 mm were too

large for components with interfering contours.

However compared to continuous generating grinding, both

profile grinding and gear honing have disadvantages in terms

of productivity, economic efficiency and consistent quality.

In order to achieve high cutting speeds with smaller tool dia -

meters, smaller grinding worms require state increased

RPM. Previous machine concepts were not designed to meet

the substantial dynamic requirements regarding tool and

workpiece drives.

The KNG 350 flex HS is characterized by superior grinding

quality and productivity, even if such small tools are used.

Thanks to a high-speed grinding spindle (HS) with a speed

of 25,000 rpm even gears with interfering contours can be

ground using tools with a diameter of at least 55 mm (generating

grinding) or 20 mm (profile grinding).

KNG 350 flex

A bit bigger? When machine tool manufacturers ask this

question, it’s not about getting bigger portion sizes for lunch.

The performance-optimized grinding spindle with counter

bearings allows cutting speeds of up to 100 m/s and is designed

for the use of large grinding worms with widths of

up to 200 mm. This allows an efficient realisation, especially

when machining components with large modules and using

2-sector worms for fine grinding or polishing applications.

Using a standard tool, values of an average roughness depth

Rz = 2.5 - 3 μm can be reliably achieved with continuous gener -

ating grinding. For higher requirements the company offers

tool sets with two different zones: one featuring standard grit

and another designed for fine or polishing grinding, depending

on the surface requirements. This makes it possible to

achieve roughness values of Rz < 1 μm. The significantly increased

bearing ratio of the tooth flanks boosts the maximum

load capacity of the gear. Another advantage of this process

is the integration into automated process chains with “onepiece-flow”,

which was not possible with the vibratory finishing

that was often used in the past. As a unique selling point

polishing as a single technology is offered, for example in

order to only polish gears after shot peening.

Various tool axes of the KNG 350 series

Two further aspects highlight the flexibility of this machine.

Due to the use of auxiliary spindles very small grinding

wheels with the minimum root circle of the gear to be grind

can be applied. The integrated set-up ratio enables a cutting

speed of up to 50 m/s even with a grinding wheel diameter of

30 mm. Both involute internal gears and special profiles can

be machined with the internal grinding device. Thanks to the

new quick-change interface, auxiliary spindles and internal

grinding arms can be directly and quickly set up on the tool

spindle.

External and internal gears of small and large workpieces

can be machined both by generating grinding and profile

grinding, depending on the application, with dressable

corundum or non-dressable CBN tools.

This machine type truly deserves the name “flex” and

leaves nothing to be desired in terms of gear grinding.

further information: www.kapp-niles.com


27

processes

Centerless grinding rethought

Innovative machining concept for thin-walled round workpieces

When bearing manufacturers are

looking for a machining solution that

delivers maximum precision with repeat

accuracy and is also economical, all roads

lead to Switzerland. One of the companies

based there is the grinding specialist

Kellenberger, whose production concept

on a VOUMARD 1000 has completely

won over leading companies in the bearing

industry.

When it comes to precision machining of

thin-walled sleeves or rings that are to be

ground internally and externally in a single

clamping operation, an intelligent clamping

solution is required above all. This is because

thin-walled workpieces, such as roller

bearing rings, must not be deformed during

clamping. At the same time the clamping system

must ensure absolute concentricity of the

outer dia me ter to the inner diameter during

machining.

The most obvious clamping solution is of

course a magnetic chuck, which serves to

fix the workpiece on the face side and generates

the workpiece speed. However especially

with thin-walled rings with a very small contact

surface to the magnet, it can be difficult

to build up the necessary static friction so that

the workpiece is not pushed out of position by

the grinding forces. The workpiece must also

be centered on the chuck, which takes quite

some time and requires operator intervention.

To counter this, two adjustable support shoe

devices are used to keep the workpiece centered

in rotation during the grinding process.

They also counteract the grinding force

exerted by the grinding wheel and the force of

gravity. This variant of centerless grinding is

known as “shoe-type centerless grinding”, but

is casually called “shoe grinding”.

Exemplary clamping device for bearing production:

magnetic chuck and support shoe device

direction, the workpiece is supported by the shoe fixtures, which enable very

precise positioning and support. The workpiece can therefore be inserted

without alignment. The rotation of the workpiece during machining results

in a stable position.

The front shoe (support shoe) supports the workpiece in front of the grinding

area and absorbs the weight forces. The rear shoe (measuring shoe) supports

it behind the grinding area and defines the component diameter. This

additional support enables greater dimensional accuracy and surface quality.

It also allows the workpiece to be changed quickly, which can also be done

automatically.

Voumard 1000

Shoe-type centerless grinding is a special

variant of centerless grinding. It enables,

for example, precise machining of the outer

and inner form surfaces of bearing rings in

one single clamping operation. In this process,

the magnet forms the stop for the workpiece

in the axial direction, as in normal

work with the magnetic chuck. In the radial


processes

Unique machine concept:

the patented B2-axis with table turret of the VOUMARD 1000

Michael Egeter, head of design at Kellenberger, sees the

design of the VOUMARD 1000 as the ideal prerequisite

for fully exploiting the advantages of shoe-type centerless

grinding in bearing production: “The machine concept of

the VOUMARD 1000 combines the proven features of the

Voumard machines, which today are still in use in many

companies, including bearing manufacturers, with significant

innovations that we have introduced in the new design

of the VOUMARD 1000. It is optimized for flexible, universal

internal and external circular machining of complex

workpieces up to a length of 600 mm. The variety of workpieces

ranges from the smallest individual parts for injection

systems in car engines, ball bearing rings and gears to

hydraulic and complex components in tool and machine tool

construction.”

Like the Kellenberger machines, the VOUMARD 1000 has

hydrostatic guides in all axes. These highly dynamic linear

axes are backlash-free for positioning accuracies in the nano

range. This means that workpieces can be ground extremely

precisely with maximum repeat accuracy and machine

availability over the entire service life of the machine. Minimal

maintenance costs, improved machine availability, and

greater contour accuracy and process reliability are further

advantages.”

High flexibility due to

two B-axes and grinding spindle head

The special features of the VOUMARD 1000 are the two

high-precision hydrostatic B-axes: B1-axis with spindle turret,

B2-axis with table turret. The two swiveling B-axes also carry

out all the necessary movements of the dressing and measuring

devices. The spindle turret on the B1-axis is equipped

with a uniquely compact grinding spindle head with a flexible

grinding spindle arrangement. Spindles and measuring

sensors can thus be optimally positioned and allow the

machining of almost any workpiece shape as well as the execution

of several internal and external grinding processes

in one single clamping. When grinding roller bearings, the

grinding head is equipped with an external grinding wheel,

an internal grinding spindle and a measuring device.

The high-precision hydrostatic B-axes and the exceptional

stability of the machine were ultimately decisive, and fully

won over the customer. During the factory visit in Goldach,

Switzerland, the requirements for the grinding process for

the bearing rings were specified once again and the dimensional

accuracy, roundness and cylindricity were defined.

The required dimensional accuracy in the outer diameter

is D100 ± 2 µm / D40 ± 1.5 µm, in the inner diameter

D100 ± 2.5 µm / D40 ± 2 µm. Required roundness inside and

outside < 0.7 µm and cylindricities of < 1 µm. Another require -

ment was the ability to measure during grinding (in-process

measurement). This was also fulfilled with the innovative

design of the spindle head and clamping device. The tests at

Kellenberger resulted in form accuracies during dressing

(without radius dresser) of < 1.5 µm, form accuracies of the

bearing running surfaces of < 2 µm (with forming roller),

< 1.5 µm (with radius dresser) and a coaxiality of < 2.3 µm,

thus meeting the requirements for the geometry fully.

“Our customers had already had very good experiences with

the special grinding machine manufacturer USACH, which

is part of our group, and also with the Voumard machines

that were already in operation at the factory”, Kellenberger

CSO Marcel Hollenstein explains. “From a technical point of

view the flexibility and collision-free nature of the kinematics

concept, and the two hydrostatic B-axes were particularly

impressive. And of course, the accuracy of the process.

Satisfaction was also very high in terms of sales, engineering

support and service. He adds: “Although we were at the

upper price limit with the VOUMARD 1000 and our innovative

clamping device design, we were awarded the

contract for several machines. Our concept was convincing

right down the line.”

further information: www.hardinge.com


29

processes

Roadmap for the decarbonization

of grinding processes

Development and grinding technical investigation of a

vitrified bond formulation for low-temperature firing

written by Dr. Alexander Nashed (Senior Research Engineer), Jörg Rucker and Lutz Gaida

Saint-Gobain Abrasives GmbH

Industrial companies throughout Europe are

currently busy identifying potential for massive CO 2

savings and getting closer to their defined scope 1

and scope 2 targets through optimized processes. The

Saint-Gobain Group – and with it the abrasives specialist

Saint-Gobain Abrasives – is no exception. The target:

by 2030 the aim is to achieve a 33 % reduction in

emissions for scope 1 and 2 (direct and indirect) and

a 16 % reduction in scope 3, i.e., across the entire value

chain (absolute reduction compared to 2017). The target

for 2050 is “net zero carbon”! This way all process

steps are being examined for any potential for optimization

and conversion. Saint-Gobain Abrasives has

now taken a decisive step by almost completely switching

from high-temperature to low-temperature bonds

in vitrified bonded abrasive tools.

If the ambitious targets set by the European Union and

others are to be achieved, three pillars must be considered

in parallel and driven forward accordingly:

➢ decarbonization of customer processes

➢ development and distribution of

maximally sustainable product solutions

➢ massive reduction in CO 2 emissions

during their production

At Saint-Gobain Abrasives the question arose early, as

part of the research and development work in the Grinding

Technology Centre Europe (EGTC) in Norderstedt near

Hamburg, on how to noticeably increase the energy efficiency,

particularly in the production of vitrified bonded grinding

tools. Looking at the usual firing temperature range for vitrified

bonds, which is between around 900 ° C and 1260 ° C, it

quickly becomes clear that the greatest potential, the greatest

impact on scope 1, lies in reducing the firing temperature and

therefore the (gas) energy supply. Accordingly it makes sense

to replace all high-temperature bonds (HT) in the product

portfolio of conventional grinding tools, which are generally

manufactured in the upper temperature range, with low-temperature

bonds (LT) – while retaining both the mechanical

properties and the required grinding behaviour.

Saint-Gobain Abrasives launched the first vitrified LT bond

back in 1985 and has been developing new solutions exclusively

based on LT since 1990, building up a wealth of experience

in this area over the years. The obvious next step was to

replace all HT bonds in Europe as completely as possible by

the end of 2023.

To realize this project a general approach was pursued that

takes all relevant physical properties into account in the development

of the vitrified LT bond formulation and generates

reliable and representative results in the subsequent grinding

investigation.

Aspects of the development of LT bonds

When manufacturing vitrified bonded abrasive tools it is

essential to match the bond chemistry to the respective application:

network formers, network modifiers and intermediate

oxides, for example, have a direct influence on the physical

properties of the bond, such as its strength, melting and

crystallization behaviour. Therefore they also influence the

mechanical properties and performance of the finished

grinding wheel. The mechanical properties considered include

modulus of elasticity, flexural strength, hardness and

density – these should be in the same range as the reference

wheel containing the HT bond.

Approach to the grinding inspection

The main task of the EGTC was to develop a grinding

method in which different grinding parameters are used to

determine characteristic values that enable a comparative

analysis of the grinding tools. By selecting different workpiece

and grinding wheel specifications, a wide range of applications

was mapped, which can be processed in a timeefficient

manner using the aforementioned methos. During

the tests at the EGTC the following data was measured and

analyzed in detail:

➢ power consumption of the grinding spindle

➢ grinding wheel wear

➢ material removal

➢ surface quality R a and R z

To ensure the (geometric and dynamic) comparability of the

results, the following values were kept constant:

➢ equivalent diameter d eq =>

constant contact length l g at related infeed a e

➢ workpiece speed v w

➢ cutting width a p

➢ cutting speed v c


processes

Experimental setup and execution

For the tests at the EGTC external cylindrical plunge grinding

was selected, whereby the plunge cuts were carried out

with defined grinding parameters on four workpiece blanks

of the same quality. Seven different wheel specifications from

hard to soft were tested on three different workpiece qualities.

Grinding was performed in counter direction and two different

material removal rates were run per specification in order

to load the grinding wheels to different levels of stress.

ensure that the spindle power consumption increases sharply

in the normal case during the initial cut and to avoid premature

loss of performance of the grinding wheel. On the other

hand the wheel should not be dressed too roughly to ensure

that the quasi-stationary working window is reached quickly

(in plunges two to four). Based on extensive preliminary tests

and empirical data from research, the following parameters

were therefore established for a suitable "dressing method":

About the grinding method

As already mentioned, a moderate specific material removal

rate of 3.2 mm 3 /mms and a high specific material removal

rate of 7.5 mm 3 /mms were selected. When selecting the specific

material removal rates care was taken to ensure that

grinding was neither carried out at a too low radial feed rate

(high specific grinding energy) nor at a too high radial feed

rate. Because too drastic radial feed rate leads to increased

grain pull-out and excessive wear of the grinding wheel. A

cutting speed of 45 m/s was identified as a standard cutting

speed for customer processes. It should also be mentioned

that a total infeed of 3.0 mm was sufficient to cause significant

wheel wear. The following diagrams show examples of

spindle power measurements at moderate (left) and high material

removal rates (right).

The grinding wheels have a width of 10 mm, the blanks of

5 mm. The plunge is done in the center of the grinding wheel

width so that wear creates a measurable profile on the grinding

wheel. The plunge into the first blank is done with 1/10 of

the total infeed, plunges two, three and four are each done

with 3/10 of the total infeed. After each plunge the wheel profile

generated by wear is projected onto a graphite coupon,

which is then measured optically in order to record the radial

grinding wheel wear.

Using this method the initially high grain protrusion

caused by dressing can be reduced to such an extent that a

load is applied to the bond at the plunges in blanks two, three

and four, which has a dominant effect compared to the grain

wear. This ensures that the grinding wheel ideally reaches its

quasi-stationary working window at blanks two to four and

therefore grinds outside the uncontrolled statistical range.

In addition the measured values can be correlated with each

other after each plunge, which also makes it easier to analyze

the development of the measured values within the overall

infeed.

Workpiece selection

For the grinding tests, two LT specifications per workpiece

were always compared with an HT reference wheel. In order

to compare the behaviour of the wheel specifications, three

different workpiece qualities with different grindability were

defined:

About the dressing method

The speed quotient q d , the infeed a ed and the overlap ratio U d

are the main factors influencing the topography of the grinding

wheel generated during rotary dressing. These parameters

were selected so that the grinding wheel is rough enough

(with correspondingly low grinding forces at the start) to


31

processes

The following example shows that the comparatively easier-to-grind bearing

steel can be ground by the tested grinding wheels of the specification with

the hardness and structure “I8” without any issues up to the last blank, so

without a drop in spindle power or an increase in wheel wear. In the case

of carbon steel all wheels reach their performance limit at the fourth blank,

while this limit is already reached at the second blank in the case of high

chromium steel with difficult grindability, resulting in high wheel wear and

a significant drop in spindle power.

*The tests on the 100Cr6 were carried out with ten (instead of four) plunges,

whereby the first plunge, analogous to the tests on the C60 and X100, was carried

out with 1/10 of the total infeed on blank #1; blanks #2, #3 and #4 each received

3/10 of the total infeed, also analogous to the tests on the C60 and X100

Selection of the grinding wheel specifications

The seven investigated specifications were selected according to different

structures (open, medium, closed) and grades (soft, medium, hard) in order

to represent different grain retention forces. This ensured that a representative

spectrum of specifications was analyzed and mapped. In the example

shown, all wheels from soft (I8) to hard (Q5) show almost optimum stock

removal at both material removal rates on the 100Cr6 workpiece:

➢ the harder the grinding

wheel, the higher the

power/energy/force

➢ good cutting behaviour

for all specifications

➢ soft specification (I8)

shows optimum removal

It can also be seen that the selected specifications, which differ in their grain

retention forces, also operate at different specific grinding energies, as shown

in the following diagram:

The grinding energy increases with increasing grain retention forces or – in

other words – with increasing hardness and density of the grinding wheel,

which means that the harder wheels (red and

green) have a higher energy consumption in

order to remove an equivalent volume. It is

important to note that the harder wheels tend

to reach their performance limit earlier on the

more difficult-to-grind workpieces (C60 and

X100) than softer wheels, as the latter have a

higher cutting ability.

Differentiation of

equivalent grinding wheels

When it comes to the question of which HT

bond is optimally substituted by which LT

bond in which application, a wholistic view is

required, considering all measured data and

observations. All three workpiece qualities

must be taken into consideration, as the following

example illustrates. The soft specification

with the hardness and structure “I8” was

tested on the three different workpiece materials

presented. The red bars in the diagrams

represent the reference HT grinding wheel

with the bond designation VC.1, the blue

and green bars represent the two LT grinding

wheels of the same specification with the

bond designations VC.2 and VC.3.

The Grinding Technology Centre Europe

(EGTC) of Saint-Gobain Abrasives

Since 2001 the Grinding Technology

Centre Europe (EGTC) in Norderstedt near

Hamburg has played a key role in the development

of innovative grinding solutions to

support the customers of Saint-Gobain

Abrasives GmbH. In addition to the development

of new process technologies for

diamond, cBN and bonded grinding tools,

a further focus is on application technology

research and the dialogue with experts and

end users, with the clear aim of offering

customers modern, sustainable grinding

solutions that are tailored to their processes.

As one of Saint-Gobain Abrasives‘ four

Grinding Technology Centres worldwide, the

EGTC in Norderstedt plays a fundamental role

in the design and investigation of innovative

grinding solutions and technologies for all

product families. Together with end users,

machine manufacturers and various scientific

institutions, new grinding solutions are

developed and optimized there. Trendsetting

customer-specific application projects

are also regularly launched in Norderstedt.

In addition the EGTC offers a wide range of

seminars and training programs to facilitate

a practice-oriented transfer of knowledge for

industrial grinding processes – supported by

measuring technology, the latest generation

of grinding machines and state-of-the-art

training technologies.


processes

*The tests on the 100Cr6 were carried out with ten (instead of

four) plunges, whereby the first plunge, analogous to the tests

on the C60 and X100, was carried out with 1/10 of the total

infeed on blank #1; blanks #2, #3 and #4 each received 3/10

of the total infeed, also analogous to the tests on the C60 and

X100.

With the 100Cr6 bearing steel, both the HT reference

wheel and the two LT wheels show a stable spindle power

curve and only low wheel wear as well as similar material

removal – a differentiation is therefore not yet possible

at this point. Accordingly it is necessary to analyze

the grinding tests with analogous engagement conditions

on the C60 and X100 workpieces, which are more

difficult to grind. This shows that with carbon steel C60

there is a drop in spindle power from blank 3 onwards

and thus correlates with higher wheel wear. In the case

of the high chromium steel X100 a similar spindle power

curve can be seen, but this results in a more intense decrease.

This is accompanied by even higher wheel wear.

Furthermore it can be seen that the VC.2 grinding

wheel with the highest material removal in the grinding

process produces intense chatter marks on the X100

workpiece, which also correlates with the consistently

higher spindle power of this wheel. Therefore, in this

specific case, the wheel with the second-highest material

removal (VC.3) should be selected as a substitute,

as this corresponds to the grinding behaviour of

the HT bond. No chatter marks occur here and at the

same time the wheel wear is significantly lower, compared

to the HT grinding wheel. A further argument is

the fact that the HT reference wheel operates at almost

the same level of spindle power as the VC.3 and therefore

a very similar energy consumption can be expected.

Based on the results obtained in this way, Saint-Gobain

Abrasives could replace almost all vitrified HT bonds

with LT bonds by the end of 2023 without any loss of

performance. An exception are (still) a few specialty

products, which only account for 3 % of the total range.

Summary

The tests were carried out over a period of five months and

were designed to ensure the comparability of the bond systems

and maximize time efficiency:

➢ same engagement conditions for all trials

➢ test setup with high reproducibility

➢ dressing and grinding parameters for

rapid attainment of the quasi-stationary

grinding window

➢ internal grinding investigation with around 230 trials

➢ supplemented by external trials at customer sites,

accompanied by application engineers (the results

obtained there were in line with the internal trials)

The results are therefore characterized by a high level of conclusiveness

and were also validated comprehensively with the

support of other Saint-Gobain Grinding Technology Centres

regarding different grinding applications. Hence, a complete

representation of different grinding conditions could be

reached as much as possible.

The most important fact at the end:

By almost completely replacing HT bonds with LT bonds,

the Saint-Gobain Abrasives GmbH was able to reduce CO 2

emissions from production in Europe by around 1,700

tons per year, and gas consumption was reduced by around

800,000 m 3 per year. Another important step towards achieving

the ambitious scope 1 and scope 2 targets!

further information: www.nortonabrasives.com


33

processes

High-performance micro-milling

of high-hardness steels: e.g. for bipolar plates

Tools for punching, embossing and

forming sheet materials are very demanding.

Accuracies in the range of

1-2 µm are sometimes required during

production. The challenges increase the

larger the tool and the thinner the sheet

metal is. A prime example of these difficulties

can be experienced in the production

of stamping plates for the sheet

metal shells for so-called bipolar plates

for hydrogen fuel cells.

Speakers, left to right: Marc Maier (Open Mind), Dr. Oliver Gossel (Röders),

Matthis Toppmöller (Hufschmied), Marc Geile (Voestalpine/Böhler),

Matthias Schneider (Zeiss), Herbert Merz (MHT),Marco Giarrusso (Open Mind)

(photo: Klaus Vollrath)

Filigree channel structures on a demonstrator

(300 x 150 mm) for an embossing die for bipolar

plates for automotive fuel cells


These thin hollow structures are made from

welded sheet metal half-shells enclosing filigree

flow channels. Together with the membrane

electrode units sandwiched between

them, numerous layers are arranged in regular

order in so-called “stacks”.

Sample workpiece (50 x 40 mm) with various

surface structures typical of bipolar plates


Politicians want to replace fossil fuels by promoting and favoring renewable

forms of electrical energy. But since some tasks cannot be mastered

using electricity alone, the development of a hydrogen economy is also being

promoted. The fuel cell is thus seen as an alternative to the battery. This involves

the use of so-called bipolar plates, which in the automotive sector consist

of stamped, embossed and welded sheet metal half-shells forming hollow

bodies. The bottleneck of this technology is currently the production of the

required forming and punching tools. Thinner sheet metal would help to

reduce the mass of the fuel cells. However, the thinner the material, the narrower

the cutting gap the more precise the geometry of the tool must be.

The accuracies to be achieved by the embossing and punching tools and the

presses pose extreme challenges.

This requires the development of specifically adapted process chains for

the manufacturing of embossing and punching tools for producing suitable

sheet metal parts. Key aspects are the steel for the tools, the CAD/CAM software,

the micro-milling tools, the properties of the machining center, the

lubrication and cooling of the milling cutters and the metrological control

and documentation of quality control. The companies Hufschmied, MHT,

Röders, Open Mind, Voestalpine and Zeiss have joined forces on this project.

The results currently achieved were presented at Hufschmied during a

seminar with more than 50 participants. They are not only interesting for

the core topic of “bipolar plates”, but also offer promising insights for other

sectors such as micro-production, precision mechanics, medical technology

and aerospace.

Ultra-hard steel: Böhler K888 Matrix

In order to economically achieve the extremely fine structures of such

bipolar plates, the embossing tool must have very high dimensional accuracy,

good wear resistance and a low tendency to stick. Another prerequisite is

good machinability. This requires a low proportion of primary carbides in

a hard microstructure matrix (“matrix steel”). The carbides should be tiny

and homogeneously distributed over the entire volume, as coarse specimens

could break during machining and thus cause surface defects. This implies

resorting to steels produced using powder metallurgy. Böhler K888 Matrix,


processes

a material with a maximum carbide content of < 2 %, was

selected. It is supplied in the soft-annealed condition with a

Brinell hardness of < 280 HB and achieves a Rockwell hardness

of 63 +1 HRC after hardening at temperatures between

1070-1120 ° C. It is characterized by high wear resistance even

in comparison with materials with a much higher carbide

content. Machining tests at Hufschmied have shown that the

material is nevertheless easy to machine and that very good

surface qualities can be achieved. The material is also easy to

coat, which also results in prolonged service life.

CAD-CAM software

A perfect NC program is essential for optimum workpiece

quality. With its hyperMILL CAD/CAM system, OPEN MIND

offers all the prerequisites for creating these NC programs.

The software calculates the toolpaths with the utmost accuracy

and thus delivers correspondingly precise NC data. A

few points should be given particular attention to. In order to

fully take into account the topology of the component when

calculating the toolpaths, geometric features such as sharp

edges, gaps and the nature of the surface transitions have to

be analyzed and recognized. These inputs are considered in

the calculations and control the point distribution in the tool

path, for example. Further optimizations such as adjusting

the feed rate are possible. This allows the milling tool to machine

the component at a constant feed rate. A “smooth overlap”

function avoids visible transitions resulting from the use

of different milling tools or strategies and reduces the expenditure

required for manual reworking to almost zero.

Another important feature makes it possible to link geometrically

identical structures within a component, which

are recognized or defined either automatically or manually.

The corresponding toolpaths, which were first created for

a single area, can then be brought to the previously recognized

or manually defined positions via a transformation and

linked fully automatically. Superfluous movements are eliminated

in the process. This considerably reduces the computation

times in the CAM system.

Requirements for the milling machine

The machining of embossing dies for bipolar plates is characterized

by high material hardness, small milling cutters

with diameters well below one millimeter, high demands on

surface quality and accuracies down to the 1 µm range. The

multiple small contour details also result in long machining

times, thus requiring very good long-term thermal stability

of the machine tool.

Röders’ machine tools are particularly suitable for such

precision machining tasks. Among other things they are

characterized by frictionless direct drives, highly rigid roller

guides, frictionless weight compensation of the Z-axis, precision

HSC spindles and highly accurate tool measurement. An

outstanding feature is the extremely high control cycle rate

of 32 kHz in all control loops, which enables rapid correction

of even the smallest deviations. Another decisive factor

is the sophisticated temperature management by means of a

temperature control medium that is kept stable at ± 0.1 K and

circulates through all key components of the machine. This

makes it possible to reliably maintain tolerances in the lower

micrometer range.

The tools of the Bumble-Bi series made by Hufschmied used to

process the various segments of the demonstrator (50 x 40 mm) on

the Röders system, as well as the corresponding processing times

(graphic: Röders/ Hufschmied)

Bumble-Bi micro-tools from Hufschmied

The machining of embossing tools for bipolar plates is a particular

challenge for the milling tools. This is due to the hardness

of the material to be machined and the long running

time of the programs, sometimes well over 100 hours. And

the required accuracy only allows for low wear. Hufschmied

developed the special "Bumble-Bi" series of micro-tools for

this purpose. These include high-feed milling cutters for

roughing as well as torus milling cutters, ball nose end mills

and flat ball end mills. The latter are a kind of hybrid between

torus and ball end mills. All tools receive a specially developed

PVD coating, whose extremely smooth layers ensure

good temperature management. The milling tools used to

manufacture the sample and their application parameters are

summarized in the table.

The demonstrator was

milled in Hufschmied’s

technical center on this

five-axis Röders RXP

501 DS; the system is

equipped with the MHT

medium distributor


Application data of the Hufschmied tools

used to machine the demonstrator

(graphic: Hufschmied)


35

processes

removes the chips and their heat content from the milling

cutter and the workpiece. The lubricating medium, consisting

of carefully selected hydrocarbons, is supplied in extremely

small quantities (2-10 ml/hour). This is nevertheless sufficient

to optimally lubricate the cutting edges. During hard machining,

the heat generated at the cutting edges is reduced

by approx. 50 %. The main advantages are significantly

longer tool lives, higher cutting performance of the machine

and better workpiece surfaces.

The hollow sleeve of the MHT media distributor encloses the tool

holder without touching it or rotating with it; air and lubricant

are supplied via the docking interface underneath the spindle


Optimum lubrication with the

MHT media distributor

The right combination of cooling, lubrication and removal

of chips from the work area plays a decisive role in machining

processes. The MHT media distributor enables a particularly

efficient and at the same time cost and energy saving

approach. The core element is a conical sleeve that is permanently

assigned to the tool holder and is exchanged with it

when the tool is changed, but does not rotate with the milling

cutter. It is docked underneath the spindle and supplied with

compressed air and lubricant from there.

Measurement technology and quality control

The milling cutters used in this project have diameters down

to 0.2 mm. For quality control very small and narrow contour

areas, e.g. on the flanks of the flow channels and on the

cutting edges of the forming/stamping tools, must be monitored.

As this involves recognizing details down to a single

µm, the measurement uncertainty of the measuring system

used should normally be ten times better than the production

tolerances to be checked. However only a few coordinate

measuring machines are up to such requirements.

In order to be able to record these measuring points with

reasonable effort, a Zeiss DotScan optical sensor with a measuring

rate of up to 1,000 measuring points/s was used, which

was guided over the sample in three different angular positions

using a rotary swivel unit.

The main cooling and cleaning work is performed by compressed

air ejected from nozzles arranged in a ring at the

lower edge of the sleeve. This powerful air jet immediately

The achieved quality of the component

(graphic: Röders)

Monitoring the demonstrator using the Zeiss DotScan

optical sensor with an MPE of 1.8 µm + L/350; in order to be able

to better measure the flanks, it was moved over the sample

using a Zeiss “Contura” coordinate measuring machine

with an RDS rotary swivelling unit

(photo: Zeiss)

Results

The results presented here (scatter ± 3 µm) demonstrate the

efficiency of the process chain described. With the right

choice of components and a suitable procedure, a high level

of process reliability can be achieved even when machining

high-strength or hard tool steels. In addition high quality

requirements can be met. It should be emphasized though

that this requires the consideration of all aspects of a given

process chain in detail.

further information:

www.hufschmied.net // www.mht-gmbh.de //

www.roeders.de //www.openmind-tech.com //

www.bohler.de // www.zeiss.de



Planetary Lapping machine

for PCD and CVD

Coborn’s Planetary Lapping machines are designed to polish the

top surface of PCD discs to a flat, mirror finish. They can also be

used to polish CVD discs and PcBN.

The machine consists of a number of independent work heads which hold the

discs against a large, horizontally mounted planetary motion grinding wheel.

It is impossible to use flood cooling when polishing large areas of PCD as the

discs ‘aqua-plane’ on the wheel surface. Therefore the lapping is a dry process

and the wheel is internally cooled using water from an associated water

chiller.

Chilled water is also fed to the back of each disc. This maintains the disc at

a uniform temperature to minimize disc dishing. The PL5i is equipped with

six work heads as standard. Each arm is fitted with a double gimbal fixture

to allow the disc to self-level. The disc holders are motor-driven. The lapping

pressure can be individually adjusted.

The lapping or polishing of the top surface of PCD or CVD components is

desirable to produce a smooth surface for chip flow and a good cutting edge

for geometric integrity. It also maximizes edge life, enhancing the characteristics

of PCD and also minimizes surface deviations over a large PCD or

CVD area.

The PL5i has a new, user-friendly touchscreen control system providing

more clarity on display status and more detailed diagnostics. New features

include spindle load monitoring and the planetary wear indicator.

Planetary Scaife benches for single crystal diamond

Coborn’s Planetary Scaife benches are generally used to polish facets on

single crystal diamond tools. They may also be used in gem diamond polishing.

The bench is available with a granite top, PS2BG or a steel top, PS2BS.

The Planetary Scaife bench combines the high speed rotation of a scaife plate

with a relatively slow, smooth, horizontal planetary motion. The planetary

motion speed is variable between 0-50 cycles/minute.

This motion gives a number of advantages over a standard scaife:

the plate does not become tracked as polishing takes place over an

annular band, the scaife surface remains smooth and flat

the motion results in a constantly changing angle of attack: this gives a

‘self-zooting’ action producing line-free facets without manual work

in many situations the optional tang can be set on the machine and

the diamond or tool left to polish

‘knarted’ stones become easier to polish as the angle of attack

constantly changes

Coborn has developed the PB2 Portable Balancing System, which can be

used in conjunction with the balance cap supplied on all PS2B benches. The

PB2 is an optional extra and is utilized to fine-tune the balance of the scaife

plate in-situ on the bench. This does not replace the need to pre-balance the

plate before mounting, but can eliminate almost all vibration from the polishing

system.

PL-150,

precision lapping of PCD and CVD discs

TL1 – the dual-purpose table lapping

and wheel preparation machine

The TL1 is the latest addition to Coborn’s single

crystal and natural diamond processing range

of machinery. The TL1 is a dual-purpose machine

that may be used to generate the final

cutting edge on SCD tooling after processing

on Coborn’s Planetary grinding machine

ranges, or it can be used to prepare a grinding

wheel before use.

For producing high-quality SCD tools, new

wheels need to be prepared correctly. This

process can take up to three days and during

that time the premium grinding machines

will not be producing tools – or profit. The

TL1 is a cost-effective solution to this problem.

Wheels can be prepared while the precision

machinery continues to produce tools

uninterrupted. One TL1 can provide prepared

wheels for many grinding machines.

The second function of the TL1 is for table

lapping to produce the final cutting edge

either for new or repaired SCD tools. This

process is a more hands-on operation but still

releases the more expensive machinery to

enable continued tool production.

further information: www.coborn.com


37


Together to success

At the Polish plant of WHITE, the

world’s leading manufacturer of orbital

motors and steering solutions, an S110

internal cylindrical grinding machine

from STUDER has recently been contribut

ing to efficient production.

It is April when the truck sets off on its journey

north from the STUDER plant in Biel,

Switzerland, to a distance of around 1000 km.

Its destination: the Polish production plant

of WHITE in Wrocław, the world’s leading

manufacturer of orbital motors and steering

solutions. On board is a valuable cargo – the

S110, a modern and high-precision internal

cylindrical grinding machine. “It’s always a

great moment when a new machine is delivered”,

says Paweł Soćko, senior process engineer

at WHITE after the arrival in Wrocław.

STUDER S110 internal cylindrical grinding machine

“We opted for the S110 because it exactly

meets our high requirements in terms of performance

and quality in production. Thanks

to the cooperation with STUDER we can

grind our components with the highest precision

and comparatively low costs – they therefore

contribute to our success”, he explains. In

the modern plant with around 600 employees,

several STUDER machines are in use, as well

as other machines from sister companies of

the UNITED GRINDING Group. They enable

the production of innovative electrohydraulic

high-performance solutions, for example for

steering systems in agricultural and construction

machinery. WHITE has over 50 years of

experience in this field and is now part of the

internationally established Interpump Group.

Customers benefit from optimization

“The relationship with WHITE has existed for decades and we are delighted

that our grinding machines can continuously contribute to their success

there”, says Adrian Schürch, area sales manager for Poland at STUDER. As

STUDER has a local representative in Poland, communication went very

well right from the start. However, before deciding on a specific machine

model, the requirements of the component to be produced with it had to be

determined. “As always, we examined this in detail with our specialist team

to find the optimum solution for the customer”, reports Schürch.

Adrian Schürch, area sales manager Poland

Automation solution on the S110



competence center in Biel. “The optimization is based on the specifications,

where all technical specifications, the geometry of the component to be manu -

factured and operation plans are defined”, he explains. His team worked

closely with the specialists from WHITE. “We were very impressed by their

technical expertise, professionalism and constructive attitude. It was a very

pleasant cooperation, and we found the perfect solution between customer

requirements and technical implementation”, emphasizes Mastroianni.

One of the challenges was to find the best mix of short cycle times in

series production and high component quality. Thanks to the optimization,

the S110 can grind around 350,000 high-quality sleeves per year at the plant

in Wrocław. WHITE is also satisfied with the result: “We produce in high

volume, and this requires the best solutions in the world – because we cannot

afford any losses due to insufficient precision or fluctuating capacity”,

emphasizes Paweł Soćko and adds: “The STUDER S110 meets our requirements

perfectly, it is stable and reliable.”

OSPM – a compact steering unit suitable for

vehicles and mobile machines with

high axle loads

Specifically it is about the internal grinding

of hardened steel sleeves for hydraulic steering

systems. It quickly became clear that the

S110 from STUDER’s wide range of models

was ideal for the component geometry and

production requirements. “In addition to high

precision, reliability and compactness, this

internal cylindrical grinding machine also

offers an excellent price-performance ratio”,

says Schürch. But that was just the beginning.

The companies team specially configured

and adapted the S110 for WHITE so that the

machine could be optimally integrated into

the production process.

Perfect combination of

short cycle times and high quality

This process fell within the remit of Cesare

Mastroianni, who is responsible for project

management at STUDER’s internal grinding

The S110 at a glance:

• compact and flexible internal cylindrical

grinding machine for processing

medium-sized workpieces

• center height of 102 mm (4”) and

a maximum grinding length of

120 mm (4.72”)

• optional loader for loading and

unloading

• up to three grinding spindles in a

linear arrangement enable external

and internal grinding in just

one clamping operation

• the StuderSIM and StuderWIN operating

systems enable safe programming of all

basic cycles for grinding, dressing and

process-supporting measurement

Automation ensures more efficient production

Soćko cites yet another reason for choosing the S110: its automation capability.

In the optional loading and unloading cell, a robot picks up the raw

parts from a pallet, clamps them in the machine, and places the finished

ground sleeves in another pallet. This process only takes a few seconds per

sleeve. The S110 can therefore operate autonomously for at least an hour

without human intervention and internal functions facilitate quality control.

“In practice we even have almost two hours of autonomy, which reduces

labor costs enormously”, reports Soćko. This also has major benefits for

production efficiency: the employees can devote themselves to other tasks

and the robot ensures a speed and consistency that would otherwise not

be possible.

Overhaul gives a second life to aging machines

While the new S110 improves production with its high-tech capabilities,

WHITE continues to rely on tried and tested technology. “The oldest of our

eight STUDER machines is still working well after 30 years”, emphasizes

Soćko. One reason for this is the machine overhaul service that the company

offers its customers. With this service an aging machine is restored to

as-new condition as when it was delivered. Steven Thiel, STUDER Customer

Care Consultant for Eastern Europe and Northern Germany, explains the

benefits: “Customers who are familiar with their machines and do not

require new technologies for grinding components benefit enormously from

this. This is because the machine overhaul only costs a fraction of the price

of a new system and the customer can continue to work with the familiar

machine in as-new precision and quality.”

The ecological factor is also important for WHITE, which has

already taken advantage of several machine overhauls. “Environmental

aspects always play a role for us, which is why STUDER machines with their

energy-saving solutions fit in with our corporate values”, explains Soćko.

This is because instead of replacing an outdated model that once required

a lot of energy and resources to build, it can be used again for decades. It

takes around three months to overhaul a machine in Thun, Switzerland,

with STUDER taking care of all aspects of logistics. “During this time, we

provide a loan machine so that there are no production downtimes”, says

Thiel, who is available to WHITE as a daily contact. Proven processes combined

with the latest technology: WHITE believes it is well-positioned for

the future. “Properly implemented processes ensure success”, says Soćko,

adding: “STUDER has shown that they are the ideal company to accompany

us on this journey.”

further information: www.studer.com


39


Successful conversion of production

E-mobility is taking hold around the world – and

the automotive industry is changing. Many manufacturers

are shifting from internal combustion engines

to electric powertrains. The Ford Motor Company – a

long-term partner of Liebherr-Verzahntechnik GmbH –

will be making most of the electric drive units for its

European production at its UK transmission plant at

Halewood near Liverpool.

As before, Ford will be using Liebherr gantry technology, but

for electric drive units rather than transmissions for internal

combustion engines.

The world’s sixth-largest car manufacturer aims to “electrify”

its portfolio in Europe. The switch to producing electrical

components in Halewood plays a crucial part in this. At this

plant, Ford has invested for the first time in Europe in the

production of components for all-electric vehicles, producing

power units consisting of an electric motor and a singlespeed

transmission. 420,000 units will come off the production

line annually instead of the previous 250,000 units,

enough for 70 % of the 600,000 electric vehicles Ford plans to

sell in Europe each year.

There are two reasons why Halewood was chosen. Firstly,

it has enough space to expand production, and secondly, it

is very close to the Liverpool city region Freeport. This is a

special economic zone created following Brexit, which offers

special economic regulations, as well as customs and tax

incentives.

Using existing technology differently

Ford and Liebherr have been working together for 30 years,

implementing numerous projects including retooling projects.

However this was the first one to involve moving existing

equipment to another location. “We took equipment from

lines that were no longer producing internal combustion

engines from Dagenham to Halewood, then upgraded and

modernized them”, reports project manager Steve Treweek,

senior process engineer at Ford Motor Company. “This saved

us a lot of money – buying the lines brand new would have

cost an additional 30 to 40 million Euro.” The converted

equipment was built in 2010 and is thus still relatively new.

Retooling it is cost-effective and the result is production lines

that look – and run – like new. The plant is still in the rampup

phase and production is scheduled to start October 2024.

Gantry technology and e-mobility

“If the project shows one thing, it’s that gantry technology is

alive and well”, says Roman Buhmann, key account manager

and Liebherr’s project manager for Halewood. “Anyone who

thinks that gantry systems will die out along with combustion

engines has got it wrong. Gantry technology is still

needed – for producing gearboxes for electric drives just as

much as for traditional engine blocks.”

The friction roller outfeed conveyor for

unloading the reject parts

Liebherr gantry technology

for the entire material flow

The converted plant uses four lines to produce electric motor

housings, gearboxes and covers and for assembling the transmission.

Liebherr technology plays a leading role everywhere,

including gantry robots for tooling the CNC machines (LP

200), gripper systems, connecting belts between gantry lines

and maintenance areas, a tower storage system, state-of-theart

part tracking and SPC stations for removing workpieces

for quality assurance.

“Liebherr technology handles the entire material flow of

transport, temporary storage, control and tracking – including

process reliability, material flow optimization to guarantee

cycle times on the production lines, as well as removal

and data evaluation”, says Uwe Radigk, Powertrain Manufacturing

sales manager at Liebherr-Verzahntechnik GmbH.

“Only the control technology is completely new; 90 % of the

hardware is re-used and upgraded. The energy supply chains

have also been retrofitted, and the safety systems have been

brought up to date to ensure the maximum possible occupational

safety.”

Productivity, quality and flexibility

The new plant offers a significant increase in productivity:

availability will increase from 80 % to 87.5 % in the first step

and up to 90 % in the future. In terms of the gantry technology

alone, it is no less than 98 %. “The advantages of Liebherr

gantry technology are clearly productivity, quality and flexibility

in equipment and engineering – and also tidiness”, says

Steve Treweek. “Looking around the factory, you can’t tell

that it’s used equipment. Everything looks brand new.”

Challenges during the conversion

The change from producing heavy cast iron parts for diesel

engines in commercial vehicles to the much lighter, more



deli cate parts for electric powertrains was one of the key

characteristics of the project. The engine block for which the

lines were originally designed weighed 120 kg, while the new

electric motor block is about the same size, but is made of

aluminum and weighs only 13 kg. This meant all the axes and

grippers of the gantry robots had to be replaced.

Another particular challenge was adapting the equipment

to the low roof height in Halewood. The halls there are only

5.2 m high, while the standard height of Ford production

halls is 6.4 m. Liebherr specially converted the entire gantry

system for the 1.2 m lower height.

The IT system was also changed: part tracking no longer

takes place by reading data tags but using a cloud system.

This means Liebherr not only moves the parts but also transfers

the associated data.

On top of this, it was all done in a very short time, made

more difficult by the coronavirus pandemic. Normally a

timeframe of 18 to 24 months is estimated for installing a

new gantry system – without transferring all the equipment.

This time, though, it only took eight months from the installation

of the first beam to the initial test runs in production.

Seamless collaboration

Steve Treweek knew from the start that he would carry out

this project with Liebherr. The decisive factors being not only

the quality of the equipment, but also the know-how, comprehensive

expertise in Ford projects and the reliability of the

companies engineering team. “Over the last 15 years I have

had all my gantry technology supplied by Liebherr”, he says.

“I’m very experienced and know exactly what I need – but even

with less experienced Ford project managers, the Liebherr

team would have mastered the task. I know what the teams,

assembly crews and project managers can do. When it comes

to the whole system, there’s no one comparable.”

The excellent collaboration between the two teams was

crucial in ensuring that the Halewood project ran smoothly

despite all the challenges. “This kind of thing is only possible

with Liebherr”, Steve Treweek emphasizes. “We have a deep

mutual understanding and both teams complement each other

perfectly. I would always argue for Liebherr as a supplier.

As a Ford project manager I need quality, reliable project

partners and a good team on my side – and this is exactly

what they give me. It’s a pleasure to work with Liebherr."

information: www.liebherr.com

England receives its first arc80X

At the beginning of the year, GEFERTEC introduced

its new generation of the arc80X with an

assembly space of up to 8 m 3 to allow additive manufacturing

of very large metal parts. Kingsbury has now

purchased the first new generation machine for the

application center at its subsidiary, Additure.

Kingsbury and GEFERTEC have enjoyed a close partnership

over the past five years, with the English company acting as

the exclusive distributor for GEFERTEC’s arc machines on

the British market. Approximately two years ago, Kingsbury

founded its subsidiary Additure, which focuses exclusively

on additive manufacturing methods. Because potential

customers for additive manufacturing need a great deal of

advice and support, Additure operates an application center

in its Preston location. This center is equipped for contract

manufacturing and can also be used to perform feasibility

studies. An arc405 is already in operation here. The contract

for purchase of the new arc80X was signed in April, with

delivery of the machine scheduled for early 2025.

Demand for larger parts

Wire Arc Additive Manufacturing (WAAM) is particularly

well suited for the creation of large parts. The arc machines

produced by GEFERTEC are complete manufacturing systems

based on the WAAM process. Traditional metal inert

gas welding is used for the additive manufacture of parts, creating

a near-net-shape part layer by layer. The arc machines

combine this process with the standard NX software from

Siemens and a Sinumerik control architecture. GEFERTEC

GEFERTEC is

delivering the

first machine

from the new

arc80X series

to its longtime

partner

Kingsbury in

the UK

offers specially developed CAM software for individual production

requirements. The resulting process offers high build

rates, and because wire is used as the raw material, handling

is easy and the material is cost-effective.

Having observed the growing need for larger parts,

Kingsbury decided to invest in a new arc80X, which can

manufacture parts weighing up to eight tons depending upon

the respective design. The assembly space for the 3-axis version

is 2 x 2 x 2 m, and the 5-axis version can print parts with

a diameter of up to 0.9 m and a height of up to 1.4 m. This

new generation of machines also offers a very high degree of

automation to increase manufacturing efficiency. Automated

functions include integrated tool measurement, gas nozzle

cleaning, wire cutting and replacement of wear parts.

information: www.gefertec.de


41


Automation of the UMILL 630 with

EROWA Robot Compact 80

EMCO was pleased to announce the possibility to

automate the UMILL 630 vertical milling machine

with the EROWA Robot Compact 80 (ERC80) pallet

changing system at AMB in Stuttgart 2024. Already

renowned for its precision and reliability in 5-axis

simultaneous machining, the UMILL 630 can now be

further enhanced through integration with EROWA’s

advanced automation systems.

The UMILL 630 is a universal milling machine for 5-axis

simultaneous machining, which is characterized by a clamping

range of 630 x 500 mm and a robust machine structure

made of cast iron and welded steel, which guarantees maximum

stability and thermal symmetry.

Example of a magazine

configuration

Supported by 45 mm

roller guides on the X-

and Y-axes and direct

drives in all linear axes,

the large traverse paths

of 500 mm in X, 460 mm

in Y and 450 mm in Z of

the UMILL 630 enable

the production of workpieces

with a maximum

diameter of 600 x 400 mm

in a wide range of batch

sizes. Another positive

feature is the high rigidity,

which stands for optimum

precision and excellent

surface quality

on the workpiece. All

axes are equipped with

a direct measuring systems

to achieve perfect

results.

Thanks to the front support for the included table as standard,

workpieces weighing up to 300 kg can be machined

without compromising performance. The water-cooled

motor ized spindle with a maximum speed of 15,000 rpm

ensures high performance and optimum precision.

Despite the generous traverse paths, the machine design

is compact and ergonomic. Complex machining processes

can be carried out easily and efficiently with the 30-position

tool magazine which can be extended to 60 or 90 tool positions,

other magazine sizes on request. The motor ized spindle

can be designed with HSK-63A or ISO40 holders. The large

machine door makes it easy to load the machine. As an option,

an automatic door can be fitted on the right-hand side

for the integration of intelligent automation systems, such as

the solution presented at the AMB trade fair in Stuttgart.

Universal milling center for 5-axis simultaneous machining

and Erowa Robot Compact 80 (rendering)

Features and benefits of automation with ERC80

One example is the combination of the UMILL 630 with the

EROWA Robot Compact 80 (ERC 80), offering the optimum

ratio between a large number of magazine positions and a

small footprint, increased productivity and improved operational

efficiency. With the ERC80 pallet changing system,

the possibilities of the UMILL 630 can be fully utilized. With

a transfer weight of up to 80 kg, the ERC80 can serve one or

two processing machines, offering flexibility and competitiveness

without compromising on quality.

The ERC80 combines perfectly with the UMILL 630 to

make the best use of the available space. It is ideal for production

environments where space is a critical factor. The ERC80

has features that ensure accurate and reliable parts handling,

optimizing cycle times and reducing downtime.

By integrating the UMILL 630 with the EROWA Robot

Compact 80, EMCO offers a complete solution to optimize

production processes. The automated loading and unloading

system increases productivity, improves flexibility and

reduces operating costs, while ensuring high quality of the

machined parts.

The machines are developed and produced entirely in

Central Europe for fulfilling the highest requirements in

terms of quality, productivity and efficiency.

The UMILL 630 is the ideal vertical milling center for 5-axis

simultaneous machining of demanding workpieces, whether

in small or large quantities, with high demands on accuracy

and surface quality. Integration with a pallet changing system

enables high-precision and productive machining, even

in unmanned shift operation. It is particularly suitable for

tool & mould making, contract manufacturers, industrial

companies such as automotive suppliers, general mechanical

production and advanced training facilities.

information: www.emco-world.com


New standards with world premieres


GF Machining Solutions made a strong impression

at this year’s AMB with the presentation of groundbreaking

innovations. Highlights included the world

premiere of the MILL S 400 U with Sinumerik One,

which combines HSC Milling with Siemens technology,

and the European premiere of the Laser S 500 (U),

which opens new possibilities in the micromachining

of 3D molds.

Visitors were also able to experience other top products

such as the MILL S 600 U with grinding function and the

CUT X 500 with cobot automation, a benchmark in wirecutting

EDM.

World premiere of a milling machine

with Siemens control

The MILL S 400 U has been equipped with a Siemens

control system – a unique feature for HSC milling machines.

This further development demonstrates the constant endeavor

to combine state-of-the-art technology with superior userfriendliness.

At the booth the MILL S 600 U G showcased

the combination of milling and grinding technology with

extremely high machine dynamics and consistent thermal

stability results in high-quality products, which helps customers

to achieve a quick return on their investment. This

feature provides a seamless transition between processes

avoiding the need to reclamp the part, with reduction in

idle and waiting times, whereas the main benefit is increased

accuracy. The MILL S/X (U) is the ideal machine, especially

for applications that require high surface quality.

Tiltable and adjustable dressing spindles close to the

working area on the MILL S and MILL X ensure a

fast-sanding set-up and process

The My rConnect platform offers a complete digital overview

and fast connections to service

European premiere of the LASER S 500 (U)

combining all the know-how in one machine

Accuracy and speed are at the heart of the brand-new LASER

S 500 (U), shown at the exhibition. With its outstanding

capa bilities and performance in processing a wide range of

soft and hard materials, it sets the course for the future of

micromachining and 3D surface processing. Manufacturers

in the information and communication technology, medical

technology and watchmaking sectors can look forward to

more effective and efficient machining technology.

Pioneers of electric discharge machining

display their skills

The latest CUT X series combines more than 70 years of EDM

history in the best wire-cutting EDM machine ever built.

There is no compromise between precision, surface quality

or speed: the unique technologies of a CUT X ensure the

best results in all three areas. The CUT X is characterized by

perfect axis accuracy and a thermal management system that

ensures constant precision under all operating conditions.

The well-known Intelligent Power Generator with Direct

Power Supply (IPG-DPS) and the unique twin-wire technology

make the impossible possible at unbeatable speed.

My rConnect – the new platform with

direct service access, digital and without detours

“My rConnect” offers users a seamless way to reach their

service contacts with a single click, eliminating the need for

hotlines or waiting in queues. This digital portal provides

access to the ticket system, facilitates communication

through chat and video calls, and allows easy monitoring of

machine status on the go. Users can also receive push notifications

on their phones, enabling proactive problem identification

and resolution before production is impacted. This is

just the beginning, as more functionalities and features are

set to be added soon.

information: www.gfms.com


43


Simple and secure networking

The UNITED GRINDING Group’s customers are

as diverse as the group itself. They range from small

businesses to large corporations, from single to mass

production, and from the automotive industry to aerospace,

tool and die, and precision mechanics. For the

manufacturing of complex and sophisticated parts,

not only the Group’s grinding, eroding, or measuring

machines are used, but also other technologies and

therefore machines from third-party manufacturers,

such as milling machines or lathes.

Aggregating valuable data from this heterogeneous machine

park to optimize production can be cumbersome and timeconsuming.

However this has been made easy with umati

(universal machine technology interface), which has become

the global interface standard for machine tools.

The simple networking of various machines from different

manufacturers and ages was demonstrated in production

at STUDER, the Group’s cylindrical grinding machine

specialist. In addition to these grinding machines, machine

tools from DMG Mori and WALDRICH COBURG were networked

using umati. The data was then merged into the production

monitor of UNITED GRINDING Digital Solutions.

The interlinking has shown that umati can not only be used

for new machines, but also older existing machines can be

networked without any problems.

The WALDRICH COBURG machine has been in production

at STUDER for over a decade and is predestined for this

project. An exciting project for an apprentice, Christian Josi,

head of digital engineering at the Group, thought. He immediately

received support from Marc Baumgartner, who is responsible

for training automation technician apprentices at

STUDER. Christian Breitenbaumer (4 th -year automation

technician apprentice at STUDER) then took on the task, analyzed

the structure, functionality, and electrical diagram of

the WALDRICH machine, and provided support in evaluating

a suitable, umati-compatible and cost-effective IoT device

for interface communication. This was wired and parameterized

by him. Integration into the production monitor was

then just a formality – thanks to umati. The key productivity

figures of the WALDRICH machine, together with the data

from the other production systems at STUDER, can now be

displayed in real-time on the shop floor dashboard, the PC, or

on a smartphone using the Digital Solutions mobile app.

information: www.grinding.ch

Compact solution for high-end machining

For DN Solutions, AMB 2024 in Stuttgart was

all about transformation. The global manufacturer

of CNC machine tools unveiled its new DNX 2100S

machining center to the public for the first time.

With the DNX 2100S, DN Solutions launches a new high-end

turn-mill center, whose flexibility bridges the gap between universal

lathes and turn-mill machines. Through the 4+1-axis

machine, DN Solutions aims to target companies that have

not yet transitioned from universal turret lathes to high-end

turn-mill machines. Many metalworking companies, for

instance, still rely on inflexible turret machines due to cost

considerations. The CNC machine tool expert seeks to partner

with these customers and assist them in developing and

transforming their machines.

Process reliability through complete machining

The main difference between the DNX and a turret machine

is its increased flexibility. By integrating turning, milling

and measuring functions, the machining center can fully

process a part from all sides with fewer tools and in a single

setup – no additional machines are required. This capability

is enabled by the flexible 12,000 rpm turning/milling spindle,

which can machine the part from all sides with an indexing

accuracy of 0.0001 mm, often utilizing simple standard tools.

In contrast universal turret machines typically rely on costly

tooling solutions, and the workpiece often needs to be manually

re-clamped to machine the second side. This method not

only occupies a significant portion of the 12 tool positions on

the turret but also increases setup time – and therefore machine

downtime. Additionally the DNX’s chain magazine,

which can hold up to 60 tools, along with the ability to set up

during machining, provides a clear advantage. The combination

of complete machining of individual parts in one single

setup and in-process measurement increases process stability

significantly, which is essential for machine automation.

information: www.dncompany.com


A new ball pin leaves the machine

every seven seconds


Whether in the steering system or in the chassis –

ball joints are indispensable in our cars. They not only

act as a kind of pivot point between different elements,

but are also usually in constant motion and exposed to

high physical loads. In this context, ball pins and ball

sleeves are among the safety-critical car components

that must leave production with a high surface quality

and micrometer precision without exception – despite

high quantities and general cost pressure. How

can this task be implemented particularly efficiently

and with minimal chip-to-chip times? EMAG now has

the answer with a new machine: using the VST 50, a finished

ball pin leaves the machine every seven seconds

with each component undergoing an exceptionally

comprehensive measurement.

A new task for the turning specialists from southern

Germany – until now ball pins were not a typical automotive

component that passed through an EMAG machine. So how

did this design and development come about? “It has to be

said that the task sounds very much like EMAG in many

respects. It involves large quantities, special surface requirements

and low unit production costs. We repeatedly ensure

these qualities for various components”, explains project

manager and development engineer Frank Haas from

EMAG. “In this respect it was obvious that a major customer

approached us with this task some time ago. The main question

was whether we could exceed the performance values of

existing machines in ball pin production. This was the starting

point for the development of the VST 50.”

The result has now been available for some time and a

simple look at this machine makes it clear: the designers

have done a particularly good job here. On the one hand the

VST 50 has highly automated processes, including the use of

three robots. On the other hand it is easy to operate using the

EDNA apps, which also include various measurements and

the robots. For the actual turning of the ball and neck of the

ball pin (only these areas are involved here), there are two

suspended workpiece spindles that can be moved irrespective

of each other. As a result one spindle is always loaded

and unloaded while the other is in use during the machining

process. The associated tool compound slides are split in two:

the tools on the left-hand side are mounted on a rotary B-axis,

which enables the ball to be turned and smoothed with precision.

In addition, the ball diameter and shape can be adjusted

using a linear U-axis. Special tools for neck machining are

mounted on the right-hand side.

High-productivity loading

Loading and unloading are in turn carried out by the three

robots, which are arranged in parallel in front of the machine.

Each is responsible for a different sub-process: the left-hand

robot handles the workpiece between the transfer station and

the first workpiece spindle. The middle robot performs the

The tools for

machining the neck

are on the righthand

side of the

compound slides

and those for

machining the ball

are on the left-hand

same task on the second workpiece spindle, while the right

robot handles the workpiece between the transfer station and

the outer automation assemblies. But why not use a robot that

performs these three tasks alternately at this point? “That

would certainly be possible”, confirms Haas. “However we

wouldn’t be able to achieve the extremely short cycle times.

The various movements are sometimes carried out simultaneously.

Our solution ensures that a finished workpiece

leaves the machine every seven seconds and the chip-to-chip

time is less than two seconds.”

Rapid speed and precision – this also explains why the robots

mentioned are also used for tool changes, whereby EMAG

has divided the entire process into two parts, so to speak.

On the one hand, there is the operator’s task: he always sees

a prediction for the tool change on the central control panel.

If he wants to change a tool he simply presses a button and

the tool magazine swivels outwards for the change. It is important

to note that the production process is not interrupted

during this process. After the exchange, the magazine swivels

back to its starting position. The manual process is now complete

and an automated process follows in the second step.

For this the left-hand robot first puts down its workpiece

gripper and picks up a tool gripper. It then removes the worn

tool from the interior of the machine and replaces it with a

new one, taking it from the magazine. To further increase

process capa bility, each tool is coded with an RFID chip so

that the tool data can be transferred accordingly. The entire

tool change takes less than 90 s.

Light band micrometer provides

many measured values

Finally, there is the issue of process reliability as a key economic

factor for a component that must leave production

without any error tolerance. EMAG relies here on a 100 %

solution: each component passes through a light-band

micrometer, which determines the required measured

values in fractions of a second with a comprehensive result.

The final ball and neck diameter is determined and any chips

are detected at the same time. In addition, a high-resolution

process camera is located directly in front of the loading

hatches. Its live image appears on the panel at the touch of a

button. The operator can easily check whether, for example,

the chip formation is causing a fault in the process.

further information: www.emag.com


45

components

Modular systems for cable carrier systems

TSUBAKI KABELSCHLEPP places a focus on its

TOTALTRAX solutions at SPS 2024 in Nuremberg.

The pre-assembled cable carrier systems, ready to

install, help users to increase productivity, while also

improving the predictability of their processes and

creating cost transparency and reliable quality.

“In the current volatile economic situation, medium-sized

companies face various challenges such as uncertainties in

the supply chain, rising costs and high competitive pressure”,

explains Jochen Becker, sales director D/A/CH at TSUBAKI

KABELSCHLEPP. “Complete systems are an advantage in

this situation, as they improve the predictability of processes

and costs while minimizing the risk of downtime caused by

delivery bottlenecks or incorrect assembly. With our tailormade

TOTALTRAX systems we additionally offer customers

long-standing experience, assured quality and flexibility in

the event of fluctuating demand.”

TOTALTRAX systems are available from simple to complex,

from one-off custom items to large production runs,

with and without connectors, sheet-metal and

add-on components, as single-axis or multi-axis systems

Predictability, cost transparency and reliable quality:

the pre-assembled TOTALTRAX cable carrier systems

help users focussing on their core skills

Not only the mechanical and plant engineering sector

benefits from the TOTALTRAX system. Because ten years

ago, customers came mainly from the mechanical engineering

industry, TSUBAKI KABELSCHLEPP has now considerably

expanded the scope of application for its system concept.

Today TOTALTRAX can be found in port cranes and automatic

milking systems, for example, as well as in a range of

other applications.

Extensive range of modular systems

without material dogma

When configuring the customized TOTALTRAX systems,

the company always considers all its cable carrier ranges

and components. This provides an extensive modular system

that can be used to generate an optimum solution for virtually

any requirement. A special advantage: the options also

apply to the available materials. Steel, plastic or hybrid carriers

can be used, depending on the application and the local

conditions. Hybrid carriers combine plastic sidebands with

alu minum profiles and can cover any required width in millimeter

increments.

“Compared to our competitors we can fall back on one of the

broadest portfolios in the industry”, explains Jochen Becker.

“That gives us the option of offering a large number of size

and width variants – all without any material dogma. Customers

can find everything in our range from small plastic

cable carriers to XXL steel cable carriers. Our TOTALTRAX

systems are available from simple to complex, from one-off

custom items to large production runs, with and without

connectors, sheet-metal panels and add-on components, as

single-axis or multi-axis systems. Anything is possible.”

Expert coaching from start to finish

The engineers and specialists from the company ensure

that the right solution from the vast number of options is

produced every time. They have many years of experience in

the field of cable carriers and are also well versed in mechanical

and plant engineering. This means that each project

receives competent support, from the initial inquiry to the

installation of the TOTALTRAX system.

further information: www.tsubaki-kabelschlepp.com


components

On the fast track

Mobile robots reduce costs for SMEs

Mobile robotic systems are being used in more

and more work areas, from e-commerce warehouses

to modern restaurants. Conventional models on the

market start at around € 25,000, while solutions with

an integrated robot arm are priced at approx. € 70,000

(prices may vary, depending on the country).

However, widespread use is often unaffordable for small and

medium-sized companies due to the high prices. igus wants

to change this with new low-cost robotics offerings and is

presenting a series of low-cost mobile plastic robots at the

Hannover Messe.

The market for automated guided vehicles (AGV) and

autonomous mobile robots (AMR) is booming: the global

market for mobile robotics, including service robotics,

currently totals around $ 20.3 billion, and experts expect this

figure to almost double by 2028*. Mobile robots are particularly

widespread in material handling and industrial applications.

And these smart helpers are even increasingly making

their rounds in catering and hospitals. The plastics experts

at motion plastics specialist igus have also been successfully

testing AGVs in-house for four years – driverless shelves

that deliver mail and shipments to offices as well as mobile

robots in production that move transports and rotary stacking

containers. The experience gained flows directly into the

development of a new Low Cost Automation product line,

the “ReBeL on wheels”. The goal: to pave the way for small

and medium-sized enterprises (SMEs) to cost-effective

mobile robotics.

* German Robotics Association:

“Autonome Mobile Roboter (AMR) –Was sind AMR,

Aktuelle Zahlen, Hersteller”, March 2024

Mobile ReBeL solutions for

education, logistics and service

The foundation of any mobile robotic system is the ReBeL.

Using plastic makes the robot particularly affordable at

€ 4,970 and, with a net weight of 8.2 kg, the lightest service

robot with cobot function in its class (prices may vary). Without

exception, igus develops and manufactures all mechanical

components that make up the ReBeL.

Its payload amounts to 2 kg and it has a reach of 664 mm.

Various moving systems are planned in which the ReBeL is

centrally integrated: igus is launching an affordable version

for the education sector for € 14,699 – including the robot

arm (prices may vary). Based on open-source software and

equipped with a gripper, the ReBeL EduMove serves as an

autonomous learning platform for educational institutions.

It has a modular design, so that other functions can be

added, such as lidar, camera technology or a slam algorithm.

Another version is an automated guided vehicle for SMEs,

igus launches a new series of cost-effective mobile AGVs

(automated guided vehicles) and AMRs (autonomous mobile

robots) for education, logistics and service with the aim of

making mobile robotic systems affordable for SMEs

(small and medium-sized enterprises)

which can transport up to 30 kg. With the optional ReBeL,

simple A to B positioning tasks can be carried out. It dispenses

with expensive sensor technology and instead relies on 3D

sensor technology developed in-house. Its price is € 17,999

(prices may vary). The ReBeL Butler is best for simple but

time-consuming pick-up and delivery services, for example

in the hotel and catering industry.

A lighthouse project on wheels

The goal of all these developments is the lighthouse project,

a mobile robot with integrated HMI and vision that would

even be able to tidy up an office on its own. “With this project

we are pursuing a bottom-to-top strategy in which certain

components such as safety laser scanners are not included

in the basic package so as to keep the price low”, explains

Alexander Mühlens, vice president and head of the Low Cost

Automation Business Unit at igus.

“Nevertheless, the solution can be retrofitted for industrial

requirements.” igus wants to present an affordable gripper

with a large stroke and travel that offers a high degree of

flexibility when gripping different geometries, among other

things. Says Mühlens: “The areas of application for this

planned low-cost AMR are extremely diverse and go far

beyond simple transport tasks. They cover a huge range of

use cases in different areas of life, such as cleaning tasks or

serving coffee directly at the workplace.”

further information: www.igus.de


47

components

New AI solution launched to accelerate

the CNC machining estimating process

CloudNC – a manufacturing technology

company – announces the launch of

CAM Assist Cycle Time Estimator, a new

tool that accelerates the CNC machining

estimation process and eliminates bottlenecks

in the quoting workflow.

Estimating and quoting for machining work

is a manual, time-consuming and labor-intensive

task for any machine shop. By automating

this process for multiple parts simultaneously,

Cycle Time Estimator allows users to turn

around estimates up to twenty times faster,

depending on the complexity of the part.

As a result, estimators using CloudNC’s

CAM Assist solution within Mastercam

or Autodesk Fusion can generate accurate

machining times and tool path strategies in

bulk for 3-axis and 3+2-axis parts in minutes.

They can then export that data seamlessly

and integrate it with their estimation workflow,

enabling them to quote for and win

more work, while using their resources more

efficiently.

Theo Saville, chief executive and co-founder

at CloudNC, said: “Estimating and quoting

for new work is one of the biggest bottlenecks

in machining, not only because it’s an expertlevel

task that’s critical for winning new business,

but also a huge time suck. Our solution

accelerates that process while also allowing

users to execute it on many parts at once,

CAM Assist Cycle Time Estimator, a

new solution from CloudNC, uses AI

to accelerate how quickly machinists can

estimate new work will take –

a bottleneck in any machine shop

By automating the estimation process for

multiple parts simultaneously, Cycle Time

Estimator allows CAM Assist users to turn

around estimates for 3+2-axis parts

up to twenty times faster

That advance helps machine shops

quote for and win more work, while

using their resources more efficiently

At the AMB diverse approaches of automated machine loading from

simple entry to high-end solutions was shown

turning around accurate estimates much faster than is manually possible,

even for a genius-level estimator. Its capacity is far beyond existing estimation

alternatives, and it’s a step change for any machine shop that regularly

looks to pull in new projects or win new clients.”

The Cycle Time Estimator is a new feature for CloudNC’s CAM Assist AI

solution, which accelerates CAM programming. By using CAM Assist’s

machining algorithms and tool selection to carry out estimates, Cycle Time

Estimator reduces human inconsistencies in the estimating process, improving

and standardising quote accuracy.

The solution also provides meta-data for each part, including part volume,

stock volume and other relevant data such as machining efficiency and

number of operations, enabling the estimates to be easily integrated into

existing workflows.

Mark Hyde of FJH Group, a CAM assist user, said: “CAM Assist significantly

reduces the time needed to generate tool paths and accurate cycle

times, cutting our quoting time by about 70 %. It allows us to generate accurate

cycle times and tool paths, ensuring we don’t over-quote or under-quote.

This capability has helped us win more work by demonstrating shorter and

more accurate cycle times.”

The Cycle Time Estimator is available as a feature for CloudNC’s CAM

Assist solution for Autodesk Fusion and Mastercam today.

further information: www.cloudnc.com


components

Precise, highly reliable linear technology solutions

for machine tools

At AMB 2024 Rollon presented a wide range of

products and solutions for machine tools. The company’s

focus at the trade show was on high-performance

ball screws of the Shuton-Ipiranga brand, as well as

roller guides from Rosa Sistemi. The full-range supplier

exhibited also linear guide rails, telescopic slides and

actuators.

Rollon is among the world’s leading suppliers of linear motion

solutions and offers unique development, production,

system, and application expertise from a single source.

Whether for machine tables, tool heads, automatic machine

doors, loading and unloading systems, pull-out drawers, door

openings, movable control elements or traversing axes for

robots and cobots: the diverse products are designed for numerous

machine tool applications, where they ensure a high

level of efficiency and process reliability in metal working.

Visitors to the Rollon-Shuton-Ipiranga booth at AMB

could explore the extensive product range and discover the

advantages for their particular application. The focus was on

high-performance ball screws from Shuton-Ipiranga as well

as profile rails from Rosa Sistemi.

Precision ball screws from Shuton-Ipiranga

Shuton-Ipiranga, known for their high-precision ball screws,

is a key player in machine tool construction. The XP Xtrem

Position product family was developed with special emphasis

on linear motions in machine tools and features exceptional

rigidity, dynamics and positioning accuracy. Available in

two versions – COMPLEX and PRIME – the products ensure

a long service life and absolute reliability. The COMPLEX

series – designed for high speeds and heavy loads – is used for

example in five-axis machining centers, multi-spindle machines

and mold processing machines. The PRIME series includes

high-precision ball screws with a small pitch for medium-speed

applications, such as grinders or EDM machines.

For applications requiring heavy-duty actuators, such as injection

molding, the energy sector, lifting systems, and presses,

the XL Xtrem Load product family is the best choice. The

ball screws have been optimized for heavy-duty applications

to guarantee maximum load-bearing capacity, dynamics,

and efficiency. Three type – IML, HDL and PKL – are available

for achieving an optimal service life under different load

ratings and speed requirements.

Roller guides from Rosa Sistemi

Within the Rollon Group, Rosa Sistemi specializes in profile

rails, such as the MG Rail as the perfect answer to the increasing

technological challenges of the machine tool sector.

The COMPLEX series is designed for high speeds

and heavy loads

The roller guide features hardened and ground running surfaces

with rollers to meet the typically stringent requirements

for precision, dynamics and efficiency with no compromises.

Thanks to their high load bearing capacity, outstanding

rigidity, an innovative lubrication and seal concept, as well as

high reliability even in dirty environments, the MG Rail is

the ideal solution for high-precision positioning.

Broad application spectrum

Rollon also offers other technologies for the fast and precise

handling of parts and tools. Machine doors and vertically

opening doors benefit from the self-aligning linear guide

rails of the Rollon Compact Rail and X-Rail series. Their

self-aligning capability allows fast and easy compensation of

inaccuracies in the mounting surfaces. The telescopic slides

of the Telescopic Rail series exhibit only minimal deflection

even when fully extended under maximum loads, which

makes them ideal for pull-out elements such as drawers and

control panels. To increase the efficiency of robots and cobots,

the work area can be expanded significantly with a Robot

Transfer Unit (RTU).

Linear technology for machine tools

No matter what type of machine tool application: based on an

extensive product range and a high level of system solution

competence, Rollon offers suitable components and systems –

from ball screws to roller guides and linear technology, from

a single source. All the solutions have been developed for

maximum performance and reliability to ensure high productivity,

optimal product quality and trouble-free operation –

whether the requirement is for a standard product or a

custom development.

further information: www.rollon.de


49

components

Röhm HP Pro live center in

precision version

Precise

With its new Pro

lines HP Pro and

HVLP Pro, the clamping

and gripping specialist

offers its live

centers in precision

design. With a concentricity

of 0.003 mm, the new HP Pro and HVLP Pro live

centers from Röhm set standards when it comes to the

precise counter-clamping of workpieces on lathes and

grinding machines.

The live centers of the HVLP Pro series are equipped with an

extended center point. This enables better tool accessibility

thanks to a smaller interfering contour and therefore more

space between the center point and the workpiece. Each of

these live centers is carefully checked for concentricity on the

test bench after assembly.

“Our live centers with the blue ring have always been the

benchmark for precision and durability in efficient workpiece

machining. I am therefore pleased that we can take this

precision to the extreme, so to speak, with the Pro lines”, says

Gerhard Glanz, CEO of Röhm GmbH.

High stability and accuracy

Like all Röhm live centers, the Pro line centers have also triple

bearings, being specially developed to absorb high axial

and radial forces. This feature makes them the ideal choice

for particularly demanding machining operations where the

focus is on stability and reliability. Thanks to the lifetime

lubrication, Röhm live centers are maintenance-free.

“Many lathe operators and machining specialists know this:

Röhm live centers are not only highly precise, but also very

durable. It’s great that we can now offer precision centers

with the Pro versions”, says Gerhard Glanz.

The HP Pro with classic Röhm live center (angle 60 °) is

available in MK 2 (size 102) to MK 6 (size 114); the HVLP Pro

variant with extended center point is available in MK 3 (size

106) to MK 6 (size 114).

further information: www.roehm.biz

Fast on the move

can be customized and further developed”, explains

Werner Mäurer, managing director of HIWIN GmbH. “This

allows us to significantly reduce the development times of

such complex precision systems for our customers. With our

fast response time, the customer then has its precision system

in use within a very short time.”

Thanks to standardized types, development times for complex

motion and positioning systems can be significantly reduced

Preconfigured motion systems save a lot of development

time. By providing standard designs, HIWIN

enables faster and more targeted integration of sophisticated

motion and positioning solutions into the

customers own machine concepts.

Thanks to their modular design HIWIN’s precision axes

and precision systems can be customized to the costomers

own requirements without any major design effort. “Our

standardized axes and systems are like a sample kit that

From components to ready-to-install systems: with mechanical

and electromechanical components as the foundation

of every movement, today HIWIN is also a drive technology

specialist. The motion systems for automation, sorting and

placement, inspection or exposure are used in the automotive

industry, medical and measurement technology or the semiconductor

industry. “Our customers can choose between a

pure component solution, a customized motion subsystem

or a fully integrated motion and positioning solution. We

supply everything from a single source.”

For the configuration of the standardized movement and

positioning systems, HIWIN provides project planning

sheets that allow the available types to be easily adapted to

the customers requirements. CAD data for the standardized

versions is available for direct download.

further information: www.hiwin.tw


impressum

ISSN 2628-5444

publisher

Benno Keller

phone + 49 (0)911 - 2018 200

fax + 49 (0)911 - 2018 100

keller@harnisch.com


Eric Schäfer

phone +49 (0)911 - 504 98 82

fax +49 (0)911 - 506 38 32

eric.schaefer@harnisch.com

managing editor

Christiane Ebner

phone +49 (0)911 - 2018 260

fax +49 (0)911 - 2018 100

ebner@harnisch.com

publishing company

Dr. Harnisch Publications

management board

Dr. Claus-Jörg Harnisch

Benno Keller

Eschenstrasse 25

90441 Nuremberg

Germany

phone +49 (0)911 - 2018 0

fax +49 (0)911 - 2018 100

hpt@harnisch.com

www.harnisch.com

www.hptooling-mag.com

advertising Germany, Austria, Switzerland

Thomas Mlynarik

phone +49 (0)911 - 2018 165

phone +49 (0)9127 - 902 346

mobile +49 (0)151 - 548 181 81

fax +49 (0)911 - 2018 100

mlynarik@harnisch.com

advertising Europe

Britta Steinberg

phone +49 (0)2309 - 574 47 40

mobile +49 (0)176 - 478 601 38

fax +49 (0)911 - 2018 100

steinberg@harnisch.com

advertising USA, Canada

Steve Max

phone +1 (0)215 - 284 87 87

steve.max@harnisch.com

advertising China, Hong Kong, Taiwan

Mike Hay

phone +852 (0)9096 - 88 95

mchhay@ringier.com.hk

advertising Taiwan

Sydney Lai

phone +886 (0)4 - 232 973 18

sydneylai@ringier.com.hk

Four issues per year

printed by

Schleunungdruck GmbH

Eltertstrasse 27

97828 Marktheidenfeld, Germany

VAT DE 133 510 873

Boehlerit GmbH & Co. KG ............16

CERATIZIT ........................10

CloudNC .......................... 48

Coborn Engineering Co Ltd ...........37

DN Solutions. . . . . . . . . . . . . . . . . . . . . . . 44

EMAG GmbH. ......................45

EMCO GmbH. ..................... 42

Fritz Studer AG .................... 38

GEFERTEC GmbH ..................41

GF Machining Solutions

Management SA ...................43

Gühring KG ........................15

Guill Tool & Engineering Co., Inc. .....25

Hardinge Kellenberger AG. . ..........28

Hartmetall-Werkzeugfabrik

Paul Horn GmbH .............. 12, 13

HIWIN GmbH ......................50

HUFSCHMIED

Zerspanungssysteme GmbH.. . .......34

igus GmbH .........................47

KAPP GmbH & Co. KG. . .............26

Lach Diamant Jakob Lach

GmbH & Co. KG ............... 16, 22

company finder

Liebherr-Verzahntechnik GmbH . .... 40

MAG IAS GmbH (FFG). . ............ 20

MAPAL Fabrik für Präzisionswerkzeuge

Dr. Kress KG ......................21

Mikron AG, Division Tool ............18

MMC HARTMETALL GmbH .........17

ModuleWorks GmbH ................25

Platinum Tooling Technologies, Inc ....19

Reishauer AG ........................6

Roeders GmbH. . ....................34

Röhm GmbH. . ......................50

Rollon GmbH. . .....................49

Saint-Gobain Abrasives GmbH. . ......30

SCHUNK SE & Co. KG ..............21

SIMTEK Präzisionswerkzeuge GmbH ..14

TIGRA GMBH ..................... 20

TSUBAKI KABELSCHLEPP GmbH .. 46

UNITED GRINDING Group ........ 44

WEILER Abrasives GmbH. ............9

ZCC Cutting Tools Europe GmbH. ....11

The articles contained in this magazine,

including the illustrations, are subject

to copyright law. Any use without the

consent of the publisher is not permitted

and will be prosecuted. This applies to

every conceivable form of reproduction.

Copies and reprints can be ordered on

request. Articles which are identified by

name or which are to be assigned to an

author by an abbreviation do not necessarily

reflect the opinion of the editorial staff.

Unsolicited manuscripts cannot be returned.

If a manuscript is accepted by the editorial

staff, publishing and copyright law as well

as all rights for publication and distribution

are transferred to the publisher. The

publisher accepts no liability with regard

to the facts set out in these articles.

copyright © 2024 Dr. Harnisch Publications

advertising index

Jimmore International Corp. .............................................page 3

Kapp GmbH & Co. KG ..................................................page 11

Lach Diamant Jakob Lach GmbH & Co. KG ............................. back cover

Mikron AG, Division Tool ...............................................page 9

Reishauer AG ............................................................cover

SPR ABRASIVES. ......................................................page 13


51

... a must have for turning aluminium

®

®

hp tooling 2024-#4

Transform your PDFs into Flipbooks and boost your revenue!

Delete template?

Save as template ?
