ADAPTER SYSTEMS & BICYCLE ACCESSORIES<br />
<strong>ww</strong>w.<strong>KLICKfix</strong>.<strong>com</strong>
The b<strong>es</strong>t way to develop bicycle acc<strong>es</strong>sori<strong>es</strong> is to sit on a bike yourself Phonebag and Quad adaptersystem<br />
New KLICKfi x Adapter range for our smartphone bag, that is quickly<br />
and securely fi xed to your bike via the KLICKfi x Quad adapter<br />
and can be removed by the simple pr<strong>es</strong>s of either of the two release<br />
buttons. The stainl<strong>es</strong>s steel band facilitat<strong>es</strong> fi xation to handlebars,<br />
stem or frame of any radius.<br />
The robust body is made of glasfi bre reinforced nylon and carri<strong>es</strong><br />
up to 1kg. The patented system works<br />
similar to a snap fastener and allows<br />
the positioning in 90° steps.<br />
Quad adapter included
ULTIMA<br />
Waterproof handlebar bag with fold-out <strong>com</strong>partment for navigation devic<strong>es</strong>. The front<br />
pocket with net material for air acc<strong>es</strong>s keeps smaller things within easy reach. The transparent<br />
map holder with Velcro strips is easily attached to the lid. An<br />
inner <strong>com</strong>partment with lining contains pouch<strong>es</strong> and a large<br />
net <strong>com</strong>partment inside the lid. With detachable carrying<br />
strap, adapter plate and KLICKfi x handlebar adapter.<br />
26x24x17cm<br />
8L, 1100g<br />
DAYPACK<br />
Time-proven, light touring handlebar bag, with<br />
KLICKfi x aluminium frame in the side sleev<strong>es</strong>.<br />
Large front pocket, <strong>com</strong>partment for documents,<br />
detachable rain hood and shoulder<br />
strap. The removable, transparent map holder<br />
is attached with snap fasteners. Extra <strong>com</strong>partment<br />
for raincover at the back. Bag can be<br />
folded after use.<br />
26 x 22x16cm<br />
8L, 650g<br />
4<br />
WATERPROOF<br />
DAYPACK BOX<br />
Touring handlebar bag, <strong>com</strong>plete with many<br />
practical featur<strong>es</strong>. Solid inner frame made of<br />
fi bre glass reinforced polyamide. Large front<br />
pocket, <strong>com</strong>partment for documents, adapter<br />
plate on back side, detachable rain hood and<br />
shoulder strap. The transparent map holder<br />
is also <strong>com</strong>pletely detachable able via snap<br />
fasteners.<br />
26x22x16cm<br />
8 L, 800g<br />
ALLROUNDER<br />
GPS-POUCH<br />
The <strong>com</strong>plete, universal handlebar bag has<br />
a solid inner frame and is made of doublelayered<br />
material with foam inside. It can be used<br />
for many purpos<strong>es</strong>, even as a camera bag. Large<br />
front pocket and various inner <strong>com</strong>partments<br />
with practical partitions.<br />
26 x 22 x16cm<br />
8L, 950g<br />
ALLROUNDER XS<br />
Small<strong>es</strong>t Allrounder model, stylish and superbly<br />
well-equipped. Main <strong>com</strong>partment with<br />
buckl<strong>es</strong>, front <strong>com</strong>partment with zipper, both<br />
with various inner pockets. Ideal for photographic<br />
or video cameras. Comfortable,<br />
detachable shoulder strap<br />
with padding at the<br />
shoulder. Thanks to its<br />
slim shape, this bag can<br />
also be used on curved<br />
handlebars.<br />
13x18x12cm<br />
1,5L, 350g<br />
ALLROUNDER MINI<br />
Compact, well-organized bag. With handle,<br />
detachable shoulder strap, main and front <strong>com</strong>partment<br />
with 2-way zipper, net- and mobile<br />
<strong>com</strong>partment at the sid<strong>es</strong>. Thanks to its slim<br />
shape, this bag can also be used on strongly<br />
curved handlebars. It can also be used with<br />
Extender on seat posts.<br />
15 x18 x12cm<br />
3,5 L, 450g<br />
bags & map<br />
SUNNY<br />
Lightweight, full-size map holder for every<br />
<strong>com</strong>mon map format. Its horizontal position<br />
minimiz<strong>es</strong> the impact of wind. The removable,<br />
transparent hood protects the map from dirt<br />
and rain. Sunny automatically locks into the<br />
handlebar adapter.<br />
27x 27cm<br />
200g<br />
ALLROUNDER TOURING<br />
The bigg<strong>es</strong>t handlebar bag model in our product range with solid inner frame. The only handlebar<br />
bag onto which a lightholder can be attached at the bottom. With several inner and outer <strong>com</strong>partments,<br />
shoulder-strap, raincover and refl ector, this model is extremely well equipped. Separate<br />
section for maps and cover inside the bag. The cover can be folded into 2 different formats and can<br />
be fi xed onto the ergonomically shaped oblique top in various positions. The included lightholder is<br />
easily supplied with 1-2 battery lights and fi xed within seconds on the adapter plate at the bottom<br />
of the bag.<br />
26 x 24x16cm 9L, 1100g<br />
LIGHT HOLDER<br />
Advantag<strong>es</strong> of the KLICKfi x Handlebar Adapter:<br />
� ��������� ������ ���� ������ �� ���������� ���������� ���������<br />
� ��������� �������� ����� �������� ��� ������� ���� �������<br />
downward on the handlebar. Maximum load up to 7 Kg.<br />
� ���������� �� ���� ����� ���� ����� ��� ������� ������������<br />
� ����� �� ��� ������ ����� �� ����������� �� ��� �������<br />
market.<br />
� ����� ���������� ���� ��� ��� ��� ������������<br />
� ���� ��������� ���� �����<br />
KLICKfi x TIP ! Clamps for oversize handlebars Ø 31,8 mm<br />
are available as acc<strong>es</strong>sory (regard page: special acc<strong>es</strong>sori<strong>es</strong> for<br />
handlebar adapter)<br />
Acc<strong>es</strong>sory includ<strong>es</strong> handlebar adapter<br />
ALUMINUM<br />
BRACKET<br />
KLICKfi x convenience for every<br />
handlebar bag with side sleev<strong>es</strong>.<br />
Made of 8mm carrier aluminium, very<br />
sturdy and lightweight. Black anodized surface.<br />
25,5 x 5 x 17cm<br />
80g
BAGGY MINI<br />
Our small<strong>es</strong>t and light<strong>es</strong>t handlebar bag with 2-way zipper. Thanks to<br />
its slim shape, this bag can be used even on strongly curved handlebars.<br />
20 x15x9cm<br />
2,5L, 300g<br />
BAGGY PLUS<br />
Bigg<strong>es</strong>t Baggy with larger capacity, carrying loop and additional net pockets<br />
at the sid<strong>es</strong>. Made of high-quality soft poly<strong>es</strong>ter. Extra inner <strong>com</strong>partment<br />
with zipper for valuabl<strong>es</strong>.<br />
27 x 22 x14cm<br />
8L, 400g<br />
BAGGY<br />
An economical, <strong>com</strong>pact handlebar bag for medium space requirements.<br />
Made of high-quality poly<strong>es</strong>ter, with reinforced shape. Main <strong>com</strong>partment<br />
can be widely opened. Extra <strong>com</strong>partment inside. Practical fabric carryingloop<br />
covers the two-way zipper.<br />
22 x 19 x12cm<br />
5L, 350g<br />
ALLEGRA<br />
Lots of elegant space. Ladi<strong>es</strong>‘ shoulder bag that easily „clicks“ onto<br />
the KLICKfi x handlebar adapter. Large main <strong>com</strong>partment and front<br />
<strong>com</strong>partment with fl at pouch inside and zipper. Net <strong>com</strong>partments on<br />
both sid<strong>es</strong>. Adjustable shoulder strap. With its slim shape, Allegra<br />
turns into a fashionable shoulder bag when you’re exploring the city<br />
without your bike.<br />
33 x 22x 14 cm<br />
5L, 600g<br />
6 7<br />
SMILE<br />
Slim handlebar bag with foam-supported shape. With raincover, shoulder<br />
strap and handle. Main <strong>com</strong>partment can be widely opened. Flat inner and<br />
large front <strong>com</strong>partment. Thanks to its slim shape, Smile can be used even<br />
on strongly curved handlebars.<br />
20x12x21cm<br />
3,5L, 500g<br />
FANCY<br />
Casual soft handlebar bag in a hip City outfi t. With key clip, inner and<br />
outer pouch, handl<strong>es</strong> and mobile <strong>com</strong>partment. The extra fl at adapter<br />
plate disappears in the backside what mak<strong>es</strong> the bag convenient to carry<br />
as shoulder bag.<br />
40x22x15cm<br />
6 L, 400g<br />
bags for the handlebar adaptersystem<br />
T BAG<br />
A smart and sportive variant of our succ<strong>es</strong>sful Shopper models. Extremely<br />
light, unique and useful for multiple purpos<strong>es</strong>. Main <strong>com</strong>partment with<br />
roll closure. Inner net <strong>com</strong>partment and soft interlining. Front <strong>com</strong>partment<br />
and side <strong>com</strong>partment for cell phone. Includ<strong>es</strong> handle, carrying<br />
strap, detachable rain cover an<br />
aluminum bracket. Also for Kid<br />
25x20 x16cm, max. 2Kg<br />
6L, 4
8<br />
SHOPPER FASHION<br />
A fr<strong>es</strong>h look, extensive useful featur<strong>es</strong> and several thoughtful details. The stable cover with middle<br />
zipper keeps contents safe and is <strong>com</strong>pletely detachable via snap fastener. The large front <strong>com</strong>partment<br />
and inner <strong>com</strong>partment with 2 pouch<strong>es</strong> and secret pocket keep everything well organized.<br />
During rainfall, you can pull the rain hood over the zip cover for additional protection.<br />
36x 25x 27cm<br />
21L, 1300g<br />
ALLEGRA FASHION<br />
Fr<strong>es</strong>h d<strong>es</strong>ign with premium featur<strong>es</strong>. The adapter plate hid<strong>es</strong> beneath a padded textile cover,<br />
transforming the functional handlebar bag into a chic handbag with carrying strap. The pouch<strong>es</strong>,<br />
front <strong>com</strong>partment with zipper and side cell phone <strong>com</strong>partment provide perfect storage space.<br />
25x23 x10cm<br />
4L, 650g<br />
MATCHPACK FASHION<br />
A reworking of the classic duffel bag – diverse and functional for recreation,<br />
shopping, or trips to the beach. An integrated steel frame supports up<br />
to 7 Kg. High use value through the variability of its volume and thoughtfully<br />
d<strong>es</strong>igned details: detachable mobile holder, large front pocket and<br />
zip <strong>com</strong>partments.<br />
You can use the matchpack on handlebar or seatpost. The shoulder strap<br />
can be connected to 3 differently positioned eyelets.<br />
31x46x28cm<br />
25L,1000g<br />
Fashion seri<strong>es</strong> for handlebar adaptersystem<br />
In our Fashion seri<strong>es</strong> some cute and functional details were added<br />
to the basic model. The different colours and orange pipings<br />
add a sportive fr<strong>es</strong>h look to all models. All bags on this page fi t<br />
perfectly to the handlebaradapter system.<br />
If you don‘t like to use the bag on the handlebar, you can use<br />
it alternatively on the seatpost in <strong>com</strong>bination with the Extender<br />
or Caddy. (e.g. ideal for foldable bik<strong>es</strong> or bicycl<strong>es</strong> without carrier.<br />
Acc<strong>es</strong>sory includ<strong>es</strong> handlebar adapter
SHOPPER COMFORT MINI<br />
Smaller size for small purchas<strong>es</strong> or the next short trip. Includ<strong>es</strong> inner and<br />
outer zip <strong>com</strong>partments for keys and wallet, as well as front refl ector, soft<br />
grip handl<strong>es</strong>, and detachable raincover.<br />
Perfect also on many children‘s bik<strong>es</strong>.<br />
32x23x24cm , 13L, 800g<br />
DOGGY<br />
A safe and <strong>com</strong>fortable transportation device for pets up to 7kg (max.<br />
5kg if bag is fi xed on Extender or on handlebaradapter for stem). The<br />
special raincover leav<strong>es</strong> plenty of air and light acc<strong>es</strong>s.<br />
All sid<strong>es</strong> may be closed <strong>com</strong>pletely and<br />
the cover stored in a side pocket. Equipped<br />
inside with cushion, adjustable leash and a<br />
buckle at the bottom of the bag. Large front<br />
<strong>com</strong>partment, net-<strong>com</strong>partments at both<br />
sid<strong>es</strong>, carrying handle and refl ector. The cover<br />
is <strong>com</strong>pletely detachable for easy opening and<br />
cleaning. All materials are washable.<br />
38 x 25/ 40 x 29cm<br />
24L, 1350g<br />
SHOPPER COMFORT<br />
Lots of space with special featur<strong>es</strong> for maximum <strong>com</strong>fort. Extra inner and<br />
outer zip <strong>com</strong>partments keep keys and purse safe yet within easy reach.<br />
With front refl ector, soft grip carrying handl<strong>es</strong>, chromium-plated steel<br />
bracket and detachable rain cover.<br />
38 x 25 x29cm, 24L, 1000g<br />
Doggy, Matchpack and Shopper for handlebar adaptersystem<br />
SHOPPER PRO<br />
Our popular Shopping basket with additional<br />
drawstring cover. When needed you can close<br />
the Shopper in seconds to keep contents protected<br />
and safe from jumping out.<br />
10 11<br />
MATCHPACK<br />
For sport and leisure. With drawstring, adjustable<br />
shoulder strap and light holder. Two separate<br />
zipper <strong>com</strong>partment<br />
your things organized.<br />
detachable chromium<br />
me for KLICKfi x Extend<br />
or handlebar adapte<br />
Shoulder strap can be attached<br />
at various spots.<br />
max.7Kg.<br />
31x46x 24cm<br />
24L, 900g<br />
SHOPPER<br />
A fun alternative to the ordinary handlebar basket.<br />
The spacious bag can be folded after use.<br />
Made of robust material, with reinforced bottom<br />
and wide carrying straps.<br />
38 x25x29cm,<br />
24L, 950g<br />
38 x25x 29cm<br />
24L, 950g<br />
From Doggy to Shopping Bag – simply „klick“ on diverse acc<strong>es</strong>sori<strong>es</strong><br />
on your bike and go ! All acc<strong>es</strong>sori<strong>es</strong> can be <strong>com</strong>fortably<br />
removed by a pr<strong>es</strong>s of the red button. The patented security cable<br />
ensur<strong>es</strong> that the adapter remains securely fi xed and do<strong>es</strong> not lean<br />
downwards. The KLICKfi x handlebar adapter is also available with<br />
lock or handlebars Ø 31,8 mm.<br />
KLICKfi x TIP !<br />
In <strong>com</strong>bination with the handlebar adapter the<br />
solid steel bracket of all shopper carri<strong>es</strong> reliably a maximum load<br />
of 7kg and prevents sensitive content from<br />
being crushed – so even a bunch of fl owers, a<br />
pie or your little pets will arrive savely.<br />
SHOPPER PLUS<br />
The traditional Shopper, additionally equipped<br />
with refl ector and rain cover.<br />
38x25x29cm<br />
24 L, 950g
le, is fi xed in seconds with the extra fl at ad-<br />
aken out for a walk. The adjustable shoul-<br />
agnetic closure and the practical interior are<br />
daily routine or everything that mak<strong>es</strong> fun.<br />
x.<br />
fl eur black marigold mocha dots<br />
functionality. Fashionable and casual with<br />
pe. Mak<strong>es</strong> a good impr<strong>es</strong>sion anywhere,<br />
ag or carried on foot. Everything fi nds its<br />
pper and inside <strong>com</strong>partments. Thanks to<br />
ax.<br />
extra fl at adapterplate, the bag is easily<br />
fl eur black marigold mocha dots<br />
Reisenthel shoulder bags for handlebar adaptersystem<br />
red dots black<br />
red dots black<br />
We use the extra fl a adapterplate for the Fun- &<br />
Stylebag The bag’s more technical featur<strong>es</strong> remain<br />
hidden: the adapter plate which snaps into<br />
the Klickfi x handlebar adapter is integrated into the<br />
bag’s back side.<br />
handlebar adapter included<br />
13
on front side, inner <strong>com</strong>partment with zipper,<br />
rawstring opening and detachable multi-pur-<br />
rious d<strong>es</strong>igns; made of tough poly<strong>es</strong>ter. Practi-<br />
p. The basket is foldable when not in daily use.<br />
frame is <strong>com</strong>bined with KLICKfi x coupling for<br />
carri<strong>es</strong> up to 5 Kg.<br />
35x28 x 26cm, 15L, 800g,<br />
Bikebaskets for handlebar adapter system<br />
����������� ������� �� ��� ������ ������� ��� ������� ����������<br />
textile basket has a unique aluminium frame with KLICKfi x coupling.<br />
Even taken on foot, the new Bikebasket is a fi ne shopping<br />
<strong>com</strong>panion – even more attractive than many handbags.<br />
KLICKfi x TIP ! The adapter is not included with the bikebasket.<br />
Choose the type of handlebar adapter that is b<strong>es</strong>t suited to your<br />
bike, e.g. the handlebar adapter for stem, Caddy, handlebar adapter<br />
for head tube or Extender. The handlebar-adapter is also<br />
available as oversize version for handlebars Ø 31,8mm.<br />
rasterdots blue barock navy fl ora silver folklore black mocha dots marigold fl eur black<br />
raster dots mocha barock sand red<br />
crystals light grey crystals lime green bubbl<strong>es</strong> anthrazit bubbl<strong>es</strong> carrot black grafi c<br />
15
lack EF<br />
brown<br />
titan<br />
STRUCTURA<br />
Simply beautiful – our new plaited handlebar baskets, made of<br />
weatherproof wide or fi ne plastic straps. Continuously adjustable<br />
adapterplate at the rear side.<br />
35 x 26 x 25cm<br />
16L, 1400g<br />
SALEEN HANDLEBAR BASKET<br />
Traditional d<strong>es</strong>ign with modern material. The robust, polypropylenebased<br />
Saleen-fi bre is woven by hand according to mod<strong>es</strong> of basketmaking.<br />
Feels much like natural fi bre, yet is set apart by several<br />
advantageous qualiti<strong>es</strong>: it is r<strong>es</strong>istant to weather, UV-rays and will<br />
not turn grey or be<strong>com</strong>e brittle. The solid metal frame fi ts to the<br />
KLICKfi x handlebar adapter.<br />
34x25x19cm,16L, 1100g<br />
STANDARD BASKET<br />
Oval wire basket with handle and integrated<br />
coupling for KLICKfi x handlebar adapter. With<br />
handle and coated surface. Thanks to a higher<br />
basket position, this basket leav<strong>es</strong> enough space<br />
for your light.<br />
41x19x30cm<br />
16L, 900g<br />
WICKER BASKET<br />
This natural wicker basket is not heavier than<br />
wire baskets of <strong>com</strong>parable size. Its integrated<br />
chrome bracket is directly „clicked“ onto the<br />
KLICKfi x handlebar adapter system.<br />
40 x 31x 30cm,<br />
18L, 1250g<br />
baskets for handlebar adaptersystem<br />
LAMELLO MINI<br />
Smaller and therefore extremely stable, weather-r<strong>es</strong>istant<br />
basket made of polypropylene<br />
material. Comfortable handle and continuously<br />
adjustable adapter plate. Also perfect for kids‘<br />
bik<strong>es</strong>.<br />
32 x 24 x 22cm<br />
12L, 850g<br />
ALUMINO<br />
Solid, lightweight and antirust – even in<br />
rough sea climate. Handlebar basket made of<br />
aluminum. Stable handle with soft grip. You can<br />
hang the basket in two different heights into<br />
the adapter. Silver or black.<br />
40x 25x 26cm<br />
16L, 950g<br />
LAMELLO<br />
Weather r<strong>es</strong>istant basket also for made out<br />
of polypropylene material. With <strong>com</strong>fortable<br />
handle and continuously adjustable adapter<br />
plate.<br />
39x28x28cm<br />
18L, 950g<br />
ALUMINO FIX<br />
For all who like a light basket permanently<br />
fi xed on the bike (2 heights, Ø 22-<br />
26mm). The patented anchoring cable,<br />
holds the basket in a fi xed, stable position<br />
up to 7Kg. No additional<br />
support to fork is required.<br />
17
BaB‘s Display<br />
BAB‘S<br />
Small bag – big difference. Acc<strong>es</strong>sori<strong>es</strong> bag<br />
simply to clip onto the basket rim. A practical<br />
addition to wide and closem<strong>es</strong>h<br />
handlebar baskets. No<br />
more loose items bouncing<br />
in the basket. All important<br />
items kept right at hand. Orderly<br />
interior with keyring. A security strap<br />
helps prevent theft and can easily be changed<br />
to the alternative function as shoulder<br />
bag. On baskets or shoulders – BaB‘s always<br />
looks good !<br />
18,5 x14 x 4cm, 140g, 1L<br />
FIX BASKET<br />
For everyone who prefers a permanently<br />
mounted basket. The patented anchoring<br />
cable holds acc<strong>es</strong>sori<strong>es</strong> in<br />
a fi xed, stable position up<br />
to 7kg. No additional support<br />
to fork or headset is<br />
required. The basket can<br />
be mounted at different heights. Since the<br />
basket is without KLICKfi x function, it has<br />
no handle.<br />
18<br />
navy<br />
grey<br />
UNI BASKET WITH LIGHT CLIP<br />
Classic high shaped m<strong>es</strong>hed basket with light<br />
clip. The adapter plate can be mounted for<br />
three different basket heights. The light holder<br />
allows you to mount <strong>com</strong>mon battery<br />
lights on the front side of the basket rim. That<br />
light will not be obstructed.<br />
35x26 x25cm<br />
16L, 1000g<br />
olive<br />
beige<br />
rust<br />
black<br />
LIGHT CLIP<br />
Small but very practical plastic clip to fi x any<br />
frontlight on a basket rim. Clever solution if<br />
the light would be covered by the basket or<br />
if there is a lack of space. Simple retrofi t on<br />
wire- or m<strong>es</strong>hed baskets.<br />
Ø 24mm, 25g<br />
M<strong>es</strong>hed basket with elegant handle. The<br />
height-position of this basket is continu-<br />
����� ����������� A cylinder-shaped light<br />
holder allows you to mount <strong>com</strong>mon battery<br />
lights on the front side. The light clip clicks<br />
onto the front side of the basket rim.<br />
35x26 x25cm<br />
16L, 1350g<br />
BaB‘s, light clips and m<strong>es</strong>hed baskets for handlebar adaptersystem<br />
Small<strong>es</strong>t version of the m<strong>es</strong>hed handlebar bas-<br />
ket, with coated surface. Comfortable handle<br />
and special adapter plate for adjustable height.<br />
Especiall<br />
fi ts onto Ext<br />
29x19 x 20cm<br />
10L, 900g<br />
OVAL PLUS<br />
M<strong>es</strong>hed, oval-shaped basket with <strong>es</strong>pecially<br />
large volume. Comfortable integrated handle<br />
with a catch at 90°. The adapter plate can be<br />
adjusted to allow for 3 different basket heights.<br />
36x27x25cm<br />
18 L, 1250g<br />
OVAL PLUS<br />
M<strong>es</strong>hed, oval-shaped basket with <strong>es</strong>pecially large<br />
volume. Comfortable integrated handle with<br />
a catch at 90°. The adapter plate can be adjusted<br />
to allow for 3 different basket heights.<br />
40 x19x29cm<br />
16L, 1000g<br />
OVAL PLUS EF<br />
Large volume, extra-fi nely m<strong>es</strong>hed basket with<br />
elegant handle. The adapter plate can be adjusted<br />
to allow for 3 different basket heights.<br />
36 x 27x25cm<br />
18L, 1250g<br />
The handlebar adapter quickly transforms your touring bike into<br />
a city bike with shopping basket. Even with heavy loads up to<br />
7 kg, the patented security cable ensur<strong>es</strong> that the adapter is fi xed<br />
securely and do<strong>es</strong> not twist downward. If you wish to leave your<br />
basket safely on your bike, choose the handlebar adapter with<br />
lock ! Please observe the decreased maximum load (max. 5kg) that<br />
appli<strong>es</strong> to Extender and the adapter for stem/head tube.<br />
KLICKfi x TIP !<br />
Also practical in <strong>com</strong>bination with our handlebar<br />
baskets are our little BaB‘s bags<br />
for the basket rim or the light<br />
clip.<br />
UNI BASKET<br />
Most popular m<strong>es</strong>hed basket with<br />
classic high shape and adjustable adapterplate<br />
for handlebaradapter.<br />
35x26x25cm<br />
16L, 1000g<br />
UNI BASKET PLUS<br />
white<br />
silver<br />
black<br />
anthracite<br />
Compact m<strong>es</strong>hed handlebar basket with extended<br />
volume given by the rounded shape. With<br />
<strong>com</strong>fortable handle and small elegant hing<strong>es</strong>.<br />
The adapter plate can be mounted in 4 different<br />
heights to leave enough space for your light.<br />
35 x 26 x 27cm<br />
18L, 1100g
FREEPACK SPORT<br />
Say goodbye to riding with a sweaty back. This<br />
sportive click-on backpack is ideal for mountain<br />
bik<strong>es</strong> and all bik<strong>es</strong> without carrier in <strong>com</strong>bination<br />
with Extender. The adapter plate allows for<br />
a slanting backpack position that giv<strong>es</strong> the biker<br />
more space on the saddle. It do<strong>es</strong> not cause<br />
dis<strong>com</strong>fort when the bag is on your back.<br />
With several zipper- and net-<strong>com</strong>partments,<br />
backlight holder, raincover and extra <strong>com</strong>partment<br />
for helmet, max. 5Kg.<br />
30x40x20cm<br />
24L, 1200g<br />
FREEPACK CITY<br />
The every-day <strong>com</strong>panion for shopping, school.<br />
Outer and inner <strong>com</strong>partments with zipper, net<br />
side <strong>com</strong>partments, seperate inner <strong>com</strong>partment<br />
for valuabl<strong>es</strong>, light holder, and adjustable<br />
shoulder straps with integrated cell phone bag.<br />
No more sweaty back while biking! The fl at adapter<br />
plate allows a slanting backpack position<br />
to give the biker more space on the saddle and<br />
do<strong>es</strong> not cause dis<strong>com</strong>fort when being carried<br />
on the back, max. 5Kg.<br />
26x38x15cm<br />
18 L, 1100 g<br />
FREEPACK META<br />
A real all-rounder of excellent quality with many<br />
practical featur<strong>es</strong>: Adjustable helmet holder,<br />
hidden in an extra <strong>com</strong>partment, yellow<br />
raincover, net <strong>com</strong>partments on both sid<strong>es</strong>,<br />
several inner <strong>com</strong>partments, detachable key<br />
ring and light holder. A removable, chromiumplated<br />
frame transfers the backpack‘s weight<br />
onto the KLICKfi x adapter, max. 5Kg.<br />
Meta I: 27x 40x22cm, 21L, 1300 g<br />
Meta II: 30 x 45x22cm, 26L, 1450g<br />
backpacks and vario rack for handlebar adaptersystem<br />
20 21<br />
VARIO RACK<br />
Multifunctional nal rack for transportation of o bags, laptop cas<strong>es</strong> and<br />
backpacks on n the bike. Compatible to the KLICKfi KL x handlebar system. In<br />
seconds removable movable when not needed. Extremely Extreme light weight aluminium<br />
d<strong>es</strong>ign. The e Vario Rack can be positioned in 2 different heights on the<br />
adapter. The he straps poss<strong>es</strong>s a refl ector and can be secured easily by one<br />
central closure.Clip-on-hooks sure.Clip-on-hooks allow easy variation of straps. The d<strong>es</strong>ign of<br />
hooks is adapted dapted for all T-crossing of the skeleton rack rac structure.<br />
21x32 x17cm, 7cm, 450g, 7Kg mmax.<br />
With Extender, acc<strong>es</strong>sori<strong>es</strong> can be moved from the front of the bike<br />
to the seat post in the back. Your vision remains unobstructed, the<br />
steering is not infl uenced, and more space remains on the handlebar<br />
for your speedometer, bell or light. Especially for backpacks,<br />
we re<strong>com</strong>mend using the handlebar adapter in <strong>com</strong>bination with<br />
Extender on the seat post (max. 5kg).<br />
KLICKfi x TIP ! Depending on the amount of<br />
space on your bike, the backpacks can also be<br />
used in <strong>com</strong>bination with other variants of the<br />
adapter, such as Caddy or handlebar adapter<br />
for head tube.
HEAD TUBE<br />
STANDARD STANDARD + LOCK<br />
OVERSIZE STANDARD + OVERSIZE<br />
HANDLEBAR ADAPTER<br />
HANDLEBAR ADAPTER<br />
HANDLEBAR ADAPTER<br />
HANDLEBAR ADAPTER<br />
The basic model of the adapter<br />
with patented security cable<br />
for all standard handlebars<br />
Ø 22-26mm, max. 7Kg.<br />
FOR HANDLEBAR ADAPTER<br />
OVERSIZE CLAMPS Ø 31,8mm<br />
FOR HANDLEBAR ADAPTER FOR HANDLEBAR ADAPTER<br />
DISTANCE SET 43mm<br />
DISTANCE SET 5mm<br />
FOR HEAD TUBE FOR HEAD TUBE<br />
FOR STEM FOR STEM +LOCK FOR VERTICAL TUBES FOR SEATPOST FOR SEATPOST FOR HANDLEBAR ADAPTER<br />
HANDLEBARADAPTER<br />
HANDLEBAR ADAPTER<br />
HANDLEBAR ADAPTER<br />
HANDLEBAR ADAPTER<br />
HANDLEBAR ADAPTER CADDY EXTENDER<br />
EXTENDER SOLO<br />
MULTI CLIP PLUS<br />
Made to be <strong>com</strong>bined with the<br />
KLICKfi x handlebar adapter. Only<br />
for bik<strong>es</strong> with special head tube<br />
threads (depth gauge 16/30mm).<br />
Many Dahon bik<strong>es</strong><br />
<strong>com</strong>e prepared for<br />
this adapter, max.<br />
5Kg.<br />
If you wish to leave your acc<strong>es</strong>sori<strong>es</strong><br />
safely on your bike, choose the<br />
KLICKfi x handlebar adapter with<br />
lock ! With patented security cable<br />
for all standard handlebars Ø 22-<br />
26mm, max. 7Kg.<br />
Only for bik<strong>es</strong> with integrated<br />
threads (depth gauge 30mm).<br />
The steering remains <strong>com</strong>pletely independent<br />
of acc<strong>es</strong>sory weight. Its<br />
shape increas<strong>es</strong><br />
the distance to<br />
the front wheel,<br />
that many bags<br />
and baskets can<br />
be used even on small fram<strong>es</strong>, max.<br />
5 Kg.<br />
STANDARD<br />
Additionally to the Standard model<br />
you get our handlebar adapter also<br />
with 2 bigger clamps for oversize<br />
handlebars Ø 31,8mm, max. 7Kg.<br />
Allows the KLICKfi x handlebar adapter<br />
to be mounted on stems Ø<br />
22,2-25,4mm. This mounting position<br />
allows the adapter to remain<br />
independent of the inclination of<br />
adjustable stems. It also leav<strong>es</strong> more<br />
space on the handlebar for your bell,<br />
speedometer or bike light, max. 5Kg.<br />
specialti<strong>es</strong>, variant<strong>es</strong> and acc<strong>es</strong>sori<strong>es</strong> for handlebar adaptersystem<br />
CADDY<br />
Handlebaradapter with 2 standard<br />
clamps Ø 22-26mm and 2 oversize<br />
clamps for Ø 31,8mm,<br />
max. 7Kg.<br />
The basic model for stem with additional<br />
lock. The bracket can be<br />
turned upside down, permitting a<br />
second possible mounting position,<br />
lower by 70mm,<br />
according to suit<br />
the frame size and<br />
type of your bike,<br />
max. 5Kg.<br />
KLICKfi x TIP ! The variable handlebar adapter system offers different<br />
typ<strong>es</strong> of sockets that allow you to mount the adapter elsewhere<br />
on your bike. So you can use the big acc<strong>es</strong>sory range either<br />
on handlebar, seat post, stem head tube or vertical tub<strong>es</strong>. Clamps<br />
and distance sets allow for the use on many diameters and shap<strong>es</strong>.<br />
Variant of the KLICKfi x handlebar<br />
adapter for mounting on vertical<br />
tub<strong>es</strong> Ø 25-36mm. Robust<br />
body of glass fi bre reinforced polyamide.<br />
Especially well suited for<br />
foldable bik<strong>es</strong>, scooters, golf carts,<br />
wheelchairs, etc.,max. 7Kg.<br />
The Extender allows you to use all<br />
handlebar acc<strong>es</strong>sori<strong>es</strong> like bags, backpacks<br />
and baskets on the seat post.<br />
Easy mounting with stainl<strong>es</strong>s steel<br />
strap on seat posts<br />
of Ø 25-32mm,<br />
the adapter head<br />
is included, max.<br />
5Kg.<br />
Light<br />
cycle<strong>com</strong>puter<br />
GPS or mapholder<br />
FOR HANDLEBAR ADAPTER<br />
MULTI CLIP<br />
22 23<br />
EXTENDER<br />
For mounting the KLICKfi x handlebar<br />
adapter onto oversized handlebars<br />
extra wide clamps are available<br />
as acc<strong>es</strong>sory.<br />
Ensur<strong>es</strong> that the adapter fi ts to<br />
curved handlebars and creat<strong>es</strong> extra<br />
space for brake cabl<strong>es</strong>. The integrated<br />
adjustable inclination is practical<br />
for adjustable stems.<br />
STEM<br />
Slightly increas<strong>es</strong> the distance to<br />
the handlebar when more space is<br />
needed.<br />
The bracket for seatposts is also<br />
available without adapter head.<br />
Easy mounting with stainl<strong>es</strong>s steel<br />
strap on seat posts Ø 25-32mm.<br />
max. 5Kg.<br />
(Oversize clamp Ø 32-36mm available<br />
as acc<strong>es</strong>sory).<br />
Creat<strong>es</strong> extra space (40mm, Ø<br />
26mm) for cycle <strong>com</strong>puter, light,<br />
GPS or mapholder. The clip can be<br />
easily mounted and removed without<br />
the need for tools.<br />
On the MultiClip Plus you can add<br />
even more space on both sid<strong>es</strong> up<br />
to 75 /115mm (extensions Ø 23mm)<br />
e.g. for further acc<strong>es</strong>sori<strong>es</strong>. Also<br />
possible in <strong>com</strong>bination with the<br />
Distance-Set.
Waterproof bag with quickrelease system for seatpost mounting giv<strong>es</strong> the<br />
rider good protection against mud and water from the rear wheel and<br />
keeps things inside dry. The smart lid d<strong>es</strong>ign allows easy acc<strong>es</strong>s and fol-<br />
ding. The bag is <strong>com</strong>pletely removable from the alloy frame, inner lining<br />
prevent<br />
and refl<br />
15 x13 x<br />
4L, 470<br />
CONTOUR MINI<br />
The <strong>com</strong>pact, expandable bag with robust, detachable glass fi bre rein-<br />
forced bracket allows even hard MTB action. Expandable main <strong>com</strong>partment.<br />
Separate zipper-<strong>com</strong>partment on top. With carrying handle, light<br />
holder and refl ector.<br />
10x15/20x22cm<br />
2-2,5L, 250 g<br />
CONTOURA<br />
The <strong>com</strong>pact, expandable bag with robust, detachable, glass fi bre reinforced<br />
bracket. Especially well-suited for hard MTB action, thanks to its<br />
<strong>com</strong>pact shape. Spacious main <strong>com</strong>partment, net-<strong>com</strong>partments on both<br />
sid<strong>es</strong>, elastic string on top. With carrying handle, light holder and refl ector.<br />
Bottom made of easy-to-clean vinyl material.<br />
12 x15 x 22cm<br />
2L, 230g<br />
A simple and lightweight model, often used on racing bik<strong>es</strong>. Aerodynamic<br />
d<strong>es</strong>ign. One main <strong>com</strong>partment with central zipper and refl ector. The bag<br />
can be unbuttoned and <strong>com</strong>pletely detached from the aluminium frame<br />
for cleaning.<br />
24 25<br />
12x14x26cm<br />
3,5L, 380g<br />
CONTOUR MUDGUARD<br />
Medium-sized contour model with additional inner <strong>com</strong>partment for<br />
change or key. Flip top with covered zipper. Washable vinyl bottom. With<br />
sturdy, detachable aluminum frame, light holder and refl ector.<br />
16 x 17 x 27cm<br />
4,5L, 400g<br />
bags with Contour adapter<br />
This <strong>com</strong>pact adapter version fi ts all <strong>com</strong>mon seat posts, so that<br />
��� ��� ����� ��� ������� ��� ���������� ���� �� ����� �������<br />
carrier. When you ride without the bag, only the tiny adapter remains<br />
on the bike. Com<strong>es</strong> with two clamps for Ø 25-28 and for Ø<br />
28-32mm, 2Kg maximum load.<br />
KLICKfi x TIP !<br />
Contour bags were developed for bik<strong>es</strong> without<br />
carrier. They provide plenty of space for your raincoat, tools or<br />
food and offer good protection against dirt and water.<br />
CONTOUR SF<br />
Even when the saddle position is low, suffi cient space remains<br />
between this bag and the back tire, making this bag ideal for small<br />
fram<strong>es</strong>. Main <strong>com</strong>partment with covered middle zipper. Additional<br />
zipper <strong>com</strong>partments for small things on both sid<strong>es</strong>. Refl ector and<br />
light holder on rear side. Bottom made of easy-to-clean vinyl material.<br />
15 x14 x 28 c<br />
4L, 450g<br />
CONTOUR MAGNUM<br />
Top model of the Contour range for seatpost mounting. Elongated<br />
shape provid<strong>es</strong> excellent protection against mud and water. Inner<br />
<strong>com</strong>partment, two side <strong>com</strong>partments, lid with net and extra <strong>com</strong>partment.<br />
Back side and bottom made of easy-to-clean vinyl material.<br />
With practical two-way zipper, light holder and refl ector aluminium.<br />
17x22x32cm,<br />
6L, 500g<br />
Oversize clamp Ø 32-36mm<br />
available as an acc<strong>es</strong>sory.<br />
Contour adapter included.
CONTOUR MAX SPORT<br />
Sportive look and plenty of space. Roomy main <strong>com</strong>partment, side bags<br />
with additional puch<strong>es</strong>. Small bag at the rear side, refl ector and lightholder.<br />
Elastic string for raincoat on the top. Bottom made of easy-to-clean<br />
vinyl material.<br />
28x22x38cm<br />
10L, 880g<br />
CONTOUR MAX TOURING<br />
Elegant, <strong>com</strong>fortable bag for day-trips. Large side bags with zipper and<br />
additional <strong>com</strong>partments, on one side with net. Main <strong>com</strong>partment with<br />
2-way-zipper, small <strong>com</strong>partment for valuabl<strong>es</strong> on inner side of cover.<br />
Bottom made of easy-to-clean vinyl material. Rear side with refl ector and<br />
lightholder.<br />
28 x 25 x 35cm<br />
9L, 780g<br />
bags with Contour Max adapter<br />
The Contour Max Adapter extends the succ<strong>es</strong>sful KLICKfi x System<br />
to include mounting possibiliti<strong>es</strong> on seat posts. Can be<br />
mounted on all seatposts Ø 25-32mm. The twin aluminum frame<br />
provid<strong>es</strong> strong support for the bag. Contour and Contour<br />
Max Adapter acc<strong>es</strong>sori<strong>es</strong> are not <strong>com</strong>patible.<br />
KLICKfi x TIP ! Supported by the twin aluminium frame,<br />
Contour Max bags are able to bear a greater amount of<br />
weight (up to 3 kg) than regular Contour bags. Thanks to<br />
their slim shape, they also provide more space and <strong>es</strong>pecially<br />
good protection against dirt and splash water. Oversize<br />
clamp Ø 32-36mm available as an acc<strong>es</strong>sory.<br />
Acc<strong>es</strong>sory includ<strong>es</strong> Contour Max adapter<br />
27
RACKPACK 1<br />
Bag with foam support on all sid<strong>es</strong>. Main <strong>com</strong>partment with a double<br />
zipper and an additional top fl ap under which you can store jackets or<br />
pullovers. With refl ector, lightholder, handle, raincover, and foldable bottle<br />
<strong>com</strong>partment on rear side.<br />
28x22x35cm<br />
750g, 10L<br />
RACKPACK 1 PLUS<br />
Like Rackpack 1 yet with much more additional space thanks to 2 large<br />
fold-out sidepockets, on one side with m<strong>es</strong>h. With refl ector, lightholder,<br />
handle and raincover. Pull the strap for easy release! Only for carriers<br />
with side frame (Freerack Plus, Rackpacker).<br />
28 x 28/48 x35cm<br />
1000g, 13 -18L<br />
28<br />
RACKPACK 2<br />
Simple, functional bag in the classic R&K d<strong>es</strong>ign, with bottle <strong>com</strong>partment<br />
on the rear side. With refl ector, lightholder, handle and raincover.<br />
24 x 23 x35cm<br />
750g, 10L<br />
RACKPACK 2 PLUS<br />
Like Rackpack 2, but with two additional fold-out pockets (one side with<br />
m<strong>es</strong>h), lid with 2 net pockets. Handle works also as tension belt for fi xation<br />
of jacket. With refl ector, lightholder, handle, rain cover and shoulderbelt.<br />
Only for carriers with side support (Freerack Plus, Rackpacker).<br />
30x 23/43 x35cm<br />
900g, 12-16L<br />
FREERACK<br />
bags with Rackpack adapter & carriers<br />
Self-supporting aluminium rack for seat posts Ø 25-32mm. Secure and<br />
easy mounting with 4 srews. Especially d<strong>es</strong>igned for <strong>com</strong>bination with<br />
the new KLICKfi x „Rackpacks“ (the dimensions of the rack‘s central bar<br />
exactly corr<strong>es</strong>pond to the bottom coupling of the Rackpacks). Includ<strong>es</strong><br />
rear-side plate for refl ector or backlight. Can also be used for baskets<br />
(watch max. load).<br />
12x13x 47cm, 580g<br />
max. 10Kg<br />
FREERACK PLUS<br />
The same as Freerack, but with additional side supports that make it <strong>es</strong>pecially<br />
well suited for bags with extendable side pockets (e.g. Rackpack1<br />
Plus, Rackpack 2 Plus). Can also be used for small side panniers.<br />
12 x 30 x 47cm, 740g<br />
max. 10 Kg<br />
All Rackpack models are equipped with the Rackpack<br />
adapter at the bottom. Simply slide the bag onto the carrier<br />
and it will lock in automatically and securely. Just pull the<br />
strap for easy release!<br />
All bags with Rackpack adapter can also be used on the Tubus carriers<br />
Cosmo, Locc and Cargo.<br />
RACKPACKER<br />
Aluminium rack for 26“ and 28“ bik<strong>es</strong> with corr<strong>es</strong>ponding integrated<br />
frame threads. Secure and easy mounting with 4 srews. Especially d<strong>es</strong>igned<br />
for <strong>com</strong>bination with bags with Rackpack adapter. Includ<strong>es</strong> rear-side<br />
plate for refl ector or backlight. Good side supports for bags with fold-out<br />
pockets. Can also be used with all panniers with KLICKfi x rail or as<br />
platform for the KLICKfi x carrier adapter.<br />
11,8 x 35,5cm, 880g<br />
max. 25 Kg<br />
Acc<strong>es</strong>sory includ<strong>es</strong> Rackpack adapter
for RACKTIME<br />
RACKPACK 1<br />
Bag with foam support on all sid<strong>es</strong>. Main <strong>com</strong>partment<br />
with a double zipper and an additional<br />
top fl ap under which you can store jackets<br />
or pullovers. With refl ector, lightholder, handle,<br />
raincover, and foldable bottle <strong>com</strong>partment on<br />
rear side.<br />
28x22x35cm<br />
750g, 10L<br />
for RACKTIME<br />
RACKPACK 1 PLUS<br />
Like Rackpack 1 yet with much more additional<br />
space thanks to 2 large fold-out sidepockets, on<br />
one side with m<strong>es</strong>h. With refl ector, lightholder,<br />
handle and raincover. Pull the strap for easy release!<br />
Only for carriers with side support.<br />
28 x 28/48 x35cm<br />
1000g, 13 -18L<br />
30<br />
for RACKTIME<br />
RACKPACK 2<br />
Simple, functional bag in the classic R&K d<strong>es</strong>ign,<br />
with bottle <strong>com</strong>partment on the rear side. With<br />
refl ector, lightholder, handle and raincover.<br />
24 x 23 x35cm<br />
750g, 10L<br />
for RACKTIME<br />
RACKPACK 2 PLUS<br />
Like Rackpack 2, but with two additional foldout<br />
pockets (one side with m<strong>es</strong>h), lid with 2 net<br />
pockets. Handle works also as tension belt for<br />
fi xation of jacket. With refl ector, lightholder,<br />
handle, rain cover and shoulderbelt. Only for<br />
carriers with side support.<br />
30x 23/43 x35cm<br />
900g, 12-16L<br />
for RACKTIME<br />
BOX<br />
Basic box model that clicks into the racktime<br />
adapter. Lockable and rain-protected storage<br />
for smaller belongings such as helmets, etc. Textured<br />
surface.<br />
25 x 18 x 35cm<br />
1000g, 12L<br />
for RACKTIME<br />
CITYMAX BASKET<br />
M<strong>es</strong>h basket with handle and extra large volume.<br />
Equipped with coupling to slide into the<br />
racktime carrier.<br />
23x22,5x36cm<br />
1900g, 24L<br />
acc<strong>es</strong>sori<strong>es</strong> with Racktime adapter · Doggy basket<br />
DOGGY BASKET<br />
This pet basket for bicycl<strong>es</strong> enclos<strong>es</strong> many new ideas. No annoying leather<br />
straps to close. Two special hing<strong>es</strong> and the KLICKfi x closure allow a very<br />
komfortable handling. The grid top is <strong>com</strong>pletely detachable. The variable<br />
hood leav<strong>es</strong> plenty of air and light acc<strong>es</strong>s and giv<strong>es</strong> a good protection<br />
against wind, sun and rain. All the sid<strong>es</strong> can be closed <strong>com</strong>pletely. With<br />
washable cushion, refl ector and handle.<br />
The Doggy basket is offered with 3 different mountings.<br />
52x46 x 36cm, 1,6 Kg (basket), 0,4Kg (cover)<br />
DOGGY BASKET FOR RACKTIME<br />
with coupling for Racktime carriers<br />
DOGGY BASKET PLUS FOR RACKTIME<br />
with coupling for Racktime carriers & hood<br />
DOGGY BASKET FOR GTA<br />
with coupling for carrier adapter<br />
DOGGY BASKET PLUS FOR GTA<br />
with coupling for carrier adapter & hood<br />
DOGGY BASKET FIX<br />
for permanent mounting on carriers<br />
DOGGY BASKET PLUS FIX<br />
for permanent mounting on carriers & hood<br />
The KLICKfi x / Racktime Adapter is the r<strong>es</strong>ult of a succ<strong>es</strong>sful<br />
cooperation of Tubus and Rixen & Kaul. The Know-how of both<br />
<strong>com</strong>pani<strong>es</strong> was used to <strong>com</strong>bine high quality racks with a perfect<br />
fi xing system for acc<strong>es</strong>sori<strong>es</strong>. B<strong>es</strong>ide the racktime acc<strong>es</strong>sory<br />
range also RIXEN & KAUL offers some inter<strong>es</strong>ting acc<strong>es</strong>sori<strong>es</strong> for<br />
Racktime carriers.<br />
For Basket, Box, Bag oder Doggy-Basket – our Racktime Adapter<br />
ensur<strong>es</strong> a secure fi xation on the carrier. Convenient, fast and easy<br />
handling.<br />
KLICKfi x TIP ! With ‚Secure-it‘ (from Racktime) the red button is<br />
lockable on your carrier to prevent thefts.<br />
3 DIFFERENT MOUNTINGS AVAILABLE !
Set of hooks* With GTA hooks for the side slots of<br />
the carrier adapter you can <strong>com</strong>bine the sidebags with<br />
a topcase, box or basket and all parts are lockable in<br />
the carrier adapterplate. Citybag, Cita Plus and Cita GTA additionally enclose<br />
hooks with a blue catch. With those hooks you can use the bags<br />
directly on standard-carriers Ø 6 -12mm, no adapterplate is needed, but<br />
you cannot lock the bags or <strong>com</strong>bine them with other acc<strong>es</strong>sori<strong>es</strong> on Top.<br />
CITA GTA<br />
This smart, practical shopping bag has an expandable main <strong>com</strong>partment<br />
with drawstring as well as several extra <strong>com</strong>partments on lid and front<br />
side for key and purse. Wide, detachable shoulder belt. Reinforced with<br />
fl exible soft foam. Set of hooks included.*<br />
(Same bag is available with Vario hooks for Standard carriers Ø 6 -16mm.)<br />
30 x 35x 16cm,<br />
1100g, 18 -20L<br />
32<br />
CITYBAG<br />
Simple, functional bag for shopping or leisure. The sloped top allows easy<br />
acc<strong>es</strong>s to the bag even when used in <strong>com</strong>bination with baskets. Doublefaced<br />
fabric with foam and pouch<strong>es</strong> inside. Two-way-zipper, solid back<br />
and bottom. Set of hooks included.*<br />
30x35x14cm<br />
750g, 15L<br />
CITA PLUS<br />
Fashion model with stripe-d<strong>es</strong>ign and foam-supported shape. Yellow raincover<br />
and additional zipper <strong>com</strong>partment. Extra <strong>com</strong>partments for key and<br />
purse. Comfortable, detachable shoulder belt. Expandable volume with<br />
drawstring opening. Set of hooks included.*<br />
30 x 35x16cm, 1250 g, 18 -20L<br />
TOURINO<br />
Multi-functional bag for carrier adapter with extendable side bags and<br />
several extra <strong>com</strong>partments. Main <strong>com</strong>partment with subdivisions. Jacket<br />
etc. can be securely fi xed on top in net <strong>com</strong>partments or under adjustable<br />
handle. With bottle-sized pouch at rear, rain cover, refl ector lightholder<br />
and <strong>com</strong>fortable shoulderbelt. Coupling for KLICKfi x carrier adapter at<br />
the bottom.<br />
30x 23/43 x35cm<br />
800g, 12-16L<br />
TRAVELSET COMPLETE<br />
Comfortable travelling pannier set for KLICKfi x carrier adapter. All bags<br />
can be clicked on within seconds and are centrally secured by the integrated<br />
lock, whether they are used as a set or on their own. The set consists<br />
of 2 Travelbags GTA, Travel Topcase and carrier adapter.<br />
bags & box<strong>es</strong> for the carrier system<br />
The large plate creat<strong>es</strong> an even platform and at the same time<br />
serv<strong>es</strong> as an adapter for baskets, topcas<strong>es</strong> and bags. All acc<strong>es</strong>sori<strong>es</strong><br />
can be locked through a central bar, easy to release by pr<strong>es</strong>sing<br />
the red button. The adapter plate is screwed onto the carrier (of<br />
up to14.5 mm width) with two strong brackets. Box<strong>es</strong>, baskets or<br />
topcas<strong>es</strong> (with KLICKfi x coupling at the bottom) are „clicked“ into<br />
the middle of the adapter. Bags can be hung into the side slits.<br />
KLICKfi x TIP ! The Travelbag is also available as a single pannier<br />
for use on standard carriers (see acc<strong>es</strong>sori<strong>es</strong> with Universal<br />
Rail). However, in that case it cannot be <strong>com</strong>bined with baskets,<br />
box<strong>es</strong> or topcas<strong>es</strong>.<br />
TRAVELBAGS GTA<br />
Comfortable, elegant panniers with foam-supported shape. Well-organized<br />
with outer net <strong>com</strong>partment, large front <strong>com</strong>partment and several<br />
inner <strong>com</strong>partments. Solid handle, detachable shoulder strap, refl ectors on<br />
both sid<strong>es</strong>, separate raincover. Two-way zippers<br />
allow convenient acc<strong>es</strong>s even when<br />
bag is used in <strong>com</strong>bination with a<br />
topcase. Due to the asymmetrical<br />
rail position, available only in pairs.<br />
TRAVEL TOPCASE<br />
Large, sturdy suitcase – suitable also for better clothing. Full-size outer<br />
net <strong>com</strong>partment, handle and detachable shoulder strap. Two zipper <strong>com</strong>partments<br />
inside. Separate raincover. With coupling at the bottom for the<br />
carrier adapter or Atran carrier. Can be <strong>com</strong>bined with the side panniers<br />
Cita, Travelbags GTA or Citybags.<br />
45x15x35cm<br />
1600g, 26L<br />
40x35x14cm<br />
2x1400g, 2x 18L
Alternative R&K solutions for<br />
mounting baskets permanently<br />
If you are looking to mount your baskets permanently on your<br />
bike, explore this page for affordable and secure solutions that<br />
are quick and easy to install. Whether it is for handlebars or<br />
carriers, box<strong>es</strong>, wire baskets or m<strong>es</strong>hed baskets, a corr<strong>es</strong>ponding<br />
mounting piece is available – yet without KLICKfi x quick<br />
release featur<strong>es</strong>.<br />
KORBfi x I<br />
Universal, economical screw mounting system for all<br />
wide m<strong>es</strong>hed wire baskets on standard carriers without<br />
spring clamp. Available in pairs. For the fi xation of bigger<br />
acc<strong>es</strong>sori<strong>es</strong> with heavier loads, we re<strong>com</strong>mend installing 2<br />
pairs of KORBfi x.<br />
KORBfi x II<br />
Mounting parts for tightly m<strong>es</strong>hed baskets or for box<strong>es</strong>. Fits<br />
all carrier typ<strong>es</strong>. The acc<strong>es</strong>sory is securely fastened and will<br />
not rattle. Available in pairs. For the fi xation of bigger acc<strong>es</strong>sori<strong>es</strong><br />
with heavier loads we re<strong>com</strong>mend installing 2 pairs<br />
of KORBfi x.<br />
FIXBASKET HOLDER<br />
For everyone who prefers a permanently mounted basket.<br />
Thanks to the patented anchoring cable, the adapter holds<br />
acc<strong>es</strong>sori<strong>es</strong> in a fi xed, stable position even with heavy loads<br />
up to 7kg. Fits all standard handlebars from Ø 22-26mm.<br />
No additional support to fork or headset is required. The<br />
matching basket can be mounted on the handlebar at different<br />
heights, leaving enough space for the light. Since the<br />
basket is permanently fi xed, it has no handle.<br />
34<br />
BOX<br />
Basic box model, lockable and rain-protected storage for smaller belongings<br />
such as helmets, etc. When mounted on the KLICKfi x carrier adapter,<br />
this box can be used in <strong>com</strong>bination with side bags (Citybags, Cita or<br />
Travelbag GTA). You can alternatively mount this box permanent onto your<br />
carrier with Korbfi x II, yet without the KLICKfi x quick-release advantag<strong>es</strong>.<br />
25 x 18 x 35cm<br />
1000g, 12L<br />
CITYBOX<br />
High-quality box made for the KLICKfi x carrier system. Shell made of impact<br />
r<strong>es</strong>istant ABS with aluminum frame. Integrated lock and detachable<br />
shoulder strap. The Citybox serv<strong>es</strong> as a large and easily removable container<br />
for cloth<strong>es</strong>, helmet, jacket, etc. Also well-suited for fi l<strong>es</strong>. When<br />
mounted onto the KLICKfi x carrier adapter, the box can also be used in<br />
<strong>com</strong>bination with sidebags (Citybags, Cita<br />
or Travelbag GTA).<br />
30 x21x40cm<br />
1400g, 22L<br />
UNIX I<br />
Time-proven wire basket, ideal for school, leisure and shopping. With<br />
handle and welded KLICKfi x coupling at the bottom for carrier adapter<br />
or Atran carriers.<br />
40 x17 x 30cm,<br />
900g, 20 L<br />
CITYMAX BASKET<br />
M<strong>es</strong>h basket with handle and extra large volume. Equipped with coupling<br />
for the KLICKfi x carrier adapter, the basket simply slid<strong>es</strong> into the adapter<br />
and locks automatically. Thanks to its slim shape, it can be used in <strong>com</strong>bination<br />
with panniers (Citybags, Cita or Travelbag GTA) and will still allow<br />
easy acc<strong>es</strong>s to the bags below.<br />
23 x 22,5 x 36 cm<br />
1300g, 24 L<br />
bags & baskets for the carriersystem<br />
All wire baskets and m<strong>es</strong>hed baskets shown here lock automatically<br />
into the upper part of the KLICKfi x carrier adapter or<br />
ATRAN carrier– simply place the acc<strong>es</strong>sory on top and slide it<br />
forward. Different side panniers, baskets, box<strong>es</strong> and topcas<strong>es</strong><br />
for the carrier system can be used on their own or in <strong>com</strong>bination<br />
with others.<br />
KLICKfi x TIP ! With our coupling set GTA, you can make<br />
your own box <strong>com</strong>patible with the KLICKfi x carrier system.<br />
Carrier adapter plate<br />
UNIX III<br />
Our larg<strong>es</strong>t wire basket with plenty of volume. Welded KLICKfi x coupling<br />
at the bottom for the KLICKfi x carrier adapter or Atran carriers.<br />
Black coated surface.<br />
55 x 20 x 36cm<br />
1400g, 40L<br />
COUPLING SET GTA (FOR CARRIER ADAPTER)<br />
With the retrofi t coupling set, you can make your own box<strong>es</strong> or m<strong>es</strong>hed<br />
baskets <strong>com</strong>patible with the KLICKfi x carrier system. It is simply<br />
mounted with 4 screws at the bottom of the acc<strong>es</strong>sory.<br />
75g, max. 8 Kg
TRAVELBAG<br />
Busin<strong>es</strong>s case and Notepac with many excellent<br />
featur<strong>es</strong>. Several internal pockets with zipper,<br />
padded <strong>com</strong>partment for laptop and acc<strong>es</strong>sori<strong>es</strong>,<br />
detachable shoulder strap, yellow rain<br />
cover. All <strong>com</strong>partments have practical featur<strong>es</strong><br />
for the proper storage of documents, maps and<br />
acc<strong>es</strong>sori<strong>es</strong>.<br />
The Modul-Rail for standard carriers Ø 8-16mm<br />
is only visible when in use on bike. It can be hidden<br />
in the back pocket within seconds and can<br />
even be <strong>com</strong>pletely detached. This bag can be<br />
used on either the right or left side. (choose the<br />
Travelbags GTA for the carrieradapter if you want<br />
to <strong>com</strong>bine the bag with Topcas<strong>es</strong> or baskets)<br />
40 x 35 x14cm<br />
1400g, 18L<br />
OFFICE<br />
Busin<strong>es</strong>s case and Notepac with many excellent<br />
featur<strong>es</strong>. Several internal pockets with zipper,<br />
padded <strong>com</strong>partment for laptops (36x29cm<br />
max.) and acc<strong>es</strong>sori<strong>es</strong>, detachable shoulder<br />
strap, yellow rain cover. All <strong>com</strong>partments have<br />
practical featur<strong>es</strong> for the proper storage of documents,<br />
maps and acc<strong>es</strong>sori<strong>es</strong>.<br />
With KLICKfi x Modul-Rail for all standard carriers<br />
Ø 8-16mm. Rail is only visible when in use on<br />
bike. It can be hidden in the back pocket within<br />
seconds and can even be <strong>com</strong>pletely detached.<br />
This bag can be used on either the right or left<br />
side.<br />
40x30x15cm<br />
1800g, 12L<br />
CARGO BASIC<br />
Already the basic Cargo Version is a reliable<br />
transport partner for big loads. Highly durable<br />
due to its solid base and an internal diagonal<br />
aluminium frame. Flat foldable when not in use.<br />
With practical handl<strong>es</strong>, 2-way zipper and KLICKfi<br />
x Modul rail.<br />
You can also carry your Laptop inside a soft sleeve<br />
with that robust bag. The slight inclination of<br />
the bag increas<strong>es</strong> legroom and <strong>com</strong>fort. (a second<br />
rail position for left/right use is prepared).<br />
Available in black or blue.<br />
38 x 30 x16cm<br />
1450g, 18L<br />
busin<strong>es</strong>s & shoppingbags for standard carriers<br />
All bags directly lock onto standard car-<br />
������ ��� ����������� ������� ����� �����<br />
you to position each rail precisely and<br />
������ �� �� ��������� ���������� ��� ����<br />
er rail prevents the bag from swinging<br />
sideways. Characteristics of our three rail<br />
typ<strong>es</strong>:<br />
KOMFORT RAIL<br />
Classic, time-proven rail with solid,<br />
��������� ������� ������������ �����<br />
stable hooks and locking mechanism for<br />
standard carriers Ø 8-13mm. The solid (removable)<br />
handle allows for <strong>com</strong>fortable,<br />
single-handed use.<br />
...locking mechanism continuously ad�ustable<br />
UNIVERSAL RAIL<br />
���������� ���� ���� ������� ������ ���<br />
��� ������� ������ ����� ���� ����������<br />
standard hooks that fi t Ø 8/10/12mm and<br />
additional 16mm hooks e.g. for Kettler<br />
bik<strong>es</strong>. The Universal<br />
rail locks in automatically<br />
when<br />
it is set onto the<br />
carrier.<br />
36 37<br />
CARGO<br />
Foldable transportation bag for standard carriers,<br />
thoughtfully and functionally d<strong>es</strong>igned.<br />
Whether at college, offi ce or shopping –<br />
Cargo offers its volume only when needed.<br />
Highly durable due to its solid base and an internal<br />
diagonal aluminium frame. By a smart<br />
folding technology the aluminium handle slid<strong>es</strong><br />
into the fl at fi xation position<br />
The slight inclination of the bag increas<strong>es</strong> legroom<br />
and <strong>com</strong>fort (second rail position for left/<br />
right use). Frontbags, inner <strong>com</strong>partments, mobile<br />
bag, raincover, shoulderbelt and Modulrail<br />
included.<br />
38 x 30 x16cm<br />
1600g, 18L<br />
CARGO WATERPROOF<br />
For university, offi ce oder supermarkt. Waterproof<br />
transportation bag for carriers, thoughtfully<br />
and functionally d<strong>es</strong>igned. Cargo is highly<br />
durable due to its solid base and an internal<br />
diagonal aluminium frame.<br />
The slight inclination of the bag increas<strong>es</strong> legroom<br />
and <strong>com</strong>fort. An inner <strong>com</strong>partment<br />
and mobile bag are helpful for organisation. Big<br />
refl ectors on 3 sid<strong>es</strong>, edge protector,soft<br />
handle, <strong>com</strong>fortable shoulderbelt and modul<br />
rail included.<br />
38 x32x16cm<br />
1600g, 20 L<br />
MODUL RAIL<br />
Prof<strong>es</strong>sional aluminium rail with conti-<br />
������� ���������� ������� ���������<br />
for Ø 8-16mm. Bags are simply hung into<br />
the carrier. The spring borne latch<strong>es</strong> auto-<br />
��������� ������ �� ��� ��������� ��������<br />
when closed. The advantage: no distance<br />
piec<strong>es</strong> or tools are needed. A shoulderbelt<br />
can be fi xed in the eyelets at the sid<strong>es</strong>.<br />
With special GTA hooks for the<br />
Universal Rail, you can use the bags also<br />
on the carrier adapterplate.
38<br />
WATERPROOF<br />
ULTIMA PANNIER<br />
Large, waterproof travelling bag with fl ip-top lid and central belt. The<br />
outer net <strong>com</strong>partment can hold wet clothing and includ<strong>es</strong> an integrated<br />
zipper <strong>com</strong>partment with air acc<strong>es</strong>s. Refl ectors on both sid<strong>es</strong>. Carrying<br />
strap also serv<strong>es</strong> as a tension belt. Robust edge protective strip. Large<br />
volume main <strong>com</strong>partment with drawstring<br />
closure and inner zip <strong>com</strong>partment.<br />
An additional net <strong>com</strong>partment<br />
with zipper is located on the<br />
inside of the lid.<br />
35 x 48 x 17cm<br />
2 x 1050g, 26 L<br />
particularly practical featur<strong>es</strong><br />
and many toughtful details. Unlike<br />
most waterproof panniers,<br />
Ultima models provide facilitate<br />
excellent organisation.<br />
Contents are clearly<br />
arranged and easy to fi nd.<br />
MA COMPACT<br />
A practical all-rounder that can also be used as a front pannier thanks to<br />
its smaller format. Wet cloth<strong>es</strong> are easily stored in an outer <strong>com</strong>partment<br />
with net material for air acc<strong>es</strong>s. Main <strong>com</strong>partment with roll closure, central<br />
tension belt, side refl ectors<br />
and edge guard.<br />
28 x 40 x 15 cm<br />
730g, 17 L<br />
ULTIMA PLUS PANNIER<br />
This waterproof travelling bag featur<strong>es</strong> an additional, fully removable inner<br />
<strong>com</strong>partment within the main <strong>com</strong>partment. This allows you to remove<br />
all contents, clean and dry, in a single move. Inner <strong>com</strong>partment can be<br />
divided when nec<strong>es</strong>sary. Two-way zippers allow for easy acc<strong>es</strong>s; everything<br />
can be easily stored and clearly arranged as in a suitcase.<br />
34x46x16cm<br />
2x1380g, 24 L<br />
CLASSIC LOWRIDER<br />
Same featur<strong>es</strong> as the ‚Classic‘ panniers but smaller and without additional<br />
outer <strong>com</strong>partment. Inner lid <strong>com</strong>partment with zipper and small<br />
extra pouch for rain cover. Includ<strong>es</strong> Universal rail with adjustable hook<br />
position for standard carriers Ø 8/10/12mm, 16mm carriers and Kettler<br />
bik<strong>es</strong>. Available only in pairs. Can also be used as a small pannier on selfsupporting<br />
carriers or kids‘ bik<strong>es</strong>.<br />
26 x 36 x13cm<br />
2x750g, 2x15L<br />
CLASSIC<br />
Large pannier of time-proven d<strong>es</strong>ign. With handle, integrated rain protection,<br />
and additional outer <strong>com</strong>partment with refl ector. Inner lid <strong>com</strong>partment<br />
with zipper and small extra pouch for rain cover. High-quality soft<br />
poly<strong>es</strong>ter with waterproof coating. Includ<strong>es</strong> Universal rail with adjustable<br />
hook position for standard carriers Ø 8/10/12mm, 16mm and Kettler carriers.<br />
Available in pairs.<br />
40x40x15cm<br />
2x 900g, 2x 25L<br />
panniers for standard carriers<br />
CITA VARIO<br />
BACKPACK<br />
Back panniers permitting particularly good acc<strong>es</strong>s to all <strong>com</strong>partments<br />
thanks to 2-way zippers. With top <strong>com</strong>partment, separate main <strong>com</strong>partment<br />
with side opening, and outer <strong>com</strong>partments with large safety refl ectors.<br />
As in high-quality backpacks, the inner <strong>com</strong>partment can be divided<br />
into two sections. Automatically locks onto carriers without the need for<br />
straps or buckl<strong>es</strong>. Integrated rain cover on the front side is easily detached<br />
for cleaning and drying. Complete with Comfort Rail and removable<br />
handle. Available only in pairs.<br />
40 x 38 x14cm<br />
2x 900g, 2x21L<br />
R&K TIP ! Though our Backpacks<br />
aren‘t new, they remain exceptionally<br />
practical–and thus have <strong>com</strong>e along<br />
on all our R&K bike tours for more then<br />
15 years ! More informations about<br />
our rail models on previous page.<br />
Smart economy shopping-bag with extra <strong>com</strong>partments for key and<br />
purse. Comfortable, detachable shoulder belt. Expandable volume with<br />
drawstring opening. Includ<strong>es</strong> continuously adjustable Vario hooks for<br />
standard carriers Ø 6-16mm. (To <strong>com</strong>bine that bag with topcas<strong>es</strong> or baskets<br />
this model is also available with GTArail for KLICKfi x carrier adapter.)<br />
30 x 35 x16cm<br />
1100g, 18-20 L
MICRO BOTTLEBAG<br />
Saddle bag with special drawstring bottle <strong>com</strong>partment (e.g. for SIGG<br />
bottl<strong>es</strong> up to 0.75 L) and additional <strong>com</strong>partment with zipper for tools<br />
and spare tube. Main <strong>com</strong>partment can also hold a light wind-jacket<br />
9x14x15cm<br />
100g, 1,5L<br />
CABLE LOCK HOLDER FOR SADDLE ADAPTER<br />
Quick release <strong>com</strong>fort with saddle adapter clamp for all cable locks<br />
Ø 6-10mm. Easy mounting on sports saddl<strong>es</strong>. The clamp is simply fastened<br />
on the lock and fi ts into the saddle adapter or Mini adapter.<br />
MICRO SHELL<br />
Solid saddle bag of elegant shape with one main <strong>com</strong>partment. Compr<strong>es</strong>sion-molded<br />
neoprene material allows for easy cleaning. Adapter plate<br />
with additional release button.<br />
10x9x18cm<br />
100g, 1L<br />
MICRO 200 EXPANDABLE<br />
Larg<strong>es</strong>t R&K saddlebag with expandable d<strong>es</strong>ign for more volume (1,5 to<br />
2,0 L). Wide opening for easy acc<strong>es</strong>s. Robust poly<strong>es</strong>ter with waterproof<br />
coating. Interior padding, Scotchlite refl ector and lightholder.<br />
12 x 8 /16 x 19 cm<br />
175g, 1,5-2 L<br />
MICRO 80/150 PLUS<br />
bags & lock holders with saddle adapter<br />
Saddle bag with extra <strong>com</strong>partment for change or key. The main<br />
<strong>com</strong>partment has enough space for repair set, battery light, etc. Made of<br />
high- quality soft poly<strong>es</strong>ter and easy-to-clean synthetic material. Available<br />
in two siz<strong>es</strong>.<br />
Micro 80 Plus: 8 x 6 x18cm, 100g, 0,8L<br />
Micro 150 Plus: 9 x 7 x19cm, 110g, 1,1L<br />
For mounting on sport saddl<strong>es</strong>. Compact, inconspicuous adapter<br />
shape. Simply slide in the acc<strong>es</strong>sory and it will lock into the<br />
adapter automatically. Fits all bags in the Micro- and Handy-<br />
������� �� �������� ���� ����� ��� ��� ������� �� ���� ������<br />
KLICKfi x TIP ! An additional release button on the bag‘s<br />
adapter plate gurarante<strong>es</strong> easy, single-handed acc<strong>es</strong>s to release<br />
the saddle bag or the cable lock.<br />
40 41<br />
MICRO SL<br />
Classic race-bike d<strong>es</strong>ign, perfect for mini pump, tools, spare tube or folding<br />
cover. Separate side <strong>com</strong>partment with zipper. Coated poly<strong>es</strong>ter material.<br />
This slim bag can alternatively be mounted on the horizontal part of<br />
the frame using the Mini adapter.<br />
7x10x20cm<br />
120g, 1,2L<br />
MICRO 30/40/100<br />
Saddle bag for all small important things on the road like repair set, spare<br />
tube, tools etc. Made of soft nylon with Scotchlite refl ector and waterproof<br />
coating. Available in 3 siz<strong>es</strong>.<br />
Micro 30: 7 x 3,5 x12cm, 70g, 0,2L<br />
Micro 40: 8 x 5 x13cm, 100g, 0,4L<br />
Micro 100: 10 x 7 x15cm, 120g, 0,8L<br />
Acc<strong>es</strong>sory includ<strong>es</strong> saddle adapter
Mounting on frame threads<br />
Mounting on frame<br />
Mounting on handlebar vertical<br />
Mounting on stem<br />
Mounting on vertical stem<br />
Mounting on handlebar horizontal<br />
42<br />
FREELINER<br />
Our map-holder with swivel coupling for quick<br />
turns from horizontal to vertical position. Perfect<br />
for all „bikeline“ maps and map formats up<br />
to 24,5x12,5cm. Sturdy transparent raincover<br />
protects maps from wind and rain. Can be detached<br />
within seconds and fi xed again securely<br />
with a single „KLICK“.<br />
24,5 x 12,5 cm<br />
110 g<br />
MINIMAP<br />
Handy map-holder <strong>com</strong>petely made of plexiglass,<br />
easily mounted onto handlebar or stem<br />
using the KLICKfi x Mini-adapter. All map siz<strong>es</strong><br />
simply slide in. Can also be used in <strong>com</strong>bination<br />
with handlebar bags. Two siz<strong>es</strong> available.<br />
MiniMap I: 9 x15 cm, 90g<br />
MiniMap II: 12 x 25cm, 150g<br />
HANDY DURATEX<br />
Mobile phone pouch made of top-quality, durable<br />
Duratex fabric for optimal protection of sensitive<br />
contents. Ideal for mounting on handlebar<br />
or stem. Thanks to the elastic<br />
sid<strong>es</strong>, this model fi ts for all<br />
<strong>com</strong>mon mobile phon<strong>es</strong>.<br />
6x13x2,5cm<br />
55 g, 0,25 L<br />
mapholder, lockholder, holder for bottlecage ,bags for Miniadapter<br />
BOTTLEKLICK<br />
The popular Bottlefi x now <strong>com</strong><strong>es</strong> with its own<br />
KLICKfi x quick-release function. In this way a given<br />
bottle holder can be quickly „clicked“ onto the<br />
bike and released again within seconds. Can be<br />
used for all <strong>com</strong>mon bottle cag<strong>es</strong> (up to 1kg).<br />
Mini-adapter included.<br />
LIGHT BAG MINI<br />
Mini Bag for anything that needs to be within<br />
quick reach, whether it is your camera, glass<strong>es</strong>,<br />
energy bar or water bottle. The soft inner lining<br />
provid<strong>es</strong> ideal protection for objects with sensitive<br />
surfac<strong>es</strong>, such aluminum bottl<strong>es</strong>. Outer mini-<strong>com</strong>partment<br />
with zipper for keys and small<br />
change. The drawstring can serve to close up<br />
the main <strong>com</strong>partment or to<br />
hold bottl<strong>es</strong> tightly in place.<br />
max. 800g.<br />
Ø 1<br />
120<br />
CABLE LOCK HOLDER<br />
Universal fi xture for easy retrofi tting of cable<br />
locks. The Mini adapter is mounted via the stainl<strong>es</strong>s<br />
strap onto fram<strong>es</strong>, handlebars or seat posts<br />
Ø 15-60 mm. The associated retrofi t lock holder<br />
can be attached to cable locks Ø 6 -10mm.<br />
HANDY ZIP<br />
A handy little bag for mobile phon<strong>es</strong>, glass<strong>es</strong>,<br />
etc. Main <strong>com</strong>partment with zipper. Additional<br />
pocket for key, credit card or change. Available<br />
in two siz<strong>es</strong>. It can also be used with the saddle<br />
adapter.<br />
Zip I: 6 x 14x 3,5cm, 75g, 0,3 L<br />
Zip II: 6 x 17 x 4cm, 90g, 0,5L<br />
Small, round and multi-functional – the KLICKfi x Mini adapter.<br />
You can turn the head part of the adapter in 90° steps,<br />
allowing you to attach an acc<strong>es</strong>sory from any of four different<br />
directions. The bags can be fi xed in an upright or horizontal<br />
position on the frame, handlebar, stem or seat post.<br />
Easy UNIFIT-mounting with stainl<strong>es</strong>s strap<br />
on Ø 15 -60 mm.<br />
KLICKfi x TIP ! The Mini adapter and Twin<br />
adapter can also be screwed directly into integrated frame<br />
threads for bottle cag<strong>es</strong> (using countersunk head screws<br />
M5 x 25-30). Acc<strong>es</strong>sori<strong>es</strong> for Mini adapter are also <strong>com</strong>patible<br />
with the KLICKfi x saddle adapter.<br />
U-LOCK HOLDER<br />
Retrofi t kit for Ø 12mm U-locks. The coupling<br />
can be directly mounted on the steel U-frame.<br />
Easy mounting with two stainl<strong>es</strong>s straps which<br />
make it suitable even for heavy locks (up to<br />
2kg). Fits fram<strong>es</strong> Ø 15-60mm. The adapter can<br />
also be mounted onto integrated frame threads<br />
for bottle cag<strong>es</strong> using countersunk head screws<br />
M5 x 25-30mm (not included).<br />
COMPACT<br />
For everyone who do<strong>es</strong> not need a large handlebar<br />
bag or wish<strong>es</strong> to <strong>com</strong>bine a <strong>com</strong>pact bag<br />
with the Sunny map holder. Two main <strong>com</strong>partments<br />
with zipper for camera, glass<strong>es</strong> and<br />
anything else you need at hand. Especially wellsuited<br />
for mounting on the stem.<br />
11x19x9cm<br />
180g, 2 L<br />
Acc<strong>es</strong>sory includ<strong>es</strong> Mini adapter
PUMPfi x<br />
Universal pump holder. All pump siz<strong>es</strong> can be<br />
fi xed between Pumpfi x and the frame. Easy<br />
mounting with stainl<strong>es</strong>s steel strap on fram<strong>es</strong><br />
sized Ø 15-60mm. Only for<br />
pumps with indentation<br />
for pump holders.<br />
UNIDISC<br />
The fi rst universal chain wheel disc of break-r<strong>es</strong>istant material and modern d<strong>es</strong>ign. New mounting<br />
system with glass fi bre reinforced adapter socket that can be screwed into crank centre. Fits all cranks<br />
with inner thread. Disc do<strong>es</strong> not <strong>com</strong>e into contact with chain ring. Fast and easy mounting with<br />
single central screw. Available in black or transparent material. For chain wheels up to 48 sprockets.<br />
Diameter 21cm, 90g<br />
44<br />
MINIMOUNT<br />
Retrofi t kit for lightweight acc<strong>es</strong>sori<strong>es</strong> like refl<br />
ectors, lights etc. The 360° revolving top permits<br />
many different mounting positions. Easy<br />
mounting with stainl<strong>es</strong>s steel strap on tub<strong>es</strong><br />
Ø 12-28mm.<br />
BOTTLEfi x<br />
Retrofi t kit for any kind of bottle holder. The<br />
adapter head revolv<strong>es</strong> in 90° steps and thus permits<br />
the fi xation on handlebars, frame or seat<br />
post. Easy mounting with stainl<strong>es</strong>s steel strap on<br />
Ø 15-60mm. Especially practical on bik<strong>es</strong> without<br />
integrated frame threads<br />
(such as kids‘ bik<strong>es</strong>).<br />
BOTTLEfi x EXTENDED<br />
Retrofi t kit for mounting bottle holder on the<br />
seatpost. Fits all <strong>com</strong>mon seat posts and bottle<br />
holders.<br />
SPOKEY PROFESSIONAL<br />
The double-layered metal insert doubl<strong>es</strong> the surface contact between tool<br />
and nipple. This allows you to perform a larger number of turns with l<strong>es</strong>s<br />
pr<strong>es</strong>sure. Especially well-suited for prof<strong>es</strong>sional use, high torque, and sensitive<br />
aluminum nippl<strong>es</strong>. Double insert grips spoke nipple on all sid<strong>es</strong> and<br />
prevents damage of nipple edg<strong>es</strong>.<br />
Spokey 3,25mm, red<br />
4,5 x 5cm, 12g<br />
Spokey 3,40 mm, black<br />
4,5 x 5cm, 12g<br />
Spokey 3,25mm, blue<br />
for thicker spok<strong>es</strong> 2,34mm<br />
4,5 x 5cm, 12g<br />
SPOKEY<br />
The legendary, patented spoke tool, extremely light and robust. The<br />
unique d<strong>es</strong>ign has proven its quality for 25 years among bikers and bike<br />
mechanics alike. The hardened steel insert is manufactured with the high<strong>es</strong>t<br />
precision and grips the spoke nipple on all sid<strong>es</strong>. A must-have in any<br />
toolbox, at home and on the road.<br />
Spokey 3,25mm, red<br />
Spokey 3,40 mm, black<br />
4,5 x 4,7cm, 10g<br />
Spokey nipple wrench<br />
UNIFIT is a mounting system for bike acc<strong>es</strong>sori<strong>es</strong>. It fi ts<br />
any diameter up to 60mm and ist easily mounted even onto<br />
oval fram<strong>es</strong>. The stainl<strong>es</strong>s steel strap can be cut to the d<strong>es</strong>ired<br />
individual length.<br />
No risk of scratching even sensitive<br />
frame surfac<strong>es</strong>, thanks<br />
to rounded strap edg<strong>es</strong>.<br />
45
HANDLEBAR ADAPTER SYSTEM<br />
CONTOUR MAX CONTOUR<br />
ADAPTER DISCRIPTION EXAMPLE COMPATIBLE<br />
WITH<br />
HANDLEBAR ADAPTER proven since years, robust, glass<br />
fi bre reinforced. The patented security cable ensur<strong>es</strong> that<br />
the adapter remains securely fi xed and do<strong>es</strong> not turne<br />
downwards. The handlebar adapter can support the<br />
great<strong>es</strong>t range of acc<strong>es</strong>sori<strong>es</strong> within the bicycle market.<br />
max. 7 Kg (p. 4-23)<br />
Extras: MultiClip /Multiclip Plus: Holder<br />
for GPS, light, <strong>com</strong>puter or<br />
mapholder (p. 23)<br />
Distance-Sets 5mm /43mm: for<br />
curved handlebars and more<br />
space for cabl<strong>es</strong><br />
oversize clamps for Ø 31,8mm<br />
Versions: H.A. Standard Ø 22-26mm<br />
H.A. Standard with lock Ø 22-26mm<br />
H.A. Standard + Oversize<br />
H.A. Oversize for Ø 31,8mm<br />
HANDLEBAR ADAPTER CADDY for mounting on vertical<br />
tub<strong>es</strong> such as stems or seat posts Ø 22-36mm. Suitable<br />
for foldable bik<strong>es</strong>, scooters, wheel chairs, golf caddys etc.<br />
Robust body made of fi bre glass reinforced polyamide.<br />
max. 7 Kg (p. 23)<br />
3 6<br />
EXTENDER enabl<strong>es</strong> you to use all handlebar acc<strong>es</strong>sori<strong>es</strong><br />
on seat posts. Fits for seatposts Ø 25-32mm.<br />
max. 5 Kg (p. 20-23)<br />
Extras: Oversize clamp for Ø 32-36mm<br />
Versions: Extender with/without adapter head<br />
HANDLEBAR ADAPTER FOR STEM for mounting on long<br />
vertical stems Ø 22,2-25,4mm. Favourable acc<strong>es</strong>sory position<br />
with a lower bary centre. This mounting position<br />
allows the adapter to remain independent of the inclination<br />
of adjustable stems. The bracket can also be turned<br />
upside down. max. 5 Kg (p. 22)<br />
Versions: with or without lock<br />
3<br />
HANDLEBAR ADAPTER FOR HEAD TUBE Only for bik<strong>es</strong><br />
with special head tube threads (depth gauge 16/30mm).<br />
The new upturned shape increas<strong>es</strong> the distance to the<br />
front wheel, that KLICKfi x bags and baskets can be<br />
mounted even onto small foldable bik<strong>es</strong>.<br />
max. 5Kg (p. 22)<br />
4<br />
FRAME BRACKET Intended to be <strong>com</strong>bined with the<br />
KLICKfi x handlebar adapter. Only for bik<strong>es</strong> with special<br />
head tube threads (depth gauge 30mm).<br />
max. 5 Kg (p. 22)<br />
CONTOUR ADAPTER for Contour Bags with aluminum or<br />
glassfi bre reinforced bracket, <strong>com</strong><strong>es</strong> with two clamps for<br />
seat posts Ø 25-28 and Ø 28-32mm,<br />
max. 2 Kg (p. 24-25)<br />
Extras: Oversize Schelle für Ø 32-36mm<br />
CONTOUR MAX ADAPTER fi ts to Contour Max Bags with<br />
double aluminum bracket. A Clamp for seat posts Ø 25-<br />
32mm is included.<br />
max. 3 Kg (p. 26-27)<br />
Extras: Oversize clamp for Ø 32-36mm<br />
1<br />
6<br />
4<br />
6<br />
6<br />
S Y S T E M O V E R V I E W<br />
Baggyplate<br />
on baskets<br />
max. 7 Kg<br />
on bags<br />
max. 2 Kg<br />
inner plate<br />
max. 2 Kg<br />
Lamelloplate<br />
continuously<br />
adjustable<br />
max. 7 Kg<br />
stable<br />
Steel bracket<br />
max. 7 Kg<br />
lightweight<br />
Aluminum<br />
bracket<br />
max. 2 Kg<br />
coupling on<br />
Reisenthel<br />
Bikebaskets<br />
max. 5 Kg<br />
plate on<br />
backpacks<br />
with foldaway<br />
bracket<br />
max. 5 Kg<br />
coupling<br />
on Sunny<br />
mapholder<br />
Contour brackets<br />
Contour Max<br />
Aluminium<br />
bracket<br />
max. 3 Kg<br />
SYMBOLS<br />
POSITION<br />
1 handlebar<br />
2 Stem (horizontal)<br />
3 Stem (vertical)<br />
4 Head tube<br />
1<br />
2<br />
3<br />
4<br />
8<br />
8 8<br />
Handlebar Adapter<br />
Contour Adapter<br />
Contour Max<br />
Quad Adapter<br />
Saddle Adapter<br />
Mini Adapter<br />
Twin Adapter<br />
Racktime Adapter<br />
Rackpack Adapter<br />
GTA Platte<br />
Komfort Rail<br />
Universal Rail<br />
Modul Rail<br />
Light holder<br />
Raincover<br />
Waterproof<br />
New Product<br />
antirust<br />
Unifi t Mounting<br />
Permanent<br />
Mounting<br />
5 Saddle<br />
6 Seat post<br />
7 carrier<br />
8 frame<br />
6<br />
5<br />
7<br />
ADAPTER DESCRIPTION<br />
QUAD ADAPTER Neue Adapterlinie zur sicheren, komfortablen<br />
Fixierung der PhoneBag. Einfache Unifi t Montage<br />
mit Edelstahlband auf Ø 15-60mm von Lenker,<br />
EXAMPLE COMPATIBLE<br />
WITH<br />
Rahmen, Vorbau und Sattelstütze – auch auf unrunden<br />
Quad<br />
Querschnitten. max. 1 Kg (p. 3)<br />
Adapterplate<br />
turnable<br />
1 2 6 8<br />
TWIN ADAPTER The quick-release retrofi t kit for 12mm<br />
U-locks. The coupling can be directly mounted on the<br />
steel U-frame. Easy mounting with two stainl<strong>es</strong>s straps.<br />
Fits fram<strong>es</strong> Ø 15-60mm. max. 2Kg (p. 43)<br />
SATTELADAPTER SADDLE ADAPTER This <strong>com</strong>pact adapter<br />
fi ts most sports saddl<strong>es</strong>. The acc<strong>es</strong>sory simply slid<strong>es</strong><br />
in and locks automatically into the adapter. Fits bags in<br />
our „Micro“ and „Handy“ seri<strong>es</strong>, as well as the cable lock<br />
holder. Acc<strong>es</strong>sori<strong>es</strong> for Saddleadapter can also be used<br />
for the Miniadapter. max. 1 Kg (p.40-41)<br />
5<br />
MINIADAPTER multi-functional. Head part of the adapter<br />
can be turned in 90° steps to give acc<strong>es</strong>s from different<br />
directions. Fits for Handy, Microbags, cablelocks or<br />
mapholders. Easy mounting with stainl<strong>es</strong>s strap on frame,<br />
handlebar, stem or seat post Ø 15-60mm. Acc<strong>es</strong>sori<strong>es</strong><br />
for Miniadapter can also be used for the saddleadapter.<br />
max. 1 Kg (p. 42-43)<br />
1 2 6 8<br />
RACKTIME ADAPTER bags with this bottom coupling<br />
perfectly fi t onto racktime carriers. max. 10 Kg (p. 30-31)<br />
RACKPACK ADAPTER bags with this bottom coupling<br />
with strap release perfectly fi t onto rackpacker or freerack<br />
carriers. Slide bag onto the freerack carrier and the<br />
bag locks in automatically. Just pull the strap for easy release<br />
! max. 10 Kg (p. 28-29)<br />
6 7<br />
CARRIER ADAPTER can be mounted with two brackets<br />
onto carriers up to 14,5cm in width. All acc<strong>es</strong>sori<strong>es</strong> are<br />
locked through a central bar, easy to release by pr<strong>es</strong>sing<br />
the red button. Fix box<strong>es</strong>, baskets or topcas<strong>es</strong> (with coupling<br />
at the bottom) in the middle of the adapter. Bags<br />
can be hung into the side slits.<br />
max. 3 x10 Kg (p. 32-35)<br />
7<br />
UNIVERSAL RAIL adjustable rail with fl exible handle.<br />
With exchangeable hooks and reducing piec<strong>es</strong> for carrier<br />
siz<strong>es</strong> Ø 8/10/12mm and additional 16mm hooks for Kettler<br />
bik<strong>es</strong>. max. 10 Kg (p. 37, 39)<br />
Extras: GTA Hooks to use pannierbags with Universal<br />
rail alternatively on the carrier adapter 7<br />
MODUL RAIL Prof<strong>es</strong>sional aluminium rail with continuously<br />
adjustable locking mechanism for Ø 8-16mm. Hang<br />
bags onto the carrier and lock hooks by pr<strong>es</strong>sing them<br />
down and forward. Additionally the hooks can be horizontally<br />
positioned. max. 10 Kg (p. 36-38)<br />
7<br />
KOMFORT RAIL classic, time-proven rail with a solid,<br />
removable handle. Continuously adjustable hook and locking<br />
mechanism for carriers Ø 8-13mm.<br />
max. 10 Kg (p. 39)<br />
8<br />
7<br />
7<br />
clamp for<br />
U-locks<br />
Micro plat<strong>es</strong><br />
Bottleklick<br />
Freeliner<br />
MiniMap<br />
cable clamp<br />
Racktime<br />
carrier<br />
Freeracks<br />
Rackpacker<br />
coupling GTA<br />
GTA hooks<br />
for standard<br />
carriers<br />
Ø 8-12/16mm<br />
for standard<br />
carriers<br />
Ø 8-16mm<br />
for standard<br />
carriers<br />
Ø 8-13mm<br />
QUAD ADAPTER<br />
TWIN<br />
RACKTIME MINI / SADDLE ADAPTER<br />
PANNIER RAILS GTA RACKPACK
Generalvertrieb Deutschland<br />
ASISTA – Teile fürs Rad<br />
GmbH & Co KG<br />
D-88299 Leutkirch<br />
phone (+49) 075 61 / 98 69-0<br />
<strong>ww</strong>w.asista.de<br />
visit our homepage<br />
<strong>ww</strong>w.<strong>KLICKfix</strong>.<strong>com</strong><br />
for more informations, pricelist<br />
Download: catatogue, manuals<br />
Denx mark<br />
Sondergaard & Sonner A/S<br />
DK-8260 Viby J, Aarhus<br />
phone (+45) 86 28 / 10 22<br />
<strong>ww</strong>w.bik<strong>es</strong>ond.dk<br />
England<br />
Greyville Enterpris<strong>es</strong><br />
GB-WS 14 9TZ Lichfi eld<br />
phone (+44) 15 43 / 25 13 28<br />
<strong>ww</strong>w.greyville.<strong>com</strong><br />
England<br />
Zyro Limited<br />
GB-YO7 3BX Thirsk<br />
phone (+44) 1845 521700<br />
<strong>ww</strong>w.zyro.co.uk<br />
France<br />
Maillon Sarl<br />
F-33750 Beychac et Caillau<br />
phone (+33) 05 56 / 38 63 00<br />
<strong>ww</strong>w.maillon.fr<br />
Japan<br />
PR International Inc.<br />
Nagoya<br />
phone (+81) 52 774 8756<br />
<strong>ww</strong>w.g-style.ne.jp<br />
Austria<br />
KTM Fahrrad GmbH<br />
A-5230 Mattighofen<br />
phone (+43) 077 42 / 40 91-0<br />
<strong>ww</strong>w.ktm-bik<strong>es</strong>.at<br />
Austria<br />
Thalinger Paul Lange GmbH<br />
A-4600 Wels<br />
phone (+43) 072 42 / 4 97-0<br />
<strong>ww</strong>w.thalinger-lange.<strong>com</strong><br />
Switzerland<br />
Tekno Parts Ltd.<br />
CH-2563 Ipsach<br />
phone (+41) 032 / 332 84 60<br />
<strong>ww</strong>w.teknoparts.ch<br />
USA<br />
VeloFred LLC<br />
11375 New York<br />
phone (+1) 646 435-9805<br />
<strong>ww</strong>w.velofred.<strong>com</strong><br />
48<br />
KLICK<br />
Each acc<strong>es</strong>sory locks in automatically fast & secure<br />
when it is atttached to the adapter, without the need for straps<br />
or buckl<strong>es</strong>. It is released only when the red button is pr<strong>es</strong>sed.<br />
Acc<strong>es</strong>sori<strong>es</strong> are attached and released within seconds.<br />
You can choose from a wide range of ���������������<br />
acc<strong>es</strong>sori<strong>es</strong> and adapters. Klickfi x Products are available for<br />
many locations on the bike: for handlebar, saddle, frame, carrier,<br />
seat post, stem and head tube.<br />
You will always have the right �������������������<br />
equipment secured on your bike, carrying only those acc<strong>es</strong>sori<strong>es</strong><br />
you actually need for a given trip. Naturally, you can also transfer<br />
bags from one bike to another within seconds or use the same<br />
adapter for various different acc<strong>es</strong>sori<strong>es</strong>.<br />
RIXEN & KAUL GmbH, Limminghoferstrasse 9, D-42699 Solingen<br />
phone (+49) 075 61/ 98 69-0, fax (+49) 075 61/ 98 69-68, <strong>ww</strong>w.asista.de KLICKFIX ® 5/ · GMBH KAUL & RIXEN COPYRIGHT · GMBH KAUL & RIXEN OF TRADEMARK REGISTERED A IS 2011 MODIFICATIONS.<br />
TECHNICAL TO SUBJECT · RESERVED RIGHTS ·<br />
phone (+49) 0212/ 6 59 66-0, fax (+49) 0212/ 6 59 66-30, <strong>ww</strong>w.klickfi x.<strong>com</strong><br />
Distributor: ASISTA–Teile fürs Rad GmbH & Co.KG, Zeppelinstrasse 48, D-88299 Leutkirch
