PT Series Products Selection Guide

Size

Resolution

Nor Flash Memory

NAND Flash Memory

*Battery Backed Memory

COM1

**COM2

COM3

USB

Realtime Clock

Front Function Key

Front USB

PT150

PT150-4

15 inch (4:3)

1024 x 768

8 MB

128 MB***

128 KB

RS232/422/485

A/B/C

RS232

Client x 1 Host x 1

Yes

-

-

PT104

PT104-1/2/4

10.4 inch (4:3)

800 x 600

8 MB

128 MB***

128 KB

RS232/422/485

A/B/C

RS232


Yes

-

Yes

PT100

PT100-1/2/4

10.1 inch (16:9)

1024 x 600

8 MB

128 MB***

128 KB

RS232/422/485

A/B/C

RS232


Yes

Yes

Yes

PT Series

The PT series supports comprehensive LCD sizes range from 4.3” to 15” and equipped with ARM9 based CPU, 8M

flash memory and 128KB battery backed memory. Also, with rich communication interfaces—RS232/422/485, Ethernet

and USB port, and over 300 communication drivers, PT series can easily connect with the different equipments, such

as motion/thermal controllers, inverters or sensors. The LCD of PT series are 65536 colors TFT LCD with LED back

light which can provide clear display and high precise operation. To confront severe environment in factory setting,

PT series complies with IP65 and allows operating temperature -20 ~ 60°C. Moreover, Cermate also provides some

options for customers to shape their own HMI that tailored their needs. For example, aluminum front case is suited

for those who prefer more fashion design or will operate HMI under harsh environment; NAND flash and micro SD

provide extending the capacity of HMI; different COM port option provide elasticity for customers. All those features

bundle with our easy-to-use programming software—PM Designer— provides you perfect automation solutions.

PT080

PT080-1/2/4

8 inch (4:3)

800 x 600

8 MB

128 MB***

128 KB

RS232/422/485

A/B/C

RS232


Yes

Yes

Yes

PT070

PT070-1/2/4

7 inch (16:9)

800 x 480

8 MB

128 MB***

128 KB

RS232/422/485

A/B/C

RS232


Yes

Yes

Yes

PT056

PT056-1/2

5.6 inch (4:3)

320 x 234

8 MB

128 MB***

128 KB

RS232/422/485

A/B/C

RS232


Yes

Yes

Yes

PT043

PT043-1/2/4

4.3 inch (16:9)

480 x 272

8 MB

128 MB***

128 KB

RS232/422/485

A/B/C

RS232


Yes

-

1

* 1 MB optional

** A: RS422/485 B:RS232/485 C: RS232 with RTS&CTS

*** 128MB NAND Flash only for sub-number 2 and 4

2

-

PT Series Products Selection Guide

GX Series Products Selection Guide

Size

Resolution

Working Memory

Built-in Storage Memory

COM1

*COM2

COM3

USB

Audio

Video

Realtime Clock

Micro SD

GX150-4

GX150-4

GX121

GX121-2/4

GX104

GX104-2/4

15 inch (4:3)

12.1 inch (4:3)

10.4 inch (4:3)

1024 x 768

1024 x 768

800 x 600

256 MB

256 MB

256 MB

128 MB

(64MB: WinCE OS 64 MB: User)

128 MB


128 MB


RS232/422/485

RS232/422/485

RS232/422/485

A/B/C

A/B/C

A/B/C

RS232

RS232

RS232




Yes (optional)






Yes

Yes

Yes

Yes

Yes

Yes

GX100

GX100-1/2/4

GX080

GX080-2/4

GX070

GX104-2/4

10.1 inch (16:9)

8 inch (4:3)

7 inch (16:9)

1024 x 600

800 x 600

800 x 480

256 MB

256 MB

256 MB

128 MB


128 MB


128 MB


RS232/422/485

RS232/422/485

RS232/422/485

A/B/C

A/B/C

A/B/C

RS232

RS232

RS232










Yes

Yes

Yes

Yes

Yes

Yes

* A: RS422/485 B:RS232/485 C: RS232 with RTS&CTS

3 4

GX series

The GX series is WinCE based HMI with LCD size range from 7” to 15”. GX also equipped with 256MB working

memory and 128MB storage memory so that provide high performance operation. All the series uses high color TFT

LCD with LED back light to ensure clear display and longer backlight life. The ultra slim design is fashion and easilymounted.

Not only design for stylish, the robust structure enable the GX series used in any stringent environment.

The rich communication interface of GX series, including 3 COM ports, Ethernet and 2 USB ports (1client, 1host), can

provide easy connection with other devices. Besides, we also provide customized option for some specific purpose so

that we can promise what products you need. Here are some customized options: aluminum front case, audio/video

function and micro SD or NAND flash. GX series are what Cermate present for open HMI users who desire for high

performance products.

GX Series Products Slection Guide

PK Series Products Selection Guide

PK Series Products Selection Guide

Size

Resolution

Flash Memory

Bettery Backed Memory

Size

Resolution

Flash Memory

Bettery Backed Memory

5

PK100

PK100-10M-TOS

10.1 inch (16:9)

1024 x 600

8 MB

-

PK100-20M-T1S

10.1 inch (16:9)

1024 x 600

8 MB + 128 MB NAND Flash

128 KB

* 1MB Battery Backed Memory Optional

PK070

PK70-10M-TOS

7 inch (16:9)

800 x 480

8 MB

-

PK070-20M-T1S

10.4 inch (16:9)

800 x 480

8 MB + 128 MB NAND Flash

128 KB

PK043

PK043-10M-T1S

4.3 inch (16:9)

480 x 272

8 MB

128 KB

PanelExpress is a Windows based HMI runtime. It enables you to utilize the resources of a PC, such as computation

power, multimedia, and bigger screen, to realize a high-end sophisticated HMI. Its configuration software, PM

Designer, is also the development tool for PanelMaster series RTOS based HMI products. Thanks to the cross

platform flexibility offered by PM Designer, switching hardware for the consideration of cost and performance

becomes an easy job.

General Features

• Low cost Windows based HMI runtime

• 50 kinds of screen objects can fulfill almost all types of HMI operating and viewing needs for machine

automation

• Supports up to 16 communication links

• No limitation on the number of I/O points used in an application

• Over 100 field proven communication drivers are provided for free

• Supports data collection, alarm monitoring, recipe handling, and operation logging

• Provides a complete set of useful macro commands. Macro programs can be embedded in objects, screens,

and the global process

• The reliable HMI engine has over 100,000 installation sites

• Brand labeling possible

Advanced Features

• Number of communication links can be up to 248

• Monitors up to 64 discrete alarm blocks and 64 analog alarm blocks. Totally up to 65535 alarms can be defined

• Supports VNC(Virtual Network Computing)

• Supports Access, My SQL, and SQL databases

• Supports Visual Basic Script

6

PanelExpress

Application Story

7

Application Story

1. Building Automation

In building automation, HMI provides an economic and an easy answer for those who

need integrated and systematic solutions. Elevator, power system management, AC

system and alarm system can be integrated into a more intelligent system. You can

manage, supervise and record with easier way than what you have ever experienced

before.

2. Home Automation

Besides a traditional role that HMI plays in industrial automation, the application field

of HMI has extended for a more general usage and involves with our daily life. Home

Automation is one of it. To combine home appliances and multimedia devices in one

control system or to select a predefined mode in one touch, HMI can integrate those

descriptions and its main focus is to combine your mobile phone and Ethernet to

provide an intelligent life.

3. Factory Automation

The HMI is burgeoning in the Factory Automation field. With more accessible

price, friendly operation and wide range of selection, successful application is seen

everywhere in our daily life. The automation system for manufacturing process will

provide more stable output and save your time and cost.

4. Machine Automation

In the scope of industrialization, automation is required to provide an efficient and

precise way of manufacturing. Machine automation can provide operators to assist

with muscular work, and greatly decreases the need for human sensory and mental

requirements as well. In the chain of machine, HMI takes the helm of the automation

process and helps you manage the whole system from top down.

8

Application Story

Hardware Feature—HMI on Machine

9

Hardware Feature—Communication Hardware Feature—

General Description

You can use serial port or ethernet to complete different type of communications. You can

communicate with 1 or multiple devices direct or indirect.

Various Communication Links

Direct Link

PC

RS485

RS232/422/485

Ethernet

Panel

Gateway Server

3 sub-link

Sub-link

Using RS485 serial connection to link multiple device

with same protocol, such as temperature controller and

intelligent sensor. Users can activate/stop the sub-link

and save the communication status

Gateway Service

Ethernet

2 to 1 connection

PM Panel

Other Panel

PC

N-to-1 Connection Master

2-to-1 Server

2 to 1 transparent connection

2-to-1 transparent server



N-to-1 Communication

Data Sharer

Ethernet (UDP)

Ethernet

HMI HMI

We will provide total H.M.I. Solution for Different Various

Application of Automation Field

Our HMI is a high function but cost

effective products which can communicate

with popular programmable controllers.

Ruggedized

20°C

70°C

Wide Temperature

Customization

Rugged plastic housing, Customize

Aluminum front case, IP66 equivalent

front panel and Fanless CPU make

the PT/PX/PK series a reliable solution

for industrial or critical applications.

10

Hardware Feature—Aluminum Case and Wide Temperature

Specification of PT

Model Name PT150 PT104 PT100 PT080

Sub-model 4 1 2 4 1 2 4 1 2 4

Display

Size 15.0” (4:3) 10.4” (4:3) 10.1” (16:9) 8.0” (4:3)

Max. Resolution 1024x768 800x600 1024x600 800x600

Type TFT LCD

Max. Colors 65,536 colors

Backlight Type LED

Backlight Life (hr) 50000 20000

Luminance (cd/m2) 350 400 200 250

Touchscreen 5 wires analog resistive 4 wires analog resistive

CPU RISC 32 bits

Flash Memory 8 MB NOR Flash

Battery Backed Memory 128KB (1024KB optional)

Working Memory 64 MB 64 MB 64 MB 64 MB

NAND Flash 128 MB - 128 MB - 128 MB - 128 MB

Communication Interface

Micro-SD Slot Yes - Yes - Yes - Yes

USB Client Yes

USB Host Yes

Serial COM1: RS232/422/485; COM2: A- RS422/485 B- RS232/485 C- RS232 with RTS&CTS; COM3: RS232

Ethernet Yes (10/100M) - -

Yes

(10/100M)

- -

Yes

(10/100M)

- -

Funtional Keys (optional) - - 7Keys 6Keys

Power

Environment

Supply Voltage 24 VDC ± 10%

Consumption 25W 20W 20W 20W

Operating

Temperature

- 1 0 ~ 50°C (32 ~ 120°F)

Relative Humidity 10% ~ 90% RH @ 0 ~ 50°C, non-condensing

Shock (operation) 10 ~ 55 Hz (X,Y, Z direction, 1 G, 30 minutes)

EMI FCC Part 15 Class A

CE EN61000-6-2, EN61000-6-4

Ingress Protection NEMA4, IP66

Cooling Natural Cooling

Dimension WxHxD (mm) 399.1 x 297.6 x 55.0 270.1 x 212.1 x 42.5 270.1 x 212.1 x 42.5 231.5 x 174.5 x 42.5

Cutout Dimension WxH (mm) 384.5 x 283.0 259.5 x 201.5 259.5 x 201.5 221.0 x 164.0

Net Weight (kg) 2.9 1.2 1.2 0.93

com2 Option Description

HMB-CER-XXX General Type RS422/485 Model

HMB-CER-XXX General Type RS232/485 Model

HMB-CER-XXX General Type RS232 with RTS&CTS Model

HMB-CER-XXX Isolated Type RS422/485 Model

Yes

(10/100M)

Model Name PT070 PT056 PT043

Ordering Information 1 2 4 1 2 1 2 4

Display

Size 7.0” (16:9) 5.6” (4:3) 4.3” (16:9)

Max. Resolution 800x480 320x234 480x272

Type TFT LCD



Backlight Life (hr) 20000

Luminance (cd/m2) 300 300 400

Touchscreen 4 wires analog resistive

CPU RISC 32 bits

Flash Memory 8 MB NOR Flash

Battery Backed Memory 128KB (1024KB optional)

Working Memory 64 MB 32 MB 32 MB

NAND Flash - 128 MB - 128 MB - 128 MB


Micro-SD Slot - Yes - Yes - Yes

USB Client Yes

USB Host Yes


Ethernet - -

Yes

(10/100M)

- - -

Funtional Keys (optional) 6 Keys -

Power

Environment


Consumption 15 W 13 W 13 W

Operating

Temperature

-1 0 ~ 50°C (32 ~ 120°F)




CE EN55022, EN61000-4-2, EN61000-4-3, EN61000-4-8

Ingress Protection NEMA4, IP66


Dimension WxHxD (mm) Standard:188.0 x 143.3 x 36.0 W:203.5 x 148.5 x 36.0 130.0 x 106.2 x 39.0

Cutout Dimension WxH (mm) Standard:175.0 x 132.5 W:191.5 x 138.0 119.0 x 93.0

Net Weight (kg) 0.6 0.59 0.35

HMB-CER-XXX Isolated Type RS232 with RTS&CTS Model

11 12

Yes

(10/100M)

Specification of PT

Specification of GX

Model Name GX150 GX121 GX104

Sub-models 4 2 4 2 4

Display

Size 15.0” (4:3) 12.1” (4:3) 10.4” (4:3)


Type TFT LCD



Backlight Life (hr) 50000 20000


Touchscreen 5 wires analog resistive 4 wires analog resistive

CPU ARM11 RISC 667MHz

Working Memory 256 MB

Built-in Storage Memory 128MB (64MB:Win CE OS / 64MB:User)


Micro-SD Slot YES

USB Client YES

USB Host YES


Ethernet Yes (10/100M) - Yes (10/100M) - Yes (10/100M)

Funtional Keys (optional) - - -

Power

Environment

Audio (optional) YES



Consumption 25W

Operating

Temperature

0 ~ 50°C (32 ~ 120°F)




CE EN61000-6-2, EN61000-6-4

Ingress Protection NEMA/IP65


Dimension WxHxD (mm) 399.1 x 297.6 x 55.0 315.0 x 241.0 x 54.5 270.1 x 212.1 x 42.5

Cutout Dimension WxH (mm) 384.5 x 283.0 301.5 x 228.0 259.5 x 201.5

Net Weight (kg) 2.9 2.1 1.25

Model Name GX100 GX080 GX070

Sub-models 2 4 2 4 2 4

Display

Size 10.1” (16:9) 8.0” (4:3) 7.0” (16:9)


Type TFT LCD



Backlight Life (hr) 2000


Touchscreen 4 wires analog resistive

CPU ARM11 RISC 667MHz

Working Memory 256 MB

Built-in Storage Memory 128MB (64MB:Win CE OS / 64MB:User)


Micro-SD Slot YES

USB Client YES

USB Host YES


Ethernet - Yes (10/100M) - Yes (10/100M) - Yes (10/100M)

Funtional Keys (optional) 7 Keys 6 Keys

Power

Environment




Consumption 18W 25W 13W

Operating

Temperature

0 ~ 50°C (32 ~ 120°F)




CE EN61000-6-2, EN61000-6-4

Ingress Protection NEMA/IP65


Dimension WxHxD (mm) 270.1 x 212.1 x 42.5 231.5 x 174.5 x 42.5

Cutout Dimension WxH (mm) 259.5 x 201.5 221.0 x 164.0

Standard:188.0 x 143.3 x 36.0

W:203.5 x 148.5 x 36.0

Standard:175.0 x 132.5

W:191.5 x 138.0

Net Weight (kg) 1.25 1.25 0.54

13 14

Specification of PV

HMI Development Software - PM Designer

PM Designer is proven in many application fields and is an easy to use integrated development tool featuring solutionoriented

screen objects, high-end vector graphics, Windows fonts for multi-language applications, recipes, alarms,

data loggers and operation logging. PM Designer also includes online/offline simulation and other utility programs

such as Data Transfer Helper (DTH); recipes editors and text editors. PanelMaster runtime, a part of PM Designer,

guarantees reliability and performance because of the minimum system overhead, high communication data rates,

sub-second screen switching, and 24/7 operation.

Shortcut & Execution Toolbar

Icon Display Improves Work Efficiency

• Shortcut icons designed to show objects, figure type,

and operations improving work efficiency.

• Frequently used objects and figures can be registered

as Favorites.

Project Workspace

An Intuitive Tree Display Makes Runtime Development Easy

Easy to create, develop, and manage project property

efficiency by project-based management worksheets.

Screen Design Worksheet

Smart Screen Design

Easy to view screens during runtime development,

adjustable based on user-oriented application.

Message Build List

Compile & Simulate Results

By double clicking on the error message after compilation it

will automatically jump to the place where the problem is.

Draw Toolbar

A variety of drawing tools empower developers to

create expansive applications.

Software Features

• Allows users to switch multi-language UI dynamically,

with Unicode and multilingual screen text supported.

• Provides password protection of designs, macros and

upload/download operations.

• Provides index registers for modifying device addresses

at runtime.

• Operation log helps the review and investigation of

important events.

Simple

• Allows to download the runtime data using serial port,

Ethernet, USB and Micro SD card.

• Allows the use of USB memory sticks for trouble-free

application updates.

Innovative

Object Toolbar

Registered Components Display

Edit Toolbar

Dedicated Component Editing Screen

Designing screens is made

easy by selecting components

from the image list and putting

them on the drawing screen.

• A component editing screen appears by double-clicking

a registered component within the library workspace.

• Editing registered components is quick and easy.

Dialog Box

Edit Toolbar

Easy

• The property dialog is

displayed by double-clicking

the object or figure.

• Figure changes are

immediately reflected on

screen, thereby simplifying

the process and reducing

setting errors.

• Easy to set the properties

through pop-up dialog box.

• Supports over 300 industrial communication protocols, such as

SIMATIC S7-1200, BACNet MSTP/BACNet IP, and more.

17 18

HMI Development Software - PM Designer

PM Designer Software

Efficient Project-based Structure to Manage

Multiple Applications

Project manager

• One project can have many applications.

• The project tree provides all you need to manage a project.

• Global settings and resources sharable to all applications

in a project.

• You can make the most out of existing projects by import/

export functions for all kinds of settings.

• Containing entire project in one file makes the maintenance

job easy.

User Friendly Tools to Make Customized

Designs Easier and More Efficient

Auto Resizing, Rotating & Tone

Screen editor and toolbars

• Real-time WYSIWYG allows you to see the change of

object appearance at any time.

• Property dialogs with semi-transparent features will not

block your view to screen objects anymore.

• Automatic size adjustment of characters and pictures

according to the object size is supported.

• Groups a number of objects to move, resize, and modify

the common attributes.

• Rotate a picture or change its tone to fit the need of an

object.

Software Functionalities to Meet Various

Machine Automation Needs

Possible to achieve a mini-SCADA system

• 10 sets of text to support multiple languages.

• 4 communication links with the option to add more RS-485

and TCP/IP sub-links.

• 7999 screens.

• 1 startup macro; 1 main macro; 4 event macros, 4 time

macros, no limitation on other kinds of macros

• 16 discrete alarm, analog alarm, recipe block and data

loggers. data logger

• 1 operation logger.

Smart Screen Management

List View Thumbnail View

Screen Overview

Screen manager

• Shows the screen numbers and their names of an

application in a traditional text list or a thumbnail list.

• Select screens from the list to edit, cut, copy, delete, or

export them.

• Creating new screens and importing screens can be done

through a pop-up menu.

• Click on a screen thumbnail to highlight the connections of

that screen with others.

• Double-click on a screen thumbnail to open that screen’s

editing window or property dialog.

A Graphical Tool for Defining

Communication Configuration

Link overview

Moving the starting terminal of a link line to a different

port position changes the link port setting accordingly.

Double-click on a highlighted link line to bring up the

property dialog of that link.

• Depicts the communication links of all the panel

applications in a project. You can easily know the paneldevice

connections and the panel-panel connections.

• Edit the content of the link overview to make it more

readable and meaningful.

• Create panel applications and communication links. This is

a way of doing top-down design on communication level.

Shows All I/O Points With Their

Purpose in A Table

Screen editor and toolbars

• Double-click on an I/O point

to bring up the property

dialog of that I/O point’s

user. It is convenient to view

or modify the configuration

of an entity associated with

a certain I/O point through

this way.

Easy-to-use Macro Editor and Commands

Macro Commands

Macro Command Instant Help

Macro Editor

Macro editor and macro commands

• Macro editor and macro commands are useful for

operations, such as sequential operations, conditional

operations, interactive operations, file operations, data

exchange between two connected devices, etc.

Display All Objects With

Associated I/O Points in a List

Object list

• Shows all the objects of a screen with their types, IDs, and

associated I/O addresses. You can edit the I/O addresses

in the list directly.

Thousands of Professional Pictures to Make

Screen Designs Easy and Outstanding

Picture libraries and picture

database

• Famous industrial pictures

from Symbol Factory are

ready for use, so that making

your own picture libraries is

easy.

Changing HMI Model Can Be Done in Seconds

5.7” 640x480

Automatic size adjustment

PanelMaster symbols (.BMP)

7” 800x480

• When changing the screen resolution, all the screen objects

are automatically resized to maintain the relative positions

and size ratios to the original screens.

19 20

PM Designer Software

PM Designer Software

Simple Text Mapping Table Fulfills The Needs

for Multiple Languages

Text database and text editor

• Text database tables have multiple columns to contain

strings for all supported languages with import/export

functions, you can use Microsoft Excel to edit strings

and import them for an application.

Secure Intellectual Properties

Design Protection

• Project files, global macros, and password tables can

be protected by different passwords.

• Copying and uploading of an application can be

prohibited in advance.

Supports Dynamic Data, Scale and Time

Ranges for Complicated Applications

Dynamic range

Import/Export from or to Excel

• With the support of dynamic range, a screen object can

adapt its display to the current range settings to show

information more readable and precise.

Customized Keypad Layouts and Designs

Anti-Piracy Functions

Custom Keypads

Custom keypads and on-screen keypads

• You can design your own keypad to make it more appealing

or suitable for a special requirement.

• Using on-screen keypads instead of pop-up keypads is

possible.

Compiler

Provides Complete Recipe Handling Functions

Recipe blocks

• Support up to 16 different groups of recipes.

• Transfer of recipes between PanelMaster and PLCs/files

is supported.

• With RecipeEditor you can edit recipes on a PC.

退出

輸入

• An allowable input range can be set

for a numeric data entry object.

• Buttons, switches, and data entry

objects can be disabled or hidden

dynamically by the current user

level or the specified bits.

• Operator confirmation can be asked

for a data entry.

• Minimum holding time can be

required for a button/switch.

• Advanced Numeric Display can use

a macro to check the user input.

Easy to Configure Data Collections and

Historic Data Displays

Data loggers

• You can save/load collected data (up to 16 different data

sources) to/from a file by a function button or macro program.

• Historic Event Table displays collected data and history of

predefined events in tabular form.

• Historic Trend Graph

displays collected data

in trend lines

Operations Can Be Recorded for Improving

Quality and Efficiency

Operation logging

Operation Log Display

• The starting time and the stopping time of an application

can be recorded.

• The failure of a communication link can be recorded.

• Operation Log Display lists the logged operations

process for the operator to review.

Reduce Time and Effort to Boost Performance

through Advanced Simulations

Simulator Application

Offline simulation and online simulation

• Single Record Line Chart

displays the profile of

one sample from a set of

collected data.

Offline Simulation

• Offline simulation function can help to experience your

design result even before decide to purchase this model.

• Evaluates the communication performance using online

simulation before installation.

Versatile Alarm Monitoring and

Display Capabilities

Alarm processing

• Up to 16 discrete alarm blocks and 16 analog alarm

blocks can be monitored and recorded.

• Up to 8 data values can be read and recorded along with

an alarm event.

• A global alarm marquee is supported.

Easy-to-Use Error Messages

Compiler

• Checks the correctness and consistency of all settings and

designs to optimize the communications with connected

devices.

• Translates macros into compact and ready-to-execute codes.

• Builds runtime data to be executed by the PanelMaster.

Provides Various Choices for Application

Runtime Data Transfers

Data Transfer Tool & Data

Transfer Helper (DTH)

• Uses PM Designer or DTH to

transfer an application’s runtime

data to a PanelMaster through a

serial port, an Ethernet port, or

a USB port anytime when that

PanelMaster is running. (Some

PanelMaster models may not have

a client USB port to support the

data transfer.)

• Without a PC, transfers an

application’s runtime data to a

PanelMaster by using an USB

memory stick or Micro SD card.

21 22

Alarm History

Active Alarm

Alarm Count

Alarm Screen

PM Designer Software

Cutout

PV037LSK

Dimension WxHxD (mm) 172.0 x 102.0 x 42.9

Cutout Dimension WxH (mm) 160.5 x 89.5









PV121-GX121



PV035-PT043-PK043 PT100-PT104-GX100-GX104-PK100

PV057-PV058-PT056-PT070-GX070 PT150-GX150


Cutout Dimension WxH (mm) 259.5 × 201.5



PV080-PT080-GX080 PK070-eV056-eV070

PV104

Dimension WxHxD (mm) 204.4 × 151.0 x 33.0


Delmation Products BV

T +31 (0)79 342 2041

info@delmation.nl

www.delmation.nl

23 24

Cutout

Driver List

Brand Model (For COM)


A&D AD-4401 Weighing Indicator

Eura Inverter (Modbus ASCII)

ABIDO Automation

ACR420 984 Device/Slave (RTU)

Eura EF200-CPU202(Modbus RTU)

MS/AP/AS Series Inverter (RTU)

Eura EF200-CPU202XP/

ADLEE POWERTRONIC

BL/D305 Series (RTU)

Eura Drivers Electric Corp.

CPU204(Modbus RTU)

Eura EF200-CPU204XP/CPU206(Modbus

Null PLC

RTU)

ADAM (Modbus RTU)


ADAM-4011 (ASCII)



Fatek Automation

FATEK FBs/FBe


Festo Corporation

FPC/FEC Series


Fuji Electric

NB Series


PXR Series Temperature (RTU)

ADAM-4018+ (ASCII)

FRENIC-VP (RTU)

Advantech


FRENIC5000G11/P11 (Fuji)


FRENIC-Mini/Eco/Multi/Mega(RTU)


FVK Automation

F Series Inverter


GE Corporation

90 Series SNP


VersaMax Series (SNP)


90 and RX3i Series (SNP)


90 Series CCM


Gigarise Technology

SE5000

AIGO Technologies

SE500 Series (Modbus RTU)

GA400 Temperature (RTU)

Micrologix 1000/1500

GOFAST

NC Series

SLC 5/03, 5/04

Haiwell Technology

HW Series (RTU)

Allen Bradley

DH-485 (COM)

PLC-5

Hanbell Precise Machinery Co., Ltd.

Hitachi Industrial Equipment

Systems Co., Ltd

Air Screw Compressor

SJ200 Inverter

SLC 5/03, 5/04 (CRC)

H/EH Series

ARICO Technology

FC Type(Modbus)

EHV Series (Procedure 1)

Modbus Master (RTU)

H-252C

Modbus Device/Slave (RTU)

AD Series Servo Drives

Astraada HMI

Modicon Device/Slave (RTU, Quantum) Hitech

Computer as Slave (COM)

Modbus Master (RTU; Non-volatile slave data)

Computer as Master (COM)

Automation Technology

BLDC NLV/KLV Series

Computer as Slave V2 (COM)

Banner Engineering

BSP01 Series

Computer as Master V2 (COM)

Bosch Rexroth Group

Convo CVF-MN3 (RS485 Model)

HOLIP ELECTRONIC

HLP-C+/CP

CAPAC

TC

Honeywell

BACnet/MSTP

CHINO Corporation

DB1000 Digital Indicating Controller (ASCII)

BACnet

NF0 Controllers

Hunjoen Electronic

H_Tech PID CONTROLLER

FCT Controllers

HUST Automation

CNC Controller

CMZ Sistemi Elettronici

SD Drivers

Idec Corporation

FC Series

SDS Drivers

IECCO

Sinus Penta Inverter (RTU)

MDM Drivers

Inovance Control

H2u (CPU Port)

MD Series Inverter (RTU)

CTB Technologies

IMS Servo Controller

MD Series Inverter (RTU-1)

Danfoss Group

VLT 2800 Series (FC Protocol)

IS Servo (RTU)

DEIF A/S

Modbus RTU (COM port)

Integrated Flow Systems

iPurge Source Controller

DVP-ES/SS/EP/EH

Invt Auto-Control Technology

IVC Series

DVP-ES/SS/EP/EH (No block read)

JETTER

NANO Series

VFD-M Inverter (ASCII)

JetControl 24x Series

Delta Corporation

VFD-B Inverter (ASCII)

Joint Peer Systec Corp.

IRIS Series

DTC1000/2000 Temperature (ASCII)

JUPITER Series

ASDA-A Servo Controller (ASCII)

PDAN Series

ASDA-B Servo Controller (ASCII)

PDS Series

ASDA-A2 Servo Controller (ASCII)

Keyence Corp.

KV Series

Dirise Electric Technology

DRS2000 Series Inverter

KV-1000

DRS2800 M Series Inverter

KV-L20V

Emerson Network Power

EC Series (RTU)

Klockner Moeller

PS4-201-MM1

EV1000 Series Variable Speed Driver

SUCONET K

Epson Corporate

Epson LQ Matrix Printer

Koyo Electric

K Sequence Series

Eura EF1S/1N

Direct Logic Series

Eura Drivers Electric Corp. Eura EF2N

Direct 06 Series (K Sequence)

Eura Inverter (Modbus RTU)

Direct 06 Series (DirectNET)


Lenze Drive Systems GmbH 93xx Servo Controllers (LECOM A/B)

Master-K Series CNet

K120S CPU Port

Master-K Loader

GLOFA GM Series CNet

LG Industrial Systems

XBM-DR16S

GLOFA GM Loader

XEC/XGI CNet

XGT/XGK (CPU)

XGL-C22A

LGA Series(as Slave)

LG System

LGA Series (as Master)

Liyan Electric Industrial Ltd. EX Series (CPU Port)

LustBus ServoC/CDE Series

Lust Antriebstechnik GmbH

LustBus CDD Series

FP Series Computer Link

Matsushita Electric Works VF0C Series Inverter

VF100 Series Inverter

Maxtech

MC2 PID Controller

Maxthermo

MC 5738 (RTU)

Mean Well Enterprises Co., Ltd. PRETA

Megmeet

MC Series (RTU)

Micro Trend Corporation UTC Servo Controller

Mirle Automation Corporation nDX Controller

Melsec-FX (CPU Port)

Melsec-Q/QnA (Link Port)

Melsec-Q00/01 (CPU Port)

Melsec-Q02H (CPU Port)

Melsec-Q02 (CPU Port)

Melsec-Q02U (CPU Port)

Melsec-Q00J (CPU Port)

Melsec-FX2n (CPU Port)

Melsec-FX3U (CPU Port)

Melsec-FX3U (Link Port)

Melsec-AnN/AnS (Link Port)

FX2n-10GM/20GM

Mitsubishi Electric Corp.

Melsec-A1S/A2S (CPU Port)

FR-E500 Series (485)

Melsec-A3N/A1SH (CPU Port)

Melsec-AnA/AnU (Link Port)

Servo Amplifier MR-J2S-A

Servo Amplifier MR-J3-A

Melsec-A2A/A2AS (CPU Port)




GOT-F900 Emulator (1:1 Format 1 & 2)


Mitutoyo Corporation

EV Linear Gage Counter (ASCII)

Modicon 984 Master (RTU)

Modicon 984 Master (RTU; Little Memory)

Modicon 984 Device/Slave (RTU)

Modbus Master (ASCII)

Modbus Master (ASCII; Little Memory)

Modicon Corp.

Modbus Device/Slave (ASCII)

Modicon Device/Slave (RTU, Quantum)

TSX Premium (Uni-Telway)

TSX Quantum (Uni-Telway)

Twido (Modbus RTU)




Brand Model (For Ethernet)

Modicon Corp.

Modbus Master (ASCII; Non-volatile slave

data)

Shinko Technos

JCS-33A-R/M (Shinko Protocol) Advantech

ADAM-6017 ModBus Device/Slave (TCP/IP)

MTC

MTC96 Controller (Modbus ASCII)

JCS-33A-R/M (Modbus ASCII)


Muscle Corporation Inc.

Cool Muscle CM1-17L30

Siemens AG Simatic S7-200 (PPI; 1-to-1)


MyTech

VL-CX: Melsec-FX2n (CPU Port)

Simatic S7-200 (PPI; Network)


Newtop Co., Ltd.

PSTC (Temperature Controller)

Simatic S7-300 (MPI Port)


PSBD (Bushless Driver)

Simatic S7-300 (PC Adaptor)


PSSD (Stepping Driver)

Simatic S5 3964R


PSMC (Motion Controller)

Simatic S5

Allen Bradley

MicroLogix 1000/1500 via 1761-NET-ENI

PSNC (Embedded NC)

Taian Automation

TP03 Series (Modbus RTU)

CompactLogix/ControlLogix Ethernet/IP Tag

TP02 Series

Omron Corporation

Sysmac C Series Host Link

Astraada HMI

ModBus Master (TCP/IP)

Taiwan Instrument & Control

TAIE FY100/900 Series (RTU)

Sysmac CV Series Host Link

ModBus Device/Slave (TCP/IP)

TAIE FY100/900 Series (TAIE)

Sysmac CS/CJ Series Host Link

FY series DIGITAL PID CONTROLLER

ModBus Master (TCP/IP; Type 2)

Sysmac CS/CJ Series (FINS)

Teco Electric & Machinery

TSDA Series AC Servo

ModBus Device/Slave (TCP/IP; Type 2)

Sysmac CP Series (FINS)

TP03 Series (Modbus RTU)

CMZ Sistemi Elettronici FCT Controllers(TCP/IP; Type 2)

E5CN Temperature (CompoWay/F)

TP02 Series

DEIF A/S

TCP/IP Modbus (Ethernet port)

E5CN Temperature (Modbus RTU)

TSTA Series AC Servo

EasyIO

EasyIO-30 (RTU)

EJ1 Temperature (CompoWay/F)

TESHOW ELECTRONIC.

MY90V/MY40V Series (RTU)

Fatek Automation Corp. Fatek FBs/FBe (TCP)

KM100 (CompoWay/F)

Texas Instruments

TI505

GE Corporation

SRTP Ethernet

3G3MV Inverter (RTU)

Thinget Electronic

XC Series Controller (RTU)

SRTP Ethernet (Micro)

Panasonic Corporation

MINAS A4 Series

Tieon Electronics

IPC-03 Series (RTU)

Hitachi

EH/EHV Series (Ethernet; TCP)

PanelMaster

N-to-1 Master (COM)

TOHO Electronics

TTX-700 (Modbus RTU)

EH/EHV Series (Ethernet; UDP)

2-to-1 Server (COM)

TTM-000 Series (TOHO Protocol) Honeywell

BACnet/IP

2-to-1 Transparent Server (COM)

TTM-200 Series (TOHO Protocol) JETTER

JetControl 24x Series (Ethernet)

Null PLC

TOKY ELECRTICAL

DW8-CD18B

Lenze Drive Systems GmbH E94AYCEN GCI(TCP/IP) Protocol

General Device (COM)

Toshiba Schneider Inverter Corporation TOSVERT VF Series(Modbus RTU) Mirle Automation Corporation Fama SoftPLC Ethernet

Data Sharer (RS485)

Unitronics

Vision 120 Series (Modbus RTU)


Modbus Master (RTU)

Vertex Technology

VT26/30 Series Controllers (RTU)

Mitsubishi Electric Corp. Q Ethernet

Modbus Master (RTU; Little Memory) Vigor Corporation

M/VB Series

Modicon Corp.

ModBus Master (TCP/IP)


Vware

N-to-1 Master (COM)


Modbus Device/Slave (RTU)

Null PLC

ModBus Master (TCP/IP; Type 2)

Modbus Device/Slave (Word order in big-

General Device (COM)

ModBus Device/Slave (TCP/IP; Type 2)

endian)

Modbus Device/Slave (RTU; No block read)

Modbus Device/Slave (RTU, 30Words)

Modbus Device/Slave (ASCII)

Wanfeng Electric

YABOS

Data Sharer (RS485)

Multi-drop Client (COM)

WF Series

Hospital System

Omron Corporation

PanelMaster

Sysmac CS/CJ Series FINS/TCP

N-to-1 Master (Ethernet)

Data Sharer (UDP)

Modbus Device/Slave (ASCII; No block read)

Dentists

Ping

Barcode Scanner

YAMAHA MOTOR

Single-axis Robot Controller ERCD

Modbus Device/Slave (TCP/IP)

Epson Matrix Printer

Yamatake Corporation

SDC35/36 Temperature (RTU)

Internal Memory

PC Series PLC Module

SDC35/36 Temperature (ASCII)

TCP/IP Gateway Server

Serial Gateway Server

MA500 FA Controller (ECL Host)

Internal Memory Server

2-to-1 Client (COM)

DMC10 Controller (RTU)

N-to-1 Slave (Ethernet)

Multi-drop Client (COM)

DMC10 Controller (ASCII)

N-to-1 Client (Ethernet)

Pan-Globe Corp.

E9 Temperature Series

MX30

PORIS

XC ModBus TCP

E904 Temperature (RTU)

MX50

Saia Burgess

PCD Series (Ether-S-Bus)

HT Series Temperature Controller

Yaskawa Corporation

Σ-ΣSGDM/H Series AC Servo

Siemens AG

Simatic S7-300 Ethernet Module (CP343)

Parker Hannifin

Compax3

MP Series Controller (Memobus)

SIMATIC S7 (Ethernet)

PORIS

XC Modbus RTU

V7 inverter (Memobus)

TPM

EPC-1000

RICH Electric Co., LTD.

EI-500 Series (RTU)

NS600 Servo Controller

Vware

N-to-1 Master (Ethernet)

EI-9001 Series (RTU)

YE-LI ELECTRIC & MACHINERY

YPV Servo Controller

N-to-1 Slave (Ethernet)

RKC Instrument Inc.

Saia Burgess

MA900/CB900 Series (RTU)

CD/CH Series (ASCII)

PCD Series (S-Bus PGU)

Yokogawa Electric

Yudian Automation Technology Ltd.

YJD Servo Controller

FA-M3 Series (CPU Port)

AI-7048 (AiBus)

WAGO Kontakttechnik GmbH

& Co. KG

Yaskawa Corporation

WAGO-I/O-SYSTEM 750


Extended MEMOBUS

PCD Series (S-Bus, Data Mode)

AI518/708/808/518P/708P/808P

Controller (AIbus)

Yokogawa Electric Corporation FA-M3 Series (UDP)

Samwon Technology

NOVA Series (RTU)

Zhuhai Motion Control

BP Series PSDA driver (RTU)

FA-M3 Series (TCP)

Schneider Electric

ATV31 Inverter (RTU)

Lexium 23 Servo Controller (ASCII)

Notes:

Sharp Corporation

JW10/20 Series

* The listing brand names are in alphabetical order

Shenzhen Step Servo Ltd. Kinco Servo Controller

* Driver list may be updated at any time, please contact with your representative at any time to confirm latest information.

Shihlin Electric&Engineering Corp. SH Inverter

Key Features:

* High-performance discrete drives for high data acquisition

SHIMAX CO., LTD.

MAC3 Series (RTU)

* The communication speed of Simatic S7-300(MPI port) can reach 187.5 kbps without adapter.

Shinko Technos Co., Ltd. CPT-20A MODBUS DEVICE/SLAVE (ASCII)

25 26

Driver List

PM Designer Software - Delmation

Transform your PDFs into Flipbooks and boost your revenue!

PM Designer Software - Delmation

Transform your PDFs into Flipbooks and boost your revenue!

Delete template?

Save as template ?
