<strong>2019</strong> PRODUCT<br />

CATALOG


LBL006 Rev. <strong>2019</strong>-1 EN | © <strong>2019</strong> NORIS MEDICAL<br />

Personal Attention<br />

Accurate <strong>Dental</strong> Solutions<br />

Precision<br />

Down to the Smallest Detail<br />

Wide Range of <strong>Dental</strong> Solutions<br />

Engineered for a Lifetime<br />

Global Partners


Table of Contents<br />

Company Profile 2-4<br />

<strong>Implants</strong><br />

<strong>Implants</strong> Index 6-7<br />

Tuff 8-9<br />

Tuff Pro 10-11<br />

Tuff TT 12-13<br />

Onyx 14-15<br />

Cortical 16-17<br />

PteryCore 18<br />

PteryFit 19<br />

Pterygoid <strong>Implants</strong> Tools 21<br />

Zygomatic 22-25<br />

MBI & MBI NC 26-27<br />

Mono 28-29<br />

Packaging 30<br />

Prosthetics<br />

Prosthetic Workflow 32-33<br />

Accessories<br />

Healing Caps 34<br />

Open & Closed Tray Transfers 35<br />

Snap-On Transfer 36<br />

Clip-On Transfer 37<br />

Cement Retained Restorations<br />

Temporary Abutments 38-39<br />

Straight Abutments 40-41<br />

Angulated Abutments 42-43<br />

Titanium Base Zirconia Abutments 44<br />

Castable Abutments 45<br />

CAD/CAM Components 46-47<br />

Screw Retained Restorations<br />

Multi-Unit - Straight & Angulated 50<br />

Multi-Unit Components 52-53<br />

Multi-Unit Protocol 54-55<br />

Esthetic Screw Abutment 56<br />

Removable Restorations<br />

Vari-Connect 58<br />

Vari-Connect Components 59<br />

Ball Attachment 60<br />

Flat Attachment 61<br />

Instruments<br />

Drills Workflow 64<br />

Drills 65-68<br />

Drivers 69-71<br />

Tools 72-73<br />

Kits 74-76<br />

Index 77-82<br />

/ 1 /


Company Profile<br />

Improving the lives of dentists and<br />

patients around the world with the leading<br />

technology in dental implant systems<br />

ENGINEERED FOR HEALTH<br />

The collaboration between<br />

leading experts and our team<br />

of experienced physicians and<br />

professional engineers to design,<br />

develop and manufacture<br />

innovative products and systems<br />

results in a creative synergy that<br />

benefits both the dental industry<br />

and the patients it serves.<br />

GROUNDBREAKING<br />

RESEARCH & DEVELOPMENT<br />

Results in innovative solutions<br />

backed by clinical evidence.<br />

Each new product and system<br />

developed is supplied with<br />

comprehensive peripheral<br />

tooling needed for its<br />

successful implementation.<br />

PROFESSIONAL TRAINING<br />

Familiarizes dental surgeons<br />

and technicians with expert<br />

techniques and tools.<br />

/ 2 / Company Profile


PROVEN PRODUCTS & WIDE<br />

RANGE OF SOLUTIONS<br />

Enables all procedures, from<br />

simple to complex, to be tackled<br />

with ease.<br />

PERIPHERAL TOOLKITS<br />

Enable easy implementation,<br />

providing a total solution which<br />

covers every step of the process.<br />

ONGOING SUPPORT<br />

Ensures dental professionals<br />

benefit from knowledge<br />

sharing and backup every step<br />

of the way.<br />

/ 3 /


Standards<br />

<strong>Noris</strong> <strong>Medical</strong> invests significant resources in creating an environment for the design and manufacture of its dental<br />

products. Keeping patient safety at the forefront throughout the process, <strong>Noris</strong> <strong>Medical</strong> complies with international<br />

standards for manufacturing and quality. The entire manufacturing process is monitored and recorded for total<br />

process traceability. All facilities are subjected to strict inspection procedures.<br />

• <strong>Product</strong>s carry the CE mark and meet the European <strong>Medical</strong> Device Directive (93/42/EEC).<br />

• <strong>Product</strong>s received the FDA Clearance Premarket Notification (510k) (K140440, K151909, K153043, K162308).<br />

• Meticulous quality control system is in compliance with EN ISO 13485:2016 and FDA QSR 21 CFR Part 820.<br />

• Facilities are subject to routine audits by international auditors.<br />

• Class 10,000 Clean Room for production.<br />

Materials & Surface Treatment<br />

Titanium alloys are known for their superior<br />

biocompatibility and tensile strength. Therefore, all <strong>Noris</strong><br />

<strong>Medical</strong> <strong>Dental</strong> <strong>Implants</strong> and Prosthetic Components<br />

are produced from Titanium Alloy Ti6Al4V (Grade 5).<br />

Macroscopic and microscopic properties of <strong>Dental</strong><br />

Implant surfaces play a major role in their osseous<br />

healing process. Roughened implant surfaces provide<br />

increased retention strength. The topography, down to<br />

the micrometer, affects the attachment and growth<br />

of bone cells.<br />

<strong>Noris</strong> <strong>Medical</strong> applies RBM (Resorbable Blast Media)<br />

technique in order to induce the sub-micro topography.<br />

The material used for RBM process is Calcium Phosphate,<br />

which is a highly resorbable and biocompatible material.<br />

Usage of Calcium Phosphate as the blasting material also<br />

eliminates the need of using strong acids for the removal<br />

of blasting material remnants.<br />

Implant surfaces that have been RBM treated are<br />

considered to be more osteoconductive. Research<br />

showed higher percentage of bone to implant contact<br />

around RBM treated implants. This finding could be<br />

especially useful in severe clinical conditions like poor<br />

bone quality and in cases of early or immediate loading.<br />

References<br />

McCrcken M. <strong>Dental</strong> implant material: Commercially pure titanium and titanium alloys. J Prosthod 1999; 8:40-43.<br />

Schwartz Z, Raz P, Zhao G, Barak Y, Tauber M, Yao H, Boyan BD. Effect of micrometer-scale roughness of the surface of Ti6Al4V pedicle<br />

screws in vitro and in vivo. J Bone Joint Surg Am. 2008; 90:2485-98.<br />

Piattelli A, Manzon L, Scarano A, Paolantonio M, Piattelli M. Histologic and histomorphometric analysis of the bone response to machined<br />

and sandblasted titanium implants: An experimental study in rabbits. Int J Oral Maxillofac <strong>Implants</strong>. 1998;13:805–810.<br />

Piattelli M, Scarano A, Quaranto M, Petrone G, Piattelli A. bone response in rabbit to machined and RBM titanium implants. J Dent Res.<br />

1999;78:1126.<br />

Piattelli M, Scarano A, Paolantonio M, Iezzi G, Petrone G, Piattelli A. Bone response to machined and resorbable blast material titanium<br />

implants: an experimental study in rabbits. J Oral Implantol. 2002;28;2-8.<br />

/ 4 / Company Profile


<strong>Implants</strong><br />

/ 5 /


Internal Hex. <strong>Implants</strong> Index<br />

Pages 8-9 Pages 10-11 Pages 12-13 Pages 14-15 Pages 16-17 Pages 18 Pages 19 Pages 22-25<br />

Tuff Tuff Pro Tuff TT Onyx Cortical PteryCore PteryFit Zygomatic<br />

Internal Hex. Drivers<br />

NMHX2640 NMHX2620 NMHX2615 NMHX2610 NMHX2607 NMHX1015 NMHX1014<br />

Driver<br />

2.42mm<br />

Motor Mount<br />

2.42mm<br />

Implant Sterile Blister<br />

Information<br />

Sticker<br />

Tube<br />

Casing<br />

Implant<br />

Seal<br />

Cup<br />

Cover<br />

Screw<br />

Non-Holder Packaging<br />

/ 6 / <strong>Implants</strong>


One Piece <strong>Implants</strong> Index<br />

Pages 26-27 Pages 26-27 Pages 28-29<br />

MBI MBI NC Mono<br />

MBI Drivers<br />

Mono Drivers<br />

NM-X2415 NM-X1520 NM-X1018 NM-X1019 NM-X1620<br />

Driver<br />

Motor Mount<br />

Driver<br />

Driver<br />

Motor Mount<br />

1.7mm<br />

1.7mm<br />

2.15mm<br />

2.15mm<br />

2.15mm<br />

Information<br />

Sticker<br />

Tube<br />

Casing<br />

Implant<br />

Implant<br />

Holder<br />

Cover<br />

Screw<br />

Holder Packaging<br />

/ 7 /


Tuff<br />

L2<br />

2<br />

D<br />

With their three thread zones, Tuff implants have<br />

been uniquely designed according to the anatomy of<br />

the bone structure. The lower V-shape thread zone<br />

enables self-tapping. The middle zone square type<br />

thread is used for compressing cancellous bone and<br />

helping achieve maximum BIC. The micro thread on<br />

the upper zone adds stability and prevents crestal<br />

bone loss.<br />

2.42<br />

Implant Tuff<br />

3.75<br />

Material: Titanium (Ti6Al4V ELI)<br />

Treatment: RBM<br />

Available in two neck textures versions:<br />

Machined surface or RBM treated surface.<br />

L<br />

D1<br />

D<br />

1200-<br />

Drilling Speed (RPM)<br />

1500 1200 900- 500-<br />

700<br />

500-<br />

700<br />

400-<br />

700<br />

400-<br />

700<br />

400-<br />

600<br />

400-<br />

600<br />

400-<br />

600<br />

400-<br />

600<br />

300-<br />

500<br />

300-<br />

500<br />

200-<br />

500<br />

Drill Diameter md ø2.0 ø2.8 ø2.8 ø3.2 ø3.2 ø3.65 ø3.65 ø4.2 ø4.2 ø5.2 ø5.2 ø5-6<br />

? ? ? ?<br />

? ?<br />

Drill Sequence*<br />

Bone type D1, D2<br />

6<br />

10<br />

16<br />

ø3.3 ø3.3 ø3.3 ø3.75 ø3.75 ø4.2 ø4.2 ø5.0 ø5.0 ø6.0 ø6.0<br />

? Torque Too high Further Drilling Sequence Insert Implant<br />

Drilling Speed (RPM)<br />

1200-<br />

1500<br />

900-<br />

1200<br />

500-<br />

700<br />

400-<br />

700<br />

400-<br />

600<br />

400-<br />

600<br />

300-<br />

500<br />

Drill Diameter md ø2.0 ø2.8 ø3.2 ø3.65 ø4.2 ø5.2<br />

Drill Sequence*<br />

Bone type D3, D4<br />

6<br />

10<br />

16<br />

ø3.3 ø3.75 ø4.2 ø5.0 ø6.0<br />

* The proposed procedure is only a recommendation and should not replace the doctor's judgment.<br />

The implants may be placed in immediate function when good primary stability (above 35 Ncm) has been achieved and with appropriate occlusal loading.<br />

* Implant Carrier removal After the osteotomy preparation, the implant should be inserted with the aid of the implant carrier.<br />

The implant should be initially stabilized by a few threads and then the carrier should be removed. Farther insertion of the implant will be done with appropriate tool.<br />

* Implant hexagon During implant insertion, the hexagon of the implant, should be located with a straight part of the hexagon toward the angulation needed, in order<br />

to provide adequate rehabilitation.<br />

/ 8 / <strong>Implants</strong>


<strong>Implants</strong> Ø D (mm) Ø D1 (mm) L (mm) RBM Treated Neck Machined Neck<br />

8 NM-F3308 NMSF3308<br />

10 NM-F3310 NMSF3310<br />

3.3 2.6<br />

3.75 3.1<br />

4.2 3.5<br />

5.0 4.5<br />

6.0 5.2<br />

11.5 NM-F3311 NMSF3311<br />

13 NM-F3313 NMSF3313<br />

16 NM-F3316 NMSF3316<br />

6 NM-F3706 NMSF3706<br />

8 NM-F3708 NMSF3708<br />

10 NM-F3710 NMSF3710<br />

11.5 NM-F3711 NMSF3711<br />

13 NM-F3713 NMSF3713<br />

16 NM-F3716 NMSF3716<br />

18 NM-F3718 NMSF3718<br />

6 NM-F4206 NMSF4206<br />

8 NM-F4208 NMSF4208<br />

10 NM-F4210 NMSF4210<br />

11.5 NM-F4211 NMSF4211<br />

13 NM-F4213 NMSF4213<br />

16 NM-F4216 NMSF4216<br />

18 NM-F4218 NMSF4218<br />

20 NM-F4220 NMSF4220<br />

22 NM-F4222 NMSF4222<br />

25 NM-F4225 NMSF4225<br />

6 NM-F5006 NMSF5006<br />

8 NM-F5008 NMSF5008<br />

10 NM-F5010 NMSF5010<br />

11.5 NM-F5011 NMSF5011<br />

13 NM-F5013 NMSF5013<br />

16 NM-F5016 NMSF5016<br />

6 NM-F6006 NMSF6006<br />

8 NM-F6008 NMSF6008<br />

10 NM-F6010 NMSF6010<br />

11.5 NM-F6011 NMSF6011<br />

13 NM-F6013 NMSF6013<br />

16 NM-F6016 NMSF6016<br />

Cover Screw Included with all implants NM-S5023<br />

/ 9 /<br />

Mono MBI & MBI NC Zygomatic PteryFit PteryCore Cortical Onyx Tuff TT Tuff Pro Tuff


Tuff Pro<br />

Tuff Pro implants have been uniquely designed to<br />

match the anatomy of the bone structure. The lower<br />

V-shape thread zone enables self-tapping. The middle<br />

zone square type thread is used for compressing<br />

cancellous bone and helping achieve maximum BIC.<br />

The smooth “Neck” surface at the top helps in<br />

eliminating the adherence of Perio-Pathogens, thus<br />

reducing the chances of an inflammatory process<br />

to develop around the neck area. The RBM treated<br />

surface increases the BIC.<br />

Material: Titanium (Ti6Al4V ELI)<br />

Treatment: RBM<br />

L<br />

2<br />

2.42<br />

3.75<br />

D1<br />

D<br />

1200-<br />

Drilling Speed (RPM)<br />

1500 1200 900- 500-<br />

700<br />

500-<br />

700<br />

400-<br />

700<br />

400-<br />

700<br />

400-<br />

600<br />

400-<br />

600<br />

400-<br />

600<br />

400-<br />

600<br />

NMAFXXXX-Tuff<br />

300-<br />

500<br />

300-<br />

500<br />

Drill Diameter md ø2.0 ø2.8 ø2.8 ø3.2 ø3.2 ø3.65 ø3.65 ø4.2 ø4.2 ø5.2 ø5.2<br />

? ? ? ?<br />

?<br />

Drill Sequence*<br />

Bone type D1, D2<br />

6<br />

10<br />

16<br />

ø3.3 ø3.3 ø3.3 ø3.75 ø3.75 ø4.2 ø4.2 ø5.0 ø5.0<br />

? Torque Too high Further Drilling Sequence Insert Implant<br />

Drilling Speed (RPM)<br />

1200-<br />

1500<br />

900-<br />

1200<br />

500-<br />

700<br />

400-<br />

700<br />

400-<br />

600<br />

400-<br />

600<br />

Drill Diameter md ø2.0 ø2.8 ø3.2 ø3.65 ø4.2<br />

Drill Sequence*<br />

Bone type D3, D4<br />

6<br />

10<br />

16<br />

ø3.3 ø3.75 ø4.2 ø5.0<br />

* The proposed procedure is only a recommendation and should not replace the doctor's judgment.<br />

The implants may be placed in immediate function when good primary stability (above 35 Ncm) has been achieved and with appropriate occlusal loading.<br />

* Implant Carrier removal After the osteotomy preparation, the implant should be inserted with the aid of the implant carrier.<br />

The implant should be initially stabilized by a few threads and then the carrier should be removed. Farther insertion of the implant will be done with appropriate tool.<br />

* Implant hexagon During implant insertion, the hexagon of the implant, should be located with a straight part of the hexagon toward the angulation needed, in order<br />

to provide adequate rehabilitation.<br />

/ 10 / <strong>Implants</strong>


<strong>Implants</strong> Ø D (mm) Ø D1 (mm) L (mm) Item<br />

8 NMAF3308<br />

10 NMAF3310<br />

3.3 2.6<br />

3.75 3.1<br />

4.2 3.5<br />

5.0 4.5<br />

Cover Screw Included with all implants<br />

11.5 NMAF3311<br />

13 NMAF3313<br />

16 NMAF3316<br />

8 NMAF3708<br />

10 NMAF3710<br />

11.5 NMAF3711<br />

13 NMAF3713<br />

16 NMAF3716<br />

8 NMAF4208<br />

10 NMAF4210<br />

11.5 NMAF4211<br />

13 NMAF4213<br />

16 NMAF4216<br />

8 NMAF5008<br />

10 NMAF5010<br />

11.5 NMAF5011<br />

13 NMAF5013<br />

16 NMAF5016<br />

NM-S5023<br />

/ 11 /<br />

Mono MBI & MBI NC Zygomatic PteryFit PteryCore Cortical Onyx Tuff TT Tuff Pro Tuff


Tuff TT<br />

L2<br />

2<br />

D<br />

Tuff TT <strong>Implants</strong> share the same three-thread zone<br />

concept as Tuff implants. The taper top converging<br />

coronal shape allows platform switch technology to<br />

prevent crestal bone loss.<br />

Material: Titanium (Ti6Al4V ELI)<br />

Treatment: RBM<br />

2.42<br />

Implant Tuff TT<br />

3.75<br />

L<br />

D1<br />

D<br />

Drilling Speed (RPM)<br />

1200-<br />

1500<br />

900-<br />

1200<br />

500-<br />

700 400-700<br />

400-<br />

600<br />

400-<br />

600<br />

400-<br />

600<br />

300-<br />

500<br />

300-<br />

500<br />

200-<br />

500<br />

Drill Diameter md ø2.0 ø2.8 ø3.2 ø3.65 ø4.2 ø5-6 ø5.2 ø5-6 ø5-6<br />

? ? ?<br />

Drill Sequence*<br />

Bone type D1, D2<br />

6<br />

10<br />

16<br />

? Torque Too high Further Drilling Sequence Insert Implant<br />

ø4.2 ø4.2 ø5.0 ø6.0 ø6.0<br />

Drilling Speed (RPM)<br />

1200-<br />

1500<br />

900-<br />

1200<br />

500-<br />

700 400-700<br />

400-<br />

600<br />

400-<br />

600<br />

300-<br />

500<br />

Drill Diameter md ø2.0 ø2.8 ø3.2 ø3.65 ø4.2 ø5.2<br />

Drill Sequence*<br />

Bone type D3, D4<br />

6<br />

10<br />

16<br />

ø4.2 ø5.0 ø6.0<br />

* The proposed procedure is only a recommendation and should not replace the doctor's judgment.<br />

The implants may be placed in immediate function when good primary stability (above 35 Ncm) has been achieved and with appropriate occlusal loading.<br />

* Implant Carrier removal After the osteotomy preparation, the implant should be inserted with the aid of the implant carrier.<br />

The implant should be initially stabilized by a few threads and then the carrier should be removed. Farther insertion of the implant will be done with appropriate tool.<br />

* Implant hexagon During implant insertion, the hexagon of the implant, should be located with a straight part of the hexagon toward the angulation needed, in order<br />

to provide adequate rehabilitation.<br />

/ 12 / <strong>Implants</strong>


implants Ø D (mm) Ø D1 (mm) L (mm) Item<br />

6 NM-F4306<br />

8 NM-F4308<br />

10 NM-F4310<br />

4.2 3.5<br />

5.0 4.2<br />

6.0 5.0<br />

Cover Screw Included with all implants<br />

11.5 NM-F4311<br />

13 NM-F4313<br />

16 NM-F4316<br />

18 NM-F4318<br />

20 NM-F4320<br />

6 NM-F5106<br />

8 NM-F5108<br />

10 NM-F5110<br />

11.5 NM-F5111<br />

13 NM-F5113<br />

16 NM-F5116<br />

6 NM-F6106<br />

8 NM-F6108<br />

10 NM-F6110<br />

11.5 NM-F6111<br />

13 NM-F6113<br />

NM-S5023<br />

/ 13 /<br />

Mono MBI & MBI NC Zygomatic PteryFit PteryCore Cortical Onyx Tuff TT Tuff Pro Tuff


Onyx<br />

L2<br />

2<br />

D<br />

Onyx implants are specially designed for treatments<br />

involving placement in type I and type II bone.<br />

Material: Titanium (Ti6Al4V ELI)<br />

Treatment: RBM<br />

2.42<br />

Implant Onyx<br />

3.75<br />

L<br />

D1<br />

D<br />

Drilling Speed (RPM)<br />

1200-<br />

1500<br />

900-<br />

1200<br />

500-<br />

700 400-700<br />

200-<br />

500<br />

400-<br />

600<br />

200-<br />

500<br />

400-<br />

600<br />

200-<br />

500<br />

300-<br />

500<br />

200-<br />

500<br />

Drill Diameter md ø2.0 ø2.8 ø3.2 ø3.75 ø3.65 ø3.75 ø4.2 ø5-6 ø5.2 ø5-6<br />

Drill Sequence*<br />

Bone type D1, D2<br />

6<br />

10<br />

16<br />

ø3.3 ø3.75 ø4.2 ø5.0 ø6.0<br />

Drilling Speed (RPM)<br />

1200-<br />

1500<br />

900-<br />

1200<br />

500-<br />

700 400-700<br />

400-<br />

600<br />

400-<br />

600<br />

300-<br />

500<br />

Drill Diameter md ø2.0 ø2.8 ø3.2 ø3.65 ø4.2 ø5.2<br />

Drill Sequence*<br />

Bone type D3, D4<br />

6<br />

10<br />

16<br />

ø3.3 ø3.75 ø4.2 ø5.0 ø6.0<br />

* The proposed procedure is only a recommendation and should not replace the doctor's judgment.<br />

The implants may be placed in immediate function when good primary stability (above 35 Ncm) has been achieved and with appropriate occlusal loading.<br />

* Implant Carrier removal After the osteotomy preparation, the implant should be inserted with the aid of the implant carrier.<br />

The implant should be initially stabilized by a few threads and then the carrier should be removed. Farther insertion of the implant will be done with appropriate tool.<br />

* Implant hexagon During implant insertion, the hexagon of the implant, should be located with a straight part of the hexagon toward the angulation needed, in order<br />

to provide adequate rehabilitation.<br />

/ 14 / <strong>Implants</strong>


<strong>Implants</strong> Ø D (mm) Ø D1 (mm) L (mm) Item<br />

8 NM-G3308<br />

10 NM-G3310<br />

3.3 2.4<br />

3.75 2.8<br />

4.2 3.2<br />

5.0 4.0<br />

6.0 5.0<br />

Cover Screw Included with all implants<br />

11.5 NM-G3311<br />

13 NM-G3313<br />

16 NM-G3316<br />

6 NM-G3706<br />

8 NM-G3708<br />

10 NM-G3710<br />

11.5 NM-G3711<br />

13 NM-G3713<br />

16 NM-G3716<br />

6 NM-G4206<br />

8 NM-G4208<br />

10 NM-G4210<br />

11.5 NM-G4211<br />

13 NM-G4213<br />

16 NM-G4216<br />

6 NM-G5006<br />

8 NM-G5008<br />

10 NM-G5010<br />

11.5 NM-G5011<br />

13 NM-G5013<br />

16 NM-G5016<br />

6 NM-G6006<br />

8 NM-G6008<br />

10 NM-G6010<br />

11.5 NM-G6011<br />

13 NM-G6013<br />

NM-S5023<br />

/ 15 /<br />

Mono MBI & MBI NC Zygomatic PteryFit PteryCore Cortical Onyx Tuff TT Tuff Pro Tuff


Cortical<br />

Cortical<br />

4<br />

Cortical implants provide good stability for immediate<br />

loading. Its sharp, deep threads provide extremely<br />

strong retention for primary implant stability.<br />

The threads’ location gives stability in the cortical<br />

bone. The Cortical system can be used in extraction<br />

sites for immediate implantation. Cortical is available<br />

in different sizes to suit any implantation site.<br />

L1<br />

4<br />

3.75<br />

L<br />

2.42<br />

4<br />

3.75<br />

Cortical<br />

2<br />

Material: Titanium (Ti6Al4V ELI)<br />

Treatment: RBM<br />

L2<br />

L1<br />

4<br />

1.6<br />

D<br />

L2<br />

L<br />

1.6<br />

D<br />

Drilling Speed (RPM)<br />

1200-<br />

1500<br />

900-<br />

1200<br />

500-<br />

700<br />

200-<br />

500 400-700<br />

200-<br />

500<br />

Drill Diameter md ø2.0 ø2.8 ø3.2 ø3.2 ø3.65<br />

? ?<br />

Drill Sequence*<br />

Bone type D1, D2<br />

6<br />

10<br />

16<br />

ø4.0 ø4.0 ø5.0 ø5.0 ø6.0<br />

? Torque Too high Further Drilling Sequence Insert Implant<br />

Drilling Speed (RPM)<br />

1200-<br />

1500<br />

900-<br />

1200<br />

Drill Diameter md ø2.0<br />

Drill Sequence*<br />

Bone type D3, D4<br />

6<br />

10<br />

16<br />

ø4.0 ø5.0 ø6.0<br />

* The proposed procedure is only a recommendation and should not replace the doctor's judgment.<br />

The implants may be placed in immediate function when good primary stability (above 35 Ncm) has been achieved and with appropriate occlusal loading.<br />

* Implant Carrier removal After the osteotomy preparation, the implant should be inserted with the aid of the implant carrier.<br />

The implant should be initially stabilized by a few threads and then the carrier should be removed. Farther insertion of the implant will be done with appropriate tool.<br />

* Implant hexagon During implant insertion, the hexagon of the implant, should be located with a straight part of the hexagon toward the angulation needed, in order<br />

to provide adequate rehabilitation.<br />

/ 16 / <strong>Implants</strong>


<strong>Implants</strong> Ø D (mm) L (mm) L1 (mm) L2 (mm) Item<br />

10 4.5 5.5 NM-M4010<br />

11.5 4.7 6.8 NM-M4011<br />

4.0<br />

5.0<br />

6.0<br />

13 5 8 NM-M4013<br />

16 6 10 NM-M4016<br />

18 7 11 NM-M4018<br />

20 7.5 12.5 NM-M4020<br />

8 4.1 3.9 NM-M5008<br />

10 4.5 5.5 NM-M5010<br />

11.5 4.7 6.8 NM-M5011<br />

13 5 8 NM-M5013<br />

16 6 10 NM-M5016<br />

8 4.1 3.9 NM-M6008<br />

10 4.5 5.5 NM-M6010<br />

11.5 4.7 6.8 NM-M6011<br />

13 5 8 NM-M6013<br />

16 6 10 NM-M6016<br />

Cover Screw Included with all implants NM-S5023<br />

/ 17 /<br />

Mono MBI & MBI NC Zygomatic PteryFit PteryCore Cortical Onyx Tuff TT Tuff Pro Tuff


PteryCore<br />

PteryCore implants are installed in the posterior region of<br />

the atrophic Maxilla and located in the Pterygomaxillary<br />

region. Their Sharp, deep threads provide extremely strong<br />

retention for primary implant stability. As such they provide<br />

good stability for Immediate Loading procedures.<br />

2.42<br />

4.2<br />

3.75<br />

PteryCore <strong>Implants</strong> are designed to have a smooth<br />

surface at their “Neck”, followed by RBM treated surface<br />

underneath.<br />

The smooth “Neck” surface at the top helps in eliminating<br />

the adherence of Perio-Pathogens, thus reducing the<br />

chances of an inflammatory process to develop around the<br />

neck area. The RBM treated surface increases the BIC.<br />

L1<br />

L2<br />

4<br />

L<br />

Material: Titanium (Ti6Al4V ELI)<br />

Treatment: RBM<br />

1.7<br />

4.2<br />

Cortical-Preticore<br />

<strong>Implants</strong> Ø D (mm) L (mm) L1 (mm) L2 (mm) Item<br />

18 7 11 NM-M4218<br />

4.2<br />

20 7 13 NM-M4220<br />

22.5 7 15.5 NM-M4222<br />

25 7 18 NM-M4225<br />

Cover Screw Included with all implants<br />

NM-S5023<br />

/ 18 / <strong>Implants</strong>


PteryFit<br />

PteryFit implants are installed in the posterior<br />

region of the atrophic Maxilla and are located in the<br />

Pterygomaxillary region.<br />

PteryFit implants have been uniquely designed to match<br />

the anatomy of the bone structure. The lower V-shaped<br />

thread zone enables self-tapping. The middle zone<br />

square type thread is used for compressing cancellous<br />

bone and help achieving maximum BIC.<br />

The smooth “Neck” surface at the top helps in<br />

eliminating the adherence of Perio-Pathogens,<br />

thus reducing the chances of an inflammatory<br />

process to develop around the neck area.<br />

The RBM treated surface increases the BIC.<br />

Material: Titanium (Ti6Al4V ELI)<br />

Treatment: RBM<br />

<strong>Implants</strong> Ø D (mm) Ø D1 (mm) L (mm) Item<br />

4.2 2.5<br />

Cover Screw Included with all implants<br />

18 NMAF4218<br />

20 NMAF4220<br />

22 NMAF4222<br />

25 NMAF4225<br />

NM-S5023<br />

L<br />

5<br />

2.42<br />

3.75<br />

D1<br />

D<br />

NMAF42XX<br />

/ 19 /<br />

Mono MBI & MBI NC Zygomatic PteryFit PteryCore Cortical Onyx Tuff TT Tuff Pro Tuff


20 / <strong>Implants</strong><br />

Pterygoid <strong>Implants</strong> for<br />

Posterior Maxilla Rehabilitation


16<br />

18<br />

20<br />

22<br />

25<br />

16<br />

18<br />

20<br />

22<br />

25<br />

Pterygoid <strong>Implants</strong> Tools<br />

Osteotomes<br />

Ø D (mm)<br />

Item<br />

2.0 NM-X3001<br />

3.0 NM-X3002<br />

Long Drills<br />

Depth Groove<br />

(mm)<br />

16<br />

18<br />

20<br />

22<br />

Ø D (mm) Item L (mm)<br />

25<br />

2.3 NM-D7423 43<br />

2.8 NM-D7428 43<br />

3.2 NM-D7432 43<br />

3.65 NM-D7436 43<br />

11.5<br />

Depth Groove<br />

(mm)<br />

13<br />

15<br />

L<br />

18<br />

20<br />

22<br />

25<br />

Color Code<br />

Laser Mark<br />

3.2<br />

/ 21 /<br />

Mono MBI & MBI NC Zygomatic PteryFit PteryCore Cortical Onyx Tuff TT Tuff Pro Tuff


L<br />

L<br />

Zygomatic<br />

3.75<br />

2.42<br />

The Zygomatic Implant is designed to provide a<br />

solution for cases of atrophic maxilla. The shape<br />

of the Zygomatic Implant consists of sharp threads<br />

at the apical part for maximum retention to the<br />

Zygomatic bone. The implant has 2.42mm internal<br />

hex. connection, which enable simple and easy<br />

restoration. The Zygomatic Implant is available in<br />

a variety of lengths, from 30mm to 60mm.<br />

3.75<br />

2.42<br />

Material: Titanium (Ti6Al4V ELI)<br />

Treatment: RBM<br />

12.5<br />

D1<br />

D<br />

12.5<br />

D1<br />

D<br />

<strong>Implants</strong> Ø D (mm) Ø D1 (mm) L (mm) Item<br />

30 NM-F4430<br />

32.5 NM-F4432<br />

35 NM-F4435<br />

37.5 NM-F4437<br />

40 NM-F4440<br />

42.5 NM-F4442<br />

4.2 3.5<br />

45 NM-F4445<br />

47.5 NM-F4447<br />

50 NM-F4450<br />

52.5 NM-F4452<br />

55 NM-F4455<br />

57.5 NM-F4457<br />

60 NM-F4460<br />

Cover Screw Included with all implants<br />

NM-S5023<br />

/ 22 / <strong>Implants</strong>


Drill Sequence<br />

60<br />

55<br />

50<br />

45<br />

40<br />

35<br />

30<br />

16<br />

8<br />

4<br />

0<br />

Bone<br />

Type<br />

1<br />

60<br />

55<br />

50<br />

45<br />

40<br />

35<br />

ø4.2<br />

ø3<br />

ø2.5<br />

ø2<br />

2<br />

60<br />

55<br />

50<br />

45<br />

40<br />

35<br />

ø4.2<br />

ø3<br />

ø2.8<br />

3<br />

60<br />

55<br />

50<br />

45<br />

40<br />

35<br />

ø4.2<br />

ø3.2<br />

ø2.8<br />

3<br />

60<br />

55<br />

50<br />

45<br />

40<br />

35<br />

1 2 3 3<br />

ø4.2<br />

ø3.2<br />

ø2.8<br />

D4 D3 D2 D1<br />

/ 23 /<br />

Mono MBI & MBI NC Zygomatic PteryFit PteryCore Cortical Onyx Tuff TT Tuff Pro Tuff


Zygomatic<br />

Zygomatic Surgical Kit NM-X2118<br />

Step Drill for Zygoma, ø2.0, L 60mm<br />

Step Drill for Zygoma, ø2.8, L 60mm<br />

Step Drill for Zygoma, ø3.2, L 60mm<br />

Step Drill for Zygoma, ø2.0, L 80mm<br />

Step Drill for Zygoma, ø2.8, L 80mm<br />

Step Drill for Zygoma, ø3.2, L 80mm<br />

Diamond Burr, ø4.2mm, L 30mm, Fine<br />

Diamond Burr, ø4.2mm, L 30mm, Medium<br />

Diamond Burr, ø4.2mm, L 30mm, Coarse<br />

Depth Probe 35mm to 57.5mm<br />

Motor Mount 2.4mm, L 28mm<br />

Driver Hex 2.4mm, L 20mm<br />

Driver Hex 1.25mm, L 10.0mm<br />

Hand driver Star-Hex1.25, L 14.0mm<br />

NM-D7020<br />

NM-D7028<br />

NM-D7032<br />

NM-D7120<br />

NM-D7128<br />

NM-D7132<br />

NM-D7201<br />

NM-D7202<br />

NM-D7203<br />

NM-X1028<br />

NMHX1015<br />

NMHX2620<br />

NM-X1210<br />

NM-X7007<br />

/ 24 / <strong>Implants</strong>


Zygomatic Step Drills<br />

0 D (mm) L (mm) Drill No. Item<br />

2.0<br />

2.8<br />

3.2<br />

40<br />

0 D (mm) L (mm) Item<br />

4.2 30<br />

Fine Grit<br />

Depth Probe NM-X1028<br />

1<br />

Zygomatic Burs for Groove Preparation<br />

Medium Grit<br />

Coarse Grit<br />

35 40 45 50 55 60<br />

Drilling Depth (mm)<br />

NM-D7520<br />

60 NM-D7020<br />

80 NM-D7120<br />

40<br />

2<br />

NM-D7528<br />

60 NM-D7028<br />

80 NM-D7128<br />

40<br />

3<br />

L<br />

NM-D7532<br />

60 NM-D7032<br />

80 NM-D7132<br />

NM-D7201<br />

NM-D7202<br />

NM-D7203<br />

/ 25 /<br />

Mono MBI & MBI NC Zygomatic PteryFit PteryCore Cortical Onyx Tuff TT Tuff Pro Tuff


MBI / MBI NC<br />

MBI & MBI NC are One-Piece, self-tapping<br />

<strong>Implants</strong>, with integrated ball attachment,<br />

for single-stage implantation to stabilize<br />

a tissue-supported denture. Designed<br />

for placement in a very narrow ridge.<br />

MBI & MBI NC features a unique thread<br />

for immediate insertion. The implants can<br />

be placed in all types of bone and can be<br />

subjected to immediate load.<br />

4<br />

H<br />

Material: Titanium (Ti6Al4V ELI)<br />

Treatment: RBM<br />

L<br />

1.7<br />

1.8<br />

4.2<br />

1.7<br />

1.8<br />

L<br />

L1<br />

D1<br />

D<br />

D<br />

Mini Ball Implant<br />

Drilling Speed (RPM)<br />

1200-<br />

1500<br />

1200-<br />

1500 900-1200<br />

Implant MBI-NMTV<br />

Drill Diameter ø1.2 ø1.5 ø2.0<br />

Drill Sequence*<br />

Bone type D1, D2<br />

6<br />

10<br />

16<br />

ø2.0 ø2.4 ø2.9<br />

Drilling Speed (RPM)<br />

1200-<br />

1500<br />

1200-<br />

1500<br />

1200-<br />

1500<br />

1200-<br />

1500<br />

Drill Diameter ø1.2 ø1.2 ø1.5 ø1.5<br />

Drill Sequence*<br />

Bone type D3, D4<br />

6<br />

10<br />

16<br />

ø2.0 ø2.4 ø2.9<br />

* The proposed procedure is only a recommendation and should not replace the doctor's judgment.<br />

MBI Torque Recommendations: Do not exceed 45 Ncm during implant placement.<br />

The implants may be placed in immediate function when good primary stability (above 35 Ncm) has been achieved and with appropriate occlusal loading.<br />

/ 26 / <strong>Implants</strong>


MBI<br />

<strong>Implants</strong> Ø D (mm) Ø D1 (mm) neck (H) (mm) L (mm) Item<br />

MBI NC (Non Collar)<br />

2.8<br />

ø 4.3<br />

2.0 1.0 2.5<br />

2.4 1.5 2.5<br />

2.9 1.9 2.5<br />

<strong>Implants</strong> Ø D (mm) Ø D1 (mm) neck (H) (mm) L (mm) Item<br />

2.0 1.0 0<br />

2.4 1.5 0<br />

2.9 1.9 0<br />

MBI & MBI NC Components<br />

NM-T3201 NM-T3202 NM-T3203<br />

Metal Cap Extra Soft Nylon Cap Soft Nylon Cap<br />

2.3<br />

10 NM-V2010<br />

13 NM-V2013<br />

16 NM-V2016<br />

18 NM-V2018<br />

10 NM-V2410<br />

13 NM-V2413<br />

16 NM-V2416<br />

18 NM-V2418<br />

10 NM-V2910<br />

13 NM-V2913<br />

16 NM-V2916<br />

18 NM-V2918<br />

10 NMTV2010<br />

13 NMTV2013<br />

16 NMTV2016<br />

18 NMTV2018<br />

10 NMTV2410<br />

13 NMTV2413<br />

16 NMTV2416<br />

18 NMTV2418<br />

10 NMTV2910<br />

13 NMTV2913<br />

16 NMTV2916<br />

18 NMTV2918<br />

NM-D2312 NM-D2315 NM-X1520 NM-X2415 NM-T6124 NM-T4410<br />

Drill<br />

Ø 1.2mm<br />

Drill<br />

Ø 1.5mm<br />

Motor Mount<br />

1.7mm<br />

Driver<br />

1.7mm<br />

ø 3.4<br />

Analog<br />

Transfer<br />

/ 27 /<br />

Mono MBI & MBI NC Zygomatic PteryFit PteryCore Cortical Onyx Tuff TT Tuff Pro Tuff


Mono<br />

L<br />

D1<br />

D<br />

Mono implants are specifically indicated for replacing<br />

maxillary lateral incisors and mandibular central and<br />

lateral incisors.<br />

The implants are cleared for immediate, non-occlusal<br />

provisionalization in single-tooth restorations.<br />

Multiple-unit restorations should be splinted together.<br />

In appropriate clinical conditions MONO <strong>Implants</strong><br />

may be loaded immediately.<br />

Material: Titanium (Ti6Al4V ELI)<br />

Treatment: RBM<br />

ONE-PIECE IMPLANT<br />

L 3 6.5<br />

2.15<br />

D2<br />

D1<br />

D<br />

2.15<br />

Drilling Speed (RPM)<br />

1200-<br />

1500<br />

1200-<br />

1500<br />

200-<br />

500<br />

900-<br />

1200<br />

200-<br />

500<br />

500-<br />

700<br />

200-<br />

500 400-700<br />

200-<br />

500<br />

Drill Diameter md ø1.5 ø2.0 ø2.0 ø2.8 ø2.8 ø3.2 ø3.2 ø3.65<br />

Drill Sequence*<br />

Bone type D1, D2<br />

6<br />

10<br />

16<br />

ø3.0 ø3.3 ø3.75 ø4.2 ø5.0<br />

Drilling Speed (RPM)<br />

1200-<br />

1500<br />

1200-<br />

1500<br />

200-<br />

500<br />

900-<br />

1200<br />

500-<br />

700<br />

500-<br />

700<br />

Drill Diameter md ø1.5 ø2.0 ø2.0 ø2.8 ø3.2<br />

Drill Sequence*<br />

Bone type D3, D4<br />

6<br />

10<br />

16<br />

ø3.0 ø3.3 ø3.75 ø4.2 ø5.0<br />

* The proposed procedure is only a recommendation and should not replace the doctor's judgment.<br />

The implants may be placed in immediate function when good primary stability (above 35 Ncm) has been achieved and with appropriate occlusal loading.<br />

/ 28 / <strong>Implants</strong>


Mono<br />

<strong>Implants</strong> Ø D (mm) ø D1 (mm) ø D2 (mm) L (mm) Item<br />

Bendable Mono<br />

Mono Components<br />

6<br />

10<br />

NM-D2315 NM-X1620 NM-X1018 NM-X1019 NM-X1720 NM-T6202 NM-T4420<br />

Drill<br />

Ø 1.5mm<br />

3.0 1.7 2.0<br />

3.3 2.0 2.0<br />

3.75 2.4 2.5<br />

4.2 2.9 2.8<br />

5.0 3.7 2.8<br />

Motor Mount<br />

2.15mm<br />

Driver<br />

2.15mm<br />

Driver<br />

2.15mm<br />

20<br />

10 NM-V3010<br />

11.5 NM-V3011<br />

13 NM-V3013<br />

16 NM-V3016<br />

10 NM-V3310<br />

11.5 NM-V3311<br />

13 NM-V3313<br />

16 NM-V3316<br />

10 NM-V3710<br />

11.5 NM-V3711<br />

13 NM-V3713<br />

16 NM-V3716<br />

10 NM-V4210<br />

11.5 NM-V4211<br />

13 NM-V4213<br />

16 NM-V4216<br />

18 NM-V4218<br />

10 NM-V5010<br />

11.5 NM-V5011<br />

13 NM-V5013<br />

<strong>Implants</strong> Ø D (mm) ø D1 (mm) ø D2 (mm) L (mm) Item<br />

3.75 2.4 1.8<br />

4.2 2.9 1.8<br />

10 NMBV3710<br />

11.5 NMBV3711<br />

13 NMBV3713<br />

16 NMBV3716<br />

10 NMBV4210<br />

11.5 NMBV4211<br />

13 NMBV4213<br />

16 NMBV4216<br />

Driver<br />

2.15mm<br />

Analog<br />

Transfer<br />

/ 29 /<br />

Mono MBI & MBI NC Zygomatic PteryFit PteryCore Cortical Onyx Tuff TT Tuff Pro Tuff


Packaging<br />

Implant Label<br />

Use by date<br />

Sterile package unless opened<br />

or damaged<br />

Sterilized using irradiation<br />

Do not re-use<br />

Do not resterilize<br />

Prosthetic Label<br />

Consult accompanying<br />

documents<br />

Caution: Federal law restricts this<br />

device to sale by or on the order of<br />

a licensed healthcare practitioner<br />

CEpartner4U<br />

Esdoornlaan 13, 3951 db Maarn,<br />

The Netherlands<br />

www.cepartner4u.eu<br />

/ 30 / <strong>Implants</strong>


Prosthetics<br />

/ 31 /


Prosthetic Workflow<br />

Pages 34 Page 35-37<br />

Healing Cap<br />

Impression Components<br />

Snap-On Transfer<br />

Clip-On Tray Transfer<br />

or<br />

Open Tray Transfer<br />

Closed Tray Transfer<br />

or<br />

Analog<br />

Prosthetic Components Drivers<br />

NM-X1207 NM-X1210 NM-X1215 NM-X1006 NM-X1007 NM-X1011 NM-X1008 NM-X1009 NM-X1010<br />

Driver<br />

1.25mm<br />

Hand Driver<br />

1.25mm<br />

Motor Mount<br />

1.25mm<br />

/ 32 / Prosthetics


Page 38-45 Page 46-47 Page 50-56<br />

Page 58-61<br />

Cement Retained<br />

Restorations<br />

CAD/CAM<br />

Screw Retained<br />

Restorations<br />

Removable<br />

Restorations<br />

Temporary Abutment<br />

Scan Bodies<br />

Straight Multi-Unit<br />

Ball Vari-Connect<br />

or<br />

or<br />

or<br />

Straight Abutment<br />

Titanium Base<br />

Angulated Multi-Unit<br />

Flat Vari-Connect<br />

or<br />

or<br />

or<br />

Angulated Abutment<br />

or<br />

Esthetic Screw<br />

Abutment<br />

Ball Attachment<br />

or<br />

Zirconia Abutment<br />

Flat Attachment<br />

or<br />

Castable Abutment<br />

Multi-Unit & Vari-Connect Drivers<br />

NM-X1016 NM-X1017 NM-X7006 NM-X7007 NM-X7011 NM-X7008 NM-X7009 NM-X7010<br />

Driver<br />

2.0mm<br />

Hand Driver<br />

1.25mm<br />

Motor Mount<br />

1.25mm<br />

/ 33 /


Healing Caps<br />

Healing caps prepare the site for the superstructure<br />

insertion and “shapes” the soft tissue surrounding the<br />

implant. Selecting the correct healing cap depends on<br />

the thickness of the mucosa. Wide healing caps are used<br />

for soft-tissue contouring of molars and premolars.<br />

Recommendation: Hand-tighten using a 1.25 mm hex.<br />

driver or a motor mount with a force of 10 Ncm.<br />

Material: Titanium (Ti6Al4V ELI)<br />

L<br />

Healing Cap<br />

3.750<br />

D<br />

1.28<br />

L (mm) Ø 3.8 (mm) Ø 4.6 (mm) Ø 5.5 (mm) Ø 6.3 (mm)<br />

2<br />

NM-H3802 NM-H4602 NM-H5502 -<br />

3<br />

NM-H3803 NM-H4603 NM-H5503 NM-H6303<br />

4<br />

NM-H3804 NM-H4604 NM-H5504 NM-H6304<br />

5<br />

NM-H3805 NM-H4605 NM-H5505 NM-H6305<br />

6<br />

NM-H3806 NM-H4606 NM-H5506 NM-H6306<br />

7<br />

NM-H3807 NM-H4607 NM-H5507 NM-H6307<br />

/ 34 / Prosthetics


Open & Closed Tray Transfers<br />

Transfers are designed for impressions using<br />

the open-tray technique when the retentions are<br />

sharp, and for the closed-tray technique when<br />

the retentions are round. The body of the transfer<br />

is made of stainless steel; the screws are made<br />

of titanium alloy.<br />

L<br />

Transfer T40XX<br />

Accessories<br />

Material: Stainless Steel<br />

2.42<br />

3.75<br />

D<br />

Open Tray Transfer<br />

Transfer Ø D (mm) L (mm)<br />

NM-T4008<br />

4.75 8<br />

Closed Tray Transfer<br />

Transfer Ø D (mm) L (mm)<br />

NM-T3601<br />

4.75 8<br />

Cement Retained<br />

Restorations<br />

NM-S1610<br />

Screw 16mm<br />

Included with all<br />

transfers above &<br />

available separately<br />

NM-S1307<br />

Screw 13mm<br />

Included with all<br />

transfers above &<br />

available separately<br />

NM-T4203<br />

NM-T4201<br />

3.85 12<br />

4.3 12<br />

NM-T3507<br />

NM-T3511<br />

3.85 12<br />

4.5 12<br />

Screw Retained<br />

Restorations<br />

NM-T4012<br />

4.75 12<br />

NM-S1610<br />

Screw 16mm<br />

Included with all<br />

transfers above &<br />

available separately<br />

NM-S2418<br />

Screw 24mm<br />

Included with all<br />

transfers above &<br />

available separately<br />

Non-Hexed Transfer<br />

Transfer Ø D (mm) L (mm)<br />

NM-T4204<br />

NM-S2418<br />

3.85 12<br />

Screw 24mm<br />

Included with all<br />

transfers above &<br />

available separately<br />

/ 35 /<br />

Removable<br />

Restorations


Snap-On Transfer<br />

The Snap-On Transfer is made of titanium alloy<br />

TI-6AL-4V and designed for impressions using the<br />

closed-tray technique, in conjunction with the cap<br />

T4402. The cap remains in the impression tray after<br />

it is removed from the mouth. It is also possible to<br />

use this type of transfer as esthetic abutments.<br />

33%<br />

Long Cap for transfer<br />

8<br />

Transfer T380X<br />

Material: Titanium (Ti6Al4V ELI)<br />

L<br />

L<br />

D<br />

2.42<br />

3.75<br />

D<br />

Plastic Cap for Snap-On Transfer<br />

Transfer Ø D (mm) L1 (mm)<br />

Cap Ø D (mm) L (mm)<br />

4.8 2<br />

4.8 11<br />

NM-T3802<br />

NM-T4402<br />

4.8 3<br />

NM-T3803<br />

4.8 4<br />

NM-T3804<br />

4.8 5<br />

NM-T3805<br />

4.8 6<br />

NM-T3806<br />

NM-S8324<br />

Included with all<br />

abutments<br />

above & available<br />

separately<br />

/ 36 / Prosthetics


Clip-On Transfer<br />

A clip-on connection transfer for impressions without<br />

a screw has a hexagonal lock to ensure a tight fit. It is<br />

especially effective with molars and premolars, where<br />

there is a lack of space, and where working with a<br />

driver is difficult. It is sufficient to use this transfer for<br />

all types of impressions as the lack of screws saves<br />

significant amount of time.<br />

Material: Stainless Steel<br />

L<br />

Transfer T34XX<br />

2.42<br />

Accessories<br />

3.75<br />

D<br />

Transfer Ø D (mm) L (mm)<br />

4.7 9<br />

Cement Retained<br />

Restorations<br />

NM-T3409<br />

NM-T3413<br />

Analog<br />

4.7 13<br />

Screw Retained<br />

Restorations<br />

Analog<br />

3.75<br />

2.43<br />

Analog Ø D (mm) L (mm)<br />

4 12.7<br />

L<br />

NM-T6004<br />

NM-T6005<br />

5 12.7<br />

The analog is made of stainless steel and is used<br />

in the preparation of laboratory models.<br />

Material: Stainless Steel<br />

D<br />

Removable<br />

Restorations<br />

/ 37 /


Temporary Abutments<br />

PEEK (polyetheretherketone) is a high-grade<br />

thermoplastic polymer which is certified for<br />

medical use. PEEK is characterized by a superior<br />

combination of strength, elasticity and resilience.<br />

PEEK is one of the most chemically resistant<br />

materials, Biocompatible and esthetic with low<br />

electrical conductivity. PEEK polymer is well suited<br />

for use in the oral cavity.<br />

Material: PEEK<br />

L<br />

2<br />

L1<br />

Abutment Anatomic<br />

A46XX<br />

2.42<br />

3.750<br />

D<br />

Technical Data:<br />

• Can be sterilized without changing the mechanical properties or biocompatibility violations.<br />

• Does not create artifacts in X-ray irradiation procedures, magnetic resonance imaging (MRI), and computed<br />

tomography (CT).<br />

• Has high compressive strength.<br />

• Possesses excellent mechanical properties such as stiffness and strength.<br />

• Has proven biocompatibility for both hard and soft tissue.<br />

• Does not contain metal additives to prevent ion exchange in the mouth.<br />

• Is a natural color, a superior esthetic advantage.<br />

Straight L (mm) Angulated 15° Angulated 25° L (mm) L1 (mm)<br />

9 9.5 1<br />

NM-C6001 NM-C5001 NM-C5201<br />

10 10.5 2<br />

NM-C6002 NM-C5002 NM-C5202<br />

11 11.5 3<br />

NM-C6003 NM-C5003 NM-C5203<br />

/ 38 / Prosthetics


Temporary Abutments<br />

The titanium Temporary Abutments are<br />

designed with deep retention grooves,<br />

for the acrylic prosthesis to hold to.<br />

The abutments are available hexed and<br />

non-hexed.<br />

L<br />

Straight Soulder A5001<br />

3.2<br />

Accessories<br />

Material: Titanium (Ti6Al4V ELI)<br />

L1<br />

Hexed Non-Hexed Short Non-Hexed L (mm) L1 (mm) Ø D (mm)<br />

2.42<br />

3.75<br />

D<br />

9.5 1.7 4.4<br />

Cement Retained<br />

Restorations<br />

NM-A5001 NM-A5002 -<br />

NM-A5101 - NM-A5102<br />

Included with all abutments above & available separately<br />

NM-S8324<br />

9.5 1.7 3.8<br />

Removable<br />

Restorations<br />

Screw Retained<br />

Restorations<br />

/ 39 /


Straight Abutments<br />

A wide variety of titanium straight abutments are<br />

available for use in different situations. These<br />

abutments remain stable, even when their wall<br />

thickness is reduced to 0.1 mm. They are used in the<br />

fabrication of cement-retained restorations, single<br />

crowns or bridges.<br />

Recommendation: Tighten the screw at a torque<br />

between 25 to 30 Ncm.<br />

Material: Titanium (Ti6Al4V ELI)<br />

L<br />

2<br />

L1<br />

Abutment Anatomic<br />

A46XX<br />

2.42<br />

3.750<br />

D<br />

Anatomic Ø D (mm) L (mm) L1 (mm)<br />

Shoulder Ø D (mm) L (mm) L1 (mm)<br />

NM-A4601<br />

5.2 9 1<br />

NM-A4801<br />

4.5 8.5 1<br />

NM-A4602<br />

5.2 10 2<br />

NM-A4802<br />

4.5 9.5 2<br />

NM-A4603<br />

5.2 11 3<br />

NM-A4803<br />

4.5 10.5 3<br />

NM-A4604<br />

5.2 12 4<br />

NM-A4804<br />

4.5 11.5 4<br />

NM-S8324<br />

Included with all abutments<br />

& available separately<br />

NM-C1005<br />

Available separately<br />

/ 40 / Prosthetics


Standard Ø D (mm) L (mm)<br />

NM-A5908<br />

4.5 8.5<br />

Standard Ø D (mm) L (mm)<br />

NM-A5601<br />

4.5 8.5<br />

Accessories<br />

NM-A5909<br />

4.5 9.5<br />

NM-A5602<br />

4.5 10.5<br />

NM-A5911<br />

4.5 11.5<br />

4.5 12.5<br />

Narrow Ø D (mm) L (mm)<br />

NM-A6006<br />

3.8 6<br />

3.8 8<br />

Cement Retained<br />

Restorations<br />

NM-A5912<br />

NM-A6008<br />

Shoulder, Narrow Ø D (mm) L (mm) L1 (mm)<br />

Mega Ø D (mm) L (mm)<br />

NM-A5300<br />

NM-A5301<br />

3.75 8.5 0.5<br />

3.75 8.5 1.5<br />

NM-A5515<br />

9 15<br />

Screw Retained<br />

Restorations<br />

3.75 8.5 2.5<br />

NM-A5302<br />

Wide Ø D (mm) L (mm)<br />

NM-A5709<br />

NM-A5711<br />

5.5 9<br />

5.5 11<br />

Removable<br />

Restorations<br />

/ 41 /


Angulated Abutments<br />

Angulated abutments are used when a change to<br />

the axis of the implant is required. Normally used<br />

for constructing cement-retained single crowns or<br />

bridges. The abutments are available with angles<br />

of 15° and 25° degrees.<br />

Recommendation: Tighten the screw at a torque<br />

between 25 to 30 Ncm.<br />

L<br />

Angular Abutment Anatomic 15<br />

A24XX<br />

L1<br />

15°<br />

Material: Titanium (Ti6Al4V ELI)<br />

2<br />

2.42<br />

3.75<br />

D<br />

Anatomic<br />

Angulated 15° Angulated 25° Ø D (mm) L (mm) L1 (mm)<br />

5.4 9.5 1<br />

NM-A2401<br />

NM-A2601<br />

5.4 10.5 2<br />

NM-A2402<br />

NM-A2602<br />

5.4 11.5 3<br />

NM-A2403<br />

NM-A2603<br />

5.4 12.5 4<br />

NM-A2404<br />

NM-A2604<br />

/ 42 / Prosthetics


Standard<br />

Angulated 15° Angulated 25° Ø D (mm) L (mm)<br />

4.5 9<br />

Narrow<br />

Angulated 15° Angulated 25° Ø D (mm) L (mm)<br />

4 9<br />

Accessories<br />

NM-A3209<br />

NM-A3409<br />

NM-A3609<br />

NM-A3809<br />

4.5 11<br />

NM-A3211<br />

NM-A3411<br />

Narrow Top<br />

Angulated 15° Angulated 25° L (mm)<br />

9<br />

Included with all abutments<br />

& available separately<br />

NM-A2809<br />

NM-A3009<br />

NM-S8324<br />

Removable<br />

Restorations<br />

Screw Retained<br />

Restorations<br />

Cement Retained<br />

Restorations<br />

/ 43 /


Titanium Base Zirconia Abutments<br />

Zirconia is an esthetic alternative material for the<br />

traditional titanium abutments. The abutments are<br />

available as fully cast zirconia or with a titanium<br />

base in a wide variety of shapes and sizes.<br />

L<br />

Angular Abutment Anatomic 15<br />

A24XX<br />

15°<br />

Material: Zirconium<br />

2<br />

L1<br />

2.42<br />

3.75<br />

D<br />

Anatomic<br />

Straight L (mm) L1 (mm) Angulated 15° Angulated 25° L (mm) L1 (mm)<br />

8.5 0.5 9 0.5<br />

NM-Z5600 NM-Z3400 NM-Z3600<br />

9 1 9.5 1<br />

NM-Z5601 NM-Z3401 NM-Z3601<br />

10 2 10.5 2<br />

NM-Z5602 NM-Z3402 NM-Z3602<br />

11 3 11.5 3<br />

NM-Z5603 NM-Z3403 NM-Z3603<br />

Titanium<br />

Base<br />

for Zirconia<br />

NM-S1001<br />

NM-Z1001<br />

/ 44 / Prosthetics


Castable Abutments<br />

Plastic Castable Abutments are intended for use<br />

by the technician for simple casting of custom-made<br />

abutments for constructing the prosthetic restoration.<br />

Plastic Castable Abutments on Titanium Bases<br />

enable the dental laboratory to cast on an accurate<br />

Titanium base. The machined Titanium base provides<br />

an accurate fit to the implant.<br />

L<br />

Angular Abutment Anatomic 15<br />

A24XX<br />

L1<br />

15°<br />

Accessories<br />

Material: Delrin<br />

2<br />

2.42<br />

3.75<br />

D<br />

Straight L (mm) Angulated 15° Angulated 25° L (mm) L1 (mm)<br />

9 9.5 1<br />

NM-C4001 NM-C3001 NM-C3201<br />

Cement Retained<br />

Restorations<br />

10 10.5 2<br />

NM-C4002 NM-C3002 NM-C3202<br />

11 11.5 3<br />

NM-C4003 NM-C3003 NM-C3203<br />

Hexed Non-Hexed L (mm) Ø D (mm) Angulated 15° L (mm) Ø D (mm)<br />

8.5 4.5 8.5 4.5<br />

Screw Retained<br />

Restorations<br />

NM-C2004 NM-C2003 NM-C2005<br />

10.5 3.25<br />

NM-C1002<br />

NM-C1001<br />

Titanium Base Co-Cr Base L (mm) Ø D (mm)<br />

NM-C2001 NM-C2002<br />

10.5 4.5<br />

NM-S8324<br />

Included with all<br />

abutments & available<br />

separately<br />

Removable<br />

Restorations<br />

/ 45 /


CAD/CAM Components<br />

The CAD/CAM components are especially designed<br />

for CAD/CAM fabrication of individual abutments.<br />

Recommendation:<br />

Tighten the screw NM-S8324 at a torque between 25 to 30 Ncm.<br />

Tighten the screw NM-S7102 at a torque of 15 Ncm.<br />

Material: Titanium (Ti6Al4V ELI) & PEEK<br />

Scan for downloading<br />

CAD/CAM library<br />

Scan Bodies Ø D (mm) L (mm)<br />

4.0 7<br />

NM-C9007<br />

4.5<br />

4.0 10<br />

NM-C9010<br />

4.0 13<br />

NM-C9013<br />

Single Unit Titanium Base Ø D (mm) L (mm) L1 (mm)<br />

4.8 4.5 1<br />

NM-C2201<br />

NM-C2201<br />

NM-C2212<br />

4.8 6.0 2<br />

2.42<br />

3.75<br />

D<br />

L<br />

L<br />

2.42<br />

3.75<br />

D<br />

L1<br />

4.8 7.0 3<br />

NM-C2213<br />

Multiple Units Titanium Base Ø D (mm) L (mm)<br />

Flat Platform Base for CAD/CAM<br />

4.8 4.5<br />

L<br />

NM-C2202<br />

2.42<br />

3.75<br />

D<br />

NM-S8324<br />

Included with all abutments<br />

& available separately<br />

/ 46 / Prosthetics


Multi-Unit Scan Bodies Ø D (mm) L (mm)<br />

NM-C9207<br />

4.9 7<br />

4.0<br />

Accessories<br />

4.9 10<br />

L<br />

NM-C9210<br />

D<br />

4.9 13<br />

NM-C9213<br />

Replacing NM-C9107, NM-C9110, NM-C9113<br />

Multi-Unit Titanium Base Ø D (mm) L (mm)<br />

NM-C7124<br />

4.9 4.5<br />

D<br />

L<br />

Cement Retained<br />

Restorations<br />

Included with all abutments<br />

NM-S7102<br />

Individual Blank for Milling Ø D (mm) L (mm)<br />

8<br />

M5<br />

10 26<br />

L<br />

NM-A5517<br />

3.75<br />

D<br />

2.42<br />

NM-S8324<br />

Included with all abutments<br />

& available separately<br />

Removable<br />

Restorations<br />

Screw Retained<br />

Restorations<br />

/ 47 /


IMMEDIATE<br />

LOADING<br />

A NEW SMILE<br />

IN ONE DAY<br />

/ 48 / Prosthetics


Multi-Unit<br />

/ 49 /


Multi-Unit | Straight & Angulated<br />

The Multi-Unit system provides a<br />

solution for screw-retained prostheses<br />

even on complicated-to-restore implants<br />

(for example, multiple tilted implants).<br />

The Multi-Unit system comprises a<br />

full range of sizes for both the upper<br />

and lower jaws. Straight, 17°, 30°, 45°,<br />

52° and 60° adaptors, in a variety of<br />

heights, connects to a wide range of<br />

complementary products.<br />

L1<br />

Multi Unit Abutment<br />

A710X<br />

2.0<br />

L1<br />

Multi Unit Base<br />

A711X<br />

a<br />

Material: Titanium (Ti6Al4V ELI)<br />

3.75<br />

4.9<br />

2.42<br />

3.75<br />

Straight<br />

L (mm)<br />

Angulated<br />

17 °<br />

Angulated<br />

30°<br />

Angulated<br />

45°<br />

Angulated<br />

52°<br />

Angulated<br />

60°<br />

L (mm)<br />

1<br />

NM-A7101<br />

2<br />

2<br />

NM-A7102<br />

NM-A7112<br />

3<br />

3<br />

NM-A7103<br />

NM-A7113<br />

NM-A7133<br />

4<br />

4<br />

NM-A7104<br />

NM-A7134<br />

NM-A7144<br />

5<br />

5<br />

NM-A7105<br />

NM-A7152<br />

NM-A7160<br />

NM-X7100<br />

Included with all multi-unit bases<br />

Included with all<br />

multi-unit bases<br />

NM-S7101<br />

NM-X7101<br />

Recommendation: Tighten the<br />

base at a torque of 25 Ncm.<br />

Recommendation: Tighten the screw at a torque of 20 Ncm.<br />

/ 50 / Prosthetics


Multi-Unit System<br />

60°<br />

52°<br />

45°<br />

30°<br />

17°<br />

0°<br />

Entire <strong>Product</strong> Line<br />

for Immediate Loading<br />

Removable<br />

Restorations<br />

Screw Retained<br />

Restorations<br />

Cement Retained<br />

Restorations<br />

Accessories<br />

/ 51 /


Multi-Unit Components<br />

Healing Cap<br />

Abutments<br />

Passive Fit Castable<br />

Abutment Kit<br />

Healing Cap<br />

Ø 4.9mm H 4.8mm<br />

NM-H7101<br />

Ø 3.3 mm<br />

Universal Abutment<br />

Ø 4.9mm H 12mm<br />

Universal Abutment<br />

Ø 4.9mm H 12mm<br />

Healing Cap<br />

Ø 4.9mm H 7.0mm<br />

NM-T7121<br />

NM-T7121<br />

NM-H7102<br />

Screw<br />

NM-S7102<br />

Ø 3.8 mm<br />

Wide Universal<br />

Abutment<br />

Ø 4.9mm H 12mm<br />

NM-T7123<br />

Castable Sleeve<br />

Ø 4.9mm H 10.5mm<br />

NM-C7120<br />

Included with all healing caps above & available separately<br />

Transfers & Analog<br />

Castable Abutment<br />

Ø 4.9mm H 12mm<br />

NM-C7121<br />

Castable Sleeve<br />

Positioner<br />

Ø 4.9mm H 10mm<br />

NM-T7122<br />

Open Tray<br />

Ø 4.9mm H 11mm<br />

NM-T7111<br />

Screw*<br />

NM-S7102<br />

Included with all abutments above & available separately<br />

Screw*<br />

NM-S7102<br />

Screw<br />

L 13mm<br />

NM-S7111<br />

Included with the transfer above & available separately<br />

Plastic Cap<br />

Ø 4.9mm H 11mm<br />

NM-T4402<br />

* Recommendation: Tighten the screw<br />

at a torque of 15 Ncm.<br />

Titanium Base<br />

Ø 4.9mm H 4.5mm<br />

NM-C7124<br />

Screw*<br />

The Passive Fit Castable Abutment Kit consists of<br />

three parts aimed for the fabrications of accurate<br />

metal reinforced prostheses.<br />

The Castable Sleeve Positioner is used for<br />

locating the Castable Sleeve on the plaster<br />

model, ensuring passive fit of the fabricated<br />

metal cast when cemented to the Titanium<br />

Abutments.<br />

* Recommendation: Tighten the screw at a<br />

torque of 15 Ncm.<br />

2 mm<br />

Closed Tray<br />

Ø 4.9mm H 8mm<br />

NM-T7102<br />

NM-S7102<br />

Included with the titanium base above & available separately<br />

Scan Bodies<br />

Screw<br />

NM-S7102<br />

* Recommendation: Tighten the screw<br />

at a torque of 15 Ncm.<br />

Ø 4.9mm H 7mm<br />

NM-C9207<br />

Included with the transfer above & available separately<br />

Ø 4.9mm H 10mm<br />

NM-C9210<br />

Analog<br />

Ø 4.9mm<br />

NM-T7151<br />

Ø 4.9mm H 13mm<br />

NM-C9213<br />

Screw<br />

NM-S7102<br />

Included with all scan bodies above & available separately<br />

/ 52 / Prosthetics


Multi-Unit Drivers<br />

Straight Multi-Unit Drivers<br />

Star Hex. Drivers<br />

Accessories<br />

Short Driver<br />

2.0mm L 6mm<br />

NM-X1016<br />

Star Hex. Driver<br />

1.25mm L 7mm<br />

NM-X7006<br />

Long Driver<br />

2.0mm L 10mm<br />

NM-X1017<br />

Straight Multi-Unit<br />

Motor Mounts<br />

Short Motor Mount<br />

2.0mm L 20mm<br />

NM-X1120<br />

Star Hex. Driver<br />

1.25mm L 14mm<br />

NM-X7007<br />

Star Hex. Driver<br />

1.25mm L 20mm<br />

NM-X7011<br />

Cement Retained<br />

Restorations<br />

Long Motor Mount<br />

2.0mm L 25mm<br />

NM-X1125<br />

Star Hex. Motor Mounts<br />

Motor Mount<br />

1.25mm L 20mm<br />

NM-X7008<br />

Motor Mount<br />

1.25mm L 25mm<br />

NM-X7009<br />

Motor Mount<br />

1.25mm L 35mm<br />

NM-X7010<br />

Removable<br />

Restorations<br />

Screw Retained<br />

Restorations<br />

/ 53 /


Multi-Unit Protocol<br />

Assembly of a Straight<br />

Multi-Unit Base<br />

Assembly of Angled<br />

Multi-Unit Base<br />

Healing Cap Assembly<br />

1<br />

1<br />

Adjust the straight<br />

Multi-Unit Base to<br />

the implant by using<br />

the plastic handle.<br />

use the Angulated<br />

Guide Pin to choose<br />

the right correction<br />

angle.<br />

30°<br />

17° 30°<br />

45° 52° 60°<br />

2<br />

Remove the handle.<br />

2<br />

Adjust the Multi-Unit<br />

base to the<br />

appropriate angle.<br />

Use the handle as an<br />

indicator for the final<br />

screw emergence.<br />

Impression<br />

Choose the desired<br />

impression technique:<br />

For closed tray<br />

choose Snap-On-<br />

Transfer.<br />

3<br />

3<br />

or<br />

Tighten the base<br />

at 25 Ncm, with<br />

a 2.0mm Straight<br />

Multi-Unit Driver.<br />

Tighten the<br />

base at 20 Ncm,<br />

with a 1.25mm<br />

Hex Driver or<br />

a Star Driver.<br />

For open tray<br />

technique choose<br />

conventional<br />

Transfer.<br />

4<br />

Remove the handle<br />

by unscrewing it out.<br />

/ 54 / Prosthetics


Immediate Loading<br />

(Fabrication of the temporary bridge)<br />

Laboratory Phase<br />

Passive Fit Castable<br />

Abutment Kit<br />

1 1<br />

Assemble the<br />

Titanium Sleeve on<br />

the Multi-Unit base<br />

and tighten the<br />

screw at 15 Ncm.<br />

2<br />

Mount the Plastic<br />

Sleeve on the<br />

Multi-Unit analog<br />

and tighten with the<br />

screw.<br />

2<br />

The Passive Fit Castable<br />

Abutment Kit consists of<br />

three parts aimed for the<br />

fabrication of accurate metal<br />

reinforced prostheses.<br />

The uniquely designed<br />

Castable Sleeve Positioner<br />

is used for locating the<br />

Castable Sleeve on the<br />

plaster model, ensuring<br />

passive fit of the fabricated<br />

metal cast when cemented<br />

to the Titanium Abutments.<br />

Attach the preprepared<br />

provisional<br />

acrylic prosthesis<br />

Splint the sleeves.<br />

3<br />

Carve the Sleeves to<br />

the desired shape.<br />

4<br />

Invest and cast the<br />

metal frame of the<br />

prosthesis.<br />

/ 55 /


Esthetic Screw Abutments<br />

Esthetic Screw Abutment is designed for the screw<br />

retained rehabilitation process on single or multiple units.<br />

NM-E10XX<br />

The height of the abutment is selected according to the<br />

thickness of the mucosa.<br />

The Esthetic Screw Abutment base is supplied with<br />

an appropriate screw adjusted to the height of the<br />

abutment together with a plastic sleeve for casting.<br />

2.1<br />

L<br />

Sleeves are available with or without internal hex.<br />

Material: Titanium (Ti6Al4V ELI)<br />

2.42<br />

3.75<br />

4.7<br />

Base<br />

L (mm)<br />

Screw<br />

L (mm)<br />

0.5<br />

10.5<br />

NM-E1005<br />

NM-S1002<br />

1.5<br />

11.5<br />

NM-E1015<br />

NM-S1102<br />

2.5<br />

12.5<br />

NM-E1025<br />

NM-S1202<br />

Hexed Non-Hexed L (mm)<br />

12<br />

NM-C1015<br />

NM-C1007<br />

/ 56 / Prosthetics


Vari-Connect<br />

/ 57 /


Vari-Connect<br />

The Vari-Connect system presents a complete solution for removable prostheses on tilted implants. It provides<br />

all the required equipment for removable prostheses, both on ball attachments and flat attachments, covering<br />

a wide range of possible situations. 17°, 30° and 45° adaptors are available. Complementary products are fixed<br />

to the adaptors by the adaptor thread.<br />

Material: Titanium (Ti6Al4V ELI)<br />

Multi Unit Base<br />

A72XX<br />

a<br />

L<br />

2.42<br />

3.75<br />

Angulated 17 ° Angulated 30° Angulated 45° L (mm)<br />

2<br />

NM-A7212 - -<br />

3<br />

NM-A7213 NM-A7233 -<br />

4<br />

- NM-A7234 NM-A7244<br />

Included with all vari-connect bases<br />

NM-S7101<br />

NM-X7101<br />

Recommendation: Tighten the screw at a torque of 30 Ncm.<br />

/ 58 / Prosthetics


Vari-Connect Components<br />

Healing Cap<br />

Ball-Connect<br />

Flat-Connect<br />

Accessories<br />

Healing Cap<br />

Ø 4.9mm H 4.8mm<br />

Ball-Connect<br />

Ø 4.9mm, H 2mm<br />

Flat-Connect<br />

Ø 4.9mm, H 3mm<br />

NM-H7101<br />

NM-T7262<br />

NM-T7273<br />

Healing Cap<br />

Ø 4.9mm H 7.0mm<br />

Ball-Connect<br />

Ø 4.9mm, H 3mm<br />

Flat-Connect<br />

Ø 4.9mm, H 4mm<br />

NM-H7102<br />

NM-T7263<br />

NM-T7274<br />

Screw<br />

NM-S7102<br />

Included with all healing caps above & available separately<br />

Transfers & Analog<br />

Open Tray<br />

Ø 4.9mm H 11mm<br />

NM-T7111<br />

Screw<br />

L 13mm<br />

NM-S7111<br />

Included with the transfer above & available separately<br />

Ball-Connect<br />

Ø 4.9mm, H 4mm<br />

NM-T7264<br />

Metal Cap<br />

Ø 5mm, H 3.2mm<br />

NM-T3001<br />

Nylon Extra Soft Cap<br />

NM-T3002<br />

Nylon Soft Cap<br />

NM-T3003<br />

Nylon Standard Cap<br />

NM-T3004<br />

Metal Cap<br />

Ø 5.5mm, H 2.3mm<br />

NM-T3010<br />

Extra Soft Nylon Cap<br />

NM-T3015<br />

Soft Nylon Cap<br />

NM-T3016<br />

Standard Nylon Cap<br />

NM-T3017<br />

High Retention<br />

Nylon Cap<br />

NM-T3018<br />

Laboratory Cap<br />

Cement Retained<br />

Restorations<br />

2mm<br />

Plastic Cap<br />

Ø 4.9mm H 11mm<br />

NM-T4402<br />

Closed Tray<br />

Ø 4.9mm H 8mm<br />

NM-T7102<br />

Star Hex. Drivers<br />

NM-T3019<br />

Sealing Disc<br />

NM-T1824<br />

Available as Set NM-T3099<br />

Star Hex. Motor Mounts<br />

Screw Retained<br />

Restorations<br />

Screw<br />

NM-S7102<br />

Included with all transfers above & available separately<br />

Star Hex. Driver<br />

1.25mm L 7mm<br />

NM-X7006<br />

Motor Mount<br />

1.25mm L 20mm<br />

NM-X7008<br />

Star Hex. Driver<br />

1.25mm L 14mm<br />

Motor Mount<br />

1.25mm L 25mm<br />

Analog<br />

Ø 4.9mm<br />

NM-T7251<br />

NM-X7007<br />

Star Hex. Driver<br />

1.25mm L 20mm<br />

NM-X7011<br />

NM-X7009<br />

Motor Mount<br />

1.25mm L 35mm<br />

NM-X7010<br />

Removable<br />

Restorations<br />

/ 59 /


Ball Attachment<br />

The ball attachment superstructure is intended to<br />

secure a removable prosthesis. The attachment is<br />

used in conjunction with a stainless steel cap and an<br />

intermediate Nylone insert.<br />

Material: Titanium (Ti6Al4V ELI)<br />

L<br />

Ball Attachment<br />

2.5<br />

1.28<br />

3.75<br />

Ball Attachment<br />

L (mm)<br />

Ball Attachment<br />

L (mm)<br />

0.5<br />

4<br />

NM-T1200<br />

NM-T1204<br />

1<br />

5<br />

NM-T1201<br />

NM-T1205<br />

2<br />

6<br />

NM-T1202<br />

NM-T1206<br />

3<br />

NM-T1203<br />

Caps for 2.5mm Ball Attachment<br />

Metal Extr Soft Nylon Soft Nylon Standard Nylon<br />

ø 5<br />

3.2<br />

NM-T3001 NM-T3002 NM-T3003 NM-T3004<br />

/ 60 / Prosthetics


2.1<br />

Flat Attachment<br />

L 2<br />

The flat attachment superstructure is<br />

intended to secure a removable prosthesis.<br />

The attachment is used in conjunction with<br />

a stainless steel cap and an intermediate<br />

Nylone insert.<br />

2<br />

L<br />

Flat Attachment<br />

2.1<br />

3.75<br />

1.52<br />

Accessories<br />

Material: Titanium (Ti6Al4V ELI)<br />

3.75<br />

Flat Attachment<br />

L (mm)<br />

0.5<br />

Flat Attachment<br />

1.52<br />

L (mm)<br />

3<br />

Cement Retained<br />

Restorations<br />

NM-T1100<br />

NM-T1103<br />

1<br />

4<br />

NM-T1101<br />

NM-T1102<br />

2<br />

NM-T1104<br />

NM-T1105<br />

5<br />

Screw Retained<br />

Restorations<br />

Set NM-T3099<br />

Caps for Flat Attachment<br />

Metal<br />

Extra Soft<br />

Nylon<br />

Soft Nylon<br />

Standard<br />

Nylon<br />

High<br />

Retention<br />

Nylon<br />

Laboratory<br />

Sealing Disc<br />

NM-T3010 NM-T3015 NM-T3016 NM-T3017 NM-T3018 NM-T3019 NM-T1824<br />

Removable<br />

Restorations<br />

/ 61 /


Instruments<br />

/ 63 /


Drills Workflow<br />

Material: Stainless Steel<br />

Page 65<br />

Page 66<br />

Page 67<br />

Page 68<br />

Standard / Short<br />

Long<br />

Conical<br />

Complementary<br />

Drilling Tools<br />

Drills Color Code<br />

Ø 2.0<br />

Laser Mark<br />

Ø 2.8<br />

Ø 3.2<br />

Ø 3.65<br />

Ø 4.2<br />

Ø 5.2<br />

L<br />

Color Code<br />

16<br />

13<br />

11.5<br />

10<br />

8<br />

6<br />

Depth Groove (mm)<br />

/ 64 / Instruments


Drills<br />

Drills<br />

Standard Drills<br />

Ø D (mm) L (mm) External Irrigation<br />

2.0 19 NM-D1220<br />

2.5 19 NM-D1225<br />

2.8 19 NM-D1228<br />

3.2 19 NM-D1232<br />

Drivers<br />

3.65 19 NM-D1236<br />

4.2 19 NM-D1242<br />

5.2 19 NM-D1252<br />

Short Drills<br />

Ø D (mm) L (mm) External Irrigation<br />

Tools<br />

2.0 13 NM-D1420<br />

2.8 13 NM-D1428<br />

3.2 13 NM-D1432<br />

3.65 13 NM-D1436<br />

4.2 13 NM-D1442<br />

5.2 13 NM-D1452<br />

Kits<br />

/ 65 /


Drills<br />

Long Drills<br />

Ø D (mm) L (mm) Item<br />

2.3 43 NM-D7423<br />

2.8 43 NM-D7428<br />

3.2 43 NM-D7432<br />

3.65 43 NM-D7436<br />

Drills Color Code<br />

3.2<br />

Laser Mark<br />

Color Code<br />

Ø 2.3<br />

25<br />

Ø 2.8<br />

Ø 3.2<br />

Ø 3.65<br />

L<br />

22<br />

20<br />

18<br />

15<br />

13<br />

11.5<br />

Depth Groove (mm)<br />

/ 66 / Instruments


Drills<br />

Conical Drills<br />

Ø D1-D2 (mm) L (mm) External Irrigation<br />

1.8-2.4 19 NM-D3018<br />

2.0-3.2 19 NM-D3020<br />

2.5-3.7 19 NM-D3025<br />

2.7-4.0 19 NM-D3027<br />

Drivers<br />

2.7-4.5 19 NM-D3028<br />

3.1-5.5 19 NM-D3031<br />

Drills Color Code<br />

Ø 18.-24<br />

Laser Mark<br />

Tools<br />

Ø 2.0-3.2<br />

Ø 2.5-3.7<br />

Ø 2.7-4.0<br />

Ø 2.7-4.5<br />

Ø 3.1-5.5<br />

L<br />

Color Code<br />

D2<br />

16<br />

13<br />

11.5<br />

10<br />

8<br />

6<br />

D1<br />

Depth Groove (mm)<br />

Kits<br />

Drills<br />

/ 67 /


Drills<br />

Countersink Drills<br />

Ø D (mm)<br />

Item<br />

3.8-4.2 NM-D1034<br />

5.0-6.0 NM-D1056<br />

Marking Drill<br />

Ø D (mm)<br />

Item<br />

1.9 NM-D3410<br />

Narrow Drills<br />

Ø D (mm)<br />

Item<br />

1.2 NM-D2312<br />

1.5 NM-D2315<br />

Trephine Drills<br />

Ø D (mm)<br />

Item<br />

3.0-4.0 NM-D2030<br />

4.0-5.0 NM-D2040<br />

5.0-6.0 NM-D2050<br />

Extension Drill<br />

Ø D (mm)<br />

Item<br />

- NM-D3412<br />

/ 68 / Instruments


Drivers for <strong>Implants</strong><br />

Drivers<br />

L (mm)<br />

2.42mm<br />

Item<br />

Drills<br />

7 NMHX2607<br />

10 NMHX2610<br />

15 NMHX2615<br />

20 NMHX2620<br />

40 NMHX2640<br />

One Piece Drivers<br />

L (mm) D (mm) Item<br />

Drivers<br />

10 1.7 NM-X2415<br />

6 2.15 NM-X1018<br />

10 2.15 NM-X1019<br />

20 2.15 NM-X1720<br />

One Piece Motor Mounts<br />

L (mm) D (mm) Item<br />

20 1.7 NM-X1520<br />

20 2.15 NM-X1620<br />

Motor Mounts<br />

L (mm)<br />

2.42mm<br />

Item<br />

20 NMHX1014<br />

28 NMHX1015<br />

Kits<br />

Tools<br />

/ 69 /


Drivers for Prosthetic<br />

Drivers<br />

1.25mm<br />

L (mm)<br />

Item<br />

7 NM-X1207<br />

10 NM-X1210<br />

15 NM-X1215<br />

Hand Drivers<br />

1.25mm<br />

L (mm)<br />

Item<br />

7 NM-X1006<br />

14 NM-X1007<br />

20 NM-X1011<br />

Motor Mounts<br />

1.25mm<br />

L (mm)<br />

Item<br />

20 NM-X1008<br />

25 NM-X1009<br />

35 NM-X1010<br />

/ 70 / Instruments


Drivers for Multi-Unit & Vari-Connect<br />

Drills<br />

Straight Multi-Unit Drivers<br />

L (mm)<br />

Item<br />

2.0mm<br />

6 NM-X1016<br />

10 NM-X1017<br />

Straight Multi-Unit Motor Mounts<br />

2.0mm<br />

L (mm)<br />

Item<br />

20 NM-X1120<br />

25 NM-X1125<br />

Drivers<br />

Star Hex. Drivers<br />

L (mm)<br />

1.25mm<br />

Item<br />

7 NM-X7006<br />

14 NM-X7007<br />

20 NM-X7011<br />

Star Hex. Ratchet Drivers<br />

L (mm)<br />

1.25mm<br />

Item<br />

Tools<br />

7 NM-X7307<br />

10 NM-X7310<br />

15 NM-X7315<br />

Star Hex. Motor Mounts<br />

L (mm)<br />

1.25mm<br />

Item<br />

20 NM-X7008<br />

Kits<br />

25 NM-X7009<br />

35 NM-X7010<br />

/ 71 /


Tools<br />

Material: Stainless Steel<br />

Hand Tools<br />

Item<br />

Ratchet<br />

NM-X1020<br />

Torque Ratchet<br />

NM-X1021<br />

Surgical Screw Driver<br />

NM-X1023<br />

Contra-Angle Torque<br />

Control HandPiece<br />

Includes NM-X1009 & NM-X7009<br />

NM-X1030<br />

Depth Probe<br />

Item<br />

NM-X1025<br />

Gingival Height (mm)<br />

7<br />

6<br />

5<br />

4<br />

3<br />

2<br />

1<br />

0<br />

6<br />

8<br />

10<br />

11.5<br />

13<br />

16<br />

Osteotomy Depth (mm)<br />

/ 72 / Instruments


Angulated Guide Pin Internal Hex. 2.42mm<br />

Angle<br />

Item<br />

17° NM-X1402<br />

17°<br />

Drills<br />

30° NM-X1404<br />

30°<br />

45° NM-X1405<br />

45°<br />

52° NM-X1406<br />

52°<br />

60° NM-X1407<br />

60°<br />

Drivers<br />

Straight Guide Pin Ø2.0mm<br />

L (mm)<br />

Item<br />

10 NM-X1026<br />

16 NM-X1027<br />

Angulated Guide Pin Ø2.0 mm<br />

Angle L (mm) Item<br />

17° 10 NM-X1302<br />

17°<br />

Tools<br />

17° 16 NM-X1312<br />

17°<br />

30° 10 NM-X1304<br />

30°<br />

30° 16 NM-X1314<br />

30°<br />

45° 10 NM-X1305<br />

45°<br />

Kits<br />

45° 16 NM-X1315<br />

45°<br />

/ 73 /


Premium Surgical Kit Box<br />

Kit NM-X2111 Contains:<br />

Kit NM-X2112 (Conical Drills) Contains:<br />

Drill, ø2.0mm NM-D1220 Drill, ø1.5mm NM-D2315<br />

Drill, ø2.8mm NM-D1228 Drill, ø1.8-2.4mm NM-D3018<br />

Drill, ø3.2mm NM-D1232 Drill, ø2.0-3.2mm NM-D3020<br />

Drill, ø3.65mm NM-D1236 Drill, ø2.5-3.7mm NM-D3025<br />

Drill, ø4.2mm NM-D1242 Drill, ø2.7-4.5mm NM-D3028<br />

Drill, ø5.2mm NM-D1252 Drill, ø3.1-5.5mm NM-D3031<br />

Both Kits Contain:<br />

Countersink, ø3.8-4.2mm NM-D1034 Motor Mount 1.25, L 20mm NM-X1008<br />

Countersink, ø5.0-6.0mm NM-D1056 Motor Mount 2.42, L 20mm NMHX1014<br />

Marking Drill NM-D3410 Motor Mount 2.42, L 28mm NMHX1015<br />

Drill Extension NM-D3412 Torque Ratchet NM-X1021<br />

Driver 1.25mm, L 7mm NM-X1207 Guide Pin, L 10mm - 2 Pcs. NM-X1026<br />

Driver 1.25mm, L 15mm NM-X1215 Guide Pin, L 16mm - 2 Pcs. NM-X1027<br />

Driver 2.42mm, L 7mm NMHX2607 Depth Probe NM-X1025<br />

Driver 2.42mm, L 15mm NMHX2615 Hand Driver 1.25, L 14mm NM-X1007<br />

/ 74 / Instruments


Mini Surgical Kit Box<br />

Drivers<br />

Drills<br />

Kits NM-X2210 (Torque Ratchet)<br />

& NM-X2211 Contain:<br />

Kit NM-X2213 (Conical Drills)<br />

Contains:<br />

Drill, ø2.0mm<br />

NM-D1220<br />

Conical Drill, ø1.8-2.4mm<br />

NM-D3018<br />

Drill, ø2.8mm<br />

Drill, ø3.2mm<br />

Drill, ø3.65mm<br />

NM-D1228<br />

NM-D1232<br />

NM-D1236<br />

Conical Drill, ø2.0-3.2mm<br />

NM-D3020<br />

Conical Drill, ø2.5-3.7mm NM-D3025<br />

Conical Drill, ø.2.7-4.5mm<br />

NM-D3028<br />

Tools<br />

Drill, ø4.2mm<br />

NM-D1242<br />

Conical Drill, ø3.1-5.5mm<br />

NM-D3031<br />

Torque Ratchet (Kit NM-X2210)<br />

NM-X1021<br />

Torque Ratchet<br />

NM-X1021<br />

Ratchet (Kit NM-X2211)<br />

NM-X1020<br />

The Three Kits Contain:<br />

Drill, Countersink, ø3.8-4.2mm<br />

NM-D1034<br />

Driver 1.25mm, L 15mm<br />

NM-X1215<br />

Marking Drill<br />

NM-D3410<br />

Driver 2.42mm, L 15mm<br />

NMHX2615<br />

Guide Pin, L 10mm<br />

NM-X1026<br />

Motor Mount 1.25, L 22mm<br />

NM-X1008<br />

Guide Pin, L 16mm<br />

NM-X1027<br />

Motor Mount 2.42, L 28mm<br />

NMHX1015<br />

Kits<br />

/ 75 /


Drills Kit with Stoppers<br />

15 Drills Set<br />

Kit NM-X2216 Contains:<br />

35 Drills Set<br />

Kit NM-X2212 Contains:<br />

Drills diameters:<br />

ø2.0mm, ø2.8mm, ø3.2mm<br />

Each drill diameter has the following lengths:<br />

6mm, 8mm, 10mm, 11.5mm, 13mm<br />

Drills diameters:<br />

ø2.0mm, ø2.5mm, ø2.8mm, ø3.2mm, ø3.65mm,<br />

ø4.2mm, ø5.2mm<br />

Each drill diameter has the following lengths:<br />

6mm, 8mm, 10mm, 11.5mm, 13mm<br />

Drills <strong>Catalog</strong> No.:<br />

L (mm)<br />

Ø D (mm)<br />

2.0 2.5 2.8 3.2 3.65 4.3 5.2<br />

6 NM-D6006 NM-D6106 NM-D6206 NM-D6306 NM-D6406 NM-D6506 NM-D6606<br />

8 NM-D6008 NM-D6108 NM-D6208 NM-D6308 NM-D6408 NM-D6508 NM-D6608<br />

10 NM-D6010 NM-D6110 NM-D6210 NM-D6310 NM-D6410 NM-D6510 NM-D6610<br />

11.5 NM-D6011 NM-D6111 NM-D6211 NM-D6311 NM-D6411 NM-D6511 NM-D6611<br />

13 NM-D6013 NM-D6113 NM-D6213 NM-D6313 NM-D6413 NM-D6513 NM-D6613<br />

/ 76 / Instruments


Index<br />

NM-A Description Page<br />

NM-A2401 Angulated Anatomic Abutment, 15°, ø5.4mm, L9.5mm, SH1.0mm, Ti 42<br />

NM-A2402 Angulated Anatomic Abutment, 15°, ø5.4mm, L10.5mm, SH2.0mm, Ti. 42<br />

NM-A2403 Angulated Anatomic Abutment, 15°, ø5.4mm, L11.5mm, SH3.0mm, Ti. 42<br />

NM-A2404 Angulated Anatomic Abutment, 15°, ø5.4mm, L12.5mm, SH4.0mm, Ti. 42<br />

NM-A2601 Angulated Anatomic Abutment, 25°, ø5.4mm, L9.5mm, SH1.0mm, Ti. 42<br />

NM-A2602 Angulated Anatomic Abutment, 25°, ø5.4mm, L10.5mm, SH2.0mm, Ti. 42<br />

NM-A2603 Angulated Anatomic Abutment, 15°, ø5.4mm, L11.5mm, SH3.mm, Ti. 42<br />

NM-A2604 Angulated Anatomic Abutment, 15°, ø5.4mm, L12.5mm, SH4.0mm, Ti. 42<br />

NM-A2809 Angulated Abutment - Narrow Top, 15°, L9mm, Ti. 43<br />

NM-A3009 Angulated Abutment - Narrow Top, 25°, L9mm, Ti 43<br />

NM-A3209 Angulated Anatomic Abutment, 15°, ø4.5mm, L9.5mm, Ti. 43<br />

NM-A3211 Angulated Abutment, 15°, ø4.5mm, L11mm, Ti. 43<br />

NM-A3409 Angulated Abutment, 25°, ø4.5mm, L9mm, Ti. 43<br />

NM-A3411 Angulated Abutment, 25°, ø4.5mm, L11mm, Ti. 43<br />

NM-A3609 Angulated Narrow Abutment, 15˚, ø4.0mm, L9.0mm, Ti. 43<br />

NM-A3809 Angulated Narrow Abutment, 25˚, ø4.0mm, L9.0mm, Ti. 43<br />

NM-A4601 Straight Anatomic Abutment, ø5.2mm, L9mm, SH1.0mm,Ti. 40<br />

NM-A4602 Straight Anatomic Abutment, ø5.2mm, L10mm, SH2.0mm, Ti. 40<br />

NM-A4603 Straight Anatomic Abutment, ø5.2mm, L11mm, SH3.0mm, Ti. 40<br />

NM-A4604 Straight Anatomic Abutment, ø5.2mm, L12mm, SH4.0mm, Ti. 40<br />

NM-A4801 Straight Shoulder Abutment, ø4.5mm, L8.5mm, SH1.0mm, Ti. 40<br />

NM-A4802 Straight Shoulder Abutment, ø4.5mm, L9.5mm, SH2.0mm, Ti. 40<br />

NM-A4803 Straight Shoulder Abutment, ø4.5mm, L10.5mm, SH3.0mm, Ti. 40<br />

NM-A4804 Straight Shoulder Abutment, ø4.5mm,L11.5mm, SH4.0mm, Ti. 40<br />

NM-A5001 Temp. Abutment, Hexed, ø4.4mm, L 9.5mm, Ti. 39<br />

NM-A5002 Temp. Abutment, Non-Hexed, ø4.4mm, L9.5mm, SH1.7mm, Ti. 39<br />

NM-A5101 Temp. Abutment, Hexed, ø3.8mm, L9.5mm, SH1.7mm, Ti. 39<br />

NM-A5102 Temp. Abutment, Short Non Hexed, ø3.8mm, L9.5mm, SH1.0mm, Ti. 39<br />

NM-A5300 Straight Narrow Shoulder Abutment, ø3.75mm, L8.5mm, SH0.5mm, Ti. 41<br />

NM-A5301 Straight Narrow Shoulder Abutment, ø3.75mm, L8.5mm, SH1.5mm, Ti. 41<br />

NM-A5302 Straight Narrow Shoulder Abutment, ø3.75mm, L8.5mm, SH2.5mm, Ti. 41<br />

NM-A5515 Straight Mega Abutment, ø9.0, L15.0mm, Ti. 41<br />

NM-A5517 Individual Blank for Milling, ø10.0, L26.0mm, Ti. 47<br />

NM-A5601 Straight Abutment, ø4.5mm, L8.5mm, Ti. 41<br />

NM-A5602 Straight Abutment, ø4.5mm, L10.5mm, Ti. 41<br />

NM-A5709 Straight Wide Abutment, ø5.5mm, L9mm, Ti. 41<br />

NM-A5711 Straight Wide Abutment, ø5.5mm, L11mm, Ti. 41<br />

NM-A5908 Straight Abutment, ø4.5mm, L8.5mm, Ti. 41<br />

NM-A5909 Straight Abutment, ø4.5mm, L9.5mm, Ti. 41<br />

NM-A5911 Straight Abutment, ø4.5mm, L11.5mm, Ti. 41<br />

NM-A5912 Straight Abutment, ø4.5mm, L12.5mm, Ti. 41<br />

NM-A6006 Straight Narrow Abutment, ø3.8mm, L6mm, Ti. 41<br />

NM-A6008 Straight Narrow Abutment, ø3.8mm, L8mm, Ti. 41<br />

NM-A7101 Multi Unit Abutment, Straight, SH1.0mm, Ti. 50<br />

NM-A7102 Multi Unit Abutment, Straight, SH2.0mm, Ti. 50<br />

NM-A7103 Multi Unit Abutment, Straight, SH3.0mm, Ti. 50<br />

NM-A7104 Multi Unit Abutment, Straight, SH4.0mm, Ti. 50<br />

NM-A7105 Multi Unit Abutment, Straight, SH5.0mm, Ti. 50<br />

NM-A7112 Multi Unit Abutment, 17˚, SH2.0mm, Ti. 50<br />

NM-A7113 Multi Unit Abutment, 17˚, SH3.0mm, Ti. 50<br />

NM-A7133 Multi Unit Abutment, 30˚, SH3.0mm, Ti. 50<br />

NM-A7134 Multi Unit Abutment, 30˚, SH4.0mm, Ti. 50<br />

NM-A7144 Multi Unit Abutment, 45˚, SH4.0mm, Ti. 50<br />

NM-A7152 Multi Unit Abutment, 52˚, SH5.0mm, Ti. 50<br />

NM-A7160 Multi Unit Abutment, 60˚, SH5.0mm, Ti. 50<br />

NM-A7212 Vari Connect Abutment, 17˚, SH2.0mm, Ti. 58<br />

NM-A7213 Vari Connect Abutment, 17˚, SH3.0mm, Ti. 58<br />

NM-A7233 Vari Connect Abutment, 30˚, SH3.0mm, Ti. 58<br />

NM-A7234 Vari Connect Abutment, 30˚, SH4.0mm, Ti. 58<br />

NM-A7244 Vari Connect Abutment, 45˚, SH4.0mm, Ti. 58<br />

NM-C Description Page<br />

NM-C1001 Castable Abutment, Non-Hexed, ø3.25mm, L10.5mm, Delrin 45<br />

NM-C1002 Castable Abutment, Hexed, ø3.25mm, L10.5mm, Delrin 45<br />

NM-C1005 Castable Cap for Straight Shoulder Abutment, Plastic 40<br />

NM-C1007 Esthetic Screw Abutment, Non-Hexed, L12mm, Ti. 56<br />

NM-C1015 Esthetic Screw Abutment, Hexed, L12mm, Ti. 56<br />

NM-C2001 Titanium Base Castable Abutment, Hexed, ø4.5mm, L10.5mm, Delrin 45<br />

NM-C2002 Co-Cr Base Castable Abutment, Hexed, ø4.5mm, L10.5mm, Delrin 45<br />

NM-C2003 Castable Abutment, Non-Hexed, ø4.5mm, L8.5mm, Delrin 45<br />

NM-C2004 Castable Abutment, Hexed, ø4.5mm, L8.5mm, Delrin 45<br />

NM-C2005 Castable Angulated Abutment, 15°, ø4.5mm, L8.5mm, Delrin 45<br />

NM-C2201 CAD/CAM Abutment, Single Unit, ø4.8mm, L4.5mm, L1 1.0mm Ti. 46<br />

NM-C2202 CAD/CAM Abutment, Multiple Unit, ø4.8mm, L4.5mm, Ti. 47<br />

NM-C2212 CAD/CAM Abutment, Single Unit, ø4.8mm, L6.0mm, L1 2.0mm Ti. 46<br />

NM-C2213 CAD/CAM Abutment, Single Unit, ø4.8mm, L7mm, L1 3.0mm Ti. 46<br />

NM-C3001 Angualted Castable Abutment, 15°, L9.5mm, SH1.0mm, Delrin 45<br />

NM-C3002 Angualted Castable Abutment, 15°, L10.5mm, SH2.0mm, Delrin 45<br />

NM-C3003 Angualted Castable Abutment, 15°, L11.5mm, SH3.0mm, Delrin 45<br />

NM-C3201 Angualted Castable Abutment, 25°, L9.5mm, SH1.0mm, Delrin 45<br />

NM-C3202 Angualted Castable Abutment, 25°, L10.5mm, SH2.0mm, Delrin 45<br />

NM-C3203 Angualted Castable Abutment, 25°, L11.5mm, SH3.0mm, Delrin 45<br />

NM-C4001 Castable Abutment, L9mm, SH1.0mm, Delrin 45<br />

NM-C4002 Castable Abutment, L10mm, SH1.0mm, Delrin 45<br />

NM-C4003 Castable Abutment, L11mm, SH1.0mm, Delrin 45<br />

NM-C5001 Temp. Angulated Abutment, 15°, L9.5mm, SH1.0mm Peek 38<br />

NM-C5002 Temp. Angulated Abutment, 15°, L10.5mm, SH2.0mm Peek 38<br />

NM-C5003 Temp. Angulated Abutment, 15°, L11.5mm, SH31.0mm Peek 38<br />

NM-C5201 Temp. Angulated Abutment, 25°, L9.5mm, SH1.0mm Peek 38<br />

NM-C5202 Temp. Angulated Abutment, 25°, L10.5mm, SH2.0mm Peek 38<br />

NM-C5203 Temp. Angulated Abutment, 25°, L11.5mm, SH31.0mm Peek 38<br />

NM-C6001 Temp. Abutment, L9.0mm, SH1.0mm Peek 38<br />

NM-C6002 Temp. Abutment, L10.0mm, SH2.0mm Peek 38<br />

NM-C6003 Temp. Abutment, L11.0mm, SH3.0mm Peek 38<br />

NM-C7120 Castable Sleeve for Multi Unit, ø4.8mm, L10.5mm, Delrin 52<br />

NM-C7121 Universal Abutment for Multi Unit, ø4.9mm, L12.0mm, Delrin 52<br />

NM-C7124 Multi-Unit Titanium Base, ø4.9mm, L4.5mm, Ti. 47, 52<br />

NM-C9007 Scan Body for CAD/CAM, ø4.0mm, L7mm, Ti.&Peek 46<br />

NM-C9010 Scan Body for CAD/CAM, ø4.0mm, L10mm, Ti.&Peek 46<br />

NM-C9013 Scan Body for CAD/CAM, ø4.0mm, L13mm, Ti.&Peek 46<br />

NM-C9207 Multi-Unit Scan Body, ø4.9mm, L7mm, Ti.&Peek 47, 52<br />

NM-C9210 Multi-Unit Scan Body, ø4.9mm, L10mm, Ti.&Peek 47, 52<br />

NM-C9213 Multi-Unit Scan Body, ø4.9mm, L13mm, Ti.&Peek 47, 52<br />

/ 77 /


Index<br />

NM-D Description Page<br />

NM-D1034 Countersink Drill, ø3.8-4.2mm, SS. 68, 74, 75<br />

NM-D1056 Countersink Drill, ø5.0-6.0mm, SS. 68, 74<br />

NM-D1220 Standard Drill, L19mm, ø2mm, SS. 65, 74, 75<br />

NM-D1225 Standard Drill, L19mm, ø2.5mm, SS. 65<br />

NM-D1228 Standard Drill, L19mm, ø2.8mm, SS. 65, 74, 75<br />

NM-D1232 Standard Drill, L19mm, ø3.2mm, SS. 65, 74, 75<br />

NM-D1236 Standard Drill, L19mm, ø3.65mm, SS. 65, 74, 75<br />

NM-D1242 Standard Drill, L19mm, ø4.2mm, SS. 65, 74, 75<br />

NM-D1252 Standard Drill, L19mm, ø5.2mm, SS. 65, 74<br />

NM-D1420 Short Drill, L13mm, ø2mm, SS. 65<br />

NM-D1428 Short Drill, L13mm, ø2.8mm, SS. 65<br />

NM-D1432 Short Drill, L13mm, ø3.2mm, SS. 65<br />

NM-D1436 Short Drill, L13mm, ø3.65mm, SS. 65<br />

NM-D1442 Short Drill, L13mm, ø4.2mm, SS. 65<br />

NM-D1452 Short Drill, L13mm, ø5.2mm, SS. 65<br />

NM-D2030 Trephine Drill, ø3.0-4.0mm, SS. 68<br />

NM-D2040 Trephine Drill, ø4.0-5.0mm, SS. 68<br />

NM-D2050 Trephine Drill, ø5.0-6.0mm, SS. 68<br />

NM-D2312 Drill, ø1.2mm, L16.0mm, SS. 27, 68<br />

NM-D2315 Drill, ø1.5mm, L16.0mm, SS. 27, 29, 68, 74<br />

NM-D3018 Conical Drill, L19mm, ø1.8-2.4mm, SS. 67, 74, 75<br />

NM-D3020 Conical Drill, L19mm, ø2.0-3.2mm, SS. 67, 74, 75<br />

NM-D3025 Conical Drill, L19mm, ø2.5-3.7mm, SS. 67, 74, 75<br />

NM-D3027 Conical Drill, L19mm, ø2.7-4.0mm, SS. 67<br />

NM-D3028 Conical Drill, L19mm, ø2.7-4.5mm, SS. 67, 74, 75<br />

NM-D3031 Conical Drill, L19mm, ø3.1-5.5mm, SS. 67, 74, 75<br />

NM-D3410 Marking Drill, ø1.9mm, SS. 68, 74, 75<br />

NM-D3412 Extension Drill, SS. 68, 74<br />

NM-D6006 Stop Drill, ø2.0mm, L6.0mm, SS. 76<br />

NM-D6008 Stop Drill, ø2.0mm, L8.0mm, SS. 76<br />

NM-D6010 Stop Drill, ø2.0mm, L10.0mm, SS. 76<br />

NM-D6011 Stop Drill, ø2.0mm, L11.5mm, SS. 76<br />

NM-D6013 Stop Drill, ø2.0mm, L13.0mm, SS. 76<br />

NM-D6106 Stop Drill, ø2.5mm, L6.0mm, SS. 76<br />

NM-D6108 Stop Drill, ø2.5mm, L8.0mm, SS. 76<br />

NM-D6110 Stop Drill, ø2.5mm, L10.0mm, SS. 76<br />

NM-D6111 Stop Drill, ø2.5mm, L11.5mm, SS. 76<br />

NM-D6113 Stop Drill, ø2.5mm, L13.0mm, SS. 76<br />

NM-D6206 Stop Drill, ø2.8mm, L6.0mm, SS. 76<br />

NM-D6208 Stop Drill, ø2.8mm, L8.0mm, SS. 76<br />

NM-D6210 Stop Drill, ø2.8mm, L10.0mm, SS. 76<br />

NM-D6211 Stop Drill, ø2.8mm, L11.5mm, SS. 76<br />

NM-D6213 Stop Drill, ø2.8mm, L13.0mm, SS. 76<br />

NM-D6306 Stop Drill, ø3.2mm, L6.0mm, SS. 76<br />

NM-D6308 Stop Drill, ø3.2mm, L8.0mm, SS. 76<br />

NM-D6310 Stop Drill, ø3.2mm, L10.0mm, SS. 76<br />

NM-D6311 Stop Drill, ø3.2mm, L11.5mm, SS. 76<br />

NM-D6313 Stop Drill, ø3.2mm, L13.0mm, SS. 76<br />

NM-D6406 Stop Drill, ø3.65mm, L6.0mm, SS. 76<br />

NM-D6408 Stop Drill, ø3.65mm, L8.0mm, SS. 76<br />

NM-D6410 Stop Drill, ø3.65mm, L10.0mm, SS. 76<br />

NM-D6411 Stop Drill, ø3.65mm, L11.5mm, SS. 76<br />

NM-D6413 Stop Drill, ø3.65mm, L13.0mm, SS. 76<br />

NM-D6506 Stop Drill, ø4.3mm, L6.0mm, SS. 76<br />

NM-D6508 Stop Drill, ø4.3mm, L8.0mm, SS. 76<br />

NM-D6510 Stop Drill, ø4.3mm, L10.0mm, SS. 76<br />

NM-D6511 Stop Drill, ø4.3mm, L11.5mm, SS. 76<br />

NM-D6513 Stop Drill, ø4.3mm, L13.0mm, SS. 76<br />

NM-D6606 Stop Drill, ø5.2mm, L6.0mm, SS. 76<br />

NM-D6608 Stop Drill, ø5.2mm, L8.0mm, SS. 76<br />

NM-D6610 Stop Drill, ø5.2mm, L10.0mm, SS. 76<br />

NM-D6611 Stop Drill, ø5.2mm, L11.5mm, SS. 76<br />

NM-D6613 Stop Drill, ø5.2mm, L13.0mm, SS. 76<br />

NM-D7020 Step Drill for Zigoma, ø2.0mm, L60.0mm, SS. 24, 25<br />

NM-D7028 Step Drill for Zigoma, ø2.8mm, L60.0mm, SS. 24, 25<br />

NM-D7032 Step Drill for Zigoma, ø3.2mm, L60.0mm, SS. 24, 25<br />

NM-D7120 Step Drill for Zigoma, ø2.0mm, L80.0mm, SS. 24, 25<br />

NM-D7128 Step Drill for Zigoma, ø2.8mm, L80.0mm, SS. 24, 25<br />

NM-D7132 Step Drill for Zigoma, ø3.2mm, L80.0mm, SS. 24, 25<br />

NM-D7201 Dimond Burr, ø4.2mm, L30.0mm, Fine, Red 24, 25<br />

NM-D7202 Dimond Burr, ø4.2mm, L30.0mm, Medium, Black 24, 25<br />

NM-D7203 Dimond Burr, ø4.2mm, L30.0mm, Coarse, Blue 24, 25<br />

NM-D7423 Long Drill, L43mm, ø2.3mm, SS. 21, 66<br />

NM-D7428 Long Drill, L43mm, ø2.8mm, SS. 21, 66<br />

NM-D7432 Long Drill, L43mm, ø3.2mm, SS. 21, 66<br />

NM-D7436 Long Drill, L43mm, ø3.65mm, SS. 21, 66<br />

NM-D7520 Step Drill for Zygoma, ø2.0mm, L40mm, SS. 25<br />

NM-D7528 Step Drill for Zygoma, ø2.8mm, L40mm, SS. 25<br />

NM-D7532 Step Drill for Zygoma, ø3.2mm, L40mm, SS. 25<br />

NM-E Description Page<br />

NM-E1005 Esthetic Screw Abutment, Base, SH0.5mm, Ti. 56<br />

NM-E1015 Esthetic Screw Abutment, Base, SH1.5mm, Ti. 56<br />

NM-E1025 Esthetic Screw Abutment, Base, SH2.5mm, Ti. 56<br />

NM-F Description Page<br />

NM-F3308 Tuff Implant, ø3.3mm, L8.0mm, Ti. 9<br />

NM-F3310 Tuff Implant, ø3.3mm, L10.0mm, Ti. 9<br />

NM-F3311 Tuff Implant, ø3.3mm, L11.5mm, Ti. 9<br />

NM-F3313 Tuff Implant, ø3.3mm, L13.0mm, Ti. 9<br />

NM-F3316 Tuff Implant, ø3.3mm, L16.0mm, Ti. 9<br />

NM-F3706 Tuff Implant, ø3.75mm, L6.0mm, Ti. 9<br />

NM-F3708 Tuff Implant, ø3.75mm, L8.0mm, Ti. 9<br />

NM-F3710 Tuff Implant, ø3.75mm, L10.0mm, Ti. 9<br />

NM-F3711 Tuff Implant, ø3.75mm, L11.5mm, Ti. 9<br />

NM-F3713 Tuff Implant, ø3.75mm, L13.0mm, Ti. 9<br />

NM-F3716 Tuff Implant, ø3.75mm, L16.0mm, Ti. 9<br />

NM-F3718 Tuff Implant, ø3.75mm, L18.0mm, Ti. 9<br />

NM-F4206 Tuff Implant, ø4.2mm, L6.0mm, Ti. 9<br />

NM-F4208 Tuff Implant, ø4.2mm, L8.0mm, Ti. 9<br />

NM-F4210 Tuff Implant, ø4.2mm, L10.0mm, Ti. 9<br />

NM-F4211 Tuff Implant, ø4.2mm, L11.5mm, Ti. 9<br />

NM-F4213 Tuff Implant, ø4.2mm, L13.0mm, Ti. 9<br />

NM-F4216 Tuff Implant, ø4.2mm, L16.0mm, Ti. 9<br />

NM-F4218 Tuff Implant, ø4.2mm, L18.0mm, Ti. 9<br />

/ 78 / Index


NM-F4220 Tuff Implant, ø4.2mm, L20.0mm, Ti. 9<br />

NM-F4222 Tuff Implant, ø4.2mm, L22.0mm, Ti. 9<br />

NM-F4225 Tuff Implant, ø4.2mm, L25.0mm, Ti. 9<br />

NM-F4306 Tuff TT Implant, ø4.2mm, L6.0mm, Ti. 13<br />

NM-F4308 Tuff TT Implant, ø4.2mm, L8.0mm, Ti. 13<br />

NM-F4310 Tuff TT Implant, ø4.2mm, L10.0mm, Ti. 13<br />

NM-F4311 Tuff TT Implant, ø4.2mm, L11.5mm, Ti. 13<br />

NM-F4313 Tuff TT Implant, ø4.2mm, L13.0mm, Ti. 13<br />

NM-F4316 Tuff TT Implant, ø4.2mm, L16.0mm, Ti. 13<br />

NM-F4318 Tuff TT Implant, ø4.2mm, L18.0mm, Ti. 13<br />

NM-F4320 Tuff TT Implant, ø4.2mm, L20.0mm, Ti. 13<br />

NM-F4430 Zygomatic Implant, ø4.2mm, L30mm, Ti. 22<br />

NM-F4432 Zygomatic Implant, ø4.2mm, L32.5mm, Ti. 22<br />

NM-F4435 Zygomatic Implant, ø4.2mm, L35mm, Ti. 22<br />

NM-F4437 Zygomatic Implant, ø4.2mm, L37.5mm, Ti. 22<br />

NM-F4440 Zygomatic Implant, ø4.2mm, L40mm, Ti. 22<br />

NM-F4442 Zygomatic Implant, ø4.2mm, L42.5mm, Ti. 22<br />

NM-F4445 Zygomatic Implant, ø4.2mm, L45mm, Ti. 22<br />

NM-F4447 Zygomatic Implant, ø4.2mm, L47.5mm, Ti. 22<br />

NM-F4450 Zygomatic Implant, ø4.2mm, L50mm, Ti. 22<br />

NM-F4452 Zygomatic Implant, ø4.2mm, L52.5mm, Ti. 22<br />

NM-F4455 Zygomatic Implant, ø4.2mm, L55mm, Ti. 22<br />

NM-F4457 Zygomatic Implant, ø4.2mm, L57.5mm, Ti. 22<br />

NM-F4460 Zygomatic Implant, ø4.2mm, L60mm, Ti. 22<br />

NM-F5006 Tuff Implant, ø5.0mm, L6.0mm, Ti. 9<br />

NM-F5008 Tuff Implant, ø5.0mm, L8.0mm, Ti. 9<br />

NM-F5010 Tuff Implant, ø5.0mm, L10.0mm, Ti. 9<br />

NM-F5011 Tuff Implant, ø5.0mm, L11.5mm, Ti. 9<br />

NM-F5013 Tuff Implant, ø5.0mm, L13.0mm, Ti. 9<br />

NM-F5016 Tuff Implant, ø5.0mm, L16.0mm, Ti. 9<br />

NM-F5106 Tuff TT Implant, ø5.0mm, L6.0mm, Ti. 13<br />

NM-F5108 Tuff TT Implant, ø5.0mm, L8.0mm, Ti. 13<br />

NM-F5110 Tuff TT Implant, ø5.0mm, L10.0mm, Ti. 13<br />

NM-F5111 Tuff TT Implant, ø5.0mm, L11.5mm, Ti. 13<br />

NM-F5113 Tuff TT Implant, ø5.0mm, L13.0mm, Ti. 13<br />

NM-F5116 Tuff TT Implant, ø5.0mm, L16.0mm, Ti. 13<br />

NM-F6006 Tuff Implant, ø6.0mm, L6.0mm, Ti. 9<br />

NM-F6008 Tuff Implant, ø6.0mm, L8.0mm, Ti. 9<br />

NM-F6010 Tuff Implant, ø6.0mm, L10.0mm, Ti. 9<br />

NM-F6011 Tuff Implant, ø6.0mm, L11.5mm, Ti. 9<br />

NM-F6013 Tuff Implant, ø6.0mm, L13.0mm, Ti. 9<br />

NM-F6016 Tuff Implant, ø6.0mm, L16.0mm, Ti. 9<br />

NM-F6106 Tuff TT Implant, ø6.0mm, L6.0mm, Ti. 13<br />

NM-F6108 Tuff TT Implant, ø6.0mm, L8.0mm, Ti. 13<br />

NM-F6110 Tuff TT Implant, ø6.0mm, L10.0mm, Ti. 13<br />

NM-F6111 Tuff TT Implant, ø6.0mm, L11.5mm, Ti. 13<br />

NM-F6113 Tuff TT Implant, ø6.0mm, L13.0mm, Ti. 13<br />

NM-G Description Page<br />

NM-G3308 Onyx Implant, ø3.3mm, L8mm, Ti. 15<br />

NM-G3310 Onyx Implant, ø3.3mm, L10mm, Ti. 15<br />

NM-G3311 Onyx Implant, ø3.3mm, L11.5mm, Ti. 15<br />

NM-G3313 Onyx Implant, ø3.3mm, L13mm, Ti. 15<br />

NM-G3316 Onyx Implant, ø3.3mm, L16mm, Ti. 15<br />

NM-G3706 Onyx Implant, ø3.75mm, L6mm, Ti. 15<br />

NM-G3708 Onyx Implant, ø3.75mm, L8mm, Ti. 15<br />

NM-G3710 Onyx Implant, ø3.75mm, L10mm, Ti. 15<br />

NM-G3711 Onyx Implant, ø3.75mm, L11.5mm, Ti. 15<br />

NM-G3713 Onyx Implant, ø3.75mm, L13mm, Ti. 15<br />

NM-G3716 Onyx Implant, ø3.75mm, L16mm, Ti. 15<br />

NM-G4206 Onyx Implant, ø4.2mm, L6mm, Ti. 15<br />

NM-G4208 Onyx Implant, ø4.2mm, L8mm, Ti. 15<br />

NM-G4210 Onyx Implant, ø4.2mm, L10mm, Ti. 15<br />

NM-G4211 Onyx Implant, ø4.2mm, L11.5mm, Ti. 15<br />

NM-G4213 Onyx Implant, ø4.2mm, L13mm, Ti. 15<br />

NM-G4216 Onyx Implant, ø4.2mm, L16mm, Ti. 15<br />

NM-G5006 Onyx Implant, ø5.0mm, L6mm, Ti. 15<br />

NM-G5008 Onyx Implant, ø5.0mm, L8mm, Ti. 15<br />

NM-G5010 Onyx Implant, ø5.0mm, L10mm, Ti. 15<br />

NM-G5011 Onyx Implant, ø5.0mm, L11.5mm, Ti. 15<br />

NM-G5013 Onyx Implant, ø5.0mm, L13mm, Ti. 15<br />

NM-G5016 Onyx Implant, ø5.0mm, L16mm, Ti. 15<br />

NM-G6006 Onyx Implant, ø6.0mm, L6mm, Ti. 15<br />

NM-G6008 Onyx Implant, ø6.0mm, L8mm, Ti. 15<br />

NM-G6010 Onyx Implant, ø6.0mm, L10mm, Ti. 15<br />

NM-G6011 Onyx Implant, ø6.0mm, L11.5mm, Ti. 15<br />

NM-G6013 Onyx Implant, ø6.0mm, L13mm, Ti. 15<br />

NM-H Description Page<br />

NM-H3802 Healing Cap, ø3.8mm, L2mm, Ti. 34<br />

NM-H3803 Healing Cap, ø3.8mm, L3mm, Ti. 34<br />

NM-H3804 Healing Cap, ø3.8mm, L4mm, Ti. 34<br />

NM-H3805 Healing Cap, ø3.8mm, L5mm, Ti. 34<br />

NM-H3806 Healing Cap, ø3.8mm, L6mm, Ti. 34<br />

NM-H3807 Healing Cap, ø3.8mm, L7mm, Ti. 34<br />

NM-H4602 Healing Cap, ø4.6mm, L2mm, Ti. 34<br />

NM-H4603 Healing Cap, ø4.6mm, L3mm, Ti. 34<br />

NM-H4604 Healing Cap, ø4.6mm, L4mm, Ti. 34<br />

NM-H4605 Healing Cap, ø4.6mm, L5mm, Ti. 34<br />

NM-H4606 Healing Cap, ø4.6mm, L6mm, Ti. 34<br />

NM-H4607 Healing Cap, ø4.6mm, L7mm, Ti. 34<br />

NM-H5502 Healing Cap, ø5.5mm, L2mm, Ti. 34<br />

NM-H5503 Healing Cap, ø5.5mm, L3mm, Ti. 34<br />

NM-H5504 Healing Cap, ø5.5mm, L4mm, Ti. 34<br />

NM-H5505 Healing Cap, ø5.5mm, L5mm, Ti. 34<br />

NM-H5506 Healing Cap, ø5.5mm, L6mm, Ti. 34<br />

NM-H5507 Healing Cap, ø5.5mm, L7mm, Ti. 34<br />

NM-H6303 Healing Cap, ø6.3mm, L3mm, Ti. 34<br />

NM-H6304 Healing Cap, ø6.3mm, L4mm, Ti. 34<br />

NM-H6305 Healing Cap, ø6.3mm, L5mm, Ti. 34<br />

NM-H6306 Healing Cap, ø6.3mm, L6mm, Ti. 34<br />

NM-H6307 Healing Cap, ø6.3mm, L7mm, Ti. 34<br />

NM-H7101 Healing Cap for Multi Unit, ø4.9, L4.8mm, Ti. 52, 59<br />

NM-H7102 Healing Cap for Multi Unit, ø4.9, L7.0mm, Ti. 52, 59<br />

/ 79 /


Index<br />

NM-M Description Page<br />

NM-M4010 Cortical Implant, ø4.0mm, L10mm, Ti. 17<br />

NM-M4011 Cortical Implant, ø4.0mm, L11.5mm, Ti. 17<br />

NM-M4013 Cortical Implant, ø4.0mm, L13mm, Ti. 17<br />

NM-M4016 Cortical Implant, ø4.0mm, L16mm, Ti. 17<br />

NM-M4018 Cortical Implant, ø4.0mm, L18mm, Ti. 17<br />

NM-M4020 Cortical Implant, ø4.0mm, L20mm, Ti. 17<br />

NM-M4218 PteryCore Implant, ø4.2mm, L18mm, Ti. 18<br />

NM-M4220 PteryCore Implant, ø4.2mm, L20mm, Ti. 18<br />

NM-M4222 PteryCore Implant, ø4.2mm, L22.5mm, Ti. 18<br />

NM-M4225 PteryCore Implant, ø4.2mm, L25mm, Ti. 18<br />

NM-M5008 Cortical Implant, ø5.0mm, L8mm, Ti. 17<br />

NM-M5010 Cortical Implant, ø5.0mm, L10mm, Ti. 17<br />

NM-M5011 Cortical Implant, ø5.0mm, L11.5mm, Ti. 17<br />

NM-M5013 Cortical Implant, ø5.0mm, L13mm, Ti. 17<br />

NM-M5016 Cortical Implant, ø5.0mm, L16mm, Ti. 17<br />

NM-M6008 Cortical Implant, ø6.0mm, L8mm, Ti. 17<br />

NM-M6010 Cortical Implant, ø6.0mm, L10mm, Ti. 17<br />

NM-M6011 Cortical Implant, ø6.0mm, L11.5mm, Ti. 17<br />

NM-M6013 Cortical Implant, ø6.0mm, L13mm, Ti. 17<br />

NM-M6016 Cortical Implant, ø6.0mm, L16mm, Ti. 17<br />

NM-S Description Page<br />

NM-S1001 Screw for Zirconia Abutment Base, Ti. 44<br />

NM-S1002 Esthetic Screw Abutment, L10.5mm, Ti. 56<br />

NM-S1102 Esthetic Screw Abutment, L11.5mm, Ti. 56<br />

NM-S1202 Esthetic Screw Abutment, L12.5mm, Ti. 56<br />

NM-S1307 Screw for Transfer, L13.0mm, Ti. 35<br />

NM-S1610 Screw for Transfer, L16.0mm, Ti. 35<br />

NM-S2418 Screw for Transfer, Open Tray, L24.0mm, Ti. 35<br />

NM-S5023 Cover Screw 9, 11, 13, 15, 17, 18, 19, 22<br />

NM-S7101 Screw for Multi Unit Abutment, Ti. 50, 58<br />

NM-S7102 Screw for Multi Unit Components, Ti. 46, 47, 52, 59<br />

NM-S7111 Screw for Multi Unit Transfer, Open Tray, Ti. 52, 59<br />

NM-S8324 Screw for Abutment, Ti. 36, 39, 40, 43, 45, 47<br />

NM-T Description Page<br />

NM-T1100 Flat Attachment, SH0.5mm, Ti. 61<br />

NM-T1101 Flat Attachment, SH1mm, Ti. 61<br />

NM-T1102 Flat Attachment, SH2mm, Ti. 61<br />

NM-T1103 Flat Attachment, SH3mm, Ti. 61<br />

NM-T1104 Flat Attachment, SH4mm, Ti. 61<br />

NM-T1105 Flat Attachment, SH5mm, Ti. 61<br />

NM-T1200 Ball Attachment, SH0.5mm, Ti. 60<br />

NM-T1201 Ball Attachment, SH1mm, Ti. 60<br />

NM-T1202 Ball Attachment, SH2mm, Ti. 60<br />

NM-T1203 Ball Attachment, SH3mm, Ti. 60<br />

NM-T1204 Ball Attachment, SH4mm, Ti. 60<br />

NM-T1205 Ball Attachment, SH5mm, Ti. 60<br />

NM-T1206 Ball Attachment, SH6mm, Ti. 60<br />

NM-T1824 Sealing Disc 59, 61<br />

NM-T3001 Metal Cap, ø5.0mm, L3.2mm 59, 60<br />

NM-T3002 Nylon Extra Soft Cap 59, 60<br />

NM-T3003 Nylon Soft Cap 59, 60<br />

NM-T3004 Nylon Standart Cap 59, 60<br />

NM-T3010 Metal Cap for Flat Attachment, ø5.5, L2.3.0mm, SS. 59, 61<br />

NM-T3015 Cap Insert for Flat Attachment, Extra Soft, Nylon. 59, 61<br />

NM-T3016 Cap Insert for Flat Attachment, Soft, Nylon. 59, 61<br />

NM-T3017 Cap Insert for Flat Attachment, Standard, Nylon. 59, 61<br />

NM-T3018 Cap Insert for Flat Attachment, Hard, Nylon. 59, 61<br />

NM-T3019 Cap Insert for Flat Attachment, Laboratory. 59, 61<br />

NM-T3099 Caps for Flat Attachment Kit 61<br />

NM-T3201 Metal Cap for ø1.8mm Ball Attachment, ø4.3mm, L2.8mm, SS. 27<br />

NM-T3202 Cap Insert for ø1.8mm Ball Attachment, Extra Soft, Yellow, Nylon 27<br />

NM-T3203 Cap Insert for ø1.8mm Ball Attachment, Soft, Pink, Nylon 27<br />

NM-T3409 Clip-On Transfer, ø4.7mm, L9mm, SS. 37<br />

NM-T3413 Clip-On Transfer, ø4.7mm, L13mm, SS. 37<br />

NM-T3507 Transfer for Closed Tray, ø3.85mm, L12.0mm, SS. 35<br />

NM-T3511 Transfer for Closed Tray, ø4.5mm, L12.0mm, SS. 35<br />

NM-T3601 Transfer for Closed Tray, ø4.75mm, L8.0mm, SS. 35<br />

NM-T3802 Ball Transfer, SH2.0mm, Ti. 36<br />

NM-T3803 Ball Transfer, SH3.0mm, Ti. 36<br />

NM-T3804 Ball Transfer, SH4.0mm, Ti. 36<br />

NM-T3805 Ball Transfer, SH5.0mm, Ti. 36<br />

NM-T3806 Ball Transfer, SH6.0mm, Ti. 36<br />

NM-T4008 Transfer for Open Tray, ø4.75mm, L8.0mm, SS. 35<br />

NM-T4012 Transfer for Open Tray, ø4.75mm, L12.0mm, SS. 35<br />

NM-T4201 Transfer for Open Tray, ø4.3mm, L12.0mm, SS. 35<br />

NM-T4203 Transfer for Open Tray, ø3.85mm, L12.0mm, SS. 35<br />

NM-T4204 Transfer for Open Tray, ø3.85mm, L12.0mm, Non Hex, SS. 35<br />

NM-T4402 Plastic Cap for Snap-On Transfer, ø4.8mm, L11mm, Ti. 36, 52, 59<br />

NM-T4410 Snap On Transfer for MBI, Derlin 27<br />

NM-T4420 Snap On Transfer for MONO, Derlin 29<br />

NM-T6004 Analog, ø4.0mm, L12.7mm, SS. 37<br />

NM-T6005 Analog, ø5.0mm, L12.7mm, SS. 37<br />

NM-T6124 Analog for MBI, SS. 27<br />

NM-T6202 Analog for Mono, SS. 29<br />

NM-T7102 Snap On Transfer for Multi Unit, Closed Tray, ø4.9mm, L8.0mm, Ti. 52, 59<br />

NM-T7111 Transfer for Multi Unit, Open Tray, ø4.9mm, L11.0mm, SS. 52, 59<br />

NM-T7121 Universal Abutment for Multi Unit, ø4.9mm, L12.0mm,Ti. 52<br />

NM-T7122 Castable Sleeve Positioner, Multi Unit, ø4.8mm, L10mm, Ti. 52<br />

NM-T7123 Universal Abutment for Multi Unit, ø4.8mm, L12mm, Ti. 52<br />

NM-T7151 Analog for Multi Unit, ø4.8mm, SS. 52<br />

NM-T7251 Analog for Vari Connect, ø4.9mm, SS. 59<br />

NM-T7262 Ball Attachment for Vari Connect, ø4.8mm, L2.0mm, Ti. 59<br />

NM-T7263 Ball Attachment for Vari Connect, ø4.8mm, L3.0mm, Ti. 59<br />

NM-T7264 Ball Attachment for Vari Connect, ø4.8mm, L4.0mm, Ti. 59<br />

NM-T7273 Fall Attachment for Vari Connect, ø4.8mm, L3.0mm, Ti. 59<br />

NM-T7274 Flat Attachment for Vari Connect, ø4.8mm, L4.0mm, Ti. 59<br />

NM-V Description Page<br />

NM-V2010 MBI Implant, ø2.0mm, L10mm, Ti. 27<br />

NM-V2013 MBI Implant, ø2.0mm, L13mm, Ti. 27<br />

NM-V2016 MBI Implant, ø2.0mm, L16mm, Ti. 27<br />

NM-V2018 MBI Implant, ø2.0mm, L18mm, Ti. 27<br />

/ 80 / Index


NM-V2410 MBI Implant, ø2.4mm, L10mm, Ti. 27<br />

NM-V2413 MBI Implant, ø2.4mm, L13mm, Ti. 27<br />

NM-V2416 MBI Implant, ø2.4mm, L16mm, Ti. 27<br />

NM-V2418 MBI Implant, ø2.4mm, L18mm, Ti. 27<br />

NM-V2910 MBI Implant, ø2.9mm, L10mm, Ti. 27<br />

NM-V2913 MBI Implant, ø2.9mm, L13mm, Ti. 27<br />

NM-V2916 MBI Implant, ø2.9mm, L16mm, Ti. 27<br />

NM-V2918 MBI Implant, ø2.9mm, L18mm, Ti. 27<br />

NM-V3010 Mono Implant, ø3.0mm, L10mm, Ti. 29<br />

NM-V3011 Mono Implant, ø3.0mm, L11.5mm, Ti. 29<br />

NM-V3013 Mono Implant, ø3.0mm, L13mm, Ti. 29<br />

NM-V3016 Mono Implant, ø3.0mm, L16mm, Ti. 29<br />

NM-V3310 Mono Implant, ø3.3mm, L10mm, Ti. 29<br />

NM-V3311 Mono Implant, ø3.3mm, L11.5mm, Ti. 29<br />

NM-V3313 Mono Implant, ø3.3mm, L13mm, Ti. 29<br />

NM-V3316 Mono Implant, ø3.3mm, L16mm, Ti. 29<br />

NM-V3710 Mono Implant, ø3.75mm, L10mm, Ti. 29<br />

NM-V3711 Mono Implant, ø3.75mm, L11.5mm, Ti. 29<br />

NM-V3713 Mono Implant, ø3.75mm, L13mm, Ti. 29<br />

NM-V3716 Mono Implant, ø3.75mm, L16mm, Ti. 29<br />

NM-V4210 Mono Implant, ø4.2mm, L10mm, Ti. 29<br />

NM-V4211 Mono Implant, ø4.2mm, L11.5mm, Ti. 29<br />

NM-V4213 Mono Implant, ø4.2mm, L13mm, Ti. 29<br />

NM-V4216 Mono Implant, ø4.2mm, L16mm, Ti. 29<br />

NM-V4218 Mono Implant, ø4.2mm, L18mm, Ti. 29<br />

NM-V5010 Mono Implant, ø5.0mm, L10mm, Ti. 29<br />

NM-V5011 Mono Implant, ø5.0mm, L11.5mm, Ti. 29<br />

NM-V5013 Mono Implant, ø5.0mm, L13mm, Ti. 29<br />

NM-X Description Page<br />

NM-X1006 Hand driver Hex 1.25mm, L7.0mm, SS. 32, 70<br />

NM-X1007 Hand driver Hex 1.25mm, L14.0mm, SS. 32, 70, 74<br />

NM-X1008 Motor Mount Hex 1.25mm, L20.0mm, SS. 32, 70, 74, 75<br />

NM-X1009 Motor Mount Hex 1.25mm, L25.0mm, SS. 32, 70<br />

NM-X1010 Motor Mount Hex 1.25mm, L35.0mm, SS. 32, 70<br />

NM-X1011 Hand driver Hex 1.25mm, L20.0mm, SS. 32, 70<br />

NM-X1016 Straight Multi-Unit Driver, Int. Hex 2.0mm, L6mm, SS. 33, 53, 71<br />

NM-X1017 Straight Multi-Unit Driver, Int. Hex 2.0mm, L10mm, SS. 33, 53, 71<br />

NM-X1018 Driver, Int. Sqr 2.15mm, L6mm, SS. 7, 29, 69<br />

NM-X1019 Driver, Int. Sqr 2.15mm, L10mm, SS. 7, 27, 29, 69<br />

NM-X1020 Ratchet, SS. 72, 75<br />

NM-X1021 Torque Ratchet, SS. 72, 74, 75<br />

NM-X1023 Surgical Screw Driver, SS. 72<br />

NM-X1025 Depth Probe, SS. 72, 74<br />

NM-X1026 Straight Guide Pin ø2.0mm, L10mm, SS. 73, 74, 75<br />

NM-X1027 Straight Guide Pin ø2.0mm, L16mm, SS. 73, 74, 75<br />

NM-X1028 Depth Probe 35mm-57.5mm 24, 25<br />

NM-X1030 Contra Angle Torque Control HandPiece, SS. 72<br />

NM-X1120 Straight Multi-Unit Motor, Int. Hex 2.0mm, L20mm, SS. 53, 71<br />

NM-X1125 Straight Multi-Unit Motor, Int. Hex 2.0mm, L25mm, SS. 53, 71<br />

NM-X1207 Driver Hex 1.25mm, L7.0mm, SS. 32, 70, 74<br />

NM-X1210 Driver Hex 1.25mm, L10.0mm, SS. 24, 32, 70<br />

NM-X1215 Driver Hex 1.25mm, L15.0mm, SS. 32, 70, 74, 75<br />

NM-X1302 Angulated Guide Pin 17˚, L10.0mm, Ti. 73<br />

NM-X1304 Angulated Guide Pin 30˚, L10.0mm, Ti. 73<br />

NM-X1305 Angulated Guide Pin 45˚, L10.0mm, Ti. 73<br />

NM-X1312 Angulated Guide Pin 17˚, L16.0mm, Ti. 73<br />

NM-X1314 Angulated Guide Pin 30˚, L16.0mm, Ti. 73<br />

NM-X1315 Angulated Guide Pin 45˚, L16.0mm, Ti. 73<br />

NM-X1402 Angulated Guide Pin Int. Hex. 2.42mm, 17°, SS. 73<br />

NM-X1404 Angulated Guide Pin Int. Hex. 2.42mm, 30°, SS. 73<br />

NM-X1405 Angulated Guide Pin Int. Hex. 2.42mm, 45°, SS. 73<br />

NM-X1406 Angulated Guide Pin Int. Hex. 2.42mm, 52°, SS. 73<br />

NM-X1407 Angulated Guide Pin Int. Hex. 2.42mm, 60°, SS. 73<br />

NM-X1520 Motor Mount Int. Sqr. 1.7mm, SS. 7, 27, 69<br />

NM-X1620 Motor Mount Int. Sqr. 2.15mm, SS. 7, 29, 69<br />

NM-X1720 Driver, Int. Sqr 2.15mm, L20mm, SS. 29, 69<br />

NM-X2111 Premium Surgical Kit Box 74<br />

NM-X2112 Premium Surgical Kit Box Including Conical Drills 74<br />

NM-X2118 Zygomatic Surgical Kit 24<br />

NM-X2210 Mini Surgical Kit Box with Torque Ratchet 75<br />

NM-X2211 Mini Surgical Kit Box 75<br />

NM-X2212 35 Pcs. Stop Drill Set. 76<br />

NM-X2216 15 Pcs. Stop Drill Set. 76<br />

NM-X2415 One Piece Driver, Int. Sqr 1.7mm, L10mm, SS. 7, 27, 69<br />

NM-X3001 Osteotome, ø2.0mm, SS. 21<br />

NM-X3002 Osteotome, ø3.0mm, SS. 21<br />

NM-X7006 Driver Star-Hex 1.25mm, L7.0mm, SS. 33, 53, 59, 71<br />

NM-X7007 Driver Star-Hex 1.25mm, L14.0mm, SS. 24, 33, 53, 59, 71<br />

NM-X7008 Motor Mount, Star-Hex 1.25mm, L20.0mm, SS. 33, 53, 59, 71<br />

NM-X7009 Motor Mount, Star-Hex 1.25mm, L25.0mm, SS. 33, 53, 59, 71<br />

NM-X7010 Motor Mount, Star-Hex 1.25mm, L35.0mm, SS. 33, 53, 59, 71<br />

NM-X7011 Driver Star-Hex 1.25mm, L20.0mm, SS. 33, 53, 59, 71<br />

NM-X7100 Stright Multi-Unit holder, Delrin 50<br />

NM-X7101 Angualted Multi-Unit holder, Delrin 50, 58<br />

NM-X7307 Star Hex. Ratchet Drivers, 1.25mm, L7mm, SS. 71<br />

NM-X7310 Star Hex. Ratchet Drivers, 1.25mm, L10mm, SS. 71<br />

NM-X7315 Star Hex. Ratchet Drivers, 1.25mm, L15mm, SS. 71<br />

NM-Z Description Page<br />

NM-Z1001 Ti. Base for Zirconia, Ti. 44<br />

NM-Z3400 Angulated, Anatomic Ti. Base Zirconia Abutment, 15°, L9mm, SH0.5mm 44<br />

NM-Z3401 Angulated, Anatomic Ti. Base Zirconia Abutment, 15°, L9.5mm, SH1mm 44<br />

NM-Z3402 Angulated, Anatomic Ti. Base Zirconia Abutment, 15°, L10.5mm, SH2mm 44<br />

NM-Z3403 Angulated, Anatomic Ti. Base Zirconia Abutment, 15°, L11.5mm, SH3mm 44<br />

NM-Z3600 Angulated, Anatomic Ti. Base Zirconia Abutment, 25°, L9mm, SH0.5mm 44<br />

NM-Z3601 Angulated, Anatomic Ti. Base Zirconia Abutment, 25°, L9.5mm, SH1mm 44<br />

NM-Z3602 Angulated, Anatomic Ti. Base Zirconia Abutment, 25°, L10.5mm, SH2mm 44<br />

NM-Z3603 Angulated, Anatomic Ti. Base Zirconia Abutment, 25°, L11.5mm, SH3mm 44<br />

NM-Z5600 Straight Anatomic Ti. Base Zirconia Abutment, L8.5mm, SH0.5mm 44<br />

NM-Z5601 Straight Anatomic Ti. Base Zirconia Abutment, L9mm, SH1mm 44<br />

NM-Z5602 Straight Anatomic Ti. Base Zirconia Abutment, L10mm, SH2mm 44<br />

NM-Z5603 Straight Anatomic Ti. Base Zirconia Abutment, L11mm, SH3mm 44<br />

/ 81 /


Index<br />

NMAF Description<br />

Page<br />

NMAF3308 Tuff Pro Implant, ø3.3mm, L8.0mm, Ti. 11<br />

NMAF3310 Tuff Pro Implant, ø3.3mm, L10.0mm, Ti. 11<br />

NMAF3311 Tuff Pro Implant, ø3.3mm, L11.5mm, Ti. 11<br />

NMAF3313 Tuff Pro Implant, ø3.3mm, L13.0mm, Ti. 11<br />

NMAF3316 Tuff Pro Implant, ø3.3mm, L16.0mm, Ti. 11<br />

NMAF3708 Tuff Pro Implant, ø3.75mm, L8.0mm, Ti. 11<br />

NMAF3710 Tuff Pro Implant, ø3.75mm, L10.0mm, Ti. 11<br />

NMAF3711 Tuff Pro Implant, ø3.75mm, L11.5mm, Ti. 11<br />

NMAF3713 Tuff Pro Implant, ø3.75mm, L13.0mm, Ti. 11<br />

NMAF3716 Tuff Pro Implant, ø3.75mm, L16.0mm, Ti. 11<br />

NMAF4208 Tuff Pro Implant, ø4.2mm, L8.0mm, Ti. 11<br />

NMAF4210 Tuff Pro Implant, ø4.2mm, L10.0mm, Ti. 11<br />

NMAF4211 Tuff Pro Implant, ø4.2mm, L11.5mm, Ti. 11<br />

NMAF4213 Tuff Pro Implant, ø4.2mm, L13.0mm, Ti. 11<br />

NMAF4216 Tuff Pro Implant, ø4.2mm, L16.0mm, Ti. 11<br />

NMAF4218 PteryFit Implant, ø4.2mm, L18.0mm, Ti. 19<br />

NMAF4220 PteryFit Implant, ø4.2mm, L20.0mm, Ti. 19<br />

NMAF4222 PteryFit Implant, ø4.2mm, L22.0mm, Ti. 19<br />

NMAF4225 PteryFit Implant, ø4.2mm, L25.0mm, Ti. 19<br />

NMAF5008 Tuff Pro Implant, ø5.0mm, L8.0mm, Ti. 11<br />

NMAF5010 Tuff Pro Implant, ø5.0mm, L10.0mm, Ti. 11<br />

NMAF5011 Tuff Pro Implant, ø5.0mm, L11.5mm, Ti. 11<br />

NMAF5013 Tuff Pro Implant, ø5.0mm, L13.0mm, Ti. 11<br />

NMAF5016 Tuff Pro Implant, ø5.0mm, L16.0mm, Ti. 11<br />

NMBV Description<br />

Page<br />

NMBV3710 Bendable Mono Implant, ø3.75mm, L10.0mm, Ti. 29<br />

NMBV3711 Bendable Mono Implant, ø3.75mm, L11.5mm, Ti. 29<br />

NMBV3713 Bendable Mono Implant, ø3.75mm, L13.0mm, Ti. 29<br />

NMBV3716 Bendable Mono Implant, ø3.75mm, L16.0mm, Ti. 29<br />

NMBV4210 Bendable Mono Implant, ø4.2mm, L10.0mm, Ti. 29<br />

NMBV4211 Bendable Mono Implant, ø4.2mm, L11.5mm, Ti. 29<br />

NMBV4213 Bendable Mono Implant, ø4.2mm, L13.0mm, Ti. 29<br />

NMBV4216 Bendable Mono Implant, ø4.2mm, L16.0mm, Ti. 29<br />

NMHX Description<br />

Page<br />

NMHX1014 Motor Mount, 2.4mm, L20mm, SS. 6, 69, 74<br />

NMHX1015 Motor Mount, 2.4mm, L28mm, SS. 6, 24, 69, 74, 75<br />

NMHX2607 Driver Hex 2.42mm, L7mm, Ti. 6, 69, 74<br />

NMHX2610 Driver Hex 2.42mm, L10mm, Ti. 6, 69<br />

NMHX2615 Driver Hex 2.42mm, L15mm, Ti. 6, 69, 74, 75<br />

NMHX2620 Driver Hex 2.42mm, L20mm, Ti. 6, 24, 69<br />

NMHX2640 Driver Hex 2.42mm, L40mm, Ti. 6, 69<br />

NMSF3708 Tuff Implant, Machined Neck, ø3.75mm, L8.0mm, Ti. 9<br />

NMSF3710 Tuff Implant, Machined Neck, ø3.75mm, L10.0mm, Ti. 9<br />

NMSF3711 Tuff Implant, Machined Neck, ø3.75mm, L11.5mm, Ti. 9<br />

NMSF3713 Tuff Implant, Machined Neck, ø3.75mm, L13.0mm, Ti. 9<br />

NMSF3716 Tuff Implant, Machined Neck, ø3.75mm, L16.0mm, Ti. 9<br />

NMSF3718 Tuff Implant, Machined Neck, ø3.75mm, L18.0mm, Ti. 9<br />

NMSF4206 Tuff Implant, Machined Neck, ø4.2mm, L6.0mm, Ti. 9<br />

NMSF4208 Tuff Implant, Machined Neck, ø4.2mm, L8.0mm, Ti. 9<br />

NMSF4210 Tuff Implant, Machined Neck, ø4.2mm, L10.0mm, Ti. 9<br />

NMSF4211 Tuff Implant, Machined Neck, ø4.2mm, L11.5mm, Ti. 9<br />

NMSF4213 Tuff Implant, Machined Neck, ø4.2mm, L13.0mm, Ti. 9<br />

NMSF4216 Tuff Implant, Machined Neck, ø4.2mm, L16.0mm, Ti. 9<br />

NMSF4218 Tuff Implant, Machined Neck, ø4.2mm, L18.0mm, Ti. 9<br />

NMSF4220 Tuff Implant, Machined Neck, ø4.2mm, L20.0mm, Ti. 9<br />

NMSF4222 Tuff Implant, Machined Neck, ø4.2mm, L22.0mm, Ti. 9<br />

NMSF4225 Tuff Implant, Machined Neck, ø4.2mm, L25.0mm, Ti. 9<br />

NMSF5006 Tuff Implant, Machined Neck, ø5.0mm, L6.0mm, Ti. 9<br />

NMSF5008 Tuff Implant, Machined Neck, ø5.0mm, L8.0mm, Ti. 9<br />

NMSF5010 Tuff Implant, Machined Neck, ø5.0mm, L10.0mm, Ti. 9<br />

NMSF5011 Tuff Implant, Machined Neck, ø5.0mm, L11.5mm, Ti. 9<br />

NMSF5013 Tuff Implant, Machined Neck, ø5.0mm, L13.0mm, Ti. 9<br />

NMSF5016 Tuff Implant, Machined Neck, ø5.0mm, L16.0mm, Ti. 9<br />

NMSF6006 Tuff Implant, Machined Neck, ø6.0mm, L6.0mm, Ti. 9<br />

NMSF6008 Tuff Implant, Machined Neck, ø6.0mm, L8.0mm, Ti. 9<br />

NMSF6010 Tuff Implant, Machined Neck, ø6.0mm, L10.0mm, Ti. 9<br />

NMSF6011 Tuff Implant, Machined Neck, ø6.0mm, L11.5mm, Ti. 9<br />

NMSF6013 Tuff Implant, Machined Neck, ø6.0mm, L13.0mm, Ti. 9<br />

NMSF6016 Tuff Implant, Machined Neck, ø6.0mm, L16.0mm, Ti. 9<br />

NMTV Description<br />

Page<br />

NMTV2010 MBI NC Implant, ø2.0mm, L10mm, Ti. 27<br />

NMTV2013 MBI NC Implant, ø2.0mm, L13mm, Ti. 27<br />

NMTV2016 MBI NC Implant, ø2.0mm, L16mm, Ti. 27<br />

NMTV2018 MBI NC Implant, ø2.0mm, L18mm, Ti. 27<br />

NMTV2410 MBI NC Implant, ø2.4mm, L10mm, Ti. 27<br />

NMTV2413 MBI NC Implant, ø2.4mm, L13mm, Ti. 27<br />

NMTV2416 MBI NC Implant, ø2.4mm, L16mm, Ti. 27<br />

NMTV2418 MBI NC Implant, ø2.4mm, L18mm, Ti. 27<br />

NMTV2910 MBI NC Implant, ø2.9mm, L10mm, Ti. 27<br />

NMTV2913 MBI NC Implant, ø2.9mm, L13mm, Ti. 27<br />

NMTV2916 MBI NC Implant, ø2.9mm, L16mm, Ti. 27<br />

NMTV2918 MBI NC Implant, ø2.9mm, L18mm, Ti. 27<br />

NMSF Description Page<br />

NMSF3308 Tuff Implant, Machined Neck, ø3.3mm, L8.0mm, Ti. 9<br />

NMSF3310 Tuff Implant, Machined Neck, ø3.3mm, L10.0mm, Ti. 9<br />

NMSF3311 Tuff Implant, Machined Neck, ø3.3mm, L11.5mm, Ti. 9<br />

NMSF3313 Tuff Implant, Machined Neck, ø3.3mm, L13.0mm, Ti. 9<br />

NMSF3316 Tuff Implant, Machined Neck, ø3.3mm, L16.0mm, Ti. 9<br />

NMSF3706 Tuff Implant, Machined Neck, ø3.75mm, L6.0mm, Ti. 9<br />

/ 82 / Index


PRECISION<br />

DOWN TO THE SMALLEST DETAIL


LBL006 Rev. <strong>2019</strong>-1 EN | © <strong>2019</strong> NORIS MEDICAL<br />

www.norismedical.com

Hooray! Your file is uploaded and ready to be published.

Saved successfully!

Ooh no, something went wrong!
