editorial

Eric Schäfer

editor-in-chief

There’s more to it than that!

Sometimes, it’s the little things that make the biggest

difference. It doesn’t always have to be “the next big

thing.” This becomes clear when you look at the new

product announcements in the run-up to a trade show

like GrindingHub. Minor changes here and there can

lead to amazing results. This can be achieved through

the use of automation or AI, optimized coolant usage,

or improved coatings. By tweaking the right parameters,

surprising improvements in efficiency and productivity

can be achieved.

can help to achieve optimal results in specific machining

processes. It may be precisely such a practical tip, this

redesigned tool, that further-developed spindle, or

this new seamless in-process measurement that helps

you to further optimize your own machining process.

In short, every reader can find inspiration here. It’s often

worth making small adjustments to the right parameters

to increase efficiency, productivity, and sustainability —

and thereby get the most out of a machining process. A

trade journal like “hp tooling” simply has more to offer.

Visitors to GrindingHub in Stuttgart can look forward to

seeing such examples for themselves and, of course, they

can also find them in advance in the following pages of

our trade magazine.

We also feature numerous user reports detailing the impact

of design enhancements in machine tools or minor tool

modifications on daily operations, and how these changes

Eric Schäfer

editor-in-chief

table of contents

cover story

The perfect fitting with diamonds 6

materials & tools

Quality in CFRP milling increases with manufacturing demands 8

Precision solutions for metalworking 12

Overcome titanium machining challenge through carbide tool blank design

written by Eduardo Favila 14

How super-hard cutting materials revolutionized machining 18

Edge quality without compromise 20

processes

Gear cutting and grinding from a single source 27

Strategic aircraft component with all the trimmings 28

Micrometer in the fiber optic connector 30

machining center

Increasing efficiency in tool machining with automation and AI 32

Kellenberger expands its grinding portfolio in the entry-level segment 34

Universal grinding machines for precision manufacturing tasks 36

Size matters… 40

Innovative manufacturing of ultra-hard tools 42

components

Engineered for governed constant high speeds, ultra-precision and reliability accelerating

advanced CNC machining applications 43

Ultra-fine and high-purity cleaning 46

A new generation of oil mist separators designed for the machining industry 48

Introducing cloud-powered tooling integration to accelerate mould & die machining and

standardize workflows 49

news & facts 21

fairs 5, 25

impressum & company finder 51

4 no. 2, 2026 April

fairs in alphabetical order

AMB Stuttgart, Germany

(September 15-19, 2026)

bauma Shanghai, China

(November 24-27, 2026)

CCMT Beijing, China

(April 21-25, 2026)

EPHJ Geneva, Switzerland

(June 16-19, 2026)

FABTECH Toronto, Canada

(June 9-11, 2026)

current status

2026





FEIMEC Sao Paulo, Brazil

(May 5-9, 2026)

FILTECH Cologne, Germany

(June 30-July 2, 2026)

glasstec Düsseldorf, Germany

(October 20-23, 2026)

GrindingHub Stuttgart, Germany

(May 5-8, 2026)

Hannover fair Hanover, Germany


HIMTEX Hyderabat, India

(August 20-24, 2026)

IMTS Chicago, USA

(September 14-19, 2026)

JIMTOF Tokyo, Japan


MACH-TECH and Budapest, Hungary

INDUSTRY DAYS (May 18-21, 2026)

METALEX Bangkok, Thailand


MSV Brno, Czech Republic


SIAMS Moutier, Switzerland


SIMTOS Seoul, South Korea


sps Nuremberg, Germany


Stone+tec Nuremberg, Germany

(Juni 17-20, 2026)

Surface Stuttgart, Germany

Technology (May 5-7, 2026)

TIMTOS Taipei, Taiwan

(March 2-7, 2027)

















2027

trade fair dates as by end of March 2026; we are not responsible for reliability of these dates

no. 2, 2026 April

5

cover story

The perfect fitting with diamonds

Designers, architects and discerning clients – when

planning bathrooms or kitchens, they all place high

demands on the taps installed. The design of the taps

and shower heads must fit seamlessly into the overall

interior design concept. The Belgian company RVB

shows that not all taps are the same.

The manufacturer produces its high-quality taps in Brussels,

through which water flows every day worldwide. Production

Manager Louis-Philippe Gillieaux relies on modern CNC machining

centers and manual work in production. To ensure

the high quality of his products, he relies on diamond tools

from Paul Horn GmbH for high-gloss surfaces.

“The quality of the surfaces is very important. It should

be precisely cylindrical or, in the case of shallow fittings,

perfectly flat. We can’t achieve this precision by polishing”,

says Gillieaux. A polished surface plays and shines, but it is

not flat. This is why polishing is not a geometrically precise

manufacturing process, even if it is done by a machine. The

best possible polishing results cost a lot of time and money.

“Finding a good polisher is very difficult. It’s a job that not

many people want to do because it’s very demanding”, says

Gillieaux and continues: “To further increase the quality of

our premium fittings, we coat these fitting parts with a layer

of copper and nickel before chrome-plating or gold-plating,

just like in the old days. This enhances the subsequent shine

and color impression and improves the adhesion of gold and

chrome to the brass base material, which contributes to an

even longer service life of the fittings. Although polishing

produces a high luster, it is not a geometrically precise processing

method, as anyone who knows anything about

polishing will tell you. Polishing away one µm too much on

a geometric control surface on the brass part destroys the

perfect impression of the subsequent mirror finish. These

tiny geometric errors are particularly noticeable on rotationally

symmetrical or flat mirror finish surfaces.”

RVB:

The engineer Gaston van Bastelaere founded the RVB company

in 1935. In 1936 van Bastelaere patented his first inventions,

including the FOR valve system. This ensures that the tap

closes perfectly in 1/3 of a turn by preventing the seal from

being squeezed. A small revolution even then. With numerous

other developments and bold designs, the entrepreneur was

often ahead of the trends in the tap industry. The shapes and

functions of RVB taps are still contemporary today.

In 2004 Alain Gillieaux bought the company and modernized

it fundamentally. However, he always took care to retain the

in-house expertise. Louis-Philippe Gillieaux continues the

company with the same approach.

The user does not need any special machines

for the high-gloss turning process

Monocrystalline diamonds

For these reasons, Gillieaux and his team have been using

MCD tools for over 15 years. When used, the monocrystalline

diamonds produce surfaces that make subsequent polishing

unnecessary. The switch to machine production not

only resulted in a high increase in quality, but also in cost

savings. “By using diamond tools, we have greatly reduced

the cycle time”, explains Gillieaux. Before switching to the

diamond tool systems from Horn, the team used tools on

which the diamond was soldered directly onto the tool holder.

Due to the cumbersome handling and the time-consuming

servicing of the tools, they were looking for a modular tool

solution. The arguments put forward by Horn technician

Kees van Bers convinced Gillieaux and his team.

Today, RVB relies on a wide range of Horn MCD tools.

The high-caliber inserts are used on conventional CNC machines.

“You don’t need special machines for milling and

turning high-gloss surfaces. The quality is produced by

the inserts”, explains van Bers. In addition to turning tools,

Gillieaux also relies on MCD milling tools. “We were sceptical

at first because of the high cost of the cutting tools,

but the performance and results have now completely won

us over”, says Gillieaux. When asked about the tool life of

the tool systems, van Bers jokes: “With an infeed setting of

around 0.02 mm in brass, the tool life is ‘eternal’. If an insert

does become blunt, it can be re-polished up to 20 times – with

the same ‘eternal’ tool life. The greatest danger for MCD

tools is operator error.”

The supreme discipline in machining

High-polish machining with MCD is one of the supreme

disciplines of metalcutting processes with geometrically

defined inserts. Two hundredths of a millimeter of finishing

allowance separate a very good surface from the perfect


cover story

High-polish milling produces perfect flatness and mirror

like surface finishes in the nanometer range

High-gloss turning of the outside diameter with an

MCD-tipped ISO insert

surface with a mirror finish. The range of applications is

broad. The manufacturing process is used in numerous industries.

In the jewelry industry, for example, the tools provide

the shine in the production of visible parts of a highquality

wristwatch and most wedding rings. In the production

of mirrors for space telescopes, the almost perfect dimensional

accuracy of the milled mirror surface guarantees

a distortion-free view into space. Diamond-tipped tools were

used in the manufacture of almost every visual aid, whether

spectacles or contact lenses. Another possible application is in

tool, model and mould making. Here, time-consuming and

expensive polishing work can be saved. The list goes on, and

these tool systems are firmly established, not least in the

medical industry.

The quality of the tool cutting edge plays a decisive role in

producing surface finishes with a mirror finish. The quality

of the cutting edge is reflected in the surface to be machined.

The final inserts or polishing of the MCD cutting edge

resembles craftsmanship. Similar to the cutting of a jewelry

diamond, the finishing of a tool cutting edge for high-polish

machining is done by hand using grinding pliers. Airbearing

grinding tables with a solid granite table top provide

A successful collaboration:

Louis-Philippe Gillieaux (l.) in conversation with Kees van Bers

Source: HORN/Sauermann

optimum conditions for grinding the inserts. A microscope

with 200x magnification is used for visual inspection. Under

this magnification, the cutting edge must be absolutely free

of nicks. The resulting insert has a maximum radius of

0.0002 mm. Horn has developed a special grinding machine

for grinding MCD ball nose end mills for high-polish machining

of free surfaces, with which even the smallest radii

can be reliably ground.

Synthetic diamonds

Horn relies on high-purity MCC diamonds to equip its MCD

tools. These monocrystalline stones are created using the

CVD process. Various gases, mainly methane, are used as a

carbon source, which are deposited during the process and

allow the diamond to grow. The diamonds are characterized

by their crystal clear to, depending on their thickness, slightly

brownish color. A major advantage of this process is the

possible edge length of the stones. This means that even long

tools with cutting edge lengths of 30 mm, for example, can

be realized. Previously, natural diamonds had to be used for

such tools, which are difficult to realize due to their high

price, availability and natural inclusions.

International designers

The MCD inserts are used at RVB in over 50 different fitting

parts. The design of the various series of fittings comes from

international designers. “The design is the most important

feature for successful competition”, says Gillieaux. To this

end, RVB works closely with renowned artists. “The designers

get in touch with us with their ideas. If they match our DNA

and are technically feasible, we realise them in a series”, says

Gillieaux.

The partnership between RVB and Horn has existed for

over 15 years. In addition to MCD tools, the team also relies

on Horn tools for grooving and parting off. “No matter what

requirement we contact Horn with, we are always presented

with the appropriate solution for us. The service doesn’t stop

after the sale. The Horn technicians keep at it until the production

process runs perfectly”, says Gillieaux.

further information: www.horn-group.com


7


Quality in CFRP milling increases with

manufacturing demands

Greater process reliability and cost efficiency for aircraft construction:

CemeCon and Hufschmied collaborate to design new tool

When milling carbon fiber reinforced plastics, the

aviation industry in particular demands maximum

quality of the machined surfaces and the highest process

reliability. Hufschmied Zerspanungssysteme GmbH

and CemeCon have been working together closely to

set new standards for this important industry of the

future. A jointly developed premium tool combines

geometry, substrate and diamond coating to create an

optimal solution.

The machining of carbon fiber reinforced plastics, or CFRP

for short, which are particularly advantageous for lightweight

construction, is one of the greatest challenges in the

machining industry. Even more demanding variants of these

composite materials are used in aircraft construction. At the

same time, there is an absolute focus on maximum component

quality, which completely rules out compromises and

demands the highest performance from the milling tools

The diamond coating adapted for the new premium tool –

shown here magnified 1,000 times – ensures a very uniform

wear pattern and guarantees a clear, smooth cutting edge

at a consistently high level throughout the

entire service life of the tool

being used. This is because the high-strength fibers must

be cleanly divided, despite their different orientations within

the matrix. Otherwise fiber protrusions or delaminations

occur, which at least require time-consuming manual

reworking.

The manufacture of large aircraft parts, such as shells or

segments for the fuselage, presents aircraft manufacturers

and suppliers with a very specific problem: the wall thicknesses

here often range from a few millimeters to several

centimeters. Enormous transverse forces act on the milling

tool at the transitions. In the worst case, it can break and

fragments can get inside the component – resulting in costly

production interruptions or even the loss of entire components.

The use of copper mesh as lightning protection poses

a further challenge during machining. The aim is to achieve

a component edge that requires no reworking – without any

copper protrusions.

Jointly developed by Hufschmied and CemeCon, the new

HEXACUT® 058 milling cutter impresses with maximum

process reliability and outstanding service life when

machining CFRP for aircraft construction

These are precisely the challenges that development partners

Hufschmied and CemeCon have set themselves. The

Bavarian tool manufacturer and the coating specialist

worked together to design a new milling tool that significantly

increases process reliability in CFRP milling and

at the same time extends its service life by more than 50 %

compared to tools used in the same application.



A structured path to the new premium tool

“Our customers in the aviation industry repeatedly emphasize this in discussions:

when machining components made of fiber-reinforced composites, process reliability

is the top priority, as even the smallest component deviations can be very

expensive. This has inspired us to develop a significantly improved solution to win

over users in this field”, says Fabian Lindinger, head of application technology at

Hufschmied. The foundation was laid for the groundbreaking HEXACUT® 058

milling cutter specifically designed for CFRP aircraft components.

On the way there, the existing tool geometry was first re-examined and revised

at the Hufschmied development center near Augsburg, Germany. In addition to

optimum process reliability, the new tool had to meet another requirement: the

cutting quality had to be guaranteed over the period of use as long as possible.

Perfect coordination of tool parameters

The rest of the process showed how a strong partnership in innovative techno -

logy can make all the difference: essential to achieving an ideal overall result was,

of course, the customized coating, which was tailored to the tool geometry developed

by Hufschmied and the innovative substrate. To this end, the coating experts

at CemeCon specified a diamond coating material for the new tool, which already

achieved absolutely outstanding quality in tests. “It was extremely fascinating

to observe how the optimal pairing of carbide substrate and coating material

gradually emerged”, recalls Javier Fuentes. The head of coating and cutting material

development at Hufschmied emphasizes: “Through productive teamwork we

were finally able to achieve a homogeneous wear pattern that allowed us to achieve

a clear, smooth milling edge at a consistently high level throughout the entire tool

life. And coating spalling or even tool breakage simply no longer occurred in the

product tests.”

Marco Furrer, sales manager at CemeCon, explains: “We specifically adapted the

proven CemeCon coating material CCDia®AeroSpeed® for the new Hufschmied

tool. This enabled us to achieve exceptional adhesion to the carbide selected by

Hufschmied despite the high coating thickness. The impressive result: the new

HEXACUT® 058 from Hufschmied offers users consistently high cutting quality,

maximum process reliability, also due to substantially less vibration, and a significantly

longer service life.

Strong partners working on an equal footing

The entire project benefited greatly from the professional cooperation between the

parties involved, as the partnership between Hufschmied and CemeCon has long

gone beyond a mere supplier-customer relationship. Working closely together they

worked out important details such as edge preparation, cutting radii, layer thickness

and layer architecture. “By combining our expertise, we were able to optimize

all parameters until we had achieved a solution that was consistent in every respect”,

explains Michael Woda, manager development diamant at CemeCon.

The companies are also continuing to work together in the series production

of the HEXACUT® 058. The premium milling cutters of the new type are coated

at CemeCon’s headquarters in Würselen, in the world’s largest diamond coating

center, and subjected to comprehensive quality control. Independently of this,

Hufschmied rechecks relevant criteria, such as homogeneous layer thickness distribution

– for end customers, this means additional process reliability.

“This project, like our other collaborations with CemeCon, some of which have

been going on for many years, makes an important contribution to establishing

Hufschmied worldwide as a synonym for first-class machining solutions”, says

managing director Christel Hufschmied, delighted with the development success.

“The new diamond tool and the joint effort with CemeCon to bring it to industrial

maturity are helping us to achieve our goals in the long term.“

further information: www.cemecon.de

Tools cut better

with TIGRA

PCD

PcBN

Tungsten Carbide

Customized

Preforms

PCD and PcBN

Blanks and

Segments

Carbide Rods

and Milling

Cutter Blanks

Carbide Inserts for

tipping with PCD

or PcBN

www.tigra.com

TIGRA GmbH

Hall 9 D31

TIGRA GmbH

Gewerbering 2

D-86698 Oberndorf a. Lech

Tel +49 (0)9090 9680-01

sales@tigra.de


Wide variety of carbide blanks,

ultra-hard cutting materials and

latest straightening and hammering technologies

At GrindingHub 2026 (May 4–8) in Stuttgart,

TIGRA GmbH will present its comprehensive portfolio

of precision carbide blanks such as preforms,

milling cutter blanks, carbide inserts, rods and flat

bars, and ultra-hard cutting materials made of PCD.

Modern flatness control and hammering systems for

circular saw measuring and machining will also be

presented for the first time.

Precision preforms and milling cutter blanks

One focus of the trade fair presentation is on customerspecific

preforms, which TIGRA manufactures individually

according to customer drawings. The blanks are pressed in

application-specific carbide grades and formed close to the

final contour, significantly reducing the amount of grinding

and erosion effort required downstream. TIGRA produces

preforms with variable diameters, integrated plate

seats, functional surfaces and axial, radial and helical

coolant holes.

The preform production takes place on highly automated,

partly self-developed production facilities with multi-stage

quality controls and optical inspection. Modern CAD/CAM

processes, CNC turning and milling, and application-specific

carbide grades with optimized brazing, toughness and

bending strength properties enable the economical manufacture

of both individual pieces (batch size 1) and large

series. The range of carbide milling cutter blanks includes

rods in various lengths and diameters with different radial

coolant exits.

Rods and flat bars

The preform range is complemented by a wide assortment of

carbide rods and flat bars, which are characterized as follows:

Numerous carbide solutions and ultra-hard cutting materials are the focus of GrindingHub 2026



→ as-sintered and ground rods (h5)

→ metric and inch dimensions

→ rods with straight coolant holes, double helix

coolant holes and preformed geometries

→ in standard and application-specific carbide

grades for machining graphite, aluminum,

non-ferrous alloys and fiber-reinforced plastics,

as well as for optimum machining of steels and

non-ferrous alloys.

→ very fine-grained, tough carbide grade with

excellent properties for high-speed milling

→ for machining MDF, chipboard, laminate,

CFRP

→ flat and square bars in various dimensions

→ heavy alloy tool body blanks (TIGRAmet)

in the most important dimensions

Carbide inserts

In the field of PCD tipping, TIGRA offers carbide

inserts as blanks for positive and negative plates

in a wide variety of types, shapes, angles, tolerances

and dimensions – with and without plate

seats. The carbide inserts are specifically designed

for subsequent tipping with ultra-hard cutting

materials.

PCD for demanding applications

In the field of ultra-hard cutting materials, TIGRA

pre sents PCD as blanks and segments. The PCD

materials are available in grades adapted to specific

applications, including:

New machine developments for

circular saw production

Another highlight of the trade fair presentation will be two newly

developed machines, which TIGRA will present together with its

Italian partner Novotic. The Q800 system is used for high-precision

flatness control of circular saws and combines pneumatic

clamping technology with high-resolution sensor technology,

Siemens PLC control and 21” HMI including Novotic Tensoflat

software for measurement data acquisition and report generation.

The P800 expands the portfolio with a solution for flatness

control including automated straightening hammering. The system

features an electrically operated double hammer station,

dual IO-link measurement sensors, AI-supported straightening

functions and comprehensive modules for data acquisition, remote

diagnosis and system integration.

With this combination of high-precision preforms and other

carbide blanks, ultra-hard cutting materials and modern testing

and straightening systems, TIGRA is positioning itself as a system

partner for the tool industry. The focus is on process stability,

reproducibility, service life optimization and economical manufacturing

concepts along the entire process chain. Trade visitors

are invited to visit the TIGRA stand to discuss individual blank

solutions, material strategies and integrated system solutions. You

will find TIGRA’s booth in hall 9, booth D31.

further information: www.tigra.com

→ for super finishing and finishing

→ aluminum alloys with low and

high Si content

→ universal applications

→ MDF, chipboard, laminate, CFRP

→ concrete, limestone and highly

abrasive materials

→ wear-intensive applications and

grindable wear parts

TIGRA’s quick service for laser-cut PCD segments

enables production according to drawings within

3-5 working days – with or without angles, cleaned,

securely packaged and more cost-effective than

traditional wire cutting methods.

Carbide for woodworking

As the global market leader for reversible knives

and carbide blanks for profiling, TIGRA has been

a technological partner to the woodworking industry

for decades. Alongside its wide range of planer

knives, the company offers optimized carbide solutions

in a wide variety of dimensions and carbide

grades for solid wood and abrasive composite materials

in standard and special designs. Depending

on the application, wear-resistant, fine-grained

or particularly tough carbide grades are used. The

portfolio is complemented by an extensive range of

carbide saw tips and carbide for brazed cutters.


Precision solutions for metalworking

SIMTEK Präzisionswerkzeuge GmbH

presented its latest innovations at BIEMH

in Bilbao, one of the leading trade fairs

for manufacturing and automation technology.

Visitors could see an extended

selection of 3D laser-cut chip form geo -

metries, the versatile simmill 9W milling

tool system and newly developed, lengthadjustable

holders in addition to the

tried-and-tested tool range. There was

also a special focus on individual tool

solutions for machining the smallest

diameters.

SIMTEK is setting new standards in chip

control with its 3D lasered chip shape geometries.

This technology not only increases process

reliability, but also extends the service life

of the tools.

“The introduction of laser geometries

marks an enormous advance in tool technology.

It not only makes our tools sharper and

more precise, but also enables them to reliably

meet the requirements for chip control”,

explains CEO Norbert Seifermann.

At BIEMH, SIMTEK presented the simturn DX clamping holders – a versatile

solution for the internal machining of small components; with their variable

length adjustment and the friction-locked ME clamping system,

they offer maximum stability and precision

According to SIMTEK, the 3D lasered tools

are ideal for applications in the automotive

industry, medical technology and other sectors

with high demands on precision and process

stability. The number of customers using

cutting tools with 3D laser geometries from

SIMTEK has increased more than tenfold

since 2019.

simmill 9W - monoblock performance

meets modular flexibility

Another highlight is the simmill 9W tool

family. It combines the precision and stability

of monoblock tools with the flexibility and

cost-effectiveness of modular systems. The

system is particularly suitable for applications

Grooving and longitudinal turning with a simturn TK2 cutting insert with

a chip geometry ground in two directions produces whirling chips (left);

these can wrap around the tool or the workpiece and lead to downtimes;

the lasered version produces short chips that can be easily removed from

the machining process, thus ensuring high process reliability

The simmill 9W family, an innovative milling tool system that combines the

flexibility of modular systems with the precision and stability of monoblock

tools; the version on show has 12 teeth and is suitable for cutting depths of

up to 16.5 mm – ideal for demanding industrial applications


news & facts

such as grooving, parting and slotting – for example in

the automotive industry, in mechanical engineering and

for demanding precision applications.

“With the simmill 9W series we are closing the gap

between classic, modular interchangeable tools and monoblock

solutions”, explains Norbert Seifermann.

Thanks to innovative toothing technology, the system

guarantees maximum stability and precision – even with

milling depths of up to 16.5 mm in the standard range,

which is far beyond the capabilities of many other comparable

tool solutions. With standard cutting widths

from 0.5 mm to 6.0 mm and an integrated coolant supply,

the series scores highly in terms of both efficiency

and sustainability. In the individual area, the application

possibilities in terms of diameters, widths and depths are

even greater.

Brings solutions

to the surface.

Stuttgart, 05-08/05/2026

Length-adjustable holders for

maximum flexibility

The length-adjustable clamping holders and carrier tools

presented at BIEMH are specially designed for small series

production and individual requirements. Highlights

include the simturn DX clamp holders with infinitely

variable length adjustability and patented ME clamping

principle, which offers high stability even with long overhang

lengths.

Thanks to their versatility, the length-adjustable

holders are not only particularly economical and flexible

to use, but also help to reduce the variety of tools

required by users.

The range covers a wide spectrum of applications: from

machining small bores from Ø 4.7 mm with simturn AX

carrier tools, to simturn DX carrier tools for bores

from Ø 7.0 mm, to larger diameters from 10.5 mm with

simturn PX systems. “With these products we enable

our customers to reduce their tool inventories and still

react flexibly to new production requirements”, emphasizes

Norbert Seifermann.

High-precision tools for small diameters and

individual requirements

A growing segment at SIMTEK is the development and

production of tools for machining in the smallest diameters.

The standard range already includes numerous tools

from the simturn AX, simturn DX and simturn PX product

families, which have been specially developed for this

purpose. However, SIMTEK users are not restricted to

the use of standard tools. With more than 10,000 individual

tool concepts per year, SIMTEK offers customized

tool solutions for small diameter applications. Thanks to

many years of experience in the customization sector and

the use of laser-cut chip geometries, users benefit from

economically viable custom tools even for small batch

sizes – regardless of whether they are based on existing

standard tools or developed from scratch.

Where everything revolves

around grinding – and you!

The leading trade fair

for grinding technology.

grindinghub.de

further information: www.simtek.com

In Zusammenarbeit mit

In cooperation with

Trägerschaft

Sponsorship


Overcome titanium machining challenges

through carbide tool blank design

written by Eduardo Favila

segment director, carbide rods, Hyperion Materials & Technologies

Titanium’s strength and corrosion resistance make

it ideal for applications in the aerospace, medical and

chemical industries, but its low thermal conductivity

complicates machining. Poor heat dissipation can

lead to tool wear, thermal deformation and workpiece

distortion, while the abrasive chips that titanium

produces further increase heat and wear.

In precision-focused industries like aerospace, well-designed

coolant systems at the cutting edge are critical to enhance

tool performance, extend tool life, improve in-cut precision,

and maintain efficiency throughout the machining process.

Toolmakers can achieve significant gains in tool life and

precision by combining application-specific carbide rod

blanks with appropriate coolant systems. Depending on the

specific needs of the machining operation, toolmakers have

a few choices:

1. solid blanks and flood cooling for high-volume

tooling at controlled costs

2. standard coolant rods and through-tool cooling for

high-precision and consistent cutting tools

3. tailored coolant rods and through-tool cooling for

top-performing tools in complex cutting applications

For high-volume tooling at controlled costs

For high-volume cutting operations where cost control is

a priority, flood cooling is an effective method. Flood cooling

involves continuously pouring a large volume of coolant

over the cutting area. In these scenarios, tools can be made

from standard solid carbide rods without coolant channels

because the flood cooling system surrounds the cutting tool

and reaches the cutting edges effectively.

Using standard solid carbide rods with flood cooling has

historically been a cost-effective solution for general machining

needs. The flood cooling approach is best suited for applications

where cutting tools are used in high volumes and

changed frequently. However, flood cooling can be less efficient

in deep or complex cuts where coolant penetration into

the cutting zone is limited, potentially leading to early tool

breakage. Traditionally, standard solid rods have worked well

as a cost-conscious option because blanks have been readily

available for fast fulfillment and quick delivery times.

However, in today’s environment where the cost of carbide

is rising rapidly because of the restricted supply of am -

monium paratungstate (APT), one of the critical raw

materials in carbide, toolmakers should consider higherperformance

options that maximize the value of the carbide

they are purchasing.

Hyperion carbide rods – coolant channel assortment



Hyperion carbide rods – specialty coolant channels

For high-precision and consistent cutting tools

For more complex cutting applications, a through-tool coolant

system is recommended. Machining operations can vary

from drilling deep holes in titanium turbine discs to long

continuous milling of titanium compressor housings, engine

blades and vanes.

In a through-coolant tool, coolant is delivered through

internal channels within the tool, exiting directly at the cutting

edge. This method is highly efficient because it ensures

coolant reaches the critical areas directly, thereby preventing

overheating, tool wear and workpiece deformation.

For toolmakers looking to enhance tool life and cutting

performance without significant investment, leveraging standard

coolant rods is an excellent starting point. Using drill

blanks with one or two straight channels delivers an upgraded

solution to solid rods by more effectively applying

coolant to the cutting surface. Drill blanks with standard

helical channels support even better performance by more

effectively directing the coolant to the cutting edge and evacuating

chips. End mill blanks with a central channel and

multiple lateral exit holes around the cutting diameter allow

for upgraded performance through the creation of a coolant

curtain around the cutting edge that reduces temperature

and stabilizes performance over extended milling periods.

The direct delivery of coolant to the cutting zone mini mizes

the risk of damaging the valuable workpiece or breaking a

tool unexpectedly, which improves efficiency and reduces

scrap overall. In more complex machining operations, these

factors are even more critical.

For top-performing tools in

complex cutting applications

For toolmakers aiming to outperform the competition and

achieve superior performance in highly specialized cutting

operations, designing coolant channels tailored to specific

requirements is essential. Controlled wall thickness in these

carbide rod blanks reduces the risk of tool breakage, further

enhancing tool longevity. Precision engineering and tight

blank tolerances provide higher quality to drills and end

mills for deep hole drilling and deep pocket milling in titanium

turbine discs or drilling large numbers of consistent

holes in titanium engine casings.

While using a custom-designed coolant channel carbide

rod to develop a specialized carbide tool requires a greater

initial investment, the benefits – much longer tool life, improved

performance, reduced tool wear and increased

precision – are worth considering. High-volume operations

increase productivity and reduce tool consumption

by achieving more cutting passes or holes drilled

before replacement, which can pay for the higher cost of

the tool many times over. Highly specialized operations

often experience impressive performance gains, with easyto-measure

factors like more parts made per tool and less

downtime.

For manufacturers, especially those that make their own

specialized tooling, these benefits are undeniable. However,

toolmakers also benefit from delivering premium specialized

tools by winning market share and improving profit margins.

Additionally, because specialized tooling reduces the risk of

damaging titanium workpieces and improves cutting time,

manufacturers and toolmakers alike can position themselves

in high-performance industries and gain trust with

key players.

Choosing the right tool blank

makes the difference

Machining titanium presents unique challenges, primarily

due to its low thermal conductivity and the generation of

long, abrasive chips. To overcome these challenges, effective

coolant systems and well-designed coolant channels

in cutting tools are essential. By strategically selecting and

designing carbide rod blanks with coolant holes, toolmakers

can significantly enhance tool life, machining efficiency,

and overall performance for the specific applications of their

customers.

Whether you are managing high-volume operations with

standard carbide rods or developing custom-engineered solutions

for highly specialized applications, the right coolant

system and channel design can make a substantial difference.

Hyperion Materials & Technologies offers a wide range of

solid and coolant carbide rods and provides engineering

expertise to deliver optimal solutions.

further information: www.hyperionmt.com/carbide-rods


15


Gear skiving made easy

New digital engineering portal from LMT Fette revolutionizes skiving

Skiving offers decisive advantages in terms of

productivity, quality and efficiency, but it is one of the

most demanding manufacturing processes. Tool specialist

LMT Tools, known for its high level of innovation

and consistent customer focus, is now simplifying

the process with an engineering portal that provides

targeted support, minimizes errors, saves time and ensures

quality.

The engineering portal combines over 100 years of gear cutting

expertise with the possibilities of digitalization, ushering

in a new era for the process. Skiving has never been so easy.

Skiving is one of the most efficient methods for producing

gear teeth. It combines flexibility with high productivity and

offers clear advantages over conventional methods such as

hobbing, gear shaping and broaching. Even complex internal

gear teeth can be manufactured precisely in a very short time,

and machining close to interfering contours or block tooth

machining can also be carried out without any problems. Another

plus: the kinematics can be mapped on many universal

machines with the appropriate software, so special machines

are not necessary. Several machining steps, such as turning,

drilling, and even gear skiving, can be performed in a single

clamping. In summary, this results in a number of benefits

for the user: short machining times, reduced non-productive

and setup times, long tool life, low tool costs, excellent surface

quality and expanded application possibilities.

Skiving is technically demanding

However, despite these strengths, the process is not yet in

widespread use. The reason: it requires precise interaction

between the process, tool, and machine and is extremely demanding

from a technical standpoint. This poses challenges

for many users. “In skiving the tool is positioned at an angle

to the axis of the workpiece being machined. The gear teeth

are formed by this so-called axis cross angle in conjunction

with a synchronous movement between the tool and

LMT Fette's skiving

wheels set standards in

terms of machining time,

manufacturing costs, component

quality, tool life, and process reliability

LMT Fette's gear cutting tools

impress with their unique performance,

high level of innovation, and unparalleled efficiency

workpiece axes and an axial feed. It is a very precise and fast

process, but complex to use”, explains Sascha Beblein, head

of RD&E gear cutting at LMT Tools, adding: “Many of our

customers would like to use skiving, but lack practical and

process knowledge. We are now closing this gap. Our new

digital engineering portal makes working with our tools

noticeably easier and makes skiving usable for everyone.”

LMT Tools: excellence meets innovation

LMT Tools is one of the most renowned experts in the development

and production of precision tools and has unique

tool expertise, comprehensive technology and application experience,

and a high level of vertical integration. All process

steps are carried out in-house – from raw materials to the finished

tool. This ensures quality, flexibility and cost efficiency.

Customers appreciate the company’s forward-looking approach,

holistic methodology and collaborative partnership.

Powerful and reliable gear skiving wheels

The group’s gear cutting specialist is LMT Fette, a subsidiary

of LMT Tools. The company supplies high-performance, reliable

tools for skiving, combining the latest research findings

with proven application and manufacturing expertise. With

their unique combination of excellent cutting edge preparation

and individual process simulation, the skiving wheels set

standards in terms of machining time, manufacturing costs,

component quality, tool life and process reliability, guaranteeing

maximum performance in the production of internal

and external gears. Specially developed simulation software

allows a detailed assessment of the relevant process parameters

to be made during the design phase, considering the

respective customer requirements, and provides valuable

support on the way to safe and successful tool use.

Digital assistance for self-help

Each skiving wheel is unique: the cutting material, cutting

geometry, coating and cutting edge preparation are precisely

tailored to the component and the customer-specific process.

Accordingly each tool is individually parameterized and calibrated

on the machine. However, the complex adjustment and

calibration processes are anything but trivial and regu larly

cause even experienced users to ponder. A key problem is that



if deviations occur in the measurement report –for example

during initial commissioning, after prolonged use, or after regrinding

this usually requires consultation with LMT Tools.

That costs time. “As the manufacturer we know our tools best

and know exactly what correction values are required in the

event of deviations from the target value”, says André Bollow,

head of the gear cutting product line at LMT Tools, making it

clear: “With the new engineering portal we enable users now

to analyze deviations independently and correct them immediately

without having to forego our expertise – quickly,

easily and without detours.”

Complex in theory, simple in practice

After entering the material and serial number (indicated on

the tool) and the relevant measured values, the tool calculates

the appropriate correction values in seconds and provides

clear adjustment instructions, including for the cross

angle and kappa angle – two key parameters in skiving. This

transforms a complex correction process into a streamlined

workflow. The application is deliberately designed to be simple

and intuitive so that machine operators of all experience

levels can use the digital engineering portal with confidence.

This is groundbreaking considering the shortage of skilled

workers and demographic change.

A new standard

The engineering portal is automatically available with every

tool purchase and can be used immediately after a one-time

online registration. Determining correction values for deviations

from the target value is an essential function, but not

the only one. Other features include the retrieval of cutting

data, an overview of available tools, the provision of setting

data sheets, drawings and tool information, as well as practical

application aids. All information is accessible at any time

and from any device – be it a PC, tablet, or smartphone.

Gear skiving for everyone

“Our motto ‘to ease machining’ is both a benchmark and

a promise. We don’t just supply tools, we supply solutions”,

Sascha Beblein sums it up, emphasizing: “We support our

customers throughout the entire life cycle of our tools – from

the initial idea to recycling – and are always available to assist

them. With the new digital engineering portal we offer practical

support and give users a decisive competitive edge.” The

The envelope geometry shows the trajectory of the

cutting edge during tool engagement

Gear skiving is one of the most efficient

methods for producing internal and external gear teeth;

even when there are interfering contours at the gear tooth exit,

as on this component, skiving can be used in many cases

advantages are obvious: time savings thanks to immediately

available correction values, autonomy thanks to independence

from experts, higher gear quality thanks to precise

parameterization and greater process reliability by minimizing

sources of error. This leads to measurably higher productivity

and lower unit costs.

Gear skiving: an efficient process

with a promising future

There’s no question about it: roll forming is a process with a

bright future. With its efficiency, high performance and wide

range of applications, it offers great potential, especially in

the manufacturing of internal gear teeth. A practical example

illustrates its superiority in use: one customer relied on

erosion to manufacture gears, which took six hours per component.

After switching to roll peeling, the process step was

reduced to 1.5 minutes – an enormous time saving. This

increase in efficiency is invaluable, especially against the

backdrop of rising demand for hollow wheels with internal

gear teeth for electromobility.

Digitally simple. Simply digital

With its engineering portal LMT Tools is breaking new

ground and making it easier to access skiving. This innovative

tool simplifies the use of this complex technology and

combines expertise, data and support in a single solution. It is

the only one of its kind in the world. “Customer and market

requirements are key drivers of innovation for us. Digitalization

plays a key role in this”, says André Bollow, adding: “We

see ourselves as partners to our customers and want to make

working with our products as easy and efficient as possible.

The customer experience platform is the next logical step:

it makes our tool and process expertise digitally accessible

and opens up skiving to many users.”

Currently the engineering portal focuses primarily on

skiving but also includes other tool families. ChamferCut

and hobs are already integrated, with additional tools and

services to follow gradually.

further information: www.lmt-tools.com


17


PCD – for more than 50 years available for the cutting tool industry – 1973-2026

How super-hard cutting materials revolutionized

machining

Horst Lach, CEO of LACH DIAMANT looks back:

“When I received the first polycrystalline diamonds for testing

from the manufacturer General Electric in April 1973,

shortly before the Hanover spring tradeshow, I immediately

gave them to our diamond cutting shop for natural diamonds.

We wanted to find out how this material could be ground

compared to natural diamonds.”

The answer did not take long. The head of our natural

diamond cutters, Kurt Wagner (†), an excellent diamond

expert, came to me and said: “Boss, we usually do everything

for you, but this beastly material is impossible to cut, nothing

works…” Just “poly” – or what?! Two more days until the start

of the tradeshow. We wanted to present this PCD material

under the trademarked name “dreborid” for turning interrupted

cuts as a tradeshow novelty for aluminum processing.

Someone had an idea regarding “poly” – actually, the diamond

grit within a diamond grinding wheel is also “poly”.

No sooner said than done. During grinding with a resin bond

diamond grinding wheel, mounted on a small steel grinding

machine, the first abrasion tracks or facets became visible.

This was the initial demonstration of grinding a cutting-edge

geometry on a polycrystalline diamond.

PCD compact milling cutter with direct cooling

(patented) through the diamond cutting edge

for machining aluminum and fiber composites

PCD tool program for manufacturing the wings for

wind power systems, milling, drilling and cutting

of glass fiber materials (GRP)

PCD milling cutter for

machining composite materials –

GRP – CFRP – wood-based materials



PCD chip breaker Type »IC-plus-world’s best« with active chip breaker for process-reliable turning of aluminum alloys

In retrospect, this first presentation at the Hanover tradeshow

in 1973 marked the beginning of a new era of cutting

technology. The turbo was ignited. In 1975 cubic crystalline

boron nitride (CBN) cutting materials complemented the

program of super-hard cutting materials for machining highalloy

hardened steel, starting from 58 HRC. Based on the success

of Borazon® CBN grinding wheels since their premiere in

1969, I personally had not anticipated compact boron nitride

(CBN) inserts before PCD.

The successful presentation of PCD-tipped saws and

milling cutters for the manufacturing of glass fiber reinforced

(GRP) circuit boards at productronica in 1977 in

Munich showed LACH DIAMANT the limitations for a

further distribution of PCD rotating tools.

The polycrystalline diamond material available for us,

had to be cut extensively, piece by piece, tooth by tooth. 25-

30 min. per tooth were quite common, and it had to be with

an accurate geometry. In addition the PCD manufacturers,

like General Electric, had to elaborately segment the pressed

PCD blanks by cutting off with diamond saws in order to be

able to deliver 60 °, 90 ° cutting edges, rectangles or squares.

Change, and the truly “sparkling” idea came from

LACH DIAMANT

At the end of 1978, Horst Lach filed a patent application for

spark/electro erosion for machining and forming polycrystalline

diamond and boron nitride. The second turbo was ignited.

An up to 350 times longer tool life than that of previously

used carbide tools convinced users all over the world.

Whole industries began to compete in using diamond tools.

Ahead of all, in the 1980’s, the wood and plastic industry,

followed by the automobile and aviation industry. Using

PCD tools was fashionable and – since highly economical

– virtually a “MUST-HAVE.”

At the next IMTS in Chicago/USA, September 14 - 19, 2026,

LACH DIAMOND INC., Grand Rapids, Michigan, will showcase

a complete portfolio of their polycrystalline diamond

and CBN tools, developed in more than 50 years.

Already today, a visit to www.lach-diamant.de will be

worthwhile your time.

further information: www.lach-diamant.de


19


Edge quality without compromise

Modern furniture fronts combine sophisticated

design with high durability. High-gloss surfaces, glass

laminates and decorative coated panels have become

indispensable in industrial furniture production. At the

same time these materials place the highest demands

on machining: even the smallest chipping, damaged

edges, or frayed protective films impair the visual appearance

and often result in rework and increased

scrap rates. With the Diamaster PRO EdgeExpert,

Leitz offers a tooling solution specifically developed for

these sensitive applications.

The innovative concept of the Diamaster PRO EdgeExpert

combines the strengths of a sizing cutter and a jointing cutter

in a single tool. This results in exceptionally high edge quality

already during the sizing process – a decisive advantage, as

perfect results are achieved in the very first machining step.

Perfect cut edges on all common machine types

The Diamaster PRO EdgeExpert produces chip-free cut edges

on console machines, nesting machines and panel dividing

saws – even with demanding surfaces and high-quality top

layers. Especially in serial production, this significantly increases

process reliability. The protective film is cut cleanly

without fraying. Downstream operations can be carried out

without additional corrections.

A key quality factor is the precisely coordinated tool geometry.

The axial angles are specifically adapted to the different

material zones: a higher axial angle in the area of the

top layers improves cut quality and minimizes tear-out, while

a lower axial angle in the core layer optimizes chip evacuation.

At the same time only minimal pressure is exerted on

the core layer, preventing compression and preserving the

structural integrity of the material. Large chip gullets ensure

reliable chip removal, even at high feed speeds.

The

Diamaster

PRO EdgeExpert

combines a sizing cutter

and a jointing cutter in a

single tool, delivering exceptionally

high edge quality already during the sizing process;

for perfect surfaces without tear-out –even on the most

demanding materials

Higher feed rates, less rework

The Diamaster PRO EdgeExpert enables feed speeds of up to

25 m/min. This noticeably reduces cycle times and increases

efficiency in the production process. Less rework and lower

scrap rates further enhance cost-effectiveness. The diamondtipped

tool also sets benchmarks in terms of service life. It

can be resharpened up to three times and maintains its performance

over extended operating periods. This makes the

Diamaster PRO EdgeExpert a sustainable and economically

sound investment for companies with the highest quality

standards.

The standard range includes two versions with a diameter

of 12 mm and cutting lengths of 24 mm or 30 mm. The tool is

ideally designed for panel thicknesses from 16 to 28 mm and

offers maximum flexibility when machining a wide variety of

furniture materials with high-quality surfaces.

Optimized cutting geometry and generously dimensioned

chip gullets enable high feed rates while maintaining

excellent surface quality

The Diamaster PRO EdgeExpert stands for perfect edges,

maximum precision, and productivity that delivers measurable

benefits directly in production.

further information: www.leitz.org


news & facts

Change on the management board

After more than 36 years with the LEUCO Group,

including nine years as CEO, Jean-Michel Peter retired

at the end of February 2026.

During his time with the company, he promoted the development

of LEUCO with commitment, strategic vision, and

a sense of responsibility. Under the management board

LEUCO S.à.r.l. consolidated its position, expanded its expertise,

and continued its dynamic innovation and growth. His

leadership qualities, high professional standards and commitment

to the company’s values have had a lasting impact

on the team and partners.

To ensure continuity and maintain this momentum

Dr. Dominique Fendeleur took over the position of CEO

on March 1, 2026. Dominique Fendeleur has been with the

LEUCO Group since 1997 and has held various strategic

positions, most recently as technical product director at

LEUCO production S.à.r.l. His high level of expertise,

detailed knowledge of the company, and forward-looking

innovative strength make him the ideal person to meet the

challenges and achieve the goals facing the Group. This transition

is in line with the desire for continuity, stability and

sustainable development of the business.

Dominique Fendeleur (left) has been CEO of LEUCO S.à.r.l. since

March 1, 2026, he succeeds Jean-Michel Peter, who is retiring

after nine years as CEO and a 36-year career at LEUCO

LEUCO S.à.r.l was founded in 1961 in Ostwald (France,

near Strasbourg). Today LEUCO is one of France’s leading

suppliers of new tools, grinding services and consulting

in the field of tools for the wood and furniture industry.

LEUCO S.a.r.l employs 80 people at its headquarters in

Ostwald (département 67) and at its four grinding centers in

Meyzieu (69), Ballan Miré (37), Vitrolles (13) and Ostwald

further information: www.leuco.com

Change in management

A change in management is taking place at the British

subsidiary of the Vollmer Group. After many successful

years, Martyn Cross will step down from his role

as managing director of VOLLMER UK Ltd in April

2026 and retire.

Martyn Cross has played a key role in shaping the development

of VOLLMER UK and has significantly strengthened

the company’s market position in Great Britain. Through his

strong commitment, extensive expertise and close ties with

the Vollmer Group, he has made a substantial contribution

to the company’s success. The Vollmer Group would like to

express its sincere thanks to Martyn Cross for his dedication

and valuable work, and wishes him all the best, good health

and many new personal projects in this new phase of life.

In April 2026 Christopher Hellyer will assume the role of

managing director of VOLLMER UK Ltd. After completing

his apprenticeship, he began his professional career as a service

technician before moving into sales, where he gained

more than 33 years of extensive experience in senior sales

management positions. He will take on his new responsibilities

gradually and will work closely with Martyn Cross over

the coming months to ensure a smooth transition. With his

long-standing industry experience and in-depth market and

sales knowledge, Christopher Hellyer brings excellent qualifications

to continue the successful development of VOLLMER

UK. The Vollmer Group considers itself well positioned for

the future with this management change and looks forward

Martyn Cross (right), outgoing managing director of

VOLLMER UK Ltd, and his successor Christopher Hellyer,

who will assume the role of managing director in April

to continuing its successful collaboration with the team in

Great Britain.

“The years at VOLLMER UK have been a very special and

enriching time for me. Together with a dedicated team and

in close cooperation with the Vollmer Group, we were able

to continuously develop and strengthen our market position

in Great Britain. I am very grateful for the trust placed in me

and the support I have received. I am confident that VOLLMER

UK will continue to be successfully positioned under the

leadership of Christopher Hellyer”, adds Martyn Cross.

further information: www.vollmer-group.com


21

news & facts

Mitsubishi Materials appoints new president

of the metalworking solutions division

Mitsubishi Materials Corporation announces the

appointment of Mirko Merlo as president of its

Metalworking Solutions Division, effective from

April 1 st , 2026.

An accomplished executive with a strong track record in

organizational transformation and value creation, Merlo will

lead the division’s next phase of international expansion,

focusing on high-growth and high-margin market segments.

He succeeds Kazuo Ohara, who will retire after many years

of dedicated service to the Group.

In his previous role as chief strategy and sales officer of

the Metalworking Solutions Company, Mirko Merlo played a

pivotal role in modernizing the organization’s operating

model. Under his leadership the company implemented major

structural and operational improvements, including process

optimization, integration of shared services and cost efficiency

programs. These initiatives significantly strengthened the

company’s resilience and long-term competitiveness.

In his new position Merlo will oversee the continued international

development in established and emerging markets.

The division will continue to grow across Europe, Asia-Pacific

and the Americas responding to increasingly sophisticated

application requirements and growing sustainability expectations

from customers worldwide.

Commenting on his appointment, Mirko Merlo said: “Together

with Moldino and Mitsubishi Materials Hardmetal, we

will leverage our robust technical capabilities and profound

customer relationships to deliver innovative, high-performance

solutions. Our focus will be on supporting demanding

applications with a comprehensive, reliable service portfolio

that generates measurable value.”

Tetsuya Tanaka, chief executive officer and president of

Mitsubishi Materials, added: “Mirko Merlo’s strategic vision

and collaborative leadership will be instrumental in advancing

our internationalization strategy and strengthening our

market position. His strong focus on operational discipline,

customer value and sustainability supports both our shortterm

priorities and long-term objectives.”

This leadership transition reflects Mitsubishi Materials’

commitment to developing a resilient, more customer-centric

organization capable of delivering high-impact technologies

and services across global markets.

further information: www.mmc-carbide.com

New director of global key account management

at MAPAL Group

Recently Mark Lich assumed the role of director global

key account management, taking over the leadership

of this newly established department with the same

name.

He is responsible for the strategic and operational management

of sales activities and results for MAPAL’s global key

accounts. Lich reports directly to the chief sales officer of the

MAPAL Group, Claudio Gabos.

Mark Lich joined the company at the end of 2013 and

has extensive experience in various sales roles at MAPAL.

Among other roles, he has served as regional sales manager

in Southern Germany and managed global strategic sales

projects.

Since January 2023 he has headed the sales management

office (SMO), which is responsible for steering and supporting

global growth and efficiency goals within strategic sales

management. He will continue to fulfil this role alongside his

other responsibilities.

further information: www.mapal.com


news & facts

STUDER reports positive results

for the 2025 financial year

The Swiss technology company for precision cylindrical

grinding machines was able to strengthen its

global market position despite the challenging geopolitical

situation, expand its portfolio with innovative

new products, develop its customer care further

and invest several million Euros in infrastructure.

Fritz Studer AG’s annual press conference took place in

Steffisburg in front of international media representatives

under the motto “Swiss Made”. “The year 2025 was marked

by challenging markets and geopolitical uncertainties.

Nevertheless we exceeded our expectations and emerged

from this phase stronger than ever”, said CEO Sandro

Bottazzo. Despite complex global conditions, the Swiss technology

company was able to strengthen its market position

worldwide, expand its portfolio with important innovations

and further increase its operational efficiency. Particularly

pleasing was the excellent market response to the new S23

universal cylindrical grinding machines and the latest generation

of favoritCNC. In customer care, the long-established

manufacturer even achieved record sales in paid

service and maintenance.

STUDER maintains and expands market share

worldwide

Total sales were slightly below the previous year’s level but

exceeded expectations thanks to a strong year-end performance.

Thanks to its excellent market positioning, STUDER

achieved good sales in North America despite customs

challenges. The result in Asia was also positive and above

the previous year’s level, especially in China. STUDER

also exceeded the previous year’s level in terms of machine

orders received. The high proportion of new customers, at

44 %, was also encouraging. Orders from North America,

Asia, and European countries such as France, Czechia and

Denmark in particular supported this result.

Germany, Italy and Switzerland, on the other hand, fell

short of expectations. Overall, however, market share was

maintained or expanded in all regions of the world. The

customer care segment performed very well. “Thanks to

our global, customer-focused service organization, we were

able to set new sales records in the service and maintenance

business areas,” explained Bottazzo. In many markets, over

70 % of the active installed base has a maintenance contract

now. In the area of machine overhauls, the year ended

with one of the best order backlogs in the company’s 114-year

history.

STUDER is very well positioned

in the aerospace industry

The aerospace segment delivered another record. It closed as

the largest single segment for the first time, accounting for

Stephan Stoll – COO, Sandro Bottazzo – CEO,

Daniel Huber – CTO (from left to right)

almost a third of all orders. Other important categories were

precision engineering, machine tools and the automotive

industry. “Our broad portfolio remains a pillar of success

and covers a wide range of universal cylindrical grinding applications”,

emphasized Bottazzo. The best-selling machine

was the S33, followed by the S31 and the S41. External and

machines for internal cylindrical grinding also both performed

well. The S141 even achieved one of the best sales

results of the last ten years.

An additional event in 2025 was the acquisition of

GF Machining Solutions by the UNITED GRINDING Group,

which now operates under the name UNITED

MACHINING SOLUTIONS. With total sales of over USD

1.5 billion and around 5,000 employees at over 50 locations,

the group is one of the largest machine tool manufacturers

in the world. As part of the acquisition the STUDER

Competence Center for internal cylindrical grinding moved

to the modern premises of UNITED MACHINING at

Roger-Federer-Allee 7 in Biel (Switzerland), just a few minutes

away from its previous location.

STUDER expects the economy to pick up in 2026

In the third and especially in the fourth quarter, STUDER

recorded a significant increase in the number of sold

machines, which, from today’s perspective, is set to continue

in 2026. Consequently the company expects a further

increase for the current fiscal year.

further information: www.studer.com


23

news & facts

New center for applications and

assembly of drive systems

Motion control specialist Aerotech is significantly expanding

its capacity at its Fürth site. In addition to

setting up a state-of-the-art laser laboratory, controls

components will also be assembled there in the future.

With this expansion, the company is responding to the growing

global demand for its high-precision positioning and

automation solutions while also strengthening its delivery

capabilities in Europe.

The first phase of the expansion will focus on the assembly

and testing of XA4 series servo drives and motion controllers.

The additional capacity is intended to create greater flexibility

in production, help stabilize supply chains and further

increase product availability in European markets.

“With the expansion of our site in Fürth we are investing

specifically in growth, customer proximity and operational

flexibility”, explains David Holmes, COO of Aerotech Inc.

“By assembling drives locally we are accelerating our market

response and scaling production while maintaining our

high quality standards.”

The building in Fürth was designed in 2016 to support

future growth. The current initiative is therefore part of

Aerotech’s long-term investment strategy to systematically

develop and strengthen its European location.

Laser laboratory as a European center of excellence

In parallel with the expansion of its assembly capacities,

Aerotech is commissioning a new laser laboratory for applications

in laser material processing. In order to not only

Initial assembly workstations ensure fast delivery

of Aerotech drives to the European market

be able to design processes theoretically, but also to verify

them in interaction with real systems, Aerotech is creating

the appropriate environment in Fürth, thereby significantly

facilitating cooperation with customers and interested parties.

Customers from all over Europe will have the opportunity

to test and optimize laser-based manufacturing processes

under realistic conditions and develop them further

in collaboration with Aerotech. In the long term, the laboratory

will serve as a European center of excellence for micro

and precision material processing.

further information: www.aerotech.com

VIGEL to announce the acquisition of MCM

On January 30 th , 2026, VIGEL S.p.A. (Borgaro Torinese,

TO) and MCM S.p.A. (Vigolzone, PC) announced

that the transfer of ownership of the MCM S.p.A. to

MCM Manufacturing Technologies S.r.l., a subsidiary

of the GENFIN holding , which also controls VIGEL

S.p.A., was completed.

Both Vigel and MCM are recognized as players of excellence

in the manufacturing technologies sector, the acquisition

supports the long-term vision of building a strong and diversified

organization focused on advanced machining

solutions for the global industry.

VIGEL SpA is a company founded in 1947 in Torino and

still owned by the founder’s family. VIGEL was one of the

pioneers in the design and manufacture of multi-spindle

machining centers and is now a multinational company with

factories in Italy (Turin), India and China, and branches in

Europe, the United States, Mexico, India, China and Korea.

MCM Manufacturing Technologies S.r.l.Vigolzone, PC

In addition to machining centers, VIGEL’s product range

also includes vertical lathes and special machine tools for

the automotive industry.


fairs

news & facts

MCM SpA is a company founded in 1978 in Piacenza,

specializing in the design and manufacture of horizontal

machining centers and flexible production systems that

operate through supervision software developed by its own

IT division. MCM’s mechanical processing technologies are

applied to a wide range of industrial sectors, with a focus

on aerospace.

The acquisition strengthens the ability to offer a wider

range of products and technologies, diversify the market

of reference and build up strategies which will reinforce the

synergies between the two companies as sales, product’s

development, manufacturing, procurement as well reinforce

the presence and closeness to our today even wider and

diversified customer base.

further information: www.vigel.com

Vigel S.p.A., sede Borgaro Torinese, TO

Strong international presence

at GrindingHub

With over 430 exhibitors from 28 countries, the worldleading

trade fair, taking place from May 5-8, 2026, in

Stuttgart is once again sending out a powerful message

to the industry: despite falling production and export

figures, grinding technology remains highly innovative,

and GrindingHub is positioning itself as the

central platform for the industry.

Industry caught between decline and innovation

The economic conditions remain challenging, as recent statistics

show. German production of grinding, honing, lapping

and polishing machines reached € 626 million in the first

three quarters of 2025 – down 15 % from the same period

of the previous year. The downturn was particularly pronounced

in exports, which fell by 25 % to € 456 million. In

contrast, domestic sales developed positively, growing to

a volume of € 170 million between January and September

2025 – a 33 % increase. Incoming orders tapered off toward

the end of 2025, with the annual balance closing with a 5 %

deficit. The domestic market in particular was significantly

weaker, whereas exports remained largely stable. “The numbers

show clearly that the industry is navigating a challenging

environment. Yet we are also seeing strong innovation

momentum across many companies. In times like these the

sector needs guidance, avenues for information sharing

and tangible business opportunities – which is exactly what

GrindingHub delivers”, says Dr. Markus Heering, executive

director of VDW and organizer of GrindingHub.

International participation continues at

all-time high

More than 430 exhibitors – from start-ups to global giants –

have confirmed their booths at GrindingHub. Over three

halls at Messe Stuttgart exhibitors from Germany, China,

Switzerland and Italy in particular will present their innovations

from every stage of the valued chain – from

grinding machines and abrasives, process peripherals and

software solutions, to measuring and testing technology.

“GrindingHub is so much more than just a product show. It

is the international stage for grinding technology and a place

where partnerships are forged, investments are prepared and

future technologies are set in motion”, emphasizes Heering.

The fact that Switzerland is one of the most strongly represented

countries among the exhibitors highlights the importance

of grinding technology for its industry at home.

“Grinding machines make up around a fifth of Swiss machine

tool exports. This underscores the critical role of such technology

for our member companies”, says Christoph Blättler

from Swissmem, the association for the Swiss technology

industry. “The Grinding Pavilion Switzerland gives smaller

companies in particular an efficient way to shine at the

trade fair.”

further information: www.grindinghub.de


25

news & facts

A reward for sustained innovation

Hainbuch GmbH has been awarded the TOP 100-Innovator

2026 – in category C (more than 200 employees).

The recognition places HAINBUCH among Germany’s

most innovative mid-sized companies. The official

award ceremony will take place on June 26, 2026,

at the Congress Center Heidelberg, as part of the

German SME Summit.

At HAINBUCH innovation is not accidental – it’s systematic.

The TOP 100 evaluation does not focus on individual inventions;

instead it assesses innovation management and innovation

performance. Professor Nikolaus Franke (Vienna University

of Economics and Business Administration) and his

team examine more than 100 criteria in five categories:

innovation-friendly senior management, climate of innovation,

innovative processes/organization, outward looking/

open innovation and successful innovations.

“Smart solutions” – and the courage

to try something new

HAINBUCH is a leading manufacturer of solutions for

clamping, change-over, measurement and automation for

milling, turning and grinding on machine tools. The familyowned

company has been based in Marbach am Neckar since

1951 and operates worldwide with eleven subsidiaries.

HAINBUCH is defined by a blend of Swabian ingenuity,

hands-on practicality and a clear customer focus. Doers,

thinkers and developers share one mission: to continuously

simplify, advance and automate workholding processes.

The company’s innovation culture is closely linked to the

spirit of the owner family. Gerhard Rall, owner and inventor

of the SPANNTOP principle, sums up this mindset: “We

want to make our customers successful and strive for excellence

and smart solutions. We would rather fail with an

innovation than succeed by copying.”

Employes and management celebrate the award

This attitude has shaped HAINBUCH for decades –

from the breakthrough in workpiece clamping with the

SPANNTOP principle in the 1970’s to today’s solutions for

reliable, connected, and automation-ready manufacturing.

Examples include intelligent IQ clamping devices and the

automated centroteX AC quick change-over interface for

changing over entire clamping devices in automated manufacturing

processes. Innovation also shows up in everyday

execution: every year HAINBUCH develops more than 1,000

custom solutions together with customers for demanding

clamping applications.

“For us the TOP 100 award confirms that our commitment

to innovation is lived throughout the entire company – from

the idea and the process to measurable customer benefits.

We invest specifically in technology, know-how and collaboration

to make manufacturing easier, more precise and more

automatable”, explains Sylvia Rall, owner and CEO.

further information: www.hainbuch.de

Enhanced e-commerce platform to

enhance customer experience

Sunnen Products Company, a global leader in highprecision

bore finishing and measurement, announced

the launch of its new public website and B2B e-commerce

platform, designed to enhance the online experience

for customers seeking precision honing equipment

and solutions.

The website introduces a modern look and intuitive feel, offering

easier and more user-friendly navigation for shoppers.

Online ordering of Sunnen’s consumable products is currently

available for customers in the US and Canada. Visitors

to the site will benefit from access to all their online orders,

including those placed through the previous online ordering

platform, ensuring continuity and convenience. Users can

create saved lists similar to wish lists and save shopping carts

for future use, while the ability to place orders for any saved

ship to location from the same account removes the hassle of

multiple logins.

In addition to the new online ordering experience, the over -

all website has been redesigned to help global visitors access

the product and application information they need when eval -

uating Sunnen’s portfolio of machines and consumables.

further information: www.sunnen.com


Gear cutting and grinding from a single source

processes

Liebherr-Verzahntechnik GmbH is continuing the

systematic development of its platform strategy with

the redesign of its machine platform for workpieces

up to two meters in diameter. The new series encompasses

all relevant gear technologies and is aimed

at manufacturers of large gears, particularly in the

mechanical engineering, marine propulsion, construction

machinery and wind power industries.

The lineup begins with milling and profile grinding

machines designed for this size range – making it possible,

for the first time, to perform precision hard machining on

large workpieces.

By expanding the platform Liebherr now offers the entire

machining spectrum in this size range and is responding

to growing demand for soft and hard-fine machining

from a single source. “Our concept is designed specifically

for this segment as a comprehensive solution”, explains

Thomas Breith, head of product management for Gear Technology.

The new LGP 2000 enables profile grinding of

workpieces up to 2,000 mm in diameter. In future customers

will receive a machine package that includes milling and

grinding – a combination that is often used in the machining

of large components.

mally than with the previous machines”, explains Thomas

Breith. The machines feature a high-precision, hydrostatically

mounted table with wear-free direct drive. Depending

on the machine type, flat or roller linear guides are used,

which enable high damping during gear cutting and maximum

precision during grinding and gear testing on the machine.

Two main stand variants with 1,500 and 2,000 mm of

stroke enable efficient machining of even particularly long

shafts with multiple gear teeth. The platform’s machines are

designed to accommodate automation solutions like pallet

changers and ringloaders.

New gear cutting features: integrable

chamfering device, optimized chip removal

A new feature is that the gear cutting machines offer an

optional chamfering device with a conventional end mill

(FlexChamfer) that can be used directly on the cutter head.

This allows for cost-effective machining even with small

batch sizes. When milling internal gear teeth, an integrated

chip removal system eliminates the need for a separate,

costly channel in the factory floor. The gear cutting machines

are suitable for both dry and wet machining.

Profile grinding:

new LGP series for large gear teeth

Various grinding head configurations are available on the

LGP for profile grinding of large gears. A unique feature

is the sequential use of two grinding wheels without a tool

change. This allows different tool specifications to be used,

which either shorten the grinding time or enable higher

surface qualities to be achieved in production.

LGP allows both high speed grinding and creep feed

grinding. Single- or double-sided topological profile grinding

and internal grinding using an optional, swivelling internal

grinding arm are possible thanks to the modern

LHGearTec. In addition to a conventional double dresser,

the LGP can also be equipped with a double dresser for simultaneous

dressing of both grinding wheel flanks. This

allows dressing times to be almost halved and the productivity

of the profile grinding machine to be significantly

increased once again.

New platform:

modular, economical, precise

The newly designed large machine platform offers consistent

synergies across all machining processes, thanks in part

to a uniform control interface. Shorter processing times for

profile grinding reduce machine costs and thus reduce unit

costs for the customer. The modular design also improves

the availability of spare parts, ensuring high machine availability.

The new milling and profile grinding machines

was unveiled at EMO in September 2025.

The new high-performance grinding head

Modular system

The redesign was focused on modularity, flexibility and

reduced component diversity – with the aim of optimizing

delivery times and spare parts availability. All machines are

built on a thermally symmetrical machine bed that is precisely

temperature-regulated via circulating coolant. “This

makes gear cutting and grinding even more stable therfurther

information: www.liebherr.com


27

processes

Strategic aircraft component with all the trimmings

As part of a joint project, MAPAL and machine

manufacturer bavius designed and manufactured a

demonstration part for the aerospace industry. The

aluminum component, measuring approximately

3 x 1 m, is based on a real rear spar from aircraft manufacturing

enhanced with a variety of complex features.

Besides its complexity, the component is also impressive due

to the short machining time of ten hours thanks to the productivity

of the bavius AeroCell and the special MAPAL tools

used for aluminum machining.

bavius technologie, from Baienfurt in Southern Germany,

is specialized in the high-speed volume machining of structural

components made of aluminum, which are typically

required in the aerospace industry for wings and fuselages.

Previously known as Handtmann A-Punkt Automation, bavius

has been active as an independent family business since 2017,

concentrating on two product lines: HBZ and AeroCell horizontal

machining centers and the PBZ profile machining centers.

With around 120 employees, bavius generates more than

80 % of its turnover in the aerospace industry. As an OEM or

supplier, their customers produce components for commercial

and military applications. Components for satellites or

rockets like the Ariane 6 are also produced on their machines.

Entirely ‘Made in Germany’

Most bavius machines are located in Europe, but they are

also strong in North American and Asian markets. While

the company has offices in the United States, production for

all markets worldwide exclusively takes place in Baienfurt in

two air-conditioned halls with a production area of approximately

10,000 m 2 .

The NeoMill-Alu-QBig with Ø 50 mm

A particular strength of bavius’s five-axis machining

centers is that they are extraordinarily dynamic, which ensures

high productivity during high-speed machining. To

get every last drop of productivity out of their machines,

bavius manufactures its own milling heads. The flagship of

their product range is the bavius AeroCell 160 | 400 with a

spindle power of 140 kW and top speeds of 30,000 rpm. The

140 kW are already reached at 18,000 rpm, i.e. the maximum

power is available over a wide range of speeds. “When

we do something, we make sure it’s done excellently – we are

global technology leaders with our AeroCell 160 | 400”, says

Dominik Merz, director global sales.

Over 90 % chips

The rear spar is selected as a demonstration part because

it fits perfectly on the machine with a table height of 1.6 m

and width of 4 m. The rear spar is a common structural component

in wings. Ribs run between the rear spar and front

spar, which are arranged perpendicularly to the spars. These

structural components define the geometry of the wings.

The outer skin is riveted onto them. The completed component

is made of 7075 aircraft aluminum and measures

2977 × 748 mm. Its flat form measuring 138 mm high is typical

of aircraft components. From one ton of starting weight,

only 70.61 kg remain after machining – a proportion that is

quite common in the aerospace industry.

Legal reasons prevented bavius and MAPAL from using a

real aeroplane component for the machining. This however

gave those responsible the freedom to use the design for

a variety of applications. As a result, this demonstration piece

is much more complex than any normal rear spar. It includes

features that are not necessarily associated with a spar but

could be useful for other components. “A customer who

knows structural components and sees our part will recognize

it and notice characteristics that are also found in their

own components”, Merz says, explaining this approach.

Proudly presenting the finished demonstration part

in front of the AeroCell 160 | 400 (from left): Jens Ilg (MAPAL),

Alexander Follenweider (MAPAL), Stefan Diem (bavius) and

Dominik Merz (bavius), left to right;

the clamping setup can be seen in the foreground

Machining takes place in Baienfurt in two clamping setups.

While setup 1 uses low tension, setup 2 harnesses vacuum for

secure hold. At first glance, the front looks simpler than it actually

is. The surface is not flat but curves slightly outward

over a radius of 9.5 m. This means that the component cannot

simply be face milled. Instead five-axis machining is nec-


processes

essary. For roughing and finishing the NeoMill-Alu-QBig

with Ø 50 mm and the OptiMill-Alu-Wave with Ø 25 mm are

employed. The surface finish is performed by a PCD custom

milling cutter.

All sorts of pockets

The machining of the back is particularly sophisticated. It is

separated in nine different sections, each with its own special

features. Like any rear spar, the demonstration part has

many pockets. They are however completed here in all sorts

of forms: rectangular, triangular, round, open, closed, some

with inclined or curved bottoms. The ribs are very thin; the

walls are mostly inclined. The pockets are up to 137 mm deep.

After pre-machining with the NeoMill-Alu-QBig, the

pockets are cleared out by an OptiMill-Alu-Wave of various

lengths. The semi-finishing is performed by a shoulder

milling cutter modified specifically for aerospace applications.

Thanks to its special geometry, the tool is particularly

suitable for machining residual material in the corners as

well as subsequent finish milling of the floors and walls. The

special core rise ensures optimal stability during the machining

process. To machine all the areas efficiently, MAPAL experts

use different diameters and lengths of the modified

shoulder milling cutter.

MAPAL also sets great store by efficiency during programming,

as component manager Alexander Follenweider

explains: “We work with a zigzag strategy in the parallel

and counter feed to save on travel time. We thus constantly

switch strategies during machining.” Despite the high machining

speeds the aluminum may not be damaged as it

changes properties when overheated.

At top speeds, the OptiMill-Alu-Wave achieves a feed of

12 m/min at a cutting depth of 48 mm at 29,000 rpm. The bigger

NeoMill-Alu-QBig achieves a feed of 25 m/min at 10 mm

cutting depth. Alone in the first 55 min. of machining of the

second clamping, 425 kg of aluminum are thus machined. At

its peak, this results in a chip volume of more than 14 l/min.

“The results we were able to achieve here are excellent – and

we were also able to create very good surfaces in the process”,

says Stefan Diem, application engineer at bavius.

Nothing is standard

The various pockets are not the only challenges on the component:

the bores on the four lugs can only be reached via an

angled head. Undercuts are required elsewhere. A T-stiffener,

which is common for structural components and provides

rigidity, is also found on the demonstration part and is machined

with a special PCD tool. Bore and reaming operations

are also called for in certain areas. “Nothing is normal on our

component”, Merz says, referring to the fact that you will be

hard pressed to find a right angle anywhere on the part. Such

oblique constructions are however the norm in the aerospace

industry.

For the involved partners’ customer presentations and as

an eyecatcher for trade fairs, five of these rear spars are produced

in Baienfurt. The machining of a part takes a total

of almost precisely 10 h. “A component like this can take

The pockets with various forms were the biggest challenge of the

demonstration part; some special features were included, such

as lugs with bores or a T-stiffener (top left of figure)

between 20 - 30 h on other machines”, Merz estimates.

Structural parts are usually machined vertically on gantry

machines with big tools. Cutter heads with diameters of

125 mm are normal. Feeds and speeds remain low. One disadvantage

of this way are chips being left behind which

can cause scratches. Heat is also transferred to the component.

Horizontal machining precludes this. Together with

powerful tools that enable high cutting data, the dynamic

AeroCell 160 | 400 opens entirely new possibilities thanks to

its extreme acceleration.

Close collaboration

MAPAL and bavius have been profiting from their close cooperation

since many years. While MAPAL was developing

the NeoMill-Alu-QBig and OptiMill-Alu-Wave, they were

able to test and further optimize prototypes of the new tools

in Baienfurt. As a tool manufacturer MAPAL doesn’t have

equally powerful machines in Aalen, and bavius depends on

innovative tools, as Diem explains: “For our premium machines

we need top tools by suppliers like MAPAL offering

high-volume milling cutters that take our machines to their

limits. That doesn’t work with universal tools – we don’t gain

any insights with them.” Two years ago the partners demonstrated

what the AeroCell 160 could do. During test operations

with overloading, the solid-carbide milling cutter

OptiMill-Alu-Wave achieved chip volumes of up to 20 l/min

while full slot milling normal aluminum. The top results

achieved here are every bit as impressive: 12 l/min for a component

made of the AL 7075 with its higher tensile strength.

“I really appreciate the collaboration with MAPAL because

we speak openly and treat each other fairly, and because

they always provide a solution”, Diem highlights. For Jens Ilg,

business development Aerospace & Composites at MAPAL,

the success has also a personal dimension: “I also get an optimal

feel of our own products when I see them being used in

real and demanding conditions. And then I can offer them to

customers with corresponding recommendations.”

further information: www.mapal.com


29

processes

Micrometer in the fiber optic connector

Data transmission rates in high-speed networks

are influenced by many different things – one of the

most important ones is the quality of the connectors.

Especially in fiber optic networks, insert housings play

a central role in speed and signal quality. The more

precisely these parts are manufactured, the less loss

and the more stable electromagnetic light waves are

transmitted.

Kern Microtechnik implements the highest precision standards

in contract manufacturing – with tolerances of up to

2 μm and production quantities of several thousand units.

Plug connections are often the “bottleneck” for transmissions.

This applies to high-pressure applications of liquids as

well as to data that is transmitted with fiber optic cables in

electromagnetic light waves. Even the slightest inaccuracies

in position, angle or parallelism inhibit the transmission rate.

To prevent this the insert housings of the connectors, which

are primarily made of stainless steel, brass or Arcap, must be

manufactured with uncompromising precision.

The contract manufacturing department of Kern

Microtechnik GmbH in Murnau, Germany, has developed a

high level of expertise in this area over many years together

with demanding customers. Many companies working with

data processing, analytics and metrology technology as well

as chemical and pharmaceutical industries appreciate this.

Alexander Stauder, plant manager of Kern’s shop, explains:

“The main challenge for us is to meet the requirements of

each individual customer. To be able to guarantee this we

are usually always on board during the development phase

of the first prototypes.”

Kern Microtechnik manufactures the insert housings of the

fiber optic connectors, which are primarily made of stainless

steel, brass or Arcap, with uncompromising precision; here,

Alexander Stauder (left), plant manager of Kern’s shop explains

what is important

Precision manufacturing makes test redundant

In this way, according to Stauder, aspiration and result can

be steered in the right direction right from the start. Depending

on requirements, quality and cost specifications

are weighed up together to achieve the best result in the

end. As a high-end quality example, the experienced engineer

cites insert housings for fiber optic connectors from

various customers, which can be found in many different

industries, for example in entertainment technology and

defense industries.

The connectors must be very durable so that they can also

be used under difficult conditions. For example in the event

of extreme natural influences they still need reliably to transmit

maximum data volumes. This means that if the opposite

holes of the connector are shifted by even a few μm, this has

enormous, negative effects.

“To prevent this, most high-end manufacturers often check

the conformity of the holes during connector assembly by a

one hundred percent visual inspection”, explains Alexander

Stauder. “But after intensive development work and with

the high-end Kern Micro HD machining center we use for

production, this expensive additional test effort is a thing

of the past for our customers.”

The Kern Micro HD five-axis machining centers are crucial

for the extremely high, reproducible precision that

Kern Microtechnik’s shop achieves on its parts

Fully automated series production – μm-accurate

The Murnau-based shop manages to reliably manufacture

the insert housings of the fiber optic connector with an

accuracy of ≤ 2 μm in position, and not only as one single

part or a small series, but a fully automated batch size of ten

thousand pieces per year. “This number is by no means an

upper limit for us”, plant manager Stauder explains.


processes

Kern Microtechnik’s shop reliably manufactures

insert housings of fiber optic connectors – such

as the test parts shown in the photo – with an

accuracy of ≤ 2 μm in position and position;

this is not only possible on a single part or a

small series, but also fully automated in

batches of ten thousand parts per year

Kern’s contract manufacturing department is working with

the high-end Kern Micro HD five-axes machining center

to manufacture insert housings. The entire process is fully

automated. This means that the operator loads the tool

changer and workpiece changer at the beginning of the job.

He then calls up the corresponding program and clicks on

‘start’. Then, without any further action needed, a prefabricated

blank is positioned in the machine by the automation

system (internal or external). Then the part is completely

machined, removed and deposited as a finished part in the

same way while the next blank is already being picked up.

Quality of the machining center

makes the difference

What is described here in a few simple words represents a

highly complex process in practice, which is mainly based on

the quality of the machining center used. The most delicate

chips fly, and it only needs to be re-clamped once, including

finishing. This is important because the requirements for

position, angle and diameter tolerances of the decisive drill

are one in the single digit μm range. No matter what material

is being machined.

AMETEK, Inc., Berwyn, Pennsylvania, USA, was founded

in 1930 and is today a globally leading provider of

industrial technology solutions with annual sales of

approximately 7.0 billion USD. With a focus on highly

precise and differentiated products in various niche

markets, the group holds well over 100 renowned brands

in its portfolio. About 20 years ago, AMETEK invested in a

German medium-sized company for the first time.

Since February 2025, Kern Microtechnik has been the

sixth German company to join.

For Alexander Stauder and his team, this is not a problem

at all. According to their own statements, they feel absolutely

comfortable even in large-scale production with up to 2 μm

in all the aforementioned position tolerances: “The finished

parts are usually even more accurate. The biggest challenge

above all is reproducibility. And we prefer to stay conservative

with our information. We can proudly say that we are

the supplier with the best possible results.”

Highest precision with micro-gap technology

Several technical highlights are decisive for the extremely

high, reproducible precision of the used Kern Micro HD

five-axes machining centers. One of them are the largedimensioned

and temperature-controlled linear motors,

which do not require any mechanical transmission elements

that could wear out. Additionally the machines features a

unique hydrostatic micro-gap technology, developed and

patented by Kern. According to Sebastian Guggenmos, technical

director of Kern Microtechnik GmbH, the thin gap

of less than 10 μm in all linear axes ensures highest rigidity

and the best damping properties of the system.

In addition, chief technologist Guggenmos emphasizes the

actively temperature-controlled aluminum axes and hydrostatic

systems and adds: “With all these technical details, we

can guarantee highest stability and persistent perfect quality

of the parts coming out of serial production. Ultimately this

also applies when the surrounding is less than ideal, such as

we currently have in Murnau.” This refers primarily to trains

passing on nearby tracks and cause slight vibrations in the

building. Plant manager Stauder is unimpressed by this:

“Other machines would have a problem with the required

accuracies. Ours don’t.”

Growing demand from analytics and metrology

For customers with particularly high demands, the achieved

results are very helpful. On the one hand this allows them to

reliably guarantee their customers the highest data transfer

rates. On the other hand, possible further work steps – such

as pairing or inserting lenses – are significantly simplified

during assembly. And since the advantages of high-precision

serial production are also interesting for other industries,

this has a positive effect on the general order intake in

Murnau. According to Alexander Stauder, the demand from

companies in the analytics and metrology industries is increasing

just as strongly as from those that, as described here,

require insert housings for fiber optic connectors.

further information: www.kern-microtechnik.com


31


Increasing efficiency in tool machining

with automation and AI

At GrindingHub 2026, VOLLMER WERKE

Maschinenfabrik GmbH will present itself as a competent

partner for tool manufacturing. The Biberachbased

sharpening specialist will showcase its comprehensive

portfolio of grinding, erosion and laser

machines for the efficient machining of ultra-hard

cutting materials such as PCD, CVD diamond, PcBN

and carbide. The focus will be on automated production

concepts, digital solutions and the targeted use

of artificial intelligence (AI).

Hybrid machine concept as the key to efficiency

With increasing demands for precision and cost-effectiveness,

Vollmer is specifically focusing on the hybrid machine concept

of the VHybrid 260, which combines mechanical

grinding processes with contactless EDM technology and

digital solutions in a single machine. The VHybrid 260

not only represents the combination of several sharpening

technologies but also forms the basis for fully digitalized

and automated production processes. A central element is

the Vpulse EDM generator, which enables the highly precise

production of even the smallest micro-tools with Ø of

0.2 mm. During the erosion process, surface finishes of up

to 0.05 µm Ra can be achieved. In addition cutting edge radii

of up to 1.5 µm can be produced. This can eliminate the need

for subsequent grinding of functional surfaces, avoiding

tolerance risks caused by re-clamping as well as additional

process-intensive steps, thereby significantly reducing overall

production costs.

At GrindingHub 2026 Vollmer will present its portfolio of

grinding, erosion and laser machines that allow customers to

machine ultra-hard cutting materials such as carbide, PCD,

CVD diamond and PcBN. With a view to greater efficiency,

hybrid machines in particular make it possible to sharpen

tools faster and with higher quality. This can be seen, for

example, in full-head PCD tools with complex geometries:

within a single clamping operation, contours can be ground

in carbide while the cutting edges in the PCD head are

eroded. This approach not only shortens main and auxiliary

processing times but also ensures a virtually seamless transition

between the PCD head and the carbide blank – without

irregularities or steps. The VHybrid 260 demonstrates particular

strengths in cylindrical EDM. This contactless, highly

precise process enables economical machining. Micro-tools

in particular benefit from this, where dimensional accuracy,

surface quality and reproducible processes are decisive. The

combination of cylindrical grinding and cylindrical EDM

enables the production of extremely small tool diameters

with high precision, process reliability and efficiency – within

a continuous, automated process chain.

Process for producing defined edge chamfers

For drilling tools a rounded edge chamfer proves advantageous

for several reasons. Sharply eroded cutting edges can

lead to problems in various application scenarios – particularly

in the area of PCD drilling tools. A cutting edge without

a rounded chamfer can result in unstable cutting, increased

wear, reduced tool reliability and deterioration in workpiece

quality.

A rounded chamfer not only creates a defined cutting edge

contour with reduced chipping but also improves the stability

of the cutting edge as well as the surface structure and roughness

in the cutting edge area. This leads to longer tool life, increased

process reliability and improved workpiece quality.

By integrating the chamfering process into the VHybrid 260,

users are able to perform complete machining on a single

machine. Geometry machining and the production of the

rounded chamfer – whether eroded or ground – can be carried

out in one clamping operation. By using the LaserCheck, a

closed-loop process can also be implemented, eliminating

the need for manual adjustments during machining.

Automation and digitalisation for 24/7 production

Regardless of the sharpening technology used, all Vollmer

machines are consistently designed for automated 24/7 production.

Central robot systems handle loading via carts,

pallet loaders or chain magazines and monitor the fully

automated complete machining process. A newly developed

ND gripper with an automatically adjustable gripping

diameter significantly expands possibilities in tool handling.

Its flexible adaptation to a wide range of tool types increases

both process reliability and versatility in operation. These innovative

solution helps noticeably increase efficiency in automated

loading.

Machine and production data are recorded, analyzed and

managed via a central IoT platform. The web-based VPortal

serves as a central information and service platform, offering



users a transparent overview of documentation and service

information. In addition the Smart Hub intelligently consolidates

production and machine data and prepares them for

further analysis. AI-supported algorithms and an intelligent

chatbot assist users in analyzing documentation and historical

data, providing relevant information on machine utilization,

production volumes and scrap rates.

AI and digitalization as an opportunity for SMEs

“Especially for small and medium-sized enterprises, the

combination of hybrid machine technology, digitalization

and AI offers major opportunities”, says Tobias Trautmann,

managing director of the Vollmer Group. “Processes can be

made more transparent, downtime reduced and resources

used more efficiently. With the VHybrid 260 we are creating

a platform where different sharpening technologies, digital

solutions and AI applications work seamlessly together to

measurably optimize production processes.”

Machine portfolio live at GrindingHub

At GrindingHub 2026 Vollmer Werke will also present additional

solutions from its current machine program. These

include the VLaser 370 in an automated version as well as

the VGrind Infinity linear. The exhibition appearance will

be rounded off by the models CS 860 and CP 650 as well as

the KSC560-B from the subsidiary Loroch.

further information: www.vollmer-group.com

Multi-axis machining and ai-driven

smart manufacturing

TMTS 2026 Taiwan International Machine Tool

Show took place from March 25 - 28 at the Taichung

International Convention and Exhibition Center

(TICEC). The Fair Friend Group (FFG) brought together

its Italian brand SIGMA alongside Taiwanese

brands FEELER, LEADWELL and EQUIPTOP.

This joint exhibition presented a comprehensive technological

layout ranging from stand-alone machining and

multi-axis solutions to multitasking machining, with the AI

Command Center and Smart Manufacturing Systems serving

as the core highlights.

The exhibit focused on high-rigidity structural design,

multi-axis applications, process integration, and intelligent

user interfaces, addressing industry demands for highprecision,

high-efficiency, and flexible production. SIGMA

showcased the UCH-660 5-axis machining center, featuring

a large-stroke design with B-axis ± 110 ° and C-axis 360 °

capabilities – ideal for multi-sided and complex curved surface

machining while maintaining stable quality through

high-rigidity and dynamic stability. FEELER presented the

VUX-300T multitasking machine and VUX-400 4/5-axis vertical

machining center, equipped with AICC II and Manual

Guide i to enhance precision and efficiency for sectors like

automotive, medical, and precision molds. LEADWELL put

the TM-1700IST multitasking machine on display, capable

of 5-axis simultaneous machining, drilling, milling, slanted

holes, and self-measurement compensation. EQUIPTOP

featured the ESG-1244CNC surface grinder, integrating big

data analysis and life-cycle monitoring to track utilization

rates in real-time and enable predictive maintenance.

In response to smart manufacturing trends, the booth

featured an AI command center that centralizes equipment

operation and production line data. It tracks power con-

FEELER

SIGMA

sumption and costs to calculate carbon emissions and carbon

footprints. Through analysis and warning mechanisms,

it assists managers in real-time decision-making and effi -

ciency optimization, driving the transition from stand-alone

machines to data-driven smart factories and rapidly establishing

professional domain data models.

further information: www.tmts.tw


33


Kellenberger expands its grinding portfolio

in the entry-level segment

The Swiss grinding specialist

Kellenberger is presenting two new

cylindrical grinding machines at

GrindingHub fair in Stuttgart – the

KELLENBERGER K8 and the

KELLENBERGER K10– significantly expanding

its machine portfolio for beginners

and smaller companies.

Kellenberger cylindrical grinding machines

are characterized by maximum precision,

process reliability, productivity, and flexibility.

Until now the range available to dedicated

grinding professionals extended from

the cost- and cycle-time-optimized, energyefficient

universal cylindrical grinding machine

K10, through the flexibly configurable

K100, up to the premium-class K1000

and VM1000. All of Kellenberger cylindrical

grinding concepts are optimally configured

for their respective application areas and can

be expanded with a wide range of options.

With the new KELLENBERGER K8 cylindrical

grinding solution, Kellenberger offers

an optimally configured standard machine in

which advanced equipment options have been

deliberately omitted. The K8 was designed

for beginners and smaller companies looking

for a cost-effective machine without having

to compromise on Kellenberger’s proven premium

quality.

0i-TF control system and user-friendly standard grinding software for external,

internal and shoulder grinding ensure excellent grinding results.

Unlike the K10, K100, K1000 and VM1000 series, the KELLENBERGER

K8 does not have a loader interface. The KELLENBERGER K8 is distributed

through its own sales structure, which also integrates the service network in

accordance with the Kellenberger standard.

More features and a wide range of options:

the new KELLENBERGER K10

In addition to the K8, the advanced universal cylindrical grinding machine

KELLENBERGER K10 stands out with new features and an expanded range

of options. These include, among other things, active longitudinal positioning,

which enables precise position control of the workpiece during external,

face and internal grinding.

The universal grinding head of the K10 accommodates two external

grinding wheels (Ø 500/400 mm) as main and auxiliary wheels, as well as

a directly driven high-frequency internal grinding spindle available in two

speed ranges: 6,000–40,000 rpm and 10,000–60,000 rpm. The continuous

Kellenberger table profile – already proven in the K100 and K1000 and suitable

for all standard and optional configurations –is also used in the K10.

A special feature is the low-maintenance energy supply via table interfaces.

The dressing interface running along the entire rear side of the table reduces

setup time and expands dressing options.

This includes the stability and rigidity

required for a successful grinding process,

ensured by the solid machine bed cast in

a single piece. The V-flat guideways in the

Z-axis also contribute to this, featuring a special

coating to prevent friction losses. Highquality

Fagor measuring systems with a resolution

of 0.05 μm guarantee maximum precision

throughout the grinding process.

The K8 is ideally suited for grinding workpieces

in small and medium batch production.

With a center height of 200 mm, a center

distance of 1,000 mm, and a maximum

grinding Ø of 380 mm, the K8 covers a wide

range of parts. The grinding head can be

equipped with an external grinding wheel

and an internal grinding spindle. The Fanuc

Kellenberg K10



For extended machining capabilities, the

KELLENBERGER K10 offers generous X- and

Z-axis strokes (X = 365 mm / Z = 1,150 mm).

The low-maintenance, high-precision linear

guide in the X-axis and the V-flat slideways in

the Z-axis are equipped with optical, absolute

linear measuring systems. The B-axis is designed

as an automatic indexing axis (1 °) with

high positioning accuracy and a swivel range

of + 30 ° / – 210 °.

Like the high-performance machines K100,

K1000 and VM1000, the KELLENBERGER

K10 is equipped with the powerful Fanuc

0i-TFP control system featuring a 19-inch

touch control panel and Kellenberger user

interface. The BLUE Solution software with

object guide, ISO guide, and DXF import enables

fast programming and setup, even for

inexperienced operators. The BLUE Solution

is continuously developed by Kellenberger’s

software experts and enhanced with innovative

features for process optimization. These

features include the structure-borne sound

sensor gTOUCH and the semi-automatic

balancing system gBALANCE. The latest

program enhancements for optimal grinding

processes include the quality measurement

control gMEASURE and grinding time monitoring

gTIME. The newest BLUE Solution

edition will be demonstrated at GrindingHub.

Global leadership team complete

Kellenberger’s board of directors

has appointed Jörg Schmauder as the

new chief sales officer (CSO) with

immediate effect. Jörg is an experienced

international sales and general

management executive with a

distinguished career as CSO in

various globally operating machine

tool companies; he will be based in

Goldach, Switzerland.

With this additional appointment,

Kellenberger’s global leadership team is

complete – in addition to Jörg Schmauder,

it consists of:

Carsten Liske (CEO),

Norbert Finger (CFO),

Joe Loiselle (president America),

Viktor Gaspar (president Europe),

Alison Zhang (president China) and

Sandro Mock (senior director sales &

service ROW, i.e. Asia outside of China)

Kellenberg K8

Visitors can also look forward to a presentation of the company’s new inhouse

component manufacturing. In the future Kellenberger will produce

key machine components – essential for achieving the highest precision

standards required by the company – at its Goldach facility. These include,

among others, spindles and grinding heads.

At GrindingHub Kellenberger will also showcase its proven cylindrical

grinding concepts for the highest demands: the KELLENBERGER K100,

KELLENBERGER K1000, and KELLENBERGER VM1000. The Kellenberger

100 is available with center distances of 1,700 / 1,000 and 600 mm and a

center height of 200 mm, and is designed for workpiece weights of up to

200 kg. High grinding wheel drive power ensures high productivity, while

the new Z-guide system delivers high profile accuracy. The C-axis with

direct drive provides increased precision in non-cylindrical grinding. The

K100 features a tandem grinding head with 10 grinding head variants.

The KELLENBERGER K1000 is equipped with hydrostatic guideways

in all main axes for maximum form accuracy in grinding tasks involving

interpolating axes. The CNC-controlled B-axis for the grinding head is

hydrostatically mounted and therefore wear-free. It features a direct drive

with a water-cooled high-torque motor and an angular measuring system

with a resolution of 0.1 arcseconds. The K1000 is optionally available with

center distances of 1,000 / 1,600 mm and center heights of 200 / 250 and

300 mm. More than 30 different grinding head variants with external and

internal grinding spindles are available as standard, covering virtually every

machining requirement.

The VM1000 is optimized for flexible, universal internal and external

cylindrical machining of complex workpieces up to 300 mm in length. The

range of workpieces includes the smallest individual parts for fuel injection

systems in car engines, ball bearing rings, transmission components,

hydraulic components and complex components used in machine tool

construction. The special feature of the VOUMARD 1000 are the two highly

precise hydrostatic B-axes. The spindle turret on the B1 axis is equipped

with a uniquely compact grinding spindle head with a flexible spindle

arrangement. This allows spindles and measuring sensors to be optimally

positioned, enabling the machining of virtually any workpiece geometry

as well as multiple internal and external grinding operations in a single

clamping setup.

further information: www.kellenberger.com


35


Universal grinding machines for

precision manufacturing tasks

The universal grinding machines in the EMAG

UG series combine proven grinding technology with

a cost-efficient machine base. They are ideal for users

who are looking for a sophisticated solution for internal,

exter nal and out-of-round grinding and do not

want to com promise flexibility, precision and process

reliability.

The UG series include machines with grinding lengths from

400 to 1,500 m. This gradation covers a wide range of requirements

– from compact workshop machines for toolmaking to

universal production solutions for longer shafts and complex

geometries – whether clamped between centers or in a chuck.

Model overview and range of applications

The series is divided into four variants:

• UG 400 with 400 mm grinding length

• UG 630 with 630 mm grinding length

• UG 1000 with 1,000 mm grinding length

• UG 1500 with 1,500 mm grinding length

Linear guides in the X- and Z-axes, servo drives with recirculating

ball screws and direct-drive motorized grinding spindles

form the technical basis. The standard center height is

175 mm and the maximum workpiece weight is 120 kg (model

UG 1000). Larger center heights and workpiece weights are

possible with additional equipment.

Grinding head – precision through direct drive

The grinding head is equipped with direct-drive motor

spindles. The spindle power is up to 11 kW. As there is no

belt drive, there are no sources of vibration, and the torque is

transmitted without loss. This leads to uniform power transmission

and reduces vibrations during the grinding process.

The automatically swiveling B-axis enables infinitely variable

positioning between - 15 ° and + 225 ° with an accuracy

of 0.0005 °. This precision is required for surface and contour

grinding, where the exact angular position of the

grinding wheel determines the machining result. The achievable

peripheral speed of the grinding wheel is 50 m/s. Precision

grinding spindles are used for internal machining.

These spindles are characterized by high motor speeds and a

robust bearing with oil-air lubrication, which is required for

internal grinding of small bores.

Workhead – rigidity and concentricity

The workhead is equipped with precision tapered roller bearings

that ensure high rigidity. The concentricity accuracy on

the test workpiece is 0.5 μm. This accuracy is the result of the

rigid bearings and the quality of the components used.

A swivel range of 0 ° to + 30 ° enables various grinding strate -

gies for cone grinding. A pneumatic lifting device facilitates

set-up and positioning of the workpiece. AE sensory equipment

can be integrated as an option. These sensors detect

the contact between the grinding wheel and workpiece and

reduce idle times.

An optional workpiece spindle with C-axis is available for

out-of-round and thread grinding. In this case, the workpiece

spindle is designed as a motor spindle with rotary positioning.

This enables synchronized movements between the feed

of the grinding spindle and the rotation of the workpiece.

Tailstock – precision centering

when grinding between centers

The standard tailstock is equipped with a quill with a Ø of

63 mm for MK4 centers. It runs low backlash in the guide,

which enables precise centering of the workpiece. A fine adjustment

of ± 40 μm allow the correction of taper deviations

and ensures concentricity of well under one micrometer.

Manual or hydraulic actuation systems are available. The

hydraulic version speeds up workpiece changeover, as the

quill is automatically retracted after machining. An integrated

sensory equipment monitors the correct position of

the workpiece tip and increases process reliability.

Work area of the EMAG UG series; the combination of

swiveling B-axis and direct-drive spindles enables

internal and external grinding

Dressing systems – ensuring

constant grinding conditions

Various dressing systems are available for different requirements.

Dressing is an essential part of the grinding process,

as the geometry and sharpness of the grinding wheel

signifi cantly determine the surface quality and dimensional

accuracy.



The EMAG UG series at a glance: UG 400, UG 630, UG 1000 and UG 1500 cover grinding lengths from 400 to 1,500 mm

The following systems are available:

→ Table dresser with flexible positioning: the table dresser

can be placed at any position on the top table. This

flexibility allows it to be adapted to different workpiece

geometries and grinding wheel diameters. The user can

optimize the dressing position for specific workpieces,

which shortens set-up times for frequently changing

production tasks.

→ Dressing spindle on the workhead: the dressing spindle

is mounted at the rear of the workhead and enables

automated dressing without manual intervention.

This solution is suitable for batch production where

constant dressing cycles increase process reliability.

Integration into the machine structure reduces the

footprint and shortens non-productive times.

→ Holder for dressing tiles on the tailstock and workhead:

for simple dressing tasks, holders for dressing tiles

can be mounted on the tailstock or workhead. This

cost-effective solution is suitable for manual dressing

processes or as a supplement to automated systems.

The modular design allows the dressing system to be adapted

to the respective application. The selection of a suitable dressing

system depends on the type of grinding wheel, number

of pieces, workpiece geometry and required surface qualities.

Of course, the machines in the UG series can be extended

according to customer requirements, for example with NC

synchronous tailstock, in-process measuring technology,

automatic tailstock with NC axis, hydraulic steady rests and

many other options.

Control and operation

The UG machines are equipped with the FANUC 0i-TF CNC

control as standard. This control offers a dialog-oriented

HMI that simplifies programming and operation.

User guidance is logically structured, and frequently used

functions are directly accessible. The FANUC 31iB Plus

is available for more complex contours, especially for outof-round

and thread grinding. This controller has a higher

computing power and supports extended functions for synchronized

motion control. Interpolation between the axes

is performed with high precision, which is necessary for

machining out-of-round geometries.

The use of FANUC controllers offers advantages in international

applications. The controllers are used worldwide,

service availability is high and spare parts are available at

short notice. This minimizes downtime and facilitates the

training of operators who are familiar with FANUC controls.

Worldwide customer support

EMAG maintains a global service network covering all continents.

The service locations are in Germany, Great Britain,

France, Spain, Italy, the USA, Mexico, Brazil, India, China

and South Korea. This decentralized structure enables

short response times and a rapid on-site presence for service

requests.

The service technicians at all locations have access to a

shared knowledge pool. Experiences from service cases are

systematically analyzed and made available worldwide. This

allows customers to benefit from the accumulated know-how

of the EMAG organization irrespective of their location.

As an OEM supplier, EMAG guarantees to help the customer

as quickly as possible – whether during commissioning,

with technical questions or in the event of a malfunction. On

request EMAG can supply a turn-key package that includes

not only the machine but also the tool, workholding technology,

cutting fluids and the finished workpiece program. The

customer thus receives a production-ready solution from a

single source.

The service program also offers preventive servicing,

training courses at the EMAG academy, retrofits and original

spare parts that are always available. The aim of all services is

to maximize machine availability and ensure a long service

life for the investment.

further information: www.emag.com


37


Precision and process reliability redefined

In the high-precision world of mechanical engineering

and tool reconditioning, every detail matters.

For Fraisa GmbH, a leading provider in the field of

cutting tools, defined edges and absolute process reliability

are critical to success. To further secure their

already established quality standards while simultaneously

increasing efficiency and the level of automation,

Fraisa sought a solution to specifically optimize their

existing processes. They found the answer in OTEC’s

Mass Finishing Technology.

This collaboration demonstrates how remarkable results can

be achieved through customized adaptations and technological

excellence.

The challenge: long setup times and

process optimization potential

Before partnering with OTEC, Fraisa faced specific challenges

in surface finishing. The company, based in Willich

and specializing in the ReTool process and the reconditioning

of milling tools, was using a DF 4 Tools machine. While

this system was already delivering reliable performance and

good results, there was room for further optimization. The

focus was primarily on reducing setup times and achieving

longer autonomous operation through a higher degree of

automation. In a market where precision and efficiency are

key factors for competitiveness, it was essential to further

develop these aspects. Yves Krause, team leader of process

technology at Fraisa, and his team sought a solution that was

technologically advanced and could seamlessly integrate into

their existing workflows. The goal was to establish a method

that ensured consistently high quality while reducing time

and cost efforts.

The solution: customized

Mass Finishing Technology from OTEC

Fraisa has been utilizing OTEC technology for around

25 years. The most recent implementation in early 2025, an

SF-DC-78 1/1 PLS, marks another milestone in this longstanding

and successful partnership. This machine was

specifically selected and tailored to meet Fraisa’s demanding

requirements. The integration of the OTEC solution into the

existing process was carried out step by step in close coordination

between Fraisa and OTEC.

Crucial to the success was OTEC’s willingness to accommodate

customer-specific requests and tailor the machine

precisely to the user’s challenges. This flexibility, combined

with quick response times and open communication, was a

key aspect that Fraisa particularly values. OTEC delivered

not just a machine but a holistic solution approach designed

to address the specific challenges of tool reconditioning.

Results that convince:

higher quality, less required time

The introduction of the OTEC SF-DC-78 1/1 PLS led to

immediate and measurable improvements at Fraisa. The

results speak for themselves and highlight the effectiveness

of mass finishing technology.

→ increased process reliability

Fraisa was able to further enhance process reliability.

The defined edge conditioning was standardized and

developed into an even more stable and repeatable

process. This ensures consistently high quality

for the reconditioned milling tools.

→ reduced setup and processing times

The previously time-intensive setup processes were

significantly reduced with the new system. Thanks

to the minimal setup requirements of the OTEC

machine, Fraisa was able to optimize auxiliary times.

Combined with faster processing times, this resulted

in a noticeable increase in overall efficiency.

→ high flexibility in application

The new system offers Fraisa high flexibility to

quickly adapt to different tool types and processing

requirements. This is a decisive advantage in a

dynamic market environment

A partnership for the future

The success story of Fraisa and OTEC is an impressive example

of how technological innovation and a customer-focused

approach lead to outstanding results. Fraisa not only overcame

its initial challenges but also consistently advanced its

processes, particularly in terms of efficiency and automation.

When asked whether he would recommend OTEC, Yves

Krause, team leader of process technology at Fraisa, responded

with a resounding “Yes, 100 %.” His reasoning highlights

OTEC’s strengths: “They manage to act in a timely,

technologically advanced and user-oriented manner.”

This strong endorsement underscores OTEC’s commitment

to not just delivering machines but acting as a true

partner, understanding their customers’ processes and

improving them sustainably. The collaboration with Fraisa

demonstrates that the right surface finishing technology

can be a decisive lever for greater productivity and quality

in mechanical engineering.

further information: www.otec.de



Automated assembly of clamping devices and

mobile robot cells for adaptive manufacturing

With Smart FMS (flexible manufacturing system),

Schwäbische Werkzeugmaschinen GmbH (SW) opened

a new chapter in automation systems in 2025. The

new manufacturing system enables flexible, resourcesaving

and sustainable workpiece processing – regardless

of the number of pieces.

Two core technologies, the automated clamping system Sfix

and the mobile robot cell S-cell, were presented for the first

time at automatica in Munich and EMO in Hanover, where

they were met with a positive response.

While classic production lines are designed for fixed processes,

the Smart FMS enables flexible machining of different

workpiece types and batch sizes without time-consuming

changeovers. This results in an approach that addresses

both economic requirements – such as higher utilization and

shorter setup times – and ecological goals aimed at reducing

material and energy consumption. With its three core technologies

– the Sfix system, the S-cell mobile robot cell and

the pallet changing system – the Smart FMS enables the transition

from isolated machine concepts to adaptive manufacturing

systems that can be dynamically adapted to changing

production conditions.

The Sfix system for

different workpiece variants and batch sizes

The Sfix system greatly simplifies the clamping of workpieces.

Until now each workpiece required an individual clamping

device that had to be designed and stored – an expense

that was particularly significant for small series with many

variants. In the Sfix-cell, a robot automatically assembles the

required clamping device from standardized components in

just a few minutes. The basis for this is the patented Sfix plate,

on which the elements are precisely positioned using the

CAD model of the workpiece.

“Sfix makes the clamping process plannable and reproducible”,

explains Michael Kreuzberger, product manager at

SW. “This significantly reduces setup and storage costs and increases

process reliability – especially with frequently changing

components.” The modular system can replace up to 150

conventional clamping devices. This reduces material consumption

and storage needs while enabling economical, resource-saving

production across a wide range of batch sizes.

The pallet changing system – also a component of the

Smart FMS – further automates the production process: it acts

as an interface between the Sfix-cell and the machine tool,

enabling the quick and safe exchange of workpiece pallets

without manual intervention. The pallet changing system

can be moved flexibly via a floor axis or positioned by an

autonomous mobile robot (AMR).

At the heart of the Sfix systemis a robot

that automatically assembles

clamping devices from

standardized

components

in just a few

minutes

S-cell system: mobile automation for

flexible manufacturing environments

The S-cell system complements the Smart FMS with an intelligent

automation solution. It enables flexible material flow

between machining, cleaning, or assembly stations without

rigid interlinking. The S-cell, a mobile platform with a permanently

installed industrial robot, moves autonomously

through the production facility via a driverless transport

system. It docks precisely at the respective station, takes over

the loading and unloading of workpieces, and moves on to

the next task once the process is complete. The cell independently

recognizes the type of station it is connected to and

automatically adapts its processes. This eliminates the need

for manual changeovers, which are usually associated with

high costs in classic production lines. At the same time

the machines remain freely accessible, for example for

maintenance or setup processes.

In combination with the advanced orchestration software

SmartFlow, the system ensures optimal efficiency and utilization

of the entire plant. Thanks to AI-supported planning, it

adapts dynamically and flexibly to changes in the production

process – without any manual intervention. “This solution

is highly cost-effective, as it enables step-by-step investment,

high component reusability and short amortization times”,

says Michael Kreuzberger about the advantages. “Companies

can implement the system gradually and expand it as needed,

as it can be easily networked with SW machines and systems

from other manufacturers thanks to open interfaces.”

Introduction of Smart FMS generates great interest

SW presented the Smart FMS concept for the first time at

automatica and EMO. “The feedback at both trade fairs

showed that companies are looking for solutions that are

flexibly scalable and do not require long changeover times”,

says Michael Kreuzberger. “The Smart FMS provides exactly

this foundation – regardless of industry, batch size, or workpiece

variant.”

further information: www.sw-machines.com


39


Size matters…

Zimmermann, Inc. has installed and commissioned

its FZU37 portal milling machine, with a 5 x 4 x 1.5 m

workpiece capacity, at Century Tool, a major tool and

die manufacturer in Fenton, Michigan and part of the

Tooling Tech Group. The machine has already proven

its worth, according to the customer’s director of manufacturing,

Tom Bradford: “The table size, speed and

accuracy of this Zimmermann machine have already

increased our capabilities by 30 % or more.”

Bradford and the operator on the machine, David Hawes,

further note the benefits of the Heidenhain TNC7 control,

the first machine tool installation in America for this advanced

CNC, as a key factor in production planning,

CAD/CAM integration, cycle performance and data logging.

The CNC also features a visual simulator of the cutting path

for cycle validation and in-process monitoring.

According to Cornelius Kiesel, president of Zimmermann,

Inc., his company was approached for the discussion of a

new machine, which would be replacing an existing, smaller

machine that was no longer in operation, plus expand the

capabilities of other machines on the floor at Century. “We

determined the spec of the new machine and its tasks for finishing

and semi-finishing. The primary goal was to cut down

the immense number of hours for such processes on the very

large workpieces at Century, while enabling them to run the

roughing process on their existing equipment.”

Kiesel continues, “To keep things simple, we selected

the FZU37 machine, so the foundation of the replacement

machine could be filled up to make it flush without a major

foundation rework. After several conversations and a few

adjustments on the accessories, we were able to lock in the

layout. These layout improvements allowed us to go even

wider for a total of 5000 x 4000 x 1500 mm (197” x 157” x 59”)

of travel, which was 79 % more travel in the same amount of

floor space. The FZU37 was subsequently ordered with the

state-of-the-art spec for an advanced machine shop such as

Century, including our tool changer, top cover, mist extraction,

high-pressure coolant, tool laser, touch probe and more.

Century Tool also wanted to step up their control to the new

generation Heidenhain TNC7.”

Lastly, Kiesel notes “Zimmermann also integrated an extended

spindle housing for deeper cavities plus the side walls

Century machine operator David Hawes

sets the tooling on the spindle of the

Zimmermann machine

A 5 x 4 x 1.5 m work envelope is

available on the Zimmermann

machine, which substantially

increased the run capabilities

at Century

Tom Bradford and David Hawes of Century

review a cycle setup on the Heidenhain TNC7

CNC on the Zimmermann machine; this

portal milling machine is the first in America

with this advanced CNC onboard; the cycle

can be simulated before running



were raised to create enough clearance and the machine table

reinforced for the challenging molds our customer expected

to be produced on this machine. When all these machine

parameters got worked out and finalized, we completed the

machine rather quickly, commissioned it, did the training

onsite and helped Tom and his team start up.” Tom Bradford

cited Alfio Campagna, project manager for Zimmermann,

for his critical help in getting the machine into production

at Century, as this was the first Zimmermann portal mill

purchased by the moldmaker.

Bradford also commended the Heidenhain team, who

provided three days of training on the CNC at their

Chicago location and two more onsite at Century. Operator

Hawes commented that he had substantial experience on

Heidenhain controls, so the training went quickly for him,

though the new control has numerous new features, including

its smart programming, a graphical programming

feature that allows the user to draw contours directly onto

the touchscreen, after which the CNC converts the result into

a “Klartext” (German for clear text) program. Century uses

Visi as its main CAD program and Tebis as its CAM software

and Bradford noted the seamless matching of these programs

with the onboard CNC software to configure programs and

posts made startup and run a smoother process.

In addition the new CNC offers the user its Component

Monitoring feature, which can protect the spindle bearing

from overloading, while also detecting increased component

wear in the drive train, all while the machine is running.

This feature provides valuable data for predictive maintenance

and evaluation of the process capability of the machine.

This is vital at Century, who uses the Zimmermann

machine exclusively for large, one-off mold prep, often

removing over 90 % of the material from a workpiece, over

multiple days of machining.

Also, the ergonomics of the CNC are extremely user-friendly.

Screen layouts and touchpad controls can be suited to user

preferences. The intuitive contour programming is enabled by

symbolic gestures on the touchscreen. Since Klartext remains

the main format for files and exporting from the Heidenhain

control, existing NC programs can continue in use.

Currently, the Zimmermann machine at Century is running

on two shifts, often remotely tended in a low-light or

lights-out mode.

Tom Bradford comments on the Zimmermann machine

performance. “We do a lot of large tools for compression

molding of composites and other substrates. We work for a

variety of industries, from automotive to heavy truck, offhighway

to agriculture, power sports to infrastructure such

as water tanks. Century specializes in class-A exterior body

panels, so the surface finish is critical. During the very long

runs we do on the Zimmermann, maintaining tight tolerances

is key and the machine plus its onboard control technology

make that happen for us.”

Brian Czapla, director of sales at Century, adds “The trend

toward high-strength, lightweight composites and large

Cornelius Kiesel, president of Zimmermann, Inc.,

Brian Czapla, director of sales at Century,

Yousif Sallan, project manager at Zimmermann, Inc. and

Tom Bradford, director of manufacturing at Century,

with the FZU37 portal milling machine

dimensioned, unitized parts for auto and heavy truck make

this machine a real asset in our operation.”

In use, the typical workpiece on the Zimmermann is P20

steel, the industry standard for molds, as well as various aluminum

materials. HSK 63 and HSK 80 are the primary toolholder

types, used for cutting and laser touch probing here.

Standard carbide cutting tools and inserts are typical, as well.

Bradford further notes “As a tooling source we serve the

Tier One and OEMs in the manufacturing space. We have a

strong reputation in automotive and heavy truck and we’re

looking to expand into aerospace and other consumer products

as well. As Brian noted, our core strength in composite

molds gives us a real advantage in entering these other

markets. The Zimmermann machine helps us achieve

superior RA finishes with consistent quality, even on much

larger structures.”

Century Tool is part of the Tooling Tech Group. With

roots that go back over 40 years, Tooling Tech Group (TTG)

has grown to be a leading manufacturer of tooling in the

United States. They provide solutions for thermoform molding,

high compression composite molding, blow molding,

rotational molding, die casting and stamping, as well as custom

automation systems for assembly, joining and inspection

applications in a variety of industrial sectors. TTG comprises

Century Tool, Century Automation for post-molding materials

handling and assembly strategies, Die Cad for tooling

design & simulation, Majestic for production of stamping

dies, Tooling Technology for turnkey cast & billet aluminum

tooling solutions, Alpha Integration for assembly automation

and G&H Tool & Mold for high-pressure die cast molds.

further information: www.zimmermann-inc.com


41


Innovative manufacturing of ultra-hard tools

In modern production involving difficult-tomachine

materials and high quality requirements,

tools made from ultra-hard cutting materials such as

PCD, CVD, MCD and CBN are becoming increasingly

important. Users benefit from optimal cutting speeds,

longer service life and better surfaces. Machining these

cutting materials is more demanding than machining

conventional carbides, which is driving the development

of innovative manufacturing solutions for these

advanced tools.

At GrindingHub in Stuttgart, May 5 - 8, 2026, DMG MORI

will present a holistic process chain in which a LASERTEC

12 SLM first builds a milling head from polycrystalline diamond

(PCD) in a powder bed. The cutting edge is finished

on a LASERTEC 20 PrecisionTool using a laser. In addition

the machine tool manufacturer will be showcasing a secondgeneration

vertical Mate 85 for conventional grinding.

LASERTEC SLM:

ultra-hard milling heads from the powder bed

Both the LASERTEC 12 SLM exhibited at GrindingHub and

the larger LASERTEC 30 SLM 3. Generation serve as productive

solutions for the additive manufacturing of milling heads

in a powder bed. The decisive advantage over conventional

manufacturing processes lies in the complex geometries that

the additive process can achieve. For example internal cooling

channels can be integrated, ensuring optimal heat dissipation

when machining with ultra-hard cutting materials.

On the control side LASERTEC SLM machines feature

CELOS X with easyAM. This makes the powder bed machines

easy to operate and maintain. rePLUG powder modules

also enable quick changes between different materials.

LASERTEC 20 PrecisionTool:

cutting edge rounding in a single clamping ong

DMG MORI offers advanced finishing of cutting edges with

the LASERTEC 20 PrecisionTool. The 5-axis laser machine

rounds cutting edges without any post-processing in a single

clamping at a speed of up to 5 mm/min with 1.6 mm thick

PCD. It is also possible to measure the stroke profile of the

round laser chamfer and to customize or adjust it on the

machine. The LASERTEC 20 PrecisionTool produces cutting

edges with a sharpness of less than 1 μm and a defined cutting

edge rounding of 3 μm, 6 μm, 9 μm, and 15 μm. Negative

chamfers are also possible. In addition the process-reliable

laser processing contributes to higher cost-effectiveness because

it increases the service life of the tools by a factor of 2.5.

LASERTEC 50 PrecisionTool Femto: miniature tools

The DMG MORI LASERTEC 20 PrecisionTool produces

sharp cutting edges under 1 μm. In addition to this process

chain DMG MORI serves another highly dynamic market

segment with micro tool machining on the LASERTEC 50

PrecisionTool Femto. The focus here is on miniature tools

with a diameter of 0.2 mm or more, which consist of soldered

PCD diamonds and are manufactured with extreme precision

using ultra-short pulsed femto laser ablation. With tools

of this size in particular, classic mechanical machining

processes such as grinding or electrical discharge grinding

often reach their technological limits. High process forces,

tool wear and complex and fragile geometries often make

reproducible machining impossible.

The femto laser technology of the LASERTEC 50

PrecisionTool, on the other hand, enables virtually force-free

material removal with maximum geometric accuracy. This

allows even the most demanding cutting geometries and defined

cutting edge qualities to be achieved, which is a decisive

advantage, especially in applications with the highest requirements

for precision, service life and process reliability. Users

benefit not only from the laser processing itself, but also from

DMG MORI’s comprehensive machine, control and process

expertise in the field of precision tool manufacturing.

Vertical Mate 85 2. Generation: multi-process

grinding for demanding industries

With the Vertical Mate 85 2. Generation multi-process grinding

machine DMG MORI is building on the success of its predecessor

model. It allows the machining of inner and outer diameters

as well as flat surfaces in a single clamping. Its speed-

MASTER LongNose spindle achieves an output of 18.5 kW,

35.3 Nm torque and a speed of 10,000 rpm. An optimized machine

structure and high thermal stability contribute to highprecision

machining, as does the linear scale in the X-axis.

The Vertical Mate 85 2. Generation achieves a roundness of

1 μm, making it ideal for precision applications in challenging

industries such as mobility, semiconductors, and aviation.

With its combination of additive manufacturing, laser

finishing and classic grinding technology, DMG MORI is underlining

its position at GrindingHub as a technology partner

for the entire value chain of modern tool manufacturers,

from micro to macro machining.

further information: www.dmgmori.com


components

Engineered for governed constant high speeds,

ultra-precision and reliability accelerating

advanced CNC machining applications

Air Turbine Technology Inc., the leading manufacturer

of revolutionary high-speed turbine products,

highlights its ‘All Rounder’ 625 Series Spindles, transforming

high-speed machining for manufacturers

seeking precision, reliability and higher productivity

in industrial applications.

Governed constant high speeds under load from 30,000 to

65,000 RPM with power ratings up to 0.55 HP are easily added

to any CNC with the 625 Series Spindle and are ideal for

engraving, mold making, milling and finishing with small

tools up to 1/8” (3 mm) capacity. Utilizing a patented directdrive

design with only two moving parts and optimized

air circulation over bearings, these spindles operate 24/7

with no heat or thermal expansion and eliminate duty cycle

limitations.

By increasing air flow volume to match cutting load,

Air Turbine Technology’s governor-controlled turbine maintains

constant rated speeds and torque under load, allowing

users to cut faster and cleaner while extending tool life and

ending frequent breakages of small tools. The performance

of the 625 Series Spindle therefore stands apart for its proven

ability to accelerate cycle times and minimize tool breakage,

while maintaining exceptional accuracy at 2 micron TIR and

vibration at just 0.4 mm/s. This is completely different from

nominal high speed coolant spindles that fade in cut and clog

up with chips.

All that is required is a connection to 90 PSI compressed

air. Full ATC is available on any CNC with air through the

spindle or using the patented Air Turbine Technology collar

and block.

By avoiding gears, vanes and brushes, the spindle’s design

reduces friction and wear as well as eliminates heat. This

reliable turbine direct drive dramatically reduces downtime

as well as repair costs from friction and overheating.

Supported by a range of toolholder configurations including

JS, HSK, CAT, BT and DIN, the 625 Series Spindle can be

seamlessly integrated into any CNC machine magazine for

automated, uninterrupted production.

The extra power 625X Series Spindle further boosts

performance on any CNC with its patented double turbine

delivering speeds up to 50,000 RPM and power of 0.76 HP.

This makes the 625X Series Spindle effective in demanding

operations with larger tools or operations such as contouring

and peck drilling in hard materials with tools up to 1/4”

(6 mm) capacity.

Both 625 Series Spindles provide practical benefits, power

to maintain high speed, no duty cycle, continuous operation,

predictable precision and versatile mounting options,

enabling manufacturers to achieve superior surface finishes,

reduce cycle times and maintain quality across a wide range

of machining tasks.

further information: www.airturbinetools.com


43

components

The new standard for

digital shop floor data management

With the new TDM release 2026, customers can take data

management on the shop floor to a whole new level, with automated

data flows to the machine and even more processes that are fully

digital and mobile.

The TDM release 2026 features automatic and seamless data transfer to the

machine using a standard connection, without interruptions or intermediate

manual steps. In addition mobile apps enable quick access to data and tasks

directly in the machine and tool crib environment, whereby tools can be

booked directly to cost centers via barcodes and NC programs are accessed

on the go.

The main highlight of the 2026 release is the new standardized Interface

“TDM Machine Data Connector”, that further supports and accelerates the

automation on the shopfloor. TDM already had several dedicated solutions

in place, but the new standardized machine connection from TDM can work

with most current machine controls on the market. The interface already

works with Heidenhain machine controls, with Siemens and Fanuc controls

as of mid-2026. This means that all tool-related information, from master-data

to wear values, flows bidirectionally and without manual intervention,

independent of the control system in use. This gives full transparency,

allows for forward-looking planning and results in significantly higher

productivity.

TDM ScanEasy, the mobile barcode scanner for the shop floor, now supports

all tool crib processes and inventory, as well as quantity bookings. The

significantly simplified workflows result in faster and more efficient management

of items on the shop floor. In addition to querying item information,

TDM ScanEasy now allows for mobile booking of tools in any situation,

The two essential scenarios of the Interface TDM Machine Data Connector

are reliable data transmission and continuous tool monitoring

The TDM Machine Data Connector interface’s availability will initially

be limited to selected Heidenhain controls, with Siemens and

FANUC controls to follow shortly

at the workplace or at the machine, while the

new dynamic search function displays suitable

item suggestions for selection after entering

just a few letters.

One of TDM’s biggest advantages is its high

level of integrability and connectivity with

other systems. As of release 2026, TDM software

can communicate with the CRIBWISE

(Sandvik) manufacturing inventory management

system. This includes the exchange of

component data, synchronized inventories

and stock postings, which can be booked in

either system. By using TDM and CRIBWISE,

TDM-users can implement automated ordering

processes and a transparent warehouse

structure for consumable tools. And thanks

to the systems’ synchronization, both systems

are always up to date.

A new feature in TDM’s integrated

NC Program Manager is the TDM NC web

transfer that enables mobile, browser-based

provision of approved NC programmes.

These can be available in machine-related directories

for further use or transferred back

after optimization on the machine. This saves

time, creates greater transparency in the machine

environment and increases the usability

of the TDM Integrated NC Program Manager.

As calibration and testing of measuring and

calibration equipment is often conducted by

external suppliers, the resulting data may not

be immediately available to users of the TDM

Gauge and Calibration Management Module.

By transferring the calibration data from

external systems, users can optimize this

process as well as their measurement and test

equipment management.

TDM release 2026 also offers comprehensive

new features for data entry and maintenance.

This ensures the efficient processing of

mass data for components and complete tools,

with easy conversion from inches to metric

and vice versa, automatic collision data

generation for large amounts of data, deletion

of graphics or data in specific fields,

optimized measurement of graphics and simplified

assembly of complex tools.

further information: www.tdmsystems.com


components

ISBE: a reliable partner for

digital tool manufacturing

The demands placed on tool manufacturing companies

have intensified significantly in recent years.

Increasing product diversity, smaller batch sizes,

extensive documentation requirements, and a growing

shortage of skilled workers coincide with highly automated

machinery and mounting cost pressure. Also

expectations for transparent, stable and reproducible

processes continue to rise – without compromising the

flexibility essential to modern production.

In this challenging environment, ISBE GmbH has supported

tool manufacturers for many years as a reliable partner. Its

objective is clearly defined: to develop software solutions that

accurately reflect industrial reality. ISBE combines in-depth

expertise in tool manufacturing processes with modern software

architecture, deliberately focusing on areas where standard

systems reach their limits.

Proximity to production as a core principle

ISBE’s solutions are developed from practical experience.

They are aligned with real-world processes along the entire

value chain – from order entry and production to quality

assurance. The goal is to make complexity manageable without

oversimplifying it. Variants, special processes and company-specific

rules are not bypassed but instead mapped in a

structured and transparent way.

Rather than offering isolated IT tools, ISBE provides

flexible software solutions that meaningfully complement

existing tool grinding machines, measuring systems and ERP

solutions. The result is a consistent data flow that effectively

supports operational teams.

Products with tangible technical value for

tool manufacturing

At the heart of ISBE’s solutions lies not traditional process

tracking, but the structured provision and utilization of manufacturing

data for cutting tools throughout the entire value

chain. The objective is to consistently translate technical

requirements – from the tool user through production to

quality assurance – into actionable data.

The starting point is always the end customer’s requirements:

geometries, tolerances, operating conditions and tool

life criteria. This information is processed, for example, in

ISBE TD Sketcher in such a way that it forms a reliable basis

for tool design. Manufacturing and quality assurance teams

therefore work from a shared, clearly defined data foundation

– regardless of batch size or product variation.

Building on this foundation ISBE supports the structured

provision of necessary grinding wheel data, programs and

descriptive manufacturing information. Instead of relying on

implicit knowledge or scattered data sources, relevant parameters

are centrally maintained and made available in context.

This increases reproducibility, reduces dependency on individual

expertise, and ensures stable manufacturing processes,

even in environments with frequently changing products.

Another key component is the systematic evaluation of

measurement and quality data. Measurement results are not

viewed in isolation but directly linked to tool requirements

and manufacturing parameters, and made accessible at the

tool measuring machine. This enables targeted analysis of

deviations and real-time process adjustments. Quality assurance

thus evolves from a mere inspection checkpoint into an

active contributor to process control.

Partnership instead of software project

What distinguishes ISBE is its partnership-based approach.

Collaboration does not end with the commissioning of a software

solution. Instead, software products and systems are

continuously developed together with customers, aligned

with real manufacturing requirements. Changes in product

portfolios, new customer demands, or organizational adjustments

can therefore be implemented gradually and in a controlled

manner.

For tool manufacturers, this means investment security,

predictable digitalization steps, and a partner who understands

industrial contexts – technically and economically.

Conclusion

Digital solutions only deliver their full value when they are

consistently aligned with the realities of tool manufacturing.

ISBE GmbH represents precisely this approach: software that

understands context, accommodates variants and makes industrial

rules explicit. As a reliable partner ISBE supports its

customers in shaping transparent, stable and future-ready

processes.

further information: www.isbe.de


45

components

Ultra-fine and high-purity cleaning

In the course of industrial transformation, more

and more companies are focusing on the manufacture

of high-quality products and components with good

margins. The focus is on high-tech industries that

promise stable demand through growth in the future.

The extremely high demands on manufacturing precision

in these industrial sectors, such as the semiconductor

supply industry, electronics manufacturing,

e-mobility, the optical and optoelectronic industry,

sensor technology, photonics, thin-film technology,

vacuum, laser and analysis technology, and aerospace,

include the cleanliness of components.

This applies regardless of whether the components are barely

visible electronic parts, millimeter-small connecting

elements, precision optics or meter-sized structural components,

and regardless of the materials from which they are

manufactured.

The specifications for particulate cleanliness extend into the

submicrometer range, and in the case of film-like

contamination, even nanolayers of organic and inorganic

residues, for example, must be removed in a

process-reliable and reproducible manner

Defining cleanliness according to requirements

This trend poses challenging tasks for parts cleaning. Unlike

conventional component cleaning, which usually involves

removing large quantities of manufacturing residues such as

chips and processing media, ultra-fine and high-purity cleaning

is all about removing minimal residual contamination.

The specifications for particulate cleanliness extend into the

submicrometer range. Depending on the industry, component

and its application, film-like residual contamination,

such as organic and inorganic residues, ionic residues and

microorganism residues, must be removed in a processreliable

and reproducible manner down to nanometer levels.

In high-purity applications, such as the manufacture of components

for EUV lithography, so-called hydrogen-induced

outgassing (HIO) substances must also be taken into account.

The requirements for particulate cleanliness to be met

during cleaning are specified by the corresponding surface

cleanliness class (ORK) according to EN ISO 14644-9 (SCP –

surface cleanliness by particle concentration) or the corresponding

VDI guideline 2083, sheet 9.1. Film-chemical, organic

and inorganic surface cleanliness is usually defined by

individual specifications or factory standards. In addition,

outgassing rates may be evaluated using mass spectrometers.

These demanding tasks require a partner who has comprehensive

technological expertise and knowledge of the applications

and physical relationships. And experience in this field

of cleaning, and appropriate test facilities for cleaning trials

under production-related conditions should be available. As

an experienced full-service provider of future-oriented and

globally available solutions for ultra-fine and high-purity

cleaning, Ecoclean meets these requirements.

Whether you need to handle a wide variety of materials,

meet high throughput requirements and/or strict cleanliness

specifications, modular ultrasonic multi-bath immersion

systems can be efficiently adapted to the task at hand – even

for integration into or connection to a cleanroom

Selecting the right cleaning process

and system technology

In order to meet these very strict cleanliness specifications

in a process-reliable, reproducible and sustainable manner,

several cleaning steps are usually required along the manufacturing

chain. The following questions play a role in selecting

the optimal solution for the respective cleaning process:

what material is the part made of? What are the geometry, dimensions

and weight of the component? What contaminants

need to be removed? What cleanliness requirements must be

met? Which cleaning process and which chemicals are suitable

for this? On this basis, it is possible to determine which


components

The extremely high demands placed on manufacturing precision

in high-tech industries include the cleanliness of components.

These sometimes extremely strict requirements call for

appropriately designed cleaning processes and systems

as well as a suitable manufacturing environment

and how many cleaning steps are required, using which

medium and which process technologies. Other aspects to

be taken into account include the required quality of the

rinsing medium and the appropriate drying technology, as

well as clean part handling and the ambient conditions, for

example connection or integration into a clean room or clean

environment.

Cleaning along the production chain

The basis for ultra-fine or high-purity cleaning is “oil- and

grease-free” parts. In order to achieve and maintain this level

of cleanliness a cleaning process is carried out after the various

processing steps, such as machining, forming, grinding

or polishing. The effect of the cleaning medium used is enhanced

by various process technologies that can be combined

in almost any combination, such as steam degreasing,

spray, high-pressure, immersion, ultrasonic and megasonic

cleaning, as well as plasma cleaning, injection flood washing,

pulsed pressure cleaning (PPC) and ultrasonic plus. These

process options ensure that the required cleanliness is consistently

achieved, even for geometrically complex workpieces.

For intermediate cleaning processes or parts with less

stringent cleanliness specifications, modular single- or multichamber

systems operating under full vacuum, such as

EcoCstretch or EcoCvela, are typically used. Depending on

the processing medium used, these systems can be operated

with an environmentally friendly solvent, e.g. hydrocarbons

or modified alcohol, or a specially selected water-based

cleaner. The design, system engineering, media flow and

treatment of these systems are specially tailored to ultra-fine

cleaning and high-purity applications. Thanks to the process

mechanics concentrated in the working chamber, e.g.

injection flood washing, ultrasound and PPC, this type of

system also offers advantages when cleaning large and complex

workpieces.

Ultrasonic multi-bath immersion systems are the optimal

solution for parts with a wide variety of materials, high

throughput requirements and/or strict cleanliness specifications.

In addition to individually designed cleaning systems

for high-end applications, Ecoclean offers an efficient solution

with the UCMSmartLine and UCMPerformanceLine

series of systems consisting of standardized modules. The

electrical and control technology is integrated into the

respective modules for the process steps of cleaning, rinsing,

drying, loading and unloading, as well as for the transport system.

This, together with the provision of process mechanics

tailored to requirements, such as PPC, allows the systems to

be optimally adapted to the respective task. The option of

upgrading the cleaning system at a later date ensures futureproofing

in the event of increased requirements.

Test center for process design or contract cleaning

Ecoclean determines the right system concept for the application

and the optimal cleaning process in its own High

Purity Test Centre. It has a Class 7 clean room with Class 6

zones and various measurement and analysis methods (e.g.

microscopy, residual gas analysis, UV light and fluorescence

measurement). In addition to the product-specific development

of cleaning processes and parameters, the test centre

is used to carry out contract cleaning orders. A packaging

station for cleaned parts ensures that the high level of cleanliness

achieved is also delivered to the customer.

further information: www.ecoclean-group.net


47

components

A new generation of oil mist separators

designed for the machining industry

Built on 3nine’s proven centrifugal separation

technology, the APEX series represents a new step in

simplifying oil mist management while improving

air quality and reducing operating costs in industrial

workshops.

Unlike traditional collectors that capture oil mist in filters

requiring frequent filter replacement, 3nine’s separators

remove oil mist from the air through patented separation

technology. This enables:

→ recovery and reuse of cutting fluids,

reducing waste and operating costs

→ long-lasting filters requiring minimal maintenance

→ consistently clean air, improving both

working conditions and operator health

The APEX series is designed as a universal solution capable

of handling a wide range of machining applications – including

demanding grinding operations, cast-iron machining,

and processes using both neat oil and emulsions. At

GrindingHub 2026, 3nine will showcase FREJA and VERA,

two models from the APEX Series.

◆ FREJA handles airflow rates up to 1000 m³/h,

making it suitable for larger and more demanding

machining applications

◆ VERA is optimized for smaller machines and

applications, handling airflow rates up to 500 m³/h

Both models offer:

→ 99.9 % separation efficiency down to 1 micron

before the final filter

→ automatic cleaning (CIP system) to maintain

optimal separation performance and

reduce manual maintenance

→ real-time monitoring with an LED indicator

showing operating status and filter performance

With the APEX Series, 3nine continues its mission to simplify

oil mist management in machine shops while helping manufacturers

create cleaner, safer and more sustainable working

environments.

further information: www.3nine.com

Measurement of metal workpieces

The use of the new TomoScope® XS machines from

Werth Messtechnik is not limited to typical measurement

objects made of plastic. Economic measurements

during production with high throughput are also possible

for different metal workpieces.

The Werth TomoScope® XS FOV provides high-performance

computed tomography at the price of tactile or multisensor

coordinate measuring machines. Special software tools also

make the machine suitable for worker self-inspection: the

workpiece is simply placed on the rotary table and the associated

measuring program is started by pressing a button,

barcode or RFID code. The measurement result consists in,

for example, exact measured values for each geometrical

characteristic or, in the simplest case, a color-coded deviation

plot from a nominal-actual comparison. Complete

auto mation for inline applications is also possible, e.g., with

robot loading. The machines in the TomoScope® XS family

have the smallest footprint on the market for machines in

this performance class, making them ideal for direct in-line

use. The TomoScope® XS FOV is suitable for small plastic and

metal workpieces in the medium accuracy range.

With the aid of the high-power X-ray source and tube

voltages of up to 160 kV, even uncooperative materials can

be irradiated from different orientations in a short time and

thus captured completely and three-dimensionally – including

internal geometries. With multi-object measurements

and automatic workpiece separation, measurement times of

some tens of seconds per workpiece can be achieved. The

measuring range can be optionally extended with additional

axes and Raster Tomography.

further information: www.werth.de


components

Introducing cloud-powered tooling integration

to accelerate mould & die machining and

standardize workflows

Hexagon’s Manufacturing Intelligence Business

Area has introduced a significant advancement for

mould & die and precision machining, with the first

production ready integration between its WORKNC

CAM software and the cloud-based Tool Library.

This integration strengthens how CAM programmers apply

validated tooling data and proven machining methods, enabling

faster programming and more predictable results on

complex parts.

Increasing part complexity, tighter tolerances and the scarcity

of experienced programmers continue to place pressure

on machinists. Many lose valuable time recreating tooling

assemblies, maintaining fragmented data or relying on undocu

mented knowledge exchange across shifts. Hexagon’s latest

release addresses these challenges by unifying enhanced

work flow automation in WORKNC with centralized, validated

cutting-tool information from industry leading tool

manufacturers (OEMs) through the platform.

“Reliable tooling information is one of the most powerful

levers for reducing programming time and eliminating variability”,

said Steffen Dilger, president of Hexagon’s production

software division. “As manufacturers adopt more advanced

automation and AI-assisted programming, centralized and

high-quality tool data will play an increasingly critical role.

Our focus is on removing workflow bottlenecks and connecting

the full manufacturing toolkit, from tool selection

through simulation and NC verification.”

Cloud-powered tooling for

faster, smarter CAM programming

The Tool Library provides WORKNC users with direct access

to verified cutting-tool data from a growing network of leading

tooling partners. Programmers can pull tooling information

directly into their CAM environment without re-entry

or model reconstruction, reducing set-up time and ensuring

digital tool definitions match actual cutting performance.

“This integration helps manufacturers adopt smarter, more

efficient digital workflows”, said Dr. Carlonda Reilly, chief

technology officer, Kennametal. “By combining our validated

tooling data with Hexagon’s powerful CAM technology, we’re

advancing our strategy by expanding our digital capabilities

to better serve machining shops worldwide.”

“Having Sandvik Coromant tooling available inside the

Tool Library means less guesswork and more productive machining”,

said Tobias Unosson, business & partner development

manager, Sandvik Coromant. “With validated data at

your fingertips, shops can standardize, reduce setup time,

WORKNC by Hexagon is designed as CAM software for

2- to 5-axis CNC programming of complex models

in the tool, die, and mold manufacturing industry

and maintain consistent best practices. Smarter tools mean

smarter workflows.” This growing number of featured partners

also includes MachiningCloud and ToolsUnited, with additional

partners being onboarded as the ecosystem expands,

giving shops broader access to validated tooling data.

The integration of the Tool Library enables accurate digital

twins of tools and assemblies, automatic application of material-specific

cutting data, and the sharing of standardized

tooling definitions across teams. Its cloud-based architecture

supports scalability and consistency across thousands of tool

items, while searchable catalogues give users direct access to

OEM information without installing additional applications

or consuming CAM licenses.

Enhanced automation and quality improvements

in WORKNC 2025.4

Alongside the Tool Library integration, Hexagon has introduced

new automation and finishing enhancements designed

to simplify complex programming tasks and help shops

achieve more consistent machining outcomes:

▶ Improved finishing quality: a new parallel finishing

algorithm delivers cleaner transitions at surface edges

and improves geometry accuracy. Combined with

toolpath extension in tangency, it reduces

tedious CAD preparation.

▶ Simplified programming: new enhancements improve

detection of remaining material and provide

finer control of tool entry and exit positions,

helping programmers generate collision-safe

toolpaths with less manual intervention.

With this release, Hexagon continues to prioritize

practical automation that fits existing processes, enabling

manufacturers to modernize at a pace that suits their

operations.

further information: www.hexagon.com


49

components

From a secondary process

to a productivity driver

How intelligent KSS management determines quality, productivity, and costs

In modern metalworking, the quality of the cooling

lubricant (KSS) not only determines the service life

of the tools, it also influences the entire value chain.

Full-flow microfiltration, intelligent control, and temperature-optimized

processes make KSS management

a key lever for efficiency, product quality and sustainability.

With its modular microfiltration systems, filter

specialist Vomat from Treuen demonstrates how filter

technology today not only “cleans”, but also contributes

to the optimization of the entire production

process actively.

In many companies cooling lubricant management is still

regarded merely as a necessary peripheral task. However the

purity of the cooling lubricant has a direct and measurable im -

pact on key performance indicators such as scrap rates, machine

availability, tool costs and energy consumption. Modern,

integrated cooling lubricant management therefore

includes continuous fine filtration in full flow, constanttemperature

cooling, demand-based operation of pumps

and filter elements, and well-thought-out concepts for waste

disposal and recycling.

These components interact particularly closely in tool

grinding: the cleaner the grinding oil and the more stable

the temperature, the better the geometry, surface quality and

service life can be reproduced. At the same time cooling lubricants

remain in the system for significantly longer, which

reduces costs for replacement, storage, and disposal.

How Vomat systems optimize

the entire process chain

Steffen Strobel, technical sales manager at Vomat: “Vomat

deliberately positions itself not only as a filter supplier, but

as a solution provider for the entire cooling lubricant periphery

in metalworking. We supply everything from individual

to large-scale industrial central systems.” And they all offer

the same advantages. “Full-flow ultra-fine filtration with

constant purity: Vomat fine filtration systems separate dirty

and clean oil 100 % in a full-flow process and achieve purity

classes of NAS 7 (3 - 5 μm). This ensures that extremely clean

cooling lubricants are permanently available for the grinding

process – a decisive factor for dimensional accuracy, surface

quality and tool life.

Demand-based backwashing and energy efficiency: the degree

of contamination of each filter element is monitored;

backwash cycles only run when they are actually necessary.

While one element is being backwashed, the others continue

to ensure a continuous supply of clean oil. This extends the

service life of the filter elements, reduces energy consumption

and prevents process interruptions.

Temperature-stable processes for μ-precise quality: in addition

to filtration, Vomat offers integrated cooling concepts

that keep the cooling lubricant within a narrow tolerance

range (up to approx. ± 0.2 - 0.5 K, depending on the design).

This minimizes thermal influences on the tool and workpiece

– a must for demanding grinding processes with tight

tolerances.

Modular systems for every size of operation

From individual FA systems to central ZFA systems with outputs

in the four to five-digit liter range per minute: the modular

concepts can be tailored precisely to machining volumes,

machine configurations and future expansions. This transforms

filtration from an isolated unit into strategic infrastruc -

ture: cooling lubricant microfiltration, cooling and recyclable

material processing are planned as an integrated system and

contribute directly to OEE, TCO, and process reliability.

Clean processes, better parts:

quality gains through ultra-fine filtration

Clean processes mean better parts, because ultra-fine filtration

has a direct impact on product quality. Contaminants

in the cooling lubricant act like an invisible abrasive in the

circuit during everyday production: they cause scoring, unclean

cutting edges, thermal damage and increased wear on

grinding wheels and machine parts. Conversely, consistently

clean cooling lubricants offer several quality advantages: dimensional

accuracy and surface quality increase thanks to

stable removal rates and homogeneous heat dissipation. Tool

life is extended due to reduced abrasive wear, and scrap and

rework are significantly reduced thanks to reproducible

grinding conditions. Also machine downtime is reduced

because components such as spindles, seals and valves are

subjected to less stress. Clean machining processes thus

directly contribute to delivery quality, adherence to delivery

dates, and competitiveness – both in series production and

in precision toolmaking.

Ultrafine filtration is core technology,

not an accessory

Ultrafine filtration of cooling lubricants is not just a “filter

box next to the machine.” As an integral part of a welldesigned

cooling lubricant management system, it influences

product quality, productivity, energy consumption, and sustainability

throughout the entire production process.

further information: www.vomat.de


impressum

ISSN 2628-5444

publisher

Benno Keller

phone + 49 (0)911 - 2018 200

fax + 49 (0)911 - 2018 100

keller@harnisch.com

editor-in-chief

Eric Schäfer

phone +49 (0)911 - 504 98 82

fax +49 (0)911 - 506 38 32

eric.schaefer@harnisch.com

managing editor

Christiane Ebner

phone +49 (0)911 - 2018 260

fax +49 (0)911 - 2018 100

ebner@harnisch.com

publishing company

Dr. Harnisch Publications

management board

Dr. Claus-Jörg Harnisch

Benno Keller

Eschenstrasse 25

90441 Nuremberg

Germany

phone +49 (0)911 - 2018 0

fax +49 (0)911 - 2018 100

hpt@harnisch.com

www.harnisch.com

www.hptooling-mag.com

3nine AB .......................... 48

Aerotech, Inc. ...................... 24

Air Turbine Technology Inc. ..........43

CemeCon AG ........................8

DMG MORI ....................... 42

EMAG Systems GmbH ...............36

Fritz Studer AG .....................23

GrindingHub .......................25

HAINBUCH GMBH SPANNENDE

TECHNIK ........................26

company finder

LEUCO AG .........................21

Liebherr-Verzahntechnik GmbH. ......27

LMT Tools GmbH & Co. KG ..........16

MAPAL Dr. Kress SE & CO. KG ... 22, 28

Mitsubishi Materials Corporation .....22

OTEC Präzisionsfinish GmbH ........38

SBS Ecoclean Group ................ 46

Schwäbische Werkzeugmaschinen

GmbH ............................39

SIMTEK Präzisionswerkzeuge GmbH ..12

advertising Germany, Austria, Switzerland

Thomas Mlynarik

phone +49 (0)911 - 2018 165

phone +49 (0)9127 - 902 346

mobile +49 (0)151 - 548 181 81

fax +49 (0)911 - 2018 100

mlynarik@harnisch.com

advertising Europe

Britta Steinberg

phone +49 (0)911 - 2018 275

fax +49 (0)911 - 2018 100

steinberg@harnisch.com

advertising USA, Canada

Steve Max

phone +1 (0)215 - 284 87 87

steve.max@harnisch.com

advertising China, Hong Kong, Taiwan

Mike Hay

phone +852 (0)9096 - 88 95

mchhay@ringier.com.hk

advertising Taiwan

Charles Lin

phone +886 (0)4 - 232 973 18

charleslin@ringier.com.hk

four issues per year

printed by

Akontext s.r.o.

Beranových 65

199 00 PRAHA 9, Czechia

VAT DE 133 510 873

Hartmetall-Werkzeugfabrik

Paul Horn GmbH ............ 6, 14, 15

Hexagon AB ........................49

Hyperion

Materials & Technologies, Inc. .......14

ISBE GmbH .........................45

Kellenberger Machines Holdings

GmbH ............................34

KERN Microtechnik GmbH ..........30

Lach Diamant Jakob Lach

GmbH & Co. KG ...................18

Leitz GmbH & Co. KG .............. 20

Sunnen Products Company ...........26

TDM Systems GmbH ............... 44

TIGRA GmbH ......................10

TMTS ..............................33

Vigel SpA .......................... 24

VOLLMER WERKE Maschinenfabrik

GmbH .........................21, 32

Vomat GmbH .......................50

Werth Messtechnik GmbH. . . . . . . . . . . 48

Zimmermann Inc. .................. 40

The articles contained in this magazine,

including the illustrations, are subject

to copyright law. Any use without the

consent of the publisher is not permitted

and will be prosecuted. This applies to

every conceivable form of reproduction.

Copies and reprints can be ordered on

request. Articles which are identified by

name or which are to be assigned to an

author by an abbreviation do not necessarily

reflect the opinion of the editorial staff.

Unsolicited manuscripts cannot be returned.

If a manuscript is accepted by the editorial

staff, publishing and copyright law as well

as all rights for publication and distribution

are transferred to the publisher. The

publisher accepts no liability with regard

to the facts set out in these articles.

copyright © 2026 Dr. Harnisch Publications

advertising index

GrindingHub ..........................................................page 13

Hartmetall-Werkzeugfabrik Paul Horn GmbH ...............................cover

JOHN CHEN SCREW Ind. Co., Ltd. ................................... back cover

Lach Diamant Jakob Lach GmbH & Co. KG .......................inside front cover

Liebherr-Verzahntechnik GmbH. .........................................page 11

TIGRA GmbH ..........................................................page 9


51

hp tooling 2026-#2

Transform your PDFs into Flipbooks and boost your revenue!

Delete template?

Save as template ?
