<strong>Joker</strong><br />
<strong>Prisma</strong>Tech/<strong>Prisma</strong>Space
Illuminare con elementi<br />
essenziali, dove l’acciaio<br />
inox domina le forme. Cer-<br />
care una soluzione<br />
unica, in<br />
Roberto Fiorato firma la serie <strong>Joker</strong> per la linea<br />
<strong>Prisma</strong>Tech. Il progetto si distingue per l’atten-<br />
zione rivolta alla versatilità applicativa. La ri-<br />
cerca finalizzata allo sviluppo di linee rigorose<br />
rafforzata dall’impiego dell’acciaio inox per le<br />
finiture definisce l’impronta formale della serie.<br />
accordo con tecnologia ed<br />
estetica. Esplorare nuove<br />
possibilità attraverso il<br />
colore della luce e decidere<br />
i dettagli da sottolineare.<br />
<strong>Joker</strong> è geometria perfetta<br />
e versatilità in interni e<br />
in esterni. <strong>In</strong> continuità di<br />
stile. Sempre.
<strong>Prisma</strong>Tech
<strong>Prisma</strong>Tech<br />
<strong>Joker</strong> P<br />
<strong>Joker</strong> - 5
<strong>Prisma</strong>Tech<br />
6 - <strong>Joker</strong><br />
<strong>Joker</strong> Ray
<strong>Joker</strong> Wall<br />
<strong>Prisma</strong>Tech<br />
<strong>Joker</strong> - 7
<strong>Prisma</strong>Tech<br />
8 - <strong>Joker</strong><br />
<strong>Joker</strong> Line<br />
<strong>Joker</strong> <strong>In</strong>
<strong>Prisma</strong>Tech<br />
Soffi tto<br />
La serie <strong>Joker</strong> offre tre diversi apparecchi<br />
installabili a soffi tto, in interni e in esterni,<br />
con sporgenze variabili tra 62 e 120 mm.<br />
Una versione, con anello di soli 3 mm di<br />
sporgenza, è adatta per l’incasso in controsoffi<br />
tti. I diametri variano tra 90 e 108 mm.<br />
Oltre alle versioni led, gli apparecchi sono<br />
disponibili con alogene da 10w, 20w o 40w.<br />
<strong>In</strong>casso<br />
Tre sono gli apparecchi della serie <strong>Joker</strong><br />
adatti per l’incasso a parete, in interni e in<br />
esterni, con sporgenze dal muro variabili<br />
tra 3 e 61 millimetri. La profondità della<br />
controcassa è contenuta in 107 mm.<br />
Una versione di soli 3 mm di sporgenza,<br />
con corpo di profondità ridotta a 85 mm,<br />
è adatta per l’incasso in pareti cave.<br />
I diametri sono compresi tra 90 e 108 mm.<br />
Oltre alle versioni led, gli apparecchi sono<br />
disponibili con alogene da 10w a 40w.<br />
Parete<br />
La serie <strong>Joker</strong> dispone di tre versioni per<br />
l’installazione a parete in superfi cie, senza<br />
controcassa, con sporgenze dal muro<br />
comprese tra 62 e 120 mm e diametro di 90<br />
mm. Sono previste fonti luminose alogene<br />
da 10w, 20w o 40w, oltre alle versioni led.<br />
È disponibile anche un’applique, dalle<br />
dimensioni decisamente più importanti,<br />
che prevede invece tubi fl uorescenti da<br />
18w o 24w.<br />
Terra<br />
La serie <strong>Joker</strong> estende la sua versatilità<br />
con le numerose opzioni di installazione a<br />
terra e su palo, con altezze variabili da 60<br />
mm fi no a oltre 2 metri. Oltre alle versioni<br />
led, le potenze variano dall’alogena 20w,<br />
alla fl uorescente compatta 26w, fi no ai tubi<br />
fl uorescenti, da un minimo di 18w ad un<br />
massimo di 54w.<br />
<strong>Joker</strong> - 9
<strong>Prisma</strong>Tech<br />
10 - <strong>Joker</strong>
<strong>Prisma</strong>Tech<br />
<strong>Joker</strong> Line<br />
<strong>Joker</strong> - 11
<strong>Prisma</strong>Tech<br />
12 - <strong>Joker</strong>
<strong>Joker</strong> Line 2<br />
<strong>Joker</strong> Line 4<br />
<strong>Joker</strong> <strong>In</strong>ground 2<br />
<strong>Joker</strong> <strong>In</strong>ground 4<br />
Ray<br />
Lo schermo e il vetro trasparente<br />
lenticolare dividono la luce<br />
emessa in quattro fasci orientati<br />
con angolo di 90°. Per decorare<br />
una parete, per sottolineare<br />
dettagli architettonici.<br />
<strong>Joker</strong> Line Wall 2<br />
<strong>Joker</strong> Line Wall 4<br />
Line<br />
<strong>Joker</strong> Ray<br />
Fresnel<br />
Un vetro Fresnel trasparente<br />
temperato determina la direzione<br />
dell’emissione luminosa.<br />
Per illuminare selettivamente,<br />
per creare attenzione, per<br />
segnalare percorsi e scalinate.<br />
<strong>Joker</strong> <strong>In</strong> F <strong>Joker</strong> Tondo F <strong>Joker</strong> Wall F<br />
Uno schermo con due finestre<br />
contrapposte oppure con quattro<br />
finestre a 90°, determina le direzioni<br />
di emissione della luce.<br />
Altre configurazioni di emissione<br />
realizzabili su richiesta.<br />
<strong>Prisma</strong>Tech<br />
<strong>Joker</strong> - 13
<strong>Prisma</strong>Tech<br />
14 - <strong>Joker</strong><br />
<strong>Joker</strong> Tondo<br />
<strong>Joker</strong> Wall
<strong>Prisma</strong>Tech<br />
Led<br />
Cinque i colori disponibili per le<br />
versioni led a parete. Le versioni<br />
Vision, caratterizzate dal diffusore<br />
cilindrico, sia su palo che a parete<br />
prevedono solo led di colore blu.<br />
Tutti i led sono ad alto rendimento<br />
luminoso. Gli apparecchi sono forniti<br />
completi di alimentatore 230/24 V.<br />
16 - <strong>Joker</strong><br />
<strong>Joker</strong> P Led<br />
<strong>Joker</strong> Tondo S Led
<strong>Joker</strong> Line 4<br />
<strong>Prisma</strong>Tech<br />
Colore<br />
Tubi fluorescenti T5 e T8 possono<br />
dare a <strong>Joker</strong> luce colorata in tante,<br />
interessanti tonalità. Tutta la libertà<br />
del colore unita al rendimento<br />
luminoso della fluorescenza. Per tutte<br />
le versioni Line, a terra e su mensola.<br />
<strong>Joker</strong> - 17
<strong>Prisma</strong>Tech<br />
<strong>Joker</strong> P<br />
18 - <strong>Joker</strong><br />
<strong>Joker</strong> Line Wall
<strong>Prisma</strong>Tech<br />
<strong>Joker</strong> - 19
<strong>Prisma</strong>Tech<br />
20 - <strong>Joker</strong><br />
<strong>Joker</strong> Quadro S<br />
<strong>Joker</strong> Quadro S Led<br />
<strong>Joker</strong> Tondo S<br />
<strong>Joker</strong> Tondo F<br />
<strong>Joker</strong> Tondo S Led<br />
<strong>Joker</strong> Vision<br />
<strong>Joker</strong> Vision Led<br />
<strong>Joker</strong> Ray<br />
incasso in muratura<br />
<strong>Joker</strong> <strong>In</strong> S<br />
<strong>Joker</strong> <strong>In</strong> F<br />
<strong>Joker</strong> <strong>In</strong> S Led<br />
<strong>Joker</strong> Wall S<br />
<strong>Joker</strong> Wall F<br />
<strong>Joker</strong> Wall S Led<br />
<strong>Joker</strong> Wall Vision<br />
<strong>Joker</strong> Wall Vision Led<br />
parete incasso parete cava
200 cm<br />
150 cm<br />
100 cm<br />
50 cm<br />
controsoffitto soffitto<br />
<strong>Joker</strong> <strong>In</strong> <strong>Joker</strong> Wall<br />
è adatto anche<br />
per controsoffitti<br />
in cartongesso<br />
tutti gli apparecchi Wall<br />
possono essere installati<br />
anche a soffitto<br />
<strong>Prisma</strong>Tech<br />
<strong>Joker</strong> <strong>In</strong>ground <strong>Joker</strong> P <strong>Joker</strong> P Led <strong>Joker</strong> Line 2/<strong>Joker</strong> Line 4<br />
<strong>Joker</strong> Line Wall<br />
terra parete
<strong>Prisma</strong>Tech<br />
<strong>Joker</strong> Tondo - <strong>Joker</strong> Quadro<br />
Serie di apparecchi da incasso a parete in<br />
muratura costituiti da:<br />
¬ corpo-controcassa di ridotta profondità<br />
in tecnopolimero autoestinguente V-0<br />
da ordinare separatamente. L’apposito<br />
coperchio di protezione fornito con il<br />
corpo-controcassa consente di eseguire<br />
<strong>Joker</strong> Tondo S<br />
22 - <strong>Joker</strong><br />
<strong>Joker</strong> Tondo S<br />
G4 max 1x20w HSG SS1 III 55 ˚ ˚ ˚ IK06 15J xx3 6894 4<br />
G9 1x25w HSG SS1 I 55 ˚ ˚ ˚ IK06 15J xx3 6893 * 4<br />
<strong>Joker</strong> Tondo F<br />
<strong>Joker</strong> Tondo F<br />
G4 max 1x20w HSG SS1 III 55 ˚ ˚ ˚ IK06 15J xx3 6896 4<br />
G9 1x25w HSG SS1 I 55 ˚ ˚ ˚ IK06 15J xx3 6895 * 4<br />
<strong>Joker</strong> Tondo S Led<br />
<strong>Joker</strong> Tondo S Led<br />
qualsiasi lavoro di muratura necessario<br />
all’installazione. Sarà quindi suffi ciente<br />
rimuovere in seguito tale coperchio per<br />
inserire la struttura cablata.<br />
¬ Struttura cablata completa di:<br />
¬ Diffusore rotondo o quadro in vetro temperato<br />
satinato nelle versioni “S” per una<br />
attacco w colore classe ip : ; X F codice note master<br />
n.9 led 24V 2w SS1+WH I 55 ˚ ˚ ˚ IK06 15J xx3 6897 el 4<br />
n.9 led 24V 2w SS1+BL I 55 ˚ ˚ ˚ IK06 15J xx3 6898 el 4<br />
n.9 led 24V 2w SS1+YL I 55 ˚ ˚ ˚ IK06 15J xx3 6901 el 4<br />
n.9 led 24V 2w SS1+RD I 55 ˚ ˚ ˚ IK06 15J xx3 6900 el 4<br />
n.9 led 24V 2w SS1+GN I 55 ˚ ˚ ˚ IK06 15J xx3 6899 el 4<br />
Corpo <strong>Joker</strong> Tondo 932 4<br />
90<br />
diffusione soffusa della luce, trasparente<br />
temperato prismato nelle versioni “F” per<br />
un illuminamento più direzionato<br />
¬ Parabola in alluminio per versione G9<br />
¬ Guarnizione in silicone<br />
¬ Coperture e viti di chiusura in acciaio inox<br />
¬ Le versioni “LED” sono fornite complete di<br />
alimentatore 230/24V<br />
105 3 107<br />
110<br />
3<br />
SS1<br />
SS1+WH<br />
SS1+BL<br />
SS1+YL<br />
SS1+RD<br />
SS1+GN<br />
90<br />
<strong>In</strong>ox<br />
<strong>In</strong>ox/<br />
Led bianco<br />
<strong>In</strong>ox/<br />
Led blu<br />
<strong>In</strong>ox/<br />
Led giallo<br />
<strong>In</strong>ox/<br />
Led rosso<br />
<strong>In</strong>ox/<br />
Led verde<br />
el alimentatore<br />
elettronico<br />
* lampada<br />
compresa
La composizione dell’apparecchio si ottiene<br />
dall’unione della struttura cablata scelta con<br />
il relativo corpo-controcassa.<br />
attacco w colore classe ip : ; X F codice note master<br />
<strong>Joker</strong> Quadro S<br />
<strong>Joker</strong> Quadro S<br />
G4 max 1x20w HSG SS1 III 55 ˚ ˚ ˚ IK06 15J xx3 6904 4<br />
G9 1x25w HSG SS1 I 55 ˚ ˚ ˚ IK06 15J xx3 6903 * 4<br />
<strong>Joker</strong> Quadro S Led<br />
<strong>Joker</strong> Quadro S Led<br />
n.9 led 24V 2w SS1+WH I 55 ˚ ˚ ˚ IK06 15J xx3 6905 el 4<br />
n.9 led 24V 2w SS1+BL I 55 ˚ ˚ ˚ IK06 15J xx3 6906 el 4<br />
n.9 led 24V 2w SS1+YL I 55 ˚ ˚ ˚ IK06 15J xx3 6909 el 4<br />
n.9 led 24V 2w SS1+RD I 55 ˚ ˚ ˚ IK06 15J xx3 6908 el 4<br />
n.9 led 24V 2w SS1+GN I 55 ˚ ˚ ˚ IK06 15J xx3 6907 el 4<br />
105 3<br />
90<br />
110<br />
107 3<br />
90<br />
<strong>Prisma</strong>Tech<br />
Corpo <strong>Joker</strong> Quadro 933 4 el alimentatore<br />
elettronico<br />
* lampada<br />
compresa<br />
SS1<br />
SS1+WH<br />
SS1+BL<br />
SS1+YL<br />
SS1+RD<br />
SS1+GN<br />
<strong>In</strong>ox<br />
<strong>In</strong>ox/<br />
Led bianco<br />
<strong>In</strong>ox/<br />
Led blu<br />
<strong>In</strong>ox/<br />
Led giallo<br />
<strong>In</strong>ox/<br />
Led rosso<br />
<strong>In</strong>ox/<br />
Led verde<br />
<strong>Joker</strong> - 23
<strong>Prisma</strong>Tech<br />
<strong>Joker</strong> Vision - <strong>Joker</strong> Ray<br />
Serie di apparecchi da incasso a parete<br />
costituiti da:<br />
¬ corpo-controcassa di ridotta profondità in<br />
tecnopolimero autoestinguente V-0, fi lo incandescente<br />
960° C, da ordinare separatamente.<br />
L’apposito coperchio di protezione<br />
fornito con il corpo-controcassa consente<br />
di eseguire qualsiasi lavoro di muratura<br />
necessario all’installazione.<br />
attacco w colore classe ip : ; X F codice note master<br />
<strong>Joker</strong> Vision<br />
24 - <strong>Joker</strong><br />
<strong>Joker</strong> Vision<br />
E14 max 1x40w IBT SS1 I 55 ˚ ˚ ˚ IK06 15J xx3 6913 4<br />
G4 max 1x20w HSG SS1 III 55 ˚ ˚ ˚ IK06 15J xx3 6912 4<br />
G9 1x40w HSG SS1 I 55 ˚ ˚ ˚ IK06 15J xx3 6911 * 4<br />
<strong>Joker</strong> Vision Led<br />
<strong>Joker</strong> Vision Led<br />
led 24V 2w SS1+BL I 55 ˚ ˚ ˚ IK06 15J xx3 6915 el 4<br />
<strong>Joker</strong> Ray<br />
<strong>Joker</strong> Ray<br />
G9 1x40w HSG GR4 I 55 ˚ ˚ ˚ IK10 20J xx9 6920 * 4<br />
Corpo <strong>Joker</strong> Tondo 932 4<br />
Sarà quindi suffi ciente rimuovere in seguito<br />
tale coperchio per inserire la struttura cablata.<br />
¬ Struttura cablata completa di:<br />
¬ Diffusore cilindrico in vetro satinato nelle<br />
versioni “Vision” per una luce soffusa<br />
¬ Versione “Ray” con diffusore cilindrico in<br />
vetro trasparente prismato e schermo in<br />
alluminio grigio anodizzato con quattro<br />
fi nestre per luce direzionata<br />
105 55<br />
90<br />
¬ Guarnizione in silicone<br />
¬ Coperture e viti di chiusura in acciaio inox<br />
¬ Le versioni “LED” sono fornite complete di<br />
alimentatore 230/24V.<br />
La composizione dell’apparecchio si ottiene<br />
dall’unione della struttura cablata scelta con<br />
il relativo corpo-controcassa.<br />
105 55<br />
90<br />
105 61<br />
SS1<br />
SS1+BL<br />
GR4<br />
90<br />
<strong>In</strong>ox<br />
<strong>In</strong>ox/<br />
Led blu<br />
Grigio<br />
anodizzato<br />
el alimentatore<br />
elettronico<br />
* lampada<br />
compresa
<strong>Joker</strong> <strong>In</strong><br />
Apparecchio da interno per incasso in pareti<br />
cave e controsoffi tti costituito da:<br />
¬ Corpo interno in tecnopolimero autoestinguente<br />
V-0, fi lo incandescente 960° C<br />
¬ Riduzione per ancoraggio alle pareti cave<br />
in tecnopolimero autoestinguente V-0, fi lo<br />
incandescente 960° C<br />
attacco w colore classe ip : ; X F codice note master<br />
<strong>Joker</strong> <strong>In</strong> S<br />
<strong>Joker</strong> <strong>In</strong> S<br />
G4 max 1x10w HSG SS1 III 65 ˚ ˚ ˚ IK07 2J xx5 8722 4<br />
<strong>Joker</strong> <strong>In</strong> F<br />
<strong>Joker</strong> <strong>In</strong> F<br />
G4 max 1x10w HSG SS1 III 65 ˚ ˚ ˚ IK07 2J xx5 8723 4<br />
<strong>Joker</strong> <strong>In</strong> S Led<br />
<strong>Joker</strong> <strong>In</strong> S Led<br />
n.9 led 24V 2w SS1+WH II 65 ˚ ˚ ˚ IK07 2J xx5 8724 el 4<br />
n.9 led 24V 2w SS1+BL II 65 ˚ ˚ ˚ IK07 2J xx5 8725 el 4<br />
n.9 led 24V 2w SS1+YL II 65 ˚ ˚ ˚ IK07 2J xx5 8727 el 4<br />
n.9 led 24V 2w SS1+RD II 65 ˚ ˚ ˚ IK07 2J xx5 8726 el 4<br />
n.9 led 24V 2w SS1+GN II 65 ˚ ˚ ˚ IK07 2J xx5 8721 el 4<br />
<strong>Joker</strong> <strong>In</strong>, utilizzabile solo per incasso<br />
in pareti cave e controsoffi tti, fa parte<br />
della linea <strong>Prisma</strong>Space<br />
¬ Molle di aggancio in acciaio<br />
¬ Diffusore rotondo in vetro temperato satinato<br />
nelle versioni “S” per una diffusione<br />
soffusa della luce, trasparente temperato<br />
prismato nelle versioni “F” per un illuminamento<br />
piu’ direzionato<br />
¬ Guarnizioni in silicone<br />
ø 100<br />
64<br />
max 30<br />
3<br />
ø 108<br />
+ 100 mm<br />
SS1<br />
SS1+WH<br />
SS1+BL<br />
SS1+YL<br />
SS1+RD<br />
SS1+GN<br />
<strong>Prisma</strong>Space<br />
¬ Anello e viti di chiusura in acciaio inox<br />
¬ Le versioni “LED” sono fornite complete di<br />
alimentatore 230/24V<br />
<strong>In</strong>ox<br />
<strong>In</strong>ox/<br />
Led bianco<br />
<strong>In</strong>ox/<br />
Led blu<br />
<strong>In</strong>ox/<br />
Led giallo<br />
<strong>In</strong>ox/<br />
Led rosso<br />
<strong>In</strong>ox/<br />
Led verde<br />
el alimentatore<br />
elettronico<br />
<strong>Joker</strong> - 25
<strong>Prisma</strong>Tech<br />
<strong>Joker</strong> Wall<br />
Serie di apparecchi da interno ed esterno a<br />
parete e soffi tto costituiti da:<br />
¬ Corpo interno in tecnopolimero autoestinguente<br />
V-0, fi lo incandescente 960° C<br />
¬ Copertura estetica H.57 mm in acciaio inox<br />
¬ Diffusore rotondo in vetro temperato satinato<br />
nelle versioni “S” per una diffusione<br />
<strong>Joker</strong> Wall S<br />
26 - <strong>Joker</strong><br />
<strong>Joker</strong> Wall S<br />
G4 max 1x10w HSG SS1 III 64 ˚ ˚ ˚ IK07 2J xx5 8728 4<br />
<strong>Joker</strong> Wall F<br />
<strong>Joker</strong> Wall F<br />
G4 max 1x10w HSG SS1 III 64 ˚ ˚ ˚ IK07 2J xx5 8729 4<br />
<strong>Joker</strong> Wall S Led<br />
<strong>Joker</strong> Wall S Led<br />
n.9 led 24V 2w SS1+WH II 64 ˚ ˚ ˚ IK07 2J xx5 8730 el 4<br />
n.9 led 24V 2w SS1+BL II 64 ˚ ˚ ˚ IK07 2J xx5 8731 el 4<br />
n.9 led 24V 2w SS1+YL II 64 ˚ ˚ ˚ IK07 2J xx5 8733 el 4<br />
n.9 led 24V 2w SS1+RD II 64 ˚ ˚ ˚ IK07 2J xx5 8732 el 4<br />
n.9 led 24V 2w SS1+GN II 64 ˚ ˚ ˚ IK07 2J xx5 8734 el 4<br />
<strong>Joker</strong> Wall Vision<br />
<strong>Joker</strong> Wall Vision<br />
G4 max 1x10w HSG SS1 III 64 ˚ ˚ ˚ IK07 2J xx5 8735 4<br />
G9 1x40w HSG SS1 I 64 ˚ ˚ IK07 2J xx5 8736 * 4<br />
<strong>Joker</strong> Wall Vision Led<br />
<strong>Joker</strong> Wall Vision Led<br />
soffusa della luce, trasparente temperato<br />
prismato nelle versioni “F” per un illuminamento<br />
piu’ direzionato, diffusore cilindrico<br />
in vetro satinato temperato nelle versioni<br />
“Vision” per una luce soffusa.<br />
¬ Guarnizioni in silicone<br />
¬ Anelli e viti di chiusura in acciaio inox<br />
attacco w colore classe ip : ; X F codice note master<br />
led 24V 2w SS1+BL II 64 ˚ ˚ ˚ IK07 2J xx5 8737 el 4<br />
ø 90<br />
62 59 55<br />
90<br />
114<br />
62 59 55<br />
¬ Le versioni “LED” sono fornite complete di<br />
alimentatore 230/24V.<br />
114<br />
ø 90<br />
90<br />
SS1<br />
SS1+WH<br />
SS1+BL<br />
SS1+YL<br />
SS1+RD<br />
SS1+GN<br />
<strong>In</strong>ox<br />
<strong>In</strong>ox/<br />
Led bianco<br />
<strong>In</strong>ox/<br />
Led blu<br />
<strong>In</strong>ox/<br />
Led giallo<br />
<strong>In</strong>ox/<br />
Led rosso<br />
<strong>In</strong>ox/<br />
Led verde<br />
el alimentatore<br />
elettronico<br />
* lampada<br />
compresa
<strong>Joker</strong> Line Wall<br />
Applique da interno ed esterno costituita da:<br />
¬ Schermo di alluminio estruso e verniciato con<br />
due fi nestre (JOKER LINE WALL 2) contrapposte<br />
o quattro fi nestre a 90° (JOKER LINE WALL<br />
4) per uscita direzionata della luce<br />
¬ Altre fi nestre a richiesta<br />
¬ Diffusore cilindrico in policarbonato trasparente<br />
V0, fi lo incandescente 850° C<br />
¬ Vano portacablaggio in tecnopolimero<br />
attacco w colore classe ip : ; X F codice note master<br />
<strong>Joker</strong> Line Wall 2 h. 660<br />
<strong>Joker</strong> Line 2 h.660<br />
G5 1x24w T5 FQ FD GR3 II 55 ˚ ˚ ˚ IK07 2J xx5 6812 el * 1<br />
G5 1x24w T5 FQ FD AN3 II 55 ˚ ˚ ˚ IK07 2J xx5 6813 el * 1<br />
G13 1x18w FD GR3 II 55 ˚ ˚ ˚ IK07 2J xx5 6804 ma 1<br />
G13 1x18w FD AN3 II 55 ˚ ˚ ˚ IK07 2J xx5 6805 ma 1<br />
G13 1x18w FD GR3 II 55 ˚ ˚ ˚ IK07 2J xx5 6808 el 1<br />
G13 1x18w FD AN3 II 55 ˚ ˚ ˚ IK07 2J xx5 6809 el 1<br />
<strong>Joker</strong> Line Wall 4 h. 660<br />
<strong>Joker</strong> Line 4 h.660<br />
G5 1x24w T5 FQ FD GR3 II 55 ˚ ˚ ˚ IK07 2J xx5 6814 el * 1<br />
G5 1x24w T5 FQ FD AN3 II 55 ˚ ˚ ˚ IK07 2J xx5 6815 el * 1<br />
G13 1x18w FD GR3 II 55 ˚ ˚ ˚ IK07 2J xx5 6806 ma 1<br />
G13 1x18w FD AN3 II 55 ˚ ˚ ˚ IK07 2J xx5 6807 ma 1<br />
G13 1x18w FD GR3 II 55 ˚ ˚ ˚ IK07 2J xx5 6810 el 1<br />
G13 1x18w FD AN3 II 55 ˚ ˚ ˚ IK07 2J xx5 6811 el 1<br />
Mensola <strong>Joker</strong> Line Wall GR3 490 1<br />
Mensola <strong>Joker</strong> Line Wall AN3 491 1<br />
Mensola angolare <strong>Joker</strong> Line Wall GR3 492 1<br />
Mensola angolare <strong>Joker</strong> Line Wall AN3 493 1<br />
¬ Flange di chiusura e collegamento in alluminio<br />
verniciato<br />
¬ Corpo diametro 100mm in alluminio estruso<br />
verniciato<br />
¬ Mensola per installazione a parete in alluminio<br />
verniciato<br />
¬ Reattori elettronici<br />
¬ È possibile utilizzare tubi fl uorescenti<br />
colorati normalmente sul mercato<br />
55<br />
120<br />
47,6<br />
6<br />
6<br />
50<br />
¬ Per il suo funzionamento deve essere<br />
abbinato ai relativi pali con mensola<br />
100<br />
100<br />
100<br />
659<br />
519<br />
GR3<br />
AN3<br />
<strong>Prisma</strong>Tech<br />
Grigio<br />
met. opaco<br />
Antracite<br />
met. opaco<br />
ma reattore<br />
magnetico<br />
el reattore<br />
elettronico<br />
* lampada<br />
compresa<br />
<strong>Joker</strong> - 27
<strong>Prisma</strong>Tech<br />
<strong>Joker</strong> Line<br />
Serie di apparecchi da esterno costituiti da:<br />
¬ Schermo in alluminio estruso disponibile<br />
in tre altezze con 2 fi nestre (<strong>Joker</strong> Line 2)<br />
contrapposte o 4 fi nestre a 90° (<strong>Joker</strong> Line<br />
4) per uscita direzionata della luce<br />
¬ Altre fi nestre a richiesta<br />
¬ Diffusore cilindrico in policarbonato trasparente<br />
V-0, fi lo incandescente 850° C<br />
attacco w colore classe ip : ; X F codice note master<br />
<strong>Joker</strong> Line 2 h.260<br />
28 - <strong>Joker</strong><br />
<strong>Joker</strong> Line 2 h.260<br />
G24d-3 1x26w FSQ GR3 II 55 ˚ ˚ ˚ IK07 2J xx5 6800 ma * 1<br />
G24d-3 1x26w FSQ AN3 II 55 ˚ ˚ ˚ IK07 2J xx5 6801 ma * 1<br />
<strong>Joker</strong> Line 2 h.660<br />
<strong>Joker</strong> Line 2 h.660<br />
G5 1x24w T5 FQ FD GR3 II 55 ˚ ˚ ˚ IK07 2J xx5 6812 el * 1<br />
G5 1x24w T5 FQ FD AN3 II 55 ˚ ˚ ˚ IK07 2J xx5 6813 el * 1<br />
G13 1x18w FD GR3 II 55 ˚ ˚ ˚ IK07 2J xx5 6804 ma 1<br />
G13 1x18w FD AN3 II 55 ˚ ˚ ˚ IK07 2J xx5 6805 ma 1<br />
G13 1x18w FD GR3 II 55 ˚ ˚ ˚ IK07 2J xx5 6808 el 1<br />
G13 1x18w FD AN3 II 55 ˚ ˚ ˚ IK07 2J xx5 6809 el 1<br />
<strong>Joker</strong> Line 2 h.1264<br />
<strong>Joker</strong> Line 2 h.1264<br />
G5 1x28w T5 FH FD GR3 II 55 ˚ ˚ ˚ IK07 2J xx5 6816 el * 1<br />
G5 1x28w T5 FH FD AN3 II 55 ˚ ˚ ˚ IK07 2J xx5 6817 el * 1<br />
G5 1x54w T5 FQ FD GR3 II 55 ˚ ˚ ˚ IK07 2J xx5 6820 el * 1<br />
G5 1x54w T5 FQ FD AN3 II 55 ˚ ˚ ˚ IK07 2J xx5 6821 el * 1<br />
G13 1x36w FD GR3 II 55 ˚ ˚ ˚ IK07 2J xx5 6824 el * 1<br />
G13 1x36w FD AN3 II 55 ˚ ˚ ˚ IK07 2J xx5 6825 el * 1<br />
Palo h.510 GR3 896 1<br />
Palo h.510 AN3 897 1<br />
Palo h.930 GR3 898 1<br />
Palo h.930 AN3 899 1<br />
¬ Vano portacablaggio in tecnopolimero<br />
¬ Flange di chiusura e collegamento in alluminio<br />
verniciato<br />
¬ Palo diametro 100 mm in alluminio estruso<br />
verniciato H.510 con fl angia avvitata<br />
¬ <strong>In</strong> alternativa palo diametro 100 mm in alluminio<br />
estruso verniciato H.930 con fl angia<br />
saldata<br />
¬ Le versioni 1X18W, 1X24W, 1X28W, 1X36W e<br />
1X54W utilizzano reattori elettronici<br />
¬ È possibile utilizzare tubi fl uorescenti colorati<br />
normalmente reperibili sul mercato.<br />
L’apparecchio può essere installato solo<br />
con l’apposito palo<br />
ø 100<br />
ø 160<br />
ø 100<br />
ø 160<br />
510 260<br />
770<br />
930 260<br />
1190<br />
510 659<br />
1169<br />
930 659<br />
1589<br />
510 1264<br />
1774<br />
930 1264<br />
2194
attacco w colore classe ip : ; X F codice note master<br />
<strong>Joker</strong> Line 4 h.260<br />
<strong>Joker</strong> Line 4 h.260<br />
G24d-3 1x26w FSQ GR3 II 55 ˚ ˚ ˚ IK07 2J xx5 6802 ma * 1<br />
G24d-3 1x26w FSQ AN3 II 55 ˚ ˚ ˚ IK07 2J xx5 6803 ma * 1<br />
<strong>Joker</strong> Line 4 h.660<br />
<strong>Joker</strong> Line 4 h.660<br />
G5 1x24w T5 FQ FD GR3 II 55 ˚ ˚ ˚ IK07 2J xx5 6814 el * 1<br />
G5 1x24w T5 FQ FD AN3 II 55 ˚ ˚ ˚ IK07 2J xx5 6815 el * 1<br />
G13 1x18w FD GR3 II 55 ˚ ˚ ˚ IK07 2J xx5 6806 ma 1<br />
G13 1x18w FD AN3 II 55 ˚ ˚ ˚ IK07 2J xx5 6807 ma 1<br />
G13 1x18w FD GR3 II 55 ˚ ˚ ˚ IK07 2J xx5 6810 el 1<br />
G13 1x18w FD AN3 II 55 ˚ ˚ ˚ IK07 2J xx5 6811 el 1<br />
<strong>Joker</strong> Line 4 h.1264<br />
<strong>Joker</strong> Line 4 h.1264<br />
G5 1x28w T5 FH FD GR3 II 55 ˚ ˚ ˚ IK07 2J xx5 6818 el * 1<br />
G5 1x28w T5 FH FD AN3 II 55 ˚ ˚ ˚ IK07 2J xx5 6819 el * 1<br />
G5 1x54w T5 FQ FD GR3 II 55 ˚ ˚ ˚ IK07 2J xx5 6822 el * 1<br />
G5 1x54w T5 FQ FD AN3 II 55 ˚ ˚ ˚ IK07 2J xx5 6823 el * 1<br />
G13 1x36w FD GR3 II 55 ˚ ˚ ˚ IK07 2J xx5 6826 el * 1<br />
G13 1x36w FD AN3 II 55 ˚ ˚ ˚ IK07 2J xx5 6827 el * 1<br />
Palo h.510 GR3 896 1<br />
Palo h.510 AN3 897 1<br />
Palo h.930 GR3 898 1<br />
Palo h.930 AN3 899 1<br />
GR3<br />
AN3<br />
<strong>Prisma</strong>Tech<br />
Grigio<br />
met. opaco<br />
Antracite<br />
met. opaco<br />
ma reattore<br />
magnetico<br />
el reattore<br />
elettronico<br />
* lampada<br />
compresa<br />
<strong>Joker</strong> - 29
<strong>Prisma</strong>Tech<br />
<strong>Joker</strong> P<br />
Serie di apparecchi da palo costituiti da:<br />
¬ Base in tecnopolimero<br />
¬ Diffusore cilindrico in vetro satinato<br />
¬ Guarnizione in silicone<br />
¬ Coperture e viti di chiusura in acciaio inox<br />
¬ Palo Ø 90 mm in acciaio inox h 250 mm e h<br />
500 mm completo di fl angia saldata<br />
attacco w colore classe ip : ; X F codice note master<br />
<strong>Joker</strong> P<br />
30 - <strong>Joker</strong><br />
<strong>Joker</strong> P<br />
E14 max 1x40w IBT SS1 I 44 ˚ ˚ ˚ 6924 4<br />
G4 max 1x20w HSG SS1 III 44 ˚ ˚ ˚ 6923 4<br />
G9 1x40w HSG SS1 I 44 ˚ ˚ ˚ 6922 * 4<br />
<strong>Joker</strong> P Led<br />
<strong>Joker</strong> P Led<br />
led 24V 2w SS1+BL I 44 ˚ ˚ ˚ 6926 el 4<br />
Palo inox 250 934 4<br />
Palo inox 500 935 4<br />
¬ La versione “LED” è fornita completa di<br />
alimentatore 230/24V<br />
¬ per il suo funzionamento deve essere<br />
abbinato al relativo palo<br />
55<br />
90<br />
55<br />
90<br />
140<br />
252<br />
SS1<br />
SS1+BL<br />
140<br />
<strong>In</strong>ox<br />
<strong>In</strong>ox/<br />
Led blu<br />
el alimentatore<br />
elettronico<br />
* lampada<br />
compresa<br />
557
<strong>Joker</strong> <strong>In</strong>ground<br />
Apparecchio da esterno con corpo alloggiato<br />
a terra, costituito da:<br />
¬ Schermo in alluminio estruso disponibile<br />
in due altezze e verniciato con due fi nestre<br />
(<strong>Joker</strong> <strong>In</strong>ground 2) contrapposte o quattro<br />
fi nestre a 90° (<strong>Joker</strong> <strong>In</strong>ground 4) per uscita<br />
direzionata della luce.<br />
¬ Altre fi nestre a richiesta.<br />
attacco w colore classe ip : ; X F codice note master<br />
<strong>Joker</strong> <strong>In</strong>ground 2 h. 110<br />
<strong>Joker</strong> Line 2 h.660<br />
G24d-1 1x10w FSQ GR3 I 55 ˚ 6828 ma * 1<br />
G24d-1 1x10w FSQ AN3 I 55 ˚ 6829 ma * 1<br />
<strong>Joker</strong> <strong>In</strong>ground 2 h. 155<br />
<strong>Joker</strong> Line 4 h.660<br />
G24d-2 1x18w FSQ GR3 I 55 ˚ 6832 ma * 1<br />
G24d-2 1x18w FSQ AN3 I 55 ˚ 6833 ma * 1<br />
<strong>Joker</strong> <strong>In</strong>ground 4 h. 110<br />
<strong>Joker</strong> Line 2 h.660<br />
G24d-1 1x10w FSQ GR3 I 55 ˚ 6830 ma * 1<br />
G24d-1 1x10w FSQ AN3 I 55 ˚ 6831 ma * 1<br />
<strong>Joker</strong> <strong>In</strong>ground 4 h. 155<br />
<strong>Joker</strong> Line 4 h.660<br />
G24d-2 1x18w FSQ GR3 I 55 ˚ 6834 ma * 1<br />
G24d-2 1x18w FSQ AN3 I 55 ˚ 6835 ma * 1<br />
Controcassa <strong>Joker</strong> <strong>In</strong>ground 742<br />
¬ Diffusore cilindrico in policarbonato trasparente<br />
V0, fi lo incandescente 850° C.<br />
¬ Vano portacablaggio in tecnopolimero, fi lo<br />
incandescente 750°C<br />
¬ Flange di chiusura e collegamento in alluminio<br />
verniciato.<br />
¬ La versione led è completa di alimentatore<br />
230/24V.<br />
311 114<br />
171<br />
100<br />
124<br />
6<br />
104,5<br />
159<br />
311<br />
171<br />
124<br />
Corpo controcassa da ordinare separatamente<br />
in tecnopolimero da alloggiare a terra.<br />
6<br />
149,5<br />
GR3<br />
AN3<br />
<strong>Prisma</strong>Tech<br />
Grigio<br />
met. opaco<br />
Antracite<br />
met. opaco<br />
ma reattore<br />
magnetico<br />
* lampada<br />
compresa<br />
<strong>Joker</strong> - 31
<strong>Prisma</strong>Tech<br />
<strong>Joker</strong> Tondo S b 1x20w HSG <strong>Joker</strong> Tondo S 1 1x25w HSG<br />
H [m]<br />
1.00<br />
2.00<br />
3.00<br />
4.00<br />
5.00<br />
H [m]<br />
1.00<br />
2.00<br />
3.00<br />
4.00<br />
5.00<br />
H [m]<br />
1.00<br />
2.00<br />
3.00<br />
4.00<br />
5.00<br />
32 - <strong>Joker</strong><br />
= 63° + 63 °<br />
= 13° + 118 °<br />
H [m] 1.00 2.00 3.00 4.00 5.00<br />
OA 3.33 6.65 9.98 13.31 16.63<br />
OB 1.33 2.66 3.99 5.33 6.66<br />
= 61° + 61 °<br />
H [m] 1.00 2.00 3.00 4.00 5.00<br />
OA 1.83 3.65 5.48 7.30 9.13<br />
OB 1.83 3.65 5.48 7.30 9.13<br />
C<br />
= 0°<br />
D O<br />
B A<br />
H [m] 1.00 2.00 3.00 4.00 5.00<br />
OA 1.99 3.99 5.98 7.97 9.97<br />
OB 1.99 3.99 5.98 7.97 9.97<br />
= - 58° = 39° + 39°<br />
D O<br />
B A<br />
= 0° = 61° + 61°<br />
D O<br />
B A<br />
C<br />
H [m] 1.00 2.00 3.00 4.00 5.00<br />
OC 1.99 3.99 5.98 7.97 9.97<br />
OD 1.99 3.99 5.98 7.97 9.97<br />
H [m] 1.00 2.00 3.00 4.00 5.00<br />
OC 0.82 1.64 2.45 3.27 4.09<br />
OD 0.82 1.64 2.45 3.27 4.09<br />
C<br />
H [m] 1.00 2.00 3.00 4.00 5.00<br />
OC 1.83 3.65 5.48 7.30 9.13<br />
OD 1.83 3.65 5.48 7.30 9.13<br />
maxLux medLux<br />
14<br />
3<br />
2<br />
1<br />
1<br />
15<br />
4<br />
2<br />
1<br />
1<br />
maxLux medLux<br />
15<br />
4<br />
2<br />
1<br />
1<br />
3<br />
1<br />
0<br />
0<br />
0<br />
maxLux medLux<br />
4<br />
1<br />
0<br />
0<br />
0<br />
3<br />
1<br />
0<br />
0<br />
0<br />
H [m]<br />
1.00<br />
2.00<br />
3.00<br />
4.00<br />
5.00<br />
H [m]<br />
1.00<br />
2.00<br />
3.00<br />
4.00<br />
H [m]<br />
1.00<br />
2.00<br />
3.00<br />
4.00<br />
5.00<br />
= 55° + 55 °<br />
H [m] 1.00 2.00 3.00 4.00 5.00<br />
OA 1.42 2.83 4.25 5.66 7.08<br />
OB 1.42 2.83 4.25 5.66 7.08<br />
= 57° + 56 °<br />
H [m] 1.00 2.00 3.00 4.00 5.00<br />
OA 1.75 3.49 5.24 6.99 8.73<br />
OB 1.38 2.76 4.13 5.51 6.89<br />
= 62° + 62 °<br />
H [m] 1.00 2.00 3.00 4.00 5.00<br />
OA 1.91 3.81 5.72 7.62 9.53<br />
OB 1.91 3.81 5.72 7.62 9.53<br />
= 0°<br />
D O<br />
B A<br />
= 5° = 2° + 2°<br />
= 0°<br />
H [m] 1.00 2.00 3.00 4.00 5.00<br />
OC 1.42 2.83 4.25 5.66 7.08<br />
OD 1.42 2.83 4.25 5.66 7.08<br />
<strong>Joker</strong> Tondo F b 1x20w HSG <strong>Joker</strong> Tondo F 1 1x25w HSG<br />
H [m] 1.00 2.00 3.00 4.00 5.00<br />
OC 0.03 0.06 0.09 0.12 0.15<br />
OD 0.03 0.06 0.09 0.12 0.15<br />
D O<br />
B A<br />
C<br />
H [m] 1.00 2.00 3.00 4.00 5.00<br />
OC 1.91 3.81 5.72 7.62 9.53<br />
OD 1.91 3.81 5.72 7.62 9.53<br />
maxLux medLux<br />
maxLux medLux<br />
5.00<br />
1<br />
C<br />
B DO<br />
A<br />
<strong>Joker</strong> Quadro S b 1x20w HSG <strong>Joker</strong> Quadro S 1 1x25w HSG<br />
<strong>Joker</strong> <strong>In</strong> S b 1x10w HSG <strong>Joker</strong> <strong>In</strong> F b 1x10w HSG<br />
H [m]<br />
1.00<br />
2.00<br />
3.00<br />
4.00<br />
5.00<br />
= 83° + 30 °<br />
= - 27° = 51° + 52°<br />
B O<br />
A<br />
D<br />
H [m] 1.00 2.00 3.00 4.00 5.00<br />
OA 1.04 2.08 3.13 4.17 5.21<br />
OB 1.97 3.94 5.91 7.89 9.86<br />
H [m] 1.00 2.00 3.00 4.00 5.00<br />
OC 1.29 2.58 3.87 5.15 6.44<br />
OD 1.22 2.43 3.65 4.86 6.08<br />
Apertura a metà intensità di picco (m)<br />
C<br />
maxLux medLux<br />
5<br />
2<br />
1<br />
0<br />
0<br />
2<br />
0<br />
0<br />
0<br />
0<br />
H [m]<br />
1.00<br />
2.00<br />
3.00<br />
4.00<br />
5.00<br />
= 35° + 11 °<br />
H [m] 1.00 2.00 3.00 4.00 5.00<br />
OA 0.20 0.39 0.59 0.78 0.98<br />
OB 0.73 1.45 2.18 2.91 3.64<br />
C<br />
= - 4° = 36° + 40°<br />
D O<br />
B A<br />
C<br />
H [m] 1.00 2.00 3.00 4.00 5.00<br />
OC 0.83 1.65 2.48 3.30 4.13<br />
OD 0.73 1.45 2.18 2.90 3.63<br />
14<br />
3<br />
2<br />
1<br />
1<br />
19<br />
5<br />
2<br />
1<br />
maxLux medLux<br />
16<br />
4<br />
2<br />
1<br />
1<br />
8<br />
2<br />
1<br />
1<br />
0<br />
4<br />
1<br />
0<br />
0<br />
0<br />
7<br />
2<br />
1<br />
0<br />
0<br />
3<br />
1<br />
0<br />
0<br />
0<br />
maxLux medLux<br />
4<br />
1<br />
0<br />
0<br />
0<br />
<strong>Joker</strong> Wall S b 1x10w HSG<br />
H [m]<br />
1.00<br />
2.00<br />
3.00<br />
4.00<br />
5.00<br />
<strong>Joker</strong> Wall F b 1x10w HSG<br />
H [m]<br />
1.00<br />
2.00<br />
3.00<br />
4.00<br />
5.00<br />
= 83° + 30 °<br />
= 35° + 11 °<br />
H [m] 1.00 2.00 3.00 4.00 5.00<br />
OA 0.20 0.39 0.59 0.78 0.98<br />
OB 0.73 1.45 2.18 2.91 3.64<br />
= - 27° = 51° + 52°<br />
B O<br />
A<br />
D<br />
H [m] 1.00 2.00 3.00 4.00 5.00<br />
OA 1.04 2.08 3.13 4.17 5.21<br />
OB 1.97 3.94 5.91 7.89 9.86<br />
H [m] 1.00 2.00 3.00 4.00 5.00<br />
OC 1.29 2.58 3.87 5.15 6.44<br />
OD 1.22 2.43 3.65 4.86 6.08<br />
= - 4° = 36° + 40°<br />
D O<br />
B A<br />
C<br />
C<br />
H [m] 1.00 2.00 3.00 4.00 5.00<br />
OC 0.83 1.65 2.48 3.30 4.13<br />
OD 0.73 1.45 2.18 2.90 3.63<br />
maxLux medLux<br />
5<br />
2<br />
1<br />
0<br />
0<br />
maxLux medLux<br />
8<br />
2<br />
1<br />
1<br />
0<br />
2<br />
0<br />
0<br />
0<br />
0<br />
4<br />
1<br />
0<br />
0<br />
0
max = 61 lx/klm<br />
2.0m<br />
1.5m<br />
1.0m<br />
0.5m<br />
0.0m<br />
-0.5m<br />
-1.0m<br />
-1.5m<br />
<strong>Joker</strong> Wall Vision<br />
b 1x10w HSG<br />
-2.0m<br />
-2.0m -1.0m 0.0m 1.0m<br />
max = 59 lx/klm<br />
2.0m<br />
1.5m<br />
1.0m<br />
0.5m<br />
0.0m<br />
-0.5m<br />
-1.0m<br />
-1.5m<br />
max = 37 lx/klm<br />
4.0m<br />
3.0m<br />
2.0m<br />
1.0m<br />
0.0m<br />
-1.0m<br />
-2.0m<br />
-3.0m<br />
1<br />
3<br />
5<br />
2<br />
20 2<br />
10<br />
20 8<br />
3 20<br />
5<br />
10<br />
5 3<br />
20<br />
1 2<br />
8<br />
1<br />
30<br />
30<br />
30<br />
-4.0m<br />
-4.0m -2.0m 0.0m 2.0m<br />
120<br />
105<br />
90<br />
75<br />
60<br />
2.0m<br />
<strong>Joker</strong> Vision 4 1x40w IBT<br />
1<br />
2 10<br />
3<br />
1<br />
-2.0m<br />
-2.0m -1.0m 0.0m 1.0m<br />
<strong>Joker</strong> Line Wall 2<br />
J 1x18w FD<br />
angoli gamma<br />
10<br />
30<br />
45 30 15<br />
0° 45° 90°<br />
1<br />
3<br />
20<br />
2<br />
20<br />
5<br />
1<br />
180 165 150<br />
60<br />
40<br />
20<br />
20<br />
40<br />
60<br />
0<br />
2<br />
2.0m<br />
4.0m<br />
135<br />
15 30 45<br />
120<br />
105<br />
90<br />
75<br />
60<br />
cd/klm<br />
max = 54 lx/klm<br />
4.0m<br />
3.0m<br />
2.0m<br />
1.0m<br />
2<br />
0.0m<br />
3<br />
-1.0m<br />
-2.0m<br />
-3.0m<br />
<strong>Joker</strong> Line Wall 2 A 1x24w T5 FQ FD<br />
1 1<br />
10<br />
20<br />
-4.0m<br />
-4.0m -2.0m 0.0m 2.0m<br />
120<br />
105<br />
90<br />
75<br />
60<br />
angoli gamma<br />
45 30 15<br />
0° 45° 90°<br />
0<br />
20<br />
10<br />
3<br />
2<br />
4.0m<br />
180 165 150<br />
60<br />
40<br />
20<br />
20<br />
40<br />
60<br />
135<br />
15 30 45<br />
120<br />
105<br />
90<br />
75<br />
60<br />
cd/klm<br />
max = 37 lx/klm<br />
4.0m<br />
3.0m<br />
2.0m<br />
1.0m<br />
0.0m<br />
-1.0m<br />
<strong>Joker</strong> Line Wall 4<br />
J1x18w FD<br />
2<br />
3<br />
5<br />
1<br />
-2.0m<br />
1 1<br />
5<br />
-3.0m<br />
3<br />
2<br />
-4.0m<br />
-4.0m -2.0m 0.0m 2.0m<br />
120<br />
105<br />
90<br />
75<br />
60<br />
angoli gamma<br />
3<br />
10<br />
25<br />
45 30 15<br />
0° 45° 90°<br />
2<br />
5<br />
20<br />
15<br />
5 2<br />
3<br />
<strong>Joker</strong> P 4 1x40w IBT <strong>Joker</strong> P b 1x20w HSG<br />
<strong>Joker</strong> P 1 1x40w HSG<br />
Curve isolux unitarie riferite a 1 KLm e<br />
a 1 m di altezza<br />
Diagramma polare<br />
5<br />
max = 40 lx/klm<br />
2.0m<br />
1.5m<br />
1.0m<br />
0.5m<br />
0.0m<br />
-0.5m<br />
-1.0m<br />
-1.5m<br />
max = 125 lx/klm<br />
2.0m<br />
1.5m<br />
1.0m<br />
0.5m<br />
0.0m<br />
-0.5m<br />
-1.0m<br />
-1.5m<br />
<strong>Joker</strong> Wall Vision<br />
1 1x40w HSG<br />
1<br />
5<br />
-2.0m<br />
-2.0m -1.0m 0.0m 1.0m<br />
-2.0m<br />
-2.0m -1.0m 0.0m 1.0m<br />
4<br />
10<br />
2<br />
8<br />
1<br />
3<br />
5<br />
1<br />
3<br />
15<br />
10<br />
20 20<br />
3<br />
1<br />
20 10<br />
2<br />
8<br />
5<br />
2<br />
5<br />
2<br />
3<br />
1<br />
2.0m<br />
2.0m<br />
max = 90 lx/klm<br />
2.0m<br />
1.5m<br />
1.0m<br />
0.5m<br />
0.0m<br />
-0.5m<br />
-1.0m<br />
-1.5m<br />
1<br />
2<br />
-2.0m<br />
-2.0m -1.0m 0.0m 1.0m<br />
3<br />
10<br />
20<br />
1<br />
2<br />
5<br />
15<br />
0<br />
4.0m<br />
180 165 150<br />
60<br />
40<br />
20<br />
20<br />
40<br />
60<br />
1<br />
2.0m<br />
135<br />
15 30 45<br />
120<br />
105<br />
90<br />
75<br />
60<br />
cd/klm<br />
max = 1050 lx/klm<br />
2.0m<br />
1<br />
1.5m<br />
2<br />
1.0m<br />
3 5<br />
0.5m<br />
10<br />
0.0m<br />
-0.5m<br />
-1.0m<br />
-1.5m<br />
-2.0m<br />
-2.0m -1.0m 0.0m 1.0m<br />
max = 60 lx/klm<br />
4.0m<br />
3.0m<br />
2.0m<br />
1.0m<br />
2<br />
0.0m<br />
-1.0m<br />
-2.0m<br />
1<br />
<strong>Joker</strong> Line Wall 4<br />
A1x24w T5 FQ FD<br />
3<br />
5<br />
1<br />
40<br />
20<br />
1 1<br />
10<br />
-3.0m<br />
5<br />
3<br />
-4.0m<br />
2<br />
-4.0m -2.0m 0.0m 2.0m<br />
2<br />
3<br />
3<br />
20<br />
5<br />
2<br />
20<br />
40<br />
5<br />
1<br />
1<br />
3<br />
2<br />
<strong>Prisma</strong>Tech<br />
<strong>Joker</strong> Vision b 1x20w HSG <strong>Joker</strong> Vision 1 1x40w HSG <strong>Joker</strong> Ray 1 1x40w 12V HSG<br />
2.0m<br />
4.0m<br />
<strong>Joker</strong> - 33
<strong>Prisma</strong>Tech<br />
max = 36 lx/klm<br />
4.0m<br />
3.0m<br />
2.0m<br />
1.0m<br />
0.0m<br />
-1.0m<br />
-2.0m<br />
-3.0m<br />
<strong>Joker</strong> Line 2 h.260<br />
A1x26w FSQ<br />
2<br />
-4.0m<br />
-4.0m -2.0m 0.0m 2.0m<br />
34 - <strong>Joker</strong><br />
1<br />
10<br />
max = 55 lx/klm<br />
4.0m<br />
3.0m<br />
2.0m<br />
1.0m<br />
3<br />
0.0m<br />
-1.0m<br />
-2.0m<br />
-3.0m<br />
1<br />
5<br />
4.0m<br />
<strong>Joker</strong> Line 2 h.1264<br />
J1x36w FD<br />
2<br />
10<br />
1 1<br />
20<br />
-4.0m<br />
-4.0m -2.0m 0.0m 2.0m<br />
max = 60 lx/klm<br />
4.0m<br />
3.0m<br />
2.0m<br />
1.0m<br />
2<br />
0.0m<br />
-1.0m<br />
-2.0m<br />
5<br />
1<br />
<strong>Joker</strong> Line 4 h.660<br />
A1x24w T5 FQ FD<br />
3<br />
5<br />
1<br />
20<br />
-3.0m<br />
5<br />
3<br />
-4.0m<br />
2<br />
-4.0m -2.0m 0.0m 2.0m<br />
3<br />
20<br />
30<br />
1 1<br />
10<br />
5<br />
2<br />
40<br />
3<br />
2<br />
5<br />
4.0m<br />
4.0m<br />
Curve isolux unitarie riferite a 1 KLm e<br />
a 1 m di altezza<br />
5<br />
1<br />
3<br />
2<br />
max = 37 lx/klm<br />
4.0m<br />
3.0m<br />
2.0m<br />
1.0m<br />
0.0m<br />
-1.0m<br />
-2.0m<br />
-3.0m<br />
<strong>Joker</strong> Line 2 h.660<br />
J1x18w FD<br />
1<br />
2 10<br />
3<br />
-4.0m<br />
-4.0m -2.0m 0.0m 2.0m<br />
max = 95 lx/klm<br />
4.0m<br />
3.0m<br />
2.0m<br />
1.0m<br />
5<br />
0.0m<br />
-1.0m<br />
-2.0m<br />
-3.0m<br />
2<br />
10<br />
-4.0m<br />
-4.0m -2.0m 0.0m 2.0m<br />
20<br />
1 1<br />
60<br />
20<br />
5<br />
1<br />
10<br />
40<br />
20<br />
3 3<br />
1<br />
2<br />
2<br />
5<br />
4.0m<br />
<strong>Joker</strong> Line 2 h.1264<br />
A1x54w T5 FQ FD<br />
max = 51 lx/klm<br />
4.0m<br />
3.0m<br />
2.0m<br />
1.0m<br />
0.0m<br />
-1.0m<br />
-2.0m<br />
4.0m<br />
<strong>Joker</strong> Line 4 h.1264<br />
A1x28w T5 FQ FD<br />
3<br />
1<br />
2<br />
5<br />
8<br />
1<br />
10<br />
20<br />
8<br />
-3.0m<br />
5<br />
-4.0m<br />
2<br />
3<br />
-4.0m -2.0m 0.0m 2.0m<br />
3<br />
8<br />
5<br />
10<br />
20<br />
10<br />
40<br />
2<br />
5<br />
3<br />
10<br />
8<br />
1<br />
1<br />
2<br />
4.0m<br />
max = 54 lx/klm<br />
4.0m<br />
3.0m<br />
2.0m<br />
1.0m<br />
2<br />
0.0m<br />
3<br />
-1.0m<br />
-2.0m<br />
-3.0m<br />
<strong>Joker</strong> Line 2 h.660<br />
A1x24w T5 FQ FD<br />
1 1<br />
10<br />
20<br />
-4.0m<br />
-4.0m -2.0m 0.0m 2.0m<br />
max = 39 lx/klm<br />
4.0m<br />
3.0m<br />
2.0m<br />
1.0m<br />
0.0m<br />
-1.0m<br />
-2.0m<br />
-3.0m<br />
<strong>Joker</strong> Line 4 h.260<br />
p1x26w FSQ<br />
-4.0m<br />
-4.0m -2.0m 0.0m 2.0m<br />
20<br />
1<br />
2<br />
3<br />
5<br />
10<br />
1<br />
25<br />
1<br />
2 3<br />
15<br />
20<br />
10<br />
3<br />
2<br />
4.0m<br />
4.0m<br />
<strong>Joker</strong> Line 4 h.1264<br />
J1x36w FD<br />
max = 55 lx/klm<br />
4.0m<br />
3.0m<br />
2.0m 1<br />
1 3<br />
5<br />
8<br />
10<br />
20<br />
2 1<br />
1<br />
1.0m 2<br />
5 10 40<br />
5<br />
0.0m<br />
10<br />
-1.0m<br />
3<br />
8<br />
20<br />
50<br />
8 3<br />
2<br />
-2.0m<br />
1<br />
10<br />
1<br />
-3.0m<br />
5<br />
8<br />
-4.0m<br />
2<br />
3<br />
-4.0m -2.0m 0.0m 2.0m 4.0m<br />
max = 52 lx/klm<br />
4.0m<br />
3.0m<br />
2.0m<br />
1.0m<br />
0.0m<br />
-1.0m<br />
-2.0m<br />
-3.0m<br />
<strong>Joker</strong> Line 2 h.1264<br />
A1x28w T5 FQ FD<br />
1<br />
2<br />
5<br />
20<br />
10<br />
3<br />
10<br />
30<br />
3<br />
-4.0m<br />
-4.0m -2.0m 0.0m 2.0m<br />
max = 37 lx/klm<br />
4.0m<br />
3.0m<br />
2.0m<br />
1.0m<br />
0.0m<br />
-1.0m<br />
<strong>Joker</strong> Line 4 h.660<br />
J1x18w FD<br />
2<br />
3<br />
5<br />
1<br />
-2.0m<br />
1 1<br />
5<br />
-3.0m<br />
3<br />
2<br />
-4.0m<br />
-4.0m -2.0m 0.0m 2.0m<br />
3<br />
10<br />
25<br />
max = 79 lx/klm<br />
4.0m<br />
3.0m<br />
1 3<br />
5<br />
2.0m<br />
1<br />
2<br />
10<br />
20<br />
1.0m<br />
0.0m<br />
-1.0m<br />
2<br />
-2.0m<br />
-3.0m<br />
3<br />
5<br />
10 20<br />
40<br />
2<br />
5<br />
1<br />
2<br />
20<br />
15<br />
5 2<br />
3<br />
1 1<br />
20<br />
-4.0m<br />
2<br />
5<br />
3<br />
-4.0m -2.0m 0.0m 2.0m<br />
10<br />
50<br />
2 1<br />
20<br />
10<br />
3<br />
1<br />
5<br />
2<br />
4.0m<br />
4.0m<br />
<strong>Joker</strong> Line 4 h.1264<br />
A1x54w T5 FQ FD<br />
4.0m
Impegnata nella produzione di apparecchi<br />
di illuminazione per uso domestico e<br />
residenziale, si è da tempo affermata<br />
tra le più importanti aziende italiane del<br />
settore. Attiva dal 1978, esporta più del<br />
50% del fatturato in oltre 90 paesi esteri.<br />
È presente con filiali e consociate in<br />
Francia, Stati Uniti, Regno Unito.<br />
:<br />
Un laboratorio interno, riconosciuto<br />
dall’IMQ, garantisce che tutti i prodotti<br />
<strong>Prisma</strong> siano testati secondo le norme<br />
europee per la sicurezza e per l’efficienza.<br />
Nel luglio 1996 <strong>Prisma</strong> ha ottenuto la<br />
certificazione di qualità secondo le<br />
norme UNI EN ISO 9001, e la mantiene<br />
attualmente lavorando secondo gli<br />
standard UNI EN ISO 9001:2000.<br />
Garantire la qualità e la sicurezza dei<br />
prodotti, perseguire elevati standard<br />
tecnici, fornire adeguati strumenti e<br />
informazioni al mondo professionale:<br />
questi sono gli obbiettivi di Performance<br />
in Lighting.<br />
Le aziende del settore illuminotecnico<br />
che si uniscono in questi valori<br />
costituiscono una nuova realtà<br />
strategica, capace di valorizzare a livello<br />
finanziario, tecnologico, commerciale<br />
e professionale, tutte le politiche e le<br />
attività intraprese collettivamente.
Dalle linee <strong>Prisma</strong><br />
Cruiser<br />
<strong>Prisma</strong>Navy<br />
PRISMA S.p.A.<br />
V.le del Lavoro, 9/11<br />
37030 Colognola ai Colli<br />
Verona - Italia<br />
Tel. +39.045.61.59.211<br />
Fax Italia +39.045.61.59.292<br />
Fax Export +39.045.61.59.393<br />
www.prisma-illuminazione.com<br />
PERFORMANCE IN LIGHTING<br />
www.performanceinlighting.com<br />
<strong>In</strong>dex<br />
<strong>Prisma</strong>Tech<br />
CycloPlat<br />
<strong>Prisma</strong>Tech<br />
ITA 11-2004
