PURE Vision Plasma

EXTENDING THE LIMITS

OF PURE ENTERTAINMENT

Because everyone is different, Pioneer has created a variety of

Plasma solutions, one for every kind of lifestyle. Their timeless,

elegant design fits subtly into any home — powered off. Powered on,

each plasma display is a superb piece of bright, colourful art.

Lifelike, high-resolution images, smooth and sharp pictures and

a definitive sound experience make Pioneer PURE Vision Plasma

the ultimate canvas for all forms of entertainment.

TRUE BEAUTY IS TIMELESS

PURE Vision Plasma TV elegant design

BRINGING ART TO LIFE

Up to seven billion colours to enjoy

WHEN TECHNOLOGY MEETS CREATIVITY

High-definition picture perfection

LIVING LIFE ON A GRAND SCALE

61-inch Plasma display

A CHOICE OF PURE VISION PLASMAS

Plasma line-up

ELEGANCE AND EASE OF DISPLAY

Plasma accessories

THE MAKING OF PURE VISION

Glossary, features and specifications

.04

.12

.18

.24

.26

.27

.30

PURE Vision Plasma _ 02 I 03

“True Beauty is timeless...”

LARS OLSSON I ARCHITECT


The Beauty of Pure Black

Styled to enhance the overall look of the Pioneer PURE Vision

Plasma TV, the top-quality black Acoustic Swing speakers can be

easily adjusted into five different positions to customise your

surround sound field with precision. With three surround modes

reproducing excellent quality sound from all sources, you’ll feel

as though you were right in the centre of the action.

In every building I design, I strive to create

a sense of the here and now, as well as

what the future might bring. I have that

same feeling when I look at my Pioneer

PURE Vision Plasma TV. It is truly a

masterpiece. The attention to detail is

apparent in the top-notch material choice

as well as design details — like the

perfectly matching black speakers.


PURE Vision Plasma Elegant Design

From understated elegance to sophisticated glamour, Pioneer

PURE Vision Plasma TV is at home in any interior. Its high gloss

black frame and attractive matte aluminium finish make it a

stunning piece of artwork. You’ll never tire of admiring it.

The secret to good architecture is

continuity. This is exactly what the

Pioneer PURE Vision Plasma TV achieves.

Every line, every angle, every detail has

been carefully crafted to combine modern

elegance with a sense of timeless beauty.

Fluidity and grace have always been

important to me.


Picture-in-Picture

NexTView On-screen

PLASMA AND HOME SECURITY

Whilst enjoying any source of entertainment on the Pioneer PURE Vision Plasma, you

can still keep an eye on what’s happening around your home, via an inset image that

displays information from a security camera.

PLASMA AND COMPUTER

Hook up a Mac or PC and watch your own digital creations come to life. You’ll really

appreciate the way your projects take on new depth and meaning when portrayed to

their full advantage in high resolution. Work will never be a chore again.

PLASMA AND TV

Pioneer’s PURE Vision Plasma TVs are

equipped with the latest technologies,

offering you crisp contrast and rich

colours, with convenient features and

easy-to-use functions — including

NexTView EPG service for selective

programming and viewing. Now you can

enjoy programming at your own pace.

A masterpiece of design, my Pioneer PURE Vision Plasma not

only adds that finishing touch to my interior but it’s also so

versatile. It has totally transformed the way I work — even the

way I live my personal life. When I hook up my PC, my

blueprints come to life before my eyes. Stunning highresolution

makes every detail leap out of the screen.

My family adore watching movies from our Digital Home

Cinema System. Images are so real, it’s like having the movie

stars right there in our home. I don’t even have to get up to

see who’s at the door. I can simply call up images from my

home security system, all from the comfort of my sofa.

PLASMA AND HOME CINEMA

Pioneer PURE Vision Plasma TV provides the ultimate display

to enjoy the latest DVD-Video offerings. A Pioneer Digital Home

Cinema system is easily connected so that the whole family can

indulge in pure movie entertainment.


“Bringing art to life...”

ELENA CASAMONT I FASHION DESIGNER


VIVACIOUS BEAUTY IN BRILLIANT COLOUR

Imagine a colour, and Pioneer PURE Vision

Plasma TV can fashion it with its amazing

reproduction of up to 7 billion colours! With the

new Advanced Super CLEAR Drive technology,

brightness is controlled and enhanced. Contrast is

further intensified and every nuance of black is

reproduced perfectly. No matter how dark the

scene you are watching, you will still be able to

enjoy all the details.

FASHIONING A CONTRAST OF COLOURS

Pioneer’s new Direct Colour Filter tackles

reflection and boosts contrast to ensure that every

colour is at its purest. This revolutionary film-type

filter significantly reduces disturbing reflection

— both from outside light as well as from the

display itself. Even in broad daylight colours are

more intense and more realistic than ever before.

BRINGING BEAUTY INTO THE LIGHT

Colour doesn’t get much better or more intense.

Pioneer’s unique Deep Waffle Rib Structure

makes each plasma cell deeper, resulting in a

much higher level of brightness. With a Pioneer

PURE Vision Plasma, even the sun shines

brighter.

Conventional Plasma


Creating beautiful clothing is all about

perfection. In conceiving my outfits, I

make sure that the colours, the materials

and the cut of the fabric all come together

to create a perfect whole. I expect

perfection in all areas of my life, including

my home. That’s why Pioneer’s PURE

Vision Plasma TV fits in so well. Just like

my creations, my Plasma TV catches the

eye with its perfect reproduction of colour

and pure, bright images. It has clearly

been lovingly styled to dazzle the

audience with its brilliance. I like to think

my designs have the same effect on the

catwalk.

Pioneer Plasma TV

Pioneer Plasma TV

Up to 7 Billion Colours to Enjoy

From the dim lights of the candlelit photoshoot, to the vibrant array of colours

on the catwalks of Paris, every subtle nuance and shade is perceptible, thanks

to the Pioneer PURE Vision Plasma TV’s ability to reproduce up to an amazing

7 billion colours. Advanced Super CLEAR Drive technology does all the tough

work behind the scenes keeping the image brightness under perfect control.


PLASMA AND HOME GALLERY

Turn your home into a gallery, showcasing your own artwork or

perhaps an array of well-known works from the Home Gallery

collection. Since the Pioneer PURE Vision multimedia receiver is compatible with most

digital memory cards, you can display high-resolution JPEG images from a digital still

camera.

PLASMA AND INTERNET

Bring the glamour and glitter of the world’s top fashion shows live from the Internet

into your living room. See every curve and every contour. Add in the buzz of the crowd,

and it’s like you’re actually there.

PLASMA AND DUAL SCREEN OPTIONS

With multi-screen functions, you can watch more than one image at a time. So

whether you want to compare your own designs with those on the Paris catwalk or surf

the Internet for accessories, you’ve got it all at your fingertips on your Pioneer PURE

Vision Plasma.

Pioneer’s PURE Vision Plasma TV is the ideal canvas for my

work. Its pure brilliance of colour and high-resolution images

expose perfectly the delicate lines and subtle curves of each

design. I often hold a fashion show for guests, showing stills

of my work using Home Gallery.

Comparing my creations with the latest trends has become

very easy. I simply switch to the dual screen function and can

look at styles from the Internet or any other source, side-byside

on the screen. Pioneer’s PURE Vision Plasma TV is my

own model of perfection.


CRAIG BAKER I TELEVISION PRODUCER

“When technology

meets creativity...”


HD1 — TELEVISED PERFECTION

The launch of the first European HDTV channel HD1 by Euro1080, has

officially ushered in the age of HDTV in all its glory: stunning 16:9 quality

and vividly sharp images. The programme is reproduced exactly like the

original creators intended — right before your eyes — on your Pioneer

PURE Vision Plasma.

The arrival of High-Definition Television,

marks the beginning of a new era for me.

It’s truly satisfying to be able to watch my

latest productions exactly how they were

made. New production and transmission

equipment were needed specifically for the

HDTV format, and when I see my hard work

in high definition, it makes my investment

truly worthwhile. The stunning images on

my screen are only possible thanks to the

revolutionary technology behind my

Pioneer PURE Vision Plasma —

every image is as sharp as it should be and

every colour as bright as it was intended.

High-Definition Picture Perfection

HIGH-DEFINITION TELEVISION (HDTV) — THE ULTIMATE VIEWING EXPERIENCE

Brilliant picture quality in high-definition is now a crystal-clear reality. You can be

certain of it, when you choose a plasma display with ‘HD ready’ certification

— easily identifiable by the ‘HD ready’ label. This is a guarantee that the display

device meets certain industry standards, and can process and display true highdefinition

signals. The minimum requirements are as follows:

• minimum native resolution of 720 physical lines in wide aspect ratio

• accepts 720p and 1080i HD video formats in both 50 Hz and 60 Hz

• accepts the above HD video formats via both analogue YPbPr and digital HDMI

or DVI interface

• features HDCP content protection on the digital interface

Pioneer’s 50- and 43-inch PURE Vision Plasma TVs (PDP-505XDE, PDP-505HDE,

PDP-435XDE, PDP-435HDE and PDP-435FDE) are certified ‘HD ready’. So you can

be sure of the most perfect high-definition pictures — now and in the future!


PLASMA AND GAME CONSOLE

Race fast cars across the floor or fight aliens from remote galaxies in your own living

room. Whatever your task, you’re more likely to succeed with Pioneer Plasma. Hooking up

a games console makes games leap into life, with clearer and sharper images and sound

effects.

PLASMA AND DIGITAL TUNER

Step into the future with the Pioneer Digital Multimedia Receiver. You get access to all

available free-to-view DVB digital terrestrial TV and radio stations, so you can enjoy more

entertainment than ever before, at the highest possible quality. It even supports Dolby

Digital broadcasting (where available).

TRUE HOME CINEMA EFFECT

Watch your favourite movie heroes leap out of the screen into your home. Thanks to

Advanced PureCinema, you’ll get the same top-quality reproduction as you enjoy in the

movie theatre.

I adore being able to share the same image quality that I enjoy

at work with family and friends. Whether watching a film or

digital TV, every picture is superb in its detail. The technology

is simply astounding. The state-of-the-art digital multimedia

receiver means I have access to all available digital

THE SMOOTHEST, SHARPEST IMAGE

First, every single incoming signal is upgraded into a high-definition level signal, using

Pioneer’s Dynamic HD Converter. This attention, literally to the smallest detail, gives

the final image the maximum in sharpness, smoothness and clarity.

SEE EVERY SINGLE DETAIL

With Dual Noise Reduction technology — Digital and MPEG —picture noise is

effectively reduced and minimised, faithfully reproducing the quality of the original

image. Even the minuscule details of an image simply glitter across the Plasma panel.

STRONG AND STEADY IMAGES

A flickering screen and subsequent tired eyes are now definitely a thing

of the past. Pioneer’s Digital Flicker-Free technology guarantees

superior picture quality and an

unsurpassed viewing experience.

terrestrial TV channels, including digital radio stations.

The kids just love the way their games come to life on the big

screen. It’s as if the aliens are really fighting in the same

room with us. Images just don’t get more real than that.


Living life on a Grand Scale

Like many television producers, I am a

dedicated home cinema fan. For me, there is

no greater pleasure than an evening in my

own home theatre — whether it’s watching

the latest blockbuster, a classic film noire for

research, or screening the first-cut of my

latest show with my editors.

PLASMA AND CUSTOMISED CALIBRATION

Now you can have the most accurate image possible. The ISF C3 (Custom

Calibration Configuration) feature allows you to optimise your Plasma display

to your own environment. Via an optional service, you can rely on an ISF

professional to calibrate a customised level of contrast, tint, colour level and

other parameters for you, so that you can enjoy an even more precise image.

CUSTOMISE YOUR COLOUR TEMPERATURE

Colour temperature settings adjust the tone of white colour, which provides

depth and shadow to the images on your screen. Now you can easily adjust the

tone of the white colour on your screen, according to your preference, by simply

using four preset modes, or the additional professional mode for advanced

adjustments.

ERADICATE PICTURE NOISE

See picture reproduction of a level never before experienced on a Plasma

display, thanks to the complete eradication of picture noise. Thanks to

cutting-edge noise reduction technology, this top-quality Plasma display

faithfully reproduces the highest standard in superior quality images.

The quality of image is of utmost importance

to me. My private in-home movie theatre

reflects my hobbies, my tastes and my

standards. When I speak of “The Big Screen”,

I’m referring to my 61-inch Pioneer PURE

Vision Plasma Display.


61”

50”

43”

PACKAGES*

Digital Terrestrial Tuner

Digital Teletext

Digital EPG

Analogue Tuner

NexTView EPG

Home Gallery

Dual Screen display

Picture-in-Picture display

PC input (front)

Headphone input (front)

Subwoofer out (variable)

SR control IN/OUT

Digital Audio Out (optical)

Common Interface slot

Antenna terminal (DIN) x 2 for Digital

A Choice of PURE Vision Plasmas

Now there’s a Plasma just for you. Pioneer has created PURE Vision Plasma to meet every need.

Choose between two Plasma TV sizes (50-inch and 43-inch) and opt for the multimedia receiver that

fulfils your dreams — there’s a choice of three. Or appreciate the majestic grace of the PDP-615EX,

an ultra-large 61-inch display.

W H D

61 inch 1502 mm 912 mm 126 mm

50 inch 1270 mm 737 mm 93 mm

43 inch 1120mm 652 mm 93 mm

PDP-R05XE PDP-R05E PDP-R05FE

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

—

—

—

•

•

•

•

•

•

•

•

•

—

—

—

PDP-R05XE

PDP-R05E

PDP-R05FE

PDP-R05XE PDP-R05E PDP-R05FE

43 inch PDP-435PE (109 cm) PDP-435XDE PDP-435HDE PDP-435FDE

50 inch PDP-505PE (127 cm) PDP-505XDE PDP-505HDE —

61 inch PDP-615EX (155 cm) — — —

* Check with your local dealer which package is available in your country.

—

—

—

•

—

—

—

—

—

—

—

—

—

—

—

Elegance and Ease of Display

There’s a PURE Vision Plasma to fit every lifestyle, and a multitude of ways to display your Plasma to its best advantage. If,

like our architect, lines and angles are what you crave, you could hang it on the wall or admire it on its table top stand. Our

fashion designer uses it as a living canvas for her creations — she free-stands it on the floor. Adding a DVD player or games

console underneath, our television producer finds the floating floor stand the most efficient use of his space. The Pioneer

PURE Vision Plasma’s slender form blends easily into the background, or serves an eye-catching focal point for any room.

SPEAKERS (Black)

ACOUSTIC SWING-TYPE SPEAKERS -10°

HIGH SOUND QUALITY FROM ALL SOURCES

PDP-S25-LR (50-inch)


An entertaining TV experience requires more than just high-quality images, it also deserves high-quality sound.

The Pioneer Plasma TV speakers reproduce superior-quality sound, thanks to a range of technological

advancements brought about by Pioneer’s history of expertise in high-quality audio. Featuring a high-quality

soft dome tweeter with a large strontium ferrite magnet, the purity of the sound in the high-frequency range

has been improved. The result? Fully expanded surround sound.

3 SURROUND MODES

Dimensions (W x H x D):

- PDP-S25-LR: 95 x 737 x 62 mm

- PDP-S26-LR: 95 x 652 x 62 mm

Pioneer Plasma TV employs three specific Surround Modes to create a sound field that makes listeners feel

like they’re in the middle of the action. “SRS” improves the size of surround sound field, “TruBass” enhances

the lower bass sound and “FOCUS” elevates the frontal sound field even when the speakers are situated under

the screen.

+10°

Pioneer Plasma TVs come with innovative “Acoustic Swing” type speakers which allow

you to adjust the angles according to your preference. This versatile swing type

speaker can be adjusted into 3 tilted positions, and 2 straight. Now you can enjoy a

variety of sound fields easily and freely.

+20°

THE FIRST ACOUSTIC SWING TYPE SPEAKER

0°

Speakers in straight position for Direct Mode


SPEAKERS (Silver)



UNDER-MOUNTED SPEAKERS*

105 mm

BRACKETS

545 mm

634 mm (50”)

ANGLED WALL BRACKET** (For 43-inch and 50-inch only)

740 mm

** With under-mounted speakers, the angle options are limited.

WALL BRACKET (For 43-inch and 50-inch only)

576 mm

W x H x D: 950 x 591 x 45 mm

SYSTEM CABLES

SIDE-MOUNTED SPEAKERS*

559 mm (43”)

* Speakers can be attached both to the underneath and sides of the Plasma panel.

WALL BRACKET (For 61-inch only)

475 mm

Depth: 70 mm

* Depth = 32 mm

PDK–5011

PDK-WM02*

PDK-WM03

CONVENTIONAL LONG SYSTEM CABLE (10 M) OPTICAL LONG SYSTEM CABLE (30 M) WITH DETACHABLE PLUGS

PDA-H03 PDA-H04

Media Receiver

MDR Cable

DVI Cable

AC Adapter

30 m

1.5 m 28.5 m

MDR Cable joint connection

Conversion box

(transmitter)

DDC Cable (28 m)

Conversion box

(receiver)

MDR

Cable

DVI Cable

(1.2m)

Plasma Panel

STANDS

TABLE TOP STAND (For 43-inch and 50-inch only)

577 mm 380 mm

TABLE TOP STAND (For 43-inch and 50-inch only)

FLOOR STAND (For 43-inch and 50-inch only)

351 mm

FLOATING FLOOR STAND (For 43-inch and 50-inch only)

54 mm

701 mm

373 mm

700 mm

860 mm

960 mm

TABLE TOP STAND (For 61-inch only)

1000 mm

803 mm

476 mm

351.4 mm

856 mm

478 mm

PDK-TS05

PDK-TS08

PDK-FS03

Possibility to mount component

Note: With kangaroo stand, depth of

floor stand = 567 mm

470 mm

369.6 mm

216.7 mm

PDK-FS04

PDK-1014

43-inch PURE Vision Plasma with table top stand (PDK-TS05) and

black acoustic swing speakers (PDP-S26-LR)

43-inch PURE Vision Plasma with tabletop stand (PDK-TS08) and

under-mounted speakers (PDP-S22-LR).

50-inch with floor stand (PDK-FS03) and silver side-mounted

speakers (PDP-S21-LR)

43-inch PURE Vision Plasma with floating floor stand (PDK-FS04) and

silver undermounted speakers (PDP-S22-LR)

61-inch PURE Vision Plasma with table top stand (PDK-1014)


DEEP WAFFLE RIB STRUCTURE

DIRECT COLOUR FILTER

Enjoy minimum reflection and maximum colour with Pioneer’s

Direct Colour Filter, a world-first film-type filter which is

attached directly onto the front of the plasma panel. It

significantly reduces reflection from outside light as well as

reflection from the panel itself, typical of conventional filters.

The new filter is also very thin, making the plasma panel super-thin (only 93 mm), with a

drastically reduced weight*. Contrast in bright environments is improved by reducing

unnecessary reflections. Every colour is bold and bright — even in broad daylight.

* 4.5 kg for the 50-inch models.

Light

reflection

Conventional Filter

The Making of PURE Vision

Transparent Electrode

Rib

Red Phospor

Green Phosphor

Blue Phosphor

COLOUR MANAGEMENT

Pioneer’s exclusive technology works like this: the Deep Waffle-shaped Rib Structure increases the area of light-emitting phosphors

— increasing the brightness. Each plasma cell is deeper, encapsulated with horizontal ribs so emitted light won’t leak into neighbouring

cells. This deep cell structure means higher brightness. When one million tiny coloured fluorescent lamps fire at once, viewers will

experience full-on, pure colour intensity.

Front Glass Substrate

Dielectric Layer

Protective Layer (MgO)

Auxiliary Electrode

Address Protective Layer

Address Electrode

Rear Glass Substrate

Conventional Straight-type Cell Structure

Light

reflection

Film-type Direct Colour Filter

Cell Structure Comparison

43'' TV

Glass

Filter Air Panel Direct Colour Filter Panel

Auxiliary Electrode

Transparent Electrode

Rib

Red Phosphor

Green Phosphor

Blue Phosphor

Pioneer Deep Waffle Rib Structure


Front Glass Substrate

Dielectric Layer

Protective Layer (MgO)

Black Stripe

Address Protective Layer

Address Electrode

Rear Glass Substrate

Pioneer Plasma TV with Direct Colour Filter

61'' DISPLAY

With Pioneer’s PURE Vision Plasma colour management system, colours are handled individually without creating bleeds or information loss that could affect the true

reproduction of adjacent colours. The overall result is more realistic, accurate colour.

50'' TV

43'' TV

43''

TV

43'' TV

50'' TV

50'' TV

50'' TV

61'' DISPLAY

61'' DISPLAY

DYNAMIC HD CONVERTER

PURE Vision Plasma TV is

outfitted with a Dynamic HD

Converter that changes

interlaced PAL signals into

progressive 1,280 x 768 pixel

signals (1,024 x 768 with the 43-inch models). To optimise one

pixel, this system scans the surrounding 84 pixels to create

smoother, sharper and clearer images.

ADVANCED SUPER CLEAR DRIVE

Pioneer’s Super CLEAR* Drive technology has been improved and relaunched as Advanced Super CLEAR* Drive. Now with a grey

scale equivalent of up to 1,920 steps for each colour of RGB, today’s Pioneer Plasma TVs can boast reproduction of up to 7 billion

colours! Advanced Super CLEAR* Drive employs a new drive control method — Dynamic Bright-up Processing — which dynamically

controls brightness and constantly monitors the averages and distribution of brightness on-screen. This technology brightens

medium-bright

areas that are part of the main image, while

maintaining low power consumption. Advanced

Super CLEAR* Drive also eliminates overly high

reset discharges and eradicates false contour

noise. Superior noise reduction significantly

improves the signal-to-noise ratio in less bright

images. With contrast further intensified, shades

of grey are enhanced and blackness can be

reproduced perfectly. That means viewers will

enjoy brighter and clearer pictures in which every

nuance is visible, even in the shadows.

* CLEAR: high-Contrast & Low Energy Address &

Reduction of false contour sequence.

DUAL NOISE REDUCTION

PURE Vision Plasma features two types of noise

reduction systems: Digital Noise Reduction and

MPEG Noise Reduction*. Exclusive Digital Noise

Reduction minimises picture noise correctly for the

highest image quality. Compared to conventional

digital noise reduction systems that mistake tricky

elements from the original source, such as a

shooting star trail, Pioneer’s Digital Noise Reduction

controls these mistakes at the base level to

reproduce images faithful to the original. MPEG

Noise Reduction reduces mosquito noise unique to

MPEG compressed video images, an especially

useful function when viewing digital satellite

broadcasting.

* Not available on the PDP-615EX

Original Picture

43''

TV

50'' TV

Conventional Plasma Pioneer Plasma TV with Dynamic HD Converter

Pioneer Advanced Super CLEAR Drive

Conventional Plasma:

Gradation steps are visible

Pioneer Plasma with

Advanced Super CLEAR Drive:

Gradation is smoother

A 1920-step grey scale per each colour of RGB enables superior gradation in darker picture areas.

More steps eliminate brightness gaps — or moiré effect — in darker colours.

43'' TV

43'' TV

50'' TV

Conventional Plasma Pioneer Plasma with Digital Noise Reduction

Conventional Plasma Pioneer Plasma TV with MPEG Noise Reduction

50'' TV

61'' DISPLAY


DIGITAL FLICKER-FREE

— WITH PROGRESSIVE SCANNING

A TV image consists of minuscule horizontal lines, known as scan lines. Current PAL

TV standards count 576 active lines per image frame, but not all 576 scan lines are

sent simultaneously. Every other line is transmitted alternatively every 1/50 second to

create one frame every 1/25 second — a process called interlaced scanning. With this

comparatively slow speed, larger displays will have more apparent image flicker.

Progressive Scanning contributes to solving this problem by displaying a full set of

576 lines at once in 1/50 of a second to construct a complete frame. A similar

approach is applied for NTSC images, which have 480 active lines that will be

displayed every 1/60 of a second.

In combination with the Progressive Scan processing, Pioneer’s unique Digital

Flicker-free technology takes out any flicker from typical interlaced PAL video source

material, where due to the lower original scanning rate flicker would otherwise easily

become disturbing. The result? Truly high-quality images, and no more tired eyes!

HIGH-DEFINITION DISPLAY (TRUE AND WIDE XGA)

Pioneer Plasma has several times more

cells on its XGA panel than conventional VGA

screens so it can accurately display

computer signals (from PC or MAC). This

means that Pioneer Plasma TV is more than

ready for all the new, high-intensity digital formats including High

Definition DVD-ROM, HDTV (1080i and 720p), Digital Camera, and D-VHS,

as well as Blu-ray Discs and High Definition broadband contents such as

Windows Media 9 Series. Pioneer Plasma is also the best equipment to

enjoy HD1*, Europe’s first HDTV channel. HDTVs high-definition

technology results in remarkably sharper, richer and more vibrant images

— with 5 times more picture information compared with standard PAL

broadcasting. Furthermore, there’s fantastic sound and no analogue

interference whatsoever. Viewers can enjoy a wide selection of

programmes (music, sports, shows) on HD1.

* For more information on HD1 and how to receive it, visit the Euro1080 website at

www.euro1080.tv.

Note: Pioneer plasma display panels are manufactured using a high level of

ultra-precision technology. Nevertheless, permanently lit, inactive or overactive

pixels may occur. This is a consequence of plasma technology.

Note: PDP-615EX supports 720p/50 Hz via HDMI only.

DIGITAL TERRESTRIAL COMPATIBLE*

43''

TV

50'' TV

61'' DISPLAY

Original Signal

Digital Flicker-Free

VGA panel True XGA panel

With the Pioneer Digital Multimedia Receiver PDP-R05XE, you can have access to all available free-to-air DVB digital terrestrial TV** including radio stations***. That

means you can enjoy a wide range of entertainment, music, news and special interest programmes, all with the highest possible sound quality. You can enjoy other

advanced features too: the Digital multimedia Receiver even supports Dolby Digital broadcasting (where available).

43'' TV

50'' TV

* The level of compatibility with digital terrestrial services and the number of available digital terrestrial channels depends on the user’s country of residence.

** By using the Conditional Access Module, you can access pay-to-view channels as well.

*** All channels are subject to coverage and may change from time to time. Reception may depend on the type and condition of the existing aerial. Aerial upgrade may be required.

61'' DISPLAY

43'' TV

50'' TV

ADVANCED PureCinema — THE FULL CINEMATIC EXPERIENCE

The cinematic experience is more than seeing movies on the big screen;

it’s the quality of the images that leap out of the screen that leave you

mesmerised. With Advanced PureCinema technology, you will be awed by

that exact same top quality imagery on your Plasma, only you won’t have

to leave the house.

When the video signal originates from a film source, Pioneer’s exclusive

Plasma PureCinema processing will automatically detect if individual

interlaced fields are possibly coming from the same original film frame —

2-2 (PAL) and 2-3 (NTSC) pull-down detection the professionals would call

it — and consequently restore the exact same image as created for

projection in the theatre.

Once the original film frames are recomposed, the “Advanced

PureCinema” mode even goes one step further: to realize the best

possible cinematographic viewing experience — and virtually eliminating

false contours — the refresh rate is changed to 75 Hz (PAL) / 72 Hz (NTSC),

showing each film frame 3 times. Delivering Home Theatre in the pure

sense of the words, this mode is optimal for typically film-sourced

DVD-Video playback.

Note: PDP-615EX features PureCinema only.

HDMI (High Definition Multimedia Interface)

Direct High Definition digital transmission from any audio video source is possible with only a single HDMI cable. You can enjoy highest

fidelity uncompressed digital video and audio quality from original sources such as DVD discs and HD (High Definition) video signals without the fuss of complicated

or confusing cable connections.

Product Features & Specifications

Plasma Display

Features & Specifications — 1 PDP-615EX


Screen Size

Aspect Ratio

Number of Pixels

Digital Comb Filter

Video Signals

Component

Analogue (RCA/BNC)

Digital (HDMI)

PC Signals

Picture-in-Picture Display

Dual Screen Display

DNR (Digital Noise Reduction)

Gamma

Colour Management

Colour Temperature Adjustment

PureCinema

Picture memory

A/V Selection (Programmed Picture)

CONTROL

OSD Languages

Remote Controller

Power Management (for PC)

Off Timer

61-inch

16:9

1365 (Hor) x 768 (Ver)

NTSC: 3D

PAL: 3 Line

PAL/SECAM/NTSC3.58/NTSC4.43/PAL60

60 Hz: 480i, 480P, 720P, 1035i,1080i

50 Hz: 576i, 576P, 1080i

60 Hz: 480i, 480P, 720P, 1080i

50 Hz: 576i, 576P, 720P, 1080i

VGA/SVGA/XGA/SXGA/UXGA/

W-XGA/W-SXGA/W-UXGA

•

•

• (Off/High/Mid/Low)

•

•

• (High/Mid/Mid-Low/Low, Manual)

• (Off/On)

•

• (STANDARD/DYNAMIC/MOVIE1/MOVIE2/DEFAULT)

7 (GB/D/F/I/E/S/RUS)

•

• (Off/On)

•

Advanced

PureCinema

Dp

Dp

Dp

Cp

Cp

Cp

Bp

Bp

Bp

Ap

Ap

Ap

Plasma Display

Features & Specifications — 2 PDP-615EX

AUDIO

Audio Output Power

Tone Control

CONNECTION TERMINALS

Video 1

Video 2

Video 3

COMPONENT 1

PC1

PC2/COMPONENT 2

HDMI

Audio1

Audio2

Audio3

Others

GENERAL

Dimensions (W x H x D)

Weight

Power Consumption in use/standby

Power Requirements

Dp

Dp

Cp

Cp

Bp

Bp

Ap

Ap

* RGB, HD, VD In or Y’Pb’Pr’ In is selectable on main menu.

DiB

DiT

CiB

CiT

BiB

BiT

AiB

AiT

43'' TV

43'' TV

50'' TV

PURE DRIVE: PAL — 100 Hz/Advanced PureCinema

PAL interlaced (film) source processing Progressive Film Frame to interlaced Video Field

PureCinema

with 100 Hz

PAL Video

50 fields/s

FILM

24 frames/s

50'' TV

9 W + 9 W (6 Ω)

Bass, Treble, Balance

Composit video In (BNC)

Composit video In (RCA pin)

S-video In

Y’Pb’Pr’ In (RCA pin x3)

RGB In (D-sub15)

RGB,HD,VD/Y’Pb’Pr’ In* (BNC x5)

HDMI In

Audio LR In (RCA pin x2)



Speaker Out L/R (Display Rear)

External control (RS-232C, D-sub9)

1502 mm x 912 mm x 126 mm

68.0 kg

540 W/1.3 W

AC 220 — 240 V, 50/60 Hz

61'' DISPLAY

NTSC Video

60 fields/s

75 Hz 4.16 % speed-up 2-3 pull-down

PAL Video

50 fields/s

DiB

DiT

CiB

CiT

BiB

BiT

AiB

AiT

PURE DRIVE: NTSC — Advanced PureCinema

FILM

24 frames/s

Dp

Cp

Bp

Ap

NTSC Video

60 fields/s

4.16 % speed-up 2-3 pull-down

Dp

Cp

Bp

Ap

DiBr

DiT

DiB

CiT

CiB

BiTr

BiB

BiT

AiB

AiT

Progressive Film Frame to interlaced Video Field NTSC interlaced (film) source processing

DiBr

DiT

DiB

CiT

CiB

BiTr

BiB

BiT

AiB

AiT

Typical example of MPEG Top (T)/Bottom (B) field

altering, including repeated (r) fields in NTSC.

Typical example of MPEG Top (T)/Bottom (B) field

altering, including repeated (r) fields in NTSC.

PureCinema

Dp

Dp

Dp

Cp

Cp

Bp

Bp

Bp

Ap

Ap

Advanced

PureCinema

Dp

Dp

Dp

Cp

Cp

Cp

Bp

Bp

Bp

Ap

Ap

Ap

72 Hz

61'' DISPLAY

61'' DISPLAY


43''

50''

Product Features & Specifications TV

TV

Plasma TVs

Features & Specifications


Screen Size

Aspect Ratio


Brightness

Contrast Ratio

Viewing Angle

3 Line Digital Comb Filter

Video Signals

PC Signals



Still picture

Home Gallery


MPEG NR


Natural Enhancer

Digital Flicker-free

Digital CTI (Colour Transient Improvement)

Dynamic Range Expander


PureCinema


ANALOGUE TUNER

Reception System

Stereo/Dual Sound

Auto Search

Auto Programme Labeling

Auto Programme Sort

Number of Preset Programmes

Teletext

Number of Languages

Level 2.5

Page Memory

Picture and Text (Dual Screen)

EPG

DIGITAL TUNER

System capability

Modulation

Demodulation

Code rate

Guard band

FEC

Modulator output

Loop through

Video decoding

Audio decoding

Digital Teletext (MHEG5)

EPG

CONTROL

OSD

Number of languages

Remote Control

Energy Save mode (for A/V and PC)

No Signal Off (for AV)

No Operation Off (for AV)


i/o Link.A

SR+

AUDIO


Tone Control

Surround Sound

Audio Orientation

Bass Boost


Input 1 (SCART)

Input 2 (SCART/Component)

Input 3 (SCART/ HDMI)

Monitor Out (RCA pin)

Input 4 (Front)

PC (Front)

Headphone (Front)

Subwoofer Out (Variable)

SR Control In/Out

Others

GENERAL

Dimensions (Display) (W x H x D)

(Media Receiver)

Weight (Display)


Power Consumption (Display) in use/standby

(Media Receiver) in use/standby


* SRS WOW, SRS, SRS FOCUS, SRS TruBass, SRS and (o) symbol are trademarks of SRS Labs, Inc.

PDP-505XDE PDP-435XDE

50-inch

16:9

1,280 (Hor) x 768 (Ver)

1,000 cd/m 2

1,100:1

more than 160° (Hor/Ver)

PAL/NTSC (Main & Sub)

PAL/SECAM/NTSC3.58/NTSC4.43/PAL60/HD/PC

VGA/SVGA/XGA/Wide XGA

•

•

•

•



•

•

•

•


• (High/Mid-High/Mid/Mid-Low/Low, Manual)

• (Off/Standard/ADV)

• (STANDARD/DYNAMIC/MOVIE/GAME/USER)

PAL BG/I/DK, SECAM BG/DK/L/L’

NICAM UK/SK/FR, CCIR A2 BG/DK

•

•

•

99

CEEFAX/FLOF/TOP (with TOP Over View Page)

25

•

2,100 pages

•

NexTView

DVB-T compliant

COFDM (2k/8k)

QPSK, 16QAM, 64QAM

1/2, 2/3, 3/4, 5/6, 7/8

1/4, 1/8, 1/16, 1/32

Reed Solomon

—

•

MPEG2 MP@ML

MPEG1 Layer 1&2 and Dolby Digital

•

•

High-Quality Font

12 (GB/D/F/NL/I/E/P/S/FIN/GR/TR/RUS)

SR

• (Standard/Save)

• (Disable/Enable)


• (Off/Mode1/Mode2)

•

•

13 W + 13 W (1 kHz, 10 %, 8 Ω)


SRS*

FOCUS*

TruBass*

A/V In, RGB In, TV Out

A/V In/Out, S-video In, Y’Pb’Pr’ In, i/o Link.A

A/V In/Out, RGB In, S-video In, i/o Link.A, HDMI In

A/V Out, S-video Out

A/V In, S-video In

D-sub15 In, Stereo Mini jack (Audio)

Stereo Mini jack

RCA pin

Mini Jack x 2

Antenna terminal (DIN) for ANALOGUE

Antenna terminal (DIN) x 2 for DIGITAL

i/o Link.A select

System Connection x 2

(for connecting PDP screen and media receiver)

Speaker Out L/R (Display Rear, 8 — 16 Ω)

Digital audio out (optical)


1270 x 737 x 93 mm

420 x 90 x 295 mm

32.8 kg

5.6 kg

352 W/0.4 W

41 W/1.3 W (antenna off)

AC 220 — 240 V, 50/60 Hz

43-inch

16:9

1,024 (Hor) x 768 (Ver)

1,100 cd/m 2

1,200:1





•

•

•

•



•

•

•

•







•

•

•

99


25

•

2,100 pages

•

NexTView

DVB-T compliant

COFDM (2k/8k)

QPSK, 16QAM, 64QAM

1/2, 2/3, 3/4, 5/6, 7/8

1/4, 1/8, 1/16, 1/32

Reed Solomon

—

•

MPEG2 MP@ML

MPEG1 Layer 1&2 and Dolby Digital

•

•



SR





•

•

13 W + 13 W (1 kHz, 10 %, 8 Ω)


SRS*

FOCUS*

TruBass*








RCA pin

Mini Jack x 2

Antenna terminal (DIN) for ANALOGUE

Antenna terminal (DIN) x 2 for DIGITAL





Digital audio out (optical)


1120 x 652 x 93 mm

420 x 90 x 295 mm

26.8 kg

5.6 kg

295 W/0.4 W

41 W/1.3 W (antenna off)

AC 220 — 240 V, 50/60 Hz

Plasma TVs

Features & Specifications


Screen Size

Aspect Ratio


Brightness

Contrast Ratio

Viewing Angle

3 Line Digital Comb Filter

Video Signals

PC Signals



Still picture

Home Gallery


MPEG NR


Natural Enhancer

Digital Flicker-free

Digital CTI (Colour Transient Improvement)

Dynamic Range Expander


PureCinema


ANALOGUE TUNER

Reception System

Stereo/Dual Sound

Auto Search

Auto Programme Labeling

Auto Programme Sort

Number of Preset Programmes

Teletext

Number of Languages

Level 2.5

Page Memory

Picture and Text (Dual Screen)

EPG

CONTROL

OSD

Number of languages

Remote Control

Energy Save mode (for A/V and PC)

No Signal Off (for AV)

No Operation Off (for AV)


i/o Link.A

SR+

AUDIO


Tone Control

Surround Sound

Audio Orientation

Bass Boost


Input 1 (SCART)

Input 2 (SCART/Component)

Input 3 (SCART/ HDMI)

Monitor Out (RCA pin)

Input 4 (Front)

PC (Front)

Headphone (Front)

Subwoofer Out (Variable)

SR Control In/Out

Others

GENERAL

Dimensions (Display) (W x H x D)


Weight (Display)


Power Consumption (Display) in use/standby

(Media Receiver) in use/standby


Rear Panel PDP-R05XE

PDP-505HDE PDP-435HDE PDP-435FDE

50-inch

16:9

1,280 (Hor) x 768 (Ver)

1000 cd/m 2

1,100:1





•

•

•

•



•

•

•

•







•

•

•

99


25

•

2,100 pages

•

NexTView



SR





•

•

13 W + 13 W (1kHz, 10 %, 8 Ω)


SRS*

FOCUS*

TruBass*








RCA pin

Mini Jack x 2

Antenna terminal (DIN)





1270 x 737 x 93 mm

420 x 90 x 295 mm

32.8 kg

4.9 kg

352 W/0.4 W

35 W/0.5 W

AC 220 — 240 V, 50/60 Hz

43-inch

16:9

1,024 (Hor) x 768 (Ver)

1,100 cd/m 2

1,200:1





•

•

•

•



•

•

•

•







•

•

•

99


25

•

2,100 pages

•

NexTView



SR





•

•

13 W + 13 W (1 kHz, 10 %, 8 Ω)


SRS*

FOCUS*

TruBass*








RCA pin

Mini Jack x 2






1120 x 652 x 93 mm

420 x 90 x 295 mm

26.8 kg

4.9 kg

295 W/0.4 W

35 W/0.5 W

AC 220 — 240 V, 50/60 Hz

Rear Panel PDP-R05E

Rear Panel PDP-R05FE

43-inch

16:9

1,024 (Hor) x 768 (Ver)

1,100 cd/m 2

1,200:1



PAL/SECAM/NTSC3.58/NTSC4.43/PAL60/HD

—

—

—

•

—



•

•

•

•







•

•

•

99


25

•

2,100 pages

•

—



SR





•

—

13 W + 13 W (1 kHz, 10 %, 8 Ω)


SRS*

FOCUS*

TruBass*






—

—

—

—






1120 x 652 x 93 mm

420 x 90 x 295 mm

26.8kg

4.8 kg

295 W/0.4 W

27 W/0.5 W

AC 220 — 240 V, 50/60 Hz

43''

50''

Media Receivers Rear Panels TV

TV


ICELAND: BRÆDURNIR ORMSSON HF

Lágmúli 8, P.O. Box 8760, 128 Reykjavik

Tel.: +354 55 32 800

Info & service: bragi@ormsson.is

Website: www.ormsson.is

MALTA: DORELL TRADING LIMITED

Standard Bldgs., C. De Brockdorff Street, Msida MSD-02

Tel.: +356 21 33 38 61

Info & service: info@directsales.com.mt

MILITARY: PIONEER ELECTRONICS DEUTSCHLAND GmbH

Military Sales Department , Hanns-Martin-Schleyer-Strasse 35

47877 Willich, Postfach 500447, 47871 Willich

Tel.: +49 (0)2154 913 421

E-mail: macario@pioneer.de

LATVIA: BALTIC MULTI MEDIA SIA

Ventspils Iela 50, LV-1002 RIGA, LATVIA

Tel.: +371 7 610 111

Info & service: pioneer@pioneer.lv

ESTONIA: ULKOKAUPAT EESTI AS

Kanali Tee 12, 10112 Tallinn

Tel.: +372 60 33 990

Info & service: piret.pold@ulkokaupat.ee

GREAT BRITAIN: PIONEER GB Limited

Pioneer House, Hollybush Hill, Stoke Poges

Slough, Buckinghamshire SL2 4QP

Tel.: +44 (0)1753 789 789

IRELAND: AUDIO VISION IMPORT LTD.

John F. Kennedy Drive, Naas Road, Dublin 12

Tel.: +353 1 240 5600

E-mail: info@avi.ie

For detailed information concerning Pioneer’s Environmental policy,

please visit the following site:

http://www.pioneer-eur.com/environment/ The Pioneer Corporation headquarter at Meguro

and Tokorozawa plant have received ISO14001

certification.

SRS WOW, SRS Focus, SRS TruBass, SRS and the (O) symbol are trademarks of SRS Labs, Inc. The ‘HD ready’ Logo is a trademark of EICTA. All other trademarks are the property of their respective companies.

Recording equipment and copyright: Recording equipment should be used only for lawful copying, and you are advised to check carefully what is lawful copying in the country in which you are making a copy.

Copy of copyright material such as films or music is unlawful unless permitted by a legal exception or consented to by the rightowners.

Published by: PIONEER EUROPE N.V.

Haven 1087, Keetberglaan 1, B-9120 Melsele

Tel.: + 32 (0)3 570 05 11

Copyright 2005 by Pioneer Europe N.V.

All rights reserved.

Features and specifications of the products described or illustrated in this catalogue are correct at the time of printing but could change as production changes might occur. This catalogue may contain

typographical errors and the colours of the depicted products may deviate slightly from reality. Consult your Pioneer dealer to ensure that actual features and specifications match your requirements. This

catalogue may contain references to products that may or will not be available in your country. The characters and testimonials portrayed in this brochure and the names used herein are fictitious and any

resemblance to the names, character, or history of any person is coincidental and unintentional.

04-P-BROCHURE-EN2 – Printed in Belgium. As a part of Pioneer’s commitment to a cleaner environment and the protection of the earth, this catalogue has been printed on chlorine-free paper.

Pioneer PURE Vision Plasma 2004 - Pioneer Europe

Create successful ePaper yourself

Delete template?

Save as template?
