WORLD OF GATES AND WICKETS<br />

The largest warehouse stock <strong>of</strong> <strong>gates</strong> <strong>and</strong> <strong>wickets</strong> in C<strong>en</strong>tral Europe<br />

WICKET<br />

PILGATE ®<br />

WICKET<br />

IDEAL ® WICKET<br />

WICKET<br />

SOLID ®<br />

ECONOMY ®<br />

WICKET<br />

PILOFOR ®<br />

WICKET<br />

PILOFOR<br />

SUPER ®<br />

GATE<br />

PILOFOR<br />

SUPER ®<br />

GATE<br />

PILOFOR ®<br />

GATE<br />

PILGATE ®<br />

GATE<br />

IDEAL ® II.<br />

GATE<br />

SOLID ®<br />

www.svetbranabranek.cz<br />

QUALITY<br />

BRAND


ECONOMY®<br />

• frame made <strong>of</strong> round<br />

sections (closed)<br />

• welded mesh paneling<br />

• mesh size 50 × 100 mm<br />

• wire diameter 3,50 mm<br />

Single-wing <strong>wickets</strong><br />

height<br />

width*<br />

SOLID®<br />

• frame made <strong>of</strong> round<br />

sections (closed)<br />

• welded mesh paneling<br />

• mesh size 50 × 100 mm<br />

• wire diameter 3,50 mm<br />

IDEAL®<br />

• frame made <strong>of</strong> round<br />

sections (closed)<br />

• square mesh paneling<br />

• mesh size 55 × 55 mm<br />

• wire diameter 2,50 mm<br />

1078* 1073* 1085* 1085*<br />

950 <br />

980 <br />

1000 <br />

1045 <br />

1150 <br />

1180 <br />

1200 <br />

1245 <br />

1380 <br />

1450 <br />

1500 <br />

1545 <br />

1550 <br />

1580 <br />

1745 <br />

1750 <br />

1780 <br />

1950 <br />

1980 <br />

2045 <br />

Double-wing <strong>gates</strong><br />

P<br />

•<br />

•<br />

•<br />

•<br />

<br />

height<br />

2<br />

width*<br />

3605* 3021* 3037* 3605* 4037*<br />

950 <br />

980 <br />

1045 <br />

1150 <br />

1180 <br />

1200 <br />

1245 <br />

1380 <br />

1450 <br />

1545 <br />

1550 <br />

1580 <br />

1745 <br />

1750 <br />

1780 <br />

1950 <br />

1980 <br />

2045 <br />

* width at post middle


MANUFACTURE OF GATES AND WICKETS<br />

IN NON-STANDARD DIMENSIONS<br />

MADE TO ORDER<br />

PILGATE®<br />

• frame made <strong>of</strong> square<br />

sections (closed)<br />

• welded mesh paneling<br />

• mesh size 50 × 50 mm<br />

• wire diameter 3,50 mm<br />

PILOFOR®<br />

• frame made <strong>of</strong> square<br />

sections (closed)<br />

• welded solid paneling<br />

• mesh size 50 × 200 mm<br />

• wire diameter 5,00 mm<br />

PILOFOR SUPER®<br />

• frame made <strong>of</strong> square sections (closed)<br />

• welded solid paneling<br />

• mesh size 50 × 200 mm<br />

• wire diameter horizontal 2 × 6 mm,<br />

vertical 5 mm<br />

1100* 1094* 1094*<br />

<br />

<br />

<br />

<br />

<br />

<br />

<br />

<br />

<br />

<br />

<br />

<br />

<br />

<br />

<br />

<br />

<br />

<br />

<br />

<br />

3024* 4020* 4024* 4118* 4118* 4138*<br />

<br />

<br />

<br />

<br />

<br />

<br />

<br />

<br />

<br />

<br />

<br />

<br />

<br />

<br />

<br />

<br />

<br />

<br />

www.svetbranabranek.cz<br />

3


Wicket – ECONOMY ®<br />

• frame made <strong>of</strong> round sections (closed)<br />

• welded mesh paneling<br />

• mesh size 50 × 100 mm<br />

• wire diameter 3,50 mm<br />

• surface finish: galvanized + PVC RAL 6005 (gre<strong>en</strong>)<br />

• wicket consists <strong>of</strong> 2 posts, including adjustable hinges<br />

• flap lockable with padlock is included (padlock is not part <strong>of</strong> delivery)<br />

RECOMMENDED<br />

R E C O M M E N D E D<br />

wicket width *<br />

× height (mm)<br />

SINGLE-WING WICKET<br />

diameter / height<br />

<strong>of</strong> posts (mm)<br />

galvanized<br />

+ PVC<br />

EAN<br />

1078 × 1000 48 / 1500 8595068410042<br />

1078 × 1200 48 / 1700 8595068410073<br />

1078 × 1500 48 / 2000 8595068414286<br />

• high resistance <strong>of</strong> paneling<br />

• simple installation<br />

• universal design (left, right)<br />

• safety<br />

• unrivaled pricing<br />

* width at post middle<br />

Wicket<br />

with paneling,<br />

which never will be<br />

surpassed!<br />

4


QUALITY<br />

BRAND<br />

Single-wing wicket – ECONOMY ®<br />

A<br />

B<br />

1078 mm (doporuč<strong>en</strong>á minimální šířka)<br />

1078 mm (recomm<strong>en</strong>ded minimum width)<br />

We recomm<strong>en</strong>d using the supporting<br />

struts to secure the position <strong>of</strong> the<br />

wicket posts, in order to <strong>en</strong>sure higher<br />

stability <strong>and</strong> safety.<br />

A. Adjustable hinge<br />

B. Flap<br />

www.svetbranabranek.cz<br />

5


Wickets <strong>and</strong> <strong>gates</strong> – SOLID ®<br />

• frame made <strong>of</strong> round sections (closed)<br />

• welded mesh paneling<br />

• mesh size 50 × 100 mm<br />

• wire diameter 3,50 mm<br />

• surface finish: galvanized + PVC RAL 6005 (gre<strong>en</strong>)<br />

• wicket consists <strong>of</strong> 2 posts, including adjustable hinges<br />

• latch lock, plastic h<strong>and</strong>le <strong>and</strong> metal <strong>en</strong>d stop <strong>of</strong> the wicket<br />

are part <strong>of</strong> the delivery<br />

wicket width *<br />

× height (mm)<br />

SINGLE-WING WICKET<br />

diameter / height<br />

<strong>of</strong> posts (mm)<br />

galvanized<br />

+ PVC<br />

EAN<br />

1073 × 950 48 / 1500 8595068409992<br />

1073 × 1200 48 / 1750 8595068410004<br />

1073 × 1450 48 / 2000 8595068414293<br />

1085 × 1750 60 / 2300 8595068410011<br />

1085 × 1950 60 / 2500 8595068410028<br />

* width at post middle<br />

RECOMMENDED<br />

Now I will not<br />

miss ev<strong>en</strong> one!<br />

R E C O M M E N D E D<br />

Double-wing gate – SOLID ®<br />

with steel lugs for padlock<br />

• frame made <strong>of</strong> round sections (closed)<br />

• welded mesh paneling<br />

• mesh size 50 × 100 mm<br />

• wire diameter 3,50 mm<br />

• surface finish: galvanized + PVC RAL 6005 (gre<strong>en</strong>)<br />

• wicket consists <strong>of</strong> 2 posts, including<br />

adjustable hinges<br />

• gate locking with padlock<br />

(not part <strong>of</strong> delivery) in metal lugs<br />

gate width *<br />

× height (mm)<br />

DOUBLE-WING GATE<br />

diameter / height<br />

<strong>of</strong> posts (mm)<br />

galvanized<br />

+ PVC<br />

EAN<br />

3605 × 950 60 / 1600 8595068406298<br />

3605 × 1200 60 / 1850 8595068406311<br />

3605 × 1450 76 / 2100 8595068406328<br />

3605 × 1750 76 / 2400 8595068406335<br />

3605 × 1950 76 / 2600 8595068406342<br />

* width at post middle<br />

Set <strong>of</strong> accessories<br />

for double swing gate IDEAL ® – UNIVERSAL<br />

package cont<strong>en</strong>ts<br />

EAN<br />

– wicket lock with stainless steel part 8595068413913<br />

– insert 47 - IDEAL, PILGATE (23,5/23,5)<br />

– plastic cover for insert, black<br />

for round pr<strong>of</strong>ile<br />

– aluminium h<strong>and</strong>le for round pr<strong>of</strong>ile,<br />

black<br />

– gate stop IDEAL®<br />

DOUBLE SWING GATE IS MADE FOR UNIVERSAL USE. Locking the double swing gate through eylets can be changed for full-featured<br />

locking system IDEAL® – UNIVERSAL (wicket lock with stainless steel part, insert 47 (23,5/23,5), plastic cover for insert, aluminium h<strong>and</strong>le<br />

for round pr<strong>of</strong>ile, gate stop IDEAL®). Set is sold separately <strong>and</strong> it is not part <strong>of</strong> the double swing gate package.<br />

6


QUALITY<br />

BRAND<br />

Single-wing wicket – SOLID ®<br />

A<br />

B<br />

1073 mm (recomm<strong>en</strong>ded minimum width<br />

1073 mm (doporuč<strong>en</strong>á minimální šířka<br />

We recomm<strong>en</strong>d using the supporting<br />

struts to secure the position <strong>of</strong> the<br />

wicket posts, in order to <strong>en</strong>sure higher<br />

stability <strong>and</strong> safety.<br />

pro výšky 950, 1200, 1450)<br />

for heights 950, 1200, 1450)<br />

1085 mm (recomm<strong>en</strong>ded minimum width<br />

for heights 1750, 1950)<br />

1085 mm (doporuč<strong>en</strong>á minimální šířka<br />

pro výšky 1750, 1950)<br />

A. Adjustable hinge<br />

B. H<strong>and</strong>le, lock <strong>and</strong> <strong>en</strong>d stop assembly<br />

Double-wing gate – SOLID ®<br />

A<br />

Accessories for locking double swing gate with padlock<br />

(padlock is not included).<br />

Optional accessories IDEAL® – UNIVERSAL (h<strong>and</strong>le, lock, insert, stop).<br />

Set is available in sale separately <strong>and</strong> it is not part <strong>of</strong> the gate package.<br />

D<br />

C<br />

B<br />

3605 mm (recomm<strong>en</strong>ded minimum width)<br />

3605 mm (doporuč<strong>en</strong>á minimální šířka)<br />

A. Adjustable hinge<br />

B. C<strong>en</strong>tral door latch with <strong>en</strong>d stop<br />

C. Accessories for locking double swing gate with<br />

padlock (padlock is not included)<br />

D. Optional accessories IDEAL® – UNIVERSAL<br />

(h<strong>and</strong>le, lock, insert, stop).<br />

Set is available in sale separately <strong>and</strong> it is not<br />

part <strong>of</strong> the gate package.<br />

www.svetbranabranek.cz<br />

7


Wickets <strong>and</strong> <strong>gates</strong> – IDEAL ®<br />

Single-wing wicket – IDEAL®<br />

with lock <strong>and</strong> cylinder lock insert<br />

• frame made <strong>of</strong> round sections (closed)<br />

• square mesh paneling<br />

• mesh size 55 × 55 mm<br />

• wire diameter 2,50 mm<br />

• surface finish: galvanized + PVC RAL 6005 (gre<strong>en</strong>)<br />

• wicket consists <strong>of</strong> 2 posts, including adjustable pivot hinges<br />

• wicket is delivered with lock <strong>and</strong> lock insert installed in wing frame<br />

wicket width *<br />

× height (mm)<br />

SINGLE-WING WICKET<br />

diameter / height<br />

<strong>of</strong> posts (mm)<br />

galvanized<br />

+ PVC<br />

EAN<br />

1085 × 950 60 / 1600 8595068402900<br />

1085 × 1200 60 / 1850 8595068402917<br />

1085 × 1450 60 / 2100 8595068402924<br />

1085 × 1550 60 / 2200 8595068402931<br />

1085 × 1750 60 / 2400 8595068402948<br />

1085 × 1950 60 / 2600 8595068402955<br />

* width at post middle<br />

Double-wing gate – IDEAL ® II.<br />

with steel lugs for padlock<br />

• frame made <strong>of</strong> round sections (closed)<br />

• square mesh paneling<br />

• mesh size 55 × 55 mm<br />

• wire diameter 2,50 mm<br />

• surface finish: galvanized + PVC RAL 6005 (gre<strong>en</strong>)<br />

• gate consists <strong>of</strong> 2 posts, including<br />

adjustable pivot hinges<br />

• gate locking with padlock<br />

(not part <strong>of</strong> delivery) in metal lugs<br />

gate width * diameter / height<br />

× height (mm) <strong>of</strong> posts (mm)<br />

EAN<br />

gate width *<br />

× height (mm)<br />

DOUBLE-WING GATE<br />

diameter / height<br />

<strong>of</strong> posts (mm)<br />

EAN<br />

gate width * diameter / height<br />

× height (mm) <strong>of</strong> posts (mm)<br />

3021 × 950 60 / 1600 8595068413937 3605 × 950 60 / 1600 8595068440407 4037 × 950 76 / 1600 8595068414460 <br />

3021 × 1200 60 / 1850 8595068413906 3605 × 1200 60 / 1850 8595068440414 4037 × 1200 76 / 1850 8595068412596 <br />

3037 × 1450 76 / 2100 8595068416600 3605 × 1450 76 / 2100 8595068440421 4037 × 1450 76 / 2100 8595068447291 <br />

3037 × 1550 76 / 2200 8595068413647 3605 × 1550 76 / 2200 8595068440438 4037 × 1550 76 / 2200 8595068447307 <br />

3037 × 1750 76 / 2400 8595068414927 3605 × 1750 76 / 2400 8595068440445 4037 × 1750 76 / 2400 8595068447314 <br />

3037 × 1950 76 / 2600 8595068415016 3605 × 1950 76 / 2600 8595068440452 4037 × 1950 76 / 2600 8595068447468 <br />

* width at post middle<br />

FIVE-STAGE PROTECTION<br />

OF FRAME AND POSTS:<br />

degreasing<br />

phosphating<br />

demineralized water rinse 3×<br />

passivation<br />

(Envirox “SG” process)<br />

polymer paint<br />

layer 80 μm<br />

steel elem<strong>en</strong>t<br />

zinc layer<br />

Set <strong>of</strong> accessories for double swing gate IDEAL ® – UNIVERSAL<br />

package cont<strong>en</strong>ts<br />

wicket lock with stainless steel part; insert 47 - IDEAL,<br />

PILGATE (23,5/23,5); plastic cover for insert, black for round pr<strong>of</strong>ile;<br />

aluminium h<strong>and</strong>le for round pr<strong>of</strong>ile, black; gate stop IDEAL®<br />

MANUFACTURE OF GATES AND WICKETS<br />

IDEAL ®<br />

IN NON-STANDARD DIMENSIONS<br />

MADE TO ORDER<br />

EAN<br />

galvanized<br />

+ PVC<br />

EAN<br />

8595068413913<br />

DOUBLE SWING GATE IS MADE FOR UNIVERSAL USE. Locking the double swing gate through eylets can be changed for full-featured<br />

locking system IDEAL® – UNIVERSAL (wicket lock with stainless steel part, insert 47 (23,5/23,5), plastic cover for insert, aluminium h<strong>and</strong>le<br />

for round pr<strong>of</strong>ile, gate stop IDEAL®). Set is sold separately <strong>and</strong> it is not part <strong>of</strong> the double swing gate package.<br />

8


QUALITY<br />

BRAND<br />

Single-wing wicket – IDEAL ®<br />

A<br />

B<br />

1085 mm (doporuč<strong>en</strong>á minimální šířka)<br />

1085 mm (recomm<strong>en</strong>ded minimum width)<br />

A. Adjustable hinge<br />

B. H<strong>and</strong>le, lock <strong>and</strong> <strong>en</strong>d stop assembly<br />

Double-wing gate – IDEAL ® II.<br />

A<br />

Accessories for locking double swing gate with padlock<br />

(padlock is not included).<br />

Optional accessories IDEAL® – UNIVERSAL (h<strong>and</strong>le, lock, insert, stop).<br />

Set is available in sale separately <strong>and</strong> it is not part <strong>of</strong> the gate package.<br />

D<br />

C<br />

3021, 3037, 3605, 4037 mm (recomm<strong>en</strong>ded minimum width)<br />

B<br />

A. Adjustable hinge<br />

B. C<strong>en</strong>tral door latch with <strong>en</strong>d stop<br />

C. Accessories for locking double swing gate with<br />

padlock (padlock is not included)<br />

D. Optional accessories IDEAL® – UNIVERSAL<br />

(h<strong>and</strong>le, lock, insert, stop). Set is available in sale<br />

separately <strong>and</strong> it is not part <strong>of</strong> the gate package.<br />

www.svetbranabranek.cz<br />

9


Wickets <strong>and</strong> <strong>gates</strong> – PILGATE ®<br />

Single-wing wicket – PILGATE ®<br />

• surface finish: galvanized + PVC (gre<strong>en</strong> RAL 6005)<br />

• frame made <strong>of</strong> square sections (closed)<br />

• welded mesh paneling<br />

• mesh size 50 × 50 mm<br />

• wire diameter 3,50 mm<br />

• wicket consists <strong>of</strong> 2 posts, including<br />

adjustable hinges<br />

• wicket is delivered with lock<br />

wicket width *<br />

× height (mm)<br />

SINGLE-WING WICKET<br />

diameter, section /<br />

height <strong>of</strong> posts (mm)<br />

galvanized<br />

+ PVC<br />

EAN<br />

1100 × 950 60 / 1600 85950684103180318<br />

1100 × 1150 60 / 1800 54122983222172217<br />

1100 × 1450 60 / 2100 8595068405291<br />

05291<br />

1100 × 1750 60 × 60 / 2400 8595068410899<br />

0899<br />

1100 × 1950 60 × 60 / 2600 85950684108820882<br />

* width at post middle<br />

FIVE-STAGE PROTECTION<br />

OF FRAME AND POSTS:<br />

degreasing<br />

phosphating<br />

demineralized water rinse 3×<br />

passivation<br />

(Envirox “SG” process)<br />

polymer paint<br />

layer 80 μm<br />

steel elem<strong>en</strong>t<br />

zinc layer<br />

MANUFACTURE OF GATES AND WICKETS<br />

PILGATE ®<br />

IN NON-STANDARD DIMENSIONS<br />

MADE TO ORDER<br />

GALVANIZED WICKETS AND GATES<br />

MADE TO ORDER<br />

Visualisation<br />

dual-wing <strong>gates</strong><br />

950, 1150, 1450 mm.<br />

Double-wing gate – PILGATE ®<br />

• surface finish: galvanized + PVC (gre<strong>en</strong> RAL 6005)<br />

• frame made <strong>of</strong> square sections (closed)<br />

• welded mesh paneling<br />

• mesh size 50 × 50 mm<br />

• wire diameter 3,50 mm<br />

• gate consists <strong>of</strong> 2 posts, including adjustable hinges<br />

• gate is delivered with lock<br />

gate width *<br />

× height (mm)<br />

diameter, section /<br />

height <strong>of</strong> posts (mm)<br />

galvanized<br />

+ PVC<br />

Visualisation<br />

dual-wing <strong>gates</strong><br />

1750 <strong>and</strong> 1950 mm.<br />

DOUBLE-WING GATE<br />

EAN<br />

gate width *<br />

× height (mm)<br />

diameter, section /<br />

height <strong>of</strong> posts (mm)<br />

galvanized<br />

+ PVC<br />

3024 × 950 76 / 1600 8595068410905 4020 × 950 76 / 1600 8595068410912<br />

3024 × 1150 76 / 1800 8595068407523 4020 × 1150 76 / 1800 8595068407561<br />

3024 × 1450 76 / 2100 8595068404577 4020 × 1450 76 / 2100 8595068410288<br />

3024 × 1750 76 / 2400 8595068409114 4024 × 1750 80 × 80 / 2400 8595068408940<br />

3024 × 1950 76 / 2600 8595068423967 4024 × 1950 80 × 80 / 2600 8595068410301<br />

* width at post middle<br />

EAN<br />

10


QUALITY<br />

BRAND<br />

Single-wing wicket – PILGATE ®<br />

A<br />

round posts (diameter 60 mm)<br />

for heights 950, 1150, 1450 mm<br />

round posts (diameter 60 mm)<br />

for heights 950, 1150, 1450 mm<br />

B<br />

1100 mm (recomm<strong>en</strong>ded minimum width)<br />

square posts (60 × 60 mm)<br />

for heights 1750, 1950 mm<br />

square posts (60 × 60 mm)<br />

for heights 1750, 1950 mm<br />

A. Adjustable pivot hinge<br />

B. H<strong>and</strong>le, lock <strong>and</strong> <strong>en</strong>d stop assembly<br />

Double-wing gate – PILGATE ®<br />

A<br />

round posts (diameter 76 mm)<br />

for heights 950, 1150, 1450 mm<br />

B<br />

round posts (diameter 76 mm)<br />

for heights 950, 1150, 1450 mm<br />

4020 mm (recomm<strong>en</strong>ded minimum width for heights 950, 1150, 1450 mm)<br />

4024 mm (recomm<strong>en</strong>ded minimum width for heights 1750, 1950 mm)<br />

3024 mm (recomm<strong>en</strong>ded minimum width)<br />

C<br />

square posts (80 × 80 mm)<br />

for heights 1750, 1950 mm<br />

square posts (80 × 80 mm)<br />

for heights 1750, 1950 mm<br />

A. Adjustable pivot hinge<br />

B. H<strong>and</strong>le, lock <strong>and</strong> <strong>en</strong>d stop assembly<br />

C. C<strong>en</strong>tral door latch with <strong>en</strong>d stop<br />

www.svetbranabranek.cz<br />

11


Wickets <strong>and</strong> <strong>gates</strong> – PILOFOR ®<br />

Single-wing wicket – PILOFOR ®<br />

• surface finish: galvanized + PVC RAL 6005 (gre<strong>en</strong>), 2× topcoat<br />

• frame made <strong>of</strong> square sections (closed)<br />

• welded solid paneling with stamped “V” shape<br />

• mesh size 50 × 200 mm<br />

• wire diameter 5,00 mm<br />

• wicket consists <strong>of</strong> 2 posts, including adjustable pivot hinges<br />

• FAB lock, aluminum h<strong>and</strong>le <strong>and</strong> plastic <strong>en</strong>d stop<br />

<strong>of</strong> the wicket are part <strong>of</strong> the delivery<br />

• WICKET IS UNIVERSAL (left <strong>and</strong> right)<br />

wicket width *<br />

× height (mm)<br />

SINGLE-WING WICKET<br />

section / height<br />

<strong>of</strong> posts (mm)<br />

galvanized<br />

+ PVC<br />

EAN<br />

1094 × 1045 60 × 60 / 1680 8595068414958<br />

1094 × 1245 60 × 60 / 1880 8595068414965<br />

1094 × 1545 60 × 60 / 2180 8595068414972<br />

1094 × 1745 60 × 60 / 2380 8595068414989<br />

1094 × 2045 60 × 60 / 2680 8595068414996<br />

* width at post middle<br />

FIVE-STAGE PROTECTION<br />

OF FRAME AND POSTS:<br />

degreasing<br />

phosphating<br />

demineralized water rinse 3×<br />

passivation<br />

(Envirox “SG” process)<br />

polymer paint<br />

layer 80 μm<br />

steel elem<strong>en</strong>t<br />

zinc layer<br />

MANUFACTURE OF GATES AND WICKETS<br />

PILOFOR ®<br />

IN NON-STANDARD DIMENSIONS<br />

MADE TO ORDER<br />

GALVANIZED WICKETS AND GATES<br />

MADE TO ORDER<br />

Double-wing gate – PILOFOR ®<br />

• surface finish: galvanized + PVC RAL 6005 (gre<strong>en</strong>), 2× topcoat<br />

• frame made <strong>of</strong> square sections (closed)<br />

• welded solid paneling with stamped “V” shape<br />

• mesh size 50 × 200 mm<br />

• wire diameter 5,00 mm<br />

• gate consists <strong>of</strong> 2 posts, including adjustable<br />

pivot hinges <strong>and</strong> c<strong>en</strong>tral door latch with <strong>en</strong>d stop<br />

• FAB lock, aluminum h<strong>and</strong>le <strong>and</strong> plastic<br />

<strong>en</strong>d stop <strong>of</strong> the gate are part <strong>of</strong> the delivery<br />

• GATE IS UNIVERSAL<br />

gate width *<br />

× height (mm)<br />

DOUBLE-WING GATE<br />

section / height<br />

<strong>of</strong> posts (mm)<br />

galvanized<br />

+ PVC<br />

EAN<br />

4118 × 1045 80 × 80 / 1680 8595068415009<br />

4118 × 1245 80 × 80 / 1880 8595068415030<br />

4118 × 1545 80 × 80 / 2180 8595068415047<br />

4118 × 1745 80 × 80 / 2380 8595068415054<br />

4118 × 2045 80 × 80 / 2680 8595068415061<br />

* width at post middle<br />

12


QUALITY<br />

BRAND<br />

Single-wing wicket – PILOFOR ®<br />

WICKET IS UNIVERSAL (left <strong>and</strong> right)<br />

All accessories are compatible with dualsided panel<br />

installation to the wicket frame. Op<strong>en</strong>ings are universal.<br />

A<br />

B<br />

C<br />

1094 mm (recomm<strong>en</strong>ded minimum width)<br />

1094 mm (doporuč<strong>en</strong>á minimální šířka)<br />

* The accessory for the wicket includes also 4 stainless steel clamps,<br />

including the self-tapping screws (see detail „C“), which serve to reinforce<br />

the lower <strong>and</strong> upper bar <strong>of</strong> the wicket wing. The lower <strong>and</strong> upper bar does<br />

not have prepared op<strong>en</strong>ings.<br />

A. Adjustable A. Stavitelný pivot hinge kloubový závěs<br />

B. H<strong>and</strong>le, B. Sestava lock <strong>and</strong> kliky, <strong>en</strong>d zámku stop assembly a dorazu<br />

C. Recomm<strong>en</strong>ded location <strong>of</strong> the fast<strong>en</strong>ers<br />

Double-wing gate – PILOFOR ®<br />

GATE IS UNIVERSAL<br />

All accessories are compatible with dualsided panel<br />

installation to the gate frame. Op<strong>en</strong>ings are universal.<br />

A<br />

B<br />

D<br />

*<br />

4118 mm (recomm<strong>en</strong>ded minimum width)<br />

4118 mm (doporuč<strong>en</strong>á minimální šířka)<br />

C<br />

* The accessory for the gate includes also 16 stainless steel clamps,<br />

including the self-tapping screws (see detail „D“), which serve<br />

to reinforce the lower <strong>and</strong> upper bar <strong>of</strong> the gate wing. The lower<br />

<strong>and</strong> upper bar does not have prepared op<strong>en</strong>ings.<br />

A. Adjustable pivot hinge<br />

B. H<strong>and</strong>le, lock <strong>and</strong> <strong>en</strong>d stop assembly<br />

C. C<strong>en</strong>tral door latch with <strong>en</strong>d stop<br />

D. Recomm<strong>en</strong>ded location <strong>of</strong> the fast<strong>en</strong>ers<br />

www.svetbranabranek.cz<br />

13


Wickets <strong>and</strong> <strong>gates</strong> – PILOFOR SUPER ®<br />

Single-wing wicket – PILOFOR SUPER ®<br />

• surface finish: galvanized + PVC RAL 6005 (gre<strong>en</strong>), 2× topcoat<br />

• frame made <strong>of</strong> square sections (closed)<br />

• welded solid paneling with flat shape<br />

• mesh size 50 × 200 mm<br />

• diameter <strong>of</strong> wires: horizontal 2 × 6 mm, vertical 5 mm<br />

• wicket consists <strong>of</strong> 2 posts, including adjustable pivot hinges<br />

• FAB lock, aluminum h<strong>and</strong>le <strong>and</strong> plastic <strong>en</strong>d stop<br />

<strong>of</strong> the wicket are part <strong>of</strong> the delivery<br />

• WICKET IS UNIVERSAL (left <strong>and</strong> right)<br />

wicket width *<br />

× height (mm)<br />

SINGLE-WING WICKET<br />

section / height<br />

<strong>of</strong> posts (mm)<br />

galvanized<br />

+ PVC<br />

EAN<br />

1094 × 980 60 × 60 / 1630 8595068406625<br />

1094 × 1180 60 × 60 / 1830 8595068406632<br />

1094 × 1380 60 × 60 / 2030 8595068406649<br />

1094 × 1580 60 × 60 / 2230 8595068406670<br />

1094 × 1780 60 × 60 / 2430 8595068406694<br />

1094 × 1980 60 × 60 / 2630 8595068406700<br />

* width at post middle<br />

MANUFACTURE OF GATES AND WICKETS<br />

PILOFOR SUPER ®<br />

IN NON-STANDARD DIMENSIONS<br />

MADE TO ORDER<br />

FIVE-STAGE PROTECTION<br />

OF FRAME AND POSTS:<br />

degreasing<br />

phosphating<br />

demineralized water rinse 3×<br />

passivation<br />

(Envirox “SG” process)<br />

polymer paint<br />

layer 80 μm<br />

steel elem<strong>en</strong>t<br />

zinc layer<br />

GALVANIZED WICKETS AND GATES<br />

MADE TO ORDER<br />

Double-wing gate – PILOFOR SUPER ®<br />

• surface finish: galvanized + PVC RAL 6005 (gre<strong>en</strong>), 2× topcoat<br />

• frame made <strong>of</strong> square sections (closed)<br />

• welded solid paneling with flat shape<br />

• mesh size 50 × 200 mm<br />

• diameter <strong>of</strong> wires: horizontal 2 × 6 mm, vertical 5 mm<br />

• gate consists <strong>of</strong> 2 posts, including adjustable pivot hinges<br />

<strong>and</strong> c<strong>en</strong>tral door latch with <strong>en</strong>d stop<br />

• FAB lock, aluminum h<strong>and</strong>le <strong>and</strong> plastic <strong>en</strong>d stop <strong>of</strong> the gate<br />

are part <strong>of</strong> the delivery<br />

• GATE IS UNIVERSAL<br />

gate width *<br />

× height (mm)<br />

DOUBLE-WING GATE<br />

section / height<br />

<strong>of</strong> posts (mm)<br />

galvanized<br />

+ PVC<br />

EAN<br />

4118 × 980 80 × 80 / 1630 8595068406717<br />

4118 × 1180 80 × 80 / 1830 8595068406762<br />

4118 × 1380 80 × 80 / 2030 8595068406779<br />

4118 × 1580 80 × 80 / 2230 8595068406786<br />

4138 × 1780 100 × 100 / 2430 8595068406793<br />

4138 × 1980 100 × 100 / 2630 8595068406823<br />

* width at post middle<br />

Visualisation – dual-wing <strong>gates</strong><br />

980, 1180, 1380, 1580 mm.<br />

Visualisation – dual-wing <strong>gates</strong><br />

1780 <strong>and</strong> 1980 mm.<br />

14


QUALITY<br />

BRAND<br />

Single-wing wicket – PILOFOR SUPER ®<br />

A<br />

B<br />

1094 mm (doporuč<strong>en</strong>á minimální šířka)<br />

1094 mm (recomm<strong>en</strong>ded minimum width)<br />

WICKET IS UNIVERSAL (left <strong>and</strong> right)<br />

All accessories are compatible<br />

with dualsided installation.<br />

A. Adjustable pivot hinge<br />

B. H<strong>and</strong>le, lock <strong>and</strong> <strong>en</strong>d stop assembly<br />

Double-wing gate – PILOFOR SUPER ®<br />

A<br />

B<br />

4118, 4138 mm (recomm<strong>en</strong>ded minimum width)<br />

4118, 4138 mm (doporuč<strong>en</strong>á minimální šířka)<br />

GATE IS UNIVERSAL<br />

All accessories are compatible<br />

with dualsided installation.<br />

C<br />

A. Adjustable pivot hinge<br />

B. H<strong>and</strong>le, lock <strong>and</strong> <strong>en</strong>d stop assembly<br />

C. C<strong>en</strong>tral door latch with <strong>en</strong>d stop<br />

www.svetbranabranek.cz<br />

15


Accessory for <strong>wickets</strong> <strong>and</strong> <strong>gates</strong><br />

description<br />

packaging<br />

(pcs)<br />

EAN<br />

set <strong>of</strong> accessories for double swing gate IDEAL® – UNIVERSAL 1 8595068413913<br />

wicket lock with stainless steel part + plastic padding under lock for round<br />

<strong>and</strong> flat pr<strong>of</strong>ile<br />

1 8595068410417<br />

dosic lock with stainless steel part + plastic padding under lock<br />

for round <strong>and</strong> flat pr<strong>of</strong>ile<br />

1 8595068410424<br />

plastic padding under lock<br />

for round pr<strong>of</strong>ile<br />

1 8595068403846<br />

plastic padding under lock<br />

for flat pr<strong>of</strong>ile<br />

1 8595068403914<br />

gard<strong>en</strong> lock (plastic finish)<br />

LAKZ40 P1 (compatible with gate stop SMKL QF, SKRZ)<br />

gre<strong>en</strong> RAL 6005, suitable for gate pr<strong>of</strong>iles 40mm<br />

available in other colors for additional charge (RAL 6009, 9005, 9010, 7016)<br />

product cont<strong>en</strong>t: lock, insert, h<strong>and</strong>le, 3x keys<br />

gard<strong>en</strong> lock (aluminium finish)<br />

LAKQ40 U2 (compatible with gate stop SAKL QF)<br />

silver, suitable for gate pr<strong>of</strong>iles 40 – 60 mm<br />

available in other colors for additional charge (RAL 6005, 6009, 9005,<br />

9010, 7016); product cont<strong>en</strong>t: lock, insert, h<strong>and</strong>le, 3x keys<br />

mechanical code lock (aluminium finish)<br />

LMKQ40 V2 (compatible with gate stop SAKL QF)<br />

silver, suitable for gate pr<strong>of</strong>iles 40 – 60 mm<br />

available in other colors for additional charge (RAL 6005, 6009, 9005,<br />

9010, 7016); product cont<strong>en</strong>t: lock, insert, h<strong>and</strong>le, 3x keys<br />

1 8595068400074<br />

1 8595068418659<br />

1 8595068419922<br />

electric strike EMISSA<br />

black<br />

12V<br />

L/R<br />

NEW<br />

1 8595068450383<br />

16


QUALITY<br />

BRAND<br />

description<br />

insert 47 (23,5/23,5)<br />

for <strong>wickets</strong> <strong>and</strong> <strong>gates</strong><br />

IDEAL®, PILGATE®<br />

packaging<br />

(pcs)<br />

EAN<br />

1 8595068413067<br />

duplicate key (matrix)<br />

for insert 47 – IDEAL®<br />

1 8595068405390<br />

insert 65 (32,5/32,5)<br />

for <strong>wickets</strong> <strong>and</strong> <strong>gates</strong> PILOFOR®<br />

1 8595068404867<br />

duplicate key (matrix)<br />

for insert 65 – PILOFOR®<br />

1 8595068405406<br />

plastic cover for dozic lock, black 1 8595068402870<br />

plastic cover for insert, black for round pr<strong>of</strong>ile 1 8595068402887<br />

plastic cover for insert, black 1 8595068402894<br />

dummy plug for insert hole, black (2 pcs) 1 8595068403549<br />

plate for double swing gate IDEAL®<br />

with eyelet (instead <strong>of</strong> lock)<br />

1 8595068403587<br />

plate for double swing gate IDEAL®<br />

with eyelet (instead <strong>of</strong> stop)<br />

1 8595068403594<br />

www.svetbranabranek.cz<br />

17


Accessory for <strong>wickets</strong> <strong>and</strong> <strong>gates</strong><br />

description<br />

PVC h<strong>and</strong>le<br />

for round section, black<br />

packaging<br />

(pcs)<br />

EAN<br />

1 8595068412855<br />

aluminum h<strong>and</strong>le<br />

for round section, black<br />

1 8595068415115<br />

aluminum h<strong>and</strong>le, black 1 8595068412862<br />

dummy plug<br />

for h<strong>and</strong>le hole – black (2 pcs)<br />

1 8595068403556<br />

aluminum ball – set<br />

1 8595068418673<br />

3006KR<br />

5 adjustable positions, square section 8 x 8 mm<br />

– both balls are active<br />

– both balls are passive<br />

– one ball is active, other passive<br />

– one ball is active + plug<br />

– one ball is passive + plug<br />

dropbolt 1 8595068405468<br />

gate stop IDEAL® 1 8595068414934<br />

gate stop PILGATE® 1 8595068401354<br />

gate stop PILOFOR® 1 8595068413920<br />

surface mounted dropbolt<br />

aluminium finish with steel<br />

VSA/VSF<br />

throw 140 mm<br />

dropbolt l<strong>en</strong>gth 490 mm<br />

economic ground catcher<br />

EGS<br />

steel finish with plastic<br />

suitable for dropbolts with a maximum axle <strong>of</strong> 20 mm<br />

watering hole<br />

1 8595068418680<br />

1 8595068419038<br />

18


QUALITY<br />

BRAND<br />

description<br />

mounting system LOCINOX<br />

QUICK-FIX (2 pcs)<br />

packaging<br />

(pcs)<br />

EAN<br />

2 8595068419830<br />

stainless steel panel fast<strong>en</strong>er<br />

for wicket/gate PILOFOR®<br />

1 8595068412909<br />

stainless steel bolt M6×25<br />

for panel fast<strong>en</strong>er<br />

for wicket/gate PILOFOR®<br />

darcromet hinge<br />

M12×130 (2 pcs)<br />

1 8595068412954<br />

2 8595068412848<br />

adjustable stainless steel hinge<br />

M12×150 (2 pcs)<br />

2 8595068416570<br />

darcromet hinge<br />

M16×140 (2 pcs)<br />

2 8595068412962<br />

gard<strong>en</strong> hinge, stainless steel with aluminum reinforcem<strong>en</strong>t<br />

GBM12-DP40<br />

suitable for square section <strong>of</strong> gate/wicket, 40 mm<br />

helix l<strong>en</strong>gth 130 mm<br />

adjustable hinge<br />

M16×130<br />

2 8595068414309<br />

1 8595068412886<br />

adjustable hinge<br />

M16×160<br />

1 8595068412893<br />

hinge base plate M16 with four holes 1 8595068450109<br />

NEW<br />

adjustable hinge M20<br />

with four holes base plate<br />

1 8595068400746<br />

adjustable hinge M20<br />

with two holes base plate<br />

1 8595068400852<br />

rotating welding nut M16 1 8595068450093<br />

NEW<br />

adjustable hinge M20<br />

with nut for welding<br />

1 8595068400869<br />

www.svetbranabranek.cz<br />

19


Accessory for <strong>wickets</strong> <strong>and</strong> <strong>gates</strong><br />

description<br />

winged wicket/gate <strong>en</strong>d stop (aluminum)<br />

SAKL QF (compatible with LAKQ U2, LMKQ V2, LAKZ P1 locks)<br />

silver, suitable for post square section, 40 – 60 mm<br />

differ<strong>en</strong>t color for surcharge (RAL 6005, 6009, 9005, 9010, 7016)<br />

winged wicket/gate <strong>en</strong>d stop (plastic)<br />

SKRZ (compatible with LAKZ P1 lock)<br />

gre<strong>en</strong> RAL 6005, suitable for post round section, 60 mm<br />

winged wicket/gate <strong>en</strong>d stop (plastic)<br />

SMKL QF (compatible with LAKZ P1 lock), gre<strong>en</strong> RAL 6005<br />

suitable for post square section, 40 mm<br />

differ<strong>en</strong>t color for surcharge (RAL 6009, 9005, 9010, 7016)<br />

packaging<br />

(pcs)<br />

EAN<br />

1 8595068418666<br />

1 8595068414118<br />

1 8595068414095<br />

plastic wicket or gate stop, black for round pr<strong>of</strong>ile 1 8595068410394<br />

plastic wicket or gate stop, black for flat pr<strong>of</strong>ile 1 8595068413425<br />

plastic wicket or gate stop, black for PILOFOR® 1 8595068414453<br />

gate stop (steel)<br />

gre<strong>en</strong><br />

1 8595068410400<br />

U lug for gate wing 1 8595068412879<br />

hinge axis diameter 12 mm 1 8595068405444<br />

hinge axis diameter 16 mm 1 8595068405451<br />

bavolet galvanized,<br />

for wicket/gate wing,<br />

straight, terminal, left<br />

bavolet galvanized,<br />

for wicket/gate wing,<br />

straight, terminal, right<br />

bavolet galvanized + PVC RAL 6005, for wicket/gate wing, straight,<br />

terminal, left, gre<strong>en</strong> color<br />

1 8595068400630<br />

1 8595068400647<br />

1 8595068446676<br />

bavolet galvanized + PVC RAL 6005, for wicket/gate wing, straight,<br />

terminal, right, gre<strong>en</strong> color<br />

1 8595068448205<br />

anti-trespassing saw, galvanized<br />

crown protection for fast<strong>en</strong>ing <strong>of</strong> wicket/gate<br />

saw height – 30,00 mm, saw teeth spacing – 50,00 mm<br />

l<strong>en</strong>gth – 1000 mm, galvanized<br />

anti-trespassing saw, galvanized + PVC<br />

crown protection for fast<strong>en</strong>ing <strong>of</strong> wicket/gate<br />

saw height – 30,00 mm, saw teeth spacing – 50,00 mm<br />

l<strong>en</strong>gth – 1000 mm, galvanized + PVC RAL 6005<br />

1 8595068409107<br />

1 8595068412695<br />

20


QUALITY<br />

BRAND<br />

Notes<br />

www.svetbranabranek.cz<br />

21


Notes<br />

22


QUALITY<br />

BRAND<br />

www.svetbranabranek.cz<br />

23


PRAHA<br />

SENEC<br />

BRATISLAVA<br />

SLOVENSKO<br />

More than just a f<strong>en</strong>ce...<br />

PILECKY s.r.o.<br />

Mokrovraty 177, 262 03 Novy Knin<br />

Czech Republic<br />

phone: +420 318 593 848<br />

fax: +420 318 593 849<br />

e-mail: info@pilecky.cz<br />

www.pilecky.cz<br />

PILECKY SLOVENSKO s.r.o.<br />

Boldocka cesta 7, 903 01 S<strong>en</strong>ec<br />

Slovakia<br />

phone: +421 245 922 626<br />

fax: +421 245 922 727<br />

e-mail: info@pilecky.sk<br />

www.pilecky.sk<br />

16-8

Hooray! Your file is uploaded and ready to be published.

Saved successfully!

Ooh no, something went wrong!
