2017<br />
2017 International Distributor Price List<br />
PRICES EFFECTIVE 4/1/2017
Contents<br />
<strong>Sub</strong>-<strong>Zero</strong> Model Overview . . . . . . . . . . . . . . . . . . 3<br />
Built-In Refrigeration . . . . . . . . . . . . . . . . . . . . . 9<br />
Professional Refrigeration . . . . . . . . . . . . . . . . . . 24<br />
Integrated Refrigeration . . . . . . . . . . . . . . . . . . . 27<br />
Wine Storage . . . . . . . . . . . . . . . . . . . . . . . . 41<br />
Accessory Handles. . . . . . . . . . . . . . . . . . . . . 49<br />
<strong>Sub</strong>-<strong>Zero</strong> Warranties . . . . . . . . . . . . . . . . . . . . . 52<br />
Model numbers, specifications and prices are subject to change<br />
at any time without notice.<br />
Indicates Star-K certified.
Built-In Refrigeration<br />
MODEL ICBBI-36R ICBBI-36F ICBBI-36UID ICBBI-36UFDID ICBBI-42UFDID<br />
Product Type Over-and-Under Over-and-Under Over-and-Under<br />
Description All Refrigerator All Freezer Refrigerator/Freezer Refrigerator/Freezer Refrigerator/Freezer<br />
MODEL / INSTALLATION OPTIONS<br />
Built-In • • • • •<br />
Overlay<br />
•<br />
Integrated<br />
Side Panels • • • • •<br />
Dual Installation • • •<br />
PRICES<br />
Overlay / Integrated<br />
Stainless Steel (tubular handle)<br />
Stainless Steel (pro handle)<br />
SPECIFICATIONS<br />
Width (mm) 914 914 914 914 1067<br />
Height (mm) 2134 2134 2134 2134 2134<br />
Depth (mm) 610 610 610 610 610<br />
Door Clearance (mm) 946 946 946* 600 600<br />
Refrigerator Capacity (L)** 613 367 357 420<br />
Freezer Capacity (L)** 612 143 144 220<br />
Wine Storage (750 ml bottles)<br />
Temperature Zones 1 1 2 2 2<br />
Wine Temperature (°C)<br />
*For flush inset, add 13 mm. **Usable volume based on ISO 15502.<br />
FEATURES<br />
Dual Refrigeration • • •<br />
Ice Maker • • • •<br />
Max Ice • • • •<br />
Air Purification System • • • •<br />
Water Filtration System • • • •<br />
Refrigerator Shelves / Door Shelves 4 / 5 3 / 3 3 / 6 6 / 6<br />
Refrigerator Drawers 3 2 2 3<br />
Freezer Shelves / Door Shelves 3 / 5<br />
Freezer Drawers 3 2-tier 2-tier 2-tier<br />
Wine Racks<br />
Internal Water Dispenser • • •<br />
Ice / Water Dispenser<br />
Dairy Compartment • • 2 2<br />
TECHNICAL DATA<br />
Energy Class A+ A+ A+ A+ A+<br />
Temperature Rating Tropical Tropical Tropical Tropical Tropical<br />
Energy Use (kWh/yr) 175 558 412 415 417<br />
Voltage 220–240 220–240 220–240 220–240 220–240<br />
Electrical Load (amp) 1.5 3.3 4 4 4<br />
Decibel Rating 32 34 36 36 36<br />
Frequency (Hz) 50/60 50/60 50/60 50/60 50/60<br />
PRICES EFFECTIVE 4/1/2017<br />
3
Built-In Refrigeration<br />
MODEL ICBBI-36S ICBBI-42S ICBBI-42SD ICBBI-48S ICBBI-48SID ICBBI-48SD<br />
Product Type Side-by-Side Side-by-Side Side-by-Side Side-by-Side Side-by-Side Side-by-Side<br />
Description Refrigerator/Freezer Refrigerator/Freezer Refrigerator/Freezer Refrigerator/Freezer Refrigerator/Freezer Refrigerator/Freezer<br />
MODEL / INSTALLATION OPTIONS<br />
Built-In • • • • • •<br />
Overlay • • • • • •<br />
Integrated<br />
Side Panels • • • • • •<br />
Dual Installation<br />
PRICES<br />
Overlay / Integrated<br />
Stainless Steel (tubular handle)<br />
Stainless Steel (pro handle)<br />
SPECIFICATIONS<br />
Width (mm) 914 1067 1067 1219 1219 1219<br />
Height (mm) 2134 2134 2134 2134 2134 2134<br />
Depth (mm) 610 610 610 610 610 610<br />
Door Clearance (mm) 565* 668* 668 762* 762* 762*<br />
Refrigerator Capacity (L)** 328 430 408 500 491 478<br />
Freezer Capacity (L)** 225 220 194 264 244 244<br />
Wine Storage (750 ml bottles)<br />
Temperature Zones 2 2 2 2 2 2<br />
Wine Temperature (°C)<br />
*For flush inset, add 13 mm. **Usable volume based on ISO 15502.<br />
FEATURES<br />
Dual Refrigeration • • • • • •<br />
Ice Maker • • • • • •<br />
Max Ice • • • • • •<br />
Air Purification System • • • • • •<br />
Water Filtration System • • • • • •<br />
Refrigerator Shelves / Door Shelves 4 / 5 4 / 5 4 / 5 4 / 5 4 / 5 4 / 5<br />
Refrigerator Drawers 3 3 3 3 3 3<br />
Freezer Shelves / Door Shelves 3 / 5 3 / 5 2 / 5 3 / 5 2 / 5 2 / 5<br />
Freezer Drawers 3 3 3 3 3 3<br />
Wine Racks<br />
Internal Water Dispenser<br />
•<br />
Ice / Water Dispenser • • •<br />
Dairy Compartment • • • • • •<br />
TECHNICAL DATA<br />
Energy Class A+ A+ A+ A++ A+ A+<br />
Temperature Rating Tropical Tropical Tropical Tropical Tropical Tropical<br />
Energy Use (kWh/yr) 480 515 480 463 566 557<br />
Voltage 220–240 220–240 220–240 220–240 220–240 220–240<br />
Electrical Load (amp) 3.5 4.1 4.1 4.1 4.1 4.1<br />
Decibel Rating 32 35 34 37 33 33<br />
Frequency (Hz) 50/60 50/60 50/60 50/60 50/60 50/60<br />
4
PRO 48 Refrigeration<br />
MODEL ICB648PRO ICB648PROG<br />
Product Type Side-by-Side Side-by-Side<br />
Description Refrigerator/Freezer Refrigerator/Freezer<br />
MODEL / INSTALLATION OPTIONS<br />
Built-In • •<br />
Overlay<br />
Integrated<br />
Enclosure Panels • •<br />
Dual Installation<br />
PRICES<br />
Overlay / Integrated<br />
Stainless Steel (tubular handle)<br />
Stainless Steel (pro handle)<br />
SPECIFICATIONS<br />
Width (mm) 1219 1219<br />
Height (mm) 2134 2134<br />
Depth (mm) 610 610<br />
Door Clearance (mm) 781 781<br />
Refrigerator Capacity (L)** 476 476<br />
Freezer Capacity (L)** 298 298<br />
Wine Storage (750 ml bottles)<br />
Temperature Zones 2 2<br />
Wine Temperature (°C)<br />
*For flush inset, add 13 mm. **Usable volume based on ISO 15502.<br />
FEATURES<br />
Dual Refrigeration • •<br />
Ice Maker • •<br />
Max Ice<br />
Air Purification System<br />
Water Filtration System • •<br />
Refrigerator Shelves / Door Shelves 4 / 0 4 / 0<br />
Refrigerator Drawers 2 2<br />
Freezer Shelves / Door Shelves 3 / 0 3 / 0<br />
Freezer Drawers 2 2<br />
Wine Racks<br />
Internal Water Dispenser<br />
Ice / Water Dispenser<br />
Dairy Compartment<br />
TECHNICAL DATA<br />
Energy Class A+ A+<br />
Temperature Rating Tropical Tropical<br />
Energy Use (kWh/yr) 642 642<br />
Voltage 220–240 220–240<br />
Electrical Load (amp) 3.8 3.8<br />
Decibel Rating 35 35<br />
Frequency (Hz) 50/60 50/60<br />
PRICES EFFECTIVE 4/1/2017<br />
5
Integrated Refrigeration<br />
MODEL ICBIC-18FI ICBIC-24R ICBIC-24FI ICBIC-24C ICBIC-30RID ICBIC-30FI ICBIC-36RID<br />
Product Type Column Column Column Column Column Column Column<br />
Description Freezer Refrigerator Freezer Refrigerator/Freezer Refrigerator Freezer Refrigerator<br />
MODEL / INSTALLATION OPTIONS<br />
Built-In<br />
Overlay<br />
Integrated • • • • • • •<br />
Enclosure Panels • • • • • • •<br />
Dual Installation • • • • • • •<br />
PRICES<br />
Overlay / Integrated<br />
Stainless Steel (tubular handle)<br />
Stainless Steel (pro handle)<br />
SPECIFICATIONS<br />
Width (mm) 457 610 610 610 762 762 914<br />
Height (mm) 2134 2134 2134 2134 2134 2134 2134<br />
Depth (mm) 610 610 610 610 610 610 610<br />
Door Clearance (mm) 419 572 572 572 724 724 876<br />
Refrigerator Capacity (L)** 352 193 475 606<br />
Freezer Capacity (L)** 230 338 58 415<br />
Wine Storage (750 ml bottles)<br />
Temperature Zones 1 1 1 1 1 1<br />
Wine Temperature (°C)<br />
*For flush inset, add 13 mm. **Usable volume based on ISO 15502.<br />
FEATURES<br />
Dual Refrigeration<br />
•<br />
Ice Maker • • •<br />
Max Ice • • •<br />
Air Purification System • • • •<br />
Water Filtration System • • • • •<br />
Refrigerator Shelves / Door Shelves 3 / 5 3 / 3 3 / 5 3 / 5<br />
Refrigerator Drawers 3 1 3 3<br />
Freezer Shelves / Door Shelves 3 / 4 3 / 5 3 / 5<br />
Freezer Drawers 3 3 2 3<br />
Wine Racks<br />
Internal Water Dispenser • •<br />
Ice / Water Dispenser<br />
Dairy Compartment • • • •<br />
TECHNICAL DATA<br />
Energy Class A+ A+ A+ A+ A+ A+ A+<br />
Temperature Rating Tropical Tropical Tropical Tropical Tropical Tropical Tropical<br />
Energy Use (kWh/yr) 326 152 369 261 159 399 172<br />
Voltage 220–240 220–240 220–240 220–240 220–240 220–240 220–240<br />
Electrical Load (amp) 2.2 0.7 2.4 1.2 0.5 2.5 0.6<br />
Decibel Rating 46 44 46 45 42 45 42<br />
Frequency (Hz) 50/60 50/60 50/60 50/60 50/60 50/60 50/60<br />
6
Integrated Refrigeration<br />
MODEL ICBIT-30RID ICBIT-30CIID ICBIT-36CIID ICBID-24RO ICBID-30RP ICBID-30CI<br />
Product Type Tall Tall Tall Drawers Drawers Drawers<br />
Description Refrigerator Refrigerator/Freezer Refrigerator/Freezer Refrigerator Refrigerator Refrigerator/Freezer<br />
MODEL / INSTALLATION OPTIONS<br />
Built-In<br />
Overlay<br />
Integrated • • • • • •<br />
Enclosure Panels • • •<br />
Dual Installation • • • • • •<br />
PRICES<br />
Overlay / Integrated<br />
Stainless Steel (tubular handle)<br />
Stainless Steel (pro handle)<br />
SPECIFICATIONS<br />
Width (mm) 762 762 914 610 762 762<br />
Height (mm) 2134 2134 2134 876 876 876<br />
Depth (mm) 610 610 610 610 610 610<br />
Door/Drawer Clearance (mm) 724 724 876 451 451 451<br />
Refrigerator Capacity (L)** 397 295 359 71 108 58<br />
Freezer Capacity (L)** 95 130 39<br />
Wine Storage (750 ml bottles)<br />
Temperature Zones 1 2 2 1 1 2<br />
Wine Temperature (°C)<br />
*For flush inset, add 13 mm. **Usable volume based on ISO 15502.<br />
FEATURES<br />
Dual Refrigeration • •<br />
Ice Maker • • •<br />
Max Ice • • •<br />
Air Purification System • • • •<br />
Water Filtration System • • •<br />
Refrigerator Shelves / Door Shelves 3 / 3 3 / 3 3 / 3<br />
Refrigerator Drawers 2 1 1 2 2 1<br />
Freezer Shelves / Door Shelves<br />
Freezer Drawers 2 2 1<br />
Wine Racks<br />
Internal Water Dispenser • • •<br />
Ice / Water Dispenser<br />
Dairy Compartment • • •<br />
TECHNICAL DATA<br />
Energy Class A+ A+ A+ A++ A++ A+<br />
Temperature Rating Tropical Tropical Tropical Tropical Tropical Tropical<br />
Energy Use (kWh/yr) 150 339 399 86 94 189<br />
Voltage 220–240 220–240 220–240 220–240 220–240 220–240<br />
Electrical Load (amp) 2 4.5 4.3 0.6 0.6 1.8<br />
Decibel Rating 42 44 44 42 42 44<br />
Frequency (Hz) 50/60 50/60 50/60 50/60 50/60 50/60<br />
PRICES EFFECTIVE 4/1/2017<br />
7
Wine Storage<br />
MODEL ICBUW-24FS ICBUW-24 ICBIW-18 ICBIW-24 ICBIW-30 ICBIW-30R ICBBW-30<br />
Product Type Wine Storage Wine Storage Wine Storage Wine Storage Wine Storage Wine Storage Wine Storage<br />
Description Freestanding Undercounter Refrigerator Drawers<br />
MODEL / INSTALLATION OPTIONS<br />
Built-In • •<br />
Overlay • •<br />
Integrated • • • •<br />
Freestanding<br />
•<br />
Enclosure Panels • • • •<br />
Dual Installation • • • • • •<br />
PRICES<br />
Overlay / Integrated<br />
Stainless Steel (tubular handle)<br />
Stainless Steel (pro handle)<br />
SPECIFICATIONS<br />
Width (mm) 616 606 457 610 762 762 762<br />
Height (mm) 868 864 2134 2134 2134 2134 2134<br />
Depth (mm) 625 610 610 610 610 610 610<br />
Door Clearance (mm) 645 645 419 572 724 724 796<br />
Refrigerator Capacity (L)** 113<br />
Freezer Capacity (L)**<br />
Wine Storage (750 ml bottles) 46 46 59 102 146 86 146<br />
Temperature Zones 2 2 2 2 2 3 2<br />
Wine Temperature (°C) 4–18 4–18 4–18 4–18 4–18 4–18 4–18<br />
*For flush inset, add 13 mm. **Usable volume based on ISO 15502.<br />
FEATURES<br />
Dual Refrigeration<br />
Ice Maker<br />
Max Ice<br />
Air Purification System<br />
Water Filtration System<br />
Refrigerator Shelves / Door Shelves<br />
Refrigerator Drawers 2<br />
Freezer Shelves / Door Shelves<br />
Freezer Drawers<br />
Wine Racks 5 5 15 15 15 8 14<br />
Internal Water Dispenser<br />
Ice / Water Dispenser<br />
Dairy Compartment<br />
TECHNICAL DATA<br />
Energy Class B B A A A+ A+ B<br />
Temperature Rating Tropical Tropical Tropical Tropical Tropical Tropical Tropical<br />
Energy Use (kWh/yr) 201 201 146 153 136 452 232<br />
Voltage 220–240 220–240 220–240 220–240 220–240 220–240 220–240<br />
Electrical Load (amp) 1 1 0.3 0.3 0.3 1.5 1<br />
Decibel Rating 51 51 44 42 42 42 38<br />
Frequency (Hz) 50/60 50/60 50/60 50/60 50/60 50/60 50/60<br />
8
Built-In Refrigeration<br />
Built-In Refrigeration<br />
<strong>Sub</strong>-<strong>Zero</strong> designers and engineers continue to perfect the<br />
built-in line. The addition of LED lighting throughout and several<br />
new models with internal water dispensers, along with the same<br />
advanced food preservation technology <strong>Sub</strong>-<strong>Zero</strong> is known for,<br />
make the built-in line nothing short of revolutionary.<br />
All Refrigerator / All Freezer Models<br />
• Handle options coordinate with handles of Wolf cooking<br />
products.<br />
• Dual refrigeration preserves food’s goodness in two sealed<br />
compartments.<br />
• Energy efficient.<br />
• Advanced water filtration and air purification systems.<br />
ICBBI-36R<br />
ICBBI-36F<br />
• Crisper and deli drawers form a lower-temperature zone<br />
for produce and meats.<br />
Over-and-Under Models<br />
• Flip-up grille provides easy access for routine maintenance.<br />
• One 90° door stop included.<br />
• All models are Star-K certified.<br />
MODEL NUMBER KEY<br />
International Certified Body (ICB) Approved Model<br />
ICB<br />
Built-In Refrigeration<br />
BI<br />
All Refrigerator<br />
R<br />
All Freezer<br />
F<br />
Over-and-Under<br />
U<br />
Side-by-Side<br />
S<br />
French Door<br />
FD<br />
Ice and Water Dispenser<br />
D<br />
Internal Dispenser<br />
ID<br />
Overlay Model /O<br />
Stainless Steel Model /S<br />
Tubular Handle<br />
/TH<br />
Pro Handle<br />
/PH<br />
Right-Hinge<br />
-RH<br />
Left-Hinge<br />
-LH<br />
ICBBI-36UID ICBBI-36UFDID ICBBI-42UFDID<br />
Side-by-Side Models<br />
ICBBI-36S ICBBI-42S ICBBI-42SD<br />
Models shown in the stainless steel design with tubular handles.<br />
Specify right-hinge (-RH) or left-hinge (-LH) door when ordering.<br />
ICBBI-48S<br />
ICBBI-48SID<br />
ICBBI-48SD<br />
9
Built-In Refrigeration<br />
91 cm All Refrigerator<br />
Accessories<br />
Grilles<br />
FINISHED HEIGHT NUMBER MSRP<br />
2134<br />
mm<br />
OVERLAY OR FLUSH INSET<br />
2108 mm Grille Frame 7003531<br />
2134 mm Grille Frame 7007136<br />
2235 mm Grille Frame 7003535<br />
STAINLESS STEEL<br />
2108 mm Pro Louvered 7003543<br />
2134 mm Pro Louvered 7007132<br />
2235 mm Pro Louvered 7003547<br />
610<br />
mm<br />
914<br />
mm<br />
Model ICBBI-36R<br />
MODEL<br />
ICBBI-36R/S/TH<br />
ICBBI-36R/S/PH<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Shipping Weight<br />
MSRP<br />
914 mm W x 2134 mm H x 610 mm D<br />
191 kg<br />
Single Flush Inset—Stainless Steel<br />
DESCRIPTION NUMBER MSRP<br />
GRILLE*<br />
Solid SS Panel 7008869<br />
Pro Louvered 7020158<br />
TUBULAR HANDLE<br />
Door Panel 7030216<br />
PRO HANDLE<br />
Door Panel 7008884<br />
*2134 mm finished height.<br />
FEATURES<br />
4 adjustable glass shelves • high-humidity drawer with dividers<br />
• 2 storage drawers with dividers • 3 adjustable and 2 stationary<br />
door shelves • adjustable dairy compartment • air purification<br />
system<br />
10
Built-In Refrigeration<br />
Accessories<br />
Dual Flush Inset—Stainless Steel<br />
DESCRIPTION NUMBER MSRP<br />
DUAL WIDE GRILLE*<br />
1676 mm Solid Stainless<br />
Steel Panel<br />
1829 mm Solid Stainless<br />
Steel Panel<br />
TUBULAR HANDLE<br />
Door Panel 7030215<br />
PRO HANDLE<br />
*2134 mm finished height. Solid stainless steel dual wide grille panel<br />
requires purchase and use of a dual wide grille frame.<br />
Dual Installation Kit with Dual Wide Grille<br />
DESCRIPTION NUMBER MSRP<br />
OVERLAY OR FLUSH INSET<br />
7013367<br />
7008881<br />
Door Panel 7008853<br />
1676 mm Grille Frame 7012661<br />
1829 mm Grille Frame 7010483<br />
STAINLESS STEEL FLUSH INSET<br />
1676 mm Pro Louvered 7020684<br />
1829 mm Pro Louvered 7020685<br />
STAINLESS STEEL<br />
1676 mm Pro Louvered 7012662<br />
1829 mm Pro Louvered 7010485<br />
Dual Installation Kit<br />
DESCRIPTION NUMBER MSRP<br />
Dual Installation Kit 7010486<br />
Kit includes center trim strip, heater and mounting hardware.<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
REPLACEMENT CARTRIDGE<br />
Air Purification (50) 7010799<br />
MOUNTING KIT<br />
Custom Front Panel 7020607<br />
Custom Side Panel 7003407<br />
SIDE PANELS<br />
Stainless Steel 7003408<br />
White Enamel 7003409<br />
KICKPLATES<br />
Stainless Steel RH 7010371<br />
Stainless Steel LH 7010372<br />
Egg Container 7007506<br />
90° Door Stop 7005865<br />
Kit includes dual wide kickplate and dual wide grille for 2134 mm<br />
finished height, center trim strip, heater and mounting hardware.<br />
PRICES EFFECTIVE 4/1/2017<br />
11
Built-In Refrigeration<br />
91 cm All Freezer Accessories<br />
Grilles<br />
FINISHED HEIGHT NUMBER MSRP<br />
2134<br />
mm<br />
OVERLAY OR FLUSH INSET<br />
2108 mm Grille Frame 7003531<br />
2134 mm Grille Frame 7007136<br />
2235 mm Grille Frame 7003535<br />
STAINLESS STEEL<br />
2108 mm Pro Louvered 7003543<br />
2134 mm Pro Louvered 7007132<br />
2235 mm Pro Louvered 7003547<br />
610<br />
mm<br />
914<br />
mm<br />
Model ICBBI-36F<br />
MODEL<br />
ICBBI-36F/S/TH<br />
ICBBI-36F/S/PH<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Shipping Weight<br />
MSRP<br />
914 mm W x 2134 mm H x 610 mm D<br />
184 kg<br />
Single Flush Inset—Stainless Steel<br />
DESCRIPTION NUMBER MSRP<br />
GRILLE*<br />
Solid SS Panel 7008869<br />
Pro Louvered 7020158<br />
TUBULAR HANDLE<br />
Door Panel 7030216<br />
PRO HANDLE<br />
Door Panel 7008884<br />
*2134 mm finished height.<br />
FEATURES<br />
3 adjustable wire shelves • 3 storage drawers with dividers • 5<br />
adjustable door shelves • automatic ice maker • water filtration<br />
system<br />
12
Built-In Refrigeration<br />
Accessories<br />
Dual Flush Inset—Stainless Steel<br />
DESCRIPTION NUMBER MSRP<br />
DUAL WIDE GRILLE*<br />
1676 mm Solid Stainless<br />
Steel Panel<br />
1829 mm Solid Stainless<br />
Steel Panel<br />
TUBULAR HANDLE<br />
Door Panel 7030215<br />
PRO HANDLE<br />
*2134 mm finished height. Solid stainless steel dual wide grille panel<br />
requires purchase and use of a dual wide grille frame.<br />
Dual Installation Kit with Dual Wide Grille<br />
DESCRIPTION NUMBER MSRP<br />
OVERLAY OR FLUSH INSET<br />
7013367<br />
7008881<br />
Door Panel 7008853<br />
1676 mm Grille Frame 7012661<br />
1829 mm Grille Frame 7010483<br />
STAINLESS STEEL FLUSH INSET<br />
1676 mm Pro Louvered 7020684<br />
1829 mm Pro Louvered 7020685<br />
STAINLESS STEEL<br />
1676 mm Pro Louvered 7012662<br />
1829 mm Pro Louvered 7010485<br />
Dual Installation Kit<br />
DESCRIPTION NUMBER MSRP<br />
Dual Installation Kit 7010486<br />
Kit includes center trim strip, heater and mounting hardware.<br />
Water Filter<br />
DESCRIPTION NUMBER MSRP<br />
REPLACEMENT FILTER<br />
Water Filter (20) 7031688<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
MOUNTING KIT<br />
Custom Front Panel 7020607<br />
Custom Side Panel 7003407<br />
SIDE PANELS<br />
Stainless Steel 7003408<br />
White Enamel 7003409<br />
KICKPLATES<br />
Stainless Steel RH 7010371<br />
Stainless Steel LH 7010372<br />
90° Door Stop 7005865<br />
Kit includes dual wide kickplate and dual wide grille for 2134 mm<br />
finished height, center trim strip, heater and mounting hardware.<br />
PRICES EFFECTIVE 4/1/2017<br />
13
Built-In Refrigeration<br />
91 cm Over-and-Under with Internal Dispenser Accessories<br />
Grilles<br />
FINISHED HEIGHT NUMBER MSRP<br />
2134<br />
mm<br />
OVERLAY OR FLUSH INSET<br />
2108 mm Grille Frame 7003531<br />
2134 mm Grille Frame 7007136<br />
2235 mm Grille Frame 7003535<br />
STAINLESS STEEL<br />
2108 mm Pro Louvered 7003543<br />
2134 mm Pro Louvered 7007132<br />
2235 mm Pro Louvered 7003547<br />
610<br />
mm<br />
914<br />
mm<br />
Retrofit Panel Kit<br />
DESCRIPTION NUMBER MSRP<br />
Overlay or Flush Inset 7003402<br />
Model ICBBI-36UID<br />
MODEL<br />
ICBBI-36UID/O<br />
ICBBI-36UID/S/TH<br />
ICBBI-36UID/S/PH<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Shipping Weight<br />
FEATURES<br />
MSRP<br />
914 mm W x 2134 mm H x 610 mm D<br />
Refrigerator—internal water dispenser • 3 adjustable glass<br />
shelves • high-humidity drawer with dividers • storage drawer<br />
with dividers • 2 adjustable and 1 stationary door shelves •<br />
adjustable dairy compartment • air purification system<br />
234 kg<br />
Freezer—automatic ice maker • full-extension drawer with 2-tier<br />
wire baskets • water filtration system<br />
Retrofit existing 600 series panels onto a new built-in model. Grille panel<br />
must be reduced in height by 25 mm.<br />
Single Flush Inset Panels—Stainless Steel<br />
DESCRIPTION NUMBER MSRP<br />
GRILLE*<br />
Solid Stainless Steel Panel 7008869<br />
Pro Louvered 7020158<br />
TUBULAR HANDLE<br />
Door Panel 7030233<br />
Drawer Panel 7029743<br />
PRO HANDLE<br />
Door Panel 7008899<br />
Drawer Panel 7008902<br />
*2134 mm finished height.<br />
14
Built-In Refrigeration<br />
Accessories<br />
Dual Flush Inset Panels—Stainless Steel<br />
DESCRIPTION NUMBER MSRP<br />
Dual Installation Kit<br />
DESCRIPTION NUMBER MSRP<br />
DUAL WIDE GRILLE*<br />
1676 mm Solid Stainless<br />
Steel Panel<br />
1829 mm Solid Stainless<br />
Steel Panel<br />
7013367<br />
7008881<br />
ALL DESIGNS<br />
Dual Installation Kit 7010486<br />
Kit includes center trim strip, heater and mounting hardware.<br />
TUBULAR HANDLE<br />
Door Panel 7030230<br />
Drawer Panel RH 7030240<br />
Drawer Panel LH 7030241<br />
PRO HANDLE<br />
Door Panel 7008843<br />
Drawer Panel RH 7008846<br />
Drawer Panel LH 7008849<br />
*2134 mm finished height. Solid stainless steel panel requires dual<br />
installation kit 7012623 or 7004811.<br />
Filters and Cartridges<br />
DESCRIPTION NUMBER MSRP<br />
REPLACEMENT FILTER<br />
Water Filter (20) 7031688<br />
REPLACEMENT CARTRIDGE<br />
Air Purification (50) 7010799<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
Dual Installation Kit with Dual Wide Grille<br />
DESCRIPTION NUMBER MSRP<br />
OVERLAY OR FLUSH INSET<br />
1676 mm Grille Frame 7012661<br />
1829 mm Grille Frame 7010483<br />
STAINLESS STEEL FLUSH INSET<br />
1676 mm Pro Louvered 7020684<br />
1829 mm Pro Louvered 7020685<br />
STAINLESS STEEL<br />
1676 mm Pro Louvered 7012662<br />
1829 mm Pro Louvered 7010485<br />
MOUNTING KITS<br />
Custom Front Panels 7020607<br />
Custom Side Panel 7003407<br />
SIDE PANELS<br />
Stainless Steel 7003408<br />
White Enamel 7003409<br />
Stainless Steel Kickplate 7010397<br />
Egg Container 7007506<br />
90° Door Stop 7005865<br />
Kit includes dual wide kickplate and dual wide grille for 2134 mm<br />
finished height, center trim strip, heater and mounting hardware.<br />
PRICES EFFECTIVE 4/1/2017<br />
15
Built-In Refrigeration<br />
91 cm Over-and-Under with French Door and<br />
Internal Dispenser<br />
Accessories<br />
Grilles<br />
FINISHED HEIGHT NUMBER MSRP<br />
2134<br />
mm<br />
STAINLESS STEEL<br />
2108 mm Pro Louvered 7003543<br />
2134 mm Pro Louvered 7007132<br />
2235 mm Pro Louvered 7003547<br />
610<br />
mm<br />
914<br />
mm<br />
Filters and Cartridges<br />
DESCRIPTION NUMBER MSRP<br />
REPLACEMENT FILTER<br />
Water Filter (20) 7031688<br />
REPLACEMENT CARTRIDGE<br />
Air Purification (50) 7010799<br />
Model ICBBI-36UFDID<br />
MODEL<br />
ICBBI-36UFDID/S/TH<br />
ICBBI-36UFDID/S/PH<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Shipping Weight<br />
FEATURES<br />
MSRP<br />
914 mm W x 2134 mm H x 610 mm D<br />
Refrigerator— internal water dispenser • 3 adjustable glass<br />
shelves • high-humidity drawer with dividers • storage drawer<br />
with dividers • 4 adjustable and 2 stationary door shelves • 2<br />
adjustable dairy compartments • air purification system<br />
240 kg<br />
Freezer—automatic ice maker • full-extension drawer with 2-tier<br />
wire baskets • water filtration system<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
MOUNTING KITS<br />
Custom Front Panels 7020607<br />
Custom Side Panel 7003407<br />
SIDE PANELS<br />
Stainless Steel 7003408<br />
White Enamel 7003409<br />
Stainless Steel Kickplate 7010397<br />
Egg Container 7007506<br />
90° Door Stop 7005865<br />
16
Built-In Refrigeration<br />
107 cm Over-and-Under with French Door<br />
and Internal Dispenser<br />
For availability contact your regional distributor.<br />
Accessories<br />
Grilles<br />
FINISHED HEIGHT NUMBER MSRP<br />
STAINLESS STEEL<br />
2108 mm Pro Louvered 7003544<br />
2134 mm Pro Louvered 7007133<br />
2235 mm Pro Louvered 7003548<br />
2134<br />
mm<br />
Filters and Cartridges<br />
DESCRIPTION NUMBER MSRP<br />
610<br />
mm 1067<br />
mm<br />
Model ICBBI-42UFDID<br />
MODEL<br />
ICBBI-42UFDID/S/TH<br />
ICBBI-42UFDID/S/PH<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Shipping Weight<br />
FEATURES<br />
MSRP<br />
1067 mm W x 2134 mm H x 610 mm D<br />
264 kg<br />
Refrigerator— internal water dispenser • 6 adjustable glass<br />
shelves • high-humidity drawer with dividers • 2 storage drawers<br />
• 4 adjustable and 2 stationary door shelves • 2 adjustable dairy<br />
compartments • air purification system<br />
Freezer—automatic ice maker • full-extension drawer with 2-tier<br />
wire baskets • water filtration system<br />
REPLACEMENT FILTER<br />
Water Filter (20) 7031688<br />
REPLACEMENT CARTRIDGE<br />
Air Purification (50) 7010799<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
MOUNTING KITS<br />
Custom Front Panels 7020607<br />
Custom Side Panel 7003407<br />
SIDE PANELS<br />
Stainless Steel 7003408<br />
White Enamel 7003409<br />
Stainless Steel Kickplate 7011039<br />
Egg Container 7007506<br />
90° Door Stop 7005865<br />
PRICES EFFECTIVE 4/1/2017<br />
17
Built-In Refrigeration<br />
91 cm Side-by-Side Accessories<br />
Flush Inset Panels—Stainless Steel<br />
DESCRIPTION NUMBER MSRP<br />
2134<br />
mm<br />
GRILLE*<br />
Solid Stainless Steel Panel 7008869<br />
Pro Louvered 7020158<br />
TUBULAR HANDLE<br />
Refrigerator Door Panel 7030218<br />
Freezer Door Panel 7030219<br />
PRO HANDLE<br />
Refrigerator Door Panel 7008908<br />
Freezer Door Panel 7008911<br />
*2134 mm finished height.<br />
610<br />
mm 914<br />
mm<br />
Model ICBBI-36S<br />
MODEL<br />
ICBBI-36S/O<br />
ICBBI-36S/S/TH<br />
ICBBI-36S/S/PH<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Shipping Weight<br />
FEATURES<br />
Accessories<br />
Grilles<br />
FINISHED HEIGHT NUMBER MSRP<br />
OVERLAY OR FLUSH INSET<br />
2108 mm Grille Frame 7003531<br />
2134 mm Grille Frame 7007136<br />
2235 mm Grille Frame 7003535<br />
STAINLESS STEEL<br />
2108 mm Pro Louvered 7003543<br />
2134 mm Pro Louvered 7007132<br />
2235 mm Pro Louvered 7003547<br />
MSRP<br />
914 mm W x 2134 mm H x 610 mm D<br />
244 kg<br />
Refrigerator—4 adjustable glass shelves • high-humidity drawer<br />
• 2 storage drawers • 3 adjustable and 2 stationary door shelves<br />
• adjustable dairy compartment • air purification system<br />
Freezer—automatic ice maker • 3 adjustable wire shelves • 3<br />
storage drawers • 5 adjustable door shelves • water filtration<br />
system<br />
Retrofit Panel Kit<br />
DESCRIPTION NUMBER MSRP<br />
Overlay 7011531<br />
Retrofit existing 600 series panels onto a new built-in model. Grille panel<br />
must be reduced in height by 25 mm.<br />
Filters and Cartridges<br />
DESCRIPTION NUMBER MSRP<br />
REPLACEMENT FILTER<br />
Water Filter (20) 7031688<br />
REPLACEMENT CARTRIDGE<br />
Air Purification (50) 7010799<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
MOUNTING KITS<br />
Custom Front Panels 7020607<br />
Custom Side Panel 7003407<br />
SIDE PANELS<br />
Stainless Steel 7003408<br />
White Enamel 7003409<br />
Stainless Steel Kickplate 7007266<br />
Egg Container 7007506<br />
90° Door Stop 7005865<br />
18
Built-In Refrigeration<br />
107 cm Side-by-Side<br />
Accessories<br />
Flush Inset Panels—Stainless Steel<br />
DESCRIPTION NUMBER MSRP<br />
2134<br />
mm<br />
GRILLE*<br />
Solid Stainless Steel Panel 7008871<br />
Pro Louvered 7020159<br />
TUBULAR HANDLE<br />
Refrigerator Door Panel 7030220<br />
Freezer Door Panel 7030221<br />
PRO HANDLE<br />
Refrigerator Door Panel 7008914<br />
Freezer Door Panel 7008917<br />
*2134 mm finished height.<br />
610<br />
mm 1067<br />
mm<br />
Model ICBBI-42S<br />
MODEL<br />
ICBBI-42S/O<br />
ICBBI-42S/S/TH<br />
ICBBI-42S/S/PH<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Shipping Weight<br />
FEATURES<br />
Accessories<br />
Grilles<br />
FINISHED HEIGHT NUMBER MSRP<br />
OVERLAY OR FLUSH INSET<br />
2108 mm Grille Frame 7003532<br />
2134 mm Grille Frame 7007137<br />
2235 mm Grille Frame 7003536<br />
STAINLESS STEEL<br />
2108 mm Pro Louvered 7003544<br />
2134 mm Pro Louvered 7007133<br />
2235 mm Pro Louvered 7003548<br />
MSRP<br />
1067 mm W x 2134 mm H x 610 mm D<br />
264 kg<br />
Refrigerator—4 adjustable glass shelves • high-humidity drawer<br />
with divider • 2 storage drawers with divider • 3 adjustable and<br />
2 stationary door shelves • adjustable dairy compartment • air<br />
purification system<br />
Freezer—automatic ice maker • 3 adjustable wire shelves • 3<br />
storage drawers • 5 adjustable door shelves • water filtration<br />
system<br />
Retrofit Panel Kit<br />
DESCRIPTION NUMBER MSRP<br />
Overlay 7003400<br />
Retrofit existing 600 series panels onto a new built-in model. Grille panel<br />
must be reduced in height by 25 mm.<br />
Filters and Cartridges<br />
DESCRIPTION NUMBER MSRP<br />
REPLACEMENT FILTER<br />
Water Filter (20) 7031688<br />
REPLACEMENT CARTRIDGE<br />
Air Purification (50) 7010799<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
MOUNTING KITS<br />
Custom Front Panels 7020607<br />
Custom Side Panel 7003407<br />
SIDE PANELS<br />
Stainless Steel 7003408<br />
White Enamel 7003409<br />
Stainless Steel Kickplate 7011039<br />
Egg Container 7007506<br />
90° Door Stop 7005865<br />
PRICES EFFECTIVE 4/1/2017<br />
19
Built-In Refrigeration<br />
107 cm Side-by-Side with Dispenser Accessories<br />
Grilles<br />
FINISHED HEIGHT NUMBER MSRP<br />
2134<br />
mm<br />
STAINLESS STEEL<br />
2108 mm Pro Louvered 7003544<br />
2134 mm Pro Louvered 7007133<br />
2235 mm Pro Louvered 7003548<br />
Filters and Cartridges<br />
DESCRIPTION NUMBER MSRP<br />
610<br />
mm 1067<br />
mm<br />
REPLACEMENT FILTER<br />
Water Filter (20) 7031688<br />
REPLACEMENT CARTRIDGE<br />
Air Purification (50) 7010799<br />
Model ICBBI-42SD<br />
MODEL<br />
ICBBI-42SD/S/TH<br />
ICBBI-42SD/S/PH<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Shipping Weight<br />
FEATURES<br />
MSRP<br />
1067 mm W x 2134 mm H x 610 mm D<br />
276 kg<br />
Refrigerator—4 adjustable glass shelves • high-humidity drawer<br />
with divider • 2 storage drawers with divider • 3 adjustable and<br />
2 stationary door shelves • adjustable dairy compartment • air<br />
purification system<br />
Freezer—automatic ice maker with dispenser • 2 adjustable wire<br />
shelves • 3 storage drawers • 5 adjustable door shelves • water<br />
filtration system<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
MOUNTING KIT<br />
Custom Side Panel 7003407<br />
SIDE PANELS<br />
Stainless Steel 7003408<br />
White Enamel 7003409<br />
Stainless Steel Kickplate 7011039<br />
Egg Container 7007506<br />
90° Door Stop 7005865<br />
20
Built-In Refrigeration<br />
122 cm Side-by-Side Accessories<br />
Flush Inset Panels—Stainless Steel<br />
DESCRIPTION NUMBER MSRP<br />
GRILLE*<br />
Solid Stainless Steel Panel 7008872<br />
Pro Louvered** 7020160<br />
2134<br />
mm<br />
TUBULAR HANDLE<br />
Refrigerator Door Panel 7030223<br />
Freezer Door Panel 7030224<br />
PRO HANDLE<br />
Refrigerator Door Panel 7008923<br />
Freezer Door Panel 7008926<br />
*2134 mm finished height.<br />
610<br />
mm 1219<br />
mm<br />
Retrofit Panel Kit<br />
Model ICBBI-48S<br />
MODEL<br />
ICBBI-48S/O<br />
ICBBI-48S/S/TH<br />
ICBBI-48S/S/PH<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Shipping Weight<br />
FEATURES<br />
MSRP<br />
1219 mm W x 2134 mm H x 610 mm D<br />
286 kg<br />
DESCRIPTION NUMBER MSRP<br />
Overlay 7003399<br />
Retrofit existing 600 series panels onto a new built-in model. Grille panel<br />
must be reduced in height by 25 mm.<br />
Filters and Cartridges<br />
DESCRIPTION NUMBER MSRP<br />
REPLACEMENT FILTER<br />
Water Filter (20) 7031688<br />
REPLACEMENT CARTRIDGE<br />
Air Purification (50) 7010799<br />
Refrigerator—4 adjustable glass shelves • high-humidity drawer<br />
with divider • 2 storage drawers with divider • 3 adjustable and<br />
2 stationary door shelves • adjustable dairy compartment • air<br />
purification system<br />
Freezer—automatic ice maker • 3 adjustable wire shelves • 3<br />
storage drawers • 5 adjustable door shelves • water filtration<br />
system<br />
Accessories<br />
Grilles<br />
FINISHED HEIGHT NUMBER MSRP<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
MOUNTING KITS<br />
Custom Front Panels 7020607<br />
Custom Side Panel 7003407<br />
SIDE PANELS<br />
Stainless Steel 7003408<br />
White Enamel 7003409<br />
Stainless Steel Kickplate 7011049<br />
Egg Container 7007506<br />
90° Door Stop 7005865<br />
OVERLAY OR FLUSH INSET<br />
2108 mm Grille Frame 7003533<br />
2134 mm Grille Frame 7007138<br />
2235 mm Grille Frame 7003537<br />
STAINLESS STEEL<br />
2108 mm Pro Louvered 7003545<br />
2134 mm Pro Louvered 7007134<br />
2235 mm Pro Louvered 7003549<br />
PRICES EFFECTIVE 4/1/2017<br />
21
Built-In Refrigeration<br />
122 cm Side-by-Side with Internal Dispenser<br />
Accessories<br />
Flush Inset Panels—Stainless Steel<br />
DESCRIPTION NUMBER MSRP<br />
GRILLE*<br />
Solid Stainless Steel Panel 7008872<br />
Pro Louvered** 7020160<br />
2134<br />
mm<br />
TUBULAR HANDLE<br />
Refrigerator Door Panel 7030223<br />
Freezer Door Panel 7030224<br />
PRO HANDLE<br />
Refrigerator Door Panel 7008923<br />
Freezer Door Panel 7008926<br />
*2134 mm finished height.<br />
610<br />
mm 1219<br />
mm<br />
Retrofit Panel Kit<br />
Model ICBBI-48SID<br />
MODEL<br />
ICBBI-48SID/O<br />
ICBBI-48SID/S/TH<br />
ICBBI-48SID/S/PH<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Shipping Weight<br />
FEATURES<br />
MSRP<br />
1219 mm W x 2134 mm H x 610 mm D<br />
298 kg<br />
DESCRIPTION NUMBER MSRP<br />
Overlay 7003399<br />
Retrofit existing 600 series panels onto a new built-in model. Grille panel<br />
must be reduced in height by 25 mm.<br />
Filters and Cartridges<br />
DESCRIPTION NUMBER MSRP<br />
REPLACEMENT FILTER<br />
Water Filter (20) 7031688<br />
REPLACEMENT CARTRIDGE<br />
Air Purification (50) 7010799<br />
Refrigerator—internal ice and water dispenser • 4 adjustable<br />
glass shelves • high-humidity drawer with divider • 2 storage<br />
drawers with divider • 3 adjustable and 2 stationary door shelves<br />
• adjustable dairy compartment • air purification system<br />
Freezer—automatic ice maker • 2 adjustable wire shelves • 3<br />
storage drawers • 5 adjustable door shelves • water filtration<br />
system<br />
Accessories<br />
Grilles<br />
FINISHED HEIGHT NUMBER MSRP<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
MOUNTING KITS<br />
Custom Front Panels 7020607<br />
Custom Side Panel 7003407<br />
SIDE PANELS<br />
Stainless Steel 7003408<br />
White Enamel 7003409<br />
Stainless Steel Kickplate 7011049<br />
Egg Container 7007506<br />
90° Door Stop 7005865<br />
OVERLAY OR FLUSH INSET<br />
2108 mm Grille Frame 7003533<br />
2134 mm Grille Frame 7007138<br />
2235 mm Grille Frame 7003537<br />
STAINLESS STEEL<br />
2108 mm Pro Louvered 7003545<br />
2134 mm Pro Louvered 7007134<br />
2235 mm Pro Louvered 7003549<br />
22
Built-In Refrigeration<br />
122 cm Side-by-Side with Dispenser Accessories<br />
Flush Inset Panels—Stainless Steel<br />
DESCRIPTION NUMBER MSRP<br />
GRILLE*<br />
Solid Stainless Steel Panel 7008872<br />
Pro Louvered** 7020160<br />
2134<br />
mm<br />
TUBULAR HANDLE<br />
Refrigerator Door Panel 7030225<br />
Freezer Door Panel 7030224<br />
PRO HANDLE<br />
Refrigerator Door Panel 7008929<br />
Freezer Door Panel 7008926<br />
*2134 mm finished height.<br />
610<br />
mm 1219<br />
mm<br />
Filters and Cartridges<br />
DESCRIPTION NUMBER MSRP<br />
Model ICBBI-48SD<br />
MODEL<br />
ICBBI-48SD/O<br />
ICBBI-48SD/S/TH<br />
ICBBI-48SD/S/PH<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Shipping Weight<br />
FEATURES<br />
MSRP<br />
1219 mm W x 2134 mm H x 610 mm D<br />
298 kg<br />
Refrigerator—4 adjustable glass shelves • high-humidity drawer<br />
with divider • 2 storage drawers with divider • 3 adjustable and<br />
2 stationary door shelves • adjustable dairy compartment • air<br />
purification system<br />
Freezer—automatic ice maker with dispenser • 3 adjustable wire<br />
shelves • 3 storage drawers • 5 adjustable door shelves • water<br />
filtration system<br />
REPLACEMENT FILTER<br />
Water Filter (20) 7031688<br />
REPLACEMENT CARTRIDGE<br />
Air Purification (50) 7010799<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
MOUNTING KITS<br />
Custom Front Panels 7020607<br />
Custom Side Panel 7003407<br />
SIDE PANELS<br />
Stainless Steel 7003408<br />
White Enamel 7003409<br />
Stainless Steel Kickplate 7011049<br />
Egg Container 7007506<br />
Door Stop 7005865<br />
Accessories<br />
Grilles<br />
FINISHED HEIGHT NUMBER MSRP<br />
OVERLAY OR FLUSH INSET<br />
2108 mm Grille Frame 7003533<br />
2134 mm Grille Frame 7007138<br />
2235 mm Grille Frame 7003537<br />
STAINLESS STEEL<br />
2108 mm Pro Louvered 7003545<br />
2134 mm Pro Louvered 7007134<br />
2235 mm Pro Louvered 7003549<br />
PRICES EFFECTIVE 4/1/2017<br />
23
Professional Refrigeration<br />
PRO 48 Refrigeration<br />
Freshness finds unmistakable expression in the <strong>Sub</strong>-<strong>Zero</strong><br />
PRO 48. A 363 kg monument to food preservation—equal<br />
parts sculpted metal design statement and culinary secret<br />
weapon. Its vast interior, like its bold exterior, is crafted of<br />
stainless steel. The PRO 48 is available with or without a<br />
glass door and may be either built in or freestanding.<br />
PRO 48 Models<br />
• Can be used freestanding or installed as a standard or<br />
flush built-in application.<br />
• Handles coordinate with handles of Wolf ranges.<br />
• Stainless steel interior as well as exterior.<br />
• Dual refrigeration system enhanced with triple evaporators<br />
allow independent control of storage conditions in<br />
refrigerator cabinet and drawer compartments.<br />
• Advanced water filtration system.<br />
• Exterior temperature display.<br />
• Flip-up grille provides easy access for quick routine<br />
maintenance.<br />
• Star-K certified.<br />
ICB648PRO<br />
ICB648PROG<br />
MODEL NUMBER KEY<br />
International Certified Body (ICB) Approved Model<br />
PRO 48 Refrigeration<br />
Glass Door<br />
ICB<br />
PRO<br />
G<br />
24
Professional Refrigeration<br />
122 cm Side-by-Side Accessories<br />
Stainless Steel Panels<br />
DESCRIPTION NUMBER MSRP<br />
Side Panel 0000043<br />
Top Panel* 4204360<br />
2134<br />
mm<br />
Front and Side Kickplates 0000055<br />
*Requires at least one side panel for proper installation.<br />
Miscellaneous<br />
610<br />
mm<br />
1219<br />
mm<br />
DESCRIPTION NUMBER MSRP<br />
REPLACEMENT FILTER<br />
Water Filter (20) 7031688<br />
Slide-Out Bin 0000045<br />
Drawer Divider Set 0000049<br />
90° Door Stop 0000046<br />
Model ICB648PRO<br />
MODEL<br />
ICB648PRO<br />
MSRP<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Shipping Weight<br />
1219 mm W x 2134 mm H x 610 mm D<br />
390 kg<br />
FEATURES<br />
Refrigerator—3 adjustable glass shelves • 2 stainless steel slideout<br />
bins • 2 storage drawers • crisper lid • set of interchangeable<br />
drawer dividers<br />
Freezer—automatic ice maker • 3 adjustable stainless steel<br />
shelves • 2 storage drawers • stainless steel ice bucket • water<br />
filtration system<br />
PRICES EFFECTIVE 4/1/2017<br />
25
Professional Refrigeration<br />
122 cm Side-by-Side with Glass Door Accessories<br />
Stainless Steel Panels<br />
DESCRIPTION NUMBER MSRP<br />
Side Panel 0000043<br />
Top Panel* 4204360<br />
2134<br />
mm<br />
Front and Side Kickplates 0000055<br />
*Requires at least one side panel for proper installation.<br />
Miscellaneous<br />
610<br />
mm<br />
1219<br />
mm<br />
DESCRIPTION NUMBER MSRP<br />
REPLACEMENT FILTER<br />
Water Filter (20) 7031688<br />
Slide-Out Bin 0000045<br />
Drawer Divider Set 0000049<br />
90° Door Stop 0000046<br />
Model ICB648PROG<br />
MODEL<br />
ICB648PROG<br />
MSRP<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Shipping Weight<br />
1219 mm W x 2134 mm H x 610 mm D<br />
397 kg<br />
FEATURES<br />
Refrigerator—3 adjustable glass shelves • 2 stainless steel slideout<br />
bins • 2 storage drawers • crisper lid • set of interchangeable<br />
drawer dividers • triple-pane, UV-resistant glass door<br />
Freezer—automatic ice maker • 3 adjustable stainless steel<br />
shelves • 2 storage drawers • stainless steel ice bucket • water<br />
filtration system<br />
PRICES EFFECTIVE 4/1/2017<br />
26
Integrated Refrigeration<br />
Integrated Refrigeration<br />
With custom cabinet fronts and hardware, <strong>Sub</strong>-<strong>Zero</strong> invented<br />
integrated columns, drawers and tall units that disappear into<br />
the decor. Integrated units fit flush with other cabinets, making<br />
integrated refrigeration as practical and beautiful in the master<br />
suite, bar or theatre room as in the kitchen.<br />
Column Models<br />
18" 18"<br />
18" 24" 24"<br />
(457) (457)<br />
(457)(610)<br />
(610)<br />
18" 24"<br />
(457)(610)<br />
30" 30"<br />
(762) (762)<br />
24"<br />
(610)<br />
30"<br />
(762)<br />
36" 36"<br />
(914) (914)<br />
30"<br />
(762)<br />
36"<br />
(914)<br />
MODEL NUMBER KEY<br />
84" 84"<br />
(2134) (2134)<br />
84"<br />
(2134)<br />
84"<br />
(2134)<br />
International Certified Body (ICB) Approved Model<br />
ICB<br />
Integrated Column<br />
IC<br />
Integrated Tall<br />
IT<br />
Integrated Drawers<br />
All Refrigerator<br />
ID<br />
R<br />
ICBIC-18FI<br />
ICBIC-24R<br />
ICBIC-24FI<br />
ICBIC-24C<br />
All Freezer<br />
Combination<br />
Internal Dispenser<br />
18"<br />
(457)<br />
18"<br />
(457)<br />
18" 24"<br />
(457) (610)<br />
F<br />
C<br />
ID<br />
24"<br />
(610)<br />
24" 30"<br />
(610) (762)<br />
24" 24"<br />
(610) (610)<br />
24"<br />
(610)<br />
30"<br />
(762)<br />
30"<br />
(762)<br />
27" 27"<br />
(686) (686)<br />
36"<br />
(914)<br />
24"<br />
(610)<br />
27"<br />
(686)<br />
36"<br />
(914)<br />
36"<br />
(914)<br />
30" 30"<br />
(762) (762)<br />
30"<br />
(762)<br />
27"<br />
(686)<br />
30"<br />
(762)<br />
30"<br />
(762)<br />
30"<br />
(762)<br />
36" 36"<br />
(914) (914)<br />
36"<br />
(914)<br />
30"<br />
(762)<br />
36<br />
(91<br />
Ice Maker<br />
Indoor/Outdoor Model<br />
Preservation Model<br />
84"<br />
(2134)<br />
84" 84"<br />
(2134) (2134)<br />
I<br />
O<br />
P<br />
34 1 /2" 34 1 /2"<br />
(876) (876)<br />
34 1 /2"<br />
(876)<br />
34 1 /2"<br />
(876)<br />
Right-Hinge<br />
-RH<br />
Left-Hinge<br />
-LH<br />
Models are shown with stainless steel panels and tubular handles.<br />
Specify right-hinge (-RH) or left-hinge (-LH) door when ordering,<br />
excludes drawer models.<br />
ICBIC-30RID<br />
ICBIC-30FI<br />
ICBIC-36RID<br />
18"<br />
(457)<br />
18"<br />
(457)<br />
18" 24"<br />
(457) (610)<br />
24"<br />
(610)<br />
24" 30"<br />
(610) (762)<br />
34 1 /2"<br />
(876)<br />
24"<br />
(610)<br />
30"<br />
(762)<br />
30"<br />
(762)<br />
24"<br />
(610)<br />
36"<br />
(914)<br />
24" 27"<br />
(610)(686)<br />
36"<br />
(914)<br />
34 1 /2" 34 1 /2"<br />
(876) (876) 18"<br />
18" 24"<br />
(457)<br />
(457) (610)<br />
27" 27" 30"<br />
(686) (686) (762)<br />
Tall Models<br />
36"<br />
(914)<br />
18"<br />
(457)<br />
30"<br />
(762)<br />
30"<br />
(762)<br />
24" 30"<br />
(610) (762)<br />
30"<br />
(762)<br />
30"<br />
(762)<br />
24"<br />
(610)<br />
30"<br />
(762)<br />
36"<br />
(914)<br />
36"<br />
(914)<br />
30"<br />
(762)<br />
36"<br />
(914)<br />
36" 30"<br />
(914) (762)<br />
36"<br />
(914)<br />
36"<br />
(914)<br />
36"<br />
(914)<br />
36"<br />
(914)<br />
30" 36"<br />
(762) (914)<br />
30<br />
(762<br />
84"<br />
(2134)<br />
84" 84"<br />
(2134) (2134)<br />
84"<br />
(2134)<br />
84"<br />
(2134)<br />
84"<br />
(2134)<br />
ICBIT-30RID<br />
ICBIT-30CIID<br />
ICBIT-36CIID<br />
24"<br />
(610)<br />
24"<br />
(610)<br />
24" 27"<br />
(610)(686)<br />
27"<br />
(686)<br />
27"<br />
(686)<br />
30"<br />
(762)<br />
30"<br />
(762)<br />
30"<br />
(762)<br />
36"<br />
(914)<br />
36"<br />
(914)<br />
36"<br />
Drawer (914) Models<br />
34 1 /2"<br />
(876)<br />
34 1 /2" 34 1 /2"<br />
(876) (876)<br />
24"<br />
(610)<br />
24" 27"<br />
(610)(686)<br />
24"<br />
(610)<br />
27"<br />
(686)<br />
30" 27"<br />
(762) (686)<br />
30"<br />
(762)<br />
36" 30"<br />
(914) (762)<br />
36"<br />
(914)<br />
36"<br />
(914)<br />
34 1 /2"<br />
(876)<br />
34 1 /2"<br />
(876)<br />
34 1 /2"<br />
(876)<br />
ICBID-24RO<br />
ICBID-30RP<br />
ICBID-30CI<br />
27
Integrated Refrigeration<br />
46 cm All Freezer—Column<br />
Accessories<br />
Stainless Steel Door Panels<br />
DESCRIPTION NUMBER MSRP<br />
2134<br />
mm<br />
2134 mm FIN HEIGHT—102 mm TOE KICK<br />
Tubular Handle / RH 7025372<br />
Tubular Handle / LH 7025373<br />
Pro Handle / RH 7025324<br />
Pro Handle / LH 7025325<br />
2134 mm FIN HEIGHT—152 mm TOE KICK<br />
Tubular Handle / RH 7025374<br />
Tubular Handle / LH 7025375<br />
Pro Handle / RH 7025326<br />
Pro Handle / LH 7025327<br />
610<br />
mm<br />
457<br />
mm<br />
Dual Installation<br />
DESCRIPTION NUMBER MSRP<br />
Model ICBIC-18FI<br />
MODEL<br />
ICBIC-18FI<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Shipping Weight<br />
FEATURES<br />
MSRP<br />
457 mm W x 2134 mm H x 610 mm D<br />
118 kg<br />
DUAL INSTALLATION KITS<br />
Handle-to-Handle 7027904<br />
Handle-to-Hinge 7030378<br />
Hinge-to-Hinge 7030379<br />
KICKPLATES*<br />
914 mm Stainless Steel 7026837<br />
1067 mm Stainless Steel 7027399<br />
1219 mm Stainless Steel 7026838<br />
1372 mm Stainless Steel 7026839<br />
*Will accommodate 102 mm and 152 mm toe kick heights.<br />
3 adjustable wire shelves • 3 storage drawers • 4 adjustable door<br />
shelves • automatic icemaker • water filtration system<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
ENCLOSURE PANELS<br />
Stainless Steel Side (1)* 7031340<br />
Stainless Steel Top 7031341<br />
Reduced Toe Kick Divider** 7029956<br />
Water Filter (20) 7031688<br />
*Two side enclosures are required to install top enclosure.<br />
**Required for toekicks from 98 mm to 51 mm.<br />
28
Integrated Refrigeration<br />
61 cm All Refrigerator—Column Accessories<br />
Stainless Steel Door Panels<br />
DESCRIPTION NUMBER MSRP<br />
2134<br />
mm<br />
2134 mm FIN HEIGHT—102 mm TOE KICK<br />
Tubular Handle / RH 7023710<br />
Tubular Handle / LH 7023711<br />
Pro Handle / RH 7025320<br />
Pro Handle / LH 7025321<br />
2134 mm FIN HEIGHT—152 mm TOE KICK<br />
Tubular Handle / RH 7025370<br />
Tubular Handle / LH 7025371<br />
Pro Handle / RH 7025322<br />
Pro Handle / LH 7025323<br />
610<br />
mm<br />
610<br />
mm<br />
Dual Installation<br />
DESCRIPTION NUMBER MSRP<br />
Model ICBIC-24R<br />
MODEL<br />
ICBIC-24R<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Shipping Weight<br />
FEATURES<br />
MSRP<br />
610 mm W x 2134 mm H x 610 mm D<br />
154 kg<br />
DUAL INSTALLATION KITS<br />
Handle-to-Handle 7027904<br />
Handle-to-Hinge 7030378<br />
Hinge-to-Hinge 7030379<br />
KICKPLATES*<br />
1067 mm Stainless Steel 7027399<br />
$45 1219 mm Stainless Steel 7026838<br />
1372 mm Stainless Steel 7026839<br />
1524 mm Stainless Steel 7026840<br />
*Will accommodate 102 mm and 152 mm toe kick heights.<br />
3 adjustable glass shelves • 2 high humidity crisper drawers with<br />
dividers • deli drawer with dividers • 3 adjustable and 2 stationary<br />
door shelves • adjustable dairy compartment • air purification<br />
system<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
ENCLOSURE PANELS<br />
Stainless Steel Side (1)* 7031340<br />
Stainless Steel Top 7031342<br />
Reduced Toe Kick Divider** 7029956<br />
Egg Container 7007506<br />
Air Purification Cartridge (50) 7010799<br />
*Two side enclosures are required to install top enclosure.<br />
**Required for toekicks from 98 mm to 51 mm.<br />
PRICES EFFECTIVE 4/1/2017<br />
29
Integrated Refrigeration<br />
61 cm Combination—Column<br />
For availability contact your regional distributor.<br />
Accessories<br />
Stainless Steel Door Panels<br />
DESCRIPTION NUMBER MSRP<br />
2134<br />
mm<br />
2134 mm FIN HEIGHT—102 mm TOE KICK<br />
Tubular Handle / RH 7023710<br />
Tubular Handle / LH 7023711<br />
Pro Handle / RH 7025320<br />
Pro Handle / LH 7025321<br />
2134 mm FIN HEIGHT—152 mm TOE KICK<br />
Tubular Handle / RH 7025370<br />
Tubular Handle / LH 7025371<br />
Pro Handle / RH 7025322<br />
Pro Handle / LH 7025323<br />
610<br />
mm<br />
610<br />
mm<br />
Dual Installation<br />
DESCRIPTION NUMBER MSRP<br />
Model ICBIC-24C<br />
MODEL<br />
ICBIC-24C<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Shipping Weight<br />
FEATURES<br />
MSRP<br />
610 mm W x 2134 mm H x 610 mm D<br />
118 kg<br />
DUAL INSTALLATION KITS<br />
Handle-to-Handle 7023628<br />
Handle-to-Hinge 7029829<br />
Hinge-to-Hinge 7029830<br />
KICKPLATES*<br />
1067 mm Stainless Steel 7027399<br />
1219 mm Stainless Steel 7026838<br />
1372 mm Stainless Steel 7026839<br />
1524 mm Stainless Steel 7026840<br />
*Will accommodate 102 mm and 152 mm toe kick heights.<br />
3 adjustable glass shelves • 1 high humidity crisper drawer with<br />
dividers • 2 adjustable and 1 stationary door shelves • adjustable<br />
dairy compartment • 2 freezer drawers • air purification system<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
ENCLOSURE PANELS<br />
Stainless Steel Side (1)* 7031340<br />
Stainless Steel Top 7031342<br />
Reduced Toe Kick Divider** 7029956<br />
Egg Container 7007506<br />
Air Purification Cartridge (50) 7010799<br />
*Two side enclosures are required to install top enclosure.<br />
**Required for toekicks from 98 mm to 51 mm.<br />
30
Integrated Refrigeration<br />
61 cm All Freezer—Column<br />
Accessories<br />
Stainless Steel Door Panels<br />
DESCRIPTION NUMBER MSRP<br />
2134<br />
mm<br />
2134 mm FIN HEIGHT—102 mm TOE KICK<br />
Tubular Handle / RH 7023710<br />
Tubular Handle / LH 7023711<br />
Pro Handle / RH 7025320<br />
Pro Handle / LH 7025321<br />
2134 mm FIN HEIGHT—152 mm TOE KICK<br />
Tubular Handle / RH 7025370<br />
Tubular Handle / LH 7025371<br />
Pro Handle / RH 7025322<br />
Pro Handle / LH 7025323<br />
610<br />
mm<br />
610<br />
mm<br />
Dual Installation<br />
DESCRIPTION NUMBER MSRP<br />
Model ICBIC-24FI<br />
MODEL<br />
ICBIC-24FI<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Shipping Weight<br />
FEATURES<br />
MSRP<br />
610 mm W x 2134 mm H x 610 mm D<br />
154 kg<br />
DUAL INSTALLATION KITS<br />
Handle-to-Handle 7027904<br />
Handle-to-Hinge 7030378<br />
Hinge-to-Hinge 7030379<br />
KICKPLATES*<br />
1067 mm Stainless Steel 7027399<br />
1219 mm Stainless Steel 7026838<br />
1372 mm Stainless Steel 7026839<br />
1524 mm Stainless Steel 7026840<br />
*Will accommodate 102 mm and 152 mm toe kick heights.<br />
3 adjustable wire shelves • 3 storage drawers • 5 adjustable door<br />
shelves • automatic icemaker • water filtration system<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
ENCLOSURE PANELS<br />
Stainless Steel Side (1)* 7031340<br />
Stainless Steel Top 7031342<br />
Reduced Toe Kick Divider** 7029956<br />
Water Filter (20) 7031688<br />
*Two side enclosures are required to install top enclosure.<br />
**Required for toekicks from 98 mm to 51 mm.<br />
PRICES EFFECTIVE 4/1/2017<br />
31
Integrated Refrigeration<br />
76 cm All Refrigerator—Column Accessories<br />
Stainless Steel Door Panels<br />
DESCRIPTION NUMBER MSRP<br />
2134<br />
mm<br />
2134 mm FIN HEIGHT—102 mm TOE KICK<br />
Tubular Handle / RH 7023626<br />
Tubular Handle / LH 7023627<br />
Pro Handle / RH 7025304<br />
Pro Handle / LH 7025305<br />
2134 mm FIN HEIGHT—152 mm TOE KICK<br />
Tubular Handle / RH 7025364<br />
Tubular Handle / LH 7025365<br />
Pro Handle / RH 7025306<br />
Pro Handle / LH 7025307<br />
610<br />
mm<br />
762<br />
mm<br />
Dual Installation<br />
DESCRIPTION NUMBER MSRP<br />
Model ICBIC-30RID<br />
MODEL<br />
ICBIC-30RID<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Shipping Weight<br />
FEATURES<br />
MSRP<br />
762 mm W x 2134 mm H x 610 mm D<br />
181 kg<br />
DUAL INSTALLATION KITS<br />
Handle-to-Handle 7027904<br />
Handle-to-Hinge 7030378<br />
Hinge-to-Hinge 7030379<br />
KICKPLATES*<br />
1219 mm Stainless Steel 7026838<br />
1372 mm Stainless Steel 7026839<br />
1524 mm Stainless Steel 7026840<br />
1676 mm Stainless Steel 7026841<br />
*Will accommodate 102 mm and 152 mm toe kick heights.<br />
3 adjustable glass shelves • 2 high humidity crisper drawers with<br />
dividers • deli drawer with dividers • 3 adjustable and 2 stationary<br />
door shelves • adjustable dairy compartment • air purification<br />
system • internal water dispenser • water filtration system<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
ENCLOSURE PANELS<br />
Stainless Steel Side (1)* 7031340<br />
Stainless Steel Top 7031343<br />
Reduced Toe Kick Divider** 7029956<br />
Egg Container 7007506<br />
Water Filter (20) 7031688<br />
Air Purification Cartridge (50) 7010799<br />
*Two side enclosures are required to install top enclosure.<br />
**Required for toekicks from 98 mm to 51 mm.<br />
32
Integrated Refrigeration<br />
76 cm All Freezer—Column<br />
Accessories<br />
Stainless Steel Door Panels<br />
DESCRIPTION NUMBER MSRP<br />
2134<br />
mm<br />
2134 mm FIN HEIGHT—102 mm TOE KICK<br />
Tubular Handle / RH 7023626<br />
Tubular Handle / LH 7023627<br />
Pro Handle / RH 7025304<br />
Pro Handle / LH 7025305<br />
2134 mm FIN HEIGHT—152 mm TOE KICK<br />
Tubular Handle / RH 7025364<br />
Tubular Handle / LH 7025365<br />
Pro Handle / RH 7025306<br />
Pro Handle / LH 7025307<br />
610<br />
mm<br />
762<br />
mm<br />
Dual Installation<br />
DESCRIPTION NUMBER MSRP<br />
Model ICBIC-30FI<br />
MODEL<br />
ICBIC-30FI<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Shipping Weight<br />
FEATURES<br />
MSRP<br />
762 mm W x 2134 mm H x 610 mm D<br />
181 kg<br />
DUAL INSTALLATION KITS<br />
Handle-to-Handle 7027904<br />
Handle-to-Hinge 7030378<br />
Hinge-to-Hinge 7030379<br />
KICKPLATES*<br />
1219 mm Stainless Steel 7026838<br />
1372 mm Stainless Steel 7026839<br />
1524 mm Stainless Steel 7026840<br />
1676 mm Stainless Steel 7026841<br />
*Will accommodate 102 mm and 152 mm toe kick heights.<br />
3 adjustable wire shelves • 3 storage drawers • 5 adjustable door<br />
shelves • automatic icemaker • water filtration system<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
ENCLOSURE PANELS<br />
Stainless Steel Side (1)* 7031340<br />
Stainless Steel Top 7031343<br />
Reduced Toe Kick Divider** 7029956<br />
Water Filter (20) 7031688<br />
*Two side enclosures are required to install top enclosure.<br />
**Required for toekicks from 98 mm to 51 mm.<br />
PRICES EFFECTIVE 4/1/2017<br />
33
Integrated Refrigeration<br />
91 cm All Refrigerator—Column Accessories<br />
Stainless Steel Door Panels<br />
DESCRIPTION NUMBER MSRP<br />
2134<br />
mm<br />
2134 mm FIN HEIGHT—102 mm TOE KICK<br />
Tubular Handle / RH 7025366<br />
Tubular Handle / LH 7025367<br />
Pro Handle / RH 7025316<br />
Pro Handle / LH 7025317<br />
2134 mm FIN HEIGHT—152 mm TOE KICK<br />
Tubular Handle / RH 7025368<br />
Tubular Handle / LH 7025369<br />
Pro Handle / RH 7025318<br />
Pro Handle / LH 7025319<br />
610<br />
mm<br />
914<br />
mm<br />
Dual Installation<br />
DESCRIPTION NUMBER MSRP<br />
Model ICBIC-36RID<br />
MODEL<br />
ICBIC-36RID<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Shipping Weight<br />
FEATURES<br />
MSRP<br />
914 mm W x 2134 mm H x 610 mm D<br />
209 kg<br />
DUAL INSTALLATION KITS<br />
Handle-to-Handle 7027904<br />
Handle-to-Hinge 7030378<br />
360Hinge-to-Hinge 7030379<br />
KICKPLATES*<br />
1372 mm Stainless Steel 7026839<br />
1524 mm Stainless Steel 7026840<br />
1676 mm Stainless Steel 7026841<br />
1829 mm Stainless Steel 7026842<br />
*Will accommodate 102 mm and 152 mm toe kick heights.<br />
3 adjustable glass shelves • 2 high humidity crisper drawers with<br />
dividers • deli drawer with dividers • 3 adjustable and 2 stationary<br />
door shelves • adjustable dairy compartment • air purification<br />
system • internal water dispenser • water filtration system<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
ENCLOSURE PANELS<br />
Stainless Steel Side (1)* 7031340<br />
Stainless Steel Top 7031344<br />
Reduced Toe Kick Divider** 7029956<br />
Egg Container 7007506<br />
Water Filter (20) 7031688<br />
Air Purification Cartridge (50) 7010799<br />
*Two side enclosures are required to install top enclosure.<br />
**Required for toekicks from 98 mm to 51 mm.<br />
34
Integrated Refrigeration<br />
76 cm All Refrigerator—Tall Accessories<br />
Stainless Steel Door Panels<br />
DESCRIPTION NUMBER MSRP<br />
2134<br />
mm<br />
2134 mm FINISHED HEIGHT<br />
Tubular Handle / RH 7023706<br />
Tubular Handle / LH 7023707<br />
Pro Handle / RH 7025312<br />
Pro Handle / LH 7025313<br />
Stainless Steel Drawer Panels (2-panel set)<br />
DESCRIPTION NUMBER MSRP<br />
610<br />
mm<br />
Model ICBIT-30RID<br />
MODEL<br />
ICBIT-30RID<br />
762<br />
mm<br />
MSRP<br />
102 mm TOE KICK<br />
Tubular Handle 7023702<br />
Pro Handle 7025308<br />
152 mm TOE KICK<br />
Tubular Handle 7023703<br />
Pro Handle 7025309<br />
Dual Installation<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Shipping Weight<br />
FEATURES<br />
762 mm W x 2134 mm H x 610 mm D<br />
181 kg<br />
3 adjustable glass shelves • deli drawer with dividers • high<br />
humidity crisper drawer with sliding cover and removable dividers<br />
• refrigerator storage drawer with removable dividers • 1 stationary<br />
and 2 adjustable door shelves • adjustable dairy compartment<br />
• air purification system • internal water dispenser • water filtration<br />
system<br />
DESCRIPTION NUMBER MSRP<br />
DUAL INSTALLATION KITS<br />
Handle-to-Handle 7027904<br />
Handle-to-Hinge 7030378<br />
Hinge-to-Hinge 7030379<br />
KICKPLATES*<br />
1219 mm Stainless Steel 7026838<br />
1372 mm Stainless Steel 7026839<br />
1524 mm Stainless Steel 7026840<br />
1676 mm Stainless Steel 7026841<br />
*Will accommodate 102 mm and 152 mm toe kick heights.<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
ENCLOSURE PANELS<br />
Stainless Steel Side (1)* 7031340<br />
Stainless Steel Top 7031343<br />
Reduced Toe Kick Divider** 7029956<br />
Egg Container 7007506<br />
Water Filter (20) 7031688<br />
Air Purification Cartridge (50) 7010799<br />
*Two side enclosures are required to install top enclosure.<br />
**Required for toekicks from 98 mm to 51 mm.<br />
PRICES EFFECTIVE 4/1/2017<br />
35
Integrated Refrigeration<br />
76 cm Combination—Tall Accessories<br />
Stainless Steel Door Panels<br />
DESCRIPTION NUMBER MSRP<br />
2134<br />
mm<br />
2134 mm FINISHED HEIGHT<br />
Tubular Handle / RH 7023706<br />
Tubular Handle / LH 7023707<br />
Pro Handle / RH 7025312<br />
Pro Handle / LH 7025313<br />
Stainless Steel Drawer Panels (2-panel set)<br />
DESCRIPTION NUMBER MSRP<br />
610<br />
mm<br />
Model ICBIT-30CIID<br />
MODEL<br />
ICBIT-30CIID<br />
762<br />
mm<br />
MSRP<br />
102 mm TOE KICK<br />
Tubular Handle 7023702<br />
Pro Handle 7025308<br />
152 mm TOE KICK<br />
Tubular Handle 7023703<br />
Pro Handle 7025309<br />
Dual Installation<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Shipping Weight<br />
FEATURES<br />
762 mm W x 2134 mm H x 610 mm D<br />
181 kg<br />
Refrigerator—2 temperature zones • 3 adjustable glass shelves<br />
• high humidity crisper drawer with dividers • 1 stationary and 2<br />
adjustable door shelves • adjustable dairy compartment • air purification<br />
system • internal water dispenser • water filtration system<br />
Freezer—2 freezer storage drawers with removable dividers •<br />
automatic icemaker<br />
DESCRIPTION NUMBER MSRP<br />
DUAL INSTALLATION KITS<br />
Handle-to-Handle 7027904<br />
Handle-to-Hinge 7030378<br />
Hinge-to-Hinge 7030379<br />
KICKPLATES*<br />
1219 mm Stainless Steel 7026838<br />
1372 mm Stainless Steel 7026839<br />
1524 mm Stainless Steel 7026840<br />
1676 mm Stainless Steel 7026841<br />
*Will accommodate 102 mm and 152 mm toe kick heights.<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
ENCLOSURE PANELS<br />
Stainless Steel Side (1)* 7031340<br />
Stainless Steel Top 7031343<br />
Reduced Toe Kick Divider** 7029956<br />
Egg Container 7007506<br />
Water Filter (20) 7031688<br />
Air Purification Cartridge (50) 7010799<br />
*Two side enclosures are required to install top enclosure.<br />
**Required for toekicks from 98 mm to 51 mm.<br />
36
Integrated Refrigeration<br />
91 cm Combination—Tall Accessories<br />
Stainless Steel Door Panels<br />
DESCRIPTION NUMBER MSRP<br />
2134<br />
mm<br />
2134 mm FINISHED HEIGHT<br />
Tubular Handle / RH 7023708<br />
Tubular Handle / LH 7023709<br />
Pro Handle / RH 7025314<br />
Pro Handle / LH 7025315<br />
Stainless Steel Drawer Panels (2-panel set)<br />
DESCRIPTION NUMBER MSRP<br />
610<br />
mm<br />
Model ICBIT-36CIID<br />
MODEL<br />
ICBIT-36CIID<br />
914<br />
mm<br />
MSRP<br />
102 mm TOE KICK<br />
Tubular Handle 7023704<br />
Pro Handle 7025310<br />
152 mm TOE KICK<br />
Tubular Handle 7023705<br />
Pro Handle 7025311<br />
Dual Installation<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Shipping Weight<br />
FEATURES<br />
914 mm W x 2134 mm H x 610 mm D<br />
209 kg<br />
Refrigerator—2 temperature zones • 3 adjustable glass shelves<br />
• high humidity crisper drawer with dividers • 1 stationary and 2<br />
adjustable door shelves • adjustable dairy compartment • air purification<br />
system • internal water dispenser • water filtration system<br />
Freezer—2 freezer storage drawers with removable dividers •<br />
automatic icemaker<br />
DESCRIPTION NUMBER MSRP<br />
DUAL INSTALLATION KITS<br />
Handle-to-Handle 7027904<br />
Handle-to-Hinge 7030378<br />
Hinge-to-Hinge 7030379<br />
KICKPLATES*<br />
1372 mm Stainless Steel 7026839<br />
1524 mm Stainless Steel 7026840<br />
1676 mm Stainless Steel 7026841<br />
1829 mm Stainless Steel 7026842<br />
*Will accommodate 102 mm and 152 mm toe kick heights.<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
ENCLOSURE PANELS<br />
Stainless Steel Side (1)* 7031340<br />
Stainless Steel Top 7031344<br />
Reduced Toe Kick Divider** 7029956<br />
Egg Container 7007506<br />
Water Filter (20) 7031688<br />
Air Purification Cartridge (50) 7010799<br />
*Two side enclosures are required to install top enclosure.<br />
**Required for toekicks from 98 mm to 51 mm.<br />
PRICES EFFECTIVE 4/1/2017<br />
37
Integrated Refrigeration<br />
61 cm Indoor/Outdoor All Refrigerator—<br />
Drawers<br />
Accessories<br />
Indoor Installation<br />
Stainless Steel Drawer Panels (2-panel set)<br />
876<br />
mm<br />
610<br />
mm<br />
610<br />
mm<br />
DESCRIPTION NUMBER MSRP<br />
102 mm TOE KICK<br />
Tubular Handle 7023702<br />
Pro Handle 7025308<br />
152 mm TOE KICK<br />
Tubular Handle 7023703<br />
Pro Handle 7025309<br />
Model ICBID-24RO<br />
MODEL<br />
ICBID-24RO<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Shipping Weight<br />
MSRP<br />
610 mm W x 876 mm H x 610 mm D<br />
77 kg<br />
Outdoor Installation<br />
Stainless Steel Drawer Panels (2-panel set)<br />
DESCRIPTION NUMBER MSRP<br />
102 mm TOE KICK<br />
Pro Handle (with lock) 9011615<br />
Pro Handle (without lock) 9011700<br />
Dual Installation<br />
FEATURES<br />
2 refrigerator storage drawers with removable dividers • suitable<br />
for indoor and outdoor installations<br />
DESCRIPTION NUMBER MSRP<br />
Dual Installation Kit 7027903<br />
KICKPLATES* ‡<br />
1219 mm Stainless Steel 7026838<br />
1372 mm Stainless Steel 7026839<br />
1524 mm Stainless Steel 7026840<br />
1676 mm Stainless Steel 7026841<br />
*Will accommodate 102 mm and 152 mm toe kick heights.<br />
‡<br />
For indoor installation only.<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
Reduced Toe Kick Divider* ‡<br />
7029956<br />
Egg Container 7007506<br />
*Required for toekicks from 98 mm to 51 mm.<br />
‡ For indoor installation only.<br />
38
Integrated Refrigeration<br />
76 cm All Refrigerator—Drawers Accessories<br />
Stainless Steel Drawer Panels (2-panel set)<br />
876<br />
mm<br />
610<br />
mm<br />
DESCRIPTION NUMBER MSRP<br />
102 mm TOE KICK<br />
Tubular Handle 7023702<br />
Pro Handle 7025308<br />
152 mm TOE KICK<br />
Tubular Handle 7023703<br />
Pro Handle 7025309<br />
762<br />
mm<br />
Dual Installation<br />
Model ICBID-30RP<br />
MODEL<br />
ICBID-30RP<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Shipping Weight<br />
MSRP<br />
762 mm W x 876 mm H x 610 mm D<br />
95 kg<br />
DESCRIPTION NUMBER MSRP<br />
Dual Installation Kit 7027903<br />
KICKPLATES*<br />
1219 mm Stainless Steel 7026838<br />
1372 mm Stainless Steel 7026839<br />
1524 mm Stainless Steel 7026840<br />
1676 mm Stainless Steel 7026841<br />
*Will accommodate 102 mm and 152 mm toe kick heights.<br />
FEATURES<br />
2 refrigerator storage drawers with removable dividers • sliding<br />
crisper cover • air purification system<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
Reduced Toe Kick Divider* 7029956<br />
Egg Container 7007506<br />
Crisper Cover 7025420<br />
Air Purification Cartridge (50) 7010799<br />
*Required for toekicks from 98 mm to 51 mm.<br />
PRICES EFFECTIVE 4/1/2017<br />
39
Integrated Refrigeration<br />
76 cm Combination—Drawers Accessories<br />
Stainless Steel Drawer Panels (2-panel set)<br />
876<br />
mm<br />
610<br />
mm<br />
DESCRIPTION NUMBER MSRP<br />
102 mm TOE KICK<br />
Tubular Handle 7023702<br />
Pro Handle 7025308<br />
152 mm TOE KICK<br />
Tubular Handle 7023703<br />
Pro Handle 7025309<br />
762<br />
mm<br />
Dual Installation<br />
Model ICBID-30CI<br />
MODEL<br />
ICBID-30CI<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Shipping Weight<br />
MSRP<br />
762 mm W x 876 mm H x 610 mm D<br />
95 kg<br />
DESCRIPTION NUMBER MSRP<br />
Dual Installation Kit 7027903<br />
KICKPLATES*<br />
1219 mm Stainless Steel 7026838<br />
1372 mm Stainless Steel 7026839<br />
1524 mm Stainless Steel 7026840<br />
1676 mm Stainless Steel 7026841<br />
*Will accommodate 102 mm and 152 mm toe kick heights.<br />
FEATURES<br />
Refrigerator—2 temperature zones • refrigerator storage drawer<br />
with removable dividers<br />
Freezer—freezer storage drawer with removable dividers •<br />
automatic ice maker<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
Reduced Toe Kick Divider* 7029956<br />
Egg Container 7007506<br />
*Required for toekicks from 98 mm to 51 mm.<br />
40
Wine Storage<br />
Wine Storage<br />
Wine finds a well-deserved place of honor in a <strong>Sub</strong>-<strong>Zero</strong> wine<br />
storage unit. Every detail is designed to ensure better wine<br />
preservation. Cherrywood-faced shelves, soft lighting, custom<br />
cabinetry if desired—<strong>Sub</strong>-<strong>Zero</strong> helps make a wine collection an<br />
element of beauty in the home.<br />
Wine Storage Models<br />
• Overlay, flush inset, stainless steel and integrated design<br />
options complement built-in, integrated and undercounter<br />
units for dual installation.<br />
ICBUW-24FS<br />
ICBUW-24<br />
• Full-view glass door on all models.<br />
• Discreet interior lighting with illuminated display shelf.<br />
• Two independent storage zones maintain temperature,<br />
humidity and UV protection.<br />
• Cherrywood-faced shelves display the wine beautifully and<br />
accommodate 750 ml bottles, half-bottles and magnums.<br />
• Star-K compliant with installation of a harness kit.<br />
MODEL NUMBER KEY<br />
International Certified Body (ICB) Approved Model<br />
ICB<br />
ICBIW-18<br />
ICBIW-24<br />
ICBIW-30<br />
ICBIW-30R<br />
Built-in Wine Storage<br />
BW<br />
Integrated Wine Storage<br />
IW<br />
Undercounter Wine Storage<br />
UW<br />
Freestanding<br />
FS<br />
Refrigerator Drawers<br />
R<br />
Overlay Model /O<br />
Stainless Steel Model /S<br />
Tubular Handle<br />
/TH<br />
Pro Handle<br />
/PH<br />
Right-Hinge<br />
-RH<br />
Left-Hinge<br />
-LH<br />
ICBBW-30<br />
Models are shown in the stainless steel design with tubular handles.<br />
Specify right-hinge (-RH) or left-hinge (-LH) door when ordering.<br />
PRICES EFFECTIVE 4/1/2017<br />
41
Wine Storage<br />
61 cm Freestanding Wine Storage<br />
61 cm Undercounter Wine Storage<br />
868<br />
mm<br />
864<br />
mm<br />
625<br />
mm<br />
616<br />
mm<br />
610<br />
mm 606<br />
mm<br />
Model ICBUW-24FS<br />
MODEL<br />
ICBUW-24FS/S/TH<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Design<br />
Wine Storage Capacity<br />
Shipping Weight<br />
FEATURES<br />
MSRP<br />
616 mm W x 868 mm H x 625 mm D<br />
Freestanding<br />
46 bottles (750 ml)<br />
100 kg<br />
2 temperature zones • 2 upper and 3 lower compartment shelves<br />
• full-view, UV-resistant glass door • stainless steel exterior for<br />
freestanding application<br />
No solid door option available for this model.<br />
Model ICBUW-24<br />
MODEL<br />
ICBUW-24/O<br />
ICBUW-24/S/TH<br />
ICBUW-24/S/PH<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Design<br />
Wine Storage Capacity<br />
Shipping Weight<br />
FEATURES<br />
MSRP<br />
606 mm W x 864 mm H x 610 mm D<br />
Undercounter<br />
46 bottles (750 ml)<br />
88 kg<br />
2 temperature zones • 2 upper and 3 lower compartment shelves<br />
• full-view, UV-resistant glass door<br />
Accessories<br />
DESCRIPTION NUMBER MSRP<br />
Lock Kit 7040171<br />
Inventory Tiles (15) 7031944<br />
Inventory Tiles / Writable (15) 7030331<br />
Dessert Wine Rack 7040428<br />
Accessories<br />
DESCRIPTION NUMBER MSRP<br />
Solid Overlay Door** 7005924<br />
Silver Kickplate 7030801<br />
Lock Kit 7030802<br />
Inventory Tiles (15) 7031944<br />
Inventory Tiles / Writable (15) 7030331<br />
Dessert Wine Rack 7040428<br />
DUAL INSTALLATION<br />
Dual Installation Kit* 7031699<br />
Dual Lock Kit 7030527<br />
Black Dual Kickplate 7030799<br />
Silver Dual Kickplate 7030800<br />
*Handle to handle installation only.<br />
**Installation may require authorized service.<br />
42
Wine Storage<br />
46 cm Wine Storage<br />
Accessories<br />
Stainless Steel Door Panels<br />
DESCRIPTION NUMBER MSRP<br />
2134<br />
mm<br />
610<br />
mm<br />
457<br />
mm<br />
Model ICBIW-18<br />
MODEL<br />
ICBIW-18<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Design<br />
Wine Storage Capacity<br />
Shipping Weight<br />
MSRP<br />
457 mm W x 2134 mm H x 610 mm D<br />
Integrated<br />
59 bottles (750 ml)<br />
158 kg<br />
2134 mm FIN HEIGHT—102 mm TOE KICK<br />
Tubular Handle / RH 7025376<br />
Tubular Handle / RH / Lock 7025380<br />
Tubular Handle / LH 7025377<br />
Tubular Handle / LH / Lock 7025381<br />
Pro Handle / RH 7025328<br />
Pro Handle / RH / Lock 7025332<br />
Pro Handle / LH 7025329<br />
Pro Handle / LH / Lock 7025333<br />
2134 mm FIN HEIGHT—152 mm TOE KICK<br />
Tubular Handle / RH 7025378<br />
Tubular Handle / RH / Lock 7025382<br />
Tubular Handle / LH 7025379<br />
Tubular Handle / LH / Lock 7025383<br />
Pro Handle / RH 7025330<br />
Pro Handle / RH / Lock 7025334<br />
Pro Handle / LH 7025331<br />
Pro Handle / LH / Lock 7025335<br />
Dual Installation<br />
DESCRIPTION NUMBER MSRP<br />
DUAL INSTALLATION KITS<br />
Handle-to-Handle 7027904<br />
Handle-to-Hinge 7030378<br />
Hinge-to-Hinge 7030379<br />
FEATURES<br />
2 temperature zones • 5 upper and 10 lower compartment<br />
shelves • full-view, UV-resistant glass door • inventory tile system<br />
KICKPLATES*<br />
914 mm Stainless Steel 7026837<br />
1067 mm Stainless Steel 7027399<br />
1219 mm Stainless Steel 7026838<br />
1372 mm Stainless Steel 7026839<br />
*Will accommodate 102 mm and 152 mm toe kick heights.<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
PRICES EFFECTIVE 4/1/2017<br />
ENCLOSURE PANELS<br />
Stainless Steel Top 7031341<br />
Stainless Steel Side (1)* 7031340<br />
Reduced Toe Kick Divider** 7029956<br />
Solid Overlay Door RH*** 7031923<br />
Solid Overlay Door LH*** 7031924<br />
Lock Kit 7028773<br />
Inventory Tiles (15) 7031944<br />
Inventory Tiles / Writable (15) 7030331<br />
Bulk Storage Drawer 7028448<br />
Dessert Wine Rack 7028451<br />
*Two side enclosures are required to install top enclosure.<br />
**Required for toekicks from 98 mm to 51 mm.<br />
***Installation may require authorized service.<br />
43
Wine Storage<br />
61 cm Wine Storage<br />
Accessories<br />
Stainless Steel Door Panels<br />
DESCRIPTION NUMBER MSRP<br />
2134<br />
mm<br />
610<br />
mm<br />
610<br />
mm<br />
Model ICBIW-24<br />
MODEL<br />
ICBIW-24<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Design<br />
Wine Storage Capacity<br />
Shipping Weight<br />
MSRP<br />
610 mm W x 2134 mm H x 610 mm D<br />
Integrated<br />
102 bottles (750 ml)<br />
185 kg<br />
2134 mm FIN HEIGHT—102 mm TOE KICK<br />
Tubular Handle / RH 7025384<br />
Tubular Handle / RH / Lock 7025388<br />
Tubular Handle / LH 7025385<br />
Tubular Handle / LH / Lock 7025389<br />
Pro Handle / RH 7025336<br />
Pro Handle / RH / Lock 7025340<br />
Pro Handle / LH 7025337<br />
Pro Handle / LH / Lock 7025341<br />
2134 mm FIN HEIGHT—152 mm TOE KICK<br />
Tubular Handle / RH 7025386<br />
Tubular Handle / RH / Lock 7025390<br />
Tubular Handle / LH 7025387<br />
Tubular Handle / LH / Lock 7025391<br />
Pro Handle / RH 7025338<br />
Pro Handle / RH / Lock 7025342<br />
Pro Handle / LH 7025339<br />
Pro Handle / LH / Lock 7025343<br />
Dual Installation<br />
DESCRIPTION NUMBER MSRP<br />
DUAL INSTALLATION KITS<br />
Handle-to-Handle 7027904<br />
Handle-to-Hinge 7030378<br />
Hinge-to-Hinge 7030379<br />
FEATURES<br />
2 temperature zones • 5 upper and 10 lower compartment<br />
shelves • full-view, UV-resistant glass door • inventory tile system<br />
KICKPLATES*<br />
1067 mm Stainless Steel 7027399<br />
1219 mm Stainless Steel 7026838<br />
1372 mm Stainless Steel 7026839<br />
1524 mm Stainless Steel 7026840<br />
*Will accommodate 102 mm and 152 mm toe kick heights.<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
ENCLOSURE PANELS<br />
Stainless Steel Top 7031342<br />
Stainless Steel Side (1)* 7031340<br />
Reduced Toe Kick Divider** 7029956<br />
Solid Overlay Door RH*** 7031925<br />
Solid Overlay Door LH*** 7031926<br />
Lock Kit 7028773<br />
Inventory Tiles (15) 7031944<br />
Inventory Tiles / Writable (15) 7030331<br />
Bulk Storage Drawer 7028449<br />
Dessert Wine Rack 7028451<br />
*Two side enclosures are required to install top enclosure.<br />
**Required for toekicks from 98 mm to 51 mm.<br />
***Installation may require authorized service.<br />
44
Wine Storage<br />
76 cm Wine Storage<br />
Accessories<br />
Stainless Steel Door Panels<br />
DESCRIPTION NUMBER MSRP<br />
2134<br />
mm<br />
610<br />
mm<br />
762<br />
mm<br />
Model ICBIW-30<br />
MODEL<br />
ICBIW-30<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Design<br />
Wine Storage Capacity<br />
Shipping Weight<br />
MSRP<br />
762 mm W x 2134 mm H x 610 mm D<br />
Integrated<br />
146 bottles (750 ml)<br />
208 kg<br />
2134 mm FIN HEIGHT—102 mm TOE KICK<br />
Tubular Handle / RH 7025392<br />
Tubular Handle / RH / Lock 7025396<br />
Tubular Handle / LH 7025393<br />
Tubular Handle / LH / Lock 7025397<br />
Pro Handle / RH 7025344<br />
Pro Handle / RH / Lock 7025348<br />
Pro Handle / LH 7025345<br />
Pro Handle / LH / Lock 7025349<br />
2134 mm FIN HEIGHT—152 mm TOE KICK<br />
Tubular Handle / RH 7025394<br />
Tubular Handle / RH / Lock 7025398<br />
Tubular Handle / LH 7025395<br />
Tubular Handle / LH / Lock 7025399<br />
Pro Handle / RH 7025346<br />
Pro Handle / RH / Lock 7025350<br />
Pro Handle / LH 7025347<br />
Pro Handle / LH / Lock 7025351<br />
Dual Installation<br />
DESCRIPTION NUMBER MSRP<br />
DUAL INSTALLATION KITS<br />
Handle-to-Handle 7027904<br />
Handle-to-Hinge 7030378<br />
Hinge-to-Hinge 7030379<br />
FEATURES<br />
2 temperature zones • 5 upper and 10 lower compartment<br />
shelves • full-view, UV-resistant glass door • inventory tile system<br />
KICKPLATES*<br />
1219 mm Stainless Steel 7026838<br />
1372 mm Stainless Steel 7026839<br />
1524 mm Stainless Steel 7026840<br />
1676 mm Stainless Steel 7026841<br />
*Will accommodate 102 mm and 152 mm toe kick heights.<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
PRICES EFFECTIVE 4/1/2017<br />
ENCLOSURE PANELS<br />
Stainless Steel Top 7031343<br />
Stainless Steel Side (1)* 7031340<br />
Reduced Toe Kick Divider** 7029956<br />
Solid Overlay Door RH*** 7031927<br />
Solid Overlay Door LH*** 7031928<br />
Lock Kit 7028773<br />
Inventory Tiles (15) 7031944<br />
Inventory Tiles / Writable (15) 7030331<br />
Bulk Storage Drawer 7028450<br />
Dessert Wine Rack 7028451<br />
Cherrywood Humidor**** 7040181<br />
*Two side enclosures are required to install top enclosure.<br />
**Required for toekicks from 98 mm to 51 mm.<br />
***Installation may require authorized service.<br />
****100+ capacity with humidity control.<br />
45
Wine Storage<br />
76 cm Wine Storage with Refrigerator Drawers<br />
Accessories<br />
Stainless Steel Drawer Panels (2-panel set)<br />
DESCRIPTION NUMBER MSRP<br />
2134<br />
mm<br />
102 mm TOE KICK<br />
Tubular Handle 7023702<br />
Pro Handle 7025308<br />
152 mm TOE KICK<br />
Tubular Handle 7023703<br />
Pro Handle 7025309<br />
Dual Installation<br />
610<br />
mm<br />
762<br />
mm<br />
DESCRIPTION NUMBER MSRP<br />
DUAL INSTALLATION KITS<br />
Handle-to-Handle 7027904<br />
Handle-to-Hinge 7030378<br />
Hinge-to-Hinge 7030379<br />
Model ICBIW-30R<br />
MODEL<br />
ICBIW-30R<br />
SPECIFICATIONS<br />
MSRP<br />
KICKPLATES*<br />
1219 mm Stainless Steel 7026838<br />
1372 mm Stainless Steel 7026839<br />
1524 mm Stainless Steel 7026840<br />
1676 mm Stainless Steel 7026841<br />
*Will accommodate 102 mm and 152 mm toe kick heights.<br />
Overall Dimensions<br />
Design<br />
Wine Storage Capacity<br />
Shipping Weight<br />
FEATURES<br />
762 mm W x 2134 mm H x 610 mm D<br />
Integrated<br />
86 bottles (750 ml)<br />
222 kg<br />
2 temperature zones • 5 upper and 3 lower compartment shelves<br />
• display shelf • full-view, UV-resistant glass door • 2 refrigerator<br />
drawers with removable dividers<br />
Accessories<br />
Stainless Steel Door Panels<br />
DESCRIPTION NUMBER MSRP<br />
2134 mm FINISHED HEIGHT<br />
Tubular Handle / RH 7025400<br />
Tubular Handle / RH / Lock 7025402<br />
Tubular Handle / LH 7025401<br />
Tubular Handle / LH / Lock 7025403<br />
Pro Handle / RH 7025352<br />
Pro Handle / RH / Lock 7025354<br />
Pro Handle / LH 7025353<br />
Pro Handle / LH / Lock 7025355<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
ENCLOSURE PANELS<br />
Stainless Steel Top 7031343<br />
Stainless Steel Side (1)* 7031340<br />
Reduced Toe Kick Divider** 7029956<br />
Solid Overlay Door RH*** 7031929<br />
Solid Overlay Door LH*** 7031930<br />
Lock Kit 7028773<br />
Inventory Tiles (15) 7031944<br />
Inventory Tiles / Writable (15) 7030331<br />
Bulk Storage Drawer 7028450<br />
Dessert Wine Rack 7028451<br />
Cherrywood Humidor**** 7040181<br />
*Two side enclosures are required to install top enclosure.<br />
**Required for toekicks from 98 mm to 51 mm.<br />
***Installation may require authorized service.<br />
****100+ capacity with humidity control.<br />
46
Wine Storage<br />
76 cm Wine Storage Accessories<br />
Grilles<br />
FINISHED HEIGHT NUMBER MSRP<br />
2134<br />
mm<br />
OVERLAY OR FLUSH INSET<br />
2108 mm Grille Frame 7003530<br />
2134 mm Grille Frame 7007135<br />
2235 mm Grille Frame 7003534<br />
STAINLESS STEEL<br />
2108 mm Pro Louvered 7003542<br />
2134 mm Pro Louvered 7007131<br />
2235 mm Pro Louvered 7003546<br />
610<br />
mm<br />
762<br />
mm<br />
Model ICBBW-30<br />
MODEL<br />
ICBBW-30/O<br />
ICBBW-30/S/TH<br />
ICBBW-30/S/PH<br />
MSRP<br />
Single Flush Inset Panels—Stainless Steel<br />
DESCRIPTION NUMBER MSRP<br />
GRILLE*<br />
Solid Stainless Steel Panel 7008870<br />
Pro Louvered 7020157<br />
TUBULAR HANDLE<br />
Door Panel 7029159<br />
PRO HANDLE<br />
Door Panel 7010268<br />
*2134 mm finished height.<br />
SPECIFICATIONS<br />
Overall Dimensions<br />
Design<br />
Wine Storage Capacity<br />
Shipping Weight<br />
FEATURES<br />
762 mm W x 2134 mm H x 610 mm D<br />
Built-In<br />
146 bottles (750 ml)<br />
202 kg<br />
2 temperature zones • 5 upper and 9 lower compartment shelves<br />
• display shelf • full-view, UV-resistant glass door • 90° door stop<br />
No solid door option available for this model.<br />
Dual Flush Inset Panels—Stainless Steel<br />
DESCRIPTION NUMBER MSRP<br />
DUAL WIDE GRILLE*<br />
1524 mm Solid Stainless<br />
Steel Panel<br />
1676 mm Solid Stainless<br />
Steel Panel<br />
TUBULAR HANDLE<br />
Door Panel 7029160<br />
PRO HANDLE<br />
*2134 mm finished height.<br />
7008882<br />
7013367<br />
Door Panel 7010274<br />
PRICES EFFECTIVE 4/1/2017<br />
47
Wine Storage<br />
Accessories<br />
Dual Installation Kit with Dual Wide Grille<br />
DESCRIPTION NUMBER MSRP<br />
OVERLAY OR FLUSH INSET<br />
1524 mm Grille Frame 7010482<br />
1676 mm Grille Frame 7012661<br />
STAINLESS STEEL FLUSH INSET<br />
1524 mm Pro Louvered 7020683<br />
1676 mm Pro Louvered 7020684<br />
STAINLESS STEEL<br />
1524 mm Pro Louvered 7010484<br />
1676 mm Pro Louvered 7012662<br />
Kit includes dual wide kickplate and dual wide grille for 2134 mm<br />
finished height, center trim strip, heater and mounting hardware.<br />
Dual Installation Kit<br />
DESCRIPTION NUMBER MSRP<br />
ALL DESIGNS<br />
Dual Installation Kit 7010486<br />
Kit includes center trim strip, heater and mounting hardware.<br />
Miscellaneous<br />
DESCRIPTION NUMBER MSRP<br />
MOUNTING KIT<br />
Custom Side Panel 7003407<br />
SIDE PANELS<br />
Stainless Steel 7003408<br />
White Enamel 7003409<br />
KICKPLATES<br />
Stainless Steel RH 7010358<br />
Stainless Steel LH 7010359<br />
Lock Kit 7011215<br />
90° Door Stop 7005865<br />
Inventory Tiles (15) 7031944<br />
Inventory Tiles / Writable (15) 7030331<br />
Bulk Storage Drawer 7040427<br />
Dessert Wine Rack 7040428<br />
Cherrywood Humidor* 7040426<br />
*100+ capacity with humidity control.<br />
48
Accessory Handles<br />
Stainless Steel Handles<br />
Tubular Handles (Square Standoffs)<br />
DESCRIPTION NUMBER MSRP<br />
19 mm DIAMETER<br />
540 mm 7025231<br />
616 mm 7025230<br />
692 mm 7025229<br />
845 mm 7025228<br />
1273 mm 7025227<br />
25 mm DIAMETER<br />
633 mm 7029181<br />
770 mm 7029174<br />
922 mm 7030668<br />
1124 mm 7029168<br />
1622 mm 7029157<br />
Tubular Handles (Obround Standoffs)<br />
DESCRIPTION NUMBER MSRP<br />
25 mm DIAMETER<br />
633 mm 7007247<br />
770 mm 7007248<br />
1124 mm 7007251<br />
1622 mm 7007253<br />
Pro Handles<br />
DESCRIPTION NUMBER MSRP<br />
495 mm 7026119<br />
572 mm 7026118<br />
648 mm 7026117<br />
772 mm 7027250<br />
800 mm 7026116<br />
1229 mm 7026115<br />
Framed Full-Length Handles<br />
DESCRIPTION NUMBER MSRP<br />
ICBBI-36R, ICBBI-36RG, ICBBI-36F AND ICBBW-30<br />
Standard Handle 7014887<br />
Extended Handle 7003462<br />
ICBBI-30U AND ICBBI-30UG<br />
Standard 2-Handle Set 7014888<br />
Extended 2-Handle Set 7003463<br />
ICBBI-36U AND ICBBI-36UG<br />
Standard 2-Handle Set 7014889<br />
ICBBI-36UFD<br />
Extended 2-Handle Set 7003464<br />
Standard 3-Handle Set 7023375<br />
Extended 3-Handle Set 7023376<br />
ICBBI-42UFD<br />
Standard 3-Handle Set 7027154<br />
Extended 3-Handle Set 7027155<br />
SIDE-BY-SIDE<br />
Standard 2-Handle Set 7014890<br />
Extended 2-Handle Set 7003465<br />
PRICES EFFECTIVE 4/1/2017<br />
49
Accessory Handles<br />
Stainless Steel Handles<br />
Standard Handle Length<br />
MODEL TUBULAR PRO<br />
BUILT-IN<br />
Full Door 1622 mm 1147 mm<br />
Over-and-Under Door 1124 mm 952 mm<br />
1067 mm Drawer 922 mm 753 mm<br />
914 mm Drawer 770 mm 600 mm<br />
762 mm Drawer 633 mm 447 mm<br />
PRO 48<br />
Door NA 703 mm<br />
Refrigerator Drawer NA 506 mm<br />
Freezer Drawer NA 294 mm<br />
INTEGRATED<br />
Column Door 1273 mm 1229 mm<br />
Tall Door 845 mm 800 mm<br />
914 mm Drawer 845 mm 800 mm<br />
762 mm Drawer 692 mm 648 mm<br />
686 mm Drawer 616 mm 572 mm<br />
610 mm Drawer 540 mm 495 mm<br />
WINE STORAGE<br />
ICBBW-30 Door 1622 mm 1147 mm<br />
ICBIW-18, ICBIW-24, ICBIW-30 Door 1273 mm 1229 mm<br />
ICBIW-30R Door 845 mm 800 mm<br />
ICBUW-24 Door 616 mm 572 mm<br />
ICBIW-30R Drawer 692 mm 572 mm<br />
UNDERCOUNTER<br />
Door 616 mm 572 mm<br />
Outdoor Door NA NA<br />
50
The information and images in this guide are the copyright property of <strong>Sub</strong>-<strong>Zero</strong>, Inc. Neither this guide nor any information or images contained herein may be copied or used in<br />
whole or in part without the express written permission of <strong>Sub</strong>-<strong>Zero</strong>, Inc. ©<strong>Sub</strong>-<strong>Zero</strong>, Inc. all rights reserved.<br />
<strong>Sub</strong>-<strong>Zero</strong>, <strong>Sub</strong>-<strong>Zero</strong> & Design, Dual Refrigeration, The Living Kitchen, Great American Kitchens The Fine Art of Kitchen Design, and Ingredients are registered trademarks and service<br />
marks of <strong>Sub</strong>-<strong>Zero</strong>, Inc. Wolf, Wolf & Design, Wolf Gourmet, W & Design and the color red as applied to knobs are registered trademarks and service marks of Wolf Appliance, Inc.<br />
All other trademarks or registered trademarks are property of their respective owners in the United States and other countries.<br />
51
<strong>Sub</strong>-<strong>Zero</strong> Products Limited Warranty<br />
INTERNATIONAL PRODUCTS<br />
FOR RESIDENTIAL USE ONLY<br />
FULL TWO YEAR WARRANTY<br />
For two years from the date of original installation, your <strong>Sub</strong>-<strong>Zero</strong> product warranty covers all parts<br />
and labor to repair or replace, under normal residential use, any part of the product that proves to be<br />
defective in materials or workmanship. All service provided by <strong>Sub</strong>-<strong>Zero</strong> under the above warranty<br />
must be performed by <strong>Sub</strong>-<strong>Zero</strong> factory certified service, unless otherwise specified by <strong>Sub</strong>-<strong>Zero</strong>,<br />
Inc. Service will be provided during normal business hours.<br />
FULL FIVE YEAR SEALED SYSTEM WARRANTY<br />
For five years from the date of original installation, your <strong>Sub</strong>-<strong>Zero</strong> product warranty covers all parts<br />
and labor to repair or replace, under normal residential use, the compressor, condenser, evaporator,<br />
drier and all connecting tubing that prove to be defective in materials or workmanship. All service<br />
provided by <strong>Sub</strong>-<strong>Zero</strong> under the above warranty must be performed by <strong>Sub</strong>-<strong>Zero</strong> factory certified<br />
service, unless otherwise specified by <strong>Sub</strong>-<strong>Zero</strong>, Inc. Service will be provided during normal<br />
business hours.<br />
52
<strong>Sub</strong>-<strong>Zero</strong> Outdoor Limited Warranty*<br />
INTERNATIONAL PRODUCTS<br />
FOR RESIDENTIAL USE ONLY<br />
FULL ONE YEAR WARRANTY**<br />
For one year from the date of original installation, this <strong>Sub</strong>-<strong>Zero</strong> product warranty covers all parts<br />
and labor to repair or replace, under normal residential use, any part of the product that proves to be<br />
defective in materials or workmanship. All service provided by <strong>Sub</strong>-<strong>Zero</strong> under the above warranty<br />
must be performed by <strong>Sub</strong>-<strong>Zero</strong> factory certified service, unless otherwise specified by <strong>Sub</strong>-<strong>Zero</strong>,<br />
Inc. Service will be provided during normal business hours.<br />
FULL FIVE YEAR SEALED SYSTEM WARRANTY<br />
For five years from the date of original installation, this <strong>Sub</strong>-<strong>Zero</strong> product warranty covers all parts<br />
and labor to repair or replace, under normal residential use, these parts that prove to be defective<br />
in materials or workmanship: compressor, condenser, evaporator, drier and all connecting tubing.<br />
All service provided by <strong>Sub</strong>-<strong>Zero</strong> under the above warranty must be performed by <strong>Sub</strong>-<strong>Zero</strong> factory<br />
certified service, unless otherwise specified by <strong>Sub</strong>-<strong>Zero</strong>, Inc. Service will be provided during normal<br />
business hours.<br />
TERMS APPLICABLE TO EACH WARRANTY<br />
The warranty applies only to products installed for normal residential use. This warranty does not<br />
cover any parts or labor to correct any defect caused by negligence, accident or improper use,<br />
maintenance, installation, service or repair.<br />
For more information regarding your <strong>Sub</strong>-<strong>Zero</strong> product warranty, contact your dealer. Warranties<br />
must comply to all country, state, city, local and or ordinance.<br />
*Product must be approved for outdoor use, designated by model and serial number.<br />
**Stainless steel (doors, panels, handles, product frames and interior surfaces) are covered by a<br />
limited 60-day parts and labor warranty for cosmetic defects.<br />
**Replacement water filters are not covered by the product warranty.<br />
53
2017<br />
SUB-ZERO, INC. P. O. BOX 44130 MADISON, WI 53744 USA SUBZERO.COM<br />
1/2017
