Total log distance<br />
Total log distance is<br />
counted up to 99'999,9<br />
NM. The first two most<br />
significant digits "d<br />
00" <strong>and</strong> the four lower<br />
digits "000.0" are<br />
alternately displayed.<br />
The value is permanently<br />
stored in<br />
memory. In addition,<br />
total log distance is<br />
permanently copied<br />
into all other displays in<br />
the system, to provide a<br />
backup.<br />
Total log distance is a<br />
global function in the net.<br />
Alerts:<br />
<br />
SELECT<br />
<br />
Sensor Type Alert<br />
It is displayed<br />
automatically, if more<br />
than one display unit<br />
has been configured<br />
for the same log sensor.<br />
All displays<br />
should be checked for<br />
correct "SE" (see display<br />
configuration).<br />
Three dashes instead<br />
of the numbers<br />
are an indication that<br />
no display has been<br />
configured for a log<br />
sensor. Verify the<br />
correct SE=.. of the<br />
<strong>Display</strong> which has<br />
the log sensor connected.<br />
Low Battery Alarm<br />
The battery alarm<br />
comes on when the<br />
supply voltage has<br />
dropped below 10<br />
Volts. It disappears<br />
after voltage has risen<br />
above 11 Volts.<br />
The display stops<br />
working below 9 Volts.<br />
Settings:<br />
Voltmeter<br />
This function displays<br />
the battery<br />
voltage (as measured<br />
at the display).<br />
Illumination<br />
If you have a dimmer<br />
installed in the<br />
system, it must be<br />
used. Only without a<br />
dimmer use the push<br />
SELECT<br />
buttons for illumination<br />
control:<br />
1. Press <strong>and</strong> hold<br />
all three buttons.<br />
2. Release SELECT<br />
button first, then the others.<br />
3. Adjust brightness with left or right button.<br />
All other displays with the same group<br />
number will follow in brightness.<br />
4. Exit from the dimmer function with the<br />
SELECT-button.<br />
<br />
3
