<strong>Lederam</strong>
<strong>Lederam</strong><br />
I would have never thought that technology could compete with nature!<br />
I must change my mind looking at the strange ‘total eclipse’<br />
manufactured by Enzo Catellani using a small microchip – a LED.<br />
If I close my eyes the effect is the same and, even emotionally, this light<br />
is able to produce the same feeling as if I were looking at the moon.<br />
It is a collection realized to save energy. It offers LED technology at<br />
mains voltage without the need for a transformer and is also dimmable.<br />
It is a 17W LED module with an output of 1.300 lumen, which<br />
corresponds to approximately 80W of the old linear halogen lamp.<br />
Using several modules, 5.000 lumens can be achieved, which is<br />
equivalent to approximately 250W of the old halogen bulbs. These<br />
LEDs have a life of approximately 30.000 hours and can be replaced.<br />
Therefore, in addition to having a long life and achieving savings in<br />
energy, they also have lower maintenance costs.<br />
It is a highly technological and minimal collection, completed with thin<br />
discs made with copper leaf, a warm, soft colour, which could be said<br />
‘the gold of the third Millennium’.<br />
And just looking at one of these objects composed by two overlapping<br />
and moveable discs that I immediately thought to the moon.<br />
The collection includes three wall lamps, two ceiling lamps and two<br />
floor lamps.<br />
coming soon
4 - <strong>Lederam</strong><br />
NO DRIVER<br />
REQUIRED<br />
(1) HIGH POWER<br />
17W *= 80W<br />
1260 lm* = 1450 lm<br />
*for each module<br />
HIGH POWER (1)<br />
DIMMING (3)<br />
with phase<br />
cutting dimmer<br />
or PWM<br />
LIFE<br />
35.000 h<br />
ADVANTAGES EFFICIENCY<br />
INTERCHANGEABLE<br />
(2) ENERGETIC CLASS A<br />
A<br />
B<br />
C<br />
D<br />
E<br />
F<br />
G<br />
RESISTANCE<br />
ENERGY SAVING (2)<br />
(3) DIMMING<br />
you don’t need extra cables to<br />
dimm the lamp
coming soon<br />
<strong>Lederam</strong> 1 P<br />
wall lamp<br />
6 - <strong>Lederam</strong><br />
Materials<br />
metal base, aluminium disc lined with copper<br />
coloured leaf, nickel plated metal joint<br />
Dimensions<br />
disc Ø 17 or 25 cm, variable ledge<br />
LED<br />
1 module (interchangeable) x 17W,<br />
Warm White (2700 °K): 1260 lm.<br />
Power supply<br />
voltage 230V, no driver required<br />
Dimmable<br />
with phase cutting dimmer or PWM<br />
comparison data<br />
consumption<br />
lumen output<br />
energetic class<br />
life<br />
LED<br />
17W<br />
1260 lm<br />
A<br />
35.000 h<br />
R7s eco<br />
80W<br />
1450 lm<br />
C<br />
2.000 h
coming soon<br />
<strong>Lederam</strong> 2 P<br />
wall lamp<br />
8 - <strong>Lederam</strong><br />
Materials<br />
nickel plated metal base and structure, aluminium discs<br />
lined with copper coloured leaf, nickel plated metal joints<br />
Dimensions<br />
base Ø 9x3 cm, H 35 cm, width 65 cm,<br />
ledge 40 cm, discs Ø 17 cm, sticks length 30 cm<br />
LED<br />
2 modules (interchangeable) x 17W,<br />
Warm White (2700 °K): 2520 lm<br />
Power supply<br />
voltage 230V, no driver required<br />
Dimmable<br />
with phase cutting dimmer or PWM<br />
comparison data<br />
consumption<br />
lumen output<br />
energetic class<br />
life<br />
LED<br />
34W<br />
2520 lm<br />
A<br />
35.000 h<br />
R7s eco<br />
120W<br />
2300 lm<br />
C<br />
2.000 h
coming soon<br />
<strong>Lederam</strong> 3 P<br />
wall lamp<br />
10 - <strong>Lederam</strong><br />
Materials<br />
nickel plated metal base and structure, aluminium discs<br />
lined with copper coloured leaf, nickel plated metal joints<br />
Dimensions<br />
base Ø 8x3 cm, H 55 cm, width 38 cm,<br />
variable ledge max 26 cm, discs Ø 17 cm<br />
LED<br />
3 modules (interchangeable) x 17W,<br />
Warm White (2700 °K): 3780 lm<br />
Power supply<br />
voltage 230V, no driver required<br />
Dimmable<br />
with phase cutting dimmer or PWM<br />
comparison data<br />
consumption<br />
lumen output<br />
energetic class<br />
life<br />
LED<br />
51W<br />
3780 lm<br />
A<br />
35.000 h<br />
R7s eco<br />
160W<br />
3300 lm<br />
C<br />
2.000 h
coming soon<br />
<strong>Lederam</strong> 2 S<br />
ceiling lamp<br />
<strong>Lederam</strong> 3 S<br />
ceiling lamp<br />
12 - <strong>Lederam</strong><br />
Materials<br />
nickel plated metal base and structure,<br />
aluminium discs lined with copper coloured leaf,<br />
nickel plated metal joints<br />
Dimensions<br />
base Ø 9x3 cm, H 35 cm,<br />
width 50 cm, discs Ø 17 cm<br />
LED<br />
2 S: 2 modules (interchangeable) x 17W,<br />
Warm White (2700 °K): 2520 lm<br />
3 S: 3 modules (interchangeable) x 17W,<br />
Warm White (2700 °K): 3780 lm<br />
Power supply<br />
voltage 230V, no driver required<br />
Dimmable<br />
with phase cutting dimmer or PWM<br />
comparison data 2 S<br />
consumption<br />
lumen output<br />
energetic class<br />
life<br />
comparison data 3 S<br />
consumption<br />
lumen output<br />
energetic class<br />
life<br />
LED<br />
34W<br />
2520 lm<br />
A<br />
35.000 h<br />
LED<br />
51W<br />
3780 lm<br />
A<br />
35.000 h<br />
R7s eco<br />
120W<br />
2300 lm<br />
C<br />
2.000 h<br />
R7s eco<br />
160W<br />
3300 lm<br />
C<br />
2.000 h
coming soon<br />
<strong>Lederam</strong> 4 S<br />
ceiling lamp<br />
14 - <strong>Lederam</strong><br />
Materials<br />
nickel plated metal base and structure,<br />
aluminium discs lined with copper coloured leaf,<br />
nickel plated metal joints<br />
Dimensions<br />
base Ø 9x3cm, H 113 cm,<br />
width 38 cm, discs Ø 17cm<br />
LED<br />
4 modules (interchangeable) x 17W,<br />
Warm White (2700 °K): 5040 lm<br />
Power supply<br />
voltage 230V, no driver required<br />
Dimmable<br />
with phase cutting dimmer or PWM<br />
comparison data<br />
consumption<br />
lumen output<br />
energetic class<br />
life<br />
LED<br />
68W<br />
5040 lm<br />
A<br />
35.000 h<br />
R7s eco<br />
230W<br />
5000 lm<br />
C<br />
2.000 h
coming soon<br />
<strong>Lederam</strong> 2 T<br />
standing lamp<br />
16 - <strong>Lederam</strong><br />
Materials<br />
nickel plated metal base and structure,<br />
aluminium discs lined with copper coloured leaf<br />
Dimensions<br />
base Ø 22 cm, width 36 cm,<br />
H 193 cm, discs Ø 17 cm<br />
LED<br />
2 modules (interchangeable) x 17W,<br />
Warm White (2700 °K): 2520 lm<br />
Power supply<br />
voltage 230V, no driver required<br />
Dimmable<br />
with floor dimmer<br />
comparison data<br />
consumption<br />
lumen output<br />
energetic class<br />
life<br />
LED<br />
34W<br />
2520 lm<br />
A<br />
35.000 h<br />
R7s eco<br />
120W<br />
2300 lm<br />
C<br />
2.000 h
coming soon<br />
<strong>Lederam</strong> 3 T<br />
standing lamp<br />
18 - <strong>Lederam</strong><br />
Materials<br />
metal base and structure, aluminium discs<br />
lined with copper coloured leaf,<br />
nickel plated metal joints<br />
Dimensions<br />
base 30x30 cm, H 200 cm,<br />
width 38 cm, discs Ø 17 cm<br />
LED<br />
3 modules (interchangeable) x 17W,<br />
Warm White (2700 °K): 3780 lm<br />
Power supply<br />
voltage 230V. No driver required<br />
Dimmable<br />
with floor dimmer<br />
comparison data<br />
consumption<br />
lumen output<br />
energetic class<br />
life<br />
LED<br />
51W<br />
3780 lm<br />
A<br />
35.000 h<br />
R7s eco<br />
160W<br />
3300 lm<br />
C<br />
2.000 h
page 6 page 8 page 10 page 12 page 12 page 14 page 16 page 18<br />
<strong>Lederam</strong> 1 P<br />
wall lamp with two discs<br />
17W<br />
<strong>Lederam</strong> 2 P<br />
wall lamp with two discs<br />
34W<br />
<strong>Lederam</strong> 3 P<br />
wall lamp with three discs<br />
51W<br />
<strong>Lederam</strong> 2 S<br />
ceiling lamp with two discs<br />
34W<br />
<strong>Lederam</strong> 3 S<br />
ceiling lamp with three discs<br />
51W<br />
<strong>Lederam</strong> 4 S<br />
ceiling lamp with four discs<br />
68W<br />
<strong>Lederam</strong> 2 T<br />
standing lamp with two discs<br />
34W<br />
<strong>Lederam</strong> 3 T<br />
standing lamp with three discs<br />
51W
designer<br />
Enzo Catellani<br />
engineering<br />
Guido Parenzan<br />
photographic credits<br />
Chiara Isner Matera<br />
graphic project<br />
Roberta Mazzoleni<br />
furniture by<br />
Plinio il Giovane<br />
office and distribution<br />
via Antonio Locatelli, 47 / 24020 Villa di Serio (BG) / Italy<br />
Tel. +39 035 656088 / www.catellanismith.com / info@catellanismith.com<br />
show-room<br />
via Palma il Vecchio, 3 / 24122 Bergamo / Italy<br />
Tel. +39 035 210193 / show-room@catellanismith.com
