NZ Bakery Solutions

Bakery Solutions

BURNS & FERRALL | BAKERY SOLUTIONS 1

“The difference between

ordinary and extraordinary

is that little extra.”

Jimmy Johnson

2 BURNS & FERRALL | BAKERY SOLUTIONS

Seventy years is a long

time in anyone’s book and

even longer in the fickle

world of business.

From humble beginnings in a garden

shed in 1948 to an iconic commercial kitchen

company. Burns & Ferrall established a reputation

for successfully designing, building, project

managing, commissioning then maintaining a vast

number of New Zealand’s commercial kitchens

and bars. From a corner café to the largest

stadium and everything in between.

Now trading as REWARD HOSPITALITY and continuing

to be backed by the world’s most trusted brands of

commercial kitchen equipment we have a passionate,

experienced team whose sole objective is to deliver a total

solution that meets your individual requirements as to:

• Space

• Minimising operating

• Specification

and maintenance costs

• Performance

• Maximising return

• Reliability

on investment

• Budget


Rack

Ovens

Sveba Dahlen C150

Eco Plus

• Single rack oven

• Smaller foot print, heavy duty

bearing

• SD touch panel energy saving

unit

• Oil fired unit / Gas / Electric

options

• 400V + 3Ph + N + G + 50Hz

Code: Sveba Dahlen C151, C150,

C152 Eco Plus

Bongard Rotating Rack

Oven 8.43E

• Rotating single rack oven

• Platform or hook based options

• Polished stainless steel, tool

holder, blade holder,

2 electric steam dampers

• Maximum baking temp 280°C

• Fast recovery and intuitive controls

• 400V + 3Ph + N + G + 50Hz

Code: Bongard Rack Oven 8.43E

Sveba Dahlen V40

Rack Oven

• Double rack oven

• Energy efficient unti for baking

two racks

• SD touch panel, heavy duty

platform

• Oil fired unit / Gas / Electric

options

• 400V + 3Ph + N + G + 50Hz

Code: Sveba Dahlen V40, V41, V42

Bongard Rotating Rack

Oven 8.84E

• Rotating double rack oven

• Platform or hook based options

• Polished stainless steel, tool holder,

blade holder,

2 electric steam dampers

• Maximum baking temp 280°C

• Fast recovery and intuitive controls

• 400V + 3Ph + N + G + 50Hz

Code: 9310100

Reward Hospitality | Bakery Solutions



Deck

Ovens

Bongard Soleo Deck Oven M4

• Modular Decking with 2, 3 or 4 options

• Opticom controls

• With/without integrated loader

• 400V + 3Ph + N + G + 50Hz

Bongard Omega 2 Range

• 4 decks

• 2 doors of 600mm or 2 doors of 800mm

• Intuitiv controls

• 400V + 3Ph + N + G + 50Hz

Bongard Cervap

RS Range

• 5 decks with options

• Number of doors at 800mm or 1200mm

• 400V + 3Ph + N + G + 50Hz

Sveba Dahlen

Combination Oven

• Flexismart 2.0

• 10 Tray convection oven

• 2 tray deck, 5 tray prover

• 400V + 3Ph + N + G + 50Hz

Sveba Dahlen P-Series

Pizza Ovens

• Options of 1-5 decks with or

without steam

• SD touch panels

• 400V + 3Ph + N + G + 50Hz

Sveba Dahlen D-Series

Deck Oven

• Options of 1-5 decks with or

without steam

• SD touch panels

• 400V + 3Ph + N + G + 50Hz




Pastry Sheeters/

Make Up Lines

Compas 3000HD

• Automatic reeler

• Automatic flour duster

• Table length overall 3500mm

• Speed of discharge conveyor

50 - 96cm/sec

Code: Compass 3000HD

Rondostar Cutomat 4000

• Safety guard opening

• Roller length 660mm

• Net weight 330kg

• Speed of discharge conveyor

- 85cm/sec

Code: Rondostar 4000

Rondo Polyline

• Modular lengths - 3800, 5000,

6200 and 7600mm

• Mechanical guillotine

• Microprocessor control system

• Touchpanel with 99 memory slots

Code: Rondo Poly

Rondo Ecoline

• Running direction - left to right

• Belt speed - 0.5-8m/min

• Table width x height - 715mm x 915mm

Croissmat SCM

• With calibrating unit

• Infeed belt

• Belt speed - 9m/min

• Weight 765kg

Cromaster

• Standard and integrated configurations

• Weight variations between 700 - 950kg

• Up to 3000 unfilled croissants or 2000

filled per hour

Code: Rondo Eco Code: CroissmatSCM Code: Cromaster

8 BURNS & FERRALL | BAKERY SOLUTIONS

Reward Hospitality | Bakery Solutions

Pastry

Sheeters

Rondo STM 513

Rondo SSO 615

Rondomat 4000 SSO 6405

• Conveyer Belt - 475mm (w)

• Table - 490mm (w) x 1560mm (l) overall

• Roller - 500mm (w) x 05mm-30mm gap

• Power rated .75Kw

• Supply Voltage - 3 x 400V 50Hz

• Working Position - 940mm x 1560mm

• Resting Position - 940mm x 670mm

• Net weight - 80kg

Code: STM513




• Power rated 1.0Kw





Code: SSO615

• Conveyer Belt - 640 (w)






Code: SS06405

Manomat 2000 SSO 667

• Conveyer Belt - 640 (w)






Rondostar Eco SFE 6607.E0

• Automatic pastry sheeter

• Conveyor Belt - 640mm (w)




Rondostar 5000 Pro SS6727H



• Roller - 660mm (w) x .02mm-45mm gap




Code: SS0667 Code: SFE6607.EO Code: SSH6727




Spiral

Mixers

Bongard Spiral Evo Mixer 50e

• Flour capacity 1.2kg - 20kg

• 400V + 3ph + N + G + 50Hz




• 400V + 3ph + N + G + 50Hz




• 400V + 3ph + N + G + 50Hz


Code: Bongard 50e



• Flour capacity 2.5kg - 62.5kg

• 400V + 3ph + N + G + 50Hz




• 400V + 3ph + N + G + 50Hz




• 400V + 3ph + N + G + 50Hz







Spiral

Mixers

Ferneto Spiral Mixer 12kg

• Flour capacity min 0.75g - 12kg

• Bowl volume 29l

• 400V + 3Ph + 50/60Hz + 2 speeds


Code: Fernato AEF012


• Flour capacity min 1.8kg - 30kg


• 400V + 3Ph + 50/60Hz + 2 speeds




• Flour capacity min 2.5kg - 50kg


• 400V + 3Ph + 50/60Hz + 2 speeds




• Flour capacity min 4kg - 80kg


• 400V + 3Ph + 50/60Hz + 2 speeds




• Flour capacity min 5kg - 100kg


• 400V + 3Ph + 50/60Hz + 2 speeds






Planetary

Mixers

Ferneto Planetary

Mixer BTF010

• Bowl capacity 10l

• Includes: bowl, whisk, paddle, hook

• 23V/110V + 1Ph + 50/60Hz

• Variable speed


Code: BTF010


Mixer BTF020



• 400V + 3Ph + 50/60Hz



Code: BTF020


Mixer BTF040



• 400V + 3Ph + 50/60Hz



Code: BTF040


Mixer BTF060



• 400V + 1Ph + 50/60Hz



Code: BTF060

Bakequip Planetary Mixer 10l



• 250W

• Dimensions: 600l x 580w x 960h mm

• 3 speeds: 59 / 110 / 201 rpm

Code: BTF10

Bakequip Planetary Mixer 25l



• 3/4 HP

• Dimensions: 610l x 670w x 1020h mm

• 3 speeds: 108 / 183 / 352 rpm

Code: BTF25



Provers/

Blast Freezers

Hengel Roll in Retarder Prover

• Multiple options available

• Exterior white lacquered steel or stainless options

• Ergonomic door mounted control panel

• Tropicalized remote refrigeration unit

• Anti-short cycle for longer compressor life

• 400V + 3Ph + N 50/60Hz

Code: HF1

Bongard Roll In Retarder Prover BFC

• Multiple configurations

• Split chambers - great for afternoon bakes

• Can retard doughs up to 72 hours

• Available with windows in doors, stainless steel inside

and outside if requested

• 400V + 3ph + N + G + 50/60Hz

Code: BFC

Bongard Reach In Retarder Prover BFA

• Single or split door options

• 230V + single Ph + Gr + 50Hz

• 20 adjustable tray slides


Code: BFA

Bongard Blast Freezer BSC 68.1

• Roll in Rack Blast Freezer

• Pre-built unit

• Blast chill/blast freeze options

• Roll in rack unit single trolley

• 400V 3Ph + N + G 50Hz

Code: Bongard Blast Freezer BSC 68.1




Divider

Rounders

Bongard Bun Divider Rounder

• 30 divisions

• Dough piece min 40gm - max 130gm

• 400V + 3ph + 50/60Hz + 2 speeds


Code: DB230-4

Bongard Divider Rounder - Auto

• Fully automatic


• 400V + 3ph + 50/60Hz + 2 speeds


Code: DB3 FA 30-4

Ferneto Semi Automatic Bun

Divider with Removable Press

• Piece capacity 30

• Head size from 900gm - 3000kg

• Roll size 30gm - 100gm

• Changeable heads - 15, 22, 30, 36, 54


Code: DSA330

Ferneto Fully Automatic Bun

Divider/Rounder DDA

• Full body & top stainless steel

• Safety cover (incl front) safety from moving parts



Code: DDA330



Divider

Rounders

Bongard Divimach AGP

• Divides no time doughs/bulk fermentation

• Doughs can divide into 10/20 plus grid options

• 400V + 3Ph + 50/60Hz


Code: Bongard Divimach AGP

Bongard Paneotrad

• Inter-changeable grids giving a large range of cuts and shapes

• Revolutionary in its concept

• 400V + 3Ph + N + 50/60Hz


Code: Bongard Paneotrad



Water Chiller/

Meter

Baktec Water Meter B1 CERES II

• Electronic accurate and reliable dosing of water to mixers

• Single phase 220-240 VAC 50/60Hz

• Weight 8.6kg

Code: B1

Baktec Water Chiller

• Wall mounted

• Eco-friendly & very low water temperatures continuously available

• Up to 150l chiller water per hour

• Single Phase 220-240 VAC / 50Hz


Code: BLK200



Slicers

Ferneto Bread Slicer

• Tabletop Bread Slicer

• 16mm slice thickness

• Max loaf length 440l x 310w x 160h mm

• Power 400/230V + 3Ph + 50/60Hz


Code: Fernato CMF416

Rollmatic Samurai MR52

• Industrial Type

• Rear loading

• Normal cut width 520mm

• Loaf height 25/180mm

• Blade pitches available from 9 - 20

Code: Rollmatic MR52



Bread

Moulders

Bongard Major Manu Inclined Moulder

• Inclined Moulder - stand optional

• Capacity 1500 pieces per hour

• Dough piece min 80gm - max 1000gm

• 400V + 3Ph + 50/60Hz + 2


Code: Bongard Major Manu/with Stand

Ferneto Baguette Moulder

• Piece size 50gm - 1200gm

• Units per hour min 60 - max 1200

• 400V + 3Ph + 50/60Hz


Code: Ferneto FVF800



Donut Fryers

Stok Donut Fryer

• Fully automatic with electronic controls

• 100% high-quality stainless steel

• 20l capacity frying reservoir

• 4000 watts of heat to the oil, keeping oil at frying

temperature of 190c

Riehle Mini 20

• Digital heater control to reduce temperature loss

• Integrated steam proof fermentation

chamber with 10 rows and 2L water tank

• 20 dough pieces per baking process

Code: RiehleMini20

Riehle Fettboy Digital

• Up to approximately 20-30 dough pieces per

baking process

• Digital heating and temperature control

• Closed steam lid

Code: RiehleFettboy



Bread Lines

Konig Mini Rex

• Mini bread roll plant

• Compact design, labour

saving benefits

• Maximum hourly capacity

3,960 pieces

Code: DR-RR4400

• Stainless steel design

• Quick and easy cleaning

• Plug in elements


Glimek Flexible Bread Line

• Fully automatic bread line

• Designed for large runs with speed and accuracy

• Weight range 100-1500gm

• Speed 3000p/hr

• Labour saving benefits

Code: Glimek Flexible Bread Line



Bratt Pans

& Kettles

Mareno Gas Bratt Pan

• 60l tilting bratt pan

• 800w x 730d x 870h mm

• Electric option available



• 800mm x 900mm x 870mm



• 1200w x 900d x 870h mm

Code: NBR78GF

Code: NBR98GF

Code: NBR912GFM

Cleveland Electric Steam Mixer

• Tilting steam unit with mixer

• 708w x 1009d 1110h mm

• Available in 45l or 80l

Code: MKET

Cleveland Electric Steam Mixer

• Tilting steam unit with mixer

• Includes water faucet

• Level adjustable feet

• Available in 150l, 225l, 300l and 375l.

Code: MKEL-T

Cleveland Electric Twin Mixer

• Total capacity: 757l

• Capacity per unit: 378l

• 2995w x 1194d x 1213h mm

Code: TMKEL



Blast

Freezers

Nuovair Blast Freezer

• Max capacity: 18kg

• 325/530 trays

• 740w x 700d x 830h mm



• 400/600 trays

• 800w x 813d x 1560h mm

Code: NA1.18

Code: NA1.30


• Roll in rack

• 600/800 trays


• 960w x 1500d x 2750h mm

Code: NA2.80T1


• Roll in rack

• 2 trolleys

• 400/600 trays


• 1680w x 1350d x 2380h mm

Code: NA2.140T1



Cabinets

Cossiga Tower

• Refrigerated

• Double glazed glass

• 3 adjustable shelves with ticket strips

• 600mm and 1200mm options available

Code: BTGRF900

Cossiga Tower

• Ambient

• Circular fan in ceiling



Code: BTGAB900

Cossiga Tower

• Heated

• Single glazed glass



Code: BTGHT900

Cossiga Countertop Tower

• Refrigerated

• Double glazed glass


• Integral condenser



• Ambient

• Circulation fan in ceiling





• Heated



• Undershelf and canopy LED lights


Code: STGRF900 Code: STGAB900 Code: STGHT900



Dishwashers

Hobart Ecomax 504

• Electronic control with digital temperature indication

• 2 selectable wash cycles

• Indented nozzles prevent blocking

• USB connect for easier service access

Code: Ecomax504

Hobart Ecomax H615

• Easy to use electronic controls with 3 cycles

• Electronic temperature gauges

• Suitable for all dish & glass washing applications

• Usable chamber height of 440mm

Code: EcomaxH615

Hobart Ecomax 700T Utensil

• Soft touch electronic control panel with 3 cycles

• Double skinned chamber construction with coved corners for

easy cleaning

• Low rinse volume

• Usable chamber height of 850mm

Code: Ecomax700T




Grants

Bakeware

Swiss Style Tray

• 16” tray

• 406w x 735l x 25d mm

Code: BT16P

Three Sided Tray

• 16” tray

• 406w x 735l x 25d mm

Code: BT3/16

Four Sided Tray

• 16” tray

• 406w x 735l x 25d mm

Code: BT4/16

Lamington Tray

French Stick Tray

Muffin Tray

Texas Muffin Tray

• 406w x 735l x 50d mm

• Teflon coated

• 32 x 70mm cups

• 18 x 88mm cups

• 5 x 65mm impressions

• 406w x 735l x 35d mm

• 406w x 735l x 43d mm

• 455w x 737l x 32d mm

Code: BT4/16L Code: BT/FS65/16PT Code: BT/MT70/16T Code: BT/MT88/16T



Grants

Bakeware

Pie Tray

Pie Tray

Savoury Pie Tray

Pie Tray

• 18 oval tins

• 21 round tins

• 66 round tins

• 21 square tins

• 406w x 660l mm

• 406w x 750l mm

• 406w x 737l mm

• 406w x 750l mm

Code: PP05/16S Code: PPR1/16S Code: PPR10/16S Code: PPS1/16S

Cooling Wire

Bread Pans

Bread Pans

Bread Pans

• Pack of 5

• 450GM pans



• Stainless Steel

• 400mm x 250mm x 3 pans



• 406w x 737d x 5h mm

Code: CW16/5 Code: BT109/3SU Code: BT122/3SU Code: BP751/3S




Auckland

12 Reg Savory Place, East Tamaki

Auckland 2013

Hamilton

60 Alexandra Street

Hamilton 3204

Wellington

122 Tory Street, Te Aro

Wellington 6011

Christchurch

345 St Asaph Street

Christchurch 8011

rewardhospitality.co.nz | 0800 428 733

PROUDLY PART OF THE ECF GROUP

NZ Bakery Solutions

Create successful ePaper yourself

Delete template?

Save as template?
