IskraPLAMENSKE ŽARILNE SVEČKEFLAME HEATER PLUGSKODA STARA KODA cm 3 /minREF. NO. REF. NO.-old M1 M2 **** V A11720303 11.303 1/2” BSP 3/8” 24 UNF 2-3,2 12 12,5 211720304 11.304 M 22X1,5 M 10X1 3,5-5 12 12,5 211720305 11.305 7/8” 14 UNF 3/8” 24 UNF 3,5-5 12 12,5 211720306 11.306 1/2” BSP 3/8” UNF 3,5-5 12 12,5 211720308 11.308 1/2” BSP 3/8” 24 UNF 7-12 24 8,0 111720309 11.309 1/2” BSP 3/8” 24 UNF 11-15 24 8,0 211720310 11.310 A 1/2” BSP 3/8” 24 UNF 3,5-5 24 6,0 211720311 11.301 M 22X1.5 M 10X1 3,5-5 12 12,5 111720312 11.302 7/8” 14 UNF 3/8” 24 UNF 3,5-5 12 12,5 111720313 11.311 M 22X1,5 M 10X1 2-3,2 12 12,5 111720316 11.312 7/8” 14 UNF 3/8” 24 UNF 7-12 24 8,0 111720317 11.307 M 22X1,5 M 10X1 3,5-5 24 6,0 111720318 11.313 7/8” 14 UNF 3/8” 24 UNF 7-12 24 8,0 211720319 11.314 1/2” BSP 3/8” 24 UNF 3,5-5 12 12,5 111720320 11.315 M 22X1,5 3/8” 24 UNF 2-3,2 12 12,5 211720321 11.316 7/8” 14 UNF 3/8” 24 UNF 2-3,2 12 12,5 211720323 * 7/8” 14 UNF 3/8” 24 UNF 3,5-5 12 12,5 211720324 * 7/8” 14 UNF 3/8” 24 UNF 3,5-5 12 12,5 111720328 11.318 M 20X1,5 M 10X1 7-12 24 8,0 111720331 11.320 M 20X1,5 M 10X1 3,5-5 24 6,0 211720333 11.321 7/8” 14 UNF 3/8” 24 UNF 3,5-5 24 6,0 111720337 11.324 1/2” BSP 3/8” 24 UNF 7-12 24 8,0 211720339 11.326 7/8” 14 UNF 3/8” 24 UNF 7-12 12 15,5 211720343 * 1/2” BSP 3/8” 24 UNF 3,5-5 12 12,5 211720344 * 7/8” 14 UNF 3/8” 24 UNF 2-3,2 12 12,5 111720345 7/8” 14 UNF 3/8” 24 UNF 7-12 12 15,5 111720359 1/2” BSP 3/8” 24 UNF 7-12 12 15,5 111720360 M 22X1,5 3/8” 24 UNF 3,5-5 12 12,5 211720361 * 1/2” BSP 3/8” 24 UNF 11-15 24 8,0 211720371 * 1/2” BSP 3/8” 24 UNF 7-12 24 8,0 211720375 *** 7/8” 14 UNF 3/8” 24 UNF 2-3,2 12 12,5 211720401 * M 22X1,5 3/8” 24 UNF 3,5-5 12 12,5 211720402 * M 22X1,5 3/8” 24 UNF 3,5-5 12 12,5 111720409 * 7/8” 14 UNF 3/8” 24 UNF 7-12 12 15,5 211720410 ** 7/8” 14 UNF 3/8” 24 UNF 3,5-5 12 12,5 211720430 M 22X1,5 M 10 x 1 300 # 8 24,0 3 FORD* ZA TURBO MOTORJEFOR TURBO ENGINES** FASTON 6,3 x 0,8*** ZA TURBO MOTORJE + FASTON 6,3 x 0,8FOR TURBO ENGINES + FASTON 6,3 x 0,8**** PRETOK GORIVA - PLINSKO OLJE (NAFTA D2) PRI TEMPERATURI 20°C, VISKOZNOST 1,55°E, TLAK 2,5kPaFUEL FLOWRATE - GAS OIL AT 20°C, VISCOSITY 1,55°E, PRESSURE 2,5 kPa# PRETOK ZRAKA cm 3 /min PRI 20°C IN TLAKU 150 kPaAIR FLOW cm 3 /min AT 20°C AND PRESSURE 150 kPa (ROTA VALUE)60
IskraPOSEBNE ŽARILNE SVEČKESPECIAL HEATER PLUGS1 -enopolnaKODA TESNENJE* VGRADNJA -single poleM L L1 SW V AREF.NO. TIGHTENING* APPLICATION 2 -dvopolna-double pole11720101 M18 X 1.50 85 23 21 0,8 51,5 2 MERCEDES 2 211720103 M18 X 1.50 91,0 28,0 21 0,9 42,0 2 MERCEDES 2 211720204 M18 X 1.50 93 49 24 4 15,8 1 WEBASTO 2 /11720205 M14 X 1.25 65,0 32,5 19 12,0 20,0 1 WEBASTO 2 111720207 M14 X 1.25 62,5 42,5 19 12,0 20,0 1 EBERSPÄCHER 2 111720208 M14 X 1.25 64,0 43,0 19 24,0 13,0 1 WEBASTO 2 111720209 M22 X 1.50 103,0 65,0 27 12,0 58,0 2 PERKINS 2 111720210 UNF 7/8-14 89,0 65,0 27 11,0 64,0 2 FIAT, JD 1 111720211 M22 x 1,50 89,0 65,0 27 11,0 50,0 2 FORD 1 111720212 G 1/2 85,5 53,0 24 12,0 28,0 2 LISTER PETTER 1 1* 1 - TESNILNI OBROČ- GASKET2 - RAVNO- PLANIskraMAGNETNI VENTILISOLENOID VALVESKODA NAPETOST NAPETOST REL. DOBAV W l/h * Ω PRITEG ODPUST VKL. (%)REF.NO. STARTING HOLDING DUTYTENSION [V] VOLTAGE CYCLE (%)11728104 12 20 7 32+/-0.5 7,5 V 3 V 100 111728106 12 20 4 8+/- 0,5 7,5 V 3 V 100 111728107 12 48 4 3+/- 0.25 7,5 V 3 V 25 111728108 12 48 7 3+/- 0,25 7,5 V 3 V 25 111728204 24 20 7 32 +/-2 14 V 7 V 100 111728206 24 20 4 32+/- 2 14 V 7 V 100 111728207 24 45 4 13+/- 0,5 12 V 7 V 25 111728208 24 45 7 13+/- 0,5 12 V 7 V 25 111728303 12 48 4 3+/- 0,25 7,5 V 3 V 25 211728304 12 20 4 8+/- 0,5 7,5 V 3 V 100 211728403 24 45 4 13+/- 0,5 12 V 7 V 25 211728404 24 20 4 32+/- 2 14 V 7 V 100 262* T = 20°C; p = 5kPa
IskraZAPORNI VENTILISTOP SOLENOIDSKODA REL. DOBA VKL. (%)V W ΩREF.NO. DUTY CYCLE (%)11728120 12 18 8,0 100 111728121 12 16 9,0 100 211728125 12 20 7,5 100 311728134 12 18 7,5 100 311728220 24 20 32,0 100 311728224 24 16 35,0 100 211728228 24 18 30,0 100 311728229 24 16 35,0 100 111728305 12 16 9,2 100 411728407 24 16 35,0 100 4KODA REL. DOBA VKL. (%)VWREF.NO. DUTY CYCLE (%)11728139 12 1-8 10063
IskraKRMILNIKI ZA ČEPNE SVEČKECONTROL UNITS FOR GLOW PLUGSKODA ČAS ČAS NAPETOSTNA TOKOVNA VGRAJENV PREDŽARENJA POŽARENJA ZAŠČITA ZAŠČITA TEMP. SENZORREF.NO. PREHEATING POSTHEATING OVERVOLTAGE OVERCURRENT INCORPORATEDTIME * TIME * PROTECTION PROTECTION TEMP. SENSOR11 760 035 12 8s - YES YES YES11 760 036 12 8s 11s YES YES YES11 760 037 12 20s 15s YES YES YES11 760 038 12 11s - YES YES YES11 760 130 12 11s 10s YES YES YES11 760 131 12 11s - YES YES YES11 760 132 12 20s - YES YES YES* ambient temperature = 0 °CIskraGRELNIKI ZRAKAAIR HEATERSKODAREF. NO.W11722602 1200 12 111722603 2000 12/24 211722604 2000 12 311722605 2000 24 311722606 1400 24 111722607 700 12 1V64
IskraMOČNOSTNI RELEJIPOWER RELAYSMOČNOSTNI RELE SE UPORABLJA ZA NEKATERE VRSTE STARTERJEV IN ZA KATERIKOLI DRUGI MOČNOSTNI ELEMENT VVOZILU. PROIZVAJAMO DVE VRSTI RELEJEV:POWER RELAY IS USED FOR SOME TYPE OF STARTERS AND FOR ANY OTHER POWER PART IN VEHICLE. WE PRODUCE TWOTYPES:• 12 V: max 200 A• 24 V: max 100 AIskraPREDUPORI Z BIMETALNIM KONTAKTOMSERIES RESISTORS FOR HEATER PLUGSKODAREF. NO.STARA KODAREF. NO.-old11722401 12.401 4,5 22,811722402 12.402 4,5 11,411722403 12.403 2,5 22,411722404 12.404 2,5 44,011722406 ASC 1401 3,7 22,811722407 ASC 1451 1,5 22,811722408 ASC 1402 3,5 11,411722410 2,5 22,411722412 2,0 22VAIskraTERMOSTATTHERMOSTATKODA STARA KODA PREKLOPNA TEMPERATURA PT (°C) POLOČAJ KONTAKTOVPOSITION OF CONTACTSREF. NO. REF. NO.-old CHANGE OVERTEMPERATURE COT (°C) DO PT NAD PTUNDER COT ABOVE COT11726109 11.107 250-350 0-1 0-265
