2019 Supply Cache Master Catalog

A
MALE QUARTER TURN
C & S Supply and S & H Products are Made in the USA.
A Quarter Turn Aluminum Adapters
One end is the size noted and the other end is neutral. Specify NH or NP.
(0.360 lbs)
859-10502 Male 1” Quarter Turn. .............. $51.95
859-10552 Female 1” Quarter Turn. .............. $63.95
859-11502 Male 1.5” Quarter Turn. .............. $54.95
859-11552 Female 1.5” Quarter Turn. .............. $60.95
FEMALE QUARTER TURN
B
D
C
B Ball Shut-Off Valves, S & H Products
Anodized aluminum bodies and cast handles. The internal polymer ball
valve has front and rear seals to eliminate leaks and provide easier
opening and closing. Specify NH or NP thread.
Rigid (1.400 lbs)
853-30651 1” NH or NP. ......................... $133.95
1.5” NH ............................... $136.95
Swivel (1.600 lbs)
853-30701 1” NH or NP. ......................... $146.95
1.5” NH ............................... $157.95
C Full Flow Shut-Off Valve, S & H Products
1.5” Full Flow Shut-off Valve is the lightest and most compact in the
industry. Most forestry 1.5” shut-off valves have a 1” flow through the
ball valve. S&H has been able to install a 1 3/8” ball in the standard 1.5”
body. This increases flow and facilitates foam bubble integrity. This is
the perfect valve to use with foam applicator nozzles. 600 psi operating
pressure. 1.5” NH. (1.250 lbs)
853-30723. ........................................ $173.95
D Ball Shut Off (Swivel), C & S Supply
These swivel style ball shut-off valves have hard anodized aluminum
bodies and cast handles. The internal polymer ball valve has front and
rear seals to eliminate leaks and provide easier opening and closing.
Specify 1 or 1.5 Inch and NH/NST or NPSH Thread. (1.750 lbs)
858-30705 1” ...................................... $205.95
1.5”. .................................... $205.95
E
F
E Hose Line Tees, S & H Products
Inlet x Outlet
1.5” NH/NST Inlets x 1” NH/NST Outlet hose line tee valve. Specify
thread type. (1.050 lbs)
853-30851 1.5” NH x 1” NH. ....................... $77.95
1.5” NH x 1” NP. ....................... $77.95
F Hose Line Tee 1.5 NH X 1”, C & S Supply
1.5” NH/NST Inlets x 1” NH or NP Outlet hose line tee valve. Specify NH
or NP outlet thread type. (1.100 lbs)
858-30855. ........................................ $112.95
G
I
G Hose Line Tees, S & H Products
Inlet x Outlet
Capped Inlet/Outlet Hose Line Tee. Includes Cap and Chain. Specify size
and thread type. (0.550 lbs)
853-30801 1” NP x 1” NP ........................ $55.95
853-30821 1.5” NH x 1” NP ........................ $55.95
H
J
H Hose Line Tee 1 NP x 3/4 GHT, S & H Products
Lightweight Aluminum construction. 1” NP inline male and female
threads, 3/4” GHT “T”. Cap and chain included. Meets Forest Service
Specifications (FSS). (0.500 lbs)
853-30815. ........................................ $55.95
I Hose Line Tee, 1.5 NH/NST, C & S Supply
.1.5” NH/NST Inlets x 1” NPSH Cap hose line tee. Includes cap and chain.
(0.650 lbs)
858-30825. ........................................ $83.95
J Hose Line Tee 1 NP, C & S Supply
1” NP capped inlet/outlet hose line tee. Includes cap and chain.(0.500 lbs)
858-30805. ....................................... $74.95
100 800.839.0821 fax 970.225.1051 Prices subject to change without notice.
