Betafit

Filter Elements

E 7.205.1/07.02

E 7.205.1/07.02

2

QUALITY AND PERFORMANCE

FROM HYDAC

HYDAC Betafit ® filter elements

safeguard the performance and long life

of important and expensive hydraulic

components through their high quality

standard. They have the same quality

and performance standards as original

HYDAC elements.

These are:

� High β x values

� High β x stability

� High contamination retention capacity

� High collapse/burst pressure

� Low initial differential pressure

� Universal applications

� Good flow fatigue resistance

PRICE /

PERFORMANCE RATIO

When buying a filter, cost is a decisive

factor. Our BETAFIT ® filter elements are

therefore very competitively priced.

However, HYDAC also recommends

calculating the long-term cost savings

achieved by using an especially efficient

filter with a high contamination retention

capacity and the high cleanliness level of

the hydraulic fluid which results. If these

factors are included in the cost/benefit

calculation, HYDAC products show an

excellent price performance ratio.

QUALITY ASSURANCE

Regular measurements of filter element

performance data and continuous quality

control checks guarantee the high

quality standard at HYDAC (ISO 9001).

FAST DELIVERY

HYDAC distributors are at your disposal

all over the world to advise you on the

appropriate selection of elements.

HYDAC supports the agents with an

additional stock of BETAFIT ®

replacement elements. There are

BETAFIT ® production plants in both

Germany and the USA.

SELECTION PROCEDURE

The manufacturers are listed in

alphabetical order. Your HYDAC

distributor will gladly discuss your

current filter usage with you and will

recommend a suitable replacement

element.

The information on BETAFIT ®

replacement elements contained in this

introduction is a service for our

customers and the information is current

at the time of printing. HYDAC does not

guarantee the accuracy, whether specific

or implied, of the information given here

for element replacement. For

problematical applications, please

contact HYDAC.

TECHNICAL

SPECIFICATIONS

� Permissible ∆p across the element:

– 20 bar for Betamicron ® (BN)

(exception: 1.06...: 10 bar)

– 10 bar for ECOmicron ® (ECO/N)

– 210 bar for Betamicron ® (BH)

� Temperature range:

– Betamicron ® = -30 °C to +100 °C

– ECOmicron ® = -10 °C to +100 °C

� Compatibility with fluids:

– Mineral oils

– Non-flam fluids and fluids

containing water

– Rapidly biodegradable fluids

– Special fluids

(Test criteria to ISO 2943)

� Flow fatigue resistance to ISO 3724:

High flow fatigue resistance due to

solid filter material support on both

sides and high inherent strength of

filter materials.

NOTE

The information in this brochure relates

to the operating conditions and

applications described.

For applications or operating conditions

not described, please contact the

relevant technical department.

Subject to technical modifications.

MODEL CODE FOR BETAFIT REPLACEMENT ELEMENTS

Manufacturer

1 = Pall 6 = Fairley Arlon

2 = Mahle 7 = Eppensteiner

3 = Argo 8 = Internormen

4 = Parker 9 = Regeltechnik

5 = Schroeder

Series

PALL SCHROEDER

01 = 6400 01 = A

03 = 8400 02 = J

04 = 8500 03 = K

05 = 8700 04 = C

06 = 8300 05 = B

07 = 9020/9021 06 = D

08 = 8900 07 = M

09 = 3310 08 = H18L

10 = 9400 FAIRLEY ARLON

11 = 9600; 9601 01 = 170

12 = 9100 02 = 270

13 = 9800/9801 03 = 370

14 = 8310/8314/8304 INTERNORMEN

15 = 6500 120 = 01.E120

16 = 8200 320 = 01.E320

17 = 8800 EPPENSTEINER

18 = 9650; 9651 32 = 2.004/2.32

PARKER 225 = 2.225

01 = H 901 = 1.0901

Element length (in inches, rounded up or down, or size)

Element type

R = return line filter

D = pressure filter

S = suction filter

Filtration rating in µm (based on manufacturer's figures)

03

05

10

20

06 = 05 (Pall BN & BH)

12 = 10 (Pall BN)

17 = 20 (Pall BH)

25 = 20 (Pall BN)

Filter medium

ECO/N = ECOmicron ® (all synthetic)

BN3 = Betamicron ® (low pressure)

BN = Betamicron ® (low pressure)

BH = Betamicron ® (high pressure)

BNK = Betamicron ® (low pressure; synthetic support)

W = wire mesh

P = paper

AM = Aquamicron ® (water absorption)

Supplementary details

No details = standard (NBR seal)

/-EPR = ethylene propylene

/-V = FPM seal, element suitable for rapidly biodegradable oils and phosphate esters (HFD-R)

1. 06. 39 D 03 BN /-V

E 7.205.1/07.02

3

AC - BEH

E 7.205.1/07.02

4

Manuf. code

AC

HYDAC

Type code (new)

PF16 0080MA010P

PF26

AIAG

0080MA025P

HF3-03-1-F 1.11.08D03BN/-V

HF3-03-1-N 1.11.08D03BN

HF3-03-3-F 1.11.08D03BH/-V

HF3-03-3-N 1.11.08D03BH

HF3-05-1-F 1.11.08D06BN/-V

HF3-05-1-N 1.11.08D06BN

HF3-05-3-N 1.11.08D06BH

HF3-10-1-F 1.11.08D12BN/-V

HF3-10-1-N 1.11.08D12BN

HF3-10-3-F 1.11.08D10BH/-V

HF3-10-3-N 1.11.08D10BH

HF3-25-1-F 1.11.08D25BN/-V

HF3-25-1-N 1.11.08D25BN

HF3-25-3-N 1.11.08D17BH

HF4-03-1-F 5.03.09D03BN/-V

HF4-03-1K-F 5.03.05D03BH/-V

HF4-03-1K-N 5.03.05D03BH

HF4-03-1-N 5.03.09D03BN

HF4-05-1-F 5.03.09D05BN/-V

HF4-05-1K-F 5.03.05D05BH/-V

HF4-05-1K-N 5.03.05D05BH

HF4-05-1-N 5.03.09D05BN

HF4-10-1-F 5.03.09D10BN/-V

HF4-10-1K-F 5.03.05D10BH/-V

HF4-10-1K-N 5.03.05D10BH

HF4-10-1-N 5.03.09D10BN

HF4-25-1-F 5.03.09D20BN/-V

HF4-25-1K-F 5.03.05D20BH/-V

HF4-25-1K-N 5.03.05D20BH

HF4-25-1-N

Argo

5.03.09D20BN

V3.0510-26 3.510 D 10 BNK

V3.0510-36 3.510 D 10 BNK

V3.0525-06 3.525 D 10 BNK

V3.0607-06 3.607 D 10 BNK

V3.0607-08 3.607 D 20 BNK

V3.0623-06 3.623 D 10 BNK

V3.0623-08 3.833 D 10 BNK

V3.0623-09 3.623 D 10 BHK

V3.0623-26 3.623 D 10 BHK

V3.0723-06 3.723 RK 10 BN

V3.0723-08 3.723 RK 20 BN

V3.0817-06 3.817 D 10 BNK

V3.0817-16 3.817 D 10 BHK

V3.0817-26 3.817 D 10 BNK

V3.0823-06 3.823 D 10 BNK

V3.0823-08 3.823 D 20 BNK

V3.0823-16 3.823 D 10 BHK

V3.0823-18 3.823 D 20 BHK

V3.0823-26 3.823 D 10 BNK

V3.0833-06 3.623 R 20 BNK

V3.0833-08 3.833 D 20 BNK

V3.0933-28 3.933 RK 15 BN

W3.0623-08

Baldwin

3.623 R 20 BNK

BT287 0160MA025P

BT287-10 0160MA010P

BT351 0160MG010P

BT366-10 0080MG010P

BT387 0180MA003P

BT839 0080MA025P

BT958 0080MA010P

PT707-HD10 5.03.09D10P

PT727-HD10 5.01.05R10P

PT737-10

Behringer

5.02.09D10P

BE110P03A 0110D003BN3HC

BE110P03AH 0110D003BH3HC

BE110P03AHE 0110D003BH3HC/EPR

BE110P03AHR 0110D003BH

BE110P03AHV 0110D003BH3HC/V

BE110P03AV 0110D003BN3HC/V

BE110P06A 0110D005BN3HC

Manuf. code

Behringer (continued)

HYDAC






BE110P12A 0110D010BN3HC


BE110P12AHR 0110D010BH



BE110P25A 0110D020BN3HC




BE140P03A 0140D003BN3HC


BE140P06A 0140D005BN3HC


BE140P12A 0140D010BN3HC


BE140P25A 0140D020BN3HC


BE160P03A 0160D003BN3HC





BE160P06A 0160D005BN3HC




BE160P12A 0160D010BN3HC



BE160P12AR 0160D010BN


BE160P25A 0160D020BN3HC




BE240P03A 0240D003BN3HC





BE240P06A 0240D005BN3HC




BE240P12A 0240D010BN3HC


BE240P12AHR 0240D010BH



BE240P25A 0240D020BN3HC




BE280P03A 0280D003BN3HC



BE280P06A 0280D005BN3HC


BE280P12A 0280D010BN3HC


BE280P12AV 0280D010BN3HC-V

BE280P25A 0280D020BN3HC



BE30P03A 0030D003BN3HC





BE30P06A 0030D005BN3HC


BE30P06AHV 0030D005BH3HC/V

Manuf. code


HYDAC



BE30P12A 0030D010BN3HC




BE30P25A 0030D020BN3HC




BE330P03A 0330D003BN3HC



BE330P03AHR 0330D003BH



BE330P06A 0330D005BN3HC





BE330P12A 0330D010BN3HC


BE330P12AHR 0330D010BH


BE330P25A 0330D020BN3HC



BE500P03A 0500D003BN3HC

BE500P06A 0500D005BN3HC


BE500P12A 0500D010BN3HC


BE500P25A 0500D020BN3HC


BE60P03A 0060D003BN3HC


BE60P03AHR 0060D003BH


BE60P03AR 0060D003BN


BE60P06A 0060D005BN3HC




BE60P06AR 0060D005BN

BE60P06AR 0060D010BN

BE60P12A 0060D010BN3HC





BE60P25A 0060D020BN3HC




BE60P25AR 0060D020BN


BE660P03A 0660D003BN3HC



BE660P03AHR 0660D003BH



BE660P06A 0660D005BN3HC




BE660P06AR 0660D005BN


BE660P12A 0660D010BN3HC


BE660P12AHR 0660D010BH


BE660P12AR 0660D010BN


BE660P25A 0660D020BN3HC

Manuf. code


HYDAC




BE8300/16-03A 1.06.16D03BN

BE8300/16-03AV 1.06.16D03BN/-V

BE8300/16-06A 1.06.16D06BN

BE8300/16-12A 1.06.16D12BN

BE8300/16-25A 1.06.16D25BN

BE8300/16-25AV 1.06.16D25BN/-V

BE8300/39-03A 1.06.39D03BN

BE8300/39-03AV 1.06.39D03BN/-V

BE8300/39-06A 1.06.39D06BN

BE8300/39-06AV 1.06.39D06BN/-V

BE8300/39-12A 1.06.39D12BN

BE8300/39-12AV 1.06.39D12BN/-V

BE8300/39-25A 1.06.39D25BN

BE8300/8-03A 1.06.08D03BN

BE8300/8-06A 1.06.08D06BN

BE8300/8-06AV 1.06.08D06BN/-V

BE8300/8-12A 1.06.08D12BN

BE8300/8-25A 1.06.08D25BN

BE8300/8-25AV 1.06.08D25BN/-V

BE8400/16-03A 1.03.16R03BN

BE8400/16-06A 1.03.16R06BN

BE8400/16-12A 1.03.16R12BN

BE8400/16-25A 1.03.16R25BN

BE8400/26-03A 1.03.26R03BN

BE8400/26-06A 1.03.26R06BN

BE8400/26-12A 1.03.26R12BN

BE8400/26-25A 1.03.26R25BN

BE8400/39-03A 1.03.39R03BN

BE8400/39-06A 1.03.39R06BN

BE8400/39-12A 1.03.39R12BN

BE8400/39-25A 1.03.39R25BN

BE8400/8-03A 1.03.08R03BN

BE8400/8-06A 1.03.08R06BN

BE8400/8-12A 1.03.08R12BN

BE8400/8-25A 1.03.08R25BN

BE8500/13-03A 1.04.13R03BN

BE8500/13-06A 1.04.13R06BN

BE8500/13-12A 1.04.13R12BN

BE8500/13-25A 1.04.13R25BN

BE8500/26-03A 1.04.26R03BN

BE8500/26-06A 1.04.26R06BN

BE8500/26-12A 1.04.26R12BN

BE8500/26-25A 1.04.26R25BN

BE8500/8-03A 1.04.08R03BN

BE8500/8-06A 1.04.08R06BN

BE8500/8-12A 1.04.08R12BN

BE8500/8-25A 1.04.08R25BN

BE8800/13-03A 1.17.13D03BN

BE8800/13-06A 1.17.13D06BN

BE8800/13-12A 1.17.13D12BN

BE8800/13-25A 1.17.13D25BN

BE8800/16-03A 1.17.16D03BN

BE8800/16-06A 1.17.16D06BN

BE8800/16-06AV 1.17.16D06BN/-V

BE8800/16-12A 1.17.16D12BN

BE8800/16-25A 1.17.16D25BN

BE8900/13-03A 1.08.13D03BN

BE8900/13-06A 1.08.13D06BN

BE8900/13-12A 1.08.13D12BN

BE8900/13-25A 1.08.13D25BN

BE8900/16-03A 1.08.16D03BN

BE8900/16-06A 1.08.16D06BN

BE8900/16-12A 1.08.16D12BN

BE8900/16-25A 1.08.16D25BN

BE8900/16-25AV 1.08.16D25BN/-V

BE8900/8-03A 1.08.08D03BN

BE8900/8-06A 1.08.08D06BN

BE8900/8-12A 1.08.08D12BN

BE8900/8-25A 1.08.08D25BN

BE9020/4-03A 1.07.04D03BN

BE9020/4-03AV 1.07.04D03BN/-V

BE9020/4-06A 1.07.04D06BN

BE9020/4-06AV 1.07.04D06BN/-V

BE9020/4-12A 1.07.04D12BN

BEHRINGER

E 7.205.1/07.02

5

E 7.205.1/07.02 BEH - BOS

6

Manuf. code


HYDAC


BE9020/4-12AV 1.07.04D12BN/-V

BE9020/4-25A 1.07.04D25BN

BE9020/4-25AV 1.07.04D25BN/V

BE9020/8-03A 1.07.08D03BN

BE9020/8-03AV 1.07.08D03BN/-V

BE9020/8-06A 1.07.08D06BN

BE9020/8-06AV 1.07.08D06BN/-V

BE9020/8-12A 1.07.08D12BN

BE9020/8-12AV 1.07.0812BN/-V

BE9020/8-25A 1.07.08D25BN

BE9020/8-25AV 1.07.08D25BN/-V

BE9021/4-03A 1.07.04D03BH

BE9021/4-03AV 1.07.04D03BH/-V

BE9021/4-06A 1.07.04D06BH

BE9021/4-12A 1.07.04D10BH

BE9021/4-25A 1.07.04D17BH

BE9021/4-25A 1.07.04D17BH/-V

BE9021/8-03A 1.07.08D03BH

BE9021/8-03AV 1.07.08D03BH/-V

BE9021/8-06A 1.07.08D06BH

BE9021/8-06AV 1.07.08D06BH/-V

BE9021/8-12A 1.07.08D10BH

BE9021/8-12AV 1.07.08D10BH/-V

BE9021/8-25A 1.07.08D17BH

BE9400/13-03A 1.10.13D03BN

BE9400/13-06A 1.10.13D06BN

BE9400/13-06AV 1.10.13D06BN/-V

BE9400/13-12A 1.10.13D12BN

BE9400/13-25A 1.10.13D25BN

BE9400/26-03A 1.10.26D03BN

BE9400/26-06A 1.10.26D06BN

BE9400/26-12A 1.10.26D12BN

BE9400/26-25A 1.10.26D25BN

BE9400/39-03A 1.10.39D03BN

BE9400/39-03AV 1.10.39D03BN/-V

BE9400/39-06A 1.10.39D06BN

BE9400/39-06AV 1.10.39D06BN/-V

BE9400/39-12A 1.10.39D12BN

BE9400/39-25A 1.10.39D25BN

BE9600/13-03A 1.11.13D03BN

BE9600/13-03AV 1.11.13D03BN/-V

BE9600/13-06A 1.11.13D06BN

BE9600/13-06AV 1.11.13D06BN/-V

BE9600/13-12A 1.11.13D12BN

BE9600/13-12AV 1.11.13D12BN/-V

BE9600/13-25A 1.11.13D25BN

BE9600/13-25AV 1.11.13D25BN/-V

BE9600/16-03A 1.11.16D03BN

BE9600/16-03AV 1.11.16D03BN/-V

BE9600/16-06A 1.11.16D06BN

BE9600/16-06AV 1.11.16D06BN/-V

BE9600/16-12A 1.11.16D12BN

BE9600/16-25A 1.11.16D25BN

BE9600/16-25AV 1.11.16D25BN/-V

BE9600/4-03A 1.11.04D03BN

BE9600/4-03AV 1.11.04D03BN/-V

BE9600/4-06A 1.11.04D06BN

BE9600/4-06AV 1.11.04D06BN/-V

BE9600/4-12A 1.11.04D12BN

BE9600/4-12AV 1.11.04D12BN/-V

BE9600/4-25A 1.11.04D25BN

BE9600/4-25AV 1.11.04D25BN/-V

BE9600/8-03A 1.11.08D03BN

BE9600/8-03AV 1.11.08D03BN/-V

BE9600/8-06A 1.11.08D06BN

BE9600/8-06AV 1.11.08D06BN/-V

BE9600/8-12A 1.11.08D12BN

BE9600/8-12AV 1.11.08D12BN/-V

BE9600/8-25A 1.11.08D25BN

BE9600/8-25AV 1.11.08D25BN/-V

BE9601/13-03A 1.11.13D03BH

BE9601/13-03AV 1.11.13D03BH/-V

BE9601/13-12A 1.11.13D10BH

BE9601/16-03A 1.11.16D03BH

BE9601/16-03AV 1.11.16D03BH/-V

BE9601/16-12A 1.11.16D10BH

Manuf. code


HYDAC


BE9601/4-03A 1.11.04D03BH

BE9601/4-03AV 1.11.04D03BH/-V

BE9601/4-12A 1.11.04D10BH

BE9601/8-03A 1.11.08D03BH

BE9601/8-03AV 1.11.08D03BH/-V

BE9601/8-12A 1.11.08D10BH

BE9601/8-12AV 1.11.08D10BH/-V

BE9650/16-03A 1.18.16D03BN

BE9650/16-03AV 1.18.16D03BN/-V

BE9650/16-06A 1.18.16D06BN

BE9650/16-12A 1.18.16D12BN

BE9650/16-25A 1.18.16D25BN

BE9650/8-03A 1.18.08D03BN

BE9650/8-06A 1.18.08D06BN

BE9650/8-12A 1.18.08D12BN

BE9650/8-25A 1.18.08D25BN

BE9651/16-03A 1.18.16D03BH

BE9651/16-12A 1.18.16D10BH

BE9651/8-03A 1.18.08D03BH

BE9651/8-03AV 1.18.08D03BH/-V

BE9651/8-12A 1.18.08D10BH

BE9800/4-03A 1.13.04D03BN

BE9800/4-06A 1.13.04D06BN

BE9800/4-06AV 1.13.04D06BN/-V

BE9800/4-12A 1.13.04D12BN

BE9800/4-25A 1.13.04D25BN

BE9800/8-03A 1.13.08D03BN

BE9800/8-03AV 1.13.08D03BN/-V

BE9800/8-06A 1.13.08D06BN

BE9800/8-06AV 1.13.08D06BN/-V

BE9800/8-12A 1.13.08D12BN

BE9800/8-25A 1.13.08D25BN

BE9801/13-03A 1.13.13D03BH

BE9801/13-12A 1.13.13D10BH

BE9801/4-03A 1.13.04D03BH

BE9801/4-03AV 1.13.04D03BH/-V

BE9801/4-12A 1.13.04D10BH

BE9801/8-03A 1.13.08D03BH

BE9801/8-12A 1.13.08D10BH

BE9801/8-12AV 1.13.08D10BH/-V

BE9901/13-03A 1.09.13D03BH

BE9901/13-12A 1.09.13D10BH

BE9901/26-03A 1.09.26D03BH

BE9901/26-12A 1.09.26D10BH

BE9901/39-03A 1.09.39D03BH

BE9901/39-12A 1.09.39D10BH

BEA/5-03A 5.01.05R03BN

BEA/5-03AV 5.01.05R03BN/-V

BEA/5-06A 5.01.05R05BN

BEA/5-12A 5.01.05R10BN

BEA/5-12AV 5.01.05R10BN/-V

BEA/5-25A 5.01.05R20BN

BEJ/9-03A 5.02.09D03BN

BEJ/9-06A 5.02.09D05BN

BEJ/9-12A 5.02.09D10BN

BEJ/9-25A 5.02.09D20BN

BEK/9-03A 5.03.09D03BN

BEK/9-03AH 5.03.05D03BH

BEK/9-03AHE 5.03.05D03BH/-EPR

BEK/9-03AHV 5.03.05D03BH/-V

BEK/9-03AV 5.03.09D03BN/-V

BEK/9-06A 5.03.09D05BN

BEK/9-06AH 5.03.05D05BH

BEK/9-06AHV 5.03.05D05BH/-V

BEK/9-06AV 5.03.09D05BN/-V

BEK/9-12A 5.03.09D10BN

BEK/9-12AH 5.03.05D10BH

BEK/9-12AHE 5.03.05D10BH/-EPR

BEK/9-12AHV 5.03.05D10BH/-V

BEK/9-12AV 5.03.09D10BN/-V

BEK/9-25A 5.03.09D20BN

BEK/9-25AH 5.03.05D20BH

BEK/9-25AHV 5.03.05D20BH/-V

BEK/9-25AV

Bosch

5.03.09D20BN/-V

1 457 431 108 2.080 D 10 BN

Manuf. code

Canflo

HYDAC


RSE30-10N 0080MA010P

RSE30-25N 0080MA025P

RSE35-10N 0080MG010P

RSE50-10F 0160MA010BN

RSE50-10N 0160MA010P

RSE50-25F 0160MA020BN

RSE50-25N 0160MA025P

RSE50-3F 0160MA003BN

RSE50-3N 0160MA003P

RSE50-5N 0160MA005BN

RSE51-10N 0160MG010P

RSE60-10F 0180MA010BN

RSE60-10N 0180MA010P

RSE60-25N 0180MA025P

RSE60-3F 0180MA003BN

RSE60-3N

CO-OP

0180MA003P

P1551 0080MA010P

PK10 5.03.09D10P

PL436

Cross

0160MA025P

1A9021 0080MA010P

1A9023 0080MA025P

1A9251 0160MA010P

1A9253

Deluxe

0160MA025P

WD278 0085MA025P

WD347 0160MA025P

WD397

Donaldson

0160MA010P

P163903 5.03.09D10BN

P163910(SYN) 5.03.09D05BN

P164164 1.11.04D12BN

P164166 1.11.08D12BN

P164168 1.11.13D12BN

P164170 1.11.16D12BN

P164172 1.11.04D25BN

P164174 1.11.08D25BN

P164176 1.11.13D25BN

P164178 1.11.16D25BN

P164215 1.06.08D12BN

P164217 1.06.08D25BN

P164219 1.06.16D12BN

P164221 1.06.16D25BN

P164223 1.10.13D12BN

P164225 1.10.13D25BN

P164227 1.10.26D12BN

P164229 1.10.26D25BN

P164364 1.11.04D12BN/-V

P164365 1.11.08D12BN/-V

P164366 1.11.13D12BN/-V

P164368 1.11.04D25BN/-V

P164369 1.11.08D25BN/-V

P164371 1.11.16D25BN/-V

P164432 1.06.16D25BN/-V

P164561 1.10.39D12BN

P164563 1.10.39D25BN

P164565 1.06.39D12BN

P164566 1.06.39D12BN/-V

P164567 1.06.39D25BN

P164574 1.06.08D06BN

P164576 1.06.16D06BN

P164578 1.06.39D06BN

P164580 1.06.08D06BN/-V

P164583 1.10.13D06BN

P164585 1.10.26D06BN

P164587 1.10.39D06BN

P164591 1.10.39D06BN/-V

P164592 1.11.04D03BN

P164592 1.11.04D06BN

P164594 1.11.08D06BN

P164596 1.11.13D06BN

P164598 1.11.16D06BN

P164601 1.11.08D06BN/-V

P164602 1.11.13D06BN/-V

P164603 1.11.16D06BN/-V

HYDAC

Manuf. code Type code (new)

Donaldson (continued)

P164810(SYN) 5.02.09D03BN

P164812(SYN) 5.02.09D20BN

P165006 1.07.04D12BN

P165015 1.07.08D12BN

P165041 1.07.04D06BN

P165043 1.07.08D06BN

P165136 1.07.04D25BN

P165138 1.07.08D25BN

P165140 1.03.08R06BN

P165142 1.03.16R06BN

P165144 1.03.26R06BN

P165146 1.03.39R06BN

P165149 1.03.08R25BN

P165151 1.03.16R25BN

P165153 1.03.26R25BN

P165155 1.03.39R25BN

P165158 1.04.08R06BN

P165160 1.04.13R06BN

P165162 1.04.26R06BN

P165164 1.04.08R25BN

P165166 1.04.13R25BN

P165168 1.04.26R25BN

P165584 1.18.08D06BN

P165585 1.18.08D12BN

P165586 1.18.08D25BN

P165587 1.18.16D06BN

P165588 1.18.16D12BN

P165589 1.18.16D25BN

P165762 0180MA005BN

P165875 0160MA003P

P165876 0180MA010BN

P165877 0160MA020BN

P165878 0180MA020BN

P165879 0160MA010BN

P167162 0160MA005BN

P167180 1.07.04D03BH

P167181 1.07.04D17BH/-V

P167182 1.07.08D03BH/-V

P167184 1.11.04D03BH/-V

P167185 1.11.08D03BH/-V

P167187 1.11.16D03BH

P167188 1.11.16D17BH/-V

P167411 1.11.13D03BH/-V

P167415 1.13.08D17BH/-V

P167425(CEL) 5.03.09D25P

P167516(CEL) 5.02.09D10P

P167520 5.01.05R03BN

P167522(CEL) 5.01.05R10P

P167829 0090MA003BN

P167830 0090MA003P

P167832 0180MA003BN

P167842 1.11.08D03BN

P167887 1.08.08D12BN

P167888 1.08.13D12BN

P167889 1.08.08D25BN

P167890 1.08.13D25BN

P167891 1.08.16D25BN

P167942 1.08.08D03BN

P167943 1.08.16D12BN

P168107 5.03.09D10P

P169341 5.03.09D03BN

P169392 0095MA003BN

P169393 0095MA010P

P169424 1.18.08D03BH

P169425 1.18.08D03BH/-V

P169426 1.18.08D17BH

P169427 1.18.16D17BH

P169430 0160MA003BN

P169432 1.11.13D03BN

P169433 1.11.16D03BN

P169435 1.18.08D03BN

P169436 1.18.16D03BN

P169444 5.02.09D05BN

P169445 1.13.04D03BN

P169446 1.13.04D06BN

P169447 1.13.04D12BN

CAN - DON

E 7.205.1/07.02

7

E 7.205.1/07.02 DON - EPP

8

Manuf. code

Donaldson (continued)

HYDAC


P169447(CEL) 5.01.05R25P

P169448 1.13.08D03BN

P169449 1.13.08D12BN

P169450 1.13.08D25BN

P169477 5.01.05R20BN

P169478(CEL) 5.02.09D25P

P169797 1.13.04D25BN

P169798 1.13.08D06BN

P169904 1.11.08D03BN/-V

P170586 0060D003BH3HC

P170587 0060D010BH3HC

P170588 0110D003BH3HC

P170589 0110D010BH3HC

P170590 0160D003BH3HC

P170591 0160D010BH3HC

P170592 0240D003BH3HC

P170593 0240D010BH3HC

P170594 0330D003BH3HC

P170595 0330D010BH3HC

P170596 0660D003BH3HC

P170597 0660D010BH3HC

P170598 0030D005BH3HC

P170599 0030D010BN3HC

P170600 0060D005BN3HC

P170601 0060D010BN3HC

P170602 0110D005BN3HC

P170604 0110D010BN3HC

P170605 0160D005BN3HC

P170606 0160D010BN3HC

P170607 0240D005BN3HC

P170608 0240D010BN3HC

P170609 0330D005BN3HC

P170610 0330D010BN3HC

P170611 0660D005BN3HC

P170612

Eppensteiner

0660D010BN3HC

1.0040 H10SL-A00-0-P0 0040 RN 010 BN/HC

1.0040 H20SL-A00-0-P0 0040 RN 025 BN/HC

1.0040 H3SL-A00-0-P0 0040 RN 003 BN/HC

1.0040 H6SL-A00-0-P0 0040 RN 006 BN/HC

1.0063 H10SL-A00-0-P0 0063 RN 010 BN/HC

1.0063 H20SL-A00-0-P0 0063 RN 025 BN/HC

1.0063 H3SL-A00-0-P0 0063 RN 003 BN/HC

1.0063 H6SL-A00-0-P0 0063 RN 006 BN/HC

1.0100 H10SL-A00-0-P0 0100 RN 010 BN/HC

1.0100 H20SL-A00-0-P0 0100 RN 025 BN/HC

1.0100 H3SL-A00-0-P0 0100 RN 003 BN/HC

1.0100 H6SL-A00-0-P0 0100 RN 006 BN/HC

1.0160 H10SL-A00-0-P0 0160 RN 010 BN/HC

1.0160 H20SL-A00-0-P0 0160 RN 025 BN/HC

1.0160 H3SL-A00-0-P0 0160 RN 003 BN/HC

1.0160 H6SL-A00-0-P0 0160 RN 006 BN/HC

1.0250 H10SL-A00-0-P0 0250 RN 010 BN/HC

1.0250 H20SL-A00-0-P0 0250 RN 025 BN/HC

1.0250 H3SL-A00-0-P0 0250 RN 003 BN/HC

1.0250 H6SL-A00-0-P0 0250 RN 006 BN/HC

1.0400 H10SL-A00-0-P0 0400 RN 010 BN/HC

1.0400 H20SL-A00-0-P0 0400 RN 025 BN/HC

1.0400 H3SL-A00-0-P0 0400 RN 003 BN/HC

1.0400 H6SL-A00-0-P0 0400 RN 006 BN/HC

1.0630 H10SL-A00-0-P0 0630 RN 010 BN/HC

1.0630 H20SL-A00-0-P0 0630 RN 025 BN/HC

1.0630 H3SL-A00-0-P0 0630 RN 003 BN/HC

1.0630 H6SL-A00-0-P0 0630 RN 006 BN/HC

1.1000 H10SL-A00-0-P0 1000 RN 010 BN/HC

1.1000 H20SL-A00-0-P0 1000 RN 025 BN/HC

1.1000 H3SL-A00-0-P0 1000 RN 003 BN/HC

1.1000 H6SL-A00-0-P0 1000 RN 006 BN/HC

1.140 H10 P 7.140 D 10 BN

1.140 H20 P 7.140 D 20 BN

1.140 H3 P 7.140 D 03 BN

1.140 H6 P 7.140 D 06 BN

1.1401 H10SL-A00-0-P0 7.1401 R 10 BN

1.1401 H20SL-A00-0-P0 7.1401 R 20 BN

1.1801 H10SL-A00-0-P0 7.1801 R 10 BN

1.1801 H20SL-A00-0-P0 7.1801 R 20 BN

Manuf. code

Eppensteiner (continued)

HYDAC


1.561 H6SL-A00-0-P0 7.561 R 06 BN

1.561 H10SL-A00-0-P0 7.561 R 10 BN

1.561 H20SL-A00-0-P0 7.561 R 20 BN

1.901 H6SL-A00-0-P0 7.901 R 05 BN

1.901 H10SL-A00-0-P0 7.901 R 10 BN

1.901 H20SL-A00-0-P0 7.901 R 20 BN

2.0040 H10SL-A00-0-P0 0040 DN 010 BN/HC

2.0040 H10SL-B00-0-P0 0040 DN 010 BH/HC

2.0040 H20SL-A00-0-P0 0040 DN 025 BN/HC

2.0040 H20SL-B00-0-P0 0040 DN 025 BH/HC

2.0040 H3SL-A00-0-P0 0040 DN 003 BN/HC

2.0040 H3SL-B00-0-P0 0040 DN 003 BH/HC

2.0040 H6SL-A00-0-P0 0040 DN 006 BN/HC

2.0040 H6SL-B00-0-P0 0040 DN 006 BH/HC

2.0063 H10SL-A00-0-P0 0063 DN 010 BN/HC

2.0063 H10SL-B00-0-P0 0063 DN 010 BH/HC

2.0063 H20SL-A00-0-P0 0063 DN 025 BN/HC

2.0063 H20SL-B00-0-P0 0063 DN 025 BH/HC

2.0063 H3SL-A00-0-P0 0063 DN 003 BN/HC

2.0063 H3SL-B00-0-P0 0063 DN 003 BH/HC

2.0063 H6SL-A00-0-P0 0063 DN 006 BN/HC

2.0063 H6SL-B00-0-P0 0063 DN 006 BH/HC

2.0100 H10SL-A00-0-P0 0100 DN 010 BN/HC

2.0100 H10SL-B00-0-P0 0100 DN 010 BH/HC

2.0100 H20SL-A00-0-P0 0100 DN 025 BN/HC

2.0100 H20SL-B00-0-P0 0100 DN 025 BH/HC

2.0100 H3SL-A00-0-P0 0100 DN 003 BN/HC

2.0100 H3SL-B00-0-P0 0100 DN 003 BH/HC

2.0100 H6SL-A00-0-P0 0100 DN 006 BN/HC

2.0100 H6SL-B00-0-P0 0100 DN 006 BH/HC

2.0160 H10SL-A00-0-P0 0160 DN 010 BN/HC

2.0160 H10SL-B00-0-P0 0160 DN 010 BH/HC

2.0160 H20SL-A00-0-P0 0160 DN 025 BN/HC

2.0160 H20SL-B00-0-P0 0160 DN 025 BH/HC

2.0160 H3SL-A00-0-P0 0160 DN 003 BN/HC

2.0160 H3SL-B00-0-P0 0160 DN 003 BH/HC

2.0160 H6SL-A00-0-P0 0160 DN 006 BN/HC

2.0160 H6SL-B00-0-P0 0160 DN 006 BH/HC

2.0250 H10SL-A00-0-P0 0250 DN 010 BN/HC

2.0250 H10SL-B00-0-P0 0250 DN 010 BH/HC

2.0250 H20SL-A00-0-P0 0250 DN 025 BN/HC

2.0250 H20SL-B00-0-P0 0250 DN 025 BH/HC

2.0250 H3SL-A00-0-P0 0250 DN 003 BN/HC

2.0250 H3SL-B00-0-P0 0250 DN 003 BH/HC

2.0250 H6SL-A00-0-P0 0250 DN 006 BN/HC

2.0250 H6SL-B00-0-P0 0250 DN 006 BH/HC

2.0400 H10SL-A00-0-P0 0400 DN 010 BN/HC

2.0400 H10SL-B00-0-P0 0400 DN 010 BH/HC

2.0400 H20SL-A00-0-P0 0400 DN 025 BN/HC

2.0400 H20SL-B00-0-P0 0400 DN 025 BH/HC

2.0400 H3SL-A00-0-P0 0400 DN 003 BN/HC

2.0400 H3SL-B00-0-P0 0400 DN 003 BH/HC

2.0400 H6SL-A00-0-P0 0400 DN 006 BN/HC

2.0400 H6SL-B00-0-P0 0400 DN 006 BH/HC

2.140 H10SL-A00-0-P0 7.140 D 10 BN

2.140 H20SL-A00-0-P0 7.140 D 20 BN

2.140 H3SL-A00-0-P0 7.140 D 03 BN

2.140 H6SL-A00-0-P0 7.140 D 06 BN

2.225 G 40 P 7.225 D 40 W

2.225 H10SL-A00-0-P 7.225 D 10 BN

2.225 H20SL-A00-0-P 7.225 D 20 BN

2.225 H3SL-A00-0-P 7.225 D 03 BN

2.225 H6SL-A00-0-P 7.225 D 06 BN

2.225 H6SL-C00-0-P 7.225 D 06 BH

2.225 H10SL-C00-0-P 7.225 D 10 BH

2.32 H 10 P 7.32 D 10 BN

2.32 H 20 P 7.32 D 20 BN

2.32 H 3 P 7.32 D 03 BN

2.32 H 6 P 7.32 D 06 BN

2.32 H10SL-A00-0-P 7.32 D 10 BN

2.32 H10SL-A00-0-V 7.32 D 10 BN /-V

2.32 H20SL-A00-0-P 7.32 D 20 BN

2.32 H3SL-A00-0-P 7.32 D 03 BN

2.32 H6SL-A00-0-P 7.32 D 06 BN

2.32 G10-A00-0-P 7.32 D 10 V

Manuf. code

Fairey Arlon

HYDAC


170-Z-101A 6.01.03D05BN

170-Z-105A 6.01.03D10BN

170-Z-110A 6.01.03D20BN

170-Z-1FFA 6.01.03D03BN

170-Z-201A 6.01.06D05BN

170-Z-205A 6.01.06D10BN

170-Z-210A 6.01.06D20BN

170-Z-2FFA 6.01.06D03BN

270-Z-101A 6.02.04D05BN

270-Z-105A 6.02.04D10BN

270-Z-110A 6.02.04D20BN

270-Z-1FFA 6.02.04D03BN

270-Z-201A 6.02.08D05BN

270-Z-205A 6.02.08D10BN

270-Z-210A 6.02.08D20BN

270-Z-2FFA 6.02.08D03BN

370-Z-101A 6.03.04D05BN

370-Z-105A 6.03.04D10BN

370-Z-110A 6.03.04D20BN

370-Z-1FFA 6.03.04D03BN

370-Z-201A 6.03.08D05BN

370-Z-205A 6.03.08D10BN

370-Z-210A 6.03.08D20BN

370-Z-2FFA 6.03.08D03BN

370-Z-301A 6.03.12D05BN

370-Z-305A 6.03.12D10BN

370-Z-310A 6.03.12D20BN

370-Z-3FFA 6.03.12D03BN

R740-H-0403A 0095MA025P

R740-H-0406A 0090MA003P

R740-H-0412A 0090MA010A

R740-H-0425A 0090MA010P

R750-H-0403A 4.01.09D20P

R750-H-0406A 0160MA003P

R750-H-0412A 0160MA010A

R750-H-0425A 0160MA010P

R750-H-0803A 0160MA025P

R750-H-0806A 0180MA003P

R750-H-0812A 0180MA010A

R750-H-0825A 0180MA010P

R830-Z-0803A 1.06.08D03BN

R830-Z-0806A 1.06.08D06BN

R830-Z-0812A 1.06.08D12BN

R830-Z-0825A 1.06.08D25BN

R830-Z-1603A 1.06.16D03BN

R830-Z-1606A 1.06.16D06BN

R830-Z-1612A 1.06.16D12BN

R830-Z-1625A 1.06.16D25BN

R830-Z-3903A 1.06.39D03BN

R830-Z-3906A 1.06.39D06BN

R830-Z-3912A 1.06.39D12BN

R830-Z-3925A 1.06.39D25BN

R920-Z-0403A 1.07.04D03BN

R920-Z-0406A 1.07.04D06BN

R920-Z-0412A 1.07.04D12BN

R920-Z-0425A 1.07.04D25BN

R920-Z-0803A 1.07.08D03BN

R920-Z-0806A 1.07.08D06BN

R920-Z-8012A 1.07.08D12BN

R920-Z-8025A 1.07.08D25BN

R921-H-0403A 1.07.04D03BH

R921-H-0415A 1.07.04D17BH

R921-H-0803A 1.07.08D03BH

R921-H-0815A 1.07.08D17BH

R950-Z-0803A 1.18.08D03BN

R950-Z-0806A 1.18.08D06BN

R950-Z-0812A 1.18.08D12BN

R950-Z-0825A 1.18.08D12BN

R950-Z-1603A 1.18.16D03BN

R950-Z-1606A 1.18.16D06BN

R950-Z-1612A 1.18.16D12BN

R950-Z-1625A 1.18.16D25BN

R951-H-0803A 1.18.08D03BH

R951-H-0815A 1.18.08D17BH

R951-H-1603A 1.18.16D03BN

R951-H-1615A 1.18.16D17BH

Manuf. code

Fairey Arlon (continued)

HYDAC


R960-Z-0403 1.11.04D03BN

R960-Z-0406A 1.11.04D06BN

R960-Z-0412A 1.11.04D12BN

R960-Z-0425A 1.11.04D25BN

R960-Z-0803A 1.11.08D03BN

R960-Z-0806A 1.11.08D06BN

R960-Z-0812A 1.11.08D12BN

R960-Z-0825A 1.11.08D25BN

R960-Z-1303A 1.11.13D03BN

R960-Z-1306A 1.11.13D06BN

R960-Z-1312A 1.11.13D12BN

R960-Z-1325A 1.11.13D25BN

R960-Z-1603A 1.11.16D03BN

R960-Z-1606A 1.11.16D06BN

R960-Z-1612A 1.11.16D12BN

R960-Z-1625A 1.11.16D25BN

R961-H-0403A 1.11.04D03BH

R961-H-0415A 1.11.04D17BH

R961-H-0803A 1.11.08D03BH

R961-H-0815A 1.11.08D17BH

R961-H-1303A 1.11.13D03BH

R961-H-1315A 1.11.13D17BH

R961-H-1603A 1.11.16D03BH

R961-H-1615A 1.11.16D17BH

R980-Z-0403A 1.13.04D03BN

R980-Z-0406A 1.13.04D06BN

R980-Z-0412A 1.13.04D12BN

R980-Z-0425A 1.13.04D12BN

R980-Z-0803A 1.13.08D03BN

R980-Z-0806A 1.13.08D06BN

R980-Z-0812A 1.13.08D12BN

R980-Z-0825A 1.13.08D12BN

R981-H-0403A 1.13.04D03BH

R981-H-0415A 1.13.04D17BH

R981-H-0803A 1.13.08D03BH

R981-H-0815A

Fleetguard

1.13.08D17BH

HF6510 0080MA010P

HF6520 0080MA025P

HF6600 0090MA003P

HF6601 0095MA003P

HF6603 0090MA003BN

HF6604 0095MA003BN

HF6606 0090MA005BN

HF6607 0095MA005BN

HF6610 0090MA010P

HF6611 0095MA010P

HF6612 0090MA010BN

HF6613 0095MA010BN

HF6625 0090MA020BN

HF6632 0090MA025P

HF6633 0095MA025P

HF6700 0160MA003P

HF6701 0180MA003P

HF6703 0160MA003BN

HF6704 0180MA003BN

HF6706 0160MA005BN

HF6707 0180MA005BN

HF6710 0160MA010P

HF6711 0180MA010P

HF6712 0160MA010BN

HF6713 0180MA010BN

HF6720 0160MA020BN

HF6721 0180MA020BN

HF7000 1.06.08D03BN

HF7001 1.06.08D06BN

HF7002 1.06.08D12BN

HF7003 1.06.08D25BN

HF7003F 1.06.08D25BN/-V

HF7004 1.06.16D03BN

HF7004F 1.06.16D03BN/-V

HF7005 1.06.16D06BN

HF7006 1.06.16D12BN

HF7007 1.06.16D25BN

HF7007F 1.06.16D25BN/-V

HF7008 1.06.39D03BN

FAI - FLE

E 7.205.1/07.02

9

E 7.205.1/07.02 FLE - HAS

10

Manuf. code

Fleetguard (continued)

HYDAC


HF7008F 1.06.39D03BN/-V

HF7009 1.06.39D06BN

HF7010 1.06.39D12BN

HF7011 1.06.39D25BN

HF7012 1.03.08R03BN

HF7013 1.03.08R06BN

HF7014 1.03.08R12BN

HF7015 1.03.08R25BN

HF7016 1.03.16R03BN

HF7017 1.03.16R06BN

HF7018 1.03.16R12BN

HF7019 1.03.16R25BN

HF7020 1.03.26R03BN

HF7021 1.03.26R06BN

HF7022 1.03.26R12BN

HF7023 1.03.26R25BN

HF7024 1.03.39R03BN

HF7025 1.03.39R06BN

HF7026 1.03.39R12BN

HF7028 1.04.08R03BN

HF7029 1.04.08R06BN

HF7030 1.04.08R12BN

HF7031 1.04.08R25BN

HF7032 1.04.13R03BN

HF7033 1.04.13R06BN

HF7034 1.04.13R12BN

HF7035 1.04.13R25BN

HF7036 1.04.26R03BN

HF7037 1.04.26R06BN

HF7038 1.04.26R12BN

HF7039 1.04.26R25BN

HF7040 1.07.04D03BN

HF7041 1.07.04D06BN

HF7042 1.07.04D12BN

HF7043 1.07.04D25BN

HF7044 1.07.08D03BN

HF7045 1.07.08D06BN

HF7046 1.07.08D12BN

HF7047 1.07.08D25BN

HF7048 1.07.04D03BH

HF7048F 1.07.04D03BH SO107

HF7051 1.07.04D17BH

HF7051F 1.07.04D17BH/-V

HF7052 1.10.13D03BN

HF7053 1.10.13D06BN

HF7054 1.10.13D12BN

HF7055 1.10.13D25BN

HF7056 1.10.26D03BN

HF7057 1.10.26D06BN

HF7058 1.10.26D12BN

HF7059 1.10.26D25BN

HF7060 1.10.39D03BN

HF7060F 1.10.39D03BN/-V

HF7061 1.10.39D06BN

HF7061F 1.10.39D06BN/-V

HF7062 1.10.39D12BN

HF7063 1.10.39D25BN

HF7064 1.11.04D03BN

HF7064F 1.11.04D03BN/-V

HF7065 1.11.04D06BN

HF7065F 1.11.04D06BN/-V

HF7066 1.11.04D12BN

HF7066F 1.11.04D12BN/-V

HF7067 1.11.04D25BN

HF7067F 1.11.04D25BN/-V

HF7068 1.11.08D03BN

HF7068F 1.11.08D03BN/-V

HF7069 1.11.08D06BN

HF7070 1.11.08D12BN

HF7070F 1.11.08D12BN/-V

HF7071 1.11.08D25BN

HF7071F 1.11.08D25BN/-V

HF7072 1.11.13D03BN

HF7072F 1.11.13D03BN/-V

HF7073 1.11.13D06BN

HF7073F 1.11.13D06BN/-V

Manuf. code

Fleetguard (continued)

HYDAC


HF7074 1.11.13D12BN

HF7074F 1.11.13D12BN/-V

HF7075 1.11.13D25BN

HF7075F 1.11.13D25BN/-V

HF7076 1.11.16D03BN

HF7076F 1.11.16D03BN/-V

HF7077 1.11.16D06BN

HF7077F 1.11.16D06BN/-V

HF7078 1.10.26D12BN

HF7078 1.11.16D12BN

HF7079 1.11.16D25BN

HF7079F 1.11.16D25BN/-V

HF7080 1.11.04D03BH

HF7080F 1.11.04D03BH/-V

HF7081 1.11.04D10BH

HF7082 1.11.08D03BH

HF7082F 1.11.08D03BH/-V

HF7083 1.11.08D17BH

HF7083F 1.11.08D17BH-V

HF7084 1.11.13D03BH

HF7084F 1.11.13D03BH/-V

HF7085 1.11.13D17BH

HF7086 1.11.16D03BH

HF7086F 1.11.16D03BH/-V

HF7087 1.11.16D17BH

HF7087F 1.11.16D17BH/-V

HF7088 1.18.08D03BN

HF7089 1.18.08D06BN

HF7090 1.18.08D12BN

HF7091 1.18.08D25BN

HF7092 1.18.16D03BN

HF7092F 1.18.16D03BN/-V

HF7093 1.18.16D06BN

HF7094 1.18.16D12BN

HF7095 1.18.16D25BN

HF7096 1.18.08D03BH

HF7099 1.18.16D17BH

HF7100 1.13.04D03BN

HF7101 1.13.04D06BN

HF7102 1.13.04D12BN

HF7103 1.13.04D25BN

HF7104 1.13.08D03BN

HF7105 1.13.08D06BN

HF7106 1.13.08D12BN

HF7107 1.13.08D25BN

HF7108 1.13.04D03BH

HF7108F 1.13.04D03BH/-V

HF7109 1.13.04D17BH

HF7110 1.13.08D03BH

HF7111 1.13.08D17BH

HF7111F 1.13.08D17BH/-V

HF7125 1.17.13D03BN

HF7126 1.17.13D06BN

HF7127 1.17.13D12BN

HF7128 1.17.13D25BN

HF7129 1.17.16D03BN

HF7130 1.17.16D06BN

HF7130F 1.17.16D06BN/-V

HF7131 1.17.16D12BN

HF7132

Fleetrite

1.17.16D25BN

HFR86057

Fram

0085MA025P

P1653A 0080MA010P

P1654A

Gresen

0080MA025P

K22001 0080MA010P

K22002 0080MA025P

K23018 0160MA010P

K23019 0160MA025P

K23020

Hastings

0160MA003P

P731 0080MA010P

P732 0080MA025P

P738 0160MA010P

Manuf. code

HY-PRO

HYDAC


HP03DHL4-12MB 0030D010BH3HC




HP03DNL4-12MB 0030D010BN3HC






HP06DHL4-25MSB 0060D020BH











HP06DNL4-12MSB 0060D010BN
























HP16RNL5-12MB 0160R010BN3HC








HP20L4-12MB 1.07.04D12BN

HP20L4-25MB 1.07.04D25BN

HP20L4-3MB 1.07.04D03BN

HP20L4-6MB 1.07.04D06BN

HP20L8-12MB 1.07.08D12BN

HP20L8-25MB 1.07.08D25BN

HP20L8-3MB 1.07.08D03BN

HP20L8-6MB 1.07.08D06BN

HP21L4-15MB 1.07.04D10BH

HP21L4-2MB 1.07.04D03BH

HP21L8-15MB 1.07.08D10BH

HP21L8-2MB 1.07.08D03BH












Manuf. code

HY-PRO (continued)

HYDAC











HP33RNL14-12MSB 0660D010BH

HP33RNL14-3MSB 0660D003BH













HP50L16-12MB 1.18.16D12BN

HP50L16-25MB 1.18.16D25BN

HP50L16-3MB 1.18.16D03BN

HP50L16-6MB 1.18.16D06BN

HP50L8-12MB 1.18.08D12BN

HP50L8-25MB 1.18.08D25BN

HP50L8-3MB 1.18.08D03BN

HP50L8-6MB 1.18.08D06BN

HP51L16-15MB 1.18.16D10BH

HP51L16-2MB 1.18.16D03BH

HP51L8-15MB 1.18.08D10BH

HP51L8-2MB 1.18.08D03BH

HP60L13-12MB 1.11.13D12BN

HP60L13-25MB 1.11.13D25BN

HP60L13-3MB 1.11.13D03BN

HP60L13-6MB 1.11.13D06BN

HP60L16-12MB 1.11.16D12BN

HP60L16-25MB 1.11.16D25BN

HP60L16-3MB 1.11.16D03BN

HP60L16-6MB 1.11.16D06BN

HP60L4-12MB 1.11.04D12BN

HP60L4-25MB 1.11.04D25BN

HP60L4-3MB 1.11.04D03BN

HP60L4-6MB 1.11.04D06BN

HP60L8-12MB 1.11.08D12BN

HP60L8-25MB 1.11.08D25BN

HP60L8-3MB 1.11.08D03BN

HP60L8-6MB 1.11.08D06BN

HP61L13-15MB 1.11.13D10BH

HP61L13-2MB 1.11.13D03BH

HP61L16-15MB 1.11.16D10BH

HP61L16-2MB 1.11.16D03BH

HP61L4-15MB 1.11.04D10BH

HP61L4-2MB 1.11.04D03BH

HP61L8-15MB 1.11.08D10BH

HP61L8-2MB 1.11.08D03BH

HP74L4-12MB 0090MA010BN

HP74L4-25MB 0090MA020BN

HP74L4-3MB 0090MA003BN

HP74L4-6MB 0090MA005BN

HP74L8-12MB 0095MA010BN

HP74L8-3MB 0095MA003BN

HP74L8-6MB 0095MA005BN

HP75L4-12MB 0160MA010BN

HP75L4-25MB 0160MA020BN

HP75L4-3MB 0160MA003BN

HP75L4-6MB 0160MA005BN

HP75L8-12MB 0180MA010BN

HP75L8-25MB 0180MA020BN

HP75L8-3MB 0180MA003BN

HP75L8-6MB 0180MA005BN

HP80L4-12MB 1.13.04D12BN

HP80L4-25MB 1.13.04D25BN

HY-PRO

E 7.205.1/07.02

11

E 7.205.1/07.02 HYP - INT

12

Manuf. code


HYDAC


HP80L4-3MB 1.13.04D03BN

HP80L4-6MB 1.13.04D06BN

HP80L8-12MB 1.13.08D12BN

HP80L8-25MB 1.13.08D25BN

HP80L8-3MB 1.13.08D03BN

HP80L8-6MB 1.13.08D06BN

HP81L4-15MB 1.13.04D10BH

HP81L4-2MB 1.13.04D03BH

HP81L8-15MB 1.13.08D10BH

HP81L8-2MB 1.13.08D03BH

HP83L16-12MB 1.06.16D12BN

HP83L16-25MB 1.06.16D25BN

HP83L16-3MB 1.06.16D03BN

HP83L16-6MB 1.06.16D06BN

HP83L39-12MB 1.06.39D12BN

HP83L39-25MB 1.06.39D25BN

HP83L39-3MB 1.06.39D03BN

HP83L39-6MB 1.06.39D06BN

HP83L8-12MB 1.06.08D12BN

HP83L8-25MB 1.06.08D25BN

HP83L8-3MB 1.06.08D03BN

HP83L8-6MB 1.06.08D06BN

HP84L16-12MB 1.03.16R12BN

HP84L16-25MB 1.03.16R25BN

HP84L16-3MB 1.03.16R03BN

HP84L16-6MB 1.03.16R06BN

HP84L39-12MB 1.03.39R12BN

HP84L39-25MB 1.03.39R25BN

HP84L39-3MB 1.03.39R03BN

HP84L39-6MB 1.03.39R06BN

HP84L8-12MB 1.03.08R12BN

HP84L8-25MB 1.03.08R25BN

HP84L8-3MB 1.03.08R03BN

HP84L8-6MB 1.03.08R06BN

HP85L13-12MB 1.04.13R12BN

HP85L13-25MB 1.04.13R25BN

HP85L13-3MB 1.04.13R03BN

HP85L13-6MB 1.04.13R06BN

HP85L26-12MB 1.04.26R12BN

HP85L26-25MB 1.04.26R25BN

HP85L26-3MB 1.04.26R03BN

HP85L26-6MB 1.04.26R06BN

HP85L8-12MB 1.04.08R12BN

HP85L8-25MB 1.04.08R25BN

HP85L8-3MB 1.04.08R03BN

HP85L8-6MB 1.04.08R06BN

HP88L13-12MB 1.17.13D12BN

HP88L13-25MB 1.17.13D25BN

HP88L13-3MB 1.17.13D03BN

HP88L13-6MB 1.17.13D06BN

HP88L16-12MB 1.17.16D12BN

HP88L16-25MB 1.17.16D25BN

HP88L16-3MB 1.17.16D03BN

HP88L16-6MB 1.17.16D06BN

HP89L13-12MB 1.08.13D12BN

HP89L13-25MB 1.08.13D25BN

HP89L13-3MB 1.08.13D03BN

HP89L13-6MB 1.08.13D06BN

HP89L16-12MB 1.08.16D12BN

HP89L16-25MB 1.08.16D25BN

HP89L16-3MB 1.08.16D03BN

HP89L16-6MB 1.08.16D06BN

HP89L8-12MB 1.08.08D12BN

HP89L8-25MB 1.08.08D25BN

HP89L8-3MB 1.08.08D03BN

HP89L8-6MB 1.08.08D06BN

HP91L13-15MB 1.09.13D10BH

HP91L13-2MB 1.09.13D03BH

HP91L26-15MB 1.09.26D10BH

HP91L26-2MB 1.09.26D03BH

HP91L39-15MB 1.09.39D10BH

HP91L39-2MB 1.09.39D03BH

HP94L13-12MB 1.10.13D12BN

HP94L13-25MB 1.10.13D25BN

HP94L13-3MB 1.10.13D03BN

HP94L13-6MB 1.10.13D06BN

Manuf. code


HYDAC


HP94L26-12MB 1.10.26D12BN

HP94L26-25MB 1.10.26D25BN

HP94L26-3MB 1.10.26D03BN

HP94L26-6MB 1.10.26D06BN

HP94L39-12MB 1.10.39D12BN

HP94L39-25MB 1.10.39D25BN

HP94L39-3MB 1.10.39D03BN

HP94L39-6MB 1.10.39D06BN













HPAL5-12MB 5.01.05R10BN

HPAL5-25MB 5.01.05R20BN

HPAL5-3MB 5.01.05R03BN

HPAL5-6MB 5.01.05R05BN

HPJL9-12MB 5.02.09D10BN

HPJL9-25MB 5.02.09D20BN

HPJL9-3MB 5.02.09D03BN

HPJL9-5MB 5.02.09D05BN

HPKL9-12MB 5.03.09D10BN

HPKL9-25MB 5.03.09D20BN

HPKL9-3MB 5.03.09D03BN

HPKL9-6MB

Hydra Mac

5.03.09D05BN

3401-303 0160MA010P

3401-307

Hydreco

0160MA025P

MFE80-10P/2 0080MA010P

EHP-100B15B 1.11.08D06BN

EHP-130B15B 1.11.16D06BN

EHP-50B15B

Internormen

1.11.04D06BN

01.E 120.10VG.16.S.P 8.120 R 10 BN

01.E 120.16VG.16.S.P 8.120 R 16 BN

01.E 120.25VG.16.S.P 8.120 R 20 BN

01.E 120.3VG.16.S.P 8.120 R 03 BN

01.E 120.6VG.16.S.P 8.120 R 06 BN

01.E 320.10VG.16.S.P 8.320 R 10 BN

01.E 320.16VG.16.S.P 8.320 R 16 BN

01.E 320.25VG.16.S.P 8.320 R 20 BN

01.E 320.3VG.16.S.P 8.320 R 03 BN

01.E 320.6VG.16.S.P 8.320 R 06 BN

01NL.100.10VG.30.E.P 0100 DN 010 BN/HC

01NL.100.10VG.HR.E.P 0100 DN 010 BH/HC

01NL.100.25VG.30.E.P 0100 DN 025 BN/HC


01NL.100.3VG.30.E.P 0100 DN 003 BN/HC


01NL.100.6VG.30.E.P 0100 DN 006 BN/HC



01NL.250.3VG.30.E.P 0250 DN 003 BN/HC


01NL.250.6VG.30.E.P 0250 DN 006 BN/HC


01NL.250.10VG.30.E.P 0250 DN 010 BN/HC


01NL.250.25VG.30.E.P 0250 DN 025 BN/HC


01NL.400.3VG.30.E.P 0400 DN 003 BN/HC


01NL.400.6VG.30.E.P 0400 DN 006 BN/HC


01NL.400.10VG.30.E.P 0400 DN 010 BN/HC


01NL.400.25VG.30.E.P 0400 DN 025 BN/HC

01NL.40.10VG.30.E.P 0040 DN 010 BN/HC

Manuf. code

Internormen (continued)

HYDAC



01NL.40.25VG.30.E.P 0040 DN 025 BN/HC


01NL.40.3VG.30.E.P 0040 DN 003 BN/HC


01NL.40.6VG.30.E.P 0040 DN 006 BN/HC


01NL.63.10VG.30.E.P 0063 DN 010 BN/HC


01NL.63.25VG.30.E.P 0063 DN 025 BN/HC


01NL.63.3VG.30.E.P 0063 DN 003 BN/HC


01NL.63.6VG.30.E.P 0063 DN 006 BN/HC


01NR.100.10VG.10.B.P 0100 RN 010 BN/HC

01NR.100.25VG.10.B.P 0100 RN 025 BN/HC

01NR.100.3VG.10.B.P 0100 RN 003 BN/HC

01NR.100.6VG.10.B.P 0100 RN 006 BN/HC

01NR.160.10VG.10.B.P 0160 RN 010 BN/HC

01NR.160.25VG.10.B.P 0160 RN 025 BN/HC

01NR.160.3VG.10.B.P 0160 RN 003 BN/HC

01NR.160.6VG.10.B.P 0160 RN 006 BN/HC

01NR.250.10VG.10.B.P 0250 RN 010 BN/HC

01NR.250.25VG.10.B.P 0250 RN 025 BN/HC

01NR.250.3VG.10.B.P 0250 RN 003 BN/HC

01NR.250.6VG.10.B.P 0250 RN 006 BN/HC

01NR.630.3VG.10.B.P 0630 RN 003 BN/HC

01NR.630.6VG.10.B.P 0630 RN 006 BN/HC

01NR.630.10VG.10.B.P 0630 RN 010 BN/HC

01NR.630.25VG.10.B.P 0630 RN 025 BN/HC

01NR.1000.3VG.10.B.P 1000 RN 003 BN/HC

01NR.1000.6VG.10.B.P 1000 RN 006 BN/HC

01NR.1000.10VG.10.B.P 1000 RN 010 BN/HC

01NR.1000.25VG.10.B.P 1000 RN 025 BN/HC

01NR.63.10VG.10.B.P 0063 RN 010 BN/HC

01NR.63.25VG.10.B.P 0063 RN 025 BN/HC

01NR.63.3VG.10.B.P 0063 RN 003 BN/HC

01NR.63.6VG.10.B.P 0063 RN 006 BN/HC

05.9020.6VG.10.E.P.8

John Deere

1.07.08 D 06 BN

308-0020 0080MA010P

AE-37594

Kralinator

0090MA003P

L-194 0160MA010P

L-37

Lenz

0080MA010P

CP1282-10-50 0160MA025P

CP752-10 0080MA010P

CP752-30

LHA

0080MA025P

SPE15-10 0080MA010P

SPE15-25 0080MA025P

SPE16-10 0080MG010P

SPE16-25 0080MG010P

SPE25-10 0085MA010P

SPE25-25 0085MA025P

SPE50-10 0160MA010P

SPE50-25 0160MA025P

SPE50-3 0160MA003P

SPE52-10 0160MG010P

SPE60-10

Luberfiner

0180MA010P

LPF-1652 0080MA025P

LPF-449 0160MA010P

LPF-51

Mahle

0080MA010P

852 435 SMX 10 2.250 R 10 BN

852 435 SMX 25 2.250 R 25 BN

852 435 SMX 3 2.250 R 03 BN

852 439 SMX 10 2.185 R 10 BN

852 439 SMX 25 2.185 R 25 BN

852 439 SMX 3 2.185 R 03 BN

852 690 SMX 10 2.520 R 10 BN

852 690 SMX 25 2.520 R 25 BN

852 690 SMX 3 2.520 R 03 BN

Manuf. code

Mahle (continued)

HYDAC


852 760 SMX 3 2.400 D 03 BN

852 760 SMX 6 2.400 D 06 BN

852 760 SMX 10 2.400 D 10 BN

852 760 SMX 25 2.400 D 25 BN

PI 1105 Mic 10 2.050 D 25 BN

PI 1108 Mic 10 2.080 D 25 BN

PI 1111 Mic 10 2.110 D 25 BN

PI 1115 Mic 10 2.150 D 25 BN

PI 1130 Mic 10 2.300 D 25 BN

PI 1145 Mic 10 2.450 D 25 BN

PI 13006 RN 0063 RN 010 BN/HC

PI 1710/3 0015 S 125 W

PI 1710/4 0025 S 125 W

PI 1710/52 0050 S 125 W

PI 1710/71 0100 S 125 W

PI 1710/81 0180 S 125 W

PI 21004 DN 0040 DN 003 BN/HC

PI 21004 RN 0040 RN 003 BN/HC

PI 21006 DN 0063 DN 003 BN/HC

PI 21006 RN 0063 RN 003 BN/HC

PI 21010 DN 0100 DN 003 BN/HC

PI 21010 RN 0100 RN 003 BN/HC

PI 21016 DN 0160 DN 003 BN/HC

PI 21016 RN 0160 RN 003 BN/HC

PI 21025 DN 0250 DN 003 BN/HC

PI 21025 RN 0250 RN 003 BN/HC

PI 21040 DN 0400 DN 003 BN/HC

PI 21040 RN 0400 RN 003 BN/HC

PI 2105 SMX 3 2.050 D 03 BN

PI 21063 RN 0630 RN 003 BN/HC

PI 2108 SMX 3 2.080 D 03 BN

PI 21100 RN 1000 RN 003 BN/HC

PI 2111 SMX 3 2.110 D 03 BN

PI 2115 SMX 3 2.150 D 03 BN

PI 2130 SMX 3 2.300 D 03 BN

PI 2145 SMX 3 2.450 D 03 BN

PI 22004 DN 0040 DN 006 BN/HC

PI 22004 RN 0040 RN 006 BN/HC

PI 22006 DN 0063 DN 006 BN/HC

PI 22006 RN 0063 RN 006 BN/HC

PI 22010 DN 0100 DN 006 BN/HC

PI 22010 RN 0100 RN 006 BN/HC

PI 22016 DN 0160 DN 006 BN/HC

PI 22016 RN 0160 RN 006 BN/HC

PI 22025 DN 0250 DN 006 BN/HC

PI 22025 RN 0250 RN 006 BN/HC

PI 22040 DN 0400 DN 006 BN/HC

PI 22040 RN 0400 RN 006 BN/HC

PI 2205 SMX VST 3 2.050 D 03 BH

PI 22063 RN 0630 RN 006 BN/HC

PI 2208 SMX VST 3 2.080 D 03 BH

PI 22100 RN 1000 RN 006 BN/HC

PI 2211 SMX VST 3 2.110 D 03 BH

PI 2215 SMX VST 3 2.150 D 03 BH

PI 2230 SMX VST 3 2.300 D 03 BH

PI 2245 SMX VST 3 2.450 D 03 BH

PI 23004 DN 0040 DN 010 BN/HC

PI 23004 RN 0040 RN 010 BN/HC

PI 23006 DN 0063 DN 010 BN/HC

PI 23006 RN 0063 RN 010 BN/HC

PI 23010 DN 0100 DN 010 BN/HC

PI 23010 RN 0100 RN 010 BN/HC

PI 23016 DN 0160 DN 010 BN/HC

PI 23016 RN 0160 RN 010 BN/HC

PI 23025 DN 0250 DN 010 BN/HC

PI 23025 RN 0250 RN 010 BN/HC

PI 23040 DN 0400 DN 010 BN/HC

PI 23040 RN 0400 RN 010 BN/HC

PI 23063 RN 0630 RN 010 BN/HC

PI 23100 RN 1000 RN 010 BN/HC

PI 25004 DN 0040 DN 025 BN/HC

PI 25004 RN 0040 RN 025 BN/HC

PI 25006 DN 0063 DN 025 BN/HC

PI 25006 RN 0063 RN 025 BN/HC

PI 25010 DN 0100 DN 025 BN/HC

PI 25010 RN 0100 RN 025 BN/HC

INT - MAH

E 7.205.1/07.02

13

E 7.205.1/07.02 MAH- MP

14

Manuf. code

Mahle (continued)

HYDAC


PI 25016 DN 0160 DN 025 BN/HC

PI 25016 RN 0160 RN 025 BN/HC

PI 25025 DN 0250 DN 025 BN/HC

PI 25025 RN 0250 RN 025 BN/HC

PI 25040 DN 0400 DN 025 BN/HC

PI 25040 RN 0400 RN 025 BN/HC

PI 25063 RN 0630 RN 025 BN/HC

PI 25100 RN 1000 RN 025 BN/HC

PI 3105 SMX 10 2.050 D 10 BN

PI 3108 SMX 10 2.080 D 10 BN

PI 3111 SMX 10 2.110 D 10 BN

PI 3115 SMX 10 2.150 D 10 BN

PI 3130 SMX 10 2.300 D 10 BN

PI 3145 SMX 10 2.450 D 10 BN

PI 3205 SMX VST 10 2.050 D 10 BH

PI 3208 SMX VST 10 2.080 D 10 BH

PI 3211 SMX VST 10 2.110 D 10 BH

PI 3215 SMX VST 10 2.150 D 10 BH

PI 3230 SMX VST 10 2.300 D 10 BH

PI 3245 SMX VST 10 2.450 D 10 BH

PI 4105 SMX 25 2.050 D 25 BN

PI 4108 SMX 25 2.080 D 25 BN

PI 4111 SMX 25 2.110 D 20 BN

PI 4115 SMX 25 2.150 D 25 BN

PI 4130 SMX 25 2.300 D 25 BN

PI 4145 SMX 25 2.450 D 25 BN

PI 4205 SMX VST 25 2.050 D 25 BH

PI 4208 SMX VST 25 2.080 D 25 BH

PI 4211 SMX VST 25 2.110 D 20 BH

PI 4215 SMX VST 25 2.150 D 25 BH

PI 4230 SMX VST 25 2.300 D 25 BH

PI 4245 SMX VST 25 2.450 D 25 BH

PI 5105 SMX 6 2.050 D 06 BN

PI 5108 SMX 6 2.080 D 06 BN

PI 5111 SMX 6 2.110 D 05 BN

PI 5115 SMX 6 2.150 D 06 BN

PI 5130 SMX 6 2.300 D 06 BN

PI 5145 SMX 6 2.450 D 06 BN

PI 5205 SMX VST 6 2.050 D 06 BH

PI 5208 SMX VST 6 2.080 D 06 BH

PI 5211 SMX VST 6 2.110 D 05 BH

PI 5215 SMX VST 6 2.150 D 06 BH

PI 5230 SMX VST 6 2.300 D 06 BH

PI 5245 SMX VST 6 2.450 D 06 BH

PI 71004 DN 0040 DN 003 BH/HC

PI 71006 DN 0063 DN 003 BH/HC

PI 71010 DN 0100 DN 003 BH/HC

PI 71016 DN 0160 DN 003 BH/HC

PI 71025 DN 0250 DN 003 BH/HC

PI 71040 DN 0400 DN 003 BH/HC

PI 72004 DN 0040 DN 006 BH/HC

PI 72006 DN 0063 DN 006 BH/HC

PI 72010 DN 0100 DN 006 BH/HC

PI 72016 DN 0160 DN 006 BH/HC

PI 72025 DN 0250 DN 006 BH/HC

PI 72040 DN 0400 DN 006 BH/HC

PI 73004 DN 0040 DN 010 BH/HC

PI 73006 DN 0063 DN 010 BH/HC

PI 73010 DN 0100 DN 010 BH/HC

PI 73016 DN 0160 DN 010 BH/HC

PI 73025 DN 0250 DN 010 BH/HC

PI 73040 DN 0400 DN 010 BH/HC

PI 75004 DN 0040 DN 025 BH/HC

PI 75006 DN 0063 DN 025 BH/HC

PI 75010 DN 0100 DN 025 BH/HC

PI 75016 DN 0160 DN 025 BH/HC

PI 75025 DN 0250 DN 025 BH/HC

PI 75040 DN 0400 DN 025 BH/HC

PI 8330 DRG 40 2.300 D 50 W

PI 8415 DRG 60 2.150 D 50 W

PI 8430 DRG 60 2.300 D 50 W

PI 8445 DRG 60 2.450 D 50 W

PI 8530 DRG 100 2.300 D 100 W

PI 8545 DRG 100 2.450 D 100 W

PI 9230 DRG 25 2.300 D 25 W

PI 9245 DRG 25 2.450 D 25 W

Manuf. code

Mich. F.P.

HYDAC


S28 0080MA010P

S29 0080MA025P

S58 0160MA010P

S59

Moog

0160MA025P

071-60174 0160MA020BN

071-60175 0160MA003BN

071-60176 1.07.08D10BH

071-60177 1.11.04D10BH

071-60260 1.11.08D10BH

071-60299 1.07.04D10BH

071-60300 1.07.04D03BH

071-60311 1.07.04D12BN

071-60312 1.07.08D12BN

071-60313 1.07.04D03BN

071-60314 1.07.08D03BN

071-60645 1.07.08D03BH

071-60707 1.11.08D03BH

071-60711 1.11.04D03BN

071-60712 1.11.04D12BN

071-60714 1.11.08D03BN

071-67056 1.11.04D03BH

071-68896 1.11.08D12BN

A31254 1.13.08D03BH

A31255 1.13.08D10BH

A31375 1.13.08D03BN

A37011 1.13.08D12BN

B64564-2 1.07.08D17BH

B64565-1 1.07.04D17BH

B64566-1 1.13.04D03BH

B64567-1 1.13.04D17BH

B64567-2 1.13.08D17BH

B64572-1

Mopar

1.13.04D03BN

L316 0080MA025P

L318 0080MA010P

L59

Motorcraft

0160MA025P

FH10 0080MA010P

FH11 0080MA025P

FH61 0160MA010P

FL275

MP

0160MA025P

CSG100A03 0160MA003BN

CSG100A06 0160MA005BN

CSG100A10 0160MA010BN

CSG100A25 0160MA020BN

CSG100P10A 0160MA010P

CSG100P25A 0160MA025P

CSG100P5A 0160MA003P

CSG150A03 0180MA003BN

CSG150A06 0180MA005BN

CSG150A10 0180MA010BN

CSG150A25 0180MA020BN

CSG150P10A 0180MA010P

CSG150P25A 0180MA025P

CSG150P5A 0180MA003P

CSG50A10 0080MA010BN

CSG50A25A 0080MA020BN

CSG50A3A 0080MA003BN

CSG50P10A 0080MA010P

CSG50P25A 0080MA025P

MP10300 6.02.04D03BN

MP10301 6.02.04D05BN

MP10302 6.02.04D10BN

MP10303 6.02.04D20BN

MP10304 6.02.08D03BN

MP10305 6.02.08D05BN

MP10306 6.02.08D10BN

MP10307 6.02.08D20BN

MP10500 6.03.04D03BN

MP10501 6.03.04D05BN

MP10502 6.03.04D10BN

MP10503 6.03.04D20BN

MP10504 6.03.08D03BN

MP10505 6.03.08D05BN

Manuf. code

MP (continued)

HYDAC


MP10506 6.03.08D10BN

MP10507 6.03.08D20BN

MP10508 6.03.12D03BN

MP10509 6.03.12D05BN

MP10510 6.03.12D10BN

MP10511 6.03.12D20BN

MP3201 1.06.08D03BN

MP3202 1.06.08D06BN

MP3203 1.06.08D12BN

MP3204 1.06.08D25BN

MP3205 1.06.16D03BN

MP3206 1.06.16D06BN

MP3207 1.06.16D12BN

MP3208 1.06.16D25BN

MP3209 1.06.39D03BN

MP3301 1.03.08R03BN

MP3302 1.03.08R06BN

MP3303 1.03.08R12BN

MP3304 1.03.08R25BN

MP3305 1.03.16R03BN

MP3306 1.03.16R06BN

MP3307 1.03.16R12BN

MP3308 1.03.16R25BN

MP3309 1.03.26R03BN

MP3310 1.03.26R06BN

MP3311 1.03.26R12BN

MP3312 1.03.26R25BN

MP3313 1.03.39R03BN

MP3314 1.03.39R06BN

MP3315 1.03.39R12BN

MP3316 1.03.39R25BN

MP3505 1.17.13D03BN

MP3506 1.17.13D06BN

MP3507 1.17.13D12BN

MP3508 1.17.13D25BN

MP3509 1.17.16D03BN

MP3510 1.17.16D06BN

MP3511 1.17.16D12BN

MP3512 1.17.16D25BN

MP3601 1.08.08D03BN

MP3602 1.08.08D06BN

MP3603 1.08.08D12BN

MP3604 1.08.08D25BN

MP3605 1.08.13D03BN

MP3606 1.08.13D06BN

MP3607 1.08.13D12BN

MP3608 1.08.13D25BN

MP3609 1.08.16D03BN

MP3610 1.08.16D06BN

MP3611 1.08.16D12BN

MP3612 1.08.16D25BN

MP3701 1.07.04D03BN

MP3702 1.07.04D06BN

MP3703 1.07.04D12BN

MP3704 1.07.04D25BN

MP3705 1.07.08D03BN

MP3706 1.07.08D06BN

MP3707 1.07.08D12BN

MP3708 1.07.08D25BN

MP3801 1.07.04D03BH

MP3802 1.07.04D10BH

MP3803 1.07.08D03BH

MP3804 1.07.08D10BH

MP3901 1.10.13D03BN

MP3902 1.10.13D06BN

MP3903 1.10.13D12BN

MP3904 1.10.13D25BN

MP3905 1.10.26D03BN

MP3906 1.10.26D06BN

MP3907 1.10.26D12BN

MP3908 1.10.26D25BN

MP3909 1.10.39D03BN

MP3910 1.10.39D06BN

MP3911 1.10.39D12BN

MP3912 1.10.39D25BN

MP4001 1.11.04D03BH

Manuf. code

MP (continued)

HYDAC


MP4002 1.11.04D10BH

MP4003 1.11.08D03BH

MP4004 1.11.08D10BH

MP4005 1.11.13D03BH

MP4006 1.11.13D10BH

MP4007 1.11.16D03BH

MP4008 1.11.16D10BH

MP4101 1.11.04D03BN

MP4102 1.11.04D06BN

MP4103 1.11.04D12BN

MP4104 1.11.04D25BN

MP4105 1.11.08D03BN

MP4106 1.11.08D06BN

MP4107 1.11.08D12BN

MP4108 1.11.08D25BN

MP4109 1.11.13D03BN

MP4110 1.11.13D06BN

MP4111 1.11.13D12BN

MP4112 1.11.13D25BN

MP4113 1.11.16D03BN

MP4114 1.11.16D06BN

MP4115 1.11.16D12BN

MP4116 1.11.16D25BN

MP4301 1.04.08R03BN

MP4302 1.04.08R06BN

MP4303 1.04.08R12BN

MP4304 1.04.08R25BN

MP4305 1.04.13R03BN

MP4306 1.04.13R06BN

MP4307 1.04.13R12BN

MP4308 1.04.13R25BN

MP4309 1.04.26R03BN

MP4310 1.04.26R06BN

MP4311 1.04.26R12BN

MP4312 1.04.26R25BN

MP5001 1.18.08D03BN

MP5002 1.18.08D06BN

MP5003 1.18.08D12BN

MP5004 1.18.08D25BN

MP5005 1.18.16D03BN

MP5006 1.18.16D06BN

MP50A07 1.18.16D12BN

MP5008 1.18.16D25BN

MP5009 1.18.08D03BH

MP5010 1.18.08D10BH

MP5101 1.13.04D03BN

MP5102 1.13.04D06BN

MP5103 1.13.04D12BN

MP5104 1.13.04D25BN

MP5105 1.13.08D03BN

MP5106 1.13.08D06BN

MP5107 1.13.08D12BN

MP5108 1.13.08D25BN

MP5113 1.13.04D03BH

MP5114 1.13.04D06BH

MP5115 1.13.08D03BH

MP5116 1.13.08D10BH

MP5201 1.09.13D03BH

MP5202 1.09.13D10BH

MP5203 1.09.26D03BH

MP5204 1.09.26D10BH

MP5205 1.09.39D03BH

MP8001 5.01.05R03BN

MP8002 5.01.05R10BN

MP8003 5.01.05R20BN

MP8201 5.02.09D03BN

MP8202 5.02.09D10BN

MP8203 5.02.09D20BN

MP8301 5.03.09D03BN

MP8302 5.03.09D10BN

MP8303

NAPA

5.03.09D20BN

1553 0080MA025P

1758 0160MA025P

1759 0160MA010P

MP - NAP

E 7.205.1/07.02

15

E 7.205.1/07.02 NEL - PAL

16

Manuf. code

Nelson

HYDAC


87181N 1.11.13D12BN

87640N 1.11.08D12BN

87758N 1.11.08D03BN

87759N 1.11.08D06BN

87760N 1.11.08D25BN

87761N 1.11.04D03BN

87762N 1.11.04D06BN

87763N 1.11.04D12BN

87764N 1.11.04D25BN

87765N 1.11.13D03BN

87766N 1.11.13D03BN/-V

87767N 1.11.13D12BN/-V

87768N 1.11.13D25BN

87769N 1.11.16D03BN

87770N 1.11.16D06BN

87771N 1.11.16D25BN

87773N 1.10.13D03BN

87774N 1.10.13D06BN

87776N 1.10.13D25BN

87778N 1.10.26D06BN

87798N 1.11.13D06BN

87811N 1.06.08D06BN

87812N 1.06.16D03BN/-V

87813N 1.06.16D06BN

87814N 1.06.16D25BN/-V

87815N 1.06.39D06BN

87816N 1.06.39D12BN

87818N 1.03.08R25BN

87819N 1.03.16R06BN

87820N 1.03.16R12BN

87821N 1.03.26R06BN

87822N 1.03.39R12BN

87823N 1.04.13R06BN

87824N 1.04.13R25BN

87825N 1.04.26R06BN

87826N 1.04.26R25BN

87827N 1.07.04D03BN

87828N 1.07.04D06BN

87829N 1.07.04D12BN

87830N 1.07.04D25BN

87831N 1.07.08D03BN

87832N 1.07.08D06BN

87833N 1.07.08D12BN

87834N 1.07.08D25BN

87835N 1.07.04D03BH

87836N 1.07.04D03BH/-V

87837N 1.07.08D03BH

87838N 1.07.04D17BH

87839N 1.07.04D17BH/-V

87840N 1.07.08D17BH

87842N 1.11.08D17BH

87843N 1.11.13D17BH

87844N 1.18.08D03BN

87846N 1.18.08D12BN

87847N 1.18.08D03BH

87848N 1.13.04D03BN

87849N 1.13.04D06BN

87850N 1.13.04D25BN

87851N 1.13.08D03BN

87852N 1.13.08D06BN

87853N 1.13.08D12BN

87854N

Pall

1.13.08D25BN

HC008FKP11H Element 01208910 003 BNK /-Arburg

HC008FKS11H Element 01208910 010 BNK /-Arburg

HC008FKT11H Element 01208910 020 BNK /-Arburg

HC0162FDN10H 0250 DN 006 BN/HC

HC0162FDN16H 0400 DN 006 BN/HC

HC0162FDN6H 0160 DN 006 BN/HC

HC0162FDP10H 0250 DN 003 BN/HC

HC0162FDP16H 0400 DN 003 BN/HC

HC0162FDP6H 0160 DN 003 BN/HC

HC0162FDS10H 0250 DN 010 BN/HC

HC0162FDS16H 0400 DN 010 BN/HC

HC0162FDS6H 0160 DN 010 BN/HC

HC0171FDN10H 0160 RN 006 BN/HC

HYDAC


Pall (continued)

HC0171FDN16H 0630 RN 006 BN/HC

HC0171FDP10H 0160 RN 003 BN/HC

HC0171FDP16H 0630 RN 003 BN/HC

HC0171FDS10H 0160 RN 010 BN/HC

HC0171FDS16H 0630 RN 010 BN/HC

HC0250FDP10H 0100 DN 003 BN/HC

HC0250FDP6H 0063 DN 003 BN/HC

HC0250FDS10H 0100 DN 010 BN/HC

HC0250FDS6H 0063 DN 010 BN/HC

HC0251FDN10H 0100 RN 006 BN/HC

HC0251FDN6H 0063 RN 006 BN/HC

HC0251FDP10H 0100 RN 003 BN/HC

HC0251FDP6H 0063 RN 003 BN/HC

HC0251FDS10H 0100 RN 010 BN/HC

HC0251FDS6H 0063 RN 010 BN/HC

HC0252FKN10H 0250 RN 006 BN/HC

HC0252FKN6H 0160 RN 006 BN/HC

HC0252FKP10H 0250 RN 003 BN/HC

HC0252FKP6H 0160 RN 003 BN/HC

HC0252FKS10H 0250 RN 010 BN/HC

HC0252FKS6H 0160 RN 010 BN/HC

HC0364FUS26H 1.08.26 D 12 BN

HC0600FKN16H 1000 RN 006 BN/HC

HC0600FKP16H 1000 RN 003 BN/HC

HC0600FKS16H 1000 RN 010 BN/HC

HC0683FKP4H 1.15.04 D 03 BN /-01208156

HC2206FKP3H 0060D003BN3HC

HC2206FKP3Z 0060D003BN3HC/-V





HC2206FKS3H 0060D010BN3HC

HC2206FKS3Z 0060D010BN3HC/-V













HC2216FKT6H 0240 D 020 BN3HC

HC2218FKN4H 0160 R 005 BN3HC

HC2218FKP4H 0160 R 003 BN3HC

HC2218FKS4H 0160 R 010 BN3HC

HC2218FKT4H 0160 R 020 BN3HC

HC2237FDP6H 0330 D 003 BH3HC

HC2285FKN12H 0660 R 005 BN3HC

HC2285FKP12H 0660 R 003 BN3HC

HC2285FKS12H 0660 R 010 BN3HC

HC2285FKT12H 0660 R 020 BN3HC

HC3300FPR09M 1.19.09 L 40 PP

HC3310FPB40H 1.09.40 R 120 PP /-KB

HC3310FPG13H 1.09.13 R 70 PBT /-KB

HC3310FPG40H 1.09.40 R 70 PBT /-KB

HC3310FPN13H 1.09.13 R 06 PBT /-KB

HC3310FPN40H 1.09.40 R 06 PBT /-KB

HC3310FPP13H 1.09.13 R 03 PBT /-KB

HC3310FPP40H 1.09.40 R 03 PBT /-KB

HC3310FPR13H 1.09.13 R 40 PBT /-KB

HC3310FPR40H 1.09.40 R 40 PBT /-KB

HC3310FPS13H 1.09.13 R 10 PBT /-KB

HC3310FPS40H 1.09.40 R 10 PBT /-KB

HC3310FPT13H 1.09.13 R 20 PBT /-KB

HC3310FPT40H 1.09.40 R 20 PBT /-KB

HC3310FPY13H 1.09.13 R 90 PBT /-KB

HC3310FPY40H 1.09.40 R 90 PBT /-KB

HC3310FPZ13H 1.09.13 R 01 PBT /-KB

HC3310FPZ40H 1.09.40 R 01 PBT /-KB

HC6400FKN13H 1.01.13R06BN

HC6400FKN16H 1.01.16R06BN

Manuf. code


HYDAC


HC6400FKN26H 1.01.26R06BN

HC6400FKN8H 1.01.08R06BN

HC6400FKP13H 1.01.13R03BN

HC6400FKP16H 1.01.16R03BN

HC6400FKP26H 1.01.26R03BN

HC6400FKP8H 1.01.08R03BN

HC6400FKS13H 1.01.13R12BN

HC6400FKS16H 1.01.16R12BN

HC6400FKS26H 1.01.26R12BN

HC6400FKS8H 1.01.08R12BN

HC6400FKT13H 1.01.13R25BN

HC6400FKT16H 1.01.16R25BN

HC6400FKT26H 1.01.26R25BN

HC6400FKT8H 1.01.08R25BN

HC6500FKN16H 1.15.16R06BN

HC6500FKN26H 1.15.26R05BN

HC6500FKP16H 1.15.16R03BN

HC6500FKP26H 1.15.26R03BN

HC6500FKS16H 1.15.16R12BN

HC6500FKS26H 1.15.26R12BN

HC6500FKS26Z 1.15.26R12BN/-V

HC6500FKT16H 1.15.16R25BN

HC6500FKT26H 1.15.26R25BN

HC7400SKN4H 0090MA005BN


HC7400SKP4H 0090MA003BN


HC7400SKS4H 0090MA010BN


HC7400SKT4H 0090MA020BN

HC7400SUJ4H 0090MA010P

HC7400SUJ8H 0095MA010P

HC7400SUK4H 0090MA003P

HC7400SUK8H 0095MA003P









HC7500SUJ4H 0160MA003P

HC7500SUJ4H 0160MG010P

HC7500SUJ8H 0180MA010P

HC7500SUK8H 0180MA003P

HC8200FKN13H 1.16.13D06BN

HC8200FKN16H 1.16.16D.06BN

HC8200FKN8H 1.16.08D06BN

HC8200FKP13H 1.16.13D03BN

HC8200FKP16H 1.16.16D03BN

HC8200FKP8H 1.16.08D03BN

HC8200FKS13H 1.16.13D12BN

HC8200FKS16H 1.16.16D12BN

HC8200FKS8H 1.16.08D12BN

HC8200FKT13H 1.16.13D25BN

HC8200FKT16H 1.16.16D25BN

HC8200FKT8H 1.16.08D25BN

HC8300FKN16H 1.06.16D06BN

HC8300FKN39H 1.06.39D06BN

HC8300FKN39Z 1.06.39D06BN/-V

HC8300FKN8H 1.06.08D06BN

HC8300FKN8Z 1.06.08D06BN/-V

HC8300FKP16H 1.06.16D03BN

HC8300FKP16Z 1.06.16D03BN/-V

HC8300FKP39H 1.06.39D03BN

HC8300FKP39Z 1.06.39D03BN/-V

HC8300FKP8H 1.06.08D03BN

HC8300FKS16H 1.06.16D12BN

HC8300FKS39H 1.06.39D12BN

HC8300FKS39Z 1.06.39D12BN/-V

HC8300FKS8H 1.06.08D12BN

HC8300FKT16H 1.06.16D25BN

HC8300FKT16Z 1.06.16D25BN/-V

HC8300FKT39H 1.06.39D25BN

HC8300FKT8H 1.06.08D25BN

Manuf. code


HYDAC


HC8300FKT8Z 1.06.08D25BN/-V

HC8300FKZ39H 1.06.39 D 01 BN

HC8300FWP8H 1.06.08 D 03 BN/AM

HC8304FKN16H 1.14.16D06ECO/N

HC8304FKN39H 1.14.39D06ECO/N

HC8304FKN39Z 1.14.39D06ECO/N/-V

HC8304FKP16H 1.14.16D03ECO/N

HC8304FKP39H 1.14.39D03ECO/N

HC8304FKS16H 1.14.16D12ECO/N

HC8304FKS39H 1.14.39D12ECO/N

HC8304FKT16H 1.14.16D25ECO/N

HC8304FKT39H 1.14.39D25ECO/N

HC8304FKZ16H 1.14.16 D 01 ECO/N

HC8304FKZ39H 1.14.39 D 01 ECO/N

HC8310FKN16H 1.14.16D06BN

HC8310FKN16Z 1.14.16D06BN/-V

HC8310FKN39H 1.14.39D06BN

HC8310FKN39Z 1.14.39D03BN/-V

HC8310FKP16H 1.14.16D03BN

HC8310FKP16Z 1.14.16D03BN/-V

HC8310FKP39H 1.14.39D03BN

HC8310FKP39Z 1.14.39 D 03 BN /-V

HC8310FKS16H 1.14.16D12BN

HC8310FKS39H 1.14.39D12BN

HC8310FKS8H 1.14.08D12BN

HC8310FKT16H 1.14.16D25BN

HC8310FKT16Z 1.14.16D25BN/-V

HC8310FKT39H 1.14.39D25BN

HC8310FKT8H 1.14.08D25BN

HC8314FKN16H 1.14.16D06ECO/N

HC8314FKN39H 1.14.39D06ECO/N

HC8314FKN39Z 1.14.39D06ECO/N/-V

HC8314FKP16H 1.14.16D03ECO/N

HC8314FKP39H 1.14.39D03ECO/N

HC8314FKS16H 1.14.16D12ECO/N

HC8314FKS39H 1.14.39D12ECO/N

HC8314FKT16H 1.14.16D25ECO/N

HC8314FKT39H 1.14.39D25ECO/N

HC8314FKZ16H 1.14.16 D 01 ECO/N

HC8314FKZ39H 1.14.39 D 01 ECO/N

HC8400FKN16H 1.03.16R06BN

HC8400FKN26H 1.03.26R06BN

HC8400FKN39H 1.03.39R06BN

HC8400FKN8H 1.03.08R06BN

HC8400FKP16H 1.03.16R03BN

HC8400FKP26H 1.03.26R03BN

HC8400FKP39H 1.03.39R03BN

HC8400FKP8H 1.03.08R03BN

HC8400FKS16H 1.03.16R12BN

HC8400FKS26H 1.03.26R12BN

HC8400FKS39H 1.03.39R12BN

HC8400FKS8H 1.03.08R12BN

HC8400FKT16H 1.03.16R25BN

HC8400FKT26H 1.03.26R25BN

HC8400FKT39H 1.03.39R25BN

HC8400FKT8H 1.03.08R25BN

HC8500FKN13H 1.04.13R06BN

HC8500FKN26H 1.04.26R06BN

HC8500FKN8H 1.04.08R06BN

HC8500FKP13H 1.04.13R03BN

HC8500FKP26H 1.04.26R03BN

HC8500FKP8H 1.04.08R03BN

HC8500FKS13H 1.04.13R12BN

HC8500FKS26H 1.04.26R12BN

HC8500FKS8H 1.04.08R12BN

HC8500FKT13H 1.04.13R25BN

HC8500FKT26H 1.04.26R25BN

HC8500FKT8H 1.04.08R25BN

HC8700FKN4H 1.05.04R06BN

HC8700FKN8H 1.05.08R06BN

HC8700FKP4H 1.05.04R03BN

HC8700FKP8H 1.05.08R03BN

HC8700FKS4H 1.05.04R12BN

HC8700FKS8H 1.05.08R12BN

HC8700FKT4H 1.05.04R25BN

HC8700FKT8H 1.05.08R25BN

PALL

E 7.205.1/07.02

17

E 7.205.1/07.02 PALL

18

Manuf. code


HYDAC


HC8800FKN13H 1.17.13D06BN

HC8800FKN16H 1.17.16D06BN

HC8800FKN16Z 1.17.16D06BN/-V

HC8800FKP13H 1.17.13D03BN

HC8800FKP16H 1.17.16D03BN

HC8800FKS13H 1.17.13D12BN

HC8800FKS16H 1.17.16D12BN

HC8800FKT13H 1.17.13D25BN

HC8800FKT16H 1.17.16D25BN

HC8900FKN13H 1.08.13D06BN

HC8900FKN16H 1.08.16D06BN

HC8900FKN16Z 1.08.16 D 06 BN /-V

HC8900FKN26H 1.08.26D06BN

HC8900FKN39H 1.08.39D06BN

HC8900FKN8H 1.08.08D06BN

HC8900FKP13H 1.08.13D03BN

HC8900FKP16H 1.08.16D03BN

HC8900FKP16Z 1.08.16 D 03 BN /-V

HC8900FKP26H 1.08.26D03BN

HC8900FKP39H 1.08.39D03BN

HC8900FKP8H 1.08.08D03BN

HC8900FKS13H 1.08.13D12BN

HC8900FKS16H 1.08.16D12BN

HC8900FKS26H 1.08.26D12BN

HC8900FKS26Z 1.08.26 D 12 BN /-V

HC8900FKS39H 1.08.39D12BN

HC8900FKS8H 1.08.08D12BN

HC8900FKT13H 1.08.13D25BN

HC8900FKT16H 1.08.16D25BN

HC8900FKT16Z 1.08.16D25BN/-V

HC8900FKT26H 1.08.26D25BN

HC8900FKT26Z 1.08.26 D 25 BN /-V

HC8900FKT39H 1.08.39D25BN

HC8900FKT8H 1.08.08D25BN

HC9020FKN4H 1.07.04D06BN

HC9020FKN4Z 1.07.04D06BN/-V

HC9020FKN8H 1.07.08D06BN

HC9020FKN8Z 1.07.08D06BN/-V

HC9020FKP4H 1.07.04D03BN

HC9020FKP4Z 1.07.04D03BN/-V

HC9020FKP8H 1.07.08D03BN

HC9020FKP8Z 1.07.08D03BN/-V

HC9020FKS4H 1.07.04D12BN

HC9020FKS4Z 1.07.04D12BN/-V

HC9020FKS8H 1.07.08D12BN

HC9020FKS8Z 1.07.0812BN/-V

HC9020FKT4H 1.07.04D25BN

HC9020FKT4Z 1.07.04D25BN/V

HC9020FKT8H 1.07.08D25BN

HC9020FKT8Z 1.07.08D25BN/-V

HC9021FDN4H 1.07.04D06BH

HC9021FDN8H 1.07.08D06BH

HC9021FDN8Z 1.07.08D06BH/-V

HC9021FDP4H 1.07.04D03BH

HC9021FDP4Z 1.07.04D03BH/-V

HC9021FDP8H 1.07.08D03BH

HC9021FDP8Z 1.07.08D03BH/-V

HC9021FDS4H 1.07.04D10BH

HC9021FDS8H 1.07.08D10BH

HC9021FDS8Z 1.07.08D10BH/-V

HC9021FDT4H 1.07.04D17BH

HC9021FDT4Z 1.07.04D17BH/-V

HC9021FDT8H 1.07.08D17BH

HC9021FDZ4H 1.07.04 D 01 BH

HC9021FDZ8H 1.07.08 D 01 BH

HC9100FKN13H 1.12.13 D 06 BN

HC9100FKN4H 1.12.04 D 06 BN

HC9100FKN8H 1.12.08 D 06 BN

HC9100FKP13H 1.12.13 D 03 BN

HC9100FKP4H 1.12.04 D 03 BN

HC9100FKP8H 1.12.08 D 03 BN

HC9100FKS13H 1.12.13 D 12 BN

HC9100FKS13Z 1.12.13 D 12 BN /-V

HC9100FKS4H 1.12.04 D 12 BN

HC9100FKS8H 1.12.08 D 12 BN

HC9100FKT13H 1.12.13 D 25 BN

Manuf. code


HYDAC


HC9100FKT4H 1.12.04 D 25 BN

HC9100FKT8H 1.12.08 D 25 BN

HC9101FDP13H 1.12.13 D 03 BH

HC9101FDP4H 1.12.04 D 03 BH

HC9101FDP8H 1.12.08 D 03 BH

HC9101FDS13H 1.12.13 D 10 BH

HC9101FDS4H 1.12.04 D 10 BH

HC9101FDS8H 1.12.08 D 10 BH

HC9101FDT13H 1.12.13 D 17 BH

HC9101FDT4H 1.12.04 D 17 BH

HC9101FDT8H 1.12.08 D 17 BH

HC9400FKN13H 1.10.13D06BN

HC9400FKN13Z 1.10.13D06BN/-V

HC9400FKN26H 1.10.26D06BN

HC9400FKN39H 1.10.39D06BN

HC9400FKN39Z 1.10.39D06BN/-V

HC9400FKP13H 1.10.13D03BN

HC9400FKP26H 1.10.26D03BN

HC9400FKP39H 1.10.39D03BN

HC9400FKP39Z 1.10.39D03BN/-V

HC9400FKS13H 1.10.13D12BN

HC9400FKS26H 1.10.26D12BN

HC9400FKS39H 1.10.39D12BN

HC9400FKT13H 1.10.13D25BN

HC9400FKT26H 1.10.26D25BN

HC9400FKT39H 1.10.39D25BN

HC9401FDN13H 1.10.13D06BH

HC9401FDN26H 1.10.26D06BH

HC9401FDN39H 1.10.39D06BH

HC9401FDP13H 1.10.13D03BH

HC9401FDP26H 1.10.26D03BH

HC9401FDP39H 1.10.39D03BH

HC9401FDS13H 1.10.13D10BH

HC9401FDS26H 1.10.26D10BH

HC9401FDS39H 1.10.39D10BH

HC9401FDT13H 1.10.13D17BH

HC9401FDT26H 1.10.26D17BH

HC9401FDT39H 1.10.39D17BH

HC9600EOT4H 1.11.04 D 25 W

HC9600EOT8Z 1.11.08 D 25 W /-V

HC9600FKN13H 1.11.13D06BN

HC9600FKN13Z 1.11.13D06BN/-V

HC9600FKN16H 1.11.16D06BN

HC9600FKN16Z 1.11.16D06BN/-V

HC9600FKN4H 1.11.04D06BN

HC9600FKN4Z 1.11.04D06BN/-V

HC9600FKN8H 1.11.08D06BN

HC9600FKN8Z 1.11.08D06BN/-V

HC9600FKP13H 1.11.13D03BN

HC9600FKP13Z 1.11.13D03BN/-V

HC9600FKP16H 1.11.16D03BN

HC9600FKP16Z 1.11.16D03BN/-V

HC9600FKP4H 1.11.04D03BN

HC9600FKP4J 1.11.04 D 03 BN /-E

HC9600FKP4Z 1.11.04D03BN/-V

HC9600FKP8H 1.11.08D03BN

HC9600FKP8Z 1.11.08D03BN/-V

HC9600FKS13H 1.11.13D12BN

HC9600FKS13Z 1.11.13D12BN/-V

HC9600FKS16H 1.11.16D12BN

HC9600FKS16Z 1.11.16 D 12 BN /-V

HC9600FKS4H 1.11.04D12BN

HC9600FKS4Z 1.11.04D12BN/-V

HC9600FKS8H 1.11.08D12BN

HC9600FKS8Z 1.11.08D12BN/-V

HC9600FKT13H 1.11.13D25BN

HC9600FKT13Z 1.11.13D25BN/-V

HC9600FKT16H 1.11.16D25BN

HC9600FKT16Z 1.11.16D25BN/-V

HC9600FKT4H 1.11.04D25BN

HC9600FKT4J 1.11.04 D 25 BN /-E

HC9600FKT4Z 1.11.04D25BN/-V

HC9600FKT8H 1.11.08D25BN

HC9600FKT8Z 1.11.08D25BN/-V

HC9601FDN13H 1.11.13D06BH

HC9601FDN16H 1.11.16D06BH

Manuf. code


HYDAC


HC9601FDN4H 1.11.04D06BH

HC9601FDN8H 1.11.08D06BH

HC9601FDN8Z 1.11.08 D 06 BH /-V

HC9601FDP13H 1.11.13D03BH

HC9601FDP13Z 1.11.13D03BH/-V

HC9601FDP16H 1.11.16D03BH

HC9601FDP16Z 1.11.16D03BH/-V

HC9601FDP4H 1.11.04D03BH

HC9601FDP4Z 1.11.04D03BH/-V

HC9601FDP8H 1.11.08D03BH

HC9601FDP8Z 1.11.08D03BH/-V

HC9601FDS13H 1.11.13D10BH

HC9601FDS16H 1.11.16D10BH

HC9601FDS16Z 1.11.16 D 10 BH /-V

HC9601FDS4H 1.11.04D10BH

HC9601FDS8H 1.11.08D10BH

HC9601FDS8Z 1.11.08D10BH/-V

HC9601FDT13H 1.11.13D17BH

HC9601FDT16H 1.11.16D17BH

HC9601FDT16Z 1.11.16D17BH/-V

HC9601FDT4H 1.11.04D17BH

HC9601FDT4Z 1.11.04D17BH/-V

HC9601FDT8H 1.11.08D17BH

HC9601FDT8Z 1.11.08D17BH-V

HC9650FKN16H 1.18.16D06BN

HC9650FKN8H 1.18.08D06BN

HC9650FKN8Z 1.18.08 D 06 BN /-V

HC9650FKP16H 1.18.16D03BN

HC9650FKP16Z 1.18.16D03BN/-V

HC9650FKP8H 1.18.08D03BN

HC9650FKS16H 1.18.16D12BN

HC9650FKS8H 1.18.08D12BN

HC9650FKT16H 1.18.16D25BN

HC9650FKT8H 1.18.08D25BN

HC9651FDN16H 1.18.16D06BH

HC9651FDN8H 1.18.08D06BH

HC9651FDP16H 1.18.16D03BH

HC9651FDP8H 1.18.08D03BH

HC9651FDP8Z 1.18.08D03BH/-V

HC9651FDS16H 1.18.16D10BH

HC9651FDS8H 1.18.08D10BH

HC9651FDT16H 1.18.16D17BH

HC9651FDT8H 1.18.08D17BH

HC9700FKN18H 5.03.18D05BN

HC9700FKN18Z 5.03.18D05BN/-V

HC9700FKN9H 5.03.09D05BN

HC9700FKP18H 5.03.18D03BN

HC9700FKP18Z 5.03.18D03BN/-V

HC9700FKP9H 5.03.09D03BN

HC9700FKS18H 5.03.18D10BN

HC9700FKS18Z 5.03.18D10BN/-V

HC9700FKS9H 5.03.09D10BN

HC9700FKT18H 5.03.18D20BN

HC9700FKT9H 5.03.09D20BN

HC9735FKN9H 5.02.09D05BN

HC9735FKP9H 5.02.09D03BN

HC9735FKS9H 5.02.09D10BN

HC9800FKN13H 1.13.13D06BN

HC9800FKN16H 1.13.16D06BN

HC9800FKN4H 1.13.04D06BN

HC9800FKN4Z 1.13.04D06BN/-V

HC9800FKN8H 1.13.08D06BN

HC9800FKN8Z 1.13.08D06BN/-V

HC9800FKP13H 1.13.13D03BN

HC9800FKP13Z 1.13.13 D 03 BN /-V

HC9800FKP16H 1.13.16D03BN

HC9800FKP4H 1.13.04D03BN

HC9800FKP4Z 1.13.04 D 03 BN /-V

HC9800FKP8H 1.13.08D03BN

HC9800FKP8Z 1.13.08D03BN/-V

HC9800FKS13H 1.13.13D12BN

HC9800FKS16H 1.13.16D12BN

HC9800FKS4H 1.13.04D12BN

HC9800FKS4Z 1.13.04 D 12 BN /-V

HC9800FKS8H 1.13.08D12BN

HC9800FKS8Z 1.13.08 D 12 BN /-V

HYDAC



HC9800FKT13H 1.13.13D25BN

HC9800FKT16H 1.13.16D25BN

HC9800FKT4H 1.13.04D25BN

HC9800FKT4Z 1.13.04 D 25 BN /-V

HC9800FKT8H 1.13.08D25BN

HC9801FDN13H 1.13.13D06BH

HC9801FDN4H 1.13.04D06BH

HC9801FDN8H 1.13.08D06BH

HC9801FDP13H 1.13.13D03BH

HC9801FDP13Z 1.13.13 D 03 BH /-V

HC9801FDP4H 1.13.04D03BH

HC9801FDP4Z 1.13.04D03BH/-V

HC9801FDP8H 1.13.08D03BH

HC9801FDS13H 1.13.13D10BH

HC9801FDS4H 1.13.04D10BH

HC9801FDS8H 1.13.08D10BH

HC9801FDS8Z 1.13.08D10BH/-V

HC9801FDT13H 1.13.13D17BH

HC9801FDT4H 1.13.04D17BH

HC9801FDT8H 1.13.08D17BH

HC9801FDT8Z 1.13.08D17BH/-V

HC9901FKP13H 1.09.13D03BH

Parker

920369 1.07.04D25BN

920370 1.07.04D25BN/V

920370 1.07.08D25BN

921999 0080MA010P

924451 4.01.09D20P

924452 4.01.09D03BN

924453 4.01.09D10BN

924792 4.01.18D10P

924793 4.01.18D20P

924794 4.01.18D03BN

924795 4.01.18D10BN

925023 0080MA025P

925580 1.07.04D06BN

925582 1.07.04D03BN

925598 1.07.08D12BN

925600 1.07.08D06BN

925602 1.07.08D03BN

925664 1.07.04D03BH/-V

925666 1.07.04D10BH

925669 1.07.08D03BH

925671 1.07.08D03BH/-V

925771 5.03.09D20BN

925772 5.03.09D03P

925773 5.03.09D25P

925774 5.03.09D25W

925780 5.03.09D20BN/-V

925784 5.03.09D74W/-V

925794 5.03.18D25W

925798 5.03.18D03BN

925799 5.03.18D10BN

925804 5.03.18D25W/-V

925808 5.03.18D03BN/-V

925809 5.03.18D10BN/-V

926475 5.03.09D74W

926696 1.11.04D03BN

926697 1.11.08D03BN

926698 1.11.13D03BN

926699 1.11.16D03BN

926716 1.11.04D03BN/-V

926717 1.11.08D03BN/-V

926718 1.11.13D03BN/-V

926719 1.11.16D03BN/-V

926835 1.11.04D12BN

926836 1.11.04D12BN/-V

926837 1.11.08D12BN

926838 1.11.08D12BN/-V

926839 1.11.13D12BN

926840 1.11.13D12BN/-V

926841 1.11.16D12BN

926971 0180MA020BN

926990 1.18.08D12BN

926992 1.18.08D03BN

926996 1.18.16D12BN

PAL - PAR

E 7.205.1/07.02

19

E 7.205.1/07.02 PAR - PTI

20

Manuf. code

Parker (continued)

HYDAC


926998 1.18.16D03BN

926999 1.18.16D03BN/-V

927111 1.06.39D25BN

927169 1.11.04D10BH

927170 1.11.04D03BH

927173 1.11.04D03BH/-V

927175 1.11.08D10BH

927176 1.11.08D03BH

927178 1.11.08D17BH-V

927181 1.11.13D10BH

927182 1.11.13D03BH

927185 1.11.13D03BH/-V

927661 1.06.08D12BN

927661Q 1.14.16 D 12 ECO/N

927663 1.06.08D06BN

927663Q 1.14.16 D 03 ECO/N

927664 1.06.08D06BN/-V

927666 1.06.16D12BN

927668 1.06.16D06BN

927694 1.07.08D10BH

927725 1.07.04D03BH

927861Q 1.14.16 D 06 ECO/N

927945 1.06.39D06BN

927946 1.06.39D12BN

928142 1.11.16D17BH

928143 1.11.16D03BH

928144 1.11.16D17BH/-V

928145 1.11.16D03BH/-V

928150 1.18.08D17BH

928152 1.18.08D03BH

928153 1.18.08D03BH/-V

928154 1.18.16D10BH

928156 1.18.16D03BH

928334 5.03.18D74W

928335 5.03.18D74W/-V

928763 0080MA010BN

928764 0080MA020BN

929099 1.06.08D25BN

929099Q 1.14.16 D 25 ECO/N

929100 1.06.08D25BN/-V

929105 1.06.16D25BN

929106 1.06.16D25BN/-V

929884 1.10.13D03BN

929885 1.10.13D12BN

929890 1.10.26D03BN

929891 1.10.26D25BN

930099 1.11.04D25BN

930100 1.11.04D25BN/-V

930118 1.11.08D25BN

930119 1.11.08D25BN/-V

930162 1.11.13D25BN

930163 1.11.13D25BN/-V

930164 1.11.16D25BN

930165 1.11.16D25BN/-V

930189 1.13.04D03BN

930190 1.13.04D12BN

930191 1.13.04D25BN

930192 1.13.08D03BN

930193 1.13.08D06BN/-V

930194 1.13.08D25BN

931437 5.03.09D10P

925778/932668Q 5.03.09D03BN

925779/932670Q 5.03.09D10BN

925788/932671Q 5.03.09D03BN/-V

925789/932673Q 5.03.09D10BN/-V

927737B 0180MA025P

928085/928087 1.06.39D12BN/-V

932872Q 1.14.39 D 03 ECO/N

932873Q 1.14.39 D 06 ECO/N

932874Q 1.14.39 D 12 ECO/N

932875Q 1.14.39 D 25 ECO/N

G01097 4.94.300 D 25 W

G01098 4.94.300 D 10 BN

G01099 4.94.300 D 03 BN

G02622 0630 RN 010 BN/HC

G02623 0630 RN 006 BN/HC

HYDAC


Parker (continued)

G02624 0630 RN 003 BN/HC

G02628 1000 RN 010 BN/HC

G02629 1000 RN 006 BN/HC

G02630 1000 RN 003 BN/HC

G04049 0040 DN 003 BN/HC

G04050 0040 DN 006 BN/HC

G04051 0040 DN 010 BN/HC

G04052 0040 DN 025 BN/HC

G04053 0040 DN 003 BH/HC

G04054 0040 DN 006 BH/HC

G04055 0040 DN 010 BH/HC

G04056 0040 DN 025 BH/HC

G04065 0063 DN 003 BN/HC

G04066 0063 DN 006 BN/HC

G04067 0063 DN 010 BN/HC

G04068 0063 DN 025 BN/HC

G04069 0063 DN 003 BH/HC

G04070 0063 DN 006 BH/HC

G04071 0063 DN 010 BH/HC

G04072 0063 DN 025 BH/HC

G04081 0100 DN 003 BN/HC

G04082 0100 DN 006 BN/HC

G04083 0100 DN 010 BN/HC

G04084 0100 DN 025 BN/HC

G04085 0100 DN 003 BH/HC

G04086 0100 DN 006 BH/HC

G04087 0100 DN 010 BH/HC

G04088 0100 DN 025 BH/HC

G04097 0160 DN 003 BN/HC

G04098 0160 DN 006 BN/HC

G04099 0160 DN 010 BN/HC

G04100 0160 DN 025 BN/HC

G04101 0160 DN 003 BH/HC

G04102 0160 DN 006 BH/HC

G04103 0160 DN 010 BH/HC

G04104 0160 DN 025 BH/HC

G04113 0250 DN 003 BN/HC

G04114 0250 DN 006 BN/HC

G04115 0250 DN 010 BN/HC

G04116 0250 DN 025 BN/HC

G04117 0250 DN 003 BH/HC

G04118 0250 DN 006 BH/HC

G04119 0250 DN 010 BH/HC

G04120 0250 DN 025 BH/HC

G04129 0400 DN 003 BN/HC

G04130 0400 DN 006 BN/HC

G04131 0400 DN 010 BN/HC

G04132 0400 DN 025 BN/HC

G04133 0400 DN 003 BH/HC

G04134 0400 DN 006 BH/HC

G04135 0400 DN 010 BH/HC

G04136 0400 DN 025 BH/HC

G04484 0100 RN 010 BN/HC

G04485 0100 RN 006 BN/HC

G04486 0100 RN 003 BN/HC

G04487 0250 RN 010 BN/HC

G04488 0250 RN 006 BN/HC

G04489 0250 RN 003 BN/HC

PTI

F4E-030BC 0080MA003P

F4E-030CC 0080MA010P

F4E-030DC 0080MA025P

F4E-030GC 0080MA003BN

F4E-030HC 0080MA010BN

F4E-030JC 0080MA020BN

F4E-040BC 0085MA003P

F4E-040CC 0085MA010P

F4E-040DC 0085MA025P

F4E-040HC 0085MA010BN

F4E-050BC 0160MA003P

F4E-050CC 0160MA010P

F4E-050DC 0160MA025P

F4E-050GC 0160MA003BN

F4E-050HC 0160MA010BN

F4E-050JC 0160MA020BN

F4E-070BC 0180MA003P

Manuf. code

PTI (continued)

HYDAC


F4E-070CC 0180MA010P

F4E-070DC 0180MA025P

F4E-070GC 0180MA003BN

F4E-070HC 0180MA010BN

F4E-070JC 0180MA020BN

F4F-030BC 0090MA003P

F4F-030CC 0090MA010P

F4F-030DC 0090MA025P

F4F-030HC 0090MA010BN

F4F-030JC 0090MA020BN

F4F-040BC 0095MA003P

F4F-040CC 0095MA010P

F4F-040DC 0095MA025P

F4F-040GC-B 0095MA003BN

F4F-040HC-B 0095MA005BN

FK-010-GG-B 1.07.04D03BN

FK-010-GU-B 1.07.04D03BH

FK-010-HG-B 1.07.04D06BN

FK-010-JU-B 1.07.04D10BH

FK-020-GG-B 1.07.08D03BN

FK-020-GU-B 1.07.08D03BH

FK-020-HG-B 1.07.08D06BN

HF3-015-GF-B 1.11.04D03BN

HF3-015-HF-B 1.11.04D12BN

HF3-015-JF-B 1.11.04D25BN

HF3-015-GU-B 1.11.04D03BH

HF3-015-JU-B 1.11.04D17BH

HF3-030-GF-B 1.11.08D03BN

HF3-030-GU-B 1.11.08D03BH

HF3-030-HF-B 1.11.08D12BN

HF3-030-JF-B 1.11.08D25BN

HF3-030-JU-B 1.11.08D17BH

HF3-050-GF-B 1.11.13D03BN

HF3-050-GU-B 1.11.13D03BH

HF3-050-HF-B 1.11.13D12BN

HF3-050-JF-B 1.11.13D25BN

HF3-050-JU-B 1.11.13D17BH

HF3-060-GF-B 1.11.16D03BN

HF3-060-GU-B 1.11.16D03BH

HF3-060-HF-B 1.11.16D12BN

HF3-060-JF-B 1.11.16D25BN

HF3-060-JU-B 1.11.16D17BH

HF4-050CCB 5.03.09D10P

HF4-050DBC 5.03.09D25P

HF4-050GFB 5.03.09D03BN

HF4-050HFB 5.03.09D10BN

HF4-050JFB 5.03.09D20BN

P83-100HFB 1.06.08D06BN

P83-100JBF 1.06.08D25BN

P83-150GFB 1.06.16D03BN

P83-150HFB 1.06.16D06BN

P83-150JBF 1.06.16D25BN

P83-250GFB 1.06.39D03BN

P83-250HFB 1.06.39D06BN

P83-250JBF 1.06.39D25BN

P94-100GFB 1.10.13D03BN

P94-100HFB 1.10.13D06BN

P94-150GFB 1.10.26D03BN

P94-150HFB 1.10.26D06BN

P94-200GFB 1.10.39D03BN

P94-200HFB 1.10.39D06BN

P96-030GFB 1.18.08D03BN

P96-030GUB 1.18.08D03BH

P96-030HFB 1.18.08D06BN

P96-030JFB 1.18.08D25BN

P96-030JUB 1.18.08D17BH

P96-060GFB 1.18.16D03BN

P96-060HFB 1.18.16D06BN

P96-060JFB 1.18.16D12BN

P98-015GGB 1.13.04D03BN

P98-015GUB 1.13.04D03BH

P98-015HGB 1.13.04D06BN

P98-015JGB 1.13.04D25BN

P98-015JUB 1.13.04D06BH

P98-030GGB 1.13.08D03BN

P98-030GUB 1.13.08D03BH

Manuf. code

PTI (continued)

HYDAC


P98-030HGB 1.13.08D06BN

P98-030JGB 1.13.08D25BN

P98-030JUB

Ripley

1.13.08D17BH

DP752-10 0080MA010P

DP752-30

Schroeder

0080MA025P

18LS15 5.08.18D20BN

18LS7 5.08.18D10BN

A10 5.01.05R10P

A10V 5.01.05R10P/-V

A25 5.01.05R25P

A3 5.01.05R03P

AS1 5.01.05R03BN

AS15 5.01.05R20BN

AS1V 5.01.05R03BN/-V

AS3 5.01.05R05BN

AS7 5.01.05R10BN

AS7V 5.01.05R10BN/-V

J10 5.02.09D10P

J25 5.02.09D25P

HJ-003P 5.02.09D03P

JS1 5.02.09D03BN

JS15 5.02.09D20BN

JS3 5.02.09D05BN

JS7 5.02.09D10BN

K10 5.03.09D10P

K25 5.03.09D25P

K3 5.03.09D03P

KM150 5.03.09D149W

KM25 5.03.09D25W

KM60 5.03.09D74W

KS1 5.03.09D03BN

KS15 5.03.09D20BN

KS15V 5.03.09D20BN/-V

KS1V 5.03.09D03BN/-V

KS3 5.03.09D05BN

KS3V 5.03.09D05BN/-V

KS7 5.03.09D10BN

KS7V 5.03.09D10BN/-V

KSX1 5.03.09D03BH

KSX15 5.03.09D20BH

KSX15V 5.03.09D20BH/-V

KSX1H 5.03.09D03BH/-EPR

KSX1V 5.03.09D03BH/-V

KSX3 5.03.09D05BH

KSX3V 5.03.09D05BH/-V

KSX7 5.03.09D10BH

KSX7H 5.03.09D10BH/-EPR

KSX7V 5.03.09D10BH/-V

MS3-G1087 0160MA005BN

MS7-G1087 0180MA010BN

SBF-8300-16S1B 1.06.16D03BN

SBF-8300-16S1V 1.06.16D03BN/-V

SBF-8300-16S3B 1.06.16D06BN

SBF-8300-16S7B 1.06.16D12BN

SBF-8300-39S1B 1.06.39D03BN

SBF-8300-39S1V 1.06.39D03BN/-V

SBF-8300-39S3B 1.06.39D06BN

SBF-8300-39S7B 1.06.39D12BN

SBF-8300-39S7V 1.06.39D12BN/-V

SBF-8300-39SV3 1.06.39D06BN/-V

SBF-9600-13S1B 1.11.13D03BN

SBF-9600-13S1V 1.11.13D03BN/-V

SBF-9600-13S3B 1.11.13D06BN

SBF-9600-13S3V 1.11.13D06BN/-V

SBF-9600-13S7B 1.11.13D12BN

SBF-9600-13S7V 1.11.13D12BN/-V

SBF-9600-16S1B 1.11.16D03BN

SBF-9600-16S1V 1.11.16D03BN/-V

SBF-9600-16S3B 1.11.16D06BN

SBF-9600-16S3V 1.11.16D06BN/-V

SBF-9600-16S7B 1.11.16D12BN

SBF-9600-8S1B 1.11.08D03BN

SBF-9600-8S1V 1.11.08D03BN/-V

SBF-9600-8S3B 1.11.08D06BN

PTI - SCH

E 7.205.1/07.02

21

E 7.205.1/07.02 SCH- STA

22

Manuf. code

Schroeder (continued)

HYDAC


SBF-9600-8S3V 1.11.08D06BN/-V

SBF-9600-8S7B 1.11.08D12BN

SBF-9600-8S7V 1.11.08D12BN/-V

SBF-9601-8S3B 1.11.08D10BH

SBF-9601-8S3V

Sofrance

1.11.08D10BH/-V

C2011T0Y0A 0040 DN 003 BN/HC

C2011D0Y0A 0040 DN 010 BN/HC

C2011V0Y0A 0040 DN 025 BN/HC

C2011T0Y1A 0040 DN 003 BH/HC

C2011D0Y1A 0040 DN 010 BH/HC

C2011V0Y1A 0040 DN 025 BH/HC

C2012T0Y0A 0063 DN 003 BN/HC

C2012D0Y0A 0063 DN 010 BN/HC

C2012V0Y0A 0063 DN 025 BN/HC

C2012T0Y1A 0063 DN 003 BH/HC

C2012D0Y1A 0063 DN 010 BH/HC

C2012V0Y1A 0063 DN 025 BH/HC

C2013T0Y0A 0100 DN 003 BN/HC

C2013D0Y0A 0100 DN 010 BN/HC

C2013V0Y0A 0100 DN 025 BN/HC

C2013T0Y1A 0100 DN 003 BH/HC

C2013D0Y1A 0100 DN 010 BH/HC

C2013V0Y1A 0100 DN 025 BH/HC

C2021T0Y0A 0160 DN 003 BN/HC

C2021D0Y0A 0160 DN 010 BN/HC

C2021V0Y0A 0160 DN 025 BN/HC

C2021T0Y1A 0160 DN 003 BH/HC

C2021D0Y1A 0160 DN 010 BH/HC

C2021V0Y1A 0160 DN 025 BH/HC

C2022T0Y0A 0250 DN 003 BN/HC

C2022D0Y0A 0250 DN 010 BN/HC

C2022V0Y0A 0250 DN 025 BN/HC

C2022T0Y1A 0250 DN 003 BH/HC

C2022D0Y1A 0250 DN 010 BH/HC

C2022V0Y1A 0250 DN 025 BH/HC

C2023T0Y0A 0250 DN 003 BN/HC

C2023D0Y0A 0400 DN 010 BN/HC

C2023V0Y0A 0400 DN 025 BN/HC

C2023T0Y1A 0400 DN 003 BH/HC

C2023D0Y1A 0400 DN 010 BH/HC

C2023V0Y1A 0400 DN 025 BH/HC

C1012T0Y0A 0063 RN 003 BN/HC

C1012S0Y0A 0063 RN 006 BN/HC

C1012D0Y0A 0063 RN 010 BN/HC

C1012V0Y0A 0063 RN 025 BN/HC

C1013T0Y0A 0100 RN 003 BN/HC

C1013S0Y0A 0100 RN 006 BN/HC

C1013D0Y0A 0100 RN 010 BN/HC

C1013V0Y0A 0100 RN 025 BN/HC

C1022T0Y0A 0250 RN 003 BN/HC

C1022S0Y0A 0250 RN 006 BN/HC

C1022D0Y0A 0250 RN 010 BN/HC

C1022V0Y0A 0250 RN 025 BN/HC

C1032T0Y0A 0630 RN 003 BN/HC

C1032S0Y0A 0630 RN 006 BN/HC

C1032D0Y0A 0630 RN 010 BN/HC

C1032V0Y0A 0630 RN 025 BN/HC

C1041T0Y0A 1000 RN 003 BN/HC

C1041S0Y0A 1000 RN 006 BN/HC

C1041D0Y0A 1000 RN 010 BN/HC

C1041V0Y0A

Stauff

1000 RN 025 BN/HC

RE008A10B 0030R010V

RE008A20B 0030R020V

RE008B25B 0030R025W/HC

RE008D10B 0030R010P/HC

RE008D20B 0030R020P/HC

RE008E03B 0030R003BN3HC

RE008E05B 0030R005BN3HC

RE008E10B 0030R010BN3HC

RE008E20B 0030R020BN3HC

RE014A03B 0060R003V

RE014A05B 0060R005V

RE014A10B 0060R010V

RE014A20B 0060R020V

HYDAC


Stauff (continued)

RE014B25B 0060R025W

RE014D10B 0060R010P

RE014D20B 0060R020P

RE014E03B 0060R003BN3HC

RE014E05B 0060R005BN3HC

RE014E10B 0060R010BN3HC

RE014E20B 0060R020BN3HC

RE014G03B 0060R003BN3HC

RE014G05B 0060R005BN3HC

RE014G10B 0060R010BN3HC

RE014G20B 0060R020BN3HC

RE014N10B 0060R010P/HC

RE014N20B 0060R020P/HC

RE014S25B 0060R025W/HC

RE030A03B 0110R003V

RE030A05B 0110R005V

RE030A10B 0110R010V

RE030A20B 0110R020V

RE030B25B 0110R025W

RE030D10B 0110R010P

RE030D20B 0110R020P

RE030G02B 0110R020BN3HC

RE030G03B 0110R003BN3HC

RE030G05B 0110R005BN3HC

RE030G10B 0110R010BN3HC

RE030N10B 0110R010P/HC

RE030N20B 0110R020P/HC

RE030S25B 0110R025W/HC

RE045A03B 0160R003V

RE045A05B 0160R005V

RE045A10B 0160R010V

RE045A20B 0160R020V

RE045B25B 0160R025W

RE045D10B 0160R010P

RE045D20B 0160R020P

RE045G03B 0160R003BN3HC

RE045G05B 0160R005BN3HC

RE045G10B 0160R010BN3HC

RE045G30B 0160R020BN3HC

RE045N10B 0160R010P/HC

RE045N20B 0160R020P/HC

RE045S25B 0160R025W/HC

RE070A03B 0240R003V

RE070A05B 0240R005V

RE070A10B 0240R010V

RE070A20B 0240R020V

RE070B25B 0240R025W

RE070D10B 0240R010P

RE070D20B 0240R020P

RE070E05B 0240R005BN3HC

RE070G03B 0240R003BN3HC

RE070G10B 0240R010BN3HC

RE070G20B 0240R020BN3HC

RE070N10B 0240R010P/HC

RE070N20B 0240R020P/HC

RE070S25B 0240R025W/HC

RE090A03B 0330R003V

RE090A05B 0330R005V

RE090A10B 0330R010V

RE090A20B 0330R020V

RE090B25B 0330R025W

RE090D10B 0330R010P

RE090D20B 0330R020P

RE090G03B 0330R003BN3HC/V

RE090G05B 0330R005BN3HC

RE090G10B 0330R010BN3HC

RE090G20B 0330R020BN3HC

RE090N10B 0330R010P/HC

RE090N20B 0330R020P/HC

RE090S25B 0330R025W/HC

RE130A03B 0500R003V

RE130A05B 0500R005V

RE130A10B 0500R010V

RE130A20B 0500R020V

RE130B25B 0500R025W

RE130D10B 0500R010P

Manuf. code


HYDAC


RE130D20B 0500R020P

RE130G03B 0500R003BN3HC

RE130G05B 0500R005BN3HC

RE130G10B 0500R010BN3HC

RE130G20B 0500R020BN3HC

RE130N10B 0500R010P

RE130N20B 0500R020P/HC

RE130S25B 0500R025W/HC

RE160A03B 0660R003V

RE160A05B 0660R005V

RE160A10B 0660R010V

RE160A20B 0660R020V

RE160B25B 0660R025W

RE160D10B 0660R010P

RE160D20B 0660R020P

RE160G03B 0660R003BN3HC

RE160G05B 0660R005BN3HC

RE160G10B 0660R010BN3HC

RE160G20B 0660R020BN3HC

RE160N10B 0660R010P/HC

RE160N20B 0660R020P/HC

RE160S25B 0660R025WHC

RE200B25B 0850R025W

RE200D10B 0850R010P

RE200D20B 0850R020P

RE200G03B 0850R003BN3HC

RE200G05B 0850R005BN3HC

RE200G10B 0850R010BN3HC

RE200G20B 0850R020BN3HC

RE200N10B 0850R010P/HC

RE200N20B 0850R020P/HC

RE200S25B 0850R025W/HC

RE250B25B 0950R025W

RE250D10B 0950R010P

RE250D20B 0950R020P

RE250G03B 0950R003BN3HC

RE250G05B 0950R005BN3HC

RE250G10B 0950R010BN3HC

RE250G20B 0950R020BN3HC

RE250N10B 0950R010P/HC

RE250N20B 0950R020P/HC

RE250S25B 0950R025WHC

RE300B25B 1300R025W

RE300D10B 1300R010P

RE300D20B 1300R020P

RE300G03B 1300R003BN3HC

RE300G05B 1300R005BN3HC

RE300G10B 1300R010BN3HC

RE300G20B 1300R020BN3HC

RE300N10B 1300R010P/HC

RE300N20B 1300R020P/HC

RE300S25B 1300R025W/HC

RE600B25B 2600R025W

RE600D10B 2600R010P

RE600D20B 2600R020P

RE600G03B 2600R003BN3HC

RE600G05B 2600R005BN3HC

RE600G10B 2600R010BN3HC

RE600G20B 2600R020BN3HC

RE600N10B 2600R010P/HC

RE600N20B 2600R020P/HC

RE600S25B 2600R025WHC

RP050E03B 1.04.08R03BN

RP050E05B 1.04.08R06BN

RP050E10B 1.04.08R12BN

RP050E20B 1.04.08R25BN

RP075E03B 1.01.08R03BN

RP075E05B 1.01.08R06BN

RP075E10B 1.01.08R12BN

RP075E20B 1.01.08R25BN

RP080E03B 1.04.13R03BN

RP080E05B 1.04.13R06BN

RP080E10B 1.04.13R12BN

RP080E20B 1.04.13R25BN

RP085E03B 1.01.13R03BN

RP085E05B 1.01.13R06BN

Manuf. code


HYDAC


RP085E10B 1.01.13R12BN

RP085E20B 1.01.13R25BN

RP090E03B 1.04.26R03BN

RP090E05B 1.04.26R06BN

RP090E10B 1.04.26R12BN

RP090E20B 1.04.26R25BN

RP095E03B 1.01.16R03BN

RP095E05B 1.01.16R06BN

RP095E10B 1.01.16R12BN

RP095E20B 1.01.16R25BN

RP100E03B 1.03.08R03BN

RP100E05B 1.03.08R06BN

RP100E10B 1.03.08R12BN

RP100E20B 1.03.08R25BN

RP115E03B 1.01.26R03BN

RP115E05B 1.01.26R06BN

RP115E10B 1.01.26R12BN

RP115E20B 1.01.26R25BN

RP200E03B 1.03.16R03BN

RP200E05B 1.03.16R06BN

RP200E10B 1.03.16R12BN

RP200E20B 1.03.16R25BN

RP240E03B 1.03.26R03BN

RP240E05B 1.03.26R06BN

RP240E10B 1.03.26R12BN

RP240E20B 1.03.26R25BN

RP300E03B 1.03.39R03BN

RP300E05B 1.03.39R06BN

RP300E10B 1.03.39R12BN

RP300E20B 1.03.39R25BN

SE008B25B 0030D025W

SE008D10B 0030D010P

SE008D20B 0030D020P

SE008E03B 0030D003BN3HC

SE008E05B 0030D005BN3HC

SE008E10B 0030D010BN3HC

SE008E20B 0030D020BN3HC

SE008F03B 0030D003BH3HC

SE008F05B 0030D005BH3HC

SE008F10B 0030D010BH3HC

SE008F20B 0030D020BH3HC

SE014A03B 0060D003V

SE014A05B 0060D005V

SE014A10B 0060D010V

SE014A20B 0060D020V

SE014B25B 0060D025W

SE014F20B 0060D020BH

SE014D10B 0060D010P

SE014D20B 0060D020P

SE014E03B 0060D003BN

SE014E05B 0060D005BN

SE014E10B 0060D010BN

SE014E20B 0060D020BN

SE014F03B 0060D003BH

SE014F05B 0060D005BH

SE014G03B 0060D003BN3HC

SE014G05B 0060D005BN3HC

SE014G10B 0060D010BN3HC

SE014G20B 0060D020BN3HC

SE014H03B 0060D003BH3HC

SE014H05B 0060D005BH3HC

SE014H10B 0060D010BH3HC

SE014H20B 0060D020BH3HC

SE030A03B 0110D003V

SE030A05B 0110D005V

SE030A10B 0110D010V

SE030A20B 0110D020V

SE030B25B 0110D025W

SE030D10B 011D010P

SE030D20B 011D020P

SE030G03B 0110D003BN3HC

SE030G05B 0110D005BN3HC

SE030G10B 0110D010BN3HC

SE030G20B 0110D020BN3HC

SE030H03B 0110D003BH3HC

SE030H05B 0110D005BH3HC

STAUFF

E 7.205.1/07.02

23

E 7.205.1/07.02 STAUFF

24

Manuf. code


HYDAC


SE030H10B 0110D010BH3HC

SE030H20B 0110D020BH3HC

SE035B25B 0140D025W

SE035G03B 0140D003BN3HC

SE035G05B 0140D005BN3HC

SE035G10B 0140D010BN3HC

SE035G20B 0140D020BN3HC

SE035H03B 0140D003BH3HC

SE035H05B 0140D005BH3HC

SE035H10B 0140D010BH3HC

SE035H20B 0140D020BH3HC

SE045A03B 0160D003V

SE045A05B 0160D005V

SE045A10B 0160D010V

SE045A20B 0160D020V

SE045B25B 0160D025W

SE045D10B 0160D010P

SE045D20B 0160D020P

SE045G03B 0160D003BN3HC

SE045G05B 0160D005BN3HC

SE045G10B 0160D010BN3HC

SE045G20B 0160D020BN3HC

SE045H03B 0160D003BH3HC

SE045H05B 0160D005BH3HC

SE045H10B 0160D010BH3HC

SE045H20B 0160D020BH3HC

SE070A03B 0240D003V

SE070A05B 0240D005V

SE070A10B 0240D010V

SE070A20B 0240D020V

SE070B25B 0240D025W

SE070D10B 0240D010P

SE070D20B 0240D020P

SE070G03B 0240D003BN3HC

SE070G05B 0240D005BN3HC

SE070G10B 0240D010BN3HC

SE070G20B 0240D020BN3HC

SE070H03B 0240D003BH3HC

SE070H05B 0240D005BH3HC

SE070H10B 0240D010BH3HC

SE070H20B 0240D020BH3HC

SE090A03B 0330D003V

SE090A05B 0330D005V

SE090A10B 0330D010V

SE090A20B 0330D020V

SE090D10B 0330D010P

SE090D20B 0330D020P

SE090G03B 0330D003BN3HC

SE090G05B 0330D005BN3HC

SE090G10B 0330D010BN3HC

SE090G20B 0330D020BN3HC

SE090H03B 0330D003BH3HC

SE090H05B 0330D005BH3HC

SE090H10B 0330D010BH3HC

SE090H20B 0330D020BH3HC

SE125B25B 0280D025W

SE125G03B 0280D003BN3HC

SE125G05B 0280D005BN3HC

SE125G10B 0280D010BN3HC

SE125G20B 0280D020BN3HC

SE125H03B 0280D003BH3HC

SE125H05B 0280D005BH3HC

SE125H10B 0280D010BH3HC

SE125H20B 0280D020BH3HC

SE130A03B 0500D003V

SE130A05B 0500D005V

SE130A10B 0500D010V

SE130A20B 0500D020V

SE130G03B 0500D003BN3HC

SE130G05B 0500D005BN3HC

SE130G10B 0500D010BN3HC

SE130G20B 0500D020BN3HC

SE130H03B 0500D003BH3HC

SE130H05B 0500D005BH3HC

SE130H10B 0500D010BH3HC

SE130H20B 0500D020BH3HC

Manuf. code


HYDAC


SE160A03B 0660D003V

SE160A05B 0660D005V

SE160A10B 0660D010V

SE160A20B 0660D020V

SE160B25B 0660D025W

SE160D10B 0660D010P

SE160D20B 0660D020P

SE160G03B 0660D003BN3HC

SE160G05B 0660D005BN3HC

SE160G10B 0660D010BN3HC

SE160G20B 0660D020BN3HC

SE160H03B 0660D003BH3HC

SE160H05B 0660D005BH3HC

SE160H10B 0660D010BH3HC

SE160H20B 0660D020BH3HC

SP010E03B 1.07.04D03BN

SP010E05B 1.07.04D06BN

SP010E10B 1.07.04D12BN

SP010E20B 1.07.04D25BN

SP010F05B 1.07.04D06BH

SP010F10B 1.07.04D10BH

SP010F20B 1.07.04D17BH

SP020E03B 1.07.08D03BN

SP020E05B 1.07.08D06BN

SP020E10B 1.07.08D12BN

SP020E20B 1.07.08D25BN

SP020F03B 1.07.08D03BH

SP020F05B 1.07.08D06BH

SP020F10B 1.07.08D10BH

SP020F20B 1.07.08D17BH

SP024F03B 1.13.04D03BH

SP024E03B 1.13.04D03BN

SP024E05B 1.13.04D06BN

SP024E10B 1.13.04D12BN

SP024E20B 1.13.04D25BN

SP024F05B 1.13.04D06BH

SP024F10B 1.13.04D10BH

SP024F20B 1.13.04D17BH

SP030E03B 1.13.08D03BN

SP030E05B 1.13.08D06BN

SP030E10B 1.13.08D12BN

SP030E20B 1.13.08D25BN

SP030F03B 1.13.08D03BH

SP030F05B 1.13.08D06BH

SP030F10B 1.13.08D10BH

SP030F20B 1.13.08D17BH

SP045E03B 1.11.04D03BN

SP045E05B 1.11.04D06BN

SP045E10B 1.11.04D12BN

SP045E20B 1.11.04D25BN

SP045F03B 1.11.04D03BH

SP045F05B 1.11.04D06BH

SP045F10B 1.11.04D10BH

SP045F20B 1.11.04D17BH

SP070E03B 1.11.08D03BN

SP070E03B0BE 1.18.08D03BN

SP070E10B 1.11.08D12BN

SP070E20B 1.11.08D25BN

SP070E10B0BE 1.18.08D12BN

SP070E20B0BE 1.18.08D25BN

SP070F03B 1.11.08D03BH

SP070F03B0BE 1.18.08D03BH

SP070F10B 1.11.08D10BH

SP070F10B0BE 1.18.08D10BH

SP070F20B0BE 1.18.08D17BH

SP090E03B 1.11.13D03BN

SP090E10B 1.11.13D12BN

SP090E20B 1.11.13D25BN

SP090F03B 1.11.13D03BH

SP090F10B 1.11.13D10BH

SP09E05B 1.11.13D06BN

SP100E03B 1.06.08D03BN

SP100E10B 1.06.08D12BN

SP100E20B 1.06.08D25BN

SP101F03B 1.07.04D03BH

SP110E03B 1.10.13D03BN

Manuf. code


HYDAC


SP110E10B 1.10.13D12BN

SP110F03B 1.09.13D03BH

SP110F03B 1.09.13D10BH

SP120E03B 1.08.08D03BN

SP120E10B 1.08.08D12BN

SP120E20B 1.08.08D25BN

SP130E03B 1.11.16D03BN

SP130E03B0BE 1.18.16D03BN

SP130E10B 1.11.16D12BN

SP130E10B0BE 1.18.16D12BN

SP130E20B 1.11.16D25BN

SP130E20B0BE 1.18.16D25BN

SP130F03B 1.11.16D03BH

SP130F03B0BE 1.18.16D03BH

SP130F10B 1.11.16D10BH

SP130F10B0BE 1.18.16D10BH

SP130F20B 1.11.16D17BH

SP130F20B0BE 1.18.16D17BH

SP140E03B 1.08.13D03BN

SP140E10B 1.08.13D12BN

SP140E20B 1.08.13D25BN

SP160E03B 1.08.16D03BN

SP160E10B 1.08.16D12BN

SP160E20B 1.08.16D25BN

SP170E03B 1.10.26D03BN

SP170E10B 1.10.26D12BN

SP170E20B 1.10.26D25BN

SP170F03B 1.09.26D03BH

SP170F10B 1.09.26D10BH

SP200E03B 1.06.16D03BN

SP200E10B 1.06.16D12BN

SP200E20B 1.06.16D25BN

SP250E03B 1.10.39D03BN

SP250E10B 1.10.39D12BN

SP250E20B 1.10.39D25BN

SP300E03B 1.06.39D03BN

SP300E10B 1.06.39D12BN

SP300E20B 1.06.39D25BN

SP304E03B 1.14.39D03ECO/N

SP304E06B 1.14.39D06ECO/N

SP304E12B 1.14.39D12ECO/N

SP304E25B

Triboguard

1.14.39D25ECO/N

060D003H 0060D003BH3HC

060D003HV 0060D003BH3HC/V

060D003N 0060D003BN3HC

060D003NV 0060D003BN3HC/V

060D005H 0060D005BH3HC

060D005HV 0060D005BH3HC/V

060D005N 0060D005BN3HC

060D010H 0060D010BH3HC

060D010HV 0060D010BH3HC/V

060D010N 0060D010BN3HC

060D010NV 0060D010BN3HC/V

060D020H 0060D020BH3HC

060D020HV 0060D020BH3HC/V

060D020N 0060D020BN3HC

060D020NV 0060D020BN3HC/V

110D003H 0110D003BH3HC

110D003HV 0110D003BH3HC/V

110D003N 0110D003BN3HC

110D003NV 0110D003BN3HC/V

110D005H 0110D005BH3HC

110D005HV 0110D005BH3HC/V

110D005N 0110D005BN3HC

110D005NV 0110D005BN3HC/V

110D010H 0110D010BH3HC

110D010HV 0110D010BH3HC/V

110D010N 0110D010BN3HC

110D010NV 0110D010BN3HC/V

110D020H 0110D020BH3HC

110D020HV 0110D020BH3HC/V

110D020N 0110D020BN3HC

110D020NV 0110D020BN3HC/V

160D003H 0160D003BH3HC

160D003HV 0160D003BH3HC/V

Manuf. code

Triboguard (continued)

HYDAC


160D003N 0160D003BN3HC

160D003NV 0160D003BN3HC/V

160D005H 0160D005BH3HC

160D005HV 0160D005BH3HC/V

160D005N 0160D005BN3HC

160D005NV 0160D005BN3HC/V

160D010H 0160D010BH3HC

160D010HV 0160D010BH3HC/V

160D010N 0160D010BN3HC

160D010NV 0160D010BN3HC/V

160D020H 0160D020BH3HC

160D020HV 0160D020BH3HC/V

160D020N 0160D020BN3HC

160D020NV 0160D020BN3HC/V

240D003H 0240D003BH3HC

240D003HV 0240D003BH3HC/V

240D003N 0240D003BN3HC

240D003NV 0240D003BN3HC/V

240D005H 0240D005BH3HC

240D005HV 0240D005BH3HC/V

240D005N 0240D005BN3HC

240D005NV 0240D005BN3HC/V

240D010H 0240D010BH3HC

240D010HV 0240D010BH3HC/V

240D010N 0240D010BN3HC

240D010NV 0240D010BN3HC/V

240D020H 0240D020BH3HC

240D020HV 0240D020BH3HC/V

240D020N 0240D020BN3HC

240D020NV 0240D020BN3HC/V

330D003N 0330D003BN3HC

330D003NV 0330D003BN3HC/V

330D005H 0330D005BH3HC

330D005N 0330D005BN3HC

330D005NV 0330D005BN3HC/V

330D010N 0330D010BN3HC

330D010NV 0330D010BN3HC/V

330D020N 0330D020BN3HC

330D020NV 0330D020BN3HC/V

660D003N 0660D003BN3HC

660D003NV 0660D003BN3HC/V

660D005N 0660D005BN3HC

660D005NV 0660D005BN3HC/V

660D010N 0660D010BN3HC

660D010NV 0660D010BN3HC/V

660D020N 0660D020BN3HC

660D020NV 0660D020BN3HC/V

7400412UM 0090MA010BN

7400425UM 0090MA020BN

740043UM 0090MA003BN

740046UM 0090MA005BN

7400812UM 0095MA010BN

740083UM 0095MA003BN

740086UM 0095MA005BN

7500412UM 0160MA010BN

7500425UM 0160MA020BN

750043UM 0160MA003BN

750046UM 0160MA005BN

7500812UM 0180MA010BN

7500825UM 0180MA020BN

750083UM 0180MA003BN

750086UM 0180MA005BN

82001312UM 1.16.13D12BN

82001325UM 1.16.13D25BN

8200133UM 1.16.13D03BN

8200136UM 1.16.13D06BN

82001612UM 1.16.16D12BN

82001612UMV 1.16.16D12BN/-V

82001625UM 1.16.16D25BN

8200163UM 1.16.16D03BN

8200166UM 1.16.16D.06BN

8200812UM 1.16.08D12BN

8200825UM 1.16.08D25BN

820083UM 1.16.08D03BN

820086UM 1.16.08D06BN

83001612UM 1.06.16D12BN

STA - TRI

E 7.205.1/07.02

25

E 7.205.1/07.02 TRIBOGUARD

26

Manuf. code


HYDAC


83001625UM 1.06.16D25BN

83001625UMV 1.06.16D25BN/-V

8300163UM 1.06.16D03BN

8300163UMV 1.06.16D03BN/-V

8300166UM 1.06.16D06BN

83003912UM 1.06.39D12BN

83003912UMV 1.06.39D12BN/-V

83003925UM 1.06.39D25BN

8300393UM 1.06.39D03BN

8300393UMV 1.06.39D03BN/-V

8300396UM 1.06.39D06BN

8300396UMV 1.06.39D06BN/-V

8300812UM 1.06.08D12BN

8300825UM 1.06.08D25BN

830083UM 1.06.08D03BN

830086UM 1.06.08D06BN

830086UMV 1.06.08D06BN/-V

84001612UM 1.03.16R12BN

84001625UM 1.03.16R25BN

8400163UM 1.03.16R03BN

8400166UM 1.03.16R06BN

84002612UM 1.03.26R12BN

84002625UM 1.03.26R25BN

8400263UM 1.03.26R03BN

8400266UM 1.03.26R06BN

84003912UM 1.03.39R12BN

84003925UM 1.03.39R25BN

8400393UM 1.03.39R03BN

8400396UM 1.03.39R06BN

8400812UM 1.03.08R12BN

8400825UM 1.03.08R25BN

840083UM 1.03.08R03BN

840086UM 1.03.08R06BN

85001312UM 1.04.13R12BN

85001325UM 1.04.13R25BN

8500133UM 1.04.13R03BN

8500136UM 1.04.13R06BN

85002612UM 1.04.26R12BN

85002625UM 1.04.26R25BN

8500263UM 1.04.26R03BN

8500266UM 1.04.26R06BN

8500812UM 1.04.08R12BN

8500825UM 1.04.08R25BN

850083UM 1.04.08R03BN

850086UM 1.04.08R06BN

88001312UM 1.17.13D12BN

88001325UM 1.17.13D25BN

8800133UM 1.17.13D03BN

8800136UM 1.17.13D06BN

88001612UM 1.17.16D12BN

88001625UM 1.17.16D25BN

8800163UM 1.17.16D03BN

8800166UM 1.17.16D06BN

8800166UMV 1.17.16D06BN/-V

89001312UM 1.08.13D12BN

89001325UM 1.08.13D25BN

8900133UM 1.08.13D03BN

8900136UM 1.08.13D06BN

89001612UM 1.08.16D12BN

89001625UM 1.08.16D25BN

89001625UMV 1.08.16D25BN/-V

8900163UM 1.08.16D03BN

8900166UM 1.08.16D06BN

8900812UM 1.08.08D12BN

8900825UM 1.08.08D25BN

890083UM 1.08.08D03BN

890086UM 1.08.08D06BN

9020412UM 1.07.04D12BN

9020412UMV 1.07.04D12BN/-V

9020425UM 1.07.04D25BN

9020425UMV 1.07.04D25BN/V

902043UM 1.07.04D03BN

902043UMV 1.07.04D03BN/-V

902046UM 1.07.04D06BN

902046UMV 1.07.04D06BN/-V

9020812UM 1.07.08D12BN

Manuf. code


HYDAC


9020812UMV 1.07.0812BN/-V

9020825UM 1.07.08D25BN

9020825UMV 1.07.08D25BN/-V

902083UM 1.07.08D03BN

902083UMV 1.07.08D03BN/-V

902086UM 1.07.08D06BN

902086UMV 1.07.08D06BN/-V

9021415UM 1.07.04D10BH

902142UM 1.07.04D03BH

902142UMV 1.07.04D03BH/-V

902182UM 1.07.08D03BH

902182UMV 1.07.08D03BH/-V

94001312UM 1.10.13D12BN

94001325UM 1.10.13D25BN

9400133UM 1.10.13D03BN

9400136UM 1.10.13D06BN

9400136UMV 1.10.13D06BN/-V

94002612UM 1.10.26D12BN

94002625UM 1.10.26D25BN

9400263UM 1.10.26D03BN

9400266UM 1.10.26D06BN

94003912UM 1.10.39D12BN

94003925UM 1.10.39D25BN

9400393UM 1.10.39D03BN

9400393UMV 1.10.39D03BN/-V

9400396UM 1.10.39D06BN

9400396UMV 1.10.39D06BN/-V

96001312UM 1.11.13D12BN

96001312UMV 1.11.13D12BN/-V

96001325UM 1.11.13D25BN

96001325UMV 1.11.13D25BN/-V

9600133UM 1.11.13D03BN

9600133UMV 1.11.13D03BN/-V

9600136UM 1.11.13D06BN

9600136UMV 1.11.13D06BN/-V

96001612UM 1.11.16D12BN

96001625UM 1.11.16D25BN

96001625UM 1.11.16D25BN/-V

9600163UM 1.11.16D03BN

9600163UMV 1.11.16D03BN/-V

9600166UM 1.11.16D06BN

9600166UMV 1.11.16D06BN/-V

9600412UM 1.11.04D12BN

9600412UMV 1.11.04D12BN/-V

9600425UM 1.11.04D25BN

9600425UMV 1.11.04D25BN/-V

960043UM 1.11.04D03BN

960043UMV 1.11.04D03BN/-V

960046UM 1.11.04D06BN

960046UMV 1.11.04D06BN/-V

9600812UM 1.11.08D12BN

9600812UMV 1.11.08D12BN/-V

9600825UM 1.11.08D25BN

9600825UMV 1.11.08D25BN/-V

960083UM 1.11.08D03BN

960083UMV 1.11.08D03BN/-V

960086UM 1.11.08D06BN

960086UMV 1.11.08D06BN/-V

96011215UM 1.11.13D10BH

9601132UM 1.11.13D03BH

9601132UMV 1.11.13D03BH/-V

960115UM 1.11.04D10BH

96011615UM 1.11.16D10BH

9601162UM 1.11.16D03BH

9601162UMV 1.11.16D03BH/-V

960142UM 1.11.04D03BH

960142UMV 1.11.04D03BH/-V

9601815UM 1.11.08D10BH

9601815UMV 1.11.08D10BH/-V

960182UM 1.11.08D03BH/-V

960182UMV 1.11.08D03BH/-V

96501612UM 1.18.16D12BN

96501625UM 1.18.16D25BN

9650163UM 1.18.16D03BN

9650163UMV 1.18.16D03BN/-V

9650166UM 1.18.16D06BN

Manuf. code


HYDAC


9650812UM 1.18.08D12BN

9650825UM 1.18.08D25BN

965083UM 1.18.08D03BN

965086UM 1.18.08D06BN

96511615UM 1.18.16D10BH

9651162UM 1.18.16D03BH

9651815UM 1.18.08D10BH

965182UM 1.18.08D03BH

965182UMV 1.18.08D03BH/-V

97001812UM 5.03.18D10BN

97001825UM 5.03.18D20BN

9700183UM 5.03.18D03BN

9700186UM 5.03.18D05BN

9700912UM 5.03.09D10BN

9700912UMV 5.03.09D10BN/-V

9700925UM 5.03.09D20BN

9700925UMV 5.03.09D20BN/-V

970093UM 5.03.09D03BN

970093UMV 5.03.09D03BN/-V

970096UM 5.03.09D05BN

970096UMV 5.03.09D05BN/-V

9800412UM 1.13.04D12BN

9800425UM 1.13.04D25BN

980043UM 1.13.04D03BN

980046UM 1.13.04D06BN

980046UMV 1.13.04D06BN/-V

9800812UM 1.13.08D12BN

9800825UM 1.13.08D25BN

980083UM 1.13.08D03BN

980083UMV 1.13.08D03BN/-V

980086UM 1.13.08D06BN

980086UMV 1.13.08D06BN/-V

9801415UM 1.13.04D10BH

9801425UM 1.13.04D17BH

980142UM 1.13.04D03BH

980142UMV 1.13.04D03BH/-V

9801815UM 1.13.08D10BH

9801815UMV 1.13.08D10BH/-V

9801825UM 1.13.08D17BH

9801825UMV 1.13.08D17BH/-V

980182UM 1.13.08D03BH

99011315UM 1.09.13D10BH

9901132UM 1.09.13D03BH

99012615UM 1.09.26D10BH

9901262UM 1.09.26D03BH

99013915UM 1.09.39D10BH

9901392UM

UCC

1.09.39D03BH

MX-1518-4-10 0080 MG 010 P

UC-1319 0015 S 125 W

UC-1320 0025 S 125 W

UC-1323 0100 S 125 W

UC-1324 0100 S 125 W

UC-1326 0180 S 125 W

UC-1457 0050 S 125 W

UC-5100 0015 S 125 W /-B0.2

UC-5101 0025 S 125 W /-B0.2

UC-5102 0050 S 125 W /-B0.2

UC-5103 0100 S 125 W /-B0.2

UC-5104 0100 S 125 W /-B0.2

UC-5105 0180 S 125 W /-B0.2

US-1500-4-10 0080MA010P

US-1500-4-25

Vickers

0080MA025P

575943 0160MA025P

575994 0180MA020BN

736474 0160MA020BN

941107 0160MA010P

V0411B2C03 1.06.08D03BN

V0411B2C05 1.06.08D06BN

V0411B2C10 1.06.08D12BN

V0411B2C20 1.06.08D25BN

V0411B5C03 1.06.16D03BN

V0411B5C05 1.06.16D06BN

V0411B5C10 1.06.16D12BN

V0411B5C20 1.06.16D25BN

Manuf. code

Vickers (continued)

HYDAC


V0411B8C03 1.06.39D03BN

V0411B8C05 1.06.39D06BN

V0411B8C10 1.06.39D12BN

V0411B8C20 1.06.39D25BN

V0411V2C05 1.06.08D06BN/-V

V0411V2C20 1.06.08D25BN/-V

V0411V5C03 1.06.16D03BN/-V

V0411V5C20 1.06.16D25BN/-V

V0411V8C03 1.06.39D03BN/-V

V0411V8C10 1.06.39D12BN/-V

V0621B2C10 1.11.08D12BN

V0621B2C20 1.11.08D25BN

V0621V2C05 1.11.08D06BN/-V

V0621V2C10 1.11.08D12BN/-V

V0621V2C20 1.11.08D25BN/-V

V2051B2C03 1.18.08D03BN

V2051B2C05 1.18.08D06BN

V2051B2C10 1.18.08D12BN

V2051B2C20 1.18.08D25BN

V2051B5C03 1.18.16D03BN

V2051B5C05 1.18.16D06BN

V2051B5C10 1.18.16D12BN

V2051B5C20 1.18.16D25BN

V2051V2C05 1.18.08D06BN/-V

V2051V5C03 1.18.16D03BN/-V

V2054B2C03 1.18.08D03BH

V2054B2C05 1.18.08D06BH

V2054B2C10 1.18.08D10BH

V2054B2C20 1.18.08D17BH

V2054B5C03 1.18.16D03BH

V2054B5C05 1.18.16D06BH

V2054B5C10 1.18.16D10BH

V2054B5C20 1.18.16D17BH

V2054V2C03 1.18.08D03BH/-V

V2681B4C03 1.17.13D03BN

V2681B4C05 1.17.13D06BN

V2681B4C10 1.17.13D12BN

V2681B4C20 1.17.13D25BN

V2681B5C03 1.17.16D03BN

V2681B5C05 1.17.16D06BN

V2681B5C10 1.17.16D12BN

V2681B5C20 1.17.16D25BN

V2681V5C05 1.17.16D06BN/-V

V2691B2C03 1.08.08D03BN

V2691B2C05 1.08.08D06BN

V2691B2C10 1.08.08D12BN

V2691B4C03 1.08.13D03BN

V2691B4C03 1.08.16D03BN

V2691B4C05 1.08.13D06BN

V2691B4C10 1.08.13D12BN

V2691B4C20 1.08.13D25BN

V2691B5C05 1.08.16D06BN

V2691B5C10 1.08.16D12BN

V2691B5C20 1.08.16D25BN

V3042B1C03 1.07.04D03BN

V3042B1C05 1.07.04D06BN

V3042B1C10 1.07.04D12BN

V3042B1C20 1.07.04D25BN

V3042B2C03 1.07.08D03BN

V3042B2C05 1.07.08D06BN

V3042B2C10 1.07.08D12BN

V3042B2C20 1.07.08D25BN

V3042V1C05 1.07.04D06BN/-V

V3042V1C10 1.07.04D12BN/-V

V3042V1C20 1.07.04D25BN/V

V3042V2C03 1.07.08D03BN/-V

V3042V2C05 1.07.08D06BN/-V

V3042V2C10 1.07.0812BN/-V

V3042V2C20 1.07.08D25BN/-V

V3043V1C03 1.07.04D03BN/-V

V3045B1C03 1.07.04D03BH

V3045B1C05 1.07.04D06BH

V3045B1C10 1.07.04D10BH

V3045B1C20 1.07.04D17BH

V3045B2C03 1.07.08D03BH

V3045B2C05 1.07.08D06BH

TRI - VIC

E 7.205.1/07.02

27

VIC - WIX

E 7.205.1/07.02

28

Manuf. code


HYDAC


V3045B2C10 1.07.08D10BH

V3045B2C20 1.07.08D17BH

V3045V1C03 1.07.04D03BH/-V

V3045V1C20 1.07.04D17BH/-V

V3045V2C03 1.07.08D03BH/-V

V3045V2C05 1.07.08D06BH/-V

V3045V2C10 1.07.08D10BH/-V

V4051B3C03 5.03.09D03BN

V4051B3C05 5.03.09D05BN

V4051B3C10 5.03.09D10BN

V4051B3C20 5.03.09D20BN

V4051V3C03 5.03.09D03BN/-V

V4051V3C05 5.03.09D05BN/-V

V4051V3C10 5.03.09D10BN/-V

V4051V3C20 5.03.09D20BN/-V

V4054B6H03 5.03.18D003BH

V4054B7H03 5.03.27D003BH

V6011B1C05 1.13.04D06BN

V6011B1C10 1.13.04D12BN

V6011B1C20 1.13.04D25BN

V6011B2C03 1.13.08D03BN

V6011B2C10 1.13.08D12BN

V6011B2C20 1.13.08D25BN

V6011V1C05 1.13.04D06BN/-V

V6011V2C03 1.13.08D03BN/-V

V6014B1C03 1.13.04D03BH

V6014B1C03 1.13.04D03BH/-V

V6014B1C05 1.13.04D06BH

V6014B1C10 1.13.04D10BH

V6014B1C20 1.13.04D17BH

V6014B2C03 1.13.08D03BH

V6014B2C05 1.13.08D06BH

V6014B2C10 1.13.08D10BH

V6014B2C20 1.13.08D17BH

V6014V2C05 1.13.08D06BN/-V

V6014V2C10 1.13.08D10BH/-V

V6014V2C20 1.13.08D17BH/-V

V6021B1C03 1.11.04D03BN

V6021B1C05 1.11.04D06BN

V6021B1C10 1.11.04D12BN

V6021B1C20 1.11.04D25BN

V6021B2C03 1.11.08D03BN

V6021B2C05 1.11.08D06BN

V6021B4C03 1.11.13D03BN

V6021B4C05 1.11.13D06BN

V6021B4C10 1.11.13D12BN

V6021B4C20 1.11.13D25BN

V6021B5C03 1.11.16D03BN

V6021B5C05 1.11.16D06BN

V6021B5C10 1.11.16D12BN

V6021B5C20 1.11.16D25BN

V6021V1C03 1.11.04D03BN/-V

V6021V1C05 1.11.04D06BN/-V

V6021V1C10 1.11.04D12BN/-V

V6021V1C20 1.11.04D25BN/-V

V6021V2C03 1.11.08D03BN/-V

V6021V4C03 1.11.13D03BN/-V

V6021V4C05 1.11.13D06BN/-V

V6021V4C10 1.11.13D12BN/-V

V6021V4C20 1.11.13D25BN/-V

V6021V5C03 1.11.16D03BN/-V

V6021V5C05 1.11.16D06BN/-V

V6021V5C20 1.11.16D25BN/-V

V6024B1C03 1.11.04D03BH

V6024B1C05 1.11.04D06BH

V6024B1C10 1.11.04D10BH

V6024B1C20 1.11.04D17BH

V6024B2C03 1.11.08D03BH

V6024B2C10 1.11.08D10BH

V6024B2C20 1.11.08D17BH

V6024B4C03 1.11.13D03BH

V6024B4C05 1.11.13D06BH

V6024B4C10 1.11.13D10BH

V6024B4C20 1.11.13D17BH

V6024B5C04 1.11.16D03BH

V6024B5C05 1.11.16D06BH

Manuf. code


HYDAC


V6024B5C10 1.11.16D10BH

V6024B5C20 1.11.16D17BH

V6024V1C03 1.11.04D03BH/-V

V6024V1C20 1.11.04D17BH/-V

V6024V2C03 1.11.08D03BH/-V

V6024V2C10 1.11.08D10BH/-V

V6024V2C20 1.11.08D17BH-V

V6024V4C03 1.11.13D03BH/-V

V6024V5C03 1.11.16D03BH/-V

V6024V5C20 1.11.16D17BH/-V

V602B2V05

Western

1.11.08D06BH

E0410B1U03 1.06.08D03BN

E0410B1U10 1.06.08D12BN

E0410B1U25 1.06.08D25BN

E0410B2U03 1.06.16D03BN

E0410B2U10 1.06.16D12BN

E0410B2U25 1.06.16D25BN

E0410B3U03 1.06.39D03BN

E0410B3U10 1.06.39D12BN

E0410B3U25 1.06.39D25BN

E0410V1U25 1.06.08D25BN/-V

E0410V2U03 1.06.16D03BN/-V

E0410V2U25 1.06.16D25BN/-V

E0410V3U03 1.06.39D03BN/-V

E0410V3U10 1.06.39D12BN/-V

E3041B-U03 1.07.04D03BN

E3041B-U10 1.07.04D12BN

E3041B-U25 1.07.04D25BN

E3041V-U03 1.07.04D03BN/-V

E3041V-U10 1.07.04D12BN/-V

E3041V-U25 1.07.04D25BN/V

E3042B-U03 1.07.04D03BH

E3042B-U10 1.07.04D10BH

E3042V-U03 1.07.04D03BH/-V

E3070B-U10 1.07.08D12BN

E3070B-U25 1.07.08D25BN

E3070B-Y03 1.07.08D03BN

E3070V-U03 1.07.08D03BN/-V

E3070V-U10 1.07.0812BN/-V

E3070V-U25 1.07.08D25BN/-V

E3071B-U03 1.07.08D03BH

E3071B-U25 1.07.08D17BH

E3071V-U03 1.07.08D03BH/-V

E3071V-U10 1.07.08D10BH/-V

E6020B1U03 1.11.04D03BN

E6020B1U10 1.11.04D12BN

E6020B1U25 1.11.04D25BN

E6020B2U03 1.11.08D03BN

E6020B2U25 1.11.08D12BN

E6020B2U25 1.11.08D25BN

E6020B3U03 1.11.13D03BN

E6020B3U10 1.11.13D12BN

E6020B3U20 1.11.13D25BN

E6020B4U03 1.11.16D03BN

E6020B4U10 1.11.16D12BN

E6020B4U25 1.11.16D25BN

E6020V1U03 1.11.04D03BN/-V

E6020V1U10 1.11.04D12BN/-V

E6020V1U25 1.11.04D25BN/-V

E6020V2U03 1.11.08D03BN/-V

E6020V2U10 1.11.08D12BN/-V

E6020V2U25 1.11.08D25BN/-V

E6020V3U03 1.11.13D03BN/-V

E6020V3U10 1.11.13D12BN/-V

E6020V3U25 1.11.13D25BN/-V

E6020V4U03 1.11.16D03BN/-V

E6020V4U25

Wix

1.11.16D25BN/-V

51407 5.03.09D10P

51756 0160MA003P

51758 0160MA025P

51759 0160MA010P

51849 0180MA003P

51860 0180MA010P

51861 0180MA025P

HYDAC


Wix (continued)

CW-1551-MP 0080MA010P

Zinga

AE10 0080MA010P

G0403HN 1.07.04D03BH

G0403LN 1.07.04D03BN

G0406LN 1.07.04D06BN

G0410HN 1.07.04D17BH

G0410LN 1.07.04D12BN

G0420LN 1.07.04D25BN

G0803HN 1.07.08D03BH

G0803LN 1.07.08D03BN

G0806LN 1.07.08D06BN

G0810HN 1.07.08D17BH

G0810LN 1.07.08D12BN

G0820LN 1.07.08D25BN

HE10 0090MA010P

HE10L 0095MA010P

HE3 0090MA003P

HE3L 0095MA003P

LE10 0180MA010P

LE10AB 0180MA010A

LE25 0180MA025P

LE3 0180MA003P

RE-10 5.03.09D10P

S0403HN 1.13.04D03BH

S0403LN 1.13.04D03BN

S0406LN 1.13.04D06BN

S0410HN 1.13.04D17BH

S0410LN 1.13.04D12BN

S0420LN 1.13.04D25BN

S0803HN 1.13.08D03BH

S0803LN 1.13.08D03BN

S0806LN 1.13.08D06BN

S0810HN 1.13.08D17BH

S0810LN 1.13.08D12BN

S0820LN 1.13.08D25BN

SE10 0160MA010P

SE25 0160MA025P

SE3 0160MA003P

W0403HN 1.11.04D03BH

W0403LN 1.11.04D03BN

W0406LN 1.11.04D06BN

W0410HN 1.11.04D10BH

W0410LN 1.11.04D12BN

W0420LN 1.11.04D25BN

W0803HN 1.11.08D03BH

W0803LN 1.11.08D03BN

W0806LN 1.11.08D06BN

W0810HN 1.11.08D17BH

W0810LN 1.11.08D12BN

W0820LN 1.11.08D25BN

W1303HN 1.11.13D03BH

W1303LN 1.11.13D03BN

W1306LN 1.11.13D06BN

W1310LN 1.11.13D12BN

W1310LN 1.11.13D17BH

W1320LN 1.11.13D25BN

W1603HN 1.11.16D03BH

W1606LN 1.11.16D06BN

W1610HN 1.11.16D17BH

W1610LN 1.11.16D12BN

W1620LN 1.11.16D25BN

Y0803 1.06.08D03BN

Y0806 1.06.08D06BN

Y0810 1.06.08D12BN

Y0820 1.06.08D25BN

Y1603 1.06.16D03BN

Y1606 1.06.16D06BN

Y1610 1.06.16D12BN

Y1620 1.06.16D25BN

Y3903 1.06.39D03BN

Y3906 1.06.39D06BN

Y3910 1.06.39D12BN

Y3920 1.06.39D25BN

HYDAC


WIX-ZIN

E 7.205.1/07.02

29

E 7.205.1/07.02

30

NOTES:

E 7.205.1/07.02

31

BETAFIT® filter elements - filtr, filtry, filtrace

Create successful ePaper yourself

Delete template?

Save as template?
