Malcolm C. Smith<br />
with<br />
Jason Zheng Jiang<br />
Cambridge University Engineering Department<br />
YY Fest<br />
29 March 2010<br />
Kyoto
<strong>Passive</strong> <strong>Network</strong> <strong>Synthesis</strong> <strong>without</strong> <strong>Transformers</strong> M.C. Smith<br />
The three linear, passive two-terminal electrical<br />
elements<br />
resistor capacitor inductor<br />
Why three?<br />
YY Fest 2010 2
<strong>Passive</strong> <strong>Network</strong> <strong>Synthesis</strong> <strong>without</strong> <strong>Transformers</strong> M.C. Smith<br />
forbidden<br />
v<br />
i<br />
i<br />
<strong>Passive</strong><br />
<strong>Network</strong><br />
O. Brune (1931): the drivingpoint<br />
impedance of a linear<br />
passive two-terminal network is<br />
positive-real. Conversely:<br />
Any (rational) positive-real function<br />
can be realised using resistors,<br />
capacitors, inductors and<br />
transformers.<br />
YY Fest 2010 3
<strong>Passive</strong> <strong>Network</strong> <strong>Synthesis</strong> <strong>without</strong> <strong>Transformers</strong> M.C. Smith<br />
Bott-Duffin <strong>Synthesis</strong><br />
R. Bott and R.J. Duffin showed<br />
that transformers were unnecessary<br />
in the synthesis of positive-real<br />
functions. (1949)<br />
YY Fest 2010 4
<strong>Passive</strong> <strong>Network</strong> <strong>Synthesis</strong> <strong>without</strong> <strong>Transformers</strong> M.C. Smith<br />
Foster preamble for a positive-real Z(s)<br />
Removal of poles on jR ∪ {∞}<br />
Z = sL+Z1, (Z1 proper)<br />
Removal of zeros on jR ∪ {∞}<br />
<br />
As Z =<br />
s2 +ω2 −1 + Y1<br />
Subtract minimum real part<br />
Z = R+Z2<br />
Not necessarily a unique process<br />
YY Fest 2010 5<br />
L<br />
L<br />
R<br />
Y1<br />
Z1<br />
C<br />
Z2
<strong>Passive</strong> <strong>Network</strong> <strong>Synthesis</strong> <strong>without</strong> <strong>Transformers</strong> M.C. Smith<br />
Minimum functions<br />
A minimum function Z(s) is a positive-real function with no poles<br />
or zeros on jR ∪ {∞} and with the real part of Z(jω) equal to 0 at one<br />
or more frequencies.<br />
ReZ(jω)<br />
0 ω1<br />
ω2<br />
ω<br />
YY Fest 2010 6
<strong>Passive</strong> <strong>Network</strong> <strong>Synthesis</strong> <strong>without</strong> <strong>Transformers</strong> M.C. Smith<br />
Biquadratic minimum function<br />
Z(s) = As2 + Bs + C<br />
Ds 2 + Es + F<br />
with A,B,...,F > 0 and BE = ( √ AF − √ CD) 2 > 0 is a minimum<br />
function. Bott-Duffin realisation:<br />
Z(s)<br />
3 capacitors, 3 inductors and 2 resistors!!<br />
YY Fest 2010 7
<strong>Passive</strong> <strong>Network</strong> <strong>Synthesis</strong> <strong>without</strong> <strong>Transformers</strong> M.C. Smith<br />
Some of the literature on RLC synthesis<br />
E. L. Ladenheim, A <strong>Synthesis</strong> of Biquadratic<br />
Impedances, Master’s thesis, Polytechnic<br />
Inst. of Brooklyn, 1948.<br />
R. H. Pantell, A new method of driving<br />
point impedance synthesis, Proc. IRE, 861,<br />
1954.<br />
F. M. Reza, Conversion of a Brune Cycle,<br />
Trans. I. R. E., March, PGCT-1, 1954.<br />
F. M. Reza, A bridge equivalent for a Brune<br />
cycle terminated in a resistor, Proc. I. R. E.,<br />
March, 42(8):1321, 1954.<br />
J. E. Storer, Relationship between the<br />
Bott-Duffin and Pantell Impedance<br />
<strong>Synthesis</strong>, Proc. IRE March, Sep., 42:1451,<br />
1954.<br />
F. M. Reza, A supplement to Brune<br />
synthesis, Commun. and Electronics.,<br />
March, 85–90, 1955.<br />
E. A. Guillemin, <strong>Synthesis</strong> of <strong>Passive</strong><br />
<strong>Network</strong>s, John Wiley & Sons, 1957.<br />
S. Seshu, Minimal Realizations of the<br />
Biquadratic Minimum Function, IRE<br />
Transactions on Circuit Theory, Dec.,<br />
345–350, 1959.<br />
R. M. Foster, Academic and Theoretical<br />
Aspects of Circuit Theory, Proc. IRE,<br />
866–871, 1962.<br />
R. M. Foster, Biquadratic Impedances<br />
Realisable by a Generalization of the<br />
Five-Element Minimum-Resistance<br />
Bridges, IEEE Trans. on Circuit Theory,<br />
363–367, 1963.<br />
R. M. Foster, Minimum Biquadratic<br />
Impedances, IEEE Trans. on Circuit<br />
Theory, 527, 1963.<br />
S. Seshu , Author’s Reply, IRE Transactions<br />
on Circuit Theory, Dec., 527, 1963.<br />
R. M. Foster and E. L. Ladenheim, A Class<br />
of Biquadratic Impedances, IEEE Trans. on<br />
Circuit Theory, 262–265, 1963.<br />
E. L. Ladenheim, Three-Reactive<br />
Five-Element Biquadratic Structures, IEEE<br />
Trans. on Circuit Theory, 455–456, 1963.<br />
E. L. Ladenheim, A Special Biquadratic<br />
Structure, IEEE Trans. on Circuit Theory,<br />
88–97, 1964.<br />
P. M. Lin, A theorem on equivalent<br />
one-port networks, IEEE Trans. on Circuit<br />
Theory, 619–621, 1965.<br />
M. Reichert, Die Kanonisch und<br />
Übertragerfrei realisierbaren<br />
Zweipolfunktionen zweiten Grades<br />
(Transformerless and canonic realisation of<br />
biquadratic immittance functions), Arch.<br />
Elek. Übertragung, Apr., 23:201–208,<br />
1969.<br />
C. G. Vasiliu, Three-Reactive Five-Element<br />
Structures, IEEE Trans. Circuit Theory,<br />
Feb., CT-16, 99, 1969.<br />
C. G. Vasiliu, Series-Parallel Six-Element<br />
<strong>Synthesis</strong> of the Biquadratic Impedances,<br />
IEEE Trans. on Circuit Theory, 115–121,<br />
1970.<br />
C. G. Vasiliu, Series-Parallel Six-Element<br />
<strong>Synthesis</strong> of the Biquadratic Impedances,<br />
IEEE Trans. on Circuit Theory, 115–121,<br />
1970.<br />
C. G. Vasiliu, Four-Reactive Six-Element<br />
Biquadratic Structures, IEEE Trans. on<br />
Circuit Theory, Sep., 530–531, 1970.<br />
C. G. Vasiliu, Correction to ‘Series-Parallel<br />
Six-Element <strong>Synthesis</strong> of the Biquadratic<br />
Impedances’, IEEE Trans. on Circuit<br />
Theory, Nov., 207, 1970.<br />
G. Dittmer, Zur Realisierung von<br />
RLC-Brückenzweipolen mit zwei<br />
Reaktanzen und mehr als drei<br />
Widerständen (On the realisation of RLC<br />
two-terminal bridge networks with two<br />
reactive and more than three resistive<br />
elements), Nachrichtentechnische<br />
Zeitschrift, 225-230, 1970.<br />
P. M. Lin, On Biquadratic Impedances with<br />
Two Reactive Elements, IEEE Trans. on<br />
Circuit Theory, 277, 1971.<br />
YY Fest 2010 8
<strong>Passive</strong> <strong>Network</strong> <strong>Synthesis</strong> <strong>without</strong> <strong>Transformers</strong> M.C. Smith<br />
Ladenheim’s master’s thesis (1948)<br />
Ladenheim considered all networks<br />
with at most five elements and at most<br />
two reactive elements, and reduced<br />
the whole set to 108 networks (1948).<br />
Questions not answered:<br />
◮ What is the totality of<br />
biquadratics which may be<br />
realised?<br />
◮ How many different networks<br />
are needed?<br />
YY Fest 2010 9
<strong>Passive</strong> <strong>Network</strong> <strong>Synthesis</strong> <strong>without</strong> <strong>Transformers</strong> M.C. Smith<br />
The Concept of Regular Positive Real Functions<br />
Definition<br />
A positive-real function Z(s) is defined to be regular if the smallest<br />
value of Re(Z(jω)) or Re Z −1 (jω) occurs at ω = 0 or ω = ∞.<br />
Example 1. Z1(s) =<br />
Imaginary Axis<br />
2<br />
1<br />
0<br />
−1<br />
2 s+2<br />
s+1<br />
−2<br />
0 1 2 3 4<br />
Real Axis<br />
Smallest value of Re(Z1(jω)) occurs<br />
at ω = ∞, hence Z1(s) is regular.<br />
YY Fest 2010 10
<strong>Passive</strong> <strong>Network</strong> <strong>Synthesis</strong> <strong>without</strong> <strong>Transformers</strong> M.C. Smith<br />
The Concept of Regular Positive Real Functions<br />
Example 2. Z2(s) =<br />
Imaginary Axis<br />
15<br />
10<br />
5<br />
0<br />
−5<br />
−10<br />
Z2(s)<br />
−15<br />
0 5 10 15 20 25<br />
Real Axis<br />
2 s+5<br />
s+1 , which is non-regular:<br />
Imaginary Axis<br />
1<br />
0.5<br />
0<br />
−0.5<br />
Y2(s) = 1/Z2(s)<br />
−1<br />
0 0.2 0.4 0.6 0.8 1<br />
Real Axis<br />
YY Fest 2010 11
<strong>Passive</strong> <strong>Network</strong> <strong>Synthesis</strong> <strong>without</strong> <strong>Transformers</strong> M.C. Smith<br />
<strong>Network</strong> Quartets<br />
◮ Exchange of capacitors and<br />
inductors<br />
◮ Duality (series ⇆ parallel,<br />
capacitor ⇆ inductor)<br />
Lemma 1.<br />
Na is regular =⇒ Nb,Nc,Nd are<br />
all regular.<br />
A network quartet which has<br />
only one network:<br />
YY Fest 2010 12<br />
IV
<strong>Passive</strong> <strong>Network</strong> <strong>Synthesis</strong> <strong>without</strong> <strong>Transformers</strong> M.C. Smith<br />
Properties of Regular Positive Real Functions<br />
Lemma 2<br />
The following networks are always regular:<br />
Regular<br />
<strong>Network</strong><br />
Regular<br />
<strong>Network</strong><br />
Lemma 3<br />
A network that has all reactive elements of the same kind can only<br />
realise regular immittances.<br />
Lemma 4<br />
The following networks are always regular:<br />
<strong>Passive</strong><br />
<strong>Network</strong><br />
<strong>Passive</strong><br />
<strong>Network</strong><br />
YY Fest 2010 13
<strong>Passive</strong> <strong>Network</strong> <strong>Synthesis</strong> <strong>without</strong> <strong>Transformers</strong> M.C. Smith<br />
Five-Element Series-Parallel <strong>Network</strong>s with Two<br />
Reactive Elements—Elimination Process<br />
Assume structure 11 can be<br />
non-regular:<br />
Contradiction.<br />
YY Fest 2010 14
<strong>Passive</strong> <strong>Network</strong> <strong>Synthesis</strong> <strong>without</strong> <strong>Transformers</strong> M.C. Smith<br />
Five-Element Series-Parallel <strong>Network</strong>s with Two<br />
Reactive Elements<br />
IV<br />
Theorem 1<br />
A biquadratic impedance can be realised by series-parallel<br />
five-element networks with two reactive elements if and only if it is<br />
regular. Moreover, the following two network quartets cover all cases.<br />
dual<br />
s↔s −1 s↔s −1<br />
dual<br />
dual<br />
s↔s −1 s↔s −1<br />
Jason Z. Jiang and Malcolm C. Smith, Regular Positive-Real Functions and <strong>Passive</strong> <strong>Network</strong>s Comprising Two Reactive Elements, 10th<br />
ECC, Pages 219–224, August 2009.<br />
IV<br />
YY Fest 2010 15<br />
dual
<strong>Passive</strong> <strong>Network</strong> <strong>Synthesis</strong> <strong>without</strong> <strong>Transformers</strong> M.C. Smith<br />
Five-Element Bridge <strong>Network</strong>s with Two Reactive<br />
Elements<br />
(1)<br />
(2)<br />
(3)<br />
IV<br />
IV<br />
IV<br />
dual<br />
dual<br />
s↔s −1<br />
Theorem 2<br />
Bridge networks with two<br />
reactive and three resistive<br />
elements can only realise<br />
regular immittances except<br />
for the third network<br />
quartet.<br />
YY Fest 2010 16
<strong>Passive</strong> <strong>Network</strong> <strong>Synthesis</strong> <strong>without</strong> <strong>Transformers</strong> M.C. Smith<br />
A canonical form and the regular region<br />
Extraction of a constant multiplier<br />
and frequency scaling gives a<br />
canonical form for biquadratics:<br />
Zc(s) = s2 + 2U √ Ws + W<br />
s 2 + (2V/ √ W)s + 1/W ,<br />
where U, V, W > 0.<br />
Positive-real ⇔ σc ≥ 0<br />
λ † λ c = 0 † c = 0<br />
Regular ⇔ λc,λ † c ≥ 0 σc σc < 0<br />
V<br />
2<br />
1<br />
λ † λ c > 0 † c > 0<br />
W=0.5<br />
Kc Kc < 0<br />
λc λc > 0<br />
Kc Kc = 0<br />
λc λc = 0<br />
0<br />
0 1<br />
U<br />
σc σc = 0<br />
2<br />
YY Fest 2010 17
<strong>Passive</strong> <strong>Network</strong> <strong>Synthesis</strong> <strong>without</strong> <strong>Transformers</strong> M.C. Smith<br />
The impedances that can be realised by the third bridge<br />
network quartet with W ∈ (1/3,1).<br />
V<br />
γ2 = 0<br />
2<br />
1<br />
λ † c = 0<br />
γ1 = 0<br />
W=0.6<br />
λc = 0<br />
0<br />
0 γ2 = 0<br />
1<br />
U<br />
σc = 0<br />
2<br />
YY Fest 2010 18
<strong>Passive</strong> <strong>Network</strong> <strong>Synthesis</strong> <strong>without</strong> <strong>Transformers</strong> M.C. Smith<br />
Mechanical <strong>Network</strong> <strong>Synthesis</strong><br />
Theorem<br />
It is possible to build a passive mechanism<br />
of small mass whose impedance<br />
(velocity/force) is any rational postive-real<br />
function.<br />
Proof<br />
Bott-Duffin + ideal inerter: F = b(¨x1 − ¨x2),<br />
where physical embodiments must satisfy:<br />
◮ Inertance b (kg) is independent of mass;<br />
◮ Inertance is independent of travel.<br />
ms<br />
<strong>Passive</strong><br />
Mechanism<br />
YY Fest 2010 19<br />
mu
<strong>Passive</strong> <strong>Network</strong> <strong>Synthesis</strong> <strong>without</strong> <strong>Transformers</strong> M.C. Smith<br />
Ballscrew inerter made in Cambridge University<br />
Engineering Department (2003)<br />
Mass ≈ 1 kg, Inertance (adjustable) = 60–180 kg<br />
YY Fest 2010 20
<strong>Passive</strong> <strong>Network</strong> <strong>Synthesis</strong> <strong>without</strong> <strong>Transformers</strong> M.C. Smith<br />
Yutaka’s Birthday Puzzle<br />
YY Fest 2010 22
