EDITORIAL<br />
It’s Showtime!<br />
The quadrennial innovation cycle is over at last, so foundrymen<br />
and their suppliers from all over the world will meet again in<br />
Düsseldorf for the world’s largest international foundry trade fair<br />
from 25 - 29 June <strong>2019</strong>.<br />
Robert Piterek<br />
e-mail: robert.piterek@bdguss.de<br />
As usual, the interest is enormous:<br />
about 900 exhibitors will be showing<br />
their products at GIFA. And<br />
there will actually be a total of about<br />
2,100 exhibitors at the four simultaneous<br />
trade fairs GIFA, METEC, THERMPROCESS<br />
and NEWCAST. 78,000 visitors are also<br />
expected, more than half of whom are<br />
travelling here from abroad.<br />
If we check out the developments<br />
that have taken place during the last<br />
four years we note that digitalization<br />
and additive manufacture have grown<br />
out of their infancy. This year’s Düsseldorf<br />
trade fairs are paying particular<br />
attention to these two technological<br />
trends, because the increasingly sophisticated<br />
sensor technology in the foundries<br />
is generating more and more data on<br />
production processes. Digitalization thus<br />
simplifies and refines, for example, the<br />
charge make up. And the constant availability<br />
of production data enables realtime<br />
monitoring of all important parameters<br />
– in die-casting foundries and in<br />
core shops (more about this from P. 10),<br />
but also in some iron and steel foundries.<br />
The evaluation of production data with<br />
the help of algorithms will, sooner or<br />
later, also make the identification of<br />
faults conceivable before they even arise.<br />
In short: the reason why digitalization is<br />
a constant subject of discussions in the<br />
sector is plain to see: it offers enormous<br />
potential for improving efficiency, transparency<br />
and quality. And equally affects<br />
all the sectors represented in the quartet<br />
of trade fairs – from the foundry sector,<br />
through the steel industry, to the thermo-process<br />
technology sector.<br />
Additive manufacture, on the other<br />
hand, has already developed into a sensible<br />
expansion of business for some casters,<br />
particularly with low batch numbers.<br />
Molds and patterns are the main<br />
products printed. The extensive use of<br />
3-D printers already pays in invest ment<br />
casting – and considerably accelerates<br />
the production of some components.<br />
GIFA visitors will find out more about<br />
this at the special Additive Manufacturing<br />
exhibition in Hall 3, at the specialist<br />
3-D Metal Printing Conference on 26<br />
June or in this magazine in an article<br />
about 3-D printing and art casting from<br />
P. 68.<br />
When it comes to the outcome of the<br />
trade fairs GIFA President Heinz Nelissen<br />
is optimistic. In an interview with <strong>CPT</strong><br />
(from P. 34), he says that he expects a<br />
“veritable explosion of innovations”. In<br />
addition to his assessments, <strong>CPT</strong>’s GIFA<br />
Special offers an article about recycling<br />
in the foundry sector, a Hall Plan and the<br />
GIFA News which offer a foretaste of the<br />
new developments that will define<br />
foundry operation in the coming years.<br />
Have a good read!<br />
CASTING PLANT & TECHNOLOGY 2/<strong>2019</strong> 3
CONTENTS<br />
FEATURES<br />
6 INTERVIEW<br />
Creating value for our customers –<br />
with innovative solutions<br />
In an Interview with <strong>CPT</strong>, Dr. Jens Müller, Global<br />
Head of Innovation at ASK Chemicals, gives a brief<br />
outlook on the upcoming GIFA fair and describes<br />
the importance of innovation for ASK Chemicals.<br />
10 COMPANY<br />
The core shop of the future<br />
It is intended to become a benchmark for the sector<br />
regarding digitalization, efficiency and networking<br />
of plants and machinery: the new high-tech<br />
core shop Inacore in Lower Bavaria.<br />
Robert Piterek<br />
16 COMPONENT DEVELOPMENT<br />
GIFA-SPECIAL<br />
GIFA- and NEWCAST<br />
president Nelissen<br />
expects a „veritable<br />
explosion of innovations.“<br />
COMPANY<br />
In a new joint venture<br />
two engineering<br />
companies evolve<br />
from supplier to<br />
manufacturer.<br />
Aluminum structural castings: integrated<br />
development of component and process<br />
A structural component for the AUDI A8 was awarded<br />
first prize in the Aluminium Die-Casting Competition<br />
at EUROGUSS – the work behind an award.<br />
Klaus Vollrath<br />
20 ENGINEERING OF FOUNDRY PLANTS<br />
Foundry planning undergoing digital change<br />
Companies are required to adopt a sustainable<br />
orien tation of all units – including digitalization –<br />
to create a modern factory.<br />
Axel Edlich, Robin Freitag, Frances Barchmann<br />
24 CLEANING, FETTLING & FINISHING<br />
Fire and flame for metal casting<br />
and processing<br />
An innovative metal foundry in Austria shows how<br />
mass finishing can contribute towards achieving<br />
the customer’s desired surface quality.<br />
Gerhard Franz Roth<br />
COMPONENT<br />
DEVELOPMENT<br />
At DGS Druckguss in<br />
Switzerland the<br />
development of component<br />
and process is<br />
taking place in an<br />
inte grated process.<br />
GIFA Special:<br />
Latest assessments on the<br />
course of the trade show –<br />
Trade fair plan – GIFA News<br />
for product overview.<br />
4
CONTENTS<br />
CLEANING, FETT LING &<br />
FINISHING<br />
Mass finishing at Schösswender<br />
Werke.<br />
28 SIMULATION<br />
Realistic simulation of the combustion<br />
of exothermic feeders<br />
The companies Flow Science and GTP Schäfer have<br />
jointly developed a realistic simulation model of the<br />
combustion of exothermic feeder systems.<br />
Malte Leonhard, Matthias Todte, Jörg Schäfer<br />
33 SPECIAL: GIFA <strong>2019</strong><br />
GIFA <strong>2019</strong> – „A veritable explosion<br />
of innovations!<br />
Interview with GIFA- and NEWCAST president<br />
Heinz Nelissen on the value of the upcoming trade<br />
fairs for exhibitors and visitors.<br />
Tremendous potential – environmental, economic<br />
and social sustainability in foundries<br />
Foundries are one of the best examples of resource<br />
efficiency and sustainability. Because castings implement<br />
the recycling concept almost completely.<br />
Carina Hendricks<br />
Hall plan<br />
GIFA-News<br />
62 COATINGS<br />
Multitasking: Coatings for centrifugal<br />
casting<br />
Innovative coatings formulated for centrifugal casting<br />
help to avoid casting defects, influence mechanical<br />
parameters and even serve as a forming medium.<br />
Klaus Seeger, Ekaterina Potaturina<br />
68 3-D-PRINTING<br />
COATINGS<br />
The range of centrifugal<br />
casting applications<br />
increases – so<br />
does the importance<br />
of coatings.<br />
3-D printing systems evolutionize<br />
traditional art casting<br />
Art foundry Strassacker creates artistic works using<br />
3-D printing systems by voxeljet.<br />
Frederik von Saldern, Peter Mühlhäuser<br />
COLUMNS<br />
3 EDITORIAL<br />
72 FAIRS AND CONGRESSES/AD INDEX<br />
74 PREVIEW/IMPRINT<br />
CASTING PLANT & TECHNOLOGY 2/<strong>2019</strong> 5
INTERVIEW<br />
6
“Innovations are crucial for success and<br />
growth on both the customer and supplier<br />
side!“<br />
When it comes to innovation Dr. Jens Müller is the suitable<br />
person to talk to at ASK Chemicals. At the fair the<br />
company presents several interesting new developments.<br />
Creating value for our customers<br />
– with innovative solutions<br />
Dr. Jens Müller, Global Head of Innovation at ASK Chemicals, gives in conversation<br />
with <strong>CPT</strong> a brief outlook on the upcoming GIFA fair in Düsseldorf and describes the<br />
importance of innovation for ASK Chemicals and the role of customers in the<br />
company‘s innovation process.<br />
Photo: ASK Chemicals<br />
GIFA <strong>2019</strong> is just around the corner<br />
and we are all eager to see what the<br />
foundry industry will be presenting at<br />
the industry‘s most important exhibition.<br />
What new solutions can we look<br />
forward to at ASK Chemicals?<br />
A highlight at GIFA <strong>2019</strong> will certainly<br />
be our latest solutions for 3-D sand<br />
printing. Here we will present some<br />
exciting developments both in the field<br />
of organic binders as well as inorganic<br />
binders. We will also present our new<br />
Exactpore 3-D filter technology.<br />
As a leading supplier of environmentally<br />
friendly and employee-friendly<br />
solutions, we will present new products<br />
for this area, such as our latest innovation<br />
– the low-formaldehyde system – a<br />
package solution consisting of binder,<br />
additive and coating that complies with<br />
the stricter formaldehyde limits in<br />
exhaust gas flow that will come into<br />
force at the beginning of 2<strong>02</strong>0. Of<br />
course, that‘s not all. Visitors to our<br />
stand can look forward to further innovative<br />
products that improve technical<br />
and economic performance.<br />
What is innovative for you?<br />
New offers that create high value and<br />
are sustainable are innovative. Knowledge<br />
is translated into values such as<br />
performance, environmental compatibility<br />
or cost savings. Ultimately, customers<br />
and suppliers benefit from this<br />
together. The value for the customer is<br />
that he becomes more competitive,<br />
while the provider of innovative solutions<br />
invests part of the value created<br />
in generating knowledge and developing<br />
further innovation. Innovations are<br />
therefore crucial for success and<br />
growth on both the customer and supplier<br />
side. An innovative product or<br />
business model does not have to be<br />
perfect from the very first minute, but<br />
it has to generate enthusiasm with customers,<br />
surprise them and, at least in<br />
some aspects, offer more than they<br />
expected.<br />
As you say, innovation transforms<br />
knowledge into benefit and ultimately<br />
into value. Can you put this into concrete<br />
terms?<br />
The easiest way to illustrate this is<br />
probably to use examples – such as<br />
cold box binders, which are now standard<br />
in the industry. When Ashland<br />
(then the parent company of ASK<br />
Chemicals) invented this technology, its<br />
knowledge of polyurethane chemistry<br />
converged with the automotive foundries‘<br />
need for fast and reproducible<br />
processes to produce sand cores. Then,<br />
technology push and market pull<br />
forces came together, and our customers<br />
and we at ASK Chemicals benefit<br />
from this innovation until this day.<br />
Another example is the Inotec inorganic<br />
binder system invented by ASK.<br />
The anticipation of stricter environmental<br />
guidelines resulted in a market<br />
pull that our researchers combined<br />
with the possibilities of silicate chemistry.<br />
Without a close cooperation with<br />
our customers‘ innovative thinking and<br />
acting, this development would not<br />
have been possible. Today, both our<br />
customers‘ employees and the environment<br />
benefit from this innovation.<br />
What is the innovation process at ASK<br />
Chemicals like?<br />
Our innovation process consists of<br />
three phases: In the first step, the creative<br />
phase, we develop new<br />
approaches. This is done, for example,<br />
through trend analyses and evaluation<br />
of new topics in discussions with customers,<br />
sales, technical service, R&D,<br />
suppliers and other internal and external<br />
partners. This is primarily about<br />
effectiveness, or “doing the right<br />
thing“. This is a very important step,<br />
because it is basically about “discovering<br />
problems that need to be solved“.<br />
In the second step, idea and project<br />
management, the core assumptions of<br />
the innovation approach, i.e. the technology<br />
and the business model, are<br />
tested. This is then about efficiency, or<br />
CASTING PLANT & TECHNOLOGY 2/<strong>2019</strong> 7
INTERVIEW<br />
“doing it the right way“. The projects<br />
that also survive this selection process<br />
– and these are usually only a few –<br />
then enter the 3rd phase, the market<br />
launch. At the same time, we aim to<br />
have sufficiently clarified all uncertainties<br />
critical to success at this point in<br />
time in order to be able to convince<br />
our customers of the intrinsic value of<br />
the innovation.<br />
What role does the customer play in<br />
the process described?<br />
ASK Chemicals puts the customer at<br />
the centre. As already mentioned<br />
above, it is about solving a customer‘s<br />
problem or arousing enthusiasm. We<br />
often use the so-called lead-user<br />
method. This means that we try to<br />
involve particularly innovative customers,<br />
with whom we usually have a very<br />
good relationship of trust, in the innovation<br />
process. Our customers not only<br />
contribute to the honing of our ideas<br />
and projects, but are also the essential<br />
litmus test for the value we want to<br />
generate with innovation. In concrete<br />
terms, this can also be seen in the<br />
example of the development of our<br />
low-formaldehyde (LFS) technology.<br />
The customer is confronted with a<br />
problem, namely a tightening of limit<br />
values for formaldehyde in the exhaust<br />
gas flow from 2<strong>02</strong>0 (deadline applies<br />
to old plants), which triggers a process<br />
as described above. Ideas for solving<br />
the problem are generated, initial preliminary<br />
tests carried out and optimised<br />
in an iterative process between<br />
laboratory, test foundry and customer<br />
to such an extent that at the end a<br />
product package was put together<br />
which demonstrably reduces formaldehyde<br />
emissions in the drying oven by<br />
more than 70 %. And this is exactly<br />
what I see as an essential task of innovation,<br />
namely the solution of a customer<br />
problem.<br />
What are the value drivers that ASK<br />
Chemicals has identified for its innovation<br />
activities?<br />
We focus on three core areas that are<br />
particularly important for our customers:<br />
In the “Performance“ area, we<br />
develop products that simplify,<br />
improve or accelerate foundry processes<br />
and thus offer our customers<br />
cost and competitive advantages. In<br />
the “Environment” area, on the other<br />
hand, we have a clear focus on products<br />
that comply with the environmental<br />
regulations and rules to be<br />
expected in the future today without<br />
compromising performance. In this<br />
way, our customers can already now<br />
make their processes and investments<br />
fit for the future.<br />
It has always been part of our philosophy<br />
to work closely with our customers<br />
so that foundries can achieve<br />
optimum results with our products. This<br />
would not be possible without service<br />
as a core element of our business<br />
model. This is why we are also placing a<br />
very clear focus on innovation in the<br />
third area “Services“. In doing so, we<br />
are now increasingly relying on digital<br />
possibilities that enable us to support<br />
our customers even faster and more<br />
competently.<br />
Mr. Müller, thank you for the interview!<br />
8
YXLON – QUALITY ASSURANCE<br />
AND PROCESS OPTIMIZATION<br />
WITH CT IN DIFFERENT FLAVORS<br />
Live at<br />
GIFA <strong>2019</strong><br />
Booth 11F24<br />
YXLON MU60 AE, the universal industrial X-ray and<br />
CT inspection system was designed for a broad<br />
range of applications for foundries in the aerospace<br />
and automotive industries. Compliant with the current<br />
standards such as DICONDE, ASTM, MAI and Nadcap,<br />
and equipped with ADR (automatic defect recognition),<br />
it is the perfect At-Line inspection system for large<br />
castings. The live demonstrations of both 2-dimensional<br />
radioscopy and 3-dimensional computed tomography<br />
will probably impress visitors due to the size of the<br />
cabinet and the parts that can be inspected.<br />
Inline Computed Tomography is the next step toward Industry 4.0, gathering comprehensive data about every<br />
single object in production for reliable product quality and continuous process optimization. Yxlon provides<br />
CT-Inline solutions for individual customer requirements. Equipped with cutting-edge detector technology, mechanics<br />
that keep up with every production cycle, and based on the proven analysis software from Microvista, Yxlon<br />
CT-Inline will raise manufacturing processes to a new level. At the Gifa trade fair, the solution will be introduced to<br />
the public.<br />
YXLON FF35 CT, the high-resolution industrial CT system<br />
for small and medium-sized parts, is presented in its<br />
latest version. The system is designed as laboratory<br />
device to achieve extremely precise inspection results<br />
for a wide range of applications. Available in a single<br />
or dual tube configuration, it is perfect for most diverse<br />
parts inspection in the automotive, aviation, electronics,<br />
and material science industries. Based on the award-winning<br />
software platform Geminy, FF35 CT provides best<br />
inspection results for specialists as well as unexperienced<br />
users. A brand-new detector, additional trajectories and<br />
live filters increase the spectrum of parts and optimize<br />
image quality even more. With the metrology version,<br />
accurate measurements of objects’ inner structures<br />
can reliably be realized.<br />
www.yxlon.com
COMPANY<br />
Photos: Inacore<br />
The new Inacore core shop in Ergoldsbach is intended to set standards and increase the<br />
potentials of core production.<br />
The core shop of the future<br />
It is intended to become a benchmark for the sector regarding digitalization, efficiency<br />
and network ing of plants and machinery: the new Inacore core shop, a joint venture<br />
between Laempe Mössner Sinto and R. Scheuchl GmbH. To manufacture more than<br />
1.5 million core packages for engine production at the BMW light-metal foundry in<br />
Landshut during coming years production began a year ago. Now three-shift operation<br />
has also started in the Lower Bavarian town of Ergoldsbach to further increase capacity.<br />
Robert Piterek, Düsseldorf<br />
At the official opening of the<br />
works in Ergoldsbach in late<br />
September 2018 it was announced<br />
that in future up to two thousand<br />
vehicles with engine blocks produced<br />
using Inacore cores were to roll off<br />
BMW’s assembly line every day. The<br />
BMW light-metal foundry in Landshut<br />
had already been using inorganically<br />
bound cores from Inacore for the casting<br />
molds to produce the 4-cylinder<br />
gasoline engines of the 3 and 5 Series<br />
since early 2018. Construction of the<br />
state-of-the-art core shop, costing double-digit<br />
millions of euros, was financed<br />
by the partners and banks.<br />
Tight time window for construction<br />
of the works<br />
The countdown to start production<br />
began when construction of the works<br />
was initiated in mid-2017 in the industrial<br />
area of Ergoldsbach. The plan was<br />
that the first samples would be ready in<br />
December 2017, and that delivery of<br />
10
the first cores would take place as early<br />
as January 2018.<br />
In logistical terms, the site was well<br />
chosen – it is only 19 kilometers to the<br />
BMW core depot, for whose cores Inacore<br />
is responsible. And Ergoldsbach is a<br />
commuter town with few production<br />
sites of its own. So the new, up to now<br />
only, industrial company there offered<br />
new career prospects, which were<br />
rapidly grasped. Numerous employees<br />
signed their contracts with Inacore<br />
before the core shop had even started<br />
work – more than 30 personnel are now<br />
employed at Inacore. The new company’s<br />
administration and its Research &<br />
Development Department are accommodated<br />
at the joint-venture partners<br />
Scheuchl, Ortenburg, and Laempe Mössner<br />
Sinto, Barleben (both Germany).<br />
Highly automated and networked<br />
production<br />
Six fully automatic high-tech Type<br />
LHL30 core-shooting machines from<br />
Laempe Mössner Sinto are used to<br />
secure BMW’s supply of core packages,<br />
consisting of nine individual cores each.<br />
The Managing Directors and partners Andreas Mössner (left) and Udo Dinglreiter are<br />
also Managing Directors of the family-run companies Laempe Mössner Sinto and<br />
R. Scheuchl GmbH.<br />
The machines are used to shoot cooling<br />
jacket cores, central cores and balance<br />
shaft cores, among other things. Tool<br />
changes can be carried out within a<br />
few minutes. After shooting, industrial<br />
robots from ABB do the deburring,<br />
before employees carry out the final<br />
quality inspection of the cores and<br />
place them in racks equipped with RFID<br />
chips. The racks – and thus the batch<br />
CASTING PLANT & TECHNOLOGY 2/<strong>2019</strong> 11
COMPANY<br />
production parameters stored in the<br />
RFID chips – form the interface between<br />
production, climatized storage,<br />
and the core depot at the BMW works.<br />
The production cycles and the associated<br />
data can be called up in real time<br />
using a computer or tablet, and can be<br />
compared with old data. This is the<br />
finest side of digitalization, delighting<br />
the Inacore partners and Managing<br />
Directors Udo Dinglreiter and Andreas<br />
Mössner, and spurring them on to<br />
make bold plans: “We are working<br />
with the Chair of Mathematics at the<br />
University of Passau on a multi-parameter<br />
system controlled by artificial intelligence<br />
(AI). We are right at the start<br />
here, our long-term objective, however,<br />
is that the AI learns to derive conclusions<br />
from the data and will ultimately<br />
prevent defects,” ex plains Udo Dinglreiter,<br />
and Andreas Mössner adds:<br />
“Machine and plant constructors have<br />
to take Industry 4.0 into their own<br />
hands.” Other technical possibilities<br />
such as augmented reality (i.e. the computer-supported<br />
expansion of perception)<br />
and virtual reality could one day<br />
be used for maintenance and servicing.<br />
Training of the employees began<br />
after the joint company was founded in<br />
April 2017, parallel to construction of<br />
the works in the industrial area of<br />
Ergoldsbach. Intensive training was<br />
undertaken at BMW because the personnel<br />
had no specific core shop experience<br />
at all. Laempe Mössner Sinto had<br />
already started working on digitalization<br />
in collaboration with the Pragmatic<br />
Industries start-up in January 2017.<br />
In view of the short time window<br />
until production started, the partners<br />
followed the principle of ‘learning by<br />
doing’. The declared aim was to build a<br />
core shop as a sector benchmark, and<br />
thus uncover hidden potentials. The<br />
tools for this were to be the possibilities<br />
of consistent digitalization offering<br />
transparency, networking and traceability.<br />
“It is still uncharted territory,”<br />
admits Andreas Mössner.<br />
But in addition to the technology-driven<br />
aspiration, a great deal of<br />
expertise is necessary. Scheuchl exploited<br />
its many years of experience in the<br />
construction of the works infrastructure,<br />
the air-conditioning and the project<br />
management, while Laempe used<br />
theirs for the machinery – from the<br />
core-shooting plant, through the sand<br />
mixer, to the sand conveyor system. The<br />
partners installed the necessary plants<br />
in two halls, to start with. Hall 1 accommodates<br />
production with the six<br />
Fully automated core production:<br />
industrial robots take over<br />
practically all the work steps<br />
carried out after core shooting.<br />
A finished core leaves the<br />
core-shooting machine, in front<br />
of which a robot is already<br />
waiting.<br />
core-shooting machines and the manipulators.<br />
Hall 2 has the climatized storage<br />
plant and the server, the raw<br />
material depot, and the two sand silos<br />
from the company FAT, in Niederfischbach,<br />
Germany. A third hall is being<br />
planned.<br />
IT security is essential with so much<br />
high-tech, otherwise the system would<br />
face the risk of Trojans, hacking or overloading<br />
attacks initiated by cybercriminals.<br />
The partners invested about<br />
100,000 euros on data security for the<br />
server, and for a doubly protected security<br />
system. Regarding IT security, Udo<br />
Dinglreiter and Andreas Mössner are<br />
confident that the data is not so easy to<br />
interpret.<br />
Sustainable air-conditioning<br />
technology<br />
Climate control is the sticking point in<br />
the production of inorganic cores, and<br />
determines their durability and functional<br />
capability. The two family-run<br />
companies selected a sustainable<br />
approach: they use the waste heat<br />
from the compressors to drive the sorption<br />
rotors that regulate the temperature<br />
in the climatized room. “The cores<br />
harden in the core-shooting machine<br />
and are then put in the climatized<br />
room that is air-conditioned by the<br />
waste heat,” explains Udo Dinglreiter.<br />
In order to ensure transport from the<br />
works to the BMW depot with an air<br />
humidity of a few grams per cubic<br />
meter, Inacore works with a special for-<br />
12
After removal, a robot<br />
deburrs the cores with<br />
this tool.<br />
External view of Inacore’s<br />
works grounds:<br />
only six months was<br />
available for construction<br />
and installation of<br />
the equipment.<br />
IT plays a decisive role<br />
at Inacore. Not only in<br />
the quality assurance<br />
taking place here. Production<br />
cycles and the<br />
associated data can be<br />
called up in real time<br />
via computer or tablet<br />
at any time.<br />
Short-wave.<br />
Also interested in really fast, rugged, light,<br />
accurate, customised and inexpensive infrared<br />
thermometers and cameras for non-contact<br />
measurements between −50 °C to +3000 °C?<br />
Visit www.optris.global<br />
There’s no two ways about it:<br />
our short wavelength infrared<br />
cameras enable temperature<br />
measurements of metal surfaces,<br />
graphite or ceramics.<br />
25.–29.06.<strong>2019</strong><br />
Visit us in hall 9,<br />
stand A40<br />
from<br />
3150 €<br />
warder who delivers the cores in airtight<br />
trucks.<br />
According to partner Andreas Mössner,<br />
the decision to use sustainable climate<br />
control technology was not taken<br />
following purely economic points-ofview:<br />
“We all have children, so sustainability<br />
is the guard rail for an entrepreneurial<br />
life. Where one can control<br />
things, one does so; if it is also economical<br />
then so much the better.”<br />
2,000 core packages per day are currently<br />
produced in Ergoldsbach, each<br />
weighing 15 kilograms. 30 tonnes of<br />
Innovative Infrared<br />
Technology
COMPANY<br />
sand is required every day – and it has<br />
to be moved by pneumatic vessel conveyor:<br />
from the sand silos to the sand<br />
mixers which, as a result of the hall’s<br />
infrastructure, had to be specially modified<br />
so that they could stand on the<br />
floor. Then the sand flows via more<br />
pneumatic vessel conveyors to the<br />
core-shooting machines in Hall 1. The<br />
filling level of the silos will in future be<br />
networked with the sand suppliers to<br />
secure the sand supply to the silos at all<br />
times. After hardening of the cores in<br />
the core-shooting machines they are<br />
transported to the climatized depot,<br />
where nine different core types are stored<br />
with the help of an ERP system.<br />
Whereby expertise on the storability of<br />
inorganic cores is also used and taken<br />
into account when selecting the storage<br />
spaces. In view of the sensitive climatizing<br />
situation the depot at Inacore is<br />
not only monitored by the company’s<br />
own team – there is also real-time networking<br />
with the BMW depot, resulting<br />
in transparency on both sides, intended<br />
to optimize production reliability and<br />
collaboration.<br />
The partners also consider quality<br />
very important: they have invested<br />
more than 200,000 euros in quality<br />
assurance equipment. This includes a<br />
laboratory core-shooting machine for<br />
determining sand quality, the quality of<br />
the mix, and core breaking strength, as<br />
well as a measurement system by Zeiss,<br />
Oberkochen, Germany, with which,<br />
among other things, measurements are<br />
carried out as proof provided by the<br />
supplier for the customer. The sand<br />
grain size is also determined in the<br />
laboratory. The average grain size at<br />
Inacore is 0.32 micrometers. There is<br />
also a small furnace available for moisture<br />
measurement.<br />
Employee discussions in the production hall. More than 30 personnel are currently<br />
working at Inacore.<br />
Inacore to increase process<br />
understanding<br />
Production could start in Ergoldsbach<br />
shortly before the sampling took place<br />
in early December 2017. 30 core packages<br />
were sent off to BMW punctually –<br />
and they met the carmaker’s requirements.<br />
The gambit had worked, and<br />
machine and plant constructors<br />
R. Scheuchl GmbH and Laempe Mössner<br />
Sinto had become core-makers. The two<br />
partners deliberately exceeded their traditional<br />
business fields in machine and<br />
plant construction in order to gain operator<br />
expertise. “The demands have<br />
increased; process understanding is<br />
required nowadays. How can one plan<br />
plants without understanding the<br />
details?” asks Andreas Mössner, adding:<br />
“We want to understand the daily activities,<br />
and thus also improve the machines.”<br />
Another motivation for the investment<br />
by Laempe and Scheuchl, however,<br />
was undoubtedly to win the order<br />
from BMW. But the new company does<br />
not want to be dependent on a single<br />
OEM so it is currently acquiring more<br />
customers for the high-tech core shop.<br />
All those involved in the new company<br />
are confident about its future<br />
pros pects, as became clear during the<br />
opening ceremony in September 2018.<br />
The founders of R. Scheuchl GmbH<br />
attended, alongside high-ranking guests<br />
from the worlds of politics and commerce.<br />
Finally, the BMW team was also<br />
screened in the production hall. The<br />
men in the BMW waistcoats were showing<br />
solidarity with the Inacore team –<br />
and were thus also celebrating an exemplary<br />
collaboration between supplier<br />
and customer.<br />
<br />
www.inacore.de<br />
14
FOUNDRY –<br />
A PASSION FROM<br />
OUR HEART.<br />
DR. CHRISTIAN APPELT, GLOBAL BUSINESS MANAGER INORGANICS<br />
“COURAGE AND<br />
CREATIVITY FOR<br />
INNOVATIVE<br />
SOLUTIONS”<br />
Emission-free binder systems for productive applications.<br />
Meet us at GIFA <strong>2019</strong>:<br />
Hall 12, Booth A22<br />
The development and implementation of emission-free binder systems in large-scale production<br />
of metal castings is a key concern of modern foundries. Our product solutions surpass the<br />
ecological and economic requirements of conventional and additive manufacturing processes.<br />
With INOTEC TM and INOTEC TM 3D technology we are driving the most efficient and green<br />
foundry applications today.<br />
www.gifa.ask-chemicals.com<br />
CASTING PLANT & TECHNOLOGY 2/<strong>2019</strong> 15
COMPONENT DEVELOPMENT<br />
Photo: Audi AG<br />
Die-cast components produced by DGS Druckguss Systeme from St. Gallen.<br />
Aluminum structural castings:<br />
integrated development<br />
of component and process<br />
The work behind a casting award<br />
Klaus Vollrath, Aarwangen, Switzerland<br />
On the occasion of the Euroguss<br />
2018 trade fair in Nuremberg, on<br />
15 January 2018, the German<br />
Association of the Aluminium Industry<br />
awarded first prize in the Aluminium<br />
Die-Casting Competition to a casting<br />
jointly developed by AUDI AG and DGS<br />
Druckguss Systeme AG, St. Gallen, Switzerland.<br />
The large and extremely<br />
thin-walled structural element developed<br />
for the new Audi A8 has a wall thickness<br />
that is mostly only 1.8 - 2 mm, and it<br />
there fore only weighs 3043 grams, despite<br />
dimensions of 797 x 437 x 304 mm.<br />
Just as interesting as the component itself,<br />
however, is the development that lies<br />
behind it, as a conversation with Markus<br />
Heim, Key Account Manager, and Axel<br />
Schmidt, Technology Manager at DGS,<br />
reveals.<br />
“What was special about the development<br />
of the new component for the<br />
Audi A8 was the integrated development<br />
both of the product itself and the production<br />
process, in close collaboration<br />
with our customer Audi,” explains Markus<br />
Heim, Key Account Manager at DGS<br />
Druckguss Systeme. Audi took the decision<br />
to approach this project together<br />
with DGS at the end of 2015, after DGS<br />
made an appropriate offer. The component<br />
is a large but very thin-walled structural<br />
casting that connects the C- and<br />
D-pillars of the new Audi A8 (Model D5).<br />
The structural element also redirects the<br />
safety belt and supports the rear damper<br />
strut via three threaded rings, as well as<br />
accepts the parcel shelf, rear panel and<br />
the hinge of the tailgate. Additional<br />
requirements included as low a weight as<br />
possible compared to the element previously<br />
used, necessitating low wall thicknesses.<br />
The prerequisite for this was the<br />
use of a special high-strength alloy in<br />
combination with a new heat treatment<br />
process. Audi had already begun developing<br />
this new type of alloy (AlSi10MnMgZnZr)<br />
in 2011/2012. In addition to the<br />
material, it was also essential to implement<br />
an evolutionary modification of<br />
the heat treatment process. Trials were<br />
16
Photos: Klaus Vollrath<br />
carried out in close collaboration with<br />
DGS Druckguss Systeme, which invested<br />
in the plant technology necessary for the<br />
heat treatment.<br />
The material, with a yield strength<br />
(R p0.2<br />
) of 180 - 210 MPa at elongation<br />
values of > 7 %, is described in an internal<br />
Group standard. The test program<br />
for qualification of the component was<br />
extremely extensive, ranging from the<br />
die-casting of test panels for the usual<br />
castability and strength experiments to<br />
the production of real components for<br />
test drives and the determination of<br />
their suitability for the most varied of<br />
joining processes – such as welding,<br />
self-piercing riveting, flow-drilling<br />
screws, gluing and MIG welding.<br />
Development of the<br />
casting process<br />
“The process necessary for producing<br />
thin-walled castings was also specially<br />
developed for the new material,” adds<br />
Axel Schmidt, Technology Manager at<br />
DGS. Simulation programs were extensively<br />
employed during development. This<br />
not only involved the complex geometry/<br />
strength testing as well as the design of<br />
the casting system and mold temperature<br />
control, but also the heat treatment<br />
– because the component’s thin walls<br />
make it highly susceptible to warpage.<br />
Audi was able to make a considerable<br />
contribution towards component tolerance<br />
thanks to its pioneering work in<br />
the field of warpage simulation.Where by<br />
important target criteria were the determination<br />
of the optimum course of the<br />
temperature over time and the method<br />
for storing the castings on special heat<br />
treatment racks. In this connection, a<br />
specific Audi test tool was created as a<br />
thin-walled casting tool. The component<br />
cast in the test tool already had dimensions<br />
of 650 x 650 x 300 mm. The production<br />
of smaller serial parts for the Audi<br />
R8 was another preliminary step.<br />
Advantages of the improved<br />
component<br />
“The main advantages of the newly<br />
implemented component are, above all,<br />
a weight reduction of 19 % and a 50 %<br />
increase in strength (R p0.2<br />
) compared to<br />
the component with the same functions<br />
used in the previous model,” explains<br />
Markus Heim. This was achieved by<br />
means of a weight-optimized design<br />
with thinner walls using the new highstrength<br />
and easy-flowing alloy in combination<br />
with a T6 heat treatment. On the<br />
The fully automated die-casting cell<br />
with dosing furnace, extractor robot<br />
and punch.<br />
Each casting is already provided with an individual<br />
data matrix code in the die-casting<br />
cell, enabling access to all the data regarding<br />
its process and quality parameters.<br />
one hand, this requires a complex<br />
stress-optimized wall thickness and rib<br />
distribution and, on the other hand,<br />
complicated optimization of the casting<br />
process and the molding technology<br />
CASTING PLANT & TECHNOLOGY 2/<strong>2019</strong> 17
COMPONENT DEVELOPMENT<br />
employed. The latter point involves the<br />
use of mold components with cooling<br />
channels that are produced in a 3-D printing<br />
process, and optimization of the<br />
ejectors regarding their number, diameter<br />
and positioning. This permitted a<br />
15 % reduction in the average wall thickness,<br />
which is only between 1.8 mm and<br />
2.0 mm in large areas of the component.<br />
Verified high-tech process chain<br />
“A striking feature of the production<br />
process is the complete traceability of<br />
the entire quality history for each individual<br />
casting,” reveals Axel Schmidt.<br />
This starts as early as the casting cell,<br />
where the component is laser-printed<br />
with an individual data matrix code<br />
after casting and deburring. This allows<br />
allocation of all quality-relevant process<br />
and test parameters throughout the<br />
entire process chain right up to the<br />
packaging and dispatch data. The code<br />
is scanned-in before each process step<br />
and inspected for completeness and<br />
matching of the specifications. The next<br />
processing step is only approved when<br />
the computer confirms that everything<br />
is in order so far. After the stamping<br />
process, the components pass through<br />
the above-mentioned T6 heat treatment<br />
on special racks that prevent any<br />
warpage, and are then polished and<br />
aligned. All further transport processes<br />
also take place in special racks, which<br />
also carry a data matrix code. The code<br />
of each individual casting is scanned<br />
during insertion and allocated to the<br />
rack. This complete traceability concept<br />
was implemented internationally with<br />
Audi – also in the DGS works in the<br />
Czech Republic and China.<br />
Robot processing cells<br />
“Processing takes place in two completely<br />
enclosed robot cells that are mirrored<br />
for reasons of redundancy,” says<br />
Heim. The components are pushed into<br />
the cells on the racks before being individually<br />
removed by the robot. First there<br />
is an inspection, during which the data<br />
matrix code is scanned-in and the correct<br />
heat-treatment state is checked with the<br />
help of a special eddy current process to<br />
determine electrical conductivity. Threaded<br />
inserts are placed in the tap holes<br />
after mechanical processing. Whereby<br />
appropriate inspection processes ensure<br />
that the slugs required for screwing-in<br />
are also reliably removed after the subsequent<br />
breaking off. This prevents any<br />
delay, which could cause difficulties<br />
during subsequent processes. After completion<br />
of the processing, the robot<br />
A view of the fully automatic<br />
cell for processing<br />
the casting, including<br />
insertion of the thread<br />
inserts.<br />
After the casting has<br />
been put down, the<br />
screen delivers all the<br />
data for assessing component<br />
warpage.<br />
18
Left: Fully automatic<br />
plant for heat-treating<br />
the deburred castings.<br />
On the left, the<br />
special racks that are<br />
designed to prevent<br />
warpage.<br />
Right: The castings in<br />
their racks pass<br />
through numerous<br />
pools in the wash and<br />
passivation plant.<br />
Electric driverless<br />
forklifts automatically<br />
transport full and<br />
empty racks for the<br />
castings from station<br />
to station.<br />
replaces the part on the rack – which is<br />
then transported to a fully automatic<br />
wash and passivation line with successive<br />
baths. Some internal transport within the<br />
foundry is carried out by electric driverless<br />
forklifts that drive backwards and<br />
forwards between the stations without<br />
collisions. The final step of the process<br />
chain is the packaging line where employees<br />
manually insert the parts into<br />
Audi-specific transport con tainers. Scanning<br />
of the data matrix code again ensures<br />
that only ‘in order’ parts are<br />
dispatched, and that each part is precisely<br />
allocated to its transport container.<br />
Swiss reliability during<br />
the development and supply<br />
of castings<br />
“This project underlines that we can<br />
ensure a reliable worldwide supply of<br />
high-tech die-cast components for our<br />
partners in the automotive industry,”<br />
sums up Axel Schmidt. In addition to the<br />
jointly implemented component and process<br />
development, DGS also largely designed<br />
and implemented the necessary<br />
plant technology itself. One thus proves<br />
oneself to be a competent partner who<br />
can be trusted with the highly reliable<br />
supply of high-tech components on a<br />
worldwide basis. Naturally, DGS also had<br />
to, and could, take into account the price<br />
expectations of the customer during this<br />
project, otherwise the collaboration<br />
would never have been possible. He is, of<br />
course, particularly pleased that this<br />
development was awarded first prize in<br />
the die-casting competition at Euroguss<br />
trade fair in 2018. This is also an incentive<br />
for proving that European companies<br />
still have plenty of inventive spirit<br />
and technical perfection for successfully<br />
asserting themselves in worldwide competition<br />
on demanding markets.<br />
www.dgs-druckguss.com<br />
CASTING PLANT & TECHNOLOGY 2/<strong>2019</strong> 19
ENGINEERING OF FOUNDRY PLANTS<br />
Photo: Hörmann Rawema<br />
Foundry planning<br />
undergoing digital change<br />
Digital factory planning is an increasingly<br />
important element for modern<br />
production companies.<br />
The demands made of products, processes and technologies are constantly rising in this<br />
era of digitalization, and require companies to adopt a sustainable orientation of all<br />
units to create a modern factory. The focus is on a general acceleration and parallelization<br />
of processes in planning, implementation and operation.<br />
Axel Edlich, Robin Freitag, Frances Barchmann, Chemnitz<br />
The varied and high demands<br />
made of today’s products and<br />
their industrial production inevitably<br />
necessitate structural changes<br />
with in factories.<br />
Megatrends change the factory<br />
of the future<br />
A few so-called megatrends have<br />
developed regarding how to create the<br />
required conditions in foundry and corporate<br />
planning.<br />
Digitalization along the value stream<br />
Systems such as sensors, robots and<br />
virtual reality can become useful<br />
(Figure 1) as a result of digitalization.<br />
These technical solutions can be combined<br />
and holistically represented in a<br />
model with the help of a digital twin.<br />
The networking of systems in the wake<br />
of digitalization allows, for example,<br />
the constant monitoring of machine<br />
and plant states, and the provision of<br />
warnings before potential breakdowns.<br />
Robots are working increasingly<br />
closely with humans within production<br />
or logistics – increasing quality<br />
and efficiency.<br />
Light construction<br />
Light construction is one of the key<br />
technologies of the future because, in<br />
addition to weighing less, such products<br />
also offer improved properties. In this<br />
connection, the conservation of resources<br />
and material has an important status.<br />
So not only are the materials undergoing<br />
constant further development,<br />
20
ut also the design, joining and production<br />
technologies.<br />
Automation<br />
Production processes and information<br />
technologies interact closely with one<br />
another nowadays. Products, production<br />
plants and operating materials can<br />
be networked with one another due to<br />
their automation – and thus react more<br />
intelligently and faster to improve processes<br />
in real time. This reduces operating<br />
costs and counteracts the shortage<br />
of skilled labor. Lean, flexible and sustainable<br />
production is vital for<br />
safeguard ing future competitiveness.<br />
New business models and market<br />
participants<br />
The digital transformation is subjecting<br />
companies to more rapid change than<br />
has ever been experienced before.<br />
Whereby rigid corporate structures<br />
must be disrupted and transformed.<br />
New business models should be universally<br />
coordinated and aligned upon the<br />
digital changes, while reflecting a company’s<br />
core competences.<br />
In the global information age, information<br />
and knowledge are available<br />
rapidly anywhere and at any time.<br />
There is thus global competition for<br />
Figure 1: The use of a digital twin can<br />
support the work of employees in factories<br />
with, for example, sensors, robots<br />
and virtual reality.<br />
products, processes and services, as well<br />
as resources. Individual customer-specific<br />
products are increasingly forcing<br />
themselves into the spotlight, so it is<br />
important to create innovative products<br />
and services. But factors such as the<br />
alignment of the entire value creation<br />
chain, and the search for cooperating<br />
partners and additional competences,<br />
involve important fundamental decisions<br />
that must be made.<br />
Changes in skills profiles and<br />
personnel requirements<br />
The requirements for personnel and<br />
their skill sets will change a lot in<br />
future. Companies increasingly require<br />
skilled employees with a comprehensive<br />
knowledge of IT, as well as an awareness<br />
of process, production and logistical<br />
structures. Specialists will be needed<br />
with a deep understanding of planning<br />
and the implementation of complex<br />
interactive data-based work processes.<br />
The digital transformation will therefore<br />
not only lead to employees being<br />
supported by machines and robots, but<br />
also to new jobs with new qualification<br />
requirements.<br />
All these megatrends have profound<br />
effects on the development of products<br />
and processes within the factory. The<br />
upcoming changes should be exploited<br />
as opportunities to fundamentally<br />
shape the company of the future and<br />
thus meet new paradigms. From the<br />
factory planner’s point-of-view, the<br />
planning methods will remain the same<br />
– only the content, structures and markets<br />
will be different. Whereby the<br />
objective will be to plan the factory of<br />
the future in such a way that it operates<br />
highly efficiently, its products and processes<br />
are self-monitoring, short delivery<br />
times can be guaranteed, and production<br />
waste and rejects are reduced<br />
to a minimum.<br />
Digitalized processes in the<br />
foundry<br />
Corporate processes are continuously<br />
being permeated by the technologies of<br />
digitalization – so the cycles of production<br />
factories are also changing. New<br />
technologies must be integrated into<br />
the company’s own solutions in order to<br />
cope with this change. Whereby the<br />
existing value creation chain, and all<br />
CASTING PLANT & TECHNOLOGY 2/<strong>2019</strong> 21
ENGINEERING OF FOUNDRY PLANTS<br />
Figure 2: The simulation model of a<br />
production plant.<br />
the processes within it, must be expanded<br />
and adapted to achieve the goal of<br />
an efficient factory. In this regard, it is<br />
also vital to constantly keep up with all<br />
the new and relevant developments<br />
and, if necessary, implement them. The<br />
following tendencies can be seen in<br />
individual corporate processes:<br />
Sales<br />
The age of digitalization opens up new<br />
possibilities for sales because the focus<br />
is on individual customer requirements.<br />
Central data management plays a major<br />
role in core tasks – such as the registration<br />
of enquiries, costing, and the preparation<br />
of offers – by centrally and<br />
digitally administrating all the important<br />
customer and product data, and<br />
enabling consistency of the information.<br />
It is therefore possible to offer<br />
customers tailor-made solutions whose<br />
details are adapted to their specific<br />
needs. The use of product lifecycle<br />
management systems also provides<br />
further advantages.<br />
Material procurement and storage<br />
The monitoring of warehouse capacities<br />
and stocks, as well as the associated<br />
material planning and procurement,<br />
can change fundamentally and also<br />
affects supplier management. Material<br />
lists can, for example, be generated<br />
using existing 3-D models of the components<br />
and variants. An intelligent and<br />
automated stock monitoring and ordering<br />
system shortens delivery times and<br />
procurement processes. Fully automated<br />
storage systems and automated guided<br />
vehicles are increasingly being<br />
used, saving space and time – and thus<br />
costs.<br />
Production<br />
Digitalization enables the automation<br />
of many production processes, the comprehensive<br />
tracing of products, and the<br />
allocation of certain post-processing<br />
steps. More and more processes will in<br />
future be monitored and evaluated via<br />
sensor or radio-frequency identification<br />
(RFID). Errors and defects can be more<br />
rapidly detected and corrected by<br />
means of monitoring during production,<br />
with the aim of minimizing production<br />
problems and downtimes.<br />
Interdisciplinary processes<br />
In addition to the core processes of molding,<br />
melting, casting and machining,<br />
there are interdisciplinary processes<br />
that are positively influenced by digitalization.<br />
These include, for example,<br />
pattern construction and storage, an<br />
area that is subject to high customer<br />
requirements. Storage and transport<br />
can be supported by automated logistics<br />
and intelligent component tracing<br />
in order to increase process transparency.<br />
The state-oriented maintenance<br />
(condition monitoring) of plant technology<br />
is also being used increasingly in<br />
foundries. It is very important to be<br />
able to predict a breakdown before it<br />
happens – damaging the plant technology<br />
and causing long downtimes – particularly<br />
with automated processes and<br />
interlinked plants.<br />
Work preparation<br />
Pattern designs are created during work<br />
preparation, followed by material<br />
requirements planning and, on this<br />
basis, process planning including<br />
machine utilization. The use of new<br />
technologies such as planning in 3-D,<br />
simulation tools (Figure 2) and virtual<br />
reality allows process and value stream<br />
analyses to be carried out before initial<br />
operation. This enables an examination<br />
of work stations and their safety, as<br />
well as comprehensive planning and<br />
documentation, to be carried out<br />
before implementation.<br />
Figure 3: A three-phase model is<br />
used in factory planning.<br />
22
Potential solutions in foundry<br />
planning<br />
Different demands are made along the<br />
value creation chain at all the above-mentioned<br />
areas. When these are<br />
implemented, a linear unstructured production<br />
flow can be transformed into a<br />
circular networked production site. This<br />
makes new demands of factory and<br />
production planning, to which factory<br />
planners such as Hörmann Rawema<br />
Engineering & Consulting GmbH react<br />
by using a variety of tools and methods<br />
(Figure 3). 3D laser scanning, material<br />
flow simulation and virtual commissioning<br />
are used here, for example. As a<br />
result, a variety of planning variants can<br />
be examined in a short time, significantly<br />
increasing planning security. For<br />
customers this means a considerably<br />
lower level of risk in implementation,<br />
and the prevention of potential follow-up<br />
costs. In addition, the visualization<br />
and dynamic representation of processes<br />
increase the comprehensibility<br />
and transparency of the planning solution.<br />
The methodical, structured and<br />
holistic approach towards planning is<br />
intended to ensure the provision of<br />
solutions that are as sustainable and<br />
efficient as possible, and that meet the<br />
aspirations of future factories in the<br />
context of global competition.<br />
Void in casting, after<br />
machining, seen with a<br />
Hawkeye Pro Hardy 7”<br />
Inspection Solutions...<br />
80 different borescopes, and 20 years<br />
experience helping you select<br />
just the right one!<br />
Sand visible with a<br />
Hawkeye Pro Slim<br />
12” Rigid Borescope<br />
Flash as seen with a<br />
Hawkeye V2<br />
Video Borescope<br />
High-quality rigid, flexible and video borescopes,<br />
at far lower prices than comparable instruments!<br />
The factory planner for<br />
manufacturing industries<br />
Hörmann Rawema Engineering &<br />
Consulting GmbH is a member of the<br />
Hörmann Group. As innovative producer-neutral<br />
factory planners, 50<br />
engineers and technicians concentrate<br />
on providing specialist technical planning<br />
in industry, focusing on production<br />
technologies and logistics. Hörmann<br />
Rawema Engineering & Consulting supports<br />
customers from the most varied of<br />
sectors (such as forming, casting and<br />
recycling technology; the automotive<br />
sector; mechanical engineering or logistics),<br />
offering consulting, planning,<br />
process optimization and project<br />
management.<br />
www.hoermann-rawema.de<br />
www.der-fabrikplaner.de<br />
Robin Freitag, Project Manager,<br />
Axel Edlich, Manager, Forming and<br />
Cast ing Technology Competence Centre,<br />
Frances Barchmann, Project Engineer,<br />
Hörmann Rawema Engineering &<br />
Consulting GmbH, Chemnitz<br />
We stock over 80 models of rigid, flexible and video<br />
borescopes, and accessories. Hawkeyes deliver detailed<br />
images of sand, voids, flash, surface-finish irregularities,<br />
and numerous other defects that can affect the quality of<br />
a wide range of mission-critical castings.<br />
gradientlens.com 800.536.0790 Made in USA
CLEANING; FETTLING & FINISHING<br />
Photo: Thomas Topf<br />
Successful technological partnership: Leopold Haubenberger,<br />
Sales and Project Manager at Rösler (left) with<br />
Martin Gaugusch, Project Coordinator Vibratory Finishing<br />
at Schösswender, beside the pilot plant for vibratory<br />
finishing.<br />
Fire and flame for<br />
metal casting and processing<br />
An innovative metal foundry in Austria’s northernmost town shows how mass finishing<br />
can contribute towards achieving the customer’s desired surface quality in the 21st century<br />
– with a lot of initiative and a committed technology partner.<br />
Gerhard Franz Roth, Vienna, Austria<br />
The Litschau town council in the<br />
Gmünd district is famous for<br />
being the northernmost town in<br />
Austria and a forest health resort. The<br />
path between tottering rocks, thick<br />
forest and idyllic hills leads directly to<br />
S. Schösswender Werke. The company<br />
has proved that one can make the transition<br />
from down-to-earth metal casters<br />
to internationally renowned cast-iron<br />
technicians for aluminum and copper<br />
alloys. Founded in 1959 – specializing in<br />
metal door fittings, locking plates and<br />
door handles – the company and its 68<br />
employees has developed into a specialist<br />
for industrial castings and cast components<br />
for the rail vehicle industry<br />
worldwide. This is demonstrated by its<br />
well-known customers and its orders<br />
from the USA, Asia and Europe.<br />
From small quantities to serial<br />
production<br />
Schösswender expanded gradually:<br />
after concentrating on small quantities,<br />
the first CNC machine was purchased<br />
twenty years ago. Today the<br />
24
foundry is busy working with eight<br />
CNC machines and ten melting furnaces.<br />
Mass finishing technology is used<br />
to deburr castings, initially with two<br />
plants from Tauss that have been successfully<br />
doing their job for fifty years<br />
– and are still doing it. “We commissioned<br />
Rösler Oberflächentechnik to<br />
modernise the plants,” Martin Gaugusch,<br />
Project Coordinator Mass<br />
Finishing at Schösswender, recalls his<br />
first contact with the subsequent technology<br />
partner. “And then we gave<br />
Rösler an order to build us a completely<br />
new mass finishing plant for aluminum<br />
alloy castings.” And this resulted<br />
in a very innovative, but also<br />
personal, business relationship between<br />
Martin Gaugusch and Leopold<br />
Haubenberger, his Sales and Project<br />
Manager at the Rösler branch in<br />
Vienna. The specialists in surface technology<br />
are headquartered in Bad Staffelstein<br />
in Franconia, Germany.<br />
It’s simply better when it’s<br />
personal<br />
How did the cooperation come about?<br />
Leopold Haubenberger puts it down to<br />
competence: “We are the number one<br />
worldwide for mass finishing plants.”<br />
Robert Halke, Team Leader for Marketing<br />
at Rösler, adds: “Customers are sold<br />
a process, not the machine.” And<br />
Schösswender was looking for just such<br />
a partner for the new mass finishing<br />
plant, stresses Gaugusch: “At Rösler<br />
everything comes from a single source,<br />
they buil d whatever the customer<br />
needs.” In addition to examining the<br />
existing plants, Rösler set up a complete<br />
pilot plant for Schösswender that met<br />
its customer’s personal wishes. “The<br />
results of the trial clinched the sale,”<br />
Halke sums up the strong argument in<br />
favor of cooperation. “One always has<br />
to test vibratory finishing in reality, not<br />
just on paper.” They also offer a wide<br />
range of grinding bodies, the be all and<br />
end all of vibratory finishing. “We have<br />
a portfolio that includes 8,000 grinding<br />
bodies,” says Haubenberger, not<br />
without pride, “and we find what fits<br />
economically and technologically.” Even<br />
the peripheral equipment and conveyor<br />
belts come from Rösler. They have been<br />
developing grinding bodies for more<br />
Greater than the sum of its parts<br />
There is only one company fully focused on metal: from melting and dosing machines, green<br />
sand foundry and die-casting technology, right through to surface preparation and finishing<br />
equipment. And only Norican Group can support all this technology with upgrade and parts<br />
packages, maintenance and support, and leading Industry 4.0 solutions.<br />
Connect with Norican Group at GIFA.<br />
Düsseldorf, 25 - 29 June <strong>2019</strong>, Hall 11, Stand A74-78<br />
+40,000<br />
machines in operation<br />
...in over<br />
10,000<br />
customer plants<br />
...covering<br />
...served by<br />
~2,700 +100 countries<br />
Norican employees<br />
...from<br />
50<br />
Norican locations<br />
1<br />
Together, as<br />
company<br />
...delivering<br />
4 brand technologies<br />
We are Norican: DISA | Italpresse Gauss | StrikoWestofen | Wheelabrator<br />
www.noricangroup.com
CLEANING; FETTLING & FINISHING<br />
than 60 years, with geometries that<br />
now range from 0.5 to 60 mm.<br />
From the trial to the purchase<br />
The new R425/4600DA continuous-flow<br />
vibratory grinding plant from Rösler has<br />
been in successful operation at Schösswender<br />
since January 2018 in a completely<br />
enclosed sound-insulating cabin,<br />
with care and maintenance constantly<br />
available from the producer. “The two<br />
companies have been working together<br />
for twelve years now,” Gaugusch praises<br />
S. SCHÖSSWENDER WERKE<br />
As one of Austria’s leading metal casting<br />
and processing companies,<br />
Schösswender sets worldwide standards<br />
for high-quality cast-iron<br />
developments and solutions – from<br />
batch size one to mass production;<br />
through design consulting, casting<br />
simulation, the hardening of aluminum,<br />
and X-ray inspection; to prototype<br />
construction and surface treatment.<br />
The company, based in<br />
Litschau, focuses on the rail sector,<br />
responsible for more than half of the<br />
company’s sales.<br />
www.schoesswender-metallguss.at<br />
the partner company. “Leopold Haubenberger<br />
comes round within a few days of<br />
receiving a message.” Further development<br />
of the consumables, as well as the<br />
water supply and output, are the main<br />
topics that are discussed again and<br />
again. “The plant must be well set up in<br />
process terms – then it covers the costs,”<br />
adds Robert Halke from a marketing<br />
point-of-view. “The topic of waste water<br />
is also important, both ecologically and<br />
economically.” In continuous flow systems,<br />
after CNC machining vibratory<br />
finishing frees the cast aluminum components<br />
of burrs and structures that are<br />
not part of the component. “The plant is<br />
currently running in one-shift operation<br />
but we could use two-shift operation,”<br />
Gaugusch stresses the capacity reserves.<br />
“Due to intensive automation, one<br />
employee is sufficient to operate the<br />
plant.” Only slots and the insides of<br />
threads are still manually deburred, but<br />
all the exterior burrs are removed<br />
mechanically with the grinding bodies.<br />
Worldwide focus on railway<br />
vehicles<br />
The R425/4600DA is fully automatic: the<br />
parts are inserted and, depending on<br />
the casting material, vibratory finishing<br />
takes place using plastic grinding<br />
Including regular support from the producer:<br />
the new continuous flow vibratory<br />
grinding plant has been in successful<br />
operation in a completely enclosed<br />
sound-insulating cabin at Schösswender<br />
since January 2018.<br />
Even the peripheral equipment and conveyor<br />
belts come from Rösler. They have been<br />
developing grinding bodies for more than 60<br />
years, with geometries that now range from<br />
0.5 to 60 mm.<br />
bodies, water is added containing a<br />
chemical treatment agent (so-called<br />
‘compound’), and the finished parts are<br />
transported out again dry and deburred.<br />
“In the sound-absorbing enclosure,<br />
26
the mass finishing system can deburr<br />
components of all shapes with sizes of<br />
up to 20 x 20 x 20 cm³, mainly made of<br />
aluminum alloys for railway vehicles,”<br />
Leopold Haubenberger emphasizes the<br />
flexibility benefits of the plant from<br />
Rösler. Above all mountings and bearing<br />
blocks for doors, but also parts for<br />
brakes and emergency actuation on<br />
trains and trams, are deburred here.<br />
“For instance for subway trains in many<br />
major cities worldwide,” Martin Gaugusch<br />
provides an example. The optimum<br />
process adjustment can be seen<br />
from the consumption of grinding<br />
bodies: “We only need 75 kg of grinding<br />
bodies per month now,” calculates<br />
Patrick Eggenberger, responsible for the<br />
vibratory finishing machine. “The parameters<br />
are individually set for each<br />
deburring process, for example bearing<br />
components on train doors.” Whereby<br />
the throughput time and input cycle of<br />
the parts are determined, i.e. how long<br />
the machine should run for. The throughput<br />
time varies between 10 and 20<br />
minutes, depending on the part. “For<br />
small parts, for example, input can also<br />
take place every few seconds,” Martin<br />
Gaugusch knows from experience.<br />
“Parts that are still visible after installation<br />
need a longer throughput time<br />
because they require more accurate<br />
deburring – for aesthetic reasons and a<br />
nice feel.”<br />
<br />
www.rosler.com<br />
After vibratory finishing of the aluminum<br />
components, the grinding bodies are<br />
transported upwards again via a conveyor<br />
channel and returned to the circulatory<br />
system.<br />
EXCLUSIVELY FOR READERS OF<br />
CASTING PLANT AND TECHNOLOGY<br />
Secure your fair ticket at a preferential price<br />
And this is how it works:<br />
5 At www.metec.com, head for the ticket shop in the visitor area.<br />
5 Register as a trade visitor.<br />
5 Enter the voucher code and click on „Add to cart“. Your discounted<br />
ticket at a price of Euro 35.00 instead of Euro 45.00<br />
will thus be put in the cart automatically.<br />
Voucher code 0000 042g 327f<br />
WE ARE LOOKING FORWARD TO SEEING YOU.<br />
VISIT US IN HALL 4, BOOTH G38.<br />
CASTING PLANT & TECHNOLOGY 2/<strong>2019</strong> 27
SIMULATION<br />
Photo: GTP Schäfer/Flow Science Deutschland<br />
Course of the burning process in exothermic feeder sleeves. Comparison between reality and the simulation.<br />
Realistic simulation of the combustion<br />
of exothermic feeders<br />
Exothermic feeder sleeves are increasingly being used in iron casting and are now the<br />
most commonly used type of feeder system. Simulations have hitherto only described<br />
exothermic feeders using simple analogous models that use the release of a defined<br />
energy over the entire volume. The companies Flow Science and GTP Schäfer have jointly<br />
developed a model that enables realistic simulation of the combustion of exothermic<br />
feeder systems. With the help of casting trials it has been possible to show that the deviations<br />
of the simulation results from the test results lie within the range of measurement<br />
accuracy.<br />
Malte Leonhard, Matthias Todte, Rottenburg, and Jörg Schäfer, Grevenbroich<br />
The use of feeders is generally unavoidable<br />
in gravity casting, but<br />
often represents a conflict for<br />
designers: the dimensions and number<br />
of feeders should be large enough to<br />
reliably prevent shrinkage cavities, but<br />
the feeder weight should be minimized<br />
to reduce energy and processing costs,<br />
as well as recycled material, as far as<br />
possible. The rising complexity of castings<br />
further increases development<br />
demands. Highly exothermic feeder systems<br />
have become increasingly important<br />
because they are more space-saving<br />
and efficient than traditional natural<br />
sand feeders.<br />
Feeder systems can be divided into<br />
two types: with insulating or exothermic<br />
feeder materials. In the case of insulation<br />
feeders, the solidification time of<br />
the melt in the feeder is lengthened by<br />
means of a feeder body whose thermal<br />
conductivity is considerably lower than<br />
that of the mold material. The melt thus<br />
remains liquid for longer and is available<br />
to the junction to compensate for<br />
shrinkage. Reduction of the size of the<br />
feeder can be achieved by using an exothermic<br />
cap material. As a result, there<br />
is an exothermic reaction of the cap<br />
material when the ignition temperature<br />
has been exceeded. The melt is warmed<br />
by the heat that is released and thus<br />
remains liquid for longer [1]. Exothermic<br />
feeder systems are therefore very efficient,<br />
and can supply the casting with<br />
liquid melt for longer with less volume.<br />
Whereas the simple formulae of geometric<br />
modulus calculations were used<br />
in the past, casters can now exploit casting<br />
simulations that can predict the<br />
thermic module and solidification mor-<br />
28
State of the art<br />
Exothermic feeder materials contain,<br />
among other things, aluminum and iron<br />
oxide. These react strongly exothermically<br />
because the aluminum has a higher<br />
affinity to oxygen than iron does.<br />
Aluminum oxide and iron are produced<br />
when iron oxide and aluminum react,<br />
generating a lot of heat (aluminothermy,<br />
or the Goldschmidt Process).<br />
Fe 2<br />
O 3<br />
+ 2Al → Al 2<br />
O 3<br />
+ 2Fe (1)<br />
Figure 1: Test setup to examine the burning behavior of exothermic feeder materials.<br />
Photo: GTP Schäfer/Flow Science Deutschland<br />
phology, among other things, and are<br />
thus helpful for feeder design. Simulations<br />
are an effective tool for finding<br />
efficient solutions, particularly regarding<br />
the selection and dimensioning of<br />
appropriate feeders. The growing<br />
demands made of digital design and the<br />
use of casting simulations have been<br />
addressed again and again, and the<br />
methods have meanwhile become a<br />
fixed component of most development<br />
processes in foundries. The numerical<br />
description of natural and insulating<br />
feeder systems is accurate, and<br />
dependable results can be achieved. The<br />
models for using exothermic feeder systems,<br />
however, have so far been unable<br />
to predict processes accurately enough,<br />
leading to over-dimensioning of the<br />
feeder in practice – and thus to uneconomical<br />
solutions. The motivation to<br />
depict the burning behavior of exothermic<br />
feeder materials as accurately as<br />
possible in simulation programs is high<br />
because exothermic feeders are now the<br />
most commonly used feeder variant in<br />
iron casting. The model developed<br />
jointly by GTP Schäfer, Grevenbroich,<br />
and Flow Science, Rottenburg (both<br />
Germany) now makes it possible, for the<br />
first time, to accurately describe the burning<br />
behavior of the feeder cap, i.e. the<br />
chronological and spatial course of the<br />
release of energy in the cap.<br />
This reaction only gets going above a<br />
particular ignition temperature – which<br />
the feeder material reaches as a result<br />
of the melt filling the mold. In most<br />
feeder systems the exothermic material<br />
burns radially outwards from within the<br />
feeder. The burning time depends on<br />
the feeder sleeve geometry and the<br />
specific combustion speed of the material.<br />
There is constant development of<br />
further variants and combinations of<br />
feeders, for example hybrid feeders like<br />
the Eco series from GTP Schäfer, consisting<br />
of a combination of insulating and<br />
exothermic materials.<br />
Exothermic feeder systems have up<br />
to now only been simply depicted in<br />
simulation programs, with the entire<br />
sleeve volume being assigned an energy<br />
content that is constantly released<br />
during a defined burning time. It is<br />
already difficult enough for users to<br />
determine the energy content, but it is<br />
even more difficult to define a burning<br />
time because, as previously explained,<br />
this depends on the feeder geometry.<br />
This simplified form of modelling can<br />
potentially lead to major deviations of<br />
the simulation results from reality – and<br />
consequently to over-dimensioning of<br />
the feeder. The fact that the material<br />
properties also vary in the unburnt and<br />
burnt states has hitherto not been<br />
taken into account in foundry simulations.<br />
Photos: Flow Science Deutschland<br />
Figure 2: Simulation of the burning behavior of exothermic test bodies.<br />
CASTING PLANT & TECHNOLOGY 2/<strong>2019</strong> 29
SIMULATION<br />
Figure 3: Positions of the thermocouples in the real casting trials.<br />
Temperature [°C]<br />
1200<br />
1000<br />
800<br />
600<br />
400<br />
200<br />
Standard deviaon TE1<br />
Standard deviaon TE2<br />
Standard deviaon TE3<br />
Standard deviaon TE4<br />
Standard deviaon TE5<br />
Simulaon TE1<br />
Simulaon TE2<br />
Simulaon TE3<br />
Simulaon TE4<br />
Simulaon TE5<br />
0<br />
350 550 750 950 1150 1350 1550 1750 1950 2150<br />
Time, s<br />
Figure 4: Comparison of measured temperature curves with the simulation results.<br />
Figure 5: Representation of the burning behavior of exothermic feeder sleeves: Left: Start of<br />
the exothermic reaction, Middle: Combustion of the exothermic feeder, Right: ‘Afterglow’ of<br />
the feeder material.<br />
Experimental investigations<br />
GTP Schäfer started by carrying out<br />
measurements of the thermo-physical<br />
properties in order to obtain data on<br />
exothermic feeder materials. Whereby a<br />
sample with a defined energy per time<br />
unit was heated and the material properties<br />
continuously determined. One<br />
difficulty during these measurements<br />
was the high level of dynamism caused<br />
by the exothermic reaction. As soon as<br />
the ignition temperature is reached, the<br />
material burns up autonomously – and<br />
no longer follows the temperature of<br />
the measurement system. So it was only<br />
possible to reliably determine the material<br />
properties in the unburnt state<br />
during these experiments. Therefore<br />
the combustion behavior and material<br />
properties during and after burning<br />
were initially inaccurate or unknown.<br />
So it was necessary to examine the<br />
burning behavior with more precision.<br />
For this purpose, an experimental setup<br />
similar to that in the German Foundrymen’s<br />
Association (VDG) Specification<br />
P81 on the testing of exothermic materials<br />
[2] was selected (Figure 1). Two test<br />
pieces (D = 50 mm, H = 50 mm) were<br />
made for the experiment using exothermic<br />
material, and one was placed on<br />
top of the other. The lower test piece<br />
was ignited and the burning behavior<br />
of the two samples investigated. This<br />
setup allowed good observation and<br />
understanding of the progress of the<br />
combustion process. Then the chronological<br />
and spatial course of the burning<br />
behavior was compared with the simulation<br />
model (Figure 2).<br />
Real casting trials in furan sand<br />
molds were then carried out after the<br />
investigation of the burning behavior<br />
of the test bodies. The effort required<br />
for these experiments turned out to be<br />
considerably greater than anticipated.<br />
But it was shown that the burning<br />
behavior of feeders within sand molds<br />
differs substantially from that in ambient<br />
air. This difference can be explained<br />
by the fact that only a limited amount<br />
of oxygen is available for the exothermic<br />
material within a sand mold. During<br />
the casting experiments, exothermic<br />
feeder sleeve in a furan sand mold were<br />
filled with melt and the temperature<br />
curves were determined. For this purpose,<br />
separate thermocouples were<br />
positioned in the exothermic material,<br />
the molding sand, and the melt in order<br />
to determine the temperature changes.<br />
One thermocouple was placed within<br />
the melt in the feeder. Two more were<br />
located in the sleeve, and two in the<br />
30
Figure 6: GTP Schäfer feeder database within the Flow 3D Cast software.<br />
molding sand (Figure 3). The sleeve was<br />
filled with molten GJS 400 iron for the<br />
measurements.<br />
The measurements were carried out<br />
repeatedly to provide high reproducibility<br />
and temperature curves that would<br />
be as conclusive as possible. The tests<br />
were repeated with three different cap<br />
sizes with a thermal module of 0.95 cm,<br />
GIFA <strong>2019</strong><br />
Hall 16<br />
Booth F11<br />
- NEW MONITORING SYSTEM<br />
THOR V4.0<br />
CASTING PLANT & TECHNOLOGY 2/<strong>2019</strong> 31
SIMULATION<br />
Figure 7: Casting clusters with different feeder sleeves: left: Insulating feeder material,<br />
right: Exothermic feeder material.<br />
1.5 cm and 2.7 cm. They were intended<br />
to include as many different factors as<br />
possible (e.g. differing measurement<br />
positions, materials or densities) and the<br />
simulation model was examined with a<br />
large geometric bandwidth. Standard<br />
deviations were calculated from the<br />
recorded temperature curves and compared<br />
with the measurement values of<br />
the simulation results (Figure 4).<br />
It was possible to show that the<br />
temperature curves of the simulation<br />
results mostly lay within the calculated<br />
standard deviations. It could therefore<br />
be derived that the deviations of the<br />
temperature curves between the simulation<br />
and the experimental results<br />
were within the measurement accuracies<br />
and, furthermore, that the implemented<br />
model of exothermic feeder<br />
sleeve behavior was accurately represented.<br />
The new model<br />
The Flow 3D Cast model is intended to<br />
reflect reality as precisely as possible.<br />
Therefore the feeder is not treated as a<br />
complete exothermic volume that<br />
behaves identically everywhere, but<br />
instead each cell of the computational<br />
grid is treated separately. The exothermic<br />
reaction is triggered as soon as a<br />
grid cell of the feeder reaches the ignition<br />
temperature, and heat is released<br />
according to a calculated function. The<br />
temperature of the cells increases and<br />
heats the neighboring cells as in a<br />
chain reaction, so that they also reach<br />
their ignition temperature. In this way<br />
a realistic combustion behavior is<br />
shown within the feeder sleeve. After<br />
the exothermic reaction has taken<br />
place, the properties of the feeder<br />
material change and there is then an<br />
insulating effect. The material properties<br />
of the feeder sleeves for each cell<br />
were also adapted to the level of combustion<br />
in the simulation. Thus the<br />
thermo-physical properties of the<br />
unburnt and burnt material vary,<br />
having a further effect on temperature<br />
distribution during the combustion of<br />
the exothermic material. The different<br />
stages of the combustion process are<br />
shown in Figure 5. The feeder insert<br />
starts the exothermic reaction when<br />
the melt has raised the material to<br />
above the ignition temperature. Then<br />
the material burns autonomously and<br />
releases heat that warms the melt.<br />
After the exothermic reaction has finished,<br />
there is an ‘afterglow’ as a result<br />
of the insulating properties. The high<br />
temperature of the exothermic reaction<br />
can therefore be retained, and the<br />
feeder can supply liquid melt to the<br />
casting for a long time.<br />
A major added value compared to<br />
previous definitions is that a material,<br />
all of whose parameters are known, can<br />
be laid down in the database with<br />
general validity. Unknown values, such<br />
as the burning time of the entire sleeve,<br />
come up autonomously during simulation.<br />
A feeder database from GTP Schäfer<br />
has been implemented in the Flow 3D<br />
Cast software (Figure 6). The database<br />
contains feeder data on exothermic and<br />
insulating feeder sleeves. It is possible<br />
to select and position a suitable feeder<br />
with just a few mouse-clicks. The correct<br />
feeder for a casting can therefore be<br />
selected rapidly and efficiently on the<br />
basis of a modulus calculation, and its<br />
effect examined.<br />
Validation<br />
A case study in which an insulating feeder<br />
is used is shown in Figure 7. A<br />
porosity analysis shows that the feeder<br />
can only just compensate for the shrinkage<br />
of the component. As a result of<br />
the high solidification time, insulating<br />
feeders cannot maintain the melt at a<br />
high temperature sufficiently long, and<br />
a critical secondary cavity forms in the<br />
gate area. Although the defect is located<br />
within the feeder it is nevertheless<br />
very unstable, as fluctuations in the<br />
process parameters (such as the chemical<br />
composition of the casting material,<br />
or the casting temperature) lead to<br />
shifts in the porosities in the component<br />
and thus to rejection. There are<br />
therefore some defective components<br />
despite the process parameters being<br />
within the tolerances. Exothermic feeders<br />
were selected and dimensioned<br />
using the new simulation model in<br />
order to find a robust and efficient<br />
solution. It can clearly be seen that<br />
there is now no formation of<br />
secondary cavities, i.e. there is sufficient<br />
liquid melt available to compactly<br />
fill the component before solidification<br />
is complete. As a result of the more<br />
efficient mode of action a smaller feeder<br />
body – with 30 % less melt volume<br />
– can be selected, preventing unnecessary<br />
recycling material. It was possible<br />
to achieve a robust solution with the<br />
feeders used as they do not behave<br />
sensitively to process-related fluctuations,<br />
and reliably prevent imperfections<br />
within the component.<br />
Summary<br />
Simulations always merely approach<br />
reality. The models used for the simulation<br />
should, however, be capable of sufficiently<br />
accurately describing the physical<br />
effects of importance to the<br />
objectives of the simulation so that the<br />
correct conclusions for practical use can<br />
be drawn from the simulation results.<br />
This is now the case, for the first time,<br />
for the design of exothermic feeders<br />
thanks to the new model that has been<br />
implemented in Flow 3D Cast. The new<br />
approach of comparing temperature<br />
measurement values from casting trials<br />
with simulation results ensures a high<br />
level of accuracy for the use of exothermic<br />
feeders. www.gtp-schaefer.com<br />
<br />
www.flow3d.de<br />
Malte Leonhard & Dr. Matthias Todte,<br />
Flow Science Deutschland GmbH, Rottenburg,<br />
and Jörg Schäfer, GTP Schäfer<br />
GmbH, Grevenbroich.<br />
Literature:<br />
www.cpt-international.com<br />
32
CASTING<br />
Special<br />
GIFA <strong>2019</strong><br />
Part 2: Opportunities provided by new<br />
technologies<br />
GIFA<br />
Special<br />
Photo: Fotolia
SPECIAL: GIFA <strong>2019</strong>/INTERVIEW<br />
34
“Germany is a trade fair country with a high<br />
level of quality. GIFA is high quality because<br />
all foundry decision-makers attend!“<br />
It‘s always about products: GIFA-President<br />
Heinz Nelissen, Managing Director of<br />
Vesuvius, in the local company in Borken<br />
“A veritable explosion<br />
of innovations”<br />
Heinz Nelissen is expecting a “veritable explosion of innovations” at the trade-fair<br />
quartet of GIFA, METEC, THERMPROCESS and NEWCAST (GMTN, also known as the<br />
Bright World of Metals). The President of GIFA and NEWCAST explains in an interview<br />
what makes the trade fair so enormously valuable for exhibitors and visitors, and how<br />
the sector can attract new talent.<br />
Photo: BDG/Vogt<br />
Let’s start with what is, in effect, a<br />
never-ending topical subject: what is<br />
your view about Brexit?<br />
One has to say that the elemental anxiety<br />
that economic life as we know it<br />
will collapse completely is long past.<br />
This will evidently not happen. How<br />
Brexit is developing, however, is<br />
annoying because it is simply unnerving.<br />
One would have wished to have<br />
had a concrete and dependable date.<br />
The twenty-ninth of March has passed<br />
– and now? I hope for a reasonable<br />
settlement and the prevention of<br />
customs duties.<br />
Big plans: Heinz Nelissen (middle) shows <strong>CPT</strong> editors Robert Piterek (left) and Martin Vogt,<br />
what is planned for the trade fair quartet.<br />
At least GIFA has a concrete date at<br />
the end of June. What can you tell us<br />
about it?<br />
GIFA and NEWCAST seamlessly pick up<br />
from their successful predecessors in<br />
2015. Both trade fairs are superbly<br />
booked up; the world market leaders<br />
are represented, as are the SMEs. Overall,<br />
at all four trade fairs of the quartet,<br />
the Bright World of Metals will<br />
again break the threshold of 2,000<br />
exhibitors: more than 2,100 companies<br />
are expected from all over the world.<br />
The international range of visitors is<br />
correspondingly large: we expect – not<br />
least thanks to our extensive marketing<br />
measures – about 78,000 visitors<br />
from Europe and overseas.<br />
The economy is deteriorating. Could it<br />
affect this year’s GIFA?<br />
The exhibitors have largely completed<br />
their planning for the trade fair, the<br />
stands have been firmly booked, and<br />
the innovations intended for GIFA have<br />
been developed and made suitable for<br />
trade fair presentation in collaboration<br />
with the customers. We come from two<br />
years of excellent production figures,<br />
from a clear boom phase. We had several<br />
thriving years in the non-ferrous<br />
and iron foundries. Now we face a<br />
Photos: Martin Scheidtmann, BDG/Vogt<br />
CASTING PLANT & TECHNOLOGY 2/<strong>2019</strong> 35
SPECIAL: GIFA <strong>2019</strong>/INTERVIEW<br />
sharp dip in the economy. This will not<br />
blow us casters away. Particularly now<br />
it is important to ask oneself the question:<br />
how do I, as a businessman,<br />
handle the coming years? And GIFA is<br />
coming at just the right time.<br />
In what way?<br />
There is a lot going on regarding digitalization.<br />
The high tempo of digitalization<br />
opens up new possibilities for<br />
automating production. Plant constructors<br />
are exploiting this and will be presenting<br />
innovative solutions. So GIFA is<br />
focusing on this, among other things.<br />
The trade fair offers a wide-ranging<br />
framework program of specialist conferences.<br />
How important are they?<br />
The specialist framework program,<br />
with its range of international congresses,<br />
symposia, forums and special<br />
events, really is extremely important<br />
and, indeed, is unique worldwide.<br />
Whether additive manufacturing,<br />
metallurgical topics, trends in the steel<br />
sector, current aspects in thermo-processing<br />
technology, or innovations in<br />
energy and resource efficiency – the<br />
entire spectrum of foundry technology,<br />
cast products, metallurgy and thermo-processing<br />
technology is covered.<br />
Some specialist events are having their<br />
premieres, for example the two-day<br />
expert forum on thermal energy storage,<br />
the specialist conference on 3-D<br />
printing with metals, and the special<br />
events on additive manufacturing or<br />
digitalization & climate protection.<br />
Digitalization is quite advanced and<br />
will lead to innovative solutions that<br />
will be presented at the trade fair.<br />
Numerous congresses and presentations<br />
help build up networks and shed<br />
light on innovative topics.<br />
Is the impression misleading, or has<br />
the automotive sector – with its e-vehicles<br />
– really made the most progress<br />
since our conversation last autumn?<br />
That is my perception too. There really<br />
has been some movement in the field<br />
of e-mobility in recent months. One<br />
has to differentiate between commercial<br />
vehicles and cars. Regarding commercial<br />
vehicles, particularly for overland<br />
transport, work is still continuing<br />
with conventional fuel-powered drives,<br />
while package services in the cities,<br />
inner city traffic, and buses are increasingly<br />
electrically powered.<br />
What you describe is a market that is<br />
becoming even more differentiated.<br />
What does this mean for the sector?<br />
I think it is good that cast products will<br />
continue to be used for all types of drives<br />
and vehicles. Both conventional<br />
vehicles and e-vehicles need cast products,<br />
but very different ones of<br />
course. And the casters have to position<br />
themselves appropriately for this.<br />
And so parts are being constructed,<br />
particularly in the non-ferrous field –<br />
battery housings and structural elements,<br />
for example.<br />
And what can a caster of classic engine<br />
components do now?<br />
They will have to think about what to<br />
do, because the machine park may not<br />
be suitable for e-mobility components.<br />
Then one could either concentrate<br />
more on the commercial vehicle seg-<br />
36
ment – which will continue to produce trucks with combustion<br />
engines – or look for new sectors. Specialization will be<br />
decisive.<br />
Back to GIFA. The Bright World of Metals, as well as the<br />
German Foundry Association (BDG) and the German Foundrymen’s<br />
Association (VDG), have announced a youth program<br />
like that at the last trade fair. The ‘Gießzeit’ (Casting<br />
Time) competition is about casting a clock face. Many youth<br />
groups are again expected to attend the trade fair. What’s<br />
your take on this?<br />
We know how much the future of foundry work depends on<br />
finding new personnel –one of the priorities in the BDG’s<br />
Mission Statement – and the Association has already organized<br />
a lot of events. The VDG has even defined finding new<br />
personnel as a statutory task. So a significant proportion of<br />
the trade fair presence of both the BDG and VDG is dedicated<br />
to this topic. Numerous groups of schoolkids will get to<br />
know about careers in foundries during their visit to the<br />
trade fair, and especially at the school foundry in Hall 13.<br />
Castings will also be produced here. This is a strong argument<br />
for the career, because the casting produced gives a<br />
tangible meaning to the whole thing. Groups of schoolchildren<br />
can mold and cast the clock face of a classroom clock this<br />
year. The best ones will receive prizes. Such a youth program<br />
is indispensable for demonstrating the profession’s fascination.<br />
And the competition spurs the young people on. I can<br />
only encourage the foundries to participate in the excursions<br />
to the trade fair in Düsseldorf organized by the<br />
Metals4You Initiative. After all, we are expecting more than<br />
500 potential new foundrymen and -women every day!<br />
What youth recruitment activities of your own can we<br />
expect at the trade fair?<br />
We are using part of our stand as a Career Corner this year.<br />
It will be run by our personnel department and trainees,<br />
outlining to some extent the aim of the stand concept. The<br />
personnel department will provide relevant information on<br />
the site and the company, while the trainees will present<br />
interesting projects from their training. We are also inviting<br />
our partner school and participating in Metals4You. The<br />
concept is designed to win over young people for technical<br />
professions before they take their final decisions on their<br />
career orientation.<br />
What do you think GIFA contributes to the sector?<br />
The entire range of casting products will be presented at<br />
NEWCAST. METEC and THERMPROZESS are the leading international<br />
trade fairs for metallurgy and thermo-processing<br />
technology. GIFA takes place in its proven 4-year cycle. So<br />
the world’s best will be presented there. The major suppliers<br />
have coordinated their development programs to this trade<br />
fair rhythm, so we can expect a veritable explosion of innovations.<br />
SEIATSU<br />
FlASk MOUldING MACHINES<br />
ANd MOUldING lINES<br />
The requirements placed on cast parts, in particular dimen sional<br />
accuracy, repeatability, surface quality and the constantly high<br />
demands on the mouldability of the most complex models<br />
requires the maximum in mould quality, which is facilitated by<br />
the different HWS moulding processes. The following methods<br />
are available:<br />
• SEIATSU airflow squeeze moulding process<br />
• SEIATSU.plus (model-side pressing)<br />
• SEIATSU aeration technology ACE<br />
Available moulding machines that utilise the aforementioned<br />
processes include not only fully-automatic high performance<br />
moulding machines, but also simple series moulding machines<br />
for manual and semi-manual operation.<br />
25.-29.06.<strong>2019</strong><br />
Visit us!<br />
Hall 17, Booth B20/d20<br />
What is your closing message for the sector?<br />
Germany is a trade fair country – and with an extremely<br />
high level of quality in worldwide comparisons. GIFA is also<br />
high-quality, because all the decision-makers in the global<br />
foundry sector are at GIFA. This is an excellent opportunity<br />
for networking, also internationally. The proportion of international<br />
visitors is nowhere near as high at comparable specialist<br />
trade fairs as it is in Düsseldorf. Make sure you don’t<br />
miss this opportunity! <br />
www.gifa.com<br />
HEINRICH WAGNER SINTO<br />
Maschinenfabrik GmbH<br />
SINTOKOGIO GROUP<br />
www.sinto.com<br />
Bahnhofstr.101 · 57334 Bad Laasphe, Germany<br />
Phone +49 2752 / 907 0 · Fax +49 2752 / 907 280<br />
CASTING PLANT & TECHNOLOGY 2/<strong>2019</strong><br />
www.wagner-sinto.de<br />
37
SPECIAL: GIFA <strong>2019</strong><br />
Photo: Andreas Bednareck<br />
Foundries use scrap as a raw material for production<br />
Tremendous potential – environmental,<br />
economic and social<br />
sustainability in foundries<br />
Foundries are one of the best examples of resource efficiency and sustainability.<br />
Because castings implement the recycling concept almost completely.<br />
Carina Hendricks, Kleve<br />
Sustainability and resource<br />
efficiency<br />
This energy-intensive industry has, in<br />
addition, always had a strong commitment<br />
to the objectives of sustainability<br />
and resource efficiency. Innovations in<br />
the product and process simulation field<br />
make it possible nowadays to manufacture<br />
cast components that satisfy the<br />
requirements of economically and<br />
environmentally sound lightweight<br />
structure production. Cesare Troglio,<br />
Technology and Innovation Division<br />
Manager at the German Foundry Association<br />
(BDG), thinks that there are<br />
numerous significant ways to take<br />
account of the demands for sustainability<br />
and resource minimization in product<br />
development, in production and<br />
during product life: “Cast components<br />
embody the basic idea behind the eco-<br />
Metals label outstandingly well.”<br />
With the latter, the four Düsseldorf<br />
metallurgy trade fairs GIFA, METEC,<br />
THERMPROCESS and NEWCAST emphasize<br />
the importance of resource and<br />
energy efficiency, climate protection<br />
and innovative processes and products.<br />
Exhibitors who present products, solutions<br />
or process operations relating to at<br />
least one of these areas will once again<br />
be highlighted particularly strongly<br />
in Düsseldorf in June <strong>2019</strong> (25th to<br />
29th of June). “The USP of the four<br />
trade fairs GIFA, METEC, THERMPRO-<br />
CESS and NEWCAST is their coverage of<br />
almost the entire market – so sustainability<br />
is an issue that cannot be left<br />
out”, explains Friedrich Kehrer, Global<br />
Portfolio Director Metals and Flow<br />
Technology at Messe Düsseldorf GmbH.<br />
Visitors to the event can inform them-<br />
38
selves about what the exhibitors are<br />
presenting at ecoMetals via a special<br />
brochure about this subject as well as<br />
online. There will also be guided tours<br />
– known as ecoTrails – specifically for all<br />
visitors who are interested.<br />
A number of exhibitors are allowed<br />
to display the ecoMetals label in this<br />
context. Because many foundries are<br />
investing in manufacturing processes,<br />
are increasing vertical integration and<br />
are reducing resource consumption on<br />
an ongoing basis. One major feature of<br />
this process – and the driving force<br />
behind it – is the digitization of production.<br />
This is creating enormous opportunities<br />
not only to improve one’s competitive<br />
position but also to implement<br />
sustainable strategies.<br />
Saving time and money<br />
Simulation and, to an increasing extent,<br />
3-D printing are making it possible not<br />
merely to produce highly complex parts<br />
but also to replace the energy-/resource-intensive<br />
and time-consuming trial<br />
and error method. The Leipzig team<br />
from GF Casting Solutions came to this<br />
conclusion too. Series production of sand<br />
cores by 3-D printing started here in the<br />
summer of 2018. “The foundations for<br />
With the 3-D printer, the Leipzig location has become an innovation center.<br />
this were laid as long as two years ago”,<br />
reports Matthias Heinrich, Director of GF<br />
Casting Solutions Leipzig GmbH.<br />
As part of the corporate strategy for<br />
2<strong>02</strong>0, the Leipzig location succeeded in<br />
persuading the division management to<br />
invest in a 3-D series printer for sand<br />
cores by presenting a convincing concept.<br />
As a result, the location now acts<br />
not just as an innovation centre and<br />
supplier of prototypes to all the other<br />
foundries in the GF Division; it also<br />
manufactures in series. Heinrich explains:<br />
“The cold-curing phenolic 3-D<br />
printer in Leipzig is the second of its<br />
kind in Germany and the first one in the<br />
Photo: GF Casting Solutions<br />
RUDOLF UHLEN GmbH<br />
Face protection for every application<br />
Rudolf Uhlen GmbH is a manufacturer of personal protective<br />
equipment (PPE) for face protection. Especially for the steel<br />
and foundry industry we provide special solutions in the field<br />
of IR-protection. We produce:<br />
Ÿ Visor Carriers<br />
Ÿ Gold-coated visors<br />
Ÿ Mesh visors<br />
Ÿ PC-visors<br />
Ÿ Bochumer Brillen<br />
Ÿ Flip-up goggles<br />
PRODUCTIVITY IN 3D<br />
3D- PRINTED CAST SOLUTIONS<br />
Düsseldorf <strong>2019</strong><br />
Hall 10 - C18<br />
RUDOLF UHLEN GmbH Telefon: (<strong>02</strong>129) 1444<br />
Am Höfgen 13 - 42781 Haan Telefax: (<strong>02</strong>129) 59980<br />
www.aschua-uhlen.de info@aschua-uhlen.de<br />
CREATE COMPLEX COMPONENTS<br />
Innovative 3D printing solutions for sand &<br />
investment casting using common casting<br />
materials, where all light and heavy metals that<br />
are castable and of series-production quality<br />
can be processed. Complex geometric shapes<br />
can be created with speed and precision.<br />
voxeljet AG<br />
Paul-Lenz-Straße 1a 86316 Friedberg Germany<br />
info@ voxeljet.com<br />
CASTING PLANT & TECHNOLOGY 2/<strong>2019</strong> 39
FILTECH<br />
October 22 – 24, <strong>2019</strong><br />
Cologne – Germany<br />
The Filtration Event<br />
www.Filtech.de<br />
SPECIAL: GIFA <strong>2019</strong><br />
ASK Chemicals uses<br />
its own technical<br />
center to increase<br />
the effectiveness of<br />
the products, thus<br />
providing users with<br />
added value such as:<br />
lower resource consumption.<br />
Photo: ASK Chemicals<br />
Platform<br />
for your<br />
success<br />
Targeted<br />
Solutions<br />
for the<br />
Casting<br />
Industry<br />
Your Contact: Suzanne Abetz<br />
E-mail: info@filtech.de<br />
40<br />
Phone: +49 (0)2132 93 57 60<br />
country that is being used in series production”.<br />
The advantages for customers: considerable<br />
time and money is saved in the<br />
production of prototypes and spare<br />
parts. In addition to this, process reliability<br />
is increased by the elimination of<br />
core assembly, while designers are enthusiastic<br />
about the unlimited design<br />
potential. There are many different<br />
application areas for the castings, which<br />
weigh between 100 and 1,000 kg. Heinrich<br />
lists them: “They are used in lorries,<br />
construction equipment, agriculture and<br />
forestry management, solar farms and<br />
wind turbines, rolling stock, machine<br />
manufacturing in general and hydraulics,<br />
our new product segment”. BDG<br />
executive Troglio summarizes: “Such<br />
technologies can help to save a great<br />
deal of time and energy when tooling is<br />
being built, particularly where prototypes<br />
and short series are concerned”.<br />
Products with greater impact<br />
The progress that has been made with<br />
organic bonding agents and the use of<br />
inorganic bonding agents of the kind<br />
developed by, for example, foundry<br />
supplier ASK Chemicals, Hilden, Germany,<br />
also improves environmental performance.<br />
Dr. Jens Müller, Research and<br />
Development Manager at ASK Chemicals,<br />
explains: “We are focusing primarily<br />
on increasing the impact of our products<br />
and on generating added value<br />
for our customers, as – for example –<br />
material input can be decreased and<br />
the total potential emissions can be<br />
reduced as a consequence.”<br />
The company has succeeded in<br />
developing the first unmarked phenolic<br />
resin in the world for the cold box process<br />
in iron casting. A hazardous product<br />
is therefore not needed in this process.<br />
Müller adds: “There are other<br />
advantages apart from the environmental<br />
benefits: The particularly high reactivity<br />
of this new system makes it possible<br />
to reduce bonding agent and catalyst<br />
volumes in many cases.”<br />
Inorganic bonding systems are becoming<br />
increasingly important in aluminium<br />
casting. ASK Chemicals is also<br />
noticing greater awareness of sustainable<br />
products. Müller thinks that “this is<br />
certainly driven by the fact that the<br />
general conditions in Europe particularly<br />
have become more demanding<br />
due to the implementation of relevant<br />
regulations” and is therefore delighted<br />
that product developments for protection<br />
of the environment are successful<br />
above and beyond this too: “Initially,<br />
no-one really believed that the technology<br />
of inorganic bonding systems<br />
would replace conventional processes.<br />
This may be attributable to the fact that<br />
there are technological and economic<br />
benefits in addition to the original<br />
environmental aspect. Now it is an established<br />
feature in lightweight metal<br />
permanent casting.“<br />
Environmental, economic, social Sustainability<br />
cannot, after all, always be<br />
considered solely at the environmental<br />
level. Elke Radtke, who is responsible<br />
for environmental protection as well as<br />
occupational health and safety at BDG,<br />
also thinks that “sustainability involves<br />
economic and social action too. As an<br />
association, we provide information<br />
about the regulations that affect the<br />
foundry industry. Our observation is<br />
that legal regulations designed to protect<br />
the environment often fail in particular<br />
to take social and economic factors<br />
into sufficient account. Wherever<br />
appropriate, small and medium-sized<br />
companies especially also need to be<br />
able to adapt processes and take advantage<br />
of new technologies. Because operations<br />
that are not economic lead in<br />
the long run to failure, which in turn<br />
jeopardizes jobs. That is not sustainable<br />
at the social level.”
HÜTTENTAG <strong>2019</strong><br />
Get-Together of the steel industry<br />
Thursday, 7 November <strong>2019</strong><br />
Motto: STEEL — Traditional material and hightech<br />
product<br />
FOLLOW<br />
TRADITION,<br />
SHAPE THE<br />
FUTURE!<br />
09:00 — 17:30<br />
Lecture programme with company exhibition<br />
starting 18:00 "Hüttenabend"<br />
Get-Together and Networking<br />
Venue: Messe Essen<br />
Messeplatz 1 | 45131 Essen, Germany<br />
Information at:<br />
www.homeofsteel.de/huettentag<br />
Organizer:<br />
SAVE THE DATE<br />
7 NOVEMBER <strong>2019</strong><br />
Photo: worldsteel / Gregor Schläger
Halls<br />
10–13<br />
15–17<br />
Halls<br />
3 + 4 + 5<br />
Halls<br />
9 + 10<br />
Halls<br />
13 + 14<br />
P1<br />
P2<br />
Entrance North<br />
MERKUR<br />
SPIEL-ARENA<br />
5<br />
9<br />
3<br />
4<br />
17<br />
CCD Süd<br />
CCD Ost/CCD Süd<br />
Congresses<br />
Entrance South II/<br />
GIFA MAIN TOPICS<br />
Grafik: messe-duesseldorf<br />
42<br />
Entrance South<br />
Hall 13<br />
Additive manufacturing<br />
Hall 12<br />
Gating and feeding<br />
Hall 15-17<br />
Moulding, pattern and core ma
The Bright World of Metals<br />
With the international claim "The Bright World of Metals"<br />
Messe Düsseldorf summarizes the technology fair quartet of<br />
GIFA, METEC, THERMPROCESS and NEWCAST. Thanks to<br />
the largest number of exhibitors and hall space, GIFA will be<br />
the focal point of the fair. GIFA and NEWCAST meet in Hall 13.<br />
Visit us in Hall 13, Stand C30!<br />
CASTING<br />
PLANT AND TECHNOLOGY<br />
INTERNATIONAL<br />
10<br />
18<br />
11<br />
12<br />
13<br />
16<br />
15<br />
14<br />
CCD Ost<br />
Hall 17<br />
P4<br />
Entrance East<br />
king<br />
Hall 12<br />
Chemical materials for foundries<br />
Hall 11<br />
Die casting and peripheral equipment<br />
Hall 15-17<br />
Foundry machines and foundry plants<br />
CASTING PLANT & TECHNOLOGY 2/<strong>2019</strong> 43
SPECIAL: GIFA <strong>2019</strong><br />
MAGMA<br />
“The Digital Foundry Process”<br />
At GIFA <strong>2019</strong>, MAGMA<br />
GmbH presents a new<br />
generation of trendsetting<br />
solutions for virtual<br />
casting, tooling<br />
and process optimization.<br />
In Hall 12 at Booth A19/20, the<br />
company will demonstrate how Autonomous<br />
Engineering is replacing conventional<br />
casting process simulation. Magmasoft<br />
autonomous engineering<br />
supports casting design, robust process<br />
layout and optimized casting evaluation<br />
even before the first part is produced.<br />
By making use of the fully integrated<br />
capabilities of virtual Design of Experiments<br />
and genetic optimization, Magmasoft<br />
easily and reliably finds the best<br />
solutions – from the first casting design<br />
to improvement of a running production<br />
layout. As a world premiere, visitors<br />
will experience Autonomous Engineering<br />
live in 4-D in a captivating<br />
Holo-Theater performance.<br />
MAGMA has been developing powerful<br />
solutions for digitizing foundry<br />
processes for over 30 years. With the<br />
“Virtual Core Shooting Machine”, the<br />
company showcases an innovative<br />
Industry 4.0 application together with<br />
leading industry partners. A direct coupling<br />
between process simulation, core<br />
box design, molding material and core<br />
shooting machine enables the real-time<br />
optimization of the complete core<br />
shooting system for the first time.<br />
With the “Virtual Die Casting Die”,<br />
MAGMA demonstrates how to simultaneously<br />
realize and reliably evaluate a<br />
robust tooling design and an optimized<br />
production window simultaneously within<br />
the shortest possible time for high<br />
pressure die casting processes. Moreover,<br />
the company introduces numerous<br />
new capabilities for virtual optimization<br />
of all casting processes and alloys, heat<br />
treatment and the complete core production<br />
process. In cooperation with<br />
leading partners from the supplying<br />
industry, new developments for digitizing<br />
molding materials and for quantitative<br />
prediction of core distortion,<br />
degradation behavior of binder systems<br />
and core gas related defects during the<br />
casting process will be presented.<br />
Through new solutions, accessing databases<br />
for feeding system components in<br />
Magmasoft has become even easier.<br />
MAGMAinteract, the new and innovative<br />
visualization program for<br />
Foundrymen’s Playground 2.0 – playfully learn how to optimize casting designs with the<br />
MAGMAacademy<br />
Magma soft results, supports communication<br />
internally within a company as<br />
well as a fast exchange of information<br />
with both customers and suppliers.<br />
Using real castings as examples,<br />
MAGMA will interactively show how<br />
easy it is to use information from<br />
Magma soft with MAGMAinteract. The<br />
MAGMAacademy will present its offering<br />
of comprehensive opportunities<br />
for further education for foundrymen,<br />
casting designers and casting consumers.<br />
The “Foundrymen’s Playground<br />
2.0” will playfully show how easy it is<br />
to virtually optimize casting designs<br />
today. Here, visitors can interactively<br />
run their own simulations in a virtual<br />
test field, while simultaneously pursuing<br />
different quality and cost-related<br />
objectives. As part of a competition<br />
against Magmasoft autonomous<br />
engineering, visitors will lay out their<br />
own casting on an electronic drawing<br />
board in just a few minutes.<br />
MAGMA will also be presenting its<br />
innovative solutions for process optimization<br />
in continuous and ingot casting<br />
at its own booth at METEC (Hall 4,<br />
Stand E 29). Here, too, the company will<br />
showcase state-of-the-art solutions for<br />
the virtual optimization of conflicting<br />
objectives regarding productivity and<br />
quality, as well as for establishing<br />
robust process windows.<br />
With its Student Camp, MAGMA<br />
once more shows its commitment to<br />
recruiting young professionals for the<br />
foundry industry. The young visitors will<br />
be shown in a fun and playful manner<br />
how interesting and innovative the<br />
foundry world is.<br />
Be inspired by the fascinating world of<br />
“Magmasoft - The Digital Foundry Process”!<br />
Hall 12, Stand A19/20<br />
www.magmasoft.de/en<br />
Photo: Magma<br />
44
FOSECO<br />
Non ferrous melt shop<br />
Insural multi-part and<br />
highly insulating<br />
dosing furnace linings<br />
for aluminium foundries<br />
combine energy<br />
savings with long-service<br />
life and resistance to oxide<br />
build-up.<br />
The use of energy efficient dosing<br />
furnaces in aluminium foundries is seen<br />
by many as the best available technology<br />
today. Foseco is now able to supply<br />
a new multi-part and highly insulating<br />
lining made of Insural which is delivered<br />
ready to install. Installation can<br />
be achieved in 3 days with no ongoing<br />
hydrogen issues and due to a totally dry<br />
installation process no sintering of the<br />
lining is necessary. Energy saving can be<br />
as high as 17 %.<br />
Hall 12 – Stand A1 + A2<br />
www.foseco.com<br />
Insural dosing furance lining for aluminium foundries<br />
FOTOS AND GRAPHICS: FOSECO<br />
Competence in<br />
Shot Blast Technology<br />
We offer a complete service in surface preparation technology,<br />
not just as machine designers and manufacturers.<br />
Our emphasis is on providing reliable service on:<br />
• Wear and Spare Parts<br />
• Repair and (remote) maintenance<br />
• Inspection and process advice<br />
• Machine upgrades and performance<br />
enhancement<br />
• Upgraded used machines<br />
Please see us at GIFA,<br />
Düsseldorf, June 25-29,<br />
hall 16, stand A39<br />
AGTOS<br />
Gesellschaft für technische Oberflächensysteme mbH<br />
Gutenbergstraße 14 · D-48282 Emsdetten<br />
Tel. +49(0)2572 96<strong>02</strong>6-0 · info@agtos.de<br />
www.agtos.com<br />
157-01/19-4c-GB<br />
CASTING PLANT & TECHNOLOGY 2/<strong>2019</strong> 45
SPECIAL: GIFA <strong>2019</strong><br />
Graphics: ASK Chemicals<br />
ASK CHEMICALS, MAGMA<br />
Material database for predicting binder<br />
decomposition and core gases<br />
Prediction of the time dependent<br />
penetration of core<br />
gases into the melt for different<br />
mold materials (left) and<br />
visualized defect risk within<br />
the casting<br />
MAGMA GmbH,<br />
Aachen, Germany ,specialist<br />
in virtual optimization<br />
of casting processes,<br />
and ASK<br />
Chemicals GmbH,<br />
Hilden (both Germany) one of the<br />
world‘s leading suppliers of foundry<br />
chemicals and consumables, are involved<br />
in a joint development project on binder<br />
decomposition in sand cores and associated<br />
gas formation. The aim is to provide<br />
the Magmasoft users with validated<br />
data on quantitative prediction of process-relevant<br />
effects for ASK products.<br />
With a new database, joint customers<br />
should be even better supported in the<br />
interpretation of the venting behavior<br />
of sand cores and the prediction of core<br />
gas-related casting defects.<br />
During the casting process, gases<br />
form and expand in cores and molds<br />
amongst others due to the decomposition<br />
of binder components and other<br />
volatile components. This is closely<br />
related to the basic sand binder mixture<br />
used and its compaction as well as its<br />
specific gas permeability. Different volumes<br />
of gas are produced at different<br />
times depending on the type and quantity<br />
of the volatile components, the<br />
thermal exposure and the respective<br />
decomposition behavior. Relatively high<br />
gas pressures at the interface to the<br />
melt can result in gas inclusions in the<br />
casting. In the cases of complex cores or<br />
even core packages, it is difficult in<br />
practice to determine if core gases are<br />
the cause of defects due to the numerous<br />
and diverse influencing factors.<br />
Newly developed simulation models<br />
in Magmasoft virtually depict gas formation,<br />
gas flow, and venting through core<br />
prints or the penetration into the melt.<br />
This functionality enables accurate prediction<br />
of the risk of defects due to gases<br />
from cores and molds. The availability of<br />
practical quantitative data already<br />
during simulation-based design of castings<br />
and cores therefore contributes significantly<br />
to the prevention of defects.<br />
ASK Chemicals and MAGMA have<br />
agreed on a collaboration as part of a<br />
development project to quantify the<br />
decomposition behavior and gas formation<br />
of different ASK binder systems. To<br />
this end, ASK Chemicals will carry out<br />
extensive research in their laboratories<br />
and Technical Center. Respective laws of<br />
decomposition behavior and resulting<br />
gas formation will be quantitatively<br />
determined for different binder systems<br />
and heating characteristics. Product-dependent<br />
kinetic models will be derived<br />
from these data that will make the formation<br />
of gas volumes and the resulting<br />
effects in Magmasoft quantitatively<br />
predictable.<br />
“For MAGMA, this project is an<br />
important step in the direction of<br />
‚robust process design for casting technology‘.<br />
The possibility of systematically<br />
avoiding core gas-related casting<br />
defects through quantitative consideration<br />
of different ASK binder systems<br />
already at the project planning stage<br />
represents a significant benefit for our<br />
customers,“ confirms Dr.-Ing. Jörg C.<br />
Sturm, Managing Director of MAGMA<br />
GmbH. “We are pleased to have gained<br />
a competent development partner with<br />
ASK Chemicals, who are interested in<br />
quantifying the behavior of their binder<br />
systems during casting.“<br />
“With the possibility to predict the<br />
behavior of our products with any core<br />
geometries during casting, we can support<br />
our customers in a more targeted<br />
manner. Comprehensive customer service<br />
therefore already has the highest<br />
priority for us in the planning stage of<br />
production processes,“ confirms Jörg<br />
Brotzki, Executive Vice President Europe<br />
at ASK Chemicals. „The user-friendly<br />
integration of our data in Magmasoft is<br />
thus decisive for the quality of planning.“<br />
Both partners will present the first<br />
results of the joint development project<br />
at the GIFA trade fair. The collaboration<br />
is designed for the long-term.<br />
Hall 12 Stand A19/20, Hall 4, Stand<br />
E29 and Hall 12, Stand A22<br />
www.ask-chemicals.com<br />
ww.magmasoft.de/en<br />
46
IMERYS<br />
Kersand and Durandal –<br />
the right alternative<br />
to chromite sands<br />
Two sands by Imerys, Paris, France, Kersand<br />
(AFS 60) & Durandal 60 (AFS 50) now used<br />
by sand casting foundries, appear to fulfill<br />
requirements in terms of refractoriness<br />
and thermal expansion, as well as in terms<br />
of supplying, and price condition stability.<br />
Those two products are similar, made with natural minerals<br />
with intrinsic high refractoriness and low thermal expansion.<br />
In addition, they are respirable crystalline silica free,<br />
and this over the several sand loops. The two sands are<br />
performing in all steel alloys, cast iron & copper alloy<br />
foundries and are compatible with all type of binding systems<br />
(organic & Inorganic), and furthermore, generate no<br />
low melting temperature point when mixed with silica<br />
sand.<br />
In a two years time period, chromite price FOB South<br />
Africa more than doubled from initial price. This clearly<br />
shows the high volatility of the chromite market price. This<br />
is not surprising, considering that all South African producers<br />
are primarily in the ferrochrome business producing<br />
metallurgical grade, with non-metallurgical grades being<br />
produced as a by-product.<br />
Special sand, even if used in lower volume compared to<br />
silica sand (for instance 10 %), can represent roughly 50 %<br />
of the expenses when it is compared to silica sand, resin<br />
and coating cost.<br />
New types of special sands were developed over the<br />
past 10 years, in order to improve the performance and<br />
compensate the high price volatility associated with the<br />
traditional chromite sand. Durandal D60 and Kersand are<br />
two natural mineral products which have been designed<br />
specifically to reduce casting defects and are respectively<br />
produced in South Africa & France. European sourcing is an<br />
important advantage considering logistic delivery delays as<br />
well as geopolitics stability situation.<br />
Chromite is heavy and will need 40 % more in weight<br />
to fill the same volume of cores compared to Kersand and<br />
Durandal 60. This is a key point regarding sand consumption.<br />
Indeed, loose bulk density is around 1,6 for Kersand<br />
and Durandal 60 whereas chromite sand lies at 2,7. This difference<br />
leads to immediate savings of 40 % of sand<br />
consumption for a constant volume of core produced.<br />
Both, Kersand and Durandal 60 show linear and low<br />
expansion with temperature compared to silica which exhibits<br />
the well know transition quartz a to b at about 573 °C.<br />
Anti-veining properties have been proven in numbers of<br />
foundries, in tough casting conditions for Kersand and<br />
Durandal 60 products. Iron casting has been performed<br />
with chromite, silica sand, Durandal 60, and a mix of<br />
Durandal 60 and silica sand cores with alkaline phenolic<br />
resin. Results show sand fusion defect when silica is used,<br />
and clean casting for chromite and Durandal 60. Furthermore,<br />
under those casting conditions it is demonstrated<br />
that a mix 50 %/50 % Durandal 60 and silica still leads to<br />
clean casting. Hall 12, Stand C 34<br />
<br />
www.imerys.com<br />
A CENTURY<br />
OF FOUNDRY<br />
EXPERIENCE<br />
GIFA <strong>2019</strong><br />
Hall 17 Booth 18A<br />
We have tailored solutions for your<br />
casting application – worldwide.<br />
Individual machines or complete systems.<br />
100 years of experience in vibrating technology.
SPECIAL: GIFA <strong>2019</strong><br />
Fotos and Graphics: Foseco<br />
Schematic setting of Foseco’s automated treatment technology Smartt.<br />
FOSECO<br />
Non ferrous metal treatment<br />
In recent years, a number<br />
of new features<br />
and technologies have<br />
been added to the<br />
Foseco FDU and MTS<br />
equipment range – the<br />
state of the art in technology for the<br />
automated treatment of an aluminium<br />
melt. Smartt software offers various<br />
programs for rotary degassing and the<br />
operator simply defines a melt quality<br />
after treatment. Smartt predicts the<br />
best treatment practice based on ambient<br />
conditions, melt temperature,<br />
rotor design and alloy composition.<br />
The treatment parameters are automatically<br />
transferred into the FDU<br />
MTS.<br />
In conjunction with innovative rotor<br />
designs Foseco guarantees a constant<br />
quality level and reliable results. Smartt<br />
not only controls degassing but<br />
together with forming gas any defined<br />
hydrogen level can be reached. A customised<br />
report system records all parameters.<br />
The chemical grain refiner in granulated<br />
form can be added through the<br />
automated Metal Treatment Station.<br />
This grain refiner offers many advantages<br />
such as improved melt fluidity<br />
during casting, reduced inclusion level<br />
and better mechanical properties. The<br />
dross remaining after the treatment is<br />
low in metal which additionally saves<br />
costs. The dosing equipment uses a gravimetric<br />
load cell to ensure highest<br />
dosing precision for best metallurgical<br />
results as well as repeatability and traceability.<br />
Shaft and rotor design are continuously<br />
improved to offer high efficiency<br />
in degassing at long service life.<br />
Hall 12, Stand A1 + A2<br />
www.foseco.com<br />
ASK CHEMICALS<br />
New binder-additive-coating system for compliance<br />
with formaldehyde limits<br />
German foundries are<br />
faced with the challenge<br />
of reducing<br />
formaldehyde emissions<br />
in the exhaust<br />
gas flow of their existing<br />
plants from 20 mg/m 3 (mass concentration)<br />
to 5 mg/m 3 by February<br />
2<strong>02</strong>0 at the latest. At GIFA <strong>2019</strong>, ASK<br />
Chemicals, Hilden, Germany, will present<br />
a specially designed binderadditive-coat<br />
ing package that allows<br />
foundries to comply with this new<br />
limit value without investing in additional<br />
secondary measures.<br />
ASK Chemicals has developed a new<br />
concept to provide foundries with a<br />
solution that greatly reduces the formaldehyde<br />
emissions by more than 70 %<br />
and does not require investment in<br />
washers or RTO (i.e. regenerative thermal<br />
oxidation).<br />
Analyses have shown that, in particular,<br />
the exhaust gas flow from coating<br />
drying furnaces plays a special role in<br />
the reduction of formaldehyde emissions.<br />
Cores produced in the cold box<br />
process have residual amounts of formaldehyde<br />
per se, but can, in conjunction<br />
with an additive and coating, emit additional<br />
formaldehyde, especially at temperatures<br />
around 150 °C, so that the<br />
limit of 5 mg/m 3 is easily exceeded.<br />
The newly developed low-formaldehyde<br />
system (LFS) from ASK Chemicals is<br />
a specially designed package of binder,<br />
additive and coating that, due to its<br />
design, develops only a very low basicload<br />
and thus a greatly reduced formal-<br />
48
dehyde potential. Furthermore, the<br />
new system absorbs released formaldehyde,<br />
so that the first users of this technology<br />
have the ability to undercut the<br />
5 mg/m 3 limit.<br />
“I am convinced that we offer users<br />
real added value with this new system.<br />
With the application of the Ecocure<br />
BLUE LFS binder, Miratec LFS coating<br />
and VEINO LFS additive tailored to the<br />
specific requirements, the LF system<br />
meets the legal formaldehyde limits<br />
with pinpoint accuracy. This is a clear<br />
advantage for foundries that do not<br />
want to invest in secondary equipment<br />
at this time“, says Frank Lenzen, Technical<br />
Product Manager at ASK Chemicals,<br />
summarizing the benefits of the new<br />
system.<br />
Hall 12, Stand A22<br />
www.ask-chemicals.com<br />
Low formaldehyde system<br />
Photo: ASK Chemicals<br />
WALTHER TROWAL<br />
Compact continuous feed shot blast machine<br />
for small, delicate castings<br />
At the GIFA <strong>2019</strong> exhibition<br />
Walther Trowal,<br />
Haan, Germany, introduces<br />
the compact<br />
troughed belt continuous<br />
shot blast system<br />
THM 300/1 to the public. This machine<br />
was especially developed for processing<br />
high volumes of small, delicate work<br />
pieces. The new design combines the<br />
small footprint of batch machines with<br />
the advantages of continuous feed<br />
operation and, thus, helps streamline<br />
and speed up the blast cleaning processes<br />
for small castings.<br />
Walther Trowal developed the THM<br />
300/1 specifically for small, delicate or<br />
thin-walled cast work pieces like, for<br />
example, aluminum or zinc die-castings<br />
with diagonal dimensions of between<br />
20 and 150 mm (about 0.8 to 6.0”).<br />
Work pieces can range from components<br />
for toys (model cars and trains),<br />
furniture parts, components for the<br />
computer industry and even small automotive<br />
parts.<br />
For the first time a shot blast<br />
machine for processing small work<br />
pieces is available with the footprint of<br />
a batch tumble belt machine that permits,<br />
however, continuous feed operation.<br />
Compared to the smallest THM<br />
machines supplied to date by Walther<br />
Trowal, the THM 300/1 design is considerably<br />
more compact: It requires an<br />
area of only 1,4 × 2,7 m (5 x 9 feet) and<br />
can, therefore, be easily integrated into<br />
existing production lines.<br />
With this new machine concept Walther<br />
Trowal meets the demands of customers<br />
in the foundry industry, who<br />
want to integrate their blast cleaning<br />
operations seamlessly into already existing<br />
manufacturing lines.<br />
The troughed belt work piece transport<br />
system Walther Trowal is utilizing<br />
for its continuous shot blast machines is<br />
gently moving the work pieces through<br />
the machine in a spiral motion. This<br />
ensures that all work piece surface<br />
areas are equally exposed to the blast<br />
media stream.<br />
Meik Seidler, sales manager at Walther<br />
Trowal, recognizes a significant<br />
trend towards continuous shot blasting:<br />
“The THM continuous feed machines<br />
with their unique troughed belt work<br />
piece transport system are more and<br />
more displacing the conventional batch<br />
tumble belt machines. Our customers<br />
integrate the THM systems into linked<br />
manufacturing processes allowing them<br />
to significantly simplify the work piece<br />
handling. The work pieces are continuously<br />
fed into the machine at preset<br />
cycle times determined by the actual<br />
production volume. Intermediate transport<br />
operations from one process stage<br />
to the next, as well as intermediate<br />
storage, are completely eliminated.”<br />
For the new blast system Walther<br />
Trowal is using the newly developed<br />
Photo: Walther Trowal<br />
The compact troughed belt continuous shot<br />
blast system THM 300/1 combines the small<br />
footprint of batch machines with the advantages<br />
of continuous feed operation<br />
WTY turbines with curved throwing<br />
blades. Compared to conventional blast<br />
turbines they generate a substantially<br />
higher throwing speed. This increases<br />
the impact energy of the blast media on<br />
the work pieces, which in turn helps<br />
reduce the processing times.<br />
A communication processor allows<br />
integrating the shot blasting operation<br />
into higher-level process controls.<br />
Explosion protected dust collectors<br />
ensure safe operation in line with prevailing<br />
explosion prevention standards.<br />
Hall 15, Stand D 15<br />
www.walther-trowal.de<br />
CASTING PLANT & TECHNOLOGY 2/<strong>2019</strong> 49
SPECIAL: GIFA <strong>2019</strong><br />
Graphics: Elkem<br />
ELKEM<br />
New foundry products takes casting<br />
iron to the next level<br />
Elkem’s stand at GIFA <strong>2019</strong>.<br />
From 25 until 29 June<br />
foundry products by<br />
Elkem, Oslo, Norway,<br />
will be present at GIFA,<br />
the world’s leading<br />
trade fair for casting<br />
technology, in Düsseldorf, Germany.<br />
There, Elkem will highlight its all-round<br />
competence to improve the metallurgical<br />
iron foundry process.<br />
GIFA is the international exhibition<br />
for foundry, foundry products and<br />
foundry technology and one of the<br />
world‘s largest and most comprehensive<br />
fairs of this kind. The focus of<br />
GIFA is on foundry equipment, raw<br />
materials and supplies, die-casting<br />
technology, foundry chemicals, suppliers<br />
and processing technology. This<br />
exhibition provides an excellent stage<br />
for Elkem Foundry Products to highlight<br />
its capabilities and most current<br />
innovations.<br />
Elkem Foundry Products has evolved<br />
to being an all-round solution provider<br />
for the metallurgy of iron foundries,<br />
supporting its customers globally with<br />
highly specialized alloys and excellent<br />
advice, which results in premium castings.<br />
Elkem innovates constantly and<br />
supports its customers with new, digital<br />
and automated solutions for analysis<br />
and alloy dosing.<br />
One of these solutions is the new<br />
Dynamic Dosing System, which enables<br />
foundries to precisely and automatically<br />
calculate, dose and position the treatment<br />
alloys into a dedicated pocket in<br />
the treatment ladle, for high quality<br />
ductile iron production.<br />
This customized equipment calculates<br />
the alloy addition rates based on the<br />
chemical analysis of the iron and other<br />
important parameters before and after<br />
each treatment. This self-learning<br />
equipment stabilizes and documents<br />
the treatment process, reduces cycle<br />
time, improves the iron quality and<br />
avoids human error.<br />
Another example of Elkem’s improvements<br />
is Elkem’s EPIC, an important<br />
process control tool based on thermal<br />
analysis of cast irons. The EPIC system<br />
provides real-time information on the<br />
condition of cast iron that can be used<br />
at any point in the liquid state production<br />
process. EPIC enables the foundry<br />
to acquire, record and evaluate a considerable<br />
amount of relevant data, which<br />
helps to improve the castings.<br />
Increased efficiency in alloy treatment<br />
not only results in increased process<br />
stability for Elkem’s customers, but<br />
it also leads to less consumption and<br />
emissions, supporting Elkem’s focus on<br />
sustainability.<br />
Hall 13, Stand C 50<br />
www.elkem.com<br />
50
BÜRKERT<br />
Modular platform for heating and cooling<br />
in metal processing<br />
Exact temperature control<br />
is a critical factor<br />
in many industrial<br />
metal and plastic processing<br />
sequences. In<br />
these scenarios, the<br />
requirements regarding temperature<br />
control can vary substantially depending<br />
on the production conditions.<br />
However, what is always required are<br />
solutions that guarantee one-hundredpercent<br />
repeatability wherever possible<br />
to ensure high product quality.<br />
They must also be simple to integrate<br />
and capable of being extended or converted<br />
as required.<br />
The modular temperature control<br />
platform developed by Bürkert Fluid<br />
Control Systems, Ingelfingen, Germany,<br />
which permits seamless adjustment to<br />
suit the most varied processes, was designed<br />
precisely with these requirements<br />
in mind. It is based on a broad range of<br />
electromotive and pneumatic valves as<br />
well as various measurement principles,<br />
e.g. for coolant flows (ultrasound and<br />
paddle wheel), air quantities (thermal<br />
sensor) as well as pressure and temperature.<br />
Supplied as a custom assembled<br />
complete system, the temperature control<br />
can then easily be integrated into<br />
the most diverse applications.<br />
Thanks to the modular design, individual<br />
valve clusters can easily be realized,<br />
as can multi-channel media distribution<br />
systems or complete media<br />
cabinets – always adapted to meet individual<br />
requirements. The user avoids<br />
the need to install piping between individual<br />
valves and dead spaces are<br />
reduced thanks to the compact design.<br />
In contrast to discrete assembly solutions,<br />
this allows the valve block to be<br />
placed close to the tool. Since the very<br />
compact design also reduces the<br />
heat-radiating surfaces, energy efficiency<br />
improves accordingly. The service-friendly<br />
structure also makes it<br />
easier to replace individual components.<br />
Orbital welding seams and<br />
high-temperature graphite seals that<br />
can also withstand extreme temperature<br />
differences guarantee leak-free<br />
operation.<br />
The Bürkert EDIP (Efficient Device<br />
Integration Platform) can be used to<br />
connect the temperature control to all<br />
standard bus systems; the wiring complexity<br />
is reduced, start-up and parameterization<br />
are simple. Depending on the<br />
tool and process, temperatures can be<br />
specified, the flow control set automatically,<br />
or a constant pressure maintained.<br />
Once parameters have been stored,<br />
they can be restored at any time. All<br />
things considered, the temperature control<br />
processes are reliably repeatable<br />
which boosts product quality and eliminates<br />
waste.<br />
Hall 10, Stand A74<br />
www.buerkert.de<br />
CASTING PLANT & TECHNOLOGY 2/<strong>2019</strong> 51
SPECIAL: GIFA <strong>2019</strong><br />
Photo: Gemco<br />
GEMCO<br />
Since 1978, complete foundry solutions<br />
Turnkey greenfield foundry realization in Mexico.<br />
GEMCO, Eindhoven,<br />
The Netherlands, a<br />
family owned business<br />
for more than 40 years<br />
with worldwide experience<br />
in the foundry<br />
industry offers foundry solutions for<br />
iron, steel, aluminum and all other castable<br />
metals.<br />
Topics as Industry 4.0, IOT, 3-D Printing,<br />
Automation, Sustainable development<br />
and Environmental impact are<br />
increasingly important. Quality equipment<br />
is important but only part of the<br />
solution. The added value that GEMCO<br />
provides is related to how this equipment<br />
is incorporated into the complete<br />
production facility, making sure no bottlenecks<br />
will occur, making sure that<br />
supporting systems are adequately designed;<br />
making sure that equipment<br />
maintenance can be carried out with<br />
easy access and in right conditions. And<br />
making sure the design is appreciated<br />
by the workers with regard to<br />
movement, lighting, noise and dust.<br />
Since last GIFA, GEMCO has completed<br />
turnkey foundry projects for among<br />
other, Linde (DE), Brembo (PL, MX),<br />
MFA (FR) and Rassini (MX). Projects concerned<br />
modernization and/or capacity<br />
expansion or new greenfield foundry<br />
realizations. Projects currently in course<br />
or close to completion include new<br />
foundries and modernization projects in<br />
North America, Europe, Russia and<br />
China.<br />
The company’s track record includes the<br />
realization of over 100 Greenfield and<br />
Brownfield foundries worldwide. An<br />
extensive global network of foundry<br />
experts covers all foundry disciplines<br />
and provides a complete range of services<br />
that encompass:<br />
> Design and Feasibilities of Greenfield<br />
& Brownfield Projects (for justification<br />
and development of investment)<br />
> Realization (turnkey), ranging from<br />
customized engineering projects to<br />
large multimillion investments<br />
> Strategic Information (Market information,<br />
Technical Due Diligence,<br />
M&A, Competitor Analysis)<br />
> Process Know-how (based in<br />
expert-network)<br />
Gemco is an independent company and<br />
makes use of the latest technology and<br />
engineering tools such as 3-D design<br />
and Foundry Logistics Simulation,<br />
emphasizing on Efficiency, Energy and<br />
Environment. Clients can be found<br />
among international key-players in the<br />
automotive and truck industry, mining,<br />
dredging, oil & gas, rail, heavy machinery,<br />
wind energy and many other business<br />
sectors. GEMCO operates from<br />
offices in The Netherlands, Germany,<br />
China, Mexico and Russia.<br />
Hall 16, Stand C12<br />
www.gemco.nl<br />
52
Photo: Foseco<br />
Foseco’s new, patented Feedex VAK feeding technology<br />
will be presented with best in class application examples.<br />
FOSECO<br />
Feeding systems for iron<br />
and steel foundries<br />
The application of feeder sleeves is a major<br />
factor in reducing metal remelt and fettling<br />
costs in foundry customers. By working in<br />
close partnership with foundries, Foseco<br />
continues to deliver tailored solutions for<br />
specific applications and develop new process<br />
technologies. In this year’s exhibition, we will showcase<br />
several new developments that advance the capabilities of<br />
the foundryman in optimising casting yield, minimising<br />
defects and reducing production costs.<br />
The new range of Feedek VAK spot feeders will be presented<br />
through a variety of ductile iron castings. This patented<br />
development provides an improved feeder neck pass-through<br />
on the most critical feeding applications.<br />
The development of Feedex SCK (Sleeve Construction Kit)<br />
feeders opens up the application of spot feeding to the jobbing<br />
iron and steel sector where the modular product range<br />
enables our customers to optimise both casting yield and fettling<br />
costs on large steel and iron castings.<br />
All relevant exhibits will feature simulations using the<br />
most recent version of the Foseco Pro Module for Magmasoft.<br />
<br />
www.foseco.com<br />
Hall 12 – Stand A1 + A2<br />
CLARIANT<br />
Catch LE+ Technology’s<br />
foundry successes<br />
LE+ Technology for green sand casting makes a big difference<br />
to operations. Why? Because it ticks the boxes for enhancing<br />
eco-credentials, lowering total cost of ownership and ensuring<br />
high precision casting. And it’s proving its value where it<br />
matters – in foundries. Latest updates on how Clariant’s Low<br />
Emission+ Technology is delivering on its promises will will be<br />
presented at the media “Meet & Greet” on June 27th at<br />
8 a.m. at the Clariant booth.<br />
Hall 12, Stand C 13<br />
www.clariant.com<br />
QualiMaster AT1<br />
Step by Step to the Ideal<br />
Molding Material Quality<br />
Molding material always exactly as required<br />
Individual solutions<br />
Preventive molding material controlling<br />
Choose your own individual solution. This new generation of the quality system has a modular structure.<br />
Compaction, shear strength, deformability, springback, gas permeability – you decide which values you consider important<br />
for improved casting quality and stable automated processes. QualiMaster AT1 Eco, Profi or ProfiPlus provide<br />
a reporting tool for stand-alone operation and a web interface for mobile viewing.<br />
Find out more about our new inline tester. Visit us at GIFA <strong>2019</strong> in Hall 17/ A38.<br />
www.eirich.com
SPECIAL: GIFA <strong>2019</strong><br />
ASK CHEMICALS<br />
Optimizing Environmental Protection and Occupational<br />
Health and Safety, Increasing Productivity<br />
Protecting the environment<br />
and employees<br />
from emissions: This is<br />
one of the biggest challenges<br />
currently in the<br />
foundry industry. ASK<br />
Chemicals, Hilden, Germany, uses its<br />
innovative product portfolio to help<br />
customers produce sustainably – with<br />
additional advantages for economic<br />
efficiency and quality. Foundries can<br />
therefore meet stringent regulatory<br />
requirements, without having to make<br />
big investments in additional filter and<br />
exhaust systems.<br />
ASK Chemicals helps to improve<br />
environmental protection and occupational<br />
health and safety and optimized<br />
economic efficiency by developing<br />
more powerful and environmentally-friendly<br />
solutions. Innovative technology<br />
platforms, such as Ecocure Blue<br />
and Inotec, as well as product packages,<br />
such as the Low Formaldehyde<br />
System (LFS), offer answers to typical<br />
challenges of the foundry industry<br />
regarding emissions.<br />
ASK’s sustainability approach is to<br />
reduce the emissions of phenol, formaldehyde,<br />
VOC and aromatic hydrocarbons<br />
(BTX) and to increase the effect of<br />
its products. “Innovative and more sustainable<br />
products ensure the competitiveness<br />
of a company in the long<br />
term,” emphasizes Dr. Jens Müller,<br />
Global Head of Research & Development<br />
at ASK. “Countries in East Asia,<br />
especially China, are also increasingly<br />
investing in innovative processes and<br />
sustainable products.”<br />
The patented inorganic binder technology<br />
is currently the optimum in<br />
terms of environmental protection. The<br />
Inotec procedure for aluminum casting<br />
developed by the Hilden company is<br />
characterized by an impressive environmental<br />
balance and increased productivity<br />
in production processes. It is completely<br />
free of emissions. No additional<br />
measures are required to filter or treat<br />
the exhaust air.<br />
Together with the development<br />
partners from the automotive industry,<br />
ASK Chemicals is working on making it<br />
possible to use inorganic binders as a<br />
forward-looking technology in the<br />
future for iron and steel casting on an<br />
industrial scale.<br />
Innovations for greater sustainability in the foundry industry.<br />
Increased regulatory requirements<br />
– such as the amendment to the TA Luft<br />
(Clean Air Guidelines) – concern, for<br />
example, formaldehyde emissions in the<br />
exhaust air of foundries. In Germany,<br />
these must be reduced to a quarter by<br />
no later than February 2<strong>02</strong>0.<br />
ASK Chemicals is supporting its customers<br />
here with the Low Formaldehyde<br />
System (LFS). This is a package of<br />
Ecocure Blue LFS binder, Miratec LFS<br />
coating and Veino LFS additive specially<br />
tailored to the respective requirements.<br />
Users can therefore precisely comply<br />
with the new emissions limits and<br />
improve occupational health and safety<br />
without having to invest in secondary<br />
measures, such as scrubbers or RTOs.<br />
The new Ecocure Blue, which combines<br />
efficiency with a significant reduction<br />
in emissions, stands for the holistic<br />
approach of product innovations at ASK<br />
Chemicals. With the phenolic resin Ecocure<br />
Blue, ASK Chemicals has introduced<br />
the first label-free, Cold Box part<br />
1 component in the history of binder<br />
chemistry. It saves up to 66 % of BTX<br />
emissions and reduces the required<br />
amount of binder by up to 22 %.<br />
Given this success, ASK Chemicals<br />
has expanded the Ecocure Blue families:<br />
Ecocure Blue is now called Ecocure Blue<br />
Pure, and there is also Ecocure Blue<br />
Ultra, which contains even less formaldehyde<br />
than Ecocure Blue Pure. The<br />
product family is complemented by Ecocure<br />
Blue Ice, which can withstand storage<br />
at temperatures as low as -18 °C.<br />
Modern foundries are increasingly<br />
relying on the Pep Set process due to<br />
the processing properties, the better<br />
casting results and higher productivity.<br />
ASK Chemicals has recognized this<br />
trend and is now presenting a new solution<br />
at GIFA for reducing phenol emissions<br />
in the PU No-Bake process: The<br />
new generation of the self-curing Pep<br />
Set binder system on a polyurethane<br />
basis – Pep Set Silver.<br />
This is characterized by a particularly<br />
low proportion of environmentally-friendly<br />
monomers, especially phenol.<br />
In practical applications, it is shown that<br />
the phenol concentrations in the regenerate<br />
are significantly reduced with the<br />
help of Pep Set Silver. In addition to<br />
advantages for the environment, this<br />
also means a clear plus for economic<br />
efficiency, because the landfill costs are<br />
also reduced. In addition, employees as<br />
well as residents in adjacent residential<br />
areas will appreciate the use of the new<br />
technology due to the reduced smoke<br />
pollution.<br />
Hall 12, Stand A22<br />
www.ask-chemicals.com<br />
Photo: ASK Chemicals<br />
54
IDECO<br />
Hydrogen Analysis in<br />
Aluminum Melt<br />
The company IDECO GmbH, situated in<br />
Bocholt, Germany, is the exclusive distributor<br />
for the HYCAL series in Central Europe, India<br />
and China.<br />
The HYCAL series is a<br />
brand of devices for<br />
measuring the hydrogen<br />
content of liquid<br />
aluminum and aluminum<br />
alloy melts.<br />
Even at very low concentrations, it is<br />
possible to analyze and adjust the<br />
hydrogen content quickly and precisely<br />
during both the melting and casting<br />
processes to meet the highest possible<br />
material requirements. The company<br />
IDECO GmbH, situated in Bocholt, Germany,<br />
is the exclusive distributor for<br />
the HYCAL series in Central Europe,<br />
India and China.<br />
IDECO is expanding their product<br />
range by adding a second measuring<br />
device for hydrogen analysis in aluminum<br />
melts. In addition to the classical<br />
procedure of “first bubble” measurement<br />
and the Density Index systems<br />
for determining the overall potential<br />
pore behavior (H2 and oxides) of a<br />
melt, the devices from the company<br />
EMC Ltd. offer the possibility of analyzing<br />
the hydrogen content directly in<br />
the liquid melt. A sensor based on a<br />
new ceramic material (CaZrO3-In) can<br />
be introduced directly into the melt at<br />
any point during the entire melting<br />
and casting process. It produces a<br />
potentiality measurement of the H2<br />
ion concentration as compared to a<br />
standard concentration contained within<br />
the probe.<br />
The aviation and automotive industries<br />
set high standards of material<br />
requirements for the aluminum industry.<br />
HYCAL devices eliminate the subjective<br />
judgment factor from the classification<br />
of pore behavior and, with<br />
their great precision, make it possible<br />
to maintain a pre-defined range of<br />
hydrogen concentration, even as low<br />
as 0,05 ml/100 g, for example. The continuous<br />
online monitoring allows for<br />
the feasibility of finding a variable<br />
optimum end point for the melting<br />
process. By continuing measurement<br />
during the casting process, one can<br />
further assure that no external factors<br />
have changed the hydrogen concentration,<br />
which results in reduced quality.<br />
For overall quality control, all measurements<br />
during the entire process<br />
are digitally saved and made available<br />
to a databank network.<br />
Particularly for the casting process<br />
with its high standards of material<br />
quality, the use of the HYCAL series for<br />
hydrogen analysis has proven to be<br />
especially economical. The HYCAL Mini<br />
is comparable in cost to classical measuring<br />
devices. The variable additional<br />
investment for the insertion probe<br />
with a capacity of 20 hours of accumulated<br />
data may be compensated by a<br />
commensurate rise in the material<br />
quality of the product.<br />
“HYCAL 1000” is the panel mounted<br />
hydrogen analysis unit featuring<br />
great flexibility for different control<br />
processes. A portable analysis unit with<br />
the identical internal components may<br />
be fitted variably to different production<br />
conditions. It has an internal gas<br />
tank, a storage battery, along with<br />
extensive software. Both devices are<br />
suited for foundries producing large<br />
quantities of top quality cast aluminum<br />
products.<br />
“HYCAL Mini” is a small portable<br />
system for the direct analysis of hydrogen<br />
concentration. It includes the analysis<br />
unit, the HYCAL measurement<br />
probe with adapter, a connection cable<br />
and PC based software for processing<br />
and storage of the measurement data.<br />
Hall 11, Stand C56<br />
www.ideco-gmbh.de<br />
Photo: Ideco<br />
NEW<br />
multiPuls<br />
160 °C<br />
Hall 11H73
SPECIAL: GIFA <strong>2019</strong><br />
DISA<br />
Premieres of game-changing foundry innovations<br />
for Zero Defect Manufacturing<br />
At GIFA <strong>2019</strong>, DISA,<br />
Taastrup, Denmark,<br />
will reveal three radical<br />
new digitally-driven<br />
innovations that move<br />
foundries closer to<br />
Zero Defect Manufacturing (ZDM). Inspired<br />
by DISA’s unmatched experience<br />
in helping customers continuously<br />
improve casting quality, these cutting-edge<br />
ZDM solutions – the novel<br />
Trace and Guidance (TAG) concept, the<br />
patent-pending Mold Accuracy Controller<br />
(MAC) and the upgraded Monitizer<br />
– open the door to a new era of<br />
scrap elimination.<br />
Visitors to the DISA section of the<br />
Norican Group stand will have hands-on<br />
access to both hardware and digital<br />
models so they can see for themselves<br />
how process data, real-time analysis and<br />
forensic quality control combine to help<br />
trace and eliminate scrap. “Finding the<br />
root cause of scrap can be extremely<br />
difficult,” says Per Larsen, Portfolio and<br />
Innovation Manager at DISA. “The total<br />
quality-related costs across foundries<br />
and casting users can represent up to<br />
10 % of the casting price.”<br />
For the first time ever, foundries can<br />
gain full traceability with DISA’s ingenious<br />
new Trace and Guidance (TAG)<br />
concept. TAG adds a unique ID number<br />
to each casting to provide the missing<br />
link between individual scrapped castings<br />
and their process parameters like<br />
sand compressibility, shot pressure and<br />
pouring temperature. TAG tracking<br />
also paves the way for advanced<br />
machine-learning-based analysis of<br />
scrap causes.<br />
“TAG tracking promises to be a<br />
major game changer for our industry,<br />
helping drive down quality-related costs<br />
to previously unseen levels,” says Larsen.<br />
“GIFA visitors will be able to<br />
explore the patent-pending TAG design<br />
for themselves in the demonstration<br />
area on our stand and sign up for exclusive<br />
news as this exciting concept is<br />
developed further.”<br />
The trailblazing Mold Accuracy Controller<br />
(MAC) forms the second plank of<br />
DISA’s ZDM strategy. The MAC alerts<br />
operators to mold mismatches and gaps<br />
– causing scrap, rework and damaging<br />
melt run-through – before the mold is<br />
DISA CIM (Computer Integrated Modules), featuring a completely new suite of data analysis<br />
and alerting tools<br />
poured. At GIFA <strong>2019</strong>, visitors to the<br />
DISA stand can test drive the MAC using<br />
a Disamatic Digital Twin (a digital simulation<br />
of a molding machine). They can<br />
change the virtual machine’s settings<br />
via a Disamatic D3 control panel and<br />
immediately see how those changes<br />
affect mold quality.<br />
“Delegates can inspect a full-size<br />
MAC on the stand, then use the Digital<br />
Twin to virtually test how the MAC<br />
monitors the molding machine’s output<br />
and helps spot any developing problems,”<br />
explains Larsen. “They will get a<br />
real feel for how operators are kept<br />
fully informed and can react to quality<br />
issues seconds after they first appear<br />
and, most importantly, before pouring<br />
the molds.”<br />
The MAC will be released at GIFA as<br />
a retrofit option for Disamatic machines<br />
with Automatic Mold Conveyors, helping<br />
more customers wave goodbye to<br />
scrap.<br />
GIFA also sees the release of Monitizer<br />
| CIM, DISA’s third ZDM solution.<br />
This is the next generation of DISA CIM<br />
(Computer Integrated Modules), featuring<br />
a completely new suite of data<br />
analysis and alerting tools.<br />
As the digital platform which collects<br />
and shares data between your<br />
foundry equipment, Monitizer keeps<br />
processes synchronized and delivers a<br />
full digital view of real-time and historic<br />
foundry data. Monitizer | CLOUD from<br />
Norican Group extends the platform,<br />
using IIoT technology to collect, monitor,<br />
and analyse complete foundry data<br />
from one or multiple global foundry<br />
sites.<br />
“With the Disamatic Digital Twin,<br />
MAC, TAG, and Monitizer, visitors can<br />
see how DISA’s disruptive digital innovations<br />
make it possible to “dive into the<br />
data” to troubleshoot problems, optimize<br />
critical foundry processes and take<br />
major steps towards zero scrap,” states<br />
Larsen.<br />
During on-stand sessions and within<br />
the official GIFA lecture programme,<br />
DISA experts will discuss how its ZDM<br />
solutions enable the data-driven<br />
foundry and help improve productivity,<br />
quality and resource utilization.<br />
Hall 11, stand A74-A78<br />
www.disagroup.com<br />
Photo: Disa<br />
56
FOSECO<br />
Filtration for iron and steel foundries<br />
The demand for improved<br />
casting integrity<br />
and performance continues,<br />
often associated<br />
with the need to<br />
reduce casting weight.<br />
The benefits provided by molten metal<br />
filters are increasingly valuable to casting<br />
producers and their customers in<br />
achieving these goals.<br />
In addition to enhancements to the<br />
range of Sedex and Stelex filters that<br />
offer foundries enhanced choice and<br />
performance characteristics in filter<br />
application, Foseco will be launching a<br />
new filter technology for large, high<br />
value steel castings.<br />
The Hollotex shroud filtration<br />
system combines the<br />
known benefits of Stelex filters<br />
with a fused silica shroud.<br />
This innovative technology<br />
provides a method of protecting<br />
the molten steel as it is<br />
poured from a bottom pour<br />
ladle into the mould and casting<br />
cavity. Aspiration of air is<br />
eliminated reducing re-oxidation<br />
inclusions and enhancing<br />
the performance of the integral<br />
filters. An application case<br />
study will detail the major<br />
improvements that this process<br />
can facilitate in the production<br />
and quality of highly<br />
specified castings.<br />
Recent developments in<br />
the Sedex and Stelex product<br />
portfolios offer foundries<br />
increasing choice in filter products.<br />
The attributes of these<br />
products will be compared so<br />
the user can understand the<br />
associated benefits and select<br />
the correct filter type for<br />
their casting needs.<br />
Foseco will be showing<br />
many case studies demonstrating<br />
the benefits provided by<br />
applying Sedex and Stelex filters<br />
to a variety of iron and<br />
steel castings. These will be<br />
complemented by Magmasoft<br />
simulations which model the<br />
molten metal flow control and<br />
turbulence reduction that are<br />
vital to achieving high finished<br />
casting quality.<br />
Hall 12 – Stand A1 + A2<br />
www.foseco.com<br />
Photo: Foseco<br />
Hollotex shrould<br />
application for large<br />
steel castings will be<br />
highlighted at the<br />
Foseco stand at GIFA<br />
<strong>2019</strong><br />
CASTING PLANT & TECHNOLOGY 2/<strong>2019</strong> 57
SPECIAL: GIFA <strong>2019</strong><br />
MAGMA<br />
Prediction of hot distortion of sand cores<br />
MAGMA GmbH,<br />
Aachen, specialist for<br />
the virtual optimization<br />
of foundry processes,<br />
and HA, Düsseldorf<br />
(both Germany), as a<br />
supplier of foundry chemicals, have<br />
joined forces in a long-term cooperation<br />
to quantitatively describe the hot<br />
distortion of sand cores. Together, they<br />
intend to develop and provide digital<br />
core data for foundries. Visitors at GIFA<br />
<strong>2019</strong> have the chance to see the concrete<br />
steps being taken at the stands of<br />
the two cooperation partners.<br />
Increasing demands on the dimensional<br />
tolerances of castings are especially<br />
critical for thin-walled sections,<br />
where even small deformations of sand<br />
cores can be critical for maintaining the<br />
required wall thicknesses and component<br />
geometry. The deformation of a<br />
sand core is dependent on its thermal<br />
expansion and the position of the corresponding<br />
core marks. For long thinwalled<br />
cores, buoyancy forces of the<br />
metal on the core play an additional<br />
important role. In the case of organic<br />
binders, even low buoyancy forces can<br />
lead to time-dependent deformation of<br />
the core due to creep effects in the<br />
binder resin.<br />
In order minimize the deformation<br />
of sand cores, their thermal and<br />
mechanical behavior during casting<br />
must be understood. With this knowledge,<br />
simulation programs can be used<br />
to predict how the core sand will<br />
behave during the casting process, particularly<br />
at high temperatures.<br />
MAGMA has implemented a numerical<br />
model in Magmasoft in which the<br />
core sand is treated as a porous medium,<br />
and both the pressure and temperature<br />
dependence of the core strength is considered.<br />
Time-dependent core deformation<br />
due to binder softening and decomposition<br />
are additionally taken into<br />
account through creep models. The<br />
effects on the core of e.g. buoyancy<br />
Core distortion during casting is a complex interaction between thermal, mechanical and<br />
time-dependent influencing factors<br />
forces during casting are also calculated.<br />
The cooperation between HA and<br />
MAGMA is aimed at quantifying the<br />
thermo-mechanical behavior of different<br />
molding materials during casting<br />
for the primary HA binder systems.<br />
MAGMA has developed a methodology<br />
to characterize the material<br />
behavior of cores using standard samples.<br />
HA is using this systematic<br />
approach in carrying out extensive<br />
investigations at its Center of Competence<br />
for both organic and inorganic<br />
HA binder systems and different sand<br />
types. These data will be used to generate<br />
product-dependent data sets, to<br />
make both the time and temperature<br />
dependent behavior of core distortion<br />
quantitatively predictable in Magmasoft.<br />
The results are being validated<br />
through in-situ measurements at the<br />
HA technical center in Baddeckenstedt,<br />
Germany, using optical measurement<br />
methods to quantify the deformation<br />
of sand cores as a function of<br />
time during solidification.<br />
“The aim of our cooperation is to<br />
provide users of Magmasoft with validated<br />
data for the quantitative prediction<br />
of core distortion for HA products,“<br />
confirms Dr.-Ing. Jörg C. Sturm,<br />
a Managing Director of MAGMA. “With<br />
this new database, our joint customers<br />
will be supported even better in the layout<br />
of their core and casting designs.“<br />
“We have a great interest in quantifying<br />
the behavior of our binder systems<br />
during casting,“ says Amine Serghini,<br />
member of HA‘s Executive Board<br />
responsible for Sales and Marketing.<br />
“The cooperation with MAGMA in this<br />
area will enable us to offer our customers<br />
another important added benefit.”<br />
At GIFA, both partners will present<br />
the first results of the joint development<br />
project, which is planned as a<br />
long-term cooperation.<br />
HA at GIFA: Hall 12, Stand C50<br />
MAGMA at GIFA: Hall 12, Stand A19/20<br />
www.magmasoft.de/en<br />
www.huettenes-albertus.com/en/<br />
Photo: MAGMA<br />
58
WHEELABRATOR<br />
A new wheel, advanced<br />
simulation technology and<br />
equipment evolutions<br />
Surface preparation<br />
specialist Wheelabrator,<br />
a Norican technology,<br />
will be showcasing<br />
a suite of new<br />
blast machines and<br />
solutions at GIFA <strong>2019</strong>, evolved and<br />
improved to meet emerging customer<br />
requirements and industry trends.<br />
A host of updates and extensions<br />
to existing equipment ranges has<br />
been developed particularly with aluminium<br />
applications in mind – fitting<br />
in with the brand’s new stand location<br />
in the aluminium hall (Hall 11) at<br />
GIFA, as part of the Norican Group<br />
presence.<br />
The Wheelabrator line-up for GIFA<br />
includes:<br />
> a new heavy-duty Universal blast<br />
wheel<br />
> a deep dive into the very latest<br />
blast simulation technology<br />
> numerous machine innovations<br />
Visitors to the Norican stand will also<br />
be able to learn about the latest digital<br />
developments, for Wheelabrator<br />
equipment and beyond, with experts<br />
from Norican Digital on hand to share<br />
the latest thinking.<br />
Wheelabrator’s new blast wheel<br />
for foundry applications will be unveiled<br />
at GIFA. Representing the latest<br />
innovations and proven technologies<br />
from across the company’s global<br />
blast wheel range, the new Universal<br />
wheel has been refined in rigorous<br />
testing over the past 12 months. It<br />
will offer a new level of performance<br />
and productivity for foundry blast<br />
operations.<br />
Simulation of blast processes can<br />
speed up development of new machines<br />
and even inform the design process<br />
of the produced part – by testing<br />
buildability early on.<br />
Working with leading manufacturers,<br />
namely in Automotive, as well as<br />
simulation specialists, Wheelabrator<br />
has been advancing blast simulation<br />
technology to enable the design of<br />
ever more complex parts and associated<br />
processes, particularly those with<br />
intricate internal surface areas.<br />
At GIFA, Wheelabrator will show<br />
what is possible in blast simulation,<br />
including how advanced simulation<br />
techniques save time and money<br />
during part and process design – a key<br />
advantage in today’s ever faster product<br />
development cycles.<br />
Also on show will be the latest<br />
machine developments soft-launched<br />
in recent months. They include extensions<br />
to and variations on existing<br />
ranges, which have been adapted to<br />
anticipate evolving customer requirements.<br />
They are:<br />
> The SPH-2-3/8, a new compact<br />
blast machine designed specifically<br />
for aluminium applications. Based<br />
on Wheelabrator’s trusted batchtype<br />
spinner-hanger wheel blast<br />
concept, the new machine excels<br />
at descaling, deburring/deflashing<br />
and cleaning of a variety of aluminium<br />
parts. Optimising the<br />
machine for this application enabled<br />
the design team to also reduce<br />
its price significantly.<br />
> The LBS 1000, a lighter version of<br />
the LBS mesh belt shot blast<br />
machine range. The mesh belt concept<br />
allows the efficient blasting<br />
of parts from all sides within a<br />
relatively compact space and<br />
without tumbling. It offers pitless<br />
installation and a more ergonomic<br />
loading height. Like the new SPH,<br />
it is suited particularly to the processing<br />
of aluminium parts.<br />
> A new range of wire mesh belt<br />
shot blast machines for medium-duty<br />
applications. The new<br />
CMS machine sits between Wheelabrator’s<br />
light LBS for nonfoundry<br />
and the high capacity<br />
CMC range for heavy duty foundry<br />
applications. The CMS wire mesh<br />
belt machine completes Wheelabrator’s<br />
mesh belt machine offering.<br />
Mesh belt machines are perfect for<br />
applications where parts are too<br />
big or too delicate for the tumblast<br />
processes.<br />
Hall 11, Stand A74-A78<br />
www.noricangroup.com/gifa<br />
FONDAREX<br />
MODULAR<br />
GIFA 11 / D41<br />
new
SPECIAL: GIFA <strong>2019</strong><br />
ZPF GMBH<br />
New furnace plant enables simultaneous melting<br />
of aluminium chips and ingots<br />
Due to the different<br />
shapes of ingots, return<br />
material and aluminium<br />
chips, different furnace<br />
types were previously<br />
required for<br />
melting the respective material. However,<br />
separate plants for the different<br />
types of material do not pay off for die<br />
casting foundries with too low volumes<br />
of aluminium chips or return material,<br />
so that only ingots are molten down.<br />
ZPF GmbH, Siegelsbach, Germany, have<br />
now developed a melting furnace<br />
which is qualified for melting down aluminium<br />
chips as well as recycling material<br />
and ingots – a sustainable utilization<br />
of the system is thus always<br />
ensured. The plant is equipped with an<br />
automatic charging system and is able<br />
to melt up to 500 kg raw material per<br />
hour, for example 250 kg aluminium<br />
chips and 250 kg ingots. The new melting<br />
furnace technology will be presented<br />
for the very first time at this<br />
year‘s GIFA with an exhibit.<br />
Production by-products such as scrap<br />
material and runner systems or even<br />
aluminium chips are usually collected<br />
and recycled externally in most foundries,<br />
as they cannot be returned directly<br />
to the melting process for economic<br />
reasons. This results in high costs for<br />
storage and transport, and the logistical<br />
effort should not be underestimated.<br />
“Until now, our aluminium melting furnaces<br />
were only designed for charging<br />
with unmixed material; a material mix<br />
of ingots and recirculation aluminium<br />
parts was previously only possible to a<br />
limited extent due to the desired<br />
boundary parameters such as melting<br />
loss and melting rate“, reports Sven-<br />
Olaf Sauke, head of R & D at ZPF GmbH.<br />
“For some foundries, a pure chip furnace<br />
is uneconomic, since the metal-cutting<br />
share in the cast product is often<br />
too low.“ ZPF has taken this market<br />
need as an opportunity to develop a<br />
new technology for melting furnaces<br />
enabling the simultaneous melting of<br />
chips, ingots or return material while still<br />
keeping the melting loss values at an<br />
extremely low level. This offers companies<br />
greater flexibility in the recycling<br />
process and new opportunities to optimize<br />
the melting process.<br />
For an optimal constructive design<br />
“Since there are two different shapes in the case of chips and ingots, we first had to<br />
choose the main variant“, reports Sven-Olaf Sauke, head of R & D at ZPF GmbH. “For our<br />
prototype, we opted for chips as the main material and designed the furnace as a heel<br />
melter (Graphics: ZPF GmbH).<br />
of the new furnace, simulations were<br />
used in the course of development to<br />
be able to assess the basic system<br />
behaviour. In addition, power and<br />
exhaust gas measurements were carried<br />
out under foundry conditions which<br />
were used to determine the functional<br />
parameters. “The decisive factor for us<br />
was the optimum melting of the metal<br />
and the required temperature control<br />
in the furnace,“ explains Sauke. “In<br />
addition to energy consumption,<br />
numerous other factors that strongly<br />
influence the melting result play a role<br />
here in a modern furnace system - for<br />
example the quality of the raw material<br />
and the melting loss. For practical<br />
implementation, ZPF analysed the data<br />
collected and determined the parameters<br />
required for simultaneous melting<br />
of chips and other aluminium materials.<br />
Based on these results, a prototype with<br />
the new technology was implemented.<br />
The melting furnace has dimensions<br />
of 575 cm x 380 cm x 445 cm (L x W x H)<br />
at an empty weight of approximately<br />
28 tons. It is dimensioned for a maximum<br />
throughput of 500 kg/h in total.<br />
The furnace system is extended by an<br />
automatic charging unit. This modular<br />
unit is designed in such a way that different<br />
types of material can be loaded<br />
according to customer requirements.<br />
“For the simultaneous melting of different<br />
material forms in one furnace,<br />
the first step is to determine the leading<br />
material variant,“ Sauke says. “For our<br />
prototype, we opted for aluminium<br />
chips as the main material and therefore<br />
designed the furnace as a heel melter.<br />
As a result, the chips can be molten<br />
down in combination with return material,<br />
return wheels or ingots“. Which<br />
variant is added to the chips can be<br />
selected by the operator. The only<br />
important thing is to pay attention to<br />
the optimum quantity ratio between<br />
chips and secondary material in order to<br />
achieve optimum melting performance.<br />
The new system will be presented at<br />
this year‘s GIFA in Düsseldorf. “We will<br />
be demonstrating the new system technology<br />
using a furnace at our trade fair<br />
stand. This gives us the opportunity to<br />
present the innovations to interested<br />
users in a detailed and practical manner,“<br />
explains Sauke. Hall 10, Stand F59<br />
www.zpf-gmbh.de<br />
60
GIFA <strong>2019</strong><br />
hall 16 / C11<br />
Torque motors – here on an Eirich Intensive<br />
Mixer R28 – are an energy saving alternative to<br />
asynchronous motors.<br />
EIRICH<br />
Molding Material as<br />
an Opportunity<br />
As a specialist in the<br />
processing of clay-bonded<br />
molding materials,<br />
Eirich, Hardheim, Germany,<br />
enables foundries<br />
to meet ever-increasing<br />
demands. The molding<br />
material holds opportunities for improving<br />
the casting quality. A preparation<br />
system from Eirich achieves higher<br />
energy efficiency. Optimized and automated<br />
processes enable the autonomous<br />
preparation of molding material.<br />
They are the basis for the Industrial<br />
Internet of Things (IIoT). At GIFA <strong>2019</strong>,<br />
visitors can gather information about<br />
groundbreaking EIRICH technology,<br />
from which every founder can benefit.<br />
The highlights and exhibits presented<br />
at the fair include a QualiMaster AT1<br />
of the new generation and an Intensive<br />
Mixer R28 with torque motors.<br />
The QualiMaster AT1 system is well<br />
known and proven as the heart of quality<br />
assurance in molding material preparation.<br />
The new generation of modular<br />
design is available as Eco, Profi or<br />
ProfiPlus version. In the Eco version, the<br />
inline tester is equipped with a compactability<br />
measuring unit. A reporting tool<br />
facilitates using it as a stand-alone unit.<br />
The Profi version additionally measures<br />
compactability and shear strength with<br />
deformability. Completely new possibilities<br />
are now available with the Quali-<br />
Master AT1 ProfiPlus: For the first time,<br />
the inline tester also measures springback<br />
and gas permeability. Due to its<br />
modular design, the AT1 Eco can be<br />
upgraded to the AT1 Profi or AT1 ProfiPlus<br />
at any time Eirich mixers equipped<br />
with torque motors as direct drives<br />
achieve a new level of energy efficiency.<br />
Energy savings of up to 25 % are a realistic<br />
prospect. These motors also have<br />
the advantages of lower maintenance<br />
requirements and reduced noise emissions.<br />
Torque motors are not just a good<br />
option for new Eirich mixers; they can<br />
also be retrofitted to Eirich mixers in<br />
operation without any problems. Another<br />
highlight expected at the fair is the<br />
prototype of an Evactherm mixer in a<br />
new small size.<br />
Hall 17, Stand A 38<br />
www.eirich.de<br />
Pneumatic conveying<br />
technology<br />
For dry, free-flowing, abrasive and<br />
abrasion-sensitive material<br />
Core sand preparation<br />
technology<br />
For organic and inorganic processes,<br />
turn-key systems including sand,<br />
binder and additive dosing and<br />
core sand distribution<br />
Reclamation technology<br />
Reclamation systems for<br />
no-bake sand and core sand,<br />
CLUSTREG® for inorganically<br />
bonded core sands<br />
Shockwave Technology<br />
CERABITE ®<br />
Clean Castings<br />
for the efficient removal<br />
of residual sand and coatings<br />
out of complex castings<br />
KLEIN Anlagenbau AG<br />
KLEIN Stoßwellentechnik GmbH<br />
a subsidiary of KLEIN Anlagenbau AG<br />
Obere Hommeswiese 53-57<br />
57258 Freudenberg | Germany<br />
Phone +49 27 34 | 501 301<br />
info@klein-group.eu<br />
www.klein-ag.de<br />
www.stosswellentechnik.de<br />
CASTING PLANT & TECHNOLOGY 2/<strong>2019</strong> 61
COATINGS<br />
Multitasking: Coatings for<br />
centrifugal casting<br />
As the range of centrifugal casting applications increases, so does the importance of<br />
coatings. In the past, coatings were mainly used as a separating layer between the mold<br />
and the casting part, whereas today they are designed to meet very specific requirements:<br />
Innovative coatings formulated for centrifugal casting help to avoid casting<br />
defects, influence mechanical parameters and even serve as a forming medium to allow<br />
the creation of special surface structures.<br />
Klaus Seeger, Ekaterina Potaturina, Düsseldorf<br />
The centrifugal casting process<br />
Centrifugal casting was first used in the<br />
middle of the 19th century by the British<br />
engineer and inventor Sir Henry<br />
Bessemer to produce rotationally symmetrical<br />
parts. In centrifugal casting,<br />
the melt is poured into a metal mold<br />
which rotates around its central axis at<br />
high speed. The centrifugal forces<br />
acting on it press the melt against the<br />
mold wall and produce a very pure and<br />
highly densified composite. The metal<br />
solidifies as the mold rotates – with the<br />
advantage that a cavity-free casting in<br />
the form of a cylindrical (hollow) body<br />
is produced without the use of feeders.<br />
The inner geometry of the mold determines<br />
the outer contour of the casting,<br />
62
act the casting and extends the life of<br />
the mold.<br />
Avoiding casting defects<br />
Casting defects such as inclusions, gas or<br />
reaction defects, which cannot be completely<br />
eliminated simply by changing<br />
the process parameters, are a significant<br />
problem in the centrifugal casting process.<br />
As the metallic permanent mold is<br />
impermeable to gas during centrifugal<br />
casting, the mold coating plays an<br />
important “gas management” role. In<br />
order to avoid gas defects such as pinholes,<br />
the coating must have a certain<br />
porosity and be able to absorb the<br />
decomposition gases produced.<br />
By targeted optimisation of the<br />
composition and structure of the coating,<br />
casting defects can be effectively<br />
avoided. If, for example, organic components<br />
are replaced with inorganic<br />
ones, or calcined raw materials are<br />
used, the loss on ignition and thus the<br />
risk of gas defects is reduced. Selecting<br />
raw materials with low reactivity also<br />
helps reduce the risk of reaction errors<br />
(Figure 3).<br />
In centrifugal casting castings can be<br />
manufactured without voids, where you<br />
can dispense with the use of feeders.<br />
Photo: ??<br />
Figure 1: The mold is coated using a spray<br />
lance.<br />
coatings for centrifugal casting make it<br />
possible to achieve clearly defined properties<br />
and advantages. The various<br />
functions that a centrifugal casting coating<br />
can perform are described below<br />
and illustrated using practical application<br />
examples (Figure 2).<br />
Coatings as separating agents<br />
The coating can be applied by<br />
sprinkling a dry powder into the rotating<br />
mold. An alternative frequently<br />
used process involves applying the coating<br />
by spraying a coating dispersion<br />
into the mold.. The coating’s primary<br />
task is to achieve a separating effect<br />
between mold and melt. Powder coatings<br />
can, for example, consist of a mixture<br />
of ferrosilicon, graphite, quartz<br />
dust, bentonite or diatomaceous earth .<br />
The addition of water and a dispersion<br />
agent makes it possible to paint or<br />
spray the coating. The uniform coating<br />
of the mold wall makes it easier to ext-<br />
Insulating effect<br />
The insulating effect of the coating is<br />
an important factor in the composition<br />
formation and the hardness profile. It<br />
regulates the heat transfer from the<br />
molten metal to the mold, thus contributing<br />
to the control of solidification<br />
and the casting structure.<br />
The insulating properties depend on<br />
the one hand on the composition of the<br />
coating, and on the other hand, on the<br />
layer thickness on the mold. Both para-<br />
the quantity of metal supplied determines<br />
the wall thickness.<br />
In horizontal casting, the melt is<br />
poured into a lying mold. In the case of<br />
particularly long castings or during continuous<br />
centrifugal casting, the runner<br />
can be moved during the casting process<br />
(Figure 1). In vertical casting, the<br />
casting takes place in a mold with a vertically<br />
rotating axis. Vertical casting can<br />
be used to produce conical or spherical<br />
outer contours. The rotational speed is<br />
often significantly slower than with<br />
horizontal casting.<br />
In centrifugal casting, the mold is<br />
usually lined with a ceramic protective<br />
layer, the so-called coating. Since the<br />
development of the centrifugal casting<br />
process, the demands placed on the casting<br />
parts and, at the same time, the<br />
functions to be met by the coating have<br />
continuously increased. Today, modern<br />
Figure 2: Several molds can be arranged in a casting carousel to produce large numbers of<br />
castings.<br />
CASTING PLANT & TECHNOLOGY 2/<strong>2019</strong> 63
COATINGS<br />
Figure 3: A coating with good<br />
gas permeability helps to<br />
avoid gas-related casting<br />
defects such as “dents” (left)<br />
or “pinholes” (right)<br />
Figure 4: High-quality<br />
centrifugal casting products<br />
after finishing.<br />
Figure 5: Castings<br />
before further processing.<br />
meters have a significant impact on the<br />
cooling rate of the melt and consequently<br />
the mechanical properties of<br />
the casting. These, in turn, are a crucial<br />
component of customer requirements.<br />
Particularly with thin-walled pipes, insulating<br />
properties need to be specifically<br />
adjusted in order to achieve maximum<br />
workability.<br />
The selection of suitable raw materials<br />
has an impact on thermal conductivity,<br />
but also on factors such as chemical<br />
reactivity, fire resistance, hardness and<br />
application properties of the coating.<br />
The grain size distribution is also<br />
important: a fine grain size has many<br />
grain boundaries and thus slows down<br />
heat transfer. A large grain size, on the<br />
other hand, creates more cavities between<br />
the individual grains, which also<br />
leads to an insulating effect.<br />
Solids content, viscosity and rheological<br />
properties must be balanced in<br />
such a way that, on the one hand, the<br />
desired layer thickness is achieved<br />
while, at the same time, the coating is<br />
easy to spray on and allows an even<br />
application. Since the coating is a dispersion<br />
that may sediment out during<br />
storage, appropriate preparation is<br />
required before application. Before use,<br />
the coating is adjusted to the desired<br />
processing viscosity by determining the<br />
density or efflux time.<br />
Controlling surface textures<br />
Since most castings are machined after<br />
production, there are no special requirements<br />
regarding the roughness of the<br />
casting surface for many applications.<br />
For certain applications, the shape and<br />
height of any roughness are clearly<br />
defined. This applies, for example, to<br />
grey cast iron wastewater pipes: during<br />
their manufacture, the aim is to achieve<br />
smooth cast surfaces. Although this<br />
requirement has no direct influence on<br />
the functionality of the casting, some<br />
foundries regard it as an externally<br />
visible quality criterion with which they<br />
want to score points with their customers.<br />
There are, however, also customer<br />
specifications that require the production<br />
of rough surface textures: For cylinder<br />
liners, a rough surface with a precisely<br />
defined surface structure is<br />
expressly desired (Figures 4 and 5).<br />
Cylinder liners can be pressed into<br />
engine blocks. It is also possible to cast<br />
the liners into the engine block after<br />
machining. With the further development<br />
of casting processes and coatings,<br />
it is now possible to produce defined<br />
surface structures that enable the liners<br />
to be cast directly into the engine block.<br />
The molten metal flows around the<br />
structured surface, filling in recesses<br />
and undercuts so that the engine block<br />
and liner materials form an extremely<br />
strong and resilient bond.<br />
The aim of this process is to obtain a<br />
rough surface structure during casting<br />
so that the outside of the cylinder liner<br />
does not require any further processing.<br />
The depth and shape of the structure<br />
can be determined according to customer<br />
specifications. Hedgehog or mushroom-shaped<br />
elevations are possible,<br />
as are structures with undercuts. The<br />
structure depths vary between 0.3 and<br />
1.1 mm, depending on customer requirements.<br />
The structures with undercuts<br />
can only be processed in pressure die<br />
casting, while the liners with hedgehog<br />
or mushroom structure can be processed<br />
in conventional gravity die casting.<br />
In addition to the special configuration<br />
of certain machine parameters, the<br />
coating plays a decisive role in achieving<br />
these surface structures. It can therefore<br />
be said that the coating acts as a<br />
forming factor (molding material).<br />
A modern coating for the production<br />
of structured cylinder liners is composed<br />
of special refractory materials<br />
64
MASTER<br />
EVERY MELT<br />
Speed up the production process and reduce tap-to-tap time with<br />
Hitachi High-Tech spark spectrometers. A range of precision tools<br />
that ensure the right ingredients are in the melt, so you can quickly<br />
deliver outstanding results.<br />
See our OES range at hha.hitachi-hightech.com<br />
14<br />
Si<br />
SILICON<br />
6<br />
C<br />
CARBON<br />
3.32%<br />
3.45%<br />
42<br />
Mo<br />
MOLYBDENUM<br />
16<br />
S<br />
SULPHUR<br />
0.0138 %<br />
0.38%<br />
25<br />
Mn<br />
MANGANESE<br />
0.48%<br />
7<br />
N<br />
NITROGEN<br />
0.0064%<br />
15<br />
P<br />
PHOSPHORUS<br />
0.0391%<br />
Visit us and win a drone!<br />
GIFA <strong>2019</strong><br />
Booth 11H29<br />
Entry voucher<br />
FOUNDRY-MASTER Smart FM EXPERT FOUNDRY-MASTER Pro2<br />
Hitachi High-Tech optical emission spectrometers<br />
contact@hitachi-hightech-as.com +49 2825 9383-0
COATINGS<br />
Figure 6: Schematic illustration of the Leidenfrost effect.<br />
Figure 7: The formation of different structures is controlled, among other things, by the<br />
coating.<br />
Figure 8: When drawing the tubes, the coating should adhere to the cast part and be completely<br />
removed.<br />
with defined grain sizes and shapes,<br />
water, binder, dispersion agent and surfactants<br />
to control surface tension.<br />
Figure 6 shows the various processes<br />
that occur when an aqueous coating is<br />
sprayed onto the hot centrifugal casting<br />
mold. If drops of the coating hit the<br />
mold, the coating is accelerated by the<br />
rotary motion of the mold and pressed<br />
against the hot mold as a result of the<br />
centrifugal forces. The water in the coating<br />
immediately begins to boil. Leidenfrost<br />
effects cause gas layers or gas bubbles<br />
to form. As the coating dries,<br />
channels form in the coating. Figure 7<br />
illustrates the concept of forming different<br />
structures from the gas bubbles.<br />
Depending on the coating composition,<br />
the centrifugal forces and the mold<br />
temperature, different channels are formed,<br />
which in turn lead to different<br />
surface structures during casting.<br />
Additional coating requirements<br />
In addition to the functions of coating<br />
for centrifugal casting described above,<br />
there are a number of additional, application-specific<br />
requirements: A key characteristic<br />
with regard to the process<br />
steps is, for example, extraction behaviour:<br />
When the tube is extracted from<br />
the mold after solidification, the coating<br />
should adhere to the casting and,<br />
ideally, be completely removed from<br />
the mold with the casting (Figure 8).<br />
In terms of cleanliness in the workplace,<br />
it is also desirable that a contiguous<br />
layer of the coating remains on<br />
the casting, and that it is as dust-free as<br />
possible (Figure 9). If the next process<br />
step involves blasting, the coating<br />
should be easy to remove – in case of a<br />
textured surface it may also need to be<br />
removed from the undercuts. For health<br />
and safety reasons, the coating must<br />
not contain crystalline quartz.<br />
Consistent quality is crucial<br />
In order to gain a competitive advantage,<br />
many foundries strive to increase<br />
the productivity of their processes and/<br />
or improve the quality of their castings.<br />
This leads to ever narrower process<br />
windows, with the risk that even the<br />
smallest defects can cause major disruption.<br />
Coatings must also meet these<br />
more demanding requirements. It is<br />
therefore becoming increasingly<br />
important to use stable coating products<br />
of uniform quality. Foundries<br />
need products with consistent properties<br />
in terms of composition, viscosity<br />
and application behaviour. However,<br />
natural raw materials are typically used<br />
66
Figure 9: A continuous layer of coating remains on the casting, which minimizes dust.<br />
Figure 10: The uniformity of the defined surface<br />
structure is checked during the quality<br />
inspection.<br />
in the production of coatings, and these<br />
can vary in their quality. Comprehensive<br />
quality testing of the raw materials<br />
enables deviations from specified properties<br />
to be detected at an early stage.<br />
In addition, regular process checks<br />
should be carried out using suitable<br />
measuring methods. In structural casting,<br />
the uniformity of the surface structure<br />
desired by the customer is also an<br />
integral component of the quality<br />
assurance process (Figure 10).<br />
Innovation potential for foundries<br />
and coating suppliers<br />
From the automotive to the chemical<br />
and paper industries; from pipes to<br />
rolls to cylinder liners: when it comes<br />
to the production of rotationally symmetrical<br />
components, centrifugal casting<br />
is a proven, technically sophisticated<br />
casting process with enormous<br />
application and innovation potential.<br />
For foundries, it is well worth consulting<br />
an experienced coating supplier at<br />
an early stage in the development process<br />
of any new centrifugal casting<br />
applications. The foundry specialists<br />
and chemists at Hüttenes-Albertus are<br />
always happy to take on new challenges.<br />
Since there is often no “off-theshelf”<br />
product for special applications,<br />
we develop and test solutions step by<br />
step together with our customers –<br />
from initial testing all the way through<br />
to series production readiness.<br />
www.huettenes-albertus.com<br />
Dr. Klaus Seeger, Head of Research and<br />
Development Coatings, Dr. Ekaterina<br />
Potaturina, Product Manager Coatings,<br />
Hüttenes-Albertus Chemische Werke<br />
GmbH<br />
YOUR PARTNER<br />
FOR TURNKEY PROJECTS<br />
in no-bake moulding shops for:<br />
• moulding lines<br />
• continuous mixers<br />
• mechanical and thermal reclamations<br />
• chromite separations<br />
Smooth pneumatic conveying system for:<br />
• sand • bentonite • carbon • filter dust<br />
QUALITY<br />
MADE IN GERMANY<br />
CASTING PLANT & TECHNOLOGY 2/<strong>2019</strong> 67<br />
FAT Förder- und Anlagentechnik GmbH · D-57572 Niederfischbach · Tel. +49 (0) 27 34/5 09-0 · fat.info@f-a-t.de · www.f-a-t.de
3-D-PRINTING<br />
68
The Kinetic Assembly Structure reflects the materialization<br />
of a train of thought. The lines form an infinite<br />
loop. voxeljet printed the models of the complex<br />
sculpture in several parts.<br />
The stool „Infiniala“ by designer<br />
Sergej Ehret: Future of Sculpture.<br />
With voxeljet 3-D printing systems,<br />
even the most complex<br />
sculptures that would have been<br />
impossible using traditional molding<br />
techniques can be realized.<br />
3-D printing systems evolutionize<br />
traditional art casting<br />
Art foundry Strassacker creates artistic works using 3-D printing systems by voxeljet<br />
Frederik von Saldern, Friedberg; Peter Mühlhäuser, Süßen<br />
Photos: Voxeljet<br />
Strassacker, one of the oldest and<br />
largest art foundries in Europe, is<br />
modernizing art casting with 3-D<br />
printing from voxeljet, Friedberg, Germany.<br />
The printing technology is used<br />
to create investment casting patterns<br />
and increases the artists’ freedom of<br />
design. Artworks which previously could<br />
not be produced using traditional molding<br />
techniques can now be printed<br />
directly in the form of a casting pattern.<br />
Have you heard of The Bambi<br />
Award? The German Media and Television<br />
Prize, which is awarded annually to<br />
people with visions and for outstanding<br />
achievements? The award winners<br />
include world stars such as Christoph<br />
Waltz, Samuel L. Jackson and Kate<br />
Winslet. But far less known is the company<br />
that produces the coveted bronze<br />
deer: the family owned company Strassacker<br />
from Süßen near Stuttgart. Since<br />
it was founded in 1919, the company<br />
has evolved from the manufacture of<br />
pasta machines and everyday objects to<br />
the production of numerous precious<br />
artworks. The company has made a<br />
name for itself especially in the art<br />
industry and is now a well-known<br />
player. Their customers include world<br />
renowned contemporary artists, who<br />
rely on the Strassackers’ specialist expertise.<br />
Digital model creation at Strassacker<br />
While traditional production<br />
methods have characterized the creation<br />
of works of art to date, today there<br />
The Strassacker foundry can offer customers both manual and digital manufacturing<br />
processes. If necessary, even both can be combined. Like here at a part of the sculpture<br />
KAS by Simon Mühlhäußer.<br />
are new possibilities for the design of<br />
art. One that clearly pushes the<br />
boundaries of what is possible is 3-D<br />
printing. Industrial 3-D printing systems<br />
can be used to print models made from<br />
acrylic glass (PMMA) or casting molds<br />
made from silica sand. These are then<br />
handled by casters in the same way as<br />
traditional wax patterns or sand casting<br />
molds. Strassacker recognized the<br />
potential of 3-D printing early on. For<br />
more than 15 years, the company has<br />
been working with printed patterns –<br />
including printed plastic patterns from<br />
voxeljet. During this time, the family<br />
business has been able to build up a<br />
wealth of experience that it is sharing<br />
with its customers.<br />
This means that customers can either<br />
send in their completed CAD data sets<br />
to Strassacker, where they will be processed<br />
in the company’s in-house digital<br />
workshop, or customers can approach<br />
Strassacker with their project plans and<br />
allow the specialists in the 3-D modelling<br />
department to advise them. „There<br />
CASTING PLANT & TECHNOLOGY 2/<strong>2019</strong> 69
3-D-PRINTING<br />
are hardly any limits to the ideas, but<br />
you still need to develop them yourself,“<br />
says Peter Mühlhäußer, product<br />
line manager at Strassacker. “The same<br />
way you have to know where the application<br />
of technology makes sense and<br />
where it doesn’t. Our technicians, designers<br />
and 3-D modelling experts are the<br />
right people to talk to, in order to<br />
define the right technological execution.”<br />
Strassacker can offer its customers<br />
both manual and digital manufacturing<br />
processes. If required, they can even<br />
combine the two together in a hybrid<br />
approach.<br />
Examples<br />
“Wachsende Steine” (“Growing Stones”)<br />
by Timm Ulrichs. A stone, in its<br />
natural form, was used as the initial<br />
model. At Strassacker it was 3-D<br />
scanned, digitized, scaled to the desired<br />
size and then printed in several parts by<br />
voxeljet. The larger stones, made from<br />
several individually printed PMMA<br />
parts, were manually assembled and<br />
then prepared for casting by hand. The<br />
PMMA models were cast like conventional<br />
wax models and then individually<br />
patinated by hand. Finally, the bronze<br />
casts were airbrushed to look like the<br />
natural model and painted by hand.<br />
Another project are the bronze<br />
reconstructions of the “Boxer at Rest”<br />
and the “Hellenistic Prince” sculptures<br />
by Prof. Dr. Vinzenz Brinkmann, which<br />
were originally handmade between the<br />
4th and 1st centuries BC and rediscovered<br />
on the Quirinal in Rome in 1885.<br />
The original sculptures were<br />
3-D-scanned, digitized and printed as<br />
PMMA patterns by voxeljet in their service<br />
center in Friedberg, Bavaria. Finally,<br />
the patterns were cast by Strassacker,<br />
chiselled by hand, partially restored and<br />
patinated. The finishing touches were<br />
made by experts at the Liebieghaus<br />
sculpture museum in Frankfurt.<br />
Unpacking of the PMMA part,<br />
which is then dipped into ceramic<br />
and burnt out.<br />
Printed and wax-infiltrated<br />
PMMA part “KAS”.<br />
Two other more current examples of<br />
the collaboration between Strassacker<br />
and voxeljet can be seen in the sculpture<br />
“KAS”, an in-house project by<br />
artist Peter Simon Mühlhäußer, and the<br />
sculpture “Infiniala” by designer Sergej<br />
Ehret.<br />
“KAS” stands for “Kinetic Assembly<br />
Structure” and reflects the materialization<br />
of a digital thought process. This<br />
also served as inspiration for the seat<br />
„Infiniala“. A closer look at the numerous<br />
contours of the seat reveals that<br />
the lines always form an endless loop.<br />
„KAS“ and „Infiniala“ show the<br />
unique possibilities in the realization of<br />
3-D printing gives<br />
artists the opportunity<br />
to make<br />
fantastic changes.<br />
For this reason,<br />
3-D printing is<br />
already firmly<br />
established in the<br />
repertoire of<br />
sculptural artists<br />
and will gain<br />
further market<br />
share.<br />
ABOUT STRASSACKER<br />
Ernst Strassacker GmbH & Co. KG was founded in Süßen, Germany, in 1919,<br />
and today is one of the world’s leading manufacturers in artistic casting.<br />
Since 2001, Edith Strassacker has been at the head of the family business in<br />
its fourth generation. Their workshop creates ambitions sculptures, modern<br />
architectural elements, sacred art and large-scale sculptures for public spaces.<br />
Various processes are used, including the lost wax process and ceramic, fire<br />
clay, vacuum and sand casting. The main focus is on preserving and encouraging<br />
craftwork skills. Their customer base includes renowned artists, designers<br />
and architects from all over the world. The company employs around 300<br />
people at the headquarters in Süßen and their French branch in Heimsbrunn.<br />
They also have sales offices in the USA and Saudi Arabia.<br />
highly complex, digitally created works<br />
of art.<br />
The complex nested geometries can<br />
only be realized by the use of additive<br />
processes, such as binder jetting from<br />
voxeljet. It would be impossible to produce<br />
these casting models using conventional<br />
molding processes.<br />
70
Production of a 3-D pattern and<br />
its advantages<br />
Strassacker uses voxeljet‘s 3-D printing<br />
service to produce, among other things,<br />
positive and tooling less patterns for<br />
bronze casting. In order to achieve this,<br />
they send the 3-D data set of an artwork<br />
to the voxeljet service center in<br />
Friedberg near Augsburg. Here, the<br />
CAD data is checked and further uploaded<br />
into the VX1000 3-D printing system.<br />
In the subsequent Binder-Jetting<br />
process, the recoater moves over the<br />
1,000 x 600 x 500 millimetre building<br />
platform and spreads a 150 micrometre<br />
thin layer of the plastic polymethyl methacrylate<br />
(PMMA). Then, the print head<br />
bonds the PMMA with a binder through<br />
polymerisation wherever the artwork is<br />
to be created. After each of these two<br />
steps, the building platform is lowered<br />
by one layer thickness and the recoater<br />
and print head process the next layer.<br />
This process produces the CAD data<br />
layer by layer with a resolution of up to<br />
600 dpi.<br />
Once the print is finished, voxeljet<br />
employees remove the model from the<br />
The elaborate interlaced geometries<br />
can only be realized<br />
through the use of additive<br />
processes, such as the voxeljet<br />
binder jetting. Making a cast<br />
blank with conventional<br />
molding techniques would<br />
be impossible.<br />
The production of complex<br />
model geometries is now<br />
easily possible. Even the<br />
gating system can be printed.<br />
job box, remove unbound plastic powder<br />
which can be reused 100 %,<br />
infiltrate the components with wax to<br />
further smoothen the surface and send<br />
the positive pattern to Strassacker. 3 to<br />
5 days after the placed order the pattern<br />
is on-site at Strassacker and ready<br />
for further processing.<br />
The casting process at Strassacker<br />
can then take its regular course. With a<br />
significant advantage: no silicone negative<br />
mold has to be created. The supplied<br />
PMMA pattern can then be<br />
immersed directly in ceramic to build a<br />
shell and burnt out in the furnace at<br />
700 °C. The PMMA material burns out<br />
without leaving any residue, leaving<br />
just the ceramic mold, into which the<br />
liquid metal can then be poured.<br />
In combination with 3-D printing,<br />
the investment casting process opens up<br />
completely new design possibilities.<br />
Complex geometries that would have<br />
been unthinkable in the past are now<br />
possible in the near future. Added to<br />
that, the gating system can also be printed<br />
directly. This saves time and delivers<br />
consistent casting results.<br />
Chiselling and patination<br />
Once the casting process has been completed,<br />
the chiselling and patinating<br />
work begins. A service that Strassacker<br />
customers particularly appreciate. In<br />
intensive cooperation with the artist, the<br />
final appearance of an artwork is created<br />
mutually. With custom-made tools,<br />
the chisellers precisely carve out intricate<br />
shapes and structures. Multi-piece cast<br />
parts are joined by a specially developed<br />
welding process without any visible<br />
welds on the finished work of art. The<br />
Bambi also gets its highly polished surface<br />
here. Last but not least, the patinater<br />
gives the work its colour by anticipating<br />
the natural oxidation process using<br />
chemical reactions. A high level of craftsmanship<br />
and expertise is required to create<br />
the subtlest of nuances in colour.<br />
The future of sculpting<br />
Nobody can exactly say, what the future<br />
holds for the art of sculpting. But<br />
change is clearly audible. There are<br />
already a significant number of<br />
open-minded artists using new, digital<br />
technologies. This change will be of particular<br />
benefit when it comes to conceptualizing<br />
new artistic works. It allows<br />
drafts to be drawn up and developed<br />
using a computer in cases where manual<br />
shaping techniques would be insufficient.<br />
Innovative artists are constantly<br />
striving to shift boundaries and develop<br />
something new. The path they take to<br />
achieve their vision is not the priority.<br />
Decisive is the transformation into reality.<br />
3-D printing gives artists the opportunity<br />
to truly innovate. This is why 3-D<br />
printing has already become firmly established<br />
in sculptors’ repertoires and will<br />
continue to gain market share.<br />
It could also be conceivable that in<br />
the distant future the model pre-acceptance<br />
could take place using Virtual Reality<br />
glasses. This would allow customers<br />
to view the finished artwork in size,<br />
colour and shape in three-dimensional<br />
space before it actually is fabricated.<br />
Peter Mühlhäußer is certain: “This would<br />
be a practical relief that could solve<br />
many problems in advance. It continues<br />
expanding the dynamic creative dialogue<br />
between artist and craftsman.”<br />
Until then, it remains to be seen<br />
what new, unique, 3-D-printed projects<br />
will emerge at Strassacker in the near<br />
future with the help of Binder Jetting<br />
from voxeljet. One thing is for sure:<br />
next time you get to see another Bambi<br />
Award celebration, you’ll certainly<br />
know, where the Bambi originated.<br />
www.voxeljet.com<br />
CASTING PLANT & TECHNOLOGY 2/<strong>2019</strong> 71
INTERNATIONAL FAIRS AND CONGRESSES<br />
Fairs and Congresses<br />
20th <strong>International</strong> Die Casting, Foundry & Industrial<br />
Furnace Exhibition<br />
June, 13-15, <strong>2019</strong>, Pazhou, Guangzhou, China<br />
www.julang.com.cn/english/yazhu/index.asp<br />
GIFA, METEC, THERMPROCESS, NEWCAST<br />
June, 25-29, <strong>2019</strong>, Düsseldorf, Germany<br />
www.gifa.com<br />
China Diecasting <strong>2019</strong><br />
July, 17-19, <strong>2019</strong>, Shanghai, China<br />
www.diecastexpo.cn/en<br />
11th <strong>International</strong> Exhibition of Steel, Metallurgy, Foundry,<br />
Machinery and related Industries<br />
September, 1-4, <strong>2019</strong>, Isfahan, Iran<br />
https://bit.ly/2MrZT1P<br />
FENAF <strong>2019</strong> – Latin American Foundry Fair<br />
September, 17-20, <strong>2019</strong>, São Paulo, Brazil<br />
https://bit.ly/2MrZT1P<br />
WFO Technical Forum and 59th IFC<br />
September, 18-20, <strong>2019</strong>, Portoroz, Slovenia<br />
www.drusto-livarjev.si<br />
<strong>International</strong> Conference of Metals, Ceramics and Composites<br />
September, 25-27, <strong>2019</strong>, Varna, Bulgaria<br />
https://mcc.foundry-conference.com<br />
<strong>International</strong> Foundry Congress & Exhibition (IFCE-2<strong>02</strong>0)<br />
November (3rd Week), <strong>2019</strong>, Lahore, Pakistan<br />
www.pfa.org.pk/info/8th-IFCE/587/0<br />
72<br />
Advertisers‘ Index<br />
Admar Group, Ocala FL/USA 23<br />
AGTOS Gesellschaft für technische<br />
Oberflächensysteme mbH, Emsdetten/Germany 41<br />
ASK Chemicals GmbH, Hilden/Germany 15<br />
ASTI - Gießereigeräte GmbH, Sinsheim/Germany 19<br />
DISA Industries A/S, Taastrup/Denmark 25<br />
DVS Media GmbH, Düsseldorf/Germany Inside Front<br />
Cover, Inside Back Cover, 40<br />
Euromac srl, Marano Vicentino (VI)/Italy 47<br />
ExOne GmbH, Gersthofen/Germany Front Cover<br />
FAT Förder- und Anlagentechnik GmbH,<br />
Niederfischbach/Germany 63<br />
Filtech Exhibitions Germany GmbH & Co. KG,<br />
Meerbusch/Germany 40<br />
FONDAREX SA, St. Légier/Switzerland 55<br />
Hitachi High-Tech Analytical Science GmbH,<br />
Uedem/Germany 61<br />
Hüttenes-Albertus Chemische Werke GmbH,<br />
Düsseldorf/Germany<br />
Back Cover<br />
Jasper Gesellschaft für Energiewirtschaft und<br />
Kybernetik mbH, Geseke/Germany 8<br />
JÖST GmbH & Co. KG, Dülmen/Germany 43<br />
KLEIN Anlagenbau AG, Freudenberg/Germany 57<br />
KÜNKEL WAGNER Germany GmbH,<br />
Alfeld/Germany 53<br />
Luoyang Hongfeng Abrasives Co., Ltd.,<br />
Luoyang/PR China 14<br />
Maschinenfabrik Gustav Eirich GmbH & Co KG,<br />
Hardheim/Germany 49<br />
O.M.LER S.r.l. Bra, (CN)/Italy 31<br />
Optris GmbH, Berlin/Germany 13<br />
regloplas AG, St. Gallen/Switzerland 51<br />
RUMP Strahlanlagen GmbH & Co. KG,<br />
Salzkotten/Germany 31<br />
Rudolf Uhlen GmbH, Haan/Germany 39<br />
Heinrich Wagner Sinto Maschinenfabrik GmbH,<br />
Bad Laasphe/Germany 37<br />
voxeljet AG, Friedberg/Germany 39<br />
YXLON <strong>International</strong> GmbH, Hamburg/Germany 9
Order Form - NEWSLETTER <strong>2019</strong><br />
NEWSLETTER<br />
men<br />
Newsletter Ad Formats<br />
Format/Größe in Pixel Preis* in €<br />
Ad Formats Format/Size in Pixel Ad Rate* in EURO<br />
Full Banner 468 x 60 289,-<br />
Text Ad max 400 characters, PDF-link or web page 299,-<br />
Tex/Image Ad max 468 300 x characters, 60 PDF-link or web page 309,- 275,-<br />
Special Banner 580 x 90 409,-<br />
max. 400 Zeichen,<br />
PDF-Verlinkung<br />
bzw. Webseite<br />
Dates <strong>2019</strong>/20<br />
Bild max. Höhe von 250 px oder<br />
max. Breite von 150 px<br />
max. 300 Zeichen,<br />
PDF-Verlinkung<br />
bzw. Webseite<br />
*All prices are exclusive of VAT.<br />
285,-<br />
Special forms of advertising such as Stand Alone Newsletter, Sponsoring, Advertorial, Logo Placement on request.<br />
Issue Transmission Delivery Ad Format – Please tick <br />
January 10.01.<strong>2019</strong> 08.01.<strong>2019</strong> Full Banner Text Ad Text/Image Ad Special Banner<br />
February 31.01.<strong>2019</strong> 25.01.<strong>2019</strong> Full Banner Text Ad Text/Image Ad <br />
295,-<br />
Special Banner<br />
March 28.<strong>02</strong>.<strong>2019</strong> 22.<strong>02</strong>.<strong>2019</strong> Full Banner Text Ad Text/Image Ad Special Banner<br />
April 28.03.<strong>2019</strong> 22.03.<strong>2019</strong> Full Banner Text Ad Text/Image Ad Special Banner<br />
May 07.05.<strong>2019</strong> 29.04.<strong>2019</strong> Full Banner Text Ad Text/Image Ad Special Banner<br />
June 1 04.06.<strong>2019</strong> 27.05.<strong>2019</strong> Full Banner Text Ad Text/Image Ad Special Banner<br />
June 2 11.06.<strong>2019</strong> 07.06.<strong>2019</strong> Full Banner Text Ad Text/Image Ad Special Banner<br />
June 3 18.06.<strong>2019</strong><br />
58014.06.<strong>2019</strong> x 90<br />
Full Banner Text Ad Text/Image Ad <br />
385,-<br />
Special Banner<br />
June 4 25.06.<strong>2019</strong> 19.06.<strong>2019</strong> Full Banner Text Ad Text/Image Ad Special Banner<br />
July 06.07.<strong>2019</strong> 28.06.<strong>2019</strong> Full Banner Text Ad Text/Image Ad Special Banner<br />
August 01.08.<strong>2019</strong> 26.07.<strong>2019</strong> Full Banner Text Ad Text/Image Ad Special Banner<br />
September 29.08.<strong>2019</strong> 23.08.<strong>2019</strong> Full Banner Text Ad Text/Image Ad Special Banner<br />
October 26.09.<strong>2019</strong> 20.09.<strong>2019</strong> Full Banner Text Ad Text/Image Ad Special Banner<br />
November 05.11.<strong>2019</strong> 28.10.<strong>2019</strong> Full Banner Text Ad Text/Image Ad Special Banner<br />
December 28.11.<strong>2019</strong> 22.11.<strong>2019</strong> Full Banner Text Ad Text/Image Ad Special Banner<br />
sich zzgl. der gesetzlichen MwSt.<br />
ie Sponsoring, Advertorial, Logo Platzierung u.a. auf Anfrage.<br />
ng benötigen 2<strong>02</strong>0 wir die folgenden<br />
nen<br />
The order is hereby placed.<br />
- Ansprechpartener für<br />
Rückfragen<br />
- Motivname (optional)<br />
- Klick-URL<br />
Dateiformate<br />
January 1 09.01.2<strong>02</strong>0 07.01.2<strong>02</strong>0 Full Banner Text Ad Text/Image Ad Special Banner<br />
January 2 13.01.2<strong>02</strong>0 09.01.2<strong>02</strong>0 Full Banner Text Ad Text/Image Ad Special Banner<br />
GIF, JPG, PDF (direkt als Verlinkung)<br />
Bitte geben Sie bei der Datenanlieferu<br />
Verlinkung (z.B. Internetadresse) an.<br />
Company: ..................................................................................................................................................................<br />
Contact: .....................................................................................................................................................................<br />
Phone/Email: ..............................................................................................................................................................<br />
Address: .....................................................................................................................................................................<br />
Date/Signature: ..........................................................................................................................................................<br />
se<br />
Contact:<br />
Markus Winterhalter<br />
T. +49 211 1591 142<br />
markus.winterhalter@dvs-media.info<br />
hr (Versand nach Hefterscheinen)<br />
Format des Newsletters<br />
HTML-Code oder Text<br />
Aachener Straße 172 • D-4<strong>02</strong>23 Düsseldorf
PREVIEW/IMPRINT<br />
A group of foundymen is waiting<br />
for the end of the tapping on the<br />
cupola of Gießerei Stolle in Bonn-<br />
Beuel. Deliveries and services for<br />
worldwide investment projects<br />
make up a considerable part of<br />
sales.<br />
Photo: Andreas Bednareck<br />
Preview of the next issue<br />
Selection of topics:<br />
R. Piterek: The foundry as project partner<br />
The iron foundry Gießerei Stolle is successfully involved in the casting of special machines – the range of services not only<br />
includes the casting and machining, but the complete project planning.<br />
D. Sauerwald: Recycling – certainly safely!<br />
The GreCon spark extinguishing system sees to a safe production at Siegfried Jacob Metal Works, which has been specializing<br />
in metal recycling for more than six decades.<br />
B. Pinto et al.: Thermally-efficient crucibles: Fundamentals, modelling and applications for energy savings<br />
Since melting and holding metal in crucibles accounts for a large portion of energy demand in foundries, recent advancements<br />
in crucible technologies resulting from these studies could significantly impact cost-efficiency and carbon footprint.<br />
Imprint<br />
Publisher:<br />
German Foundry Association<br />
Editor in Chief:<br />
Martin Vogt, Dipl.-Journalist<br />
Deputy Editor in Chief:<br />
Robert Piterek, M.A.<br />
P.O. Box 10 51 44<br />
40042 Düsseldorf, Germany<br />
Telephone: +49 211 6871-358<br />
Telefax: +49 211 6871-365<br />
E-mail: redaktion@bdguss.de<br />
Published by:<br />
DVS Media GmbH<br />
Aachener Straße 172<br />
4<strong>02</strong>23 Düsseldorf, Germany<br />
Telephone: +49 211 1591-0<br />
Telefax: +49 211 1591-150<br />
E-Mail: media@dvs-media.info<br />
Managing Director:<br />
Dirk Sieben<br />
Advertising Manager:<br />
Markus Winterhalter<br />
Art Director:<br />
Dietmar Brandenburg<br />
Circulation:<br />
DVS Media GmbH, Reader Service<br />
Telephone +49 6123 9238-242<br />
E-Mail media@dvs-media.info<br />
Annual subscription rate (incl. postage)<br />
Home: € 110,– incl. 7% VAT; Member States<br />
in the EC: Subscribers with VAT-No. and<br />
Third Countries: € 110,–; Subscribers without<br />
VAT-No.: € 110,– plus 7% VAT;<br />
Single copy € 33,–.<br />
Minimum subscription period 12 months.<br />
Termination of subscriptions can only be made<br />
from 31st December and notice of<br />
termination must be received by the<br />
Publishers by 15th November.<br />
Otherwise, the subscription is automatically<br />
renewed and payable for a further<br />
12 months.<br />
Advertising rate card No. 28 from 1.1.<strong>2019</strong><br />
Publication: Quarterly<br />
© <strong>2019</strong> DVS Media GmbH · Düsseldorf<br />
Printed by:<br />
W. Kohlhammer Druckerei GmbH + Co. KG<br />
Augsburger Straße 722<br />
70329 Stuttgart, Germany<br />
Printed on paper bleached totally chlorine-free<br />
All rights, including those of translation into<br />
foreign languages and storage in data banks,<br />
reserved.<br />
Photomechanical reproduction (photocopy,<br />
microcopy) of this technical publication or<br />
parts of it is not allowed without special<br />
permission.<br />
The reproduction in this journal of registered<br />
trademarks does not warrant the assumption,<br />
even without any special marking, that such<br />
names are to be considered free under the<br />
trade-mark law and may be used by anyone.<br />
Certification of circulation by the German<br />
Audit Bureau of Circulation<br />
ISSN 0935-7262<br />
74
