Sequoia power steering rack service

Spring 2008

In this issue:

Sequoia power

steering rack service

Match-mounting

wheels and tires

Oxygen sensor

circuit diagnosis

OXYGEN SENSOR

CIRCUIT DIAGNOSIS

Taking a look at the 2005

Land Cruiser, from circuit

descriptions to inspection

procedures to trouble

codes — 4

MATCH-MOUNTING

WHEELS/TIRES

A detailed description of phase

matching, radial force variation,

orders of vibration and correcting

complaints — 14

STAR Service News

Toyota’s Support to Automotive Repair

Editor: Roberta Ritter, Toyota Motor Sales, U.S.A., Inc.

Content: Birchwood Automotive Group, Creston, Ohio

Source: Toyota Service Manuals

Design: Bobit Business Media, Uniontown, Ohio

STAR departments

Jerry Raskind letter — 3

Back issues ordering — 21

Toyota Topics — 30

Dealer listings — 32

POWER STEERING

RACK SERVICE

Servicing the 2005 Sequoia

from fluid bleeding to

reassembly — 23

Issue 120

STAR Service News is a quarterly publication of Toyota Motor Sales, U.S.A., Inc. Editorial and circulation offices: Toyota Customer Services, STAR Program WC21, 19001 South Western Avenue,

Torrance, CA 90509. Fax (310) 468-0913.

STAR Service News is available through Toyota STAR Dealers and is also available by subscription. Toyota makes no warranty, expressed or implied, regarding the contents of this publication, nor should any be construed. All procedures, specifications

and part numbers were in effect at the time of printing. Toyota reserves the right to change procedures and/or specifications at any time, without prior notice and without incurring any obligation. Articles and technical data contained in this

publication are based in whole or in part on prior communications by Toyota to its dealers. FOR COMPLETE SPECIFICATIONS AND PROCEDURAL INFORMATION, PLEASE REFER TO THE APPROPRIATE REPAIR MANUAL. For part number changes,

please contact your Toyota dealer.

Copyright 2008 Toyota Motor Sales, U.S.A., Inc. Contents of this publication may not be reprinted without written permission. The Toyota name and logo and Toyota STAR name and logo are registered trademarks of Toyota Motor Corporation and may

not be used in any manner without the prior written consent of Toyota Motor Sales, U.S.A., Inc.

Caution: Vehicle servicing performed by untrained persons could result in serious injury to those persons or others.

2 STAR Service News

Spring 2008

It’s time for spring

cleaning!

S

pring cleaning — a ritual or something you overlook? For

some, it’s done with reckless abandon — rolling up sleeves

and digging in, filling up boxes and trash bags and tossing

everything that hasn’t been used or doesn’t have a purpose.

For others, it’s a time to look around, tidy up a bit and carry on.

Personally, I’m a bit in the middle — I wake up one morning and

really clean out the garage, or my office and I feel pretty good

about it! Whichever approach you take, it’s a good idea to take

inventory from time to time and eliminate the things that have

worn out their welcome.

I don’t want to harp about the economy, but it does impact all

of us. And a little spring cleaning may be in order. Some of us

are driving less, spending less and putting off tasks when we

can. As far as running a business is concerned, this can be a

tricky time — we want to cut back to save a buck — but now’s

the time to invest in your business wisely. Make sure your business

is up-to-speed and is fully prepared to offer each and every

customer the best value possible. You want to be sure that the

parts you use are the most reliable and durable available, and that your technicians

have the know-how to complete repairs as quickly as possible.

The easiest way to provide all of that to your customers is to align yourself with a

Toyota STAR dealer — they’re dedicated to getting you information and Genuine Toyota

parts quickly so you can get your customers back on the road. By using Genuine

Toyota parts and performing quality repairs, you can offer your customers excellent

value. The benefits of the Toyota STAR program — such as excellent dealer support,

and sites like www.toyotapartsandservice.com and www.techinfo.toyota.com as well

as technical information found in STAR Service News, can keep your shop one step

ahead.

As always, we’re here for you. A slow economy means we have to think carefully

about the value of the service we offer — and if there’s something we can add to our

program to help you do your job better or more efficiently, let us know. We’re here

to help you — if we’re doing it right, let me know. If we need to improve, tell me. I’m

easy to reach at jerry_raskind@Toyota.com and I look forward to hearing from you.

Best regards,

Jerry Raskind

Wholesale Development Manager, Toyota Motor Sales, U.S.A., Inc.

Spring 2008

STAR Service News 3

TOYOTA TECHNICAL

2005 LAND CRUISER OXYGEN

SENSOR CIRCUIT DIAGNOSIS

From descriptions to trouble codes

Throttle control motor

and sensor

Camshaft

position sensor

Ignition coil with igniter

Mass air

flow meter

Engine coolant

temperature sensor

Crankshaft position

sensor

Knock sensor 2

Heated oxygen sensor

(Bank 2, Sensor1)


(Bank 1, Sensor1)

Injector

ECM

Knock sensor 1

Engine room R/B and J/B:

• Circuit opening relay

• Fuel pump relay

• EFI or ECD relay

• Starter relay

• EFI or ECD No. 1 fuse

• ECTS fuse

VSV for EVAP

Combination meter

VSV for CCV

Fuel pump resister

The Bank 1 and Bank 2, Sensor 1 locations are before the catalytic converters.

DLC3

Accelerator pedal assembly

(Accelerator pedal position sensor)

VSV for pressure

switching valve

Vapor pressure sensor

Cowl side J/B LH:

• STOP fuse

• EFI or ECD No. 2 fuse

Park/neutral position switch


Spring 2008

OXYGEN SENSOR BANK

LOCATIONS

Bank 1 (B1) refers to the bank

that includes cylinder No. 1 (cylinder

No. 1 is located at the front of

the engine’s left side).

Bank 2 (B2) refers to the right

Heat

insulator

Gasket

Front

exhaust pipe

Heat

insulator

Ring

Gasket

Front exhaust pipe

engine side (passenger side).

Sensor 1 (S1) is located before

the catalytic converters.

Sensor 2 (S2) is located after the

catalytic converters.

Gasket

Heat insulator

Gasket


(Bank 2, Sensor 2)


(Bank 1, Sensor 2)

Heat

insulator

Bank 1 and Bank 2, Sensor 2 locations are after the catalytic converters.

Ring

Ring

Ring

Gasket

Spring 2008 STAR Service News

TWC


Clamp

Center exhaust pipe

CIRCUIT DESCRIPTION

In order to obtain a high purification

rate for the CO, HC and Nox

components of the exhaust gas,

a three-way catalytic converter is

used. For the most efficient use

of the three-way converter, the

Ring

Ring

Tailpipe

No.2 front

exhaust pipe

Gasket

Gasket

Heat

insulator

5


Cover

Heated oxygen sensors feature a heating element inside the core of the electrode, allowing faster and

more accurate monitoring of the air/fuel ratio. The ECM provides a pulse width modulated control circuit

to adjust current through the heater.

air/fuel ratio must be precisely

controlled to maintain as close to

an ideal (stoichiometric) ratio as

possible.

The heated oxygen sensor’s

output voltage is able to change

suddenly (more responsive) when

the air/fuel ratio is very close to

this stoichiometric ideal. This detects

the oxygen concentration in

the exhaust gas and provides the

electronic control module (ECM)

with a more timely feedback in the

effort to control the air/fuel ratio.

When the air/fuel ratio becomes

lean, the oxygen concentration

in the exhaust gas increases, and

the heated oxygen sensor informs

the ECM of this lean condition

(less than 0.45V). When the air/

fuel ratio becomes richer than the

stoichiometric ideal, the oxygen

concentration in the exhaust gas

is reduced and the heated oxygen

sensor informs the ECM by

producing more than 0.45V. The

ECM uses this lean/rich (lower/

higher voltage signal) information

to determine if the air/fuel ratio

is rich or lean and, in turn, adjusts

the injection time accordingly in

Atmosphere

Exhaust gas

Housing

Platinum electrode

Solid electrolyte

(zirconia element)

Platinum electrode

Heater

Coating (ceramic)

an effort to maintain the ideal air/

fuel ratio.

However, if a malfunction of the

heated oxygen sensor causes the

output of abnormal voltage, the

ECM may not be able to perform

accurate air/fuel ratio control. The

heated oxygen sensors include a

heater which heats the zirconia

element. The heater is controlled

by the ECM. When the air intake

volume is low (low exhaust gas

temperature), current flows to

the heater to heat the oxygen

sensor(s) for quicker and accurate

oxygen concentration detection.

The sensing portion of the heated

oxygen sensor has a zirconia

element which is used to detect

oxygen concentration in the

exhaust gas. If the zirconia element

is at the proper temperature

and the difference of the oxygen

concentration between the inside

and outside surface of the sensor

is large, the zirconia element will

generate voltage signals. In order

to increase the oxygen concentration

detecting capacity in the

zirconia element, the ECM supplements

the heat from the exhaust

Output voltage

Ideal air/fuel mixture

Richer - air/fuel ratio - Leaner

with heat from a heating element

inside the sensor.

When current in the sensor is

outside of the standard operating

range, the ECM interprets this as

a fault in the heated oxygen sensor

and sets a DTC. For example,

the ECM will set a high current

DTC if the current in the sensor

is greater than 2.0 amps when

the heater is off. Similarly, the

ECM will set a low current DTC if

the current is less than 0.25 amp

when the heater is on.

The inner surface of the sensor

element is exposed to outside air.

The outer surface of the sensor

element is exposed to exhaust

gas. The sensor element is made

of platinum-coated zirconia and

includes an integrated heating

element. The heated oxygen sensor’s

output voltage changes suddenly

in the vicinity of the ideal

air/fuel ratio. The heated oxygen

sensor generates output voltage

between 0V and 1.0V in response

to the oxygen concentration in

the exhaust gas mix. When the

output voltage of the heated oxygen

sensor is 0.55V or more, the


Spring 2008

ECM judges that the air/fuel ratio

is rich. When output voltage is

0.4V or less, the ECM judges that

the mixture is lean. Under normal

conditions, the output voltage

from the heated oxygen sensor

alternates rich and lean periodically.

If the heated oxygen sensor

outputs a rich signal or lean

signal on a constant basis, or if

the heated oxygen sensor cannot

output enough voltage to reach

the minimum specification, the

ECM interprets this as a malfunction

in the heated oxygen sensor

and sets a DTC.

The vehicle is equipped with

two heated oxygen sensors for

each engine bank. One is mounted

upstream from the three-way

catalytic converter (Sensor 1), and

one is mounted downstream from

the catalytic converter (Sensor 2).

The catalyst efficiency monitor

compares Sensor 1 and Sensor 2

Waveform of

heated oxygen sensor

(before catalyst)

Waveform of


(before catalyst)

signals in order to calculate the

converter’s ability to store oxygen

in the exhaust stream. During

normal operation, the three-way

catalytic converter stores and

releases oxygen as needed. This

results in low oxygen variations in

the Sensor 2 exhaust stream.

TYPICAL MALFUNCTION

THRESHOLDS

P0031, P0037, P0051, P0057

(low current): Heated oxygen

sensor heater current is less than

0.25 amp (at 0.3 seconds after the

heater is on).

P0032, P0038, P0052, P0058

(high current): Heated oxygen sensor

heater current is more than 2.0

amps (while heater is off).

COMPONENT

OPERATING RANGE

The heated oxygen sensor

heater current standard value is

Normal catalyst

Abnormal catalyst


0.4 to 1.0 amp (when the engine

has been warmed up, with engine

idling or when battery voltage is

11 to 14 V).

CHECKING RESISTANCE

OF A HEATED OXYGEN

SENSOR HEATER

Disconnect the H5, H6, H7 or H8

heated oxygen sensor connector

and, using an ohmmeter, measure

resistance between the terminals

of the sensor as follows:

HT (H5-1) - +B (H5-2)

11 to 16 ohms (68 degrees F)

HT (H6-1) - +B (H6-2)


HT (H7-1) - +B (H7-2)


HT (H8-1) - +B (H8-2


Waveform of


(after catalyst)

Waveform of


(after catalyst)

The three-way catalytic converter stores and releases oxygen as needed. As a result, there should be a

difference between Sensor 1 and Sensor 2 data during operation.


7


Components side:

Bank 1, Sensor 1; Bank 2, Sensor 1


Check resistance of a heated oxygen

sensor heater at its connector

as shown.

INSPECTION

PROCEDURE

(Using the Toyota hand-held

tester.)

The trouble area may be narrowed

down by performing the

ACTIVE TEST for A/F Control.

Connect the hand-held tester to

the DLC3. Start the engine and

allow it to warm up with engine

speed at 2,500 rpm for about 90

seconds. Select the item DIAG-

NOSIS/ENHANCED OBD II/ACTIVE

TEST/AF CONTROL. Perform A/F

CONTROL with the engine in an

idle condition (press the right or

left button).

The heated oxygen sensor

should react in accordance with

an increase or decrease of fuel

injection volume:

+25% -> rich output: more than

0.5V

-12.5% -> lean output: less than

0.4V

Note that there may be a fewsecond

delay for Sensor 1 (front

sensor) output, and there may be

about a 20-second delay for Sensor

2 (rear sensor) output.

The following A/F CONTROL

procedure enables the technician

to check and graph the voltage

output of the heated oxygen sensors

(Sensors 1 and 2).

For displaying the graph indication,

enter ACTIVE TEST/A/F

CONTROL/USER DATA, then select

O2S B1S1 and O2S B1S2 by press-

TESTER CONDITION SPECIFIED CONDITION

OX (H5-3) - OX1A (E6-23) Below 1 ohm

HT (H5-1) - HT1A (E6-4) Below 1 ohm

OX (H6-3 - OX1B (E6-29) Below 1 ohm

HT (H6-1) - HT1B (E6-5) Below 1 ohm

OX (H7-3) - OX2A (E6-22) Below 1 ohm

HT (H7-1) - HT2A (E6-33) Below 1 ohm

OX (H8-3) - OX2B (E6-21) Below 1 ohm

HT (H8-1) - HT2B (E6-25) Below 1 ohm

OX (H5-3) OR OX1A (E6-23) - BODY GROUND 10 kohm or higher

HT (H5-1) OR HT1A (E6-4) - BODY GROUND 10 kohm or higher

OX (H6-3) OR OX1B (E6-29) - BODY GROUND 10 kohm or higher

HT (H6-1) OR HT1B (E6-5) - BODY GROUND 10 kohm or higher

OX (H7-3) OR OX2A (E6-22) - BODY GROUND 10 kohm or higher

HT (H7-1) OR HT2A (E6-33) - BODY GROUND 10 kohm or higher

OX (H8-3) OR OX2B (E6-21) - BODY GROUND 10 kohm or higher

HT (H8-1) OR HT2B (E6-25) - BODY GROUND 10 kohm or higher

ing the YES button, and push the

ENTER button before pressing the

F4 button.

If the engine is short on fuel, the

air/fuel ratio becomes lean, and

heated oxygen sensor DTCs will

be recorded (and the MIL light

illuminates).

If different DTCs related to different

systems that use terminal

E2 as the ground terminal are

output at the same time, terminal

E2 may be open.

Read freeze frame data using

the hand-held tester. Freeze

frame data records the engine

conditions when a malfunction

is detected. When troubleshooting,

it’s useful for determining

whether the vehicle was running

or stopped, if the engine was

warmed up or not, if the air/fuel

ratio was lean or rich, etc., at the

time of the malfunction.

A high heated oxygen sensor

(Sensor 1) voltage of 0.5V or

greater could be caused by a rich

air/fuel mixture. Check for conditions

that would cause the engine

to run rich.

A low heated oxygen sensor

(Sensor 1) voltage of 0.4V or less

could be caused by a lean air/fuel

mixture. Check for conditions that

would cause the engine to run lean.

NOTE: Other codes (aside from

DTC P0130, P0150, P2195, P 2197,

P2196 or P2198) may be present.

If so, perform troubleshooting for

those DTCs first.

Check for open and short in the

harness and connector between

the ECM and the heated oxygen

sensor. Disconnect the H5, H6, H7

or H8 heated oxygen sensor connector.

Disconnect the E6 ECM


Spring 2008

Components side:



ECM connector

Check for open and short in the

harness and connector between

the ECM and the heated oxygen

sensors.

connector. Measure the resistance

between the wire harness side

connectors.

Oxygen sensor output voltage (V)

Slow slope condition

DIAGNOSTIC

TROUBLE CODES

DTC numbers P0031, P0037,

P0051 and P0057 indicate that

heater current is 0.25 amp or less

when the heater operates with

more than 10.5 V positive battery

voltage.

DTC numbers P0032, P0038,

P0052 and P0058 indicate that

when the heater operates, heater

current exceeds 2.0 amps.

DTC P0031

Oxygen sensor heater control

circuit low (Bank 1, Sensor 1).

TROUBLE AREA

Open in the heater circuit of

heated oxygen sensor, oxygen

sensor heater, EFI or ECD relay,

ECM.

DTC P0032


circuit high (Bank 1, Sensor 1).

TROUBLE AREA

Short in heater circuit of heated

oxygen sensor, heated oxygen


ECM.

Lean to rich time

Lean to rich / Rich to lean time definition

Oxygen sensor output voltage during lean/rich and rich/lean intervals.


Rich

Lean

Rich to lean time


DTC P0037



TROUBLE AREA

Open in heater circuit of heated

oxygen sensor, oxygen sensor

heater, EFI or ECD relay, ECM.

DTC P0038



TROUBLE AREA




DTC P0051



TROUBLE AREA




DTC P0052



TROUBLE AREA




Time

9


DTC P0057



TROUBLE AREA




DTC P0058



TROUBLE AREA




DTC P0130

Oxygen sensor circuit (Bank 1,

Sensor 1).

(Output voltage of heated oxygen

sensor remains at 0.4V or more, or

0.55V or less, during idling, with

engine warmed up.)

TROUBLE AREA

Open or short in heated oxygen

sensor circuit, heated oxygen

sensor, oxygen sensor heater, EFI

or ECD relay, air induction system,

fuel pressure, injector, ECM.

DTC P0133

Oxygen sensor circuit

slow response

(Bank 1, Sensor 1.)

TROUBLE AREA

Open or short in

heated oxygen

sensor circuit,

heated oxygen

sensor, oxygen

sensor heater, EFI

or ECD relay, air

induction system,

fuel pressure, injector,

ECM.

DTC P0134

Oxygen sensor

circuit no activity

detected (Bank 1,

Sensor 1).

TROUBLE AREA

Open or short in

heated oxygen

sensor circuit,

heated oxygen

sensor, oxygen

sensor heater, EFI

or ECD relay, air

induction system,

fuel pressure, PCV

hose connection,

PCV valve and hose, injector, gas

leakage in exhaust system, PCV

piping, ECM.

DTC P0136

Oxygen sensor circuit malfunction

(Bank 1, Sensor 2).

TROUBLE AREA


sensor circuit, heated oxygen sensor,

oxygen sensor heater, EFI or

ECD relay.

DTC P0150

Oxygen sensor circuit (Bank 2,

Sensor 1).


sensor remains at 0.4V or more, or

0.55V or less, during idling, with

engine warmed up.)

TROUBLE AREA






DTC P0153

Oxygen sensor circuit slow response


TROUBLE AREA






DTC P0154

Oxygen sensor circuit no activity

detected (Bank 2, Sensor 1).

TROUBLE AREA





fuel pressure, PCV hose connec-


Spring 2008

tion, PCV valve and hose, injector,

gas leakage in exhaust system,

PCV piping, ECM.

DTC P0156

Oxygen sensor circuit malfunction


TROUBLE AREA


sensor circuit, heated oxygen sensor,

oxygen sensor heater, EFI or

ECD relay.

DTC P0171

System too lean (Bank 1).

TROUBLE AREA

Air induction system, injector

blockage, mass airflow meter,

engine coolant temperature sensor,

fuel pressure, gas leakage in

exhaust system, open or short

in heated oxygen sensor circuit

(Bank 1, Sensor 1), heated oxygen

sensor (Bank 1, Sensor 1), oxygen



DTC P0172

System too rich (Bank 1).

TROUBLE AREA

Injector leakage or blockage,

mass airflow meter, engine coolant

temperature sensor, ignition

system, fuel pressure, gas leakage

in exhaust system, open or short



sensor (Bank 1, Sensor 1), ECM.

DTC P0174

System too lean (Bank 2).

TROUBLE AREA

Air induction system, injector

blockage, mass airflow meter,

engine coolant temperature sensor,

fuel pressure, gas leakage in

exhaust system, open or short



sensor (Bank 2, Sensor 1), oxygen



DTC P0175

System too rich (Bank 2).

TROUBLE AREA

Injector leakage/blockage, mass

airflow meter, engine coolant

temperature sensor, ignition

system, fuel pressure, gas leakage

in exhaust system, open or short



sensor (Bank 2, Sensor 1), ECM.

DTC P0420

Catalyst system efficiency below

threshold (Bank 1).

TROUBLE AREA

Gas leakage in exhaust system,

heated oxygen sensor (Bank 1,

Sensors 1, 2), three-way catalytic

converter.

DTC P0430

Catalyst system efficiency below

threshold (Bank 2).

TROUBLE AREA

Gas leakage in exhaust system,

heated oxygen sensor (Bank 2,

Sensors 1, 2), three-way catalytic

converter.

DTC P2195

Oxygen sensor signal stuck lean



sensor remains at 0.55V or

less, during idling after engine is

warmed up.)

TROUBLE AREA








DTC P2196

Oxygen sensor signal stuck rich




more, during idling with engine

warmed up.)

TROUBLE AREA






DTC P2197

Oxygen sensor signal stuck lean




less, during idling after engine is

warmed up.)

TROUBLE AREA






DTC P2198

Oxygen sensor signal stuck rich




more, during idling with engine

warmed up.)

TROUBLE AREA





fuel pressure, injector, ECM. ★

11


PHASE MATCHING

Often referred to as “match

mounting,” phase matching involves

mounting the tire onto the

wheel to align the tire’s point of

maximum dynamic runout (radial

force variation, or RFV) with the

wheel’s point of minimum radial

runout.

Toyota tires and wheels are

factory assembled to minimize

MATCH-MOUNTING

WHEELS/TIRES

Chasing vibrational complaints

the effects of RFV. All OEM wheel

assemblies are phase matched to

align the tire’s point of maximum

RFV to the wheel’s point of minimum

RFV.

The tire’s maximum RFV is

generally indicated by a red

dot on the tire sidewall. During

mounting, this red dot should be

aligned with the white dot on an

OEM steel wheel (the white dot

A red dot on the tire sidewall indicates the tire’s point of maximum

radial force variation. Always align a red dot on the tire with

a white dot on the wheel, or with the wheel’s valve position.

indicates the wheel’s minimum

radial runout point). On alloy

wheels, the tire’s red dot should

be aligned with the valve stem, as

the valve stem area is the Toyota

wheel’s point of minimum radial

runout. Note that the tire may

also feature a yellow dot, which

indicates the tire’s point of least

weight. This dot may be referenced

during balancing issues.

Toyota emphasizes that even if

dynamic wheel balance is correct,

misalignment of the red dot may

likely result in a vibration complaint.

On Toyota OEM tires and

wheels, always align the tire’s red

dot to the wheel’s white dot (or

valve stem, in the case of a Toyota

alloy wheel).

NOTE: If the vehicle has been

fitted with aftermarket alloy

wheels, it is possible that the

valve stem location may not

indicate the wheel’s point of

minimum radial runout. This is

because some aftermarket alloy

wheels may have been designed

to locate the valve stem in a visually

appealing location, instead of

at the point of minimum runout.

RADIAL FORCE

VARIATION (RFV)

There are two types of radial

runout — runout deviation that

can be measured statically and

that which may only show itself


Spring 2008

under dynamic conditions —

when the tire runs with a load.

Static runout, as we noted earlier,

refers to a high spot on the tire,

a physical characteristic that can

be measured with no load placed

on the tire. Radial force variation,

however, refers to a runout

condition that only occurs when

the tire runs at speed, under load,

due to variations in construction

stiffness.

When a tire’s contact patch

meets the road surface, its sidewall

flexes, absorbing road forces,

much like a spring. The rigidity of

the tire’s sidewall varies slightly

along the tire’s circumference.

The variation in sidewall rigidity is

caused by tire construction differences,

material distribution and

radial runout.

All tires are manufactured with

a degree of RFV, simply due to

manufacturing tolerances, and in

most cases, these slight variations

don’t cause a problem. However,

excessive radial force variation

will cause the axle’s spindle to

deflect upwards as the tire’s stiffest

area meets the road surface.

This force results in a wheel tramp

vibration.

If excessive RFV is determined

to be the problem (after verifying

that the source of the vibration is

not caused by wheel balance, tire,

hub or axle runout, or suspension

and steering component wear),

the only solution is to replace the

tire.

Radial force variation is sonamed

because the radius of the

tire varies according to vehicle

speed and load. Of course, any

tire, because of its compliance,

will slightly vary in radius at

the load spot during operation.

Although a “radial force” might

be the result of a runout area that

is pronounced enough to affect

the tire’s impact on the road, a

radial “force variation” may occur

if the tire has appreciably different

“soft” spots and “stiff” spots

in the carcass and/or tread or in

the sidewall construction. Given

the high quality control processes

used by today’s tire makers, it’s

rare that a force variation problem

will occur, but when it does, it can

be a tricky demon to chase.

Even though no problems

may be found as the tire rotates

on the balancer, when the tire

experiences a load, the transition

of the harder and softer sections

of the tire may create a series of

harmonic vibrations as the tire

contacts and leaves the road surface.

Depending on conditions,

this harmonic may occur once per

revolution of the tire, or it may

occur in a series of multiple vibrations

per revolution. It’s possible

that this phenomenon may vary

Valve stem



according to changes in tire pressure,

vehicle speed, individual tire

load and the road surface conditions,

all of which may serve to

reduce and/or amplify the vibration

problem. In other words, the

vibration that the driver feels may

not occur with any one rate of

speed, or on any one road surface,

because the problem may appear

only under a specific combination

of these variables.

If a tire/wheel will not balance

properly, or if a vibration exists after

a successful balance job, don’t

automatically blame the tire. If

you haven’t checked the hub and

wheel for runout, you may be

jumping to conclusions. If, however,

all balance, static runout and

chassis parts variables have been

exhausted, then it may be time

to suspect a radial force variation

problem.

In order to check for and attempt

to actually verify a dynamic

radial runout condition, a spinbalancer

with a built-in load roller

is recommended. This type of

balance machine places a load

Valve stem

The red dot on a tire sidewall (of an OEM tire) indicates the tire’s position

of maximum radial force variation. During tire mounting, this

point can be aligned with the wheel’s white dot (on steel wheels)

or the valve stem location on alloy wheels. If a yellow dot is present

on the tire, this indicates the tire’s point of least weight. In order to

minimize RFV, align the red dot to the wheel’s white dot or to the

valve stem.

15

(which attempts to simulate road

load) onto the tire as it’s spun,

while monitoring and recording

variances of runout. If load variation

is found, this may be corrected

to an acceptable state via

balancing weights, or in extreme

cases, it may verify that the tire

should be replaced.

THE DYNAMIC EFFECT

OF RFV

A minimum range of between

.3 to .5 ounce (7-14 grams) of

imbalance is usually enough for

the average motorist to notice an

imbalance-induced vibration. If a

vehicle is sensitive enough to exhibit

noticeable vibration at only

.3 - .5 ounces of imbalance, that

same amount of vibration may be

present with as little as 10 to 15

pounds of radial force variation,

which (although hard to believe)

can be caused by as little as .010

inch - .015 inch of loaded radial

runout. Using this as an example,

it’s easy to see how loaded runout

Stiff

spot


The tire’s flexible sidewall serves

as the first, or initial, “spring” in

the vehicle’s suspension. Excessive

variations in sidewall stiffness/flexibility

can result in a

vibration complaint as a result of

dynamic radial runout, or radial

force variation.

A yellow dot on the tire indicates the tire’s point of least weight. If no

red dot is present, this yellow dot may be aligned with the wheel’s

white dot (if present) or with the wheel’s valve stem, in order to minimize

imbalance.

can dramatically affect vibration.

In other words, a little bit of “loaded”

tire runout variance can result

in a notable impact on operating

smoothness or harshness.

One method of phase matching

is performed using a radar

chart. The radar chart allows you

to measure and plot the runout at

12 positions around the circumference

of both the tire and the

wheel. The method can be used

to correct either lateral or radial

runout.

1. Mount a dial indicator to

measure either the radial or the

lateral runout of the tire (whichever

needs correction).

2. Divide the tire and wheel

into 12 equal segments using tire

chalk or masking tape.

3. Locate the wheel valve stem.

The stem position will be considered

as the 12 o’clock position.

Zero the dial indicator.

4. Place a mark under the 12

o’clock position on the chart. This

distance (from the outer edge of

the chart) is the zero point. All

other marks will be + (plus) or -

(minus).

5. Rotate the tire clockwise to

the 1 o’clock position and note

the indicated runout.

6. Plot this value under the

1 o’clock position on the chart.

Each box should represent 0.005

inch or 0.010 inch. If the indicated

value is larger than zero, the mark

should be above the zero line. If

the indicated value is less than

zero, the mark should be below

the zero line.

7. Continue in this manner for

the remaining 10 points around

the tire circumference and connect

the plotted points, forming

the outer circle.

8. Perform the same steps for

wheel runout, beginning again

at the 12 o’clock point. Plot the


Spring 2008

wheel values inside of the tire

circle.

9. Connect each of the 12 plotted

points between the tire and

the wheel circles.

10. Measure the length of the

connecting lines. The longest line

indicates the point of maximum

total runout and the shortest line

indicates the point of minimum

total runout.

To reduce total runout, the tire

must be dismounted from the

wheel. Positioning the tire with

the maximum tire runout, aligned

with the point of minimum wheel

runout should reduce the amount

of total runout.

After remounting, total runout

at the tire must be re-measured

to confirm that the runout has

been reduced to within specification.

If the runout is still excessive,

and wheel runout itself is within

specification, the tire should be

replaced.

Bear in mind that the above

procedure, while allowing you

This example shows a tire that features both red and yellow dots at

the same location on the tire, which indicates that this tire’s point of

maximum RFV and its point of least weight share the same location.

to minimize static radial runout,

does not address dynamic radial

force variation. The most efficient

way to measure and to attempt

to correct a radial force variation

problem is to check the wheel/tire

assembly on a balancing machine

Tire

Wheel


that is equipped with a road force

feature.

ORDERS OF

VIBRATION

A single vibrating force may

generate more than one vibra-

The radar chart can be used to accomplish phase matching. Keep in mind that this addresses static

runout, not dynamic radial force variation.


17


tion. For example, an out of

balance tire can develop multiple

vibrations due to the distortion of

the tire as it rotates. The distortion

of the tire is caused by centrifugal

force as the tire rotates.

As the tire rotates, the heavy

spot on the tire causes an up-anddown

motion as it contacts the

road surface. This will induce a

vibration into the suspension and

steering system which will be felt

by the driver.

A vibration caused by a heavy

spot is a first-order vibration. It

occurs once per revolution of the

tire. A first-order vibration can

be the largest amplitude vibration

caused by imbalance. Due to

Tire distortion

Imbalance

Imbalance

Imbalance

Radial runout

Lateral runout

Radial runout appears as an eccentric or egg-shaped tire during operation,

resulting in a vertical (up/down) movement as the wheel and

tire assembly rotates. Lateral runout appears as horizontal movement

(side-to-side) of the wheel/tire assembly, causing a shimmy condition.

First-order vibration – once per revolution

Second-order vibration – twice per revolution

Third-order vibration – three times per revolution

Top view

If an imbalance condition is present, the tire begins to change shape during rotation as a result of centrifugal

force, causing the tire to distort and become out-of-round during operation.


Spring 2008

centrifugal force and the heavy

spot, the tire changes shape, raising

additional high spots on the

tire. As these spots contact the

road, they also cause an up/down

motion that is induced into the

suspension and steering systems.

This second vibration is caused by

a second bump in the tire as a result

of the tire’s change in shape.

It is usually smaller in amplitude

than the first-order vibration. This

is called second-order vibration.

Because there are two vibrations

within one revolution of the

tire, the second-order vibration

will be approximately twice the

frequency of the first order.

The third vibration is caused

by a third bump as a result of the

tire’s change in shape. It is generally

smaller in amplitude than

the second-order vibration. This

vibration is called the third-order

vibration.

WHEEL PINPOINT

DIAGNOSIS

Body shake, steering flutter

and steering shimmy complaints

can be initially diagnosed by verifying

bead seating, hub-to-wheel

Inspect the assembly for proper

bead seating. Improper bead

seating can cause a radial runout

condition of the tire.

centering and wheel/tire runout.

Check all four tires for brand,

size and specifications. Be sure to

check for proper inflation pressures.

Inspect for damage, deformation

and wear. Inspect the tires for

Check for proper wheel-to-hub

centering. A wheel that is mounted

off-center (beyond specification)

will cause a radial runout

condition

unusual wear patterns.

Inspect the tire and wheel to

confirm proper bead seating on

both front and rear bead areas.

Hub-to-wheel centering is important

to ensure that the clearance

is even and within

the target value of 0.004

in. (0.1mm). If the clearance

is beyond specification,

the wheel can be

rotated to minimize the

difference. If the clearance

is still out of specification,

check the hub for runout

to determine if the con-

dition is caused by the

wheel or the hub.

Both radial and lateral

runout can be checked.

Radial runout is the

change in the radius as



the assembly rotates. This can

be checked with a dial indicator

that is mounted to a stationary

position, parallel with the rotating

plane. Slowly rotate the tire/

wheel assembly while mounted

to the hub, through a complete

360 degree rotation.

Lateral runout is the side-toside

deviation of the rotating assembly.

Position the dial indicator

plunger at the wheel bead area

and slowly rotate the assembly

360 degrees.

The hub itself can be checked

Vertical runout


Radial runout (also called vertical

runout) can cause a wheel tramping

condition. Lateral runout can

cause a shimmying condition.

Radial runout


When checking wheel radial runout, the

dial indicator should be positioned vertically

onto a horizontal area of the rim. For

lateral runout, the indicator should contact

the wheel’s vertical surface, with

the indicator placed at 90 degrees to the

vertical wall of the rim.

19


The best method of determining a mounted tire’s radial force variation is to run the assembly on a balancing

machine that features a load-force road wheel. The example shown here is Hunter’s GSP9700.

for lateral runout using a dial

indicator.

The brake rotor can also be

checked for lateral runout. With

the rotor secured to the hub with

at least three wheel nuts, a dial

indicator can monitor the rotor

surface as the rotor is slowly

rotated 360 degrees.

NOTE: When checking rotor

runout, be sure to place the dial

indicator plunger approximately

10mm or so from the rotor edge,

to make sure that the indicator

contacts the area of the rotor that

is swept by the brake pads.

While performing an inspection,

the technician should be

aware that a variety of steering

and/or suspension components

may contribute to vibration or

shimmy complaints. Steering

system component checks should

include ball joint play, steering

linkage play or damage, steering

damper condition and condition

of rubber bushings. Suspension

system component checks should

include suspension arms and

bushings, springs, wheel bearing

adjustment/condition and shock

absorber condition.

Bear in mind that while irregular

tire wear may cause a vibration,

any irregular tire wear is the

result of another condition, such

as incorrect wheel alignment or

worn steering and/or suspension

components. ★


Spring 2008

STAR Service News

Issue # Months

25 Fall 1987

27 Spring 1988

28 Summer 1988

29 Fall 1988

30 Winter 1988

31 Spring 1989

32 Summer 1989

33 Fall 1989

34

35

36

38

42

43

45

48

49

60

71

Winter 1990

Spring 1990

Summer 1990

Winter 1991

Winter 1992

Spring 1992

Fall 1992

Summer 1993

Fall 1993

Summer 1996

Jul./Aug. 1998

Missed an issue? You’re in luck!

The following back issues of the Toyota STAR Service News are available

FREE in limited quantities. Use the form to request back issues.

Contents

Toyota Computer Controlled System

Emission Control Systems

Air Conditioning

Charging & Starting Systems

The Variable Venturi Carburetor

Toyota Publications Information — Repair Manuals, Collision Manuals, Diagnosis Manuals

The Fuel Systems

Suspension — Toyota Electronically Modulated Suspension (TEMS)/

1986 Celica Front Brake System

Special Service Tools for Toyota Vehicles/Toyota Engine & Transmission Applications Chart

(1981-1989)

Free Wheeling Hubs (1984-1988 4WD)/MR2 Cooling System (1985-1989)/

“Y” Series Engines (1984-1989 Van)

Security — Toyota Intrusion Monitoring System/Brakes — Toyota Anti-Lock Brake System (ABS)/

Engine (2S-E Engine)

2WD & 4WD Wheel Alignment (1984-1988 Pickup Truck)/Rust Repair

Body Repair — Outer Door Panel Replacement/Battery Testing for Winter

Camry Timing Belt Inspection & Installation/Four Ways to Control Idle Speed

1988 Camry Automatic Transaxle Description & Troubleshooting

1990 Truck Engine Cooling Systems/22R & 22R-E Engine

(4-Cyclinder)/3VZ-E Engine (6-Cyclinder)

Diagnosing & Troubleshooting the 1990 Camry Automatic Transmission

1993 Truck Air Conditioning System

Engine Short Block Service/Truck Suspension Basics/Automatic Transaxles


21

76

82

83

86

87

92

93

94

95

96

103

104

105

106

107

108

109

110

112

113

114

115

116

117

118

119

May/Jun. 1999

May/Jun. 2000


Jan./Feb. 2001

Mar./Apr. 2001

Jan./Feb. 2002

Mar./Apr. 2002

May/Jun. 2002


Sep./Oct. 2002

Winter 2004

Spring 2004

Summer 2004

Fall 2004

Winter 2005

Spring 2005

Summer 2005

Fall 2005

Spring 2006

Summer 2006

Fall 2006

Winter 2007

Spring 2007

Summer 2007

Fall 2007

Winter 2008

Cylinder Head Inspection & Service/A/C Diagnostic & Service Tips/

CV Shaft Service

Engine Timing Belt/Ride Control/Automatic Transmission Service

Engine Knock Sensors/Power Rack & Pinion Steering System Service/

Wheel Bearing Service

Wheel Alignment/Cylinder Head Service/Four-Wheel Disc Brake Service

A/C Service/Fuel Injector Service/Piston & Ring Service

OHC Service/Clutch System Service/Fuel Pump & Fuel Delivery

Distributorless Ignition Systems/Lighting Systems/Common Codes

Stabilizer Bars/Cooling System Service/Brake Pulsation

Noise, Vibration, Harshness/Front Suspension Lower Control Arm Service On FWD/Threaded

Fasteners

Crankshaft Bearing Service/Temperature Sensors/Strut & Shock Service

Wheel Alignment Basics/Automatic Transmission/Cooling System

Fuel Injectors/Wheel/Tire Vibration & Balancing/Towing & Trailering

Alloy Wheel Installation/Power Steering/Engine Short Block Service

MAP, Knock & TPS/Stabilizer Bars/Traction Control Systems

Truck Rear Axle Service/Temperature Sensors/Brake System Service

Crankshaft & Camshaft Position Sensors/Electronic Fuel Injection/DOHC Timing Belt Service

Cooling System Service/ABS Theory & Service/Cylinder Head Service

Connecting Rod Service/Toyota Tire Pressure Warning System/Airbag Service

Torque Converter Operation & Diagnosis/Wheel Alignment/Cooling System Service

Antilock Brake System/Fuel Injection System/Piston Ring Service

Cylinder Head Service/Understanding & Measuring Ride Height/Engine Immobiliser System

Brake System Service/Fuel System Service/Oxygen Sensor Tech

Vehicle Stability Control/A/C Service

Air Suspension/Run-flat Tires/Tundra SFI

Brake System Service/Toyota’s Hybrid Vehicle Continuously Variable Transmission/Power Steering Service

Tranaxle Service/Cylinder Head Gasket Service/hybrid Technology

I want the following FREE back issues of Toyota STAR

Service News (available while supplies last)


Spring 2008

SEQUOIA POWER STEERING RACK SERVICE

From fluid bleeding to reassembly

BLEEDING POWER

STEERING FLUID

Jack up the front of the vehicle

and support it with stands.

Check fluid level. With the engine

stopped, turn the steering wheel

slowly from lock to lock several

times.

Lower the vehicle and start the

engine, allowing the engine to

run at idle for several minutes.

With the engine idling, turn the

steering wheel left or right to the

full lock position and keep it there

for two to three seconds, then

turn the wheel to the opposite

full lock position and keep it there

for two to three seconds.

Repeat this procedure several

times. Stop the engine and

check fluid level and check for

fluid foaming or emulsification.

If the system must be bled twice

specifically because of foaming or

emulsification, check the system

for fluid leaks.

The 2005 Sequoia power steering

system requires the use of

ATF Dexron II or III. When the fluid

is hot, check that the fluid level

is within the HOT range on the

reservoir. If cold, check that fluid

level is within the COLD range.

HINT: Turn the steering wheel

from full lock to full lock several

times to boost fluid temperature

(with the engine idling). When

within the HOT range, fluid temperature

should be 176 degrees F

(80 degrees C).

With the engine idling, measure

the fluid level in the reservoir.

Stop the engine and wait a few

minutes and re-measure the fluid

level. The maximum fluid level

rise should be 0.20 in. (5mm). If a

problem is found, bleed air from

the power steering system again.

HOT and COLD fluid ranges are

marked on the power steering

fluid reservoir.

CHECKING POWER

STEERING FLUID

PRESSURE

Remove the air cleaner assembly

and disconnect the pressure

feed tube from the power

steering vane pump. Connect

SST 09640-10010 (09641-01010,

09641-01030, 09641001060).

Check that the valve of the SST

is in the open position. Bleed the

power steering system. Start the

engine and allow it to run at idle

speed. Turn the steering wheel

from lock to lock several times to

boost fluid temperature.

While the engine is idling, close

the valve of the SST and observe

the reading on the SST gauge.

Minimum fluid pressure should

be 1,209 psi (8,336 kPa). Do not

keep the valve closed for more



than 10 seconds, and do not allow

fluid temperature to become

too high.

With the engine idling, open

the valve fully and measure the

fluid pressure at engine speeds

of 1,000 rpm and 3,000 rpm. The

difference in fluid pressure should

be 71 psi (490 kPa) or less. NOTE:

Do not turn the steering wheel

during this check.

With the engine idling and the

SST valve fully open, now turn the

steering wheel left or right to the

full lock position. At this point,

minimum fluid pressure should

be 1,209 psi. Do not maintain the

full lock position for more than 10

seconds, and do not allow fluid

temperature to become too high.

SST

In Out

Attachment

Pressure feed tube

In order to measure power steering

fluid pressure, install the SST.

Make sure that the SST’s valve is

in the open position.

Stop the engine and remove

the SST. Connect the pressure

feed tube, reinstall the air cleaner

23


assembly and bleed the power

steering system.

TROUBLESHOOTING

SYMPTOM: HARD STEERING

SUSPECT: Tire inflation, power

steering fluid level, loose drive

belt, front wheel alignment, worn

steering system joints, worn suspension

arm ball joints, binding

steering column, power steering

vane pump, power steering gear.

SYMPTOM: POOR STEERING

RETURN

SUSPECT: Tire inflation, front

wheel alignment, binding steering

column, power steering gear.

SYMPTOM: EXCESSIVE PLAY

SUSPECT: Worn steering system

joints, worn suspension arm ball

joints, worn intermediate shaft

sliding yoke, worn front wheel

bearing(s), power steering gear.

SYMPTOM: ABNORMAL NOISE

SUSPECT: Low power steering

fluid level, worn steering system

joints, power steering vane pump,

power steering gear.

POWER STEERING GEAR

Remove the rack & pinion unit

following Toyota Service Manual

instructions.

In order to disassemble the rack

& pinion assembly, first remove

the two pressure tubes, using SST

09023-38401. Remove the four

O-rings from the tubes. Install SST

09512-00012, two bolts and nuts

to the rack housing, and secure

the SST to a vise. Avoid over-tightening

the SST to the rack housing.

Place matchmarks on the outer

Clamp plate

Cotter pin

Pressure feed tube

Grommet

The 2005 Sequoia features a power rack & pinion steering gear.

tie rod ends, lock nuts and rack

ends. This will allow re-assembly

without altering the existing tie

rod length (to avoid changing the

toe adjustment).

Loosen and lock nuts and

remove the tie rod ends and lock

nuts. Remove the rack boots and

boot clamps (use a screwdriver to

loosen the clamps). If you plan to

SST

Bracket

Disconnect the pressure tubes

from the rack housing and remove

the tube O-rings.

PS gear assembly

Return tube

SST

No. 2 intermediate

shaft assembly

Cotter pin

Bolt

Use the SST to secure the rack

unit to a vise.

re-use the boots, mark each for

RH and LH. Using a screwdriver

and a hammer, unstake the locking

washer at the inner tie rod

end-to-rack connection. NOTE:

Avoid any impact to the rack to

prevent rack damage.

Using an open end wrench,

hold the rack steady and remove

the inner tie rod from the rack


Spring 2008

O-ring

Clamp

Rack housing

Steering rack

Teflon ring

Power steering gear rack, housing and tie rods.

using SST 09922-10010. The inner

tie rod features right-hand

threads, so remove the inner tie

rod using a counterclockwise

rotation as shown in the illustration.

Mark the inner tie rods and

rack ends RH and LH, accordingly.

Remove the locking washers.

Rack boot

Cylinder end stopper

Wire

Oil seal

Clip

Claw washer

Oil seal

Lock nut

Bushing

Rack end

O-ring

Tie rod end

Using the same SST (09922-

10010), remove the housing lock

nut. Using a hex wrench, remove

the rack guide spring cap, and

remove the rack guide spring and

rack guide sub-assembly.

Remove the rack housing cap

using SST 09816-30010. Next, us-



ing SST 09616-0001 1 to hold the

control valve shaft steady, remove

the self-locking nut and remove

the dust cover.

Place matchmarks on the

control valve housing and rack

SST

Remove the rack guide spring cap

lock nut using SST 09922-10010.

SST

Use SST 09816-30010 to remove

the rack housing cap.

housing. Remove the two bolts

and the control valve housing,

with the control valve assembly

attached. Remove the gasket

from the rack housing.

Next, the control valve assembly

must be pressed out of its

housing. To prevent oil seal lip

damage, wrap vinyl tape around

the serrated area of the valve

shaft. Place a shop rag between

the valve housing and a pair of

resting blocks, and press the valve

assembly out of its housing.

Remove the oil seal and bearing

from the control valve housing

using SST 09950-60010 (09951-

00250), 09950-70010 (09951-

07150). Next, the rack’s cylinder

25

O-ring

Steering gear pinion assembly.

Matchmarks


Rack housing

Turn pressure tube

Turn pressure tube

O-ring

Gasket

Remove the control valve housing

(with control valve attached)

from the rack housing.

end stopper must be removed.

Using SST 09631-16010, turn the

stopper clockwise until the wire

end is visible through the service

Bearing

Dust cover

Oil seal

Bearing

Rack guide

sub-asembly

Self-locking nut

Rack housing cap

Vinyl tape

Shop rag

Oil seal

Bearing

Control valve

housing

Control valve assembly

Teflon ring

Rack guide spring

Cap lock nut

Rack guide

spring cap

Rack guide spring

Press the control valve assembly

from its housing. Protect the seal

lip by wrapping vinyl tape onto

the serrated section of the shaft,

and place a shop rag on the press

blocks.

hole. Next, turn the stopper counterclockwise

and remove the wire.

Using SST 09950-70010 (09951-

07200), press out the steering

rack with the bushing. Remove

the bushing and O-ring.

Using SST 09950-60010 (09951-

00360) and 09950-70010 (09951-

07360), press out the oil seal.

With the rack removed from the

SST

Cylinder end

stopper

Rotate the stopper clockwise until

the locking wire can be seen

through the service hole, then

rotate the stopper counterclockwise

and remove the wire.

SST

SST

Wire

Press out the

steering rack

and remove

the bushing

and O-ring.

Oil seal

Press out the oil seal using the

SSTs.

housing, place the rack on clean

V blocks. Using a dial indicator,

slowly rotate the rack and inspect

for runout. Maximum allowable

runout is 0.0035 in. (0.09mm).


Spring 2008

Also check the rack teeth and the

rack’s rear surface for wear and

damage.

REASSEMBLY

Coat a new control valve housing’s

oil seal lip with power steering

fluid. Using SST 09950-60010

(09951-00180, 09951-00320,

09952-06010), 09950-70010

(09951-07150), press the new seal

into position, being sure to orient

the seal correctly with the lip facing

out.

Coat the new bearing with molybdenum

disulfide lithium base

grease, and using SST 09950-

60010 (09951-00340), 09950-

70010 (09951-07150), press the

bearing into place in the control

valve housing.

If necessary, replace the two

bearings in the rack housing

(in the pinion gear path). Press

out the lower bearing using SST

09950-60010 (09951-00260),

09950-70010 (09950-07150). Press

out the upper bearing using the

same SST.

Coat new bearings with mo-

SST

Bearing

If pinion bearings must be replaced

in the rack housing, press out the

bottom bearing, followed by pressing

out the upper bearing.

lybdenum disulfide lithium base

grease and press into the rack

housing. Install the upper bear-

ing first, followed by the lower

bearing. Use SST 09950-60010

(09951-00310), 09950-70010

(09951-07150) to press the upper

bearing. Use SST 09950-60010

(09951-00320), 09950-70010

(09951-07150) to press the lower

bearing.

If necessary, replace the bushing’s

oil seal. Use SST 09527-2001 1, 09612-

24014 (09613-22011) to remove

the old seal. Coat the new seal

with power steering fluid, and

install the seal using SST 09950-

60010 (09951-00300, 09951-

00460, 09952-06010). Be sure to

install the oil seal in the correct

direction.

Using a screwdriver, remove the

Bushing

SST

Oil seal

Use the SST to remove the bushing’s

oil seal.

old Teflon ring and O-ring from

the rack’s center seal support. Be

careful to avoid nicking the Teflon

ring location’s groove. Coat a new

O-ring with power steering fluid

Remove the Teflon ring and the

O-ring from the rack, being careful

to avoid nicking the ring location’s

groove.


SST


and install the O-ring. Very carefully,

slightly expand a new Teflon

ring with your fingers.

Coat the new Teflon ring with

power steering fluid and install

the ring, using your fingers to

carefully settle the ring into place.

If necessary, replace the four

Teflon rings on the control valve

assembly (pinion gear assembly).

Use a screwdriver to remove the

old rings, being careful not to nick

the ring grooves.

Gently expand the new Teflon

rings with your fingers, coat them

with power steering fluid, and

install them into their grooves.

Settle the new rings with your

fingers.

Next, carefully slide the tapered

end of SST 09631-20081 over the

Teflon rings until they fit to the

control valve assembly.

SST

Teflon ring

After installing the new Teflon

rings to the control valve assembly

(and after settling the rings

with your finger), seat the rings

using the SST to obtain proper

ring seating.

Lubricate a new oil seal (for

the rack housing) and press the

seal into the rack housing using

SST 09950-60010 (09951-00330,

09951-00490, 09952-06010),

09950-70010 (09951-07360).

Make sure that the seal is oriented

properly.

Install the seal carefully, making

27


sure that it is not reversed during

installation. Make sure that the

rack is clean and free of burrs. If

necessary, scrape any burrs off

and burnish the rack. Install SST

09631-20051 to the rack. Coat the

SST with power steering fluid, and

install the rack into the rack housing,

being careful not to damage

the rack housing’s oil seal lip.

Remove the SST from the rack.

Coat a new O-ring with power

steering fluid and install the Oring

to the rack bushing. In order

to prevent oil seal lip damage,

first wrap the steering rack end

with vinyl tape and apply power

steering fluid. The bushing must

be installed with the O-ring facing

the rack housing. Install the

cylinder end stopper to the rack

housing.

Align the installation hole for

the stopper’s wire with the slot

in the rack housing. Install a new

wire into the stopper. Using SST

09631-16010, turn the stopper

clockwise 400 to 500 degrees

(about one and one-quarter turn).

SST

Oil seal

SST

Install a new oil seal inside the

rack housing.

AIR TIGHTNESS TEST

At this point, an air tightness

check should be performed to

verify performance of the oil

seals. Install SST 09631-12071 to

the rack housing, at the pressure

tube ports. Apply 15.75 in. Hg of

vacuum for about 30 seconds,

and check that there is no change

in vacuum. If a change is noted,

check the installation of the seals.

SST

Using the SST, perform a vacuum

check to verify seal performance.

INSTALL THE CONTROL

VALVE ASSEMBLY

Wrap vinyl tape on the serrated

area of the valve shaft to prevent

oil seal lip damage. Coat the

Teflon rings with power steering

fluid and carefully install the valve

assembly into the valve housing.

With the valve assembly installed,

coat a new oil seal lip with power

steering fluid and press the seal

into the housing using SST 09612-

2201 1. Make sure that the oil seal

is oriented correctly.

Place a new gasket onto the

rack housing and install the control

valve housing assembly to the

rack, aligning the matchmarks.

Tighten the two housing bolts to

a value of 13 ft-lbf (18 N-m).

To secure the control valve,

secure the control valve shaft

Vinyl tape

With the serrated section of the

control valve taped, install the

valve into the valve housing.

with SST 09616-0001 1 and install

a new nut, tightening the nut to a

value of 18 ft-lbf (25 N-m). Install

the dust cover.

Apply thread sealant (Loctite

242, Toyota Part No. 08833-00080

or equivalent) to two or three

threads of the rack housing cap

and install the cap using SST

09816-30010, tightening to a

value of 43 ft-lbf (59 N-m).

Using a punch and a hammer,

stake the two parts of the cap.

Install the rack guide sub-assembly

and rack guide spring. Apply

thread sealant (Loctite 242, Toyota

Part No. 08833-00080 or equivalent)

to two or three threads of the

rack guide spring cap, and temporarily

install the cap.

At this point, total preload must

be adjusted. Temporarily install

the RH and LH rack ends (to prevent

the rack teeth from damaging

the oil seal lip). Using a hex

wrench, tighten the spring cap to

a value of 18 ft-lbf (25 N-m). Next,

turn the rack guide spring cap 12

degrees.

Using SST 09616-0001 1, turn

the control valve shaft right and

left one or two turns. Carefully

loosen the rack guide spring cap

until the rack guide spring cap

is not applying any force. Next,

using the same SST, a beam-type

torque wrench and a hex wrench,

SST

While holding the control valve

shaft steady with the SST, tighten

the shaft nut to 18 ft-lbf.


Spring 2008

tighten the rack guide spring cap

until the preload is within specification.

Preload turning force

should be within 10.4 to 13.9 in.lbf

(1.2 to 1.6 N-m).

SST

Rack guide

spring cap lock nut

Fulcrum

length

When tightening the rack guide

spring cap lock nut, use the SST,

attached to a torque wrench that

features a fulcrum length of 13.58

in. (345 mm).

Next, install the rack guide

spring cap locking nut. Apply

thread sealant to two or three

threads of the nut and hand-install

the nut. Next, using a torque

wrench attached to SST 09922-

10010, tighten the nut to a value

of 32 ft-lbf (44 N-m), while holding

the rack guide spring cap with

a hex wrench.

NOTE: Use a torque wrench

that features a fulcrum length of

13.58 in. (345 mm). At this point,

it’s a good idea to re-check total

preload. Verify that the control

valve shaft will rotate using 10.4

to 13.9 in.-lbf.

Remove the RH and LH rack

ends. Install the RH and LH claw

washers and rack ends. Align the

Claw

The rack end claw washers must

be positioned to allow the claws to

align to the grooves on the rack.

claws of the claw washers to the

steering rack grooves.

Using an open-end wrench,

hold the steering rack steady

while tightening the rack end to

a value of 56 ft-lbf (76 N-m), using

SST 09922-10010 and a torque

wrench with a fulcrum length of

13.58 in. Using a brass bar and

hammer, stake the claw washer.

Check to make sure that the

small bleed hole in the rack is not

clogged with grease (if this hole

is clogged, the pressure inside

the rack boot will change when

the steering wheel is turned). At

this point, the rack boots may be

installed. Carefully install the rack

boots. Be careful to avoid twisting

the boots. Using SST 09521-24010,

tighten the inboard boot clamp,

crimping the clamp’s adjuster

head to a width of 0.12 in. (3mm)

or less. Install the outboard boot

clips to both boots.

SST

Fulcrum length

While holding the rack steady,

use the SST with torque wrench

attached to tighten the inner tie

rod ends to 56 ft-lbf.

Brass bar

Remember to stake the inner tie

rod claw washers. Use a brass

bar to avoid damage.



The outer tie rod ends may now

be installed. Thread each nut into

position until the matchmarks

are aligned. After adjusting toe-in

during wheel alignment, remember

to tighten the lock nuts to a

value of 41 ft-lbf (55 N-m).

SST

Use the SST to tighten the inboard

boot clamps.

INSTALL THE PRESSURE

TUBES

Coat four new O-rings with

power steering fluid and install

them onto the pressure tubes. Using

SST tube nut adapter 09023-

38401 and a torque wrench that

features a fulcrum length of 9.84

in. (250mm), tighten the tube

nuts to a value of 10 ft-lbf (13

N-m). NOTE: the SST must be attached

to the torque wrench so

that the SST is positioned parallel

to the beam of the torque

wrench. If the SST is mounted at

an angle relative to the torque

wrench, an inaccurate torque

value will be obtained. ★

Fulcrum

length

SST

3 mm

(0.12 in.)

or less

Make sure that the SST tube nut

adapter is mounted parallel to

the beam of the torque wrench.

29

TOYOTA TOPICS

Toyota NASCAR update:

What a difference a year makes

TRD, U.S.A. surpasses 2007 efforts

thanks to new partnership with

premier racing team and

continued commitment of

resources to all teams

By Chris Brown

Motor Trend named the Toyota Camry

Car of the Year for 2007. The judges

couldn’t have been watching Camry’s

inaugural performance in NASCAR.

After establishing dominance in

NASCAR’s Craftsman Truck Series in

three short years, Toyota’s first foray into

NASCAR Sprint Cup and Nationwide

Series racing may be described as “a

learning year” at best.

There was promise, highlighted by two

Nationwide Series wins and Brian Vickers’

five top-10 finishes for Red Bull Racing

Team. However, “The first year was incredibly

stressful,” says Les Unger, Toyota

Motor Sales U.S.A. national motorsports

manager. “We had two brand new teams,

new drivers, two new sets of cars and we

had to race our way in.”

In 2007 Toyota was not only supporting

a brand new startup in Red Bull

Racing Team, it was playing catch-up with

NASCAR’s transition to the “Car of Tomorrow”

(COT). While established teams had

already built a stable of COTs, Red Bull

Racing Team, Michael Waltrip Racing

and Bill Davis Racing were scrambling

to engineer, build and test the new style

while figuring out the standard model on

the track.

“That’s brutal, and our teams are the

only ones that had to go through that,”

Unger says.

On top of that, under NASCAR rules

drivers out of the top 35 in owner points

have to qualify, which meant Toyota

drivers were often competing with each

other for the same spots.

What a difference a year makes

The “Car of Tomorrow” is now the “Car

of Today.” Young Toyota drivers A.J. All-

mendinger and David Reutimann gained

valuable seat time. And the manufacturer

landed a very high-profile team in Joe

Gibbs Racing (JGR).

JGR’s transition from Chevy gave

Toyota instant marquee value in two-time

NASCAR Cup champion Tony Stewart and

2006 “Rookie of the Year” Denny Hamlin.

Kyle Busch, the fifth-place points finisher

in the 2007 Cup driver standings, joined

the team from Hendrick Motorsports.

J.J. Yeley of Hall of Fame Racing, a JGR

partner, also gets a seat in a Camry.

JGR’s record speaks for itself: In its 17th

year of Cup competition, JGR has 61 wins

in 997 starts to date. Gibbs won championships

in 2000 with Bobby Labonte and

in 2002 and 2005 with Stewart.

The dividends are paying off in short

order.

In only nine NASCAR Sprint (formerly

NEXTEL) Cup Series races this year, JGR

has already scored three wins. Kyle Busch

elevated Toyota to “victory lane” for the

first time in Atlanta and again in Talladega.

Hamlin won in Martinsville.

In the Nationwide (formerly Busch)

Series, JGR has hoisted six trophies, three

apiece for Stewart and Busch.

The trickle down theory

This whole success thing has been rubbing

off on Toyota’s other teams.

Brian Vickers has already tied his best

finish in a Camry with a fifth-place finish

at Talladega, along with two top-10 Cup

finishes. A total of six Camry drivers led

at least one lap during the race. Michael

Waltrip led four laps at Talladega, leading

on the final restart with five laps to go.

According to Unger, that’s part of the

plan. “TRD engineers and technical staff

don’t withhold information from Toyota

teams, nor do they favor one team with

special engines and support,” Unger says.

This level of sharing has been part of the

TRD mantra since its days in open-wheel

racing, though, “It’s a bit unusual from

a manufacturer’s perspective,” Unger

admits.

When Toyota and Joe Gibbs Racing

first solidified the deal, JGR and its team

of 400 racing professionals vowed from

the outset to help the other Toyota teams

develop and grow.

“The partnership between Toyota

and JGR has raised the tide for our three

original teams,” Unger states. “In addition

to having an incredible organization,

Gibbs has committed to assisting Toyota

and the other teams any way they can,

which is almost unheard of in professional

sports.”

Hamlin at Martinsville

Denny Hamlin of Joe

Gibbs Racing won in

Martinsville on March 30.

Les Unger

Les Unger talks with Dave Blaney,

A.J. Allmendinger and J.J. Yeley

during Toyota Motorsports Day at

Toyota Motor Sales, U.S.A., Inc.


Spring 2008

The learning curve

The Joe Gibbs Racing transition to

Toyota has been less about learning a

new set of wheels and more about solidifying

a business partnership in terms of

personnel and resources.

For the fan in the stands, the only

way to tell a Toyota Camry from a Chevy

Impala is the front grille, hood and headlamps

in the mold of their production

brethren, though even the headlamps are

only decals.

No wonder the Motor Trend judges

weren’t paying attention.

Under the hood, NASCAR mandates

the exact engine size, allowable horsepower,

top speed, ground clearance,

fuel tank size, curb weight, tire size

and almost every other

dimension. The rules limit

the amount of aerodynamic assist and

require that the racecar body conform to

a set of surface templates.

And with the new style of car, the tolerances

are mandated to be even tighter,

Unger explains.

That means TRD, and all other Cup car

manufacturers, must simply conduct

their engineering efforts within a very

tight box. And that’s one area where Joe

Gibbs Racing’s engineers’ experience and

expertise is greatly benefitial to Toyota.

The relationship is mutual. “TRD works

very closely with the Gibbs engine shop

to make sure they — and all the other

teams — offer the very best that TRD has

to offer,” Unger says.

Toyota supplies completed engines to

Red Bull Racing Team and Michael Waltrip

Racing. Bill Davis Racing and Joe Gibbs


TOYOTA TOPICS

Racing build their own engines, while

TRD provides some basic components.

Both veteran teams do a lot of research

and development on their own.

JGR had already built its initial supply

of the new style cars.

To further support its teams, Toyota

is building a new technical engineering

facility on 60 acres in Rowan County,

N.C., the heart of NASCAR country. While

TRD will maintain its Costa Mesa, Calif.,

location, the new facility will serve as

a hub for its aerodynamics and chassis

engineers.

TRD worked diligently to provide JGR

with the resources befitting a top-caliber

team. “Very frankly, we didn’t want any

fall-off from what they were used to on

the Chevy side,” Unger says.

So far, so good. ★

Busch at Talladega

Kyle Busch bows to the crowd at Talladega

Superspeedway after his second Sprint Cup

victory of the year on April 27. It was the third

Cup win for Toyota this season. “This Toyota

Camry was just awesome — I had a blast,”

said Busch following the race.

31

Alabama

Hoover Toyota

Hoover AL

205-978-2600; 800-292-4329

Limbaugh Toyota Inc.

Birmingham AL

205-780-0500; 800-239-5050

Palmer’s Airport Toyota

Mobile AL

251-639-0800; 800-874-2777

Reinhardt Motors Inc.

Montgomery AL

334-272-7147; 800-264-8019

Serra Toyota Inc.

Birmingham AL

205-838-4400; 800-476-6100

Springhill Toyota

Mobile AL

251-479-9581

Sunny King Toyota

Anniston AL

256-835-0800; 800-762-2380

Arizona

Alexander Toyota

Yuma AZ

928-344-1170

Camelback Toyota

Phoenix AZ

602-264-2841; 800-529-6051

Desert Toyota

Tucson AZ

520-886-3041

Earnhardt Toyota

Mesa AZ

480-807-2696; 800-446-7193

Larry Miller Toyota

Peoria AZ

623-876-3500

Precision Toyota of Tucson

Tucson AZ

520-795-5565; 800-876-9682

Right Toyota

Scottsdale AZ

480-778-2200

Sierra Toyota

Sierra Vista AZ

520-458-8880

Arkansas

Landers Toyota

Little Rock AR

501-568-5800; 877-668-1599

STAR dealer listings

Where is a STAR dealer?

STAR (Support to Automotive Repair) is a special Toyota support program offered by a select group of Toyota dealers, recognized

by Toyota as having made an extraordinary commitment to serving the special needs of independent repair and body shops.

From extra parts inventory and special local or WATS telephone lines to specially trained counter people backed by outstanding

delivery services, Toyota STAR dealers are a unique group of parts wholesale specialists who offer support, services and benefits

not usually found at the typical dealership.

North Point Toyota

North Little Rock AR

501-753-0400

California

Antioch Toyota

Antioch CA

925-778-0331; 800-778-4888

Cabe Toyota

Long Beach CA

562-595-7411; 800-576-2223 x250

Capitol Toyota

San Jose CA

408-267-0500

Carson Toyota

Carson CA

310-549-3131; 800-549-2929

City Toyota

Daly City CA

650-755-5500

Claremont Toyota

Claremont CA

909-625-1500

Concord Toyota

Concord CA

925-682-7131

DCH Toyota of Oxnard

Oxnard CA

805-988-7900; 800-229-6988

DCH Toyota of Simi Valley

Simi Valley CA

805-526-7500

Downtown Toyota

Oakland CA

510-547-4436

Dublin Toyota

Dublin CA

925-829-7700

Elk Grove Toyota

Elk Grove CA

916-405-8000

Elmore Toyota

Westminster CA

714-894-3322

Fairfield Toyota

Fairfield CA

707-402-3100

Folsom Lake Toyota

Folsom CA

916-355-1500; 800-544-1680

Frank Toyota

National City CA

619-474-5573; 800-237-7273

Freeman Toyota

Santa Rosa CA

707-542-1791; 800-862-4627

Fremont Toyota

Fremont CA

510-252-5100; 800-938-6968

Frontier Toyota

Valencia CA

661-255-7575

Gilroy Toyota

Gilroy CA

408-848-8000; 800-727-1878

Hamer Toyota

Mission Hills CA

818-365-9621; 800-762-2122

Hanlees Hilltop Toyota

Richmond CA

510-243-2020

Hansel Toyota

Petaluma CA

707-769-2333

Hayward Toyota

Hayward CA

510-889-8000

I-10 Toyota

Indio CA

760-772-3300

John Elway’s Crown Toyota

Ontario CA

909-390-9700

Kearny Mesa Toyota

San Diego CA

858-279-8151; 800-287-8157

Keyes Toyota

Van Nuys CA

818-782-0122

Lithia Toyota of Redding

Redding CA

530-722-3850

Lithia Toyota of Vacaville

Vacaville CA

707-446-7000

Longo Toyota

El Monte CA

626-580-6000

Magnussen’s Auburn Toyota

Auburn CA

530-885-8484

Magnussen’s Toyota of Palo Alto

Palo Alto CA

650-494-2100; 800-394-8080

Maita’s Toyota of Sacramento

Sacramento CA

916-481-0855; 800-640-6248

Manhattan Beach Toyota

Manhattan Beach CA

310-546-4848

Marina del Rey Toyota

Marina del Rey CA

310-821-8979

Melody Toyota

San Bruno CA

650-635-1000

Merced Toyota

Merced CA

209-725-9000

Miller Toyota

Culver City CA

310-559-3777

Miller Toyota of Anaheim

Anaheim CA

714-879-6300; 800-995-0334

Modesto Toyota World

Modesto CA

209-529-2933; 800-554-3284

Moss Brothers Toyota

Moreno Valley CA

951-247-8000

Mossy Toyota

San Diego CA

858-581-4000

Northridge Toyota

Northridge CA

818-734-5600; 877-972-7870

Norwalk Toyota

Norwalk CA

562-868-0035; 800-378-7713

Piercey Toyota

San Jose CA

408-436-8890

Power Toyota Cerritos

Cerritos CA

562-860-6561

Puente Hills Toyota

City of Industry CA

626-964-7100; 800-942-9997

Putnam Toyota

Burlingame CA

650-340-6900; 800-978-8626


Spring 2008

Quality Toyota

Corona CA

951-734-6020

Roseville Toyota

Roseville CA

916-782-2163

San Francisco Toyota

San Francisco CA

415-750-8300; 800-738-6968

Sierra Toyota

Lancaster CA

661-948-0731

South Bay Toyota

Gardena CA

310-323-7800; 800-750-9780

South Coast Toyota

Costa Mesa CA

949-722-2000

Stevens Creek Toyota

San Jose CA

408-984-1234

Thousand Oaks Toyota

Thousand Oaks CA

818-889-8919

Torrance Toyota

Torrance CA

310-325-7500; 800-325-7508

Toyota 101

Redwood City CA

650-365-5000

Toyota Carlsbad

Carlsbad CA

760-438-2000

Toyota Marin

San Rafael CA

415-457-4156

Toyota of Alameda

Alameda CA

510-522-6400; 800-986-9727

Toyota of El Cajon

El Cajon CA

619-440-0225

Toyota of Escondido

Escondido CA

760-746-0601; 800-552-6609

Toyota of Glendale

Glendale CA

323-461-7228; 800-954-5245

Toyota of Glendora

Glendora CA

909-305-2000; 800-986-9682

Toyota of Hollywood

Los Angeles CA

323-467-6161

Toyota of Huntington Beach

Huntington Beach CA

714-847-8555

Toyota of North Hollywood

North Hollywood CA

818-508-2900; 800-766-8836

Toyota of Orange Inc.

Orange CA

714-639-6750; 800-498-3424

Toyota of Redlands

Redlands CA

909-793-0300

Toyota of Riverside

Riverside CA

951-687-1622

Toyota of San Bernardino

San Bernardino CA

909-381-4444

Toyota of Santa Barbara

Goleta CA

805-967-5611

Toyota of Santa Maria

Santa Maria CA

805-928-3881

Toyota of the Desert

Cathedral City CA

760-328-0871; 800-479-5744

Toyota of Vallejo

Vallejo CA

707-552-4545; 800-537-5151

Toyota of Walnut Creek

Walnut Creek CA

925-933-7440

Toyota Place

Garden Grove CA

714-895-5595; 800-896-8244

Toyota Santa Monica

Santa Monica CA

310-394-6744

Toyota Sunnyvale

Sunnyvale CA

408-245-6640; 800-TOYOTA-9

Toyota Town

Stockton CA

209-473-2513

Tracy Toyota

Tracy CA

209-834-1111

Tustin Toyota

Tustin CA

714-832-3111

Valley-Hi Toyota-Honda

Victorville CA

760-241-6484

Victory Toyota

Seaside CA

831-393-3020; 800-861-6848

West Covina Toyota

West Covina CA

626-859-7400

Wondries Toyota

Alhambra CA

626-289-8000

Yuba City Toyota/Lincoln-Mercury

Yuba City CA

530-673-5661

Colorado

Boulder Toyota-Scion

Boulder CO

303-443-3250

Burt Toyota Scion Inc.

Englewood CO

303-761-3222; 800-525-8403

Ehrlich Toyota & Scion

Greeley CO

970-339-3900; 877-894-5424

Go Toyota-Scion Arapahoe

Englewood CO

303-792-2000; 800-477-1145

Liberty Toyota-Scion

Colorado Springs CO

719-598-2222; 800-289-0401

Mountain States Toyota/Scion

Denver CO

303-302-8888

Pedersen Toyota-Scion-Volvo

Fort Collins CO

970-223-3100; 800-800-0788

Pueblo Toyota

Pueblo CO

719-543-1719

Stevinson Toyota East & Scion

Aurora CO

303-340-2170; 800-332-5877

Stevinson Toyota West & Scion

Lakewood CO

303-277-0550; 800-525-8858

Western Slope Auto Co.

Grand Junction CO

970-243-0843; 800-525-7072

Connecticut

A-1 Toyota

New Haven CT

203-389-1521; 800-428-8678

Colonial Toyota

Milford CT

203-878-7401

Greentree Toyota

Brookfield CT

203-730-4040

Hartford Toyota

Hartford CT

860-278-5411

Hoffman Toyota

Simsbury CT

860-651-3393

Lynch Toyota

Manchester CT

860-646-4321



Middletown Toyota

Middletown CT

860-347-7294; 800-972-1067

Stephen Toyota

Bristol CT

860-589-6211

Toyota of Stamford

Stamford CT

203-348-3751

Delaware

Newark Toyota World-Scion

Newark DE

302-368-6262; 800-537-4510

Florida

Arlington Toyota Inc.

Jacksonville FL

904-721-3000; 877-301-6734

Armstrong Toyota/Homestead

Homestead FL

305-248-6330; 888-967-8772

Autoway Toyota

Pinellas Park FL

727-577-1231; 800-832-8680

Bev Smith Toyota

Fort Pierce FL

772-464-8440; 800-432-7369

Bob Tyler Toyota

Pensacola FL

850-478-9999; 800-946-9904

Central Florida Toyota

Orlando FL

407-846-1600; 800-432-8090

Courtesy Toyota

Tampa FL

813-621-7747; 800-444-4983

Courtesy Toyota

Winter Park FL

407-678-1234; 800-942-7926

David Maus Toyota

Sanford FL

407-302-8800; 800-864-8023

Daytona Toyota

Daytona Beach FL

386-255-7475

Deland Toyota

Deland FL

386-734-2184

Earl Stewart Toyota

of North Palm Beach

Lake Park FL

561-844-3461

Ed Morse Delray Toyota

Delray Beach FL

561-276-5000; 800-940-0390

Ernie Palmer Toyota


904-389-4561; 800-869-7278

33

Germain Toyota of Naples

Naples FL

239-592-5550; 877-GO-GERMAIN

Gettel Toyota

Bradenton FL

941-756-5511;

800-282-3964 (FL only)

Headquarter Toyota

Hialeah FL

305-364-9800; 800-779-8696

Keith Pierson Toyota


904-771-9100; 800-777-0976

Kendall Toyota Service Center

Miami FL

786-573-5900

King Toyota

Deerfield Beach FL

954-421-4000

Legacy Toyota

Tallahassee FL

850-251-2720; 800-383-0619

Lehman Toyota

Miami FL

305-652-6500

Maroone Toyota

Davie FL

954-659-1800; 800-503-6988

Palm Toyota

Punta Gorda FL

941-639-1155

Palm Beach Toyota

West Palm Beach FL

561-712-2700; 800-423-7710

Stadium Toyota Inc.

Tampa FL

813-872-4881; 800-858-2387

Toyota of Hollywood

Hollywood FL

954-966-2150

Toyota of Melbourne

Melbourne FL

321-254-8888

Toyota of Orlando

Orlando FL

407-298-4500; 800-842-4699

Georgia

Atlanta Toyota

Duluth GA

770-476-8282; 800-334-5149

Butler Toyota

Macon GA

478-784-0600; 800-858-7240

Cobb County Toyota

Kennesaw GA

770-422-8555; 800-238-6968

Conyers Toyota

Conyers GA

770-922-5500


Hank Aaron Toyota

McDonough GA

770-288-3766; 800-940-3766

Heyward Allen Toyota

Athens GA

706-549-7002; 800-260-0228

Jay Toyota

Columbus GA

706-322-8891; 800-367-4760

LaGrange Toyota

LaGrange GA

706-882-2963; 800-882-2963

Lowe Toyota/Warner Robins

Warner Robins GA

478-929-7900

Nalley Toyota of Roswell

Roswell GA

770-594-8696; 888-594-8696

Sandy Springs Toyota

Atlanta GA

404-256-3392

Savannah Toyota

Savannah GA

912-927-1234; 800-633-8805

Stone Mountain Toyota

Stone Mountain GA

770-736-0030; 800-210-9391

Team Toyota

Lithia Springs GA

770-941-1200

Toyota Mall of Georgia

Buford GA

678-546-1212

Toyota South

Morrow GA

770-961-0225; 800-24-LEXUS

Idaho

Parker Toyota Inc.

Coeur D’Alene ID

208-765-8228; 800-733-8170

Peterson Toyota

Boise ID

208-378-9000; 800-584-7751

Illinois

Anderson Toyota

Rockford IL

815-397-8995

Arlington Toyota

Buffalo Grove IL

847-394-5100; 800-426-1854

Chicago Northside Toyota

Chicago IL

773-728-5000

Elmhurst Toyota

Elmhurst IL

630-279-2160; 800-266-3000

Grossinger Toyota North

Lincolnwood IL

847-675-7100

Libertyville Toyota

Libertyville IL

847-362-1500; 888-771-9997

Oakbrook Toyota in Westmont

Westmont IL

630-789-9600

Orland Toyota

Tinley Park IL

708-429-3900; 800-755-3987

Peoria Toyota

Peoria IL

309-693-7000; 800-949-6351

Schaumburg Toyota

Schaumburg IL

847-882-1800; 800-882-7228

Toyota of Naperville

Naperville IL

630-357-1578

Toyota on Western

Chicago IL

773-776-4016

Indiana

Beck Toyota

Indianapolis IN

317-882-2600; 800-541-7635

Evans Toyota

Ft. Wayne IN

260-482-3730; 800-218-1046

Richmond Toyota

Richmond IN

765-935-8057; 888-820-4569

Iowa

Dan Deery Toyota

Waterloo IA

319-233-5000; 800-383-4348

Toyota of Des Moines

Des Moines IA

515-276-4911; 800-342-7045

Wilson Toyota

Ames IA

515-232-4081; 800-232-4081

Kansas

Lewis Toyota

Topeka KS

785-273-2220

Olathe Toyota

Olathe KS

913-780-9919

Superior Toyota

Merriam KS

913-831-0800; 800-798-8267

Kentucky

Green’s Toyota of Lexington

Lexington KY

859-254-5751

Kerry Toyota

Florence KY

859-371-3939

Mike Smith Toyota

Paducah KY

270-415-0474; 866-423-0474

Oxmoor Toyota

Louisville KY

502-426-1200; 800-880-3381

Toyota of Louisville

Louisville KY

502-935-1433

Toyota on Nicholasville

Nicholasville KY

859-887-4200

Toyota South Inc

Richmond KY

859-624-1313; 800-688-6968

Louisiana

All Star Toyota/Baton Rouge

Baton Rouge LA

225-925-2525; 800-225-2769

Courvelle Toyota

Opelousas LA

337-948-8255

Greg LeBlanc Toyota

Houma LA

985-876-7210; 800-764-6422

Hampton Toyota

Lafayette LA

337-984-5010; 800-633-5010

John Harvey Toyota

Bossier City LA

318-741-1337

Lakeside Toyota

Metairie LA

504-833-3311; 800-833-2128

Northshore Toyota

Covington LA

985-893-7778

Price LeBlanc Toyota


225-408-1100; 800-960-1157

Ray Brandt Toyota

Kenner LA

504-464-4500



225-273-5880; 800-696-5895

Toyota of New Orleans

New Orleans LA

504-940-0000; 800-980-6252

Toyota of Slidell

Slidell LA

985-643-0005; 800-521-8101

Yokem Toyota

Shreveport LA

318-798-3773; 800-456-0501

Maine

Charlie’s Toyota

Augusta ME

207-622-4748


Spring 2008

Down East Toyota

Brewer ME

207-989-6400; 800-869-6827

Maine Mall Toyota

Portland ME

207-321-3477

Prime Toyota

Saco ME

207-282-6161

Maryland

355 Toyota

Rockville MD

301-340-0900

Beltway Toyota

Marlow Heights MD

301-899-6000; 800-543-7093

DarCars Toyota

Silver Spring MD

301-622-0300; 800-298-6900

Fitzgerald’s Lakeforest Toyota

Gaithersburg MD

301-921-0300

Jerry’s Toyota

Baltimore MD

410-661-4610; 800-492-1981

Jim Coleman Toyota Inc.

Bethesda MD

301-469-7100

Koons Toyota

Annapolis MD

410-268-6480; 800-262-3330

R&H Toyota

Owings Mills MD

410-363-2000

Russel Toyota

Baltimore MD

410-788-8400; 800-638-8401

Toyota of Glen Burnie

Glen Burnie MD

410-761-9000; 800-848-4451

Toyota of Waldorf

Waldorf MD

301-843-3700; 800-243-3949

Massachusetts

Acton Toyota

Acton MA

978-263-1500

Balise Toyota

West Springfield MA

413-734-8795

Bernardi Toyota

Framingham MA

508-879-1520; 800-248-3035

Boch Toyota Inc.

Norwood MA

781-769-8100; 800-532-9622

Boch Toyota South

North Attleboro MA

508-699-7551

Copeland Toyota

Brockton MA

508-584-2440

Expressway Toyota

Dorchester MA

617-265-4321

Falmouth Toyota Inc.

Bourne MA

508-759-1900; 800-442-1330

Harr Toyota Inc.

Worcester MA

508-852-5511

Herb Chambers Mid-State Toyota

Auburn MA

508-832-8000; 800-767-1898

Ira Toyota

Danvers MA

978-777-2330; 800-774-8411

Ira Toyota II

Tewksbury MA

978-863-9009

Ira Toyota III

Milford MA

508-478-0500; 800-698-5711

Jaffarian Volvo Toyota

Haverhill MA

978-372-8551

Lexington Toyota

Lexington MA

781-861-7400

800-521-3101 (local)

McGee Toyota

Hanover MA

781-826-8333; 800-642-3000

Norm Wagner Toyota

Lancaster MA

978-342-1330

Prime Toyota - Boston

Boston MA

617-469-1024; 800-354-5100

Route 44 Toyota

Raynham MA

508-824-4044; 877-ROUTE-44

Sullivan Brothers Toyota

Kingston MA

781-585-1300

Toyota of Dartmouth

North Dartmouth MA

508-993-2616

Toyota of Watertown

Watertown MA

617-926-5200

Toyota of Wellesley

Wellesley MA

781-237-2970; 800-734-0006

Toyota of Weymouth

North Weymouth MA

781-337-2000; 800-371-2001

Tri-State Toyota

Dudley MA

508-943-7474; 800-339-2321

Woburn Toyota

Woburn MA

781-933-1100;

800-624-8000 (MA only)

Michigan

Crown Toyota

Holland MI

616-393-0400

Dunning Toyota Ann Arbor

Ann Arbor MI

734-997-7600

Grand Blanc Motor Cars

Grand Blanc MI

810-579-2107; 800-968-6968

LaFontaine Toyota

Dearborn MI

313-561-6600; 800-989-2886

Metro Toyota

Kalamazoo MI

269-375-1000

Page Toyota

Southfield MI

248-352-8580; 800-325-8578

Spartan Toyota

Lansing MI

517-394-6000; 800-998-7557

Suburban Toyota-Volvo

Troy MI

248-643-8500; 800-875-3300

Toyota of Grand Rapids

Grand Rapids MI

616-942-5290; 800-354-7037

Minnesota

Burnsville Toyota

Burnsville MN

952-435-8200; 800-448-5912

Maplewood Toyota

Maplewood MN

651-482-1322; 877-574-0667

Rudy Luther Toyota

Golden Valley MN

763-544-1313; 800-742-5690

Toyota City

Brooklyn Park MN

763-566-0060

Walser Toyota

Bloomington MN

952-888-5581


Mississippi

Carlock Toyota of Tupelo

Tupelo MS

662-842-6428

Gray-Daniels Toyota

Brandon MS

601-948-0576; 800-530-7955


Herrin-Gear Toyota

Jackson MS

601-956-9696; 800-748-9921

Missouri

Adams Toyota Lee’s Summit

Lee’s Summit MO

816-358-7600; 800-800-7291

Jay Wolfe Toyota of West County

Ballwin MO

636-207-3900; 800-603-2146

Jerry Ackerman Toyota

St. Louis MO

314-351-3000; 800-871-3433

John Weiss Toyota of South County

St. Louis MO

314-849-3700; 800-221-4021

Nevada

Desert Toyota of Las Vegas

Las Vegas NV

702-871-4111

Findlay Toyota & Scion

Henderson NV

702-566-2000

Fletcher Jones Toyota/Scion

Las Vegas NV

702-457-2000

New Hampshire

Grappone Toyota

Concord NH

603-224-9912

Ira Toyota of Manchester

Manchester NH

603-624-1800

Rockingham Toyota

Salem NH

603-893-3525

Toyota of Nashua

Nashua NH

603-888-3555; 800-231-0688

Toyota of Portsmouth

Portsmouth NH

603-431-6100; 888-888-9070

New Jersey

Autoland Toyota

Springfield NJ

973-467-6137; 800-752-0086

Crestmont Toyota

Pompton Plains NJ

973-839-2500; 800-839-6444

Dayton Toyota

Dayton NJ

732-329-9191

DCH Brunswick Toyota

North Brunswick NJ

732-418-8888; 800-368-0097

DCH Freehold Toyota

Freehold NJ

732-431-1300; 800-221-0032

35

East Coast Toyota

Wood Ridge NJ

201-939-9400

Gateway Toyota

Toms River NJ

732-240-2000

Glen Motors Inc.

Fairlawn NJ

201-791-3800; 800-444-1959

Hudson Toyota

Jersey City NJ

201-433-0009; 800-342-3300

James Toyota

Flemington NJ

908-788-5700

Lawrence Toyota

Lawrenceville NJ

609-883-4200

Liberty Toyota

Burlington NJ

609-386-6300

Parkway Toyota

Englewood Cliffs NJ

201-944-3300

Prestige Toyota

Ramsey NJ

201-825-2700


Avenel NJ

732-815-2324; 800-545-5850


Hillside NJ

973-705-9400

Shore Toyota

Mays Landing NJ

609-645-2770

Toyota of Hackensack

Hackensack NJ

201-488-7777

Toyota of Morristown

Morristown NJ

973-540-1111; 800-541-1127

Toyota of Turnersville

Turnersville NJ

856-728-5000

Toyota of Vineland

Vineland NJ

856-696-5900; 800-566-3225

Toyota World of Lakewood

Lakewood NJ

732-364-9000

New Mexico

Beaver Toyota

Santa Fe NM

505-992-1535; 866-845-1799

Karl Malone Toyota

Albuquerque NM

505-294-8800; 800-444-6702


New York

Advantage Toyota

Lynbrook NY

516-887-8600

Bay Ridge Toyota

Brooklyn NY

718-439-7888

City World Toyota

Bronx NY

718-655-1800

Fordham Toyota

Bronx NY

718-367-0400; 866-932-2111

Fucillo Toyota

Grand Island NY

716-773-7505

Huntington Toyota

Huntington Station NY

631-423-6644

Interstate Toyota

Monsey NY

845-352-6200; 800-942-6449

Jack Sherman Toyota

Binghamton NY

607-724-1334; 800-572-4561

Johnstons Toyota

New Hampton NY

845-374-8600

Lee’s Toyota

Jamaica NY

718-657-2220

Lia Toyota of Colonie

Schenectady NY

518-374-3700

Northtown Toyota

Amherst NY

716-836-4600

Northway Motor Car

Latham NY

518-783-1951

Penn Toyota

Greenvale NY

516-621-8600; 866-5-TOYOTA

Plaza Toyota

Brooklyn NY

718-253-8400

Queensboro Toyota

Woodside NY

718-335-8600

Rockland Toyota

Blauvelt NY

845-358-2220; 800-844-9976

Romano Toyota

East Syracuse NY

315-445-1071

Smithtown Toyota

Smithtown NY

631-724-3300

Star Toyota of Bayside

Flushing NY

718-359-7454

Sunrise Toyota

Oakdale NY

631-589-9000

Toyota of Manhattan

New York City NY

212-582-5767

Toyota of Newburgh

New Windsor NY

845-561-0340

Vanderstyne Toyota

Rochester NY

585-225-6600; 800-950-4827

West Herr Toyota

Orchard Park NY

716-648-4141

Westbury Toyota

Westbury NY

516-333-3100

Westchester Toyota

Yonkers NY

914-779-8700; 800-831-8360

North Carolina

Cloninger Toyota

Salisbury NC

704-637-5353; 888-617-1147

Fred Anderson Toyota

Raleigh NC

919-787-0099; 800-727-8101

Greenville Toyota

Greenville NC

252-321-3000; 800-788-2440

Jim Barkley Toyota

Asheville NC

828-667-8888; 800-951-0672

Leith Toyota

Raleigh NC

919-876-5900; 800-394-5008

Mark Jacobson Toyota

Durham NC

919-493-5599

Mike Johnson’s Hickory Toyota

Hickory NC

828-328-5586; 800-627-0321

Modern Toyota

Winston-Salem NC

336-785-3100; 800-642-0808

Patterson Toyota

Mount Airy NC

336-786-2118

Rice Toyota

Greensboro NC

336-288-1190

Scott Clark’s Toyota City

Charlotte NC

704-535-1972; 800-849-1972

Town & Country Toyota-Scion

Charlotte NC

704-552-7600; 888-704-7278

Toyota of Concord

Concord NC

704-979-7700

Toyota of Gastonia

Gastonia NC

704-824-7777; 800-849-8696

Toyota of Goldsboro

Goldsboro NC

919-778-3232

Toyota of Lake Norman

Huntersville NC

704-875-9199

Toyota West

Statesville NC

704-872-2771; 800-326-4455

Victory Toyota

North Wilkesboro NC

336-667-1185; 800-588-0215

North Dakota

Tim Corwin Toyota

Fargo ND

701-282-8425

Ohio

Beechmont Toyota Inc.

Cincinnati OH

513-388-3800

Brunswick Toyota

Brunswick OH

330-273-3300; 888-468-6226

Cain Toyota-BMW Inc.

North Canton OH

330-494-8855

Classic Toyota

Mentor OH

440-953-0910; 800-942-1980

Don Joseph Toyota

Kent OH

330-673-2200; 800-714-6635

Ganley Toyota

Akron OH

330-733-7511; 800-686-4355

Germain Toyota of Columbus

Columbus OH

614-868-0300; 800-686-2277

Glockner Toyota

Portsmouth OH

740-354-3255; 800-837-1072

Jim White Toyota

Toledo OH

419-841-6681

Joseph Airport Toyota

Vandalia OH

937-898-8060

800-451-6511 (local)


Spring 2008

Kings Toyota Inc.

Cincinnati OH

513-683-5440

Metro Toyota

Cleveland OH

216-267-7000; 800-441-3441

Montrose Toyota

Akron OH

330-836-2500; 800-837-2357

Motorcars Toyota

in Cleveland Heights

Cleveland Heights OH

216-321-9100

Performance Toyota

Fairfield OH

513-874-8797

Sunnyside Toyota

North Olmsted OH

440-777-9911

Tansky Sawmill Toyota

Dublin OH

614-766-4800

Toyota of Cincinnati Co.

Cincinnati OH

513-385-1800

Toyota West

Columbus OH

614-465-4820

Oklahoma

Fowler Toyota-AMC-Jeep

Norman OK

800-375-9550

Janzen Toyota

Stillwater OK

405-372-4550

Jim Norton Toyota

Tulsa OK

918-250-6888; 800-888-3555

Riverside Toyota

Tulsa OK

918-836-2769; 800-225-2769

Oregon

Beaverton Toyota-Scion

Beaverton OR

503-626-7200

Kendall Toyota-Scion

Eugene OR

541-344-5566; 800-231-2909

Pennsylvania

Ardmore Toyota

Ardmore PA

610-645-5000; 800-473-1203

Baierl Toyota

Mars PA

724-772-1600; 888-772-3412

Carousel Toyota

Glen Mills PA

610-558-6800; 800-403-4048

Conicelli Toyota

Conshohocken PA

610-825-7128; 800-825-7128 x5

Conicelli Toyota of Springfield

Springfield PA

610-690-6035; 800-737-6300

Faulkner Toyota

Trevose PA

215-244-9300; 800-341-1717

Halterman’s Toyota

East Stroudsburg PA

570-421-6930; 800-922-8867

Lancaster Toyota

East Petersburg PA

717-569-7371; 800-322-1639

New Holland Toyota

New Holland PA

717-354-4907; 800-367-3232

Sloane Toyota

Glenside PA

215-885-5400; 800-235-7444

Sloane Toyota of Devon

Devon PA

610-647-2300; 800-672-7870

Spitzer Toyota

Monroeville PA

412-856-9561


Langhorne PA

215-741-4200

Thompson Toyota Inc.

Doylestown PA

215-345-9460; 800-THOMPSON

Rhode Island

Balise Toyota of Warwick

Warwick RI

401-780-3661

Bristol Toyota

Bristol RI

401-253-2100; 800-284-2916

Colonial Toyota

Smithfield RI

401-723-0972; 800-631-0199

Tarbox Toyota

North Kingstown RI

401-884-5438; 888-982-7269

South Carolina

Dave Edwards Toyota Inc.

Spartanburg SC

864-595-2300; 800-636-3283

Florence Toyota

Florence SC

843-669-1676; 800-922-7598

Gene Reed Toyota Inc.

North Charleston SC

843-797-8000; 800-922-1353

Harrelson Toyota

Rock Hill SC

803-328-2886; 800-242-4274

Taylor Toyota Inc.

North Augusta SC

803-279-8400; 800-763-8696

Toyota Center

West Columbia SC

803-796-6650; 800-635-8213

Toyota of Easley Inc.

Easley SC

864-855-2233; 800-922-2307

West Ashley Toyota

Charleston SC

843-556-9110; 800-316-3017

Tennessee

Capital Toyota Inc.

Chattanooga TN

423-892-0661

Fox Toyota

Clinton TN

865-425-1906; 800-654-7576

Performance Toyota

Memphis TN

901-758-4040

Phil Bachman Toyota

Johnson City TN

423-282-2241

Rivergate Toyota

Madison TN

615-868-4480; 800-251-3011

Rusty Wallace Toyota

Morristown TN

423-587-1972

Toyota Knoxville

Knoxville TN

865-218-3300

Toyota of Bristol

Bristol TN

423-764-3155

Toyota of Cleveland

Cleveland TN

423-339-1138

Texas

Alamo Toyota Inc.

San Antonio TX

210-657-6100


Atkinson Toyota

Bryan TX

979-776-0404; 800-922-5030

Cavender Toyota


210-681-6031; 800-292-5899

Champion Toyota

Austin TX

512-440-4500; 800-856-4527

Champion Toyota Gulf Freeway

Houston TX

713-943-9900; 800-327-2087

Charles Maund Toyota

Austin TX

512-458-2222


Cowboy Toyota

Dallas TX

214-324-0411; 800-266-0752

Dick Poe Toyota

El Paso TX

915-775-2000; 800-395-9331

Don Davis Toyota

Arlington TX

817-588-5308; 800-762-9852

Don McGill Toyota Inc.

Houston TX

281-496-2000

Don McGill Toyota of Katy

Katy TX

832-772-1000

Durant Toyota

Weatherford TX

817-597-5000; 877-538-7268

Fort Bend Toyota

Richmond TX

281-341-5900; 800-856-5956

Frank Smith Toyota

McAllan TX

956-686-3767; 800-347-2360

Fred Haas Toyota Country

Houston TX

281-357-4000

Fred Haas Toyota World

Spring TX

281-297-7000; 800-231-2064

Freeman Toyota

Hurst TX

817-287-5200

Gene Messer Toyota

Lubbock TX

806-748-4802; 800-682-4300

Gullo Toyota of Conroe

Conroe TX

936-441-4141; 800-47-GULLO

Hoy-Fox Toyota

El Paso TX

915-598-0399; 800-285-7278

Joe Myers Toyota

Houston TX

281-890-8700; 800-749-9632

John Eagle Sport City Toyota

Dallas TX

972-681-8361; 800-876-1843

Kinsel Toyota Inc.

Beaumont TX

409-899-4000; 800-323-4090

Loving Toyota

Lufkin TX

936-699-1028

Metroplex Toyota

Duncanville TX

972-780-1166; 800-877-6672

37

Mike Calvert Toyota

Houston TX

713-558-8100; 800-527-5368

Red McCombs Toyota


210-530-3000; 800-292-7810

Rene Isip Toyota/Lewisville

Lewisville TX

469-671-5500

Round Rock Toyota

Round Rock TX

512-244-6900

San Marcos Toyota

San Marcos TX

512-805-6546; 866-213-1999

Star Toyota

League City TX

281-338-9700

Sterling McCall Toyota

Houston TX

713-270-3900

Street Toyota Inc.

Amarillo TX

806-355-9846

Tejas Toyota Inc.

Humble TX

281-446-0271

Texas Toyota of Grapevine

Grapevine TX

817-329-5949; 888-866-8577

Toyota of Dallas

Dallas TX

972-241-6655; 800-442-4349

Toyota of Fort Worth

Fort Worth TX

817-560-1500; 866-295-8384

Toyota of Irving Inc.

Irving TX

972-258-1200; 800-527-5874

Toyota of Killeen

Killeen TX

254-690-7273; 888-437-2514

Toyota of Laredo

Laredo TX

956-718-4200

Toyota of Longview

Longview TX

903-295-9300

Toyota of Plano

Plano TX

972-248-7777; 800-925-8009

Toyota of Richardson

Richardson TX

972-238-4400; 800-527-2781

Universal Toyota


210-654-1515; 800-489-7575


Vandergriff Toyota

Arlington TX

817-468-8696

Utah

Brent Brown Toyota

Provo UT

801-223-4407

Karl Malone Toyota

Sandy UT

801-553-5800; 888-281-3185

Larry H. Miller Toyota

Murray UT

801-264-3800; 800-453-6456

Menlove Toyota

Bountiful UT

801-295-3554; 800-574-9100

Vermont

Heritage Toyota

South Burlington VT

802-865-8200; 800-439-8856

White River Toyota

White River Junction VT

802-299-2800; 800-639-1101

Virginia

Alexandria Toyota

Alexandria VA

703-684-0700; 800-766-9767

Berglund Oak Ridge Toyota

Lynchburg VA

434-528-3202; 888-287-0333

Bill Page Toyota

Falls Church VA

703-532-8800

Checkered Flag Toyota

Virginia Beach VA

757-490-1111; 800-277-2122

David R. McGeorge Toyota

Richmond VA

804-755-9200; 800-888-9753

First Team Toyota

Chesapeake VA

757-673-2345

Haley Toyota

Roanoke VA

540-345-1666; 800-294-2539

Haley Toyota of Farmville

Farmville VA

434-392-8166

Haley Toyota of Richmond

Midlothian VA

804-545-7401; 800-328-7121

Koons Arlington Toyota

Arlington VA

703-522-6000

Koons Tysons Toyota

Vienna VA

703-790-5920; 800-299-8310

Leesburg Toyota

Leesburg VA

703-771-8990; 800-545-6925

Lustine Toyota/Dodge

Woodbridge VA

703-494-9154; 800-537-1746

Mechanicsville Toyota

Mechanicsville VA

804-417-1121; 800-338-5538

Miller Toyota

Manassas VA

703-369-3040

Ourisman Fairfax Toyota

Fairfax VA

703-359-1010; 800-626-2236

Priority Toyota

Chesapeake VA

757-366-5000

Priority Toyota Richmond

Chester VA

804-526-2811

Springfield Toyota

Springfield VA

703-451-0300; 800-269-1406

Washington

Appleway Toyota

Spokane WA

509-924-1150; 800-876-4412

Foothills Toyota

Burlington WA

360-757-7575; 800-962-7384

Heartland Toyota

Bremerton WA

360-377-1200

Magic Toyota

Edmonds WA

425-775-4422

Michael’s Toyota of Bellevue

Bellevue WA

425-455-9500

Rodland Toyota

Everett WA

425-353-2929; 800-562-1805

Toyota of Lake City

Seattle WA

206-367-0080; 800-426-2300

Toyota of Seattle

Seattle WA

206-382-4300

Toyota of Tri-Cities

Kennewick WA

509-547-9888; 888-616-3648

West Virginia

Bert Wolfe Toyota

Charleston WV

304-344-1601; 800-989-8520

Wisconsin

Don Jacobs Toyota

Milwaukee WI

414-281-3100; 800-572-6490

Jack Safro Toyota

Brookfield WI

262-781-2626; 800-242-2086

Kolosso Toyota

Appleton WI

920-738-3666; 800-236-4333

Rhinelander Toyota

Rhinelander WI

715-365-8120; 800-560-7701

Wilde Toyota Inc.

West Allis WI

414-545-8010; 800-452-4255


Spring 2008

Sequoia power steering rack service - Locate Your OEM Toyota ...

Transform your PDFs into Flipbooks and boost your revenue!

Sequoia power steering rack service - Locate Your OEM Toyota ...

Transform your PDFs into Flipbooks and boost your revenue!

Delete template?

Save as template ?
