nucmag.com<br />

2019<br />

<strong>11</strong>/12<br />

Per<strong>for</strong>mance Shaping<br />

Factors <strong>for</strong> Human Error<br />

Reduction<br />

Decommissioning & Dismantling<br />

of the Rossendorf Research<br />

Reactor RFR<br />

First On-site Demonstration<br />

of Laser- based Decontamination<br />

Technology in Germany<br />

ISSN · 1431-5254<br />

24.– €<br />

Register Now!


Kommunikation und<br />

Training für Kerntechnik<br />

Suchen Sie die passende Weiter bildungs maßnahme im Bereich Kerntechnik?<br />

Wählen Sie aus folgenden Themen: Dozent/in Termin/e Ort<br />

3 Atom-, Vertrags- und Exportrecht<br />

Atomrecht – Ihr Weg durch Genehmigungs- und<br />

Aufsichtsverfahren<br />

RA Dr. Christian Raetzke 18.02.2020 Berlin<br />

Atomrecht – Was Sie wissen müssen<br />

RA Dr. Christian Raetzke<br />

Akos Frank LL. M.<br />

<strong>11</strong>.<strong>11</strong>.2020 Berlin<br />

Atomrecht – Das Recht der radioaktiven Abfälle RA Dr. Christian Raetzke 10.03.2020 Berlin<br />

Export kerntechnischer Produkte und Dienstleistungen –<br />

Chanchen und Regularien<br />

3 Kommunikation und Politik<br />

RA Kay Höft M.A. (BWL) 17.06.2020 Berlin<br />

Public Hearing Workshop –<br />

Öffentliche Anhörungen erfolgreich meistern<br />

Dr. Nikolai A. Behr 10.<strong>11</strong>. - <strong>11</strong>.<strong>11</strong>.2020 Berlin<br />

3 Rückbau und Strahlenschutz<br />

In Kooperation mit dem TÜV SÜD Energietechnik GmbH Baden-Württemberg:<br />

Das neue Strahlenschutzgesetz –<br />

Folgen für Recht und Praxis<br />

Stilllegung und Rückbau in Recht und Praxis<br />

Dr. Maria Poetsch<br />

RA Dr. Christian Raetzke<br />

Dr. Stefan Kirsch<br />

RA Dr. Christian Raetzke<br />

28.01. - 29.01.2020<br />

16.06. - 17.06.2020<br />

23.09. - 24.09.2020<br />

Berlin<br />

17.03. - 18.03.2020 Berlin<br />

3 <strong>Nuclear</strong> English<br />

English <strong>for</strong> <strong>Nuclear</strong> Business Angela Lloyd 01.04. - 02.04.2020 Berlin<br />

3 Wissenstransfer und Veränderungsmanagement<br />

Veränderungsprozesse gestalten – Heraus <strong>for</strong>derungen<br />

meistern, Beteiligte gewinnen<br />

Erfolgreicher Wissenstransfer in der Kerntechnik –<br />

Methoden und praktische Anwendung<br />

Dr. Tanja-Vera Herking<br />

Dr. Christien Zedler<br />

Dr. Tanja-Vera Herking<br />

Dr. Christien Zedler<br />

21.01. - 22.01.2020 Berlin<br />

24.03. - 25.03.2020 Berlin<br />

Haben wir Ihr Interesse geweckt? 3 Rufen Sie uns an: +49 30 498555-30<br />

Kontakt<br />

INFORUM Verlags- und Verwaltungs gesellschaft mbH ı Robert-Koch-Platz 4 ı 10<strong>11</strong>5 Berlin<br />

Petra Dinter-Tumtzak ı Fon +49 30 498555-30 ı Fax +49 30 498555-18 ı Seminare@KernD.de<br />

Die INFORUM-Seminare können je nach<br />

Inhalt ggf. als Beitrag zur Aktualisierung<br />

der Fachkunde geeignet sein.


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

TMI and Lessons Learned – Afterwards<br />

and <strong>for</strong> the Future<br />

No technical development is perfect from the outset, each involves specific risks. A responsible approach to<br />

technology there<strong>for</strong>e requires a responsible and <strong>for</strong>ward-looking approach to its risks, the best possible protection and,<br />

if necessary, further development. This also means that there are no such things as absolutely perfect technology and<br />

absolute safety.<br />

With a view to criticism of technologies, technology sceptics<br />

are provided with a com<strong>for</strong>table approach <strong>for</strong> transporting<br />

their respective concerns by anniversaries. One such event<br />

is the 1979 Three-Mile-Island (TMI 2) accident.<br />

On 28 March 1979, shortly after 4 a.m., the feed water<br />

supply <strong>for</strong> the steam generators in unit 2 of the Three Mile<br />

Island (TMI 2) nuclear power plant near Harrisburg,<br />

Pennsylvania, USA, failed. Such a malfunction was taken<br />

into account in the operating procedures with a view to<br />

the future and can be easily dealt with by the plant and<br />

operators. The event is one of the design cases. But what<br />

began as a normal incident later developed into the most<br />

serious accident to date in a Western nuclear power plant<br />

due to a combination of technical defects, human error<br />

and organisational inadequacies.<br />

The technical aspects of the TMI-2 accident have been<br />

extensively reviewed and can be traced in detail in the<br />

literature: After the failure of the feed-water supply, the<br />

safety systems of the nuclear power plant reacted as<br />

designed. However, due to valves in the emergency feedwater<br />

system that were closed manually on site, the steam<br />

generators were not supplied with water and a link in the<br />

chain <strong>for</strong> the residual heat dissipation of the reactor, which<br />

was switched off but still supplies heat due to the decay<br />

heat, was missing. This error was corrected 8 minutes<br />

after the start of the fault. Subsequently, the increase in<br />

pressure in the primary circuit caused the safety relief<br />

valve on the pressure holder to open, the escape of steam<br />

from the primary circuit and the intended pressure<br />

reduction. However, the opened blow-off valve did not<br />

close as designed. This caused large quantities of coolant<br />

to escape from the primary circuit – a loss of coolant<br />

accident “ LOCA” had occurred. Only 2 hours later it was<br />

detected by the operators and corrected by closing other<br />

existing shut-off valves. After further misinterpretations<br />

about the condition of the reactor core and the primary<br />

circuit, the core was no longer cooled by water and the<br />

exothermic reaction between water vapour and the<br />

cladding tube material of the fuel elements then set on,<br />

releasing additional heat. About half of the fuel rod mass<br />

in the core melted or was severely damaged. Core masses<br />

shifted and partially reached the bottom of the reactor<br />

pressure vessel where they solidified. After it had been<br />

recognised that a core melt was in full swing, measures <strong>for</strong><br />

core cooling were taken and it was possible to ensure the<br />

heat removal of the TMI-2 core again in the long term.<br />

Of the radioactive substances released in the plant, a<br />

small part was released into the environment. Triggered<br />

by fears of the additional radiation exposure associated<br />

with the release of a calculated average of 0.02 mSv – i.e.<br />

about 1 % of the natural annual radiation exposure – the<br />

Pennsylvania Department of Health kept a register <strong>for</strong><br />

18 years containing the data of more than 30,000 persons<br />

who had lived within a five-mile radius of the nuclear<br />

power plant at the time of the accident. This state register<br />

was closed in June 1997 after no unusual health<br />

developments had been identified. More than a dozen<br />

comprehensive studies on the physical health effects of the<br />

accident did not provide evidence of an abnormally high<br />

number of cancer cases in the region around the nuclear<br />

power plant years after the event.<br />

Despite all the shortcomings and shortcomings that<br />

led to the TMI-2 accident, the basic safety concept of<br />

Western nuclear power plants that had been established at<br />

an early stage was confirmed: The amount of radioactive<br />

substances released from the plant was low and there were<br />

no fatalities or injuries. On the other hand, the accident<br />

sequence underlines the suitability of successively<br />

staggered safety barriers, which, taking even serious<br />

accidents into account, aims at the confinement of the<br />

radioactive substances in the plant itself: The reactor<br />

building of TMI-2 withstood, the containment remained<br />

intact.<br />

In addition, research and development <strong>for</strong> reactor<br />

safety further minimised the risks in an international<br />

context during the past 40 years: Expressed in figures,<br />

even <strong>for</strong> running plants in Germany and elsewhere, a<br />

safety level was achieved, which is 100 times higher than<br />

the original international reference level. The reactor<br />

disaster at Fukushima in 20<strong>11</strong> will not change this point<br />

of view either, as other <strong>for</strong>eseeable risks and specific<br />

boundary conditions were the causes.<br />

Safety is and remains an international task <strong>for</strong> all<br />

concerned. <strong>Nuclear</strong> safety and the maintenance and<br />

promotion of competences, especially when they are<br />

available with excellent know-how in research and<br />

development and are internationally recognised – as in<br />

Germany – are part of the overall social and political<br />

responsibility at the same level as other goals of<br />

environmental protection. Today's and future safety and<br />

the promotion of safety culture and technology, also <strong>for</strong><br />

nuclear technology, cannot and must not be the subject<br />

of restricted or restrictive action. Research and<br />

development should always be allowed to advance in<br />

the spirit of freedom of science and technology.<br />

Christopher Weßelmann<br />

– Editor in Chief –<br />

507<br />

EDITORIAL<br />

Editorial<br />

TMI and Lessons Learned – Afterwards and <strong>for</strong> the Future


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

508<br />

EDITORIAL<br />

TMI und Lessons Learned – danach<br />

und für die Zukunft<br />

Keine technische Entwicklung ist von vornherein perfekt, jede birgt spezifische Risiken. Ein verantwortungsvoller<br />

Umgang mit Technik er<strong>for</strong>dert daher einen verantwortungsvollen und vorausblickenden Umgang mit ihren<br />

Risiken, bestmöglichen Schutz und ggf. auch spätere Weiterentwicklung. Dies bedeutet jedoch auch, dass es eine<br />

absolut perfekte Technik nicht gibt, ebenso keine absolute Sicherheit.<br />

Mit Blick auf Kritik an Technologien liefern Jahrestage gerne<br />

Technologieskeptikern einen kom<strong>for</strong>tablen Ansatz, ihre<br />

jeweiligen Anliegen zu transportieren. Ein solches Ereignis<br />

ist auch der Three-Mile-Island (TMI 2)-Unfall von 1979.<br />

Am 28. März 1979, kurz nach 4 Uhr morgens, fiel im<br />

Block 2 des US-amerikanischen Kernkraftwerks Three Mile<br />

Island (TMI 2) nahe Harrisburg, Pennsylvania, die<br />

Speisewasser versorgung der Dampferzeuger aus. Eine<br />

solche Störung ist in den Betriebsabläufen vorausblickend<br />

berücksichtigt und kann von Anlage und Operateuren ohne<br />

Weiteres bewältigt werden. Das Ereignis gehört zu den<br />

Auslegungsfällen. Doch was als normale Störung begann,<br />

entwickelte sich im weiteren Verlauf aufgrund einer Kombination<br />

aus technischen Mängeln, mensch lichen Fehlern und<br />

organisatorischen Unzulänglichkeiten zum bis dahin schwerwiegendsten<br />

Unfall in einem west lichen Kernkraftwerk.<br />

Die technischen Aspekte zum TMI-2-Unfall sind ausgiebig<br />

aufgearbeitet und können in der Literatur detailliert<br />

nachvollzogen werden: Nach dem Ausfall der Speisewasserversorgung<br />

reagierten die Sicherheitssysteme des Kernkraftwerks<br />

auslegungsgemäß. Aufgrund versehentlich<br />

manuell Vor-Ort geschlossener Ventile im Notspeisewassersystem<br />

fehlte aber die Bespeisung der Dampferzeuger und<br />

damit ein Glied in der Kette für die Nachwärmeabfuhr des<br />

zwar abgeschalteten aber durch die Nachzerfalls wärme<br />

immer noch Wärme liefernden Reaktors. Dieser Fehler<br />

wurde 8 Minuten nach Störungsbeginn korrigiert. In<br />

weiterer Folge kam es durch den Druckanstieg im Primärkreislauf<br />

zum Öffnen des für diesen Fall vorgesehenen<br />

Sicherheits-Abblaseventils am Druckhalter, dem Entweichen<br />

von Dampf aus dem Primärkreislauf und der<br />

beabsichtigten Druckabsenkung. Das geöffnete Abblaseventil<br />

schloss aber folgend nicht auslegungsgemäß. Über<br />

diesen Weg entwichen große Mengen Kühlmittel aus dem<br />

Primärkreislauf – ein Loss of coolant accident „LOCA“ war<br />

eingetreten. Erst 2 Stunden später wurde er durch die<br />

Operateure erkannt und durch Schließen weiterer vorhandener<br />

Absperrarmaturen korrigiert. Nach weiteren<br />

Fehlinterpretationen über den Zustand von Reaktorkern<br />

und Primärkreislauf war der Kern nicht mehr durch Wasser<br />

gekühlt und die dann einsetzende exotherme Reaktion<br />

zwischen Wasserdampf und dem Hüllrohrmaterial der<br />

Brenn elemente setzte zusätzliche Wärme frei. Etwa die<br />

Hälfte der Brennstabmasse im Kern schmolz bzw. wurde<br />

schwer beschädigt. Kernmassen verlagerten sich und<br />

erreichten teilweise den Boden des Reaktordruckbehälters,<br />

wo sie erstarrten. Nachdem erkannt worden war, dass eine<br />

Kernschmelze in vollem Gange war, wurden Maßnahmen<br />

zur Kernkühlung ergriffen und es gelang, die Wärmeabfuhr<br />

des TMI-2-Kerns wieder langfristig zu gewährleisten.<br />

Von den in der Anlage frei gesetzten radioaktiven<br />

Stoffen gelangte ein geringer Teil in die Umgebung.<br />

Ausgelöst durch die Ängste der mit der Freisetzung<br />

verbundenen zusätzlichen Strahlenbelastung von berechneten<br />

im Mittel 0,02 mSv – also etwa 1 % der natürlichen<br />

jährlichen Strahlenbelastung – führte das Pennsylvania<br />

Department of Health während 18 Jahren ein Register mit<br />

den Daten von mehr als 30.000 Personen, die zum Zeitpunkt<br />

des Unfalls im Umkreis von fünf Meilen um das<br />

Kernkraftwerk gelebt hatten. Dieses staatliche Register<br />

wurde im Juni 1997 geschlossen, nachdem keine ungewöhnlichen<br />

Entwicklungen bei der Gesundheit festgestellt<br />

worden waren. Mehr als ein Dutzend Studien über die<br />

Auswirkungen des Unfalls auf die physische Gesundheit<br />

gaben auch Jahre nach dem Ereignis keine Hinweise auf<br />

eine abnormal hohe Zahl von Krebsfällen in der Region um<br />

das Kernkraftwerk.<br />

Trotz aller Unzulänglichkeiten und Fehler die zum TMI-<br />

2-Unfall führten, bestätigte sich einerseits das grundlegende<br />

frühzeitig etablierte Sicherheitskonzept westlicher<br />

Kernkraftwerke: Die aus der Anlage freigesetzte Menge an<br />

radioaktiven Stoffen war gering und weder Todesopfer<br />

noch Verletzte waren zu beklagen. Und andererseits<br />

unterstreicht der Unfallablauf den Sinn hintereinander<br />

gestaffelter Sicherheitsbarrieren, die unter Berücksichtigung<br />

auch schwerer Unfälle, den Einschluss der radioaktiven<br />

Stoffe in der Anlage selbst zum Ziel haben: Das<br />

Reaktorgebäude von TMI-2 hielt stand, der Sicherheitsbehälter<br />

blieb intakt.<br />

Zudem haben Forschung und Entwicklung für die<br />

Reaktor sicherheit in den letzten 40 Jahren die Risiken<br />

im internationalen Kontext weiter minimiert: In Zahlen<br />

ausgedrückt wurde selbst für laufende Anlagen in<br />

Deutschland und anderswo ein Sicherheitsniveau erreicht,<br />

das um den Faktor 100 höher liegt, als das ursprüngliche<br />

inter nationale Referenz niveau. Daran ändert auch die<br />

Reaktorhavarie von Fukushima 20<strong>11</strong> nichts, da andere<br />

absehbare Ursachen und spezifische Rand bedingungen<br />

Auslöser waren.<br />

Sicherheit ist und bleibt dabei eine international zu<br />

lebende Aufgabe für alle Beteiligten. Kerntechnische<br />

Sicherheit und der Erhalt und die Förderung von<br />

Kompetenzen, vor allem dann, wenn sie mit exzellentem<br />

Know-how in Forschung und Entwicklung vorhanden und<br />

international anerkannt sind – wie in Deutschland –<br />

gehören auf gleicher Ebene zur gesamtgesellschaftlichen<br />

und politischen Verantwortung wie andere Ziele des<br />

Umweltschutzes. Heutige und künftige Sicherheit und<br />

Förderung von Sicherheitskultur und -technik, auch für<br />

die Kerntechnik, können und dürfen nicht Gegenstand<br />

eingeschränkten oder beschränkenden Handelns sein.<br />

Forschung und Entwicklung sollte immer im Geist der<br />

Freiheit von Wissenschaft und Technik vorgetrieben<br />

werden dürfen.<br />

Christopher Weßelmann<br />

– Chefredakteur –<br />

Editorial<br />

TMI und Lessons Learned – danach und für die Zukunft


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

Did you know...?<br />

Growing Popular Support <strong>for</strong> <strong>Nuclear</strong> <strong>Power</strong> in Belgium<br />

Forum Nucléaire, the association of the nuclear sector in Belgium,<br />

commissioned the 2019 edition of its regular opinion poll<br />

with Kantar TNS. Between 15 July and 6 September 2019<br />

756 Belgians over the age of 16 were interviewed by phone<br />

about their opinion on nuclear power and the nuclear sector<br />

in Belgium. The opinion poll shows a clear increase in support<br />

<strong>for</strong> nuclear power in Belgium compared to the 2017 edition<br />

of the poll, in particular with regard to the security of supply and<br />

the reduction of CO 2 -emissions. Below you can find a selection<br />

of results. The complete poll was published 18 October 2019<br />

on www.<strong>for</strong>umnucleaire.be and is available there in Dutch and<br />

French.<br />

For further details<br />

please contact:<br />

Nicolas Wendler<br />

KernD<br />

Robert-Koch-Platz 4<br />

10<strong>11</strong>5 Berlin<br />

Germany<br />

E-mail: presse@<br />

KernD.de<br />

www.KernD.de<br />

DID YOU EDITORIAL KNOW...?<br />

509<br />

For our country the production of nuclear energy in Belgium means …<br />

2017<br />

(n=1027)<br />

49 %<br />

13 %<br />

38 %<br />

2019<br />

(n=756)<br />

57 %<br />

More advantages than inconvenients 9 %<br />

Advantages<br />

and inconvenients equally<br />

32 %<br />

More inconvenients than advantages<br />

Are you favourable to keeping nuclear in Belgium <strong>for</strong> the production of electricity?<br />

2017<br />

(n=1027)<br />

30 %<br />

50 %<br />

19 % 2 %<br />

2019<br />

(n=756)<br />

46 %<br />

Yes, in long term too<br />

37 %<br />

Yes, but in short term (2025)<br />

16 %<br />

No<br />

1 %<br />

Don't know<br />

The current legislation <strong>for</strong>esees the closure of all nuclear power plants by 2025.<br />

Do you think that this can be realized without endangering the energy supply? (n=756)<br />

69 %<br />

No<br />

28 %<br />

Yes<br />

3 %<br />

Undecided,<br />

don't know<br />

It is good to replace nuclear power plants with gas fired power plants<br />

even if they emit much more CO 2 . (n=756)<br />

26 %<br />

I don't agree at all<br />

51 %<br />

I rather don't agree<br />

1 %<br />

I don't know<br />

<strong>11</strong> %<br />

I neither agree or disagree<br />

7 %<br />

I rather agree<br />

5 %<br />

I completely agree<br />

Figures in percent. Rounded values.<br />

Source:<br />

Forum Nucléaire<br />

Did you know...?


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

510<br />

Issue <strong>11</strong>/12 | 2019<br />

November/December<br />

CONTENTS<br />

Contents<br />

Editorial<br />

TMI and Lessons Learned – Afterwards<br />

and <strong>for</strong> the Future E/G 507<br />

Did you know...? . . . . . . . . . . . . . . . . . . . . . . . . . . . .509<br />

Inside <strong>Nuclear</strong> with NucNet<br />

Key to Unlocking Bulgaria’s Belene Project<br />

is Finding Right Financing Package 512<br />

Feature | Environment and Safety<br />

Development of Per<strong>for</strong>mance Shaping Factors <strong>for</strong> Human Error<br />

Reduction during Reactor Decommissioning Activities through<br />

the Task Analysis Method 515<br />

Environment and Safety<br />

Root Causes of the Three Mile Island Accident 521<br />

Spotlight on <strong>Nuclear</strong> Law<br />

The New Radiation Protection Law –<br />

Protection Against Radon G 525<br />

Research and Innovation<br />

Evaluation of a Double-Ended Guillotine LBLOCA Transient<br />

in a Generic Three-Loops PWR-900 with TRACE Code<br />

Coupled with DAKOTA Uncertainty Analysis 526<br />

Experiment Research on the Insurge Transient Behavior<br />

of Gas-steam Pressurizer under Various Pressure 533<br />

Decommissioning and Waste Management<br />

Decommissioning & Dismantling of the Rossendorf<br />

Research Reactor RFR | Part 1 G 537<br />

First On-site Demonstration of Laser- based Decontamination<br />

Technology in Germany 543<br />

Report<br />

The 25 th Edition of the Frédéric Joliot/Otto Hahn Summer School<br />

on <strong>Nuclear</strong> Reactors “Physics, Fuels and Systems“ 549<br />

Special Topic | A Journey Through 50 Years AMNT<br />

Protection of Man and Environment – <strong>Nuclear</strong> Usage<br />

Outside of Energy Sector G 550<br />

KTG Inside . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .555<br />

Cover:<br />

Korea Kori NPP.<br />

Copyright: ©Korea Kori NPP<br />

News . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .556<br />

<strong>Nuclear</strong> Today<br />

Taking a Leaf out of Greta’s Climate Change Book 562<br />

G<br />

E/G<br />

= German<br />

= English/German<br />

Imprint 542<br />

Insert: INFORUM – Seminarprogramm 2020<br />

Contents


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

Feature<br />

Environment and Safety<br />

515 Development of Per<strong>for</strong>mance Shaping<br />

Factors <strong>for</strong> Human Error Reduction<br />

during Reactor Decommissioning Activities<br />

through the Task Analysis Method<br />

5<strong>11</strong><br />

CONTENTS<br />

Byung-Sik Lee, Hyun-Jae Yoo and Chang-Su Nam<br />

Environment and Safety<br />

521 Root Causes of the Three Mile Island Accident<br />

Zoltan R. Rosztoczy<br />

Research and Innovation<br />

526 Evaluation of a Double-Ended Guillotine LBLOCA Transient<br />

in a Generic Three-Loops PWR-900 with TRACE Code<br />

Coupled with DAKOTA Uncertainty Analysis<br />

Andrea Bersano and Fulvio Mascari<br />

Decommissioning and Waste Management<br />

537 Decommissioning & Dismantling<br />

of the Rossendorf Research Reactor RFR | Part 1<br />

Reinhard Knappik, Klaus Geyer, Sven Jansen and Cornelia Graetz<br />

543 First On-site Demonstration<br />

of Laser- based Decontamination Technology in Germany<br />

Torsten Kahl, Georg Greifzu, Carsten Friedrich, Christian Held, Marion Herrmann,<br />

Wolfgang Lippmann and Antonio Hurtado<br />

Contents


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

512<br />

INSIDE NUCLEAR WITH NUCNET<br />

Key to Unlocking Bulgaria’s Belene<br />

Project is Finding Right Financing Package<br />

Last year the government decided to <strong>for</strong>mally revive the nuclear power station project. The process is now<br />

underway to select an investor.<br />

The History of Belene<br />

The project goes back to the mid-1970s when a<br />

two-unit nuclear station at Belene, on the<br />

Danube river in the north of the country, was planned by<br />

Bulgaria’s communist government. Site work began in<br />

1981 and construction of the first Russian-supplied<br />

VVER-1000 began in 1987. This was aborted in 1991 due to<br />

lack of funds and environmental and financial concerns.<br />

The project was revived in 2008, but <strong>for</strong>mally abandoned<br />

in 2012 after failing to find investors and with Sofia facing<br />

pressure from Washington and Brussels to limit its energy<br />

dependence on Russia, which was under contract to build<br />

the facility. The estimated €10bn cost of the project was<br />

too high to be funded by Bulgaria alone. In June 2018, the<br />

government decided to <strong>for</strong>mally revive the project. A call<br />

<strong>for</strong> interest was published and seven companies, three of<br />

which are Bulgarian, applied to invest in the project.<br />

Russia’s state-owned Rosatom, China’s state-owned CNNC<br />

and state-run Korea Hydro and <strong>Nuclear</strong> <strong>Power</strong> Company<br />

all filed applications confirming their interest. Press<br />

reports said that among the three Bulgarian companies<br />

there are two consortia with interests in energy that have<br />

been <strong>for</strong>med specifically <strong>for</strong> the Belene project and a third<br />

company, IPK-UP, which is registered in Kozloduy, but<br />

lacks any registered assets or income. The seventh<br />

company that filed its interest is Karlsruhe-registered<br />

Becktron-Liaz Technical Engineering.<br />

Bulgaria’s <strong>Nuclear</strong> Status<br />

Bulgaria, which joined the EU in 2007, closed four 440-MW<br />

VVER reactors at the Kozloduy nuclear station <strong>for</strong> safety<br />

reasons as part of its accession treaty with Brussels.<br />

Kozloduy has two newer 1,000-MW VVER reactors in commercial<br />

operation, supplying about 34 % of the country’s<br />

electricity. These two units have been renovated with<br />

financing from Euratom, the US ExportImport Bank,<br />

Citibank and Russia’s Roseximbank. Kozloduy-6 recently<br />

received a licence to operate <strong>for</strong> another 10 years until<br />

2029; Kozloduy-5 received a 10-year extension in 2017.<br />

Reviving the Belene Project<br />

The idea to revive the Belene project was born during<br />

negotiations with the European Union on Bulgaria’s<br />

accession. The centrist government at the time said Belene<br />

could replace generation that would be lost with the<br />

retirement of the four older Kozloduy units. In 2005, a<br />

socialist-led government revived Belene and a tendering<br />

procedure <strong>for</strong> a 2000-MW station was approved. A year<br />

later, Bulgaria chose an offer by a proposed consortium<br />

between Atomstroyexport (ASE) of Russia, Areva (now<br />

Framatome) of France and Siemens of Germany <strong>for</strong> the<br />

deployment of two Generation III VVER-1000 PWRs. In<br />

2008, Bulgaria signed a contract with ASE <strong>for</strong> the<br />

design, construction and commissioning of the two units.<br />

However, in 2012 a new government headed by current<br />

prime-minister Boyko Borissov cancelled Belene after<br />

failing to find financing. Russia took Bulgaria to international<br />

arbitration over the cancellation.<br />

Bulgaria again began looking <strong>for</strong> ways to revive Belene<br />

after it lost the arbitration and paid € 600 m in 2016 in<br />

compensation to ASE <strong>for</strong> components which had already<br />

been ordered. The 2016 decision by the Geneva-based<br />

<strong>International</strong> Court of Arbitration of the <strong>International</strong><br />

Chamber of Commerce said Bulgarian state energy<br />

company Nationalna Elektricheska Kompania (NEK) had to<br />

pay € 620 m to ASE and assume ownership of the components.<br />

The price was reduced after interest adjustments.<br />

By the beginning of 2018 Russia had delivered most of the<br />

equipment that was at the centre of the court ruling,<br />

including two reactor pressure vessels, the RPV heads, the<br />

full steam generator sets and the main pipelines. The<br />

equipment is stored at the Belene site.<br />

A Question Of Financing<br />

According to energy minister Temenuzhka Petkova Bulgaria<br />

wants to build the two units within 10 years and at a cost of<br />

up to € 10 bn. However, the exact nature of how the station<br />

will be financed remains unclear. Ms Petkova told parliament<br />

that the government would like state energy company<br />

NEK to have a “blocking stake” – potentially giving it a veto if<br />

necessary – in the project, but only by contributing existing<br />

assets and infrastructure at the Belene site, valued at<br />

€ 1.5 bn. The government’s policy is to attract private investment<br />

<strong>for</strong> the project with no state guarantees or long-term<br />

electricity purchase contracts. Critics have said that would<br />

be difficult given the magnitude of nuclear new-build<br />

projects.<br />

The Need For <strong>Nuclear</strong><br />

Bulgaria says it needs nuclear because it is heavily dependent<br />

on imported primary energy resources and uses the most<br />

electricity relative to GDP in the EU. Bulgaria imports almost<br />

100 % of its oil and gas, 100 % of its nuclear fuel and about<br />

35 to 40 % of its coal. It exports electricity to neighbouring<br />

countries, but the electricity sector is dependent on imports<br />

of primary energy, mainly from Russia. Russia sees Bulgaria<br />

as a transit point into the rest of Europe <strong>for</strong> Russian energy<br />

sources because it bypasses Ukraine.<br />

Bulgaria is under pressure by the EU to reduce carbon<br />

emissions in line with the bloc’s climate ambitions. Bulgaria<br />

generates about 40 % of its electricity from coal and new<br />

nuclear could replace a major proportion of this. The government<br />

has also hinted that new reactors might be needed<br />

to replace the two Kozloduy units, which are scheduled to<br />

be retired in 2027 and 2029. A report by the Bulgarian<br />

Academy of Science said electricity demand in Bulgaria is<br />

expected to increase after 2030 and new nuclear could be<br />

economically viable if construction costs are kept in check.<br />

What Happens Next?<br />

Mr Borissov’s ruling party and its allies command a<br />

com<strong>for</strong>table majority so plans to build new units at Belene<br />

would not appear to pose a political problem. The<br />

opposition socialists also support nuclear energy. Public<br />

support is high, with almost two-thirds of Bulgarians<br />

voting in support of nuclear in a 2013 referendum,<br />

Inside <strong>Nuclear</strong> with NucNet<br />

Key to Unlocking Bulgaria’s Belene Project is Finding Right Financing Package


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

although the result was not binding because of the low<br />

turnout. The EU and the US have urged Bulgaria to take<br />

stock of its dependence on Russian gas and oil and<br />

encouraged it to seek Western investors <strong>for</strong> Belene. The<br />

key is to find the right financing package. China is said to<br />

be asking <strong>for</strong> financial guarantees from Sofia in return <strong>for</strong><br />

its participation, but Sofia favours the creation of some<br />

<strong>for</strong>m of public- private partnership. Any financing scheme<br />

will need to be approved by the EU’s state aid watchdog.<br />

A risk analysis of the Belene project, prepared by the<br />

Vienna <strong>International</strong> Centre <strong>for</strong> <strong>Nuclear</strong> Competence <strong>for</strong><br />

the Bulgarian Atomic Forum, recommended that the<br />

government reconsider its position of non-participation in<br />

the project. Globally, there is no precedent in which nuclear<br />

projects are implemented without state involvement, the<br />

analysis said. Different <strong>for</strong>ms and levels of participation are<br />

possible, including direct sponsorship, loan guarantees, tax<br />

credits, long-term energy purchase agreements and price<br />

differences, the analysis noted. Another option is to use the<br />

Belene equipment <strong>for</strong> a new unit at Kozloduy, but this<br />

would incur additional costs. Abandoning the project and<br />

selling the equipment as scrap would result in a loss of<br />

about $ 1.5 m. The sale of the project is also a possibility to<br />

companies from Russia or China.<br />

Whoever the project owner and investors are, the<br />

government has said the main contractor <strong>for</strong> the nuclear<br />

part of the project will be Russia’s Rosatom, because of the<br />

nature of the technology already paid <strong>for</strong> by Bulgaria.<br />

Turbine hall equipment and instrumentation and control<br />

systems could be supplied by US-based General Electric<br />

and France’s Framatome. Both companies participated in<br />

the recent tender, but as equipment suppliers rather than<br />

investors.<br />

Author<br />

David Dalton<br />

Advertisement<br />

INSIDE NUCLEAR WITH NUCNET 513<br />

Radioaktive Abfälle bis zu ihrer Endlagerung nach höchsten Sicherheitsstandards aufzubewahren – das ist unser Auftrag. Als Gesellschaft des Bundes gewährleisten<br />

wir den sicheren und zuverlässigen Betrieb von Zwischenlagern für hochradioaktive Abfälle. Ab 2020 werden wir zudem zwölf Zwischenlager mit<br />

schwach- und mittelradioaktiven Abfällen an den Standorten deutscher Kernkraftwerke führen. Dadurch liegt die Verantwortung für die Zwischenlagerung<br />

der radioaktiven Abfälle der Energieversorgungsunternehmen zentral in unserer Hand. Neben bewährter und solider Technik sind es vor allem unsere<br />

Mitarbeiterinnen und Mitarbeiter, die eine sichere und zuverlässige Zwischenlagerung an zahlreichen Standorten in Deutschland gewährleisten. Für diese<br />

verantwortungsvolle Aufgabe suchen wir Verstärkung.<br />

Verantwortung übernehmen.<br />

Anlagensicherheit<br />

Qualität<br />

Schutz<br />

Zuverlässigkeit<br />

Für unsere Organisationseinheit Betrieb an unserem Standort in Grafenrheinfeld suchen wir zum nächstmöglichen Zeitpunkt einen<br />

Abteilungsleiter/Leiter des Zwischenlagers (m/w/d)<br />

Wir bieten Ihnen die Möglichkeit, Ihr Wissen in ein interessantes und abwechslungsreiches Tätigkeitsfeld einzubringen. Spannende Projekte und<br />

verantwortungsvolle Aufgaben warten auf Sie.<br />

Fühlen Sie sich angesprochen? Unter https://karriere.bgz.de finden Sie die Details zu Ihren Aufgaben und An<strong>for</strong>derungen sowie die Möglichkeit,<br />

sich direkt online zu bewerben. Bitte geben Sie dabei Ihre Gehaltsvorstellung sowie Ihren frühestmöglichen Eintrittstermin an.<br />

BGZ Gesellschaft für Zwischenlagerung mbH<br />

Personalwesen • Jens Abker • Frohnhauser Straße 67 • 45127 Essen • Telefon 0201 2796-16<strong>11</strong><br />

www.bgz.de<br />

Inside <strong>Nuclear</strong> with NucNet<br />

Key to Unlocking Bulgaria’s Belene Project is Finding Right Financing Package


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

CALENDAR 514<br />

Calendar<br />

2020<br />

12.01. – 16.01.2020<br />

<strong>Power</strong> Plant Simulation Conference. Chattanooga,<br />

Tennessee United States, Society <strong>for</strong> Modeling &<br />

Simulation <strong>International</strong>, www.scs.org<br />

13.01. – 14.01.2020<br />

ICNPPS 2020 – 14 th <strong>International</strong> Conference on<br />

<strong>Nuclear</strong> <strong>Power</strong> Plants Safety. Zurich, Switzerland,<br />

Waset, www.waset.org<br />

20.01. – 21.01.2020<br />

6 th Central & Eastern Europe <strong>Nuclear</strong> Industry<br />

Congress 2020. Prague, Czech Republic, SZWGroup,<br />

www.szwgroup.com<br />

22.01.2020<br />

31.03. – 03.04.2020<br />

ATH'2020 – <strong>International</strong> Topical Meeting on<br />

Advances in Thermal Hydraulics. Paris, France,<br />

Société Francaise d’Energie Nucléaire (SFEN),<br />

www.sfen-ath2020.org<br />

19.04. – 24.04.2020<br />

<strong>International</strong> Conference on Individual<br />

Monitoring. Budapest, Hungary, EUROSAFE,<br />

www.eurosafe-<strong>for</strong>um.org<br />

20.04. – 22.04.2020<br />

World <strong>Nuclear</strong> Fuel Cycle 2020. Stockholm,<br />

Sweden, WNA World <strong>Nuclear</strong> Association,<br />

www.world-nuclear.org<br />

06.06. – 12.06.2020<br />

ATALANTE 2020. Montpellier, France, CEA,<br />

www.atalante2020.org<br />

08.06. – 12.06.2020<br />

20 th WCNDT – World Conference on<br />

Non-Destructive Testing. Seoul, Korea, EPRI,<br />

www.wcndt2020.com<br />

15.06. – 19.06.2020<br />

<strong>International</strong> Conference on <strong>Nuclear</strong> Knowledge<br />

Management and Human Resources Development:<br />

Challenges and Opportunities. Moscow,<br />

Russian Federation, IAEA, www.iaea.org<br />

15.06. – 20.07.2020<br />

<strong>Nuclear</strong> Fuel Supply Forum. Washington, D.C., USA,<br />

NEI, www.nei.org<br />

WNU Summer Institute 2020. Japan, World <strong>Nuclear</strong><br />

University, www.world-nuclear-university.org<br />

10.02. – 14.02.2020<br />

01.09. – 04.09.2020<br />

37 th Short Courses on Multiphase Flow. Zurich,<br />

Switzerland, Swiss Federal Institute of Technology<br />

ETH, www.lke.mavt.ethz.ch<br />

IGORR – Standard Cooperation Event in the <strong>International</strong><br />

Group on Research Reactors Conference.<br />

Kazan, Russian Federation, IAEA, www.iaea.org<br />

10.02. – 14.02.2020<br />

09.09. – 10.09.2020<br />

ICONS2020: <strong>International</strong> Conference on <strong>Nuclear</strong><br />

Security. Vienna, Austria, The <strong>International</strong> Atomic<br />

Energy Agency (IAEA), www.iaea.org<br />

02.03. – 06.03.2020<br />

<strong>International</strong> Workshop on Developing a National<br />

Framework <strong>for</strong> Managing the Response to<br />

<strong>Nuclear</strong> Security Events. Madrid, Spain, IAEA,<br />

www.iaea.org<br />

08.03. – 12.03.2020<br />

WM Symposia – WM2019. Phoenix, AZ, USA,<br />

www.wmsym.org<br />

08.03. – 13.03.2020<br />

IYNC2020 – The <strong>International</strong> Youth <strong>Nuclear</strong><br />

Congress. Sydney, Australia, IYNC, www.iync2020.org<br />

18.03. – 20.03.2020<br />

12. Expertentreffen Strahlenschutz. Bayreuth,<br />

Germany, TÜV SÜD, www.tuev-sued.de<br />

25.03. – 27.03.2020<br />

H2020 McSAFE Training Course. Eggenstein-<br />

Leopoldshafen, Germany, Karlsruher Institute für<br />

Technologie (KIT), www.mcsafe-h2020.eu<br />

29.03. – 02.04.2020<br />

PHYSOR2020 — <strong>International</strong> Conference on<br />

Physics of Reactors 2020. Cambridge, United<br />

Kingdom, <strong>Nuclear</strong> Energy Group,<br />

www.physor2020.com<br />

31.03. – 02.04.2020<br />

4 th CORDEL Regional Workshop on<br />

Harmonization to support the Operation and<br />

New Build fo NPPs including SMRs. Lyon, France,<br />

NUGENIA, www.nugenia.org<br />

KERNTECHNIK 2020.<br />

Berlin, Germany, KernD and KTG,<br />

www.kerntechnik.com<br />

05.05. – 06.05.2020<br />

10.05. – 15.05.2020<br />

ICG-EAC Annual Meeting 2020. Helsinki, Finland,<br />

ICG-EAC, www.icg-eac.org<br />

<strong>11</strong>.05. – 15.05.2020<br />

<strong>International</strong> Conference on Operational Safety<br />

of <strong>Nuclear</strong> <strong>Power</strong> Plants. Beijing, China, IAEA,<br />

www.iaea.org<br />

12.05. – 13.05.2020<br />

INSC — <strong>International</strong> <strong>Nuclear</strong> Supply Chain<br />

Symposium. Munich, Germany, TÜV SÜD,<br />

www.tuev-sued.de<br />

17.05. – 22.05.2020<br />

BEPU2020, Giardini Naxos. Sicily, Italy, NINE,<br />

www.nineeng.com<br />

18.05. – 22.05.2020<br />

SNA+MC2020 – Joint <strong>International</strong> Conference on<br />

Supercomputing in <strong>Nuclear</strong> Applications + Monte<br />

Carlo 2020, Makuhari Messe. Chiba, Japan, Atomic<br />

Energy Society of Japan, www.snamc2020.jpn.org<br />

20.05. – 22.05.2020<br />

<strong>Nuclear</strong> Energy Assembly. Washington, D.C., USA,<br />

NEI, www.nei.org<br />

31.05. – 03.06.2020<br />

13 th <strong>International</strong> Conference of the Croatian<br />

<strong>Nuclear</strong> Society. Zadar, Croatia, Croatian <strong>Nuclear</strong><br />

Society, www.nuclear-option.org<br />

VGB Congress 2020 – 100 Years VGB. Essen,<br />

Germany, VGB <strong>Power</strong>Tech e.V., www.vgb.org<br />

09.09. – <strong>11</strong>.09.2020<br />

World <strong>Nuclear</strong> Association Symposium 2020.<br />

London, United Kingdom, WNA World <strong>Nuclear</strong><br />

Association, www.world-nuclear.org<br />

16.09. – 18.09.2020<br />

3 rd <strong>International</strong> Conference on Concrete<br />

Sustainability. Prague, Czech Republic, fib,<br />

www.fibiccs.org<br />

16.09. – 18.09.2020<br />

<strong>International</strong> <strong>Nuclear</strong> Reactor Materials<br />

Reliability Conference and Exhibition.<br />

New Orleans, Louisiana, USA, EPRI, www.snetp.eu<br />

28.09. – 01.10.2020<br />

NPC 2020 <strong>International</strong> Conference on <strong>Nuclear</strong><br />

Plant Chemistry. Antibes, France, SFEN Société<br />

Française d’Energie Nucléaire,<br />

www.sfen-npc2020.org<br />

28.09. – 02.10.2020<br />

Jahrestagung 2020 – Fachverband Strahlenschutz<br />

und Entsorgung. Aachen, Germany, Fachverband<br />

für Strahlenschutz, www.fs-ev.org<br />

26.10. – 30.10.2020<br />

NuMat 2020 – 6 th <strong>Nuclear</strong> Materials Conference.<br />

Gent, Belgium, IAEA, www.iaea.org<br />

09.<strong>11</strong>. – 13.<strong>11</strong>.2020<br />

<strong>International</strong> Conference on Radiation Safety:<br />

Improving Radiation Protection in Practice.<br />

Vienna, Austria, IAEA, www.iaea.org<br />

30.03. – 01.04.2020<br />

INDEX <strong>International</strong> <strong>Nuclear</strong> Digital Experience.<br />

Paris, France, SFEN Société Française d’Energie<br />

Nucléaire, www.sfen-index2020.org<br />

This is not a full list and may be subject to change.<br />

Calendar


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

Feature | Environment and Safety<br />

Development of Per<strong>for</strong>mance Shaping<br />

Factors <strong>for</strong> Human Error Reduction during<br />

Reactor Decommissioning Activities<br />

through the Task Analysis Method<br />

Byung-Sik Lee, Hyun-Jae Yoo and Chang-Su Nam<br />

In this study, we present the process of deriving Per<strong>for</strong>mance Shaping Factors (PSFs) and developing a classification<br />

system <strong>for</strong> them to account <strong>for</strong> human errors that may occur during the decommissioning activities due to the shutdown<br />

of the Kori <strong>Nuclear</strong> <strong>Power</strong> Plant Unit 1. Furthermore, Human Reliability Analysis (HRA) <strong>for</strong> the reduction of human<br />

errors was per<strong>for</strong>med on the Reactor Pressure Vessel Internal (RPVI) cutting work. Task Analysis was conducted on the<br />

RPVI decommissioning activities and possible human errors were identified. The PSF selection criteria that affect the<br />

decommissioning activities were set up based on the human errors identified through the results of the Task Analysis<br />

and review of the PSFs applied to the field of nuclear energy power generation. Finally, the PSFs were derived and their<br />

classification system was developed.<br />

1 Introduction<br />

In recent years, industries have experienced a reduction in<br />

the rate of accidents due to technical problems because of<br />

the development of technologies <strong>for</strong> accident prevention.<br />

However, it is difficult to evaluate the reliability of such<br />

systems without considering the impact of human errors<br />

by their operators. In particular, according to real statistical<br />

accident data, about 60 to 90 % of all accidents are due to<br />

human errors, while the remainder is due to technical<br />

errors in the system [1-3]; thus, it is evident that even<br />

minor operator errors in real life can severely undermine<br />

the operational per<strong>for</strong>mance of the system. Furthermore,<br />

in large or crucial systems, such as large power plants<br />

( including nuclear power plants), air transportation, and<br />

railways, human error can lead to large and more harmful<br />

accidents; there<strong>for</strong>e, the reduction of human errors in the<br />

case of such systems requires significant attention [4].<br />

At present, Korea is preparing to safely and economically<br />

decommission Unit 1 of the Kori <strong>Nuclear</strong> <strong>Power</strong> Plant,<br />

whose operation was permanently suspended in June<br />

2017. Various technological developments are being<br />

conducted <strong>for</strong> the decommissioning of Kori Unit 1 with the<br />

primary objective of ensuring the safety of human life and<br />

property and improving economic efficiency. There<strong>for</strong>e, it<br />

is important to establish countermeasures to decrease<br />

human errors during this decommissioning, because these<br />

human errors not only hinder the safety of the operators,<br />

but also affect the economics of the project by causing<br />

delays in the decommissioning schedule. In order to do so,<br />

human error trends and influencing factors need to be<br />

identified through Human Reliability Analysis (HRA) [1];<br />

in particular, HRA is used to identify, model, and quantify<br />

the likelihood of human error [3]. Figure 1 shows the<br />

flowchart <strong>for</strong> HRA that needs to be applied <strong>for</strong> the cutting<br />

of the Reactor Pressure Vessel Internal (RPVI) components,<br />

which is the decommissioning activity targeted in this<br />

study.<br />

It is important to conduct an HRA <strong>for</strong> the cutting<br />

operation of RPVI components, because they have the<br />

highest levels of radioactivity among all the other parts of<br />

the unit, and this operation is highly susceptible to human<br />

errors because of the use of remote equipment, among<br />

others. There<strong>for</strong>e, in particular, the objective of this study<br />

is to obtain the Per<strong>for</strong>mance Shaping Factors (PSFs) that<br />

| Fig. 1.<br />

Procedure to per<strong>for</strong>m the HRA in the decommissioning activity [5].<br />

affect RPVI cutting and develop a classification system<br />

<strong>for</strong> these PSFs.<br />

Task characteristics, procedures, and in<strong>for</strong>mation on<br />

the decommissioning of RPVI components were identified<br />

by reviewing related domestic and <strong>for</strong>eign literature as<br />

well as by examining previous cases of decommissioning of<br />

overseas nuclear power plants. In addition, task analysis<br />

<strong>for</strong> the decommissioning of the RPVI was conducted<br />

to identify probable human errors. First, potential PSFs<br />

were identified <strong>for</strong> this study based on a combination of<br />

the expected human errors from the detailed task<br />

analysis and the general PSFs from the evaluation of<br />

PSFs in nuclear facilities. Then, the selection criteria <strong>for</strong><br />

the PSFs affecting the decommissioning activities were<br />

established. Finally, the PSFs were derived to construct<br />

the classification system.<br />

FEATURE | ENVIRONMENT AND SAFETY 515<br />

Feature<br />

Development of Per<strong>for</strong>mance Shaping Factors <strong>for</strong> Human Error Reduction during Reactor Decommissioning Activities through the Task Analysis Method ı Byung-Sik Lee, Hyun-Jae Yoo and Chang-Su Nam


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

FEATURE | ENVIRONMENT AND SAFETY 516<br />

Task<br />

Task In<strong>for</strong>mation<br />

and Requirements<br />

Task to Consider<br />

Working Time<br />

Teamwork and<br />

Communication<br />

Workload<br />

Task Support<br />

Workplace Factors<br />

Hazard Identification<br />

Expected PSFs<br />

2 Task Analysis<br />

Task Analysis (TA) is the initial step in the case of human<br />

error assessment. It provides the characteristics of different<br />

tasks, their vulnerabilities, and properties by understanding<br />

the objectives, per<strong>for</strong>mance methods, scopes of<br />

the tasks, and procedures involved [6]. In addition, TA<br />

helps eliminate the conditions that can cause errors be<strong>for</strong>e<br />

they occur by providing detailed in<strong>for</strong>mation about the<br />

tasks as well as other in<strong>for</strong>mation <strong>for</strong> predicting and<br />

preventing errors.<br />

2.1 TA Method<br />

Although several TA methods exist, considering the<br />

physical characteristics (complexity) and Human Machine<br />

Interface (HMI) aspect (using remote devices) of the<br />

decommissioning activities, we utilized the Hierarchical<br />

TA (HTA) method.<br />

HTA is a systematic and detailed TA method that is used<br />

to achieve task objectives. It is appropriate <strong>for</strong> not only<br />

identifying detailed task configuration and conditions, but<br />

also expressing complex task steps as a simple, hierarchical<br />

structure. Furthermore, the HTA method was used because<br />

it can easily describe the characteristics of the work<br />

involved and identify significant in<strong>for</strong>mation about the<br />

Title<br />

| Tab. 1.<br />

Details of tasks to be per<strong>for</strong>med <strong>for</strong> TA.<br />

• Task influencing factors<br />

(cutting size, number of cutting operations, precision, etc.)<br />

• Task output requirements<br />

• Record feedback to indicate adequacy of action taken<br />

• Alarms and warnings<br />

• Actions to be taken<br />

• Equipment needed (type, size, per<strong>for</strong>mance,<br />

required utility, equipment usage constraint, etc.)<br />

• Task frequency and required accuracy<br />

• Physical position of the operator<br />

(standing, sitting, squatting, etc.)<br />

• Biomechanics<br />

• Movement<br />

(lifting, pushing, rotating, pulling, swaying, etc.)<br />

• Force required<br />

• Unit working time based on “work contents”<br />

• Additional work hours taking into account “work support”<br />

and “workplace environmental conditions”<br />

• Number of work shifts and workers per work shift<br />

• Cooperation required between the teams per<strong>for</strong>ming<br />

the work<br />

• Personal communication <strong>for</strong> monitoring or<br />

taking control actions<br />

• Cognitive workload<br />

• Physical workload<br />

• Overlap of task requirements (serial versus parallel task<br />

elements)<br />

• Special and protective clothing <strong>for</strong> work<br />

• Job aids, procedures, or reference materials needed<br />

• Required auxiliary tools and equipment<br />

• Ingress and egress paths to the work site<br />

• Workspace required to per<strong>for</strong>m the task<br />

• Typical workplace environmental conditions<br />

(e.g. lighting, temperature, noise, etc.)<br />

• Work breaks taking into account “work support” and<br />

“ workplace environmental conditions”<br />

• Identify work-related hazards,<br />

e.g. potential personal injury hazards<br />

Examples include:<br />

• Stress<br />

• Time pressure (critical path operations)<br />

• Extreme environmental conditions<br />

• Reduced staffing<br />

HMI, communication and decision making processes, as<br />

well as possible accidents. The HTA method involves<br />

describing the manner in which tasks need to be per<strong>for</strong>med<br />

after establishing their overall objectives and classifying<br />

them into their sub-tasks [6].<br />

Using a tabular <strong>for</strong>mat to per<strong>for</strong>m HTA allows one to<br />

express complex tasks that require significant skill in a<br />

suitable manner, because one can include detailed notes, if<br />

necessary. In this study, we comprehensively reviewed<br />

various items, such as HMI, Communication, Time, and<br />

Accident, <strong>for</strong> the decommissioning activity in a tabular<br />

<strong>for</strong>mat; this is shown in Table 1 [5].<br />

2.2 Target Decommissioning Activity <strong>for</strong> TA<br />

In general, one of the most challenging tasks during plant<br />

decommissioning is believed to be the removal of the<br />

highly radioactive internal components of the reactor pressure<br />

vessel (RPV); this is true <strong>for</strong> Kori Unit 1 as well. In<br />

addition, another reason that this is one of the most<br />

difficult activities is because these radioactive components<br />

must be dismantled and cut underwater owing to the<br />

severe radiological conditions of the RPVI components<br />

[7-8]. There<strong>for</strong>e, it is recommended that the reactor<br />

internals be removed as early as possible in the plant<br />

dismantling sequence, so that these water systems and<br />

their associated support systems can be released <strong>for</strong><br />

decommissioning, which minimizes the costs associated<br />

with maintaining these systems in operation after<br />

permanent plant shutdown [8].<br />

The cross-section of the RPV with the primary internal<br />

components at Kori Unit 1 is shown in Figure 2. As can be<br />

seen from the figure, the internal structures adjacent to the<br />

core barrel active region are the most highly activated, and<br />

in most cases, include intermediate level waste components<br />

that might require removal prior to the disposal of the<br />

remainder of the RPV and reactor internal components<br />

[7]. Thus, in this study, this RPV internal segmentation<br />

activity is selected from among the various dismantling<br />

activities in Kori Unit 1.<br />

Furthermore, in this study, the TA was per<strong>for</strong>med <strong>for</strong><br />

the most complex and highly radioactive RPVI cutting task<br />

among various disassembly activities by using the HTA<br />

method. The sequence of operations <strong>for</strong> each sub-activity<br />

in this target task is listed in Table 2.<br />

2.3 TA Results<br />

The TA <strong>for</strong> the RPVI Dismantling Activity was per<strong>for</strong>med as<br />

per the activities listed in Table 2 based on the items listed<br />

in Table 1. In our study, this analysis was per<strong>for</strong>med <strong>for</strong><br />

each of the 10 sub-activities. The summary of the TA <strong>for</strong><br />

the RPVI Dismantling Activity is given as follows.<br />

p In general, in the decommissioning of nuclear power<br />

plants, the cutting of parts in the RPVI is the most<br />

complicated and difficult task during the dismantling<br />

process. There<strong>for</strong>e, the influence on the internal factors<br />

of the workers was evaluated in order to have a relatively<br />

high value in terms of operator internal response.<br />

p This kind of dismantling operation, which is complex<br />

and requires accuracy and reliability, is significantly<br />

influenced by the internal and external characteristics<br />

of the worker. There<strong>for</strong>e, sufficient education and<br />

training is required. However, as the driving principle<br />

and operation method of these cutting equipment and<br />

accessories ( cutting equipment, remote control device,<br />

display, auxiliary equipment, etc.) are not complicated<br />

and operation is relatively simple, an operator is not<br />

required to have considerable experience in using them.<br />

Feature<br />

Development of Per<strong>for</strong>mance Shaping Factors <strong>for</strong> Human Error Reduction during Reactor Decommissioning Activities through the Task Analysis Method ı Byung-Sik Lee, Hyun-Jae Yoo and Chang-Su Nam


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

No Sub activity Activity Description<br />

1 Control Rod Guide Tube Upper Area Cutting<br />

and Packaging<br />

2 Control Rod Guide Tube Lower Area Cutting<br />

and Packaging<br />

1) Lift up the Upper Internal Assembly and fix it to the turntable<br />

2) Cut the control rod guide tube upper area<br />

3) Transfer and package the cut section to a storage container<br />

1) Cut the control rod guide tube lower area<br />

2) Transfer and package the cut section to a storage container<br />

3 Upper Plate Cutting and Packaging 1) Move and release the Upper Support Plate in an empty space in the reactor tank<br />

2) Cut the Upper Core Plate fixed to the turntable<br />

3) Fix the Upper Core Plate to the turntable and cut the Upper Support Plate<br />

4) Transfer and package the cut pieces to a storage container<br />

4 Baffle Fixed Bolt Head Cutting 1) Install the mechanical drill <strong>for</strong> Baffle Separation<br />

2) Cut the Baffle Fixing Bolt Head by placing the mechanical drill inside the RPV<br />

5 Baffle Cutting and Packaging 1) Lift the Baffle and remove it from the Former<br />

2) After fixing it to the turntable, cut the Baffle<br />

3) Transfer and package the cut Baffle pieces to a storage container<br />

6 Core Barrel Lower Area Cutting 1) Lift up the Lower Internal Assembly and fix it to the turntable<br />

2) Rotate the turntable to cut the Lower Internal Assembly<br />

3) Lift the upper area of the Lower Internal Assembly into the Vessel<br />

7 Lower Internal Structure Assembly Cutting<br />

and Packaging<br />

8 Thermal Shield Separation, Cutting and<br />

Packaging<br />

1) Cut the Instrument Nozzle from the Core Support Structure Assembly<br />

2) Transfer and package the cut nozzle to a storage container<br />

3) Cut and package the tie plate fixed to the Turntable<br />

4) Fix the Lower Core Plate to the Turntable and cut it<br />

5) Transfer and package the cut pieces to a storage container<br />

1) Lift the upper area of the Lower Internal Assembly and fix it to the turntable<br />

2) Separate the Thermal Shield by cutting the Bolt Head<br />

3) Release the removed Core barrels from the Thermal Shield inside the vessel<br />

4) After fixing the Thermal Shield to the Turntable, remove the Irradiation Specimen Guide<br />

5) Cut the Turntable Thermal Shield Upper and Lower Panels<br />

9 Former Separation 1) Lift the Core Barrel to the turntable and fix it<br />

2) Cutting the Former fixing bolt head outside the Core Barrel<br />

3) Separate the Former from the Core Barrel<br />

4) Transfer and package the separated Former to a storage container<br />

10 Core Barrel Cutting and Packaging 1) Fix the Core Barrel to the turntable and cut it<br />

2) Temporarily release the cut Upper Core Barrel in the Vessel<br />

3) Segment the Lower part of the Core Barrel fixed to the turntable<br />

4) Transfer and package the cut pieces to a storage container<br />

5) Repeat the procedure <strong>for</strong> the cutting the remaining Core Barrel<br />

FEATURE | ENVIRONMENT AND SAFETY 517<br />

| Tab. 2.<br />

Task Description of RPVI Dismantling Activity.<br />

p Considering the characteristics of the work (equipment<br />

and facilities, the object to be cut, and clothing <strong>for</strong><br />

radiation protection in the work environment), a<br />

detailed work plan must be established in advance.<br />

Further, as this cutting work is time-consuming, the<br />

psychological and physical influences that the supervisor<br />

and the worker can receive are considerable.<br />

p If the cutting activity is dangerous, takes a long time,<br />

and has associated time constraints, it should be<br />

per<strong>for</strong>med during the day/night time. In this case,<br />

various difficulties (such as break time, clothing<br />

discom<strong>for</strong>t, and physio logical factors) are generated.<br />

Because these difficulties have a significant impact on<br />

the internal and external factors affecting the worker,<br />

much cooperation and communication is required<br />

between the worker and the supervisor in this working<br />

environment.<br />

p The radiation and the physical environment of the<br />

workplace are the major risk factors <strong>for</strong> the workers,<br />

and the influence of these working environments on the<br />

internal and external factors of the workers was<br />

con siderable.<br />

p <strong>Nuclear</strong> decommissioning work is not a frequently<br />

per<strong>for</strong>med task. There<strong>for</strong>e, workers may have insufficient<br />

experience and education/training. There<strong>for</strong>e,<br />

after the decommissioning activity has been carried<br />

out, it is necessary to feedback the results of the work to<br />

be reflected in the necessary work procedures and to be<br />

managed as experience data.<br />

| Fig. 2.<br />

Internal components <strong>for</strong> the RPV in Kori Unit 1 [7].<br />

3 PSFs in the Decommissioning Activities<br />

Because the workers’ activities are the fundamental factors<br />

that renders the system vulnerable, it is necessary to<br />

identify, model, and quantify the possibility of human<br />

error using HRA [3]. In particular, the nominal Human<br />

Error Probability (HEP) used in the HRA is estimated<br />

Feature<br />

Development of Per<strong>for</strong>mance Shaping Factors <strong>for</strong> Human Error Reduction during Reactor Decommissioning Activities through the Task Analysis Method ı Byung-Sik Lee, Hyun-Jae Yoo and Chang-Su Nam


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

FEATURE | ENVIRONMENT AND SAFETY 518<br />

based on the workers’ activity, most often based on the<br />

PSFs. This is because PSFs characterize the important<br />

aspects of human error and provide numerical criteria <strong>for</strong><br />

adjusting the average HEP level [9]. There<strong>for</strong>e, the key<br />

step in the HRA <strong>for</strong> decommissioning activities of a nuclear<br />

power plant is to select appropriate PSFs, develop the<br />

classification system, and quantify their impacts on the<br />

decommissioning activity.<br />

3.1 Criteria <strong>for</strong> selecting PSFs<br />

When selecting PSFs that affect the decommissioning<br />

activities of nuclear plants, it is important to carefully<br />

select all the important situational factors that affect the<br />

hazard level so as to not miss any of the factors. In addition,<br />

it should be ensured that there is no overlap in the meaning<br />

and scope of the PSFs; furthermore, the factors should be<br />

selected based on their actual effect on human error<br />

analysis. There<strong>for</strong>e, the PSFs are selected <strong>for</strong> the HRA of<br />

the decommissioning activities of the nuclear power plant<br />

considering the following criteria.<br />

p The PSFs should be selected to appropriately reflect the<br />

work characteristics. There<strong>for</strong>e, the TA results of the<br />

work should be fully reflected by the PSFs.<br />

p The internal and external factors that might affect<br />

the workers’ per<strong>for</strong>mance should be comprehensively<br />

considered.<br />

p When a worker encounters an abnormal event, the<br />

internal factors should be included in the PSFs<br />

appro priately to account <strong>for</strong> the reactions that occur<br />

naturally in workers, including physical, cognitive, and<br />

emotional factors.<br />

p The external factors should comprehensively include<br />

those that directly or indirectly affect the workers’<br />

response to per<strong>for</strong>mance, i.e., the business organization<br />

and work environment factors, among others.<br />

p Based on previous research results, in our case, the<br />

PSFs will consist of three levels (namely, Level 1, Level<br />

2, and Level 3). Though there are direct and indirect<br />

dependencies between the PSFs in Level 1 and Level 2,<br />

the PSFs are selected in a manner that there is no<br />

dependency between the Level 3 PSFs.<br />

p In practice, the PSFs are selected based on factors<br />

that directly affect the trends of the ongoing events.<br />

There<strong>for</strong>e, factors such as workers’ training and work<br />

shifts, among others, indirectly affecting the work<br />

per<strong>for</strong>mance of the workers, are excluded from the PSF<br />

Classification Direct effect Indirect effect<br />

Personal Factors<br />

System factors<br />

Task factors<br />

| Tab. 3.<br />

Derived PSF factor.<br />

• Duration of mental stress<br />

• Mental tension<br />

• Pain or discom<strong>for</strong>t<br />

• Hunger or thirst<br />

• Emotional state<br />

• Duration of physical stress<br />

• Disruption of circadian rhythm<br />

• Lack of sleep<br />

• Work hours<br />

• Shift rotation<br />

• Suddenness of onset<br />

• State of current practice or skill<br />

• Motivation and attitudes<br />

• Personality and<br />

intelligence variables<br />

knowledge of required<br />

per<strong>for</strong>mance previous<br />

training/experience<br />

• Sensory deprivation<br />

• Distractions (noise, glare,<br />

movement, flicker. color)<br />

• Complexity<br />

• Movement constriction<br />

• Workplace layout<br />

• Threats of failure<br />

• Lack of physical exercise<br />

• High jeopardy risk<br />

• Conflicts of motives<br />

about job per<strong>for</strong>mance<br />

selection because they are considered to be inherent in<br />

the other PSFs themselves.<br />

p The PSFs should have clear definitions so that their<br />

meanings and roles do not overlap. There<strong>for</strong>e, as much<br />

as possible, the scale of the PSFs should be reduced by<br />

grouping all the PSFs and reducing the number of tasks<br />

involved.<br />

3.2 Selection and definition of PSFs<br />

Based on our review of existing literature related to the<br />

work per<strong>for</strong>mances of individual workers from various<br />

industrial fields, we observed that it is not easy to find<br />

a consensus on the factors influencing the workers’<br />

per<strong>for</strong>mance. However, considering the results of these<br />

previous studies, it is deemed that the possibility <strong>for</strong> human<br />

error can be determined based on the degradation of the<br />

workers’ human error factor, i.e., their task per<strong>for</strong>mance.<br />

The Institute of <strong>Nuclear</strong> <strong>Power</strong> Operations (INPO)<br />

presents 85 error precursors that can lead to possible<br />

human errors considering the business requirements, personal<br />

abilities, work environments, and human nature in<br />

terms of the operation of the nuclear power plants [10].<br />

These precursors are considered as the risk variables <strong>for</strong><br />

human errors made by workers.<br />

There<strong>for</strong>e, it is realistic to utilize an Error Precursor,<br />

i.e., PSF, that affects work per<strong>for</strong>mance. While estimating<br />

the probability of human error, it is desirable to add<br />

psychological factors that cannot be directly managed<br />

after the possibility of human error <strong>for</strong> manageable<br />

factors is reduced through safety management or accident<br />

prevention activities. The PSFs extracted <strong>for</strong> use in the<br />

human error assessment model in this study are listed<br />

in Table 3 below.<br />

3.3 Development of a classification system<br />

<strong>for</strong> PSFs<br />

TA was conducted to derive the PSFs <strong>for</strong> RPVI cutting,<br />

which is one of the primary tasks involved in the<br />

decommissioning of nuclear power plants. Because it is<br />

difficult to select PSFs such that their meanings and roles<br />

are clearly delineated, the PSFs are classified into three<br />

major categories, which are defined by their task analysis<br />

results. In other words, the human factors of the workers<br />

themselves, the operating system factors related to the<br />

work, and the ergonomic factors linking the worker and<br />

the dismantling activities were suitably classified.<br />

In particular, an important aspect of the TA is “Human,”<br />

i.e., a worker who per<strong>for</strong>ms the task of decommissioning<br />

the RPV and can cause human errors. It is noteworthy<br />

that human factors are important to consider not only<br />

in the field of nuclear power generation, but also, in<br />

other industrial fields, such as the railways and aviation<br />

[<strong>11</strong>-16].<br />

p Supervisors and workers might be affected psychologically<br />

while per<strong>for</strong>ming the tasks described above.<br />

Because the cutting process takes considerable time, it<br />

is important to consider the various stresses and<br />

emotional conditions that supervisors and workers<br />

might experience.<br />

p In particular, the work environment and conditions <strong>for</strong><br />

the cutting task in normal or abnormal situations affect<br />

the workers’ physical and physiological factors. Thus, to<br />

per<strong>for</strong>m the RPVI cutting tasks, wearing the appropriate,<br />

protective work clothes and protective cap<br />

and having good physical and health conditions to<br />

carry or handle the equipment are considered important.<br />

Furthermore, while per<strong>for</strong>ming the tasks, the<br />

Feature<br />

Development of Per<strong>for</strong>mance Shaping Factors <strong>for</strong> Human Error Reduction during Reactor Decommissioning Activities through the Task Analysis Method ı Byung-Sik Lee, Hyun-Jae Yoo and Chang-Su Nam


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

physiological factors of the workers, such as fatigue,<br />

hunger, and excretion, is equally important.<br />

p When the nuclear power plant is dismantled <strong>for</strong> the<br />

first time, there might be a lack of personal skills and<br />

experiences, because the workers are not accustomed<br />

to the decommissioning work. There<strong>for</strong>e, in<strong>for</strong>mation<br />

about the complete decommissioning task and equipment<br />

used <strong>for</strong> each task should be taught through<br />

training and education.<br />

Next, there is a need <strong>for</strong> an operating system that can be<br />

managed, supervised, and overseen to efficiently per<strong>for</strong>m<br />

the decommissioning tasks. There<strong>for</strong>e, the “operation”<br />

elements, such as organization, including the supervisors<br />

and workers; task management <strong>for</strong> managing work<br />

schedules and workload efficiently; and documents<br />

include detailed in<strong>for</strong>mation on decommissioning, such as<br />

procedure and scenarios, are important.<br />

p In order to ensure that the cutting work is per<strong>for</strong>med<br />

smoothly, the supervisors and workers need to <strong>for</strong>m<br />

appropriate teams. Organizational factors, such as the<br />

objectives of these team, necessary team-building<br />

elements (cooperation, role, etc.), and precise and<br />

detailed communication of the supervisors’ judgement/decisions<br />

to the workers are important.<br />

p Next, the tasks should be well-designed including the<br />

preparation, methods and strategy, as well as processes<br />

involved in the tasks. Because the work is actively<br />

con ducted throughout the day, the work assignment<br />

Level 1 Level 2 Level 3<br />

Human<br />

Operation<br />

Ergonomic<br />

System<br />

Psychological<br />

State<br />

Physical<br />

State<br />

Per<strong>for</strong>mance<br />

Capability<br />

Organizational<br />

Factors<br />

Task Management<br />

Procedure and<br />

In<strong>for</strong>mation<br />

HMI<br />

(Human Machine<br />

Interface)<br />

Workplace Design<br />

Workplace Physical<br />

Environment<br />

Stress<br />

and shift work schedule should be coordinated and<br />

managed.<br />

p Finally, because supervisors and workers understand<br />

and per<strong>for</strong>m their work based on the procedures and<br />

scenarios related to the decommissioning of the RPVI<br />

components, in<strong>for</strong>mation on regulations, equipment<br />

and facilities, as well as accuracy and details of the<br />

procedures are important.<br />

Furthermore, because the cutting work is human- centric,<br />

the surrounding situations and conditions must be<br />

designed in a manner that is suitable <strong>for</strong> human beings.<br />

There<strong>for</strong>e, “ergonomic system” factors, such as worker<br />

interaction with the necessary equipment and facilities,<br />

which are based on the decommissioning task characteristics<br />

and requirements <strong>for</strong> RPVI components, workplace<br />

design based on the path of the supervisor and worker and<br />

task types, and optimal workplace environment <strong>for</strong><br />

workers, are important points to consider.<br />

p The systems and equipment the supervisors and<br />

workers operate must be interactive to ensure that they<br />

are not difficult to use to ensure the convenience and<br />

safety of the workers.<br />

p Because the RPV is located under water and is not<br />

directly visible and accessible to humans, the cutting<br />

processes under the RPVI decommissioning task<br />

are generally per<strong>for</strong>med using remotely controlled<br />

devices. There<strong>for</strong>e, the configuration, condition,<br />

and per <strong>for</strong>mance of these remote systems, such as<br />

Emotional State (Excitement, Boredom, Accomplishment, Frustration, Dissatisfaction)<br />

Safety Awareness<br />

Fatigue<br />

Physical Capability<br />

Discom<strong>for</strong>t<br />

Task Knowledge and Memory (Diagnoses, Action, Results, In<strong>for</strong>mation)<br />

Experience<br />

Personal Capability<br />

Overall Planning<br />

Supervision of Management including Decision Making<br />

Team Factors(Roles, Coordination, Risk Management, Atmosphere, Assisting Other)<br />

Work Process Design (considering Task Characteristic)<br />

Workload Management<br />

Problem Identification and Solution<br />

Communication Availability and Quality<br />

Procedure and In<strong>for</strong>mation Availability<br />

Procedure and In<strong>for</strong>mation Complexity<br />

Procedure and In<strong>for</strong>mation Accuracy and Completeness<br />

Procedure and In<strong>for</strong>mation Feedback and Recency<br />

Interaction Element (Menu, Push Button, Direct Manipulation, Special Symbol, Shape Type)<br />

Familiarity of Equipment and Facility<br />

Complexity of Equipment and Facility<br />

Maintenance<br />

Physical Access to Work Items<br />

Warning Sign (Alarm Location, Quantity, Intensity, Importance and Easy of Identification)<br />

Arrangement of Functional Areas<br />

Safety Device<br />

Noise<br />

Lighting<br />

Temperature<br />

Radiation Level<br />

FEATURE | ENVIRONMENT AND SAFETY 519<br />

| Tab. 4.<br />

PSF Classification System in the Reactor Decommissioning Activity.<br />

Feature<br />

Development of Per<strong>for</strong>mance Shaping Factors <strong>for</strong> Human Error Reduction during Reactor Decommissioning Activities through the Task Analysis Method ı Byung-Sik Lee, Hyun-Jae Yoo and Chang-Su Nam


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

FEATURE | ENVIRONMENT AND SAFETY 520<br />

remote control, camera, and display should be well<br />

established, and designers should consider functional<br />

spatial arrangements and accessibility in order to use<br />

them.<br />

p An optimal working environment is required to ensure<br />

the safety of workers during the decommissioning<br />

work. In particular, it is important to establish an<br />

optimal physical environment <strong>for</strong> the workers by<br />

checking <strong>for</strong> factors, such as the noise of the equipment,<br />

temperature experienced by the workers wearing<br />

protective clothing, level of radiation exposure, cleanliness<br />

of the workplace, and turbidity of the water in<br />

which the cutting operation is being per<strong>for</strong>med.<br />

In particular, the PSFs are classified into three categories<br />

per the level of detail and importance required <strong>for</strong> the<br />

decommissioning activities. Level 1 includes “Human<br />

Factors,” “Operation Factors,” and “Ergonomic System<br />

Factors.” Next, Level 2 of Human Factors includes the<br />

basic elements responsible <strong>for</strong> human error, namely<br />

the psychological and physical state and per<strong>for</strong>mance<br />

capability of the supervisors and workers. Level 2 of<br />

Operation Factors is composed of Organizational Factors,<br />

Task Management, Procedures, and In<strong>for</strong>mation. Finally,<br />

Level 2 <strong>for</strong> human-oriented Ergonomic Factors is composed<br />

of HMI, Workplace Design, and Workplace Physical<br />

Environment. The PSFs under Level 3 are selected in a<br />

manner so as to not overlap with each other; in particular,<br />

these include a total of 44 factors as shown in Table 4.<br />

4 Concluding Remarks<br />

In this work, we study and present the methodology <strong>for</strong><br />

HRA <strong>for</strong> the cutting task of the <strong>Nuclear</strong> RPVI components<br />

in order to reduce human errors during the nuclear decommissioning<br />

activities. In order to do so, the HRA implementation<br />

procedures were reviewed to identify the components<br />

of the HRA and the most important TA was per<strong>for</strong>med<br />

in preparation <strong>for</strong> the HRA. The task characteristics,<br />

procedures, and in<strong>for</strong>mation on the decommissioning<br />

of the RPVI components were identified by reviewing relevant<br />

literature in the field and examining experiences in<br />

decommissioning at overseas nuclear power plants.<br />

In addition, PSFs required <strong>for</strong> the nuclear decommissioning<br />

activities were identified using TA results and<br />

PSFs selection criterion <strong>for</strong> RPVI cutting (10 tasks in total).<br />

The results of the PSF review applied to nuclear facilities<br />

and types of human errors identified through the detailed<br />

TA were synthesized. Furthermore, the selection criteria<br />

<strong>for</strong> the PSFs affecting the decommissioning activities were<br />

set. Finally, PSFs were selected and classified using a<br />

classification system.<br />

In a future study, we will examine the interrelationship<br />

among the PSFs and consider methods <strong>for</strong> assessing<br />

the PSFs. Moreover, we will develop a framework to model<br />

the mutual influences that exist among the PSFs with<br />

appropriate consideration of the relationships and<br />

dependencies among them. The collection of experience<br />

data <strong>for</strong> decommissioning nuclear power plants will also<br />

reduce the uncertainty in the in<strong>for</strong>mation used to per<strong>for</strong>m<br />

HRA.<br />

References<br />

[1] Madonna, M., et al.: Il Fattore Umano Nella Valutazione Dei Rischi: Confronto Metodologico Fra<br />

Le Tecniche Per L’analisi Dell’affidabilità Umana. Prevenzione Oggi. 5 (n. 1/2), 67–83 (2009).<br />

[2] Hollnagel, E.: Cognitive reliability and error analysis method (CREAM). Elsevier, (1998).<br />

[3] Griffith, C.D., Mahadevan, S.: Inclusion of fatigue effects in human reliability analysis. Reliability<br />

Engineering & System Safety, 96 (<strong>11</strong>), 1437–1447 (20<strong>11</strong>).<br />

[4] Lee, Y., et al.: Research Activities and Techniques <strong>for</strong> the Prevention of Human Errors during the<br />

Operation of <strong>Nuclear</strong> <strong>Power</strong> Plants. <strong>Journal</strong> of the Ergonomics Society of Korea, 30 (1), 75-86<br />

(20<strong>11</strong>).<br />

[5] O’Hara, J. M., et al.: Human Factors Engineering Program Review Model, US NRC, NUREG-07<strong>11</strong>,<br />

Rev. 3, 2012<br />

[6] Center <strong>for</strong> Chemical Process Safety : Guidelines <strong>for</strong> preventing human error in process safety<br />

(1994)<br />

[7] Byung-Sik Lee: Optimization of reactor pressure vessel internals segmentation in KoreaATW<br />

Vol.62 (2017), Issue <strong>11</strong>, 654~658, November, 2017<br />

[8] Boucau, J., et.al.: Best practices <strong>for</strong> preparing vessel internals segmentation projects. No.<br />

NEA-PREDEC--2016. February 16–18, Lyon, France (2016).<br />

[9] Boring, R.L.: Modelling human reliability analysis using MIDAS. In: <strong>International</strong> Workshop on<br />

Future Control Station Designs and Human Per<strong>for</strong>mance Issues in <strong>Nuclear</strong> <strong>Power</strong> Plants (2006).<br />

[10] Human per<strong>for</strong>mance reference manual, Institute of <strong>Nuclear</strong> <strong>Power</strong> Operations, INPO-06-003,<br />

2006<br />

[<strong>11</strong>] Chang, Y. H. J., Mosleh, A.: Cognitive modeling and dynamic probabilistic simulation of operating<br />

crew response to complex system accidents. Part 2: IDAC per<strong>for</strong>mance influencing factors model.<br />

Reliability Engineering & System Safety, 92(8), 1014-1040 (2006).<br />

[12] Blackman, H. S., Gertman, D. I., Boring, R. L.: Human error quantification using per<strong>for</strong>mance<br />

shaping factors in the SPAR-H method. In Proceedings of the human factors and ergonomics<br />

society annual meeting (Vol. 52, No. 21, pp. 1733-1737). Sage CA: Los Angeles, CA: SAGE<br />

Publications (2008).<br />

[13] Li, P. C., Chen, G. H., Dai, L. C., Zhang, L.: A fuzzy Bayesian network approach to improve the<br />

quantification of organizational influences in HRA frameworks. Safety science, 50(7), 1569-1583<br />

(2012).<br />

[14] Jung, K., Byun, S., Kim, J., Heo, E., Park, H.: An empirical study on evaluation of per<strong>for</strong>mance<br />

shaping factors on AHP. <strong>Journal</strong> of the Ergonomics Society of Korea, 30(1), 99-108 (20<strong>11</strong>).<br />

[15] Mindock, J.: Development and Application of Spaceflight PSFs <strong>for</strong> HRA. PhD Thesis , University of<br />

Colorado at Boulder (2012).<br />

[16] Baek, D., Koo, L., Lee, K., Kim, D., Yoon, W., Jung, M.: Taxonomy of PSFs <strong>for</strong> human error analysis<br />

of railway accidents. Business Administration, Hanyang University (2007).<br />

Authors<br />

Byung-Sik Lee<br />

Hyun-Jae Yoo<br />

Chang-Su Nam<br />

Dankook University<br />

<strong>11</strong>9, Dandae-ro, Dongnam-gu, Cheonan-si<br />

Chungnam, 3<strong>11</strong>16<br />

Republic of Korea<br />

Acknowledgments<br />

This work was supported by the National Research<br />

Foundation of Korea (NRF), granted financial resource<br />

from the Ministry of Science, ICT and Future Planning<br />

(No. 2017M2A8A5015148 and No.2016M2B2B1945086),<br />

Republic of Korea.<br />

Feature<br />

Development of Per<strong>for</strong>mance Shaping Factors <strong>for</strong> Human Error Reduction during Reactor Decommissioning Activities through the Task Analysis Method ı Byung-Sik Lee, Hyun-Jae Yoo and Chang-Su Nam


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

Root Causes of the<br />

Three Mile Island Accident<br />

Zoltan R. Rosztoczy<br />

The accident at Unit 2 of the Three Mile Island nuclear power plant, at that time operated and partly owned by<br />

Metropolitan Edison Company, occurred 40 years ago, on March 28, 1979. Following the accident, two major<br />

investigations were conducted, one by the President’s Commission on the Accident at Three Mile Island [1], appointed<br />

by President Carter, and the other by the <strong>Nuclear</strong> Regulatory Commission’s Special Inquiry Group. [2] The investigations<br />

documented the timeline of the accident and the availability and failure of equipment, and addressed operator actions<br />

during the accident, the training of operators, and NRC procedures that applied to the event. The design process <strong>for</strong> the<br />

plant and the designer’s responsibilities, including the plant’s safety analysis, were not addressed. Many additional<br />

studies and papers have been published over the past 40 years, none of which have addressed the design process or the<br />

safety analysis of the plant. The only ef<strong>for</strong>t specifically addressing the design of the plant and responsibility <strong>for</strong> the<br />

accident was Metropolitan Edison’s lawsuit against Babcock & Wilcox (B&W), the designer of the plant. A trial began<br />

but was terminated, and the case was settled out of court. The court records are sealed; in<strong>for</strong>mation is not available.<br />

More than 10 years prior to the TMI-2<br />

accident, B&W was designing its first<br />

nuclear power plant. In the designation<br />

of safety systems and in the safety<br />

analysis of the plant, there were two<br />

relatively minor but important omissions.<br />

These omissions turned out to<br />

be the root causes of the accident. If<br />

just one of them had been corrected<br />

during the intervening years, the<br />

accident would have been avoided.<br />

The TMI design was reviewed by<br />

utilities purchasing plants from B&W<br />

and by the NRC. The omissions<br />

remained undetected. The safety role<br />

of the pilot-operated relief valve<br />

(PORV) and the PORV block valve<br />

were not fully appreciated. The manufacturer<br />

of the PORV was not notified<br />

of the valve’s safety function, namely<br />

that it has to be able to close after<br />

being exposed to accident loads. [2]<br />

Also, the plant’s safety analysis report<br />

(SAR) did not address loss-of-coolant<br />

accidents (LOCA) initiated by very<br />

small breaks. Un<strong>for</strong>tunately, the plant<br />

responds very differently to an event<br />

initiated by a stuck PORV than to the<br />

small-break events presented in the<br />

SAR. At the time, this was unknown.<br />

Lessons learned from the omissions<br />

in the TMI design are timely today,<br />

when new types of reactors, such<br />

as small modular reactors, are on the<br />

drawing board. The designers of these<br />

new systems can learn from the TMI<br />

experience.<br />

The initiating event<br />

Operators attempting to clean a<br />

condensate polisher tripped the steam<br />

generator feedwater pumps. Then,<br />

the plant safety system tripped the<br />

turbine. The turbine was no longer<br />

removing heat from the reactor coolant<br />

system (RCS), the temperature<br />

and pressure of the RCS started rising<br />

rapidly, and the PORV opened, as<br />

designed.<br />

Upon shutdown of the feedwater<br />

pumps, the plant’s safety system<br />

turned on the emergency feedwater<br />

pumps. Due to a maintenance error,<br />

both emergency feedwater block<br />

valves, which are supposed to be open<br />

when the plant is operating, were<br />

closed, so no emergency feed-water<br />

reached the steam generators. The<br />

closed valves caused the RCS to heat<br />

up faster than in the case of a normal<br />

turbine trip, and the PORV was<br />

exposed to a larger load than normal,<br />

most likely a heavy two-phase flow<br />

(steam and water mixture) or water<br />

discharge. Thus, the closed valves<br />

could have played a role in causing<br />

the accident. This possibility is not<br />

addressed in the literature.<br />

As RCS pressure increased, the<br />

reactor protection system shut the<br />

reactor down, after which the RCS<br />

pressure dropped. The PORV should<br />

have closed, but instead it stuck open,<br />

and the plant faced a LOCA. The<br />

obvious question is, “Why did the<br />

PORV fail to close?”<br />

Designers of nuclear power plants<br />

have a dual responsibility. They must<br />

design the plant not only <strong>for</strong> normal<br />

operation of generating electricity,<br />

but also <strong>for</strong> safe per<strong>for</strong>mance in case<br />

of events that might occur during the<br />

lifetime of the plant and in case of<br />

postulated accidents.<br />

Components of systems that have<br />

both an operating function and a<br />

safety function have to be identified<br />

and designed to per<strong>for</strong>m both functions<br />

in a reliable manner. The PORV<br />

is a good example of such a component.<br />

During normal operation, the<br />

PORV maintains RCS pressure below<br />

specified limits by opening and closing<br />

and by discharging steam from the<br />

pressurizer. During abnormal events,<br />

as in the TMI-2 case, the PORV could<br />

be discharging two-phase flow or<br />

water. The valve must be designed to<br />

per<strong>for</strong>m its safety function – namely,<br />

to close following a two-phase flow or<br />

water discharge. Apparently, this was<br />

not the case at TMI. The PORV was<br />

not designed to per<strong>for</strong>m its safety<br />

function. The purchase order failed to<br />

specify this requirement, and the<br />

supplier of the valve did not know that<br />

the valve had a safety function and<br />

that it had to close following twophase<br />

flow or water discharge. [2]<br />

Designers are also responsible <strong>for</strong><br />

incorporating operating experience<br />

into their design. Prior to the TMI-2<br />

accident, PORVs failed to close seven<br />

times at B&W plants. [2] Despite<br />

this record, the PORV itself was not<br />

modified or replaced. Instead, an<br />

indicator light was installed to show<br />

whether the block valve upstream of<br />

the PORV had received a signal to<br />

close, but there was no indication in<br />

the control room that the valve had<br />

actually closed.<br />

Reprinted with<br />

permission from the<br />

March 2019 issue of<br />

<strong>Nuclear</strong> News<br />

Copyright © 2019 by<br />

the American <strong>Nuclear</strong><br />

Society<br />

| From right to left: President Jimmy Carter, Pennsylvania Gov. Richard<br />

Thornburgh, and the NRC’s Harold Denton tour the TMI-2 control room on<br />

April 1, 1979. Photo: The Jimmy Carter Presidential Library and Museum<br />

521<br />

ENVIRONMENT AND SAFETY<br />

Environment and Safety<br />

Root Causes of the Three Mile Island Accident ı Zoltan R. Rosztoczy


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

ENVIRONMENT AND SAFETY 522<br />

PORVs opened relatively frequently<br />

on B&W-designed pressurized<br />

water reactors. The thermal hydraulic<br />

design of the reactor core was closer<br />

to acceptable limits than other PWR<br />

cores, and the amount of water<br />

contained in the secondary side of<br />

the steam generators was very small –<br />

only 25 percent of some other PWRs’<br />

water content. [2] These differences<br />

made the system react faster to<br />

changes. With quick plant response,<br />

the PORV came into action relatively<br />

frequently. More frequent use of the<br />

PORV led to more frequent failures.<br />

The PORV failure at TMI-2 was the<br />

eighth at a B&W plant, more than<br />

an order of magnitude higher than<br />

PORV failures with other reactor<br />

designs. [2]<br />

The NRC has specific requirements<br />

<strong>for</strong> equipment related to safety. Equipment<br />

essential to accident mitigation<br />

and equipment whose failure can<br />

cause or aggravate an accident are<br />

considered “safety related.” A stuckopen<br />

PORV causes a breach in the<br />

boundary of the RCS, creating a<br />

LOCA. Among postulated accidents,<br />

LOCAs are considered to be the<br />

most serious, and there<strong>for</strong>e they<br />

receive special attention. <strong>Nuclear</strong><br />

power plants are designed with three<br />

barriers to protect the public from<br />

radioactive material release: The<br />

fuel is enclosed in a sealed cladding,<br />

the reactor core is within the closed<br />

RCS, and the RCS is covered by a<br />

containment building. Among all<br />

postulated accidents, there is only<br />

one – the LOCA – where two of the<br />

barriers are predicted to be damaged.<br />

In the case of a LOCA, the event itself<br />

breaches the RCS, and the predicted<br />

consequences of the accident are<br />

expected to damage some of the<br />

fuel cladding. Protection of the public<br />

is reduced to a single barrier, the<br />

containment building. Furthermore,<br />

valve failures are more likely than<br />

pipe breaks. Thus, the most likely<br />

LOCA is the stuck-open PORV.<br />

Surprisingly, the PORV was not<br />

identified by the designer as safetyrelated<br />

equipment. The design was<br />

reviewed by Metropolitan Edison<br />

and evaluated by the NRC. Neither<br />

objected to the PORV not being<br />

designated as safety related, and<br />

the NRC approved the construction<br />

permit application. Had the PORV<br />

been designated as safety-related<br />

equipment, it would have had to<br />

meet reliability requirements and be<br />

tested under accident conditions. If<br />

the TMI-2 PORV had been tested, it<br />

most likely would not have passed.<br />

Following the accident, the manufacturer<br />

of the valve stated that the<br />

TMI-2 PORV was not qualified to close<br />

following a two-phase flow or water<br />

discharge. [2] If the PORV had been<br />

designated as safety related, it would<br />

have been replaced or modified.<br />

The reason given <strong>for</strong> not designating<br />

the PORV as safety related was<br />

the presence of a block valve upstream<br />

of the PORV. If the PORV is stuck<br />

open, the block valve can be closed,<br />

terminating the accident. Thus, the<br />

block valve is essential <strong>for</strong> the mitigation<br />

of a PORV failure accident, and<br />

it is also considered safety-related<br />

equipment. It must have automatic<br />

safety-grade actuation initiated from<br />

the stuck-open PORV or, if the initiation<br />

is manual, safety-grade position<br />

indication must be available in the<br />

control room with sufficient time<br />

<strong>for</strong> operator action. Neither of these<br />

conditions existed at TMI-2.<br />

Consequences of PORV failure<br />

Part of the designer’s responsibility is<br />

to conduct a complete and detailed<br />

safety analysis of the plant. The<br />

analysis must include transients that<br />

might occur in the plant. The analysis<br />

of transients must show that continued<br />

operation of the plant following<br />

these events is justified. The<br />

plant’s safety analysis also has to<br />

address all potential accidents, both<br />

system failures and operator errors<br />

that the plant could be subject to,<br />

unless they are considered to be<br />

extremely unlikely (severe accidents).<br />

It is the designer’s responsibility to<br />

identify all accident types specific<br />

to the design of the plant. In the case<br />

of water-cooled reactors, one of these<br />

accident types is a breach in the RCS<br />

– a LOCA.<br />

For PWRs such as TMI-2, it is an<br />

NRC requirement that a complete<br />

spectrum of breaches in the RCS be<br />

analyzed, starting from the doubleended<br />

break of the largest pipe in the<br />

RCS down to the break size that the<br />

makeup water system can keep up<br />

with. Un<strong>for</strong>tunately, it was not emphasized<br />

that a breach in the system<br />

includes stuck-open valves if the<br />

valve’s discharge area is within the<br />

size range of the postulated accident.<br />

The PORV falls within the size range.<br />

Complete spectrum also means all<br />

possible break locations. The consequences<br />

of a stuck-open valve on<br />

the top of the pressurizer could be<br />

different from a same-size break at a<br />

lower elevation.<br />

Typically, prior to the TMI accident,<br />

the large-break LOCA analysis<br />

| A six-page special report – <strong>Nuclear</strong> News’s<br />

initial coverage of the TMI accident –<br />

was mailed separately to subscribers and<br />

ANS members in April 1979.<br />

included break sizes in both the hot<br />

and cold legs of the RCS, starting<br />

from a double-ended break down<br />

to a 0.5 square-foot break. Usually,<br />

the consequences were most severe<br />

at one of the larger breaks. From<br />

there on, smaller sizes resulted in<br />

more favorable consequences. The<br />

small-break LOCA analysis ran from<br />

0.5 square foot down to about<br />

0.1 square foot. The trend was the<br />

same; smaller breaks had less severe<br />

consequences. Breaks even smaller<br />

were not analyzed <strong>for</strong> two reasons:<br />

(1) the calculations ran long on the<br />

computer and the analyses were<br />

expensive, and (2) the trend was<br />

already established. Instead, the<br />

assumption was made that the<br />

trend would continue down to the<br />

smallest required size. Also, smallbreak<br />

LOCA analysis was assumed<br />

to be independent of break location.<br />

Thus, breaks less than 0.5 square<br />

foot were not analyzed at different<br />

locations, and breaks less than<br />

0.1 square foot were not analyzed<br />

at all.<br />

The safety analysis of the plant<br />

serves many purposes. It provides<br />

both the designer and the operator of<br />

the plant with an understanding of<br />

how the plant responds to a specific<br />

event or accident, indicates potential<br />

damage if mitigating actions are<br />

not taken, guides the designer in the<br />

design of the needed safety systems,<br />

and provides in<strong>for</strong>mation <strong>for</strong> training<br />

the operating staff. The analysis<br />

shows how reactor operators can<br />

recognize a specific event and what<br />

actions they must take and provides<br />

the needed in<strong>for</strong>mation <strong>for</strong> the<br />

preparation of emergency procedures.<br />

The results of the analysis also show<br />

Environment and Safety<br />

Root Causes of the Three Mile Island Accident ı Zoltan R. Rosztoczy


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

compliance with applicable regulations.<br />

It shows that potential damage<br />

has been mitigated and the safety<br />

of plant personnel and the public is<br />

ensured.<br />

The TMI-2 LOCA analysis was<br />

per<strong>for</strong>med by the designer. It was<br />

rather elaborate but was incomplete<br />

in the sense that it failed to show that<br />

very small breaks behave differently<br />

and have more serious consequences<br />

than small breaks. As part of the<br />

TMI-2 licensing process, no LOCA<br />

analysis was per<strong>for</strong>med by the<br />

designer, and no LOCA analysis was<br />

submitted to the NRC by the utility<br />

<strong>for</strong> a break size anywhere close to<br />

the size of the discharge opening of<br />

the PORV (about 2 square inches). No<br />

analyses were per<strong>for</strong>med <strong>for</strong> any size<br />

break at the top of the pressurizer or<br />

<strong>for</strong> a LOCA caused by a stuck-open<br />

PORV. Un<strong>for</strong>tunately, as was learned<br />

from the TMI accident and from<br />

analysis per<strong>for</strong>med after the accident,<br />

a stuck-open PORV.<br />

LOCA is very different from the<br />

small-break LOCA analyses presented<br />

<strong>for</strong> TMI-2. Analysis of smaller breaks<br />

showed that the trend reverses<br />

and the consequences increase with<br />

decreasing break size. The plant<br />

responds differently, reliance on<br />

safety systems and instrumentation<br />

changes, and different operator actions<br />

are required. The consequences<br />

of a PORV failure are even more<br />

different. RCS pressure can drop while<br />

the water level in the pressurizer is<br />

rising. Void can <strong>for</strong>m in the reactor<br />

core and accumulate at high locations<br />

of the RCS while the pressurizer water<br />

level is high. Furthermore, the water<br />

level can drop below the top of the<br />

core, resulting in core damage, while<br />

the pressurizer water level is still high.<br />

Obviously, pressurizer water level<br />

indication is not a useful tool <strong>for</strong> the<br />

handling of this accident.<br />

A special design feature of B&W<br />

plants further aggravates this effect.<br />

The pressurizer surge line is designed<br />

with a loop seal to prevent steam from<br />

entering the pressurizer. Eliminating<br />

steam flow to the pressurizer prevents<br />

water level drops in the pressurizer,<br />

keeping the water level high, while<br />

void is accumulating in the RCS.<br />

Due to the lack of analysis, the<br />

consequences of a PORV failure<br />

were unknown. As it turned out, the<br />

actual consequences without proper<br />

mitigation were a lot worse than<br />

one would expect. The assumption<br />

that consequences get better with<br />

decreasing break size was incorrect.<br />

The actual consequences of the<br />

accident equally surprised the designers,<br />

the owner/operator of the<br />

plant, and the regulators. The plant’s<br />

response to the PORV failure was<br />

totally unexpected.<br />

Accident management<br />

Early in the morning of March 28,<br />

1979, four young operators at<br />

TMI-2 realized that something had<br />

happened, but they had no idea what<br />

it was. The turbine shut down, the<br />

reactor scrammed, and a cascade of<br />

alarms sounded and flashed. The<br />

plant was acting strangely. RCS<br />

pressure was decreasing while the<br />

pressurizer water level was increasing.<br />

The operators had not faced this<br />

situation be<strong>for</strong>e. It was not covered in<br />

their training. They did not know<br />

what to do.<br />

The event facing the operating<br />

crew was a stuck-open PORV and a<br />

very small LOCA. They did not know<br />

that was the case. There was no direct<br />

indication of PORV position in the<br />

control room. They could not see that<br />

the PORV was stuck open.<br />

Not knowing what was going on<br />

and not having familiarity with the<br />

event, the operators were improvising,<br />

trying to maintain water level<br />

in the RCS within prescribed limits.<br />

They relied on the pressurizer water<br />

level reading, as they were trained to<br />

do. Un<strong>for</strong>tunately, they took a few<br />

inappropriate actions, which included<br />

turning off the high-pressure emergency<br />

core cooling system, opening<br />

the letdown line, ignoring signs of<br />

overheating of the reactor core, and<br />

pumping radioactive water to the<br />

auxiliary building. All of this occurred<br />

be<strong>for</strong>e they learned – two hours and<br />

20 minutes into the accident – that the<br />

PORV was stuck open. Then they<br />

took corrective action and closed<br />

the block valve.<br />

The obvious question is, “Why<br />

were the operators in the dark, and<br />

why did they lack familiarity with<br />

this event?” Their training covered<br />

mitigation of postulated accidents, including<br />

LOCAs. There was only one<br />

set of accidents missing, very small<br />

LOCAs, including PORV failure. Since<br />

the designer did not analyze this<br />

event, it was not included in operator<br />

training. Not knowing the plant’s<br />

response to a PORV failure, the<br />

designers and the training staff<br />

instructed the operators to always<br />

rely on the pressurizer water level<br />

indication <strong>for</strong> water level measurements<br />

in the RCS. The operators<br />

followed their training on that<br />

morning.<br />

Despite the total lack of training<br />

<strong>for</strong> a stuck-open PORV event, could<br />

the operators have realized what<br />

was going on and taken appropriate<br />

action? The answer is yes. [1] The<br />

temperature of the PORV drain pipe<br />

was monitored and showed high<br />

readings, an alarm signaled high<br />

water level in the containment building<br />

sump, high neutron level indications<br />

were observed in the reactor<br />

core, temperature and pressure were<br />

rising in the containment building,<br />

and the reactor coolant pumps were<br />

vibrating. Any of these observations,<br />

typical of a LOCA, could have brought<br />

attention to a stuck-open PORV. The<br />

remedy should have been obvious:<br />

Close the block valve.<br />

Once the block valve was closed,<br />

the LOCA was terminated. The next<br />

step was to cool the core by natural<br />

circulation of the water in the RCS.<br />

This was not possible, however, due to<br />

the large amount of void that had<br />

accumulated in the RCS. The operating<br />

staff had to improvise again to<br />

reduce the void and the bubble in<br />

the RCS, and then to establish neutral<br />

circulation. It took a couple of days’<br />

work <strong>for</strong> them to accomplish this.<br />

Both the plant’s designer and<br />

operator lacked the knowledge of how<br />

the plant would respond to a stuckopen<br />

PORV. What they did not know,<br />

they could not pass on to the operators.<br />

The operators’ training was<br />

misleading, and the emergency procedure<br />

was incorrect <strong>for</strong> the incident<br />

they were facing.<br />

Industry practice and<br />

oversight<br />

B&W’s two omissions – safety-related<br />

classification of the PORV and the<br />

PORV block valve, and the lack of<br />

PORV failure analysis – were not<br />

unique to B&W. The other U.S. PWR<br />

designers, Westinghouse and Combustion<br />

Engineering, made the same<br />

omissions. How could three independent<br />

sets of engineers make the<br />

same mistake? Licensing of the plants<br />

was a major consideration. The SAR<br />

was the centerpiece of the licensing<br />

review. Precedent provided guidance<br />

<strong>for</strong> the preparation of the report.<br />

Analyses presented in previous<br />

applications were included in the<br />

report; analysis that was not<br />

required was ignored. Dozens of<br />

utilities received SARs with the<br />

same omissions. The omissions<br />

had a direct and major effect on<br />

the training of reactor operators.<br />

The operators received training on<br />

a plant simulator, with postulated<br />

ENVIRONMENT AND SAFETY 523<br />

Environment and Safety<br />

Root Causes of the Three Mile Island Accident ı Zoltan R. Rosztoczy


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

ENVIRONMENT AND SAFETY 524<br />

| TMI II – Late accident phase.<br />

Zoltan R. Rosztoczy<br />

was Manager of the<br />

Safety Analysis<br />

Department of<br />

Combustion Engineering’s<br />

<strong>Nuclear</strong> Division<br />

in its <strong>for</strong>mative years.<br />

He later joined the<br />

<strong>Nuclear</strong> Regulatory<br />

Commission and was<br />

a charter member of<br />

the commission’s<br />

Senior Executive<br />

Service.<br />

accidents programmed into the<br />

simulator. One accident, the PORV<br />

failure, was missing. Nobody noticed<br />

it or took corrective action. After<br />

PORVs failed seven times at B&W<br />

plants, this accident was still missing<br />

from the operator training program<br />

and from the simulator.<br />

In the case of PWR evaluations,<br />

the NRC had the distinct advantage<br />

of reviewing SARs from three<br />

independent designers. Comparisons<br />

among the three designs frequently<br />

helped in the reviews. The NRC,<br />

however, failed to recognize its own<br />

effect on plant design and analysis.<br />

A nuclear power plant is a complex<br />

system. A regulatory review and<br />

evaluation cannot address all aspects<br />

of the design, and priorities have to<br />

be set. There was a tendency not to<br />

require more from an applicant than<br />

was required from previous ones.<br />

Spending time reviewing areas of the<br />

design that weren’t reviewed in the<br />

past was discouraged. Consequently,<br />

regulators and designers addressed<br />

the same areas of the design and the<br />

safety analyses over and over again<br />

and ignored other areas.<br />

Conclusions<br />

Failure to incorporate the safety<br />

function of the PORV and the block<br />

valve in the design of the plant created<br />

the condition <strong>for</strong> the TMI accident.<br />

With no positive indication in the<br />

control room of an open PORV and no<br />

positive position indication of the<br />

block valve, the operators were left to<br />

guess what was going on and what<br />

needed to be done.<br />

Not having addressed PORV failure<br />

in the plant safety analysis, the<br />

designers, as well as the training and<br />

operating staff, were unfamiliar with<br />

the plant’s response to this type of<br />

accident. They did not know that<br />

| TMI II – Late accident phase.<br />

the plant conditions the operators<br />

were facing were possible, and as<br />

a result, training and instructions<br />

were inadequate. When similar plant<br />

designs are being reviewed or evaluated<br />

one after the other, there is a<br />

tendency to address the same issues<br />

in each case. Plants are very complex,<br />

and not everything can be evaluated<br />

as part of one review. It is appropriate<br />

to shift emphasis in subsequent<br />

reviews and to address issues previously<br />

not covered.<br />

Appropriate NRC regulations relative<br />

to LOCAs to control the design<br />

and operation of the plants’ safety<br />

systems and develop operator training<br />

programs and emergency procedures<br />

were evolving when B&W designed its<br />

first plants, but they were in place at<br />

the time of TMI-2’s licensing. The<br />

problem was that some of the<br />

regulations were not followed.<br />

The two omissions – not recognizing<br />

the safety function of the PORV<br />

and the block valve, and the failure to<br />

analyze the stuck-open PORV event –<br />

were the root causes of the TMI-2<br />

accident. Correcting the first omission<br />

would have prevented the accident.<br />

Correcting the second omission would<br />

have resulted in prompt and effective<br />

mitigation of the accident.<br />

Lessons learned<br />

Understanding the root causes of<br />

the TMI accident provides valuable<br />

guidance <strong>for</strong> nuclear power plant<br />

designers, especially <strong>for</strong> designers<br />

of new plant types, such as small<br />

modular reactors. The recognition<br />

of safety-related components and<br />

design-specific accidents is more<br />

complex and more difficult than it<br />

appears to be. It is the designer’s<br />

responsibility to identify all safetyrelated<br />

systems and components<br />

and to analyze all accident types.<br />

Many systems and components<br />

of a plant have both an operational<br />

function and a safety function. In the<br />

design of every system, the question<br />

must be raised as to whether a system<br />

or component has a safety function.<br />

Then, if applicable, it must be<br />

designed <strong>for</strong> both the operational<br />

function and the safety function.<br />

Plant response during accidents<br />

can be abnormal and never seen<br />

during normal operation. The plant’s<br />

safety analysis must be complete, and<br />

it must describe all potential plant<br />

responses.<br />

Designers cannot depend on<br />

utilities’ reviews and regulatory<br />

evaluations to correct shortcomings.<br />

The design must be done right in the<br />

first place, and the quality assurance<br />

process should guarantee perfection<br />

of the design.<br />

Acknowledgment<br />

I am grateful to Sheldon Trubatch <strong>for</strong><br />

his valuable suggestions, review of<br />

this article, and thoughtful comments<br />

and insight into the era from the legal<br />

perspective surrounding the accident.<br />

I have derived great benefit from our<br />

stimulating discussions.<br />

References<br />

1. John G. Kemeny, et al.: Report of the President’s Commission on<br />

the Accident at Three Mile Island (October 30, 1979).<br />

2. Mitchell Rogovin, George T. Frampton Jr.: Three Mile Island: A<br />

Report to the Commissioners and to the Public (January 1980).<br />

Author<br />

Zoltan R. Rosztoczy<br />

Environment and Safety<br />

Root Causes of the Three Mile Island Accident ı Zoltan R. Rosztoczy


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

Das neue Strahlenschutzrecht (IV) – Schutz vor Radon<br />

Christian Raetzke<br />

Den vorläufigen Abschluss der kleinen Reihe zum neuen Strahlenschutzrecht sollen heute die neuen Regelungen zum<br />

Schutz vor Radon bilden. Das ist zwar ein Thema, das in der Kernenergie und Kerntechnik nicht unbedingt im<br />

Vordergrund steht; dafür dürfte es künftig in Teilen der Wirtschaft und der Bevölkerung um so mehr für Aufmerksamkeit<br />

sorgen und ist sicherlich von allgemeinem Interesse.<br />

Der Schutz vor Radon wird im neuen Strahlenschutzrecht<br />

(im Strahlenschutzgesetz – StrlSchG – vom 27.06.2017<br />

und in der neuen Strahlenschutzverordnung – StrlSchV –<br />

vom 29.<strong>11</strong>.2018), das an vielen Stellen und besonders<br />

auch hier die Euratom-Grundnorm zum Strahlenschutz<br />

(Richtlinie 2013/59/Euratom) umsetzt, einschneidend<br />

neu und viel umfassender als bisher geregelt. In der alten<br />

StrlSchV gab es bei „Arbeiten“ (so die damalige Terminologie),<br />

die im Zusammenhang mit natürlich vorkommender<br />

Radioaktivität standen, bestimmte Regelungen für<br />

Arbeitsplätze bis hin zu einer Anzeigepflicht (§ 95 StrlSchV<br />

a.F.); dazu gehörte in Anlage XI Teil A eine kurze Liste<br />

„Arbeitsfelder mit erhöhten Radon-222-Expositionen“.<br />

Die Regelungen im neuen Strahlenschutzrecht sind viel<br />

umfassender aufgestellt. Sie betreffen nicht nur Arbeitsplätze,<br />

also die berufliche Strahlenexposition, sondern<br />

auch Aufenthaltsräume, also die Exposition der Bevölkerung.<br />

Einige Regelungen gelten speziell für eine der beiden<br />

Expositionskategorien, andere sind allgemeiner, übergreifender<br />

Art. Am besten findet man sich wohl zurecht,<br />

wenn man die Regelungen entsprechend in drei Gruppen<br />

betrachtet: allgemeine, auf Arbeitsplätze bezogene und<br />

auf Aufenthaltsräume bezogene Bestimmungen. So sind<br />

sie auch im Gesetz und in der Verordnung eingeteilt.<br />

Bei den allgemeinen Regelungen ist besonders die<br />

Pflicht der zuständigen Länderbehörden zu erwähnen, bis<br />

Ende 2020 sog. Radonvorsorgegebiete auszuweisen. Dieser<br />

Begriff (der so im Gesetz nicht auftaucht) be zeichnet<br />

Gebiete gem. § 121 StrlSchG, in denen die Radon-222-<br />

Aktivitätskonzentration in der Raumluft „in einer beträchtlichen<br />

Zahl von Gebäuden“ die Referenzwerte für Aufenthaltsräume<br />

oder Arbeitsplätze überschreitet. Die beiden<br />

Referenzwerte für Aufenthaltsräume und Arbeitsplätze sind<br />

im Gesetz <strong>for</strong>mal getrennt festgelegt (§§ 124 bzw. 126<br />

StrlSchG), lauten aber übereinstimmend 300 Becquerel<br />

(Bq) je Kubikmeter (m 3 ). Die Bestimmung der Vorsorgegebiete<br />

erfolgt „auf Grundlage einer wissenschaftlich<br />

basierten Methode“, die „Vorhersagen“ ermöglicht (so § 153<br />

StrlSchV); geeig nete Daten hierfür können auf tatsächlichen<br />

Messwerten, aber auch auf geologischen Daten, also<br />

letztlich auf Berechnungen beruhen. Eine „beträcht liche<br />

Zahl von Gebäuden“ soll erreicht sein, wenn auf mindestens<br />

75 % des auszuweisenden Gebiets der Referenzwert in<br />

min destens zehn Prozent der Gebäude überschritten wird.<br />

Sind erst einmal diese Radonvorsorgegebiete ausgewiesen,<br />

so ergibt sich aus § 123 StrlSchG die Pflicht, bei<br />

Neubauten in diesen Gebieten „geeignete Maßnahmen zu<br />

treffen, um den Zutritt von Radon aus dem Baugrund zu<br />

verhindern oder erheblich zu erschweren“. Das gilt einheitlich<br />

für Gebäude mit Arbeitsplätzen und/oder mit Aufenthaltsräumen,<br />

also auch für Wohngebäude oder Bauten<br />

für Schulen und Kindergärten. § 154 StrlSchV zählt fünf<br />

Arten von Maßnahmen auf und lässt „mindestens eine“<br />

davon genügen; damit soll offenkundig die An<strong>for</strong>derung<br />

handhabbar gemacht und eine Übersteigerung vermieden<br />

werden. Zu den Maßnahmen zählen etwa die Verringerung<br />

der Radon-222-Aktivitätskonzentration unter dem<br />

Gebäude, die Begrenzung der Rissbildung in Wänden und<br />

Böden mit Erdkontakt und die Absaugung von Radon an<br />

Randfugen oder unter Abdichtungen.<br />

Der Bund ist nach § 122 StrlSchG verpflichtet, einen<br />

Radonmaßnahmenplan zu erstellen; das ist mittlerweile<br />

geschehen (siehe www.bmu.de/publikation/radonmassnahmenplan).<br />

Das Dokument nennt, neben den gesetzlich<br />

ge<strong>for</strong>derten Maßnahmen, auch und vor allem In<strong>for</strong>mationskampagnen,<br />

Förderung der Allgemeinbildung<br />

zu Radon und der beruflichen Qualifikation und Weiterbildung,<br />

Entwicklung einheitlicher Messstrategien, Vergabe<br />

weiterer Studien und Ähnliches.<br />

Bei Arbeitsplätzen besteht dann eine Handlungspflicht,<br />

wenn sie entweder einem der bereits in der alten StrlSchV<br />

genannten „Arbeitsfelder“ angehören (vor allem Berg werke<br />

und Anlagen der Wassergewinnung und -ver teilung), und<br />

zwar unabhängig vom geografischen Gebiet, oder wenn sie<br />

sich im Erd- oder Kellergeschoss eines Gebäudes in einem<br />

Radonvorsorgegebiet befinden. §§ 127 bis 131 StrlSchG<br />

ordnen dann ein abgestuftes Verfahren an. Zeigt eine erste<br />

Messung, die innerhalb von 18 Monaten nach Einrichten<br />

des Arbeitsplatzes oder nach Ausweisung des Gebietes vorzunehmen<br />

ist, eine Überschreitung des Referenzwerts,<br />

muss der für den Arbeitsplatz Verantwortliche Maßnahmen<br />

zur Reduzierung der Radonkonzentration ergreifen und<br />

erneut messen. Liegt der Wert dann immer noch über dem<br />

Referenzwert, muss er den Arbeitsplatz bei der zuständigen<br />

Behörde anmelden und die Exposition abschätzen; vom<br />

Ergebnis dieser Abschätzung hängen dann bestimmte Maßnahmen<br />

des beruflichen Strahlenschutzes ab. Der Arbeitgeber<br />

wird damit nicht zum Strahlenschutzverantwortlichen,<br />

da es sich – in der neuen Terminologie des StrlSchG<br />

– nicht um eine geplante Expositionssituation, sondern um<br />

eine bestehende Expositionssituation handelt; er hat aber<br />

teils vergleich bare Pflichten.<br />

Für Aufenthaltsräume (also Wohnungen, Schulen,<br />

Kinderg ärten etc.) enthalten §§ 124 und 125 StrlSchG<br />

Regelungen, die keinen verpflichtenden Charakter haben,<br />

sondern auf Unterrichtung der Bevölkerung und auf das<br />

„Anregen“ von Messungen und ggf. von Schutzmaßnahmen<br />

hinauslaufen. Wie oben erwähnt, gibt es aber für<br />

Neubauten in Radonvorsorgegebieten, die Aufenthaltsräume<br />

enthalten, eine Pflicht, Maßnahmen zum Schutz<br />

vor Radon zu treffen; insofern sind nur Bestandsbauten<br />

vorerst von verbindlichen Maßnahmen verschont.<br />

Wie geht es weiter? Das Thema Radon steht schon seit<br />

einigen Jahren im Fokus der Strahlenschützer, im allgemeinen<br />

Bewusstsein dürfte es aber erst dann wirklich ankommen,<br />

wenn ab 2021 die Radonvorsorgegebiete ausgewiesen<br />

sind, In<strong>for</strong>mationskampagnen richtig anlaufen und echte<br />

Pflichten für viele Arbeitgeber und Bauherren entstehen. Es<br />

steht zu hoffen, dass die neuen Regelungen dann die<br />

gewünschte Steuerungswirkung entfalten und die findige<br />

Bevölkerung nicht einfach nur gemäß einem Spruch handelt,<br />

den der Verfasser von einem geschätzten Kollegen aus<br />

dem (radonmäßig stark betroffenen) Vogtland gehört hat:<br />

„Die Zahnarztpraxis unters Dach, die Oma in den Keller“.<br />

Author<br />

Rechtsanwalt Dr. Christian Raetzke,<br />

Beethovenstr. 19, 04107 Leipzig<br />

525<br />

SPOTLIGHT ON NUCLEAR LAW<br />

Spotlight on <strong>Nuclear</strong> Law<br />

 The New Radiation Protection Law – Protection Against Radon ı Christian Raetzke


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

526<br />

RESEARCH AND INNOVATION<br />

Evaluation of a Double-Ended Guillotine<br />

LBLOCA Transient in a Generic<br />

Three-Loops PWR-900 with TRACE Code<br />

Coupled with DAKOTA Uncertainty<br />

Analysis<br />

Andrea Bersano and Fulvio Mascari<br />

In the present study, the model of a generic three-loops PWR-900 western type reactor has been developed and a<br />

double-ended guillotine break on the cold leg has been simulated by TRACE code. Through the SNAP graphical<br />

interface, a DAKOTA uncertainty analysis, based on the probabilistic method to propagate input uncertainty, has been<br />

per<strong>for</strong>med by selecting uncertain parameters related to the safety injection system and to the initial plant status. In<br />

particular, six uncertain input parameters have been considered: the accumulators’ initial pressure and temperature,<br />

the safety injection system temperature and flow rate, the reactor initial power and the containment initial pressure.<br />

The main figure of merit selected <strong>for</strong> the application of regression correlation is the hot rod cladding temperature. Both<br />

Pearson and Spearman’s correlation coefficients have been computed <strong>for</strong> the cladding temperature of the hot rod to<br />

characterize its correlation with the input uncertain parameters in the different phases of the transient. In addition, the<br />

dispersion of the calculated data have been discussed <strong>for</strong> selected relevant thermal-hydraulic parameters, such as the<br />

primary pressure, the core mass flow rate and the water collapsed level in the vessel.<br />

1 Introduction<br />

<strong>Nuclear</strong> energy is part of the energy<br />

mix of several countries considering<br />

its important role in the reduction of<br />

air pollution and CO 2 emissions<br />

caused by energy pro duction [1]. Due<br />

to the complexity of nuclear plants,<br />

caused by their complex geometry<br />

where multicomponent and twophase<br />

thermal hydraulic phenomena<br />

take place, their thermal hydraulic behavior<br />

is characterized with computational<br />

tools to assess their operating<br />

conditions and to evaluate their safety<br />

(both <strong>for</strong> Design Basis Accidents and<br />

Beyond Design Basis Accident) [2, 3].<br />

The computational tools used in<br />

the nuclear sector, also called codes,<br />

undergo a process of Verification and<br />

Validation (V&V) [4]. It is part of this<br />

rigorous process the use of an experimental<br />

“assessment database” [3];<br />

results from Separate Effect Test<br />

Facilities (SETF) and Integral Test<br />

Facilities (ITF) are used to evaluate<br />

the qualitative and quantitative code<br />

accuracy in the prediction of the<br />

phenomena of interest. The codes<br />

that use more realistic in<strong>for</strong>mation<br />

concerning phenomena and plant<br />

behavior are often referred to as Best<br />

Estimate (BE) codes [5].<br />

Though the high level of maturity<br />

reached by BE thermal hydraulic<br />

system codes in the last decades, in<br />

their application there are still some<br />

sources of uncertainty ( uncertainty is<br />

used as a measure of the error made<br />

with the code in predicting the plant<br />

behavior) affecting the calculation<br />

results [3]. In general the sources of<br />

uncertainty can be grouped as a) code<br />

uncertainty (e.g. approximations in<br />

the onservation equation and in the<br />

closure models and correlations)<br />

b) representation uncertainty (nodalization<br />

effect), c) scaling issue (codes<br />

validated against scaled-down facilities),<br />

d) plant uncertainty (e.g. initial<br />

and boundary conditions), e) user<br />

effect. For this reason, providing the<br />

result of a BE calculation alone may be<br />

not sufficient and the evaluation of<br />

the uncertainty on the results is<br />

required. Several methodologies have<br />

been developed in the past to per<strong>for</strong>m<br />

Uncertainty Analysis. In particular<br />

these uncertainty methodologies can<br />

be grouped in a) methods to propagate<br />

input uncertainty, divided in<br />

probabilistic (e.g. CSAU, GRS, IPSN,<br />

etc.) and deterministic methods (e.g.<br />

AEAW, EDF-Framatome, etc.); and b)<br />

method to extrapolate output uncertainty<br />

(e.g. UMAE) [6].<br />

In this framework, the target of the<br />

present paper is to use the probabi listic<br />

method to propagate the input<br />

uncertainty in the calculation of a cold<br />

leg double- ended guillotine break<br />

transient of a generic three-loops PWR-<br />

900 western type reactor with the<br />

avail ability of active and passive Emergency<br />

Core Cooling Systems (ECCS).<br />

The Uncertainty Quanti fication (UQ)<br />

application of this methodology is<br />

based on a set of statistical techniques<br />

<strong>for</strong> the evaluation of the number of<br />

needed code runs and <strong>for</strong> the correlation<br />

of the output results with the<br />

uncertain inputs. The method has been<br />

applied using DAKOTA toolkit [7],<br />

developed by Sandia National Laboratories,<br />

and has been used in the SNAP<br />

(Symbolic <strong>Nuclear</strong> Analysis Package)<br />

environment/architecture [8] with the<br />

related DAKOTA uncertainty plug-in<br />

[9]. The calculations have been per<strong>for</strong>med<br />

with TRACE (TRAC/RELAP<br />

Advanced Computational Engine) v5<br />

patch 4 BE thermal- hydraulic system<br />

code developed by USNRC [10]. The<br />

hot rod cladding temperature has been<br />

selected as a figure of merit and a<br />

limited number of input un certainty<br />

parameters, mostly related to plant<br />

initial conditions, have been chosen <strong>for</strong><br />

the UQ application.<br />

2 Description of probabilistic<br />

method to propagate<br />

input uncertainty,<br />

Dakota Toolkit, and UQ<br />

hyphothesis<br />

2.1 Probabilistic method<br />

to propagate input<br />

uncertainty<br />

The probabilistic method to propagate<br />

the input uncertainty [<strong>11</strong>] is, in brief,<br />

based on a random sampling of the<br />

input uncertain parameters selected<br />

by the user; a set of N code runs having<br />

in the input a combination of the uncertain<br />

parameters is created and<br />

solved with the selected code. Then,<br />

by using regression analysis, the effect<br />

of the input parameters uncertainty<br />

on the results is computed, in terms of<br />

selected Figure of Merits (FOMs). The<br />

Research and Innovation<br />

Evaluation of a Double-Ended Guillotine LBLOCA Transient in a Generic Three-Loops PWR-900 with TRACE Code Coupled with DAKOTA Uncertainty Analysis ı Andrea Bersano and Fulvio Mascari


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

main advantages of this method are<br />

that the number of code runs does not<br />

depend on the number of input<br />

uncertain parameters and it is not<br />

necessary a prior development of<br />

a Phenomena Identification and<br />

Ranking Table (PIRT), which is a long<br />

process. The number of code runs N<br />

depends on the probability content<br />

and on the confidence level set by the<br />

user and on the number of FOMs<br />

selected <strong>for</strong> the analysis and it is computed<br />

using the Wilks <strong>for</strong>mula [12,<br />

13]. Each uncertain input parameter<br />

should be defined by its range of<br />

variation and its Probability Density<br />

Function (PDF); this means that even<br />

if the exact value of a parameter is<br />

uncertain, some values are more likely<br />

to be close to the real one than others.<br />

This is one of the main task to be<br />

tackled because the evaluation of the<br />

correct PDF <strong>for</strong> each parameter is not<br />

a trivial task and a careful study is<br />

required. The selection of the most<br />

suitable PDF <strong>for</strong> each parameter depends<br />

mainly on the physical quantity<br />

and on the availability of reducedscale<br />

or full-scale measured data. If<br />

data are available, it is possible to<br />

build a histogram and to derive the<br />

PDF. A comprehensive overview of<br />

PDF type and derivation techniques is<br />

provided in [14].<br />

2.2 DAKOTA toolkit in the<br />

SNAP environment/<br />

architecture<br />

DAKOTA [7] is an open source software<br />

written in C++ and developed by<br />

Sandia National Laboratories to per<strong>for</strong>m<br />

parametric and uncertainty<br />

analysis in a fast and automatic way.<br />

The aim of this toolkit is to bridge<br />

simulation codes and analysis methods<br />

<strong>for</strong> parametric evaluation, uncertainty<br />

quantification and system optimization<br />

[15]. The DAKOTA toolkit is also<br />

provided as a plug-in [9] <strong>for</strong> the<br />

Symbolic <strong>Nuclear</strong> Analysis Package<br />

(SNAP), which is a graphical user<br />

interface designed to support the use<br />

of USNRC nuclear codes (e.g. TRACE,<br />

RELAP, MELCOR, etc.). Using SNAP, it<br />

is possible to build the input deck in a<br />

graphical environment and to have a<br />

direct visualization of the code calculated<br />

data by using its animation<br />

capability. Through SNAP it is possible<br />

to set up the DAKOTA uncertainty<br />

analysis [16, 17] and to per<strong>for</strong>m automatically<br />

all the steps qualitatively<br />

described in the previous section.<br />

Figure 1 shows a schematic representation<br />

of DAKOTA uncertainty analysis<br />

workflow in a SNAP environment/<br />

architecture.<br />

In particular, DAKOTA plugin allows<br />

to:<br />

1) Enter the uncertain input parameters<br />

with their range and PDF;<br />

2) Select the sampling method<br />

( Monte Carlo or Latin Hypercube);<br />

3) Enter the desired FOMs <strong>for</strong> the<br />

analysis;<br />

4) Set the final report that contains<br />

the results of the uncertainty<br />

analysis application; the report is<br />

auto matically generated at the end<br />

of the uncertainty quantification<br />

analysis.<br />

DAKOTA is used at the beginning of<br />

the analysis to sample the uncertain<br />

input parameter values and to<br />

generate the set of code inputs. Then,<br />

after the solution of the set of code<br />

inputs and the extraction of the<br />

desired data, DAKOTA per<strong>for</strong>ms the<br />

uncertainty analysis and apply<br />

regression techniques to evaluate the<br />

correlation between input and output<br />

parameters selected as a FOM.<br />

The required number of code runs<br />

can be found solving the Wilks<br />

<strong>for</strong>mula with respect to N <strong>for</strong> a probability<br />

α and a confidence level β [<strong>11</strong>]:<br />

(1)<br />

With α=0.95 and β=0.95, <strong>for</strong> one<br />

FOM the required number of code<br />

runs is 59.<br />

2.3 UQ application hypothesis<br />

The target of this analyses, is not to be<br />

a detail uncertainty study in term of<br />

input uncertainty parameters as<br />

presented in [18], but a) to develop a<br />

full UQ application with TRACE and<br />

DAKOTA toolkit in a SNAP environment/architecture<br />

and b) to have<br />

some insights about the degree of<br />

corre lation between the input parameters<br />

selected and the FOM chosen<br />

<strong>for</strong> this analysis. Six uncertain parameters<br />

have been selected <strong>for</strong> this<br />

uncertainty application based also on<br />

BEMUSE program results [18] and<br />

through SNAP have been implemented<br />

in the DAKOTA and TRACE<br />

input: the Safety Injection System<br />

(SIS) temperature, the SIS characteristic,<br />

the accumulator initial temperature<br />

and pressure, the initial core<br />

power and the initial con tainment<br />

pressure. The SIS characteristic is a<br />

value that multiply the default injected<br />

flow rate curve as function of the<br />

primary pressure. Table 1 summarizes<br />

the uncertain input parameters,<br />

their mean value used <strong>for</strong> the reference<br />

calculation, the range of variation<br />

and the adopted PDF.<br />

One FOM was selected <strong>for</strong> the<br />

analysis, the cladding temperature of<br />

the hot rod; there<strong>for</strong>e, with a probability<br />

of 95% and a confidence level of<br />

95%, a total of 59 calculations were<br />

required based on Wilks <strong>for</strong>mula as<br />

previously described. Latin Hypercube<br />

sampling [19,20] has been used<br />

<strong>for</strong> this analysis. It is a stratified<br />

sampling method that, with respect to<br />

a pure Monte Carlo sampling, allows<br />

to achieve the target statistical<br />

| Fig. 1.<br />

DAKOTA uncertainty analysis workflow <strong>for</strong> TRACE code in a SNAP environment/architecture.<br />

RESEARCH AND INNOVATION 527<br />

Research and Innovation<br />

Evaluation of a Double-Ended Guillotine LBLOCA Transient in a Generic Three-Loops PWR-900 with TRACE Code Coupled with DAKOTA Uncertainty Analysis ı Andrea Bersano and Fulvio Mascari


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

Parameter Average value Range of variation PDF type<br />

RESEARCH AND INNOVATION 528<br />

Safety injection system (SIS) temperature [K] 285 [-10,+10] K Normal<br />

Safety injection system (SIS) characteristic [-] 1 [0.95,1.05] Normal<br />

Accumulator initial temperature [K] 325 [-10,+10] K Normal<br />

Accumulator initial pressure [bar] 40.8 [-2,+2] bar Normal<br />

Initial core power [MW] 2785 [0.98,1.02] Normal<br />

Initial containment pressure [bar] 1.013 [0.85,1.15] Uni<strong>for</strong>m<br />

| Tab. 1.<br />

Input uncertain parameters selected <strong>for</strong> the analysis.<br />

| Fig. 2.<br />

TRACE nodalization of the primary system and of the containment of the generic three-loops PWR developed with SNAP.<br />

accuracy with a minor number of<br />

samples. All 59 runs were correctly<br />

executed and they reached the end of<br />

calculation without any failure. To<br />

analyze the transient progression, the<br />

primary system pressure, the core<br />

flow rate, the cladding hot rod temperature<br />

and the vessel collapsed level<br />

have been plotted <strong>for</strong> the complete set<br />

of 59 runs, while the application of<br />

regression analysis has been carried<br />

out only <strong>for</strong> the cladding temperature.<br />

3 Generic PWR-900 TRACE<br />

model and steady state<br />

operation<br />

3.1 TRACE nodalization<br />

description<br />

TRACE, developed by USNRC, is a<br />

component-oriented code designed<br />

to per<strong>for</strong>m best-estimate thermalhydraulic<br />

analysis <strong>for</strong> LWR. It is a<br />

finite volume, two fluid, code with 3D<br />

capability and it is based on two fluid,<br />

two-phase field equations. This set of<br />

equations consists of the conservation<br />

laws of mass, momentum and energy<br />

<strong>for</strong> the liquid and gas phases [10, 21].<br />

The code version adopted in this<br />

analysis is TRACE code v5 patch 4 and<br />

the input deck has been developed<br />

with SNAP.<br />

The nodalization of a generic threeloops<br />

PWR-900, shown in Figure 2,<br />

has been developed to per<strong>for</strong>m the<br />

large break LOCA analysis. In order to<br />

minimize the computational time (in<br />

view of input uncertainty propagation<br />

with probabilistic method) and maintain<br />

an accurate prediction of target<br />

phenomena, the nodalization strategy<br />

used follows the general nodalization<br />

approach of the TRACE W4loops<br />

samples input-deck distributed with<br />

SNAP. Starting from that nodalization<br />

approach sample and considering the<br />

level of detail target of this analysis<br />

(e.g. modeling the three loops separately,<br />

modeling the interaction containment/primary<br />

coolant system,<br />

etc…), more details have been considered<br />

in the input-deck development.<br />

In the nodalization of the generic<br />

three-loop PWR-900 no lumped loops<br />

have been considered and the three<br />

loops have been modeled separately,<br />

one simulates the broken one (loop A)<br />

and two simulate the intact loops<br />

(loop B and C). The model is composed<br />

of 69 Hydraulic Components<br />

(HC) and 45 Heat Structures (HS).<br />

<strong>Power</strong> is provided to the three heat<br />

structures simulating the core through<br />

one power component, the total<br />

thermal power is around 2800 MW; in<br />

one of the HS that compose the core is<br />

inserted a supplemental rod that simulates<br />

the hot rod in the reactor with a<br />

total peaking factor of 2.278 [22]. The<br />

pressurizer is connected to the hot leg<br />

of an intact loop (loop B). The break<br />

has been modeled with a set of three<br />

valves; at the break opening one valve<br />

interrupts the connection between the<br />

two sections of the guillotine break on<br />

the cold leg of loop A; simultaneously,<br />

the other two valves connect the two<br />

closed sections of the leg to the components<br />

simulating the containment.<br />

Particular attention has been paid<br />

to the containment building modeling<br />

in order to simulate the interaction<br />

containment/primary system during<br />

the LOCA. In particular, the containment<br />

has been modeled with two connected<br />

hydraulic regions thermally<br />

coupled to the heat structure simulating<br />

the containment solid structure<br />

and the thermal interaction with<br />

the environment. Figure 2 shows<br />

the TRACE nodalization of the<br />

generic PWR primary system and the<br />

Research and Innovation<br />

Evaluation of a Double-Ended Guillotine LBLOCA Transient in a Generic Three-Loops PWR-900 with TRACE Code Coupled with DAKOTA Uncertainty Analysis ı Andrea Bersano and Fulvio Mascari


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

| Fig. 3.<br />

TRACE nodalization of<br />

the RPV of the generic<br />

three-loops PWR developed<br />

with SNAP.<br />

| Fig. 4.<br />

SNAP animation showing the fluid condition of the primary system during the steady state (at 900 s).<br />

RESEARCH AND INNOVATION 529<br />

containment (the containment drawing<br />

is scaled down with a factor 0.2 in<br />

comparison with the other reactor<br />

components <strong>for</strong> a better visualization<br />

of the complete plant layout). The<br />

ECCS are connected on the cold leg of<br />

each loop; <strong>for</strong> each loop, the ECCS<br />

consist of an accumulator and the<br />

high pressure and low pressure safety<br />

injection systems (HPIS, LPIS). The<br />

HPIS and LPIS are modeled by a single<br />

“fill” component with a table that<br />

controls the injected flow rate as<br />

function of the pressure in the primary<br />

system. The Reactor Pressure Vessel<br />

(RPV) has been modeled by using the<br />

3D Vessel component available in<br />

TRACE. The 3D vessel nodalization<br />

has been divided into: 2 radial sectors,<br />

the inner one <strong>for</strong> the core and the<br />

outer one <strong>for</strong> the downcomer, 3 angular<br />

sectors, one <strong>for</strong> each primary loop<br />

and 7 axial sectors, 2 <strong>for</strong> the vessel<br />

lower plenum, 3 <strong>for</strong> the core and 2<br />

<strong>for</strong> the vessel upper plenum. The 3D<br />

vessel nodalization representation<br />

made with SNAP is shown in Figure 3,<br />

with the core region highlighted.<br />

3.2 Steady state<br />

characterization<br />

Be<strong>for</strong>e the beginning of the LOCA,<br />

1000 s of steady state operation have<br />

been simulated to test the nodalization<br />

in steady state condition. The<br />

steady state parameters are reported<br />

in Table 2 and they have been checked<br />

<strong>for</strong> consistency with public available<br />

in<strong>for</strong>mation [23, 24].<br />

Figure 4 shows the fluid con ditions<br />

in the primary system during the<br />

steady state; the color legend refers to<br />

the fluid status, ranging from blue<br />

(subcooled liquid) to red (superheated<br />

gas/steam). Figure 5 shows<br />

the axial pressure profile in the<br />

primary system in steady state conditions,<br />

to support the steady state<br />

qualification of the nodalization. The<br />

normalized pressure profile is consistent<br />

with other similar data available<br />

in the public scientific literature<br />

[25].<br />

4 Cold leg lbloca transient<br />

and uncertainty analysis<br />

4.1 LBLOCA transient analysis<br />

The analyzed transient is a doubleended<br />

guillotine break (200 %) in the<br />

cold leg of loop A. After 1000 s of<br />

steady state simulation the break is<br />

opened (start of the transient: t = 0 s)<br />

and 500 s of transient are simulated.<br />

The reactor SCRAM is supposed after<br />

0.5 s from the break. From ­Figure 6 to<br />

Figure 9 the results <strong>for</strong> the 59 runs are<br />

shown <strong>for</strong> the primary system pressure,<br />

the core flow rate, the cladding<br />

hot rod temperature and the vessel<br />

collapsed level. Figure 6 shows the<br />

behavior of the primary system pressure;<br />

after the LOCA initiation, water<br />

flows from the primary system to the<br />

containment and the primary system<br />

pressure drops significantly in few<br />

tens of milliseconds in agreement<br />

with the publically available technical<br />

scientific literature [26]; after this<br />

first drop of pressure and the phase<br />

of subcooled depressurization, the<br />

saturation con dition is reached and<br />

saturated depressurization starts at a<br />

reduced rate. The maximum flow rate<br />

through the break is limited by the<br />

critical velocity at the break. After the<br />

transient initiation, the flow rate in<br />

the core (Figure 7) drops from the<br />

nominal value and it is reversed since<br />

the flow is directed to the break<br />

location; there<strong>for</strong>e, water flows downwards<br />

in the core region and then<br />

upward in the downcomer to reach<br />

the break in the cold leg.<br />

The high voiding in the core and<br />

the subsequent SCRAM stop the chain<br />

reaction and, due to a sensible<br />

reduction of heat removal in the<br />

core, the heat stored in the fuel is<br />

Thermal power [MW] 2785<br />

Primary system pressure [bar] 155<br />

Total core flow rate [kg/s] 13,947<br />

Core inlet temperature [K] 558.4<br />

Core outlet temperature [K] 594.1<br />

Secondary system pressure [bar] 58<br />

Steam generator feedwater temperature [K] 440<br />

Steam generator feedwater flow rate [kg/s] 512<br />

| Tab. 2.<br />

Steady state parameters of the reference calculation.<br />

| Tab. 5.<br />

Normalized axial pressure profile along the primary system in steady state<br />

condition (at 900 s).<br />

Research and Innovation<br />

Evaluation of a Double-Ended Guillotine LBLOCA Transient in a Generic Three-Loops PWR-900 with TRACE Code Coupled with DAKOTA Uncertainty Analysis ı Andrea Bersano and Fulvio Mascari


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

RESEARCH AND INNOVATION 530<br />

redistributed, leading to the first<br />

cladding temperature peak, as shown<br />

in Figure 8. The cladding temperature<br />

passes from the steady state value<br />

(around 617 K) to 955 K. The result<br />

of the core voiding is a sudden drop<br />

of the water collapsed level in the<br />

reactor vessel, as shown in Figure 9,<br />

under the Bottom of Active Fuel<br />

(BAF). When the pressure in the<br />

primary system is lower than the<br />

accumulator initial pressure, the<br />

accumulator check valves open and<br />

water is discharged in the primary<br />

system; this happens around <strong>11</strong> s after<br />

the transient initiation. The water<br />

initially injected in the cold legs by the<br />

accumulators bypasses the vessel<br />

lower plenum through the upper<br />

down comer region and it is directed to<br />

the break without penetrating the<br />

core. After the first fast depressurization<br />

phase, the primary pressure<br />

continues to reduce at a lower rate,<br />

equalizing the containment pressure<br />

(around 0.45 MPa after around 40 s)<br />

and ending the blowdown phase.<br />

Water is injected in the primary<br />

system by the accumulators and the<br />

low pressure safety injection system<br />

start to inject water after around 30 s<br />

from the break initiation. The refill<br />

phase starts around 40 s, when the<br />

emergency core coolant water reaches<br />

the vessel lower plenum and the<br />

collapsed level in the vessel starts to<br />

rise. During this phase the core is<br />

mainly uncovered and heat is not<br />

removed from the fuel rods, with the<br />

exception of a small amount of heat<br />

removed by thermal radiation and<br />

natural convection of the steam<br />

present in the core. For this reason<br />

during the refill period the cladding<br />

temperature increases (Figure 8) due<br />

to the quasi adiabatic heating of<br />

fission product decay. When, around<br />

50 s from the LOCA initiation, the<br />

water level reaches the core bottom<br />

(Figure 9) the refill period ends<br />

and the reflood phase starts. Water<br />

collapsed level rises quickly up to<br />

around 65 s (time of end of accumulators<br />

injection), and it continues at a<br />

lower rate due to the LPIS. In this<br />

phase the net core flow rate is positive,<br />

even if very small and with many<br />

oscillations. The water entering the<br />

core is heated up, starts to boil and<br />

entrains water droplets that help the<br />

cooling of the hottest parts of the core.<br />

With the rising of the water level, the<br />

cooling is increased and the cladding<br />

temperature starts to decrease. The<br />

complete rewetting of the cladding<br />

surface caused by the rising water<br />

level produces a strong temperature<br />

drop (core quenching). This happens<br />

around 125 s after the beginning of<br />

the LOCA.<br />

Analyzing the dispersion of the<br />

results, the primary pressure (Figure<br />

6) presents an almost negligible<br />

dispersion during the blowdown<br />

phase and the predictions of the 59<br />

runs are very similar; after the blowdown<br />

the dispersion band width is<br />

always lower than 0.1 MPa with a final<br />

average value of 0.475 MPa. As<br />

regards the core mass flow rate<br />

(Figure 7), cladding temperature<br />

(Figure 8) and vessel water collapsed<br />

level (Figure 9), the results dispersion<br />

is very limited during the blowdown<br />

phase, while it is more noticeable in<br />

the refill phase, especially <strong>for</strong> the<br />

vessel water collapsed level, and it is<br />

higher during the reflood phase.<br />

In particular, the refill initial time<br />

shows a dispersion band width of 12 s<br />

(33 – 45 s); during the reflood the<br />

collapsed level dispersion band width<br />

is around 1 m and the Top of Active<br />

Fuel (TAF) is reached in a time band<br />

of 33 s (126 – 159 s). The cladding<br />

temperature has, at the first peak, a<br />

low dispersion band width of 14 K<br />

and the peak has almost the same<br />

timing <strong>for</strong> all runs; instead, the dispersion<br />

band width is higher <strong>for</strong> the<br />

second peak (50 K) and with a time<br />

dispersion band width of 10 s. The hot<br />

rod cladding quenching time is also<br />

affected by a dispersion band width<br />

of 20 s (<strong>11</strong>5 – 135 s).<br />

| Tab. 6.<br />

Primary system pressure predicted by TRACE code.<br />

| Tab. 7.<br />

Core mass flow rate predicted by TRACE code.<br />

| Tab. 8.<br />

Cladding temperature of the hot rod predicted by TRACE code.<br />

| Tab. 9.<br />

Reactor vessel water collapsed level predicted by TRACE code.<br />

Research and Innovation<br />

Evaluation of a Double-Ended Guillotine LBLOCA Transient in a Generic Three-Loops PWR-900 with TRACE Code Coupled with DAKOTA Uncertainty Analysis ı Andrea Bersano and Fulvio Mascari


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

| Tab. 10.<br />

Pearson’s simple regression correlation coefficients.<br />

4.2 Uncertainty analysis<br />

response correlations<br />

4.2.1 Description of regression<br />

correlations in DAKOTA<br />

As a result of the uncertainty analysis,<br />

DAKOTA [7, 8, 20] computes four<br />

response correlation coefficients:<br />

simple, partial, simple rank and<br />

partial rank. The simple coefficient is<br />

related to the actual input and output<br />

data. The simple coefficient r between<br />

an input variable x and an output<br />

variable y, in n samples, is computed<br />

using the Pearson’s correlation. It is a<br />

measure of the degree of linear correlation<br />

between the two variables and<br />

its value is comprised between -1 and<br />

1. If r0 the<br />

correlation is positive (an increment<br />

of x leads to an increment of y). The<br />

simple correlation coefficient between<br />

x and y is obtained by dividing the<br />

covariance of the two variables by the<br />

product of their standard deviations<br />

[27]:<br />

(2)<br />

The partial correlation coefficient is<br />

computed similarly to simple one but<br />

taking into accounts the effects of<br />

the other variables. This is useful, <strong>for</strong><br />

example, if there is a strong correlation<br />

between two inputs; in this way<br />

the correlation of the second input on<br />

the output may be adjusted after<br />

having considered the correlation between<br />

the first input and the output<br />

[7]. Rank correlation coefficients use<br />

the ranked data instead of the actual<br />

ones. Ranks are obtained by ordering<br />

the data in ascending order, and are<br />

more convenient to be used when<br />

inputs and outputs are characterized<br />

by sensible difference in magnitude; it<br />

is possible to understand if the input<br />

sample with the lower rank is associated<br />

to the output with the lower<br />

rank and so on [7, 20]. To compute the<br />

rank correlation, DAKOTA uses the<br />

Spearman’s rank correlation that is<br />

similar to Pearson’s one but with the<br />

ranked data instead of the actual<br />

values. If two variables are monotonically<br />

related, without repetitions,<br />

the Spearman coefficient is -1 or +1<br />

(depending if the function is monotonically<br />

decreasing or increasing),<br />

since the ranked values are used.<br />

Moreover, Spearman’s correlation is<br />

less sensitive to possible outlier values<br />

of the variables than Pearson’s one.<br />

4.2.2 Results of response correlation<br />

coefficients <strong>for</strong> the<br />

cold leg LBLOCA transient<br />

The time dependent computation of<br />

response correlation coefficients has<br />

been per<strong>for</strong>med extracting the FOM<br />

value at different selected instant of<br />

the transient evolution. Figure 10<br />

shows the Pearson’s simple correlation<br />

coefficient <strong>for</strong> the six input<br />

uncertain parameters from the LOCA<br />

beginning to the complete core<br />

quenching (after 130 s). Figure <strong>11</strong><br />

shows the Spearman’s rank correlation<br />

coefficient <strong>for</strong> the same parameters.<br />

On both graphs the values 0.2<br />

and 0.5 (and -0.2 and -0.5) have been<br />

highlighted as measure of the correlation<br />

between the input parameter<br />

and the FOM. As indicated in the [20],<br />

<strong>for</strong> the Spearman coefficient, if the<br />

coefficient is higher than 0.5 (or lower<br />

than -0.5) the correlation is significant,<br />

if it is between 0.2 and 0.5 (or<br />

-0.2 and -0.5) the correlation is<br />

moderate, otherwise it is low [20]. In<br />

| Tab. <strong>11</strong>.<br />

Spearman’s simple rank regression correlation coefficients.<br />

the following analysis the same<br />

threshold values have been adopted<br />

also <strong>for</strong> the Pearson coefficient. In this<br />

application, the two response correlations<br />

show similar trends; the main<br />

advantage of this time dependent<br />

analysis is the possibility to have a<br />

measure and characterize the correlation<br />

of the different input parameters<br />

on the uncertainty of the<br />

selected FOM in all the phases of the<br />

transient.<br />

In the blowdown phase (0-40 s) the<br />

effect of the initial core power on the<br />

hot rod cladding temperature is<br />

positive due to the heat stored in the<br />

solid structures. Both Pearson’s and<br />

Spearman’s coefficients are higher<br />

than 0.8 <strong>for</strong> this parameter so the<br />

correlation is significant and almost<br />

monotonically linear. In the remaining<br />

part of the transient both coefficients<br />

are close to 0.2 so the corre lation is<br />

much weaker than in the initial phase.<br />

After around 20 s from the LOCA<br />

initiation the accumulators initial<br />

pressure has a negative Pearson’s and<br />

Spearman’s coefficients around -0.3;<br />

there<strong>for</strong>e the lower is the accumulator<br />

pressure the higher is the cladding<br />

temperature since the accumulator<br />

starts to inject water later. In the refill<br />

phase (40-50 s), also the SIS characteristic<br />

has both response correlation<br />

coefficients around -0.3; in fact, with a<br />

lower injection flow rate the hot rod<br />

cladding temperature is higher. In the<br />

reflood phase (after 50 s) also the<br />

initial containment pressure has negative<br />

Pearson’s and Spearman’s coefficients<br />

around -0.35. This is due to the<br />

fact that with a lower pressure in the<br />

containment a greater amount of<br />

coolant water is expelled through<br />

the break and the cladding temperature<br />

is higher. The uncertainty in the<br />

accumulators and SIS temperature<br />

have a low correlation with the FOM.<br />

RESEARCH AND INNOVATION 531<br />

Research and Innovation<br />

Evaluation of a Double-Ended Guillotine LBLOCA Transient in a Generic Three-Loops PWR-900 with TRACE Code Coupled with DAKOTA Uncertainty Analysis ı Andrea Bersano and Fulvio Mascari


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

RESEARCH AND INNOVATION 532<br />

5 Conclusions<br />

Uncertainty analysis is used in the<br />

nuclear sector to evaluate uncertainties<br />

still present in the results of code’s<br />

calculations. Among the several<br />

methodologies developed in the past<br />

to per<strong>for</strong>m Uncertainty Analysis, the<br />

probabi listic method to propagate the<br />

input uncertainties has been selected<br />

<strong>for</strong> this analysis considering its<br />

suitability to be coupled with simulation<br />

codes; moreover, several<br />

toolkits, some integrated in computational<br />

plat<strong>for</strong>ms, have been developed<br />

<strong>for</strong> this purpose. In the present<br />

activity, a double-ended cold leg<br />

LBLOCA transient has been simulated<br />

with the BE thermal hydraulic system<br />

code TRACE <strong>for</strong> a generic three-loops<br />

PWR-900 reactor. Using DAKOTA<br />

toolkit, in a SNAP environment/architecture,<br />

an uncertainty analysis has<br />

been carried out by selecting six<br />

uncertain input parameters and the<br />

hot rod cladding temperature as the<br />

main figure of merit. In addition, the<br />

primary pressure, the core flow rate<br />

and the pressure vessel collapsed level<br />

have been analyzed to evaluate the<br />

transient progression and the results<br />

dispersion. The aim of this analysis is<br />

not to be a detail and exhaustive<br />

uncertainty study in term of input<br />

uncertainty parameters but to develop<br />

a complete uncertainty quantification<br />

application with DAKOTA in a SNAP<br />

environment/architecture and to have<br />

some insights characterizing the<br />

correlation between the input uncertainty<br />

parameters and the selected<br />

FOM. Pearson’s and Spearman’s<br />

response correlation coefficients have<br />

been computed between the LOCA<br />

initiation and the complete core<br />

quenching. In the blowdown phase,<br />

the hot rod cladding temperature has<br />

a significant correlation with the<br />

initial core power; the accumulators’<br />

initial pressure has a moderate correlation<br />

with the FOM only in the period<br />

of water injection from the accumulators.<br />

The time dependent response<br />

analysis, adopted in this application,<br />

is very useful since it could be used to<br />

characterize the effect of the uncertain<br />

input parameters on the output<br />

global uncertainty in the different<br />

phases of a transient. In a future<br />

follow-up, additional uncertain input<br />

parameters and FOMs can be introduced<br />

in the analysis in order to have<br />

a more complete evaluation of the<br />

results uncertainty.<br />

Acknowledgement<br />

The authors are grateful to Ms Cristina<br />

Bertani <strong>for</strong> the review of the manuscript.<br />

Nomenclature<br />

N<br />

n<br />

p<br />

r<br />

x<br />

y<br />

α<br />

β<br />

Subscripts<br />

m<br />

Number of code runs<br />

Number of samples of a certain variable<br />

Number of Figure of Merit<br />

Pearson’s correlation coefficient<br />

Input variable in the computation of response correlations<br />

Output variable in the computation of response correlations<br />

Probability<br />

Confidence level<br />

mean value of the related parameter<br />

References<br />

1. F. Mascari, G. Vella, B.G. Woods, K. Welter, F. D’Auria, “Analysis<br />

of Primary/Containment Coupling Phenomena Characterizing<br />

the MASLWR Design During a SBLOCA Scenario”, <strong>Nuclear</strong><br />

<strong>Power</strong> Plant, Intech (2012)<br />

2. F. Mascari, H. Nakamura, F. De Rosa, F. D’ Auria, “Scaling<br />

Rationale Design and Extrapolation Problem <strong>for</strong> ITF and SETF”,<br />

Book of Abstract of <strong>International</strong> Workshop on <strong>Nuclear</strong> Safety<br />

and Severe Accident (NUSSA-2014), Kashiwa, Chiba, Japan,<br />

September 3-5 (2014)<br />

3. F. Mascari, H. Nakamura, K. Umminger, F. De Rosa, F. D’Auria,<br />

“Scaling Issues For The Experimental Characterization Of<br />

Reactor Coolant System In Integral Test Facilities And Role Of<br />

System Code As Extrapolation Tool”, Proceedings Of<br />

<strong>International</strong> Topical Meeting on <strong>Nuclear</strong> Reactor Thermal<br />

Hydraulics 2015, NURETH 2015, Volume 6, pp. 4921-4934<br />

(2015)<br />

4. W.L. Oberkampf, T.G. Trucano, “Verification and validation<br />

benchmarks”, <strong>Nuclear</strong> Engineering and Design 238,<br />

pp. 716-743 (2008)<br />

5. NEA/CSNI “A state-of-the-art report on scaling in system<br />

thermal hydraulics applications to nuclear reactor safety and<br />

design”, NEA/CSNI/R(2016)14 (2017)<br />

6. IAEA <strong>International</strong> Atomic Energy Agency “Best Estimate<br />

Safety Analysis <strong>for</strong> <strong>Nuclear</strong> <strong>Power</strong> Plants: Uncertainty<br />

Evaluation”, Safety Reports Series (2008)<br />

7. B.M. Adams, M.S. Ebeida, M.S. Eldred, G. Geraci, J.D. Jakeman,<br />

K.A. Maupin, J.A. Monschke, J.A. Stephens, L.P. Swiler,<br />

D.M. Vigil, T.M. Wildey, W.J. Bohnhoff, K.R. Dalbey, J.P. Eddy,<br />

J.R. Frye, R.W. Hooper, K.T. Hu, P.D. Hough, M. Khalil,<br />

E.M. Ridgway, A. Rushdi, Dakota, A Multilevel Parallel<br />

Object-Oriented Framework <strong>for</strong> Design Optimization,<br />

Parameter Estimation, Uncertainty Quanti fication, and<br />

Sensitivity Analysis: Version 6.7 User’s Manual,<br />

SAND2014-4633 (2017)<br />

8. Applied Programming Technology, Inc. Symbolic <strong>Nuclear</strong><br />

Analysis Package (SNAP) User’s Manual (2012)<br />

9. Applied Programming Technology, Inc. Uncertainty analyses<br />

User manual, Symbolic <strong>Nuclear</strong> Analyses Package (SNAP),<br />

(2012)<br />

10. U.S. <strong>Nuclear</strong> Regulatory Commission TRACE v5.840 Theory<br />

Manual (2013)<br />

<strong>11</strong>. H. Glaeser, “GRS Method <strong>for</strong> Uncertainty and Sensitivity<br />

Evaluation of Code Results and Applications”, Science and<br />

Technology of <strong>Nuclear</strong> Installations (2008)<br />

12. S.S. Wilks, “Determination of sample sizes <strong>for</strong> setting tolerance<br />

limits”, The Annals of Mathematical Statistics 12(1), pp. 91-96<br />

(1941)<br />

13. S.S. Wilks, “Statistical prediction with special reference to the<br />

problem of tolerance limits”, The Annals of Mathematical<br />

Statistics 13(4), pp. 400-409 (1942)<br />

14. M.E. Stephens, B.W. Goodwin, T.H. Andres, “Deriving<br />

parameter probability density functions”, Reliability<br />

Engineering & System Safety 42, pp. 271-291 (1993)<br />

15. https://dakota.sandia.gov/<br />

16. J.R. Wang, C.W. Tsai, H.T. Lin, C. Shih, “Per<strong>for</strong>ming Uncertainty<br />

Analysis of IIST facility SBLOCA by TRACE and DAKOTA”,<br />

NUREG/IA-0428 (2013)<br />

17. J.R. Wang, J.H. Yang, H.T. Lin, C. Shih, “Uncertainty Analysis <strong>for</strong><br />

Maanshan LBLOCA by TRACE and DAKOTA”, NUREG/IA-0448<br />

(2014)<br />

18. M. Perez, F. Reventos, L. Batet, A. Guba, I. Tóth, T. Mieusset,<br />

P. Bazin, A. de Crécy, S.Borisov, T. Skorek, H. Glaeser, J. Joucla,<br />

P. Probst, A. Ui, B.D. Chung, D.Y. Oh, R. Pernica, M. Kyncl,<br />

J. Macek, A. Manera, J. Freixa, A. Petruzzi, F. D’Auria,<br />

A. Del Nevo, “Uncertainty and sensitivity analysis of a LBLOCA<br />

in a PWR <strong>Nuclear</strong> <strong>Power</strong> Plant: Results of the Phase V of the<br />

BEMUSE programme”, <strong>Nuclear</strong> Engineering and Design 241,<br />

pp. 4206-4222 (20<strong>11</strong>)<br />

19. J.C. Helton, F.J. Davis “Latin hypercube sampling and the<br />

propagation of uncertainty in analyses of complex systems”,<br />

Reliability Engineering & System Safety 81, pp. 23-69 (2003)<br />

20. K.A. Gamble, L.P. Swiler “Uncertainty Quantification and<br />

Sensitivity Analysis Applications to Fuel Per<strong>for</strong>mance<br />

Modeling”, SAND2016-4597C<br />

21. F. Mascari, F. De Rosa, B.G. Woods, K. Welter, G. Vella,<br />

F. D’Auria, “Analysis of the OSU-MASLWR 001 and 002 Tests by<br />

Using the TRACE Code”, NUREG/IA-0466 (2015)<br />

22. T. Iguchi, T. Okubo, Y. Murao, “Effect of Loop Seal on Reflood<br />

Phenomena in PWR”, <strong>Journal</strong> of <strong>Nuclear</strong> Science and<br />

Technology 25(6), pp. 520-527 (1988)<br />

23. P. Coppolani, N. Hassenboehler, J. Joseph, J.F. Petetrot, J.P. Py,<br />

J.S. Zampa, La chaudière des réacteurs à eau sous pression,<br />

EDP Sciences, Les Ulis, France (2004)<br />

24. F. Mascari, J.C. De La Rosa Blul, M. Sangiorgi, G. Bandini,<br />

“Analyses of an unmitigated station blackout transient with<br />

ASTEC, MAAP and MELCOR code”, 9th Meeting of the<br />

“ European MELCOR User Group” (2017)<br />

25. F. D’Auria, M. Frogheri, W. Giannotti “RELAP/MOD3.2 Post Test<br />

Analysis and Accuracy Quantification of SPES Test SP-SB-04”,<br />

NUREG/IA-0155 (1999)<br />

26. O.C. Jones, <strong>Nuclear</strong> Reactor Safety Heat Transfer, Hemisphere<br />

Publishing Corporation, Washington, USA (1981)<br />

27. J.L. Rodgers, W.A. Nicewander, “Thirteen Ways to Look at the<br />

Correlation Coefficient”, The American Statistician 42(1),<br />

pp. 59-66<br />

Authors<br />

Andrea Bersano<br />

Energy Department (DENERG)<br />

Politecnico di Torino<br />

Corso Duca degli Abruzzi 24<br />

10129, Turin<br />

Italy<br />

Fulvio Mascari<br />

<strong>Nuclear</strong> Safety<br />

Security and Sustainability Division<br />

(FSN-SICNUC), ENEA<br />

Via Martiri di Monte Sole 4<br />

40129, Bologna<br />

Italy<br />

Research and Innovation<br />

Evaluation of a Double-Ended Guillotine LBLOCA Transient in a Generic Three-Loops PWR-900 with TRACE Code Coupled with DAKOTA Uncertainty Analysis ı Andrea Bersano and Fulvio Mascari


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

Experiment Research on the Insurge<br />

Transient Behavior of Gas-steam<br />

Pressurizer under Various Pressure<br />

Wang Bolong, Li Weihua, Jia Haijun, Li Jun and Zhang Yajun<br />

For small and medium sized reactors with gas-steam pressurizer, the transient behavior of gas-steam pressurizer plays<br />

a vital role on the safety of the nuclear reactor operation. This paper focuses on the transient behavior of gas-steam<br />

pressurizer. The pressure response was investigated under various insurge experimental conditions, and the influence<br />

factors of pressure changes were analyzed.<br />

Research shows initial pressure of the pressurizer and the presence of a non-condensable gas with varying mass<br />

fraction will all have some kind of effect on the transient behavior of gas-steam pressurizer. Initial pressure decides initial<br />

magnitude of liquid temperature of the pressurizer, and the presence of a non-condensable gas with varying mass<br />

fraction can greatly affect the heat and mass transfer process both wall and interface, and further affect the system<br />

pressure variations. This paper focus on the effects on pressurizer insurge transients under various initial pressure of the<br />

pressurizer and the presence of a non-condensable gas with varying mass fraction.<br />

Introduction<br />

A transient can be caused from a<br />

simple loss of secondary steam flow to<br />

more complicated accidents. After<br />

the Three Mile Island accident [1],<br />

Chernobyl accident [2] and Fukushima<br />

nuclear accident [3]. Many people<br />

realized the importance of small break<br />

LOCA’s and the necessity <strong>for</strong> having<br />

reliable physical models <strong>for</strong> all of the<br />

components in the loop.<br />

In view of increasing pressure on<br />

energy restructuring and the serious<br />

environmental pollution concerns,<br />

the integrated natural circulation<br />

reactor is receiving a great attention<br />

<strong>for</strong> its ability to provide energy that is<br />

clean, safe and economic. And the integrated<br />

reactor is going to be one of<br />

the best option <strong>for</strong> small and medium<br />

sized reactors (SMRs) in lots of countries<br />

with the high level of great safety<br />

and reliability. SMRs have been developed<br />

in many countries <strong>for</strong> small-scale<br />

power generation, district heating,<br />

and seawater desalination. Argentine<br />

CAREM reactor, Russian VVER-300/<br />

VK-300 reactor, Korean REX-10/<br />

SMART reactor, Japanese IMR reactor,<br />

American NuScale reactor, Chinese<br />

NHR reactor and so on, these are the<br />

typical representatives of the SMRs<br />

[4]. In order to simplify the structure<br />

and design and enhance safety, the<br />

steam-gas pressurizer is generally<br />

utilized in the integrated reactor. The<br />

non-condensable gas is used to keep<br />

the pressure stable in the steam-gas<br />

pressurizer and the transient behavior<br />

of gas-steam pressurizer plays a vital<br />

role on the safety of the nuclear reactor<br />

operation. As so far, early pressurizer<br />

transient models were generally<br />

developed under certain conditions,<br />

slow insurge velocity or low pressure<br />

<strong>for</strong> example. And these models may<br />

not be applicable to various velocity or<br />

create a greater risk of inaccurate<br />

results under the high pressure.<br />

Westinghouse [5] developed the<br />

TOPS pressurizer model included<br />

the effects of wall condensation by applying<br />

Nusselt Laminar film theory<br />

to estimate a wall heat transfer<br />

coefficient. Saedi [6] investigated the<br />

relative magnitudes of the physical associated<br />

with insurge transients, and<br />

initiated a data base (at low pressure)<br />

<strong>for</strong> a model, developed<br />

by Kim [7], at MIT. In some other<br />

pressurizer analysis, Mark [8] came<br />

up with the effects of the presence of a<br />

non-condensable gas on insurge<br />

transient. Leonard [9] per<strong>for</strong>med the<br />

experiment on the pressure behavior<br />

of steam-gas pressurizer during the<br />

insurge and he focused on the various<br />

non-condensable gas, various gas<br />

content and stratification in his study.<br />

Kim [10] found the condensation heat<br />

transfer at wall is an important physical<br />

phenomenon during the insurge<br />

transient. Paulsen [<strong>11</strong>] improved and<br />

developed the theoretical modeling<br />

<strong>for</strong> RELAP5. Wu lei [12, 13] and Ma<br />

Xizhen [14, 15] established the nonequilibrium<br />

gas-steam pressurizer<br />

model and improved the steam condensation<br />

heat transfer model in<br />

presence of non-condensable gas.<br />

In order to understand and model<br />

an accident, one should recognize the<br />

processes that take place during a<br />

transient. In general, these processes<br />

include insurges, outsurges, and combined<br />

insurges and outsurges. Early<br />

pressurizer transient models were<br />

generally developed under certain<br />

conditions, slow insurge flow rate or<br />

low pressure <strong>for</strong> example, and these<br />

models may not be applicable under<br />

various pressure. At present, the<br />

transient behavior of steam-gas pressurizer<br />

under various pressure need to<br />

be further studied in the integrated<br />

natural circulation reactor with<br />

steam-gas pressurizer. Through the<br />

design and establish of the experiment<br />

system, the combination of<br />

theoretical and experimental which<br />

can provide the data support <strong>for</strong> the<br />

design and operation of the integrated<br />

natural circulation reactor.<br />

1 Description of<br />

Experimental System<br />

To find out the experimental physical<br />

processes occurs in a pressurizer, an<br />

experimental apparatus has been<br />

built (Figure 1).<br />

The primary tank (2420 mm high<br />

and 450 mm ID) which models the<br />

pressurizer volume equipped with a<br />

magnetic level gauge to accurately<br />

measure the initial liquid level and<br />

the change of liquid level during the<br />

insurge. The storage tank (2490 mm<br />

high and 400 mm ID) is filled with<br />

cold water to a level also measured<br />

with a magnetic level gauge and<br />

pressurized with nitrogen. This tank<br />

| Fig. 1.<br />

Schematic diagram of apparatus.<br />

Nomenclature<br />

p t system pressure<br />

T w temperature at each<br />

measured point of gasphase<br />

space<br />

p N2<br />

nitrogen partial pressure<br />

p s steam partial pressure<br />

n N2<br />

nitrogen amount of<br />

substance<br />

n s steam amount of substanc<br />

V g gas-phase space volume<br />

Z N2<br />

nitrogen compressibility<br />

factor<br />

Z s<br />

steam compressibility<br />

factor<br />

x N2<br />

nitrogen mole fraction<br />

T g average temperature in<br />

gas-phase space<br />

RESEARCH AND INNOVATION 533<br />

Research and Innovation<br />

Experiment Research on the Insurge Transient Behavior of Gas-steam Pressurizer under Various Pressure ı Wang Bolong, Li Weihua, Jia Haijun, Li Jun and Zhang Yajun


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

RESEARCH AND INNOVATION 534<br />

| Fig. 2.<br />

Heating rod installation method and voltage regulator.<br />

| Fig. 3.<br />

Data acquisition system and computer data network.<br />

serves as a reservoir <strong>for</strong> “cold” injection<br />

water.<br />

Two tanks are both equipped with<br />

nine heating rods totaling 36 kW and<br />

the electric heating system utilizes the<br />

TSGC2J-40 type voltage regulator to<br />

adjust the load voltage of the heating<br />

rod, and then control the heating rod<br />

power to meet the requirements<br />

of each experimental condition<br />

(Figure 2).<br />

Besides, the experimental system<br />

also consists of electric heating system<br />

and data measurement and acquisition<br />

system (Figure 3).<br />

2 Experimental conditions<br />

and parameter control<br />

Several precautionary procedures were<br />

listed as followed prior to initiating<br />

each of the transient experiments. The<br />

primary and storage tanks were filled<br />

to the required levels with deionized<br />

water. Steam was bubbled through the<br />

primary tank to assist the heating rods<br />

in bringing the tank up to saturation<br />

conditions. The relief valve was opened<br />

and the water allowed to boil <strong>for</strong> a<br />

while when the primary tank reached<br />

saturation. This process was intended<br />

to rid the system of dissolved gases in<br />

the water. For the experiments with an<br />

initial non-condensable gas fraction in<br />

the vapor, the gas was injected into the<br />

vapor space after the tank had been<br />

purged of dissolved gases, and be<strong>for</strong>e<br />

the system had reached the desired<br />

operating pressure.<br />

The partial pressure of the steam<br />

and the temperature of gas-phase<br />

space, which are directly determined<br />

by nitrogen mole fraction in the<br />

pressurizer. There<strong>for</strong>e, the experiment<br />

should put strict controls on its<br />

initial value. Based on the real gas<br />

equations, the nitrogen mole fraction<br />

can be obtained by measuring the<br />

temperature of gas-phase space and<br />

system pressure. It should be noted<br />

that the calculation leaves out of<br />

account stratification of hot gas and<br />

steam superheating phenomenon.<br />

The concrete calculating methods are<br />

as follows: measurement parameters:<br />

system pressure p t ,the temperature at<br />

each measured point of gas-phase<br />

space in the pressurizer T w1 , T w2 … T wn .<br />

Based on the real gas equations,<br />

the nitrogen mole fraction can be<br />

obtained by measuring the temperature<br />

of gas-phase space and system<br />

pressure. It should be noted that the<br />

calculation leaves out of account<br />

stratification of hot gas and steam<br />

superheating phenomenon. The<br />

concrete calculating methods are as<br />

follows:<br />

Measurement parameters: system<br />

pressure, the temperature at each<br />

measured point of gas-phase space in<br />

the pressurizer T w1 , T w2 … T wn .<br />

Middle parameters: nitrogen<br />

partial pressure p N2<br />

, steam partial<br />

pressure p s , nitrogen amount of<br />

substance n N2<br />

, steam amount of substance<br />

n s , gas-phase space volume V g ,<br />

nitrogen compressibility factor Z N2<br />

,<br />

steam compressibility factor Z s .<br />

The average temperature T g in gasphase<br />

space can be obtained by<br />

measuring the temperature at each<br />

measured point of gas-phase space<br />

in the pressurizer.<br />

The real gas equations of steam and<br />

nitrogen are as follows where R indicates<br />

gas constant:<br />

Then, it can come to the nitrogen mole<br />

fraction X n2<br />

.<br />

=<br />

| Fig. 4.<br />

Computing framework.<br />

The computing framework is demonstrated<br />

by Figure 4.<br />

Research and Innovation<br />

Experiment Research on the Insurge Transient Behavior of Gas-steam Pressurizer under Various Pressure ı Wang Bolong, Li Weihua, Jia Haijun, Li Jun and Zhang Yajun


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

Parameter Value Unit<br />

Non-condensable gas species Nitrogen /<br />

Non-condensable gas mass fraction 0, 10%, 20% /<br />

Regulator space initial pressure 0.5, 1.0, 1.5 MPa<br />

Initial height of liquid level 800 mm<br />

Final height of liquid level 1200 mm<br />

Insurge time 20 s<br />

| Tab. 1.<br />

Specific experimental conditions.<br />

The data acquisition system was<br />

initiated prior to beginning the<br />

insurge to allow some steady data to<br />

be taken, the specific experimental<br />

conditions are shown in Table 1.<br />

3 Experimental results and<br />

analysis<br />

There are two main reasons affected<br />

the pressure in a transient experiment,<br />

the first part is the increase of<br />

liquid level plays a role that compresses<br />

gas-phase space and the<br />

pressure is going up, the second part is<br />

a higher initial pressure leading to a<br />

higher initial liquid temperature of<br />

the pressurizer and affect the heat and<br />

mass transfer process both wall and<br />

interface, and further affect the system<br />

pressure variations. The pressure<br />

variation is a combination of the two<br />

aspects.<br />

The pressure and temperature<br />

histories <strong>for</strong> the experiments with<br />

20 % mass fraction nitrogen are<br />

shown in Figure 5 and Figure 6. To<br />

make conclusions of trials more<br />

comparable, this analysis applies<br />

dimensionless method to the system<br />

pressure, and pressure variation<br />

was represented by the ratio of<br />

system pressure to initial pressure.<br />

Figure 7 shows the dynamic change<br />

process of dimensionless pressure<br />

corresponding to different initial<br />

pressures.<br />

The system pressure growth rate<br />

and the initial pressure of the pressurizer<br />

have positive correlation. The<br />

higher the initial pressure, the faster<br />

the system pressure growth rate in the<br />

transient.<br />

The presence of a non-condensable<br />

gas with varying mass fraction will all<br />

have some kind of effect on the<br />

transient behavior of gas-steam<br />

pressurizer. At the same system pressure,<br />

the main effects of the presence<br />

of a non-condensable gas are given as<br />

follows:<br />

I<br />

Affect the nitrogen partial pressure,<br />

the steam partial pressure<br />

and the vapor temperature of the<br />

pressurizer.<br />

II Affect the compressibility of the<br />

vapor space in the pressurizer.<br />

III Affect the heat and mass transfer<br />

process of the vapor space in the<br />

pressurizer.<br />

The pressure histories <strong>for</strong> the experiments<br />

with various mass fraction<br />

nitrogen are shown in Figure 8,<br />

Figure 9 and Figure 10. The initial<br />

primary tank non-condensable gas<br />

mass fraction <strong>for</strong> the transient is<br />

labeled in the figure. The most obvious<br />

difference in the results is the large<br />

variation in peak pressure, the higher<br />

initial non-condensable gas mass<br />

fraction in the primary tank, the<br />

higher the peak pressure in the<br />

transient. And the specific values are<br />

shown in Table 2.<br />

RESEARCH AND INNOVATION 535<br />

| Fig. 5.<br />

The system pressure histories with 20 % mass fraction nitrogen.<br />

| Fig. 6.<br />

The temperature histories with 20 % mass fraction nitrogen.<br />

| Fig. 7.<br />

The dimensionless pressure histories with 20 % mass fraction nitrogen.<br />

| Fig. 8.<br />

The pressure histories with various mass fraction nitrogen under 0.5MPa pressure.<br />

Research and Innovation<br />

Experiment Research on the Insurge Transient Behavior of Gas-steam Pressurizer under Various Pressure ı Wang Bolong, Li Weihua, Jia Haijun, Li Jun and Zhang Yajun


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

RESEARCH AND INNOVATION 536<br />

Initial<br />

system pressure<br />

| Tab. 2.<br />

Specific experimental values.<br />

| Fig. 9.<br />

The pressure histories with various mass fraction nitrogen under 1.0 MPa<br />

pressure.<br />

Non-condensable gas<br />

mass fraction<br />

Peak<br />

pressure<br />

0.5 0 0.55<br />

0.5 10 % 0.59<br />

0.5 20 % 0.61<br />

1.0 0 1.08<br />

1.0 10 % 1.21<br />

1.0 20 % 1.25<br />

1.5 0 1.69<br />

1.5 10 % 1.87<br />

1.5 20 % 1.92<br />

In particular, the research demonstrated<br />

that when the pressurizer is<br />

free from non-condensable gas,<br />

may present the twice peak pressure<br />

phenomenon during the transient,<br />

and the first peak pressure will present<br />

about the same time. While only<br />

one peak pressure will present during<br />

the transient containing the noncondensable<br />

gas.<br />

There are two main reasons<br />

affected the pressure in a transient<br />

experiment, the first part is the increase<br />

of liquid level plays a role that<br />

compresses gas-phase space and the<br />

pressure is going up, the second part is<br />

steam condensation leading to a decrease<br />

pressure at some degrees. The<br />

peak pressure is combination of the<br />

two aspects. In the early stage of the<br />

transient, the compression of the<br />

vapor space plays leading roles and<br />

the pressure is going up. At this stage,<br />

there was no distinct effect on the temperature<br />

of the interface by incoming<br />

the cold water during the transient. In<br />

the second stage, steam condensation<br />

leads to a decrease pressure at some<br />

degrees due to the temperature reduction<br />

of the interface. And in next stage,<br />

the compression of the vapor space<br />

also plays leading roles comparing<br />

with the steam condensation and the<br />

pressure is going up.<br />

Conclusion<br />

Based on the proceeding analysis and<br />

experiments, an experimental study<br />

of the pressure response during an<br />

insurge transient under various pressure<br />

has been per<strong>for</strong>med. The following<br />

conclusions are drawn based upon<br />

the experimental and analytical<br />

results:<br />

I<br />

The system pressure growth rate<br />

and the initial pressure of the pressurizer<br />

have positive correlation.<br />

The higher the initial pressure, the<br />

faster the system pressure growth<br />

rate in the transient.<br />

II The changes in system temperature<br />

coincided well with those of<br />

system pressure.<br />

III The higher initial non-condensable<br />

gas mass fraction in the primary<br />

tank, the higher the peak pressure<br />

in the transient.<br />

IV In particular, when the pressurizer<br />

is free from non-condensable gas,<br />

may present the twice peak pressure<br />

phenomenon during the transient,<br />

and the first peak pressure<br />

will present about the same time.<br />

While only one peak pressure will<br />

present during the transient containing<br />

the non-condensable gas.<br />

Acknowledgments<br />

Special thanks should go to Mr Ma<br />

Xizhen who have put considerable<br />

time and ef<strong>for</strong>t into the designing and<br />

constructing work of the experiment<br />

plant.<br />

References<br />

[1]. Bot P L. Human reliability data, human error and accident<br />

models—illustration through the Three Mile Island accident<br />

analysis[J]. Reliability Engineering & System Safety, 2004,<br />

83(2):153-167.<br />

[2]. Jr H T P. Summary report on the post-accident review meeting<br />

on the chernobyl accident : <strong>International</strong> <strong>Nuclear</strong> Safety Advisory<br />

Group. <strong>International</strong> Atomic Energy Agency (IAEA) Safety Series<br />

No. 75-INSAG-1 (STI/PUB/ 740), Vienna, IAEA, 1986. 260 Austrian<br />

Schillings[J]. <strong>Journal</strong> of Environmental Radioactivity, 1987,<br />

5(5):403-404.<br />

| Fig. 10.<br />

The pressure histories with various mass fraction nitrogen under 1.5 MPa<br />

pressure.<br />

[3]. Kinoshita N, Sueki K, Sasa K, et al. Assessment of individual<br />

radionuclide distributions from the Fukushima nuclear accident<br />

covering central-east Japan[J]. Proceedings of the National<br />

Academy of Sciences of the United States of America, 20<strong>11</strong>,<br />

108(49):19526-19529.<br />

[4]. <strong>International</strong> Atomic Energy Agency: Advances in small modular<br />

reactor technology developments. Vienna: the IAEA in Austria,2014.<br />

[5]. Redfield, J. A., Prescop, V., & Margolis, S. G. (1968). Pressurizer<br />

per<strong>for</strong>mance during loss-of-load tests at shippingport: analysis<br />

and test. , 4(3), 173-181.<br />

[6]. Saedi, H. R. (1982). Insurge pressure response and heat<br />

transfer <strong>for</strong> PWR pressurizer. Massachusetts Institute of Technology.<br />

[7]. Kim, S. N. (1984). An experimental and analytical model of a<br />

pwr pressurizer during transients. British <strong>Journal</strong> of Surgery,<br />

87(12), 1615–1616.<br />

[8]. Leonard, M. T., & Griffith, P. (1983). The effects of a<br />

noncondensable gas on pressurizer insurge transients. Trans.<br />

Am. Nucl. Soc.; (United States), 46(6), 844-845. NOMURA Katsuya,<br />

K.S.O.Y., Numerical analysis of droplet breakup behavior using<br />

particle method. 1999. 38(12): p. 1057-1064.<br />

[9]. Leonard M T, Griffith P. The effects of a non-condensable gas<br />

on pressurizer insurge transients[J]. Trans. Am. Nucl. Soc.; (United<br />

States), 1984, 46(6):844-845.<br />

[10]. Kim, S.N., Griffith, P., 1987. PWR pressurizer modeling. Nucl.<br />

Eng. Des.102, 199–209.<br />

[<strong>11</strong>]. Paulsen, M.P., et al., 1996. RETRAN-3D—a program <strong>for</strong> transient<br />

thermal–hydraulic analysis of complex fluid flow systems.<br />

Electric <strong>Power</strong> Research Institute, NP-7450.<br />

[12]. WU Lei JIA Hai-jun LIU Yang MA Xi-zhen. Transient Characteristics<br />

of Integrated Non-condensable Gas-steam Pressurizer [J],<br />

Atomic Energy Science and Technology, 2014, 48(s1):200-207.<br />

[13]. WU Lei LIU Yang JIA Hai-jun YANG Xing-tuan. Research on<br />

Steam Condensation Heat Transfer Model in Presence of Noncondensable<br />

Gas at High Pressure [J]. Atomic Energy Science and<br />

Technology, 2016, 50(2):261-266.<br />

[14]. MA Xi-zhen JIA Hai-jun LIU Yang WU Lei. Numerical<br />

Simulation Study on Steam Condensation in Presence of Noncondensable<br />

Gas [J]. Atomic Energy Science and Technology,<br />

2015, 49(s1):265-269.<br />

[15]. MA Xi-zhen JIA Hai-jun LIU Yang WU Lei. Effect of Noncondensable<br />

Gas on Steam-gas Pressurizer [J]. Atomic Energy<br />

Science and Technology, 2016, 50(9):1586-1591.<br />

Authors<br />

Wang Bolong<br />

Li Weihua<br />

Jia Haijun<br />

Li Jun<br />

Zhang Yajun<br />

Institute of <strong>Nuclear</strong> and New Energy<br />

Technology<br />

Tsinghua University<br />

Beijing 100084, China<br />

Collaborative Innovation Center of<br />

Advanced <strong>Nuclear</strong> Energy Technology<br />

Tsinghua University<br />

Beijing 100084, China<br />

Key Laboratory of Advanced Reactor<br />

Engineering and Safety of Ministry of<br />

Education<br />

Tsinghua University<br />

Beijing 100084, China<br />

Research and Innovation<br />

Experiment Research on the Insurge Transient Behavior of Gas-steam Pressurizer under Various Pressure ı Wang Bolong, Li Weihua, Jia Haijun, Li Jun and Zhang Yajun


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

Stilllegung und Rückbau des<br />

Rossendorfer Forschungsreaktors RFR<br />

Teil 1: Objektbeschreibung, Genehmigungsverfahren, Ausgangssituation,<br />

Planungskonzept und Meilensteine<br />

Reinhard Knappik, Klaus Geyer, Sven Jansen und Cornelia Graetz<br />

Mit der Entlassung des Rossendorfer Forschungsreaktors im September 2019 aus dem Geltungsbereich des Atomgesetzes<br />

(AtG) sind die Stilllegung und der Rückbau der alten kerntechnischen Anlagen des ehemaligen Zentralinstituts für Kern<strong>for</strong>schung<br />

(ZfK) der Akademie der Wissenschaften der DDR bis auf ein ca. 50 m langes Reststück einer Rohrleitung der<br />

Speziellen Kanalisation abgeschlossen.<br />

In der zweiteiligen Veröffentlichung werden die Arbeiten zur Stilllegung und zum Rückbau des Rossendorfer<br />

Forschungsreaktors (RFR) übersichtsartig vorgestellt, wobei im Teil 1 (<strong>atw</strong> <strong>11</strong>-12 2019) anknüpfend an die Objektbeschreibung<br />

die Genehmigungsverfahren, die Ausgangssituation radiologisch und konventionell, das realisierte Planungskonzept<br />

sowie die Meilensteine vor gestellt werden. Im Teil 2 (<strong>atw</strong> 1/2020) wird auf ausgewählte Aspekte der Stilllegung- und<br />

Rückbaudurchführung, zum Strahlenschutz, zur Freigabe sowie zum Reststoff- und Abfallmanagement eingegangen.<br />

1 Einleitung Die Geschichte des Rossendorfer Forschungsreaktors und damit des Forschungsstandortes<br />

Rossendorf bei Dresden (jetzt Dresden-Rossendorf) begann mit dem „Abkommen über die Hilfeleistung der Union der<br />

Sozialistischen Sowjetrepubliken an die Deutsche Demokratische Republik bei der Entwicklung der Forschung auf dem<br />

Gebiet der Physik des Atomkerns und der Nutzung der Kernenergie für die Bedürfnisse der Volkswirtschaft“, das am<br />

28. April 1955 abgeschlossen wurde. Auf dieser Grundlage erfolgte die Lieferung zweier Großgeräte, ein 2 MW<br />

Forschungsreaktor vom Typ WWR-S (Abb. 1) und ein 25 MeV-Zyklotron, an das am 1. Januar 1956 gegründete<br />

Zentral institut für Kernphysik (später Zentralinstitut für Kern<strong>for</strong>schung).<br />

Am 14. Dezember 1957 wurde der<br />

erste Forschungsreaktor der DDR<br />

nach einer Bauzeit von nur 21<br />

Monaten erstmals kritisch und am<br />

16. Dezember 1957 offiziell im Rahmen<br />

eines Staatsaktes in Betrieb<br />

genommen. Der RFR war ein leichtwassermoderierter<br />

und -gekühlter<br />

Tankreaktor. Über einen Zwischenschritt<br />

(von 2 MW auf 4 MW und<br />

5 MW im Jahre 1965) erfolgte zuletzt<br />

eine Leistungs erhöhung auf 10 MW<br />

(1967), die ab 1981 im Dauerbetrieb<br />

realisiert wurde. Die Leistungserhöhung<br />

auf 10 MW konnte nur durch<br />

Einsatz neuer Brennstäbe mit einer<br />

Anreicherung von 36 % U-235 gegenüber<br />

vorher von 10 % U-235 erreicht<br />

werden. Die Energieabgabe des RFR<br />

betrug insgesamt rund 28.000 MWd<br />

bei einem Leistungseinsatz von rund<br />

105.000 Stunden. Es gab während der<br />

Betriebszeit des RFR kein Ereignis,<br />

welches strahlenschutzrelevant war.<br />

Interessante Details über die RFR-<br />

Betriebszeit enthält das Buch „Beiträge<br />

zur Geschichte des Rossendorfer<br />

Forschungsreaktors RFR“ [1].<br />

Im Zuge der weiteren Entwicklung<br />

des Forschungsstandortes entstanden<br />

eine Vielzahl von weiteren Anlagen<br />

und Einrichtungen in denen eine kerntechnische<br />

Nutzung bis 1991 erfolgte,<br />

wobei hier der RFR nur bis zum<br />

27. Juni 1991 betrieben wurde. Mit<br />

der Neuordnung des Forschungsstandortes<br />

nach der Wiedervereinigung und<br />

der Auflösung der Akademie der<br />

Wissenschaften zum 31. Dezember<br />

1991 wurden dann auf der Grundlage<br />

mehrerer in den Jahren 1993 und<br />

1996 vollzogener Kabinettsbeschlüsse<br />

mit der Stilllegung und dem Rückbau<br />

der kerntechnischen Anlagen am<br />

Forschungsstandort begonnen. Der<br />

Freistaat Sachsen beauftragte den<br />

Verein für Kern verfahrenstechnik und<br />

Analytik Rossendorf e. V. (VKTA, Umbenennung<br />

in „VKTA – Strahlenschutz,<br />

Analytik & Entsorgung Rossendorf<br />

e. V.” im Dezember 2014) mit der vollständigen<br />

Beseitigung der nuklearen<br />

Altlasten des Forschungsstandortes<br />

Rossendorf. Im Folgenden werden die<br />

wichtigsten Rückbauobjekte mit<br />

Termin der Ent lassung (in Klammern)<br />

aus dem Geltungsbereich des Atomgesetzes<br />

aufgeführt:<br />

p die Rossendorfer Anordnung für<br />

kritische Experimente (RAKE,<br />

1998)<br />

p das Urantechnikum (2000)<br />

p der Rossendorfer Ringzonenreaktor<br />

(RRR, 2000)<br />

p die Spezielle Kanalisation am<br />

Forschungsstandort (AtG-Teilentlassungen<br />

2010, 2013 und 2018)<br />

p die Objekte und Anlagen der Isotopenproduktion<br />

(von 2009 bis<br />

2014, [2])<br />

p die Anlagen und das Gelände der<br />

Entsorgungs wirtschaft des ehemaligen<br />

ZfK (2005, 20<strong>11</strong> und 2018)<br />

p der RFR (2009, 2010, 2019)<br />

| Abb. 1.<br />

Ansicht des Forschungsreaktors während der Fertigstellungsphase.<br />

Die Kosten für Stilllegung, Rückbau<br />

und Entsorgung werden vollständig<br />

vom Freistaat Sachsen getragen,<br />

sodass die Mittelbereitstellung auch<br />

Einfluss auf die terminlichen Arbeitsabläufe<br />

hatte. So mussten in den<br />

Jahren 2005 und 2006 die Rückbauarbeiten<br />

aufgrund der zu knapp bemessenen<br />

Finanzmittel durch den<br />

Freistaat Sachsen eingestellt werden,<br />

was zu entsprechend längeren Rückbauzeiten<br />

führte, da z. B. Mitarbeiter<br />

nicht mehr zur Verfügung standen.<br />

2 Objektbeschreibung<br />

Zu den RFR-Anlagen (Abb. 2) gehörten<br />

der „Rückbau komplex RFR“<br />

mit einer Fläche von ca. 9.000 m 2 und<br />

den Objekten:<br />

p Labortrakt (1) mit Reaktorwarte<br />

(2)<br />

537<br />

DECOMMISSIONING AND WASTE MANAGEMENT<br />

Decommissioning and Waste Management<br />

Decommissioning & Dismantling of the Rossendorf Research Reactor RFR ı Reinhard Knappik, Klaus Geyer, Sven Jansen and Cornelia Graetz


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

DECOMMISSIONING AND WASTE MANAGEMENT 538<br />

| Abb. 2.<br />

Territoriale Lage der RFR-Anlagen.<br />

p Reaktorhalle mit Vorhalle und<br />

Anbau (3)<br />

p Pavillon und einen weiteren<br />

Anbau (4)<br />

p Ventilations- und Filtergebäude<br />

mit Fortluftschornstein (5)<br />

p Schauer (6)<br />

sowie die außerhalb des Komplexes<br />

liegenden Objekte:<br />

p Trafostation (7)<br />

p Notstromgebäude (8)<br />

p altes Armaturenhaus (9)<br />

p Armaturenhaus (10)<br />

p Trockenkühlturm 1 und 2 (<strong>11</strong>)<br />

p Rohrleitungen des 2. Kühlkreislaufes<br />

(12)<br />

Weiterhin gab es außerhalb noch die<br />

Sammelbehälter anlage mit der Pumpbedienstation,<br />

in der die radioaktiven<br />

Abwässer des RFR aufgefangen<br />

wurden. Diese Anlagen befanden sich<br />

im Kontrollbereich der Entsorgungswirtschaft<br />

und wurden im Rahmen<br />

dieses Rückbaukomplexes aus der<br />

atomrechtlichen Aufsicht entlassen.<br />

Die territoriale Lage der nummerierten<br />

RFR-Anlagen ist schematisch in der<br />

Abb. 2 dargestellt. Im Betriebshof befanden<br />

sich befestigte Verkehrsflächen,<br />

Rohre der Regen- und Schmutzwasserkanalisation<br />

sowie Leitungen für<br />

konta minationsverdächtige Abwässer<br />

bis zu einer Tiefe von 5 m, unterirdische<br />

Abluftleitungen, Heizungskanäle,<br />

Schächte sowie Medienleitungen.<br />

Im Folgenden werden wichtige<br />

Objekte kurz charakterisiert:<br />

Labortrakt mit Reaktorwarte<br />

(1 und 2)<br />

Der Labortrakt war ein viergeschossiger<br />

Ziegelbau mit Stahlbetondecken,<br />

dessen Grundfläche ca. 960 m 2<br />

betrug. In diesem Gebäude waren<br />

ursprünglich Laboratorien, die Reaktorwarte<br />

und Büroräume untergebracht.<br />

Im Zuge der Erneuerung<br />

des RFR wurde eine neue Warte in<br />

Stahlbeton- Skelettbauweise mit einer<br />

Fläche von ca. 260 m 2 an der NO-Seite<br />

des Labortraktes angebaut.<br />

Reaktorhalle (3)<br />

Die Reaktorhalle war ein unterkellerter<br />

Ziegel-Stahl- Skelettbau mit<br />

einer Gesamthöhe von 24,5 m und<br />

einer Grundfläche von ca. 700 m 2 .<br />

Darin befanden sich neben dem<br />

Reaktor unter anderem Brennelemente-Lagerbecken<br />

(AB 1 und AB 2)<br />

sowie im Keller geschoss vier Heiße<br />

Kammern.<br />

Pavillon (4)<br />

Der Gebäudebereich „Pavillon“ mit<br />

einer Grundfläche von ca. 170 m 2<br />

bildete einen stark gegliederten einbzw.<br />

zweigeschossigen Anbau, unter<br />

dem Abluftkanäle zum Filter- und<br />

Ventilationsgebäude sowie Rohrleitungen<br />

für kontaminierte Abwässer<br />

verliefen. Im Gebäudebereich waren<br />

ein radiochemisches Labor und eine<br />

Gamma- Bestrahlungsanlage untergebracht.<br />

Ventilations- und Filtergebäude (5)<br />

Das Filter- und Ventilationsgebäude<br />

mit einer Grundfläche von ca. 350 m 2<br />

war ein anderthalbgeschossiger<br />

Ziegel bau mit einem Flachdach, auf<br />

dem sich der ca. 33 m hohe Fortluftschornstein<br />

befand. Im Inneren<br />

waren die Venti lationskammern mit<br />

den dazugehörigen Filteranlagen.<br />

Altes Armaturenhaus (9)<br />

Das Gebäude mit einer Grundfläche<br />

von ca. 22,7 m x 7,2 m und einer Höhe<br />

von ca. 4,5 m hatte über zwei Drittel<br />

der Grundfläche eine ca. 3,5 m tiefe<br />

Grube mit dem Pumpenfundament.<br />

Das Gebäude bestand aus Mauerwerk;<br />

die Fundamente und Teile der<br />

aufgehenden Wände aus Stampfbeton.<br />

Armaturenhaus (10)<br />

Das Armaturenhaus mit einer<br />

Abmessung von ca. 18,4 m x 12,4 m x<br />

6,0 m wurde im Rahmen der Gesamtrekonstruktion<br />

RFR im Jahr 1985 neu<br />

errichtet und beinhaltete Pumpen,<br />

Armaturen und eine Reinigungs anlage<br />

für das Sekundärkühlsystem. Es<br />

handelte sich um eine Stahl betonskelettkonstruktion<br />

aus Fertigteilen,<br />

| Abb. 3.<br />

Schnittdarstellung RFR-Gebäudekomplex.<br />

Decommissioning and Waste Management<br />

Decommissioning & Dismantling of the Rossendorf Research Reactor RFR ı Reinhard Knappik, Klaus Geyer, Sven Jansen and Cornelia Graetz


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

wobei die Außenwände aus Gasbetonfertigteilen<br />

bestanden.<br />

Trockenkühltürme (<strong>11</strong>)<br />

Die Trockentürme hatten eine Abmessung<br />

von ca. 23,3 m x 13,2 m x 8,0 m.<br />

Sie bestanden aus einem Traggerüst<br />

aus Stahl, das mit Leichtmetallelementen<br />

verkleidet war.<br />

Die umbaute Fläche des RFR ohne<br />

Filter- und Venti lationsgebäude betrug<br />

ca. 2.100 m 2 , wobei der Kontrollbereich<br />

die Reaktorhalle mit Kellergeschoss,<br />

Teile des Kellergeschosses des<br />

Anbaus der Reaktorhalle und Teile des<br />

Kellergeschosses des Labortraktes<br />

umfasste. Die Schnittdarstellung in<br />

der Abb. 3 vermittelt einen Eindruck<br />

von der baulichen Anordnung.<br />

Neben dem Reaktor (Detaildarstellung<br />

nach Re konstruktion in Abb. 4)<br />

waren die vier Heißen Zellen, das<br />

Lagerbecken AB 2 und der Pumpenraum<br />

(vgl. Abb. 5) hinsichtlich des<br />

Rückbaus schwierige Teilobjekte.<br />

Aus der Betriebshistorie waren für<br />

die ersten Schritte des Rückbaus und<br />

der Entsorgung vor allem zu berücksichtigen:<br />

p betriebliche und strahlenschutzrelevante<br />

Ereignisse<br />

p der Einsatz von Brennelementen<br />

mit einem hohen Anreicherungsgrad<br />

p die nahezu vollständige Erneuerung<br />

des RFR in den Jahren 1986<br />

bis 1989 mit der Wiederinbetriebnahme<br />

am 27. Januar 1990 sowie<br />

die endgültige Einstellung des<br />

nuklearen Betriebes des RFR am<br />

27. Juni 1991 bedingt durch eine<br />

befristete Genehmigung zum<br />

Versuchsbetrieb.<br />

3 Genehmigungsverfahren<br />

Im Jahre 1991 wurden Aufsichtliche<br />

Anordnungen gemäß § 19 Absatz<br />

3 AtG durch das Sächsische<br />

Staatsministerium für Umwelt und<br />

Landesentwicklung (SMU) erlassen,<br />

um bedingt durch die Auflösung der<br />

Institute der Akademie der Wissenschaften<br />

der DDR zum 31. Dezember<br />

1991 letztendlich einen ungeregelten<br />

Zustand für den RFR zu vermeiden<br />

sowie am 19. Dezember 1991 den<br />

Betreiberwechsel zum VKTA vorzunehmen.<br />

1993 fasste die Sächsische<br />

Staatsregierung den Kabinettsbeschluss,<br />

den Forschungsreaktor endgültig<br />

stillzulegen und zurück zubauen.<br />

Um das Genehmigungsverfahren<br />

nach § 7 Absatz 3 AtG einzuleiten,<br />

stellte der VKTA bereits im Dezember<br />

1994 beim Sächsischen Staatsministerium<br />

für Umwelt und Landesentwicklung<br />

einen Antrag auf Genehmigung<br />

zur Stilllegung und zum Abbau<br />

| Abb. 4.<br />

Schnittdarstellung RFR.<br />

des RFR. Von 1993 bis 1998 wurden<br />

technische, sicherheitstech nische und<br />

strahlenschutztechnische Maßnahmen<br />

zur Anpassung an den bundesdeutschen<br />

Standard durch geführt.<br />

Hervorzuheben ist die Erstellung<br />

eines brandschutztechnischen Gutachtens<br />

durch eine Fremdfirma, auf<br />

deren Grundlage bautechnische Maßnahmen,<br />

die Reduzierung der Brandlast<br />

sowie die Inbetriebnahme einer<br />

neuen Brandschutzanlage erfolgten.<br />

Weiterhin mussten am Forschungsstandort<br />

Rossendorf erst die Voraussetzungen<br />

geschaffen werden, um die<br />

Kernbrennstoffe bzw. Kernmaterialien<br />

verwahren, die radioaktiven Abfälle<br />

und Reststoffe zwischenlagern,<br />

behandeln, analysieren und freigeben<br />

zu können. Dies er<strong>for</strong>derte zahlreiche<br />

atom- und strahlenschutzrechtliche<br />

Genehmigungen sowie deren bauliche<br />

Umsetzung, die in den Jahren<br />

1992 bis 1999 ebenfalls stattfanden.<br />

Hervorzuheben sind hierbei die Einrichtung<br />

zur Entsorgung von Kernmaterial,<br />

die Transportbereitstellungshalle<br />

für die CASTOREN, das<br />

Zwischenlager, die Reststoffbehandlungsanlage,<br />

das Freimesszentrum,<br />

das Analytiklabor sowie die notwendigen<br />

Einrichtungen für den<br />

Strahlenschutz, wie die Inkorporationsmessstellen<br />

sowie für die<br />

| Abb. 5.<br />

Schnittdarstellung RFR.<br />

Umgebungsüberwachung. Nach Erhalt<br />

der ersten beiden Genehmigungen<br />

zur RFR-Stilllegung [3, 4] wurden<br />

von 1998 bis 2001 die Anlagen kernbrennstoff-<br />

und kernmaterialfrei [5,<br />

6, 7] gefahren und für den VKTA mit<br />

dem Rückbau des 2. Kühlwasserkreislaufes<br />

der Abschluss der Stilllegungsphase<br />

erreicht. Von 2001 bis 2018<br />

erfolgten dann der Rückbau sowie die<br />

Geländesanierung mit abschließender<br />

Flächenprofilierung im Rahmen<br />

DECOMMISSIONING AND WASTE MANAGEMENT 539<br />

Decommissioning and Waste Management<br />

Decommissioning & Dismantling of the Rossendorf Research Reactor RFR ı Reinhard Knappik, Klaus Geyer, Sven Jansen and Cornelia Graetz


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

DECOMMISSIONING AND WASTE MANAGEMENT 540<br />

der Dritten und Vierten RFR-<br />

Stilllegungsgenehmigungen.<br />

Die Grundlage für die Stilllegung<br />

und den Rückbau des RFR waren insgesamt<br />

vier Genehmigungen mit ihren<br />

Änderungen. Die Erste Genehmigung<br />

45-4653.18 VKTA 01 zur Stilllegung<br />

des Rossendorfer Forschungsreaktors<br />

RFR [3] wurde am 30. Januar 1998<br />

durch das SMU erteilt. Deren 1. Änderungsgenehmigung<br />

45-1653.18 VKTA<br />

01/1, erteilt vom Sächsischen Staatsministerium<br />

für Umwelt und Landwirtschaft<br />

(SMUL) am 06. November<br />

2000, bein hal tete vor allem das Innehaben<br />

der endgültig abgeschalteten<br />

Anlage, die sichere Betriebsführung<br />

der abgeschalteten Anlage zum Zwecke<br />

der Stilllegung, die Überführung<br />

von Brennelementen aus der Spaltzone<br />

in das Brennelement lagerbecken<br />

AB 2 und den innerbetrieblichen<br />

Transport.<br />

Mit der Zweiten Genehmigung<br />

45-4653.18 VKTA 02 des SMUL vom<br />

30. Oktober 1998 zur Stilllegung des<br />

Rossendorfer Forschungsreaktors<br />

RFR [4] (eingereicht im Oktober<br />

1997) konnte der Rückbau des 2.<br />

Kühlkreislaufes realisiert werden,<br />

deren 1. Änderung vom <strong>11</strong>. Februar<br />

beinhaltete die Erweiterung des<br />

Genehmigungsumfanges bzgl. eines<br />

Raumes im RFR-Labortrakt.<br />

| Abb. 6.<br />

Überblick zum Aktivitätsinventar.<br />

Die Dritte Genehmigung 4653.18<br />

VKTA 03 zur Still legung und zum<br />

Abbau des Rossendorfer Forschungsreaktors<br />

RFR des SMUL vom 3. April<br />

2001 [8] ermög lichte die Entsorgung<br />

der Betriebsmedien sowie die Außerbetriebnahme<br />

und den Rückbau der<br />

nicht mehr benötigten Systeme und<br />

Komponenten des RFR. Dazu zählte<br />

z. B. der Rückbau des 1. Kühlkreislaufes,<br />

des Speisewassersystems und<br />

des Reaktorbehälters. Insgesamt gab<br />

es 14 Vorhaben, wobei mit Erteilung<br />

der Genehmigung bereits für vier<br />

Vorhaben die Zustimmungen des<br />

SMUL vorlagen. Die restlichen Vorhaben<br />

wurden abbaubegleitend mit<br />

dem SMUL abgestimmt.<br />

Mit der Vierten Genehmigung<br />

4653.18 VKTA 04 des SMUL vom<br />

1. Februar 2005 [9] konnte schließlich<br />

der Abbau der Restanlage des RFR vorgenommen<br />

werden. Der Änderungsbescheid<br />

4653.18 VKTA 04/1 vom<br />

9. November 2010 beinhaltete die Freigabe<br />

und Ent lassung des Raumes 01 im<br />

Gebäude 103 (Notstrom gebäude) und<br />

mit der 2. Änderungsgenehmigung<br />

4653.18 VKTA 04/2 des SMUL vom<br />

9. Januar 2014 wurden die Änderungen<br />

des räumlichen Geltungsbereiches<br />

sowie des Genehmigungsumfanges<br />

beschieden. Hintergrund war die Entscheidung<br />

des VKTA aufgrund von<br />

radiologischen Voruntersuchungen sowie<br />

durch technologisch bedingte<br />

Änderungen der Planungen des Abbaus,<br />

einen Total abbruch der RFR-<br />

Restanlage unter Strahlenschutzbedingungen<br />

vorzunehmen, wobei<br />

hierfür die notwen digen Erläuterungsberichte<br />

benötigt wurden wie ebenfalls<br />

für die Baufreiheit die Erweiterung des<br />

räumlichen Geltungsbereiches.<br />

Zur jeweiligen Genehmigungsplanung<br />

erfolgte die grundlegende<br />

Beschreibung des Gesamtvorhabens<br />

durch Erläuterungsberichte. Im<br />

Rahmen der Vierten Genehmigung<br />

gab es beispielsweise 18 Vorhaben,<br />

wobei das Vor haben <strong>11</strong> und das Vorhaben<br />

15 jeweils in drei Teile<br />

gegliedert war. Es wurden folglich<br />

22 Erläuterungs berichte erstellt, von<br />

denen sieben bereits bei Erteilung der<br />

Genehmigung von der zuständigen<br />

Behörde bestätigt wurden. Die weiteren<br />

Erläuterungsberichte erhielten im<br />

Zuge des Aufsichtsverfahrens die<br />

Zustimmung. Nach Abschluss eines<br />

Vorhabens wurde ein Abschlussbericht<br />

erstellt und an die zuständige<br />

Behörde übergeben.<br />

4 Ausgangssituation<br />

(radiologisch,<br />

konventionell)<br />

Die radiologische Ausgangssituation<br />

war geprägt durch das Vorhandensein<br />

von be- und unbestrahltem Kernbrennstoff,<br />

Kernmaterial sowie von<br />

Aktivierung und Kontamination<br />

unterschiedlichster Stoffe, die lokal<br />

und aktivitäts mäßig sehr differenziert<br />

waren. Einen Grobüberblick zum<br />

Aktivitätsinventar gibt die Abb. 6.<br />

Die Herstellung der Kernbrennstoff-<br />

Freiheit der RFR- Anlage war ein<br />

wichtiger Schritt für den Start des<br />

Rückbaus. Dazu mussten sowohl die<br />

951 bestrahlten Brenn elemente mit<br />

einer Gesamtaktivität von 8,91 E+15<br />

Bq als auch einige Posten kernbrennstoffhaltige<br />

Abfälle aus der RFR-<br />

Anlage entfernt werden. Diese Vorhaben<br />

wurden im Februar 2001 abgeschlossen.<br />

Weitere Einzelheiten sind<br />

im Abschnitt 7.2 zu entnehmen (s. <strong>atw</strong><br />

1/2020).<br />

Hinsichtlich der Aktivierung waren<br />

alle reaktornahen Baustrukturen<br />

und Anlagenteile, wie z. B. die Inneneinbauten<br />

des Reaktors, die Bestrahlungskanäle,<br />

das Biologische Schild,<br />

die Thermische Säule zu beachten.<br />

Wichtige Aktivierungsnuklide waren<br />

beispielsweise Eu-152, Ba-133, H-3,<br />

Co-60 (Beton/Bauschutt), Fe-55,<br />

Co-60, Ni-63, H-3 (Eisenteile), Fe-55,<br />

Co-60, Ni-63, H-3 (Stahlguss-Reaktordeckel),<br />

H-3, Ni-63, Co-60, Be-10<br />

Decommissioning and Waste Management<br />

Decommissioning & Dismantling of the Rossendorf Research Reactor RFR ı Reinhard Knappik, Klaus Geyer, Sven Jansen and Cornelia Graetz


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

(Be-Reflektorelemente), Ni-63, Ni-59,<br />

H-3, C-14, Co-60 (Borcarbid-<br />

Absorberstäbe), C-14, H-3, Eu-152,<br />

Co-60 (Graphit). Unerwartet wurde<br />

bei der radiologischen Voruntersuchung<br />

festgestellt, dass anstatt<br />

des in den auunterlagen ausgewiesenen<br />

Barytbetons das Biologische<br />

Schild aus Beton mit Eisenteilen<br />

bestand.<br />

Kontaminationen resultierten vor<br />

allem aus flüssigkeitsgetragenem<br />

Transport nach Freisetzung sowie aus<br />

einem Am-241-Ereignis (Freisetzung<br />

aus einem Target, 1969). Die Hauptnuklide<br />

in der RFR-Anlage waren<br />

H-3, Co-60, Sr-90+, Cs-137, Eu-152,<br />

U- und Pu-Nuklide und Am-241. Zur<br />

Erfassung der jeweiligen Ausgangssituation<br />

wurde nach der historischen<br />

Erkundung die radiologische Voruntersuchung<br />

nach Möglichkeit mit<br />

konventionellem Schadstoffuntersuchungen<br />

gekoppelt. Dies reduzierte<br />

später den zeitlichen und finanziellen<br />

Aufwand und so konnten z. T. potentielle<br />

Verdachtsflächen besser beurteilt<br />

und die Entsorgung schneller<br />

voran gebracht werden.<br />

Das Auftreten von chemotoxischen<br />

(konventionellen) Schadstoffen resultiert<br />

sowohl aus Betriebsabläufen<br />

als auch im Wesentlichen aus schädlichen<br />

Bestandteilen der Baustoffe.<br />

Zu den Gebäudeschadstoffen zählen<br />

beispielsweise Polyzyklische Aromatische<br />

Kohlenwasserstoffe (PAK,<br />

insbesondere in Teeranstrichen),<br />

Polychlorierte Biphenyle (PCB, Oberflächenbeschichtungen),<br />

künstliche<br />

Mineralfasern (KMF) und Asbest (in<br />

Dämmstoffen). In Ausrüstungen<br />

und Anlagen fand man z. B. PCB<br />

(Trans<strong>for</strong>matoren, Kondensatoren),<br />

Mineral kohlenwasserstoffe (MKW,<br />

Pumpen) oder Asbest (Dichtungen).<br />

Aus Betriebsabläufen stammen u. a.<br />

Kontaminationen von Schwermetallen<br />

und MKW. Das frühzeitige<br />

Erkennen der Schadstoffsituation<br />

ermöglichte die planerische Einarbeitung<br />

in die Rückbauprozesse<br />

sowie vor allem einen zeitlichen Vorlauf<br />

für eine sachgerechte Entsorgung<br />

des betreffenden Materials zu erhalten.<br />

Zu der Schadstoffproblematik<br />

veröffentlichte der VKTA einige<br />

Beiträge [10–12]. Bezüglich des RFR-<br />

Rückbaus sind insbesondere festgestellte<br />

PAK-Kontaminationen im Beton<br />

und Erdreich, das Vorfinden von<br />

Asbest hinter den Stahlbecken im<br />

Lager becken AB 2 (nicht in Bauzeichnung<br />

erwähnt) sowie lokale Kontaminationen<br />

mit MKW, Quecksilber<br />

und Schwermetallen im Beton hervorzuheben.<br />

5 Planungskonzept<br />

Grundsatz für die Planung war zum<br />

einen das Ziel, bei Stilllegung und<br />

Rückbau die Entsorgung von freigegebenen<br />

Stoffen parallel vorzunehmen<br />

und die radio aktiven Abfälle im<br />

1999 errichteten Zwischenlager<br />

Rossendorf, welches 2000 erweitert<br />

wurde, ordnungs gemäß für die spätere<br />

Endlagerung zu lagern. Zum<br />

anderen sollte das Betriebspersonal<br />

des RFR so weit wie möglich eingebunden<br />

werden und der VKTA nicht<br />

nur die Planungshoheit innehaben,<br />

sondern auch möglichst viele kostengünstige<br />

Beiträge zur Aufgabenerfüllung<br />

leisten. Da der VKTA planungstechnisch<br />

nicht alles abdecken konnte,<br />

wurde ab 2004 mit der heutigen<br />

Siempelkamp NIS Ingenieurgesellschaft<br />

mbH (NIS) eine Fachfirma eingebunden.<br />

NIS war, unterstützt durch<br />

Fachplaner in den Gebieten Lüftung,<br />

Tragwerksplanung und Schadstofferkundung,<br />

mit der Planung, der<br />

Erstellung und Bewertung von Ausschreibungsunterlagen<br />

sowie der<br />

Bau überwachung beauftragt. Ebenso<br />

wurden für spezielle Aufgaben weitere<br />

Fachfirmen gebunden. Der VKTA<br />

selbst, zeitweilig unterstützt durch<br />

einen Projektsteuerer, stellte die<br />

Rückbauleitung, bestehend aus:<br />

p Rückbauleiter<br />

p Gebäudeverantwortlicher,<br />

Strahlen schutzbeauftragter<br />

p Strahlenschutzingenieur/in<br />

p Strahlenschutzfachkraft<br />

p technischem Personal für strahlenschutztechnische<br />

Messungen,<br />

Transporte und kleineren technischen<br />

Aufgaben<br />

Die personelle Absicherung der Rückbauleitung<br />

in der Rückbau-Etappe bis<br />

2007 wurde dabei ausschließlich<br />

durch das ehemalige Betriebspersonal<br />

des RFR sicher gestellt. Die ab 2006<br />

auszuführenden Arbeiten wurden<br />

strukturiert, geplant, ausgeschrieben<br />

und an externe Dienstleister im<br />

Rahmen von Verträgen nach VOL<br />

oder VOB vergeben. Hierzu wurde<br />

eine Struktur verwendet, die sich<br />

einheitlich in Arbeits-, Termin- und<br />

Finanzpläne gliederte mit den<br />

Baulosgruppen:<br />

p Vorbereitende Maßnahmen<br />

p Bereitstellung von Ausrüstungen<br />

p Dienstleistungen Abbau<br />

p Abbaubegleitende lufttechnische<br />

Maßnahmen<br />

p Dienstleistungen Dekontamination<br />

p Arbeitsbegleitender Strahlenschutz<br />

p Mess- und Freimessprogramme in<br />

Planung und Durchführung<br />

p Abbaubegleitende sonstige<br />

Maßnahmen<br />

p Abbrucharbeiten bis zur Geländeprofilierung<br />

Die Leistungen des arbeitsbegleitenden<br />

Strahlenschutzes, der Planung<br />

und Durchführung von radiolo gischen<br />

und konventionellen Messungen/Analysen<br />

und von (Frei)Mess programmen<br />

übernahm der VKTA weitestgehend<br />

selbst. Dazu nutzte der VKTA u. a. sein<br />

nach DIN EN ISO/IEC 17025 akkreditiertes<br />

Labor für Umwelt- und Radionuklidanalytik.<br />

Andere auszuführende<br />

Arbeiten wurden in rund 200 Losen<br />

i. d. R. ausgeschrieben und den Losgruppen<br />

zugeordnet. Die bewusst<br />

kleinteilige Vergabe von Losen erlaubte<br />

es dem VKTA, mit seinen Planern<br />

auf besondere und erst im Verlauf des<br />

Abbaus erkennbare neue Situationen<br />

zügig zu reagieren, ortsnahe Firmen<br />

einzubinden und letztlich Kosten zu<br />

sparen.<br />

Der Arbeitsumfang des Gesamtprojektes<br />

entsprechend der jeweiligen<br />

Genehmigung wurde, wie bereits<br />

erwähnt, in Einzelvorhaben gegliedert,<br />

die in Erläuterungsberichten<br />

der Genehmigungsbehörde dargelegt<br />

wurden. Die zeit liche Abarbeitung der<br />

einzelnen Vorhaben erfolgte entsprechend<br />

eines Rahmenplanes, der<br />

mehrmals den objektiven Umständen<br />

angepasst werden musste. Für jedes<br />

Einzelvorhaben lag ein Detailplan vor.<br />

Die Durch führung der Arbeiten erfolgte<br />

auf der Grundlage von Arbeitsanweisungen<br />

und Ablaufplänen,<br />

wobei u. a. vor jedem Vorhaben ein<br />

Rückbauerlaubnis- sowie ein Arbeitserlaubnisverfahren<br />

gemäß der entsprechenden<br />

VKTA- Regelung durchzuführen<br />

war.<br />

6 Meilensteine Stilllegung<br />

und Rückbau<br />

Nach dem Erhalt der jeweiligen<br />

Genehmigung konnten die geplanten<br />

Arbeiten durchgeführt werden, wobei<br />

nach folgend wichtige Meilensteine<br />

des Rückbau<strong>for</strong>tschrittes beim RFR<br />

chronologisch (Durchführungszeitraum<br />

in Klammern) aufgeführt<br />

werden:<br />

p Kabinettsbeschluss des Freistaates<br />

Sachsen zur „Endgültige Stilllegung“<br />

(13. Juli 1993)<br />

p Antrag auf Stilllegung<br />

(21. Dezember 1994), Erhalt der<br />

Ersten Genehmigung (30. Januar<br />

1998, vgl. Abschnitt 3) und somit<br />

ab 2. Februar 1998 RFR-Betriebsführung<br />

nicht mehr auf der<br />

Grund lage der Aufsichtlichen<br />

Anord nungen des SMU, u. a.<br />

vom 28. Juni 1991<br />

p Herstellen der Kernbrennstofffreiheit<br />

des Reaktor behälters<br />

DECOMMISSIONING AND WASTE MANAGEMENT 541<br />

Decommissioning and Waste Management<br />

Decommissioning & Dismantling of the Rossendorf Research Reactor RFR ı Reinhard Knappik, Klaus Geyer, Sven Jansen and Cornelia Graetz


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

DECOMMISSIONING AND WASTE MANAGEMENT 542<br />

durch Umlagerung der Brennelemente<br />

aus dem Reaktorkern ins<br />

Lagerbecken AB 2 und dem Ausbau<br />

der kernbrennstoffhaltigen<br />

Neutro nen detektoren (6. April<br />

1998)<br />

p Antrag auf Zweite Stilllegungsgenehmigung<br />

(10. Oktober 1997);<br />

Erhalt der Zweiten Genehmigung<br />

(30. Oktober 1998) mit<br />

1. Änderung (<strong>11</strong>. Februar 1999)<br />

p Rückbau des 2. Kühlkreislaufes<br />

mit Entkernung und Abriss des<br />

Armaturenhauses, der Trockenkühltürme,<br />

des Pumpenhauses<br />

sowie der Verbindungsleitungen<br />

zwischen den Gebäuden und dem<br />

Reaktorgebäude; mit SMUL-<br />

Schreiben vom 16. August 1999<br />

waren diese Anlagen nicht mehr<br />

Bestandteil der RFR-Anlage<br />

p Überführung der Brennelemente<br />

aus dem Lagerbecken AB 2 in<br />

CASTOR® MTR 2-Behälter, Endabfertigung<br />

mit anschließendem<br />

Transport in die Transportbereitstellunghalle<br />

des VKTA<br />

(24. November 2000)<br />

p RFR-Anlage kernbrennstofffrei<br />

nach Abgabe/Konditionierung der<br />

restlichen Posten Kernbrennstoffabfälle<br />

(26. Februar 2001)<br />

p Antrag auf Dritte Stilllegungsgenehmigung<br />

(29. Dezember<br />

1998); Erhalt der Dritten<br />

Genehmigung (3. April 2001)<br />

p Ausbau des Reaktorbehälters,<br />

Arbeiten zur Transportbereitstellung<br />

und Transport zum<br />

Konditionierer (2001/2002)<br />

p Antrag auf Vierte Stilllegungsgenehmigung<br />

(31. Juli 2003);<br />

Erhalt der Vierten Genehmigung<br />

(1. Februar 2005) mit 2. Änderungsgenehmigung<br />

(9. Januar<br />

2014)<br />

p Transport der RFR-Brennelemente<br />

mittels CASTOREN ins Zwischenlager<br />

Ahaus (3 Konvoitransporte<br />

vom 30. Mai 2005 bis 13. Juni<br />

2005)<br />

p Abbau des RFR-Baukörpers einschließlich<br />

der Aus kleidung des<br />

Lagerbeckens AB 1 (2008/2009)<br />

p Ausräumen, Dekontamination und<br />

Abbruch der Heißen Zellen<br />

(2009/2010)<br />

p Ausbau des Deaerators<br />

(2010/20<strong>11</strong>)<br />

p Ausräumen, Dekontamination und<br />

Entkernung des Kellergeschosses<br />

(20<strong>11</strong>/2012)<br />

p Abbau, Dekontamination und<br />

Entsorgung der Teile des<br />

frei gegebenen Fortluftschornsteines<br />

(2013/2014)<br />

p Dekontamination, Entkernung<br />

und Abriss des Filter- und<br />

Ven tilationshauses (2014/2015)<br />

p Dekontamination, Entkernung<br />

und Abriss des Labortraktes mit<br />

Reaktorhalle und -warte (2016)<br />

p Abschluss des Ausbaus aller<br />

tiefliegender Bau strukturen und<br />

Bodensanierung (2016)<br />

p Abschluss der Baugrubenverfüllung<br />

sowie Beendigung der<br />

restlichen bautechnischen<br />

Maß nahmen (Profi lierung,<br />

Oberflächengestaltung<br />

(2017/2018)<br />

Autoren<br />

Reinhard Knappik<br />

Klaus Geyer<br />

Sven Jansen<br />

Cornelia Graetz<br />

VKTA Rossendorf<br />

Bautzner Landstraße 400<br />

01328 Dresden<br />

Deutschland<br />

Imprint<br />

| Editorial Advisory Board<br />

Frank Apel<br />

Erik Baumann<br />

Dr. Erwin Fischer<br />

Carsten George<br />

Eckehard Göring<br />

Dr. Florian Gremme<br />

Dr. Ralf Güldner<br />

Carsten Haferkamp<br />

Christian Jurianz<br />

Dr. Anton Kastenmüller<br />

Prof. Dr. Marco K. Koch<br />

Ulf Kutscher<br />

Herbert Lenz<br />

Jan-Christan Lewitz<br />

Andreas Loeb<br />

Dr. Thomas Mull<br />

Dr. Joachim Ohnemus<br />

Olaf Oldiges<br />

Dr. Tatiana Salnikova<br />

Dr. Andreas Schaffrath<br />

Dr. Jens Schröder<br />

Norbert Schröder<br />

Prof. Dr. Jörg Starflinger<br />

Dr. Brigitte Trolldenier<br />

Dr. Walter Tromm<br />

Dr. Hans-Georg Willschütz<br />

Dr. Hannes Wimmer<br />

| Editorial Office<br />

Christopher Weßelmann (Editor in Chief)<br />

Im Tal 121, 45529 Hattingen, Germany<br />

Phone: +49 2324 4397723<br />

Fax: +49 2324 4397724<br />

E-mail: editorial@nucmag.com<br />

Nicole Koch (Editor)<br />

c/o INFORUM, Berlin, Germany<br />

Phone: +49 176 84184604<br />

E-mail: nicole.koch@nucmag.com<br />

| Official <strong>Journal</strong> of Kerntechnische Gesellschaft e. V. (KTG)<br />

| Publisher<br />

INFORUM Verlags- und Verwaltungsgesellschaft mbH<br />

Robert-Koch-Platz 4, 10<strong>11</strong>5 Berlin, Germany<br />

Phone: +49 30 498555-30<br />

Fax: +49 30 498555-18<br />

www.nucmag.com<br />

| General Manager<br />

Dr. Thomas Behringer<br />

| CvD<br />

Marika Didonaki<br />

| Advertising and Subscription<br />

Petra Dinter-Tumtzak<br />

Phone: +49 30 498555-30<br />

Fax: +49 30 498555-18<br />

E-mail: petra.dinter@nucmag.com<br />

| Layout<br />

zi.zero Kommunikation<br />

Antje Zimmermann<br />

Berlin, Germany<br />

| Printing<br />

inpuncto:asmuth<br />

druck + medien gmbh<br />

Baunscheidtstraße <strong>11</strong>, 53<strong>11</strong>3 Bonn, Germany<br />

| Price List <strong>for</strong> Advertisement<br />

Valid as of 1 January 2019<br />

Published monthly, 9 issues per year<br />

Germany:<br />

Per issue/copy (incl. VAT, excl. postage) 24.- €<br />

Annual subscription (incl. VAT and postage) 187.- €<br />

All EU member states without VAT number:<br />

Per issue/copy (incl. VAT, excl. postage) 24.- €<br />

Annual subscription (incl. VAT, excl. postage) 187.- €<br />

EU member states with VAT number<br />

and all other countries:<br />

Per issues/copy (no VAT, excl. postage) 22.43 €<br />

Annual subscription (no VAT, excl. postage) 174.77 €<br />

| Copyright<br />

The journal and all papers and photos contained in it are protected by<br />

copyright. Any use made thereof outside the Copyright Act without the<br />

consent of the publisher, INFORUM Verlags- und Verwaltungsgesellschaft<br />

mbH, is prohibited. This applies to reproductions, translations,<br />

micro filming and the input and incorporation into electronic systems.<br />

The individual author is held responsible <strong>for</strong> the contents of the<br />

respective paper. Please address letters and manuscripts only to the<br />

Editorial Staff and not to individual persons of the association´s staff.<br />

We do not assume any responsibility <strong>for</strong> unrequested contributions.<br />

Signed articles do not necessarily represent the views of the editorial.<br />

ISSN 1431-5254<br />

Decommissioning and Waste Management<br />

Decommissioning & Dismantling of the Rossendorf Research Reactor RFR ı Reinhard Knappik, Klaus Geyer, Sven Jansen and Cornelia Graetz


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

First On-site Demonstration of Laser- based<br />

Decontamination Technology in Germany<br />

Torsten Kahl, Georg Greifzu, Carsten Friedrich, Christian Held, Marion Herrmann, Wolfgang Lippmann<br />

and Antonio Hurtado<br />

1 Introduction Several ongoing dismantling and decommissioning (D&D) projects of nuclear facilities in<br />

Germany produce wide experiences in terms of the regulation framework and the practical implementation. The D&D<br />

of commercial and research reactors require a comprehensive adaption of the available technologies to meet the<br />

demands of the associated health and safety requirements. This causes a rising monetary and human ef<strong>for</strong>t.<br />

To face this challenge the German<br />

federal government focuses the<br />

research and development activities<br />

to:<br />

a- protect human beings and the<br />

environment during nuclear<br />

decommissioning,<br />

b- educate staff and young academics<br />

and<br />

c- develop and optimize decommission<br />

methods.<br />

The dismantling and decommissioning<br />

of the various nuclear facilities<br />

located at Karlsruhe Institute of<br />

Technology (KIT) Campus North, the<br />

Kerntechnische Entsorgung Karlsruhe<br />

GmbH (KTE) faces several technical<br />

challenges.<br />

On the one hand, metallic surfaces,<br />

e. g. in the Hot Cells Facility (HZ),<br />

must be decontaminated radiologically,<br />

on the other hand, paint layers<br />

as well as radiological contamination<br />

must be removed from metallic components<br />

during post treatment, e. g.<br />

in the Waste Treatment Department<br />

(EB).<br />

Furthermore, large surfaces of<br />

concrete structures, e. g. in the<br />

Reprocessing Building (PG) of the<br />

Karlsruhe Reprocessing Plant (WAK),<br />

in the Multi-Purpose Research Reactor<br />

(MZFR) and in the Research Reactor<br />

(FR-2) must be cleared from paint<br />

layers, containing sometimes high rate<br />

of polychlorinated biphenyls (PCB).<br />

The overriding task in these<br />

processes is to enclose the radioactive<br />

substances and limit the radiation<br />

exposure of personnel and environment.<br />

Furthermore, the volume of<br />

waste should be minimized. The work<br />

situation <strong>for</strong> the operating personnel<br />

must be constantly monitored and<br />

the workload should be reduced<br />

wherever possible.<br />

Sometimes, the currently available<br />

chemical and mechanical processes,<br />

reach their limit to comply with the<br />

objects mentioned be<strong>for</strong>e.<br />

Abrasive blasting of metallic structures<br />

results in the production of<br />

secondary waste, which has to be<br />

further processed in case of PCB. In<br />

chemical decontamination processes,<br />

pickling acids also must be specially<br />

treated or stored.<br />

Furthermore, all mechanical processes,<br />

such as shaving or sandblasting,<br />

also cause high workloads<br />

<strong>for</strong> the operating personnel due to<br />

vibrations, restoring <strong>for</strong>ces and noise.<br />

Chemical processes, however, can<br />

cause damage through skin contact<br />

and inhalation.<br />

Decontamination by laser beam<br />

represents an interesting alternative.<br />

This technology can expand the<br />

repertory of currently available decontamination<br />

tech nologies. Being a<br />

contact-free procedure it comes along<br />

with the advantage of waste minimization<br />

and reduces restoring <strong>for</strong>ce <strong>for</strong><br />

hand-held as well as semi-automatic<br />

application, following NEA recommendations<br />

[1].<br />

At TU Dresden laser-based decontamination<br />

tech nology has been developed<br />

during the last years. The<br />

research project LaPLUS has been<br />

aimed at the optimi zation of the<br />

chemical-toxic decontamination of<br />

concrete surfaces and the technology<br />

transfer <strong>for</strong> the radiologic decontamination<br />

of metal surfaces. For that<br />

purpose, special hand-held laser tools<br />

<strong>for</strong> the use in nuclear sites were<br />

designed and tested on a laboratory<br />

scale. An essential part of the project<br />

was the technology transfer from<br />

laboratory scale to prototype status.<br />

For that purpose, the laser-based zi.<br />

decontamination was demonstrated<br />

in a realistic environment at the<br />

Multi-Purpose Research Reactor<br />

( MZFR).<br />

Under project leadership of TU<br />

Dresden, TU Berg akademie Freiberg<br />

(Development of process analysis<br />

tools) and IABG mbH (Design of laser<br />

tools) participated in the project. The<br />

KTE accompanied the project as an<br />

associated partner and supported the<br />

technology transfer to the MZFR.<br />

This paper presents the major<br />

results achieved inside the project. It<br />

covers the laser-based decontamination<br />

of PCB containing coatings on<br />

concrete and that of radiologic contaminated<br />

metal surfaces, the design<br />

and the test of special laser tools<br />

developed <strong>for</strong> the application in<br />

nuclear facilities.<br />

2 Application of laser<br />

systems <strong>for</strong> decontamination<br />

When a laser beam hits a surface,<br />

absorption of the energy leads to rapid<br />

heating of the substrate. The resulting<br />

spatial and temporal temperature<br />

distribution depends on optical and<br />

thermal characteristics of the substrate<br />

as well as on the parameters of<br />

the laser process [2]. Heating of the<br />

surfaces can result in melting, evaporation<br />

or sublimation. All of those<br />

mechanisms can be used <strong>for</strong> the<br />

removal of unwanted species, as<br />

necessary <strong>for</strong> surface decontamination.<br />

Additionally different<br />

practical requirements defined by the<br />

decontamination task require a<br />

careful selection of a suitable laser<br />

system.<br />

Rapid heating of the treated<br />

substrate surface above evaporation<br />

temperature can be achieved using<br />

pulsed lasers. The pulse duration is directly<br />

proportional to the volume of<br />

the heat affected zone [3], which<br />

means that shorter pulses lead to<br />

smaller heat affected volume. The<br />

possibilities and requirements of<br />

radiologic decontami nation using<br />

short pulsed lasers is treated in<br />

section 3.<br />

A different result can be achieved<br />

applying a con tinuous working (cw)<br />

laser beam, which continuously heats<br />

the surface. In case of interaction with<br />

paint, e.g. epoxy based coatings, the<br />

volatile components of that coating<br />

will evaporate and incinerate after<br />

reaching the ignition temperature. A<br />

subsequent combustion process of the<br />

DECOMMISSIONING AND WASTE MANAGEMENT 543<br />

Decommissioning and Waste Management<br />

First On-site Demonstration of Laser- based Decontamination Technology in Germany ı Torsten Kahl, Georg Greifzu, Carsten Friedrich, Christian Held, Marion Herrmann, Wolfgang Lippmann and Antonio Hurtado


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

DECOMMISSIONING AND WASTE MANAGEMENT 544<br />

coating is established. Chemical-toxic<br />

decontamination of PCB-containing<br />

paint using a continuous wave laser is<br />

treated in section 4. Application of<br />

high power diode lasers allows rapid<br />

treatment of surfaces with economically<br />

desirable laser equipment.<br />

Apart from beam parameters,<br />

further practical requirements have to<br />

be met <strong>for</strong> successful application of<br />

lasers in nuclear facilities.<br />

High mobility and toughness is<br />

required from the beam shaping optics,<br />

as opposed to regular industrial<br />

application. This demand is coped<br />

with using simplified 1D scanning<br />

optics.<br />

For the cost-efficient use of lasers,<br />

the application of optical fibres <strong>for</strong><br />

beam transport is mandatory. This<br />

allows to arrange the laser-system<br />

outside the contaminated area, thus<br />

eliminating the risk of contamination<br />

<strong>for</strong> the laser- system. Only part of the<br />

fibre and the beam-shaping laser<br />

optics will be placed inside the control<br />

area and can still be reused on several<br />

decommissioning sites, as explained<br />

in section 6.<br />

3 Decontamination<br />

of metal surfaces<br />

Laser-based cleaning of metal surfaces<br />

has been established within the last<br />

decade in applications like pre-treatment<br />

<strong>for</strong> welding, restauration of art<br />

and decoating of paint. In these cases,<br />

a laser beam is scanned and moved<br />

over the soiled surfaces and removes<br />

adhering unwanted species. High<br />

process selectivity can be achieved<br />

on metal surfaces, because a large<br />

fraction of the beam is reflected on<br />

blank metals as opposed to higher<br />

absorption on organics and oxides.<br />

Laser-based cleaning substitutes<br />

chemical as well as mechanic abrasive<br />

processes and results in a reduction of<br />

waste of factor 2.6 J/cm² <strong>for</strong><br />

austenitic steel, >3.5 J/cm² <strong>for</strong> ferritic<br />

steel and >5.3 J/cm² <strong>for</strong> zinc plated<br />

Wavelength<br />

Average <strong>Power</strong><br />

Pulse-Energy<br />

Peak <strong>Power</strong><br />

Pulse length<br />

Pulse frequency<br />

Scanner<br />

1064 nm<br />

150 W<br />

<strong>11</strong>.5 mJ @ 12 kHz<br />

<strong>11</strong>2 kW @ 12 kHz<br />

102 ns@ 12kHz<br />

12 - 40 kHz<br />

Spot diameter 472 µm<br />

Scanning width<br />

Mass of optics<br />

60 mm<br />

1,7 kg<br />

| Tab. 1.<br />

Specifications of Nd:YAG Laser CL150.<br />

| Fig. 1.<br />

Idealized scenarios of contamination, blue color symbolizes contamination:<br />

contamination of uncovered surfaces (A),<br />

on top of covered surface (B) and<br />

on as well as under covering layer (C),<br />

contamination within oxide layer (D).<br />

| Fig. 2.<br />

Ablation depth as function of cumulative energy with a pulse duration<br />

of 105 ns.<br />

| Fig. 3.<br />

Concentration of surrogates on sample surface prior and after<br />

decontamination.<br />

Decommissioning and Waste Management<br />

First On-site Demonstration of Laser- based Decontamination Technology in Germany ı Torsten Kahl, Georg Greifzu, Carsten Friedrich, Christian Held, Marion Herrmann, Wolfgang Lippmann and Antonio Hurtado


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

steel. Tested paint layers can be<br />

ablated at fluence above 1.8 J/cm²,<br />

while oxide layers can be removed at<br />

even lower fluence.<br />

The achieved ablation depth <strong>for</strong><br />

the above mentioned materials is<br />

plotted in Figure 2.<br />

It can be seen that the removal<br />

speed is about 100 times higher <strong>for</strong><br />

paint than <strong>for</strong> metals, what supports<br />

the selective removal of the paint on<br />

the metal ground. A variation of laser<br />

fluences between 1.8 – 3.5 J/cm² has<br />

been tested <strong>for</strong> its decontamination<br />

effect on blank austenitic steel. Single<br />

scans resulted in a contamination<br />

reduction of 50 – 90 % <strong>for</strong> all surrogates.<br />

Similar tests have been conducted<br />

on painted surface applying a<br />

laser fluence of 4.4 J/cm², to prove<br />

complete removal of the covering<br />

layer (Figure 3).<br />

Both tested cases result in a<br />

decreased contaminant concentration<br />

and decontamination factors up to<br />

98.9 have been achieved.<br />

4 Laser-based PCB<br />

degradation<br />

The TU Dresden has developed a PCB<br />

decontamination process by utilising<br />

a continuous wave diode laser.<br />

Laboratory experiments on concrete<br />

surfaces coated with epoxy paint<br />

demonstrated a reduction of 96.83 %<br />

of the PCB value. The PCB decomposition<br />

rate on the surface and in<br />

the exhaust gas be<strong>for</strong>e filtering is<br />

88.75 % [16].<br />

PCB decomposes at temperatures<br />

above 800 °C. At optimized process<br />

parameters the temperature in the<br />

laser spot is much higher [17], enable<br />

the full decomposition of the PCB.<br />

Rapid cooling of the exhaust gas is<br />

required to prevent the <strong>for</strong>mation of<br />

toxic polychlorinated dioxins and<br />

furans (PCDD/PCDF) which can be<br />

ensured by the laser processing. The<br />

application of a fabric filter in the<br />

extraction and filtration unit limits<br />

the temperature of filtered exhaust<br />

gas to


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

DECOMMISSIONING AND WASTE MANAGEMENT 546<br />

| Fig. 6.<br />

Overview of tested samples as supplied by KTE (A– lid of a 200 liter drum, B– steel sheet, C– coated u<br />

profile, D– locker door part).<br />

| Fig. 7.<br />

Components <strong>for</strong> decontamination of complex metal surfaces, (A) laser tool <strong>for</strong> the decoating of flat<br />

surfaces and (B) laser tool <strong>for</strong> the decontamination of edges.<br />

transported using optical fibres to<br />

reach the experimental area. This<br />

feature allows <strong>for</strong> the protection of<br />

costly laser equipment from contamination<br />

in any case, as described in<br />

section 2. The user can simply equip<br />

the required laser tool and start the<br />

decontamination process. Suction<br />

and filtration of mobilized contamination<br />

at high efficiency is facilitated<br />

applying a commercial filtration and<br />

suction unit by ULT GmbH. The<br />

localized suction of aerosols leads to<br />

prevention of recontamination and<br />

guarantees clear vision <strong>for</strong> the user at<br />

all times.<br />

Restricted access to the experimental<br />

area is beneficial to simplify the<br />

laser safety requirements, even in case<br />

of a technology demonstration.<br />

A full-fledged risk assessment<br />

according to §5 of ArbSchG [18] and<br />

§3 of ArbStättV [19] has been filed to<br />

scan <strong>for</strong> any arising risks <strong>for</strong> operators<br />

coming along with the application of<br />

the whole set up. All requirements of<br />

the occupational safety have been<br />

tested and proven. The risk assessment<br />

covers the following subject<br />

area:<br />

p General occupational safety<br />

p Laser safety<br />

p Safety from toxic substances (PCB)<br />

p Radiation safety<br />

p Respiratory protection<br />

The risk assessment complies with the<br />

laws, guidelines (ASR), workers compensation<br />

board rules and provisions.<br />

The risk assessment was finalized by<br />

TU Dresden and IABG and checked by<br />

KTE and has been the fundamental<br />

milestone <strong>for</strong> approval of the on-site<br />

demonstration at MZFR.<br />

5.3 Decontamination of<br />

complex metal geometries<br />

The decontamination of metal surfaces<br />

at MZFR was conducted on<br />

paints and metals prior unknown, to<br />

check the ability to transfer results<br />

from laboratory scale to on-site tests.<br />

To test limits of the laser tool, samples<br />

of varying geometries have been<br />

supplied by KTE, e.g. painted steel<br />

sheets, bracket steel or complex surfaces<br />

like ridges/spline/serration, as<br />

shown in Figure 6.<br />

Different laser tools were designed<br />

to ensure the decontamination at<br />

different surface geometries, e.g. in<br />

case of tighter angles the tool was<br />

adapted to maintain the complete<br />

suction of particles and aerosols<br />

during the laser process. A tool change<br />

can be completed within 1.5 min,<br />

Figure 7.<br />

Similar ablation characteristics<br />

were found <strong>for</strong> all tested samples as<br />

compared to the laboratory results<br />

(Figure 2). This implies that generalized<br />

material characteristics <strong>for</strong> paint<br />

layers and metals can be applied.<br />

From practical point of view, the<br />

flexibility of the laser ablation process<br />

was verified, as all tested geometries<br />

were completely cleaned without<br />

residues (Figure 8).<br />

5.4 Decontamination of<br />

concrete walls and floor<br />

at MZFR<br />

Decontamination of concrete demands<br />

solutions <strong>for</strong> a multitude of<br />

demands, e.g. uneven surfaces, varying<br />

thicknesses of paint, different<br />

shapes of surfaces and unknown PCB<br />

concentration in the decontamination<br />

paint. The practicability of the<br />

developed laser system was tested on<br />

walls and floors at the MZFR on<br />

sample surfaces sized 30 x 30 cm².<br />

The decontamination paint on the<br />

wall was thin and exhibited a high<br />

PCB concen tration (see Table 3). The<br />

floor featured lower PCB concentration<br />

and very thick paint (approx.<br />

1.5 mm).<br />

In Figure 9 the side view of the<br />

laser head is shown during the decontamination.<br />

During the process all<br />

arising by-products, like visible particles<br />

and gases, are extracted by the<br />

extraction and filtration unit and do<br />

not endanger the working staff.<br />

Figure 10 displays the result<br />

of decontamination on a floor<br />

| Fig. 8.<br />

Steel sheet partly decoated.<br />

| Fig. 9.<br />

Laser head during the decontamination of the floor.<br />

Decommissioning and Waste Management<br />

First On-site Demonstration of Laser- based Decontamination Technology in Germany ı Torsten Kahl, Georg Greifzu, Carsten Friedrich, Christian Held, Marion Herrmann, Wolfgang Lippmann and Antonio Hurtado


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

| Fig. 10.<br />

Demonstration field floor (A) be<strong>for</strong>e and (B) after the decontamination<br />

with multiple scans.<br />

Sample number Position Be<strong>for</strong>e decontamination<br />

PCB in mg/kg<br />

demonstration field be<strong>for</strong>e (A) and<br />

after (B) the laser process.<br />

In Figure <strong>11</strong> the laser head is<br />

displayed with different adaptions<br />

<strong>for</strong> flat areas (picture A and B) and<br />

internal corners (picture C). The<br />

modular set-up enables a fast change<br />

of the adaptions omitting any changes<br />

to the leaser heads basic components.<br />

Using such adaptions the decontamination<br />

of a wall with adjoining<br />

corners was demonstrated, illustrating<br />

the clear advantage compared<br />

to shaving equipment, where usually<br />

boundary areas need an additional,<br />

time- consuming handling step.<br />

The removal of thick layers and/or<br />

remaining soot can be realized by<br />

multiple passes. Both have been<br />

demonstrated in Karlsruhe.<br />

During the demonstration an<br />

average laser power of 3.7 kW was<br />

applied, resulting in a practical<br />

determined ablation speed of 6 m²/h<br />

5.5 PCB sampling at the MZFR<br />

Within the demonstration PCB<br />

sampling was per<strong>for</strong>med to prove the<br />

decontamination rate of the laserbased<br />

paint removal. This study aimed<br />

at the evaluation of the PCB concentration<br />

of the primary source. To<br />

release material the PCB-concentration<br />

must amount less than 50 mg/<br />

kg. Samples with mass > 50 mg were<br />

extracted using an electric scraper.<br />

AGROLAB Labor GmbH per<strong>for</strong>med<br />

the analysis of the samples according<br />

to DIN EN 15308. The samples taken<br />

be<strong>for</strong>e the decontamination consisted<br />

mainly of decontamination paint.<br />

After the decontamination no paint<br />

remained on the surface anymore,<br />

there<strong>for</strong>e the now surfacing concrete<br />

was sampled.<br />

In Figure 12 the sampled surfaces<br />

are shown be<strong>for</strong>e PCB sampling (A),<br />

after PCB sampling (B) and after<br />

decontamination and the consecutive<br />

PCB sampling (C). The corresponding<br />

PCB concentration is shown in<br />

Table 3.<br />

The laser-based decontamination<br />

process resulted in an average reduction<br />

of PCB of 98.7 % within a practical<br />

application. This value is even<br />

higher than the value of the laboratory<br />

experiments per<strong>for</strong>med at the TU<br />

Dresden [16]. The remaining PCB<br />

concentration after the decontamination<br />

is mainly caused by the PCB<br />

inside the concrete matrix. After sealing<br />

the walls with PCB containing<br />

paint the PCB diffuses from the decontamination<br />

paint (primary source)<br />

into the concrete. Alternative laserbased<br />

technologies are available to<br />

remove and to vitrify concrete surfaces<br />

in a single process step [20; 21].<br />

| Fig. <strong>11</strong>.<br />

Laser head <strong>for</strong> concrete decontamination;<br />

A- laser head (round version), B- laser head (angled), C- laser head internal corner.<br />

After decontamination<br />

PCB in mg/kg<br />

Difference<br />

mg/kg<br />

| Fig. 12.<br />

Examples of a demonstration field:<br />

(A)- be<strong>for</strong>e sampling, (B)- after decontamination and (C)- after decontamination and sampling.<br />

6 Conclusion and future<br />

prospects<br />

The TU Dresden successful demonstrated<br />

the application of laser-based<br />

decontamination on radiologic and<br />

chemical-toxic contaminated metal<br />

and concrete surfaces at the MZFR in<br />

Karlsruhe. All necessary documents to<br />

obtain acceptance of the KTE were<br />

prepared by TU Dresden and approved<br />

by KTE. An independent work<br />

permit was available to TU Dresden.<br />

The selective decontamination on<br />

metal surfaces is characterized by a<br />

process stop after removing any coating<br />

(decontamination paint, oxide<br />

and/or contamination). The practical<br />

removal rate on metal is 0.42 m²/h<br />

using a mean laser power of 150 W<br />

and an average paint thickness of<br />

165 µm. The application of laser-based<br />

decontamination to PCB-contaminated<br />

concrete surfaces resulted in<br />

a mean reduction of 98.7 % of the<br />

PCB-concentration. During the onsite-demonstration<br />

a removal rate of<br />

6 m²/h of paint from concrete walls<br />

with 3.7 kW laser power were accomplished.<br />

The handheld laser tools<br />

Reduction<br />

%<br />

1 Floor 9.3 0.23 9.07 97.5<br />

2 Floor 30.1 0.04 30.06 99.9<br />

3 Wall 3,810 67.3 3,742.7 98.2<br />

4 Wall 2,360 19 2,341 99.2<br />

5 Wall 1,976 18.9 1,957.1 99.0<br />

6 Wall 2,510 14.2 2,495.8 99.4<br />

7 Wall 2,272 49.7 2,222.3 97.8<br />

| Tab. 3.<br />

PCB concentration of the sampling be<strong>for</strong>e and after the decontamination.<br />

Ø 98.7 %<br />

DECOMMISSIONING AND WASTE MANAGEMENT 547<br />

Decommissioning and Waste Management<br />

First On-site Demonstration of Laser- based Decontamination Technology in Germany ı Torsten Kahl, Georg Greifzu, Carsten Friedrich, Christian Held, Marion Herrmann, Wolfgang Lippmann and Antonio Hurtado


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

DECOMMISSIONING AND WASTE MANAGEMENT 548<br />

enable high flexibility and reduce<br />

restraining <strong>for</strong>ces <strong>for</strong> the working<br />

staff. The dry laser cleaning process<br />

runs completely without abrasive or<br />

chemical aids thus reducing the<br />

amount of secondary waste drastically.<br />

The determined removal rates on<br />

concrete and metal are highly affected<br />

by the thickness and optical pro perties<br />

of the decontamination paint. The<br />

great advantage of lasers is the scalability<br />

of their power. The use of<br />

commercial available lasers with<br />

higher power would result in higher<br />

ablation rates without any changes to<br />

the applied laser tools.<br />

The on-site demonstration at<br />

MZFR Karlsruhe verified the possibilities<br />

of that technology <strong>for</strong> decontamination<br />

of contaminated surfaces.<br />

Robust laser tools can offer an<br />

alternative <strong>for</strong> surface decontamination<br />

in the near future. Following the<br />

positive results of the research project<br />

LaPLUS more detailed insight into the<br />

behavior of mobilized aerosols as well<br />

as further tests within control areas<br />

will be provided from follow up projects.<br />

Industrial application of the<br />

laser-based decontamination process<br />

should become feasible in the next<br />

years<br />

Acknowledgement<br />

The on-site demonstration at the<br />

MZFR in Karlsruhe was carried out<br />

inside the Research and Development<br />

Project LaPLUS financed by The<br />

German Federal Ministry of Education<br />

and Research (BMBF) under the<br />

contract number 15S9215A.<br />

We would like to thank all colleagues<br />

of the MZFR that supported<br />

the on-site-demonstration with enthusiasm<br />

and useful evidences as well<br />

as practical drive. Our special thanks<br />

go to the members of our technical<br />

staff, who were a great support during<br />

the exhausting time of demonstration<br />

and the whole project as well.<br />

References<br />

[1] <strong>Nuclear</strong> Energy Agency: R&D and Innovation Needs <strong>for</strong><br />

Decommissioning of <strong>Nuclear</strong> Facilities. 2014 (7191)<br />

[2] BLIEDTNER, M.: Lasermaterialbearbeitung. München:<br />

CARL HANSER Verlag GMBH, 2013<br />

[3] Leitz, K.-H.; Redlingshöfer, B.; Reg, Y.; Otto, A.; Schmidt, M.:<br />

Metal Ablation with Short and Ultrashort Laser Pulses. In:<br />

Physics Procedia 12 (20<strong>11</strong>), S. 230–238<br />

[4] Büchter, E.: Entwicklung eines Hochleistungs-Laserstrahl-<br />

Reinigungsgerätes zur Ressourcen schonenden<br />

Entschichtung von Oberflächen. Herzogenrath, 2004<br />

[5] Carvalho, L.; Pacquentin, W.; Tabarant, M.; Maskrot, H.;<br />

Semerok, A.: Growth of micrometric oxide layers to explore<br />

laser decontamination of metallic surfaces. In: EPJ <strong>Nuclear</strong><br />

Sciences & Technologies 3 (2017), S. 30<br />

[6] Delaporte, Ph.; Gastaud, M.; Marine, W.; Sentis, M.;<br />

Uteza, O.; Thouvenot, P.; Alcaraz, J. L.; Le Samedy, J. M.;<br />

Blin, D.: Radioactive oxide removal by XeCl laser.<br />

In: Applied Surface Science 197-198 (2002), S. 826–830<br />

[7] Kim, D.; Lim, H.: Laser Decontamination of Carbon Steel<br />

Surfaces. In: ISIJ <strong>International</strong> (2003), Nr. 43, S. 1289–1291<br />

[8] Leontyev, A.; Semerok, A.; Farcage, D.; Thro, P.-Y.; Grisolia, C.;<br />

Widdowson, A.; Coad, P.; Rubel, M.: Theoretical and<br />

experimental studies on molybdenum and stainless steel<br />

mirrors cleaning by high repetition rate laser beam.<br />

In: Fusion Engineering and Design 86 (20<strong>11</strong>),<br />

9-<strong>11</strong>, S. 1728–1731<br />

[9] Edelson, M. C.; Pang, H.: A laser-based solution to industrial<br />

decontamination problems. 1995 (ICALEO 1995 768)<br />

[10] Potiens, A. J.; Dellamano, J. C.; Vicente, R.; Raele, M. P.;<br />

Wetter, N. U.; Landulfo, E.: Laser decontamination of the<br />

radioactive lightning rods. In: Radiation Physics and<br />

Chemistry 95 (2014), S. 188–190<br />

[<strong>11</strong>] Sadanori, S.; Seiji, A.; Inoue, T.: Applying laser technology to<br />

decommissioning <strong>for</strong> nuclear power plant (Advanced<br />

High-<strong>Power</strong> Lasers and Applications). Osaka, Japan, 1999<br />

[12] Takakuni, H.; Yutaka, K.; Masato, M.: Application of a laser to<br />

decontamination and decommissioning of nuclear facilities<br />

at JAERI (Advanced High-<strong>Power</strong> Lasers and Applications).<br />

Osaka, Japan, 1999<br />

[13] Vatry, A.; Grisolia, C.; Delaporte, Ph.; Sentis, M.: Removal<br />

of in vessel Tokamak dust by laser techniques. In: Fusion<br />

Engineering and Design 86 (20<strong>11</strong>), 9-<strong>11</strong>, S. 2717–2721<br />

[14] Nilaya, J. P.; Raote, P.; Kumar, A.; Biswas, D. J.: Laser-assisted<br />

decontamination – A wavelength dependent study. In:<br />

Applied Surface Science 254 (2008), Nr. 22, S. 7377–7380<br />

[15] Delaporte, Ph.; Gastaud, M.; Marine, W.; Sentis, M.; Uteza, O.;<br />

Thouvenot, P.; Alcaraz, J. L.; Le Samedy, J. M.; Blin, D.: Dry<br />

excimer laser cleaning applied to nuclear decontamination.<br />

In: Applied Surface Science 208-209 (2003), S. 298–305<br />

[16] Anthofer, A.; Kögler, P.; Friedrich, C.; Lippmann, W.;<br />

Hurtado, A.: Laser decontamination and decomposition<br />

of PCB-containing paint. In: Optics & Laser Technology 87<br />

(2017), S. 31–42<br />

[17] Anthofer, A.: Oberflächenentschichtung mittels<br />

Laserstrahlung. Untersuchungen zur Dekontamination<br />

radioaktiv und chemisch-toxisch belasteter Betonoberflächen<br />

mittels Lasertechnologie. Dissertation, Dresden, 2014<br />

[18] Bundesministerium der Justiz und für Verbraucherschutz:<br />

Gesetz über die Durchführung von Maßnahmen des<br />

Arbeitsschutzes zur Verbesserung der Sicherheit und des<br />

Gesundheitsschutzes der Beschäftigten bei der Arbeit<br />

(idF v. 31. 8. 2015) (1996-08-07)<br />

[19] Bundesministerium der Justiz und für Verbraucherschutz:<br />

Verordnung über Arbeitsstätten<br />

(idF v. 18. 10. 2017) (2004-08-12)<br />

[20] Lippmann, W.; Herrmann, M.; Pietsch, C.; Reinecke, A.;<br />

Hille, C.; Wolf, R.; Zeuner, A.: LASABA II : Dekontamination<br />

silikatischer Oberflächen in kerntechnischen Anlagen mittels<br />

Laserabtrag bei gleichzeitiger Abproduktkonditionierung.<br />

Abschlussbericht, Dresden, 2008<br />

[21] Hurtado, A.; Littwin, R.; Lippmann, W.: MANOLA: Manipulator<br />

gesteuerter Oberflächenabtrag durch Lasertechnologie.<br />

Abschlussbericht, Dresden, 20<strong>11</strong><br />

Authors<br />

Torsten Kahl,<br />

Georg Greifzu,<br />

Marion Herrmann,<br />

Wolfgang Lippmann,<br />

Antonio Hurtado<br />

Technische Universität Dresden<br />

Chair of Hydrogen and<br />

<strong>Nuclear</strong> Energy<br />

Institute of <strong>Power</strong> Engineering<br />

George-Bähr-Str. 3b<br />

01062 Dresden<br />

Germany<br />

Carsten Friedrich,<br />

Christian Held<br />

Kerntechnische<br />

Entsorgung Karlsruhe<br />

Hermann-von-Helmholtz-Platz 1<br />

76344 Eggenstein-Leopoldshafen<br />

Germany<br />

Decommissioning and Waste Management<br />

First On-site Demonstration of Laser- based Decontamination Technology in Germany ı Torsten Kahl, Georg Greifzu, Carsten Friedrich, Christian Held, Marion Herrmann, Wolfgang Lippmann and Antonio Hurtado


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

Scientists and Professionals from all around the World in Karlsruhe:<br />

The 25 th Edition of the Frédéric Joliot/Otto Hahn Summer School<br />

on <strong>Nuclear</strong> Reactors “Physics, Fuels and Systems“<br />

Victor Hugo Sanchez-Espinoza<br />

The Institute of Neutron Physics and Reactor Technology (INR) of the Karlsruhe Institute of Technology (KIT) together<br />

with the Commissariat à l’Énergie Atomique (CEA) hosted this year the “Frédéric Joliot/Otto Hahn (FJOH) Summer<br />

School“ at the Akademiehotel in Karlsruhe from August 21 st to August 30 th 2019. The topic of this year’s school was<br />

“Innovative Reactors: Matching the Design to Future Deployment and Energy Needs”.<br />

549<br />

REPORT<br />

It was organized in six technical blocks<br />

and one seminar devoted to “Public<br />

Acceptance of Energy Technologies”<br />

given by S. Hirschberg from PSI<br />

Switzerland. The first introduc tory<br />

block was devoted to “Various Innovative<br />

Reactor Concepts <strong>for</strong> Various<br />

Missions” and consisted in two<br />

lectures. The first one entitle “The<br />

Deciding Factors in Opting <strong>for</strong> a<br />

Particular Reactor Technology” was<br />

given by J. Guidez (CEA, France) and<br />

the second one entitled “Promising<br />

Reactor Concepts <strong>for</strong> Multiple Applications”<br />

given by S. Monti (IAEA).<br />

The second block was focused on the<br />

topic “Near-term-deployment <strong>Power</strong>to-grid<br />

Integrated LWR Technology”<br />

and it consisted of three lectures as<br />

follows. The first lecture deals with<br />

“From Specific Design Criteria to an<br />

Advanced Modular LWR Concept: Approach,<br />

Methods, Validation” given by<br />

F. Morin (CEA, France). The second<br />

lecture was entitled “The Challenges<br />

of Designing and Licensing a First-ofa-kind<br />

Reactor Prototype, even a Small<br />

One” given by D. Delmastro (CNEA,<br />

Argentina) and finally the third lecture<br />

was entitled “The Reliability and<br />

Safety Case of a Reactor Equipped<br />

with Passive Systems” presented by<br />

A. Schaffrath (GRS, Germany). The<br />

third block was dedicated to the topic<br />

“Multi-purpose Molten Salt Reactors”<br />

and it was organized as three<br />

lectures to the following issues. The<br />

first lecture was entitled “MSR Design<br />

Principles, Concepts, Modelling Approaches,<br />

and Methods” given by T.<br />

Abram (Univ. of Man chester, UK). The<br />

second lecture was devoted to “From<br />

the MSR Physics Principles to a Plant<br />

Layout” given by E. Merle (Grenoble<br />

INP & CNRS) and the third lecture<br />

entitled “Fuel Salts Chemistry and<br />

Materials Compati bility” given by<br />

V. Ignatev (KI, Russia). The fourth<br />

block was devoted to “­<strong>Nuclear</strong> Technology<br />

<strong>for</strong> Space ­Propulsion and<br />

Manned Space ­Exploration” and it<br />

consisted of two lectures. The first one<br />

entitled “ <strong>Nuclear</strong> Rocket Propulsion:<br />

Background, Physics and Methods,<br />

Design and Tests” given by W. Emrich<br />

Jr. ( NASA, USA) and the second one<br />

entitled “The Challenge of Fueling a<br />

<strong>Nuclear</strong> Engine <strong>for</strong> Space Exploration”<br />

given by J. Witter (BWXT, USA).<br />

The fifth block was devoted to<br />

“Minimum-intervention Long-life<br />

Breed-­and-burn Fast Reactors” and<br />

it consisted of two lectures. The first<br />

one entitled “Physics of Breed-andburn<br />

Reactors, Optimized Core and<br />

Fuel Design, Licensing Case” given by<br />

K. Weaver (INL, USA) and the second<br />

one entitled “Cladding and Structural<br />

Materials <strong>for</strong> Very Long In-core<br />

Residence Times“ given by Y. Decarlan<br />

(CEA, France). The sixth block was<br />

devoted to “Reactor Concepts <strong>for</strong><br />

Process Heat and <strong>Power</strong>-to-gas<br />

­Applications” and it consisted of two<br />

lectures. The first one entitled<br />

“ Designing a Small Reactor to Bring<br />

<strong>Power</strong> to Remote Areas or to Produce<br />

Process Heat” given by J. Kloosterman<br />

(TU Delft, Netherlands) and the<br />

second one entitled „Techno-economic<br />

Assessment of Hydrogen Production<br />

from <strong>Nuclear</strong> Energy“ given by<br />

J. Witter (BWXT, USA). In the frame of<br />

the technical visit, a guided tour was<br />

organized <strong>for</strong> the TrasnetBW GmbH<br />

in Wendlingen, which is one of the<br />

largest system Control Centre <strong>for</strong><br />

Baden Württemberg with headquarter<br />

in Stuttgart. It operates the electricity<br />

transmission grid in the German state<br />

of Baden-Württemberg, control and<br />

monitor the energy flows through the<br />

grid, and per<strong>for</strong>m the necessary<br />

maintenance and network planning<br />

and development activities. This year,<br />

44 participants of 18 countries (EU,<br />

Asia, Latin America, East Europe,<br />

Middle East, Africa, and USA) attended<br />

the FJOH Summer School.<br />

Recognized experts of 10 different<br />

countries from Asia, EU, South<br />

America, USA and East Europe from<br />

Academia, industry, research and<br />

TSOs gave high-level lectures on topics<br />

of their expertise. During the ten days,<br />

the participants had the opportunity<br />

to exhaustive discussions with the<br />

lecturers and other participants. Apart<br />

| The 25 th Edition of the Frédéric Joliot/Otto Hahn Summer School on <strong>Nuclear</strong><br />

Reactors “Physics, Fuels and Systems“, participants and lecturers in Karlsruhe.<br />

from the technical issues, another goal<br />

of the FJOH Summer School is to<br />

intensify the networking among the<br />

participants of different continents<br />

and nationalities with the common objective<br />

of enhanced safety worldwide.<br />

A well-recognized tradition during<br />

the FJOH Summer School is an extensive<br />

and diverse program with social<br />

events to get familiar with the German<br />

culture and way of life as well as to<br />

foster the exchange among the participants.<br />

This year, the Sunday trip<br />

consisted in the visit of the Technical<br />

Museum Speyer and afterwards, a<br />

Canoe Tour at the Old Rhine. After the<br />

Museum visit, the participants have<br />

free time to get familiar with the<br />

downtown of Speyer and to visit the<br />

Romanesque Cathedral that houses<br />

the grave f most important kings and<br />

emperors e.g. it is the burial place <strong>for</strong><br />

emperor Konrad II and his wife.<br />

The next Summer School will be<br />

hosted by CEA in Aix-en-Provence,<br />

from August 26 th to September 4 th ,<br />

2020 and it will be devoted to “High-­<br />

fidelity Modelling and Simulation<br />

of <strong>Nuclear</strong> Reactors: Turning a<br />

Promise into Reality”.<br />

Author<br />

Dr.-Ing. Victor Hugo Sanchez-Espinoza<br />

Head of Group<br />

“Reactor Physics and Dynamics”<br />

Project Leader<br />

“LWR Safety Methods and Codes ”<br />

Karlsruhe Institute of Technology (KIT)<br />

Institute <strong>for</strong> Neutron Physics and<br />

Reactor Technology (INR)<br />

Hermann-von-Helmholtz-Platz 1<br />

76344 Eggenstein-Leopoldshafen<br />

Report<br />

The 25th Edition of the Frédéric Joliot/Otto Hahn Summer School on <strong>Nuclear</strong> Reactors “Physics, Fuels and Systems“ ı Victor Hugo Sanchez-Espinoza


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

Special Topic | A Journey Through 50 Years AMNT<br />

550<br />

SPECIAL TOPIC | A JOURNEY THROUGH 50 YEARS AMNT<br />

Am 7. und 8. Mai<br />

2019 begingen wir<br />

das 50. Jubiläum<br />

unserer Jahrestagung<br />

Kerntechnik. Zu<br />

diesem Anlass öffnen<br />

wir unser <strong>atw</strong>-Archiv<br />

für Sie und präsentieren<br />

Ihnen in jeder<br />

Ausgabe einen<br />

historischen Beitrag.<br />

Überarbeitete<br />

Fassung eines<br />

Vortrags gehalten<br />

am 14. Mai 2002<br />

auf der Jahrestagung<br />

Kerntechnik 2002,<br />

Stuttgart,<br />

14.-16.5.2002<br />

Schutz von Mensch und Umwelt –<br />

Nukleare Anwendungen außerhalb des<br />

Energiesektors<br />

P.P. De Regge, Wien<br />

1 Einleitung Nukleare Technologien liefern immer mehr bedeutende Beiträge zum Schutz des Menschen und<br />

seiner Umwelt sowie zur Verbesserung der Lebensstandards. Die <strong>International</strong>e Atomenergie Organisation (IAEO) ist<br />

durch die Vereinten Nationen (UN) per Statut beauftragt, solche nuklearen Technologien zu entwickeln, zu fördern<br />

und deren Einsatz zu unterstützen. Sie erreicht dies durch Veröffentlichung von In<strong>for</strong>mationen, Ausbildung, Zulieferung<br />

von Ausrüstung, Dienstleistungen und Erstellung von Sicherheitsnormen.<br />

In diesem Beitrag wird diese Rolle der IAEO erläutert<br />

und es wird weiter der heutige Stand der nuklearen<br />

Anwendungen in folgenden Bereichen dargestellt:<br />

p Nuklearmedizin und Gesundheitspflege<br />

p Veterinärmedizin und Viehzucht<br />

p Bodenkultivierung und Düngemittel<br />

p Wasserversorgung und Umweltschutz<br />

p Anbau von Kulturpflanzen<br />

p Schädlingsbekämpfung<br />

p sonstige Anwendungen, wie Landminenräumung und<br />

Schutz des kulturellen Erbes<br />

2 Rolle der <strong>International</strong>en Atomenergie<br />

Organisation<br />

Die Ziele der IAEO hinsichtlich der Anwendung von<br />

nuklearen Technologien sind ein Beitrag zur nachhaltigen<br />

Entwicklung und zum Umweltschutz in den Bereichen<br />

medizinische Versorgung, Ernährung, Landwirtschaft und<br />

Industrie sowie Versorgung mit Wasser. Die Aktivitäten<br />

der IAEO in diesen Bereichen haben Grundbedürfnisse der<br />

Menschheit im Fokus. Nukleare Technologien sollen dabei<br />

wesentlichere und konkurrenzfähigere Vorteile bieten als<br />

vergleichbare andere Technologien.<br />

Entsprechende nukleare Technologien und Anwendungen<br />

werden im Rahmen von koordinierten, angewandten<br />

Forschungsprojekten entwickelt. Dazu werden<br />

über mehrere Jahre Beiträge von potenziellen Anwendern<br />

aus Industriestaaten und Entwicklungsländern koordiniert.<br />

Bereits einsetzbare Technologien werden verfügbar<br />

gemacht und interessierten Ländern bereit gestellt; über<br />

technischer Kooperationsprojekte wird die technische<br />

Ausrüstung beschafft und es wird für eine entsprechende<br />

notwendige Ausbildung zum Betrieb von Analgen und<br />

Einsatz von Technologien gesorgt.<br />

Im derzeitigen Gesamtbild der weltweiten Entwicklung<br />

erkennt man folgende wichtige Problemfelder:<br />

p Die Weltbevölkerung hat fast 6 Milliarden Menschen<br />

erreicht und wächst pro Jahr um rund 80 Millionen<br />

an – dies entspricht etwa der deutschen Gesamtbevölkerung.<br />

p Fast eine Milliarde Menschen sind chronisch unterernährt<br />

und es fehlt ihnen zudem an einer zuver lässigen<br />

Wasserversorgung.<br />

p Sechs Millionen Kinder in der Dritten Welt sterben<br />

jedes Jahr aufgrund Mangelernährung; ebenso viele<br />

Erwachsene sterben in den Industriestaaten jährlich an<br />

Krebs. Weitere Millionen sind erkrankt oder sterben an<br />

bakteriellen oder von Viren verursachten Infektionen<br />

und Krankheiten. Zum Beispiel streben allein an den<br />

Folgen der Malaria weltweit mehr als 2 Millionen<br />

Menschen pro Jahr.<br />

Viele heutige Aktivitäten des Menschen verschmutzen und<br />

verändern die Umwelt und sind auf längere Sicht nicht<br />

tragbar.<br />

Die von der IAEO entwickelten und unterstützten<br />

nuklearen Anwendungen außerhalb des Energiesektors<br />

haben daher auch<br />

p die Verbesserung der Ernährungssituation und Wasserversorgung,<br />

p die Verbesserung des Gesundheitsschutzes sowie<br />

p den Schutz der Umwelt durch Analyse, Vorbeugung<br />

und Sanierung belasteter Bereiche<br />

zum Ziel. Trends der IAEO-Unterstützung von Projekten<br />

im Rahmen der technischen Kooperation sind in Tabelle 1<br />

dargestellt.<br />

3 Gesundheitsvorsorge<br />

Die meist verbreiteten diagnostischen Anwendungen von<br />

ionisierender Strahlung und nuklearer Technologie sind<br />

die Röntgendiagnose sowie die Diagnostik mit radioaktiven<br />

biologischen Indikatoren in der Nuklearmedizin.<br />

Die therapeutische Anwendung ist die Strahlungsonkologie,<br />

bei der mit einer wirksamen Strahlungsdosis an<br />

bestimmten krebsgefährdeten Stellen des Körpers mittels<br />

einer externen Strahlungsquelle (Teletherapie) oder<br />

mittels einer implantierten Strahlungsquelle (Brachytherapie)<br />

gearbeitet wird. Auch offene Strahlungsquellen,<br />

wie radioaktive Substanzen zur Behandlung von Schilddrüsenkrebs,<br />

werden manchmal verwendet. Neue Anwendungen<br />

von radioaktiven Substanzen werden er<strong>for</strong>scht<br />

und entwickelt.<br />

Special Topic | A Journey Through 50 Years AMNT<br />

Protection of Man and Environment – <strong>Nuclear</strong> Usage Outside of Energy Sector ı P.P. De Regge, Wien


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

Projekte<br />

Eine revolutionäre Entwicklung der diagnostischen<br />

Radiologie war die Computertomografie, die genaue<br />

Schnittbilder von bestimmten Körperregionen in allen<br />

anatomischen und funktionellen Einzelheiten darstellt.<br />

Die Nuklearmedizin verwendet Radioisotope in über<br />

Hundert standardisierten Methoden für diagnostische,<br />

therapeutische und Forschungszwecke in den Bereichen<br />

Onkologie, Endokrinologie, Kardiologie, Neurologie und<br />

Nephrologie. Industriestaaten haben derzeit etwa<br />

20 Gammakameras pro einer Million Einwohner zur<br />

Verfügung, während in Entwicklungsländern nur eine<br />

pro eine Million Einwohnern verfügbar ist, und dies<br />

nur in den größeren Metropolen.<br />

Molekulare Nuklearmedizin ist ein neuer Anwendungsbereich.<br />

Erkrankungen werden auf zellulären oder<br />

gene tischem Niveau untersucht und identifiziert. Polymerase<br />

Kettenreaktionen bilden extrem empfindliche<br />

Diagnosetechniken für epidemische Infektionen, Krebs<br />

oder weiterer Symptome und sind z. B. von der US Food<br />

and Drug Administration als in vitro Tests genehmigt<br />

worden.<br />

Radioimmunoassay ist eine der wichtigsten Komponenten<br />

der in vitro Diagnosetechniken für die Quan tifizierung<br />

von Proteinänderungen oder anderer erkrankungsbedingter<br />

Metabolismusprodukte. Ein Zuwachs des<br />

Weltumsatzes für diese in vitro Diagnosetechniken von<br />

20 Milliarden Dollar im Jahr 1999 auf bis zu 26 Milliarden<br />

Dollar im Jahr 2004 wird prognostiziert und spiegelt die<br />

Bedeutung dieser Diagnosemöglichkeit wieder.<br />

Die Anzahl von Krebserkrankungen, eine der häufigsten<br />

Todesursachen in den Industriestaaten, nimmt auch aufgrund<br />

der steigenden Lebenserwartung in den Ländern<br />

der Dritten Welt ständig zu. Von etwa 10 Millionen neuen<br />

Krebsfällen im Jahr 2000 entfällt jeweils die Hälfte auf<br />

Industriestaaten und auf Entwicklungsländer. Es wird<br />

erwartet, dass 10 Millionen von 15 Millionen neuer<br />

Jahr<br />

1980 1985 1990 1995 2000<br />

Kernenergie 26 10 10 5 5<br />

Gesundheitsvorsorge <strong>11</strong> <strong>11</strong> <strong>11</strong> 16 23<br />

Physik und Chemie 25 25 20 15 10<br />

Hydrologie 2 3 5 6 <strong>11</strong><br />

Landwirtschaft und Ernährung 24 25 22 24 18<br />

Industrie 5 12 12 8 8<br />

Strahlenschutz 6 12 17 24 20<br />

Abfallverarbeitung 1 2 3 2 5<br />

| Tab. 1.<br />

IAEO Unterstützung von Projekten im Rahmen der Technischen Kooperation (Prozent der Gesamtfinanzierung)<br />

| Teletherapie.<br />

Krebsfälle im Jahr 2015 in Ländern der Dritten Welt auftreten<br />

werden. Fünfzig Prozent der Krebspatienten werden<br />

mittels Radiotherapie behandelt, mit einer Überlebenschance<br />

von ungefähr 45%.<br />

Am meisten wird noch Teletherapie verwendet, jetzt<br />

mit Präzisionsbestrahlung von komplexen und unregelmäßigen<br />

Tumor<strong>for</strong>men. Für Brachytherapie mittels<br />

implantierter Strahlungsquellen werden derzeit Caesium-<br />

137 und Iridium-192 anstelle von Radium-226 verwendet.<br />

Die IAEO, zusammen mit der Weltgesundheitsorganisation<br />

(World Health Organisation, WHO), verwaltet<br />

eine Datenbank von Spitälern und Kliniken, in denen<br />

Radio therapie zur Anwendung kommt. Länder der<br />

Dritten Welt mit 85 % der Bevölkerung verfügen über<br />

ein Drittel der Radiotherapieinstallationen, etwa 2200<br />

Teletherapie geräte mit Kobalt-60 Quellen und 850<br />

Brachytherapie geräten allerdings nur einem Fünftel der<br />

Elektronen beschleuniger. Mit jedem Gerät können<br />

600 Patienten pro Jahr behandelt werden oder insgesamt<br />

nur 1,9 Millionen von 2,5 Millionen Patienten in diesen<br />

Ländern. Mehr als 5000 zusätzliche Radiotherapiegeräte<br />

werden daher bis zum Jahr 2015 gebraucht werden. Am<br />

Rande sei erwähnt, dass die IAEO und die WHO jährlich<br />

die ordnungsgemäße Anwendung sowie die eingesetzte<br />

Strahlungsdosis von etwa 600 dieser Geräte in der Dritten<br />

Welt überprüfen.<br />

Nukleare Diagnose- und Forschungtechniken auf Basis<br />

stabiler oder radioaktiver Isotope werden auch zu Maßnahmen<br />

auf dem Ernährungssektor verwendet, insbesondere<br />

zum Nachweisen von Vitamin-, Spuren element- und<br />

Mikronährstoffmangel. Diese sind mit Ursache für Anämie,<br />

Beeinträchtigungen des Sehver mögens, Wachstum und<br />

geistige Entwicklung. Differen tielle Röntgenabsorp tiometrie<br />

wird derzeit auch als nicht intrusive Methode zur<br />

Knochendichtemessungen verwendet.<br />

4 Landwirtschaft<br />

Nukleare Technologien werden in der Landwirtschaft zur<br />

Verbesserung und zum Schutz von Nahrungsmitteln<br />

verwendet sowie zur Optimierung der Viehzucht und<br />

Vorbeugung gegen Seuchen und zur Bekämpfung von<br />

Schädlingen. Biodiversität ist entstanden durch zufällige<br />

Mutationen, induziert durch kosmische und natürliche<br />

Strahlung und auch durch Transkriptionsfehler im Erbgut.<br />

Durch Anwendung von Strahlung kann deshalb die<br />

Mutationsfrequenz erhöht und beschleunigt werden<br />

und man kann in kurzer Zeit eine große Anzahl von<br />

neuen Pflanzenvarianten bilden. Die meisten erzeugten<br />

Mutationen sind nicht weiter lebensfähig oder sogar<br />

schlechter überlebensfähig als die ursprüngliche Pflanze,<br />

aber einige sind unter Umständen besser angepasst und<br />

werden daher weiter gezüchtet. Einige Beispiele werden<br />

551<br />

SPECIAL TOPIC | A JOURNEY THROUGH 50 YEARS AMNT<br />

Special Topic | A Journey Through 50 Years AMNT<br />

Protection of Man and Environment – <strong>Nuclear</strong> Usage Outside of Energy Sector ı P.P. De Regge, Wien


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

552<br />

SPECIAL TOPIC | A JOURNEY THROUGH 50 YEARS AMNT<br />

| Züchtungen von Pflanzen:<br />

Höhere Erträge durch den Einsatz von Bestrahlungen.<br />

hier angegeben, da sie für die betreffenden Länder und<br />

Regionen eine erhebliche Bedeutung in der zukünftigen<br />

Versorgung besitzen. Reissorten, geeignet zum Wachsen<br />

im Wechsel von Salzwasser und Süßwasser der asiatischen<br />

Flussdeltas, dienen als Grundnahrungsmittel von<br />

Millionen Menschen in Pakistan, China und Bangladesh.<br />

Gerstevarianten ohne Hülse, dürretolerantes Sorghum<br />

und Reis werden durch strahlungsinduzierte Mutationen<br />

hergestellt und gezüchtet, weil sie den klimatologischen<br />

und geologischen Bedingungen in Peru oder auch in Mali<br />

besser angepasst sind. Am besten eignen sich strahlungsinduzierte<br />

Mutationen für die Optimierung von Pflanzen,<br />

die sich durch sterile Klonung vermehren, wie Bananen.<br />

Eine früh blühende, herrlich schmeckende und seuchenresistente<br />

Variante Novaria wurde auf diese Art in Malaysia<br />

entwickelt. Seuchenresistente Sorten bringen nicht nur<br />

bessere Ausbeute sondern benötigen auch weniger oder<br />

gar keinen Pestizideinsatz und sind deshalb sowohl billiger<br />

als auch umweltschonender. Bananen und Reis sind die<br />

wichtigsten Grundnahrungsmittel und Landwirtschaftsprodukte<br />

in der Dritten Welt, aber auch in der Industriestaaten<br />

werde fast zweitausend durch strahlungsinduzierte<br />

Mutationen verbesserte Produkte konsumiert.<br />

In Österreich wurde aus Golden Delicious die Variante<br />

„Golden Haidegg” gezüchtet, mit einer schöneren Farbe<br />

und längerer Haltbarkeit ohne Rostflecken. Japanische<br />

Birnen mit strahlungsinduzierter Resistenz gegen<br />

Schwarzfleckenseuche werden derzeit gezüchtet. Dies<br />

reduziert den früher notwendigen Pestizideinsatz auf ein<br />

Viertel.<br />

Nukleare Techniken werden nicht nur zur Verbesserung<br />

der Nahrungsmittel sondern auch zu deren Schutz<br />

und Konservierung verwendet. In 30 Ländern wird<br />

Bestrahlung von Nahrungsmitteln zur Gesundheits- und<br />

| Bestrahlung von Nahrungsmitteln.<br />

Qualitätssicherung genutzt sowie zur Einhaltung der<br />

Quaran täneverordnungen für bestimmte Nahrungsmittel,<br />

wie Fleisch, Früchte, Kräuter und getrocknete Gemüse.<br />

Seit Mitte 2000 wird die Bestrahlung von Hackfleisch in<br />

den Vereinigten Staaten aus mikrobiologischen Sicherheitsgründen<br />

eingesetzt. In mehr als 2000 Supermärkten<br />

werden diese Produkte ohne signifikante Vorbehalte der<br />

Verbraucher angeboten. Viele Länder, insbesondere in<br />

Asien, Lateinamerika, dem Mittler Osten und Afrika<br />

würden enorme Nutzen durch der Anwendung dieser<br />

Technologie zum Schutz der Nahrungsmittel erzielen.<br />

Die weltweit internationale Autorität für die Sicherheit<br />

der Nahrungsmittel, die Kodex Alimentarius Kommission,<br />

hat auch im Bereich der Strahlenbehandlung von Nahrungsmitteln<br />

Protokolle, Richtlinien und Empfehlungen<br />

veröffent licht.<br />

Im Landwirtschaftsbereich findet man auch die Anwendung<br />

von Radioisotopen durch den Radioimmunoassay<br />

bei Tieren für Hormonanalysen von Milch, Serum oder<br />

Plasma. Zweck ist die Optimierung der Planung und<br />

Diagnose von der Trächtigkeit, die frühzeitige Erkennung<br />

von Gesundheits- und Reproduktionsmängeln und die<br />

zeitgerechte Identifikation und Vorbeugung vor Seuchen,<br />

wie Rinderpest, Trypanosomosis, Brucellosis und Maulund-Klauen-Seuche.<br />

Nukleare Technologien und Isotopmarkierungen<br />

mit Stickstoff, Kohlenstoff und Phosphor<br />

finden auch verbreitet Anwendungen zur Untersuchung<br />

von biologischer Stickstofffixierung durch Bakterien, zur<br />

Optimierung der Anwendung von Düngemitteln nach<br />

Menge, Art und Jahreszeit in den verschiedensten Klimazonen,<br />

Bodentypen und Ernährungskulturen sowie zur<br />

Minimierung der ungenutzten Phosphat- und Stickstoffmengen<br />

in der Umwelt.<br />

| Insektensterilisierung: Schädlingsbekämpfung.<br />

Beim Ausrotten von Schädlingen werden Nukleare<br />

Technologien unter der Bezeichnung „Sterile Insekten-<br />

Technik“ verwendet. Diese Technik beinhaltet die<br />

großräumige Produktion und systematische Freisetzung<br />

von strahlungssterilisierten männlichen Fruchtfliegen,<br />

Tsetse-Fliegen, Holzwürmer usw. Freigelassen, verhalten<br />

sie sich auf ganz normale Weise, aber produzieren keinerlei<br />

Nachwuchs. Die schon geschwächte nächste Generation<br />

wird wieder mit neuen sterilen Männchen versorgt,<br />

bis sie lokal gezielt ausgerottet ist, ohne Pestizide, ohne<br />

Umwelt zerstörung und unter Erhalt des biologischen<br />

Gleich gewichtes. Insbesondere die Nachfrage und<br />

Produktionskapazität für sterilisierte Mittelmeerfruchtfliegen,<br />

notorische Schädlinge mit erheblichen Auswirkungen,<br />

sind im Lauf der letzten Dekade von einer auf<br />

drei Milliarden Fliegen pro Woche gestiegen. Am meisten<br />

Erfolg hatten die Ausrottungskampagnen in Mittel- und<br />

Special Topic | A Journey Through 50 Years AMNT<br />

Protection of Man and Environment – <strong>Nuclear</strong> Usage Outside of Energy Sector ı P.P. De Regge, Wien


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

| Insektensterilisierung: Schädlingsbekämpfung.<br />

Lateinamerika, den Südlichen Vereinigten Staaten,<br />

Australien und Japan. Subtile genetisch eingebaute Unterschiede<br />

erlauben die Sterilisierung und Aussortierung der<br />

männlichen Insekten schon im Puppenstadium. Dementsprechend<br />

werden die Zuchtkosten gesenkt und die<br />

Effektivität wird erhöht. Auf diese Weise wird diese Technologie<br />

gleich einem selektiven Insektizid zur kompletten<br />

Ausrottung verwendet. Im Rahmen eines Projektes des<br />

IAEO Programms zur „Technischen Kooperation“ wurde in<br />

Tansania eine Produktionsanlage für Millionen sterilisierte<br />

Tsetse Fliegen errichtet, womit verschiedene afrikanische<br />

Regionen von diesen Schädlingen befreit werden konnten.<br />

Derzeitige Forschungsprojekte in diesem Bereich entwickeln<br />

weitere sterile Insekten-Techniken für Motten und<br />

Würmer. Die IAEO hat ein ehrgeiziges Projekt für die<br />

Ausrottung von Malaria Moskitos gestartet.<br />

Die wirtschaftlichen Erfolge dieser Technologie sind<br />

insgesamt herausragend. Die Bekämpfung von Fruchtfliegen<br />

in Mexiko mit einem Kapitaleinsatz von<br />

10 Millionen Dollar pro Jahr bewirkt einen Ertrag von<br />

einer Milliarde Dollar Wert an Zitrusfrüchten und Gemüse.<br />

Ähnliche Ergebnisse wurden in Chile erzielt, insbesondere<br />

da die Zitrusfrüchte dort während des nördlichen Winters<br />

produziert werden und somit einen maßgeblichen Einfluss<br />

auf den Export haben.<br />

5 Hydrologie<br />

Nukleare und Isotopentechniken werden auch in der<br />

Hydrologie und Klimatologie genutzt, wo sich aufgrund<br />

der natürlich entstandenen Fingerabdrücke der Isotopenzusammensetzung<br />

die Herkunft und das Alter der Wasservorräte<br />

nachweisen lässt. Isotopentechniken, basierend<br />

auf Messungen von stabilen und radioaktiven Wasserkomponenten,<br />

werden zur Modellierung von Wassersystemen<br />

verwendet, um die in vielen Regionen<br />

| Isotopentechniken in der Hydrologie: Wasservorräte erweitern.<br />

beschränkten und kostbaren Wasserressourcen optimal zu<br />

nutzen und ein lokales Gleichgewicht zwischen verbrauchten<br />

und erneuerbaren Wassermengen zu erzielen.<br />

Diese Methoden werden auch zur Identifizierung und zum<br />

Nachweis von unerwünschten Vermischungen der Wasserversorgung<br />

mit Abwässern verwendet, wie es in dichtbesiedelten<br />

Großmetropolen öfter vorkommt. Die<br />

Temperaturabhängigkeit der Wasserisotopenzusammensetzung<br />

beim Verdampfen und Kondensieren wird in<br />

weltweiten Forschungen von Klima- und Treibhauseffekt<br />

genutzt. So ist die Klimageschichte von zehntausenden<br />

Jahren aufgrund der Isotopenanalysen von Gletschereisschichten<br />

oder antarktischen Ablagerungen rekonstruiert<br />

worden.<br />

Beispiele zur Angabe der wirtschaftlichen und humanitären<br />

Bedeutung dieser nuklearen Techniken in der<br />

Hydrologie sind:<br />

p In Venezuela wurde das Trinkwasserdefizit um 30 %<br />

verringert durch Inbetriebnahme von 50 mit Isotopentechniken<br />

georteten Frischwasserquellen.<br />

p Durch Grundwassermessungen im Niltal und in den<br />

ägyptischen und äthiopischen Wüsten wurden erneuerbare<br />

Wasserreserven in Nubischen Sandsteinschichten<br />

geortet womit die Wasserversorgung um 20 % erhöht<br />

werden konnte.<br />

p Ebenfalls in Venezuela wurde aufgrund von Isotopenmessungen<br />

die Zuverlässigkeit eines Stauseedammes<br />

nachgewiesen. Eingeplante Reparaturkosten in<br />

Höhe von 6 Mio. US-Dollar konnten somit eingespart<br />

werden.<br />

p Mit dem Ausbau von geothermischen Energiequellen<br />

werden in Mittelamerika und Südostasien Millionen<br />

Dollar an Ölimporten gespart. Isotopentechniken<br />

dienen dabei zur Suche von geeigneten Standorten und<br />

zur Optimierung der Anlageneinrichtungen.<br />

6 Umweltschutz<br />

Nukleare Technologien und Messtechniken werden weit<br />

verbreitet zur Überwachung und Er<strong>for</strong>schung der Umwelt<br />

eingesetzt. Überhaupt werden künstliche und natürliche<br />

Radioisotope in der Atmosphäre, in der Hydrosphäre und<br />

im Boden für radiologische Zwecke überwacht. Sie sind<br />

zudem ausgezeichnete Indikatoren für atmosphärische<br />

und ozeanografische Transportprozesse, für das Verhalten<br />

und den Transport von nicht radioaktiven Umweltgiften,<br />

für die geochronologische Altersbestimmung und für<br />

ökologische und biologische Forschungszwecke. Einfache<br />

tragbare Röntgenfluoreszenzgeräte mit Radioisotopenquellen,<br />

Forschungsreaktoren für die Neutronenaktivierungsanalyse<br />

und Teilchenbeschleuniger zur<br />

Charakterisierung von mikroskopischen Teilchen <strong>for</strong>men<br />

zusammen ein Arsenal von nuklearen Techniken zum<br />

Identifizieren von schädliche Substanzen in der Umwelt<br />

und zur genauer Identifizierung ihrer Zusammensetzung<br />

und Herkunft.<br />

Nicht nur zur Diagnose von schädlichen Substanzen,<br />

sondern auch zur Vorbeugung oder Eliminierung ihrer<br />

Effekte werden nukleare Technologien verwendet.<br />

Elektronenbeschleuniger werden in Kohlekraftwerken<br />

verschiedener Länder zur Abgasbehandlung eingesetzt.<br />

Schwefel- und Stickstoffoxiden werden im Rauchgas<br />

umgewandelt und mit zugefügtem Ammoniak zu Düngemittel<br />

umgesetzt. Abwässer, organisch verseuchtes Wasser<br />

und Klärschlamm werden mit ionisierender Strahlung<br />

behandelt und desinfiziert.<br />

Zur Umweltsanierung gehört auch die Ortung und<br />

Entfernung von rund 60 Millionen Landminen, die in<br />

553<br />

SPECIAL TOPIC | A JOURNEY THROUGH 50 YEARS AMNT<br />

Special Topic | A Journey Through 50 Years AMNT<br />

Protection of Man and Environment – <strong>Nuclear</strong> Usage Outside of Energy Sector ı P.P. De Regge, Wien


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

554<br />

SPECIAL TOPIC | A JOURNEY THROUGH 50 YEARS AMNT<br />

| Lokalisierung von Landminen.<br />

62 Ländern Jahr für Jahr Ursache für Tausende Tote und<br />

Verletzte sind. Nukleare Technologien werden auch für<br />

diese Anwendungen entwickelt. Derzeit verfügbare Geräte<br />

benutzen Neutronengeneratoren und Gammadetektoren<br />

zur Auswertung von Elementverhältnissen, insbesondere<br />

Wasserstoff, Stickstoff, Kohlenstoff und Sauerstoff, in<br />

minenverdächtigen Gegenständen im Boden.<br />

7 Industrie und Archäologie<br />

Unzählige Anwendungen von nuklearen Technologien,<br />

ionisierender Strahlung und Isotopen werden auch in<br />

allgemeinen Bereichen der Industrie genutzt, so in<br />

Transport- und Bauunternehmen für radiografische<br />

Materialkontrolle, in der Polymerverarbeitung (z. B.<br />

Autoreifen), für die Sterilisierung sowie das Vernichten<br />

von Viren, Bakterien und Pilzen im medizinischen<br />

Bereich.<br />

Minuten quadratmillimeter kleine Einzelheiten von<br />

Gemälden, Skulpturen, Polychromen, Münzen oder<br />

Keramiken zu charakterisieren und auszuwerten. Ein<br />

Prototyp kam im Kunsthistorischen Museum in Wien für<br />

die Identifizierung von Gemälden des 16ten Jahrhunderts<br />

und zur Katalogisierung von Etruskischen Bronzen und<br />

Münzen zum Einsatz.<br />

8 Zusammenfassung<br />

Nukleare Technologien, Isotopentechniken und Strahlungsanwendungen<br />

sind weit verbreitete Anwendungen<br />

und liefern unersetzbare Beiträge zur Verbesserung und<br />

Erhaltung des heutigen Lebensstandards sowie zum<br />

Schutz des Menschen und seiner Umwelt. Das Ausmaß<br />

dieser Anwendungen für diagnostische und thera peutische<br />

Zwecke im Gesundheitsbereich wurde dargestellt und<br />

Erfolge und Erwartungen der Entwicklungen von<br />

Computertomografie und molekularer Nuklearmedizin<br />

wurden erwähnt. Im therapeutischen Bereich ist ohne<br />

Zweifel eine Erweiterung der Anwendungen zu erwarten,<br />

inbesondere in der Dritten Welt. Anwendungen in der<br />

Landwirtschaft, der Nahrungsversorgung und dem Schutz<br />

der Nahrung, wie Pflanzenoptimierung, Ausrottung von<br />

Schädlingen, Vorbeugung vor Seuchen und Konservierung<br />

von Nahrungsmittel sind vollständig ausgereift und<br />

werden akzeptiert. Bei komplexeren Problemen kommen<br />

ebenfalls erfolgreiche Maßnahmen zum Einsatz, wie<br />

im Zusammenhang mit der Bekämpfung von Malaria,<br />

Trypanosomosis und Myasis. Anwendungen in der Hydrologie<br />

und im Umweltschutz sind seit Jahren etabliert und<br />

anerkannt. Im Bereich der Klimatologie und in der meeresoder<br />

landesbezogenen Ökologie werden sie erweitert<br />

genutzt. Nukleare Techniken und Technologien in den<br />

hier beschriebenen Anwendungsbereichen werden nicht<br />

aus reinem Interesse an der Sache oder aufgrund<br />

popukärer Überlegungen eingesetzt, oder weil besondere<br />

Förderungen zu erwarten wären, sondern weil sie nach<br />

vergleichender Begutachtung und Kosten-Nutzen-Analyse<br />

optimalere Ergebnisse versprechen als vergleichbare<br />

verfügbare Technologien.<br />

Literatur<br />

1. Annual Report 2000. <strong>International</strong> Atomic Energy Agency, Vienna, 2001<br />

2. <strong>Nuclear</strong> Technology Review 2002. Document GOV/2002/7, <strong>International</strong> Atomic Energy Agency,<br />

Vienna, February 2002<br />

3. The <strong>International</strong> Atomic Energy Agency‘s Laboratories, Meeting the Challenges of Research and<br />

<strong>International</strong> Cooperation in the Application of <strong>Nuclear</strong> Techniques. Document IAEA/PI/A67E<br />

99-02059, August 1999<br />

| Kulturelles Erbe: Analysen zur Bestätigung der Herkunft.<br />

Interessant und vielleicht weniger bekannt ist die<br />

Anwendung von zerstörungsfreien nuklearen Technologien<br />

und Messmethoden im Bereich der Archäologie und<br />

der Konservierung des Kulturellen Erbes. Vor kurzer Zeit<br />

hat die IAEO ein Projekt in Lateinamerika zur Förderung<br />

von interdisziplinärer Forschung und Unterstützung in<br />

diesem Bereich koordiniert. Jedes teilnehmende Land<br />

hat sich mit bestimmten ungelösten Fragen bezüglich<br />

Keramiken befasst und mittels Spurenanalyse durch<br />

Röntgenfluoreszenz- und Neutronenaktivierung das<br />

erwünschte Ergebnis endgültig erhalten.<br />

In Zusammenarbeit mit polnischen, kubanischen und<br />

österreichischen Wissenschaftlern hat die IAEO ein tragbares<br />

Röntgenfluoreszenzgerät entwickelt, das ideal für<br />

die zerstörungsfreie Analyse von Kunstgegenstände<br />

eingesetzt werden kann. Es ist mit Computer- und Lasersteuerung<br />

ausgestattet und in der Lage, innerhalb von<br />

Verfasser<br />

Peter P. De Regge<br />

Head, PCI Laboratorien,<br />

<strong>International</strong>e Atomenergie Organisation (IAEO),<br />

Wagramer Straße 5, 1400 Wien, Austria<br />

Special Topic | A Journey Through 50 Years AMNT<br />

Protection of Man and Environment – <strong>Nuclear</strong> Usage Outside of Energy Sector ı P.P. De Regge, Wien


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

Inside<br />

Women in <strong>Nuclear</strong> bei Framatome/ANF in Karlstein<br />

Die deutsche Sektion des international agierenden Frauennetzwerks<br />

WiN (Women in <strong>Nuclear</strong>) traf sich am 10. und<br />

<strong>11</strong>. Oktober 2019 bei Framatome in Karlstein. Nach der<br />

Mitgliederversammlung von WiN Germany wurde das<br />

Treffen mit Teilnehmerinnen aus Schweden, Finnland und<br />

der Schweiz international.<br />

Unter dem Dach des gemeinnützigen Vereins Women in<br />

<strong>Nuclear</strong> (WiN) Germany – gegründet 2008 – möchten<br />

Frauen, die auf den Gebieten Kernenergie, Strahlenschutz,<br />

Nuklearmedizin und nukleare Wissenschaften arbeiten,<br />

dazu beitragen, einen transparenten Dialog über die Notwendigkeit<br />

der nuklearen Kompetenzen für Deutschland<br />

zu führen.<br />

Chantal Greul, Präsidentin von WiN Germany, erklärt:<br />

„Auch wenn sich unser Land mehrheitlich für den Ausstieg<br />

aus der Stromerzeugung durch Kerntechnik entschieden<br />

hat, bleiben das Know-how und das hohe Sicherheitsverständnis<br />

Deutschlands nach dem Ausstieg 2022<br />

wichtig: für den Rückbau, die Endlagerung – und nicht<br />

zuletzt als Beitrag zum Erhalt des höchstmöglichen Sicherheitsniveaus<br />

weltweit. Wir ermutigen junge Frauen, eine<br />

berufliche Laufbahn in der Nukleartechnik zu wählen.<br />

Denn nur durch gut ausgebildete Nachwuchskräfte bleiben<br />

die notwendigen Ressourcen in Deutschland langfristig<br />

gesichert.“<br />

| Im Foyer der Framatome GmbH in Karlstein mit den Standortleitern<br />

Stefan Rosenberger der Framatome GmbH (links) und Matthias Gutjahr<br />

der Advanced <strong>Nuclear</strong> Fuels GmbH (Mitte).<br />

| v.l. Chantal Greul, WiN Germany Präsidentin,<br />

Preisträgerin Jenny Jessat, Martina Ezmuß,<br />

Vorstand WiN Germany.<br />

Einen wichtigen Beitrag zu diesem Vereinsziel leistet<br />

die jährliche Verleihung des WiN-Germany Preises. Für<br />

diesen mit 500 Euro dotierten Preis gab es in diesem Jahr<br />

gleich fünf Bewerberinnen. Beiträge aus Wissenschaft und<br />

Forschung sowie aus Unternehmen ließen eine hohe<br />

fachliche Kompetenz erkennen, die die Entscheidung für<br />

eine Bewerberin schwer fallen ließ. Jenny Jessat überzeugte<br />

den Kreis mit dem Thema „Studies on the interaction<br />

of plant cells with uranium (VI) and europium (III)<br />

an on stress-induced metabolite release” („Studien zur<br />

Wechselwirkung von Pflanzenzellen mit Uran (VI) und<br />

Europium (III) und zur stressinduzierten Metabolitfreisetzung“).<br />

Es handelte sich um die Präsentation<br />

ihrer Masterarbeit in Chemie an der TU Dresden. Jenny<br />

Jessat ist derzeit wissenschaftliche Mitarbeiterin am<br />

Helmholtz-Zentrum Dresden-Rossendorf, Institut für<br />

Ressourcenökologie und bereitet dort ihre Promotion vor.<br />

Neben weiteren Fachvorträgen über kerntechnische<br />

Themen fanden die Werksführungen sehr viel Anklang bei<br />

den Teilnehmerinnen. „Wir möchten uns herzlich bei den<br />

beiden Standortleitern der Framatome GmbH und ANF<br />

bedanken. Insbesondere die Standortbesuche waren ein<br />

wirkliches Highlight und die Teilnehmerinnen waren<br />

damit sehr zufrieden“, lobte Chantal Greul den Einsatz der<br />

Framatome für die Veranstaltung.“<br />

| Aus der Komponentenfertigung der ANF<br />

Karlstein stellte Petra Denner die<br />

Entwicklungs historie des neuen GAIA<br />

Abstandhalters vor und zeigte an diesem<br />

Beispiel auf, wie die hohen Qualitätsan<strong>for</strong>derungen<br />

der Kunden erfüllt werden.<br />

Karin Reiche<br />

WiN<br />

KTG Inside<br />

Verantwortlich<br />

für den Inhalt:<br />

Die Autoren.<br />

Lektorat:<br />

Natalija Cobanov,<br />

Kerntechnische<br />

Gesellschaft e. V.<br />

(KTG)<br />

Robert-Koch-Platz 4<br />

10<strong>11</strong>5 Berlin<br />

T: +49 30 498555-50<br />

F: +49 30 498555-51<br />

E-Mail:<br />

natalija.cobanov@<br />

ktg.org<br />

555<br />

KTG INSIDE<br />

Herzlichen Glückwunsch!<br />

www.ktg.org<br />

Die KTG gratuliert ihren Mitgliedern sehr herzlich zum Geburtstag<br />

und wünscht ihnen weiterhin alles Gute!<br />

Dezember 2019<br />

50 Jahre | 1969<br />

13. Bernd Gulich, Tiefenbach-Ast<br />

55 Jahre | 1964<br />

30. Thomas Schmidt, Lörrach<br />

60 Jahre | 1959<br />

15. Axel Lenzen, Titz<br />

20. Martin Schlieck-Weber, Hausen<br />

65 Jahre | 1954<br />

24. Reinhold Paul, Hanau<br />

70 Jahre | 1949<br />

2. Dipl.-Ing. Berndt Standfuß, Dresden<br />

28. Fritz Grimm, Alzenau<br />

76 Jahre | 1943<br />

8. Dr. Dieter Herrmann, Brandis<br />

77 Jahre | 1942<br />

8. Karl Georg Weber, Neckarwestheim<br />

14. Günter Breiling, Weinheim<br />

78 Jahre | 1941<br />

13. Dipl.-Ing. Klaus-Dieter Hnilica,<br />

Rodenbach/Hanau<br />

Wenn Sie künftig eine<br />

Erwähnung Ihres<br />

Geburtstages in der<br />

<strong>atw</strong> wünschen, teilen<br />

Sie dies bitte der KTG-<br />

Geschäftsstelle mit.<br />

KTG Inside


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

556<br />

79 Jahre | 1940<br />

8. Dipl.-Ing. Wolfgang Heess, Laudenbach<br />

21. Dr. Jürgen Wehmeier, Springe<br />

94 Jahre | 1925<br />

10. Dr. Arthur Pilgenröther, Kleinostheim<br />

83 Jahre | 1937<br />

9. Dipl.-Ing. Werner Rossbach,<br />

Bergisch Gladbach<br />

NEWS<br />

79 Jahre | 1940<br />

16. Dipl.-Ing. Wolfgang Breyer, Buckenhof<br />

19 Prof. Dr. Wernt Brewitz, Wolfenbüttel<br />

80 Jahre |1939<br />

1. Dipl.-Ing. Georg Dumsky, Gräfelfing<br />

6. Dipl.-Ing. Hans-Henn. Kuchenbuch,<br />

Laboe-Brodersdorf<br />

27 Dr. Horst Bauer, Sigless/AT<br />

81 Jahre | 1938<br />

1. Dr. Gert Spannagel,<br />

Linkenheim-Hochstetten<br />

82 Jahre | 1937<br />

30. Dipl.-Ing. Wilhelm Weiss, Weinheim<br />

83 Jahre | 1936<br />

7. Dipl.-Ing. Aurel Badics, Bad Kreuznach<br />

17. Prof. Dr.-Ing. Rolf Theenhaus, Linnich<br />

86 Jahre | 1933<br />

10. Prof. Dr. Jürgen Vollradt,<br />

Unna-Königsborn<br />

Januar 2020<br />

55 Jahre | 1965<br />

31. Eckhard Stengert, Worms<br />

60 Jahre | 1960<br />

26. Dr. Friedhelm Funke, Dormitz<br />

70 Jahre | 1950<br />

15. Dipl.-Ing. Andreas Hüttmann, Oering<br />

78 Jahre | 1942<br />

31. Dipl.-Phys. Werner Scholtyssek,<br />

Stutensee<br />

79 Jahre | 1941<br />

15. Dipl.-Ing. Ulf Rösser,<br />

Heiligkreuzsteinach<br />

81 Jahre | 1939<br />

16. Dr. Wolfgang Kersting, Blieskastel<br />

82 Jahre | 1938<br />

7. Dipl.-Ing. Manfred Schirra, Stutensee<br />

12. Dipl.-Ing. Hans Dieter Adami, Rösrath<br />

22. Dr. Franz Müller, Erlangen<br />

84 Jahre | 1936<br />

5. Obering. Peter Vetterlein, Oberursel<br />

23. Prof. Dr. Hartmut Schmoock,<br />

Norderstedt<br />

30. Dipl.-Phys. Wolfgang Borkowetz,<br />

Rüsselsheim<br />

30. Dipl.-Ing. Friedrich Morgenstern, Essen<br />

85 Jahre |1935<br />

10. Dipl.-Ing. Walter Diefenbacher,<br />

Karlsruhe<br />

17. Dipl.-Ing. Helge Dyroff, Alzenau<br />

24. Theodor Himmel, Bad Honnef<br />

87 Jahre |1933<br />

9. Prof. Dr. Hellmut Wagner, Karlsruhe<br />

88 Jahre | 1932<br />

3. Dipl.-Ing. Fritz Kohlhaas, Kahl/Main<br />

91 Jahre | 1929<br />

20. Dr. Devana Lavrencic-Cannata, Rom/I<br />

93 Jahre | 1927<br />

1. Prof. Dr. Werner Oldekop,<br />

Braunschweig<br />

Top<br />

World Energy Outlook 2019<br />

highlights deep disparities in<br />

the global energy system<br />

(iea) Deep disparities define today’s<br />

energy world. The dissonance<br />

between well-supplied oil markets<br />

and growing geopolitical tensions and<br />

uncertainties. The gap between the<br />

ever-higher amounts of greenhouse<br />

gas emissions being produced and the<br />

insufficiency of stated policies to<br />

curb those emissions in line with<br />

international climate targets. The gap<br />

between the promise of energy <strong>for</strong><br />

all and the lack of electricity access<br />

<strong>for</strong> 850 million people around the<br />

world.<br />

The World Energy Outlook 2019,<br />

the <strong>International</strong> Energy Agency’s<br />

flagship publication, explores these<br />

widening fractures in detail. It explains<br />

the impact of today’s decisions<br />

on tomorrow’s energy systems, and<br />

describes a pathway that enables the<br />

world to meet climate, energy access<br />

and air quality goals while maintaining<br />

a strong focus on the reliability<br />

and af<strong>for</strong>dability of energy <strong>for</strong> a<br />

growing global population.<br />

As ever, decisions made by<br />

governments remain critical <strong>for</strong> the<br />

future of the energy system. This is<br />

evident in the divergences between<br />

WEO scenarios that map out different<br />

routes the world could follow over the<br />

coming decades, depending on the<br />

policies, investments, technologies<br />

and other choices that decision<br />

makers pursue today. Together, these<br />

scenarios seek to address a fun damental<br />

issue – how to get from where<br />

we are now to where we want to go.<br />

The path the world is on right now<br />

is shown by the Current Policies<br />

Scenario, which provides a baseline<br />

picture of how global energy systems<br />

would evolve if governments make no<br />

changes to their existing policies. In<br />

this scenario, energy demand rises by<br />

1.3 % a year to 2040, resulting in<br />

strains across all aspects of energy<br />

markets and a continued strong<br />

upward march in energy-related<br />

emissions.<br />

The Stated Policies Scenario,<br />

<strong>for</strong>merly known as the New Policies<br />

Scenario, incorporates today’s policy<br />

intentions and targets in addition to<br />

existing measures. The aim is to hold<br />

up a mirror to today’s plans and<br />

illustrate their consequences. The<br />

future outlined in this scenario is still<br />

well off track from the aim of a secure<br />

and sustainable energy future. It<br />

describes a world in 2040 where<br />

hundreds of millions of people still go<br />

without access to electricity, where<br />

pollution-related premature deaths<br />

remain around today’s elevated levels,<br />

and where CO 2 emissions would<br />

lock in severe impacts from climate<br />

change.<br />

The Sustainable Development<br />

Scenario indicates what needs to be<br />

done differently to fully achieve<br />

climate and other energy goals<br />

that policy makers around the world<br />

have set themselves. Achieving this<br />

scenario – a path fully aligned with<br />

the Paris Agreement aim of holding<br />

the rise in global temperatures to well<br />

below 2° C and pursuing ef<strong>for</strong>ts to<br />

limit it to 1.5° C – requires rapid and<br />

widespread changes across all parts of<br />

the energy system. Sharp emission<br />

cuts are achieved thanks to multiple<br />

fuels and technologies providing<br />

efficient and cost-effective energy<br />

services <strong>for</strong> all.<br />

“What comes through with crystal<br />

clarity in this year’s World Energy<br />

News


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

Outlook is there is no single or simple<br />

solution to trans<strong>for</strong>ming global energy<br />

systems,” said Dr Fatih Birol, the IEA’s<br />

Executive Director. “Many technologies<br />

and fuels have a part to play<br />

across all sectors of the economy. For<br />

this to happen, we need strong leadership<br />

from policy makers, as governments<br />

hold the clearest responsibility<br />

to act and have the greatest scope to<br />

shape the future.”<br />

In the Stated Policies Scenario,<br />

energy demand increases by 1% per<br />

year to 2040. Low-carbon sources, led<br />

by solar PV, supply more than half of<br />

this growth, and natural gas accounts<br />

<strong>for</strong> another third. Oil demand flattens<br />

out in the 2030s, and coal use edges<br />

lower. Some parts of the energy sector,<br />

led by electricity, undergo rapid<br />

trans<strong>for</strong>mations. Some countries,<br />

notably those with “net zero”<br />

aspirations, go far in reshaping all<br />

aspects of their supply and consumption.<br />

However, the momentum behind<br />

clean energy is insufficient to offset<br />

the effects of an expanding global<br />

economy and growing population.<br />

The rise in emissions slows but does<br />

not peak be<strong>for</strong>e 2040.<br />

Shale output from the United<br />

States is set to stay higher <strong>for</strong> longer<br />

than previously projected, reshaping<br />

global markets, trade flows and<br />

security. In the Stated Policies<br />

Scenario, annual US production<br />

growth slows from the breakneck<br />

pace seen in recent years, but the<br />

United States still accounts <strong>for</strong> 85 % of<br />

the increase in global oil production to<br />

2030, and <strong>for</strong> 30 % of the increase in<br />

gas. By 2025, total US shale output<br />

(oil and gas) overtakes total oil and<br />

gas production from Russia.<br />

“The shale revolution highlights<br />

that rapid change in the energy<br />

system is possible when an initial push<br />

to develop new technologies is<br />

complemented by strong market<br />

incentives and large-scale investment,”<br />

said Dr Birol. “The effects<br />

have been striking, with US shale now<br />

acting as a strong counterweight to<br />

ef<strong>for</strong>ts to manage oil markets.”<br />

The higher US output pushes down<br />

the share of OPEC members and<br />

Russia in total oil production, which<br />

drops to 47 % in 2030, from 55 % in<br />

the mid-2000s. But whichever pathway<br />

the energy system follows, the<br />

world is set to rely heavily on oil supply<br />

from the Middle East <strong>for</strong> years to<br />

come.<br />

Alongside the immense task of<br />

putting emissions on a sustainable<br />

trajectory, energy security remains<br />

paramount <strong>for</strong> governments around<br />

the globe. Traditional risks have not<br />

gone away, and new hazards such as<br />

cybersecurity and extreme weather<br />

require constant vigilance. Meanwhile,<br />

the continued trans<strong>for</strong>mation<br />

of the electricity sector requires policy<br />

makers to move fast to keep pace with<br />

technological change and the rising<br />

need <strong>for</strong> the flexible operation of<br />

power systems.<br />

“The world urgently needs to put a<br />

laser-like focus on bringing down<br />

global emissions. This calls <strong>for</strong> a grand<br />

coalition encompassing governments,<br />

investors, companies and everyone<br />

else who is committed to tackling<br />

climate change,” said Dr Birol. “Our<br />

Sustainable Development Scenario<br />

is tailor-made to help guide the<br />

members of such a coalition in their<br />

ef<strong>for</strong>ts to address the massive climate<br />

challenge that faces us all.”<br />

A sharp pick-up in energy efficiency<br />

improvements is the element that<br />

does the most to bring the world<br />

towards the Sustainable Development<br />

Scenario. Right now, efficiency<br />

improvements are slowing: the 1.2 %<br />

rate in 2018 is around half the average<br />

seen since 2010 and remains far below<br />

the 3 % rate that would be needed.<br />

Electricity is one of the few energy<br />

sources that sees rising consumption<br />

over the next two decades in the<br />

Sustainable Development Scenario.<br />

Electricity’s share of final consumption<br />

overtakes that of oil, today’s<br />

leader, by 2040. Wind and solar PV<br />

provide almost all the increase in<br />

electricity generation.<br />

Putting electricity systems on a<br />

sustainable path will require more<br />

than just adding more renewables.<br />

The world also needs to focus on<br />

the emissions that are “locked in”<br />

to existing systems. Over the past<br />

20 years, Asia has accounted <strong>for</strong><br />

90 % of all coal-fired capacity built<br />

worldwide, and these plants potentially<br />

have long operational lifetimes<br />

ahead of them. This year’s WEO considers<br />

three options to bring down<br />

emissions from the existing global<br />

coal fleet: to retrofit plants with carbon<br />

capture, utilisation and storage or<br />

biomass co-firing equipment; to<br />

repurpose them to focus on providing<br />

system adequacy and flexibility; or to<br />

retire them earlier.<br />

| www.iea.org<br />

New report and webinar<br />

on the supply of medical<br />

radioisotopes<br />

(nea) The NEA hosted a webinar on<br />

18 November 2019 to present findings<br />

from a new report on the supply of<br />

medical radioisotopes, jointly produced<br />

with the Organisation <strong>for</strong><br />

Economic Co-operation and Development<br />

(OECD) Health Committee.<br />

Technetium-99m (Tc-99m) is the<br />

most commonly used medical<br />

radioisotope, essential <strong>for</strong> 85 % of the<br />

nuclear medicine diagnostic scans<br />

per<strong>for</strong>med worldwide. There are no<br />

comparable substitutes available <strong>for</strong><br />

diagnoses of various cancers and <strong>for</strong> a<br />

range of diagnostics in children.<br />

Un<strong>for</strong>tunately, the global supply of<br />

Tc-99m is not technically and economically<br />

robust, and the existing<br />

supply-chain continues to experience<br />

chronic shortages. This new study<br />

analyses the current market structure<br />

and identifies barriers <strong>for</strong> the implementation<br />

of full cost recovery.<br />

Report and the webinar recording<br />

are available at: <br />

oe.cd/nea-med-rad-webinar-2019.<br />

| www.oecd-nea.org<br />

World <strong>Nuclear</strong> Per<strong>for</strong>mance<br />

Report 2019 Asia Edition<br />

launched<br />

(wna) The World <strong>Nuclear</strong> Per<strong>for</strong>mance<br />

Report 2019 Asia Edition shows<br />

that nuclear energy in Asia is meeting<br />

the growing demand <strong>for</strong> electricity,<br />

whilst helping to tackle<br />

air pollution and climate change. The<br />

report, published by World <strong>Nuclear</strong> Association,<br />

was launched today at Singapore<br />

<strong>International</strong> Energy<br />

Week.<strong>Nuclear</strong> generation in Asia<br />

continued its rapid growth in 2018, increasing<br />

by 12 %. By replacing<br />

coal-fired generation nuclear energy<br />

avoided the emission of over<br />

500 million tonnes of carbon dioxide<br />

last year.Agneta Rising, Director<br />

General of World <strong>Nuclear</strong> Association<br />

said, “<strong>Nuclear</strong> is fast, scalable and a<br />

long-lasting way to add clean<br />

557<br />

NEWS<br />

News


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

Operating Results July 2019<br />

558<br />

NEWS<br />

Plant name Country Nominal<br />

capacity<br />

Type<br />

gross<br />

[MW]<br />

net<br />

[MW]<br />

Operating<br />

time<br />

generator<br />

[h]<br />

Energy generated, gross<br />

[MWh]<br />

Month Year Since<br />

commissioning<br />

Time availability<br />

[%]<br />

Energy availability<br />

[%] *) Energy utilisation<br />

[%] *)<br />

Month Year Month Year Month Year<br />

OL1 Olkiluoto 1) BWR FI 910 880 744 681 827 4 427 294 266 082 502 100.00 95.66 100.00 94.49 99.61 94.60<br />

OL2 Olkiluoto BWR FI 910 880 744 678 000 4 090 942 255 987 484 100.00 88.26 99.94 87.58 99.05 87.41<br />

KCB Borssele 3) PWR NL 512 484 662 326 759 4 445 853 166 167 541 88.61 80.62 88.66 80.51 85.71 76.95<br />

KKB 1 Beznau 7) PWR CH 380 365 744 265 244 1 583 283 128 917 393 100.00 82.35 100.00 82.10 93.63 81.77<br />

KKB 2 Beznau 7) PWR CH 380 365 744 266 954 1 925 0<strong>11</strong> 136 275 418 100.00 100.00 100.00 100.00 94.22 99.56<br />

KKG Gösgen 3,7) PWR CH 1060 1010 6<strong>11</strong> 634 890 4 627 036 318 502 564 82.06 86.72 82.03 86.04 80.50 85.81<br />

KKM Mühleberg BWR CH 390 373 744 274 120 1 942 150 129 346 465 100.00 100.00 99.89 99.73 94.47 97.89<br />

CNT-I Trillo PWR ES 1066 1003 744 784 619 4 605 674 251 897 342 100.00 86.01 100.00 85.50 98.03 84.41<br />

Dukovany B1 PWR CZ 500 473 744 363 425 2 485 594 <strong>11</strong>4 715 087 100.00 99.86 99.31 99.61 97.70 97.72<br />

Dukovany B2 1,2) PWR CZ 500 473 0 0 1 610 472 109 844 643 0 65.17 0 64.65 0 63.32<br />

Dukovany B3 PWR CZ 500 473 744 357 397 1 966 445 108 464 485 100.00 79.26 100.00 78.81 96.07 77.31<br />

Dukovany B4 PWR CZ 500 473 744 365 370 2 533 257 108 976 525 100.00 100.00 100.00 99.92 98.22 99.60<br />

Temelin B1 PWR CZ 1080 1030 744 798 674 3 926 675 <strong>11</strong>8 287 717 100.00 72.28 99.96 71.97 99.21 71.34<br />

Temelin B2 1,2) PWR CZ 1080 1030 0 0 4 477 198 <strong>11</strong>3 749 715 0 80.87 0 80.81 0 81.34<br />

Doel 1 PWR BE 454 433 744 340 008 1 582 284 137 026 746 100.00 67.09 99.98 66.66 97.84 67.15<br />

Doel 2 PWR BE 454 433 744 334 234 1 915 142 135 717 081 100.00 83.89 99.29 82.19 98.53 82.55<br />

Doel 3 2) PWR BE 1056 1006 181 144 566 4 063 502 259 195 987 24.37 75.48 20.70 74.72 18.01 75.13<br />

Doel 4 PWR BE 1084 1033 744 778 346 5 427 730 265 801 140 100.00 100.00 99.94 97.96 94.76 96.96<br />

Tihange 1 PWR BE 1009 962 744 725 978 5 120 495 303 951 352 100.00 100.00 99.99 99.99 96.68 99.91<br />

Tihange 2 2) PWR BE 1055 1008 693 659 639 659 639 255 3<strong>11</strong> 569 93.13 13.62 87.24 12.76 84.43 12.35<br />

Tihange 3 PWR BE 1089 1038 744 780 007 5 404 413 276 631 686 100.00 99.96 100.00 99.02 96.67 98.05<br />

Plant name<br />

Type<br />

Nominal<br />

capacity<br />

gross<br />

[MW]<br />

net<br />

[MW]<br />

Operating<br />

time<br />

generator<br />

[h]<br />

Energy generated, gross<br />

[MWh]<br />

Time availability<br />

[%]<br />

Energy availability<br />

[%] *) Energy utilisation<br />

[%] *)<br />

Month Year Since Month Year Month Year Month Year<br />

commissioning<br />

KBR Brokdorf 1,2) DWR 1480 1410 544 722 179 5 437 455 356 005 265 73.08 81.<strong>11</strong> 67.73 76.05 65.25 71.95<br />

KKE Emsland DWR 1406 1335 744 1 033 507 5 701 515 352 520 484 100.00 81.41 100.00 81.27 98.81 79.71<br />

KWG Grohnde DWR 1430 1360 744 1 000 783 5 717 420 383 291 634 100.00 82.88 99.55 82.50 93.39 78.10<br />

KRB C Gundremmingen SWR 1344 1288 744 983 969 5 481 876 336 423 631 100.00 81.32 100.00 80.60 97.93 79.74<br />

KKI-2 Isar 1,2) DWR 1485 1410 389 518 222 6 788 871 360 514 684 52.28 93.02 50.22 92.71 46.55 89.53<br />

GKN-II Neckarwestheim 4) DWR 1400 1310 744 910 310 6 858 810 336 685 644 100.00 100.00 100.00 99.88 86.99 96.47<br />

KKP-2 Philippsburg 1,2) DWR 1468 1402 448 580 690 6 339 374 372 500 529 60.22 88.81 59.74 88.52 52.23 83.60<br />

*)<br />

Net-based values<br />

(Czech and Swiss<br />

nuclear power<br />

plants gross-based)<br />

1)<br />

Refueling<br />

2)<br />

Inspection<br />

3)<br />

Repair<br />

4)<br />

Stretch-out-operation<br />

5)<br />

Stretch-in-operation<br />

6)<br />

Hereof traction supply<br />

7)<br />

Incl. steam supply<br />

8)<br />

New nominal<br />

capacity since<br />

January 2016<br />

9)<br />

Data <strong>for</strong> the Leibstadt<br />

(CH) NPP will<br />

be published in a<br />

further issue of <strong>atw</strong><br />

BWR: Boiling<br />

Water Reactor<br />

PWR: Pressurised<br />

Water Reactor<br />

Source: VGB<br />

elec tricity generation.“For the 90<br />

reactors that have started operating<br />

from 2000 to today, the typical construction<br />

time is 5 to 7 years. Of those<br />

90 reactors, 27 % were built in less<br />

than five years – and they will provide<br />

clean and reliable electricity <strong>for</strong> more<br />

than 60 years or more.”Many reactors<br />

in operation today are planned to<br />

operate <strong>for</strong> 60-80 years. Reactors are<br />

already demonstrating high per<strong>for</strong>mance<br />

irrespective of how long<br />

they have been in operation, with<br />

capacity factors of around 80 %<br />

maintained egardless of age.The<br />

report profiles Tarapur 1, a reactor<br />

located in Palghar, India, which<br />

marked 50 years of operation in<br />

April 2019. Four other reactors will<br />

match this achievement in 2019,<br />

the first year in which reactors have<br />

passed this milestone. Worldwide<br />

nuclear generation in 2018 increased<br />

<strong>for</strong> the sixth successive year, reaching<br />

2563 TWh. This is more than<br />

10 % of global electricity demand.<br />

Overall, capacity additions <strong>for</strong> the<br />

period 2016-2020 are expected to<br />

reach the targets of the nuclear<br />

industry’s Harmony programme.<br />

But build rates will have to increase<br />

significantly to achieve the overall goal<br />

of supplying 25 % of global electricity<br />

demand be<strong>for</strong>e 2050. Agneta Rising<br />

said, “<strong>Nuclear</strong> energy is key to Asia<br />

meeting the twin challenges of a growing<br />

demand <strong>for</strong> electricity, and an<br />

urgent need to switch to less polluting,<br />

low-carbon generation sources. More<br />

and more organizations are recognizing<br />

that nuclear energy is vital to the<br />

goal of a sustainable future <strong>for</strong> people<br />

and the planet.”<br />

| www.world-nuclear.org<br />

World Science Day:<br />

<strong>International</strong> <strong>Nuclear</strong><br />

In<strong>for</strong>mation System<br />

highlights open access<br />

(iaea) Public awareness of developments<br />

in scientific research is crucial<br />

<strong>for</strong> building a more in<strong>for</strong>med global<br />

society, and the IAEA is providing<br />

access to a trove of research on the<br />

peaceful uses of nuclear science and<br />

technology.<br />

The IAEA’s <strong>International</strong> <strong>Nuclear</strong><br />

In<strong>for</strong>mation System (INIS) is one of the<br />

world’s largest repositories of published<br />

research on the peaceful uses of nuclear<br />

science and technology, with more<br />

than 4.2 million bibliographic records<br />

and access to more than 1.6 million<br />

full-text documents. Each year, more<br />

than 1 million unique users per<strong>for</strong>m<br />

around 2 million searches and download<br />

3 million pages.<br />

News


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

Operating Results August 2019<br />

Plant name Country Nominal<br />

capacity<br />

Type<br />

gross<br />

[MW]<br />

net<br />

[MW]<br />

Operating<br />

time<br />

generator<br />

[h]<br />

Energy generated, gross<br />

[MWh]<br />

Month Year Since<br />

commissioning<br />

Time availability<br />

[%]<br />

Energy availability<br />

[%] *) Energy utilisation<br />

[%] *)<br />

Month Year Month Year Month Year<br />

OL1 Olkiluoto 1) BWR FI 910 880 744 680 095 5 107 389 266 762 596 100.00 96.22 99.94 95.18 99.36 95.21<br />

OL2 Olkiluoto BWR FI 910 880 744 678 578 4 769 520 256 666 062 100.00 89.76 100.00 89.16 99.14 88.91<br />

KCB Borssele PWR NL 512 484 693 336 333 4 782 186 166 503 874 91.08 81.95 91.06 81.86 88.20 78.39<br />

KKB 1 Beznau 7) PWR CH 380 365 733 272 559 1 855 842 129 189 952 100.00 84.60 100.00 84.38 96.27 83.62<br />

KKB 2 Beznau 1,2,7) PWR CH 380 365 239 86 668 2 0<strong>11</strong> 679 136 362 086 32.12 91.34 31.92 91.31 30.14 90.70<br />

KKG Gösgen 7) PWR CH 1060 1010 495 5<strong>11</strong> 876 5 138 912 319 014 440 66.47 84.14 66.04 83.49 64.91 83.14<br />

KKM Mühleberg BWR CH 390 373 744 280 420 2 222 570 129 626 885 100.00 100.00 99.93 99.75 96.64 97.73<br />

CNT-I Trillo PWR ES 1066 1003 744 785 304 5 390 978 252 682 646 100.00 87.79 99.87 87.33 98.16 86.16<br />

Dukovany B1 3) PWR CZ 500 473 379 176 941 2 662 535 <strong>11</strong>4 892 028 50.94 93.62 50.34 93.32 47.57 91.32<br />

Dukovany B2 2) PWR CZ 500 473 0 0 1 610 472 109 844 643 0 56.85 0.10 56.39 0 55.24<br />

Dukovany B3 PWR CZ 500 473 744 355 841 2 322 286 108 820 326 100.00 81.91 99.95 81.50 95.66 79.65<br />

Dukovany B4 PWR CZ 500 473 733 355 048 2 888 305 109 331 573 98.52 99.81 97.61 99.62 95.44 99.07<br />

Temelin B1 PWR CZ 1080 1030 744 793 753 4 720 428 <strong>11</strong>9 081 470 100.00 75.82 99.86 75.52 98.60 74.82<br />

Temelin B2 1) PWR CZ 1080 1030 5<strong>11</strong> 537 389 5 014 587 <strong>11</strong>4 287 104 68.68 79.32 66.85 79.03 66.76 79.48<br />

Doel 1 PWR BE 454 433 744 341 195 1 923 479 137 367 941 100.00 71.29 99.97 70.94 98.34 71.16<br />

Doel 2 PWR BE 454 433 744 330 999 2 246 141 136 048 080 100.00 85.95 99.28 84.37 97.52 84.46<br />

Doel 3 PWR BE 1056 1006 744 775 861 4 839 363 259 971 848 100.00 78.61 99.74 77.91 98.19 78.07<br />

Doel 4 PWR BE 1084 1033 744 696 829 6 124 559 266 497 969 100.00 100.00 87.42 96.62 84.39 95.36<br />

Tihange 1 PWR BE 1009 962 744 725 185 5 845 679 304 676 537 100.00 100.00 100.00 99.99 96.57 99.48<br />

Tihange 2 PWR BE 1055 1008 744 756 385 1 416 023 256 067 953 100.00 24.64 99.92 23.88 97.<strong>11</strong> 23.16<br />

Tihange 3 PWR BE 1089 1038 744 778 719 6 183 131 277 410 404 100.00 99.96 100.00 99.14 96.50 97.86<br />

559<br />

NEWS<br />

Plant name<br />

Type<br />

Nominal<br />

capacity<br />

gross<br />

[MW]<br />

net<br />

[MW]<br />

Operating<br />

time<br />

generator<br />

[h]<br />

Energy generated, gross<br />

[MWh]<br />

Time availability<br />

[%]<br />

Energy availability<br />

[%] *) Energy utilisation<br />

[%] *)<br />

Month Year Since Month Year Month Year Month Year<br />

commissioning<br />

KBR Brokdorf DWR 1480 1410 744 994 792 6 432 247 357 000 057 100.00 83.52 94.05 78.35 89.88 74.24<br />

KKE Emsland DWR 1406 1335 744 1 026 542 6 728 057 353 547 026 100.00 83.78 100.00 83.66 98.<strong>11</strong> 82.06<br />

KWG Grohnde DWR 1430 1360 744 990 908 6 708 328 384 282 542 100.00 85.06 100.00 84.73 92.41 79.93<br />

KRB C Gundremmingen SWR 1344 1288 744 978 185 6 460 061 337 401 816 100.00 83.70 99.40 83.00 97.38 81.99<br />

KKI-2 Isar 4) DWR 1485 1410 744 1 031 644 7 820 515 361 546 328 100.00 93.91 98.93 93.51 92.84 89.95<br />

GKN-II Neckarwestheim 1,2,4) DWR 1400 1310 207 223 200 7 082 010 336 908 844 100.00 100.00 21.19 89.84 21.19 86.86<br />

KKP-2 Philippsburg 1,2,5) DWR 1468 1402 409, 536 941 6 876 315 373 037 470 55.01 84.50 54.82 84.22 48.33 79.10<br />

In line with the theme of this year’s<br />

World Science Day <strong>for</strong> Peace and<br />

Development – “Open Science, leaving<br />

no one behind” – on 10 November,<br />

INIS plays a vital role in providing<br />

open access to in<strong>for</strong>mation and<br />

research.<br />

“The IAEA has been an advocate of<br />

open access to knowledge since the<br />

inception of INIS in 1970,” said<br />

Dobrica Savic, Head of the <strong>Nuclear</strong><br />

In<strong>for</strong>mation Section. All the documents,<br />

presentations and records are<br />

free of charge and accessible to anyone<br />

via the Internet.<br />

Open science is defined by<br />

UNESCO as making scientific research<br />

and data accessible to all. It includes<br />

publishing open scientific research,<br />

promoting open access and making<br />

open source software available.<br />

Libraries and repositories are key <strong>for</strong><br />

open science as many play an active<br />

role in the preservation, curation,<br />

publication and dissemination of<br />

digital scientific materials, according<br />

to the Organisation <strong>for</strong> Economic<br />

Co-operation and Development.<br />

The INIS repository includes<br />

research on a wide range of nuclearrelated<br />

topics, from environmental science<br />

and energy storage to radio logy<br />

and many more. It’s made possible<br />

through an ongoing colla borative<br />

ef<strong>for</strong>t between the IAEA and experts<br />

from 132 countries and 24 international<br />

organizations. Member States<br />

submit peer-reviewed research from<br />

their country/organization to INIS,<br />

and approximately 120,000 bibliographic<br />

records and 13,000 full-text<br />

PDF documents are added each year.<br />

To be sure, most publications are<br />

not <strong>for</strong> the lay reader. A quick glance<br />

turns up titles such as “Method and<br />

apparatus <strong>for</strong> the nondestructive<br />

assay of bulk nuclear fuel using 1 keV<br />

to Mev range neutrons” or “Regional<br />

comparison of nuclear and fossil electric<br />

power generation costs”. Many<br />

were once only available in hard copy<br />

but are now online after a massive<br />

ef<strong>for</strong>t to convert millions of microfiche<br />

pages to fully searchable electronic<br />

files.<br />

Improving INIS inputs<br />

To continually improve the quantity<br />

and quality of submissions to the INIS<br />

repository, the IAEA periodically<br />

offers trainings and e-learning courses<br />

to specialists, librarians and scientific<br />

officers involved in knowledge<br />

management. Last month, experts<br />

gathered in Vienna to discuss different<br />

aspects of INIS operations, such as<br />

News


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

560<br />

NEWS<br />

selection criteria and descriptive<br />

cataloguing, and improve their skills<br />

<strong>for</strong> the preparation of high-quality<br />

input and use of the repository. The<br />

participants, more than half of them<br />

women, came from Africa, Asia, Europe<br />

and the Americas.<br />

Full-text documents available in<br />

the INIS repository represent almost<br />

entirely nuclear-related non-conventional<br />

literature. Non-conventional<br />

literature includes any literature<br />

which is not normally available<br />

through commercial distribution<br />

channels and which is generally<br />

difficult to locate. The depth and<br />

breadth of the INIS repository and<br />

the large number of daily users<br />

demonstrate how a well-planned and<br />

implemented international cooperation<br />

project can make a significant<br />

contribution to open science.<br />

| www.iaea.org<br />

Company News<br />

Framatome successfully<br />

implements innovative<br />

maintenance technique<br />

on reactor vessel<br />

component underwater<br />

(framatome) Framatome applied a<br />

cutting-edge maintenance technique<br />

on reactor vessel primary nozzles at<br />

Dominion Energy’s Millstone <strong>Power</strong><br />

Station during the plant’s spring 2019<br />

outage. This was the first application<br />

of Framatome’s ultra-high pressure<br />

(UHP) cavitation peening process on<br />

reactor pressure vessel nozzles to<br />

primary pipe welds. Because it is<br />

deployed directly to the inner surface,<br />

it is uniquely suited to remediate the<br />

component regardless of external<br />

space restrictions or dose constraints.<br />

“Framatome’s innovative solutions<br />

are ensuring the efficient and reliable<br />

operation of today’s reactor fleet,” said<br />

Catherine Cornand, Framatome’s<br />

senior executive vice president in<br />

charge of the Installed Base Business<br />

Unit. “This new underwater application<br />

of UHP cavitation peening on a<br />

primary nozzle is another example of<br />

our team’s expertise and dedication to<br />

innovation and continuous improvement<br />

in servicing our customers<br />

worldwide.”<br />

To prepare <strong>for</strong> the work, Framatome<br />

demonstrated the qualified reactor<br />

vessel primary nozzle cavitation<br />

peening technology on a full-scale<br />

mock-up at the company’s world-class<br />

Technical Training Center in<br />

Lynchburg, Virginia, in early 2019.<br />

UHP cavitation peening is designed<br />

to prevent primary water stress<br />

corrosion cracking. The process uses<br />

ultra-high-pressure water jets to<br />

generate vapor bubbles that collapse<br />

with enough <strong>for</strong>ce to create beneficial<br />

compression of the components’<br />

surfaces. This surface compression<br />

improves components’ material<br />

properties and enhances resistance<br />

to corrosion and other types of<br />

degradation, which reduces the<br />

effects of aging.<br />

UHP cavitation peening can extend<br />

the life of nuclear reactor primary<br />

components, including the hot leg<br />

primary nozzles, <strong>for</strong> up to 40 additional<br />

years. Additionally, the process<br />

reduces outage time and saves money<br />

by eliminating the need to replace<br />

components or address indications<br />

with traditional repair methods. UHP<br />

cavitation peening can be used <strong>for</strong><br />

several different applications in most<br />

reactor designs.<br />

“Cavitation peening is an industry<br />

game-changer that was recognized in<br />

2017 as one of the Top Innovative<br />

Practices <strong>for</strong> work completed on the<br />

Byron and Braidwood reactor vessel<br />

closure heads,” said Craig Ranson,<br />

senior vice president of Framatome’s<br />

North America Installed Base Business<br />

Unit. “We are proud to work with<br />

Dominion to expand our proven<br />

capabilities and engineer a solution<br />

<strong>for</strong> this unique primary nozzle repair.”<br />

Located in Water<strong>for</strong>d, Connecticut,<br />

the Millstone <strong>Power</strong> Station’s two<br />

pressurized water reactors produce<br />

enough electricity to power 2.1 million<br />

homes.<br />

| www.framatome.com<br />

UK Government and industry<br />

champion new compact<br />

nuclear power station<br />

(rolls-royce) UK Research and Innovation<br />

(UKRI) has confirmed it has<br />

provided initial match funding to the<br />

consortium of companies designing a<br />

new type of nuclear power station in<br />

the UK.<br />

| Artist's view of the SMR design of a new UK nuclear power station project.<br />

The initial joint investment of<br />

£18million from UKRI will be matched<br />

by nuclear, civil engineering construction<br />

and manufacturing industry<br />

firms, who have been working on the<br />

preliminary design <strong>for</strong> four years.<br />

The power station is a compact<br />

design, the components <strong>for</strong> which are<br />

manufactured in sections in regional<br />

UK factories, be<strong>for</strong>e being transported<br />

to existing nuclear sites <strong>for</strong> rapid<br />

assembly inside a weatherproof<br />

canopy. This cuts costs by avoiding<br />

weather disruptions and secures<br />

gradual efficiency savings by using<br />

streamlined and standardised manufacturing<br />

processes <strong>for</strong> its components.<br />

By 2050 a full UK programme of up<br />

to 16 of these power stations could<br />

create:<br />

p Up to 40,000 jobs<br />

p £ 52 bn of value to the UK<br />

economy<br />

p £ 250 bn of exports<br />

Paul Stein, Chief Technology Officer<br />

<strong>for</strong> Rolls-Royce, which leads the<br />

consortium, said: “Tackling climate<br />

change requires collaboration across<br />

industries and governments to find<br />

effective, af<strong>for</strong>dable and sustainable<br />

ways of achieving net zero by 2050.<br />

“The consortium’s work with the<br />

Government shows that action is<br />

being taken to decarbonise our<br />

economy and meet our society’s vital<br />

and growing power needs. This is a<br />

very positive step <strong>for</strong>ward to this next<br />

phase of the programme.”<br />

The partners in the consortium<br />

are Assystem, BAM Nuttall, Laing<br />

O’Rourke, National <strong>Nuclear</strong> Laboratory<br />

(NNL), Rolls-Royce, Atkins,<br />

Wood, The Welding Institute (TWI)<br />

and <strong>Nuclear</strong> AMRC.<br />

The target cost <strong>for</strong> each station is<br />

£1.8 billion by the time five have been<br />

built, with further savings possible.<br />

Each power station will be able to<br />

operate <strong>for</strong> 60 years and provide<br />

440 MW of electricity, which is<br />

enough to power a city the size of<br />

Leeds.<br />

News


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

The shared initial investment will<br />

be used to progress the significant<br />

opportunities presented by the programme;<br />

prepare it <strong>for</strong> the UK’s<br />

regulatory Generic Design Assessment<br />

process; and make final decisions on<br />

which innovations to pursue and realise.<br />

It will also generate the valuable<br />

confidence that the supply chain needs<br />

to begin to prepare <strong>for</strong> a programme<br />

that could create around £52 billion of<br />

value <strong>for</strong> the UK economy.<br />

When licensed and supported by<br />

the required enabling legislation and<br />

siting processes, the power station<br />

could provide reliable low carbon<br />

energy from the early 2030s.<br />

The Government’s intent to<br />

support the programme was announced<br />

in July 2019.<br />

| www.rolls-royce.com<br />

Uranium<br />

Prize range: Spot market [USD*/lb(US) U 3O 8]<br />

140.00<br />

120.00<br />

100.00<br />

80.00<br />

60.00<br />

40.00<br />

20.00<br />

0.00<br />

1980<br />

Yearly average prices in real USD, base: US prices (1982 to1984) *<br />

1985<br />

1990<br />

1995<br />

2000<br />

2005<br />

) 1<br />

2010<br />

2015<br />

2019<br />

Year<br />

* Actual nominal USD prices, not real prices referring to a base year. Year<br />

Sources: Energy Intelligence, Nukem; Bild/Figure: <strong>atw</strong> 2019<br />

* Actual nominal USD prices, not real prices referring to a base year. Sources: Energy Intelligence, Nukem; Bild/Figure: <strong>atw</strong> 2019<br />

| Uranium spot market prices from 1980 to 2019 and from 2008 to 2019. The price range is shown.<br />

In years with U.S. trade restrictions the unrestricted uranium spot market price is shown.<br />

Separative work: Spot market price range [USD*/kg UTA]<br />

Conversion: Spot conversion price range [USD*/kgU]<br />

180.00<br />

22.00<br />

) 1<br />

160.00<br />

140.00<br />

120.00<br />

100.00<br />

80.00<br />

60.00<br />

40.00<br />

Uranium prize range: Spot market [USD*/lb(US) U 3O 8]<br />

140.00<br />

120.00<br />

100.00<br />

80.00<br />

60.00<br />

40.00<br />

20.00<br />

0.00<br />

20.00<br />

18.00<br />

16.00<br />

14.00<br />

12.00<br />

10.00<br />

Jan. 2008<br />

8.00<br />

6.00<br />

4.00<br />

Jan. 2009<br />

Jan. 2010<br />

) 1<br />

Jan. 20<strong>11</strong><br />

Jan. 2012<br />

Jan. 2013<br />

Jan. 2014<br />

Jan. 2015<br />

Jan. 2016<br />

Jan. 2017<br />

Jan. 2018<br />

Jan. 2019<br />

Jan. 2020<br />

561<br />

NEWS<br />

) 1 Sources: Energy Intelligence, Nukem; Bild/Figure: <strong>atw</strong> 2019<br />

Westinghouse signs<br />

agreement to acquire Rolls-<br />

Royce Civil <strong>Nuclear</strong> Systems<br />

and Services Business<br />

(west) Westinghouse Electric Company<br />

signed a definitive agreement to<br />

acquire Rolls-Royce’s Civil <strong>Nuclear</strong><br />

Systems and Services business in North<br />

America, expanding Westinghouse’s<br />

global capabilities in digital, engineering<br />

services, plant automation and<br />

monitoring systems, field services and<br />

manufacturing.<br />

“Creating customer value and<br />

supporting our customers’ operations<br />

is a key driver <strong>for</strong> Westinghouse.<br />

Acquiring Rolls-Royce will strengthen<br />

our ability to serve the nuclear<br />

operating fleet through an expanded<br />

presence in our core business while<br />

adding new digital offerings,” said<br />

Patrick Fragman, Westinghouse president<br />

and chief executive officer. “This<br />

acquisition is an important step in our<br />

growth strategy. We look <strong>for</strong>ward to<br />

welcoming the employees of Rolls-<br />

Royce to Westinghouse.”<br />

The acquisition of Rolls-Royce will:<br />

p Expand Westinghouse’s operating<br />

plant services capabilities<br />

p Enhance the company’s digital<br />

innovation ef<strong>for</strong>ts to optimize<br />

customer planning and maintenance,<br />

and provide engineering<br />

solutions to maximize cost<br />

effectiveness and obsolescence risk<br />

p Support both Westinghouse’s and<br />

Rolls-Royce’s global customer base<br />

through an expanded presence<br />

and synergies between both<br />

companies, enhancing customer<br />

offerings and experience in field<br />

services and plant automation<br />

p Further enable Westinghouse’s<br />

growth while supporting<br />

20.00<br />

0.00<br />

Jan. 2008<br />

Jan. 2009<br />

Jan. 2010<br />

Jan. 20<strong>11</strong><br />

Jan. 2012<br />

* Actual nominal USD prices, not real prices referring to a base year. Year<br />

customers in the North American<br />

and European nuclear markets<br />

Rolls-Royce operates <strong>11</strong> sites in<br />

Canada, France, the United Kingdom<br />

and the United States.<br />

| www.westinghousenuclear.com<br />

Market data<br />

(All in<strong>for</strong>mation is supplied without<br />

guarantee.)<br />

<strong>Nuclear</strong> Fuel Supply<br />

Market Data<br />

In<strong>for</strong>mation in current (nominal)<br />

U.S.-$. No inflation adjustment of<br />

prices on a base year. Separative work<br />

data <strong>for</strong> the <strong>for</strong>merly “secondary<br />

market”. Uranium prices [US-$/lb<br />

U 3 O 8 ; 1 lb = 453.53 g; 1 lb U 3 O 8 =<br />

0.385 kg U]. Conversion prices [US-$/<br />

kg U], Separative work [US-$/SWU<br />

(Separative work unit)].<br />

Jan. 2013<br />

Jan. 2014<br />

Jan. 2015<br />

Jan. 2016<br />

2017<br />

p Uranium: 19.25–26.50<br />

p Conversion: 4.50–6.75<br />

p Separative work: 39.00–50.00<br />

2018<br />

p Uranium: 21.75–29.20<br />

p Conversion: 6.00–14.50<br />

p Separative work: 34.00–42.00<br />

2019<br />

January 2019<br />

p Uranium: 28.70–29.10<br />

Jan. 2017<br />

Jan. 2018<br />

Jan. 2019<br />

Jan. 2020<br />

Sources: Energy Intelligence, Nukem; Bild/Figure: <strong>atw</strong> 2019<br />

2.00<br />

0.00<br />

* Actual nominal USD prices, not real prices referring to a base year. Year<br />

| Separative work and conversion market price ranges from 2008 to 2019. The price range is shown.<br />

)1<br />

In December 2009 Energy Intelligence changed the method of calculation <strong>for</strong> spot market prices. The change results in virtual price leaps.<br />

* Actual nominal USD prices, not real prices referring to a base year<br />

Sources: Energy Intelligence, Nukem; Bilder/Figures: <strong>atw</strong> 2019<br />

Jan. 2008<br />

Jan. 2009<br />

Jan. 2010<br />

Jan. 20<strong>11</strong><br />

Jan. 2012<br />

p Conversion: 13.50–14.50<br />

p Separative work: 41.00–44.00<br />

February 2019<br />

p Uranium: 27.50–29.25<br />

p Conversion: 13.50–14.50<br />

p Separative work: 42.00–45.00<br />

March 2019<br />

p Uranium: 24.85–28.25<br />

p Conversion: 13.50–14.50<br />

p Separative work: 43.00–46.00<br />

April 2019<br />

p Uranium: 25.50–25.88<br />

p Conversion: 15.00–17.00<br />

p Separative work: 44.00–46.00<br />

May 2019<br />

p Uranium: 23.90–25.25<br />

p Conversion: 17.00–18.00<br />

p Separative work: 46.00–48.00<br />

June 2019<br />

p Uranium: 24.30–25.00<br />

p Conversion: 17.00–18.00<br />

p Separative work: 47.00–49.00<br />

July 2019<br />

p Uranium: 24.50–25.60<br />

p Conversion: 18.00–19.00<br />

p Separative work: 47.00–49.00<br />

August 2019<br />

p Uranium: 24.90–25.60<br />

p Conversion: 19.00–20.00<br />

p Separative work: 47.00–49.00<br />

September 2019<br />

p Uranium: 24.80–26.00<br />

p Conversion: 20.00–21.00<br />

p Separative work: 47.00–50.00<br />

| Source: Energy Intelligence<br />

www.energyintel.com<br />

Jan. 2013<br />

Jan. 2014<br />

Jan. 2015<br />

Jan. 2016<br />

Jan. 2017<br />

Jan. 2018<br />

Jan. 2019<br />

Jan. 2020<br />

News


<strong>atw</strong> Vol. 64 (2019) | Issue <strong>11</strong>/12 ı November/December<br />

562<br />

NUCLEAR TODAY<br />

John Shepherd is a<br />

freelance journalist<br />

and communications<br />

consultant who has<br />

covered the nuclear<br />

industry <strong>for</strong> the past<br />

20 years and is<br />

currently editor-in-chief<br />

of UK-based Energy<br />

Storage Publishing.<br />

Sources<br />

World <strong>Nuclear</strong><br />

Association<br />

https://cutt.ly/weEfVJC<br />

IEA Sweden report<br />

https://cutt.ly/TeEfZIs<br />

Cryospheric Sciences<br />

Division blog<br />

https://cutt.ly/1eEfLyD<br />

Taking a Leaf out of Greta’s<br />

Climate Change Book<br />

The media loves a ‘warrior underdog’ and so journalists around the world have largely fallen in love with Swedish eco<br />

champion Greta Thunberg. The diminutive teenager has captured the imagination of a new generation of environmental<br />

activists since she burst onto the international scene around a year ago, when she protested on school days outside the<br />

Swedish parliament. She said her school strike was to draw attention to global warming.<br />

Her actions caught on and soon led to other students<br />

making similar protests. The rest, to coin a phrase, is<br />

already modern history. Thunberg has been feted worldwide<br />

and she even addressed the 2018 United Nations<br />

Climate Change Conference.<br />

Whatever one thinks of Thunberg’s approach, it’s hard<br />

to deny that she has reignited interest in the climate change<br />

debate and raised the political temperature on all sides.<br />

So could nuclear’s proponents take a leaf out of the<br />

young environmentalist’s book? Earlier this year, a group<br />

of reactor physicists, operators and politicians were among<br />

those who followed Thunberg’s lead and gathered outside<br />

the Swedish parliament to raise awareness of the benefits<br />

of nuclear energy.<br />

One of the organisers of the ‘Stand up <strong>for</strong> <strong>Nuclear</strong>’ event<br />

was Swedish <strong>Nuclear</strong> Society president Marcus Eriksson.<br />

He told me that, on the same day of the event, the group<br />

published an opinion article in one of Sweden’s major<br />

newspapers, Svenska Dagbladet, which explained the<br />

country’s energy situation in Sweden, making a parallel to<br />

Germany’s energy sector.<br />

The Stand up <strong>for</strong> <strong>Nuclear</strong> event is an important development<br />

in Sweden and one that could and should have<br />

wider implications <strong>for</strong> Europe. Sweden has a chequered<br />

past where nuclear is concerned.<br />

According to the World <strong>Nuclear</strong> Association, Sweden<br />

generated a combined 156 terawatt hours (TWh) of<br />

electricity in 2016, of which 63 TWh (40%) was from its<br />

eight nuclear power reactors and 62 TWh (40%) from<br />

hydro. Wind provided 15.5 TWh (10%), various fossil fuels<br />

2 TWh, and biofuels and waste 13 TWh (8%). Total<br />

installed generating capacity at the end of 2016, as<br />

recorded by the <strong>International</strong> Energy Agency‘s (IEA)<br />

‘ Electricity In<strong>for</strong>mation 2018’, was 40 gigawatts electric.<br />

In 1980, the Swedish government decided to phase out<br />

nuclear power but this policy was repealed by lawmakers<br />

in June 2010. The country‘s 1997 energy policy had<br />

allowed 10 reactor units to operate longer than envisaged<br />

by the 1980 phase-out policy. However, the policy also led<br />

to the premature closure of a two-unit (1,200 megawattelectric)<br />

plant, although some 1,600 MWe was subsequently<br />

added in uprates to the remaining 10 units.<br />

In 2015, decisions were made to close four older<br />

reactors by 2020. A year later, a tax discriminating against<br />

nuclear power was abolished.<br />

<strong>Nuclear</strong>’s impact on Sweden’s environmental credentials<br />

is impressive. The country has almost fully decarbonised its<br />

electricity generation, which the IEA has described as “a<br />

feat which is quite unique among the IEA member countries”.<br />

In a review of Swedish energy policy published last<br />

April, the IEA said the country should assess the contribution<br />

of nuclear power over the next 20 years and the impact<br />

of further potential early closures on energy security.<br />

I have no scientific basis <strong>for</strong> saying this, only a gut<br />

feeling (from reporting on nuclear and the wider energy<br />

industry over the past 20 years), that there is often a silent<br />

majority who would speak up in favour of nuclear –<br />

provided they are given the facts.<br />

It appears such a majority could exist in Sweden, if a<br />

survey conducted last summer by Novus Opinion is<br />

anything to go by. That survey indicated a majority of<br />

Swedes now believe that nuclear power could be a means<br />

to tackle the climate crisis. Which brings me back to the<br />

Stand up <strong>for</strong> <strong>Nuclear</strong> event organised in Stockholm.<br />

Marcus Eriksson told journalists covering the event:<br />

“Two years ago none of the political parties wanted to talk<br />

about nuclear power, now everyone is talking about it. It<br />

reflects a stronger opinion that the technology has an<br />

important role to play to combat climate change.”<br />

The Swedish <strong>Nuclear</strong> Society should be praised <strong>for</strong><br />

raising awareness of the benefits of nuclear in this way.<br />

Every day, when we are out and about, there is a manifestation<br />

of some sort or another with campaigners competing<br />

<strong>for</strong> our attention on issues. So why not something<br />

that speaks up <strong>for</strong> nuclear? In these gloomy winter nights,<br />

perhaps there is an inbuilt advantage <strong>for</strong> the nuclear cause<br />

in pointing out just how dark and cold many of our communities<br />

would be without the benefit of atomic power.<br />

As we head into a new year, it’s a good time to start<br />

thinking about the resolutions we will make <strong>for</strong> the months<br />

ahead. In addition to resolution favourites, such as going<br />

on a diet, or giving up smoking, those involved in the<br />

nuclear sector should pledge to make a special ef<strong>for</strong>t to<br />

stand up <strong>for</strong> nuclear in 2020.<br />

The initial unassuming campaign launched by Greta<br />

Thunberg just a year ago is, I suggest, a template <strong>for</strong> what<br />

could be a ‘2020 Vision <strong>for</strong> <strong>Nuclear</strong>’ campaign <strong>for</strong> the year<br />

ahead. Perhaps with the advent of social media we’ve<br />

<strong>for</strong>gotten about the impact of ‘grassroots’ campaigning.<br />

Social media is of course tremendously valuable in<br />

reaching millions. But let’s not <strong>for</strong>get the impact that can<br />

be had by being out on the streets and chatting to passersby<br />

about the technology that keeps the lights on and can<br />

help clean up our local and global environments.<br />

There’s no time like the present to get out there and<br />

follow Greta’s footprint. In fact, the beloved Santa Clause,<br />

a figure who returns to prominence at this time of the year,<br />

could be recruited to underline the importance of the<br />

nuclear cause.<br />

As the Cryospheric Sciences Division of the European<br />

Geosciences Union has pointed out, Santa might well have<br />

to think about moving from his fabled home of Lapland<br />

because of global warming and polar amplification. In the<br />

absence of snow, Santa does have the possibility of<br />

converting his sleigh to an all-electric model. But even if<br />

there were enough charging points around the globe, they<br />

would need reliable supplies of clean electricity, which<br />

brings us back to nuclear’s importance <strong>for</strong> our planet’s<br />

energy mix.<br />

In wrapping up this festive article, it only remains to<br />

wish everyone the compliments of the season and, if not a<br />

white Christmas, at least an increasingly green one.<br />

<strong>Nuclear</strong> Today<br />

Taking a Leaf out of Greta’s Climate Change Book ı John Shepherd


Kommunikation und<br />

Training für Kerntechnik<br />

Strahlenschutz – Aktuell<br />

In Kooperation mit<br />

TÜV SÜD Energietechnik GmbH<br />

Baden-Württemberg<br />

Seminar:<br />

Das neue Strahlenschutzgesetz –<br />

Folgen für Recht und Praxis<br />

Seminarinhalte<br />

1. Teil | Das neue Strahlenschutzgesetz (StrlSchG)<br />

ı Das neue StrlSchG: Historie<br />

ı Inkrafttreten des StrlSchG<br />

ı Überblick über grundlegende Änderungen<br />

ı Die Entwürfe der neuen Strahlenschutzverordnung(en) (soweit zum Seminarzeitpunkt vorliegend)<br />

2. Teil | Auswirkungen auf die betriebliche Praxis<br />

ı Genehmigungen, Zuständigkeiten<br />

ı Begriff der Expositionssituation (geplant, bestehend, Notfall), NORM<br />

ı Aufsichtsprogramm, § 180 StrlSchG, Rechtfertigung<br />

ı Notfallpläne<br />

ı Änderungen für SSV/SSB<br />

ı Dosisgrenzwerte<br />

ı Strahlenschutzregister<br />

3. Teil | Strahlenschutz im Back End<br />

ı Freigabe und Entsorgung<br />

ı Altlasten<br />

ı Baustoffe<br />

Zielgruppe<br />

Die 2-tägige Schulung wendet sich an Fach- und Führungskräfte, an Projekt- und Abteilungsleiter und<br />

Experten aus den Bereichen Betrieb, Abfälle, Genehmigung, Strategie und Unternehmens kommunikation<br />

sowie an Juristen.<br />

Referenten<br />

Dr. Maria Poetsch<br />

Dr. Christian Raetzke<br />

ı Strahlenschutzexpertin bei der TÜV SÜD Energietechnik GmbH<br />

Baden-Württemberg<br />

ı Rechtsanwalt, Leipzig<br />

Wir freuen uns auf Ihre Teilnahme!<br />

Bei Fragen zur Anmeldung rufen Sie uns bitte an oder senden uns eine E-Mail.<br />

Termine<br />

2 Tage<br />

28. bis 29. Januar 2020<br />

17. bis 18. März 2020<br />

16. bis 17. Juni 2020<br />

Tag 1: 10:30 bis 17:30 Uhr<br />

Tag 2: 09:00 bis 16:30 Uhr<br />

Berlin<br />

Teilnahmegebühr<br />

1.598,– € ı zzgl. 19 % USt.<br />

Im Preis inbegriffen sind:<br />

ı Seminarunterlagen<br />

ı Teilnahmebescheinigung<br />

ı Pausenverpflegung<br />

inkl. Mittagessen<br />

Kontakt<br />

INFORUM<br />

Verlags- und Verwaltungsgesellschaft<br />

mbH<br />

Robert-Koch-Platz 4<br />

10<strong>11</strong>5 Berlin<br />

Petra Dinter-Tumtzak<br />

Fon +49 30 498555-30<br />

Fax +49 30 498555-18<br />

Seminare@KernD.de


#51KT<br />

www.kerntechnik.com<br />

Medienpartner<br />

51. KERNTECHNIK<br />

2020<br />

Jetzt anmelden!<br />

www.kerntechnik.com/kerntechnik/registration/<br />

5. – 6. Mai 2020<br />

Estrel Convention Center<br />

Berlin

Hooray! Your file is uploaded and ready to be published.

Saved successfully!

Ooh no, something went wrong!
