Grass Roller slidesTable of ContentDescriptionPageFeatures and Benefits 4Technical Information 56600 Roller Slide• Side mounted with bottom lip• Made in the USA6600 Extended Roller Slide• Accomodates Face Frame cabinetry• Made in the USA6600 Roller Slide• Bottom mounted• Made in the USA6603 Extended Roller Slide• Designed for Face Frame cabinetry• Made in the USA6810126600 Mounting Aids146600 Accessories 14Features and Benefits - 1700, 1754, 1800, 5300Technical InformationRoller Slides - 1700, 1702, 1800• Bottom mounted• Nylon rollersRoller Slides - 1754• Bottom mounted• Tilt Bracket16-172022Roller Slides - 5300• Bottom mounted• Full ExtensionPull Out Shelf for 1700, 1702• Railing for single gallery• Aluminum tube24266600 Mounting Aids 146600 Accessories 14Features and Benefits - ExpressTechnical InformationExpress Roller Slide• Undermount• Made in the USA16-1736Ball Bearing Slide• Side Mounted• Full Extension343

Roller Slides6600, 6603, 6610Features and BenefitsFeatures and Benefits• Double Stop• 32mm system• Support roller for uniform drawer front height• Self-closing• Variety of sizes• Nylon rollers• Made in the USA¥ The self-closing feature automatically closes thedrawer.¥ Drawer will not bounce back when closed withforce.¥ 32mm system for easy, accurate installation¥ Epoxy powder coated finish for smooth rolling action.A wide variety of slides are available for frameand framless applications. Includes bottommount and side mount.4 Dimensions in millimeters, fractional inch equivalents as noted.

6610 Roller Slide75 lb. bottom mounted drawer slide• Bottom mounted with additional side mounting holes for convenience• Features 60mm (2 5/8") parallel self-closing action• Adapts to frame or frameless construction• Available in almond and white baked-on epoxy finish• Side clearance 12.5mm (1/2")• Made in the USA6610 Extended Roller Slide, 75 lbs.Description Nominal Length Color Item No. PU6600 / 350 350mm (14") Almond 30755-05 206600 / 400 400mm (16") Almond 30756-05 206600 / 450 450mm (18") Almond 30757-05 206600 / 500 500mm (20") Almond 30758-05 206600 / 550 550mm (22") Almond 30759-05 206600 / 350 350mm (14") White 30750-05 206600 / 400 400mm (16") White 30751-05 206600 / 450 450mm (18") White 30752-05 206600 / 500 500mm (20") White 30753-05 206600 / 550 550mm (22") White 30754-05 20For additional packaging, please contact your local Grass territory manager.Rear Mounting Brackets11Description Item No. PU6610 Adapter Bracket Screw on, left hand 13156-17 5006610 Adapter Bracket Screw on, right hand 13157-17 500FrameClearance1/8”32 mm14 mmBAFrameClearancePU = Packaging Unit10 Dimensions in millimeters, fractional inch equivalents as noted.

Drawer ExtensionASlide LengthSingle stopdrawer extension (A)Double stopdrawer extension (B)350mm (14") 220mm (8 11/16") 235mm (9 1/4")400mm (16") 270mm (10 5/8") 285mm (11 1/4")450mm (18") 320mm (15 5/8") 335mm (13 3/16")500mm (20") 370mm (14 9/16") 385mm (15 3/16")550mm (22") 420mm (16 9/16") 435mm (17 1/8")BDrawer Installation Dimensions 6610Manufacturing often is accompanied by tolerance problems. To avoid this situation,Min. 19(3/4”)Inside Cabinet Width(ICW)Drawer Width =Inside CabinetWidth - 25mm (1”)Min. 28(1 1/8”)Grass slides are designed to eliminate side movement of the drawer. Afterinstallation, the right drawer memeber blends perfectly with the right cabinetmember for guidance: the left side allows for cutting tolerance of the drawer and thecabinet components.1430 (1/2”)(1 3/16”)12.7(1/2”)7.5 mm (5/16”)12.7(1/2”)8.5(11/32”)Cabinet member boring specifications304 (11 31/32”)350 mm(14”)32(1 1/4”)32 (1 1/4”)400 mm(16”)450 mm(18”)32(1 1/4”)32(1 1/4”)96(3 25/32”)32(1 1/4”)192(7 9/16”)32(1 1/4”)192(7 9/16”)37500 mm(20”)550 mm(22”)All dimensions in millimeters.Subject to technical modifications without notice.11

6603 Roller Cabinet MemberDouble Captive cabinet member• Designed for face frame application• Can be used with 66000 or 6610 drawer member• Captive on both the left and right side• When used with adjustable bracket the slide will self-aligndrawer keeping slides aprallel• Extended front section for centering mounting screw on frame• Extended front provided clearance for inset trays, no blocking necessary• Made in the USA6603 Roller Cabinet MemberDescription Nominal Length Color Item No. PU6603/506 CML 506mm (19 15/16") White 30515-09 1006603/506 CMR 506mm (19 15/16") White 30514-09 1006603/570 CML 570mm (22 7/16") White 02663-09 1006603/570 CMR 570mm (22 7/16") White 02662-09 1006603/582 CML 582mm (22 15/16") White 02667-09 1006603/582 CMR 582mm (22 15/16") White 02668-09 100Rear Mounting Brackets12123Description Item No. PU6603 40mm Adj. Adapter Bracket, dowelled, left hand 30991-12 2006603 40mm Adj. Adapter Bracket, dowelled, right hand 30969-12 2006603 22mm Adj. Adapter Bracket, screw on, left hand 30992-12 2006603 22mm Adj. Adapter Bracket, screw on, right hand 30993-12 2006603 40mm Adj. Adapter Bracket, screw on, left hand 30994-12 2006603 40mm Adj. Adapter Bracket, screw on, right hand 30995-12 2003PU = Packaging Unit12 Dimensions in millimeters, fractional inch equivalents as noted.

Cabinet member installation dimensionsNote: Hanger Rail Length = Inside Cabinet Width = 28 (1 1/8”)All dimensions in millimeters.Subject to technical modifications without notice.13

Mounting Aidsfor 6600, 6603 6610Wood ScrewsDescription Item No. PU17823451 # 6 x 1/2" FHP, Nickel 81004-43 5002 # 6 x 7/16" FHP, Nickel 81016-43 5003 # 6 x 5/8" FHP, Nickel 81001-43 5004 # 6 x 3/4" FHP, Nickel 81003-43 5005 # 6 x 1" FHP, Nickel 81004-43 5006 # 8 x 3/4" FHP, Nickel 81005-43 5007 # 10 x 3/4" RHP, Nickel 81007-43 5008 # 10 x 1" PHP, Nickel 13720-43 5006Euro ScrewsDescription Item No. PU1 11mm (7/16"), Nickel 499.360.61.1015 5002 13mm (1/2"), Nickel 81015-43 5003 8mm (11/16"), Nickel 83000-43 5004 7.5mm (5/16"), Nickel 83001-43 5005 13mm (1/2") Pan Head, Nickel 3398-43 500Pozidrive Screw DriverDescription Item No. PUGrass Screw Driver 98000-01 1PU = Packaging Unit14 Dimensions in millimeters, fractional inch equivalents as noted.

Accessoriesfor 6600, 6603, 66106195 Spacers for cabinet members1 2 3Description Type Color Item No. PU1 66195 Spacer for cabinet member 25mm (1"), Screw-on white 86478-39 202 66195 Spacer for cabinet member 11mm (7/16"), Screw-on white 89104-39 203 66195 Spacer for cabinet member 25mm (1"), Screw-on with pin white 13097-39 20Wood screws: 6 x 5/8”Euro screws: 13mmTo provide side clearance for interiordrawers and pull out shelves.6196 Mounting BracketDescription Type Color Item No. PU6196 Mounting Bracket Screw-on white 00432-08 50With System 6610 With System 6600Attaches cabinet member of drawer slideif no side panel is available. Bracket canbe used for right or left. Mounting screwsincluded in polybag. Can be used with allGrass drawer slide systems.Door / Drawer ProtectorDescription Type Color Item No. PUDoor / Drawer Protector Screw-on white 13096-43 500Attaches to side of wooden pull-put.Designed for inset pull-out trays for frameor frameless cabinetry.All dimensions in millimeters.Subject to technical modifications without notice.15

Roller Slides 1700, 1754, 1800, 5300Features and BenefitsFeatures and Benefits• Double Stop• Bottom edge clearance• 32mm system• Variety of sizes• Bottom mounting• 12.5mm (1/2”) installation width¥ 60 mm self-closing actionMinimum gap for19 mm front = 0.5 mm¥ Bottom mountingCarefully engineeredself-closing range allowsminimum gapsbetween drawer fronts.16

Roller Slides 1700, 1754, 1800, 5300Features and BenefitsRoller Slides 1700, Features 1754, 1800, and5300 Benefits Applications• For drawer materials from 1/2" (12.5mm) up to 3/4" (19mm)• For frameless or face frame cabinetry• Use rear mount socket for face frame application (1700, 1754, 5300)• Four applications available- Standard (1700)- Tilt- front (1754)- Heavy duty (1800)- Full extension (5300)¥ 32mm system for easy, accurate installation¥ Bottom corner clearanceBottom corner clearance -chamfering of drawerbottoms and shelves isnot necessary.All dimensions in millimeters.Subject to technical modifications without notice.17

Technical Informationfor Roller Slides 1700, 1754, 1800, 5300System CompatibilitySingle and full-extension slides are vertically interchangeable in 32 system.32(1 1 /4")32(1 1 /4")32 mm(1 1 /4")system(vertical)32(1 1 /4")Over extension for Full Extension SlidesFull drawer access due to 30mm (1 3/16”) over extension. This avoidsinterference with other drawer fronts or protruding counter top.(1/2")Weight CapacitieskgGrass 1700:Grass 1754:Grass 1800:Grass 5300:100 lbs. dynamic load rating1000 lbs. dynamic load rating125 lbs. dynamic load rating125 lbs. dynamic load ratingGrass 1700-5300 Series slides meet and exceed ANSI/KCMA and ANSI/BHMAGrade 1 testing requirements.PU = Packaging Unit18 Dimensions in millimeters, fractional inch equivalents as noted.

Technical Informationfor Roller Slides 1700, 1754, 1800, 5300Twist-lock for 5300 full extension slide• Guaranteed self-closing• Load capacity 110 lbs.• Convenient drawer insertion and removalCheck mounting positionsCorrect position for drawer insertionTwist-lock triggerWrong positionInsertion of drawer is not possible.Insertion-of intermediate profile for 5300 full extension slideIntermediate profilesto be inclined forinsertion into cabinetprofiles at rear position.CorrectpositionWrong positionInsertion-securing-removal of drawer for 5300 full extension slideInsertion of drawerExtend intermediate profiles fullyto the open stop. Insert the drawerhorizontally.MalfunctionMalfunction is automaticallycorrected by fully extending the drawer.Mounting of safety lockOne pair of black safety locks is supplied witheach set of full extension slides.Separate safety locks and insert intoopenings as indicated into left and rightintermediate profiles - pay attention todirection of arrow! (A + B)Safety lockThe safety lock prevents accidentalremoval of drawer. It is a majorsafety aspect.All dimensions in millimeters.Subject to technical modifications without notice.19

Roller Slides 1700, 1702, 1800100 lbs. bottom mount drawer slide125 lbs. bottom mount, extended length drawer slide• Single-extension slide with nylon rollers,• Installation width 12.5mm (1/2”), bottom mounting• Parallel closing• Secure closing, minimum gap widths• Bottom edge clearance - no chamfering required• Clearance of screw head in cabinet slide• Double stop• Secure stop in open position• Use rear mount socket for face frame application1700 / 1702 Roller Slides, 100 lbs.Description Nominal Length Color Item No. PU1700 / 250 250mm (10") White 1700.250.2 201700 / 300 300mm (12") White 1700.300.2 201700 / 350 350mm (14") White 1700.350.2 201700 / 400 400mm (16") White 1700.400.2 201700 / 450 450mm (18") White 1700.450.2 201700 / 500 500mm (20") White 1700.500.2 201700 / 550 550mm (22") White 1700.550.2 20PU = 20 sets taped1702 / 250 250mm (10") White 1702.250.2 251702 / 300 300mm (12") White 1702.300.2 251702 / 350 350mm (14") White 1702.350.2 251702 / 400 400mm (16") White 1702.400.2 251702 / 450 450mm (18") White 1702.450.2 251702 / 500 500mm (20") White 1702.500.2 251702 / 550 550mm (22") White 1702.550.2 251702 / 575 575mm (23") White 1702.575.2 25PU = 25 bulk1702 / 250 250mm (10") Cream 1702.250.11 251702 / 300 300mm (12") Cream 1702.300.11 251702 / 350 350mm (14") Cream 1702.350.11 251702 / 400 400mm (16") Cream 1702.400.11 251702 / 450 450mm (18") Cream 1702.450.11 251702 / 500 500mm (20") Cream 1702.500.11 251702 / 550 550mm (22") Cream 1702.550.11 251702 / 575 575mm (23") Cream 1702.575.11 25PU = 25 bulk1800 Roller Slides, 125 lbs., extended length drawer slideDescription Nominal Length Color Item No. PU1800/600 600mm (23 5/8") White 1800.600.2 201800/650 650mm (25 19/32") White 1800.650.2 201800/700 700mm (27 9/16") White 1800.700.2 201800/750 750mm (29 17/32") White 1800.750.2 201800/800 800mm (31 1/2") White 1800.800.2 20PU = 20 sets tapedPU = Packaging Unit20Dimensions in millimeters, fractional inch equivalents as noted.

Roller Slides 1754100 lbs. bottom mount, tilt front drawer slide• Single-extension slide with tilt bracket, nylon rollers,• Installation width 12.5mm (1/2”), bottom mounting• Front can be tilted• Access to trays from front• Parallel closing• Secure closing• Bottom edge clearance - no chamfering required• Close fit of drawer at bottom• Double stop• Secure stop in position• Use rear mount socket for face frame application1754 Roller Slides, 100 lbs. Tilt FrontDescription Nominal Length Color Item No. PU1754/450 450mm (18") White 1754.450.2 251754/500 500mm (20") White 1754.500.2 251754/500 550mm (22") White 1754.550.2 25PU = 25 bulkApplicationPU = Packaging Unit22 Dimensions in millimeters, fractional inch equivalents as noted.

Drawer ExtensionASlide LengthSingle stopdrawer extension (A)Double stopdrawer extension (B)450mm (18") 322mm (12 11/16") 339mm (13 11/32")500mm (20") 362mm (14 1/4") 379mm (14 29/32")550mm (22") 397mm (15 5/8") 414mm (16 5/16")BDrawer Installation Dimensions 175412.5 +2 ( 1 /2" + 1 /16")23 ( 7 /8")10.5 ( 7 /16")5 ( 3 /16")5.7 ( 1 /4")12.5 ( 1 /2")33 (1 5 /16")11 ( 7 /16")LRMIN. 22 ( 7 /8")4 ( 3 /16")Bottom Width =Inside Cabinet Width - 12.5 ( 1 /2")Inside Cabinet WidthCabinet Member Boring SpecificationsCabinet Profile Mounting PositionCabinet edge32 (1 1 /4") 37 (1 7 /16")9( 3 /8")For wood screwNo. 6 x (5/8")or Euro screws6 x 11 mm ( 1 /4" x 7 /16")6 x 13 mm ( 1 /4" x 9 /16")12( 1 /2")14( 9 /16")35 (1 3 /8") 2 ( 1 /16")32(1 1 /4")64(2 1 /2")128(5 1 /16")Front edge of cabinet96(3 3 /4") 400(16")128(5 1 /16")96(3 3 /4")128(5 1 /16")450(18")500(20")550(22")237 ( 1 /16")(1 7 /16")All dimensions in millimeters.Subject to technical modifications without notice.23

Roller Slides 5300125 lbs. bottom mount, full extension drawer slide• Full-extension slide with nylon rollers, 125 lbs.• Installation width 12.5mm (1/2”), bottom mounting• 30mm (1 3/16”) over-extension• Easy access• Central rail can be adjusted• Secure parallel closing• Removal protection• Secure connection of drawer to cabinet• Bottom edge clearance• Close fit of drawer slide at bottom5300 Full Extension Roller Slides, 125 lbs.Description Nominal Length Color Item No. PU5300 / 250 250mm (10") White 5300.250.2 105300 / 300 300mm (12") White 5300.300.2 105300 / 350 350mm (14") White 5300.350.2 105300 / 400 400mm (16") White 5300.400.2 105300 / 450 450mm (18") White 5300.450.2 105300 / 500 500mm (20") White 5300.500.2 105300 / 550 550mm (22") White 5300.550.2 105300 / 600 600mm (24") White 5300.600.2 105300 / 650 650mm (26") White 5300.650.2 105300 / 700 700mm (28") White 5300.700.2 105300 / 750 750mm (30") White 5300.750.2 105300 / 800 800mm (32") White 5300.800.2 10PU = Packaging Unit24 Dimensions in millimeters, fractional inch equivalents as noted.

Drawer Extension30 mm(1 3 /16")Slide LengthOver Extension250mm (10") 30mm (13/32")300mm (12”)-350mm(14”) 15mm (19/32")400mm (16”)-800mm (32") 30mm (1 3/16")Drawer Installation Dimensions 5300min. 12( 1 /2")Top+112.5( 1 /2")+112.5( 1 /2")min. 48(1 7 /8")Bottom6.5 ( 1 /4")Drawer width = ICW -25 (1")Inside Cabinet Width (LW)5 ( 3 /16") 43 (1 11 /16")60 (2 3 /8")Cabinet Member Boring SpecificationsCabinet Profile Mounting Position96(3 3 /4")96(3 3 /4")128(5 1 /16")37(1 7 /16")Cabinet edge32 (1 1 /4") 37 (1 7 /16")9( 3 /8")6( 1 /4")64(2 1 /2")250(10")300(12")350(14")For wood screwNo. 6 x (5/8")or Euro screws6 x 11 mm ( 1 /4" x 7 /16")6 x 13 mm ( 1 /4" x 9 /16")6( 1 /4")35 (1 3 /8") 2 ( 1 /16")32(1 1 /4")64(2 1 /2")128(5 1 /16")128(5 1 /16")400(16")450(18")500(20")550(22")224(8 13 /16")600(24")650(26")700(28")750(30")128(5 1 /16")256(10 1 /16")224(8 13 /16")128(5 1 /16")800(32")237 ( 1 /16")(1 7 /16")All dimensions in millimeters.Subject to technical modifications without notice.25

Pull-out Shelffor 1700, 1754, 1800• Railing for single pull-out shelves• Aluminum tube• Epoxy coated• Color: white (RAL 9010)Pull-out shelf321Description Item No. PU1 Divider rail, 1000mm (39 3/8”) 3570.1000.2 202 Single corner post 3576.2.VE20 203 Divider clip 3575.2.VE20 2013570Round tube23576Single corner post33575Holder for divider rail1700Single extension slidePull-out shelf applicationMin. 15 ( 9 /16") Min. 62 (2 1 /4")12.5( 1 /2")6.5 ( 1 /4")+216 ( 5 /8")57 (2 1 /4")Drawer width = ICW - 25 (1")Inside Cabinet Width (ICW)12.5( 1 /2")11( 7 /16")Side Gallery Rail = NL -25 mmCross Rail = ICW -33 mmDivider Rail = NL -40 mmPU = Packaging Unit26 Dimensions in millimeters, fractional inch equivalents as noted.

Mounting Aidsfor 1700, 1754, 1800, 5300Drill Jig for cabinet member 1700, 1754, 1800Description Item No. PUDrill Jig for cabinet member 1700 / 1754 / 1800 F146083248101 1Wood Screws1782345Description Item No. PU1 # 6 x 1/2" FHP, Nickel 81004-43 5002 # 6 x 7/16" FHP, Nickel 81016-43 5003 # 6 x 5/8" FHP, Nickel 81001-43 5004 # 6 x 3/4" FHP, Nickel 81003-43 5005 # 6 x 1" FHP, Nickel 81004-43 5006 # 8 x 3/4" FHP, Nickel 81005-43 5007 # 10 x 3/4" RHP, Nickel 81007-43 5008 # 10 x 1" PHP, Nickel 13720-43 5006Euro ScrewsDescription Item No. PU1 11mm (7/16"), Nickel 499.360.61.1015 5002 13mm (1/2"), Nickel 81015-43 5003 8mm (11/16"), Nickel 83000-43 5004 7.5mm (5/16"), Nickel 83001-43 5005 13mm (1/2") Pan Head, Nickel 3398-43 500Pozidrive Screw DriverDescription Item No. PUGrass Screw Driver 98000-01 1All dimensions in millimeters.Subject to technical modifications without notice.27

Accessoriesfor 1700, 1754, 1800, 53003800 / 3802 Spacers for cabinet membersTo provide side clearance for interior drawers andpull-out shelves.Description Item No. PU3800 Spacer for cabinet member, symmetrical 3800.13.VE100 1003802 Spacer for cabinet member, asymmetrical 3802.13.VE100 10032(1 1 /4")16( 5 /8")57(2 1 /4")3800.13.VE10025(1")+212.5( 1 /2")Drawer width = LW -75Inside cabinet width (LW)12.5( 1 /2")16( 5 /8")32(1 1 /4")57(2 1 /4")3802.13.VE10025.5(1")+212.5( 1 /2")Drawer width =ICW -76 (2 15 /16")Inside cabinet width (ICW)12.5( 1 /2")6196 Mounting BracketDescription Type Color Item No. PU6196 Mounting Bracket Screw-on White 00432-08 50With System 1700/1800/5300Attaches cabinet member of drawer slide if noside panel is available. Bracket can be usedfor right or left. Mounting screws included inpolybag. Can be used with all Grass drawerslide systems.Door / Drawer ProtectorsDescription Type Color Item No. PUDoor / Drawer Protectors Screw-on White 13096-43 500Attaches to side of wooden pull-out.Designed for inset pull-out trays for frameor frameless cabinetry.PU = Packaging Unit28 Dimensions in millimeters, fractional inch equivalents as noted.

Rear Mounting Socket for 1700, 1754, 1800Description Type Color Item No. PU1700 Rear Mounting Socket, left hand Screw-on, ABS copolymer White 499.217.00.0250 2501700 Rear Mounting Socket, right hand Screw-on, ABS copolymer White 499.217.00.0150 2501700 Rear Mounting Socket, left hand Staple mount, polyethylene White 499.217.00.0249 2501700 Rear Mounting Socket, right hand Staple mount, polyethylene White 499.217.00.0149 25068.4(2 11 /16”)50.5(2”)3.5( 1 /8”)34.2(1 3 /8”)Description Type Color Item No. PUUniversal Rear Mounting Socket, left hand Screw-on, ABS copolymer White 931.248.00.0250 250Universal Rear Mounting Socket, right hand Screw-on, ABS copolymer White 931.248.00.0150 250Universal Rear Mounting Socket, left hand Staple mount, polyethylene White 831.248.00.0249 250Universal Rear Mounting Socket, right hand Staple mount, polyethylene White 931.248.00.0149 250100(3 5 /16”)46(1 13 /16”)3.2( 1 /8”)29(1 1 /8”)Description Type Color Item No. PU1800 Rear Mounting Socket, left hand Screw-on, ABS copolymer White 499.218.00.0250 2501800 Rear Mounting Socket, right hand Screw-on, ABS copolymer White 499.218.00.0150 250All dimensions in millimeters.Subject to technical modifications without notice.29

Roller Slides ExpressFeatures and BenefitsFeatures and Benefits• Concealed undermount slides• No notching of sub-front required• 1 1/4” self-closing action• Slides can rest on cross rail• Delrin rollers• Double captive, self-aligning system• Made in the USA• For drawer materials 16 mm (5/8”) and 19 mm (3/4”)• For face frame cabinetry• Double cabtive, self aligning slide system• Concealed undermount¥ Uniquely engineered drawermembereliminates¥ Delrin rollers for smooth closing action¥ 1 1/4 self-closing actionfor self-closing ease andreliability¥ Slides can rest on cross rail for easy mountingMinimum ClearancesAn exceptionally low minimum clearance on top and bottom allowsmaximum utilization of cabinet space. A minmum clearance of 8 mm(5/16”) is required above the drawer box allowing for maximum useof drawer space.Delrin rollers ensure that the slides movequietly, softly and without force,8[5/16"]Min. topclearancePU = Packaging Unit30 Dimensions in millimeters, fractional inch equivalents as noted.

Technical Informationfor Roller Slides ExpressSystem CompatibilityExpress drawer slides are engineered to becompatible with Grass Elite undermount slides.They both have the same drawer specificationsto allow for the interchangeability. One caneasily upgrade from the Express to the Eliteusing the same drawer box. Realignment ofdrawer front position may become necessary.50[2 15 /16”]¥ Delrin rollers for smooth closing actionAdjustment Front and RearExpress cabinet members offer integral frontbrackets with height adjustment and use rearsockets for attachment to the cabinet back.The rear sockets are designed for use in faceframe cabinets and feature side-to-side selfalignmentplus height and depth adjustability.Side-to-sideAlignmentWeight CapacitieskgExpress:100 lbs. static load rating75 lbs. dynamic load ratingGrass Express slides meet and exceed ANSI/BHMA A 156.9-2001 Industry Standard testing requirements.All dimensions in millimeters.Subject to technical modifications without notice.31

Express Roller Slide75 lbs. undermount slide• Regular extension, concealed slide• No notching of sub-front required• Double captive, self-aligning system• Slides can rest on cross rail for easy mounting• 1 1/4” self-closing feature• Smooth glide with delrin rollers• Available for 16mm (5/8”) and 19mm (3/4”) drawer material• Color: Almond• Made in the USAExpress Roller Slide, 75 lbs.Description Drawer Length Color Item No. Cabinet Depth Min. Installation Depth Max. Installation Depth PU5323 / 229 / 16 229mm (9”) Almond 03920-04 305mm (12”) 277.5mm (10 15/16”) 292.5mm (11 1/2”) 105323 / 305 / 16 305mm (12”) Almond 03921-04 381mm (15”) 351.5mm (13 27/32”) 366.5mm (14 7/16”) 105323 / 381 / 16 381mm (15”) Almond 03922-04 457mm (18”) 429.5mm (16 29/32”) 444.5mm (17 1/2”) 105323 / 457 / 16 457mm (18”) Almond 03923-04 533mm (21”) 507.5mm (20”) 522.5mm (200 9/16”) 105323 / 533 / 16 533mm (21”) Almond 03924-04 610mm (24”) 582.5mm (22 18/16”) 597.5mm (23 1/2”) 105323 / 229 / 19 229mm (9”) Almond 03925-04 305mm (12”) 277.5mm (10 15/16”) 292.5mm (11 1/2”) 105323 / 305 / 19 305mm (12”) Almond 03926-04 381mm (15”) 351.5mm (13 27/32”) 366.5mm (14 7/16”) 105323 / 381 / 19 381mm (15”) Almond 03927-04 457mm (18”) 429.5mm (16 29/32”) 444.5mm (17 1/2”) 105323 / 457 / 19 457mm (18”) Almond 03928-04 533mm (21”) 507.5mm (20”) 522.5mm (20 9/16”) 105323 / 533 / 19 533mm (21”) Almond 03929-04 610mm (24”) 582.5mm (22 15/16”) 597.5mm (23 1/2”) 10Rear Mounting SocketsDescription Type Color Item No. PURear Mounting Socket, non-handed Screw-on Almond 00167-17 500Rear Mounting Socket, non-handed Screw-on Almond 00167-09 100PU = Packaging Unit32Dimensions in millimeters, fractional inch equivalents as noted.

Drawer MeasurementsInset Drawer50[2 15 /16”]Length of drawer9”-12”-15”-18”-21”DrawerFrontInterior DepthBlocking behind the frameMin. 11[ 7 /16”]Min/Max. Interior Depth based on application. Trial mounting recommended.Drawer Installation DimensionsRear Mounting Socket PositionExpress 16 = 21 [13/16"]Express 19 = 24.5 [15/16"]Interior Cabinet Width (ICW)A32 [1 1/4”]50[1 15/16"]Rear notchInterior drawer width formulaExpress 16 . . . ICW - 42 [1 5/8"]Express 19 . . . ICW - 49 [1 15/16"]8[5/16"]Min. topclearanceRecessMin. 11[7/16"]14[9/16"]Bottom clearanceOpening height- 22 [7/8"]= Max. drawer height6.4[1/4"]Max. drawer sideExpress 16 = 16 [5/8"]Express 19 = 19 [3/4"]39.526.7 [1 9/16"][1 1/16"]#6 woodscrewlocation atface frameRear Socket Mounting PositionExpress 16mm Express 19mmABFrame StileB30.4[1 3 ⁄16”]22.4[ 7 ⁄8”]48 [1 7/8”]Frame Rail34 [1 5/16”]35.2[1 3 ⁄8”]27.2[1 1 ⁄16”]Cabinet Installation Dimensions8 [5/16”]1.5 [1/16”]37 [1 7/16”]27.5 [1 1/8”]Interior Depth3 [1/8”]Max. 292.5 (11 1 /2”)Min. 277.5 (10 9 /16”)229.5 (9”)1.5 ( 1 /16”)CM 270DM 25039.5 [1 9/16”]28.7 [1 1/8”]24.7 [31/32”]Cabinet Member LengthMax. 366.5 (14 7 /16”)Min. 351.5 (13 27 /32”)305 (12”)CM 344DM 313Drawer LengthMax. 444.5 (17 1 /2”)Min. 429.5 (16 29 /32”)381 (15”)CM 422DM 400( )Add screw(s) for additional stabilityDrawer Member LengthMax. 522.5 (20 9 /16”)Min. 507.5 (30”)457 (18”)Max. 597.5 (23 1 /2”)Min. 582.5 (22 15 /16”)Min. 533 (21”)CM 500DM 470CM 575DM 550Face FrameAll dimensions in millimeters.Subject to technical modifications without notice.33

Ball Bearing Drawer SlideFull extension• Frameless or face frame application• For drawer lengths 250 mm (10”) to 700 mm (28”)• Full extension• Manufactured from cold rolled steel• 12.5 mm (1/2”) installation width• Drawer member releases for easy installation• 100 lb load ratingBall bearing full extension slide, 100 lbs (45 kg)Nominal length Item No. PU250 (10”) 30156-04 10300 (12”) 30157-04 10350 (14”) 30158-04 10400 (16”) 30159-04 10450 (18”) 30160-04 10500 (20”) 30161-04 10550 (22”) 30162-04 10600 (24”) 30163-04 10650 (26”) 30164-04 10700 (28”) 30165-04 10Rear mounting sockets, 100 lbs (45 kg)Description Item No. PU(Please order separately)Face frame rear socket 30166-15 3001 each left and right socketInstallation1Dis-engage drawer members4 52 Remove drawer members3 Attach drawer members to drawer4 Attach cabinet memebers5 Insert drawer member intocabinet member231PU = Packaging Unit34 Dimensions in millimeters, fractional inch equivalents as noted.

Drawer MeasurementsMHLGKFJEID28.516128359 9ø 4.5 x 7Cø 4.5ø 4.5ø 4.6 x 9.567ø 4.5 x 9.5A B ± 3ø 4.5ø 4.5 x 9.5Slide LengthA (mm)Slide TravelB (mm)C (mm) D (mm) E (mm) F (mm) G (mm) H (mm) I (mm) J (mm) K (mm) L (mm) M (mm)250 (10”) 250 - - - - - 192 - - - - -300 (12”) 300 - - - - - 242 224 - - - -350 (14”) 350 128 - - - - 292 224 - - - -400 (16”) 400 128 - - - - 342 224 320 - - -450 (18”) 450 128 320 - - - 392 224 352 - - -500 (20”) 500 128 192 352 - - 442 224 416 - - -550 (22”) 550 128 224 416 - - 492 224 352 448 - -600 (24”) 600 128 224 416 - - 542 224 352 448 - -650 (26”) 650 128 224 416 544 - 592 224 352 544 - -700 (28”) 700 128 224 288 448 544 642 224 352 - 544 608Drawer Installation DimensionsPre-drilling recommended Ø2.5 mm (3/32”).6 x 5/8” FHP6 x 5/8” FHPEuro Screw6 x 5/8” FHP12.5(1/2”)12.5(1/2”)All dimensions in millimeters.Subject to technical modifications without notice.35

Grass America Inc.1202 Highway 66 SouthKernersville, NC 27284Phone 1-800-334-3512Fax 1-800-525-8406Grass Canada Inc.475 Finchdene Square, Unit 9Toronto, ON M1X 1B7Phone 1-800-461-4975Fax 1-416-335-5907Item #__________-RSC-5M-MAP-4/12Internet: www.grassusa.comE-Mail: info@grassusa.comInternet: www.grasscanada.comE-Mail: info@grasscanada.com
