C O M P L E T E B I K E S 2 0 1 3 P R E V I E W


26”<br />

BLACK VERSION<br />

C O M P L E T E B I K E S 2 0 1 3 P R E V I E W<br />

DASH 26” DECALS


26”<br />

PURPLE VERSION<br />

C O M P L E T E B I K E S 2 0 1 3 P R E V I E W<br />

DASH 26” DECALS


26”<br />

DETAILS<br />

C O M P L E T E B I K E S 2 0 1 3 P R E V I E W<br />

DASH 26” DETAILS


26”<br />

DETAILS<br />

C O M P L E T E B I K E S 2 0 1 3 P R E V I E W<br />

DASH 26” DETAILS


26”<br />

DETAILS<br />

C O M P L E T E B I K E S 2 0 1 3 P R E V I E W<br />

DASH 26” DETAILS


26”<br />

SPECS<br />

BLACK<br />

PURPLE<br />

COLOR 1<br />

black<br />

COLOR 2<br />

purple<br />

FRAME<br />

4130 full crmo frame, heat treated dropouts<br />

FORK<br />

<strong>BOMBTRACK</strong>, full 4130 crmo , 1pc crmo steerer<br />

BARS<br />

<strong>BOMBTRACK</strong>, full 4130 crmo bar, full heat treated<br />

GRIPS<br />

<strong>BOMBTRACK</strong>, kraton, 146mm<br />

STEM<br />

SALT "EQUAL" front loading stem, 50mm reach<br />

HEADSET<br />

FSA int. headset, sealed bearing<br />

LEVER<br />

PROMAX alloy brake lever<br />

BRAKES<br />

PROMAX alloy caliber brakes<br />

FRAME GEOMETRY<br />

A TOP TUBE LENGTH<br />

B CHAIN STAY LENGTH<br />

C HEAD TUBE ANGLE<br />

D SEAT TUBE ANGLE<br />

E BOTTOM BRACKET HEIGHT<br />

F STANDOVER HEIGHT<br />

23"<br />

15"<br />

73°<br />

71°<br />

13.4"<br />

15.8"<br />

BAR GEOMETRY<br />

A RISE<br />

B WIDTH<br />

C BACKSWEEP<br />

D UPSWEEP<br />

9"<br />

29"<br />

10°<br />

4°<br />

CRANKS<br />

BB<br />

PEDALS<br />

CHAIN<br />

SPROCKET<br />

DRIVER<br />

FRONT HUB<br />

REAR HUB<br />

<strong>BOMBTRACK</strong>, tubular 3pc crank crmo, ht,165mm, 48 spline<br />

mid size, press fi t, sealed bearing<br />

SALT “AM” nylon/fi breglass pedals<br />

KMC halfl ink chain<br />

<strong>BOMBTRACK</strong>, spline drive, crmo, cnc, 26t sprocket<br />

<strong>BOMBTRACK</strong>,10T, 1-piece fi xed driver<br />

<strong>BOMBTRACK</strong>, alloy hub, sb, 3/8"s, 36h<br />

<strong>BOMBTRACK</strong>, alloy hub, sb,fi xed driver,14mm axle,36h<br />

FRONT RIM<br />

<strong>BOMBTRACK</strong> "FS" double wall, pin type, 36h<br />

REAR RIM<br />

<strong>BOMBTRACK</strong> "FS" double wall, welded rim, 36h<br />

SEAT<br />

<strong>BOMBTRACK</strong>, mid padded pivotal seat<br />

SEAT POST<br />

pivotal seat post, hi-ten, 155mm<br />

SEAT CLAMP<br />

<strong>BOMBTRACK</strong>, "SLIM" alloy seatclamp<br />

TIRES<br />

TIOGA “FS100”, 26" x 2.3" front, TIOGA “FS100”, 26” x 2.3” rear<br />

PEGS<br />

steel pegs (1 pair)<br />

WEIGHT<br />

tba<br />

C O M P L E T E B I K E S 2 0 1 3 P R E V I E W<br />

DASH 26” SPECS


700C<br />

BLACK VERSION<br />

C O M P L E T E B I K E S 2 0 1 3 P R E V I E W<br />

DIVIDE 700C DECALS


700C<br />

WHITE VERSION<br />

C O M P L E T E B I K E S 2 0 1 3 P R E V I E W<br />

DIVIDE 700C DECALS


700C<br />

DETAILS<br />

C O M P L E T E B I K E S 2 0 1 3 P R E V I E W<br />

DIVIDE 700C DETAILS


700C<br />

DETAILS<br />

C O M P L E T E B I K E S 2 0 1 3 P R E V I E W<br />

DIVIDE 700C DETAILS


700C<br />

DETAILS<br />

C O M P L E T E B I K E S 2 0 1 3 P R E V I E W<br />

DIVIDE 700C DETAILS


700C<br />

SPECS<br />

BLACK<br />

WHITE<br />

COLOR 1<br />

black<br />

COLOR 2<br />

white<br />

FRAME<br />

4130 full crmo frame, heat treated dropouts<br />

FORK<br />

<strong>BOMBTRACK</strong>, full 4130 crmo , 1pc crmo steerer<br />

BARS<br />

<strong>BOMBTRACK</strong>, full 4130 crmo bar, full heat treated<br />

GRIPS<br />

<strong>BOMBTRACK</strong>, kraton, 146mm<br />

STEM<br />

<strong>BOMBTRACK</strong>, front loading stem, 52mm reach<br />

HEADSET<br />

FSA int. headset, sealed bearing<br />

LEVER<br />

PROMAX alloy brake lever<br />

BRAKES<br />

PROMAX alloy caliber brakes<br />

FRAME GEOMETRY<br />

A TOP TUBE LENGTH<br />

B CHAIN STAY LENGTH<br />

C HEAD TUBE ANGLE<br />

D SEAT TUBE ANGLE<br />

E BOTTOM BRACKET HEIGHT<br />

F STANDOVER HEIGHT<br />

S 22.5"/ M 23.2" / L 24.2"<br />

16"<br />

73°<br />

74"<br />

45mm<br />

17.1"<br />

BAR GEOMETRY<br />

A RISE<br />

B WIDTH<br />

C BACKSWEEP<br />

D UPSWEEP<br />

3.75"<br />

26.75"<br />

6°<br />

6°<br />

CRANKS<br />

BB<br />

PEDALS<br />

CHAIN<br />

SPROCKET<br />

DRIVER<br />

FRONT HUB<br />

REAR HUB<br />

<strong>BOMBTRACK</strong>, tubular 3pc crank crmo, ht,165mm, 48 spline<br />

mid size, press fi t, sealed bearing<br />

SALT “AM” nylon/fi breglass pedals<br />

KMC halfl ink chain<br />

<strong>BOMBTRACK</strong>, spline drive, crmo, cnc, 28t sprocket<br />

<strong>BOMBTRACK</strong>,10T, 1-piece fi xed driver<br />

<strong>BOMBTRACK</strong>, alloy hub, sb, 3/8"s, 36h<br />

<strong>BOMBTRACK</strong>, alloy hub, sb,fi xed driver,14mm axle,36h<br />

FRONT RIM<br />

<strong>BOMBTRACK</strong> "MID" double wall, welded rim, 36h<br />

REAR RIM<br />

<strong>BOMBTRACK</strong> "MID" double wall, welded rim, 36h<br />

SEAT<br />

<strong>BOMBTRACK</strong>, slim padded, 4130 cr-mo rail seat<br />

SEAT POST<br />

<strong>BOMBTRACK</strong>, 6061 alloy, multi adjust seatpost, 250mm<br />

SEAT CLAMP<br />

<strong>BOMBTRACK</strong>, "SLIM" alloy seatclamp<br />

TIRES<br />

RESIST, "Nomad", 700Cx45C front and rear<br />

PEGS<br />

-<br />

WEIGHT<br />

tba<br />

C O M P L E T E B I K E S 2 0 1 3 P R E V I E W<br />

DIVIDE 700C SPECS


700C<br />

BLUE VERSION<br />

C O M P L E T E B I K E S 2 0 1 3 P R E V I E W<br />

SCRIPT 700C DECALS


700C<br />

POLISHED VERSION<br />

C O M P L E T E B I K E S 2 0 1 3 P R E V I E W<br />

SCRIPT 700C DECALS


700C<br />

DETAILS<br />

C O M P L E T E B I K E S 2 0 1 3 P R E V I E W<br />

SCRIPT 700C DETAILS


700C<br />

DETAILS<br />

C O M P L E T E B I K E S 2 0 1 3 P R E V I E W<br />

SCRIPT 700C DETAILS


700C<br />

DETAILS<br />

C O M P L E T E B I K E S 2 0 1 3 P R E V I E W<br />

SCRIPT 700C DETAILS


700C<br />

SPECS<br />

BLUE<br />

POLISHED<br />

COLOR 1<br />

blue<br />

COLOR 2<br />

polished<br />

FRAME<br />

6061 alloy, stainless steel dropout plates<br />

FORK<br />

<strong>BOMBTRACK</strong> "Race", full 4130 crmo, crmo steerer<br />

BARS<br />

<strong>BOMBTRACK</strong>, 6061 alloy bullhorn or racing drop bar<br />

GRIPS<br />

<strong>BOMBTRACK</strong>, kraton bar tape, diamond knurling texture<br />

STEM<br />

<strong>BOMBTRACK</strong> forged 6061 alloy, goose neck, ext. 80mm<br />

HEADSET<br />

<strong>BOMBTRACK</strong>, 1" high quality headset<br />

LEVER<br />

PROMAX alloy brake lever<br />

BRAKES<br />

PROMAX alloy caliber brakes<br />

FRAME GEOMETRY<br />

A TOP TUBE LENGTH<br />

B CHAIN STAY LENGTH<br />

C HEAD TUBE ANGLE<br />

D SEAT TUBE ANGLE<br />

E BOTTOM BRACKET HEIGHT<br />

F STANDOVER HEIGHT<br />

S tba/ M tba / L tba<br />

tba<br />

tba<br />

tba<br />

tba<br />

tba<br />

BAR GEOMETRY<br />

A RISE<br />

B WIDTH<br />

C BACKSWEEP<br />

D UPSWEEP<br />

bullhorn or racing drop handlebar<br />

tba<br />

tba<br />

tba<br />

CRANKS<br />

BB<br />

PEDALS<br />

CHAIN<br />

SPROCKET<br />

DRIVER<br />

FRONT HUB<br />

REAR HUB<br />

ANDEL "RSC1-7102", 6061 forged alloy crankset<br />

ANDEL, euro size, sealed bearing<br />

<strong>BOMBTRACK</strong>, cage pedal with strap and toe clip<br />

KMC, "Z510HX" 1/2" x 1/8" chain<br />

ANDEL, "SPR-7111C" 6061 alloy, cnc, 46t sprocket<br />

16T threaded, cog<br />

<strong>BOMBTRACK</strong>, "Classic", alloy hub, sb, 32h<br />

<strong>BOMBTRACK</strong>, "Classic" alloy fl ip/fl op fi xed/freewheel, sb, 32h<br />

FRONT RIM<br />

<strong>BOMBTRACK</strong> "AERO" double wall, welded rim, 32h<br />

REAR RIM<br />

<strong>BOMBTRACK</strong> "AERO" double wall, welded rim, 32h<br />

SEAT<br />

<strong>BOMBTRACK</strong>, slim padded, 4130 cr-mo rail seat<br />

SEAT POST<br />

<strong>BOMBTRACK</strong>, 6061 alloy, multi adjust seatpost, 250mm<br />

SEAT CLAMP<br />

<strong>BOMBTRACK</strong>, "SLIM" alloy seatclamp<br />

TIRES<br />

KENDA, "Kaliente", 700 x 23c front and rear<br />

PEGS<br />

-<br />

WEIGHT<br />

tba<br />

C O M P L E T E B I K E S 2 0 1 3 P R E V I E W<br />

SCRIPT 700C SPECS
