BeyondBits

Issue 7

VYBRID EDITION

Rich applications

in real time

INTRODUCING

Vybrid Controller

Solutions

March 2012

Introducing Vybrid

Controller Solutions

Rich applications in real time

freescale.com/Vybrid

Welcome to the latest edition of Beyond Bits, created to help you bring your innovative

design ideas to life.

This edition provides an in-depth look at our Vybrid portfolio of controller solutions, designed to dramatically

simplify solutions that need rich human-machine interface (HMI) and connectivity concurrent with real-time

control and response. We’re taking the concept of a total embedded solution approach further, and helping

you bring differentiated products to market faster. Complex embedded systems must continue to operate

consistently and predictably. The Vybrid brand is distinguished by software tightly coupled with silicon—

enabling concurrent low-latency communication between high-level operating systems such as Linux and

real-time operating systems (RTOS) like MQX. We realize that the majority of product development time

lies in getting the software right. Starting with the Vybrid portfolio, we will release software virtual models of

silicon to help you begin software development before silicon is available—shortening the cycle of time to

revenue.

The Vybrid family provides unprecedented system integration, starting with a unique heterogeneous

architecture that brings together ARM ® Cortex-A and ARM Cortex-M cores as well as a powerful array

of peripherals. Extensive communication and memory options, as well as support for external peripherals and

memory, are available. Security and data integrity has been carefully considered, with features for safeguarding

memory, content management and communication. HMI and multimedia options include audio interfaces,

dual display controllers, video interface and OpenVG GPU for UI acceleration.

The Vybrid portfolio also provides a broad offering of supporting resources, including reference designs,

application notes, white papers, on-demand training, board support packages and middleware. We also

provide a way to ease early software development by releasing a software virtual model, as well as IDE tool

support such as our Eclipse-based CodeWarrior Development Studio with Processor Expert, ARM DS-5 and

the modular Tower System development platform. This support, along with the vast resources of the ARM and

open-source communities, will help simplify your design process and reduce your time to market.

Our extensive range of 8-, 16- and 32-bit MCUs and MPUs offers solutions you can trust. You can count

on us to deliver industry-leading vertical solutions, scalable product lines, intellectual property and process

technology roadmaps, outstanding technical support, a robust ecosystem and

a broad range of devices, available for a minimum of 10 years.*

Thank you for considering Freescale solutions for your next-generation design. We look forward to

working with you.

Regards,

Reza Kazerounian

Senior Vice President and General Manager

Automotive, Industrial and Multi-Market Solutions Group

Freescale Semiconductor

*For Terms and Conditions and to obtain a list of available products, visit freescale.com/productlongevity.

Vybrid Controller Solutions

1

Vybrid Family Overview

4 Vybrid Controller Solutions

8 Vybrid VF3xx Family





Technical Highlights

19 Core Technology

22 Multicore Communication

24 Multimedia Subsystem

27 Security Subsystem

29 Power Management

31 Ethernet Subsystem

33 USB Subsystem

35 Memory Subsystem

39 Universal Asynchronous Receiver/Transmitter

Software and Development Tools

42 Freescale Virtual Hardware Platform

44 Freescale MQX Software Solutions

48 Freescale Tower System

50 Swell PEG Product Line

51 Timesys LinuxLink

52 CodeWarrior Development Studio

54 DS-5

56 IAR Embedded Workbench

58 Atollic

59 Multilink and Cyclone

60 SEGGER: J-Link and Flasher

61 SEGGER: RTOS, GUI and Middleware

62 Lauterbach

Table of Contents

Vybrid Family of Products



A unique heterogeneous platform solution

The increasing complexity and

demands of embedded systems

creates greater need for sophisticated

human-machine interfaces (HMI)

and multiple connectivity options

with safe, secure and predictable

operation. To concurrently provide

rich HMI and real-time control means

bringing together two very different

system paradigms. For example, HMI

computation focuses on efficiently

processing pixels and displaying

them on a screen, while guaranteed

determinism requires highly

predictable response times for tasks.

A traditional systems-level solution for

such divergent needs would combine

different pieces of silicon, such as

an applications MPU and a real-time

MCU, on a board. It would also require

developing software and a protocol to

enable simultaneous communication

between real-time control and rich

HMI. Application developers face a

tremendous challenge of seamlessly

integrating these diverse technologies

in a single system.

Our Vybrid portfolio brings to market

a unique, low-power system solution

that provides customers a way to

combine rich applications requiring

high-resolution graphical displays

and connectivity with real-time

determinism. The Vybrid portfolio

enables customers to create systems

that concurrently run a high-level

operating system such as Linux ®

and a real-time operating system

such as MQX on the same device.

This, along with a communication

API between the rich domain and the

real-time domain and a tool chain

4

Vybrid Portfolio Key Attributes

Total

System

Solution

Optimal

System

Performance

that eases debug of such systems,

dramatically shortens customer time

to revenue. The families in the Vybrid

portfolio span entry-level products for

customers who want to upgrade from

the Kinetis MCU to devices with large

on-chip SRAM up to highly integrated,

heterogeneous dual-core solutions

that can serve industrial and consumer

markets.

Each device in the Vybrid portfolio

offers a rich suite of reference designs,

app notes, board support packages

and middleware for its market space.

This, along with the vast resources

Rich Apps in Real Time

Unprecedented

System

Integration

Low-Power

Process

of Freescale, ARM ® and open-source

communities, will help customers

to develop software solutions and

support for their applications and

dramatically reduce time to market.

Scalable and Compatible

across Multiple Cores

Vybrid devices have a dual core

architecture that combines the ARM

Cortex-A5 application processor and

the ARM Cortex-M4 for real-time

control. The Vybrid portfolio is designed

to be compatible with Kinetis MCUs

featuring the ARM Cortex-M4 core and

the i.MX6 series featuring the ARM

Cortex-A9 core, while also providing

Back to Table of Contents Beyond Bits Vybrid Edition

Vybrid Family Details

Vybrid

Families DDR

VF7xx Family

[Heterogenous Dual Core]

ARM ® Cortex-A5 up to 500 MHz

ARM Cortex-M4 up to 167 MHz

364-pin MAPBGA

VF6xx Family

[Heterogenous Dual Core]

ARM Cortex-A5 up to 500 MHz

ARM Cortex-M4 up to 167 MHz


VF5xx Family



VF4xx Family



VF3xx Family


176-pin LQFP


Camera Interface

Video ADC

Common Platform, Analog and Digital

CRC and TZ Address

12-bit ADC

Space Controllers

I 2 C 12-bit DAC

Programmable

Delay Block

USB Host w/PHY

USB OTG w/PHY

Segment LCD

TFT LCD (w/

Touch Screen)

Ethernet

Controller

L2 Switch

Security (HAB,

Tamper, Det.)

External Bus

Y 2

1

Y

Y

Secure JTAG

Flash Controller Secure Fuses

UARTs Timers

Low-Voltage,

Low-Power Multiple

Operating Modes,

Clock Gating

(1.73V–3.6V)

Secure RAM

eSDHC

DMA

ESAI SRAM

2

2

2

Tools

Packaged IDE

Packaged OS

and Multicore

Communication API

Application Software

Ind. Protocols,

Peripheral Drivers

Broad Third-Party

Ecosystem Support

Y

Y

scalable devices that can address the

needs of a market that demands critical

safety and security, connectivity and

rich HMI in the same piece of silicon.

The Vybrid roadmap is built with this

scalability and code compatibility in

mind so that the performance of the

device roadmap grows with customers‘

needs long into the future.

One of the key benefits of the Vybrid

heterogeneous architecture that

combines the ARM Cortex-A5 core

with the ARM Cortex-M4 core is the

partitioning of tasks based on their

characteristics. For tasks that need

predictable interrupt management,

for example, a typical need for realtime

applications, the Vybrid platform

has the ARM Cortex-M4 core with

a Nested Vector Interrupt Controller

(NVIC) while allowing graphical

applications and connectivity stacks

to be run on the ARM Cortex-A5

applications processor.

Software can be segmented so that

tasks that need predictable latencies

can be run on the ARM Cortex-M4

core and computer intensive processes

run on the ARM Cortex-A5 core.

Total System Solution

Vybrid devices take a total system

approach. Complementing the lowpower

silicon is a reference Linux BSP,

a full-featured MQX RTOS, reference

MQX BSP and a processor-toprocessor

communication API that lets

customers partition their code between

the ARM Cortex-A5 (e.g., running

Linux) and ARM Cortex-M4 (e.g.,

running MQX) to implement the lowest

power solution for their application

demands. In addition, customers

have access to industry-leading IDE

tool chains such as CodeWarrior

with Processor Expert, ARM DS-5

and IAR. A selection of connectivity,

motor control, LCD, security stacks

5

Vybrid Family Back to Table of Contents

and drivers is also available. Vybrid

devices are supported by Freescale’s

Tower System, offering the flexibility

to easily scale and expand customer

designs based on market need. Tower

Systems allow rapid prototyping in a

development platform that maximizes

hardware reuse and speeds time to

market.

Vybrid devices also accelerate time

to market by providing a range of

on-demand resources including

reference designs, application notes,

white papers and training to assist in

implementing designs.

Low-Power Process

One of the critical foundational pieces

of the Vybrid platform is its low-power

process technology. The devices in this

portfolio are fabricated in the 40 nm

low-power process. The static leakage

of the 40 nm LP process is 2x less

than 65 nm and almost 3x less than 90

nm. This enables more integration for a

6

Process Technology Node Comparison

Technology Node

90LP

65LP 55LP 40LP

Active Power Standby Power Speed

given power envelope thus dissipating

much less power for the same device.

Unprecedented System

Integration

The Vybrid platform has an

unprecedented level of system

integration for a solution of its class.

The centerpiece is the core complex

featuring the ARM Cortex-A5 and

ARM Cortex-M4 cores.

ARM Cortex-A5 Core

The ARM Cortex-A5 processor is a

high-performance, low-power core

with an L1 and L2 cache subsystem

that provides full virtual memory

capabilities, double precision floatingpoint

unit (FPU) and the NEON media

processing engine. It is intended

as an upgrade for the ARM9 ® and

ARM11 ® cores and is architecturally

compatible with Cortex-A9. The

ARM Cortex-A5 also has TrustZone ®

Technology for creating secure

applications.

ARM Cortex-M4 Core

The ARM Cortex-M4 core retains all the

advantages of the ARM Cortex-M3

core with an NVIC which gives

deterministic interrupt handling capability

demanded by real-time applications.

The ARM Cortex-M4 adds digital signal

processing capability in the form of

DSP and SIMD instruction extensions,

a single cycle MAC unit and single

precision FPU. In addition, Freescale

has added a direct memory access

(DMA) controller, crossbar switch, L1

on-chip cache memories and tightly

coupled memories (TCM) which

maximize processor performance and

bus bandwidth.

Communication Interfaces

Vybrid devices feature a number of

connectivity peripherals, including

dual USB 2.0 (Low-, Full- and High-

Speed) device/host/On-The-Go

with integrated PHYs, dual 10/100

Ethernet with Layer 2 Ethernet

switch with IEEE ® 1588 hardware

time stamping and reduced media

independent interface (RMII) support

for real-time industrial control. Multiple

serial interfaces include UARTs with

support for ISO7816 SIM/smart cards,

SPI and I 2 C, while dual CAN modules

enable industrial network bridging.

Support for External Peripherals

and Memory

In addition to having up to 1.5 MB

of on-chip SRAM for speedy code

and data execution, Vybrid devices

can interface to a variety of external

peripherals and memories for system

expansion and data storage. Dual

Quad SPI interfaces with eXecute-in-

Place (XiP) support can interface with

the latest flash memory to offer up to

160 MB/s of throughput. This allows

for a very powerful single-chip solution

when the large DDR memory sizes

are not required. A secure digital host

controller supports SD, SDIO, MMC

Back to Table of Contents

or CE-ATA cards for in-application

software upgrades, media files or

adding Wi-Fi ® support. For interfacing

to external peripherals such as

external SRAM, EEPROM and other

peripherals, a FlexBus external bus

interface is provided. NAND flash and

DRAM controllers with ECC support

allow connection to a wide variety of

memory types for critical applications.

Battery-backed RAM is critical for

secure systems to store authentication

keys; Vybrid devices provide 16 KB

of secure RAM. The platform also

provides 96 KB ROM used for high

assurance boot (HAB).

Multimedia Options

The Vybrid platform offers a host

of multimedia options enabling

customers to run rich applications with

real-time control.

Audio

Three different types of audio

interfaces are supported: synchronous

audio interface (SAI) for full-duplex

audio transfer, enhanced serial audio

interface (ESAI) that is also full duplex

and adds support for interfacing with

SPDIF transceivers and the Sony/

Philips Digital Interface (SPDIF) for

digital audio support.

Display Controller

Two independent display controller

units (DCU) interface with TFT LCD

displays. The DCU can drive LCD

displays up to a resolution of XGA

(1024x768). Also included is a

segment LCD controller.

Video Interface Unit (VIU)

For image and vision capture, a VIU

provides a 24-bit parallel interface for

digital video. In addition, an optional

video ADC will convert composite

video into digital format.


OpenVG Graphics

Processing Unit

Vivante GC355 OpenVG graphics

accelerator supporting OpenVG1.1

can be used for UI acceleration.

Reliability, Safety and Security

Vybrid devices include a variety of

data integrity and security hardware

features for safeguarding memory,

communication and system data.

A cyclic redundancy check module

is available for validating memory

contents and communication

data, while a memory protection

unit provides data protection and

increased software reliability. For

failsafe applications, an independently

clocked watchdog offers protection

against runaway code. When it comes

to security, a hardware encryption

unit supports several encryption

and hashing algorithms for program

validation as well as authentication

and securing data for transfer and

storage. The system security module

includes a unique chip identifier,

secure key storage and a hardware

tamper detection system. The tamper

detection system has integrated

sensors for voltage, frequency,

temperature and external sensing for

physical attack detection.

Optimal System

Performance

Vybrid devices are ideal for modern

industrial applications that require

higher integration of communication

and connectivity interfaces, as well as

HMI and UI acceleration. Customers

can easily take full advantage of all

the integrated Vybrid features to

create differentiated products by

leveraging the provided reference

board support packages (BSP) for

high-level operating systems (such

as Linux) and real-time operating

systems (such as MQX), which

Beyond Bits Vybrid Edition

include libraries and media framework

tuned to the silicon architecture.

The combination of high-efficiency

silicon design, low-leakage process

technology and software tuned for

the silicon architecture results in

low power consumption, eliminating

the need for a fan or heat sink and

helping to lower overall system BOM

cost. As an example, because the

platform architecture partitions tasks

between the applications processor

and the deterministic MCU, the ARM

Cortex-M4 core helps to improve

efficiency in industrial motor control

applications which can result in a

reduced carbon footprint.

Vybrid Product Families

The first five Vybrid families for

industrial and consumer applications

are scheduled to sample in Q3

of 2012 with production planned

for late Q4 2012 and early 2013.

Vybrid products are built around a

common set of system, analog and

digital IP blocks. The devices in each

product family are distinguishable

by their performance and peripheral

capabilities as shown in the “Vybrid

Family Details” table on page 5.

7


Vybrid VF3xx Family

Single-chip solution with dual XiP Quad SPI, dual Ethernet and

L2 switch for appliances and energy control

The VF3xx family is

the entry point into the

Vybrid portfolio and features

the ARM ® Cortex-A5 core.

It provides an efficient

solution for an applications

processor with 1.5 MB of

on-chip SRAM and a rich

suite of communication,

connectivity and humanmachine

interfaces (HMI).

Target Applications

• Home energy automation

• Low-end appliances

• Portable patient monitors

• Metering data concentrators

Mixed-Signal Capability

• Two 12-bit ADCs with configurable

resolution. Single or differential

output mode operation for improved

noise rejection. 500 ns conversion

time achievable with programmable

delay block triggering

• Two 12-bit DACs for analog

waveform generation for audio

applications or sensor manipulation

Memory

• Dual Quad SPI supporting a double

data rate interface, an enhanced

read data buffering scheme,

Execute-in-Place and support for

dual-die flashes

• Boot ROM with optional high

assurance boot for secure booting

capability

• Up to 1.5 MB on-chip SRAM with

ECC support on 512 KB

8


Vybrid V300 Block Diagram

Debug and Trace

JTAG

Trace

FlexTimer (8-ch.)



IEEE ® Timers

1588 Timers

Periodic Interrupt Timers

Low Power Timers

Memory

Boot ROM

1 MB SRAM

Memory Interfaces

NAND Flash

Controller

Quad

SPI x2

External Bus

Interface

Performance

System

AMBA NIC

Internal and

External Watchdog

Interrupt

Router

DMA

Up to 64-ch.

Power Management

Regulators

Memory Protection

Unit

• ARM Cortex-A5 core running at 266

MHz, with double precision floating

point, NEON media processing

engine for acceleration of media and

signal processing, and TrustZone

security extensions. 32 KB each of

instruction and data L1 cache and

512 KB L2 cache for optimized

bus bandwidth and on-chip SRAM

execution performance

• Up to 64-channel DMA for

peripheral and memory servicing

with reduced CPU loading and

faster system throughput

• Crossbar switch enables concurrent

multi-master bus accesses,

increasing bus bandwidth

ARM ® Cortex-A5

Up to 266 MHz

Timing and Control

• Three flex timers with a total of 12

channels. Hardware dead-time

insertion and quadrature decoding

for motor control

• Four-channel 32-bit periodic

interrupt timer provides time base

for RTOS task scheduler or trigger

source for ADC conversion and

programmable delay block

HMI

Core

DP-FPU

NEON

L1 I/D-Cache

L2 Cache

Trace/Debug

GIC

Display Security

TFT LCD

Crypytography Module

Segment LCD

Touch Screen Controller

Tamper Detect

Secure RTC

Video

Video Interface w/Camera

Secure RTIC

Audio

Secure RAM

ASRC

Secure Fuses

SAI x3

Secure WDOG

ESAI

Secure JTAG

Analog

12-bit ADC x2

12-bit DAC x2

PLL

Clocks

Clock

Monitors

Internal Reference

Clocks

Low/High Frequency

Oscillators

Communication

UART x4 CAN x2

DSPI x3 I

IEEE 1588

Ethernet x2

L2 Switch

USB OTG + PHY

LS/FS/HS

Secure Digital x1

125 GPIO

(with Interrupt)

2C x2

• TFT LCD display capable of

WQVGA resolution

• 288 segment LCD controller

• Four-wire touch screen controller for

resistive touch screens


• Xtrinsic low-power touch-sensing

interface with up to 16 inputs.

Operates in all low-power modes.

Hardware implementation avoids

software polling method. High

sensitivity level allows use of overlay

surfaces up to 5 mm thick

Multimedia

• Video interface unit with parallel

camera support for 8- and 10-bit

ITU656 video, up to 24-bit digital

RGB

• Three synchronous audio

interfaces implementing fullduplex

serial interfaces with frame

synchronization such as I2S, AC97,

and CODEC/DSP interfaces

• Optional enhanced serial audio

interface which provides a fullduplex

serial port for communication

with a variety of serial devices,

including industry-standard codecs,

SPDIF transceivers and other

processors

• Asynchronous sample rate converter

for rate conversion between 32,

44.1, 48 and 96 kHz

Connectivity and

Communications

• USB 2.0 OTG controller with

integrated PHY

• 10/100 Ethernet controllers

• Layer 2 Ethernet switch

• Four UARTs with IrDA support

including two UART with ISO7816

smart card support. Variety of data

size, format and transmission/

reception settings supported for

multiple industrial communication

protocols

• Two CAN modules for industrial

network bridging

• Three DSPI and two I2C interfaces


Reliability, Safety and

Security

• TrustZone Address Space Controllers

provide memory protection for all

masters on the crossbar switch,

increasing software reliability

• Cyclic redundancy check engine

validates memory contents and

communication data, increasing

system reliability

• Independent-clocked COP guards

against clock skew or code runaway

for fail-safe applications such as

the IEC 60730 safety standard for

household appliances

• External watchdog monitor drives

output pin to safe state external

components if watchdog event

occurs

Optional Secure

Application Support

• Cryptography acceleration and

assurance module

Supports acceleration and

off-loading for selected crypto

algorithms such as AES, DES, 3

DES, ArcFour Symmetric key blog

ciphers

• Random number generation

NIST compliant SP800-90

Combination of a true random

number generator and a pseudorandom

number generator

• Real-time integrity checker

Periodic check on system

memory for unauthorized

modifications

• Secure non-volatile storage

Secure non-rollover real-time

counter

Non-rollover monotonic counter

Zeroizable 256-bit secret key

• Tamper detection

Support for up to six external

tamper detection inputs


External Peripheral Support

• Secure digital host controller

supports SD, SDIO, MMC or

CE-ATA cards for in-application


adding Wi-Fi ® support

• NAND flash controller supports up

to 32-bit ECC current and future

NAND types. ECC management

handled in hardware, minimizing

software overhead

• FlexBus external bus interface

provides glueless interface options

to memories and peripherals such

as graphics displays. Supports up

to four chip selects

Tools and Software

• Freescale Tower System hardware

development environment

• Integrated development

environments

Reference MQX BSP

CodeWarrior V10.x (Eclipse) IDE

with Processor Expert software

ARM DS5 MDK

Runtime software

Math and encryption libraries

Motor control libraries

Lightweight media framework

Complimentary bootloaders

(USB, Ethernet, RF, serial)

Complimentary Freescale

embedded GUI software driver

for graphics LCD panels

Complimentary Freescale MQX

Cost-effective Nano SSL/

Nano SSH for Freescale

MQX RTOS

• Full ARM ecosystem

9



Single core solution with dual USB and integrated PHY

for mobility and automation

The VF4xx family features

the ARM ® Cortex-A5 core

with speeds up to 500 MHz

with 512 KB L2 cache, dual

USB 2.0 OTG controllers

with integrated PHY, 1 MB

of on-chip SRAM and a rich





• Building automation

• Gaming controllers

• Point-of-sale




output mode operation for

improved noise rejection. 500

ns conversion time achievable

with programmable delay block

triggering




Memory








capability

• Up to 1 MB on-chip SRAM with


10


Faraday F400 Block Diagram


JTAG

Trace

Timers





IEEE ® 1588 Timers



Memory

Boot ROM

1 MB SRAM


DDR Controller

NAND Flash Controller

Quad SPI x2

External Bus Interface

• 16-bit DDR controller with PHY

and ECC support capable of

DDR3/LPDDR2 800 MHz data rate

Performance

System

AMBA NIC

Internal and


Interrupt

Router

DMA

Up to 64-ch.


Regulators


Unit

TFT LCD


Video


Audio

• ARM Cortex-A5 core with

frequency up to 500 MHz, with

double precision floating point,

NEON media processing engine

for acceleration of media and


security extension. 32 KB each of










Up to 500 MHz

• Crossbar switch enables

concurrent multi-master bus

accesses, increasing bus

bandwidth


• Four flex timers with a total of 20









HMI

Core

DP-FPU

NEON

L1 I/D-Cache

L2 Cache

Trace/Debug

GIC


ASRC

SAI x4

ESAI


Tamper Detect

Secure RTC

Secure RTIC

Secure RAM

Secure Fuses

Secure WDOG

Secure JTAG

Analog

12-bit ADC x2

12-bit DAC x2

PLL

Clocks

Clock

Monitors


Clocks


Oscillators

Communication


DSPI x4 I 2 C x4

IEEE 1588

Ethernet

USB Host + PHY

LS/FS/HS

USB OTG + PHY

LS/FS/HS


141 GPIO


• TFT LCD display capable of up to

XGA resolution


• Four-wire touch screen controller

for resistive touch screens





software polling method. High

sensitivity level allows use of

overlay surfaces up to 5 mm thick

Multimedia




RGB

• Up to four synchronous audio



synchronization such as I 2 S, AC97,


• Enhanced serial audio interface

which provides a full-duplex serial

port for serial communication with

a variety of serial devices, including

industry-standard codecs, SPDIF

transceivers and other processors

• Asynchronous sample rate

converter for rate conversion

between 32, 44.1, 48 and 96 kHz



• Dual USB 2.0 OTG controller with


• 10/100 Ethernet controller

• Up to six UARTs, with IrDA support

including two UARTs with ISO7816





protocols



• Four DSPI and four I 2 C interfaces



Security

• TrustZone Address Space

Controllers provide memory

protection for all masters on

the crossbar switch, increasing

software reliability






against clock skew or code

runaway for fail-safe applications

such as IEC 60730 safety standard

for household appliances



components if watchdog event

occurs







algorithms such as AES, DES,

3 DES, ArcFour Symmetric key

blog ciphers









modifications



counter





Support for up to 10 external

passive tamper detection pins

or five active external tamper

detection pin pairs





















environments

Reference Linux BSP




ARM DS5 MDK



Media framework

Complimentary bootloaders

(USB, Ethernet, RF, serial)


embedded GUI software driver

for graphics LCD panels



Nano SSH for Freescale MQX

RTOS


11

Vybrid Family



Single core solution with dual Ethernet and L2 switch

for automation and control

The VF5xx family features

the ARM ® Cortex-A5 core

with speeds up to 500 MHz

with 512 KB L2 cache, dual

USB 2.0 OTG controllers

with integrated PHY, dual

10/100 Ethernet controllers

with L2 switch, 1 MB of





The VF5xx family is pin and

software compatible with

the VF4xx family.


• Industrial control

• Networked HVAC systems

• Portable consumer devices

• Networked audio system











Memory






12


Faraday F500 Block Diagram


JTAG

Trace

Timers








Memory

Boot ROM

1 MB SRAM




Quad SPI x2




capability



• 16-bit DDR controller with PHY and

ECC support capable of DDR3/

LPDDR2 800 MHz data rate

Performance

System

AMBA NIC

Internal and


Interrupt

Router

DMA

Up to 64-ch.


Regulators


Unit

• ARM Cortex-A5 core with

frequency up to 500 MHz, with

double precision floating point,

NEON media processing engine

for acceleration of media and


security extension. 32 KB each of





Core


Up to 500 MHz

DP-FPU

NEON

L1 I/D-Cache

L2 Cache

Trace/Debug

GIC


TFT LCD



Tamper Detect

Video

Secure RTC


OpenVG GPU

Secure RTIC

Audio

Secure RAM

ASRC

Secure Fuses

SAI x4

ESAI

Secure WDOG

SPDIF

Secure JTAG









Analog

12-bit ADC x2

12-bit DAC x2

PLL

Clocks

Clock

Monitors


Clocks


Oscillators

Communication


DSPI x4 I

IEEE 1588

Ethernet x2

L2Switch


LS/FS/HS

USB OTG + PHY

LS/FS/HS


141 GPIO


2C x4









programmable delay block

HMI


• TFT LCD display capable of XGA

resolution


resistive touch screens





software polling method

• High sensitivity level allows use of


Multimedia



ITU656 video, up to 24-bit digital RGB

• OpenVG GPU for UI acceleration








serial port for serial

communication with a variety

of serial devices, including


transceivers, and other processors

• Sony Philips Digital Interface

receives and transmits digital audio

using the IEC60958 standard

consumer format

• Asynchronous sample rate

converter for rate conversion






• Dual 10/100 Ethernet controller









protocols



• Four DSPI and four I2C interfaces


Security
















components if watchdog event occurs








DES, ArcFour Symmetric key blog

ciphers






• Real time integrity checker



modifications



counter





























environments





ARM DS5 MDK




Complimentary bootloaders (USB,

Ethernet, RF, serial)


embedded GUI (eGUI) software

driver for graphics LCD panels




RTOS


13

Vybrid Family



Dual heterogeneous core solution with XGA display, dual USB,

dual Ethernet and L2 switch for automation and HMI

The VF6xx is the

heterogeneous dualcore

family combining the

ARM ® Cortex-A5 and

Cortex-M4 cores.

It includes dual USB 2.0 OTG

controllers with integrated

PHY, dual 10/100 Ethernet

controllers with L2 switch,

1 MB of on-chip SRAM and a

rich suite of communication,




• Industrial automation

• Health care systems

• Multi-lane point-of-sale

• Buildling control











Memory


data rate interface, an enhanced read

data buffering scheme, Executein-Place

and support for dual-die

flashes



capability

14




JTAG

Trace

Timers








Memory

Boot ROM

1 MB SRAM




Quad SPI x2







Performance

Core


Up to 500 MHz

DP-FPU

NEON

L1 I/D-Cache

L2 Cache

Trace/Debug

GIC

• ARM Cortex-A5 core with frequency

up to 500 MHz, with 32 KB each

instruction and data L1 cache

and 512 KB L2 cache double

precision floating point, NEON media

processing engine for acceleration

of media and signal processing, and

TrustZone security extension

• ARM Cortex-M4 core running

up to 167 MHz, with 16 KB of

instruction/data L1 cache plus 64

KB of tightly coupled memory,

DSP support for single cycle

32-bit MAC, single instruction

System

AMBA NIC

Internal and


Interrupt

Router

DMA

Up to 64-ch.

Power

Management

Regulators

Memory

Protection

Unit

Core

ARM ® Cortex-M4

Up to 167 MHz

SP-FPU

DSP

Trace/Debug

I/D-Cache

NVIC


TFT LCD



Tamper Detect

Video


Secure RTC

OpenVG GPU

Secure RTIC

Audio

Secure RAM

ASRC

Secure Fuses

SAI x4

ESAI

Secure WDOG

SPDIF

Secure JTAG

multiple data extensions and single

precision floating point unit









Analog

12-bit ADC x2

12-bit DAC x2

PLL

Clocks

Clock

Monitors


Clocks


Oscillators

Communication


DSPI x4 I

IEEE 1588

Ethernet x2

L2Switch


LS/FS/HS

USB OTG + PHY

LS/FS/HS


141 GPIO


2C x4









programmable delay block

HMI


• TFT LCD display capable of up to

XGA resolution



• Xtrinsic low power touch-sensing


Operates in all low-power modes

(minimum current adder when

enabled). Hardware implementation

avoids software polling method.

High sensitivity level allows use of


Multimedia




RGB













transceivers and other processors





• Asynchronous Sample Rate

Converter for rate conversion






• Dual 10/100 Ethernet controller





size, format and transmission/reception


settings supported for multiple

industrial communication protocols





Security
























DES, ArcFour Symmetric key

blog ciphers









modifications



counter





























environments





ARM DS5 MDK

IAR Embedded Workbench

Runtime software and RTOS










Cost-effective Nano SSL/Nano

SSH for Freescale MQX RTOS


15



Dual heterogeneous core solution with dual XGA display,

GPU for portable systems

The VF7xx dual

heterogeneous core

solution combines the

ARM ® Cortex-A5 and

Cortex-M4 cores. Features

include dual TFT LCD

support up to XGA resolution,

dual USB 2.0 OTG controllers

with integrated PHY, 10/100

Ethernet controller, 1 MB of






• Cost-sensitive gaming systems

• Portable data terminals

• Internet appliances

• Mid-range white goods/appliances











Memory


data rate interface, an enhanced read

data buffering scheme, Execute-in-

Place and support for dual-die flashes



capability

16




JTAG

Trace

Timers








Memory

Boot ROM

1 MB SRAM




Quad SPI x2


• Up to 1 MB SRAM with ECC on

512 KB




Performance

Core


Up to 500 MHz

DP-FPU

NEON

L1 I/D-Cache

L2 Cache

Trace/Debug

GIC

• ARM Cortex-A5 core with frequency

up to 500 MHz, with 32 KB each

instruction and data L1 cache

and 512 KB L2 cache double

precision floating point, NEON media

processing engine for acceleration

of media and signal processing, and

TrustZone security extension

• ARM Cortex-M4 core running up to

167 MHz, with 16 KB of instruction/

data L1 cache plus 64 KB of tightly

coupled memory, DSP support

for single cycle 32-bit MAC, single

instruction multiple data extensions

and single precision floating point unit

System

AMBA NIC

Internal and


Interrupt

Router

DMA

Up to 64-ch.

Power

Management

Regulators

Memory

Protection

Unit


















HMI

Core


Up to 167 MHz

SP-FPU

DSP

Trace/Debug

I/D-Cache

NVIC


TFT LCD


Video


Tamper Detect


Secure RTC

Video ADC

OpenVG GPU

Secure RTIC

Secure RAM

Audio

ASRC

Secure Fuses

SAI x4

ESAI

Secure WDOG

SPDIF

Secure JTAG

Analog

12-bit ADC x2

12-bit DAC x2

PLL

Clocks

Clock

Monitors


Clocks


Oscillators

Communication


DSPI x4 I 2 C x4

IEEE 1588

Ethernet


LS/FS/HS

USB OTG + PHY

LS/FS/HS


141 GPIO


• Dual TFT LCD display capable of up

to XGA resolution




• Xtrinsic low power touch-sensing


Operates in all low-power modes

(minimum current adder when

enabled). Hardware implementation

avoids software polling method.

High sensitivity level allows use of


Multimedia



ITU656 video, up to 18-bit digital RGB













transceivers, and other processors





• Asynchronous sample rate converter

for rate conversion between 32,

44.1, 48 and 96 kHz





• 10/100 Ethernet controller







protocols






Security



masters on the cross bar switch,




















algorithms like AES, DES, 3 DES,

ArcFour Symmetric key blog

ciphers









modifications



counter





passive tamper detection pins or

up to five active external tamper























environments





ARM DS5 MDK


Runtime software and RTOS

Math, DSP and encryption

libraries











RTOS


17

Technical Highlights

Core Technology

ARM ® Cortex-A5 and ARM Cortex-M4 processors

In developing a new generation, 40 nm

integrated 32-bit family, Freescale

defined a dual-core architecture,

combining the best features of the

industry-standard ARM ® Cortex-A5

application processor with the realtime

focus of an ARM Cortex-M4

control processor. Indeed, the 32-bit

Vybrid family provides rich application

capabilities with real-time control

because each core has unique


attributes that make it the appropriate

choice for specific embedded

application spaces. The Vybrid family

is ideally suited for automotive,

industrial and general embedded

applications. This solution is highly

integrated, reducing system cost for

the target applications. It includes

a number of advanced architectural

features so it can support either MCU

or MPU configurations.

Vybrid Processor Cores and Slave Memories Block Diagram

Tag 7

(Optional)

Tag 0

0

1

Data

7

RAM

Array, 32K

Tag/Data

Arrays, 2x 8K

The processor architecture can also

be configured as a uniprocessor with

either the ARM Cortex-A5 or the ARM

Cortex-M4 as the operating core.

For markets needing a single-core

applications processor in the ARM

Cortex family, the ARM Cortex-A5 is

the best “value” application processor

(in terms of MIPS/mW). Other key

device components include a large

ARM

TPIU

CTI

DAP

® Cortex-A5 Core Complex ARM ® Cortex Core Complex

Debug (ITM, ETM, ETB, CTI)

FPU + NEON

NVIC FPU

CM4 CPU

FPB

DWT

Mul

Inst

ALU/Shift Q

Ld/St

PFU and Branch Predictor

AP Bus Matrix ITM

SystemBus CodeBus

Data uTLB Inst uTLB

TCMU

TCML

STB

D-$

TLB

4 x 8K

AXI BIU

L2 Cache Controller

AXI System Bus

64

DDRC Quad SPI

I-$

2 x 16K

OCRAM

_sys

NIC-301

OCRAM

_sys

OCRAM

_gfx

Boot

ROM

Sys-$

AHB System Bus

Sys

BIU

Code

BIU

FlexBus PBRIDGE

Code-$


RAM

Array, 32K

Tag/Data

Arrays, 2x 8K

64 64

64

AHS Code Bus AHB Backdoor Port

19


on-chip RAM, display controller units,

OpenVG graphics processing unit,

Quad SPI interfaces to external flash

memories and available RTOS. All

these components combine to provide

a low system cost BOM because

DRAM is not required.

Target applications for single-core ARM

Cortex-M4/Cortex-A5 MPU devices in

the multi-market, general embedded

space include asset tracking devices,

2D scanners, point-of-sale terminals,

networked audio and data acquisition.

In the industrial space, a single-core

ARM Cortex-A5 MPU is targeted at

industrial control, gas pumps and

building control applications. Medical

applications include patient monitoring

and drug delivery mechanisms.

A common theme in developing

a dual-core architecture for these

market segments is the inherent issues

associated with a high-performance

single (applications) processor running

a high-level operating system coupled

with the need for good real-time

control. Vybrid devices address this

growing number of consumer and

industrial embedded applications that

need higher application performance

plus real-time responsiveness with its

dual-core architecture combining the

ARM Cortex-A5 application processor

and the ARM Cortex-M4 for real-time

control.

This approach offers considerable

flexibility in partitioning the software

architecture across the dual-core

hardware resources and provides

options for reducing the RunIDD

current consumption. It also removes

the need for system designers to

specify a higher performance single

processor device in an effort to

“oversample” the real-time events,

thereby reducing system cost and

power dissipation.

20

Vybrid Core Architecture Summary Comparison

A “processor-centric” high-level

Vybrid device block diagram is

presented in the previous figure. The

basic microarchitecture includes

the dual-core structure interfacing

to the network interconnect system

bus fabric, providing the hardware

interconnect matrix and supporting a

64-bit third-generation ARM-AMBA

Advanced eXtensible Interface split

transaction protocol. This is followed


Vybrid Key

Architecture Features ARM ® Cortex-A5 ARM Cortex-M4

Instruction set architecture ARMv7-A ARMv7-ME, +-M4F (FPU)

Architecture width 32 bits 32 bits

Operating frequency

relative to platform

(2,3) x platform MHz 1x platform MHz

Integer performance

Microarchitecture

1.57 DMIPS 2.1 per MHz 1.25 DMIPS 2.1 per MHz

• Pipeline

Eight stages

Three stages

• Instruction issue

Limited superscalar (ALU + Br) Single

• Execution units

L1 processor, local memories

• Capacity, organization

VFPv3 (SP + DP FPU)

NEON SIMD

MMU, TrustZone

I-Cache, D-Cache

I-Cache = 32 KB,

2-way SA

D-Cache = 32 KB,

4-way SA

32 byte cache line size

(4 beat, 64-bit burst)

SPFPU

v7-ME (DSP + SIMD)

CodeCache, SystemCache,

TCM (Lower, Upper)

CodeCache = 16 KB,

2-way SA

SystemCache = 32 KB,

2-way SA

32 byte cache line size


TCML(ower) = 32 KB

TCMU(pper) = 32 KB

Accesses from other

masters via backdoor port

L2 processor memories Optional L2 Cache

• Capacity, organization L2-Cache = 512 KB,

8-way SA

32 byte cache line size,


System bus interface 1x 64-bit AMBA3 AXI 2x 64-bit AMBA2 AHB-Lite

On-chip RAM (OCRAM) Three 64-bit AXI ported memory controllers + arrays, 1.5 MB total

• 2x system RAM (_sys) controllers, each 256 KB in capacity,

512 KB total

Optionally includes single-bit correction, double-bit detection

(SECDED) ECC

• 1x Graphics RAM (_gfx) Controller, 1 MB total

512 Kbytes optionally used as L2 cache data array

Programmable support for on-the-fly conversion of 16-bit

pixel data to/from 32-bit ARGB8888

DDR DRAM controller 2x 64-bit AXI input ports and 16-bit external DDR data bus

Quad SPI memory controller 2x Quad SPI external memory controller

FlexBus memory controller

Gluelessly interfaces to external (non-DRAM) memories and/or

ASICs, six chip selects

by connections to a full complement of

on-chip memories and slave peripherals

connected via peripheral bridges as

well as memory controllers for external

interfaces including a multi-ported

DDR DRAM controller, dual Quad SPIs

and a FlexBus controller for glueless

interfaces to simple (non-DRAM)

memories and/or ASIC devices.


ARM ® Cortex-A5 Processor Pipeline Organization 1

Fetch 1 Fetch 2 Fetch 3

ARM ® Cortex-M3 and ARM Cortex-M4 Pipeline

For the standard configuration, Vybrid

systems can best be characterized as

a heterogeneous, symmetric, cachebased

dual-core MPU architecture.

The two ARM Cortex cores share

an instruction set architecture with

a common memory map, and the


Instruction ruc

Queue ue

Decode

1 “ARM’s Midsize Multiprocessor, Next Cortex-A5 Supports

Four-Way Coherent Multiprocessing,” Tom R. Halfhill,

Microprocessor Report, 10/26/2009

LSU branch

result

Fe De Ex

Fetch

Address

Generation

Unit

Instruction

Decode

and

Register

Read

Branch

Address

Phase

and

Writeback

Shift

Multiply

and

Divide

Branch Forwarding

and Speculation

LU Branch No Forwarded/Speculated

Issue

Addr

Gen

Data

Phase

Load/

Store

and

Branch

ALU

and

Branch

LSU Branch Result

Mul1

Shift

Delta

Cache

1

FP1

address space is effectively accessible

from either core. Memory coherency is

wholly managed by software. There is

hardware support for basic multicore

requirements including peripheral

interrupt steering plus directed

CPU interrupts for inter-processor


WR

Mul2

ALU

Delta

Cache

2

FP2

Writeback

Writeback

Writeback

FP3 FP4 FP5

communication, semaphores, run/

halt/reset control, memory protection

via ARM’s TrustZone architecture with

Freescale security extensions and

shared dual-core debug resources

including cross-triggering capabilities.

With significant amounts of both

processor-local memories (L1 core

caches, ARM Cortex-M4’s tightly

coupled memories with its backdoor

port for alternate bus master

accesses, and the optional ARM

Cortex-A5 512 KB L2 cache) and

the SoC resources associated with

on-chip RAM and boot ROM plus

the controllers for the external DDR

DRAM, Quad SPI (flash) memories

and FlexBus, the Vybrid architecture

is a high-performance dual-core

implementation, providing rich

applications in real time for a number

of growing embedded application

spaces.

21


Multicore Communication

A flexible API for communicating between

heterogeneous cores

A multicore architecture brings new

challenges to system design because

the software must be rewritten to

distribute tasks across the available

cores. In addition, all the peripheral

resources need to be properly

allocated to avoid resource contention

and share the data spaces between

the cores efficiently.

The Vybrid multicore solution with

heterogeneous cores anticipates a

customer running a high-level OS such

as Linux on the ARM ® Cortex-A5

and an RTOS such as Freescale’s

MQX on the ARM Cortex-M4.

Because of its real-time nature, the

RTOS has a priority-based preemptive

scheduler that is the heart of its

task management services. These

services could be communication and

synchronization among tasks running

on the same processor including

messaging, semaphores, mutexes

and event flags. A multicore SoC

also needs mechanisms for reliable

communication and synchronization

among tasks running on different

processing cores.

22

Multicore Communications Architecture


(Linux ® )

IPC API

Transport Layer

OS Specific Driver

The Solution: Multicore

Communication

Data Path

Freescale’s solution to the multicore

architecture with different OSs is

a multicore communication (MCC)

protocol that takes maximum

advantage of heterogeneous

asymmetric multiprocessing (AMP)

SoCs. It includes an easy-to-use API

that can be easily extended to support

additional operating systems and

features.

The MCC protocol is designed for low

latency and low overhead operation

and is optimized for embedded

environments with constrained CPU

and memory resources. To achieve this,

the protocol is exclusively implemented

using shared memory with no data

translation or message headers.

Data Path

Shared Memory


(MQX)

IPC API

Transport Layer

OS Specific Driver


Multicore, multi-OS architecture provides shared memory and message-based communication paths.

Applications communicate using a

client-server methodology. To do this,

each application participating on the

separate OS creates a connection

to a specific protocol port with one

endpoint receiving data and the

other sending data. In addition, each

endpoint has its own associated

port for each channel, similar to BSD

sockets. To simplify the design, all

communication is message-based and

avoids connection-oriented or packetbased

data streams. Messages can

be queued on the receive end up to a

configurable limit.

As shown in the figure above,

messages pass between endpoints

via bidirectional connection-less

communication channels.


A tuple (node, port) uniquely identifies

each endpoint. In addition, each

independent thread of execution

with a private memory space can

operate as a node. This implies that

a single-process RTOS like MQX will

have, at most, one node. In contrast,

a multi-process OS like Linux ® could

contain one node per process. A port

operates as a mailbox location where

data can be delivered. Each node can

utilize multiple ports and the same

port can be used simultaneously by

multiple nodes.

Implemented as a user space library,

the protocol includes an external

API and transport layer. Supported

operating systems include kernel

components that allow the protocol to

take advantage of Freescale hardware

architecture features to synchronize

shared memory access.

Hardware Architecture

The new heterogeneous AMP SoC

includes several hardware features

that allow optimal implementation of

the MCC.

The shared memory region used by

all cores has two distinct areas: one

for configuration and bookkeeping,

and the other for data buffers.

Hardware semaphores are used

as the synchronization primitive to

surround critical sections of code that

access shared memory blocks. The

hardware semaphore synchronization

is required since each core is

separately running an instance (or

instances) of the MCC library.


CPU-to-CPU interrupts signal when

new blocks are available for data

sending and when data exists

to be received. This mechanism

implements the blocking versions of

the message-send and messagereceive

API calls.

MCC Advantages

The MCC solution utilizes shared

memory as the data transport

mechanism. This design minimizes

communication latency by using

zero-copy, so data passes by

reference rather than physically

being copied.

A good example of where this low

latency can provide significant

application benefits is in network

processing. With network processing,

data transmission occurs frequently

and in large quantities based on

the high-bandwidth network traffic

that Ethernet and proprietary

communication protocols can deliver.

MCC with zero-copy can off-load

the network processing. In a typical

application, the ARM Cortex-M4 core

receives and processes complex

network data and feeds the raw data

back to the ARM Cortex-A5 core for

use by an application.


Additional use cases that can take

advantage of the Vybrid device

capabilities include:

• Segmenting real-time application

code. This involves running realtime

code on the ARM Cortex-M4

core to operate independently of

higher-latency code running on

the ARM Cortex-A5 core. The new

MCC can be used to share data

between them

• Off-loading CPU-intensive

operations. An audio software

platform may experiment with

executing audio stream parsing and

decoding on the ARM Cortex-M4

core to improve the real-time

responsiveness of the UI and other

applications running on the ARM

Cortex-A5

• Minimizing power draw. The

ARM Cortex-M4 core can be

the primary component of the

system during periods of low

CPU utilization/idling and the

ARM Cortex-A5 can be activated

during periods of high-demand or

for specific CPU-intensive tasks.

This synchronization would be

accomplished using Freescale MCC

• Partitioning sensitive code for

medical or safety reasons

23


Multimedia Subsystem

Enabling rich apps with hardware acceleration

The Vybrid multimedia subsystem

consists of the video interface unit

(VIU), display control unit, touch screen

controller, segment LCD, OpenVG

GPU and the audio subsystem.

This multimedia subsystem helps

to minimize and possibly eliminate

the need for the cores to handle

any pixels, allowing them to manage

system level tasks.

24

Multimedia Block Diagram

Display

TFT LCD


Segment LCD

Video

Video Camera Interface

Open VG GPU

Audio

ASRC

SAI x 4

ESAI

SPDIF

This section will describe the more

complex IP in the multimedia

subsystem and give a pictorial

representation of the pixel processing

of the subsystem.

Video Subsystem

VIU

The VIU provides a 24-bit parallel

interface for digital video. The VIU

accepts ITU-R BT.565-compatible

video, digital RGB and YUV444

formats on its parallel interface,

decodes it and optionally performs

processes such as down-scaling,

horizontal up-scaling, brightness

and contrast adjustment, YUV to

RGB conversion, deinterlacing and

Multimedia Pixel Processing

Digital

Input

Camera

Image Signal

Image Processing

and Scaling

Combining with Audio

Audio Compression


horizontal mirroring. The resulting

video stream is stored to system

memory for subsequent postprocessing

and displayed by a display

control unit.

The video subsystem supports both

digital and analog inputs. In the case

of digital video, the interface is directly

into the VIU module either as RGB

data or an ITU-R BT-565 compatible

YUV data stream. For composite video

the on-chip video analog decoder

(video ADC) is required, the output of

which will feed the VIU digital input.

The input formats supported for

composite video are PAL and NTSC

and up to four input channels are

muxed down to one ADC.

Image Sensor Display

Analog

Input

Video ADC

Video Interface Unit (VIU)

System Memory

Memory

Communication Network

ARM

Display Control Unit

(DCU)

RLE Decompression

of Compressed Image

in Memory

Run Length Encoder (RLE)

Lossless Decompression

Separation from Audio

Audio Decompression

Display Enhancement

Video/Graphics Combining

Graphics

Acceleration

Rotation

ColorSpace

Conversion

Graphic Processing Unit

(GPU)

Hardware Accelerated


OpenVG GPU Subsystem Block Diagram

AHB

Features

• Supports QVGA to XGA

• Input options:

8/10-bit ITU656 video

Up to 24-bit digital RGB

• Scaling:

Command

System

Up to 1/8 video down-scaling with

different scaling ratios in horizontal

and vertical directions

Up to 2x video up-scaling in

horizontal direction

• Brightness and contrast adjustment

• YUV to RGB888 or RGB565

conversion

• De-interlace function

OpenVG GPU

The vector graphics processing is

based on the Vivante GC355 core

supporting the OpenVG1.1 API. Using

a vector graphics core, Vybrid devices

support applications that require flash

acceleration or UI acceleration.

Features

• Real-time hardware curve

tesselation of lines, quadratic and

cubic Bezier curves

• 16x line anti-aliasing

• OpenVG 1.1 support

• Vector drawing


Vector Graphics

Pipeline

Tessellation

Engine

GC355

Texture +

Gradient

Unit and

Cache

Pixel

Backend

MMU

System

Interface

Display Subsystem

Display Controller Unit

The display controller unit (DCU) is

the interface to TFT LCD displays.

It generates all the signals required

to drive the display. Layer data is

stored in on-chip or external memory

and is fetched by the internal DMA

channels of the DCU. The layer

data is described using layer control

descriptors that form part of the

register set of the DCU.

Features

• Resolutions supporting up to XGA

(1024x768)

• Generates full RGB888 data and

control signals for TFT display

• Direct blitting engine with real time

alpha-blending

• Blending of each pixel using up to

six source layers

• Total of 64 graphics layers

• Gamma correction with 8-bit

resolution on each color component

• Temporal dithering

• Window feature allowing easy

cropping and horizontal scrolling

with low CPU overhead


AXI

Audio Subsystem

The audio subsystem has IP to

provide options for everything from

asynchronous sample rate conversion

to a stereo transceiver that can receive

and transmit digital audio.

Synchronous Audio Interface

Synchronous audio interfaces (SAI)

are used to transfer audio data.

The SAI supports full-duplex serial

interfaces with frame synchronization

such as I 2 S, AC97 and CODEC/ DSP

interfaces.

Features

• Transmitter with independent bit

clock and frame sync supporting

one data line

• Receiver with independent bit clock

and frame sync supporting one data

line

• Word size programmable from 8- to

32-bit

• Asynchronous 64/32 x 32-bit FIFO

for each transmit and receive data

line

25


Enhanced Serial Audio Interface

The enhanced serial audio interface

(ESAI) provides a full-duplex serial

port for communication with a variety

of serial devices including industrystandard

codecs, SPDIF transceivers,

and other processors. The ESAI

consists of independent transmitter

and receiver sections, each section

with its own clock generator.

Sony/Philips Digital Interface

The Sony/Philips Digital Interface

module is a stereo transceiver that

allows the processor to receive and

transmit digital audio over it using

the IEC60958 standard, consumer

format.

Features

• SPDIF receiver

Input sample rate measurement

Supports the following sampling

rates: 32, 44.1, 48, 64, 88.2 and

96 kHz

CD text support

CS and U bit recovery

• SPDIF transmitter

One SPDIF output, IEC 60958


CS bit support

• Low-power mode

SPDIF can be disabled to save

power when not in use

26

Audio Subsystem Block Diagram

ASRC

External

(Virtual) Clocks

SAI3

SPDIF

Asynchronous Sample Rate

Converter

The incoming audio data may be

received from various sources at

different sampling rates. The outgoing

audio data may have different

sampling rates and it can also be

associated to output clocks that are

asynchronous to the input clocks. The

asynchronous sample rate converter

(ASRC) converts the sampling rate of

a signal associated with an input clock

into a signal associated to a different

output clock. The ASRC supports

concurrent sample rate conversion of

up to 10 channels of about -120 dB

THD+N.

SAI2 SAI1 SAI0

ESAI_FIFO

ESAI


Legend

Data/Control

Audio I/F

Audio Clocks

Dedicated

Audio

Modules

Features

• Supports up to 10 channels split

into up to three sampling rate

conversion sets

• Individual association of each

channel to one of the sampling rate

pairs

• Designed for rate conversion

between 32, 44.1, 48 and 96 kHz.

The useful audio signal bandwidth is

below 24 kHz

• Other sampling rates in the range

of 8 to 200 kHz are also supported,

but with reduced audio performance

• Automatic accommodation to slow

variations in the incoming and

outgoing sampling rates

• ASRC has a disable mechanism to

save power when not in use


Security Subsystem

Secure your applications in an insecure world

Security is an increasingly

important feature for industrial

and consumer applications as the

number of hacking incidents that

expose sensitive information and

unauthorized use of copyrighted

content is on the rise. Helping to

ensure secure applications is a

high priority for the Vybrid platform.

Sensitive information and digital rights

management data can be stored in a

protected manner and used, allowing

e-commerce and advanced contentbased

subscriber services.

Security Block Diagram

Security


(CAAM)

Tamper Detect

Secure RTC

Real-Time Integrity

Checker (RTIC)

Secure RAM

Secure Fuses

Secure WDOG

Secure JTAG


Security Subsystem:

A Trusted Platform

The foundation of a secure system

consists of the hardware platform

and the critical code that executes on

that platform. This foundation is built

with an on-chip ROM-based boot-up

process that initiates validation of the

platform, including the following tasks:

• Examining key hardware elements

to help ensure that they are

functioning properly

• Verifying the authenticity and

integrity of the critical code that

controls the overall operation of

the system

The boot process gains control of

the system immediately after reset

by executing known boot code that

is resident in the on-chip ROM. After

verifying the authenticity of a start-up

script residing in external memory (i.e.,

NOR or NAND flash) the boot process

follows that script using established

cryptographic techniques to validate

the authenticity and integrity of the

operating system code and data in

external memory.


More flexibility is achieved by using

electrically programmable fuses to

enable or disable particular system

functions. For example, it is possible

to configure a production version,

security-enabled device so that

the JTAG debug port is completely

disabled. For early prototype devices,

portions of the security system can be

selectively disabled, allowing access

to otherwise inaccessible areas of the

device. Full flexibility between these

two extremes is possible.

Software that is security aware is

imperative for those products that

need security. Sensitive data in

plaintext form must not appear on

external data buses, and it should be

restricted to the minimum number of

data paths internal to the chip.

High Assurance Boot

The high assurance boot (HAB) feature

in the system boot ROM protects the

platform from executing unauthorized

software (malware) during the boot

sequence. Unauthorized software can

enter the platform during upgrades or

re-provisioning or when booting from

USB/UART connections or removable

devices. If permitted to gain control

of the boot sequence, unauthorized

software can be the attack vector for

a variety of goals including exposing

stored secrets, circumventing access

controls to sensitive data, services or

networks and re-purposing the

27


platform. HAB supports booting the

device to a known initial state by

using digital signatures to recognize

authentic software and running

software signed by the device

manufacturer.

In addition, HAB can protect the

confidentiality of software during

off-chip storage by decrypting the

software loaded into RAM prior

to execution. The figure to the

right shows HAB encrypted boot

supported on the Vybrid platform.

The software image is encrypted

using a secret key before being

programmed on the off-chip memory

(typically flash). During boot, HAB

uses the same secret key (stored

in hardware fuses not visible to the

user) to decrypt the software image.

Hardware Security

Elements

Vybrid platform security architecture

includes the following hardware

components:





algorithms

Supports NIST SP800-90

compliant hardware random


16K secure memory (automatic

zeroization) with up to four

independent partitions

Supports AES, DES, 3 DES,

ArcFour Symmetric key blog

ciphers

Supports MD5, SHA-1, SHA-224,

SHA-256 hashing algorithms




number generator and a

pseudo-random number

generator

28

Encrypted High Assurance Boot

Encryption Using

Secret Key

SW Image

Encrypt

(AES)

Encrypted

SW Image

Build Environment Device Boot

Secret Key

Manufacturing

OTP Key

CAAM (AES)




modifications

Supports up to four memory

regions

Use SHA-1 or SHA-256 as

hashing algorithm

Once started, RTIC can only be

stopped and restarted by trusted

software



counter



Support for tampers

• Tamper Detection

Support for up to six external

tamper detectors

Active tamper detection

Wire mesh tamper

Voltage, temperature and clock

tamper detectors

Key Blob

Flash

OTP Key


Secret Key

Decrypt

(AES)

Key Blob

Decryption Using

Secret Key

Decrypted

SW Image

Decrypt

(AES)

Encrypted

SW Image

• TrustZone Address Space Controller

Supports 2, 4, 8 or 16

independent address regions

Access controls are

independently programmable for

each address region

Protects all AXI slave

memories—DDR, on-chip SRAM

All AHB slave memories,

FlexBus, Quad SPI are protected

by AHB equivalent address

space controller

• Other security sub-blocks

Secure fuses (OTPs)

Central security unit

AHB TrustZone Controller

Trust Zone Watchdog

Secure JTAG Controller



Programmable power options for performance

and long battery life

The Vybrid platform was designed with

power efficiency as one of its main

goals. To reduce current consumption,

the design has:

• Dynamic power management of

core and peripherals

• Software-controlled clock gating of

peripherals

• Multiple power domains and voltage

scaling to minimize leakage in lowpower

modes

Vybrid devices have a power

management unit supporting a variety

of operating modes to optimize SoC/

application power consumption.

There are nine modes of operation

to allow the user to optimize

power consumption for the level of

functionality needed as well as several

wakeup sources for the power modes.

A low-leakage wakeup unit has up

to eight internal peripheral wake-up

sources, as well as up to sixteen

external pins for wakeups. Several

wakeup sources are available in the

lowest power mode: low-power timer,

real-time clock, ADC, DAC and several

pin interrupts. Depending on the

requirements of the user application, a

variety of stop modes are available that

provide state retention, partial power

down and/or full power down of certain

logic and/or memory. I/O states are

held in all modes of operation except

power gated modes (LPSTOP1,

LPSTOP2, LPSTOP3). I/O state for

16 wakeup pads is still retained in

power gated modes.


Modes of Operation

Modes General Description

General Description Normal Normal Recovery Recovery Method

Method

RUN

RUN

All functionality of Faraday is available

All functionality of Vybrid platform is available N/A

N/A

WAIT CA5 and CA5 CM4 and cores CM4 Halted cores halted Interrupt Interrupt

LPRUN 24MHz 24 operation, MHz operation, PLL Bypass PLL bypass Interrupt Interrupt

ULPRUN

ULPRUN

STOP

STOP

LPSTOP3

32/128 kHz operation, PLL off Interrupt

32kHz /128kHz operation, PLL Off Interrupt

Lowest power mode with all power retained,

Lowest power mode with all power retained, RAM

Interrupt

RAM retention and LVD protection

Interrupt

retention and LVD protection

64K RAM retention. I/O states held.

64K (tbd)

ADCs/DACs

RAM retention.

optionally

I/O states held. ADCs/DACs

Wake-up/Reset

FPO power-gated. RTC Wakeup/Reset

optionally power-gated. RTC functional. Wakeup from

interrupts functional. Wakeup from interrupts

LPSTOP2

LPSTOP2

16K RAM retention. I/O states held.

16K (tbd) RAM retention. I/O states held. ADCs/DACs

optionally ADCs/DACs power-gated. optionally RTC functional. power-gated. Wakeup from RTC

interrupts functional. Wakeup from interrupts

Wake-up/Reset

Wakeup/Reset

LPSTOP1 I/O states I/O states held. ADCs/DACs held. ADCs/DACs optionally powergated. optionally RTC

Wake-up/Reset

LPSTOP1 functional. powergated. Wakeup from RTC interrupts functional. Wakeup from Wakeup/Reset

Battery All supplies interrupts OFF, SRTC, 32kXOSC ON, tampers and monitors

POR

Backup ON. All supplies OFF, SRTC, 32k XOSC ON,

Battery Backup

tampers and monitors ON.

POR

LPRUN and ULPRUN are part of RUN Mode and there are no separate modes.

Features

• Single 3.3V+/-10% supply voltage

• High-power voltage regulator

with an external ballast transistor

generating internal 1.2V supply

voltage, 1.2A capacity and

quiescent current less than 1 mA

• Ability to switch supply voltage

down from 1.2 to 1.1V in lowpower

modes to minimize power

consumption

• Soft start of main high-power

regulator to minimize in-rush

currents. Start-up time < 500 us

• Low-power regulator: For Stop

modes. 50 mA capacity and

quiescent current < 50 uA


• Ultra-low power regulator: For

LPStop modes. 10 mA capacity and

quiescent current < 5 uA

• Well bias generator to increase well

by ~300mV to minimize leakage in

low-power modes

• Multiple power domains and power

gating to minimize low-power

consumption

• Low voltage detection (LVD) on main

supplies and 1.2V supplies

• 16 wakeup pins for low-power

wakeup

• The single 3.3V supply is used in

the system for I/O power with the

exception of the DRAM interface.

The DRAM interface power will

be generated external to the

Vybrid SoC

29


Power Domains

The Vybrid SoC is divided into six

power domains: PD 4:0 and Vbat.

• PD4: Main power domain. Contains

full platform, cores, peripherals,

clocking, PLLs and main 24 MHz

XOSC. This domain is power

gated off during LPSTOP modes

of operation to minimize leakage

power

• PD3: ADC-DAC domain: This

domain can be optionally powered

off in LPSTOP modes depending

if powered, ADC and DAC

conversions can be performed in

LPSTOP modes

• PD2: 48 KB SRAM power domain:

This domain can be optionally

powered off in LPSTOP modes

depending on the amount of SRAM

that needs to be maintained

• PD1: 16 KB SRAM power domain:

This domain can be optionally

powered off in LPSTOP modes if no

SRAM retention is required

• PD0: Always-on logic domain: This

domain is always powered on in

LPSTOP modes. It has wakeup

logic, 24 MIRC, 128 KHz IRC and

the voltage regulators

• VBat: Battery/RTC domain: Contains

the SecureRTC, 32 kHz XOSC,

tamper and monitors. Powered by

a coin cell when the main power

supply is switched off

30

PMU Block Diagrams

3.3V

LVDs

POR

Regulator

Coin Cell

HPreg

1.2V

External ballast

LPreg

1.2V

Internal ballast

ULPreg

1.2V

Internal ballast

2.5V LDO I/O and Analog

1.1V LDO Analog

3.3V LDO

1.1V LDO


Main Power Domain:

Core, platform, memories,

graphics, peripherals,

clocks, PLLs

ADC/DAC Domain:

2x DAC, 2X ADC

SRAM Domain1:

48k SRAM

SRAM Domain0:

16k SRAM(tbc)

Always-on Domain:

Wakeup LPTim

Battery Domain:

SRTC, 32 kHz,

Tampers, monitors

PD4

PD3

PD2

PD1

PD0


Ethernet Subsystem

Real-time networked measurement and control

Vybrid devices, depending on the

particular family, have dual Ethernet

controllers and an L2 switch. The

dual Ethernet controller modules, in

conjunction with an external Ethernet

PHY, are used to add Ethernet

connectivity. Hardware IEEE ® 1588

time stamping provides precision

clock synchronization for real-time

control in networked automation, test

and measurement applications. Midto

high-end industrial applications

typically use dual Ethernet controllers.

One Ethernet MAC can be used to

manage the control nodes while the

other Ethernet MAC can be used to

connect to a remote sever for control

or for redundancy. Most industrial

Ethernet options (i.e., Profinet IRT or


Application I/F Application I/F


uDMA

+ AHB I/F

uDMA

+ AHB I/F

3

0

Profinet IRT+) require determinism,

where IEEE 1588 is the enabling

feature. Dual Ethernet with the L2

switch allows daisy chaining which

would otherwise need an expensive

external switch. The function of the L2

switch is to route packets from one

Ethernet port to the other Ethernet

port without any CPU intervention.


Features

• Dual 10/100 Ethernet MAC (MAC-

NET)

Hardware support for IEEE 1588

standard for a precision clock

synchronization protocol for

networked measurement and

control systems

L2 Switch

2

1

Receive

FIFO

Transmit

FIFO


Ethernet MAC

TOE Functions

TCP/IP

Performance

Optimization

TCP/IP

Performance

Optimization

Reduced media independent

interface (RMII) support

Interfaces with unified DMA

Supports wakeup from lowpower

mode through magic

packets

Multiple clock source options for

time-stamping clock

• L2 Ethernet switch

3-port switch

Supports two MAC-NETs

Supports 64-bit Atlantic/FIFO

ports

IEEE 1588 support

Fast cut-through mode

QoS with eight queues per port

Port mirroring

Level 3 IP snooping

Configuration

Statistics

Register Interface

• Dual unified DMA

RX Control

CRC

Check

CRC

Generate

Pause

Frame

Terminate

TX Control

Pause

Frame

Terminate

MDIO

Master

MII/RMII

Receive

Interface

MII/RMII

Receive

Interface

PHY

Management

Interface

31


32

On-chip transmit and receive

FIFOs

Supports legacy buffer

descriptor programming models

and functionality

Enhanced buffer descriptor

programming model for new

Ethernet functionality


Clocking Options

The Ethernet subsystem uses the

following clocks:

• Dedicated on-chip PLL with fixed

multiplier to generate 50 MHz RMII

Ethernet clock. This clock also

comes as chip output and goes to

off-chip Ethernet PHY

• Optional externally-supplied 50 MHz

RMII clock. This clock is used as

the timing reference for the RMII

interface

• A time-stamping clock for the IEEE

1588 timers

IEEE 1588 Timers

The Ethernet module includes a fourchannel

timer module for IEEE 1588

time stamping. The timer supports

input capture (rising, falling or both

edges) and output compare (toggle

or pulse with programmable polarity).

The counter is able to operate

asynchronously to the Ethernet bus

by using one of the clock sources.

Ethernet Operation in

Low-Power Modes

Ethernet-Only Operation

The Ethernet MAC supports magic

packet detection that can generate a

wakeup in low-power mode. During

low-power operation:

• The MAC transmit logic is disabled

Adjustable Timer

ENETn_ATPER

Correction

Counter

ENETn_ATINC

ENETn_ATINC

[INC_COR]

Counter

Mod

• The core FIFO receive/transmit

functions are disabled

• The MAC receive logic is kept in

normal mode but it ignores all traffic

from the line except magic packets

Dual Ethernet and L2 Switch

Operation

In low-power STOP mode, the

MAC stops immediately and freezes

register values, state machines and

external pins. During this mode,

the Ethernet subsystem clocks are

shut down. Coming out of STOP

mode returns the Ethernet MAC

to operating from the state prior to

STOP mode entry.

External

Free-Running

Counter

ENETn_ATINC

[INC]


ENETn_ATCR

[SLAVE]

To MAC

Dual Ethernet and L2 Switch

Bypassed

In low-power STOP mode, the MAC

stops immediately and freezes register

values, state machines and external

pins. During this mode, the Ethernet

subsystem clocks are shut down.

Coming out of STOP mode returns the

Ethernet MAC to operating from the

state prior to STOP mode entry.

Battery Mode of Operation

The Ethernet MAC does not support

any standby mode of operation or a

capability to operate on battery power

in case the main supply fails. The

MAC will be disabled during

this mode.


USB Subsystem

Flexible USB connectivity with integrated PHY

The USB subsystem in Vybrid devices

is comprised of several blocks

that together provide flexible USB

functionality. The USB subsystem

includes:

• Dual USB On-The-Go (OTG)

2.0 compliant controller (specific

controller depends on the device).

Options are: High-Speed (HS), Full-

Speed (FS) and Low-Speed (LS)

• Dual on-chip HS USB PHY

• USB regulator

USB Controller

The USB controller is a USB

2.0-compliant serial interface engine

for implementing a USB interface. The

USB controller provides USB host

and device communications along

with support for OTG operation. The

controller supports HS, (480 Mbps),

FS (12 Mbps) and LS (1.5 Mbps)

data transfer rates. The registers and

data structures are based on the

enhanced host controller interface

specification (EHCI) for USB standard.

The USB OTG module can act as a

host or device. The USB controller

is programmable to support host or

device operations under firmware

control. On-chip HS PHY is used

for the 60 MHz clock source to the

controller. The USB controller provides

control and status signals to interface

with external USB OTG and USB

host power devices. Customers can

use these control and status signals

on the chip interface and the I 2 C bus

to communicate with external USB

On-The-Go and USB host power

devices. USB host modules must

supply 500 mA with a 5V supply

on its downstream port (referred to


USB OTG/HOST PHY Architecture

BIAS

PLL

Common

Block

OTG

as VBUS), however, the USB OTG

standard provides a minimum 8 mA

VBUS supply requirement. If the

connected device attempts to draw

more than the allocated amount of

current, the USB host must disable the

port and remove power. USB VBUS is

not provided on-chip. The Vybrid SoC

provides pins for control and status to

an external IC capable of managing

the VBUS downstream supply.


HS/FS/LS

Receivers

Squelch/

Disconnect

Clock

Buffers

Receiver

Transmitter

Local Bias

D+/D- Pull-up/

Pull-down Logic

HS/FS/LS

Transmitters

Single-Ended

Receivers

Analog Block

HS/FS/LS

Receivers

Squelch/

Disconnect

Clock

Buffers

Receiver

Transmitter

Local Bias

D+/D- Pull-up/

Pull-down Logic

HS/FS/LS

Transmitters

Single-Ended

Receivers

Analog Block

Test

Interface

HS DLL

Elasticity

Buffer

FS DPLL

HS

FS

Transceiver

MUX

Test

Interface

HS DLL

Elasticity

Buffer

FS DPLL

HS

FS

Transceiver

MUX

SYNC

Detector

MUX

FS/LS

NRZI

Decoder

NRZI

Encoder

Bit

Unstuffer

Receive

State

Machine

Transmit

State

Machine

Bit

Stuffer

USB 1.1

Transceiver

FS/LS

Digital Block

SYNC

Detector

MUX

FS/LS

NRZI

Decoder

NRZI

Encoder

Bit

Unstuffer

Receive

State

Machine

Transmit

State

Machine

Bit

Stuffer

USB 1.1

Transceiver

FS/LS

Digital Block

Rx Shift

and Hold

Control

Logic

Tx Shift

and Hold

Rx Shift

and Hold

Control

Logic

Tx Shift

and Hold

For OTG operations, external circuitry

is required to manage the host

negotiation protocol (HNP) and session

request protocol (SRP). External ICs

that are capable of providing the OTG

VBUS with support for HNP and SRP,

as well as support for programmable

pull-up and pull-down resistors on the

USB DP and DM lines, are available

from various manufacturers.

33


Features

• Complies with USB specification

rev 2.0

• USB host mode

Supports EHCI

34

Supports HS operation using

internal on-chip HS PHY

Supported by Linux ® and other

commercially available operating

systems

• USB device mode

Supports HS operation using

internal on-chip HS PHY

Supports FS/LS operation using

internal HS PHY

Supports one upstream facing

port

Supports six programmable,

bi-directional USB endpoints,

including endpoint 0

• Suspend mode/low-power

As host, firmware can suspend

individual devices or the entire

USB and disable

Chip clocks for low-power

operation

Device supports low-power

suspend

Remote wakeup supported for

host and device

Integrated with processor doze

and stop modes for low-power

operation

Start of Frame

USB audio use cases require some

sort of audio clock recovery capability.

The Vybrid system USB OTG controller

supports use of the start of frame

(SOF) signal, which is generated at

the start of a microframe in the USB

2.0 HS protocol. This is a signal with

a rate of 125 microseconds. When

operating in full-speed mode, the SOF

SOF Implementation on the Vybrid Platform

USB OTG 0

USB OTG 1

USB0 SOF

USB1 SOF

signal has a rate of 1 ms pulse that

asserts for 64 system clock cycles

when the SOF token is detected on

the USB bus and the USB controller is

in device mode.

In order to properly support USB audio

isochronous asynchronous mode of

operation, it is necessary to measure

how many audio sample clock ticks

occur between two consecutive

occurrences of the SOF signal. This

measurement is used to provide

feedback to the USB audio source in

order to speed up or slow down the

audio sample delivery over the USB

bus.

This is the method of estimating the

ratio between the USB host clock

(SOF occurrences) and the Vybrid

device local audio clock.

The figure above shows the USB SOF

connectivity with FlexTimer to enable

this scheme.

FTM0

FTM1

FTM2

FTM3


64 Cycles

Pulse

Stretcher

64 Cycles

Pulse

Stretcher

1. The two SOF signals (one from each USB port) must be brought to two timer

channels of one FlexTimer. This flexibility is provided in FTM2 and FTM3 as

shown in figure.

2. At least one of the SOF should be connected to one channel of a second

FlexTimer. This will allow measuring of two sets of audio clock/SOF signals.

To accommodate this, the USB0 SOF is connected to all FlexTimers.

USB OTG/HOST PHY

Architecture

USB0 SOF_PULSE

USB1 SOF_PULSE

Audio Master Clock should also be provided as one of the clock options to FlexTimers.

The USB OTG HS PHY is a HS/FS/

LS USB 2.0 PHY, integrated with the

controller.

The USB OTG HS HY comprises two

USB 2.0 transceiver sub-modules, one

OTG sub-module and one common

module shared between USB OTG

and USB H1 channels.

USB OTG PHY Features

• Complete physical interface module

for USB 2.0 On-the-Go

• UMTI+ Level 3 specification compliant

• Supports USB HS (480 Mbps), FS

(12 Mbps) and LS (1.5 Mbps)

• Host, slave and OTG dual role device

operational modes of OTG port

• Host modes of host port

• Integrated self-calibrated

termination resistors for HS mode

and full set of pull-up/pull-down

resistors defined by USB 2.0

electrical requirements


Memory Subsystem

Flexible memory hierarchy for optimal code footprint,

security and BOM cost

Vybrid devices have multiple memory

interface options. In addition to

having up to 1.5 MB of on-chip

SRAM for speedy code execution,

Vybrid devices can interface to a

variety of external peripherals and

memories for system expansion

and data storage. Dual Quad SPI

interfaces with Execute-in-Place (XiP)

support can interface with the latest

flash memory. A secure digital host

controller supports SD, SDIO, MMC

or CE-ATA cards for in-application

software upgrades as well as media

files or adding Wi-Fi ® support. NAND

flash and DRAM controllers with ECC

support allow connection to a wide

variety of memory types for critical

applications. Battery-backed RAM is

critical for secure systems to store

authentication keys. Vybrid devices

provide 16 KB of secure RAM and the

platform provides 96 KB ROM for high

assurance boot.

The “Vybrid Memory Hierarchy”

diagram illustrates the memory

hierarchy of Vybrid devices and the

various memory interfaces.


Tag 7

(Optional)

Vybrid Memory Hierarchy

Tag 6

0

0

Data

7

ARM ® Cortex-A5 Core Complex

ITM + ETM + ETB + CTI

FPU + NEON

Inst

Alu/ Q

Mul Ld/Sc Shift

Data uTLB

STB

D-$

4 x 8K

AXI System Bus

TLB

AXI-BIU

PFU & Branch

Predictor

Inst uTLB

L2 Cache Controller

Vybrid DRAM Controller

I-$

2 x 16K

NIC-301

SDIO x2 NAND Flash DDRC Quad SPI x2 OCRAM

_sys

Network

Inter-Connect

(NIC)

64-bit AXI

64-bit AXI


64

64

Multi-Port

Arbitration

Arbitration

Engine

OCRAM

_sys

OCRAM

_gfx

TPIU

DAP

DRAM Memory Controller

Command

Queue

Ordering

Engine

Write

Queue

Read

Queue

Transaction

Processing

Sequence

Engine

Performance

and Power

Tuning

Registers

RAM

Array, 32k

Tag/Data

Arrays, 2x 8k


Core Complex

NVIC

FPU

CM4 CPU

FPB

DWT CTI

AP Bus Matrix ITM

System Bus Code Bus

TCMU

Sys-$

Sys BIU Code BIU

TCML

Code-$

RAM

Array, 32k

Tag/Data

Arrays, 2x 8k

64 64 64

AHB System Bus AHB Code Bus AHB Backdoor Port

Boot

ROMx2

DFI Interface DFI Interface

FlexBus PBRIDGE

PHY

Interface

DLL

ECC

Device

Interfaces

DRAM

DDR3

LPDDR2

35


Vybrid DRAM Controller

The Vybrid DRAM controller offers

connectivity with application interfaces

on one side and DRAM memory on

the other.

Vybrid DRAM Features

• Supports 8-bit and 16-bit DRAM

memories

• Supports two 64-bit AXI port slave

interfaces

• Support for synchronous and

asynchronous modes

• Supports components up to 8 GB

• Supports LPDDR2 (S2 and S4) and

DDR3

Supported LPDDR2 grades:

LPDDR2-800 and under

Supported DDR3 grades:

DDR3-800

• ECC support (only for 8-bit DRAM

interface)

• DFI interface to PHY

Quad SPI

Vybrid device’s QuadSPI implements a

Double Data Rate interface, enhanced

read data buffering schemes, XiP

and support for dual-die flashes.

Quad serial flash memories with DDR

interfaces are available on the market

with throughput up to 66 Mbps

peak data rates. With a dual Quad

SPI architecture this is increased to

132 Mbps. An enhanced read data

buffering architecture, minimizes the

latency impact of cache misses. Only

the CPU will access the Quad SPI in

the XiP mode of operation. The

36

Vybrid NAND Flash Controller Block Diagram

boot_after_reset

lpg_clk

lps_clk

reset_b

IPS BUS CPU Access Bus

boot_done

Boot

Control

CMD

Data

Control

Register

Config

Addr

Dec.

DMA

Control

boot_fail

IPM DMA Bus

boot_mode

external serial flash can be used at

runtime for data storage (graphics,

fonts etc.). It can also contain the

application code image that will be

copied to external DRAM at boot.

Residue

Generation

Control

BCH Encoder

Seven ECC

Modes

ECC Control

BCH

Decoder

Quad SPI Features

• Double data rate support for

Spansion (data learning) and

Macronix (DTR2 mode) serial flash

• XiP

• Multi-master buffering support

• Up to four independent master

channels

• Support for dual-die packages with

two chip selects

SRAM

Control


SRAM

Buffer

BUS

SRAM Buffer

9 KB

NAND FLASH CONTROL

EMB IF


The NAND flash controller (NFC)

interfaces standard NAND flash

devices with Vybrid devices and hides

the complexities of accessing the

NAND flash. It provides a seamless

interface to both 8- and 16-bit NAND

flash parts with page sizes of 512

bytes, 2 kilobytes, 4 kilobytes and

8 kilobytes.

There are two specific use-cases for

NAND flash usage with Vybrid devices.

a) Boot from NFC: This allows systems

to directly boot from external NAND

memory. Bootloader may either

reside in ROM or external NAND

device while the OS kernel would be

part of external NAND memory.

irq

NFC_IO[15:0]

NFC_CLE

NFC_ALE

NFC_CEn

NFC_RE

NFC_WE

NFC/R/Bn

REQ

IDLE

GRT


Secure Digital Controller

For the cases where ROM includes

the bootloader (most likely), the

system will boot from ROM, jump

to external NFC and continue

loading the OS kernel. For the cases

where a bootloader as well as OS

kernel resides in the external NAND

memory, system will switch to

external NFC after ROM initialization.

b) NFC for bootloader: After ROM

initialization, system switches to

external NAND device to load the

bootloader.

Features

• NAND flash interface: 8-bit/16-bit

• Supports all NAND flash products

regardless of density/organization

(with page sizes of 512+16B/2K+64

B/4K+128B/4K+218B/8K)

• Supports flash device commands

such as page read, page program,

reset, block erase, read status, read

ID, copy-back, multi-plane read/

program, interleaved read/program,

random input/output and read in

EDO mode, but is not limited to

these commands


Enhanced Secure Digital Host Controller

DMA

Interface

AHB Bus

IP Bus

Transceiver

IP Gasket

IP Bus

• Two configurable DMA channels

• Bypassable ECC mode, NFC

supports 4/6/8/12/16/24/32-bit

error correction

Secure Digital Controller

The SD host controller version

provides an interface between the

host system and SD, SDIO, MMC or

CE-ATA cards. The module has a builtin

transceiver as shown in the figure

above. The SDHC acts as a bridge,

passing host bus transactions to SD/

SDIO/MMC/CE-ATA cards by sending

commands and performing data

accesses to/from the cards. It handles

SD/SDIO/MMC/CE-ATA protocols at

the transmission level.

The SD card is designed to meet the

security, capacity, performance and

environmental requirements inherent

in newly emerging audio and video

consumer electronic devices. The

physical form factor, pin assignment


Card

and data transfer protocol are forward

compatible with the multimedia card

with some additions.

The Vybrid family has two SDHC

controllers, supporting up to an 8-bit

interface for high-speed MMC/SDIO

cards.

SDHC Features

• Conforms to SD Host Controller

Standard Specification version 2.0

• Compatible with the MMC System

Specification version 4.2

• Compatible with the SD Memory

Card Specification version 2.0

• Supports high capacity SD memory

card

• Compatible with the SDIO Card


• Compatible with the CE-ATA Card


• Supports 1-bit/4-bit SD and SDIO

modes, 1-bit/4-bit/8-bit MMC

modes, 4-bit/8-bit CE-ATA devices

• Up to 200 Mbps data transfer for

SD/SDIO cards using four parallel

data lines

• Up to 416 Mbps data transfer for

MMC cards using eigiht parallel data

lines

37


FlexBus

The FlexBus interface on the Vybrid

devices is designed to gluelessly

connect with up to six external

devices. Each version has 8-, 16- and

32-bit port sizes with configuration

for multiplexed or non-multiplexed

addresses and data buses.

Features

• Byte-, halfword-, word- and 16-byte

line-sized burst transfers

• Programmable burst and burst

inhibited transfers selectable for

each chip select and transfer

direction

• Auto-acknowledge feature

Primary wait state counter up to

63 clocks

Optional secondary wait state

counter

Useful for interfacing to burst

memories that have a long

access time for the first beat of

data, but can deliver subsequent

data faster

• Programmable address setup time

with respect to the assertion of chip

select

• Programmable address hold time

with respect to the negation of chip

select and transfer direction

Flexbus supports the connection to:

• Flash

• Smart LCDs

• FPGAs

• SRAM

• PROM

• EPROM

• EEPROM

38

FlexBus Modes of Operation of Operation

Non Muxed Mode

FlexBus Key Features Customer Benefits


8-, 16-, 32- and 128-bit line sized transfers Maximize throughput according to the specific

application

Programmable burst and burst-inhibited transfers

selectable for each chip select and transfer

direction

Optimized traffic patterns for each client in

the bus

Auto-acknowledge feature Increased flexibility and lower BOM costs in

glueless external device connections

Programmable address-setup time

Programmable address-hold time

Data Data Data Data

Address Address Address Address

Data and Address Have Separate Ports

Muxed Mode

Address Data Data Address

Data and Address Are Interleaved on the Same Port

Smart LCD Mode

Data Data Data Data

Data Is Sent Sequentially on One Port


The universal asynchronous receiver/

transmitter (UART) module in Vybrid

devices allows for asynchronous,

full-duplex serial communication in a

variety of formats.

Features of the UART include:

• Standard mark/space non-return-tozero

format

• Supports IrDA 1.4 return-to-zeroinverted

format

• Supports ISO 7816 protocol for

interfacing with SIM cards and

smartcards (feature supported on

one UART module only)

• 13-bit baud rate selection with

by-32 fractional divide

• Programmable eight- or nine-bit

data formats

• Ability to select MSB or LSB to be

first on the wire

• Hardware flow control support for

request to send and clear to send

signals

• Separate transmit and receive

(feature supported on two UART

modules only) FIFOs with DMA

request capability

ISO 7816 Support

Two of the UART modules support

the ISO 7816 standard, allowing

communication with SIM cards and

smartcards. This feature has the

following characteristics:

• Supports T=0 and T=1 protocols

• Automatic retransmission

of NACKed packets with

programmable retry threshold

• Supports 11 and 12 ETU transfers

• Detects initial packet and automated

transfer parameter programming


UART Transmit Logic

UART Transmit Logic

Module

Clock

ISO ISO 7816 7816 Timing Timing Diagrams Diagrams

ISO 7816 Format without Parity Error (T=0)

START

BIT

BIT 0

BIT 1 BIT 2 BIT 3 BIT 4 BIT 5 BIT 6 BIT 7

PARITY

BIT STOP

BIT

STOP

BIT

ISO 7816 Format with Parity Error (T=0)

START

BIT

BIT 0

ISO 7816 Format (T=1)

START

BIT

Baud Rate Generator

SBR12:0 BRFA4:0

PE

PT

BIT 0

M10

M

TXINV

MSBF

Parity

Generation


Universal Asynchronous Receiver/

Transmitter

A flexible approach to full-duplex serial communication

Stop

IRQ/DMA

Logic

Internal Bus

SCI Data Register (SCID)

Variable 12-bit Transmit

Shift Register

Shift Direction

7816 Logic

Infrared Logic

Start

Transmitter

Control

TXDIR

SBK

TE


PARITY

BIT


PARITY

BIT

R485 Contol

Loop Control To Receiver

NACK

ERROR

STOP

BIT

TXD Pin Control

Tx port en

Tx output buffer en

Tx input buffer en

DMA Done

TxD

NEXT

START

BIT

TxD

DMA Requests

IRQ Requests

LOOPS

RSRC

RTS_B

CTS_B

NEXT

START

BIT

STOP

BIT

NEXT

START

BIT

39


• Interrupt-driven operation with seven

ISO-7816 specific interrupts:

Wait time violated

40

Character wait time violated

Block wait time violated

Initial character detected

Transmit error threshold

exceeded

Receive error threshold

exceeded

Guard time violated

Variety of Communications

Formats Available

The UART offers a number of options

for data size, format and transmission/

reception settings. The variety of

available options makes the UART

capable of implementing a wide variety

of serial communications protocols.

Features

• Eight- and nine-bit data formats

supporting parity over all nine bits

• MSB or LSB first on wire

• Programmable transmitter output

polarity

• Programmable receiver input polarity

FIFOs with DMA

Request Capability

The UART FIFOs reduce the frequency

of CPU processing required by the

UART.

The DMA can be configured to

transfer an entire packet of data and

then interrupt the CPU when all bytes

are received. This means the CPU can

process the entire packet all at once

instead of needing to stop the current

program flow to move data bytes as

they are received.

The size of the FIFOs vary depending

on the particular device and the

specific UART. The Vybrid platform

supports 16-byte FIFO on two UARTS

(UART0 and UART1) and 8-byte FIFO

on the other UARTS (UART2, UART3,

UART4, UART5).

UART UART Receive Receive Logic Logic

Module

Clock

RxD

LOOPS

RSRC

From

Transmitter

RxD

SBR12:0 BRFA4:0

RE

RAF

Baud Rate

Generator

Receive

Control

Receiver

Source

Control

Active Edge

Detect

UART UART Data Data Formats Formats

Infrared Logic

Eight Bits of Data with LSB First

START

BIT

BIT 0

Internal Bus

Stop

Data Buffer

Variable 12-bit Receive

Shift Register

Shift Direction

PE Parity

PT

Logic


Start

Wakeup

Logic

7816 Logic

IRQ/DMA

Logic

BIT 1 BIT 2 BIT 3 BIT 4 BIT 5 BIT 6

ADDRESS

MARK

BIT 7 STOP

BIT

Eight Bits of Data with MSB First

ADDRESS

MARK

START

BIT BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0

M

M10

LBKDE

MSBF

RXINV

DMA Requests

IRQ Requests

To TxD

START

BIT

Nine Bits of Data with LSB First

ADDRESS

MARK

START

BIT BIT 0 BIT 1 BIT 2 BIT 3 BIT 4 BIT 5 BIT 6 BIT 7 BIT 8 STOP

BIT

Nine Bits of Data with MSB First

ADDRESS

MARK

START

BIT BIT 8 BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1

STOP

BIT

BIT 0

START

BIT

STOP

BIT

START

BIT

START

BIT

Software and Development Tools


Freescale Virtual Hardware Platform

A rapid product development tool designed to

accelerate software development

Vybrid families support a wide variety

of complex I/O controllers, display

subsystems and communication

interfaces while supporting a highly

configurable multicore and multimemory

programmer’s model. Vybrid

families are designed to efficiently

handle numerous applicationlevel

design challenges as well as

traditional real-time embedded tasks.

This is where our virtual hardware

platform provides an additional

resource for managing the design and

debug of your application.

The virtual hardware platform brings

many features found in standard

desktop virtual machine environments

to embedded customers who need

a platform to accelerate software

development. Unlike traditional

modeling environments, this tool

leverages a fast instruction set model

that runs natively with no code

conversion requirements between x86

and ARMV7.

42

This is combined with broad system

modeling techniques, resulting in a

Vybrid device with an example EVB

hardware environment that can be

virtually represented on any Windowsenabled

machine.

Features

• Single executable product that loads

editable data-driven files

Editable bootimages

Peripheral parameters

(e.g., target display screen

parameters)

Feature/mux configurations on

select features (I/Os, UARTs,

GPIOs)

EVB memory sizes (editable

virtual machine configuration

files to set EVB memory)

• Fast instruction execution for one or

both ARM ® cores

Full support for ARM

Cortex-A5 and ARM

Cortex-M4 cores as

implemented in Vybrid families

Code execution capable of

running high-level operating

systems (Linux ® or others) at

chip-level performance or faster

• Bridged peripheral support between

host platform and embedded virtual

machine

File system on host machine can

be mapped to embedded virtual

machine file system

– Allows rapid testing of board

support/processor support

packages

– Allows rapid application

development (JAVA,

Android ® , Linux, MQX

and others)


Diagram of Virtual Hardware Platform

Embedded VM: Laptop Boundary

Embedded VM: EVB Boundary

Embedded VM: eMPU Boundary

Cache

VM-Cores

A5 M4

System Visiblity

Trace Data

IDE Tool

Plug-ins

Ethernet nodes on host machine

can be mapped to Ethernet

nodes on virtual target (Ethernet

bridging ability)

Display controller output to host

machine display

– Leverage GUI development

packages to develop and test

HMI/UI applications, on virtual

display controllers. Control

one or two screens at the

same time


SRAM

Ethernet

Memory

Subsystem

Display

Control

Comm

System

Serial

Flash

NAND

Flash

Virtual

Comm Ports

(UARTs)

Serial interface input and capture

– Configure test files to

generate/receive serial

communications for testing

and validating code

– Leverage virtualized UARTs in

Windows to transmit/receive

live data with model


DDR

Ethernet

VM Bridge

File

System/

Bridge

Windows

Frame

Buffer

Frame

Buffer

Config

Laptop

Ethernet/Wi-Fi ®

Laptop File System

Laptop LCD

Screen

Internal/External

Window

Virtual

Screen 1

Window

Virtual

Screen 2

Network

• Advanced debugging features

Industry-leading IDE support

allows real-time debug, trace,

and visibility to internal debug

data providing enhanced

application-level development

Debug access available through

Windows DLL extensions

43


Freescale MQX Software Solutions

Complimentary full-featured RTOS

Freescale streamlines

embedded design with

a complimentary RTOS

and software stacks

The increasing complexity of

industrial applications and expanding

functionality of semiconductors

are driving embedded developers

toward solutions that combine proven

hardware and software platforms. To

help accelerate time to market and

improve application development

success, Freescale offers the MQX

RTOS with TCP/IP and USB software

stacks and peripheral drivers to

ColdFire, ColdFire+ and Kinetis MCU

customers at no additional charge.

The combination of Freescale MQX

software solutions and our silicon

portfolio creates a comprehensive

source for hardware, software, tools

and services.

44

Freescale Comprehensive Solution Solution

CodeWarrior

Development

Environment

(MQX OS

Aware)

CodeWarrior

Processor

Expert

MQX Design

and

Development

Tools

Third Party:

IAR ®

ARM ® , Keil

(MQX OS Aware)

Open Source

BDM and

Third Party:

Emulator/Probe

PC Hosted

Freescale MQX Software Solutions

Reducing Cost,

Accelerating Success

Demo Code Applications

Application Tasks and

Industry-Specific Libraries

MQX RTOS

Optional

Services

BDM/JTAG

By providing complimentary

Freescale MQX software solutions

with its silicon products, Freescale

helps alleviate much of the initial

software investment hurdle faced by

embedded developers. Comparable

full-featured software offerings may

cost developers as much as $95,000

(USD) in licensing fees.

Ethernet

(RTCS)

File System

Core Services MQX RTOS

BSP/PSP

On Device

USB

CAN

MCU

Customized

Applications


Discrete

Driver,

Third

Party

and

Freescale

Application

Enablement

Layer

HAL

Hardware

According to recent research,

development teams spend

approximately 60 percent of their

resources on software. Embedded

projects based on 32-bit devices have

a greater need for software reuse to

manage development costs.


MQX RTOS: MQX Customizable RTOS: Customizable Component Component Set Set

The Freescale MQX RTOS and

software stacks address these

developer needs by providing a

scalable, reusable platform that works

across a wide range of Freescale

processor architectures, development

tools and third-party software

environments.


Name Services

Queues Interrupts

Partitions Utilities

Messages

Task

Management

Task Errors

Lightweight

Initialization

Core Memory

Events

Semaphores

Services

CORE

Watchdogs Mutexes

Task Queue

Automatic

Timers

Scheduling

Task Creation

RR and FIFO

IPCs

Formatted I/O

Scheduling

Exception

Handling

I/O Subsystems Kernel Log

Logs

AS-NEEDED

Freescale MQX is deployed as

production-ready source code,

including communications software

stacks and peripheral drivers, at no

additional cost. Freescale MQX is

provided with a commercial-friendly

software licensing model, enabling

developers to keep their source

modifications while being able to

distribute the required binary code.


Full Featured, Proven and

Scalable

The MQX RTOS has been the

backbone of embedded products

based on Freescale silicon for

more than 15 years. MQX software

deployment spans a broad range

of market segments and leading

manufacturers worldwide.

The Freescale MQX RTOS offers

powerful, preemptive real-time

performance with optimized context

switch and interrupt time, enabling

fast, highly predictable response

times. Its small, configurable size

conserves memory space for

embedded applications and it can be

configured to take as little as 6 KB

of ROM, including kernel, interrupts,

semaphores, queues and memory

manager.

The Freescale MQX RTOS offers

a straightforward application

programming interface with a modular,

component-based architecture that

makes it very scalable. Components

are linked in only if needed, preventing

unused functions from bloating the

memory footprint. Plug-ins, such

as security, industrial protocols and

graphical interfaces from Freescale’s

strong network of partners, can also

be added.

45


Certifiable to Medical and

Aerospace Standards

Even if your application does not

require formal certification, the

robustness of MQX provides a

trusted platform that has been

proven in thousands of timecritical,

sophisticated applications.

For designs that do have a formal

certification process to follow,

MQX is an excellent choice. Past

licensees have certified MQX-based

applications to medical specifications

(CFR 820.30 Part 21, IEC 60601-

1) and the aerospace requirements

listed under DO-178b. Safetycritical

applications based on MQX

include eye surgery equipment,

drug injection equipment, radiation

dose monitoring equipment, aircraft

braking systems and aircraft

navigation equipment.

46

RTCS Tower TCP/IP System StackModules

RPC

XDR

Sockets

*SSH

*SSL

NAT IP

*XML *SMTP *POP3 HTTP

RIP


SNMP

Telnet FTP TFTP DNS SNTP Web Server

(v1, v2)

ICMP

ARP

BootP

IP-E

DHCP

TCP UDP

IPCP

CIDR

PPP

IGMP

PAP

CHAP CCP LCP

Ethernet Serial HDLC

*SNMP

(v3)

*Denotes optional products

Application Presentation Session Transport Network Data Link Physical


Freescale MQX Add-on Software

Real-Time TCP/IP Communication Suite

(RTCS) Optional Components

Available from

Embedded Access Inc.

NanoSSL and NanoSSH Software by

Mocana Available from freescale.com/

nanossl, freescale.com/nanossh

PEG + Graphics Library


freescale.com/peg

SEGGER emWin

Graphics Library/GUI

Available from SEGGER Microcontroller

CANOpen Master/Slave for Embedded

Devices

Available from IXXAT, Inc.

Industrial Network

and Field Bus Protocols

Available from IXXAT, Inc.

SFFS Flash File System

Available from Embedded Access Inc.

Freescale eGUI: Graphical LCD Driver


freescale.com/egui

MicroBrowsers

Available from Motomic Software, Inc.

OS Changer—Reuse Application on MQX

Available from MapuSoft Technologies



• Network management: Support for SNMP version 1 and 2 is built into RTCS. EAI offers MQX

SNMPv3

• XML parsing and framing: The MQX XML component enables your device to accept data in XML,

as well as send data packaged in XML

• Email communication: The MQX SMTP module provides your device with outbound email

communication and MQX POP3 provides the capability to accept incoming email communication

• NanoSSH: Provides privacy, authentication and ensures data integrity between a secure server

and its clients

• NanoSSL: Cyptographic protocols that provide security for communications over networks such

as the Internet

• Portable embedded GUI library designed to provide a professional-quality GUI for embedded

systems applications

• Small, fast and easily ported to virtually any hardware configuration capable of supporting

graphical output

• emWin is designed to provide an efficient, LCD controller-independent GUI for any application that

operates with a graphical LCD

• CANopen is a CAN-based higher layer protocol

• Developed as a standardized embedded network with highly flexible configuration capabilities

• Unburdens the developer from dealing with CAN-specific details such as bit-timing and

implementation-specific functions

• Profinet RT for I/O device

• EtherNet/IP for adapter and scanner

• Ethernet powerlink for managing and controlled nodes

• EtherCAT for slave nodes

• SERCOS III for slave devices

• Precision time protocol IEEE ® 1588-2008 (v2)

• SFFS is a safe flash file system that can support almost any NOR or NAND flash device

• Provides a high degree of reliability and complete protection against unexpected power failure or

reset events

• Provides wear leveling, bad block handling and ECC K30C algorithms to ensure you get optimal

use out of a flash device

• Pre-integrated with the MQX RTOS: allows you to create a robust file system quickly for an embedded

device using on-chip or on-board flash devices

The complimentary Freescale embedded graphical user interface (eGUI) allows single-chip MCU

systems to implement a graphical user interface and drive the latest generation of color graphics

LCD panels with integrated display RAM and simple serial peripheral interface (SPI) or parallel bus

interface.

The uButterfly Browser runs on MQX and browses, parses and renders HTML/CSS content.

• Browse HTML 4/CSS 2.1 Web pages

• Enable dynamic HTML, active graphics and media

• An optional SDK allows browsing embedded/instanced within C, C++ or Qt apps (available as a

separate product)

OS Changer is a C/C++ source-level virtualization technology that allows you to easily re-use your

software developed for one OS on MQX, while providing real-time performance.

Available OS Changer Porting Kits:

• VxWorks Porting Kit

• pSOS Porting Kit

• Linux/POSIX Porting Kit

• Windows Porting Kit

• Nucleus Porting Kit

• micro-ITRON Porting Kit

47


Freescale Tower System

A modular development platform

Overview

The Freescale Tower System is a

modular development platform for

8-, 16- and 32-bit MCUs and MPUs

that enables advanced development

through rapid prototyping. Featuring

multiple development boards or

modules, the Tower System provides

designers with building blocks for entrylevel

to advanced MCU development.

Modular and Expandable

• Controller modules provide easyto-use,

reconfigurable hardware

• Interchangeable peripheral modules

(including communications,

memory and graphical LCD) make

customization easy

• Open-source hardware and

standardized specifications

promote the development of

additional modules for added

functionality and customization

Speeds Development Time

• Open source hardware

and software allows quick

development with proven designs

• Integrated debugging interface

allows for easy programming and

run control via standard USB cable

48

The Freescale Tower System

Controller/Processor

Module (MCU/MPU)

• Tower MCU/MPU

board

• Works stand-

alone or in

Tower System

• Features

integrated

debugging

interface for easy

programming

and run control

via standard

USB cable

Secondary

Elevator

• Additional and

secondary serial

and expansion

bus signals

• Standardized signal

assignments

• Mounting holes

and expansion

connectors for sidemounting

peripheral

Peripheral Module

• Adds features and functionality

to your designs

• Interchangeable with other peripheral

modules and compatible with all

controller/processor modules

• Examples include serial interface,

memory, Wi-Fi ® , graphical LCD, motor

control, audio, Xtrinsic sensing and high

precision analog modules


Primary Elevator

• Common serial

and expansion bus

signals

• Two 2x80

connectors on

back side for easy

signal access and

side-mounting

board (LCD

module)

• Power regulation

circuitry

• Standardized signal

assignments

• Mounting holes

Size

• Fully assembled

Tower System is

approx.

3.5” H x 3.5” W x

3.5” D

Board Connectors

• Four card-edge

connectors

• Uses PCI Express ®

connectors

(x16, 90 mm/

3.5” long, 164 pins)

Tower Plug-In (TWRPI)

• Designed to attach to modules

that have a TWRPI socket(s)

• Adds features and functionality

• Swappable with other TWRPIs

• Examples include accelerometers,

key pads, touch pads, sliders and

rotary touch pads


Tower System Modules

Controller/Processor Modules (8-, 16-, 32-bit) freescale.com/TowerController

Works stand alone or as part of Tower

System

Cost Effective

• Interchangeable peripheral

modules can be re-used with all

Tower System controller modules,

eliminating the need to purchase

redundant hardware for future

designs

• Enabling technologies like LCD,

Wi-Fi ® , motor control, serial and

memory interfacing are offered offthe-shelf

at a low cost to provide a

customized enablement solution

Take Your Design

to the Next Level

For a complete list of development

kits and modules offered as part of the

Freescale Tower System, please visit

freescale.com/Tower.


Allows rapid prototyping

Features open source debugging interface Provides easy programming and run control

via standard USB cable

Peripheral Modules freescale.com/TowerPeripheral

Can be re-used with all Tower System

controller modules

Interchangeable peripheral modules: Serial,

memory, graphical LCD, prototyping, sensor

Tower Plug-Ins freescale.com/TWRPI

Designed to attach to any Tower System

module with a TWRPI socket(s)

Eliminates the need to buy/develop redundant

hardware

Enables advanced development and broad

functionality

Adds features and functionality with little

investment

Swappable components Allows for design flexibility

Elevator Modules freescale.com/TowerELEV

Two 2x80 connectors Provides easy signal access and sidemounting

board (i.e. LCD module)

Power regulation circuitry Provides power to all boards

Standardized signal assignments Allows for customized peripheral module

development

Four card-edge connectors available Allows easy expansion using PCI Express ®

connectors (x16, 90 mm/3.5” long, 164 pins)

Partner Modules

Tap into a powerful ecosystem of

Freescale technology alliances for

building smarter, better connected

solutions. Designed to help you

shorten your design cycle and get

your products to market faster, these

technology alliances provide you with

access to rich design tools, peripherals

and world-class support and training.

A number of partners have developed

modules for the Tower System. Some

examples include the i.MX515 ARM ®

Cortex-A8 Tower Computer Module

and StackableUSB I/O Device Carrier

module from Micro/sys, as well as

the rapid prototyping system (RPS)

AM1 and FM1 modules from iMN

MicroControl.


Tower Geeks Online Community

TowerGeeks.org is an online design

engineer community that allows

members to interact, develop designs

and share ideas. Offering a direct

path to explore and interact with other

engineers designing with the Tower

System, TowerGeeks.org is a great way

to discuss your projects, post videos of

your progress, ask questions through

the forum and upload software. With

updates through Twitter and Facebook,

it’s easy to get involved.

Follow Tower Geeks on Twitter

twitter.com/towergeeks

Visit Freescale on Facebook

facebook.com/freescale

49


Swell PEG Product Line

Any LCD. Anywhere. PEG Software.

Swell Software provides graphical

user interface solutions for embedded

devices. Swell’s PEG Pro, PEG+ and

C/PEG product offering includes a GUI

library for embedded development that

works tightly with real-time operating

systems. These development tools

allow developers to lay out user

interface screens and controls using

the PEG library and external resources

to generate C or C++ code.

PEG software accelerates GUI design

for embedded devices by allowing

developers to create prototypes on

a Windows ® or Linux ® based PC. It

provides a complete visual layout and

design tool to enable GUI design to

take place in parallel to the embedded

software/hardware development.

The PEG WindowBuilder automatically

generates C or C++ source code that

is ready to be compiled and linked

into any application, accelerating the

deployment of the final product.

Swell’s GUI software products work

hand in hand with Freescale customers’

real-time operating systems to

incorporate LCD screens, display and

input interfaces into future products.

GUI Interface Technology

PEG’s modular form enables a

rapid development process. The

core library interfaces to different

50

GUI Interface Technology

RTOS

Application Layer

RTOS

Driver

PEG Library

LCD Driver

LCD Driver

Input

Driver

Window Builder Technology

PEG Pro PEG+ C/PEG

• Screen transitions

• Multiple alpha-blended

windows

• True anti-aliasing

• Gradient manager

• Open GL support

• Written in C++

real-time operating systems, input

devices and LCD controllers by

replacing the underlining driver.

PEG WindowBuilder for

Rapid Development

WindowBuilder allows a designer to lay

out each of the screens for a project

through a simple-to-use interface.

• Full WYSIWYG development

• Runs on PC/Linux/X11 to allow

proof of concept development

• Multiple window updates

• Alpha-blended images

• Run-time image decoders

and language resources

• Custom widget integration

• Dynamic themes

• Written in C++


• Designed for small LCDs

(QVGA)

• Low color-depth

• Very small footprint

• Single window update

• Multi-language capable

• Written in ANSI C

One of the smallest footprints and most efficient code bases available.

Starting 225 KB

Typical 225–250 KB

Starting at 160 KB


Starting at 90 KB


• Enables hardware/software

development to happen in parallel

• Made available for free evaluation

For more information visit

freescale.com/peg.


Timesys LinuxLink

Embedded Linux ® product development made easy

Timesys helps to eliminate the

learning time, complexity and risk in

building and maintaining embedded

Linux ® devices. As a leader among

embedded Linux solution providers,

Timesys offerings are available for

many Freescale processor families

including ColdFire, Kinetis, i.MX,

Vybrid and Power Architecture ® based

products.

Timesys offers the award-winning

LinuxLink embedded development

system, expert Linux support and

experienced professional services to

help development teams bring open

source Linux-based products to

market faster and cheaper.

With a LinuxLink subscription for your

Freescale processor, you can:

• Quickly assemble and boot an initial

embedded Linux image on your

Freescale development kit.

• Patch/configure/rebuild/update

your custom Linux platform on your

desktop with a properly installed

and configured development

environment.

• Debug/tune the platform with

common open source development

tools and development libraries/

utilities.

• Obtain help with common

development tasks via technical

assistance and a rich library of

Timesys-authored “How To”

documentation.

Key LinuxLink Components:

Linux Kernel, Toolchain, Software

Packages, Bootloader

All Timesys Linux platforms are built

and tested for compatibility with our


Timesys LinuxLink

Linux Kernel and Drivers

• Latest open-source kernels

• ARM ® and other architectures

• Extensive SoC/device support

Development Tools/Libraries

• Latest version of gcc, glibc, uClibc

• Tested on all supported SoCs

• Eclipse-based environment

OS Apps and Middleware

• Rich selection of packages

• Networking, industrial, consumer

• Pre-built, tested, supported

Boot Loader

• For supported reference platforms

• Industry-standard U-Boot

• Latest open-source code base

LinuxLink Software Development Framework

semiconductor partners’ suggested

bootloader, saving time with initial

board bring up.

Factory Distribution Builder

Timesys’s Factory Distribution Builder

enables complete customization of

your Linux platform and integration of

third-party and proprietary software.

Also includes innovative “advice”

and “recommendation” engines to

minimize mistakes.

TimeStorm IDE

TimeStorm’s powerful suite of

application development tools expertly

handles embedded chores like crosscompiling

and remote debugging

while including support for advanced

features like profiling, testing and leak

detection. And TimeStorm is built on

the Eclipse IDE foundation, a platform

already familiar to developers.

Update Notifications

As a LinuxLink user, you’ll only receive

automatic notifications of updates


CHOOSE BUILD DEPLOY

TimeStorm IDE (Eclipse)

• Application development and debug

• Fully integrated with Factory tools

• Compatible with Eclipse ecosystem

Factory Distribution Builder

• Interactive UI with intelligent advice

• Guides your selection of packages

• Web (hosted) and desktop versions

Work Orders

Updates

• Automatic kernel updates

• Automatic middleware updates

• Web-based and desktop notifications

Support

• Web-based

• In-person

• Extensive documentation

Your Custom Tools (SDK)

• gcc/C library/gdb

• Relevant application libraries

Your Custom Image (BSP)

• Kernel/drivers

• Root file system

Ready to run on

your hardware

relevant to the Linux components used

in your software.

Unmetered Expert Linux Help

As a LinuxLink subscriber, you’ll have

access to responsive technical support

from our expert engineers. Intuitive online

support enables detailed information

exchanges and allows you to submit,

view and update requests, and access

or reopen resolved requests.

Get Your Free LinuxLink—

Build Your Custom BSP/SDK

in Minutes

Register for a Free LinuxLink account,

and assemble a Linux image that you

can download and run on your board.

Register at timesys.com/register.

For more information about Timesys’s

LinuxLink embedded Linux build

system, visit timesys.com/linuxlink.

51


CodeWarrior Development Studio

Based on the Eclipse open development platform

The CodeWarrior Development

Studio for Microcontrollers V10.x

integrates the development tools for

the RS08, S08, ColdFire, ColdFire+,

DSC, Kinetis, Qorivva, PX and

Vybrid architectures into a single

product based on the Eclipse open

development platform. Eclipse offers

an excellent framework for building

software development environments

and is becoming a standard

framework used by many embedded

software vendors.

• Eclipse IDE 3.6

• Build system with optimizing C/C++

compilers for RS08, S08, ColdFire,

ColdFire+, DSC, Kinetis, Qorivva

and PX series Power Architecture ®

cores and Vybrid devices

• Extensions to Eclipse C/C++

development tools (CDT) to

provide sophisticated features to

troubleshoot and repair embedded

applications

Device/Connection

Change Wizard

The Device/Connection Change

Wizard allows a project to be

re-targeted to a new processor in

as few as six mouse clicks. Simply

select a new device (from the same

or a different architecture—RS08,

S08, ColdFire, ColdFire+, DSC,

Kinetis, Vybrid, Qorivva and PX series

Power Architecture cores or Vybrid

devices), select the default connection

and the CodeWarrior tool suite will

automatically reconfigure the project

for the new device with the correct

build tools and support files.

52

C/C++ Perspective

Device/Connection Change Wizard

Code Warrior Key Features Key Benefits


Device Connection Change Wizard Easily retarget project to a new processor

Trace and profile support for on-chip trace

buffers

Sophisticated emulator-like debug capability

without additional hardware

LiveView Monitor registers, memory and global

variables without stopping the processor

Freescale Processor Expert Problems in hardware layer can be resolved

during initial design phase


Debug Perspective

Processor Expert

Processor Expert Key Features Key Benefits

Graphical user interface Allows an application to be specified by the

functionality needed

Automatic code generator Creates tested, optimized C code tuned to

application needs and the selected Freescale

device

Built-in knowledge base Immediately flags resource conflicts and

incorrect settings so errors are caught early

in the design cycle

Component wizard Allows the creation of user-specific hardwareindependent

embedded components



• Compiler

• Assembler

• Linker

• Header files

• Vector tables

• Libraries

• Linker configuration files

Profiling and Analysis

The CodeWarrior profiling and

analysis tools provide visibility into an

application as it runs on the processor

to identify operational problems.

• Supports architectures with

on-chip trace buffers (RS08, V1

ColdFire, ColdFire+, Kinetis and

Vybrid)

• Allows tracepoints to be set to

enable and disable trace output

• Able to step through trace data

and the corresponding source

code simultaneously

• Allows trace data to be exported

into a Microsoft ® Excel ® file

Processor Expert

Freescale’s Processor Expert is a rapid

application design tool that combines

easy-to-use component-based

application creation with an expert

knowledge system.

• CPU, on-chip peripherals,

external peripherals and software

functionality are encapsulated into

embedded components

• Each component’s functionality

can be tailored to fit application

requirements by modifying the

component’s properties, methods

and events

• When the project is built,

Processor Expert automatically

generates highly optimized

embedded C-code and places the

source files into the project

For more information, visit

freescale.com/CWMCU10.

53


ARM ®

Overview

The ARM ® Development Studio

5 (DS-5) is a complete suite

of software development tools

for ARM processor-based ASICs

and standard devices, including

Freescale’s Vybrid family. DS-5

accelerates software development

by providing an easy-to-use,

integrated and validated toolchain.

Key Features and Benefits

• Support for all ARM processors

• Integration with the industrystandard

Eclipse IDE, which

provides a large ecosystem of thirdparty

plug-ins

• Flexible C/C++ editor and project

manager

• Powerful C/C++ compilation tools

• Debugger supports all phases of

development from bootloader to

kernel, and user space

• Streamline Performance Analyzer

provides system-wide profiling

based on performance counters

• Instant correlation of performance

bottlenecks (cache misses,

interrupts) and software execution

• Fast simulator for ARM software

development on the host computer

with typical speeds above 250 MHz

• Support and maintenance contract

for one year

54

Development Studio 5 (DS-5)

The reference software development tool suite for

ARM ®

powered platforms

DS-5 Debugger and DSTREAM

DS-5 Debugger

The DS-5 Debugger brings together

the convenience and productivity of

integrated embedded development

tools with the power and flexibility

of open source tools for Linux ® and

Android ® .

The DS-5 debugger provides:

• Debug of code generated by ARM

and GNU Compile.

• Advanced Session Control and

System Views control multiple

simultaneous debug sessions,

to one or more targets, from one

debugger perspective

• Run and stop mode debugging of

single-core and multicore devices


• Linux kernel and user space debug,

including context awareness,

process, and threads

• Non-intrusive instruction trace

including summarized profile

• Conditional and scripted

breakpoints

For expert Linux users, DS-5 includes

the traditional GDB command line

interface for detailed control of

target interactions and flexibility

with scripting advanced debugger

functions.


Streamline: Timeline and Call Paths

Call paths view shows the processor time

spent on each call tree. A flat profiling report is

generated for the selected call path, which enables

you to focus the analysis on a process or thread.

DSTREAM

The ARM DSTREAM high

performance debug and trace unit

enables powerful software debug and

optimization on any ARM processorbased

hardware target.

DSTREAM enables the connection of

DS-5 Debugger to ARM processorbased

devices via JTAG or serial-wire

debug. It uses FPGA acceleration to

deliver high download speeds and

fast stepping through code on single

and multi-processor devices and

enables:

• Run control debug and trace unit

supporting all ARM processors

• USB 2.0 and Ethernet interface

allows direct and remote

connections from the host PC

• Code downloads at speeds of

up to 2500 Kbps

• JTAG clocks of up to 60 MHz

provide fast software upload over

the existing debug port

• 16-bit wide trace capture at 300

MHz DDR (600 Mbit/s per pin)


Timeline view shows process and thread

information over time, matched to SoC

performance counters. This enables you to

spot thread deadlocks and inefficiencies,

as well as hot spots in time.

• Flexible trace clock positioning

(relative to trace data)

• Large 4 GB trace buffer enables

long-term trace of fast targets

Streamline

Streamline is the Linux and Android

performance analysis tool in DS-5.

Through a small driver running on the

target, Streamline captures the target’s

performance information and displays

it in an easy to understand graphical

interface. Streamline includes:

• Intuitive display of information

ranging from system-wide

performance counters to hot

spots in the source code, making

it easy for developers to identify

performance bottlenecks, multithreading

issues and general

inefficient resource usage

• Visualization tools to analyze percore

performance metrics with

threads and processes for optimal

synchronization and concurrency of

target’s resources


• Filtering capabilities to restrict the

data set used by statistical reports

over time and per-process, thread

or call path

• Call paths view shows the processor

time spent on each call tree. A flat

report is generated for the selected

call path, which enables you to

focus the analysis of a process or

thread

• Code View highlights the hot spots

within a function by displaying the

processor time spent on each

line of source code and on each

disassembly instruction

• Streamline Capture Options dialogue

enables you to select the right

balance between granularity and

information detail, and intrusiveness

ARM C/C++ Compiler

The ARM Compiler in DS-5

Professional Edition is the only

commercial compiler co-developed

with the ARM processors and

specifically designed to optimally

support the ARM architecture. It is

the industry standard C and C++

compiler for building applications

targeting the ARM, Thumb ® , Thumb-

2, VFP, and NEON instruction

sets found in the newer Cortex

processor-based devices.

ARM processors are designed to best

execute code generated by the ARM

Compiler. The ARM Compiler enables

the new features in all the ARM

processors. It supports building of

Symbian OS, ARM Linux, and Android

native applications and libraries, as

well as bare-metal applications and all

major RTOSs.

Learn more at arm.com/ds5.

55



Powerful, reliable development tools

Continuing a long-standing

relationship with Freescale

Semiconductor, IAR Systems ® has

announced that their flagship IAR

Embedded Workbench ® for ARM ®

product supports Freescale’s new

Vybrid devices based on the ARM

Cortex-A5 and ARM Cortex-M4

cores. IAR Systems supports nearly

the entire lineup of Freescale MCUs,

including the S08, HCS12, ColdFire

(and all its variants), the Kinetis MCUs

based on an ARM Cortex-M4 core

and now Vybrid devices. IAR Systems

is proud to be allied with Freescale

in bringing cutting-edge devices and

tools to our mutual customers.

IAR Embedded Workbench for

ARM is a highly efficient and

independent toolchain that supports

ARM architectures, including Vybrid

devices. The Embedded Workbench

for ARM includes IAR’s IDE, C/C++

Compiler, Assembler and Linker to

give you unparalleled performance.

56


Back to Table of Contents


• Ease of use. IAR Embedded

Workbench for ARM has over

2,500 example projects to help

you get your project off the ground

quickly. These examples are part

of the installation and are provided

free of charge.

• Support for all ARM hardware.

IAR Embedded Workbench for

ARM includes support for the

floating point DSP unit that is

available in many ARM Cortex-M4

cores. It also supports the ARM

Cortex-A5 core and the NEON

instruction set that is the heart of

the Vybrid architecture.

• Tight code generation. The code

generated is highly optimized

and IAR Systems encourages

developers to try out one of the free

versions (32 kB-limited KickStart

version or the 30-day evaluation

version) at iar.com/ewarm to

compare it to other compilers.

Prototype your code and see how

much more efficient IAR is in your

design.

• An embedded compiler brings

you full C++. IAR Embedded

Workbench for ARM brings

you full desktop C++ (including

exception handling, multiple/virtual

inheritance, etc.) to help you crosscompile

code and use the bevy

of test suites available for the PC

to validate and verify your design

before it goes into the board.


Developing your Vybrid device

application is never easier than

when you use IAR.

• Integration to popular sourcecode

control systems. If you are

using Subversion or a Microsoft

Visual Source Safe-compliant

control system, you can use the

Embedded Workbench for ARM

to check code in and out of the

system to speed your development

process.

• Kernel-aware debugging for most

RTOSs. The C-SPY ® debugger is

able to do task-aware debugging

for many popular RTOSs including

MQX, Micrium uC/OS-II and –III,

SMX, CMX, Quadros, Sciopta,

embOS, Express Logic’s ThreadX,

Free/Safe RTOS and others. This

awareness allows you to see what

is happening in your RTOS at a

glance.

• Power debugging. IAR Systems

has a unique power debugging

feature that allows you to see the

power being consumed by your

board when the board is powered

by a J-Link Ultra. Making your

design power-efficient used to

be the domain of only hardware

engineers, but IAR gives the ability

to software engineers as well.


• Local support with global

reach. IAR Systems has 10

offices worldwide (including three

in the United States) and each

one is staffed with capable and

experienced engineers who are

ready to help you with any issues

that arise. No other compiler

vendor can claim to have nearly as

much assistance readily available.

When considering which toolchain to

use in your Vybrid design, consider

the one that was first to support

Kinetis MCUs, first to support Vybrid

devices, first in service and first in

performance: choose IAR Embedded

Workbench for ARM.

For more information, please

email info.us@iar.com.

57


Atollic tools provide you with powerful

features that reduce your development

time and enable you to release a

software product with higher quality

with less effort.

Atollic aims to provide an embedded

systems toolset that covers all worktasks

that embedded developers

are doing on a day-to-day basis.

The Atollic product portfolio not only

covers great tools for editing, building

and debugging but offers powerful

solutions for team collaboration,

system and code analysis as well as

test automation.

TrueSTUDIO ® : The Embedded

Systems Development Tool for

the Next Decade

Atollic TrueSTUDIO is the premier

C/C++ development tool for

embedded systems development,

with its unrivalled feature-set and

unprecedented integration. In addition

to the state-of-the-art editor, the

optimizing C/C++ compiler and

multiprocessor-aware debugger with

tracing support, Atollic TrueSTUDIO

also includes features for team

collaboration, graphical modeling

and design, code review and review

meetings.

TrueINSPECTOR ® : Improve

Software Quality with Static

Source Code Analysis

Atollic TrueINSPECTOR is a tool

for professional code analysis. The

product performs static source code

inspection and generates software

metrics including code complexity

measurements. The source code is

validated against a database of

58

formal coding standards, and coding

constructs that are known to be errorprone

are detected automatically.

Atollic TrueINSPECTOR supports the

MISRA ® -C:2004 rule standard.

TrueVERIFIER: Get Superior

Software Quality with Embedded

Test Automation

Atollic TrueVERIFIER is a tool for

advanced test automation. The

product performs source code

analysis and auto-generate unit-test

suites that exercise an extensive

set of different execution paths. The

tool downloads the test cases and

runs them in a target board with

code coverage monitoring. Finally,

Atollic TrueVERIFIER visualizes the

test results and the achieved code

coverage (MC/DC-level).


Atollic

World-class tools for embedded systems development

True Studio

TrueANALYZER ® : Measure Test

Quality with Dynamic Execution

Flow Analysis

Atollic TrueANALYZER is a tool for

in-target measurement of test quality.

The product performs system-level

dynamic execution flow analysis and

provides rigorous code coverage

measurements. Atollic TrueANALYZER

supports many types of code

coverage analysis up to the level of

modified condition/decision coverage

(MC/DC-level), which is required by

RTCA DO-178B (Level A) for flightcontrol-system

software.

For more information on Atollic tools,

visit atollic.com.


Multilink and Cyclone

Debug interfaces and production programming

P&E’s line of Multilinks and Cyclones

are powerful solutions that cover the

complete product cycle.

USB Multilink Debug

Interfaces

P&E’s USB Multilinks are affordable,

development-oriented interfaces that

allow access to the debug interface on

a target MCU from the user’s PC. The

new Multilink Universal and Multilink

Universal FX represent the next step

forward for this very successful line

of hardware interfaces. They each

combine support, in a single interface,

for many Freescale architectures,

including: Vybrid, Kinetis, HCS08,

RS08, HC(S)12, ColdFire+/V1, ColdFire

V2-V4, Qorivva MPC55xx/56xx and

DSC. The FX version also provides

much higher communications speeds

for some architectures (up to a 10x

speed improvement), and can be used

to power the target device. These

“universal” Multilinks include ribbon

cables to allow connections to all of

the supported architectures. The user

can simply flip open the hinged section

on the Multilink case and install the

appropriate ribbon cable.

Multilink and Cyclone


Multilink Universal and Multilink

Universal FX Features

• Draws power from USB interface—

no separate power supply required

• Target voltage: 1.6–5.25V

• Includes a ribbon cable for each

supported architecture

• High-speed download (FX version)

• Can provide target power (FX version)

Supported Architectures

• Vybrid

• Kinetis

• ColdFire+, ColdFire V1–V4

• HCS08, RS08, HC(S)12

• DSC

Software Support

• CodeWarrior IDE

• P&E software (including

programmers and debuggers)

• Software tools from IAR, Keil,

Mentor Graphics, Cosmic,

and others. Support varies by

architecture. Contact vendor to

determine compatibility.

Cyclone Production

Programmers

P&E’s Cyclone products are geared

towards in-circuit production

programming, including both

low-volume, operator-controlled

programming and high-volume

automated programming. The Cyclone

can be used to program both internal

memory on a Freescale processor/

MCU as well as external memory

connected to the processor’s address/

data bus. The processor can be

mounted on the final printed circuit

board before programming and does

not need to be pre-programmed.


When connected to a PC, the Cyclone

can communicate via USB, Ethernet,

or serial port, and its operations can

be completely automated. In standalone

mode, programming images are

first loaded into on-board memory.

An LCD screen and buttons allow

one-touch programming operation

as well as configuration. P&E offers

automation software packages

allowing many Cyclone units to be

“ganged” together.

The Cyclone may also be used as a

hardware interface with many popular

debuggers, similar to the way a USB

Multilink is used, but also including

support for Ethernet and serial

connections.

Cyclone Features

• Stores multiple images for

programming

• Can be fully automated and

controlled from a PC

• Can be controlled via buttons/

display without a PC

• Display for image selection, status,

and settings

• Can provide/switch power to target

• High-speed programming

• Multiple units may be “ganged” for

parallel programming

• Support for dynamic data, including

serialization

• May be used as a debug interface

with many debuggers

For more information, visit

pemicro.com.

59


Designed using SEGGER’s industryleading

embedded software, J-Link

debug probes offer a wide array of

advanced features and boast support

for a broad spectrum of MCUs and

MPUs, including Freescale’s complete

i.MX, Kinetis and ColdFire V2–V4

lines. Many popular IDEs such as

CodeWarrior, IAR, Keil, Code Sourcery

V2–V4 and more have built-in support

for the J-Link.

The J-Link debug line offers a high

download speed into RAM* and flash

memory. Each JTAG debugger hardware

model has its own unique attributes and

offers a number of available software

add-on modules to enhance the J-Link’s

functionality. For more details, visit

segger.com/jlink.html.

J-Flash is a comprehensive user

interface for flash programming. The

flash breakpoint add-on allows for

an unlimited number of breakpoints

while debugging in flash memory. The

J-Link SDK is a standard Windows

DLL typically used from C. It makes

the entire functionality of the J-Link

available through the exported

functions and allows you to write your

own program using J-Link.

Hardware Models

J-Link Pro for Connectivity

J-Link Pro is an enhanced version of

the J-Link. It incorporates an on-board

Ethernet interface in addition to the

USB, as well as two LED hardware

status indicators. It comes with licenses

for all J-Link related SEGGER software

products, including flash breakpoints,

60

RDI, J-Flash and GDB Server, providing

the optimum debugging solution for the

professional developer.

J-Link ULTRA for High Performance

J-Link ULTRA is based on the highly

optimized and proven J-Link. It offers

even higher speed as well as target

power measurement capabilities due to

the faster CPU, built-in FPGA and High-

Speed USB interface. This permits you

to take full advantage of the low power

features offered by today’s modern

cores. J-Link Ultra raises the bar, aiming

to be the fastest emulator available.

J-Trace for Cortex-M for

Post-Mortem Analysis

J-Trace for ARM ® Cortex-M is a

JTAG probe which includes trace (ETM)

support. J-Trace assists the developer

in analyzing his target system’s

behavior. The 4 MB trace memory

provides plenty of space to store the

last executed functions. This allows you

to find out how the program arrived at a

certain position in code, which is either

not expected or wanted.


SEGGER: J-Link and Flasher

Convenient development and production programming

*The regular J-Link performs with an already high

750 Kbps, J-Link Ultra allows an even faster peak

download speed of 1.5 Mbps

SEGGER Debug Probes and Production Flash Programmer

J-Link

Intelligent

Debugging via

JTAG/SWD

• Robust communication

• Very high performance

(download speed up to 1.5 MB)*

• Unlimited flash breakpoints

(license required)

Flasher for Production Flash

Programming and in the Field

Services

The in-circuit programmer (Flasher

ARM) is a superset of the J-Link DDL.

It contains all of the debug probe

features, while being designed for use

in a production environment. Different

interfaces, like the command line

interface or the optionally available

SDK, allow an easy integration into any

production environment.

The Flasher ARM has on-board

memory to store your binary image,

permitting simple stand-alone flash

programming. This is particularly useful

for support teams that have to upgrade

devices out in the field. They only need

to carry a small box which is readily

configured to perform the update once

it is connected to the target system.

For more details, visit segger.com/

flasherarm.html.


SEGGER offers a feature rich, high

performance RTOS, GUI, and family

of middleware (file system, USB host

and device, IP stack), all of which

adhere to strict, yet efficient coding

and documentation standards. The

software is very easy to use and works

out of the box. BSPs and projects for

popular eval boards and tool chains are

available, including BSPs for the popular

Freescale based designs. SEGGER

offers very flexible license models to

meet any size project’s needs.

Embedded Graphics

Package (emWin)

emWin is a professional graphical

user interface (GUI) for any application

that operates with a graphical LCD.

For fast user interface development

emWin provides a GUI-Builder software

and an extensive widget selection.

emWin is part of SEGGER’s complete

middleware solution. Additionally,

emWin is compatible with; polled,

single-task, and multitask environments,

with a proprietary operating system

or with any commercial RTOS. It is

shipped as C source code and may

be adapted to any size physical and

virtual display with any LCD controller

and CPU. emWin can be optimized to

run on very low resources. For more

details, visit segger.com/emwin.html.

RTOS (embOS)

embOS is a priority-controlled real time

operating system, designed to be used

as a foundation for the development

of embedded real-time applications.

It is a zero interrupt latency (high

priority interrupts are never disabled

by embOS), high-performance RTOS

that has been optimized for minimum

memory consumption in both RAM


and ROM, as well as high speed and

versatility. Throughout the development

process of embOS, the limited

resources of MCUs have always been

kept in mind. The internal structure

of embOS has been optimized for

a variety of applications for different

customers, to fit the needs of different

industries. embOS is fully sourcecompatible

on different platforms

(8/16/32-bit), making it easy to port

applications to different CPUs. Its’

highly modular structure ensures that

only those functions that are needed

are linked, keeping the ROM size very

small. We took full advantage of our

partnership with Freescale by utilizing

their expertise and knowledge of their

hardware while adding support for

Vybrid devices. This permits you to take

full advantage of our software offering

while being assured that it has been

developed to the highest standards

and optimized to the fullest. For more

details, visit segger.com/embos.html.

Embedded USB Stacks

(emUSB-Device and

emUSB-Host)

emUSB-Device has been designed to

work on any embedded system with a

USB device controller. Ports for most


SEGGER: RTOS, GUI and Middleware

Embedded software for the professional developer

SEGGER RTOS, GUI and Middleware

common USB devices are available. It

can be used with USB 1.1.or USB 2.0

Full- and High-Speed devices. emUSB

supports, among others, the HID,

CDC, MSD, MSD-CDROM, printer and

custom bulk communication classes.

emUSB-Host is the counterpart of

emUSB-Device and supports HID,

CDC (and FTDI), MSD, printer and

custom bulk communication classes.

Embedded IP Stack

(embOS/IP)

embOS/IP is a TCP/IP stack that

provides a small memory footprint

for high-performance embedded

networking solutions. The stack has

been optimized for use in real-time,

memory-constrained embedded

systems. It offers RFC-compliant TCP/

IP and a standard socket API. embOS/

IP works seamlessly with the embOS

operating system. Additional higher

level protocols like SMTP, FTP and

HTTP are also available. On the link

layer, embOS/IP supports PPP to ease

the integration of M2M-communication.

For more details, visit segger.com/

embedded-software.html.

61


Lauterbach

TRACE32 ®

PowerTools

Lauterbach offers the world’s most

advanced and complete debug

environment. With more than 30

years of experience, Lauterbach’s

TRACE32 ® product line has

accumulated an arsenal of analysis

tools suitable for most debug and

testing requirements. These tools

range from traditional source code

debug to statistical analysis, code

coverage, charting and profiling of

your code execution.

With much experience supporting

the various ARM ® core architectures,

including ARM Cortex-A, ARM

Cortex-R, ARM Cortex-M,

and other Coresight components,

Lauterbach is proud to announce

support for the latest ARM

Cortex-M4/Cortex-A5 based

Freescale Vybrid devices. Offering a

4-bit ETM trace port, the Vybrid part

unleashes many of the advanced

analysis features offered by the

Lauterbach TRACE32 debugger, at

a reasonable price point. There are

several levels of debugger support, with

or without support for the ETM trace.

TRACE32 ® Debugger

for ARM Cortex-M or

ARM Cortex-A/R

The tools for the ARM Cortex-M/

Cortex-A/R processor family

are designed as an open debug

environment that offers sophisticated

features for quick and effective testing

of your embedded design. It now

supports the latest Freescale Vybrid

devices with the ARM Cortex-M4/

Cortex-A5 core.

62

TRACE32 Debugger

Hardware Configuration

The PowerDebug for the ARM

Cortex-M processor family consists of:

• A high-speed debug hardware

module

• A debug cable for the ARM Cortex-M

or ARM Cortex-A/R devices

A USB2.0 or Ethernet interface

is provided as host interface to

PC Windows, PC Linux ® or any

workstation.


TRACE32 ® Debugger for ARM Cortex-M or ARM Cortex-A/R

JTAG Debugger Features

• Supports JTAG, SWD and cJTAG

• C and C++ support for all standard

compilers

• Full and intuitive support of the

on-chip debug unit

• RTOS awareness for all commonly

available RTOS

• Real-time memory access via DAP

• Flash programming support

• Multicore debugging


TRACE32 CombiProbe

for ARM Cortex-M

TRACE32 JTAG debuggers can

be extended with the CombiProbe

which adds 4-bit ETM real time trace

capabilities to the debugger, enabling

the industry’s finest code analysis and

profiling tools.

CombiProbe Hardware

Configuration

The CombiProbe PowerDebug for

ARM Cortex-M processor family

consists of:

• High-speed debug hardware

module

• CombiProbe debug cable for

recording the 4-bit ETM v3.x in

continuous mode

• License for ARM Cortex-M

debugging

A USB2.0 or Ethernet interface is

provided as host interface to PC

Windows, PC Linux or any work

station. The product also includes

CoreSight Single Wire Viewer.

CombiProbe Features

• Up to 128 MB trace entries

• Trace port rates up to 200 Mbps

• Real-time profiling

• Long-time trace

• Energy profiling

• Re-debugging of all sampled

program steps (CTS)

• Trace filter and trigger

• Run time analysis of functions and

tasks

• Code coverage and variable analysis

• Multicore debugging

TRACE32 PowerTrace

for ARM Cortex-A/R or

ARM Cortex-M

TRACE32 JTAG debuggers can be

extended with the PowerTrace which

adds 4/8/16/32-bit ETM real-time

trace capabilities to the debugger,

enabling the industry’s finest code


analysis and profiling tools.This

configuration supports all modes of

the ETM trace port.

PowerTrace Hardware

Configuration

The PowerTrace for ARM Cortex-M

processor family consists of:

• High-speed debug hardware

module

• PowerTrace module for recording

4/8/16/32-bit ETM real-time trace

• Debug cable for Cortex-A/R or

Cortex-M debugging

A USB2.0 or Ethernet interface is

provided as host interface to PC

Windows, PC Linux or any workstation.

PowerTrace Features

• Up to 4 GB trace entries (also,

streaming to host for recording

longer run times)


TRACE32 ® CombiProbe for ARM Cortex-M

TRACE32 ® PowerTrace for ARM Cortex-A/R or ARM Cortex-M

• Trace port rates up to 600 MHz at

4/8/16/32-bit trace widths

• Real-time profiling

• Long-time trace

• Energy profiling

• Re-debugging of all sampled

program steps (CTS)

• Trace filter and trigger

• Run time analysis of functions and

tasks

• Code coverage and variable analysis

• Multicore debugging

For more information about TRACE32

tools, visit lauterbach.com.

63

For more information, visit freescale.com/Vybrid

Freescale, the Freescale logo, CodeWarrior, ColdFire, Kinetis, PowerQUICC and Qorivva are trademarks of

Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. Processor Expert, Vybrid and Xtrinsic are trademarks

of Freescale Semiconductor, Inc. ARM is the registered trademark of ARM Limited. ARM9, ARM11, ARM Cortex-A5,

ARM Cortex-A9, ARM Cortex-M3 and ARM Cortex-M4 are trademarks of ARM Limited. Java and all other Java-based

marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries. The Power

Architecture and Power.org word marks and the Power and Power.org logos and related marks are trademarks and

service marks licensed by Power.org. All other product or service names are the property of their respective owners.

© 2012 Freescale Semiconductor, Inc.

Document Number: VYBRIDBYNDBITS REV 0

Beyond Bits VII - Freescale Semiconductor

You also want an ePaper? Increase the reach of your titles

Delete template?

Save as template?
