Gebrauchte Segelyacht Amel SANTORIN - heckenweb.de

YBM - Yacht Broker Mallorca - since 1987
Boat & Yacht Broker S.L.U. - Fred Hecken
Muelle Viejo 6E/Pier 46, E-07012 Palma de Mallorca
Tel: (+34) 971 724 463 – T+Fax: 971 729 452 Mobil: 661 942
292
www.yachtbrokermallorca.eu Email: yachtbrokermallorca@gmail.com
Second-hand yacht / good condition
Sparkman & Stephens ALPA 11.50 (38´) Cruiser / Racer
year 1978 - Refit in 2004/2005
49.500,- € Euro - EU-TAX exempted
Ref 8290 ca. 66.000 US Dollar or 44.000 GBP rates on 16.04.2009 xe.com

BUILDER Alpa, Italy built no 181
DESIGNER
Sparkman & Stephens
MATERIAL
GRP hull, Deck and superstructure
Teak laid cockpit sole/seats -NEW
LYING
Europe / Spain, Balearic Islands - Mallorca
LOA 11.56 m 37´11”
LWL 8.15 m 26´8” Speed approx. 7 knots
BEAM 3.20 m 10´5”
DRAUGHT 1.82 m 5´11”
DISPLACEMENT approx. 6.300 kg Ca. 28.350 lbs
BALLAST LEAD KEEL 2.700 kg 6.000 lbs
Tank FUEL Diesel 90 litres 20.0 Imp. Gal
Tank FRESH WATER 300 litres 66.7 Imp. Gal
RIGG & SAILS: - Sloop - Aluminum Mast & Boom + Stainless steel standing rigging, adjustable
back stay tensioner, baby stay, furling foresail system – spinnaker pole -
WINCHES:
SAILS: approx. 74.5 m²
- MAINSAIL (NEW Jan./2009) with 4 battens in “like new” condition
- GENOA (NEW Jan./2009 in “like new” condition
- CRUISING CHUTE, in “as new” condition, never been used
ENGINE: VOLVO PENTA 2040 40 hp diesel (new in 1999, at present 1200 hours), with shaft
drive, 3-bladed propeller - Dual circuit cooling with sea water filter - Engine hours counter and revcounter
- Insulated engine compartment –
ELECTRICAL: Boat’s power supply switch board with automatic fuses & control lamps
• BATTERIES: for engine and service
• 220V SHORE POWER supply, interior connectors
• BATTERY CHARGER + Alternator
• SOLAR PANEL
• Navigation lights; Deck light
FRESHWATER / PLUMBING:
• Hot & cold pressurized water throughout - Electrical pressure pump with filter
• Hot water by engine heat exchanger and 220V immersion heater coil, 30 litres boiler
• Electrical bilge pump, Manual bilge pump
• shower at stern
NAUTIC / NAVIGATION:
• cockpit helm station with wheel steering positions, full engine control,
compass
• Log/speed and Echo sounder
• Wind instrument for speed/direction and close haul
• AUTOPILOT AH4000 with remote control
• GPS sat nav (hand held)
• VHF-radio telephone
SAFETY & VARIOUS:
• Electrical Anchor Windlass (NEW), remote control, Anchor, 80m/8mm chain – 2 nd anchor
• Life Raft (new in 2006), emergency equipment, fire extinguisher, emergency tiller, first aid
kit, Black ball & cone - Fog horn - Torch light - Horseshoes buoys
• SPRAY HOOD (like new)
• Inflatable dinghy
• Fenders, mooring warps, boats hook, gangplank

CONSTRUCTION: Hull & Deck in GRP, teak laid cockpit floor and seats, AFT COCKPIT with wheel
steering pedestal, stainless steel wheel, cockpit table - locker seats in cockpit - ventilators - gas
bottle locker – stainless steel pulpit, push-pit and stanchions – mooring cleats at fore and aft and
spring cleats mid-ships - hatches to open - bathing ladder
BALLAST: keel 1.85 m - RUDDER with skeg
ACCOMMODATION & INTERIOR:
2 cabins with 3 berths (+ 3 berth saloon), 1x head compartment – Headroom 1,80 m+
- Forward CABIN: large double berth with storage under, wardrobe, opening deck hatch
- forward head compartment: marine pump toilet (like new), hand washbasin + shower
- Saloon: comfortable settee to port & starboard (convertible to berth), salon table with folding
leafs, storage shelves
- Galley with 2-burner gas cooker (with fail flame)/oven – top opening refrigerated cool-box with
engine driven cool-compressor and cool-plate – twin sink with hot/cold pressurized water,
storage space for pots and pans, cutlery and crockery
- Navigation/Chart table with chart storage, navigator seat, pilot berth behind, storage under,
electrical / fuse panel and instruments
ENTERTAINMENT: radio/CD with loud speakers at saloon
BROKER COMMENT: present owner bought in 2004, extensive refit in 2004/2005 – new engine,
hull painted, new full teak foot rail, cockpit sole and seats in full teak

DISCLAIMER: Boat & Yacht Broker S.L.U – YBM-Yacht Broker Mallorca
In this case we are acting as brokers only. The Vendor is not selling in the course of a business. Whilst every care has
been taken in their preparation, the correctness of these particulars is not guaranteed. The particulars are intended only
as a guide and they do not constitute a term of any contract. A prospective buyer is strongly advised to check the
particulars and where appropriate at his own expense to employ a qualified Marine Surveyor to carry out a survey and /
or to have an engine trial conducted, which if carried out by us shall not imply any liability for such engine on our part.
Note to seller and purchaser: If the boat you are selling or purchasing is registered, please ensure that the registration is
completed after the sale of the boat. If the purchaser wishes to cancel the registration is the duty of the seller to contact
the Registry and inform them that the registration is to be cancelled. If the purchase wishes to continue with the
registration, it is the duty of the purchaser to complete the relevant forms and post off the bill of sale to the Registrar.
