EDITORIAL

Industrie

Spotlight Hannover

Messe and Powtech

Hannover Messe is booming. From 1 to 5 April, an anticipated 6500

companies from 75 nations will be exhibiting at the world’s leading

trade fair for industrial technology. Automation, robotics, industrial

software, drive systems & fluid power, energy technologies, subcontracting

and research & development will be taking centre stage at

the 2019 show. Throughout the first week of April, this pivotal confluence

of technologies will be clustered at Integrated Automation,

Motion & Drives (IAMD) spanning 14 exhibition halls. Smart sensors,

intelligent drives, modular production and holistic solutions

for intelligent manufacturing – the close integration of automation,

drive systems & fluid power and software & IT will be the focus of

the upcoming event, which will also serve as a forum for presentations

and debates under the motto “Integrated Industry – Industrial

Intelligence”. Comvac, the leading international trade show for industrial

compressed air and vacuum technology, is likewise continuing

to grow. The organisers are expecting 15 % more exhibitors

at Comvac in comparison to 2017. Industry 4.0 will be the top

theme, for instance in the area of predictive maintenance. Our

Special Subject section on Hannover Messe, in which we cast a spotlight

on several of the above-mentioned topics, begins on page 40.

From 9 to 11 April, the week following Hannover Messe, Nuremberg

Exhibition Centre will open its doors for experts from all over

the world – both established and aspiring – in powder and bulk

solids technology. Around 800 exhibitors will showcase their latest

developments for mechanical processes like size reduction, agglomeration,

separation, screening, mixing, storage and conveying in six

exhibition halls. You can learn more about the new products and

solutions awaiting you in Nuremberg starting on page 16.
